DVD/CD RECEIVER KD-DV7204/KD-DV7203
For canceling the display demonstration, see page 5.
For installation and connections, refer to the separate manual.
INSTRUCTIONS
GET0376-001A
[UI]
Thank you for purchasing a JVC product.
Please read all instructions carefully before operation, to ensure your complete understanding and to
obtain the best possible performance from the unit.
IMPORTANT FOR LASER PRODUCTS
1. CLASS 1 LASER PRODUCT
2. CAUTION: Do not open the top cover. There are no user serviceable parts inside the unit; leave
all servicing to qualified service personnel.
3. CAUTION: Visible and invisible laser radiation when open and interlock failed or defeated.
Avoid direct exposure to beam.
4. REPRODUCTION OF LABEL: CAUTION LABEL, PLACED OUTSIDE THE UNIT.
This product incorporates copyright
protection technology that is protected
by U.S. patents and other intellectual
property rights. Use of this copyright
protection technology must be authorized
by Macrovision, and is intended for home
and other limited viewing uses only unless
otherwise authorized by Macrovision.
Reverse engineering or disassembly is
prohibited.
How to use functions mode
If you press MODE, the unit goes into
functions mode, then the number buttons
and 5/∞ buttons work as different function
buttons.
[Within 5 seconds...]
How to reset your unit
• Your preset adjustments will also be erased.
How to forcibly eject a disc
“PLEASE” and “EJECT” appear alternately
on the display.
• If this does not work, reset your unit.
• Be careful not to drop the disc when it
ejects.
2
WARNINGS:
To prevent accidents and damage
• DO NOT install any unit in locations where;
– it may obstruct the steering wheel and
gearshift lever operations.
– it may obstruct the operation of safety devices
such as air bags.
– it may obstruct visibility.
• DO NOT operate the unit while driving.
• If you need to operate the unit while driving, be
sure to look ahead carefully.
• The driver must not watch the monitor while
driving.
If the parking brake is not engaged, “DRIVER
MUST NOT WATCH THE MONITOR WHILE DRIVING.”
appears on the monitor, and no playback picture
will be shown.
– This warning appears only when the parking
brake wire is connected to the parking brake
system built in the car (refer to the Installation/
Connection Manual).
CONTENTS
Introduction ............................................. 4
OPERATIONS
Basic operations
• Control panel .......................................... 6
• Remote controller (RM-RK230) ................ 7
Listening to the radio ................................ 10
Disc operations ......................................... 11
EXTERNAL DEVICES
Listening to the USB memory ..................... 19
Listening to the CD changer ....................... 20
Listening to the iPod®/D. player ................. 21
Listening to the other external
components .......................................... 22
Dual Zone operations ................................ 23
For safety...
• Do not raise the volume level too much, as
this will block outside sounds, making driving
dangerous.
• Stop the car before performing any
complicated operations.
Temperature inside the car...
If you have parked the car for a long time in hot
or cold weather, wait until the temperature in
the car becomes normal before operating the
unit.
SETTINGS
Selecting a preset sound mode ................... 24
General settings — PSM ........................... 25
Disc setup menu ........................................ 28
Assigning names to the sources .................. 30
Maintenance ............................................ 31
More about this unit ................................. 32
Troubleshooting ....................................... 37
Specifications ........................................... 40
3
Introduction
Disc type Recording format, file type, etc Playable
DVD DVD-Video
DVD-Audio
DVD-ROM
DVD Recordable/Rewritable
(DVD-R*1/-RW, +R/+RW*2)
DVD-RAM All
Dual Disc DVD side
CD/VCD Audio CD (CD-DA), DTS-CD
CD Recordable/Rewritable
(CD-R/-RW)
• Compliant to ISO 9660 level 1,
level 2, Romeo, Joliet
*1 DVD-R recorded in multi-border format is also playable (except for dual layer discs).
2
*
It is possible to play back finalized +R/+RW (Video mode only) discs. However, the use of +R double layer disc on this unit is not
recommended.
Caution for DualDisc playback
The Non-DVD side of a “DualDisc” does not
comply with the “Compact Disc Digital Audio”
standard. Therefore, the use of Non-DVD
side of a DualDisc on this product may not be
recommended.
Caution on volume setting
Discs produce very little noise compared with
other sources. Lower the volume before playing
a disc to avoid damaging the speakers by the
sudden increase of the output level.
DVD-Video
DivX Video
MPEG-1/MPEG-2 Video
MP3/WMA/WAV
JPEG
DVD-VR, +VR
Non-DVD side
VCD (Video CD)
CD-Text
CD-ROM
CD-I (CD-I Ready)
CD-DA, DTS-CD
DivX Video, VCD (Video CD)
MPEG-1/MPEG-2 Video
MP3/WMA/WAV
JPEG
Note on Region Code:
DVD players and DVD Video discs have
their own Region Code numbers. This unit
can only play back DVD discs whose Region
Code numbers include “5.”
If you insert a DVD Video disc of an
incorrect Region Code
“REGION CODE ERROR!” appears on the
monitor.
4
Before operating the unit — Cancel the display demonstration and set the clock
• See also page 26.
When the power is turned off: Check the current clock time
When the power is turned on: Change the display information
~ Turn on the power.
Ÿ Enter the PSM settings.
! ] ⁄ Cancel the display demonstrations
Select “DEMO,” then “DEMO OFF.”
Select “CLOCK H” (hour), then adjust the hour.
Select “CLOCK M” (minute), then adjust the minute.
Set the clock
@ Finish the procedure.
How to detach/attach the control panel
Detaching... Attaching...
Lever
CAUTION:
The lever comes out if you pressed the 0 button while the
panel is detached. If this happens, push the lever back into lock
position before attaching the panel.
5
Basic operations — Control panel
Select the source.
FM/AM = DISC* = USB* = CD-CH*/IPOD*/
D.PLAYER* (or EXT IN) = LINE IN =(back to the
beginning)
* You cannot select these sources if they are not ready.
• FM/AM: Select the bands.
• DISC: Start playback.
Change the display information
Detach the panel.
• FM/AM: Select preset station.
• DISC: Select chapter/title/folder/
track/disc (for CD changer).
• Turn on the power.
• Turn off the power [Hold].
• Attenuate the sound (if the power is on).
• Volume control [Turn]
USB input terminal
Select the sound mode.
Display window
Eject disc.
Adjust the sound mode.
Hold to enter the PSM settings.
Enter functions mode.
Press MODE, then one of the following buttons
(within 5 seconds)...
MO: Turn on/off monaural reception.
SSM: Automatic station presetting.
DUAL: Activate/deactivate Dual Zone.
RPT: Select repeat play.
RND: Select random play.
5/∞: Skip 10 chapters/tracks.
• FM/AM: Search for station.
• DISC: Select chapter/track.
• IPOD/D.PLAYER: Select track.
• FM/AM: Select preset station.
• DISC: Select title/folder.
• IPOD/D.PLAYER: Enter the main menu/
Pause or stop playback/Confirm selection.
6
Display window
Main display
(Time, menu, playback information)
Source display/Preset No./
Track No./Folder No./
Disc No./Chapter No.
Tuner reception indicators
Dual Zone indicator
Track information indicators
Disc type indicators
Playback source indicators
Equalizer indicator
Sound mode indicators
• also functions as level meter
(see also page 26).
Basic operations — Remote controller (RM-RK230)
Installing the lithium coin battery (CR2025)
Before using the remote controller:
• Aim the remote controller directly at the
remote sensor on the unit.
