JVC HR-S7960EX, HR-S7965EF, HR-S7965EK Parts List

SECTION 5

PARTS LIST

5.1 EXPLODED VIEW SAFETY PRECAUTION

Parts identified by the symbol are critical for safety. Replace only with specified part numbers.
BEWARE OF BOGUS PARTS

Parts that do not meet specifications may cause trouble in regard to safety
and performance. We recommend that genuine JVC parts be used.

5.1.1 PACKING AND ACCESSORY ASSEMBLY <M1>
The instruction manual to be provided with this product will differ according to the destination.

314

307
312

(HR-S7965EF,
HR-S7965EK)

SPEC OF BARCODE

317
310
319

306

ADHESIVE TAPE

308

306A

302

FINAL ASSY <M2>

313

303

311

(HR-S7960EX)

SPEC OF BARCODE

316
310

311

315 (HR-S6965EF)

302

301

SPEC OF BARCODE

5-1

5.1.2 FINAL ASSEMBLY <M2>

Hold part of roller arm ass'y while
attaching inertia plate. INERTIA PLATE
should be attached so as to ser small
diameter of central round hole above.

1. Position roller's installation
hole in the "A" part.

2. Insert roller until the "b" part of
roller's hook lock up to the "B" part

3. Hitch the "c" part of spring to
the "C" part.

(HR-S7965EF)

S/P CONVERTER
BOARD ASSY<87>

k

544

501

501G

501E

501C

529

The excessive length portion
of wire should be reat as figure.

right side

520

519A

544

h

h

k

f

h

501A

501D

501F

CN1601

A

516

519

g

511

f

"Z"

501B

501H

515

e

DEMOD BOARD
ASSY<14>

3D D/2M BOARD
ASSY<05>

h

b

c'

DRUM

510

Q3003

"A"

d

b

b

512

back side

505

"C"

g

k

a

510

510

533

c

TERMINAL BOARD

ASSY<06>

c'

D3001

JS3001

d'

c'

b

f

f

f

WR3
(HR-S7965EF)

Make a crease

CN916

A/C HEAD

525

d

516

MECHANISM ASSY<M4>

Insert the bushing of
POWER CORD so
as not to twist the cord.

517

c

533

d

533

d'

c'

b

MAIN BOARD
ASSY<03>

e

f

back side

CN2001

CN5001

b

Make a crease

CN511

Q3002

503

e

502

JS3001

<Phase alignment>
Accord the position of V gap on R. Encoder and PWB silk " ".
Accord the position of Boss on R. Encoder and PWB silk " ".

For the prevention of the DRUM FPC damage.
When you attach the Mechanism assembly on Bottom chassis.
Attach the Mechanism assembly after the positioning boss "z" of the
Bottom chassis is matched to the positioning hole of the Mehcanism assembly.

NOTE) INSERT FFC WIRE TO THE CONNECTOR BEFORE

ATTACHING JOG/SW PWB TO F.PANEL.
NOTE)INSERT FFC WIRE TO THE CONNECTOR
BEFORE ATTACHING JOG/SW PWB TO F.PANEL.

NOTE) WHEN YOU FIX FRONT S Jack PWB WITH THE SCREW.

530 530

530

ADV. JOG BOARD
ASSY<38>

CN7003
CN7004

PUT JIG UNDER FRONT PANEL ASS'Y.

Front panel assembly back side

S JACK BOARD ASSY<36>

WR1

f

REAR SIDE

f

504

NOTE

1. Insert direction of FFC WIRE as follows.

Right side Back side

CN5001

electrode side

2. FFC WIRE and DRUM FPC WIRE should
be insert as follows.

OK

90°

CN

3. Insert direction of POWER CORD.

U/U(C)/JPN

WHITE LINE

503

CN7108

531

supporting side

NG

CN CN

Except U/U(C)/JPN

BLUE

WR2

5-2

WR2

To Front S Jack board assembly

CN7001

To Adv. Jog board assembly

right side

WR1

DETAIL "A"

About 5cm

NEUTRAL

Make a crease

P/S CONV PWB

Make a crease

CN5001

NEUTRAL

CN5001

Classification Part No. Symbol in drawing

Grease KYODO-SH-JB AA

Oil COSMO-HV56 BB

NOTE:The section marked in AA and BB

indicate lubrication and greasing areas.

WR3

WR1

87

39

1

15

91

86

127

128

137

130

90

89

88

75

74

38

105

105

107

107

112

123

151

113

115

124

125

79

82

21

4

117

44

26

3

58

52

57

56

58

55

90

37

77

72

116

50

112

122

110

126

126

89

36

73

69

102

70

134

78

76

71

120

42

85

46

47

81

83

80

49

119

53

161

111

114

118

121

96

93

94

95

64

51

65

18A

19

22

20

16

23A

63

66

59

62

68

24

18

84

61

60

67

23

23B

18B

WR2

A/C HEAD
BOARD ASSY <12>

LOADING MOTOR
BOARD ASSY <55>

AA

AA

AA

AA

AA

AA

AA

AA

AA

AA

AA

AA

AA

BB

BB

BB

BB

BB

AA

AA

AA

AA

AA

AA

AA

AA

AA

AA

48

31

30

5.1.3 MECHANISM ASSEMBL Y <M4>

5-3

5.2 PARTS LIST

MODEL MARK
HR-S7960EX A
HR-S7965EF B
HR-S7965EK C

#! REF No. PART No. PART NAME, DESCRIPTION AB C

----- ------- ---------------------- ------------------------------------------ ---------- - - - -

******************************

P ACKING AND ACCESSOR Y ASSEMBLY <M1>

301 LP30855-004B PACKING CASE ABC
302 LP31187-001A CUSHION ASSY ABC
303 PQM30021-093 POLY BAG ABC
306 LP20878-016A REMOTE CTL UNIT ABC
306A LP40610-003A COVER(BATTER Y) ABC
307 ——— BATTERY,X2 ABC
308 QPC02202230P POLY BAG,CABLE ABC

! 310 LPT0753-001A INST.BOOK(ENGLISH),FOR EX A
! 310 LPT0753-002A INST.BOOK(GERMANY),FOR EX&EY A
! 310 LPT0753-003A INST.BOOK(FRENCH),FOR EX A
! 310 LPT0753-004A INST.BOOK(DUTCH),FOR EX A
! 310 LPT0753-005A INST.BOOK(SPANISH),FOR EX A
! 310 LPT0753-006A INST.BOOK(ITALIAN),FOR EX A
! 310 LPT0753-007A INST.BOOK(DANISH),FOR EY A
! 310 LPT0753-008A INST.BOOK(FINNISH),FOR EY A
! 310 LPT0753-009A INST.BOOK(SWEDISH),FOR EY A
! 310 LPT0753-010A INST.BOOK(NORWEGIAN),FOR EY A
! 310 LPT0753-011A INST.BOOK(PORTGUESE),FOR EX A
! 310 LPT0753-012A INST.BOOK(GREEK),FOR EX A
! 310 LPT0753-013A INST.BOOK(CZECH),FOR EZ A
! 310 LPT0753-014A INST.BOOK(POLISH),FOR EZ A
! 310 LPT0753-015A INST.BOOK(HUNGARIAN),FOR EZ A
! 310 LPT0775-001B INST.BOOK(FRENCH) B
! 310 LPT0770-001A INST.BOOK(ENGLISH) C

311 QPC02503530P POLY BAG,INST ABC
312 PEAC0300-02 RF CABLE ABC
313 QAL0517-005 LED CABLE ASSY BC
315 QAM0238-003 PERI CABLE B
316 BT-54013-6 WARRANTY CARD A
317 BT-54008-4 GUARANTY CARD BC
319 LYT0194-001B Q.CARD(JUK) C

******************************

FINAL ASSEMBL Y<M2>

! 501 LP10452-027C FRONT PANEL ASSY A
! 501 LP10452-017C FRONT PANEL ASSY B
! 501 LP10452-029C FRONT PANEL ASSY C

501A LP21123-008B CASSETTE DOOR ABC
501B PQ46448 TOR.SPRING ABC
501C LP21127-011B COVER(WINDOW) A C
501C LP21127-007B COVER(WINDOW) B
501D LP31188-016A WINDOW(1) A
501D LP31188-009A WINDOW(1) B
501D LP31188-018A WINDOW(1) C
501E LP31142-013B DOOR(JACK) A
501E LP31142-011B DOOR(JACK) B
501E LP31142-015B DOOR(JACK) C
501F LP30877-006A COVER(R) AB C
501G LP41035-001A STICKER ABC
501H LP41035-006A STICKER AB
501H LP41035-007A STICKER C

! 502 LP10013-051C TOP COVER ABC

503 QYTDSF3010R TAP SCREW,X4,SIDE ABC
504 QYTDSF3010M TAP SCREW,REAR ABC
505 PDV2544A DRUM FINAL ASSY ABC

#! REF No. PART No. PART NAME, DESCRIPTION AB C

----- ------- ---------------------- ------------------------------------------ ---------- - - - -

510 QYSPSPD3008Z SCREW,X3,DRUM ABC

! 511 LP10108-016H BOTTOM CHASSIS A C
! 511 LP10108-016G BOTTOM CHASSIS B
! 512 LP10014-002C BOTTOM COVER A B C

515 QYTDSF4012Z TAP SCREW,FOR MECHA ABC
516 QYSPSFG3010Z TAP SCREW,X2,FOR MECHA ABC

! 517 QMP4A10-170 POWER CORD AB
! 517 QMP51K0-170-K POWER CORD C

519 LP40370-001F ROLLER ARM ASSY ABC
519A PDM4311A-1 ROLLER ASS'Y ABC
520 PQ45160 INERTIA PLATE ABC
525 LP40700-001A SPECIAL SCREW,FOR MECHA ABC
529 LP30875-001B KNOB(ADV.JOG) A C
529 LP30875-002B KNOB(ADV.JOG) B
530 QYTPSFG2608Z TAP SCREW,X3,FOR A/J ABC
531 QYTDSF2608Z TAP SCREW,X2,FOR S-JACK AB C
533 DPSF3010Z SCREW,X3,MAIN AB C
544 QYTDSF3008Z TAP SCREW,X2,S-P CONV. B

WR1 QUQ212-0414CG FFC WIRE,A.JOG(FSA) ABC
WR2 QUQ212-0456CG FFC WIRE,S.JAC(FSA) ABC
WR3 QUQ112-1140CG FFC WIRE,S/P CONV. B

******************************

MECHANISM ASSEMBL Y<M4>

1 LP21039-001U MAIN DECK ASSY ABC
3 LP40097-002E GUIDE POLE CAP AB C
4 QAH0082-001 FULL ERASE HEAD ABC
15 LP30958-001B LOAD.GEAR BASE A B C
16 QYTPST2620Z TAP SCREW,X2,L.G.BASE ABC
18 LP40798-001A LOAD.GEAR(SUPPLY) ASSY ABC
18A LP21040-001A LOAD.GEAR(SUPPLY) ABC
18B LP40799-001A LOAD.ARM(SUPPLY) ASSY ABC
19 LP40837-001A TORSION SPRING(S),L.GEAR(S) ABC
20 LP40903-002B FIXING PLATE ABC
21 LP40806-001D POLE BASE ASSY(SUPPLY) ABC
22 LP30959-002B LOAD GEAR AB C
23 LP40802-001C LOAD.GEAR(TAKE UP) ASSY A B C
23A LP21041-001D LOAD.GEAR(TAKE UP) ABC
23B LP40803-001A LOAD.ARM(TAKE UP) ASSY AB C
24 LP40838-001A TORSION SPRING(T),L.GEAR(T) ABC
26 LP40808-001E POLE BASE ASSY(TAKE UP) ABC
30 LP31020-004B ARM BASE ABC
31 QYTDST2606Z TAP SCREW ABC
36 LP21055-001F TU LEVER ABC
37 LP40943-001A TENSION SPRING ABC
38 LP40859-001D T-UP HEAD AB C
39 LP30961-001C LID GUIDE ABC
42 LP40810-001B PINCH ROLLER ARM ASSY ABC
44 LP40840-001D TORSION SPRING,P.ROLLER ABC
46 LP30963-001B PRESS LEVER ABC
47 PQM30017-24 SLIT WASHER,P.LEVER ABC
48 LP40930-002E S-SWITCH ABC
49 LP40813-001D GUIDE ARM ASSY AB C
50 LP40841-001A TORSION SPRING,G.ARM ABC
51 LP30002-090A SPACER,CAPSTAN MOTOR ABC
52 QAH0081-001 AC HEAD AB C
53 LP30965-001A HEAD BASE ABC
55 LP40842-001D COMPRESSION SPRING AB C

5-4

MODEL MARK
HR-S7960EX A
HR-S7965EF B
HR-S7965EK C

#! REF No. PART No. PART NAME, DESCRIPTION AB C #! REF No. PART No. PART NAME, DESCRIPTION AB C

----- ------- ---------------------- ------------------------------------------ ---------- - - - - ----- ------- ---------------------- ------------------------------------------ ---------- - - - -

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

56 QYTDST2006M TAP SCREW,A/C HEAD AB C
57 LP41036-001A A/C ADJ.SCREW,X2,A/C HEAD AB C
58 QYTDST2606Z TAP SCREW,X2,A/C HEAD AB C
59 QAR0023-001 LOADING MOTOR AB C
60 QYTPSP3003Z SCREW,X2,L.MOTOR AB C
61 LP21056-002J MOTOR BRACKET AB C
62 QYTPST2620Z TAP SCREW,M.BKT AB C
63 LP40814-001B WORM BEARING AB C
64 LP21044-001E CONTROL CAM AB C
65 PQM30017-24 SLIT WASHER,CTL.CAM AB C
66 LP40815-001A WORM GEAR AB C
67 LP40816-001B HELICAL GEAR,M.BKT AB C
68 LP40817-001A CONNECT GEAR AB C
69 LP10400-001J CONTROL PLATE AB C
70 LP40843-001A TORSION SPRING AB C
71 LP40818-001B TENSION ARM ASSY AB C
72 LP40844-001E TENSION SPRING,T.ARM AB C
73 LP21045-001D TENSION ARM BASE AB C
74 LP40821-001A TENSION BAND ASSY AB C
75 LP30967-001B BAND HOLDER-1 AB C
76 LP30968-001C BAND HOLDER-2 AB C
77 LP40822-002B ADJUST PIN AB C
78 LP31000-005E TENSION ARM LEVER AB C
79 LP21046-001C MAIN BRAKE(TAKE UP) AB C
80 LP40824-001A BAND BRAKE ASSY AB C
81 LP30969-002B BRAKE LEVER AB C
82 LP30003-033B TENSION SPRING,BRK LEVER AB C
83 LP30003-035B TENSION SPRING,BRK LEVER AB C
84 LP40825-001B CAPSTAN BRAKE ASSY AB C

! 85 QAR0224-002 CAPSTAN MOTOR AB C

86 QYTPSG2606Z TAP SCREW,X3,CAP.MOTOR AB C
87 LP30005-010A BELT,CAPSTAN MOTOR AB C
88 LP30970-001A IDLER ARM AB C
89 LP40828-004A IDLER GEAR 1,X2 AB C
90 LP40829-001B IDLER GEAR 2,X2 AB C
91 LP31014-001A WIRE HOLDER A B C
93 LP40934-001B CLUTCH UNIT AB C
94 PQM30017-47 SLIT WASHER,CLUT.UNIT AB C
95 LP30973-001A DIRECT GEAR AB C
96 LP40939-001A COMPRESION SPRING,DIR.GEAR AB C
102 LP30974-001C CHANGE LEVER AB C
105 LP21049-001A REEL DISK,X2 AB C
107 LP30017-004A SPACER,X2,REEL DISK AB C
110 LP10401-001H SIDE FRAME(L) A B C
111 LP10402-001K SIDE FRAME(R) A B C
112 QYTDST2606Z TAP SCREW,X2,FOR MECHA AB C
113 LP40917-001D TORSION SPRING,FOR DUMP. AB C
114 LP30976-001E SIDE PLATE AB C
115 LP30977-002D LIMIT PLATE AB C
116 LP40846-001C LIMIT SPRING,SIDE PLATE AB C
117 LP31100-001B DRIVE LEVER AB C
118 LP30978-001B DRIVE ARM(L) AB C
119 LP30979-001P DRIVE ARM(R) AB C
120 LP40847-001B TORSION SPRING,D.ARM(R) AB C
121 LP30980-001E CONNECT PLATE AB C
122 LP10403-001C SIDE HOLDER(L) AB C
123 LP10404-001E SIDE HOLDER(R) AB C
124 LP30983-001B LOCK LEVER(L) AB C
125 LP30984-001B LOCK LEVER(R) AB C
126 LP40924-001D TENSION SPRING,X2,L.LEVER AB C
127 LP40972-001A EARTH SPRING(1) A B C

* S7960EX : LPN0797-002B-02 The VCR goes to jig RCU mode after replacing the EEPROM and the VCR does not accept some RCU command.

