John Deere 5045E, MY2015 User Manual

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

(MY2015) 5045E Utility Tractor (37 PTO hp)

Equipment for Base Machine

ENGINE:

45.7 (33.6 kW) 97/68/EC Engine Horsepower @ 2100* RPM 37 (27.3 kW) PTO Horsepower @ 2100 RPM 3 Cylinder Turbocharged John Deere PowerTech Diesel Engine 179 C.I.D. (2.9L) EPA Final Tier 4 Compliant Dry Type Air Cleaner with Safety Element Underhood Muffler with Vertical Exhaust Stack Anti-Freeze Hand and Foot Throttles Key Engine Shutoff Fan Finger Guard Heavy Duty Air Intake Pre-Heater Fuel Cooler

TRANSMISSION: 9F/3R SyncShuttle Synchronized Speed Shifts, Integrated Park Position Right Hand Shifted Speeds Left Hand Shifted Ranges Differential Lock Neutral Start Safety Switch

REAR AXLE: Flanged Rear Axle Planetary Final Drives

STEERING AND BRAKES: Hydrostatic Power Steering Hydraulically Actuated Wet Disk Brakes Self-Equalizing and Self-Adjusting

HYDRAULICS: Open Center Hydraulic System Tandem Gear Pump 18.2 GPM (68.9 LPM) Maximum Total Flow Steering Pump 6.8 GPM (25.7 LPM) Implement Pump 11.4 GPM (43.1 LPM) One Rear Selective Control Valve

POWER TAKE-OFF SHAFT: Independent "Live" 540 RPM Rear PTO Shaft Operator Presence Safety Warning - PTO Safety Start Switch

ROCKSHAFT, HITCH AND DRAWBAR: Rear Rockshaft with Position Control,

Draft Control, and Adjustable Rate of Drop

3-Point (Category II) Hitch

with Sway Chains -

Convertible to Category I

Adjustable Drawbar INSTRUMENTATION:

Electric Fuel Gauge Tachometer/Hour Meter Oil Pressure Indicator Light Coolant Temperature Gauge Alternator Indicator Light Air Restriction Indicator Light Turn Signal Indicator Light High Beam Light PTO Engagement Light

ELECTRICAL: 12-Volt Electrical System One Battery - 623 CCA** with 145 Minute Reserve Capacity 40 Amp Alternator One Rear Work Light

LIGHTS: Two Front Halogen Headlights Two Turn/Flashing Warning Lights Two Tail Lights

MISCELLANEOUS: SMV Emblem Tilt-Up Hood Toolbox

BASE MACHINE: 2-Post Foldable Roll-Over Protective

Structure (ROPS)

Deluxe Adjustable Vinyl Seat with

Retractable Seat Belt 18 U.S. Gallon (68 L) Fuel Tank Capacity Adjustable Front Axle (56-80 In.) 8-Position Steel Rear Wheels with Two Rear Tires 13.6-28 6PR (R1) 2-Position Steel Front Wheels with Two Front Tires 7.50-16 6PR (F2)

* Manufacturer's Rating ** Cold Cranking Amps

SUGGESTED

LIST PRICE

USD ($)

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

Select One Code From Each Required Category

BASE MACHINE

1724LV (MY2015) 5045E Utility Tractor (37PTO hp) 19,697.00

OPERATORS MANUAL

0409 English Operators Manual and Decal Kit In Base Price

0413 French Operators Manual and Decal Kit Same Price

03 December 2014 US & Canada

2-TRACTOR- 1

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

(MY2015) 5045E Utility Tractor (37 PTO hp)

Continued

SUGGESTED

LIST PRICE

USD ($)

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

OPERATORS MANUAL ...Continued...

0437 Spanish Operators Manual and Decal Kit Same Price

TRANSMISSION

1363 9F/3R SyncShuttle Transmission (TSS)

9F/3R Full Top Shaft Synchronized [TSS] Synchronized Speed Shifts Integrated Park Position

In Base Price

OPERATOR STATION

2000 Open Operator Station

Fixed Open Operator Station 2 Post Foldable Roll-Over Protection Structure (ROPS) Beverage Holder Single Rear Work Light 18 Gallon Fuel Tank

In Base Price

MID SELECTIVE CONTROL VALVES

3400 Less Mid Valves

Recommended for applications WITHOUT front loaders. Can later be upgraded for front loader and/or other hydraulic applications using field-installed attachments. Requires Code 6020 - 2WD.

In Base Price

3420 Dual Mid Valves with Joystick Control

Recommended for applications WITH front loaders. Requires Code 6040 - MFWD.

1,162.00

DRAFT LINKS

4115 Fixed Draft Links In Base Price

4120 Telescopic Draft Links 518.00

REAR WHEELS WITH TIRES (TWO)

5101 14.9-28 In. 6PR R1 Bias

Code 6020 requires Code 6102. Code 6040 requires Code 6101.

5103 22.5LL-16.1 In. 6PR R3 (Turf Special) Bias

Requires Code 6103.

5113 21.5L-16.1 In. 6PR R3 Bias

Code 6020 requires Code 6103. Code 6040 requires Code 6171.

5115 13.6-28 In. 6PR R1 Bias

Code 6020 requires Code 6102. Code 6040 requires Code 6101.

5184 16.9-24 In. 6PR R4 Bias

Code 6020 requires Code 6113. Code 6040 requires Code 6133.

45.00

1,078.00

-320.00

In Base Price

-61.00

03 December 2014 US & Canada

2-TRACTOR- 2

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

(MY2015) 5045E Utility Tractor (37 PTO hp)

Continued

SUGGESTED

LIST PRICE

USD ($)

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

REAR WHEELS WITH TIRES (TWO) ...Continued...

5185 16.9-28 In. 6PR R1 Bias

Code 6020 requires Code 6102. Code 6040 requires Code 6101.

301.00

FRONT AXLE

6020 2 Wheel Drive

Requires Code 1363.

6040 MFWD (4 Wheel Drive)

Mechanical Engagement. Engagement Indicator Light on PowrReverser Transmission. Requires Code 3420.

In Base Price

5,296.00

FRONT WHEELS WITH TIRES (TWO)

6102 7.50-16 In. 6PR F2 Bias In Base Price

6103 27/12LL-15 In. 6PR Turf Special Bias 486.00

FOR OPTION CODE 6020 (2WD):

6113 11L-15 In. 8PR F3 (Truck Type) Bias 114.00

6101 9.5-24 In. 6PR R1 Bias 1,052.00

6133 12.5/80-18 In. 6PR I3(R4 Type) Bias 728.00

6171 9.5-16 In. 6PR R3 Bias 396.00

FOR OPTION CODE 6040 (MFWD):

ATTACHMENTS FOR FIELD CONVERSION

L154683 Rear Axle 1.2 In. Extension (30 mm)

L154682 Rear Axle 1.6 In. Extension (40 mm)

L154684 Rear Axle 4.4 In. Extension (111 mm)

LV150155 Engine Coolant Heater Kit (3 Cyl.) 96.80

Axle - Rear:

See Parts

Two required. Requires (16) 19M9364 Cap Screws (8 per Extension), ordered separately.

See Parts

Two required. Requires (16) 19M8979 Cap Screws (8 per Extension), ordered separately.

See Parts

Two required. Requires (16) 19M9365 Cap Screws (8 per Extension), ordered separately.

Engine:

03 December 2014 US & Canada

2-TRACTOR- 3

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

(MY2015) 5045E Utility Tractor (37 PTO hp)

Continued

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

SUGGESTED

LIST PRICE

USD ($)

ATTACHMENTS FOR FIELD CONVERSION ...Continued...

T12553 Center Link Conversion Bushing, Cat. II to Cat. I

R66432 Draft Link Conversion Bushing, Cat. II to Cat. I

R133359 Drawbar - Offset See Parts

RE39830 Drawbar Clevis Kit (Hammer Strap) - Offset Drawbar See Parts

RE39829 Drawbar Clevis Kit (Hammer Strap) - Straight Drawbar See Parts

TY16042 Quik-Coupler, Economy, Category 2 See Parts

SJ11072 Left Hand Telescopic Draft Link See Parts

SJ11073 Right Hand Telescopic Draft Link See Parts

LVB25976 iMatch Quick Hitch Category 1 with adjustable top hook

Hitch and Drawbar:

See Parts

One required.

See Parts

Two required.

Hitch:

357.50

Includes one set of Bushings (LVU15507).

LVB25771 Second Rear SCV with Detented Float and Lever Control

BLV10431 Second Rear SCV with Detented Float and Lever Control

LVB25547 Auxiliary Rear Work Light Kit (1 Light)

LVB25727 PowrReverser Modulation Control Kit 147.40

LVB25926 Single Horn Kit

LVB25785 Canopy - Deluxe

LVB25334 Canopy - Standard

Hydraulics:

805.20

For 9x3 TSS Open Station Tractors.

805.20

For 12x12 PR Open Station Tractors.

Lighting:

63.80

Open Station Only.

Miscellaneous:

51.70

OOS tractors only

Operator Environment:

961.40

Requires LVB25332 Canopy Mounting Bracket and Hardware Kit ordered separately.Open Station Tractors Only.

583.00

Requires LVB25332 Canopy Mounting Bracket and Hardware Kit ordered separately. Open Station Tractors Only.

03 December 2014 US & Canada

2-TRACTOR- 4

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

(MY2015) 5045E Utility Tractor (37 PTO hp)

Continued

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

ATTACHMENTS FOR FIELD CONVERSION ...Continued...

LVB25332 Canopy Mounting Bracket and Hardware Kit

Requires LVB25334 or LVB25785 Canopy Kit ordered separately. Open Station Tractors Only.

Weights:

R213907 Weight, Rear Wheel - 95 Lb.

Not compatible on wheels sized 24" or smaller. Maximum of 2 per wheel.

SUGGESTED

LIST PRICE

USD ($)

105.60

222.20

03 December 2014 US & Canada

2-TRACTOR- 5

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

(MY2015) 5045E Utility Tractor (37 PTO hp)

Continued

THIS PAGE IS INTENTIONALLY LEFT BLANK

03 December 2014 US & Canada

2-TRACTOR- 6

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

(MY2015) 5055E Utility Tractor (41-45 PTO hp)

Equipment for Base Machine

ENGINE: 57 (42.0 kW) 97/68/EC Engine Horsepower @ 2100* RPM 45 (33.1 kW) PTO Horsepower @ 2100 ERPM (Open Station) 41 (30.1 kW) PTO Horsepower @ 2100 ERPM (Cab) 3 Cylinder Turbocharged John Deere PowerTech Diesel Engine 179 C.I.D. (2.9L) EPA Final Tier 4 Compliant Dry Type Air Cleaner with Safety Element Underhood Muffler with Vertical Exhaust Stack Anti-Freeze Hand and Foot Throttles Key Engine Shutoff Fan Finger Guard Heavy Duty Air Intake Pre-Heater Fuel Cooler

TRANSMISSION: 9F/3R TSS 9F/3R SyncShuttle Synchronized Speed Shifts, Integrated Park Position Right Hand Shifted Speeds Left Hand Shifted Ranges Differential Lock Neutral Start Safety Switch

REAR AXLE: Flanged Rear Axle Planetary Final Drives

STEERING AND BRAKES: Hydrostatic Power Steering Hydraulically Actuated Wet Disk Brakes Self-Equalizing and Self-Adjusting

HYDRAULICS: Open Center Hydraulic System Tandem Gear Pump 18.2 GPM (68.9 LPM) Maximum Total Flow Steering Pump 6.8 GPM (25.7 LPM) Implement Pump 11.4 GPM (43.1 LPM) 2 One Rear Selective Control Valve

POWER TAKE-OFF SHAFT: 9x3 TSSTransmission Independent "Live" 540 RPM Rear PTO Shaft Operator Presence Safety Warning - PTO Flip Up PTO Shield Safety Start Switch ROCKSHAFT, HITCH AND DRAWBAR: Rear Rockshaft with Position Control,

Draft Control, and Adjustable Rate of Drop

3-Point (Category II) Hitch

with Sway Chains -

Convertible to Category I Adjustable Drawbar

ELECTRICAL: Open Station 12-Volt Electrical System One Battery - 623 CCA** with

145 Minute Reserve Capacity 40 Amp Alternator LIGHTS: Two Front Halogen Headlights Two Turn/Flashing Warning Lights Two Tail Lights One Rear Work Light (Open Station)

MISCELLANEOUS: SMV Emblem Tilt-Up Hood Toolbox

BASE MACHINE: Open Station 2-Post Foldable Roll-Over Protective

Structure (ROPS) Deluxe Adjustable Vinyl Seat with

Retractable Seat Belt 18 U.S. Gallon (68 L) Fuel Tank Capacity Adjustable Front Axle (56-80 In.) 8-Position Steel Rear Wheels with

Two Rear Tires 14.9-28 6PR (R1) 2-Position Steel Front Wheels with

Two Front Tires 7.50-16 6PR (F2)

* Manufacturer's Rating ** Cold Cranking Amps

SUGGESTED

LIST PRICE

USD ($)

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

Select One Code From Each Required Category

BASE MACHINE

1734LV (MY2015) 5055E Utility Tractor (41-45 PTO hp) 22,097.00

OPERATORS MANUAL

0409 English Operators Manual and Decal Kit In Base Price

0413 French Operators Manual and Decal Kit Same Price

03 December 2014 US & Canada

2-TRACTOR- 1

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

(MY2015) 5055E Utility Tractor (41-45 PTO hp)

Continued

SUGGESTED

LIST PRICE

USD ($)

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

OPERATORS MANUAL ...Continued...

0437 Spanish Operators Manual and Decal Kit Same Price

TRANSMISSION

1363 9F/3R SyncShuttle Transmission (TSS)

9F/3R Full Top Shaft Synchronized [TSS] Synchronized Speed Shifts Integrated Park Position Code 1363 with Code 2050 - Standard Cab is available only on 5055E (Base Code 1734LV)

1381 12F/12R PowrReverser Transmission - 540/540E (PR)

Electrohydraulic (EH) Directional Reverser Wet Traction Clutch Wet PTO Clutch Neutral Start Safety Switch Electrohydraulic (EH) PTO engagement Economy-PTO/Standard PTO MFWD indicator light Digital hour meter indicator Digital ground speed indicator Digital PTO speed indicator Requires Code 6040 - MFWD.

In Base Price

2,160.00

OPERATOR STATION

2000 Open Operator Station

Fixed Open Operator Station 2 Post Foldable Roll-Over Protection Structure (ROPS) Beverage Holder Single Rear Work Light 18 Gallon Fuel Tank

In Base Price

2050 Cab

Left Side Door Air Conditioning Cup Holders Radio/CD Ready (Antenna Cable,Two Speakers, and Wiring Harness) Front Windshield Wiper Mechanical Suspension Seat

21.6 Gallon Fuel Tank Requires Code 6040 MFWD. Requires Code 4120 Telescopic Draft Link.

7,488.00

MID SELECTIVE CONTROL VALVES

3400 Less Mid Valves

Recommended for applications WITHOUT front loaders. Can later be upgraded for front loader and/or other hydraulic applications using field-installed attachments. Requires Code 6020 - 2WD.

3420 Dual Mid Valves with Joystick Control

Recommended for applications WITH front loaders. Requires Code 6040 - MFWD.

In Base Price

1,162.00

DRAFT LINKS

4115 Fixed Draft Links In Base Price

03 December 2014 US & Canada

2-TRACTOR- 2

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

(MY2015) 5055E Utility Tractor (41-45 PTO hp)

Continued

SUGGESTED

LIST PRICE

USD ($)

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

DRAFT LINKS ...Continued...

4120 Telescopic Draft Links 518.00

REAR WHEELS WITH TIRES (TWO)

5101 14.9-28 In. 6PR R1 Bias

Code 6020 requires Code 6102. Code 6040 requires Code 6101.

5103 22.5LL-16.1 In. 6PR R3 (Turf Special) Bias

Requires Code 6103.

5113 21.5L-16.1 In. 6PR R3 Bias

Code 6020 requires Code 6103. Code 6040 requires Code 6171.

5184 16.9-24 In. 6PR R4 Bias

Code 6020 requires Code 6113. Code 6040 requires Code 6133.

5185 16.9-28 In. 6PR R1 Bias

Code 6020 requires Code 6102. Code 6040 requires Code 6101.

In Base Price

1,033.00

-365.00

-106.00

256.00

FRONT AXLE

6020 2 Wheel Drive

Requires Code 1363.

6040 MFWD (4 Wheel Drive)

Mechanical Engagement. Engagement Indicator Light on PowrReverser Transmission. Requires Code 3420.

In Base Price

5,296.00

FRONT WHEELS WITH TIRES (TWO)

6102 7.50-16 In. 6PR F2 Bias

6103 27/12LL-15 In. 6PR Turf Special Bias

6113 11L-15 In. 8PR F3 (Truck Type) Bias

6101 9.5-24 In. 6PR R1 Bias 1,052.00

6133 12.5/80-18 In. 6PR I3(R4 Type) Bias 728.00

6171 9.5-16 In. 6PR R3 Bias 396.00

FOR OPTION CODE 6020 (2WD):

In Base Price

Requires Code 2000 - Open Operator Station.