• DO NOT expose the remote sensor to bright
light (direct sunlight or artificial lighting).
Warning:
To prevent accidents and damage
• Do not install any battery other than
CR2025 or its equivalent.
• Store the battery in a place where children
cannot reach.
• Do not recharge, short, disassemble, heat
the battery, or dispose of it in a fire.
• Do not leave the battery with other
metallic materials.
• Do not poke the battery with tweezers or
similar tools.
• Wrap the battery with tape and insulate
when throwing away or saving it.
Loudness indicator
Track indicator
Playback mode/item indicators
(Random/Repeat)
Remote sensor
Continued on the next page
7
OPERATIONS
IMPORTANT:
If Dual Zone is activated (see page 23),
the remote controller only functions for
operating the DVD/CD player.
MONITOR CONTROL
1 Monitor control buttons
• Used for a JVC monitor—KV-MR9010
or KV-MH6510.
DVD/RECEIVER CONTROL
2 Turns on/off the power.
• Attenuates the sound if the power is on.
3 Selects the source.
4 Selects the FM/AM bands.
1
5*
• DVD-Video/DivX: Shows disc menu.
• VCD: Starts PBC playback.
6 Activates or deactivates Dual Zone.
7 Adjusts the volume level.
• Also function as 2nd VOL when pressed
with SHIFT button (see page 23)
.
8*1 Enters disc setup menu.
9 SHIFT button
p 7 (stop), 3 (play), 8 (pause)
• 3 (play) also function as ZOOM button
when pressed with SHIFT button (see
page 14).
•
Not applicable for CD changer/iPod/
D. player operations.
q*2 For advanced disc operations:
•
/TITLE 5 / ∞
DVD-Video: Selects the titles.
DivX/MPEG Video/MP3/WMA/WAV:
Selects the folders if included.
• 4 / ¢: Reverse skip/forward skip.
• 1 / ¡: Reverse search/forward
search.
For FM/AM tuner operations:
• PRESET 5 / ∞
Changes the preset stations.
• 4 / ¢
Searches for the stations.
For Apple iPod
/JVC D. player
®
operations:
• 5 / ∞
∞: Pauses/stops or resumes playback.
5: Enters the main menu.
(Now 5/∞/4 / ¢ work as the
menu selecting buttons.)*
3
• 4 / ¢ (in menu selecting mode)
– Selects an item if pressed briefly.
(Then, press ∞ to confirm the
selection.)
– Skips 10 items at a time if pressed and
held.
• 4 / ¢
Press: Reverse skip/forward skip.
Hold: Reverse search/forward search.
8
w • Shows the on-screen bar.
• Also function as the
/TITLE button
when pressed with SHIFT button (see
pages 13 and 14).
1
e*
• DVD-Video/DivX: Shows disc menu.
• VCD: Starts PBC playback.
1
r*
• Makes selection/settings.
• @ / #: DivX: Searches for index during
play.
• DISC +/– buttons: Changes discs when
the source is “CD-CH.”
1
t*
RETURN button
y • DVD-Video: Selects audio language
(
), subtitles ( ), angle ( ).
• DivX: Selects audio language (
subtitles (
).
• VCD: Selects audio channel (
1
*
Functions as number buttons when pressed
),
).
with SHIFT button.
–
FM/AM: Selects preset stations.
–
DISC: Selects chapter/title/folder/track.
2
*
Functions as +10/–10/+100/–100 buttons
when pressed with SHIFT button.
3
*
5 : Returns to the previous menu.
∞ : Confirms the selection.
How to select a number
To select a number from 0 – 9:
To select a number greater than 9:
To select a number greater than 99 (for
searching DivX/MPEG Video/MP3/WMA/
WAV tracks):
9
OPERATIONS
Listening to the radio
Change the display information
Select preset station.
* If no name is assigned to a station, “NO NAME”
appears. To assign a name to a station, see page 30.
~ Select “FM/AM.”
Ÿ Select the bands.
Lights up when receiving an FM stereo
broadcast with sufficient signal strength.
! Search for a station to listen—Auto Search.
• Manual Search: Hold either one of the buttons until “M” flashes on the display, then press it
repeatedly.
When an FM stereo broadcast is hard to
receive
1
3
Local FM stations with the strongest signals
are searched and stored automatically in the
FM band.
2
Reception improves, but stereo effect will be
lost.
• MO indicator lights up.
FM station automatic presetting —SSM
(Strong-station Sequential Memory)
You can preset six stations for each band.
1
2
Manual presetting
Ex.: Storing FM station of 92.5 MHz into preset
number 4 of the FM1 band.
1
2
3
10
Disc operations
Before performing any operations...
Turn on the monitor to watch the playback picture. If you turn on the monitor, you can also control
playback of other discs by referring to the monitor screen. (See pages 15 – 18.)
The disc type is automatically detected, and playback starts automatically (for DVD: automatic start
depends on its internal program).
If the current disc does not have any disc menu, all tracks will be played repeatedly until you change
the source or eject the disc.
If “
” appears on the monitor when pressing a button, the unit cannot accept the operation you
have tried to do.
• In some cases, without showing “
Start playback if necessary.
,” operations will not be accepted.
Open the control panel and insert the disc.
Playback starts automatically.
Change the display information
11
Prohibiting disc ejection
To cancel the prohibition, repeat the
same procedure.
*1 If the file does not have Tag information or
“TAG DISP” is set to “TAG OFF” (see page
27), folder name and file name appear. TAG
indicator will not light up.
2
*
“NO NAME” appears for an audio CD.
Continued on the next page
OPERATIONS
Operations using the control panel
Pressing (or holding) the following buttons allows you to...
Disc type
Press: Select chapter
Hold: Reverse/fast-forward
1
chapter*
Press: Select track
Hold: Reverse/fast-forward track*
Press: Select track
Hold: Reverse/fast-forward track*
Select title During stop: Locate title
—
1
Select folder Locate particular folder directly
2
(Number buttons)
During play/pause: Locate
chapter
Locate particular track directly
(PBC not in use)
Press: Select track
Hold: Reverse/fast-forward track
Press: Select track
Hold: Reverse/fast-forward track*
*1 Search speed changes to on the monitor.
2
*
Search speed changes on the monitor.
After pressing
, press the following buttons to...
Select folder Locate particular folder directly
1
*
—
1
Disc type
Skip 10 chapters (during play
or pause)
Skip 10 tracks (PBC not in use) TRK RPT: Repeat current track
Skip 10 tracks (within the
same folder)
Skip 10 tracks (within the
same folder)
Skip 10 tracks TRK RPT: Repeat current track DISC RND: Randomly play all
• To cancel repeat play or random play, select “RPT OFF” or “RND OFF.”
CHP RPT: Repeat current
chapter
TIT RPT: Repeat current title
(PBC not in use)
TRK RPT: Repeat current track
FLDR RPT: Repeat current folder —
TRK RPT: Repeat current track
FLDR RPT: Repeat current folder
12
Locate particular track directly
—
DISC RND: Randomly play all
tracks (PBC not in use)
FLDR RND: Randomly play all
tracks of current
folder, then tracks of
next folders
DISC RND: Randomly play all
tracks
tracks
Operations using the remote controller—RM-RK230
: Stop play
: Pause (Frame by frame playback if pressed during
pause.)
: Start play (10-second review if pressed during play.)