S7965EF : LPN0798-001B-82 Therefore please set the VCR to the user RCU mode after replacing the EEPROM.
S7965EK : LPN0797-005B-03 The method of setting the VCR to the user RCU mode is written on the service manual.

128 LP40857-001B EARTH SPRING(2),TOP FRAME AB C
130 LP30981-001G CASSETTE HOLDER ASSY AB C
134 LP21051-002C REC SAFETY LEVER A B C
137 LP21052-001J TOP FRAME AB C
151 LP30985-001G DOOR OPENER,SIDE FRM(R) AB C
161 LP40993-001A TAPE GUIDE AB C
WR1 WJT0059-001D E-CARD WIRE,CAP MOTOR AB C
WR2 WJT0067-001B E-CARD WIRE,A/C HEAD AB C
WR3 WJS0022-001A E-FL/RB WIRE,L.MOTOR AB C

******************************

MAIN BOARD ASSEMBLY<03>

PW1 MAIN BOARD ASS’Y<03> includes the parts shown in the following.

PW1 3D D/2M BOARD ASS'Y<05>
PW1 TERMINAL BOARD ASS'Y<06>
PW1 DEMOD BOARD ASS'Y<14>

PW1 LPA10170-09B MAIN PWB ASSY,HR-S7960EX A
PW1 LPA10170-08B MAIN PWB ASSY,HR-S7965EF B
PW1 LPA10170-12B MAIN PWB ASSY,HR-S7965EK C
IC1 JCP8051-MSA IC,VIDEO AB C
IC201 LC74776-9791 IC AB C
IC2201 AN3651FBP IC AB C
IC3001 HD6432194SBD35F IC(MCU),MAIN CPU A C
IC3001 HD6432194SAD36F IC(MCU),MAIN CPU B
IC3001or HD64F2194CFD35 IC(MCU),MAIN CPU A C
IC3001or HD64F2194CFD36 IC(MCU),MAIN CPU B
IC3002 IC-PST3427U-X IC,RESET AB C
IC3003
IC7002 GP1UM291QK IR DETECT UNIT AB C
Q1 2SC4081/QRS/-X TRANSISTOR,SP1 SHORT AB C
Q1 or 2PC4081/R/-X TRANSISTOR AB C
Q2 2SC4081/QRS/-X TRANSISTOR,SP2 SHORT AB C
Q2 or 2PC4081/R/-X TRANSISTOR AB C
Q3 2SC4081/QRS/-X TRANSISTOR,EP1 SHORT AB C
Q3 or 2PC4081/R/-X TRANSISTOR AB C
Q4 2SC4081/QRS/-X TRANSISTOR,EP2 SHORT AB C
Q4 or 2PC4081/R/-X TRANSISTOR AB C
Q7 2SC4081/QRS/-X TRANSISTOR,RF EQ(S) AB C
Q7 or 2PC4081/R/-X TRANSISTOR AB C
Q8 2SC4081/QRS/-X TRANSISTOR,RF EQ(S) AB C
Q8 or 2PC4081/R/-X TRANSISTOR AB C
Q9 2SA1576A/QR/-X TRANSISTOR,RF EQ(S) AB C
Q9 or 2PA1576/R/-X TRANSISTOR AB C
Q10 2SA1576A/QR/-X TRANSISTOR,FSC BUF AB C
Q10 or 2PA1576/R/-X TRANSISTOR AB C
Q14 2SA1576A/QR/-X TRANSISTOR,SECAM REC B
Q14 or 2PA1576/R/-X TRANSISTOR,S B
Q16 DTC144WUA-X DIGI TRANSISTOR,DEMP(SP/EP) AB C
Q16 or UN521E-X DIGI TRANSISTOR AB C
Q16 or RN1309-X DIGI TRANSISTOR ABC
Q16 or PDTC144WU-X DIGI TRANSISTOR AB C
Q18 DTC144WUA-X DIGI TRANSISTOR,SECAM B
Q18 or UN521E-X DIGI TRANSISTOR B
Q18 or RN1309-X DIGI TRANSISTOR B
Q18 or PDTC144WU-X DIGI TRANSISTOR B
Q19 DTC144WUA-X DIGI TRANSISTOR,SECAM B
Q19 or UN521E-X DIGI TRANSISTOR B
Q19 or RN1309-X DIGI TRANSISTOR B

(*REFER TO BELOW)

IC,EEPROM(32K) AB C

5-5

MODEL MARK
HR-S7960EX A
HR-S7965EF B
HR-S7965EK C

#! REF No. PART No. PART NAME, DESCRIPTION AB C

----- ------- ---------------------- ------------------------------------------ ---------- - - - -

Q19 or PDTC144WU-X DIGI TRANSISTOR B
Q21 2SA1576A/QR/-X TRANSISTOR,PB C BUF AB C
Q21 or 2PA1576/R/-X TRANSISTOR AB C
Q24 2SA1576A/QR/-X TRANSISTOR,2FSC BUF AB C
Q24 or 2PA1576/R/-X TRANSISTOR AB C
Q25 DTC144WUA-X DIGI TRANSISTOR,C.K.(3D) AB C
Q25 or UN521E-X DIGI TRANSISTOR AB C
Q25 or RN1309-X DIGI TRANSISTOR ABC
Q25 or PDTC144WU-X DIGI TRANSISTOR AB C
Q38 2SC4081/QRS/-X TRANSISTOR,Y BDL AB C
Q38 or 2PC4081/R/-X TRANSISTOR AB C
Q41 DTC144WUA-X DIGI TRANSISTOR,MESECAM AB C
Q41 or UN521E-X DIGI TRANSISTOR AB C
Q41 or RN1309-X DIGI TRANSISTOR ABC
Q41 or PDTC144WU-X DIGI TRANSISTOR AB C
Q50 DTC144WUA-X DIGI TRANSISTOR,EE(L) ABC
Q50 or UN521E-X DIGI TRANSISTOR AB C
Q50 or RN1309-X DIGI TRANSISTOR ABC
Q50 or PDTC144WU-X DIGI TRANSISTOR AB C
Q207 2SA1576A/QR/-X TRANSISTOR,OSD OUT AB C
Q207 or 2PA1576/R/-X TRANSISTOR,OSD OUT ABC
Q208 2SC4081/QRS/-X TRANSISTOR,OSD OUT ABC
Q208 or 2PC4081/R/-X TRANSISTOR,OSD OUT AB C
Q301 2SB1218A/QR/-X TRANSISTOR B
Q301 or 2SA1576A/QR/-X TRANSISTOR B
Q301 or 2PA1576/R/-X TRANSISTOR B
Q302 UN511E-X DIGI TRANSISTOR B
Q302 or DTA144WUA-X DIGI TRANSISTOR B
Q302 or RN2309-X D TRANSISTOR B
Q302 or PDTA144WU-X DIGI TRANSISTOR B
Q2001 2SC4081/QRS/-X TRANSISTOR ABC
Q2001 or 2SD1819A/QRS/-X TRANSISTOR A B C
Q2001 or 2PC4081/R/-X TRANSISTOR AB C
Q2002 2SC4081/QRS/-X TRANSISTOR ABC
Q2002 or 2SD1819A/QRS/-X TRANSISTOR A B C
Q2002 or 2PC4081/R/-X TRANSISTOR AB C
Q2003 DTA144WUA-X DIGI TRANSIST OR AB C
Q2003 or UN511E-X DIGI TRANSISTOR ABC
Q2003 or RN2309-X D TRANSISTOR AB C
Q2003 or PDTA144WU-X DIGI TRANSISTOR AB C
Q2004 DTC144WUA-X DIGI TRANSISTOR A B C
Q2004 or PDTC144WU-X DIGI TRANSISTOR A B C
Q2004 or UN521E-X DIGI TRANSISTOR ABC
Q2004 or RN1309-X DIGI TRANSISTOR AB C
Q2051 2SC4081/QRS/-X TRANSISTOR ABC
Q2051 or 2SD1819A/QRS/-X TRANSISTOR A B C
Q2051 or 2PC4081/R/-X TRANSISTOR AB C
Q2052 2SA1576A/QR/-X TRANSISTOR A B C
Q2052 or 2SB1218A/QR/-X TRANSISTOR AB C
Q2052 or 2PA1576/R/-X TRANSISTOR ABC
Q2053 DTC144WUA-X DIGI TRANSISTOR A B C
Q2053 or UN521E-X DIGI TRANSISTOR ABC
Q2053 or RN1309-X DIGI TRANSISTOR AB C
Q2053 or PDTC144WU-X DIGI TRANSISTOR A B C
Q2054 2SA1576A/QR/-X TRANSISTOR A B C
Q2054 or 2SB1218A/QR/-X TRANSISTOR AB C
Q2054 or 2PA1576/R/-X TRANSISTOR ABC
Q2055 DTC144WUA-X DIGI TRANSISTOR A B C
Q2055 or UN521E-X DIGI TRANSISTOR ABC
Q2055 or RN1309-X DIGI TRANSISTOR AB C
Q2055 or PDTC144WU-X DIGI TRANSISTOR A B C

#! REF No. PART No. PART NAME, DESCRIPTION AB C

----- ------- ---------------------- ------------------------------------------ ---------- - - - -

Q2201 DTA144WUA-X DIGI TRANSIST OR AB C
Q2201 or PDTA144WU-X DIGI TRANSISTOR AB C
Q2201 or UN511E-X DIGI TRANSISTOR ABC
Q2201 or RN2309-X D TRANSISTOR AB C
Q2202 DTC144WUA-X DIGI TRANSISTOR A B C
Q2202 or PDTC144WU-X DIGI TRANSISTOR A B C
Q2202 or UN521E-X DIGI TRANSISTOR ABC
Q2202 or RN1309-X DIGI TRANSISTOR AB C
Q2203 2SC4081/QRS/-X TRANSISTOR ABC
Q2203 or 2PC4081/R/-X TRANSISTOR AB C
Q2203 or 2SD1819A/QRS/-X TRANSISTOR A B C
Q2204 2SC4081/QRS/-X TRANSISTOR ABC
Q2204 or 2PC4081/R/-X TRANSISTOR AB C
Q2204 or 2SD1819A/QRS/-X TRANSISTOR A B C
Q2251 DTC144WUA-X DIGI TRANSISTOR A B C
Q2251 or PDTC144WU-X DIGI TRANSISTOR A B C
Q2251 or UN521E-X DIGI TRANSISTOR ABC
Q2251 or RN1309-X DIGI TRANSISTOR AB C
Q2252 DTC144WUA-X DIGI TRANSISTOR A B C
Q2252 or PDTC144WU-X DIGI TRANSISTOR A B C
Q2252 or UN521E-X DIGI TRANSISTOR ABC
Q2252 or RN1309-X DIGI TRANSISTOR AB C
Q2253 DTC144WUA-X DIGI TRANSISTOR A B C
Q2253 or PDTC144WU-X DIGI TRANSISTOR A B C
Q2253 or UN521E-X DIGI TRANSISTOR ABC
Q2253 or RN1309-X DIGI TRANSISTOR AB C
Q2254 DTC114EUA-X DIGI TRANSISTOR AB C
Q2254 or PDTC114EU-X DIGI TRANSISTOR ABC
Q2254 or UN5211-X DIGI TRANSISTOR AB C
Q2254 or RN1302-X DIGI TRANSISTOR AB C
Q2255 DTC114EUA-X DIGI TRANSISTOR AB C
Q2255 or PDTC114EU-X DIGI TRANSISTOR ABC
Q2255 or UN5211-X DIGI TRANSISTOR AB C
Q2255 or RN1302-X DIGI TRANSISTOR AB C
Q3002 PTZ-NV16A IC(PHOTO SENSOR),STA.SENSOR AB C
Q3003 PTZ-NV16A IC(PHOTO SENSOR),END SENSOR AB C
Q3004 2SD1819A/QRS/-X TRANSISTOR,POWER DET ABC
Q3004 or 2SC4081/QRS/-X TRANSISTOR,POWER DET AB C
Q3004 or 2PC4081/R/-X TRANSISTOR,POWER DET AB C
Q3005 2SD1819A/QRS/-X TRANSISTOR,SVCC AB C
Q3005 or 2SC4081/QRS/-X TRANSISTOR,SVCC ABC
Q3005 or 2PC4081/R/-X TRANSISTOR,SVCC AB C
Q3007 UN521E-X DIGI TRANSISTOR,P50 AB C
Q3007 or DTC144WUA-X DIGI TRANSISTOR,P50 AB C
Q3007 or PDTC144WU-X DIGI TRANSISTOR,P50 AB C
Q3007 or RN1309-X DIGI TRANSISTOR,P50 AB C
Q4001 UN5211-X DIGI TRANSISTOR A B C
Q4001 or DTC114EUA-X DIGI TRANSISTOR ABC
Q4001 or RN1302-X DIGI TRANSISTOR AB C
Q4001 or PDTC114EU-X DIGI TRANSISTOR ABC
Q5101 2SK2632-CB14 POWER MOS FET AB C
Q5101 or 2SK2129-LT POWER MOS FET AB C
Q5101 or 2SK2632 POWER MOS FET AB C
Q5101 or 2SK2129 POWER MOS FET AB C
Q5102 2SD2144S/UV/-T TRANSISTOR AB C
Q5301 2SC1740S/RS/-T TRANSISTOR AB C
Q5301 or 2SC3199/YG/-T TRANSISTOR A B C
Q5303 2SC5739/QP/ POW TRANSISTOR,SW5V AB C
Q5304 2SD2144S/UV/-T TRANSISTOR,SW12V AB C
Q5305 DTA1 14EUA-X DIGI TRANSISTOR,SW12V ABC
Q5305 or UN5111-X DIGI TRANSISTOR,SW12V ABC

5-6

MODEL MARK
HR-S7960EX A
HR-S7965EF B
HR-S7965EK C

#! REF No. PART No. PART NAME, DESCRIPTION AB C #! REF No. PART No. PART NAME, DESCRIPTION AB C

----- ------- ---------------------- ------------------------------------------ ---------- - - - - ----- ------- ---------------------- ------------------------------------------ ---------- - - - -