486.00

Requires Code 2000 - Open Operator Station.

114.00

Requires Code 2000 - Open Operator Station.

FOR OPTION CODE 6040 (MFWD):

03 December 2014 US & Canada

2-TRACTOR- 3

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

(MY2015) 5055E Utility Tractor (41-45 PTO hp)

Continued

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

SUGGESTED

LIST PRICE

USD ($)

ATTACHMENTS FOR FIELD CONVERSION

L154683 Rear Axle 1.2 In. Extension (30 mm)

L154682 Rear Axle 1.6 In. Extension (40 mm)

L154684 Rear Axle 4.4 In. Extension (111 mm)

LV150155 Engine Coolant Heater Kit (3 Cyl.) 96.80

LVB25714 Rear Fender Extension Kit

T12553 Center Link Conversion Bushing, Cat. II to Cat. I

Axle - Rear:

See Parts

Two required. Requires (16) 19M9364 Cap Screws (8 per Extension), ordered separately.

See Parts

Two required. Requires (16) 19M8979 Cap Screws (8 per Extension), ordered separately.

See Parts

Two required. Requires (16) 19M9365 Cap Screws (8 per Extension), ordered separately.

Engine:

Fenders:

209.00

Cab Tractors only.

Hitch and Drawbar:

See Parts

One required.

R66432 Draft Link Conversion Bushing, Cat. II to Cat. I

Two required.

R133359 Drawbar - Offset See Parts

RE39830 Drawbar Clevis Kit (Hammer Strap) - Offset Drawbar See Parts

RE39829 Drawbar Clevis Kit (Hammer Strap) - Straight Drawbar See Parts

TY16042 Quik-Coupler, Economy, Category 2 See Parts

Hitch:

SJ11072 Left Hand Telescopic Draft Link See Parts

SJ11073 Right Hand Telescopic Draft Link See Parts

LVB25976 iMatch Quick Hitch Category 1 with adjustable top hook

Includes one set of Bushings (LVU15507).

Hydraulics:

LVB25771 Second Rear SCV with Detented Float and Lever Control

For 9x3 TSS Open Station Tractors.

BLV10348 Second Rear SCV with Detented Float and Lever Control

Compatible with 5E Cab Tractors.

See Parts

357.50

805.20

03 December 2014 US & Canada

2-TRACTOR- 4

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

(MY2015) 5055E Utility Tractor (41-45 PTO hp)

Continued

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

SUGGESTED

LIST PRICE

USD ($)

ATTACHMENTS FOR FIELD CONVERSION ...Continued...

BLV10431 Second Rear SCV with Detented Float and Lever Control

For 12x12 PR Open Station Tractors.

Lighting:

LVB25547 Auxiliary Rear Work Light Kit (1 Light)

Open Station Only.

Miscellaneous:

LVB25728 Backup Alarm Kit

Compatible with 5E 3-Cyl Cab tractors and PR Open Station Tractors.

LVB25727 PowrReverser Modulation Control Kit 147.40

LVB25926 Single Horn Kit

OOS tractors only

LVB26096 Single Horn Kit

CAB tractors only

Operator Environment:

SJ10170 Antenna

Cab only

805.20

63.80

161.70

51.70

See Parts

AH104259 Ash Tray

Cab only.

LVB25785 Canopy - Deluxe

Requires LVB25332 Canopy Mounting Bracket and Hardware Kit ordered separately.Open Station Tractors Only.

LVB25334 Canopy - Standard

Requires LVB25332 Canopy Mounting Bracket and Hardware Kit ordered separately. Open Station Tractors Only.

LVB25332 Canopy Mounting Bracket and Hardware Kit

Requires LVB25334 or LVB25785 Canopy Kit ordered separately. Open Station Tractors Only.

AR60937 Cigarette Lighter

Cab only.

RE244177 Kit, Rear View Mirror Mounting Kit

Cab only. Requires AL80127 and/or AL80126Kit contains support plates and hardware for one rear view mirror.

AL80126 Mirror, Telescopic, LH, Manually Adjustable

Cab only.

AL80127 Mirror, Telescopic, RH, Manually Adjustable

Cab only.

BLV10350 Right Hand Door

Cab Only

See Parts

961.40

583.00

105.60

See Parts

171.60

291.50

03 December 2014 US & Canada

2-TRACTOR- 5

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

(MY2015) 5055E Utility Tractor (41-45 PTO hp)

Continued

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

ATTACHMENTS FOR FIELD CONVERSION ...Continued...

BLV10173 Wiper/Washer, Rear

Cab only.

Weights:

R213907 Weight, Rear Wheel - 95 Lb.

Not compatible on wheels sized 24" or smaller. Maximum of 2 per wheel.

SUGGESTED

LIST PRICE

USD ($)

343.20

222.20

03 December 2014 US & Canada

2-TRACTOR- 6

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

(MY2015) 5065E Utility Tractor (49-53 PTO hp)

Equipment for Base Machine

ENGINE: 65 (48 kW) 97/68/EC Engine Horsepower @ 2100 RPM* 53 (39.0 kW) PTO Horsepower @ 2100 RPM* (Open Station) 49 (36.0 kW) PTO Horsepower @ 2100 RPM* (Cab) 3 Cylinder Turbocharged John Deere PowerTech Diesel Engine 179 C.I.D. (2.9L) EPA Final Tier 4 Compliant Dry Type Air Cleaner with Safety Element Underhood Muffler with Vertical Exhaust Stack Anti-Freeze Hand and Foot Throttles Key Engine Shutoff Fan Finger Guard Heavy Duty Air Intake Pre-Heater Fuel Cooler

TRANSMISSION: 9F/3R TSS 9F/3R SyncShuttle

Synchronized Speed Shifts, Integrated Park

Position Right Hand Shifted Speeds Left Hand Shifted Ranges Differential Lock Neutral Start Safety Switch

REAR AXLE: Flanged Rear Axle Planetary Final Drives

STEERING AND BRAKES: Hydrostatic Power Steering Hydraulically Actuated Wet Disk Brakes Self-Equalizing and Self-Adjusting

HYDRAULICS: Open Center Hydraulic System Tandem Gear Pump 18.2 GPM (68.8 LPM) Maximum Total Flow

Steering Pump 6.8 GPM (25.7 LPM)

Implement Pump 11.4 GPM (43.1 LPM) One Rear Selective Control Valve

POWER TAKE-OFF SHAFT: 9x3 TSS Transmission Independent "Live" 540 RPM Rear PTO Shaft Operator Presence Safety Warning - PTO Safety Start Switch Flip Up PTO Shield

ROCKSHAFT, HITCH AND DRAWBAR: Rear Rockshaft with Position Control, Draft Control, and Adjustable Rate of Drop 3-Point (Category II) Hitch

with Sway Chains Convertible to Category I Interchangeable Hitch Balls Adjustable Drawbar

INSTRUMENTATION: Electric Fuel Gauge Tachometer/Hour Meter Oil Pressure Indicator Light Coolant Temperature Gauge Alternator Indicator Light Air Restriction Indicator Light Turn Signal Indicator Light High Beam Light PTO Engagement Light Digital Display - Hour Meter ELECTRICAL: Open Station 12-Volt Electrical System One Battery - 623 CCA** with 145 Minute Reserve Capacity 40 Amp Alternator

LIGHTS: Two Front Halogen Headlights Two Turn/Flashing Warning Lights Two Tail Lights One Rear Work Light (Open Station)

MISCELLANEOUS: SMV Emblem Tilt-Up Hood Fender Mounted Toolbox

BASE MACHINE: Open Station 2-Post Foldable Roll-Over Protective

Structure (ROPS)

Deluxe Adjustable Vinyl Seat with

Retractable Seat Belt 18 U.S. Gallon (68 L) Fuel Tank Capacity Adjustable Front Axle (56-80 In.) 8-Position Steel Rear Wheels with

Two Rear Tires 16.9-28 6PR (R1) 2-Position Steel Front Wheels with

Two Front Tires 7.50-16 6PR (F2)

* Manufacturer's Rating ** Cold Cranking Amps

SUGGESTED

LIST PRICE

USD ($)

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

Select One Code From Each Required Category

BASE MACHINE

1744LV (MY2015) 5065E Utility Tractor (49-53 PTO hp) 24,708.00

OPERATORS MANUAL

0409 English Operators Manual and Decal Kit In Base Price

03 December 2014 US & Canada

2-TRACTOR- 1

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

(MY2015) 5065E Utility Tractor (49-53 PTO hp)

Continued

SUGGESTED

LIST PRICE

USD ($)

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

OPERATORS MANUAL ...Continued...

0413 French Operators Manual and Decal Kit Same Price

0437 Spanish Operators Manual and Decal Kit Same Price

TRANSMISSION

1363 9F/3R SyncShuttle Transmission (TSS)

9F/3R Full Top Shaft Synchronized [TSS] Synchronized Speed Shifts Integrated Park Position Code 1363 with Code 2050 - Standard Cab is NOT available on 5065E (Base Code 1744LV) and 5075E (Base Code 1754LV)

1381 12F/12R PowrReverser Transmission - 540/540E (PR)

In Base Price

2,160.00

OPERATOR STATION

2000 Open Operator Station

Fixed Open Operator Station 2 Post Foldable Roll-Over Protection Structure (ROPS) Beverage Holder Single Rear Work Light 18 Gallon Fuel Tank

2050 Cab

Left Side Door Air Conditioning Cup Holders Radio/CD Ready (Antenna Cable,Two Speakers, and Wiring Harness) Front Windshield Wiper Mechanical Suspension Seat

21.6 Gallon Fuel Tank Requires Code 6040 MFWD. Requires Code 4120 Telescopic Draft Link.

MID SELECTIVE CONTROL VALVES

3400 Less Mid Valves

Recommended for applications WITHOUT front loaders. Can later be upgraded for front loader and/or other hydraulic applications using field-installed attachments. Requires Code 6020 - 2WD.

3420 Dual Mid Valves with Joystick Control

Recommended for applications WITH front loaders. Requires Code 6040 - MFWD.

In Base Price

7,488.00

In Base Price

1,162.00

03 December 2014 US & Canada

2-TRACTOR- 2

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

(MY2015) 5065E Utility Tractor (49-53 PTO hp)

Continued

SUGGESTED

LIST PRICE

USD ($)

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

DRAFT LINKS

4115 Fixed Draft Links In Base Price

4120 Telescopic Draft Links 518.00

REAR WHEELS WITH TIRES (TWO)

5103 22.5LL-16.1 In. 6PR R3 (Turf Special) Bias

Requires Code 6103.

5113 21.5L-16.1 In. 6PR R3 Bias

Code 6020 requires Code 6103. Code 6040 requires Code 6171.

5184 16.9-24 In. 6PR R4 Bias

Code 6040 requires Code 6133.

5185 16.9-28 In. 6PR R1 Bias

Code 6020 requires Code 6102. Code 6040 requires Code 6101.

777.00

-621.00

-362.00

In Base Price

FRONT AXLE

6020 2 Wheel Drive

Requires Code 1363.

In Base Price

6040 MFWD (4 Wheel Drive)

Mechanical Engagement. Engagement Indicator Light on PowrReverser Transmission. Requires Code 3420.

5,296.00

FRONT WHEELS WITH TIRES (TWO)

6102 7.50-16 In. 6PR F2 Bias

6103 27/12LL-15 In. 6PR Turf Special Bias

6101 9.5-24 In. 6PR R1 Bias 1,052.00

6133 12.5/80-18 In. 6PR I3(R4 Type) Bias 728.00

6171 9.5-16 In. 6PR R3 Bias 396.00

FOR OPTION CODE 6020 (2WD):

In Base Price

Requires Code 2000 - Open Operator Station.

486.00

Requires Code 2000 - Open Operator Station.

FOR OPTION CODE 6040 (MFWD):

ATTACHMENTS FOR FIELD CONVERSION

03 December 2014 US & Canada

2-TRACTOR- 3

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

(MY2015) 5065E Utility Tractor (49-53 PTO hp)

Continued

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

SUGGESTED

LIST PRICE

USD ($)

ATTACHMENTS FOR FIELD CONVERSION ...Continued...

L154683 Rear Axle 1.2 In. Extension (30 mm)

L154682 Rear Axle 1.6 In. Extension (40 mm)

L154684 Rear Axle 4.4 In. Extension (111 mm)

LV150155 Engine Coolant Heater Kit (3 Cyl.) 96.80

LVB25714 Rear Fender Extension Kit

T12553 Center Link Conversion Bushing, Cat. II to Cat. I

Axle - Rear:

See Parts

Two required. Requires (16) 19M9364 Cap Screws (8 per Extension), ordered separately.

See Parts

Two required. Requires (16) 19M8979 Cap Screws (8 per Extension), ordered separately.

See Parts

Two required. Requires (16) 19M9365 Cap Screws (8 per Extension), ordered separately.

Engine:

Fenders:

209.00

Cab Tractors only.

Hitch and Drawbar:

See Parts

One required.

R66432 Draft Link Conversion Bushing, Cat. II to Cat. I

Two required.

R133359 Drawbar - Offset See Parts

RE39830 Drawbar Clevis Kit (Hammer Strap) - Offset Drawbar See Parts

RE39829 Drawbar Clevis Kit (Hammer Strap) - Straight Drawbar See Parts

TY16042 Quik-Coupler, Economy, Category 2 See Parts

Hitch:

SJ11072 Left Hand Telescopic Draft Link See Parts

SJ11073 Right Hand Telescopic Draft Link See Parts

LVB25976 iMatch Quick Hitch Category 1 with adjustable top hook

Includes one set of Bushings (LVU15507).

Hydraulics:

LVB25771 Second Rear SCV with Detented Float and Lever Control

For 9x3 TSS Open Station Tractors.

BLV10348 Second Rear SCV with Detented Float and Lever Control

Compatible with 5E Cab Tractors.

See Parts

357.50

805.20

03 December 2014 US & Canada

2-TRACTOR- 4

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

(MY2015) 5065E Utility Tractor (49-53 PTO hp)

Continued

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

SUGGESTED

LIST PRICE

USD ($)

ATTACHMENTS FOR FIELD CONVERSION ...Continued...

BLV10431 Second Rear SCV with Detented Float and Lever Control

For 12x12 PR Open Station Tractors.

Lighting:

LVB25547 Auxiliary Rear Work Light Kit (1 Light)

Open Station Only.

Miscellaneous:

LVB25728 Backup Alarm Kit

Compatible with 5E 3-Cyl Cab tractors and PR Open Station Tractors.

LVB25727 PowrReverser Modulation Control Kit 147.40

LVB25926 Single Horn Kit

OOS tractors only

LVB26096 Single Horn Kit

CAB tractors only

Operator Environment:

SJ10170 Antenna

Cab only

805.20

63.80

161.70

51.70

See Parts

AH104259 Ash Tray

Cab only.

LVB25785 Canopy - Deluxe

Requires LVB25332 Canopy Mounting Bracket and Hardware Kit ordered separately.Open Station Tractors Only.

LVB25334 Canopy - Standard

Requires LVB25332 Canopy Mounting Bracket and Hardware Kit ordered separately. Open Station Tractors Only.

LVB25332 Canopy Mounting Bracket and Hardware Kit

Requires LVB25334 or LVB25785 Canopy Kit ordered separately. Open Station Tractors Only.

AR60937 Cigarette Lighter

Cab only.

RE244177 Kit, Rear View Mirror Mounting Kit

Cab only. Requires AL80127 and/or AL80126Kit contains support plates and hardware for one rear view mirror.

AL80126 Mirror, Telescopic, LH, Manually Adjustable

Cab only.

AL80127 Mirror, Telescopic, RH, Manually Adjustable

Cab only.

BLV10350 Right Hand Door

Cab Only

See Parts

961.40

583.00

105.60

See Parts

171.60

291.50

03 December 2014 US & Canada

2-TRACTOR- 5

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

(MY2015) 5065E Utility Tractor (49-53 PTO hp)

Continued

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

ATTACHMENTS FOR FIELD CONVERSION ...Continued...

BLV10173 Wiper/Washer, Rear

Cab only.

Weights:

R213907 Weight, Rear Wheel - 95 Lb.

Not compatible on wheels sized 24" or smaller. Maximum of 2 per wheel.