: Reverse/forward chapter search*1
• Slow motion during pause. No sound can be
: Press: Select chapter (during play or pause)
Hold: Reverse/fast-forward chapter search
: Select title
: Select audio language
: Select subtitle language
: Select view angle
While holding ...*
: Select chapter (during play or pause)
Select title (when stop)
, then : Select title directly
Using menu driven features...
1 /
2 Select an item you want to start play.
3
heard.*
2
3
: Stop play
: Pause (Frame by frame playback if
pressed during pause.)
: Start play
: Reverse/forward track search*1
• Slow motion during pause. No sound
can be heard.*
2
• Reverse slow motion does not work.
: Press: Select track
Hold: Reverse/fast-forward track search
: Select audio channel (ST: stereo, L: left,
R: Right)
While holding ...*
3
: Select track (For VCD with PBC, a list of items
is shown on the disc menu.)
• To return to the previous menus, press
.
Canceling the PBC playback...
1
2 While holding , press *
3
to start the
desired track.
• To resume PBC, press / .
Continued on the next page
13
OPERATIONS
: Stop play
: Pause (Frame by frame playback if
pressed during pause.)
: Start play
: Reverse/forward track search*
4
: Press: Select track
Hold: Reverse/fast-forward track search
: Select folder
: • Return/advance the scenes by about
5 minutes (Index search).
• Select chapter
: DivX: Select subtitles language
: DivX: Select audio language
While holding ...*
3
: Select track (within the same folder)
, then : Select folder directly*
Index search:
5
: Stop play
: Pause
: Start play
: Reverse/forward track search*
1
: Press: Select tracks
Hold: Reverse/fast-forward track
search
: Select folder
While holding ...*
3
: Select track (within the same folder)
, then : Select folder directly*
5
Enlarging the view—Zoom in (DVD/VCD/DivX/
MPEG Video)
During moving picture playback...
1 While holding
2 Move the enlarged portion.
• To cancel zoom, select “ZOOM OFF.”
, press repeatedly.
: Stop play
: Pause
: Start play
: Reverse/forward track search*
1
: Press: Select tracks
Hold: Reverse/fast-forward track
search
While holding ...*
3
: Select track directly
*1 Search speed changes to
2
*
Slow motion speed changes to
3
*
For selecting numbers greater than 9, see page 9.
4
*
Search speed changes on
5
*
To use direct folder access on DivX/MP3/WMA/WAV discs, it
on the monitor if pressed repeatedly.
on the monitor if
pressed repeatedly.
the monitor if pressed repeatedly.
is required that folders are assigned with 2-digit numbers at
the beginning of their folder names—01, 02, 03, and so on.
14
Operations using the on-screen bar (DVD/VCD/DivX/MPEG Video)
These operations are possible on the monitor using the remote controller.
~ Show the on-screen bar (see page 16).
(twice)
Ÿ Select an item.
! Make a selection.
If pop-up menu appears...
• To cancel pop-up menu, press
• For entering time/numbers, see the following.
⁄ Remove the on-screen bar.
Entering time/numbers
• To select numbers 0 – 9:
While holding
• To select numbers greater than 9:
While holding
To reduce numbers, use
To correct a misentry, use
• After entering the numbers, press
Ex.: Time search
DVD: _:_ _:_ _
To enter 1 (hours): 02 (minutes): 00 (seconds), press 1, 0, 2, 0, then 0.
VCD (PBC not in use): _ _:_ _
To enter 64 (minutes): 00 (seconds), press 6, 4, 0, then 0.
, press .
, press . Then, press .
.
.
.
.
15
OPERATIONS
On-screen bar
Ex.: DVD-Video
Information
Operation
Disc type
1
2 • DVD-Video/DTS-CD: Audio signal format type
and channel
• VCD: PBC
3 Playback mode
DVD-Video: T. RPT: Title repeat
C. RPT: Chapter repeat
VCD*1: T. RPT: Track repeat
D. RND: Disc random
T. INT: Track intro*
DivX/MPEG Video: T. RPT: Track repeat
F. RPT: Folder repeat
4 Playback information
Current title/chapter
Current track
Current folder/track
5 Time indication
Elapsed playing time of the disc (For
DVD-Video, elapsed playing time of
the current title.)
DVD-Video: Remaining title time
VCD: Remaining disc time
Elapsed playing time of the current
chapter/track
Remaining time of the current
chapter/track
3
6 Playback status
Play
Forward/reverse search
Forward/reverse slow-motion
Pause
Stop
7 Operation icons
Change time indication (see 5)
Time Search (Enter the elapsed playing
time of the current title or of the disc.)
Title Search (by its number)
Chapter Search (by its number)
Track Search (by its number)
Change the audio language or audio
channel
Change the subtitle language
Change the view angle
Repeat play*
Intro play*
Random play*
*1 While PBC is not in use.
2
*
For repeat play/random play, see also page 12.
3
*
Plays the beginning 15 seconds of...
TRACK INTRO: All tracks of the current disc.
FOLDER INTRO: First tracks of all folders of the current
disc.
2
3
2
16
Operations using the control screen (DivX/MPEG Video/MP3/WMA/WAV/CD)
These operations are possible on the monitor using the remote controller.
~ Show the control screen.
DivX/MPEG Video: Press during play.
MP3/WMA/WAV/CD: Automatically appear when you insert a disc.
Ÿ Select “Folder” column or “Track” column (except for CD).
! Select a folder or track.
⁄ Start playback.
DivX/MPEG Video: Press .
MP3/WMA/WAV/CD: Playback starts automatically.
Control screen
Ex.: MP3/WMA/WAV disc
1 Current folder number/total folder number
2 Folder list with the current folder selected
3 Selected playback mode
4 Elapsed playing time of the current track
5 Operation mode icon ( ‰, 7, 8, ¡, 1 )
6 Current track number/total number of
tracks in the current folder (total number of
tracks on the disc)
7 Track information
8 Track list with the current track selected
To select a playback mode
1 While control screen is displayed...
Playback mode selection screen appears on
the folder list section of the control screen.
2 Select a playback mode.
3 Select an item.
REPEAT/INTRO:
RANDOM:
1
*
Not selectable for DivX/MPEG Video
2
*
Not selectable for CD
Playback mode
F. RPT (folder repeat): Repeat current folder
T. RPT (track repeat): Repeat current track
F. INT (folder intro): Plays the beginning
15 seconds of first tracks of all
folders of the current disc
T. INT (track intro): Plays the beginning
15 seconds of all tracks of the
current disc
D. RND (disc random): Randomly play all tracks
F. RND (folder random): Randomly play all tracks of
current folder, then tracks of
next folders
17
OPERATIONS
Operations using the list screen (DivX/MPEG Video/MP3/WMA/WAV)
These operations are possible on the monitor using the remote controller.
Before playing, you can display the folder list/track list to confirm the
contents and start playing a track.
~ Display the folder list while stop.
Ÿ Select an item from the folder list.
• Track list of the selected folder appears.
• To go back to the folder list, press
.
! Select a track to start playing.
• MP3/WMA/WAV: Control screen appears (see page 17).
List screen
Ex.: Folder list
1 Current folder number/total folder number
2 Current track number/total number of
tracks in the current folder
3 Current page/total number of the pages
included in the list
4 Current folder/track (highlighted bar)
18
OPERATIONS
Listening to the USB memory
While the power is on...
USB input terminal
USB memory
This unit can play MP3/WMA tracks stored in a
USB memory.
All tracks in the USB memory will be played
repeatedly until you change the source.
• Removing the USB memory will also stop
playback.