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

Q5305 or RN2302-X D TRANSISTOR,SW12V AB C
Q5305 or PDTA114EU-X DIGI TRANSISTOR,SW12V AB C
Q5306 DTC114EUA-X DIGI TRANSISTOR,SW12V AB C
Q5306 or UN5211-X DIGI TRANSISTOR,SW12V AB C
Q5306 or RN1302-X DIGI TRANSISTOR,SW12V AB C
Q5306 or PDTC114EU-X DIGI TRANSISTOR,SW12V AB C
Q5307 2SD2144S/UV/-T TRANSISTOR,RF5V A B C
Q6030 2SB1218A/QR/-X TRANSISTOR,V BUFF AB C
Q6030 or 2SA1576A/QR/-X TRANSISTOR AB C
Q6030 or 2PA1576/R/-X TRANSISTOR AB C
Q6031 DTC114EUA-X DIGI TRANSISTOR AB C
Q6031 or UN5211-X DIGI TRANSISTOR AB C
Q6031 or RN1302-X DIGI TRANSISTOR AB C
Q6031 or PDTC114EU-X DIGI TRANSISTOR ABC
Q6032 DTC114EUA-X DIGI TRANSISTOR AB C
Q6032 or UN5211-X DIGI TRANSISTOR AB C
Q6032 or RN1302-X DIGI TRANSISTOR AB C
Q6032 or PDTC114EU-X DIGI TRANSISTOR ABC
Q7001 2SB1218A/QR/-X TRANSISTOR A B C
Q7001 or 2SA1576A/QR/-X TRANSISTOR AB C
Q7001 or 2PA1576/R/-X TRANSISTOR AB C
Q7002 2SB1218A/QR/-X TRANSISTOR A B C
Q7002 or 2SA1576A/QR/-X TRANSISTOR AB C
Q7002 or 2PA1576/R/-X TRANSISTOR AB C
Q7003 2SB1218A/QR/-X TRANSISTOR A B C
Q7003 or 2SA1576A/QR/-X TRANSISTOR AB C
Q7003 or 2PA1576/R/-X TRANSISTOR AB C
Q7004 2SB1218A/QR/-X TRANSISTOR A B C
Q7004 or 2SA1576A/QR/-X TRANSISTOR AB C
Q7004 or 2PA1576/R/-X TRANSISTOR AB C
Q7005 2SB1218A/QR/-X TRANSISTOR A B C
Q7005 or 2SA1576A/QR/-X TRANSISTOR AB C
Q7005 or 2PA1576/R/-X TRANSISTOR AB C
Q7006 2SB1218A/QR/-X TRANSISTOR,V15 7SEG AB C
Q7006 or 2SA1576A/QR/-X TRANSISTOR AB C
Q7006 or 2PA1576/R/-X TRANSISTOR AB C
Q7007 2SB1218A/QR/-X TRANSISTOR,V15 7SEG AB C
Q7007 or 2SA1576A/QR/-X TRANSISTOR AB C
Q7007 or 2PA1576/R/-X TRANSISTOR AB C
Q7008 DTC143TUA-X DIGI TRANSISTOR AB C
Q7008 or UN5216-X D TRANSISTOR AB C
Q7009 DTC143TUA-X DIGI TRANSISTOR AB C
Q7009 or UN5216-X D TRANSISTOR AB C
Q7010 DTC143TUA-X DIGI TRANSISTOR AB C
Q7010 or UN5216-X D TRANSISTOR AB C
Q7011 DTC143TUA-X DIGI TRANSISTOR AB C
Q7011 or UN5216-X D TRANSISTOR AB C
Q7012 DTC143TUA-X DIGI TRANSISTOR AB C
Q7012 or UN5216-X D TRANSISTOR AB C
Q7013 DTC143TUA-X DIGI TRANSISTOR AB C
Q7013 or UN5216-X D TRANSISTOR AB C
Q7014 DTC143TUA-X DIGI TRANSISTOR AB C
Q7014 or UN5216-X D TRANSISTOR AB C
Q7201 2SC1317/RS/-T TRANSISTOR AB C
D1 QUY153-050Y IM BUS WIRE,ESD AB C
D201 QRE141J-152Y C RESISTOR,OSD CS 1.5kØ,1/4W AB C
D202 QRE141J-101Y C RESISTOR,S.CLK 100Ø,1/4W AB C
D203 QRE141J-101Y C RESISTOR,S.DATA 100Ø,1/4W AB C
D2251 1SS133-T2 SI DIODE AB C
D2251 or 1SS270A-T2 SI DIODE AB C
D3001 LNB2301L01VI IR LED,LED AB C

D3002 1SS133-T2 SI DIODE AB C
D3002 or 1SS270A-T2 SI DIODE AB C
D3003 RD39ES/B3/-T2 Z DIODE,POWER DET ABC
D3003 or MTZJ39C-T2 Z DIODE,POWER DET ABC
D3004 11ES2-T2 SI DIODE,BU5V AB C
D3004 or 1A3G-T2 SI DIODE,BU5V AB C
D3005 11ES2-T2 SI DIODE,AL5V AB C
D3005 or 1A3G-T2 SI DIODE,AL5V AB C
D3008 1SS355-X SI DIODE,P50 A B C
D4001 QUY153-050Y IM BUS WIRE AB C
D4002 QUY153-050Y IM BUS WIRE AB C
D5001 S1WB/A/60-4102 BRIDGE DIODE A B C
D5001 or S1WB/A/60-X BRIDGE DIODE AB C
D5001 or S1WB(A)60F4072X BRIDGE DIODE AB C
D5101 AU01-T2 SI DIODE AB C
D5101 or 1SR153-400-T2 FR DIODE AB C
D5101 or ERA18-04-T2 FR DIODE A B C
D5101 or 10ELS4-T2 FR DIODE AB C
D5102 AU01-T2 SI DIODE AB C
D5102 or 1SR153-400-T2 FR DIODE AB C
D5102 or ERA18-04-T2 FR DIODE A B C
D5102 or 10ELS4-T2 FR DIODE AB C
D5103 1SS133-T2 SI DIODE AB C
D5103 or 1SS270A-T2 SI DIODE AB C
D5105 1SS133-T2 SI DIODE AB C
D5105 or 1SS270A-T2 SI DIODE AB C
D5203 AU01Z-T2 FR DIODE ABC
D5203 or 10ELS2-T2 FR DIODE AB C
D5204 AU01Z-T2 FR DIODE ABC
D5204 or 10ELS2-T2 FR DIODE AB C
D5207 AK04-T2 SB DIODE,6V AB C
D5207 or 11EQS04-T2 SB DIODE,6V ABC
D5207 or 1S4-T2 SB DIODE,6V ABC
D5207 or SBO40-T2 SB DIODE,6V A B C
D5209 AK04-T2 SB DIODE,6V AB C
D5209 or 11EQS04-T2 SB DIODE,6V ABC
D5209 or 1S4-T2 SB DIODE,6V ABC
D5209 or SBO40-T2 SB DIODE,6V A B C
D5210 AU01Z-T2 FR DIODE,BT2 ABC
D5210 or ERA18-02-T2 FR DIODE,BT2 A B C
D5210 or 1SR153-400-T2 FR DIODE,BT2 AB C
D5210 or 10ELS2-T2 FR DIODE,BT2 AB C
D5210 or PG104RS-T2 FR DIODE,BT2 AB C
D5301 MTZJ15C-T2 Z DIODE AB C
D5301 or RD15ES/B3/-T2 Z DIODE AB C
D5302 MTZJ11C-T2 Z DIODE,SW12V A B C
D5302 or RD11ES/B3/-T2 Z DIODE,SW12V AB C
D5303 MTZJ5.6A-T2 Z DIODE AB C
D5303 or RD5.6ES/B1/-T2 Z DIODE AB C
D5305 MTZJ5.6C-T2 Z DIODE,SW5V AB C
D5305 or RD5.6ES/B3/-T2 Z DIODE,SW5V AB C
D6002 HZ30-2L-T2 Z.DIODE ABC
D6002 or HZ30-2LTD Z DIODE (M) AB C
D7051 1SS133-T2 SI DIODE,ESD AB C
D7051 or 1SS270A-T2 SI DIODE,ESD A B C
R1 NRSA02J-622X MG RESISTOR 6.2kØ,1/10W AB C
R2 NRSA02J-152X MG RESISTOR 1.5kØ,1/10W AB C
R3 NRSA02J-182X MG RESISTOR 1.8kØ,1/10W AB C
R5 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W AB C
R6 NRSA02J-273X MG RESISTOR 27kØ,1/10W AB C
R7 NRSA02J-681X MG RESISTOR 680Ø,1/10W A B C

5-7

MODEL MARK
HR-S7960EX A
HR-S7965EF B
HR-S7965EK C

#! REF No. PART No. PART NAME, DESCRIPTION AB C

----- ------- ---------------------- ------------------------------------------ ---------- - - - -

R10 QRE141J-103Y C RESISTOR 10kØ,1/4W ABC
R21 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R22 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R23 NRSA02J-182X MG RESISTOR 1.8kØ,1/10W B
R25 NRSA02J-103X MG RESISTOR 10kØ,1/10W ABC
R26 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W AB C
R27 NRSA02J-221X MG RESISTOR 220Ø,1/10W AB C
R28 NRSA02J-221X MG RESISTOR 220Ø,1/10W AB C
R29 NRSA02J-561X MG RESISTOR 560Ø,1/10W AB C
R30 NRSA02J-103X MG RESISTOR 10kØ,1/10W B
R31 NRSA02J-152X MG RESISTOR 1.5kØ,1/10W AB C
R32 NRSA02J-471X MG RESISTOR 470Ø1/10W AB C
R35 NDC21HJ-470X C CAPACITOR 47pF,50V AB C
R36 NRSA02J-182X MG RESISTOR 1.8kØ,1/10W AB C
R38 NRSA02J-392X MG RESISTOR 3.9kØ,1/10W AB C
R40 NRSA02J-473X MG RESISTOR 47kØ,1/10W ABC
R41 NRSA02J-104X MG RESISTOR 100kØ,1/10W AB C
R42 NRSA02J-681X MG RESISTOR 680Ø,1/10W AB C
R46 NRSA02J-471X MG RESISTOR 470Ø1/10W AB C
R48 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R51 NRSA02J-122X MG RESISTOR 1.2kØ,1/10W AB C
R52 NRSA02J-101X MG RESISTOR 100Ø,1/10W A
R52 NQR0360-003X FERRITE BEADS B
R65 NRSA02J-102X MG RESISTOR 1kØ,1/10W B
R68 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W B
R76 NRSA02J-103X MG RESISTOR 10kØ,1/10W B
R77 NRSA02J-223X MG RESISTOR 22kØ,1/10W ABC
R78 NRSA02J-272X MG RESISTOR 2.7kØ,1/10W AB C
R84 NRSA02J-103X MG RESISTOR 10kØ,1/10W ABC
R88 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W AB C
R90 NRSA02J-391X MG RESISTOR 390Ø,1/10W AB C
R93 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W AB C
R104 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W AB C
R117 NRSA02J-104X MG RESISTOR 100kØ,1/10W AB C
R118 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W AB C
R201 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W AB C
R202 NRSA02J-103X MG RESISTOR 10kØ,1/10W ABC
R208 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W AB C
R209 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W AB C
R210 NRSA02J-182X MG RESISTOR 1.8kØ,1/10W AB C
R211 NRSA02J-562X MG RESISTOR 5.6kØ,1/10W AB C
R212 NRSA02J-101X MG RESISTOR 100Ø,1/10W AB C
R213 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W AB C
R216 NRSA02J-103X MG RESISTOR 10kØ,1/10W ABC
R224 NRSA02J-101X MG RESISTOR 100Ø,1/10W AB C
R225 NRSA02J-471X MG RESISTOR 470Ø1/10W AB C
R226 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R301 NRSA02J-273X MG RESISTOR 27kØ,1/10W B
R302 NRSA02J-124X MG RESISTOR 120kØ,1/10W B
R303 NRSA02J-273X MG RESISTOR 27kØ,1/10W B
R304 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W B
R305 NRSA02J-473X MG RESISTOR 47kØ,1/10W B
R306 NRSA02J-273X MG RESISTOR 27kØ,1/10W B
R307 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W B
R308 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W B
R309 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B
R310 NRSA02J-223X MG RESISTOR 22kØ,1/10W B
R311 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W B
R312 NRSA02J-272X MG RESISTOR 2.7kØ,1/10W B
R313 NRSA02J-223X MG RESISTOR 22kØ,1/10W B
R314 NRVA02D-243X CMF RESISTOR 24kØ,1/10W B

#! REF No. PART No. PART NAME, DESCRIPTION AB C

----- ------- ---------------------- ------------------------------------------ ---------- - - - -

R315 NRSA02J-564X MG RESISTOR 560kØ,1/10W B
R316 NRSA02J-124X MG RESISTOR 120kØ,1/10W B
R318 NRSA02J-821X MG RESISTOR 820Ø,1/10W B
R329 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B
R2041 QRE141J-0R0 C RESISTOR 0Ø,1/4W ABC
R2003 NRSA02J-101X MG RESISTOR 100Ø,1/10W AB C
R2005 NRSA02J-153X MG RESISTOR 15kØ,1/10W AB C
R2007 NRSA02J-183X MG RESISTOR 18kØ,1/10W AB C
R2008 NRSA02J-103X MG RESISTOR 10kØ,1/10W AB C
R2010 NRSA02J-123X MG RESISTOR 12kØ,1/10W AB C
R2013 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W AB C
R2014 NRSA02J-224X MG RESISTOR 220kØ,1/10W A B C
R2015 NRSA02J-181X MG RESISTOR 180Ø,1/10W AB C
R2016 NRSA02J-393X MG RESISTOR 39kØ,1/10W AB C
R2017 NRSA02J-183X MG RESISTOR 18kØ,1/10W AB C
R2018 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W AB C
R2019 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W AB C
R2020 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W AB C
R2053 NRSA02J-392X MG RESISTOR 3.9kØ,1/10W AB C
R2054 NRSA02J-123X MG RESISTOR 12kØ,1/10W AB C
R2055 NRSA02J-3R3X MG RESISTOR 3.3Ø,1/10W A B C
R2056 QRE141J-820Y C RESISTOR 82Ø,1/4W AB C
R2057 NRSA02J-473X MG RESISTOR 47kØ,1/10W AB C
R2058 NRSA02J-183X MG RESISTOR 18kØ,1/10W AB C
R2059 NRSA02J-473X MG RESISTOR 47kØ,1/10W AB C
R2060 NRSA02J-183X MG RESISTOR 18kØ,1/10W AB C
R2201 NRSA02J-473X MG RESISTOR 47kØ,1/10W AB C
R2202 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W AB C
R2203 NRSA02J-473X MG RESISTOR 47kØ,1/10W AB C
R2204 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W AB C
R2205 NRSA02J-473X MG RESISTOR 47kØ,1/10W AB C
R2206 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W AB C
R2207 NRSA02J-473X MG RESISTOR 47kØ,1/10W AB C
R2208 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W AB C
R2209 NRSA02J-681X MG RESISTOR 680Ø,1/10W AB C
R2210 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W AB C
R2211 NRSA02J-272X MG RESISTOR 2.7kØ,1/10W AB C
R2212 NRSA02J-272X MG RESISTOR 2.7kØ,1/10W AB C
R2213 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W AB C
R2214 NRSA02J-681X MG RESISTOR 680Ø,1/10W AB C
R2215 NRSA02J-181X MG RESISTOR 180Ø,1/10W AB C
R2216 NRSA02J-122X MG RESISTOR 1.2kØ,1/10W A C
R2217 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W A C
R2218 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W AB C
R2219 NRSA02J-122X MG RESISTOR 1.2kØ,1/10W AB C
R2220 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R2222 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W AB C
R2223 NRSA02J-511X MG RESISTOR 510Ø,1/10W AB C
R2224 NRSA02J-511X MG RESISTOR 510Ø,1/10W AB C
R2225 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W AB C
R2226 NRSA02J-273X MG RESISTOR 27kØ,1/10W AB C
R2227 NRSA02J-393X MG RESISTOR 39kØ,1/10W AB C
R2228 NRSA02J-273X MG RESISTOR 27kØ,1/10W AB C
R2229 NRSA02J-393X MG RESISTOR 39kØ,1/10W AB C
R2230 NRSA02J-473X MG RESISTOR 47kØ,1/10W AB C
R2231 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W AB C
R2232 NRSA02J-473X MG RESISTOR 47kØ,1/10W AB C
R2233 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W AB C
R2234 NRSA02J-101X MG RESISTOR 100Ø,1/10W AB C
R2235 NRSA02J-681X MG RESISTOR 680Ø,1/10W AB C
R2236 NRSA02J-272X MG RESISTOR 2.7kØ,1/10W AB C