SUGGESTED

LIST PRICE

USD ($)

343.20

222.20

03 December 2014 US & Canada

2-TRACTOR- 6

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

(MY2015) 5075E Utility Tractor (57-61 PTO hp)

Equipment for Base Machine

ENGINE: 75 (55.0 kW) 97/68/EC Engine Horsepower @ 2100 RPM* 61 (44.9 kW) PTO Horsepower @ 2100 RPM* (Open Station)

57.2 (42 kW) PTO Horsepower @ 2100 RPM* (Cab) 3 Cylinder Turbocharged John Deere PowerTech Diesel Engine EPA Final Tier 4 Compliant 179 C.I.D. (2.9L) Dry Type Air Cleaner with Safety Element Underhood Muffler with Vertical Exhaust Stack Anti-Freeze Hand and Foot Throttles Key Engine Shutoff Fan Finger Guar Heavy Duty Air Intake Pre-Heater Fuel Cooler

TRANSMISSION: 9F/3R TSS 9F/3R SyncShuttle

Synchronized Shuttle Shifts and Speed Shifts,

Integrated Park Position Right Hand Shifted Speeds Left Hand Shifted Ranges Differential Lock Neutral Start Safety Switch REAR AXLE: Flanged Rear Axle Planetary Final Drives

STEERING AND BRAKES: Hydrostatic Power Steering Hydraulically Actuated Wet Disk Brakes Self-Equalizing and Self-Adjusting

HYDRAULICS: Open Center Hydraulic System Tandem Gear Pump 18.2 GPM (68.8 LPM) Maximum Total Flow

Steering Pump 6.8 GPM (25.7 LPM)

Implement Pump 11.4 GPM (43.1 LPM) One Rear Selective Control Valve

POWER TAKE-OFF SHAFT: 9x3 TSS Transmission Independent "Live" 540 RPM Rear PTO Shaft Operator Presence Safety Warning - PTO Safety Start Switch Flip Up PTO Shield

ROCKSHAFT, HITCH AND DRAWBAR: Rear Rockshaft with Position Control,

Draft Control, and Adjustable Rate of Drop 3-Point (Category II) Hitch

with Sway Chains Convertible to Category I Interchangeable Hitch Balls

Adjustable Drawbar INSTRUMENTATION:

ELECTRICAL: Open Station 12-Volt Electrical System One Battery - 623 CCA** with

145 Minute Reserve Capacity

40 Amp Alternator LIGHTS:

Two Front Halogen Headlights Two Turn/Flashing Warning Lights Two Tail Lights One Rear Work Light MISCELLANEOUS: SMV Emblem Tilt-Up Hood Fender Mounted Toolbox

BASE MACHINE: 2-Post Foldable Roll-Over Protective

Structure (ROPS)

Deluxe Adjustable Vinyl Seat with

Retractable Seat Belt 18 U.S. Gallon (68 L) Fuel Tank Capacity Adjustable Front Axle (56-80 In.) 8-Position Steel Rear Wheels with

Two Rear Tires 16.9-28 6PR (R1) 2-Position Steel Front Wheels with

Two Front Tires 7.50-16 6PR (F2)

* Manufacturer's Rating ** Cold Cranking Amps

SUGGESTED

LIST PRICE

USD ($)

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

Select One Code From Each Required Category

BASE MACHINE

1754LV (MY2015) 5075E Utility Tractor (57-61 PTO hp) 27,063.00

OPERATORS MANUAL

0409 English Operators Manual and Decal Kit In Base Price

03 December 2014 US & Canada

2-TRACTOR- 1

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

(MY2015) 5075E Utility Tractor (57-61 PTO hp)

Continued

SUGGESTED

LIST PRICE

USD ($)

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

OPERATORS MANUAL ...Continued...

0413 French Operators Manual and Decal Kit Same Price

0437 Spanish Operators Manual and Decal Kit Same Price

TRANSMISSION

1363 9F/3R SyncShuttle Transmission (TSS)

1381 12F/12R PowrReverser Transmission - 540/540E (PR)

In Base Price

2,160.00

OPERATOR STATION

2000 Open Operator Station

Fixed Open Operator Station 2 Post Foldable Roll-Over Protection Structure (ROPS) Beverage Holder Single Rear Work Light 18 Gallon Fuel Tank

2050 Cab

Left Side Door Air Conditioning Cup Holders Radio/CD Ready (Antenna Cable,Two Speakers, and Wiring Harness) Front Windshield Wiper Mechanical Suspension Seat

21.6 Gallon Fuel Tank Requires Code 6040 MFWD. Requires Code 4120 Telescopic Draft Link.

In Base Price

7,488.00

DRAFT LINKS

4115 Fixed Draft Links In Base Price

4120 Telescopic Draft Links 518.00

MID SELECTIVE CONTROL VALVES

3400 Less Mid Valves

Recommended for applications WITHOUT front loaders. Can later be upgraded for front loader and/or other hydraulic applications using field-installed attachments. Requires Code 6020 - 2WD.

In Base Price

03 December 2014 US & Canada

2-TRACTOR- 2

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

(MY2015) 5075E Utility Tractor (57-61 PTO hp)

Continued

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

MID SELECTIVE CONTROL VALVES ...Continued...

3420 Dual Mid Valves with Joystick Control

Recommended for applications WITH front loaders. Requires Code 6040 - MFWD.

REAR WHEELS WITH TIRES (TWO)

5103 22.5LL-16.1 In. 6PR R3 (Turf Special) Bias

5113 21.5L-16.1 In. 6PR R3 Bias

5184 16.9-24 In. 6PR R4 Bias

5185 16.9-28 In. 6PR R1 Bias

Requires Code 6103.

Code 6020 requires Code 6103.

Code 6040 requires Code 6133.

Code 6020 requires Code 6102. Code 6040 requires Code 6101.

FRONT AXLE

6020 2 Wheel Drive

Requires Code 1363.

SUGGESTED

LIST PRICE

USD ($)

1,162.00

777.00

-621.00

-362.00

In Base Price

6040 MFWD (4 Wheel Drive)

Mechanical Engagement. Engagement Indicator Light on PowrReverser Transmission. Requires Code 3420.

5,296.00

FRONT WHEELS WITH TIRES (TWO)

6102 7.50-16 In. 6PR F2 Bias

6103 27/12LL-15 In. 6PR Turf Special Bias

6101 9.5-24 In. 6PR R1 Bias 1,052.00

6133 12.5/80-18 In. 6PR I3(R4 Type) Bias 728.00

6171 9.5-16 In. 6PR R3 Bias 396.00

FOR OPTION CODE 6020 (2WD):

In Base Price

Requires Code 2000 - Open Operator Station.

486.00

Requires Code 2000 - Open Operator Station.

FOR OPTION CODE 6040 (MFWD):

ATTACHMENTS FOR FIELD CONVERSION

L154683 Rear Axle 1.2 In. Extension (30 mm)

Axle - Rear:

See Parts

Two required. Requires (16) 19M9364 Cap Screws (8 per Extension), ordered separately.

03 December 2014 US & Canada

2-TRACTOR- 3

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

(MY2015) 5075E Utility Tractor (57-61 PTO hp)

Continued

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

SUGGESTED

LIST PRICE

USD ($)

ATTACHMENTS FOR FIELD CONVERSION ...Continued...

L154682 Rear Axle 1.6 In. Extension (40 mm)

Two required. Requires (16) 19M8979 Cap Screws (8 per Extension), ordered separately.

L154684 Rear Axle 4.4 In. Extension (111 mm)

Two required. Requires (16) 19M9365 Cap Screws (8 per Extension), ordered separately.

Engine:

LV150155 Engine Coolant Heater Kit (3 Cyl.) 96.80

Fenders:

LVB25714 Rear Fender Extension Kit

Cab Tractors only.

Hitch and Drawbar:

T12553 Center Link Conversion Bushing, Cat. II to Cat. I

One required.

R66432 Draft Link Conversion Bushing, Cat. II to Cat. I

Two required.

See Parts

209.00

See Parts

R133359 Drawbar - Offset See Parts

RE39830 Drawbar Clevis Kit (Hammer Strap) - Offset Drawbar See Parts

RE39829 Drawbar Clevis Kit (Hammer Strap) - Straight Drawbar See Parts

TY16042 Quik-Coupler, Economy, Category 2 See Parts

SJ11072 Left Hand Telescopic Draft Link See Parts

SJ11073 Right Hand Telescopic Draft Link See Parts

LVB25976 iMatch Quick Hitch Category 1 with adjustable top hook

LVB25771 Second Rear SCV with Detented Float and Lever Control

BLV10348 Second Rear SCV with Detented Float and Lever Control

BLV10431 Second Rear SCV with Detented Float and Lever Control

Hitch:

357.50

Includes one set of Bushings (LVU15507).

Hydraulics:

805.20

For 9x3 TSS Open Station Tractors.

805.20

Compatible with 5E Cab Tractors.

805.20

For 12x12 PR Open Station Tractors.

LVB25547 Auxiliary Rear Work Light Kit (1 Light)

Lighting:

Open Station Only.

03 December 2014 US & Canada

2-TRACTOR- 4

63.80

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

(MY2015) 5075E Utility Tractor (57-61 PTO hp)

Continued

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

SUGGESTED

LIST PRICE

USD ($)

ATTACHMENTS FOR FIELD CONVERSION ...Continued...

LVB25728 Backup Alarm Kit

LVB25727 PowrReverser Modulation Control Kit 147.40

LVB25926 Single Horn Kit

LVB26096 Single Horn Kit

SJ10170 Antenna

AH104259 Ash Tray

LVB25785 Canopy - Deluxe

LVB25334 Canopy - Standard

Miscellaneous:

161.70

Compatible with 5E 3-Cyl Cab tractors and PR Open Station Tractors.

51.70

OOS tractors only

51.70

CAB tractors only

Operator Environment:

See Parts

Cab only

See Parts

Cab only.

961.40

Requires LVB25332 Canopy Mounting Bracket and Hardware Kit ordered separately.Open Station Tractors Only.

583.00

Requires LVB25332 Canopy Mounting Bracket and Hardware Kit ordered separately. Open Station Tractors Only.

LVB25332 Canopy Mounting Bracket and Hardware Kit

Requires LVB25334 or LVB25785 Canopy Kit ordered separately. Open Station Tractors Only.

AR60937 Cigarette Lighter

Cab only.

RE244177 Kit, Rear View Mirror Mounting Kit

Cab only. Requires AL80127 and/or AL80126Kit contains support plates and hardware for one rear view mirror.

AL80126 Mirror, Telescopic, LH, Manually Adjustable

Cab only.

AL80127 Mirror, Telescopic, RH, Manually Adjustable

Cab only.

BLV10350 Right Hand Door

Cab Only

BLV10173 Wiper/Washer, Rear

Cab only.

Weights:

R213907 Weight, Rear Wheel - 95 Lb.

Not compatible on wheels sized 24" or smaller. Maximum of 2 per wheel.

105.60

See Parts

171.60

291.50

343.20

222.20

03 December 2014 US & Canada

2-TRACTOR- 5

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

(MY2015) 5075E Utility Tractor (57-61 PTO hp)

Continued

THIS PAGE IS INTENTIONALLY LEFT BLANK

03 December 2014 US & Canada

2-TRACTOR- 6

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5045D Open Operator Station Utility Tractor (37 PTO hp)

Equipment for Base Machine

ENGINE: 45 (33.6 kW) 97/68/EC Engine Horsepower @ 2300* RPM 37 (27.3 kW) PTO Horsepower @ 2200 3 Cylinder Turbocharged John Deere PowerTech Diesel Engine 179 C.I.D. (2.9L) Dry Type Air Cleaner with Safety Element Underhood Muffler with Vertical Exhaust Stack Anti-Freeze Hand and Foot Throttles Key Engine Shutoff Fan Finger Guard Heavy Duty Air Intake Pre-Heater

TRANSMISSION: 8F/4R Inline Forward-Reverse - 1R, 2R, 3R and 4R Synchronized Shifting (A-R) and non-synchronized speed shifts Right Hand Shifted Speeds Left Hand Shifted Ranges Differential Lock Neutral Start Safety Switch

REAR AXLE: Flanged Rear Axle Planetary Final Drives

STEERING AND BRAKES: Hydrostatic Power Steering Mechanically Actuated Wet Disk Brakes Positive Brake Pedal Latch / Release Lever on Control Console

HYDRAULICS: Open Center Hydraulic System Tandem Gear Pump 17.4 GPM (66 LPM) Maximum Total Flow

Steering Pump 6.5 GPM (24.6 LPM) Implement Pump 10.9 GPM (41.4 LPM)

One Rear Selective Control Valve POWER TAKE-OFF SHAFT:

Independent "Live" 540 RPM Rear PTO Shaft Operator Presence Safety Warning - PTO Safety Start Switch

ROCKSHAFT, HITCH AND DRAWBAR: Rear Rockshaft with Position Control,

Draft Control, and Adjustable Rate of Drop

3-Point (Category II) Hitch

with Sway Chains -

Convertible to Category I Adjustable Drawbar

ELECTRICAL: 12-Volt Electrical System One Battery - 623 CCA** with

145 Minute Reserve Capacity 40 Amp Alternator

LIGHTS: Two Front Halogen Headlights Two Turn/Flashing Warning Lights Two Tail Lights

MISCELLANEOUS: SMV Emblem Tilt-Up Hood Fender Mounted Toolbox

BASE MACHINE: 2-Post Foldable Roll-Over Protective

Structure (ROPS) Deluxe Adjustable Vinyl Seat with

Retractable Seat Belt 16 U.S. Gallon (60 L) Fuel Tank Capacity Adjustable Front Axle (56-80 In.) 8-Position Steel Rear Wheels with

Two Rear Tires 13.6-28 6PR (R1)

2-Position Steel Front Wheels with

Two Front Tires 7.50-16 6PR (F2)

* Manufacturer's Rating ** Cold Cranking Amps

SUGGESTED

LIST PRICE

USD ($)

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

Select One Code From Each Required Category

BASE MACHINE

1703LV 5045D Open Operator Station Utility Tractor (37 PTO hp) 17,233.00

OPERATORS MANUAL

0409 English Operators Manual and Decal Kit In Base Price

0413 French Operators Manual and Decal Kit Same Price

03 December 2014 US & Canada

2-TRACTOR- 1

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5045D Open Operator Station Utility Tractor (37 PTO hp)

Continued

SUGGESTED

LIST PRICE

USD ($)

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

OPERATORS MANUAL ...Continued...

0437 Spanish Operators Manual and Decal Kit Same Price

TRANSMISSION

1311 8/4 Collar Shift Transmission (CST)

8F/4R Inline Forward-Reverse - 1R, 2R, 3R and 4R.

In Base Price

MID SELECTIVE CONTROL VALVES

3400 Less Mid Valves

Recommended for applications WITHOUT front loaders. Can later be upgraded for front loader and/or other hydraulic applications using field-installed attachments. Requires Code 6020 - 2WD.

In Base Price

REAR WHEELS WITH TIRES (TWO)

5101 14.9-28 In. 6PR R1 Bias

Code 6020 requires Code 6102.

5113 21.5L-16.1 In. 6PR R3 Bias

Code 6020 requires Code 6103.

5115 13.6-28 In. 6PR R1 Bias

Code 6020 requires Code 6102.

48.00

242.00

In Base Price

5184 16.9-24 In. 6PR R4 Bias

Code 6020 requires Code 6113.

5185 16.9-28 In. 6PR R1 Bias

Code 6020 requires Code 6102.

38.00

332.00

FRONT AXLE

6020 2 Wheel Drive In Base Price

FRONT WHEELS WITH TIRES (TWO)

6102 7.50-16 In. 6PR F2 Bias In Base Price

6103 27/12LL-15 In. 6PR Turf Special Bias 486.00

6113 11L-15 In. 8PR F3(Truck Type) Bias 84.00

FOR OPTION CODE 6020 (2WD):

ATTACHMENTS FOR FIELD CONVERSION

L154683 Rear Axle 1.2 In. Extension (30 mm)

Axle - Rear:

See Parts

Two required. Requires (16) 19M9364 Cap Screws (8 per Extension), ordered separately.

03 December 2014 US & Canada

2-TRACTOR- 2

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5045D Open Operator Station Utility Tractor (37 PTO hp)

Continued

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

SUGGESTED

LIST PRICE

USD ($)

ATTACHMENTS FOR FIELD CONVERSION ...Continued...

L154682 Rear Axle 1.6 In. Extension (40 mm)

Two required. Requires (16) 19M8979 Cap Screws (8 per Extension), ordered separately.

L154684 Rear Axle 4.4 In. Extension (111 mm)

Two required. Requires (16) 19M9365 Cap Screws (8 per Extension), ordered separately.

Engine:

LV150155 Engine Coolant Heater Kit (3 Cyl.) 96.80

LVB25110 Heavy Duty Air Intake Pre-Heater

925 CCA battery recommended for optimum performance. Only compatible with machines built with serial number 340000 and before. For machines built after, see the parts catalog.

LVB26028 Horizontal Side Exhaust

Compatible on 5D Series only.

Hitch and Drawbar:

T12553 Center Link Conversion Bushing, Cat. II to Cat. I

One required.

R66432 Draft Link Conversion Bushing, Cat. II to Cat. I

Two required.