To detach the USB memory, straightly pull it
out from the unit.
Cautions:
• Avoid using the USB memory if it might
hinder your safety driving.
• Make sure all important data has been
backed up to avoid losing the data.
Press: Select track
Hold: Reverse/fast-forward
track
Select folders
Select particular folder directly
After pressing , press the following
buttons to...
Skip 10 tracks (within the same folder)
TRK RPT: Repeat current track
FLDR RPT: Repeat all tracks of current
folder
FLDR RND: Randomly play all tracks
of the current folder, then
tracks of the next folder
DISC RND: Randomly play all tracks of
the USB memory
• To cancel repeat play or random play, select
“RPT OFF” or “RND OFF.”
Change the display information
(Number buttons)
* If the file does not have Tag information or “TAG DISP” is set to
“TAG OFF” (see page 27), folder name and file name appear.
TAG indicator will not light up.
19
EXTERNAL DEVICES
Listening to the CD changer
Change the display information
(see page 11)
It is recommended to use a JVC
MP3-compatible CD changer with your unit.
• You can only play conventional CDs
(including CD Text) and MP3 discs.
~ Select “CD-CH.”
Ÿ Select a disc to start playing.
Press: For selecting disc number 1 – 6.
Hold: For selecting disc number 7 – 12.
Press: Select track
Hold: Reverse/fast-forward track
MP3: Select folders
After pressing , press the following
buttons to...
Skip 10 tracks (MP3: within the same
folder)
TRK RPT: Repeat current track
FLDR RPT: MP3: Repeat all tracks of
current folder
DISC RPT: Repeat all tracks of the
current disc
FLDR RND: MP3: Randomly play all
tracks of the current folder,
then tracks of the next folder
DISC RND: Randomly play all tracks of
current disc
MAG RND: Randomly play all tracks of
the inserted discs
• To cancel repeat play or random play, select
“RPT OFF” or “RND OFF.”
20
Listening to the iPod®/D. player
Change the display information
Before operating, connect the interface adapter
(KS-PD100 or KS-PD500) to the CD changer
jack of this unit.
Preparations:
Make sure “CHANGER” is selected for the
external input setting, see page 26.
~ Select “IPOD” or “D. PLAYER.”
Ÿ Select a song to start playing.
Selecting a track from the menu
1 Enter the main menu.
• This mode will be canceled if no
operations are done for about
5 seconds.
2 Select the desired menu.
For iPod:
PLAYLIST Ô ARTISTS Ô ALBUMS Ô SONGS
Ô GENRES Ô COMPOSER Ô (back to the
beginning)
For D. player:
PLAYLIST Ô ARTIST Ô ALBUM Ô
GENRE Ô TRACK Ô (back to the beginning)
3 Confirm the selection.
• To move back to the previous
menu, press 5.
• If a track is selected, playback starts
automatically.
• Holding
items at a time.
After pressing , press the following
buttons to...
• To cancel repeat play or random play, select
“RPT OFF” or “RND OFF.”
* iPod: Only if you select “ALL” in “ALBUMS” of the main
“MENU.”
4/¢ can skip 10
Pause/stop playback
• To resume playback, press it
again.
Press: Select tracks
Hold: Reverse/fast-forward track
ONE RPT:
Functions the same as “Repeat One” or
“Repeat Mode = One.”
ALL RPT:
Functions the same as “Repeat All” or
“Repeat Mode = All.”
ALBM RND* :
Functions the same as “Shuffle Albums”
of the iPod.
SONG RND/RND ON:
Functions the same as “Shuffle Songs” or
“Random Play = On.”
21
EXTERNAL DEVICES
Listening to the other external components
Change the display information
You can connect an external component to:
• LINE IN plugs on the rear.
• CD changer jack on the rear using the Line Input Adapter—KS-U57 (not supplied) or AUX Input
Adapter—KS-U58 (not supplied). Make sure “EXT IN” is selected for the external input setting,
see page 26.
~ Select “EXT IN” or “LINE IN.”
Ÿ Turn on the connected component and start playing the source.
! Adjust the volume.
⁄ Adjust the sound as you want (see pages 24 and 25).
Concept diagram of the external device connection
• For connection, see Installation/Connection manual (separate volume).
Unit
CD changer jack
: Adapter (separately purchased)
LINE IN plugs on the rear
(see page 26 of the
”EXT IN” setting)
(see page 26 of the
”EXT IN” setting)
22
MD player, etc.
MD player, etc.
MD player, etc.
JVC CD changer, [20]
Apple iPod, [21]
JVC D. player, [21]
Dual Zone operations
You can connect an external audio equipment to the 2nd AUDIO OUT plug on the rear, and play
back a disc separately from the source selected on the unit.
You can activate Dual Zone while listening to any source.
• When Dual Zone is in use, you can only operate the DVD/CD player using the remote controller.
On the remote controller:
These operations are possible on the monitor using the remote
controller.
~ Activate Dual Zone.
The source automatically changes to “DISC.”
To select a different source to listen through the speakers, press SRC
on the control panel.
• By using the buttons on the control panel, you can operate the
newly selected source without affecting Dual Zone operations.
Ÿ Adjust the volume through the 2nd AUDIO OUT plug.
! Operate the DVD/CD player using the remote controller by
referring to the monitor screen.
• To cancel Dual Zone operations, select “DUAL OFF” in step ~.
On the control panel:
You can also activate and deactivate Dual Zone.
1
2
The source automatically changes to “DISC” when Dual Zone is activated.
23
EXTERNAL DEVICES
Selecting a preset sound mode
Preset frequency level settings:
Sound
Preset equalizing values
mode
60 Hz
150 Hz
400 Hz
1 kHz
2.4 kHz
6 kHz
USER 00 00 00 00 00 00 00
ROCK +03 +02 00 00 +01 +02 +01
CLASSIC +01 +03 +01 00 00 +02 00
POPS 00 +02 00 00 00 +01 +02
HIP HOP +04 +01 –01 –02 00 +01 00
JAZZ +03 +02 +01 +01 +01 +03 +01
Storing your own sound adjustments
1
Enter the sound adjustment mode.
2
3 Select a frequency to adjust.
5 Repeat steps 3 and 4 to adjust the
other frequency bands.
6 Store the adjustments in the
15 kHz
respective mode.
4 Adjust the level.
24
Adjusting the sound
1
Adjust the level.
2
General settings — PSM
You can change PSM (Preferred Setting Mode)
items listed in the table that follows.
1 Enter the PSM settings.
FAD*1 (fader)
Adjust the front and rear speaker
balance.
BAL (balance)
Adjust the left and right speaker
balance.
LOUD (loudness)
Boost low and high frequencies to
produce a well-balanced sound at low
volume level.
SUB.W*2 (subwoofer)
Adjust subwoofer output level.
VOL.A*3 (volume adjust)
Adjust and store auto-adjustment
volume level for each source,
comparing to the FM volume level.
VOL (volume)
Adjust the volume.
*1 If you are using a two-speaker system, set the
fader level to “00.”
2
*
This takes effect only when a subwoofer is
connected.
3
*
You cannot make an adjustment for FM.
“FIX” appears.
4
*
Depending on the amplifier gain control
setting. (See page 27 for details.)
R06 to F06
L06 to R06
LOUD ON or
LOUD OFF
00 to 08
–05 to +05
00 to 30
4
*
(or 50)
2 Select a PSM item.
3 Select or adjust the selected PSM item.
4 Repeat steps 2 and 3 to adjust other
PSM items if necessary.