5-8

MODEL MARK
HR-S7960EX A
HR-S7965EF B
HR-S7965EK C

#! REF No. PART No. PART NAME, DESCRIPTION AB C #! REF No. PART No. PART NAME, DESCRIPTION AB C

----- ------- ---------------------- ------------------------------------------ ---------- - - - - ----- ------- ---------------------- ------------------------------------------ ---------- - - - -

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

R2237 NRSA02J-681X MG RESISTOR 680Ø,1/10W AB C
R2238 NRSA02J-272X MG RESISTOR 2.7kØ,1/10W AB C
R2251 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W AB C
R2252 NRSA02J-221X MG RESISTOR 220Ø,1/10W AB C
R2253 NRSA02J-101X MG RESISTOR 100Ø,1/10W AB C
R2254 QRE141J-103Y C RESISTOR 10kØ,1/4W AB C
R2255 NRSA02J-273X MG RESISTOR 27kØ,1/10W AB C
R2256 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W AB C
R3011 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R3012 NRSA02J-102X MG RESISTOR 1kØ,1/10W B
R3013 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R3014 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R3015 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R3016 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R3017 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R3018 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W AB C
R3019 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R3020 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R3021 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R3022 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R3025 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W AB C
R3026 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W AB C
R3027 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W AB C
R3029 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R3030 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R3031 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R3033 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W AB C
R3034 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R3035 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W AB C
R3036 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W AB C
R3037 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R3038 NRSA02J-152X MG RESISTOR 1.5kØ,1/10W AB C
R3039 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R3040 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W AB C
R3041 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W AB C
R3042 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R3044 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W AB C
R3046 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R3047 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R3048 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W AB C
R3049 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W AB C
R3050 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W AB C
R3051 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R3052 NRSA02J-471X MG RESISTOR 470Ø1/10W AB C
R3053 NRSA02J-471X MG RESISTOR 470Ø1/10W AB C
R3054 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R3055 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R3056 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R3057 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R3058 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R3059 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W AB C
R3060 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W AB C
R3061 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R3062 NRSA02J-103X MG RESISTOR 10kØ,1/10W AB C
R3063 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W AB C
R3066 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W AB C
R3069 NRSA02J-101X MG RESISTOR 100Ø,1/10W AB C
R3071 NRSA02J-103X MG RESISTOR 10kØ,1/10W AB C
R3072 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R3073 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W AB C
R3074 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W AB C

R3075 NRSA02J-471X MG RESISTOR 470Ø1/10W AB C
R3076 NRSA02J-471X MG RESISTOR 470Ø1/10W AB C
R3077 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W AB C
R3078 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W AB C
R3079 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W AB C
R3080 NRSA02J-101X MG RESISTOR 100Ø,1/10W AB C
R3081 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W AB C
R3083 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W AB C
R3085 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W AB C
R3086 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W AB C
R3087 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W AB C
R3088 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W AB C
R3089 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W AB C
R3090 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W AB C
R3091 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W AB C
R3092 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W AB C
R3093 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W AB C
R3094 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W AB C
R3095 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W AB C
R3096 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W AB C
R3097 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W AB C
R3103 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W AB C
R3105 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W AB C
R3106 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W AB C
R3205 QRE141J-181Y C RESISTOR 180Ø,1/4W ABC
R3206 NRSA02J-123X MG RESISTOR 12kØ,1/10W ABC
R3207 NRSA02J-183X MG RESISTOR 18kØ,1/10W ABC
R3208 NRSA02J-121X MG RESISTOR 120Ø,1/10W AB C
R3209 NRSA02J-183X MG RESISTOR 18kØ,1/10W ABC
R3210 NRSA02J-121X MG RESISTOR 120Ø,1/10W AB C
R3211 NRSA02J-183X MG RESISTOR 18kØ,1/10W ABC
R3212 NRSA02J-474X MG RESISTOR 470kØ,1/10W A B C
R3213 NRSA02J-334X MG RESISTOR 330kØ,1/10W A B C
R3214 NRSA02J-103X MG RESISTOR 10kØ,1/10W ABC
R3215 NRSA02J-103X MG RESISTOR 10kØ,1/10W ABC
R3216 NRSA02J-103X MG RESISTOR 10kØ,1/10W ABC
R3217 NRSA02J-103X MG RESISTOR 10kØ,1/10W ABC
R3218 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W AB C
R3219 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W AB C
R3220 NRSA02J-104X MG RESISTOR 100kØ,1/10W A B C
R3222 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W AB C
R3223 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W AB C
R3224 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W AB C
R3225 NRSA02J-103X MG RESISTOR 10kØ,1/10W ABC
R3229 NRSA02J-105X MG RESISTOR 1MØ,1/10W AB C
R3230 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W AB C
R3231 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R3234 NRSA02J-103X MG RESISTOR 10kØ,1/10W ABC
R3235 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W AB C
R3236 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W AB C
R3237 NRSA02J-103X MG RESISTOR 10kØ,1/10W ABC
R3238 NRSA02J-103X MG RESISTOR 10kØ,1/10W ABC
R3241 NRSA02J-103X MG RESISTOR 10kØ,1/10W ABC
R3242 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W AB C
R3252 NRSA02J-153X MG RESISTOR 15kØ,1/10W ABC
R3253 NRSA02J-103X MG RESISTOR 10kØ,1/10W ABC
R4003 NRSA02J-561X MG RESISTOR 560Ø,1/10W AB C
R4004 NRSA02J-561X MG RESISTOR 560Ø,1/10W AB C
R4005 NRSA02J-562X MG RESISTOR 5.6kØ,1/10W AB C
R4007 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R4008 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C

5-9

MODEL MARK
HR-S7960EX A
HR-S7965EF B
HR-S7965EK C

#! REF No. PART No. PART NAME, DESCRIPTION AB C

----- ------- ---------------------- ------------------------------------------ ---------- - - - -

R4009 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R4010 NRSA02J-103X MG RESISTOR 10kØ,1/10W ABC
R4012 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W AB C
R4013 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W AB C
R4015 NRSA02J-562X MG RESISTOR 5.6kØ,1/10W AB C
R4017 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R5101 QRE141J-224Y C RESISTOR 220kØ,1/4W AB C
R5102 QRE141J-224Y C RESISTOR 220kØ,1/4W AB C
R5103 QRE141J-683Y C RESISTOR 68kØ,1/4W AB C
R5104 QRG02GJ-683 OMF RESISTOR 68kØ,2W ABC
R5106 QRT01DJ-R39X MF RESISTOR 0.39Ø,1W AB C
R5107 QRE121J-331Y C RESISTOR 330Ø,1/2W ABC
R5108 NRSA02J-152X MG RESISTOR 1.5kØ,1/10W AB C
R5109 QRE141J-561Y C RESISTOR 560Ø,1/4W ABC
R5110 NRSA02J-224X MG RESISTOR 220kØ,1/10W A B C
R5111 NRSA02J-391X MG RESISTOR 390Ø,1/10W A B C
R5112 NRSA02J-221X MG RESISTOR 220Ø,1/10W AB C
R5302 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R5303 NRSA02J-122X MG RESISTOR 1.2kØ,1/10W AB C
R5304 NRSA02J-471X MG RESISTOR 470Ø1/10W AB C
R5306 NRSA02J-181X MG RESISTOR 180Ø,1/10W AB C
R5310 NRSA02J-103X MG RESISTOR 10kØ,1/10W ABC
R5312 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R5313 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R5319 NRSA02J-221X MG RESISTOR 220Ø,1/10W AB C
R5332 QRL02DJ-391X OMF RESISTOR 390Ø,2W A B C
R6020 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R6021 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R6030 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R6031 NRSA02J-271X MG RESISTOR 270Ø,1/10W AB C
R6032 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W A C
R6032 NRSA02J-183X MG RESISTOR 18kØ,1/10W B
R6033 NRSA02J-182X MG RESISTOR 1.8kØ,1/10W A C
R6033 NRSA02J-183X MG RESISTOR 18kØ,1/10W B
R6050 NRSA02J-101X MG RESISTOR 100Ø,1/10W A C
R6051 QRE141J-101Y C RESISTOR 100Ø,1/4W A C
R6052 NRSA02J-101X MG RESISTOR 100Ø,1/10W A C
R6056 NRSA02J-101X MG RESISTOR 100Ø,1/10W A C
R6080 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R7001 NRSA02J-151X MG RESISTOR 150Ø,1/10W AB C
R7002 NRSA02J-151X MG RESISTOR 150Ø,1/10W AB C
R7003 NRSA02J-151X MG RESISTOR 150Ø,1/10W AB C
R7004 NRSA02J-101X MG RESISTOR 100Ø,1/10W AB C
R7005 NRSA02J-151X MG RESISTOR 150Ø,1/10W AB C
R7006 NRSA02J-151X MG RESISTOR 150Ø,1/10W AB C
R7007 NRSA02J-151X MG RESISTOR 150Ø,1/10W AB C
R7015 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R7020 NRSA02J-103X MG RESISTOR 10kØ,1/10W ABC
R7021 NRSA02J-122X MG RESISTOR 1.2kØ,1/10W AB C
R7022 NRSA02J-182X MG RESISTOR 1.8kØ,1/10W AB C
R7023 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W AB C
R7024 NRSA02J-272X MG RESISTOR 2.7kØ,1/10W AB C
R7025 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W AB C
R7026 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W AB C
R7030 NRSA02J-103X MG RESISTOR 10kØ,1/10W ABC
R7031 NRSA02J-122X MG RESISTOR 1.2kØ,1/10W AB C
R7032 NRSA02J-182X MG RESISTOR 1.8kØ,1/10W AB C
R7033 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W AB C
R7034 NRSA02J-272X MG RESISTOR 2.7kØ,1/10W AB C
R7160 NRSA02J-101X MG RESISTOR 100Ø,1/10W AB C
R7161 NRSA02J-101X MG RESISTOR 100Ø,1/10W AB C

#! REF No. PART No. PART NAME, DESCRIPTION AB C

----- ------- ---------------------- ------------------------------------------ ---------- - - - -

R7162 NRSA02J-101X MG RESISTOR 100Ø,1/10W AB C
R7163 NRSA02J-750X MG RESISTOR 75Ø,1/10W AB C
R7202 NRSA02J-221X MG RESISTOR 220Ø,1/10W AB C
R7203 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W AB C
R7204 QRE121J-100Y C RESISTOR 10Ø,1/2W AB C
VR2251

QVP0039-223Z TRIM RESISTOR ABC
B5 NRSA02J-0R0X MG RESISTOR,PB FM BUF 0Ø,1/10W AB C
B10 NRSA02J-0R0X MG RESISTOR,C IN(SVHS) 0Ø,1/10W AB C
B13 QUY160-180Y IM BUS WIRE,V.REF ABC
B65 NRSA02J-0R0X MG RESISTOR,TITLE REC 0Ø,1/10W ABC
B203 QUY160-100Y IM BUS WIRE,I2C CLK2 AB C
B204 QUY160-080Y IM BUS WIRE,I2C DATA2 AB C
B214 NRSA02J-0R0X MG RESISTOR,RF VIDEO 0Ø,1/10W AB C
B302 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B
B2051 QUY160-060Y IM BUS WIRE AB C
B2221 QUY160-140Y IM BUS WIRE,AL5V AB C
B3001 QUY160-060Y IM BUS WIRE,ICT AB C
B5001 QUY160-100Y IM BUS WIRE,OPT:LF5001 ABC
B5002 QUY160-100Y IM BUS WIRE,OPT:LF5001 ABC
C1 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C
C2 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C
C3 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C
C4 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C
C5 QEKC0JM-476Z E CAPACITOR 47µF,6.3V AB C
C6 QDYB1CM-103Y C CAPACITOR 0.01µF,16V AB C
C7 NCB21HK-102X C CAPACITOR 0.001µF,50V AB C
C8 NCB21EK-104X C CAPACITOR 0.1µF,25V AB C
C9 QEKJ1HM-225Z E CAPACITOR 2.2µF,50V AB C
C10 NDC21HJ-151X C CAPACITOR 150pF,50V ABC
C11 NCB21EK-104X C CAPACITOR 0.1µF,25V AB C
C12 NDC21HJ-8R0X C CAPACITOR 8pF,50V AB C
C14 NCB21EK-104X C CAPACITOR 0.1µF,25V AB C
C15 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C
C16 NCB21EK-104X C CAPACITOR 0.1µF,25V AB C
C17 QEKJ1HM-335Z E CAPACITOR 3.3µF,50V ABC
C19 QEKJ1HM-225Z E CAPACITOR 2.2µF,50V ABC
C20 QEPF1HM-105Z BP E CAPACITOR 1µF,50V AB C
C21 NCB21EK-104X C CAPACITOR 0.1µF,25V AB C
C22 QEKJ0JM-476Z E CAPACITOR 47µF,6.3V ABC
C23 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C
C24 QCBB1HK-104Y C CAPACITOR 0.1µF,50V ABC
C25 NDC21HJ-6R0X C CAPACITOR 6pF,50V AB C
C26 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C
C27 NCB21HK-223X C CAPACITOR 0.022µF,50V AB C
C28 QEKJ1HM-335Z E CAPACITOR 3.3µF,50V ABC
C29 NCB21EK-333X C CAPACITOR 0.033µF,25V AB C
C30 NCB21CK-474X C CAPACITOR 0.47µF,16V AB C
C31 QEKJ0JM-476Z E CAPACITOR 47µF,6.3V ABC
C32 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C
C33 QEKJ1HM-225Z E CAPACITOR 2.2µF,50V ABC
C34 NCB21EK-104X C CAPACITOR 0.1µF,25V AB C
C35 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C
C36 QEKJ1HM-475Z E CAPACITOR 4.7µF,25V ABC
C37 QEKJ1HM-105Z E CAPACITOR 1µF,50V A B C
C38 QEKJ0JM-476Z E CAPACITOR 47µF,6.3V ABC
C40 QEKJ1EM-106Z E CAPACITOR 10µF,25V ABC
C44 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C
C45 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C
C53 NDC21HJ-101X C CAPACITOR 100pF,50V ABC
C59 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C
C61 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C

5-10

MODEL MARK
HR-S7960EX A
HR-S7965EF B
HR-S7965EK C

#! REF No. PART No. PART NAME, DESCRIPTION AB C #! REF No. PART No. PART NAME, DESCRIPTION AB C

----- ------- ---------------------- ------------------------------------------ ---------- - - - - ----- ------- ---------------------- ------------------------------------------ ---------- - - - -