See Parts

122.10

294.80

See Parts

R133359 Drawbar - Offset See Parts

RE39830 Drawbar Clevis Kit (Hammer Strap) - Offset Drawbar See Parts

RE39829 Drawbar Clevis Kit (Hammer Strap) - Straight Drawbar See Parts

TY16042 Quik-Coupler, Economy, Category 2 See Parts

SJ11072 Left Hand Telescopic Draft Link See Parts

SJ11073 Right Hand Telescopic Draft Link See Parts

LVB25826 Mid-Mount Dual SCV with Joystick Control

LVB25827 Second Rear SCV with Detented Float and Lever Control

LVB25547 Auxiliary Rear Work Light Kit (1 Light)

Hitch:

Hydraulics:

1,411.30

Compatible with 5D Series Tractors.

805.20

Compatible with 5D Series Tractors.

Lighting:

63.80

Open Station Only.

03 December 2014 US & Canada

2-TRACTOR- 3

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5045D Open Operator Station Utility Tractor (37 PTO hp)

Continued

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

ATTACHMENTS FOR FIELD CONVERSION ...Continued...

Miscellaneous:

LVB25926 Single Horn Kit

OOS tractors only

Operator Environment:

LVB25785 Canopy - Deluxe

Requires LVB25332 Canopy Mounting Bracket and Hardware Kit ordered separately.

LVB25334 Canopy - Standard

Requires LVB25332 Canopy Mounting Bracket and Hardware Kit ordered separately.

LVB25332 Canopy Mounting Bracket and Hardware Kit

Requires LVB25334 or LVB25785 Canopy Kit ordered separately.

Weights:

LVB25889 Weight, Front Support - 100 Lb.

Kit includes front weight support and mounting hardware.

R213907 Weight, Rear Wheel - 95 Lb.

Not compatible on wheels sized 24" or smaller. Maximum of 2 per wheel.

SUGGESTED

LIST PRICE

USD ($)

51.70

961.40

583.00

105.60

220.00

222.20

03 December 2014 US & Canada

2-TRACTOR- 4

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5055D Open Operator Station Utility Tractor (45 PTO hp)

Equipment for Base Machine

ENGINE: 55 (40.0 kW) 97/68/EC Engine Horsepower @ 2300* RPM 45 (33.1 kW) PTO Horsepower @ 2200 3 Cylinder Turbocharged John Deere PowerTech Diesel Engine 179 C.I.D. (2.9L) Dry Type Air Cleaner with Safety Element Underhood Muffler with Vertical Exhaust Stack Anti-Freeze Hand and Foot Throttles Key Engine Shutoff Fan Finger Guard Heavy Duty Air Intake Pre-Heater

REAR AXLE: Flanged Rear Axle Planetary Final Drives

STEERING AND BRAKES: Hydrostatic Power Steering Mechanically Actuated Wet Disk Brakes Positive Brake Pedal Latch / Release Lever on Control Console

HYDRAULICS: Open Center Hydraulic System Tandem Gear Pump 17.4 GPM (66.0 LPM) Maximum Total Flow

Steering Pump 6.5 GPM (24.6 LPM) Implement Pump 10.9 GPM (41.4 LPM)

One Rear Selective Control Valve POWER TAKE-OFF SHAFT:

Independent "Live" 540 RPM Rear PTO Shaft Operator Presence Safety Warning - PTO Safety Start Switch

ROCKSHAFT, HITCH AND DRAWBAR: Rear Rockshaft with Position Control,

Draft Control, and Adjustable Rate of Drop

3-Point (Category II) Hitch

with Sway Chains -

Convertible to Category I Adjustable Drawbar

ELECTRICAL: 12-Volt Electrical System One Battery - 623 CCA** with

145 Minute Reserve Capacity 40 Amp Alternator

LIGHTS: Two Front Halogen Headlights Two Turn/Flashing Warning Lights Two Tail Lights

MISCELLANEOUS: SMV Emblem Tilt-Up Hood Fender Mounted Toolbox

BASE MACHINE: 2-Post Foldable Roll-Over Protective

Structure (ROPS) Deluxe Adjustable Vinyl Seat with

Retractable Seat Belt 16 U.S. Gallon (60 L) Fuel Tank Capacity Adjustable Front Axle (56-80 In.) 8-Position Steel Rear Wheels with

Two Rear Tires 14.9-28 6PR (R1) 2-Position Steel Front Wheels with

Two Front Tires 7.50-16 6PR (F2)

* Manufacturer's Rating ** Cold Cranking Amps

SUGGESTED

LIST PRICE

USD ($)

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

Select One Code From Each Required Category

BASE MACHINE

1713LV 5055D Open Operator Station Utility Tractor (45 PTO hp) 18,754.00

OPERATORS MANUAL

0409 English Operators Manual and Decal Kit In Base Price

0413 French Operators Manual and Decal Kit Same Price

03 December 2014 US & Canada

2-TRACTOR- 1

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5055D Open Operator Station Utility Tractor (45 PTO hp)

Continued

SUGGESTED

LIST PRICE

USD ($)

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

OPERATORS MANUAL ...Continued...

0437 Spanish Operators Manual and Decal Kit Same Price

TRANSMISSION

1311 8/4 Collar Shift Transmission (CST)

8F/4R Inline Forward-Reverse - 1R, 2R, 3R and 4R.

In Base Price

MID SELECTIVE CONTROL VALVES

3400 Less Mid Valves

Recommended for applications WITHOUT front loaders. Can later be upgraded for front loader and/or other hydraulic applications using field-installed attachments. Requires Code 6020 - 2WD.

In Base Price

REAR WHEELS WITH TIRES (TWO)

5101 14.9-28 In. 6PR R1 Bias

Code 6020 requires Code 6102.

5113 21.5L-16.1 In. 6PR R3 Bias

Code 6020 requires Code 6103.

5184 16.9-24 In. 6PR R4 Bias

Code 6020 requires Code 6113.

In Base Price

194.00

Same Price

5185 16.9-28 In. 6PR R1 Bias

Code 6020 requires Code 6102.

284.00

FRONT AXLE

6020 2 Wheel Drive In Base Price

FRONT WHEELS WITH TIRES (TWO)

6102 7.50-16 In. 6PR F2 Bias In Base Price

6103 27/12LL-15 In. 6PR Turf Special Bias 486.00

6113 11L-15 In. 8PR F3(Truck Type) Bias 84.00

FOR OPTION CODE 6020 (2WD):

ATTACHMENTS FOR FIELD CONVERSION

L154683 Rear Axle 1.2 In. Extension (30 mm)

L154682 Rear Axle 1.6 In. Extension (40 mm)

Axle - Rear:

See Parts

Two required. Requires (16) 19M9364 Cap Screws (8 per Extension), ordered separately.

See Parts

Two required. Requires (16) 19M8979 Cap Screws (8 per Extension), ordered separately.

03 December 2014 US & Canada

2-TRACTOR- 2

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5055D Open Operator Station Utility Tractor (45 PTO hp)

Continued

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

SUGGESTED

LIST PRICE

USD ($)

ATTACHMENTS FOR FIELD CONVERSION ...Continued...

L154684 Rear Axle 4.4 In. Extension (111 mm)

Two required. Requires (16) 19M9365 Cap Screws (8 per Extension), ordered separately.

Engine:

LV150155 Engine Coolant Heater Kit (3 Cyl.) 96.80

LVB25110 Heavy Duty Air Intake Pre-Heater

925 CCA battery recommended for optimum performance. Only compatible with machines built with serial number 340000 and before. For machines built after, see the parts catalog.

LVB26028 Horizontal Side Exhaust

Compatible on 5D Series only.

Hitch and Drawbar:

T12553 Center Link Conversion Bushing, Cat. II to Cat. I

One required.

R66432 Draft Link Conversion Bushing, Cat. II to Cat. I

Two required.

R133359 Drawbar - Offset See Parts

RE39830 Drawbar Clevis Kit (Hammer Strap) - Offset Drawbar See Parts

See Parts

122.10

294.80

See Parts

RE39829 Drawbar Clevis Kit (Hammer Strap) - Straight Drawbar See Parts

TY16042 Quik-Coupler, Economy, Category 2 See Parts

SJ11072 Left Hand Telescopic Draft Link See Parts

SJ11073 Right Hand Telescopic Draft Link See Parts

LVB25826 Mid-Mount Dual SCV with Joystick Control

LVB25827 Second Rear SCV with Detented Float and Lever Control

LVB25547 Auxiliary Rear Work Light Kit (1 Light)

LVB25926 Single Horn Kit

Hitch:

Hydraulics:

1,411.30

Compatible with 5D Series Tractors.

805.20

Compatible with 5D Series Tractors.

Lighting:

63.80

Open Station Only.

Miscellaneous:

51.70

OOS tractors only

03 December 2014 US & Canada

2-TRACTOR- 3

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5055D Open Operator Station Utility Tractor (45 PTO hp)

Continued

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

ATTACHMENTS FOR FIELD CONVERSION ...Continued...

Operator Environment:

LVB25785 Canopy - Deluxe

Requires LVB25332 Canopy Mounting Bracket and Hardware Kit ordered separately.

LVB25334 Canopy - Standard

Requires LVB25332 Canopy Mounting Bracket and Hardware Kit ordered separately.

LVB25332 Canopy Mounting Bracket and Hardware Kit

Requires LVB25334 or LVB25785 Canopy Kit ordered separately.

Weights:

LVB25889 Weight, Front Support - 100 Lb.

Kit includes front weight support and mounting hardware.

R213907 Weight, Rear Wheel - 95 Lb.

Not compatible on wheels sized 24" or smaller. Maximum of 2 per wheel.

SUGGESTED

LIST PRICE

USD ($)

961.40

583.00

105.60

220.00

222.20

03 December 2014 US & Canada

2-TRACTOR- 4

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5045E Open Operator Station Utility Tractor (37 PTO hp)

Equipment for Base Machine

ENGINE: 45 (33.6 kW) 97/68/EC Engine Horsepower @ 2400* RPM 37 (27.3 kW) PTO Horsepower @ 2400* RPM 3 Cylinder Turbocharged John Deere

PowerTech Diesel Engine 179 C.I.D. (2.9L) Dry Type Air Cleaner with Safety Element Underhood Muffler with Vertical Exhaust Stack Anti-Freeze Hand and Foot Throttles Key Engine Shutoff Fan Finger Guard Heavy Duty Air Intake Pre-Heater

TRANSMISSION: 9F/3R SyncShuttle - 2R, 5R and 8R

Synchronized Shuttle Shifts and Speed Shifts,

Integrated Park Position Right Hand Shifted Speeds Left Hand Shifted Ranges Differential Lock Neutral Start Safety Switch

REAR AXLE: Flanged Rear Axle Planetary Final Drives

STEERING AND BRAKES: Hydrostatic Power Steering Hydraulically Actuated Wet Disk Brakes

Self-Equalizing and Self-Adjusting HYDRAULICS:

Open Center Hydraulic System Tandem Gear Pump 18.2 GPM (68.8 LPM) Maximum Total Flow

Steering Pump 6.8 GPM (25.7 LPM)

Implement Pump 11.4 GPM (43.1 LPM) One Rear Selective Control Valve

POWER TAKE-OFF SHAFT: Independent "Live" 540 RPM Rear PTO Shaft Operator Presence Safety Warning - PTO Safety Start Switch

ROCKSHAFT, HITCH AND DRAWBAR: Rear Rockshaft with Position Control,

Draft Control, and Adjustable Rate of Drop 3-Point (Category II) Hitch

with Sway Chains -

Convertible to Category I

Adjustable Drawbar INSTRUMENTATION:

ELECTRICAL: 12-Volt Electrical System One Battery - 623 CCA** with

145 Minute Reserve Capacity

40 Amp Alternator LIGHTS:

Two Front Halogen Headlights Two Turn/Flashing Warning Lights Two Tail Lights

MISCELLANEOUS: SMV Emblem Tilt-Up Hood Fender Mounted Toolbox

BASE MACHINE: 2-Post Foldable Roll-Over Protective

Structure (ROPS)

Deluxe Adjustable Vinyl Seat with

Retractable Seat Belt 18 U.S. Gallon (68.1 L) Fuel Tank Capacity MFWD (4Wheel Drive) Front Axle 8-Position Steel Rear Wheels with

Two Rear Tires 13.6-28 6PR (R1) 8-Position Steel Front Wheels with

Two Front Tires 9.5-24 6PR (R1)

* Manufacturer's Rating ** Cold Cranking Amps

SUGGESTED

LIST PRICE

USD ($)

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

Select One Code From Each Required Category

BASE MACHINE

1723LV 5045E Open Operator Station Utility Tractor (37 PTO hp) 22,790.00

OPERATORS MANUAL

0409 English Operators Manual and Decal Kit In Base Price

0413 French Operators Manual and Decal Kit Same Price

03 December 2014 US & Canada

2-TRACTOR- 1

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5045E Open Operator Station Utility Tractor (37 PTO hp)

Continued

SUGGESTED

LIST PRICE

USD ($)

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

OPERATORS MANUAL ...Continued...

0437 Spanish Operators Manual and Decal Kit Same Price

TRANSMISSION

1363 9F/3R SyncShuttle Transmission (TSS)

9F/3R Partial Top Shaft Synchronized [TSS] (with 2WD front axle code-6020) 2nd & Reverse gears are synchronized in all ranges Integrated Park Position

9F/3R Full Top Shaft Synchronized [TSS] (with 4WD front axle code-6040) Synchronized Speed Shifts Integrated Park Position

In Base Price

MID SELECTIVE CONTROL VALVES

3420 Dual Mid Valves with Joystick Control

Recommended for applications WITH front loaders. Requires Code 6040 - MFWD.

1,123.00

REAR WHEELS WITH TIRES (TWO)

5101 14.9-28 In. 6PR R1 Bias

Code 6040 requires Code 6101.

5113 21.5L-16.1 In. 6PR R3 Bias

Code 6040 requires Code 6171.

48.00

242.00

5115 13.6-28 In. 6PR R1 Bias

Code 6040 requires Code 6101.

5184 16.9-24 In. 6PR R4 Bias

Code 6040 requires Code 6133.

5185 16.9-28 In. 6PR R1 Bias

Code 6040 requires Code 6101.

In Base Price

38.00

332.00

FRONT AXLE

6040 MFWD (4 Wheel Drive)

Mechanical Engagement Engagement Indicator Light on PowrReverser Transmission. Requires Code 3420.

In Base Price

FRONT WHEELS WITH TIRES (TWO)

6101 9.5-24 In. 6PR R1 Bias In Base Price

6133 12.5/80-18 In. 6PR I3(R4 Type) Bias 88.00

6171 9.5-16 In. 6PR R3 Bias -290.00

FOR OPTION CODE 6040 (MFWD):

03 December 2014 US & Canada

2-TRACTOR- 2

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5045E Open Operator Station Utility Tractor (37 PTO hp)

Continued

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

SUGGESTED

LIST PRICE

USD ($)

ATTACHMENTS FOR FIELD CONVERSION

L154683 Rear Axle 1.2 In. Extension (30 mm)

L154682 Rear Axle 1.6 In. Extension (40 mm)

L154684 Rear Axle 4.4 In. Extension (111 mm)

LV150155 Engine Coolant Heater Kit (3 Cyl.) 96.80

LVB25110 Heavy Duty Air Intake Pre-Heater

LVB25900 Horizontal Side Exhaust

Axle - Rear:

See Parts

Two required. Requires (16) 19M9364 Cap Screws (8 per Extension), ordered separately.

See Parts

Two required. Requires (16) 19M8979 Cap Screws (8 per Extension), ordered separately.

See Parts

Two required. Requires (16) 19M9365 Cap Screws (8 per Extension), ordered separately.

Engine:

122.10

925 CCA battery recommended for optimum performance. Only compatible with machines built with serial number 340000 and before. For machines built after, see the parts catalog.

192.50

Compatible on 5E Open Station Series only.

T12553 Center Link Conversion Bushing, Cat. II to Cat. I

R66432 Draft Link Conversion Bushing, Cat. II to Cat. I

R133359 Drawbar - Offset See Parts

RE39830 Drawbar Clevis Kit (Hammer Strap) - Offset Drawbar See Parts

RE39829 Drawbar Clevis Kit (Hammer Strap) - Straight Drawbar See Parts

TY16042 Quik-Coupler, Economy, Category 2 See Parts

SJ11072 Left Hand Telescopic Draft Link See Parts

SJ11073 Right Hand Telescopic Draft Link See Parts

LVB25976 iMatch Quick Hitch Category 1 with adjustable top hook

LVB25925 Mid-Mount Dual SCV with Joystick Control

Hitch and Drawbar:

See Parts

One required.

See Parts

Two required.

Hitch:

357.50

Includes one set of Bushings (LVU15507).

Hydraulics:

1,411.30

Compatible with 5103, 5203, 5303, 5403 and 5E Series Tractors. Open Station Only.

03 December 2014 US & Canada

2-TRACTOR- 3

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5045E Open Operator Station Utility Tractor (37 PTO hp)

Continued

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

SUGGESTED

LIST PRICE

USD ($)

ATTACHMENTS FOR FIELD CONVERSION ...Continued...

LVB25788 Motor Control Kit

Compatible with 5003 and 5E Series Tractors. Also order RE251179 if no mid-mount valve installed.