5 Finish the procedure.
25
Continued on the next page
SETTINGS
Indication Item Setting, [reference page]
DEMO
• DEMO ON [Initial]
Display demonstration
• DEMO OFF
CLOCK H
Hour adjustment
CLOCK M
Minute adjustment
LEVEL
Level meter
1 – 12
[Initial: 1 (1:00)]
00 – 59
[Initial: 00 (1:00)]
• ON [Initial]
• OFF
DIMMER • AUTO [Initial]
• ON
• OFF
TEL
Telephone muting
• MUTING 1/
MUTING 2
• OFF [Initial]
1
SCROLL*
• ONCE [Initial]
• AUTO
• OFF
WOOFER
Subwoofer cutoff
frequency
• LOW
• MID [Initial]
• HIGH
: Display demonstration will be activated automatically if no
operation is done for about 20 seconds, [5].
: Cancels.
: See also page 5 for setting.
: See also page 5 for setting.
: Activates the audio level indicator.
: Cancels; sound mode indicator is shown.
: Dims the display when you turn on the headlights.
: Dims the display illumination.
: Cancels.
: Select either one which mutes the playback sounds while using
a cellular phone.
: Cancels.
: Scrolls the track information once.
: Repeats scrolling (5-second intervals).
: Cancels. (Holding DISP can scroll the display regardless of the
setting.)
: Frequencies lower than 85 Hz are sent to the subwoofer.
: Frequencies lower than 125 Hz are sent to the subwoofer.
: Frequencies lower than 165 Hz are sent to the subwoofer.
HPF
High pass filter
2
EXT IN*
External input
• HPF ON
• HPF OFF [Initial]
• CHANGER [Initial]
• EXT IN
: The cut-off frequency is chosen automatically according to the
WOOFER setting (LOW/MID/HIGH) so that you can enjoy the
bass sound purely from the subwoofer if it is connected.
: Cancels.
: To use a JVC CD changer, [20], or an Apple iPod/a JVC D. player,
[21].
: To use any other external component than the above, [22].
26
Indication Item Setting, [reference page]
TAG DISP
Tag display
NTSC/PAL*
3
Video format
REAR SPK*
4
Rear speaker output
AMP GAIN
Amplifier gain control
• TAG ON [Initial]
• TAG OFF
• PAL [Initial]
• NTSC
• ON [Initial]
• OFF
• LOW PWR
• HIGH PWR
: Shows the tag while playing MP3/WMA/WAV tracks.
: Cancels.
: Select this if your monitor is of the PAL color system.
: Select this if your monitor is of the NTSC color system.
: Select this to turn on the rear speaker output.
: Cancels.
: VOL 00 – VOL 30 (Select if the maximum power of each speaker
is less than 50 W to prevent the speaker from being damaged.)
: VOL 00 – VOL 50
[Initial]
IF BAND
Intermediate frequency
filter
• AUTO [Initial]
• WIDE
: Increases the tuner selectivity to reduce interference noises
between adjacent stations. (Stereo effect may be lost.)
: Subject to interference noises from adjacent stations, but sound
quality will not be degraded and the stereo effect will remain.
*1 Some characters or symbols will not be shown correctly (or will be blanked) on the display.
*2 Displayed only when one of the following sources is selected—FM, AM, DISC, USB, or LINE IN.
3
*
The newly selected video format takes effect only after you turn on the power again, reload the disc,
or change the source.
4
*
Displayed only when Dual Zone is activated (see page 23).
27
SETTINGS
Disc setup menu
These operations are possible on the monitor using the remote controller.
~ Enter the disc setup menu while
stop.
Ÿ Select a menu.
! Select an item you want to set
up.
• To cancel pop-up menu, press
.
⁄ Select an option.
To return to normal screen
Menu Item Setting
MENU
LANGUAGE
AUDIO
LANGUAGE
SUBTITLE Select the initial subtitle language or remove the subtitle (OFF). Refer also to
LANGUAGE
ON SCREEN
LANGUAGE
Select the initial disc menu language. Refer also to “Language codes” on page 36.
Select the initial audio language. Refer also to “Language codes” on page 36.
“Language codes” on page 36.
Select the language for the on screen display.
28
Menu Item Setting
MONITOR TYPE Select the monitor type to watch a wide screen picture on your monitor.
OSD POSITION Select the on-screen bar position on the monitor.
FILE TYPE Select the file type to play.
DIGITAL AUDIO
OUTPUT
DOWN MIX When playing back a multi-channel disc, this setting affects the signals reproduced
AUDIO
D. RANGE
COMPRESSION
DivX
REGISTRATION
OTHERS
• 1 : Higher position
• 2 : Lower position (Guidance below the disc setup
menu will disappear.)
• AUDIO : Play MP3/WMA/WAV files.
• VIDEO : Play DivX/MPEG Video files.
Select the signal format to be emitted through the DIGITAL OUT (Optical) terminal.
• OFF : Cancels.
• PCM ONLY : Select for an amplifier or a decoder incompatible
with Dolby Digital, DTS, MPEG Audio, or connecting
to a recording device.
• DOLBY DIGITAL/PCM : Select for an amplifier or a decoder compatible with
Dolby Digital.
• STREAM/PCM : Select for an amplifier or a decoder compatible with
Dolby Digital, DTS, and MPEG Audio.
through the LINE OUT jacks (and through the DIGITAL OUT terminal when “PCM
ONLY” is selected for “DIGITAL AUDIO OUTPUT”).
• SURROUND COMPATIBLE : Select to enjoy multi-channel surround audio by
connecting an amplifier compatible with Dolby
Surround.
• STEREO : Normally select this.
You can enjoy a powerful sound at low or middle volume levels while playing a
Dolby Digital software.
• AUTO : Select to apply the effect to multi-channel encoded
software (excluding 1-channel and 2-channel
software).
• ON : Select to always use this function.
This unit has its own Registration Code. Once you have played back a disc in which
the Registration Code recorded, this unit’s Registration Code is overwritten for
copyright protection.
29
SETTINGS
Assigning names to the sources
You can assign names to station frequencies and
CDs (both in this unit and in the CD changer).
Sources
Station
frequencies
CDs/CD-CH*
* You cannot assign names to any discs other
than conventional CDs.
Maximum number of
characters
Up to 8 characters (up to 30
station frequencies including
both FM and AM)
Up to 32 characters (up to 30
discs)
~ Select the sources.
• For FM/AM tuner: Select a station.
• For CDs in this unit: Insert a CD.
• For CDs in the CD changer: Select
“CD-CH,” then select a disc number.
Ÿ Show the title entry screen.
! Assign a title.
1 Select a character.
2 Move to the next (or previous) character
position.
3 Repeat steps 1 and 2 until you finish
entering the title.
⁄ Finish the procedure.
To erase the entire title
In step Ÿ on the left...
Available characters
30
SETTINGS
Maintenance
How to clean the connectors
Frequent detachment will deteriorate the
connectors.
To minimize this possibility, periodically wipe
the connectors with a cotton swab or cloth
moistened with alcohol, being careful not to
damage the connectors.
Connector
Moisture condensation
Moisture may condense on the lens inside the
DVD/CD player in the following cases:
• After starting the heater in the car.
• If it becomes very humid inside the car.
Should this occur, the DVD/CD player may
malfunction. In this case, eject the disc and
leave the unit turned on for a few hours until
the moisture evaporates.
How to handle discs
When removing a disc from
its case, press down the center
holder of the case and lift the
disc out, holding it by the edges.