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

C63 NCB21EK-104X C CAPACITOR 0.1µF,25V AB C
C64 NDC21HJ-220X C CAPACITOR 22pF,50V AB C
C65 QEKJ1HM-105Z E CAPACITOR 1µF,50V A B C
C69 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C
C70 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C
C72 NDC21HJ-470X C CAPACITOR 47pF,50V AB C
C73 NDC21HJ-120X C CAPACITOR 12pF,50V AB C
C78 NCB21HK-103X C CAPACITOR 0.01µF,50V B
C80 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C
C84 NRSA02J-153X MG RESISTOR 15kØ,1/10W AB C
C92 NDC21HJ-330X C CAPACITOR 33pF,50V AB C
C103 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C
C106 NCB21HK-821X C CAPACITOR 820pF,50V AB C
C108 NDC21HJ-680X C CAPACITOR 68pF,50V AB C
C110 NDC21HJ-820X C CAPACITOR 82pF,50V AB C
C114 NDC21HJ-181X C CAPACITOR 180pF,50V AB C
C201 QEKJ0JM-227Z E CAPACITOR 220µF,6.3V AB C
C204 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C
C206 NDC21HJ-330X C CAPACITOR 33pF,50V AB C
C207 NDC21HJ-330X C CAPACITOR 33pF,50V AB C
C209 NCB21CK-474X C CAPACITOR 0.47µF,16V AB C
C210 NDC21HJ-101X C CAPACITOR 100pF,50V AB C
C211 NDC21HJ-101X C CAPACITOR 100pF,50V AB C
C212 NCB21EK-104X C CAPACITOR 0.1µF,25V AB C
C213 QERF1EM-475Z E CAPACITOR 4.7µF,25V AB C
C214 NCB21CK-224X C CAPACITOR 0.22µF,16V AB C
C215 NCB21CK-224X C CAPACITOR 0.22µF,16V AB C
C217 NDC21HJ-560X C CAPACITOR 56pF,50V AB C
C218 QEKJ1HM-105Z E CAPACITOR 1µF,50V AB C
C222 QEKJ1HM-105Z E CAPACITOR 1µF,50V AB C
C225 QERF1AM-227Z E CAPACITOR 220µF,10V AB C
C301 NDC21HJ-151X C CAPACITOR 150pF,50V B
C302 NCB21CK-105X C CAPACITOR 1µF,16V B
C303 NCB21HK-682X C CAPACITOR 0.0068µF,50V B
C304 NCB21HK-682X C CAPACITOR 0.0068µF,50V B
C305 NCB21HK-103X C CAPACITOR 0.01µF,50V B
C306 NCB21CK-105X C CAPACITOR 1µF,16V B
C307 NDC21HJ-151X C CAPACITOR 150pF,50V B
C308 NCB21HK-103X C CAPACITOR 0.01µF,50V B
C309 NCB21EK-104X C CAPACITOR 0.1µF,25V B
C310 NCB21HK-103X C CAPACITOR 0.01µF,50V B
C311 NCB21HK-103X C CAPACITOR 0.01µF,50V B
C312 NCB21HK-102X C CAPACITOR 0.001µF,50V B
C313 NCB21CK-474X C CAPACITOR 0.47µF,16V B
C315 NCB21CK-105X C CAPACITOR 1µF,16V B
C316 NCB21HK-103X C CAPACITOR 0.01µF,50V B
C317 NCB21HK-681X C CAPACITOR 680pF,50V B
C318 NCB21EK-223X C CAPACITOR 0.022µF,25V B
C319 NCB21CK-105X C CAPACITOR 1µF,16V B
C320 NCB21HK-103X C CAPACITOR 0.01µF,50V B
C321 NDC21HG-301X C CAPACITOR 300pF,50V B
C322 NCB21CK-474X C CAPACITOR 0.47µF,16V B
C323 QEKJ0JM-476Z E CAPACITOR 47µF,6.3V B
C324 NDC21HJ-390X C CAPACITOR 39pF,50V B
C2001 QEKJ1HM-475Z E CAPACITOR 4.7µF,25V AB C
C2002 QEKJ1HM-105Z E CAPACITOR 1µF,50V AB C
C2003 QEKJ0JM-476Z E CAPACITOR 47µF,6.3V AB C
C2005 QEKJ1HM-475Z E CAPACITOR 4.7µF,25V AB C
C2006 NCB21HK-123X C CAPACITOR 0.012µF,50V AB C
C2007 QEKJ1CM-226Z E CAPACITOR 22µF,16V AB C
C2008 QEKJ1HM-475Z E CAPACITOR 4.7µF,25V AB C

C2009 NCB21HK-102X C CAPACITOR 0.001µF,50V AB C
C2010 NCB21HK-152X C CAPACITOR 0.0015µF,50V AB C
C2011 QEKJ1HM-475Z E CAPACITOR 4.7µF,25V AB C
C2012 QEKC1HM-475Z E CAPACITOR 4.7µF,50V AB C
C2013 NCB21HK-331X C CAPACITOR 330pF,50V ABC
C2017 NCB21HK-682X C CAPACITOR 0.0068µF,50V AB C
C2051 NCB21HK-331X C CAPACITOR 330pF,50V ABC
C2053 NCB21HK-472X C CAPACITOR 0.0047µF,50V AB C
C2054 NCB21EK-223X C CAPACITOR 0.022µF,25V AB C
C2055 QEKJ1EM-106Z E CAPACITOR 10µF,25V AB C
C2061 QFV91HJ-823Z MF CAPACITOR 0.082µF,50V AB C
C2201 QEKJ1EM-106Z E CAPACITOR 10µF,25V AB C
C2202 QEKJ1HM-475Z E CAPACITOR 4.7µF,25V AB C
C2203 QEKJ1HM-475Z E CAPACITOR 4.7µF,25V AB C
C2204 QEKJ0JM-336Z E CAPACITOR 33µF,6.3V AB C
C2205 QEKJ1EM-106Z E CAPACITOR 10µF,25V AB C
C2206 QEKJ1EM-106Z E CAPACITOR 10µF,25V AB C
C2207 NCB21HK-153X C CAPACITOR 0.015µF,50V AB C
C2208 NCB21HK-153X C CAPACITOR 0.015µF,50V AB C
C2209 QERF1CM-106Z E CAPACITOR 10µF,16V AB C
C2210 QERF1CM-106Z E CAPACITOR 10µF,16V AB C
C2211 QEKJ0JM-336Z E CAPACITOR 33µF,6.3V AB C
C2212 QERF0JM-476Z E CAPACITOR 47µF,6.3V AB C
C2214 QEKJ1EM-106Z E CAPACITOR 10µF,25V AB C
C2215 QEKJ1EM-106Z E CAPACITOR 10µF,25V AB C
C2216 QEKJ1CM-476Z E CAPACITOR 47µF,16V AB C
C2218 QEKJ1EM-106Z E CAPACITOR 10µF,25V A C
C2219 QEKJ1CM-226Z E CAPACITOR 22µF,16V A C
C2220 QEKJ1EM-106Z E CAPACITOR 10µF,25V AB C
C2221 NCB21EK-223X C CAPACITOR 0.022µF,25V AB C
C2222 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C
C2223 NCB21EK-473X C CAPACITOR 0.047µF,25V AB C
C2224 NCB21EK-473X C CAPACITOR 0.047µF,25V AB C
C2225 QEKJ1HM-105Z E CAPACITOR 1µF,50V AB C
C2226 QEKJ1HM-105Z E CAPACITOR 1µF,50V AB C
C2227 QERF1CM-106Z E CAPACITOR 10µF,16V AB C
C2230 QEKJ1EM-106Z E CAPACITOR 10µF,25V AB C
C2231 QEKJ1EM-106Z E CAPACITOR 10µF,25V AB C
C2251 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C
C2252 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C
C2253 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C
C2254 QEKJ0JM-476Z E CAPACITOR 47µF,6.3V AB C
C2255 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C
C2256 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C
C2257 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C
C2258 NDC21HJ-181X C CAPACITOR 180pF,50V AB C
C2259 QEKJ1HM-334Z E CAPACITOR 0.33µF,50V AB C
C2261 NDC21HJ-101X C CAPACITOR 100pF,50V AB C
C2262 NDC21HJ-101X C CAPACITOR 100pF,50V AB C
C3008 NDC21HJ-101X C CAPACITOR 100pF,50V AB C
C3011 QETL0JM-338 E CAPACITOR 3300µF,6.3V ABC
C3012 QEKJ0JM-476Z E CAPACITOR 47µF,6.3V AB C
C3014 QERF0JM-476Z E CAPACITOR 47µF,6.3V AB C
C3015 NCB21EK-104X C CAPACITOR 0.1µF,25V AB C
C3016 NCB21EK-473X C CAPACITOR 0.047µF,25V AB C
C3020 NDC21HJ-101X C CAPACITOR 100pF,50V AB C
C3021 NDC21HJ-101X C CAPACITOR 100pF,50V AB C
C3022 NCB21EK-104X C CAPACITOR 0.1µF,25V AB C
C3024 NDC21HJ-220X C CAPACITOR 22pF,50V A
C3024 NDC21HJ-120X C CAPACITOR 12pF,50V BC
C3025 QAT3725-300Z TRIM CAPACITOR A

5-11

MODEL MARK
HR-S7960EX A
HR-S7965EF B
HR-S7965EK C

#! REF No. PART No. PART NAME, DESCRIPTION AB C

----- ------- ---------------------- ------------------------------------------ ---------- - - - -

C3026 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C
C3027 QEKJ1EM-106Z E CAPACITOR 10µF,25V AB C
C3030 QEKJ0JM-476Z E CAPACITOR 47µF,6.3V AB C
C3031 NCB21EK-473X C CAPACITOR 0.047µF,25V AB C
C3033 NCB21EK-473X C CAPACITOR 0.047µF,25V AB C
C3036 NDC21HJ-180X C CAPACITOR 18pF,50V AB C
C3037 NDC21HJ-120X C CAPACITOR 12pF,50V AB C
C3040 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C
C3041 NDC21HJ-150X C CAPACITOR 15pF,50V BC
C3050 NCF21EZ-104X C CAPACITOR 0.1µF,25V AB C
C3071 QEKJ1CM-336Z E CAPACITOR 33µF,16V AB C
C4002 NCB21EK-104X C CAPACITOR 0.1µF,25V AB C
C4004 QEKJ1AM-226Z E CAPACITOR 22µF,10V AB C
C4005 NCB21HK-222X C CAPACITOR 0.0022µF,50V AB C
C4006 QEKJ0JM-476Z E CAPACITOR 47µF,6.3V AB C
C4008 NCB21AK-105X C CAPACITOR 1µF,10V AB C
C4009 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W AB C
C4010 NCB21EK-223X C CAPACITOR 0.022µF,25V AB C
C4011 NCB21EK-104X C CAP ACITOR 0.1µF,25V AB C
C4012 QERF1HM-105Z E CAPACITOR 1µF,50V AB C
C4014 NDC21HJ-101X C CAPACITOR 100pF,50V AB C
C4015 NCB21HK-102X C CAPACITOR 0.001µF,50V AB C
C4031 QEKJ1CM-336Z E CAPACITOR 33µF,16V AB C

! C5001 QFZ9072-473 MM CAPACITOR 0.047µF,125V AB C
! C5004 QCZ9071-222 C CAPACITOR 0.0022µF,250V AB C

C5006 QEZ0375-686 E CAPACITOR 68µF,400V AB C
C5101 QCZ0212-472 C CAPACITOR 0.0047µF,1kV AB C
C5102 QCZ0302-330Z C CAPACITOR 33pF,1kV AB C
C5104 QEKJ1HM-105Z E CAPACITOR 1µF,50V AB C
C5105 QFN31HJ-153Z M CAPACITOR 0.015µF,50V ABC
C5106 QCBB1HJ-271Y C CAPACITOR 270pF,50V ABC
C5107 QFV91HJ-104Z MF CAPACITOR 0.1µF,50V AB C
C5202 QETN1CM-108Z E CAPACITOR 1000µF,16V ABC
C5203 QEMT1AM-128 E CAPACITOR 1200µF,10V A B C
C5204 QETJ2AM-475Z E CAPACITOR 4.7µF,10V ABC
C5206 QEKJ1CM-476Z E CAPACITOR 47µF,16V AB C
C5207 QEKJ1CM-107Z E CAPACITOR 100µF,16V ABC
C5301 QEKJ1CM-107Z E CAPACITOR 100µF,16V ABC
C5303 QEKJ1CM-107Z E CAPACITOR 100µF,16V ABC
C5305 QFVF1HJ-274Z MF CAPACITOR 0.27µF,50V A B C
C5307 QEKJ1CM-476Z E CAPACITOR 47µF,16V AB C
C5308 QEKJ1CM-107Z E CAPACITOR 100µF,16V ABC
C6008 NCB21HK-103X C CAPACITOR 0.01µF,50V B
C6013 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C
C6032 NCB21EK-473X C CAPACITOR 0.047µF,25V A C
C6037 QEKJ1EM-106Z E CAPACITOR 10µF,25V AB C
C6055 NDC21HJ-220X C CAPACITOR 22pF,50V A C
C6056 NDC21HJ-470X C CAPACITOR 47pF,50V A C
C6501 QEKJ1EM-106Z E CAPACITOR 10µF,25V A C
C6501 QEKJ0JM-227Z E CAPACITOR 220µF,6.3V B
C6502 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C
C7011 QEKJ0JM-476Z E CAPACITOR 47µF,6.3V AB C
C7165 NCB21HK-681X C CAPACITOR 680pF,50V ABC
C7167 NCB21HK-681X C CAPACITOR 680pF,50V ABC
C7202 QETJ0JM-477Z E CAPACITOR 470µF,6.3V ABC
L1 QQL29BJ-100Z P COIL 10µH AB C
L2 QQL071J-121Y INDUCTOR 120µH ABC
L3 QQL29BJ-100Z P COIL 10µH AB C
L4 QQL29BJ-100Z P COIL 10µH AB C
L5 QQR0521-012Z NOISE FILTER AB C
L12 QQR0967-001 CHOKE COIL 12µH AB C

#! REF No. PART No. PART NAME, DESCRIPTION AB C

----- ------- ---------------------- ------------------------------------------ ---------- - - - -

L13 QQL071J-330Y INDUCTOR 33µH AB C
L15 QQL29BJ-100Z P COIL 10µH AB C
L18 QQL071J-220Y INDUCTOR 22µH AB C
L19 QQL071J-120Y INDUCTOR 12µH AB C
L20 QUY153-050Y IM BUS WIRE A B C
L22 QQL231J-1R0Y INDUCTOR 1.0µH AB C
L24 QQL071J-270Y INDUCTOR 27µH AB C
L27 QQL071J-330Y INDUCTOR 33µH AB C
L28 QQL071J-680Y INDUCTOR 68µH AB C
L201 QQL29BK-1R0Z P COIL 1.0µH AB C
L202 QUY153-050Y IM BUS WIRE A B C
L203 QQL29BJ-220Z P COIL 22µH AB C
L204 QQL29BJ-100Z P COIL 10µH AB C
L206 QQL071J-220Y INDUCTOR 22µH AB C
L301 QQL29BJ-100Z P COIL 10µH B
L302 QQL231J-6R8Y INDUCTOR 6.8µH B
L303 QQL231J-270Y INDUCTOR 27µH B
L304 QQL29BJ-101Z P COIL 100µH B
L2001 QUY153-050Y IM BUS WIRE AB C
L2201 QUY153-050Y IM BUS WIRE AB C
L2251 QQL29BJ-100Z P COIL 10µH AB C
L2252 QQL29BJ-151Z P COIL 150µH AB C
L4001 QUY153-050Y IM BUS WIRE AB C
L5201 PELN1184 CHOKE COIL 33µH AB C
L5202 PELN1184 CHOKE COIL 33µH AB C
L6001 QQL29BJ-100Z P COIL 10µH AB C
L6002 QQL29BJ-100Z P COIL 10µH AB C
L6501 QUY153-050Y IM BUS WIRE AB C
L7201 QQL29BJ-100Z P COIL 10µH AB C

!

CP3001

!

CP4001

QMFZ050-1R5X-E FUSE T1.5A,125V A B C

QMFZ050-1R5X-E FUSE T1.5A,125V A B C
DI7001 LTG-0126M-03J LED AB C
FC5001
FC5002

QNG0006-001Z FUSE CLIP,FOR F5001 AB C

QNG0006-001Z FUSE CLIP,FOR F5001 AB C
J7105 QNN0381-002 PIN JACK,NI YWR A B C
JS3001 QSW0954-002 ROTARY ENCODER,R.ENCODER AB C
K2001 NRSA02J-0R0X MG RESISTOR,SET1 0Ø,1/10W AB C
K2002 NRSA02J-0R0X MG RESISTOR,SET1 0Ø,1/10W AB C
K2003 NRSA02J-0R0X MG RESISTOR,SET1 0Ø,1/10W AB C
K2004 NRSA02J-0R0X MG RESISTOR,SET1 0Ø,1/10W AB C
K2251 NQR0007-001X FERRITE BEADS ABC
K2252 NQR0007-001X FERRITE BEADS ABC
K2253 NQR0007-001X FERRITE BEADS ABC
K5101 QQR0678-001Z FERRITE BEADS ABC
K5102 QUY153-050Y IM BUS WIRE AB C

! LF5002 QQR0978-001 LINE FILTER ABC

PC3001
PC3002

!