LVB25771 Second Rear SCV with Detented Float and Lever Control

Compatible with 5E Series Tractors and 5103-5403 models after S/N PY5103U013641, PY5203U005570, PY5303U007753, PY5403U000735. Open Station Only.

Lighting:

LVB25547 Auxiliary Rear Work Light Kit (1 Light)

Open Station Only.

Miscellaneous:

LVB25817 Backup Alarm Kit

NOT compatible with 2WD front axle (Code 1002) and 5D Series Tractors. Compatible with 5E 3-Cyl TSS open station tractors only.

BLV10407 Operator's Manual and Decal Kit - French 0.00

BLV10406 Operator's Manual and Decal Kit - Spanish 0.00

LVB25926 Single Horn Kit

OOS tractors only

2,086.70

805.20

63.80

161.70

51.70

LVB25785 Canopy - Deluxe

Operator Environment:

Requires LVB25332 Canopy Mounting Bracket and Hardware Kit ordered separately.

LVB25334 Canopy - Standard

Requires LVB25332 Canopy Mounting Bracket and Hardware Kit ordered separately.

LVB25332 Canopy Mounting Bracket and Hardware Kit

Requires LVB25334 or LVB25785 Canopy Kit ordered separately.

Weights:

LVB25889 Weight, Front Support - 100 Lb.

Kit includes front weight support and mounting hardware.

R213907 Weight, Rear Wheel - 95 Lb.

Not compatible on wheels sized 24" or smaller. Maximum of 2 per wheel.

961.40

583.00

105.60

220.00

222.20

03 December 2014 US & Canada

2-TRACTOR- 4

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5055E Open Operator Station Utility Tractor (45 PTO hp)

Equipment for Base Machine

ENGINE: 55 (40.0 kW) 97/68/EC Engine Horsepower @ 2400* RPM 45 (33.1 kW) PTO Horsepower @ 2400* RPM 3 Cylinder Turbocharged John Deere

TRANSMISSION: 9F/3R SyncShuttle - 2R, 5R and 8R

Synchronized Shuttle Shifts and Speed Shifts,

Integrated Park Position Right Hand Shifted Speeds Left Hand Shifted Ranges Differential Lock Neutral Start Safety Switch

REAR AXLE: Flanged Rear Axle Planetary Final Drives

STEERING AND BRAKES: Hydrostatic Power Steering Hydraulically Actuated Wet Disk Brakes

Self-Equalizing and Self-Adjusting HYDRAULICS:

Open Center Hydraulic System Tandem Gear Pump 18.2 GPM (68.8 LPM) Maximum Total Flow

Steering Pump 6.8 GPM (25.7 LPM)

Implement Pump 11.4 GPM (43.1 LPM) One Rear Selective Control Valve

POWER TAKE-OFF SHAFT: Independent "Live" 540 RPM Rear PTO Shaft Operator Presence Safety Warning - PTO Safety Start Switch

ROCKSHAFT, HITCH AND DRAWBAR: Rear Rockshaft with Position Control,

Draft Control, and Adjustable Rate of Drop 3-Point (Category II) Hitch

with Sway Chains -

Convertible to Category I

Adjustable Drawbar INSTRUMENTATION:

ELECTRICAL: 12-Volt Electrical System One Battery - 623 CCA** with

145 Minute Reserve Capacity

40 Amp Alternator LIGHTS:

Two Front Halogen Headlights Two Turn/Flashing Warning Lights Two Tail Lights

MISCELLANEOUS: SMV Emblem Tilt-Up Hood Fender Mounted Toolbox

BASE MACHINE: 2-Post Foldable Roll-Over Protective

Structure (ROPS)

Deluxe Adjustable Vinyl Seat with

Retractable Seat Belt 18 U.S. Gallon (68.1 L) Fuel Tank Capacity MFWD (4 Wheel Drive) Front Axle 8-Position Steel Rear Wheels with

Two Rear Tires 14.9-28 6PR (R1) 8-Position Steel Front Wheels with

Two Front Tires 9.5-24 6PR (R1)

* Manufacturer's Rating ** Cold Cranking Amps

SUGGESTED

LIST PRICE

USD ($)

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

Select One Code From Each Required Category

BASE MACHINE

1733LV 5055E Open Operator Station Utility Tractor (45 PTO hp) 25,562.00

OPERATORS MANUAL

0409 English Operators Manual and Decal Kit In Base Price

0413 French Operators Manual and Decal Kit Same Price

03 December 2014 US & Canada

2-TRACTOR- 1

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5055E Open Operator Station Utility Tractor (45 PTO hp)

Continued

SUGGESTED

LIST PRICE

USD ($)

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

OPERATORS MANUAL ...Continued...

0437 Spanish Operators Manual and Decal Kit Same Price

TRANSMISSION

1363 9F/3R SyncShuttle Transmission (TSS)

9F/3R Partial Top Shaft Synchronized [TSS] (with 2WD front axle code-6020) 2nd & Reverse gears are synchronized in all ranges Integrated Park Position

9F/3R Full Top Shaft Synchronized [TSS] (with 4WD front axle code-6040) Synchronized Speed Shifts Integrated Park Position

1381 12F/12R PowrReverser Transmission - 540/540E (PR)

Electrohydraulic (EH) Directional Reverser Wet Traction Clutch Wet PTO Clutch Neutral Start Safety Switch Electrohydraulic (EH) PTO engagement Economic-PTO/Standard PTO MFWD indicator light Digital hour meter indicator Digital ground speed indicator Digital PTO speed indicator Requires Code 6040 - MFWD.

In Base Price

2,160.00

MID SELECTIVE CONTROL VALVES

3420 Dual Mid Valves with Joystick Control

Recommended for applications WITH front loaders. Requires Code 6040 - MFWD.

REAR WHEELS WITH TIRES (TWO)

5101 14.9-28 In. 6PR R1 Bias

Code 6040 requires Code 6101.

5113 21.5L-16.1 In. 6PR R3 Bias

Code 6040 requires Code 6171.

5184 16.9-24 In. 6PR R4 Bias

Code 6040 requires Code 6133.

5185 16.9-28 In. 6PR R1 Bias

Code 6040 requires Code 6101.

FRONT AXLE

6040 MFWD (4 Wheel Drive)

Mechanical Engagement Engagement Indicator Light on PowrReverser Transmission. Requires Code 3420.

FRONT WHEELS WITH TIRES (TWO)

1,123.00

In Base Price

194.00

Same Price

284.00

In Base Price

03 December 2014 US & Canada

2-TRACTOR- 2

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5055E Open Operator Station Utility Tractor (45 PTO hp)

Continued

SUGGESTED

LIST PRICE

USD ($)

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

FRONT WHEELS WITH TIRES (TWO) ...Continued...

6101 9.5-24 In. 6PR R1 Bias In Base Price

6133 12.5/80-18 In. 6PR I3(R4 Type) Bias 88.00

6171 9.5-16 In. 6PR R3 Bias -290.00

FOR OPTION CODE 6040 (MFWD):

ATTACHMENTS FOR FIELD CONVERSION

L154683 Rear Axle 1.2 In. Extension (30 mm)

L154682 Rear Axle 1.6 In. Extension (40 mm)

L154684 Rear Axle 4.4 In. Extension (111 mm)

Axle - Rear:

See Parts

Two required. Requires (16) 19M9364 Cap Screws (8 per Extension), ordered separately.

See Parts

Two required. Requires (16) 19M8979 Cap Screws (8 per Extension), ordered separately.

See Parts

Two required. Requires (16) 19M9365 Cap Screws (8 per Extension), ordered separately.

LV150155 Engine Coolant Heater Kit (3 Cyl.) 96.80

LVB25110 Heavy Duty Air Intake Pre-Heater

LVB25900 Horizontal Side Exhaust

T12553 Center Link Conversion Bushing, Cat. II to Cat. I

R66432 Draft Link Conversion Bushing, Cat. II to Cat. I

R133359 Drawbar - Offset See Parts

RE39830 Drawbar Clevis Kit (Hammer Strap) - Offset Drawbar See Parts

RE39829 Drawbar Clevis Kit (Hammer Strap) - Straight Drawbar See Parts

TY16042 Quik-Coupler, Economy, Category 2 See Parts

SJ11072 Left Hand Telescopic Draft Link See Parts

Engine:

122.10

925 CCA battery recommended for optimum performance. Only compatible with machines built with serial number 340000 and before. For machines built after, see the parts catalog.

192.50

Compatible on 5E Open Station Series only.

Hitch and Drawbar:

See Parts

One required.

See Parts

Two required.

Hitch:

SJ11073 Right Hand Telescopic Draft Link See Parts

03 December 2014 US & Canada

2-TRACTOR- 3

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5055E Open Operator Station Utility Tractor (45 PTO hp)

Continued

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

ATTACHMENTS FOR FIELD CONVERSION ...Continued...

LVB25976 iMatch Quick Hitch Category 1 with adjustable top hook

Includes one set of Bushings (LVU15507).

Hydraulics:

LVB25925 Mid-Mount Dual SCV with Joystick Control

Compatible with 5103, 5203, 5303, 5403 and 5E Series Tractors. Open Station Only.

LVB25788 Motor Control Kit

Compatible with 5003 and 5E Series Tractors. Also order RE251179 if no mid-mount valve installed.

LVB25771 Second Rear SCV with Detented Float and Lever Control

Compatible with 5E Series Tractors and 5103-5403 models after S/N PY5103U013641, PY5203U005570, PY5303U007753, PY5403U000735. Open Station Only.

BLV10431 Second Rear SCV with Detented Float and Lever Control

Compatible with 5E Series 3-Cylinder, 12F/12R PowrReverser Transmission tractors. Open Station Only.

Lighting:

LVB25547 Auxiliary Rear Work Light Kit (1 Light)

Open Station Only.

SUGGESTED

LIST PRICE

USD ($)

357.50

1,411.30

2,086.70

805.20

63.80

LVB25817 Backup Alarm Kit

BLV10407 Operator's Manual and Decal Kit - French 0.00

BLV10406 Operator's Manual and Decal Kit - Spanish 0.00

LVB25727 PowrReverser Modulation Control Kit 147.40

LVB25926 Single Horn Kit

LVB25785 Canopy - Deluxe

LVB25334 Canopy - Standard

LVB25332 Canopy Mounting Bracket and Hardware Kit

LVB25889 Weight, Front Support - 100 Lb.

Miscellaneous:

161.70

NOT compatible with 2WD front axle (Code 1002) and 5D Series Tractors. Compatible with 5E 3-Cyl TSS open station tractors only.

51.70

OOS tractors only

Operator Environment:

961.40

Requires LVB25332 Canopy Mounting Bracket and Hardware Kit ordered separately.

583.00

Requires LVB25332 Canopy Mounting Bracket and Hardware Kit ordered separately.

105.60

Requires LVB25334 or LVB25785 Canopy Kit ordered separately.

Weights:

220.00

Kit includes front weight support and mounting hardware.

03 December 2014 US & Canada

2-TRACTOR- 4

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5055E Open Operator Station Utility Tractor (45 PTO hp)

Continued

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

ATTACHMENTS FOR FIELD CONVERSION ...Continued...

R213907 Weight, Rear Wheel - 95 Lb.

Not compatible on wheels sized 24" or smaller. Maximum of 2 per wheel.

SUGGESTED

LIST PRICE

USD ($)

222.20

03 December 2014 US & Canada

2-TRACTOR- 5

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5055E Open Operator Station Utility Tractor (45 PTO hp)

Continued

THIS PAGE IS INTENTIONALLY LEFT BLANK

03 December 2014 US & Canada

2-TRACTOR- 6

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5055E Cab Utility Tractor (45 PTO hp)

Equipment for Base Machine

ENGINE: 55 (40.0 kW) 97/68/EC Engine Horsepower @ 2400* RPM 45 (30.1 kW) PTO Horsepower @ 2400* RPM 3 Cylinder Turbocharged John Deere

TRANSMISSION: 12F/12R PowrReverser Transmission LH Electrohydraulic (EH)

Directional Reverser Right Hand Shifted Speeds and Ranges, Integrated Park Position Differential Lock Neutral Start Safety Switch Wet Traction Clutch

REAR AXLE: Flanged Rear Axle Planetary Final Drives

STEERING AND BRAKES: Hydrostatic Power Steering Hydraulically Actuated Wet Disk Brakes

Self-Equalizing and Self-Adjusting HYDRAULICS:

Open Center Hydraulic System Tandem Gear Pump 18.2 GPM (68.8 LPM) Maximum Total Flow

Steering Pump 6.8 GPM (25.7 LPM)

Implement Pump 11.4 GPM (43.1 LPM) One Rear Selective Control Valve

POWER TAKE-OFF SHAFT: Independent "Live" 540 RPM /540E

Rear PTO Shaft Electro-hydraulic PTO engagement

@ 2400 Rated Engine RPM Economy PTO setting for 540 PTO RPM

@ 1716 Engine RPM Wet PTO Clutch Flip Up PTO Shield Operator Presence Safety Warning - PTO Safety Start Switch

ROCKSHAFT, HITCH AND DRAWBAR: Rear Rockshaft with Position Control,

Draft Control, and Adjustable Rate of Drop 3-Point (Category II) Hitch

with Sway Chains -

Convertible to Category I

Adjustable Drawbar INSTRUMENTATION:

Electric Fuel Gauge Digital Display - Hour Meter/ Ground speed / PTO speed Oil Pressure Indicator Light Coolant Temperature Gauge Alternator Indicator Light Air Restriction Indicator Light Turn Signal Indicator Light High Beam Light PTO Engagement Light MFWD Engagement Indicator Light

ELECTRICAL: 12-Volt Electrical System One Battery - 950 CCA** with

180 Minute Reserve Capacity

90 Amp Alternator LIGHTS:

Two Front Halogen Headlights Two Turn/Flashing Warning Lights Two Tail Lights

MISCELLANEOUS: SMV Emblem Tilt-Up Hood Toolbox

BASE MACHINE: CAB

21.6 U.S. Gallon (82 L) Fuel Tank Capacity Left Hand Door Only Tilt and Telescopic Steering system with 12F/12R PowrReverser Transmission Air Conditioning Comfort cloth Mechanical Seat

Retractable Seat Belt Cup Holders Front Windshield Wiper Two Rear Roof-Mounted, Work Lights Two Front/Two Rear Roof-Mounted, Warning Lights MFWD (4 Wheel Drive) Front Axle 8-Position Steel Rear Wheels with

Two 14.9-28 6PR (R1) Tires 8-Position Steel Front Wheels with

Two 9.5-24 6PR (R1) Front Tires

* Manufacturer's Rating ** Cold Cranking Amps

SUGGESTED

LIST PRICE

USD ($)

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

Select One Code From Each Required Category

BASE MACHINE

1735LV 5055E Cab Utility Tractor (45 PTO hp) 34,922.00

03 December 2014 US & Canada

2-TRACTOR- 1

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5055E Cab Utility Tractor (45 PTO hp)

Continued

SUGGESTED

LIST PRICE

USD ($)

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

BASE MACHINE ...Continued...

OPERATORS MANUAL

0409 English Operators Manual and Decal Kit In Base Price

0413 French Operators Manual and Decal Kit Same Price

0437 Spanish Operators Manual and Decal Kit Same Price

TRANSMISSION

1363 9F/3R SyncShuttle Transmission (TSS)

9F/3R Partial Top Shaft Synchronized [TSS] (with 2WD front axle code-6020) 2nd & Reverse gears are synchronized in all ranges Integrated Park Position

9F/3R Full Top Shaft Synchronized [TSS] (with 4WD front axle code-6040) Synchronized Speed Shifts Integrated Park Position

1381 12F/12R PowrReverser Transmission - 540/540E (PR)

-2,160.00

In Base Price

MID SELECTIVE CONTROL VALVES

3420 Dual Mid Valves with Joystick Control

Recommended for applications WITH front loaders. Requires Code 6040 - MFWD.

REAR WHEELS WITH TIRES (TWO)

5101 14.9-28 In. 6PR R1 Bias

Code 6040 requires Code 6101.

5113 21.5L-16.1 In. 6PR R3 Bias

Code 6040 requires Code 6171.

5184 16.9-24 In. 6PR R4 Bias

Code 6040 requires Code 6133.

5185 16.9-28 In. 6PR R1 Bias

Code 6040 requires Code 6101.

FRONT AXLE

6040 MFWD (4 Wheel Drive)

Mechanical Engagement Engagement Indicator Light on PowrReverser Transmission.

03 December 2014 US & Canada

2-TRACTOR- 2

1,123.00

In Base Price

194.00

Same Price

284.00

In Base Price

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5055E Cab Utility Tractor (45 PTO hp)

Continued

SUGGESTED

LIST PRICE

USD ($)

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

FRONT AXLE ...Continued...

Requires Code 3420.