• Always hold the disc by the
edges. Do not touch its recording surface.
When storing a disc into its case, gently insert
the disc around the center holder (with the
printed surface facing up).
• Make sure to store discs into the cases after
use.
Center holder
To keep discs clean
A dirty disc may not play correctly.
If a disc does become dirty, wipe it
with a soft cloth in a straight line
from center to edge.
• Do not use any solvent (for example,
conventional record cleaner, spray, thinner,
benzine, etc.) to clean discs.
To play new discs
New discs may have some rough
spots around the inner and outer
edges. If such a disc is used, this
unit may reject the disc.
To remove these rough spots, rub the edges
with a pencil or ball-point pen, etc.
Do not use the following discs:
Warped disc
Sticker
Sticker residue
Stick-on label
31
More about this unit
General
Turning on the power
• By pressing SRC on the unit, you can also
turn on the power. If the source is ready,
playback starts.
Turning off the power
• If you turn off the power while listening to a
disc, disc play will start automatically, next
time you turn on the power.
FM/AM
Storing stations in memory
• During SSM search...
– Received stations are preset in No. 1 (lowest
frequency) to No. 6 (highest frequency).
– When SSM is over, the station stored in
No. 1 will be automatically tuned in.
• When storing stations, the previously preset
stations are erased and stations are stored
newly.
Disc
General
• In this manual, words “track” and “file” are
interchangeably used when referring to DivX/
MPEG Video/MP3/WMA/WAV files and
their file names.
• This unit can also playback 8 cm discs.
• This unit can only playback audio CD
(CD-DA) files if different type of files are
recorded in the same disc.
Inserting a disc
• When a disc is inserted upside down,
“PLEASE” and “EJECT” appear alternately on
the display. Press 0 to eject the disc.
Ejecting a disc
• If the ejected disc is not removed within
15 seconds, the disc is automatically inserted
again into the loading slot to protect it from
dust. (Disc will not play this time.)
Playing Recordable/Rewritable discs
• This unit can recognize a total of 3 500 files
and 250 folders (a maximum of 999 files per
folder).
• This unit can recognize a total 25 characters
for file/folder names.
• Use only “finalized” discs.
• This unit can play back multi-session discs;
however, unclosed sessions will be skipped
while playing.
• This unit may be unable to play back some
discs or files due to their characteristics or
recording conditions.
• Rewritable discs may require a longer readout
time.
Playing MP3/WMA/WAV files
• The maximum number of characters for
folder and file names is 25 characters; 128
characters for MP3/WMA tag information.
• This unit can play back files with the
extension code <.mp3>, <.wma>, or <.wav>
(regardless of the letter case—upper/lower).
• This unit can show the names of albums,
artists (performer), and Tag (Version 1.0,
1.1, 2.2, 2.3, or 2.4) for the MP3/WMA/WAV
files.
• This unit can display only one-byte
characters. No other characters can be
correctly displayed.
• This unit can play back files recorded in VBR
(variable bit rate).
Files recorded in VBR have a discrepancy in
elapsed time indication.
• This unit cannot play back the following files:
– MP3 files encoded with MP3i and MP3 PRO
format.
– MP3 files encoded with Layer 1/2.
– WMA files encoded with lossless,
professional, and voice format.
– WMA files which are not based upon
Windows Media
Audio.
®
32
– WMA files copy-protected with DRM.
– Files which have the data such as ATRAC3,
etc.
– AAC files and OGG files.
Playing DivX files
• This unit can play back DivX files with
the extension code <.divx>, <.div>, <.avi>
(regardless of the letter case—upper/lower).
• This unit supports DivX 6.x, 5.x, 4.x, and 3.11.
• This unit supports DivX Media Format files,
<.divx> or <.avi>.
• This unit can display a unique registration
code—DivX Video on Demand (DRM—
Digital Rights Management). For activation
and more details, visit <www.divx.com/vod>.
• Audio stream should conform to MP3 or
Dolby Digital.
• This unit does not support GMC (Global
Motion Compression).
• The file encoded in the interlaced scanning
mode may not be played back correctly.
• This unit cannot playback the following files:
– Files encoded in Codec (Compressor-
decompressor) other than DivX Codec.
Playing MPEG Video files
• This unit can play back MPEG Video files
with the extension code <.mpg> or <.mpeg>.
• Audio stream should conform to MPEG1
Audio Layer 2.
• This unit cannot playback the following files:
– WMV (Windows Media Video) files
– RM (Real Media) format files
Playing a USB memory
• While playing from a USB memory, the
playback order may differ from other players.
• This unit may be unable to play back some
USB memories or some files due to their
characteristics or recording conditions.
• It is not recommended to use a USB memory
wider than 20 mm as it will block you from
pressing the 0 button.
• This unit can play back MP3 files recorded in
VBR (variable bit rate).
Changing the source
• If you change the source, playback also stops
(without ejecting the disc).
Next time you select “DISC” for the playback
source, disc play starts from where it has been
stopped previously.
iPod® or D. player
• When you turn on this unit, the iPod or
D. player is charged through this unit.
• While the iPod or D. player is connected, all
operations from the iPod or D. player are
disabled. Perform all operations from this
unit.
• The text information may not be displayed
correctly.
• If the text information includes more than
8 characters, it scrolls on the display (see
also page 26). This unit can display up to 40
characters.
Notice:
When operating an iPod or a D. player,
some operations may not be performed
correctly or as intended. In this case, visit the
following JVC web site:
For iPod users: <http://www.jvc.co.jp/
english/car/support/ks-pd100/index.html>
For D. player users: <http://www.jvc.co.jp/
english/car/support/ks-pd500/index.html>
33
Continued on the next page
Title assignment
• If you try to assign titles to more than 30
station frequencies or 30 CDs, “NAMEFULL”
appears. Delete unwanted titles before
assignment.
• Titles assigned to CDs in the CD changer can
also be shown if you play back the disc from
the unit and vice versa.
General settings—PSM
• If you change the “AMP GAIN” setting from
“HIGH PWR” to “LOW PWR” while the
volume level is set higher than “VOL 30,” the
unit automatically changes the volume level to
“VOL 30.”
Disc setup menu
• When the language you have selected is not
recorded on a disc, the original language is
automatically used as the initial language. In
addition, for some discs, the initial languages
settings will not work as you set due to their
internal disc programming.
• When you select “16:9” for a picture whose
aspect ratio is 4:3, the picture slightly changes
due to the process for converting the picture
width.
• Even if “4:3 PAN SCAN” is selected, the
screen size may become “4:3 LETTER BOX”
for some discs.
On-screen guide icons
During playback, the following guide icons
may appear for a while on the monitor.
DVD: Appears at the beginning of a scene
containing:
: Multi-subtitle languages
: Multi-audio languages
: Multi-angle views
: Playback
: Pause
: DVD-Video/VCD: Forward slow
motion
: DVD-Video: Reverse slow motion
: Forward search
: Reverse search
About sounds reproduced through the rear
terminals
• Through the analog terminals (Speaker
out/LINE OUT/2nd AUDIO OUT):
2-channel signal is emitted. When
playing a multi-channel encoded disc,
multi-channel signals are downmixed.
(AUDIO—DOWN MIX: see page 29.)
• Through DIGITAL OUT (optical):
Digital signals (Linear PCM, Dolby Digital,
DTS, MPEG Audio) are emitted through
this terminal. (For more details, see page
35.)