PC5101

RPI-304J IC(PHOTO SENSOR),SP REEL AB C

RPI-304J IC(PHOTO SENSOR),TU REEL AB C

PC123Y22 IC(PHOTO COUPLER) AB C
T2051 PELN0832 OSC TRANS AB C

! T5001 QQS0083-001 SW TRANSF AB C

TP106 QUY160-100Y IM BUS WIRE,PB FM AB C
TP111 QUY160-100Y IM BUS WIRE,D.FF ABC
TP2253
TP2254
TP4001
TU6001
TU6001

QUY160-100Y IM BUS WIRE,A.PB FM AB C

QUY160-100Y IM BUS WIRE,A.REC.FM AB C

QUY160-100Y IM BUS WIRE,CTL.P AB C

QAU0261-002 TUNER,15ALPS3SYS A C

QAU0210-001 TUNER,LG BG/L B
X1 QAX0576-001Z CRYSTAL,PAL ABC
X2 QCBB1HK-103Y C CAPACITOR,NTSC 0.01µF,50V AB C
X3001 QAX0445-001 CRYSTAL,32K ADJ A C

5-12

MODEL MARK
HR-S7960EX A
HR-S7965EF B
HR-S7965EK C

#! REF No. PART No. PART NAME, DESCRIPTION AB C #! REF No. PART No. PART NAME, DESCRIPTION AB C

----- ------- ---------------------- ------------------------------------------ ---------- - - - - ----- ------- ---------------------- ------------------------------------------ ---------- - - - -

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

X3001 QAX0444-001 CRYSTAL,32K ADJ B
X3002 QAX0527-001 CRYSTAL,10M AB C
S3001 QSW0602-004 PUSH SWITCH,REC.SAFETY AB C
S3002 QSW0602-004 PUSH SWITCH,S.CASS AB C
S7002 QSW0456-002Z TACT SWITCH,POWER AB C
S7003 QSW0456-002Z TACT SWITCH,TIMER AB C
S7004 QSW0456-002Z TACT SWITCH,REC LINK AB C
S7006 QSW0456-002Z TACT SWITCH,SVHS ET AB C
S7010 QSW0456-002Z TACT SWITCH,REC AB C
S7011 QSW0456-002Z TACT SWITCH,PAUSE AB C
S7013 QSW0456-002Z TACT SWITCH,STOP/EJ AB C
S7015 QSW0456-002Z TACT SWITCH,PLAY AB C
S7017 QSW0456-002Z TACT SWITCH,SP/LP/EP ABC
SD1 LP21105-001A SHIELD CASE,FOR P/R AB C
ET1 PQ21623-2-5 EARTH PLATE(RF),FOR TUNER AB C
HS1 LP40090-001A HEAT SINK,FOR Q5101 AB C
OT1 QYTDSF3010Z TAP SCREW,X2,FOR TERM_B AB C
OT2 PU59915-110 #500SPACER0.014,R2041 AB C
OT3 QYTDST3006Z TAP SCREW,FOR Q5101 AB C
OT4 PM30130-001 SPACER,FOR WR6501 B
WR6501
CN1 QGF1201C2-09 FPC CONNECTOR,DRUM 1-9 AB C
CN901 QGB2024K1-10S B TO B CONNECTOR,TERMINAL AB C
CN902 QGB2024K1-12S B TO B CONNECTOR,TERMINAL AB C
CN903 QGB2024K1-10S B TO B CONNECTOR,TERMINAL AB C
CN904 QGB2024K1-11S B TO B CONNECTOR,TERMINAL AB C
CN905 QGB2024K1-09S B TO B CONNECTOR,TERMINAL AB C
CN2001
CN2002
CN3001

!

CN5001
CN7002

! F5001 QMF51E2-2R0-J1 FUSE T2.0A,AC250V AB C

QUB321-16A4A4 SIN TWIST WIRE,W421-D2 B

QGF1207C1-06 FPC CONNECTOR,A/C HEAD AB C
QGB2532J1-02 B TO B CONNECTOR,FE HEAD A B C
QGB2032M4-12 B TO B CONNECTOR,CAP+DRUM M AB C
QGA7901C3-02 W TO B CONNECTOR,POWER CORD AB C
QGF1207C1-04 FPC CONNECTOR,A.JOG V16 AB C

******************************

3D DIGITAL/2M BOARD ASSEMBLY<05>

PW1 LPA10105-09A 3D D/2M BOARD ASSY AB C
IC1401 JCP8026 IC AB C

! Q1401 2SC1317/RS/-T TRANSISTOR AB C

Q1402 2SA1576A/QR/-X TRANSISTOR A B C
Q1402 or 2PA1576/R/-X TRANSISTOR AB C
Q1406 2SA1576A/QR/-X TRANSISTOR A B C
Q1406 or 2PA1576/R/-X TRANSISTOR AB C
Q1408 2SC4081/S/-X TRANSISTOR AB C
Q1410 2SC4081/QRS/-X TRANSISTOR ABC
Q1410 or 2PC4081/R/-X TRANSISTOR AB C
Q1412 2SA1576A/QR/-X TRANSISTOR A B C
Q1412 or 2PA1576/R/-X TRANSISTOR AB C
Q1418 2SA1576A/QR/-X TRANSISTOR A B C
Q1418 or 2PA1576/R/-X TRANSISTOR AB C
Q1419 DTC124TUA-X DIGI TRANSISTOR AB C
D1401 RD4.3ES/B3/-T2 Z DIODE AB C
D1401 or MTZJ4.3B-T2 Z DIODE AB C
D1402 1SS133-T2 SI DIODE AB C
D1402 or 1N4148M-T2 DIODE AB C
R1401 NRSA02J-121X MG RESISTOR 120Ø,1/10W AB C
R1402 NRSA02J-101X MG RESISTOR 100Ø,1/10W AB C
R1404 NRSA02J-272X MG RESISTOR 2.7kØ,1/10W AB C
R1406 NRSA02J-221X MG RESISTOR 220Ø,1/10W AB C

R1410 NRSA02J-391X MG RESISTOR 390Ø,1/10W AB C
R1411 NRSA02J-152X MG RESISTOR 1.5kØ,1/10W AB C
R1413 NRSA02J-221X MG RESISTOR 220Ø,1/10W AB C
R1415 NRVA02D-221X CMF RESISTOR 220Ø,1/10W AB C
R1416 NRSA02J-104X MG RESISTOR 100kØ,1/10W A B C
R1417 NRSA02J-101X MG RESISTOR 100Ø,1/10W AB C
R1418 NRSA02J-471X MG RESISTOR 470Ø1/10W AB C
R1421 NRSA02J-331X MG RESISTOR 330Ø,1/10W AB C
R1426 NRSA02J-561X MG RESISTOR 560Ø,1/10W AB C
R1427 NRSA02J-333X MG RESISTOR 33kØ,1/10W ABC
R1428 NRSA02J-393X MG RESISTOR 39kØ,1/10W ABC
R1429 NRSA02J-182X MG RESISTOR 1.8kØ,1/10W AB C
R1430 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W AB C
R1431 NRSA02J-821X MG RESISTOR 820Ø,1/10W AB C
R1433 NRSA02J-510X MG RESISTOR 51Ø,1/10W AB C
R1434 NRVA02D-153X CMF RESISTOR 15Ø,1/10W AB C
R1435 NRVA02D-473X CMF RESISTOR 47kØ,1/10W AB C
R1436 NRVA02D-393X CMF RESISTOR 39Ø,1/10W AB C
R1437 NRSA02J-392X MG RESISTOR 3.9kØ,1/10W AB C
R1438 NRSA02J-473X MG RESISTOR 47kØ,1/10W ABC
R1439 NRSA02J-273X MG RESISTOR 27kØ,1/10W ABC
R1440 NRSA02J-473X MG RESISTOR 47kØ,1/10W ABC
R1445 NRVA02D-393X CMF RESISTOR 39Ø,1/10W AB C
R1446 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R1447 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R1448 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R1449 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R1450 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R1452 NRSA02J-471X MG RESISTOR 470Ø1/10W AB C
R1453 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R1455 NRSA02J-681X MG RESISTOR 680Ø,1/10W AB C
R1459 NRSA02J-681X MG RESISTOR 680Ø,1/10W AB C
R1460 NRSA02J-273X MG RESISTOR 27kØ,1/10W ABC
VR1401
B1401 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W ABC
B1412 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W ABC
C1401 QEKJ1CM-336Z E CAPACITOR 33µF,16V AB C
C1403 QEKJ0JM-337Z E CAPACITOR 330µF,6.3V ABC
C1404 NCF21EZ-104X C CAPACITOR 0.1µF,25V AB C
C1405 NCF21EZ-104X C CAPACITOR 0.1µF,25V AB C
C1406 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C
C1407 NDC21HJ-680X C CAPACITOR 68pF,50V AB C
C1408 NDC21HJ-330X C CAPACITOR 33pF,50V AB C
C1410 QEKJ1HM-475Z E CAPACITOR 4.7µF,25V AB C
C1411 NCF21EZ-104X C CAPACITOR 0.1µF,25V AB C
C1412 NDC21HJ-680X C CAPACITOR 68pF,50V AB C
C1413 NDC21HJ-330X C CAPACITOR 33pF,50V AB C
C1415 NCF21EZ-104X C CAPACITOR 0.1µF,25V AB C
C1416 QEKJ1EM-106Z E CAPACITOR 10µF,25V AB C
C1417 NCF21EZ-104X C CAPACITOR 0.1µF,25V AB C
C1418 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C
C1421 NDC21HJ-330X C CAPACITOR 33pF,50V AB C
C1422 NDC21HJ-680X C CAPACITOR 68pF,50V AB C
C1423 NCF21EZ-104X C CAPACITOR 0.1µF,25V AB C
C1424 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C
C1425 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C
C1426 NDC21HJ-390X C CAPACITOR 39pF,50V AB C
C1428 NDC21HJ-220X C CAPACITOR 22pF,50V AB C
C1429 QEKJ0JM-337Z E CAPACITOR 330µF,6.3V ABC
C1430 NCF21EZ-104X C CAPACITOR 0.1µF,25V AB C
C1432 NCF21CZ-105X C CAPACITOR 1µF,16V AB C

QUY153-050Y IM BUS WIRE AB C

5-13

MODEL MARK
HR-S7960EX A
HR-S7965EF B
HR-S7965EK C

#! REF No. PART No. PART NAME, DESCRIPTION AB C

----- ------- ---------------------- ------------------------------------------ ---------- - - - -

C1433 NCF21EZ-104X C CAPACITOR 0.1µF,25V AB C
C1435 NCF21EZ-104X C CAPACITOR 0.1µF,25V AB C
C1436 NCF21EZ-104X C CAPACITOR 0.1µF,25V AB C
C1437 NCF21EZ-104X C CAPACITOR 0.1µF,25V AB C
C1438 NCF21EZ-104X C CAPACITOR 0.1µF,25V AB C
C1439 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C
C1440 NCF21EZ-104X C CAPACITOR 0.1µF,25V AB C
C1441 NCF21EZ-104X C CAPACITOR 0.1µF,25V AB C
C1442 NCF21CZ-105X C CAPACITOR 1µF,16V AB C
C1444 NCF21EZ-104X C CAPACITOR 0.1µF,25V AB C
C1445 NCF21EZ-104X C CAPACITOR 0.1µF,25V AB C
C1446 QEKJ0JM-476Z E CAPACITOR 47µF,6.3V AB C
C1447 NCF21EZ-104X C CAPACITOR 0.1µF,25V AB C
C1448 QEKJ0JM-476Z E CAPACITOR 47µF,6.3V AB C
C1449 NCF21EZ-104X C CAPACITOR 0.1µF,25V AB C
C1450 NCF21EZ-104X C CAPACITOR 0.1µF,25V AB C
C1451 QEKJ1HM-475Z E CAPACITOR 4.7µF,25V AB C
C1452 NCF21EZ-104X C CAPACITOR 0.1µF,25V AB C
C1453 NCF21EZ-104X C CAPACITOR 0.1µF,25V AB C
C1454 NCF21EZ-104X C CAPACITOR 0.1µF,25V AB C
C1463 QEKJ0JM-336Z E CAPACITOR 33µF,6.3V AB C
C1468 NDC21HJ-101X C CAPACITOR 100pF,50V AB C
C1470 NDC21HJ-330X C CAPACITOR 33pF,50V AB C
C1471 NCF21EZ-104X C CAPACITOR 0.1µF,25V AB C
C1472 NCF21EZ-104X C CAPACITOR 0.1µF,25V AB C
C1473 NCF21EZ-104X C CAPACITOR 0.1µF,25V AB C
L1401 QUY153-050Y IM BUS WIRE AB C
L1402 QQL071J-6R8Y INDUCTOR 6.8µH AB C
L1403 QQL071J-6R8Y INDUCTOR 6.8µH AB C
L1404 QQL071J-6R8Y INDUCTOR 6.8µH AB C
L1405 QQL29BJ-100Z P COIL 10µH AB C
L1406 QQL071J-330Y INDUCTOR 33µH AB C
L1407 QQL29BJ-100Z P COIL 10µH AB C
L1409 QQL071J-1R0Y INDUCTOR 1.0µH AB C

!

LC1401
LC1402
SD1 LP30706-001D S.FRAME(S-VHS) AB C
SD2 LP30684-001A S.CASE(S-VHS) AB C
CN1401

QQL29BJ-101Z P COIL,M/I 100µH AB C
QQR0521-006Z NOISE FILTER ABC

QGG2502K1-17 HEADER PIN ABC

******************************

TERMINAL BOARD ASSEMBLY<06>

PW1 LPA10138-14A TERM BOARD ASSY,EX/EK A C
PW1 LPA10138-13A TERM BOARD ASSY,EF B
IC501 JCP8018 IC ABC
IC501 or JCP8028 IC AB C
IC501 or JCP8028-01 IC AB C
IC501 or JCP8038 IC AB C
IC502 VC2076DP IC AB C
IC901 BH7636S IC,CH+ AB C
Q901 UN5211-X DIGI TRANSISTOR A B C
Q901 or DTC114EUA-X DIGI TRANSISTOR AB C
Q901 or RN1302-X DIGI TRANSISTOR AB C
Q901 or PDTC114EU-X DIGI TRANSISTOR AB C
Q902 2SB1218A/QR/-X TRANSISTOR A B C
Q902 or 2SA1576A/QR/-X TRANSISTOR ABC
Q902 or 2PA1576/R/-X TRANSISTOR AB C
Q903 2SB1218A/QR/-X TRANSISTOR,S OUT AB C
Q903 or 2SA1576A/QR/-X TRANSISTOR,S OUT AB C

#! REF No. PART No. PART NAME, DESCRIPTION AB C

----- ------- ---------------------- ------------------------------------------ ---------- - - - -