FRONT WHEELS WITH TIRES (TWO)

6101 9.5-24 In. 6PR R1 Bias In Base Price

6133 12.5/80-18 In. 6PR I3(R4 Type) Bias 88.00

6171 9.5-16 In. 6PR R3 Bias -290.00

FOR OPTION CODE 6040 (MFWD):

ATTACHMENTS FOR FIELD CONVERSION

L154683 Rear Axle 1.2 In. Extension (30 mm)

L154682 Rear Axle 1.6 In. Extension (40 mm)

Axle - Rear:

See Parts

Two required. Requires (16) 19M9364 Cap Screws (8 per Extension), ordered separately.

See Parts

Two required. Requires (16) 19M8979 Cap Screws (8 per Extension), ordered separately.

L154684 Rear Axle 4.4 In. Extension (111 mm)

Two required. Requires (16) 19M9365 Cap Screws (8 per Extension), ordered separately.

Engine:

LV150155 Engine Coolant Heater Kit (3 Cyl.) 96.80

LVB25110 Heavy Duty Air Intake Pre-Heater

925 CCA battery recommended for optimum performance. Only compatible with machines built with serial number 340000 and before. For machines built after, see the parts catalog.

BSJ10021 Horizontal Side Exhaust

Compatible with 5E Cab Tractors.

Fenders:

LVB25714 Rear Fender Extension Kit

Cab Tractors only.

Hitch and Drawbar:

T12553 Center Link Conversion Bushing, Cat. II to Cat. I

One required.

R66432 Draft Link Conversion Bushing, Cat. II to Cat. I

Two required.

R133359 Drawbar - Offset See Parts

See Parts

122.10

See Parts

209.00

See Parts

RE39830 Drawbar Clevis Kit (Hammer Strap) - Offset Drawbar See Parts

03 December 2014 US & Canada

2-TRACTOR- 3

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5055E Cab Utility Tractor (45 PTO hp)

Continued

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

SUGGESTED

LIST PRICE

USD ($)

ATTACHMENTS FOR FIELD CONVERSION ...Continued...

RE39829 Drawbar Clevis Kit (Hammer Strap) - Straight Drawbar See Parts

TY16042 Quik-Coupler, Economy, Category 2 See Parts

SJ11072 Left Hand Telescopic Draft Link See Parts

SJ11073 Right Hand Telescopic Draft Link See Parts

LVB25976 iMatch Quick Hitch Category 1 with adjustable top hook

BLV10347 Mid-Mount Dual SCV with Joystick Control

LVB25788 Motor Control Kit

BLV10348 Second Rear SCV with Detented Float and Lever Control

Hitch:

357.50

Includes one set of Bushings (LVU15507).

Hydraulics:

1,411.30

Compatible with 5E Cab Tractors.

2,086.70

Compatible with 5003 and 5E Series Tractors. Also order RE251179 if no mid-mount valve installed.

805.20

Compatible with 5E Cab Tractors.

BLV10349 Front working lights

LVB25728 Backup Alarm Kit

BLV10407 Operator's Manual and Decal Kit - French 0.00

BLV10406 Operator's Manual and Decal Kit - Spanish 0.00

LVB25727 PowrReverser Modulation Control Kit 147.40

LVB26096 Single Horn Kit

SJ10170 Antenna

AH104259 Ash Tray

AR60937 Cigarette Lighter

Lighting:

150.70

Cab Only.

Miscellaneous:

161.70

Compatible with 5E 3-Cyl Cab tractors and PR Open Station Tractors.

51.70

CAB tractors only

Operator Environment:

See Parts

Cab only

See Parts

Cab only.

See Parts

Cab only.

03 December 2014 US & Canada

2-TRACTOR- 4

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5055E Cab Utility Tractor (45 PTO hp)

Continued

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

ATTACHMENTS FOR FIELD CONVERSION ...Continued...

RE334177 John Deere/Delco AM/FM Weatherband Radio

Cab Only. Requires Standard Cab Antenna Kit (SJ10170), ordered separately. MY2011 and newer Tractors also require the following: AT209965 Ground Strap, 37M7090 Self-tapping screw M6 X 1 X 16 to attach Ground Strap to roof metal structure, 14M7450 Flange nut M5 x 0.8 to attach ground strap to radio.

RE244177 Kit, Rear View Mirror Mounting Kit

Cab only. Requires AL80127 and/or AL80126Kit contains support plates and hardware for one rear view mirror.

AL80126 Mirror, Telescopic, LH, Manually Adjustable

Cab only.

AL80127 Mirror, Telescopic, RH, Manually Adjustable

Cab only.

BLV10350 Right Hand Door

Cab Only

BLV10173 Wiper/Washer, Rear

Cab only.

Weights:

LVB25889 Weight, Front Support - 100 Lb.

Kit includes front weight support and mounting hardware.

SUGGESTED

LIST PRICE

USD ($)

See Parts

171.60

291.50

343.20

220.00

R213907 Weight, Rear Wheel - 95 Lb.

Not compatible on wheels sized 24" or smaller. Maximum of 2 per wheel.

222.20

03 December 2014 US & Canada

2-TRACTOR- 5

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5055E Cab Utility Tractor (45 PTO hp)

Continued

THIS PAGE IS INTENTIONALLY LEFT BLANK

03 December 2014 US & Canada

2-TRACTOR- 6

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5065E Open Operator Station Utility Tractor (49-53 PTO hp)

Equipment for Base Machine

ENGINE: 65 (47.5 kW) 97/68/EC Engine Horsepower @ 2400 RPM* 53 (39.0 kW) PTO Horsepower @ 2400 RPM* 3 Cylinder Turbocharged John Deere

TRANSMISSION: 9F/3R SyncShuttle - 2R, 5R and 8R

Synchronized Shuttle Shifts and Speed Shifts,

Integrated Park Position Right Hand Shifted Speeds Left Hand Shifted Ranges Differential Lock Neutral Start Safety Switch

REAR AXLE: Flanged Rear Axle Planetary Final Drives

STEERING AND BRAKES: Hydrostatic Power Steering Hydraulically Actuated Wet Disk Brakes

Self-Equalizing and Self-Adjusting HYDRAULICS:

Open Center Hydraulic System Tandem Gear Pump 18.2 GPM (68.8 LPM) Maximum Total Flow

Steering Pump 6.8 GPM (25.7 LPM)

Implement Pump 11.4 GPM (43.1 LPM) One Rear Selective Control Valve

POWER TAKE-OFF SHAFT: Independent "Live" 540 RPM Rear PTO Shaft Operator Presence Safety Warning - PTO Safety Start Switch

ROCKSHAFT, HITCH AND DRAWBAR: Rear Rockshaft with Position Control,

Draft Control, and Adjustable Rate of Drop 3-Point (Category II) Hitch

with Sway Chains -

Convertible to Category I

Interchangeable Hitch Balls

Adjustable Drawbar INSTRUMENTATION:

ELECTRICAL: 12-Volt Electrical System One Battery - 623 CCA** with

145 Minute Reserve Capacity

40 Amp Alternator LIGHTS:

Two Front Halogen Headlights Two Turn/Flashing Warning Lights Two Tail Lights

MISCELLANEOUS: SMV Emblem Tilt-Up Hood Fender Mounted Toolbox

BASE MACHINE: 2-Post Foldable Roll-Over Protective

Structure (ROPS)

Deluxe Adjustable Vinyl Seat with

Retractable Seat Belt 18 U.S. Gallon (68.1 L) Fuel Tank Capacity Adjustable Front Axle (56-80 In.) 8-Position Steel Rear Wheels with

Two Rear Tires 16.9-28 6PR (R1) 2-Position Steel Front Wheels with

Two Front Tires 7.50-16 6PR (F2)

* Manufacturer's Rating ** Cold Cranking Amps

SUGGESTED

LIST PRICE

USD ($)

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

Select One Code From Each Required Category

BASE MACHINE

1743LV 5065E Open Operator Station Utility Tractor (49-53 PTO hp) 21,689.00

OPERATORS MANUAL

0409 English Operators Manual and Decal Kit In Base Price

0413 French Operators Manual and Decal Kit Same Price

03 December 2014 US & Canada

2-TRACTOR- 1

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5065E Open Operator Station Utility Tractor (49-53 PTO hp)

Continued

SUGGESTED

LIST PRICE

USD ($)

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

OPERATORS MANUAL ...Continued...

0437 Spanish Operators Manual and Decal Kit Same Price

TRANSMISSION

1363 9F/3R SyncShuttle Transmission (TSS)

9F/3R Partial Top Shaft Synchronized [TSS] (with 2WD front axle code-6020) 2nd & Reverse gears are synchronized in all ranges Integrated Park Position

9F/3R Full Top Shaft Synchronized [TSS] (with 4WD front axle code-6040) Synchronized Speed Shifts Integrated Park Position

1381 12F/12R PowrReverser Transmission - 540/540E (PR)

In Base Price

2,160.00

MID SELECTIVE CONTROL VALVES

3400 Less Mid Valves

Recommended for applications WITHOUT front loaders. Can later be upgraded for front loader and/or other hydraulic applications using field-installed attachments. Requires Code 6020 - 2WD.

3420 Dual Mid Valves with Joystick Control

Recommended for applications WITH front loaders. Requires Code 6040 - MFWD.

In Base Price

1,123.00

REAR WHEELS WITH TIRES (TWO)

5113 21.5L-16.1 In. 6PR R3 Bias

Code 6020 requires Code 6103 or Code 6040 requires Code 6171.

5184 16.9-24 In. 6PR R4 Bias

Code 6040 requires Code 6133.

5185 16.9-28 In. 6PR R1 Bias

Code 6020 requires Code 6102 or Code 6040 requires Code 6101.

-90.00

-284.00

In Base Price

FRONT AXLE

6020 2 Wheel Drive In Base Price

6040 MFWD (4 Wheel Drive)

Mechanical Engagement Engagement Indicator Light on PowrReverser Transmission. Requires Code 3420.

5,296.00

03 December 2014 US & Canada

2-TRACTOR- 2

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5065E Open Operator Station Utility Tractor (49-53 PTO hp)

Continued

SUGGESTED

LIST PRICE

USD ($)

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

FRONT WHEELS WITH TIRES (TWO)

6102 7.50-16 In. 6PR F2 Bias In Base Price

6103 27/12LL-15 In. 6PR Turf Special Bias 486.00

6101 9.5-24 In. 6PR R1 Bias 682.00

6133 12.5/80-18 In. 6PR I3(R4 Type) Bias 754.00

6171 9.5-16 In. 6PR R3 Bias 392.00

FOR OPTION CODE 6020 (2WD):

FOR OPTION CODE 6040 (MFWD):

ATTACHMENTS FOR FIELD CONVERSION

L154683 Rear Axle 1.2 In. Extension (30 mm)

L154682 Rear Axle 1.6 In. Extension (40 mm)

Axle - Rear:

See Parts

Two required. Requires (16) 19M9364 Cap Screws (8 per Extension), ordered separately.

See Parts

Two required. Requires (16) 19M8979 Cap Screws (8 per Extension), ordered separately.

L154684 Rear Axle 4.4 In. Extension (111 mm)

Two required. Requires (16) 19M9365 Cap Screws (8 per Extension), ordered separately.

Engine:

LV150155 Engine Coolant Heater Kit (3 Cyl.) 96.80

LVB25110 Heavy Duty Air Intake Pre-Heater

925 CCA battery recommended for optimum performance. Only compatible with machines built with serial number 340000 and before. For machines built after, see the parts catalog.

LVB25900 Horizontal Side Exhaust

Compatible on 5E Open Station Series only.

Hitch and Drawbar:

T12553 Center Link Conversion Bushing, Cat. II to Cat. I

One required.

R66432 Draft Link Conversion Bushing, Cat. II to Cat. I

Two required.

R133359 Drawbar - Offset See Parts

RE39830 Drawbar Clevis Kit (Hammer Strap) - Offset Drawbar See Parts

RE39829 Drawbar Clevis Kit (Hammer Strap) - Straight Drawbar See Parts

See Parts

122.10

192.50

See Parts

03 December 2014 US & Canada

2-TRACTOR- 3

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5065E Open Operator Station Utility Tractor (49-53 PTO hp)

Continued

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

SUGGESTED

LIST PRICE

USD ($)

ATTACHMENTS FOR FIELD CONVERSION ...Continued...

TY16042 Quik-Coupler, Economy, Category 2 See Parts

SJ11072 Left Hand Telescopic Draft Link See Parts

SJ11073 Right Hand Telescopic Draft Link See Parts

LVB25976 iMatch Quick Hitch Category 1 with adjustable top hook

LVB25925 Mid-Mount Dual SCV with Joystick Control

LVB25788 Motor Control Kit

LVB25771 Second Rear SCV with Detented Float and Lever Control

BLV10431 Second Rear SCV with Detented Float and Lever Control

Hitch:

357.50

Includes one set of Bushings (LVU15507).

Hydraulics:

1,411.30

Compatible with 5103, 5203, 5303, 5403 and 5E Series Tractors. Open Station Only.

2,086.70

Compatible with 5003 and 5E Series Tractors. Also order RE251179 if no mid-mount valve installed.

805.20

Compatible with 5E Series Tractors and 5103-5403 models after S/N PY5103U013641, PY5203U005570, PY5303U007753, PY5403U000735. Open Station Only.

805.20

Compatible with 5E Series 3-Cylinder, 12F/12R PowrReverser Transmission tractors. Open Station Only.

LVB25547 Auxiliary Rear Work Light Kit (1 Light)

LVB25817 Backup Alarm Kit

BLV10407 Operator's Manual and Decal Kit - French 0.00

BLV10406 Operator's Manual and Decal Kit - Spanish 0.00

LVB25727 PowrReverser Modulation Control Kit 147.40

LVB25926 Single Horn Kit

LVB25785 Canopy - Deluxe

LVB25334 Canopy - Standard

Lighting:

63.80

Open Station Only.

Miscellaneous:

161.70

NOT compatible with 2WD front axle (Code 1002) and 5D Series Tractors. Compatible with 5E 3-Cyl TSS open station tractors only.

51.70

OOS tractors only

Operator Environment:

961.40

Requires LVB25332 Canopy Mounting Bracket and Hardware Kit ordered separately.

583.00

Requires LVB25332 Canopy Mounting Bracket and Hardware Kit ordered separately.

03 December 2014 US & Canada

2-TRACTOR- 4

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5065E Open Operator Station Utility Tractor (49-53 PTO hp)

Continued

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

ATTACHMENTS FOR FIELD CONVERSION ...Continued...

LVB25332 Canopy Mounting Bracket and Hardware Kit

Requires LVB25334 or LVB25785 Canopy Kit ordered separately.

Weights:

LVB25889 Weight, Front Support - 100 Lb.

Kit includes front weight support and mounting hardware.

R213907 Weight, Rear Wheel - 95 Lb.

Not compatible on wheels sized 24" or smaller. Maximum of 2 per wheel.

SUGGESTED

LIST PRICE

USD ($)

105.60

220.00

222.20

03 December 2014 US & Canada

2-TRACTOR- 5

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5065E Open Operator Station Utility Tractor (49-53 PTO hp)

Continued

THIS PAGE IS INTENTIONALLY LEFT BLANK

03 December 2014 US & Canada

2-TRACTOR- 6

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5065E Cab Utility Tractor (49 PTO hp)

Equipment for Base Machine

ENGINE: 65 (47.5 kW) 97/68/EC Engine Horsepower @ 2400 RPM* 49 (36.0 kW) PTO Horsepower @ 2400 RPM* 3 Cylinder Turbocharged John Deere

TRANSMISSION: 12F/12R PowrReverser Transmission LH Electrohydraulic (EH)

Directional Reverser Right Hand Shifted Speeds and Ranges, Integrated Park Position Differential Lock Neutral Start Safety Switch Wet Traction Clutch

REAR AXLE: Flanged Rear Axle Planetary Final Drives

STEERING AND BRAKES: Hydrostatic Power Steering Hydraulically Actuated Wet Disk Brakes

Self-Equalizing and Self-Adjusting HYDRAULICS:

Open Center Hydraulic System Tandem Gear Pump 18.2 GPM (68.8 LPM) Maximum Total Flow

Steering Pump 6.8 GPM (25.7 LPM)

Implement Pump 11.4 GPM (43.1 LPM) One Rear Selective Control Valve

POWER TAKE-OFF SHAFT: Independent "Live" 540 RPM /540E

Rear PTO Shaft Electro-hydraulic PTO engagement

@ 2400 Rated Engine RPM Economy PTO setting for 540 PTO RPM

@ 1716 Engine RPM Wet PTO Clutch Flip Up PTO Shield Operator Presence Safety Warning - PTO Safety Start Switch

ROCKSHAFT, HITCH AND DRAWBAR: Rear Rockshaft with Position Control,

Draft Control, and Adjustable Rate of Drop 3-Point (Category II) Hitch

with Sway Chains -

Convertible to Category I

Adjustable Drawbar INSTRUMENTATION:

ELECTRICAL: 12-Volt Electrical System One Battery - 950 CCA** with

180 Minute Reserve Capacity

90 Amp Alternator LIGHTS:

Two Front Halogen Headlights Two Turn/Flashing Warning Lights Two Tail Lights

MISCELLANEOUS: SMV Emblem Tilt-Up Hood Toolbox

BASE MACHINE: CAB

21.6 U.S. Gallon (82 L) Fuel Tank Capacity Left Hand Door Only Tilt and Telescopic Steering system with 12F/12R PowrReverser Transmission Air Conditioning Comfort cloth Mechanical Seat

Two 16.9-28 6PR (R1) Tires 8-Position Steel Front Wheels with

Two 9.5-24 6PR (R1) Front Tires

* Manufacturer's Rating ** Cold Cranking Amps

SUGGESTED

LIST PRICE

USD ($)

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

Select One Code From Each Required Category

BASE MACHINE

1745LV 5065E Cab Utility Tractor (49 PTO hp) 37,426.00

03 December 2014 US & Canada

2-TRACTOR- 1

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5065E Cab Utility Tractor (49 PTO hp)

Continued

SUGGESTED

LIST PRICE

USD ($)

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

BASE MACHINE ...Continued...