To reproduce multi-channel sounds
such as Dolby Digital and DTS, connect
an amplifier or a decoder compatible
with these multi-channel sources to this
terminal, and set “DIGITAL AUDIO
OUTPUT” correctly. (See page 29.)
• About Dual Zone:
Through the 2nd AUDIO OUT, 2-channel
signal is emitted. When playing a multichannel encoded disc, multi-channel
signals are downmixed. (See page 23.)
34
Output signals through the DIGITAL OUT terminal
Output signals are different depending on the “DIGITAL AUDIO OUTPUT” setting on the
setup menu (see page 29).
Playback Disc
DVD-Video 48 kHz, 16/20/24 bits Linear PCM
96 kHz, Linear PCM
Dolby Digital
DTS DTS bitstream 48 kHz, 16 bits stereo Linear PCM
MPEG Audio MPEG bitstream 48 kHz, 16 bits stereo Linear PCM
Audio CD, Video CD 44.1 kHz, 16 bits stereo Linear PCM /48 kHz, 16 bits stereo Linear PCM
Audio CD with DTS DTS bitstream 48 kHz, 16 bits stereo Linear PCM
DivX MP3 32/44.1/48 kHz, 16 bits Linear PCM
Dolby Digital Dolby Digital bitstream 48 kHz, 16 bits stereo
MP3/WMA/MPEG Video 32/44.1/48 kHz, 16 bits Linear PCM
WAV 44.1 kHz, 16 bits stereo Linear PCM
• Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.
• “DTS” and “DTS 2.0 + Digital Out” are trademarks of Digital Theater Systems, Inc.
• “DVD Logo” is a trademark of DVD Format/Logo Licensing Corporation registered in the US, Japan and other countries.
• DivX, DivX Ultra Certified, and associated logos are trademarks of DivX, inc. and are used under license.
• Official DivX
• Plays all versions of DivX
• Microsoft and Windows Media are either registered trademarks or trademarks of Microsoft Corporation in the United States and/
or other countries.
• iPod is a trademark of Apple Computer, Inc., registered in the U.S. and other countries.
Ultra Certified product
®
video (including DivX® 6) with enhanced playback of DivX® media files and the DivX® Media Format
®
STREAM/PCM DOLBY DIGITAL/PCM PCM ONLY
Dolby Digital bitstream
Output Signal
48 kHz, 16 bits stereo Linear PCM
48 kHz, 16 bits stereo
Linear PCM
Linear PCM
35
Continued on the next page
Language codes
Code Language Code Language Code Language Code Language Code Language
AA Afar FA Persian KL Greenlandic OC Occitan ST Sesotho
AB Abkhazian FI Finnish KM Cambodian OM (Afan) Oromo SU Sundanese
AF Afrikaans FJ Fiji KN Kannada OR Oriya SW Swahili
AM Ameharic FO Faroese KO Korean (KOR) PA Panjabi TA Tamil
AR Arabic FY Frisian KS Kashmiri PL Polish TE Telugu
AS Assamese GA Irish KU Kurdish PS Pashto, Pushto TG Tajik
AY Aymara GD Scots Gaelic KY Kirghiz PT Portuguese TH Thai
AZ Azerbaijani GL Galician LA Latin QU Quechua TI Tigrinya
BA Bashkir GN Guarani LN Lingala RM
BE Byelorussian GU Gujarati LO Laothian RN Kirundi TL Tagalog
BG Bulgarian HA Hausa LT Lithuanian RO Rumanian TN Setswana
BH Bihari HI Hindi LV Latvian, Lettish RW Kinyarwanda TO Tonga
BI Bislama HR Croatian MG Malagasy SA Sanskrit TR Turkish
BN Bengali, Bangla HU Hungarian MI Maori SD Sindhi TS Tsonga
BO Tibetan HY Armenian MK Macedonian SG Sangho TT Tatar
BR Breton IA Interlingua ML Malayalam SH Serbo-Croatian TW Twi
CA Catalan IE Interlingue MN Mongolian SI Singhalese UK Ukrainian
CO Corsican IK Inupiak MO Moldavian SK Slovak UR Urdu
CS Czech IN Indonesian MR Marathi SL Slovenian UZ Uzbek
CY Welsh IS Icelandic MS Malay (MAY) SM Samoan VI Vietnamese
DZ Bhutani IW Hebrew MT Maltese SN Shona VO Volapuk
EL Greek JI Yiddish MY Burmese SO Somali WO Wolof
EO Esperanto JW Javanese NA Nauru SQ Albanian XH Xhosa
ET Estonian KA Georgian NE Nepali SR Serbian YO Yoruba
EU Basque KK Kazakh NO Norwegian SS Siswati ZU Zulu
Rhaeto-Romance
TK Turkmen
36
Troubleshooting
What appears to be trouble is not always serious. Check the following points before calling a service
center.
Symptom Remedy/Cause
• Sound cannot be heard from the speakers. • Adjust the volume to the optimum level.
• Check the cords and connections.
• The unit does not work at all. Reset the unit (see page 2).
• Remote controller does not work. Deactivate Dual Zone (see page 23).
General
(While Dual Zone is activated, the remote controller only
functions for operating the DVD/CD player.)
• SSM automatic presetting does not work. Store stations manually.
• Static noise while listening to the radio. Connect the antenna firmly.
FM/AM
• Disc cannot be played back. Insert the disc correctly.
• Disc can be neither played back nor ejected. • Unlock the disc (see page 11).
• Eject the disc forcibly (see page 2).
• Recordable/Rewritable discs cannot be played
back.
• Tracks on the Recordable/Rewritable discs
cannot be skipped.
• Disc cannot be recognized. Eject the disc forcibly (see page 2).
• Sound and pictures are sometimes interrupted
or distorted.
Disc playback
• No playback picture (DVD-Video/VCD/DivX/
MPEG) appears on the monitor.
• No picture appears on the monitor at all. • Connect the video cord correctly.
• The monitor shows black and white wavy
pictures (DVD-Video/VCD/DivX/MPEG).
• The left and right edges of the picture are
missing on the monitor.
• Insert a finalized disc.
• Finalize the discs with the component which you used for
recording.
• Stop playback while driving on rough roads.
• Change the disc.
• Check the cords and connections.
Parking brake wire is not connected properly. (See
Installation/Connection Manual.)
• Select a correct input on the monitor.
Use a disc recorded in PAL/NTSC format.
Select “4:3 LETTER BOX” (see page 29).
37
Continued on the next page
Symptom Remedy/Cause
• Disc cannot be played back. • Change the disc.
• Record the tracks using a compliant application in the
appropriate discs (see page 4).
• Add the extension code <.divx>, <.div>, <.avi>,
<.mpg>, <.mpeg>, <.mp3>, <.wma>, or <.wav> to
the file names.
• Noise is generated. Skip to another track or change the disc.
• Longer readout time is required. Readout time varies due to the complexity of the folder/file
configuration. Do not use too many hierarchies and folders.
• Tracks cannot playback as you have intended
them to play.
• No sound can be heard when picture is
displayed while playing a DivX/MPEG Video
file.
• Elapsed playing time is not correct. This sometimes occurs during playback. This is caused by
DivX/MPEG Video/MP3/WMA/WAV playback
• “PLEASE” and “EJECT” appear alternately on
the display.
• Correct characters are not displayed (e.g.
album name).
• “CHECK” keeps flashing on the display. • Readout time varies depending on the USB memory.