Q903 or 2PA1576/R/-X TRANSISTOR,S OUT AB C
Q904 2SB1218A/QR/-X TRANSISTOR,S OUT AB C
Q904 or 2SA1576A/QR/-X TRANSISTOR,S OUT AB C
Q904 or 2PA1576/R/-X TRANSISTOR,S OUT AB C
Q905 UN521E-X DIGI TRANSISTOR AB C
Q905 or DTC144WUA-X DIGI TRANSISTOR AB C
Q905 or RN1309-X DIGI TRANSISTOR AB C
Q905 or PDTC144WU-X DIGI TRANSISTOR AB C
Q906 2SD1819A/QRS/-X TRANSISTOR A B C
Q906 or 2SC4081/QRS/-X TRANSISTOR AB C
Q906 or 2PC4081/R/-X TRANSIST OR AB C
Q907 2SD1819A/QRS/-X TRANSISTOR A B C
Q907 or 2SC4081/QRS/-X TRANSISTOR AB C
Q907 or 2PC4081/R/-X TRANSIST OR AB C
Q908 2SD1819A/QRS/-X TRANSISTOR A B C
Q908 or 2SC4081/QRS/-X TRANSISTOR AB C
Q908 or 2PC4081/R/-X TRANSIST OR AB C
Q909 2SB1218A/QR/-X TRANSISTOR A B C
Q909 or 2SA1576A/QR/-X TRANSISTOR ABC
Q909 or 2PA1576/R/-X TRANSISTOR AB C
Q910 2SB1218A/QR/-X TRANSISTOR A B C
Q910 or 2SA1576A/QR/-X TRANSISTOR ABC
Q910 or 2PA1576/R/-X TRANSISTOR AB C
Q91 1 UN521E-X DIGI TRANSISTOR A B C
Q91 1 or DTC144WUA-X DIGI TRANSISTOR ABC
Q91 1 or RN1309-X DIGI TRANSISTOR A B C
Q91 1 or PDTC144WU-X DIGI TRANSISTOR ABC
Q912 UN5215-X DIGI TRANSISTOR AB C
Q912 or DTC114TUA-X DIGI TRANSISTOR A B C
Q912 or RN1311-X D TRANSISTOR ABC
Q912 or PDTC114TU-X DIGI TRANSISTOR A B C
R503 NRSA02J-221X MG RESISTOR 220Ø,1/10W AB C
R504 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W AB C
R505 NRSA02J-392X MG RESISTOR 3.9kØ,1/10W AB C
R506 NRSA02J-391X MG RESISTOR 390Ø,1/10W AB C
R507 NRSA02J-122X MG RESISTOR 1.2kØ,1/10W AB C
R508 NRSA02J-151X MG RESISTOR 150Ø,1/10W AB C
R509 NRSA02J-162X MG RESISTOR 1.6kØ,1/10W AB C
R510 NRVA02D-102X CMF RESISTOR 1kØ,1/10W AB C
R511 NRVA02D-471X CMF RESISTOR 470Ø,1/10W AB C
R512 NRVA02D-102X CMF RESISTOR 1kØ,1/10W AB C
R513 NRVA02D-152X CMF RESISTOR 1.5kØ,1/10W AB C
R514 NRVA02D-332X CMF RESISTOR 3.3kØ,1/10W AB C
R515 NRVA02D-332X CMF RESISTOR 3.3kØ,1/10W AB C
R516 QUY160-100Y IM BUS WIRE ABC
R517 QUY160-100Y IM BUS WIRE ABC
R525 QRE141J-125Y C RESISTOR 1.2MØ,1/4W ABC
R527 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W A C
R531 NRSA02J-101X MG RESISTOR 100Ø,1/10W AB C
R532 NRSA02J-101X MG RESISTOR 100Ø,1/10W AB C
R533 NRSA02J-101X MG RESISTOR 100Ø,1/10W AB C
R534 NRSA02J-101X MG RESISTOR 100Ø,1/10W AB C
R535 NRSA02J-101X MG RESISTOR 100Ø,1/10W AB C
R536 NRSA02J-101X MG RESISTOR 100Ø,1/10W AB C
R901 NRSA02J-750X MG RESISTOR 75Ø,1/10W AB C
R902 NRSA02J-750X MG RESISTOR 75Ø,1/10W AB C
R903 QRE141J-680Y C RESISTOR 68Ø,1/4W AB C
R904 NQL402M-4R7X INDUCTOR 4.7µH ABC
R905 NQL402M-4R7X INDUCTOR 4.7µH ABC
R906 QQL231J-100Y INDUCTOR 10µH AB C
R907 QQL231J-100Y INDUCTOR 10µH AB C

5-14

MODEL MARK
HR-S7960EX A
HR-S7965EF B
HR-S7965EK C

#! REF No. PART No. PART NAME, DESCRIPTION AB C #! REF No. PART No. PART NAME, DESCRIPTION AB C

----- ------- ---------------------- ------------------------------------------ ---------- - - - - ----- ------- ---------------------- ------------------------------------------ ---------- - - - -

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

R908 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W AB C
R909 NRSA02J-750X MG RESISTOR 75Ø,1/10W A B C
R910 NRSA02J-750X MG RESISTOR 75Ø,1/10W A B C
R911 NRSA02J-750X MG RESISTOR 75Ø,1/10W A B C
R912 NRSA02J-101X MG RESISTOR 100Ø,1/10W AB C
R913 NRSA02J-101X MG RESISTOR 100Ø,1/10W AB C
R914 QQL231J-100Y INDUCTOR 10µH AB C
R915 QQL231J-100Y INDUCTOR 10µH AB C
R916 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R917 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W AB C
R918 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W AB C
R919 QRE141J-101Y C RESISTOR 100Ø,1/4W AB C
R920 QRE141J-101Y C RESISTOR 100Ø,1/4W AB C
R921 QRE121J-391Y C RESISTOR 390Ø,1/2W AB C
R922 QRE121J-391Y C RESISTOR 390Ø,1/2W AB C
R923 NRSA02J-750X MG RESISTOR 75Ø,1/10W A B C
R924 NRSA02J-750X MG RESISTOR 75Ø,1/10W A B C
R929 NRSA02J-820X MG RESISTOR 82Ø,1/10W A B C
R930 NRSA02J-750X MG RESISTOR 75Ø,1/10W A B C
R931 NRSA02J-101X MG RESISTOR 100Ø,1/10W AB C
R932 NRSA02J-511X MG RESISTOR 510Ø,1/10W AB C
R933 NRSA02J-471X MG RESISTOR 470Ø1/10W AB C
R934 QRE141J-101Y C RESISTOR 100Ø,1/4W AB C
R935 QRE141J-101Y C RESISTOR 100Ø,1/4W AB C
R936 QRE141J-101Y C RESISTOR 100Ø,1/4W AB C
R937 QRE141J-101Y C RESISTOR 100Ø,1/4W AB C
R938 QRE141J-101Y C RESISTOR 100Ø,1/4W AB C
R939 QRE141J-101Y C RESISTOR 100Ø,1/4W AB C
R940 NRSA02J-103X MG RESISTOR 10kØ,1/10W AB C
R941 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W AB C
R942 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W AB C
R943 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W AB C
R944 NRSA02J-272X MG RESISTOR 2.7kØ,1/10W AB C
R945 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R946 NRSA02J-561X MG RESISTOR 560Ø,1/10W AB C
R947 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W AB C
R949 QRE121J-331Y C RESISTOR 330Ø,1/2W AB C
R951 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W AB C
R952 NRSA02J-562X MG RESISTOR 5.6kØ,1/10W AB C
R953 NRSA02J-562X MG RESISTOR 5.6kØ,1/10W AB C
R964 NRSA02J-101X MG RESISTOR 100Ø,1/10W AB C
C501 QEKJ1HM-225Z E CAPACITOR 2.2µF,50V AB C
C502 QEKJ1HM-475Z E CAPACITOR 4.7µF,25V AB C
C503 QEKJ1HM-225Z E CAPACITOR 2.2µF,50V AB C
C504 NCB21EK-104X C CAPACITOR 0.1µF,25V AB C
C505 QEKJ1HM-475Z E CAPACITOR 4.7µF,25V AB C
C506 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C
C507 QEKJ0JM-476Z E CAPACITOR 47µF,6.3V AB C
C508 QEKJ1HM-474Z E CAPACITOR 0.47µF,50V AB C
C509 QEKJ1CM-106Z E CAPACITOR 10µF,16V AB C
C510 QEKJ0JM-476Z E CAPACITOR 47µF,6.3V AB C
C511 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C
C512 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C
C513 QEKJ1HM-475Z E CAPACITOR 4.7µF,25V AB C
C514 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C
C515 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C
C516 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C
C518 NCB21EK-104X C CAPACITOR 0.1µF,25V AB C
C519 QEKJ1HM-225Z E CAPACITOR 2.2µF,50V AB C
C520 QEKJ1HM-475Z E CAPACITOR 4.7µF,25V AB C
C521 QEKJ1HM-475Z E CAPACITOR 4.7µF,25V AB C

C522 QEKJ1HM-225Z E CAPACITOR 2.2µF,50V ABC
C523 QEKJ1HM-225Z E CAPACITOR 2.2µF,50V ABC
C524 NDC21HG-301X C CAPACITOR 300pF,50V ABC
C525 NDC21HG-301X C CAPACITOR 300pF,50V ABC
C526 NDC21HJ-101X C CAPACITOR 100pF,50V AB C
C527 NDC21HJ-181X C CAPACITOR 180pF,50V AB C
C528 NDC21HG-271X C CAPACITOR 270pF,50V ABC
C529 NDC21HG-820X C CAPACITOR 82pF,50V AB C
C530 NDC21HG-221X C CAPACITOR 220pF,50V ABC
C531 NDC21HG-301X C CAPACITOR 300pF,50V ABC
C532 NDC21HG-301X C CAPACITOR 300pF,50V ABC
C533 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C
C534 QEKJ0JM-476Z E CAPACITOR 47µF,6.3V AB C
C535 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C
C551 QEKJ1HM-105Z E CAPACITOR 1µF,50V ABC
C553 QCBB1HK-103Y C CAPACITOR 0.01µF,50V AB C
C554 QEKJ1HM-105Z E CAPACITOR 1µF,50V ABC
C556 QCBB1HK-103Y C CAPACITOR 0.01µF,50V AB C
C557 QEKJ1HM-105Z E CAPACITOR 1µF,50V ABC
C559 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C
C560 QEKJ1HM-105Z E CAPACITOR 1µF,50V ABC
C561 QEKJ1HM-105Z E CAPACITOR 1µF,50V ABC
C562 QEKJ1HM-105Z E CAPACITOR 1µF,50V B
C563 NCB21HK-103X C CAPACITOR 0.01µF,50V A C
C564 NCB21HK-103X C CAPACITOR 0.01µF,50V B
C566 NCB21HK-103X C CAPACITOR 0.01µF,50V B
C568 NDC21HJ-680X C CAPACITOR 68pF,50V AB C
C569 NDC21HJ-680X C CAPACITOR 68pF,50V AB C
C570 NDC21HJ-680X C CAPACITOR 68pF,50V AB C
C571 NDC21HJ-680X C CAPACITOR 68pF,50V AB C
C572 NDC21HJ-680X C CAPACITOR 68pF,50V AB C
C573 NDC21HJ-680X C CAPACITOR 68pF,50V AB C
C575 NDC21HJ-101X C CAPACITOR 100pF,50V AB C
C901 NCB21HK-331X C CAPACITOR 330pF,50V AB C
C902 NCB21HK-331X C CAPACITOR 330pF,50V AB C
C903 NCB21HK-471X C CAPACITOR 470pF,50V AB C
C904 NCB21HK-471X C CAPACITOR 470pF,50V AB C
C905 NCB21HK-331X C CAPACITOR 330pF,50V AB C
C906 NCB21HK-331X C CAPACITOR 330pF,50V AB C
C907 NCB21HK-471X C CAPACITOR 470pF,50V AB C
C908 NCB21HK-471X C CAPACITOR 470pF,50V AB C
C910 NCB21HK-102X C CAPACITOR 0.001µF,50V AB C
C912 NCB21HK-102X C CAPACITOR 0.001µF,50V AB C
C913 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C
C914 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C
C915 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C
C916 NCB21HK-223X C CAPACITOR 0.022µF,50V AB C
C917 NCB21HK-223X C CAPACITOR 0.022µF,50V AB C
C918 QCBB1HK-223Y C CAPACITOR 0.22µF,50V AB C
C921 NDC21HJ-330X C CAPACITOR 33pF,50V AB C
C923 QEKJ1CM-476Z E CAPACITOR 47µF,16V AB C
C924 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C
C925 NCB21HK-223X C CAPACITOR 0.022µF,50V AB C
C927 QEKJ1CM-476Z E CAPACITOR 47µF,16V AB C
C928 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C
C931 QEKJ1EM-106Z E CAPACITOR 10µF,25V ABC
C935 NCB21HK-471X C CAPACITOR 470pF,50V AB C
C936 NCB21HK-471X C CAPACITOR 470pF,50V AB C
C937 NCB21HK-331X C CAPACITOR 330pF,50V AB C
C938 NCB21HK-331X C CAPACITOR 330pF,50V AB C
C939 NCB21HK-471X C CAPACITOR 470pF,50V AB C

5-15

MODEL MARK
HR-S7960EX A
HR-S7965EF B
HR-S7965EK C

#! REF No. PART No. PART NAME, DESCRIPTION AB C

----- ------- ---------------------- ------------------------------------------ ---------- - - - -

C940 NCB21HK-471X C CAPACITOR 470pF,50V AB C
C941 QEKJ0JM-227Z E CAPACITOR 220µF,6.3V AB C
C942 QEKJ1CM-476Z E CAPACITOR 47µF,16V AB C
C943 QEKJ1CM-107Z E CAPACITOR 100µF,16V AB C
C945 QEKJ1EM-106Z E CAPACITOR 10µF,25V ABC
C946 QEKJ1EM-106Z E CAPACITOR 10µF,25V ABC
C950 QEKJ0JM-227Z E CAPACITOR 220µF,6.3V AB C
C951 QEKC1CM-476Z E CAPACITOR 47µF,16V AB C
C958 NCB21HK-331X C CAPACITOR 330pF,50V AB C
C959 NCB21HK-331X C CAPACITOR 330pF,50V AB C
L501 QQL29BJ-100Z P COIL 10µH AB C
L503 QQL29BJ-100Z P COIL 10µH AB C
L504 QQL29BJ-100Z P COIL 10µH AB C
L505 QUY153-050Y IM BUS WIRE A B C
L901 QQL231J-R22Y INDUCTOR 0.22µH ABC
L902 QQL071J-1R0Y INDUCTOR 1.0µH AB C
L903 QQL071J-150Y INDUCTOR 15µH AB C
L904 QQL071J-150Y INDUCTOR 15µH AB C
L906 QUY153-050Y IM BUS WIRE A B C
L907 QUY153-050Y IM BUS WIRE A B C
L910 QQL071J-1R0Y INDUCTOR 1.0µH AB C
L913 QQL071J-4R7Y INDUCTOR 4.7µH AB C
L914 QQL071J-4R7Y INDUCTOR 4.7µH AB C
L915 QQL071J-4R7Y INDUCTOR 4.7µH AB C
L916 QQL071J-4R7Y INDUCTOR 4.7µH AB C
L917 QQL071J-4R7Y INDUCTOR 4.7µH AB C
L918 QQL071J-4R7Y INDUCTOR 4.7µH AB C
L919 QQL071J-4R7Y INDUCTOR 4.7µH AB C
L920 QQL071J-4R7Y INDUCTOR 4.7µH AB C
J901 PEMC1177 RGB21PIN SOCKET,AV1 A B C
J902 PEMC1177 RGB21PIN SOCKET,AV2 A B C
J904 QND0084-001 S JACK,S OUT ABC
J915 QNN0418-003 PIN JACK,A.OUT(L) AB C
J916 QNN0418-002 PIN JACK,A.OUT(R) AB C
J921 PU60659 MINI JACK,SAT.CTL ABC

! TB1 LP21028-006A TERMINAL BOARD AB C

ET1 LP30918-001A EARTH PLATE,FOR EMC AB C
ET2 LP30915-001A EARTH PLATE AB C
OT1 QYTDSF3008Z TAP SCREW,X6 AB C
CN511 QGF1208F1-11 FPC CONNECTOR,P/S CONV B
CN911 QGB2024J1-10S B TO B CONNECTOR AB C
CN912 QGB2024J1-12S B TO B CONNECTOR AB C
CN913 QGB2024J1-10S B TO B CONNECTOR AB C
CN914 QGB2024J1-11S B TO B CONNECTOR AB C
CN915 QGB2024J1-09S B TO B CONNECTOR AB C
CN916 QGF1208F1-04 FPC CONNECTOR,FRONT S IN AB C

******************************

A/C HEAD BOARD ASSEMBLY<12>

PW1 LPA10158-01A1 A/C HEAD BOARD ASSY AB C

#! REF No. PART No. PART NAME, DESCRIPTION AB C

----- ------- ---------------------- ------------------------------------------ ---------- - - - -