OPERATORS MANUAL

0409 English Operators Manual and Decal Kit In Base Price

0413 French Operators Manual and Decal Kit Same Price

0437 Spanish Operators Manual and Decal Kit Same Price

TRANSMISSION

1381 12F/12R PowrReverser Transmission - 540/540E (PR)

In Base Price

MID SELECTIVE CONTROL VALVES

3420 Dual Mid Valves with Joystick Control

Recommended for applications WITH front loaders. Requires Code 6040 - MFWD.

1,123.00

REAR WHEELS WITH TIRES (TWO)

5113 21.5L-16.1 In. 6PR R3 Bias

Code 6040 requires Code 6171.

5184 16.9-24 In. 6PR R4 Bias

Code 6040 requires Code 6133.

5185 16.9-28 In. 6PR R1 Bias

Code 6040 requires Code 6101.

-90.00

-284.00

In Base Price

FRONT AXLE

6040 MFWD (4 Wheel Drive)

Mechanical Engagement Engagement Indicator Light on PowrReverser Transmission. Requires Code 3420.

In Base Price

FRONT WHEELS WITH TIRES (TWO)

6101 9.5-24 In. 6PR R1 Bias In Base Price

6133 12.5/80-18 In. 6PR I3(R4 Type) Bias 88.00

FOR OPTION CODE 6040 (MFWD):

03 December 2014 US & Canada

2-TRACTOR- 2

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5065E Cab Utility Tractor (49 PTO hp)

Continued

SUGGESTED

LIST PRICE

USD ($)

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

FRONT WHEELS WITH TIRES (TWO) ...Continued...

6171 9.5-16 In. 6PR R3 Bias -290.00

ATTACHMENTS FOR FIELD CONVERSION

L154683 Rear Axle 1.2 In. Extension (30 mm)

L154682 Rear Axle 1.6 In. Extension (40 mm)

L154684 Rear Axle 4.4 In. Extension (111 mm)

LV150155 Engine Coolant Heater Kit (3 Cyl.) 96.80

LVB25110 Heavy Duty Air Intake Pre-Heater

Axle - Rear:

See Parts

Two required. Requires (16) 19M9364 Cap Screws (8 per Extension), ordered separately.

See Parts

Two required. Requires (16) 19M8979 Cap Screws (8 per Extension), ordered separately.

See Parts

Two required. Requires (16) 19M9365 Cap Screws (8 per Extension), ordered separately.

Engine:

122.10

925 CCA battery recommended for optimum performance. Only compatible with machines built with serial number 340000 and before. For machines built after, see the parts catalog.

BSJ10021 Horizontal Side Exhaust

Compatible with 5E Cab Tractors.

Fenders:

LVB25714 Rear Fender Extension Kit

Cab Tractors only.

Hitch and Drawbar:

T12553 Center Link Conversion Bushing, Cat. II to Cat. I

One required.

R66432 Draft Link Conversion Bushing, Cat. II to Cat. I

Two required.

R133359 Drawbar - Offset See Parts

RE39830 Drawbar Clevis Kit (Hammer Strap) - Offset Drawbar See Parts

RE39829 Drawbar Clevis Kit (Hammer Strap) - Straight Drawbar See Parts

TY16042 Quik-Coupler, Economy, Category 2 See Parts

Hitch:

SJ11072 Left Hand Telescopic Draft Link See Parts

SJ11073 Right Hand Telescopic Draft Link See Parts

See Parts

209.00

See Parts

03 December 2014 US & Canada

2-TRACTOR- 3

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5065E Cab Utility Tractor (49 PTO hp)

Continued

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

ATTACHMENTS FOR FIELD CONVERSION ...Continued...

LVB25976 iMatch Quick Hitch Category 1 with adjustable top hook

Includes one set of Bushings (LVU15507).

Hydraulics:

BLV10347 Mid-Mount Dual SCV with Joystick Control

Compatible with 5E Cab Tractors.

LVB25788 Motor Control Kit

Compatible with 5003 and 5E Series Tractors. Also order RE251179 if no mid-mount valve installed.

BLV10348 Second Rear SCV with Detented Float and Lever Control

Compatible with 5E Cab Tractors.

Lighting:

BLV10349 Front working lights

Cab Only.

Miscellaneous:

LVB25728 Backup Alarm Kit

Compatible with 5E 3-Cyl Cab tractors and PR Open Station Tractors.

SUGGESTED

LIST PRICE

USD ($)

357.50

1,411.30

2,086.70

805.20

150.70

161.70

BLV10407 Operator's Manual and Decal Kit - French 0.00

BLV10406 Operator's Manual and Decal Kit - Spanish 0.00

LVB25727 PowrReverser Modulation Control Kit 147.40

LVB26096 Single Horn Kit

CAB tractors only

Operator Environment:

SJ10170 Antenna

Cab only

AH104259 Ash Tray

Cab only.

AR60937 Cigarette Lighter

Cab only.

RE334177 John Deere/Delco AM/FM Weatherband Radio

RE244177 Kit, Rear View Mirror Mounting Kit

Cab only. Requires AL80127 and/or AL80126Kit contains support plates and hardware for one rear view mirror.

51.70

See Parts

AL80126 Mirror, Telescopic, LH, Manually Adjustable

Cab only.

03 December 2014 US & Canada

2-TRACTOR- 4

171.60

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5065E Cab Utility Tractor (49 PTO hp)

Continued

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

ATTACHMENTS FOR FIELD CONVERSION ...Continued...

AL80127 Mirror, Telescopic, RH, Manually Adjustable

Cab only.

BLV10350 Right Hand Door

Cab Only

BLV10173 Wiper/Washer, Rear

Cab only.

Weights:

LVB25889 Weight, Front Support - 100 Lb.

Kit includes front weight support and mounting hardware.

R213907 Weight, Rear Wheel - 95 Lb.

Not compatible on wheels sized 24" or smaller. Maximum of 2 per wheel.

SUGGESTED

LIST PRICE

USD ($)

171.60

291.50

343.20

220.00

222.20

03 December 2014 US & Canada

2-TRACTOR- 5

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5065E Cab Utility Tractor (49 PTO hp)

Continued

THIS PAGE IS INTENTIONALLY LEFT BLANK

03 December 2014 US & Canada

2-TRACTOR- 6

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5075E Open Operator Station Utility Tractor (57-61 PTO hp)

Equipment for Base Machine

ENGINE: 75 (55.0 kW) 97/68/EC Engine Horsepower @ 2400 RPM* 61 (44.9 kW) PTO Horsepower @ 2400 RPM* 3 Cylinder Turbocharged John Deere

TRANSMISSION: 9F/3R SyncShuttle - 2R, 5R and 8R

Synchronized Shuttle Shifts and Speed Shifts,

Integrated Park Position Right Hand Shifted Speeds Left Hand Shifted Ranges Differential Lock Neutral Start Safety Switch

REAR AXLE: Flanged Rear Axle Planetary Final Drives

STEERING AND BRAKES: Hydrostatic Power Steering Hydraulically Actuated Wet Disk Brakes

Self-Equalizing and Self-Adjusting HYDRAULICS:

Open Center Hydraulic System Tandem Gear Pump 18.2 GPM (68.8 LPM) Maximum Total Flow

Steering Pump 6.8 GPM (25.7 LPM)

Implement Pump 11.4 GPM (43.1 LPM) One Rear Selective Control Valve

POWER TAKE-OFF SHAFT: Independent "Live" 540 RPM Rear PTO Shaft Operator Presence Safety Warning - PTO Safety Start Switch

ROCKSHAFT, HITCH AND DRAWBAR: Rear Rockshaft with Position Control,

Draft Control, and Adjustable Rate of Drop 3-Point (Category II) Hitch

with Sway Chains -

Convertible to Category I

Interchangeable Hitch Balls

Adjustable Drawbar INSTRUMENTATION:

ELECTRICAL: 12-Volt Electrical System One Battery - 623 CCA** with

145 Minute Reserve Capacity

40 Amp Alternator LIGHTS:

Two Front Halogen Headlights Two Turn/Flashing Warning Lights Two Tail Lights

MISCELLANEOUS: SMV Emblem Tilt-Up Hood Fender Mounted Toolbox

BASE MACHINE: 2-Post Foldable Roll-Over Protective

Structure (ROPS)

Deluxe Adjustable Vinyl Seat with

Retractable Seat Belt 18 U.S. Gallon (68.1 L) Fuel Tank Capacity Adjustable Front Axle (56-80 In.) 8-Position Steel Rear Wheels with

Two Rear Tires 16.9-28 6PR (R1) 2-Position Steel Front Wheels with

Two Front Tires 7.50-16 6PR (F2)

* Manufacturer's Rating ** Cold Cranking Amps

SUGGESTED

LIST PRICE

USD ($)

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

Select One Code From Each Required Category

BASE MACHINE

1753LV 5075E Open Operator Station Utility Tractor (57-61 PTO hp) 24,310.00

OPERATORS MANUAL

0409 English Operators Manual and Decal Kit In Base Price

0413 French Operators Manual and Decal Kit Same Price

03 December 2014 US & Canada

2-TRACTOR- 1

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5075E Open Operator Station Utility Tractor (57-61 PTO hp)

Continued

SUGGESTED

LIST PRICE

USD ($)

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

OPERATORS MANUAL ...Continued...

0437 Spanish Operators Manual and Decal Kit Same Price

TRANSMISSION

1363 9F/3R SyncShuttle Transmission (TSS)

9F/3R Partial Top Shaft Synchronized [TSS] (with 2WD front axle code-6020) 2nd & Reverse gears are synchronized in all ranges Integrated Park Position

9F/3R Full Top Shaft Synchronized [TSS] (with 4WD front axle code-6040) Synchronized Speed Shifts Integrated Park Position

1381 12F/12R PowrReverser Transmission - 540/540E (PR)

In Base Price

2,160.00

MID SELECTIVE CONTROL VALVES

3400 Less Mid Valves

Recommended for applications WITHOUT front loaders. Can later be upgraded for front loader and/or other hydraulic applications using field-installed attachments. Requires Code 6020 - 2WD.

3420 Dual Mid Valves with Joystick Control

Recommended for applications WITH front loaders. Requires Code 6040 - MFWD.

In Base Price

1,123.00

REAR WHEELS WITH TIRES (TWO)

5113 21.5L-16.1 In. 6PR R3 Bias

Code 6020 requires Code 6103 or Code 6040 requires Code 6171.

5184 16.9-24 In. 6PR R4 Bias

Code 6040 requires Code 6133.

5185 16.9-28 In. 6PR R1 Bias

Code 6020 requires Code 6102 or Code 6040 requires Code 6101.

-90.00

-284.00

In Base Price

FRONT AXLE

6020 2 Wheel Drive In Base Price

6040 MFWD (4 Wheel Drive)

Mechanical Engagement Engagement Indicator Light on PowrReverser Transmission. Requires Code 3420.

5,296.00

03 December 2014 US & Canada

2-TRACTOR- 2

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5075E Open Operator Station Utility Tractor (57-61 PTO hp)

Continued

SUGGESTED

LIST PRICE

USD ($)

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

FRONT WHEELS WITH TIRES (TWO)

6102 7.50-16 In. 6PR F2 Bias In Base Price

6103 27/12LL-15 In. 6PR Turf Special Bias 486.00

6101 9.5-24 In. 6PR R1 Bias 682.00

6133 12.5/80-18 In. 6PR I3(R4 Type) Bias 754.00

6171 9.5-16 In. 6PR R3 Bias 392.00

FOR OPTION CODE 6020 (2WD):

FOR OPTION CODE 6040 (MFWD):

ATTACHMENTS FOR FIELD CONVERSION

L154683 Rear Axle 1.2 In. Extension (30 mm)

L154682 Rear Axle 1.6 In. Extension (40 mm)

Axle - Rear:

See Parts

Two required. Requires (16) 19M9364 Cap Screws (8 per Extension), ordered separately.

See Parts

Two required. Requires (16) 19M8979 Cap Screws (8 per Extension), ordered separately.

L154684 Rear Axle 4.4 In. Extension (111 mm)

Two required. Requires (16) 19M9365 Cap Screws (8 per Extension), ordered separately.

Engine:

LV150155 Engine Coolant Heater Kit (3 Cyl.) 96.80

LVB25110 Heavy Duty Air Intake Pre-Heater

925 CCA battery recommended for optimum performance. Only compatible with machines built with serial number 340000 and before. For machines built after, see the parts catalog.

LVB25900 Horizontal Side Exhaust

Compatible on 5E Open Station Series only.

Hitch and Drawbar:

T12553 Center Link Conversion Bushing, Cat. II to Cat. I

One required.

R66432 Draft Link Conversion Bushing, Cat. II to Cat. I

Two required.

R133359 Drawbar - Offset See Parts

RE39830 Drawbar Clevis Kit (Hammer Strap) - Offset Drawbar See Parts

RE39829 Drawbar Clevis Kit (Hammer Strap) - Straight Drawbar See Parts

See Parts

122.10

192.50

See Parts

03 December 2014 US & Canada

2-TRACTOR- 3

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5075E Open Operator Station Utility Tractor (57-61 PTO hp)

Continued

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

SUGGESTED

LIST PRICE

USD ($)

ATTACHMENTS FOR FIELD CONVERSION ...Continued...

TY16042 Quik-Coupler, Economy, Category 2 See Parts

SJ11072 Left Hand Telescopic Draft Link See Parts

SJ11073 Right Hand Telescopic Draft Link See Parts

LVB25976 iMatch Quick Hitch Category 1 with adjustable top hook

LVB25925 Mid-Mount Dual SCV with Joystick Control

LVB25788 Motor Control Kit

LVB25771 Second Rear SCV with Detented Float and Lever Control

BLV10431 Second Rear SCV with Detented Float and Lever Control

Hitch:

357.50

Includes one set of Bushings (LVU15507).

Hydraulics:

1,411.30

Compatible with 5103, 5203, 5303, 5403 and 5E Series Tractors. Open Station Only.

2,086.70

Compatible with 5003 and 5E Series Tractors. Also order RE251179 if no mid-mount valve installed.

805.20

Compatible with 5E Series Tractors and 5103-5403 models after S/N PY5103U013641, PY5203U005570, PY5303U007753, PY5403U000735. Open Station Only.

805.20

Compatible with 5E Series 3-Cylinder, 12F/12R PowrReverser Transmission tractors. Open Station Only.

LVB25547 Auxiliary Rear Work Light Kit (1 Light)

LVB25817 Backup Alarm Kit

BLV10407 Operator's Manual and Decal Kit - French 0.00

BLV10406 Operator's Manual and Decal Kit - Spanish 0.00

LVB25727 PowrReverser Modulation Control Kit 147.40

LVB25926 Single Horn Kit

LVB25785 Canopy - Deluxe

LVB25334 Canopy - Standard

Lighting:

63.80

Open Station Only.

Miscellaneous:

161.70

NOT compatible with 2WD front axle (Code 1002) and 5D Series Tractors. Compatible with 5E 3-Cyl TSS open station tractors only.

51.70

OOS tractors only

Operator Environment:

961.40

Requires LVB25332 Canopy Mounting Bracket and Hardware Kit ordered separately.

583.00

Requires LVB25332 Canopy Mounting Bracket and Hardware Kit ordered separately.

03 December 2014 US & Canada

2-TRACTOR- 4

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5075E Open Operator Station Utility Tractor (57-61 PTO hp)

Continued

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

ATTACHMENTS FOR FIELD CONVERSION ...Continued...

LVB25332 Canopy Mounting Bracket and Hardware Kit

Requires LVB25334 or LVB25785 Canopy Kit ordered separately.

Weights:

LVB25889 Weight, Front Support - 100 Lb.

Kit includes front weight support and mounting hardware.

R213907 Weight, Rear Wheel - 95 Lb.

Not compatible on wheels sized 24" or smaller. Maximum of 2 per wheel.