• “NO FILE” flashes on the display. Attach a USB memory that contains tracks encoded in an
• “NOT SUPP” appears on the display and track
skips.
• “READ” and “FAILED” appear alternately
on the display, then returns to the previous
source.
USB memory playback
• Correct characters are not displayed (e.g.
album name).
• While playing a track, sound is sometimes
interrupted.
Playback order is determined when files are recorded.
• Record the audio track using MP3 or Dolby Digital as the
audio stream of DivX files.
• Record the audio track using MPEG1 Audio Layer 2 as the
audio stream for MPEG Video files.
how the tracks are recorded.
Insert a disc that contains tracks of appropriate formats.
This unit can only display letters (upper case), numbers, and
a limited number of symbols.
• Do not use too many hierarchy and folders.
• Turn off the power then on again.
appropriate format.
The track is unplayable.
• The attached USB memory may be malfunctioning, or
may not have been formatted correctly. The files included
in the USB memory are corrupted.
• Do not pull out or attach the USB memory while “CHECK”
is shown.
This unit can only display letters (upper case), numbers, and
a limited number of symbols.
MP3/WMA tracks have not been properly copied into the
USB memory. Copy MP3/WMA tracks again into the USB
memory, and try again.
38
Symptom Remedy/Cause
• “NO DISC” appears on the display. Insert a disc into the magazine.
• “NO MAG” appears on the display. Insert the magazine.
• “RESET 8” appears on the display. Connect this unit and the CD changer correctly and press
the reset button of the CD changer.
CD changer
• “RESET 1” – “RESET 7” appears on the display. Press the reset button of the CD changer.
• The CD changer does not work at all. Reset the unit (see page 2).
• The iPod or D. player does not turn on or does
not work.
• Buttons do not work as intended. The functions of the buttons have been changed. Press
• The sound is distorted. Deactivate the equalizer either on this unit or the iPod/
• “NO IPOD” or “NO DP” appears on the display.
• Playback stops. The headphones are disconnected during playback. Restart
• No sound can be heard when connecting an
iPod nano.
• No sound can be heard.
• “ERROR 01” appears on the display when
iPod/D. player playback
connecting a D. player.
• “NO FILES” or “NO TRACK” appears on the
display.
• “RESET 1” – “RESET 7” appears on the display. Disconnect the adapter from both this unit and iPod/
• “RESET 8” appears on the display. Check the connection between the adapter and this unit.
• The iPod’s or D. player’s controls do not work
after disconnecting from this unit.
• Check the connecting cable and its connection.
•
Change the battery.
• Update the firmware version.
MODE before performing the operation.
D. player.
Check the connecting cable and its connection.
the playback operation (see page 21).
Disconnect the headphones from the iPod nano.
Disconnect the adapter from the D. player. Then, connect
it again.
No tracks are stored. Import tracks to the iPod or D. player.
D. player. Then, connect it again.
Reset the iPod or D. player.
39
Specifications
Maximum Power
Output:
Continuous Power
Output (RMS):
Load Impedance: 4 Ω (4 Ω to 8 Ω allowance)
Equalizer Control
Range:
Signal to Noise Ratio: 70 dB
Audio Output Level: Digital (DIGITAL OUT: Optical): Signal wave length: 660 nm
AUDIO AMPLIFIER SECTION
Subwoofer-out Level/Impedance: 2.0 V/20 kΩ load (full scale)
Color system: PAL/NTSC
Video Output (composite): 1 Vp-p/75 Ω
Other Terminals: LINE IN, CD changer, 2nd AUDIO OUT
Frequency Range: FM: 87.5 MHz to 108.0 MHz
FM Tuner Usable Sensitivity: 11.3 dBf (1.0 μV/75 Ω)
TUNER SECTION
AM Tuner Sensitivity/Selectivity: 20 μV/35 dB
Front/Rear: 50 W per channel
Front/Rear: 19 W per channel into 4 Ω, 40 Hz to
20 000 Hz at no more than 0.8% total
harmonic distortion
Frequencies: 60 Hz, 150 Hz, 400 Hz, 1 kHz, 2.4 kHz, 6 kHz,
15 kHz
Level: ±10 dB
Output level: –21 dBm to –15 dBm
Line-Out Level/Impedance: 2.5 V/20 kΩ load (full scale)
Output Impedance: 1 kΩ
AM: 531 kHz to 1 602 kHz
50 dB Quieting Sensitivity: 16.3 dBf (1.8 μV/75 Ω)
Alternate Channel Selectivity (400 kHz): 65 dB
Frequency Response: 40 Hz to 15 000 Hz
Stereo Separation: 30 dB
Signal Detection
System:
Number of Channels: 2 channels (stereo)
Frequency Response: DVD, fs=48 kHz: 16 Hz to 22 000 Hz
Dynamic Range: 96 dB
Signal-to-Noise Ratio: 98 dB
DVD/CD PLAYER SECTION
Wow and Flutter: Less than measurable limit
Non-contact optical pickup (semiconductor laser)
DVD, fs=96 kHz: 16 Hz to 22 000 Hz
CD, fs=44.1 kHz: 16 Hz to 20 000 Hz
40
DivX: Video: Max. Resolution: 720 × 480 pixels (30 fps)
720 × 576 pixels (25 fps)
Audio: Bit Rate: 32 kbps – 320 kbps
Sampling Frequency: MPEG-1: 32 kHz, 44.1 kHz, 48 kHz
MPEG-2: 16 kHz, 22.05 kHz, 24 kHz
MPEG Video: Video: Max. Resolution: 720 × 480 pixels (30 fps)
720 × 576 pixels (25 fps)
Audio: Bit Rate: 32 kbps – 384 kbps
Sampling Frequency: 32 kHz, 44.1 kHz, 48 kHz
MP3: Bit Rate: 32 kbps – 320 kbps
Sampling Frequency: MPEG-1: 32 kHz, 44.1 kHz, 48 kHz
DVD/CD PLAYER SECTION
WMA: Bit Rate: 32 kbps – 320 kbps
Sampling Frequency: 22.05 kHz, 32 kHz, 44.1 kHz, 48 kHz
WAV: Quantization Bit Rate: 16 bit
Sampling Frequency: 44.1 kHz
Format: FAT 12/16/32
Storage: Less than 4 GB (1 partition type)
Playable Audio Format: MP3/WMA
Max. Current: Less than 500 mA
MP3: Bit Rate: 32 kbps – 320 kbps
Sampling Frequency: MPEG-1: 48 kHz, 44.1 kHz, 32 kHz
USB MEMORY
WMA: Bit Rate: 5 kbps – 320 kbps
Sampling Frequency: 8 kHz – 48 kHz
MPEG-2: 16 kHz, 22.05 kHz, 24 kHz
MPEG-2: 24 kHz, 22.05 kHz, 16 kHz
MPEG-2.5: 12 kHz, 11.025 kHz, 8 kHz
Power Requirement: Operating Voltage: DC 14.4 V (11 V to 16 V allowance)
Grounding System: Negative ground
Allowable Operating Temperature: 0°C to +40°C
Dimensions (W × H × D): Installation Size (approx.): 182 mm × 52 mm × 158 mm
GENERAL
Mass (approx.):
Design and specifications are subject to change without notice.
Panel Size (approx.): 188 mm × 58 mm × 11 mm
1.7 kg (excluding accessories)
41
Having TROUBLE with operation?
Please reset your unit
Refer to page of How to reset your unit
EN
© 2006 Victor Company of Japan, Limited
0106DTSMDTJEIN
Loading...