IC6701or MSP3417D-X IC AB C
Q6701 2SC3936/BC/-X TRANSISTOR AB C
D6701 1SS133-T2 SI DIODE AB C
D6701 or 1N4148M-T2 DIODE AB C
R6701 NRSA02J-392X MG RESISTOR 3.9kØ,1/10W AB C
R6702 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W AB C
R6703 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W AB C
R6704 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R6705 NRSA02J-271X MG RESISTOR 270Ø,1/10W AB C
R6707 NQR0200-003X FERRITE BEADS A B C
R6708 NQR0200-003X FERRITE BEADS A B C
R6709 NQR0200-003X FERRITE BEADS A B C
R6710 NQR0200-003X FERRITE BEADS A B C
R6711 NRSA02J-104X MG RESISTOR 100kØ,1/10W A B C
R6712 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R6713 NRSA02J-123X MG RESISTOR 12kØ,1/10W AB C
R6714 NRSA02J-102X MG RESISTOR 1kØ,1/10W AB C
R6715 NRSA02J-123X MG RESISTOR 12kØ,1/10W AB C
R6716 NQR0200-003X FERRITE BEADS A B C
R6719 QRE141J-103Y C RESISTOR 10kØ,1/4W AB C
R6720 NRSA02J-562X MG RESISTOR 5.6kØ,1/10W AB C
R6721 NRSA02J-562X MG RESISTOR 5.6kØ,1/10W AB C
C6701 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C
C6704 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C
C6707 NDC21HJ-470X C CAPACITOR 47pF,50V AB C
C6708 NDC21HJ-7R0X C CAPACITOR 7pF,50V AB C
C6709 NDC21HJ-3R0X C CAPACITOR 3pF,50V AB C
C6713 NCF21CZ-224X C CAPACITOR 0.22µF,16V AB C
C6714 NCB21HK-222X C CAPACITOR 0.0022µF,50V A C
C6714 NCB21HK-682X C CAPACITOR 0.0068µF,50V B
C6715 QEKJ1HM-225Z E CAPACITOR 2.2µF,50V AB C
C6716 NCB21HK-222X C CAPACITOR 0.0022µF,50V A C
C6716 NCB21HK-682X C CAPACITOR 0.0068µF,50V B
C6717 QEKJ1HM-225Z E CAPACITOR 2.2µF,50V AB C
C6719 QEKJ1EM-106Z E CAPACITOR 10µF,25V AB C
C6720 QEKJ1EM-106Z E CAPACITOR 10µF,25V AB C
C6721 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C
C6723 NCB21HK-103X C CAPACITOR 0.01µF,50V AB C
C6724 QEKJ1HM-225Z E CAPACITOR 2.2µF,50V B
L6701 QUY153-050Y IM BUS WIRE AB C
X6701 QAX0443-001 CRYSTAL 18.432MHz AB C
K6701 NRSA02J-330X MG RESISTOR 33Ø,1/10W A B C
K6702 NQR0200-003X FERRITE BEADS ABC
K6703 NRSA02J-103X MG RESISTOR 10kØ,1/10W A C
K6703 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B
K6704 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W ABC
K6705 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W A C
K6705 NRSA02J-100X MG RESISTOR 10Ø,1/10W B
K6706 NRSA02J-470X MG RESISTOR 47Ø,1/10W A B C
K6707 NQR0200-003X FERRITE BEADS,MS ONLY B
BK1 LP40425-001A BRACKET(PWB) A B C
CN6701

QGG2502K1-10 HEADER PIN ABC

******************************

DEMOD BOARD ASSEMBLY<14>

PW1 LPA10094-09A DEMOD BOARD ASSY A C
PW1 LPA10094-10B DEMOD BOARD ASSY B
IC6701 MSP3417GQGB8V3XIC AB C
IC6701or MSP3417G-X IC AB C

5-16

******************************

S JACK BOARD ASSEMBLY<36>

PW1 LPA20009-02B S JACK BOARD ASSY AB C
J7102 QND0084-001 S JACK AB C
CN7108

QGF1209F1-04 FPC CONNECTOR AB C

MODEL MARK
HR-S7960EX A
HR-S7965EF B
HR-S7965EK C

#! REF No. PART No. PART NAME, DESCRIPTION AB C #! REF No. PART No. PART NAME, DESCRIPTION AB C

----- ------- ---------------------- ------------------------------------------ ---------- - - - - ----- ------- ---------------------- ------------------------------------------ ---------- - - - -

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

Q1615 2SD1819A/QRS/-X TRANSISTOR B

******************************

ADV. JOG BOARD ASSEMBLY<39>

PW1 LPA10191-03A ADV JOG BOARD ASSY AB C
R7047 QRE141J-472Y C RESISTOR 4.7kØ,1/4W AB C
UN7001
S7030 QSW0456-002Z TACT SWITCH,24H EXP AB C
CN7004

QSW0938-001 ROTARY ENCODER,400K AB C

QGF1209F1-04 FPC CONNECTOR,1-4 AB C

******************************

LOADING MOTOR BOARD ASSEMBLY<55>

PW2 LPA10158-01A2 LOADING MOTOR BOARD ASSY AB C

******************************

S-P CONVERTER BOARD ASSEMBLY<87>

PW1 LPA10144-06A S-P CONV BOARD ASSY,S->P CONV B
IC1601 BA7046F-XE IC B
IC1602 74HC132D-X IC(DIGITAL) B
IC1603 74HC4538D-X IC B
IC1604 74HC74D-X IC B
IC1605 TDA8395 IC B
IC1606 TDA4665T-X IC B
IC1607 TDA8501T/N1-X IC B
Q1601 2SB1218A/QR/-X TRANSISTOR B
Q1601 or 2SA1576A/QR/-X TRANSISTOR B
Q1601 or 2PA1576/R/-X TRANSISTOR B
Q1604 2SD1819A/QRS/-X TRANSISTOR B
Q1604 or 2SC4081/QRS/-X TRANSISTOR B
Q1604 or 2PC4081/R/-X TRANSISTOR B
Q1605 2SB1218A/QR/-X TRANSISTOR B
Q1605 or 2SA1576A/QR/-X TRANSISTOR B
Q1605 or 2PA1576/R/-X TRANSISTOR B
Q1606 2SC1740S/QRS/-T TRANSISTOR B
Q1607 2SD1819A/QRS/-X TRANSISTOR B
Q1607 or 2SC4081/QRS/-X TRANSISTOR B
Q1607 or 2PC4081/R/-X TRANSISTOR B
Q1608 2SB1218A/QR/-X TRANSISTOR B
Q1608 or 2SA1576A/QR/-X TRANSISTOR B
Q1608 or 2PA1576/R/-X TRANSISTOR B
Q1609 2SD1819A/QRS/-X TRANSISTOR B
Q1609 or 2SC4081/QRS/-X TRANSISTOR B
Q1609 or 2PC4081/R/-X TRANSISTOR B
Q1610 2SD1819A/QRS/-X TRANSISTOR B
Q1610 or 2SC4081/QRS/-X TRANSISTOR B
Q1610 or 2PC4081/R/-X TRANSISTOR B
Q1611 2SB1218A/QR/-X TRANSISTOR B
Q1611 or 2SA1576A/QR/-X TRANSISTOR B
Q1611 or 2PA1576/R/-X TRANSISTOR B
Q1612 2SD1819A/QRS/-X TRANSISTOR B
Q1612 or 2SC4081/QRS/-X TRANSISTOR B
Q1612 or 2PC4081/R/-X TRANSISTOR B
Q1613 2SC4083/NP/-X TRANSISTOR B
Q1614 2SB1218A/QR/-X TRANSISTOR B
Q1614 or 2SA1576A/QR/-X TRANSISTOR B
Q1614 or 2PA1576/R/-X TRANSISTOR B

[FOR HR-S7965EF]

Q1615 or 2SC4081/QRS/-X TRANSISTOR B
Q1615 or 2PC4081/R/-X TRANSISTOR B
Q1616 2SD1819A/QRS/-X TRANSISTOR B
Q1616 or 2SC4081/QRS/-X TRANSISTOR B
Q1616 or 2PC4081/R/-X TRANSISTOR B
Q1617 2SB1218A/QR/-X TRANSISTOR B
Q1617 or 2SA1576A/QR/-X TRANSISTOR B
Q1617 or 2PA1576/R/-X TRANSISTOR B
Q1619 DTA143TUA-X DIGI TRANSISTOR B
D1601 1SS133-T2 SI DIODE B
R1601 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W B
R1608 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W B
R1609 NRSA02J-102X MG RESISTOR 1kØ,1/10W B
R1610 NRSA02J-102X MG RESISTOR 1kØ,1/10W B
R1611 NRSA02J-272X MG RESISTOR 2.7kØ,1/10W B
R1612 NRSA02J-103X MG RESISTOR 10kØ,1/10W B
R1615 NRSA02J-331X MG RESISTOR 330Ø,1/10W B
R1616 NRSA02J-474X MG RESISTOR 470kØ,1/10W B
R1617 NRSA02J-474X MG RESISTOR 470kØ,1/10W B
R1618 NRSA02J-103X MG RESISTOR 10kØ,1/10W B
R1619 NRSA02J-134X MG RESISTOR 130kØ,1/10W B
R1620 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W B
R1621 QRE141J-103Y C RESISTOR 10kØ,1/4W B
R1622 QRE141J-103Y C RESISTOR 10kØ,1/4W B
R1623 NRSA02J-123X MG RESISTOR 12kØ,1/10W B
R1624 NRSA02J-124X MG RESISTOR 120kØ,1/10W B
R1631 NRSA02J-561X MG RESISTOR 560Ø,1/10W B
R1632 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W B
R1633 NRSA02J-223X MG RESISTOR 22kØ,1/10W B
R1635 NRSA02J-122X MG RESISTOR 1.2kØ,1/10W B
R1636 NRSA02J-102X MG RESISTOR 1kØ,1/10W B
R1637 NRSA02J-681X MG RESISTOR 680Ø,1/10W B
R1638 NRSA02J-101X MG RESISTOR 100Ø,1/10W B
R1639 NRSA02J-331X MG RESISTOR 330Ø,1/10W B
R1640 NRSA02J-122X MG RESISTOR 1.2kØ,1/10W B
R1641 NRSA02J-102X MG RESISTOR 1kØ,1/10W B
R1642 NRSA02J-681X MG RESISTOR 680Ø,1/10W B
R1643 NRSA02J-101X MG RESISTOR 100Ø,1/10W B
R1644 NRSA02J-331X MG RESISTOR 330Ø,1/10W B
R1645 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W B
R1646 NRSA02J-104X MG RESISTOR 100kØ,1/10W B
R1647 NRSA02J-152X MG RESISTOR 1.5kØ,1/10W B
R1648 NRSA02J-102X MG RESISTOR 1kØ,1/10W B
R1651 NRSA02J-123X MG RESISTOR 12kØ,1/10W B
R1652 NRSA02J-102X MG RESISTOR 1kØ,1/10W B
R1653 NRSA02J-184X MG RESISTOR 180kØ,1/10W B
R1654 NRSA02J-561X MG RESISTOR 560Ø,1/10W B
R1655 NRSA02J-102X MG RESISTOR 1kØ,1/10W B
R1656 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W B
R1657 NRSA02J-561X MG RESISTOR 560Ø,1/10W B
R1658 NRSA02J-102X MG RESISTOR 1kØ,1/10W B
R1659 NRSA02J-681X MG RESISTOR 680Ø,1/10W B
R1660 NRSA02J-273X MG RESISTOR 27kØ,1/10W B
R1661 NRSA02J-333X MG RESISTOR 33kØ,1/10W B
VR1601
VR1602
VR1603
B1601 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B
B1602 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B
B1603 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B

QVP0039-471Z TRIM RESISTOR B
QVP0039-471Z TRIM RESISTOR B
QVP0039-104Z TRIM RESISTOR B

5-17

MODEL MARK
HR-S7960EX A
HR-S7965EF B
HR-S7965EK C

#! REF No. PART No. PART NAME, DESCRIPTION AB C

----- ------- ---------------------- ------------------------------------------ ---------- - - - -

B1607 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B
B1608 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B
C1601 QEKJ1CM-476Z E CAPACITOR 47µF,16V B
C1602 NCB21HK-103X C CAPACITOR 0.01µF,50V B
C1605 QEKJ1HM-105Z E CAPACITOR 1µF,50V B
C1606 NCB21HK-102X C CAPACITOR 0.001µF,50V B
C1607 NCB21HK-103X C CAPACITOR 0.01µF,50V B
C1608 QEKJ0JM-476Z E CAPACITOR 47µF,6.3V B
C1609 NCB21HK-222X C CAPACITOR 0.0022µF,50V B
C1610 QEKJ1HM-105Z E CAPACITOR 1µF,50V B
C1611 NDC21HJ-101X C CAPACITOR 100pF,50V B
C1612 NCB21EK-104X C CAPACITOR 0.1µF,25V B
C1613 NCB21EK-104X C CAPACITOR 0.1µF,25V B
C1614 NDC21HJ-471X C CAPACITOR 470pF,50V B
C1615 NDC21HJ-561X C CAPACITOR 560pF,50V B
C1616 NCB21EK-104X C CAPACITOR 0.1µF,25V B
C1631 QEKJ1CM-476Z E CAPACITOR 47µF,16V B
C1632 QEKJ1CM-476Z E CAPACITOR 47µF,16V B
C1633 NCB21HK-103X C CAPACITOR 0.01µF,50V B
C1634 NDC21HJ-101X C CAPACITOR 100pF,50V B
C1635 NCB21EK-104X C CAPACITOR 0.1µF,25V B
C1636 NCB21CK-224X C CAPACITOR 0.22µF,16V B
C1637 NCB21HK-103X C CAPACITOR 0.01µF,50V B
C1638 QEKJ0JM-476Z E CAPACITOR 47µF,6.3V B
C1639 NCB21HK-103X C CAPACITOR 0.01µF,50V B
C1640 QEKJ0JM-476Z E CAPACITOR 47µF,6.3V B
C1641 NCB21HK-103X C CAPACITOR 0.01µF,50V B
C1642 NCB21HK-103X C CAPACITOR 0.01µF,50V B
C1643 NCB21HK-103X C CAPACITOR 0.01µF,50V B
C1644 NCB21HK-103X C CAPACITOR 0.01µF,50V B
C1645 QEKJ1HM-105Z E CAPACITOR 1µF,50V B
C1646 QEKJ1HM-105Z E CAPACITOR 1µF,50V B
C1647 NCB21CK-224X C CAPACITOR 0.22µF,16V B
C1648 QEKJ0JM-476Z E CAPACITOR 47µF,6.3V B
C1649 NCB21HK-103X C CAPACITOR 0.01µF,50V B
C1650 NCB21CK-224X C CAPACITOR 0.22µF,16V B
C1651 NCB21EK-223X C CAPACITOR 0.022µF,25V B
C1652 NDC21HJ-120X C CAPACITOR 12pF,50V B
C1653 NCB21CK-224X C CAPACITOR 0.22µF,16V B
C1654 NCB21HK-103X C CAPACITOR 0.01µF,50V B
C1655 QEKJ0JM-476Z E CAPACITOR 47µF,6.3V B
C1656 NCB21HK-103X C CAPACITOR 0.01µF,50V B
L1601 QQL29BJ-100Z P COIL 10µH B
L1602 QQL29BJ-100Z P COIL 10µH B
L1603 QQL29BJ-100Z P COIL 10µH B
L1604 QQL29BJ-100Z P COIL 10µH B
FL1601 QQR1187-001 EQ B
FL1602 QQR1187-001 EQ B
X1601 QAX0613-001Z CR YSTAL 4.433619MHz B
BK1 LP30950-001A BRACKET(1) B
BK2 LP30951-001A BRACKET(2) B
OT1 PU59915-105 #500SPACER0.01,FOR X1601 B
CN1601

QGF1208F1-11 FPC CONNECTOR B

#! REF No. PART No. PART NAME, DESCRIPTION AB C

----- ------- ---------------------- ------------------------------------------ ---------- - - - -

5-18

E. & O.E. No.82975 HR-S7960EX, HR-S7965EF, HR-S7965EK (VP)-V16S2