SUGGESTED

LIST PRICE

USD ($)

105.60

220.00

222.20

03 December 2014 US & Canada

2-TRACTOR- 5

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5075E Open Operator Station Utility Tractor (57-61 PTO hp)

Continued

THIS PAGE IS INTENTIONALLY LEFT BLANK

03 December 2014 US & Canada

2-TRACTOR- 6

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5075E Cab Utility Tractor (57 PTO hp)

Equipment for Base Machine

ENGINE: 75 (55.0 kW) 97/68/EC Engine Horsepower @ 2400 RPM*

57.2 (42.0 kW) PTO Horsepower @ 2400 RPM* 3 Cylinder Turbocharged John Deere

TRANSMISSION: 12F/12R PowrReverser Transmission LH Electrohydraulic (EH)

Directional Reverser Right Hand Shifted Speeds and Ranges, Integrated Park Position Differential Lock Neutral Start Safety Switch Wet Traction Clutch

REAR AXLE: Flanged Rear Axle Planetary Final Drives

STEERING AND BRAKES: Hydrostatic Power Steering Hydraulically Actuated Wet Disk Brakes

Self-Equalizing and Self-Adjusting HYDRAULICS:

Open Center Hydraulic System Tandem Gear Pump 18.2 GPM (68.8 LPM) Maximum Total Flow

Steering Pump 6.8 GPM (25.7 LPM)

Implement Pump 11.4 GPM (43.1 LPM) One Rear Selective Control Valve

POWER TAKE-OFF SHAFT: Independent "Live" 540 RPM /540E

Rear PTO Shaft Electro-hydraulic PTO engagement

@ 2400 Rated Engine RPM Economy PTO setting for 540 PTO RPM

@ 1716 Engine RPM Wet PTO Clutch Flip Up PTO Shield Operator Presence Safety Warning - PTO Safety Start Switch

ROCKSHAFT, HITCH AND DRAWBAR: Rear Rockshaft with Position Control,

Draft Control, and Adjustable Rate of Drop 3-Point (Category II) Hitch

with Sway Chains -

Convertible to Category I

Adjustable Drawbar INSTRUMENTATION:

ELECTRICAL: 12-Volt Electrical System One Battery - 950 CCA** with

180 Minute Reserve Capacity

90 Amp Alternator LIGHTS:

Two Front Halogen Headlights Two Turn/Flashing Warning Lights Two Tail Lights

MISCELLANEOUS: SMV Emblem Tilt-Up Hood Toolbox

BASE MACHINE: CAB

21.6 U.S. Gallon (82 L) Fuel Tank Capacity Left Hand Door Only Tilt and Telescopic Steering system with 12F/12R PowrReverser Transmission Air Conditioning Comfort cloth Mechanical Seat

Two 16.9-28 6PR (R1) Tires 8-Position Steel Front Wheels with

Two 9.5-24 6PR (R1) Front Tires

* Manufacturer's Rating ** Cold Cranking Amps

SUGGESTED

LIST PRICE

USD ($)

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

Select One Code From Each Required Category

BASE MACHINE

1755LV 5075E Cab Utility Tractor (57 PTO hp) 39,646.00

03 December 2014 US & Canada

2-TRACTOR- 1

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5075E Cab Utility Tractor (57 PTO hp)

Continued

SUGGESTED

LIST PRICE

USD ($)

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

BASE MACHINE ...Continued...

OPERATORS MANUAL

0409 English Operators Manual and Decal Kit In Base Price

0413 French Operators Manual and Decal Kit Same Price

0437 Spanish Operators Manual and Decal Kit Same Price

TRANSMISSION

1381 12F/12R PowrReverser Transmission - 540/540E (PR)

In Base Price

MID SELECTIVE CONTROL VALVES

3420 Dual Mid Valves with Joystick Control

Recommended for applications WITH front loaders. Requires Code 6040 - MFWD.

1,123.00

REAR WHEELS WITH TIRES (TWO)

5184 16.9-24 In. 6PR R4 Bias

Code 6040 requires Code 6133.

5185 16.9-28 In. 6PR R1 Bias

Code 6040 requires Code 6101.

5113 21.5L-16.1 In. 6PR R3 Bias

Code 6040 requires Code 6171.

-284.00

In Base Price

-90.00

FRONT AXLE

6040 MFWD (4 Wheel Drive)

Mechanical Engagement Engagement Indicator Light on PowrReverser Transmission. Requires Code 3420.

In Base Price

FRONT WHEELS WITH TIRES (TWO)

6101 9.5-24 In. 6PR R1 Bias In Base Price

6133 12.5/80-18 In. 6PR I3(R4 Type) Bias 88.00

FOR OPTION CODE 6040 (MFWD):

03 December 2014 US & Canada

2-TRACTOR- 2

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5075E Cab Utility Tractor (57 PTO hp)

Continued

SUGGESTED

LIST PRICE

USD ($)

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

FRONT WHEELS WITH TIRES (TWO) ...Continued...

6171 9.5-16 In. 6PR R3 Bias -290.00

ATTACHMENTS FOR FIELD CONVERSION

L154683 Rear Axle 1.2 In. Extension (30 mm)

L154682 Rear Axle 1.6 In. Extension (40 mm)

L154684 Rear Axle 4.4 In. Extension (111 mm)

LV150155 Engine Coolant Heater Kit (3 Cyl.) 96.80

LVB25110 Heavy Duty Air Intake Pre-Heater

Axle - Rear:

See Parts

Two required. Requires (16) 19M9364 Cap Screws (8 per Extension), ordered separately.

See Parts

Two required. Requires (16) 19M8979 Cap Screws (8 per Extension), ordered separately.

See Parts

Two required. Requires (16) 19M9365 Cap Screws (8 per Extension), ordered separately.

Engine:

122.10

925 CCA battery recommended for optimum performance. Only compatible with machines built with serial number 340000 and before. For machines built after, see the parts catalog.

BSJ10021 Horizontal Side Exhaust

Compatible with 5E Cab Tractors.

Fenders:

LVB25714 Rear Fender Extension Kit

Cab Tractors only.

Hitch and Drawbar:

T12553 Center Link Conversion Bushing, Cat. II to Cat. I

One required.

R66432 Draft Link Conversion Bushing, Cat. II to Cat. I

Two required.

R133359 Drawbar - Offset See Parts

RE39830 Drawbar Clevis Kit (Hammer Strap) - Offset Drawbar See Parts

RE39829 Drawbar Clevis Kit (Hammer Strap) - Straight Drawbar See Parts

TY16042 Quik-Coupler, Economy, Category 2 See Parts

Hitch:

SJ11072 Left Hand Telescopic Draft Link See Parts

SJ11073 Right Hand Telescopic Draft Link See Parts

See Parts

209.00

See Parts

03 December 2014 US & Canada

2-TRACTOR- 3

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5075E Cab Utility Tractor (57 PTO hp)

Continued

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

ATTACHMENTS FOR FIELD CONVERSION ...Continued...

LVB25976 iMatch Quick Hitch Category 1 with adjustable top hook

Includes one set of Bushings (LVU15507).

Hydraulics:

BLV10347 Mid-Mount Dual SCV with Joystick Control

Compatible with 5E Cab Tractors.

LVB25788 Motor Control Kit

Compatible with 5003 and 5E Series Tractors. Also order RE251179 if no mid-mount valve installed.

BLV10348 Second Rear SCV with Detented Float and Lever Control

Compatible with 5E Cab Tractors.

Lighting:

BLV10349 Front working lights

Cab Only.

Miscellaneous:

LVB25728 Backup Alarm Kit

Compatible with 5E 3-Cyl Cab tractors and PR Open Station Tractors.

SUGGESTED

LIST PRICE

USD ($)

357.50

1,411.30

2,086.70

805.20

150.70

161.70

BLV10407 Operator's Manual and Decal Kit - French 0.00

BLV10406 Operator's Manual and Decal Kit - Spanish 0.00

LVB26096 Single Horn Kit

CAB tractors only

Operator Environment:

SJ10170 Antenna

Cab only

AH104259 Ash Tray

Cab only.

AR60937 Cigarette Lighter

Cab only.

RE334177 John Deere/Delco AM/FM Weatherband Radio

RE244177 Kit, Rear View Mirror Mounting Kit

Cab only. Requires AL80127 and/or AL80126Kit contains support plates and hardware for one rear view mirror.

AL80126 Mirror, Telescopic, LH, Manually Adjustable

Cab only.

51.70

See Parts

171.60

AL80127 Mirror, Telescopic, RH, Manually Adjustable

Cab only.

03 December 2014 US & Canada

2-TRACTOR- 4

171.60

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5075E Cab Utility Tractor (57 PTO hp)

Continued

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

ATTACHMENTS FOR FIELD CONVERSION ...Continued...

BLV10350 Right Hand Door

Cab Only

BLV10173 Wiper/Washer, Rear

Cab only.

Weights:

LVB25889 Weight, Front Support - 100 Lb.

Kit includes front weight support and mounting hardware.

R213907 Weight, Rear Wheel - 95 Lb.

Not compatible on wheels sized 24" or smaller. Maximum of 2 per wheel.

SUGGESTED

LIST PRICE

USD ($)

291.50

343.20

220.00

222.20

03 December 2014 US & Canada

2-TRACTOR- 5

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5075E Cab Utility Tractor (57 PTO hp)

Continued

THIS PAGE IS INTENTIONALLY LEFT BLANK

03 December 2014 US & Canada

2-TRACTOR- 6

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5085E Utility Tractor (70 PTO hp)

Equipment for Base Machine

5085E Equipment for Base Machine ENGINE: 85 (62.5 kW) 97/68/EC Engine Horsepower @ 2400 RPM* 70 (51.5 kW) PTO Horsepower @ 2400 RPM* 4 Cylinder Turbocharged

John Deere PowerTech PWX Diesel Engine

EPA Interim Tier 4 Compliant 276 C.I.D. (4.5 L) High Pressure Common Rail Oil Cooler Dry Type Air Cleaner with

Safety Element

Underhood Muffler with

Vertical Exhaust Stack Anti-Freeze Water Separator Bowl Hand and Foot Throttle Key Engine Shut Off Fan Finger Guard Fuel Cooler

TRANSMISSION: 12F/12R PowrReverser Transmission LH Electrohydraulic (EH)

Directional Reverser Integrated Park Position Differential Lock Neutral Start Safety Switch Wet Traction Clutch

FRONT AXLE AND TIRES: Mechanical Front Wheel Drive

(4 Wheel Drive) Front Axle Mechanical MFWD Engagement Planetary Final Drives 8-Position Steel Front Wheels

with Two 11.2-24 6PR (R1) REAR AXLE AND TIRES:

Flanged Rear Axle Planetary Final Drives 8-Position Steel Rear Wheels

with Two 16.9-30 8PR (R1) STEERING AND BRAKES:

Hydrostatic Power Steering Hydraulic Wet Disk Brakes

Self-Equalizing and

Self-Adjusting HYDRAULICS:

Open Center Hydraulic System Tandem Gear Pump 22.5 GPM

(85.1 LPM) Maximum Total Flow

Steering Pump 6.6 GPM (24.9 LPM)

Implement Pump 15.9 GPM (60.1 LPM) Hydraulic Oil Cooler Dual Rear SCV Control Valve

POWER TAKE-OFF SHAFT: Independent "Live" 540 RPM /540E

Rear PTO Shaft

Electro-hydraulic PTO engagement

@ 2400 Rated Engine RPM

Economy PTO setting for 540 PTO RPM

@ 1716 Engine RPM Wet PTO Clutch Operator Presence Safety

Warning - PTO Safety Start Switch

Flip Up PTO Shield ROCKSHAFT, HITCH AND DRAWBAR:

Telescopic Draft Links with Category II Balls Adjustable Sway Chains Adjustable Straight Drawbar Top Link Draft Sensing

INSTRUMENTATION: Electric Fuel Gauge Tachometer/Hour Meter Oil Pressure Indicator Light Coolant Temperature Gauge Alternator Indicator Light Air Restriction Indicator Light Turn Signal Indicator Light High Beam Indicator Light PTO Engagement Indicator Light MFWD Engagement Indicator Light

ELECTRICAL: 12-Volt Electrical System One Battery - 950 CCA** with

180 Minute Reserve Capacity 7-Pin ASAE Outlet Socket 90 Amp Alternator

LIGHTS: Open Operator Station -

Two Front Halogen Headlights

Two Turn/Warning Lights

Single Rear Work Light Cab -

Two Front Halogen Headlights

Six Turn/Warning Lights

Two Rear Work Lights

Two Front Work Lights MISCELLANEOUS:

SMV Emblem Tilt-Up Hood Side-Mounted Toolbox

OPEN OPERATOR STATION: 25 U.S. Gallon (95 L)

Fuel Tank Capacity Open Station Cup Holder Deluxe Floor Mat

CAB 30 U.S. Gallon (115 L)

Fuel Tank Capacity Left Hand Door Only Air Conditioning Cup Holders Radio/CD Ready (Antenna Cable,

Two Speakers, and Wiring Harness) Front Windshield Wiper 90 Amp Alternator * Manufacturer's Rating ** Cold Cranking Amps

03 December 2014 US & Canada

2-TRACTOR- 1

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5085E Utility Tractor (70 PTO hp)

Continued

SUGGESTED

LIST PRICE

USD ($)

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

Select One Code From Each Required Category

BASE MACHINE

EX-WORKS Augusta, Georgia; Baltimore, Maryland; Benicia, California; Galveston, Texas; Brunswick, Georgia; Port Hueneme, California; Tacoma, Washington

6960LV 5085E Utility Tractor (70 PTO hp) 41,719.00

OPERATORS MANUAL

0409 English Operators Manual and Decal Kit In Base Price

0413 French Operators Manual and Decal Kit Same Price

0437 Spanish Operators Manual and Decal Kit Same Price

OPERATOR STATION

2000 Open Operator Station

Fixed Open Operator Station Tilt/ Telescopic Steering Column 2 post Foldable Roll- Over Protection Structure (ROPS) Adjustable seat with Armrests and seatbelt Speedometer.

In Base Price

2050 Standard Cab

Left Side Door Air Conditioning Cup Holders Radio/CD Ready (Antenna Cable,Two Speakers, and Wiring Harness) Front Windshield Wiper Mechanical Suspension Seat.

9,072.00

SEAT SUSPENSION

2115 Vinyl Seat for Open Operator Station In Base Price

2110 Mechanical Suspension Seat for Cab Tractors Same Price

2120 Air Suspension Seat for Cab Tractors 706.00

ENGINE EXHAUST

3020 Vertical Exhaust In Base Price

3025 Deluxe Cornerpost Exhaust

Only compatible with the Cab Operator Station.

500.00

REAR SELECTIVE CONTROL VALVES

3300 Less Rear SCV with Lever Control -1,057.00

3320 Dual Rear SCV's with Lever Control In Base Price

03 December 2014 US & Canada

2-TRACTOR- 2

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5085E Utility Tractor (70 PTO hp)

Continued

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

REAR SELECTIVE CONTROL VALVES ...Continued...

3335 Triple Rear Deluxe SCV's with Lever Control

Features:

- Three selectable detent positions on EACH valve (auto kickout, continuous flow, or no detent)

- Float position on EACH valve

- Flow priority to #1 valve

- Pressure compensated flow control for running hydraulic motors on #1 valve.

MID SELECTIVE CONTROL VALVES

3400 Less Mid Valves

3420 Dual Mid Valves with Joystick Control

Recommended for applications WITHOUT front loaders. Can later be upgraded for front loader and/or other hydraulic applications using field-installed attachments.

Recommended for applications WITH front loaders.

REAR WHEELS WITH TIRES (TWO)

5121 16.9 - 30 In. 6PR R1 Bias

5911 18.4 - 30 In. 8PR R1 Bias

MFWD (4WD) requires Code 6111.

MFWD (4WD) requires Code 6701.

SUGGESTED

LIST PRICE

USD ($)

1,135.00

In Base Price

1,236.00

In Base Price

395.00

5914 19.5L - 24 In. 10PR R4 Bias

MFWD (4WD) requires Code 6114.

Same Price

FRONT AXLE

6040 MFWD (4 Wheel Drive) In Base Price

FRONT WHEELS WITH TIRES (TWO)

See Loader Section of the Sales Manual for Front Tire/Loader Compatibility Information.

6111 11.2 - 24 In. 6PR R1 Bias In Base Price

6114 12.5/80 - 18 In. 6PR I3 (R4 Type) Bias -470.00

6701 12.4 - 24 In. 8PR R1 Bias 283.00

ATTACHMENTS FOR FIELD CONVERSION

L154683 Rear Axle 1.2 In. Extension (30 mm)

L154682 Rear Axle 1.6 In. Extension (40 mm)

Axle - Rear:

See Parts

Requires (Qty. 2). Order installation hardware separate - See Parts. Requires (16) 19M9364 Cap Screws (8 per Extension), ordered separately.

See Parts

Two required. Requires (16) 19M8979 Cap Screws (8 per Extension), ordered separately.

03 December 2014 US & Canada

2-TRACTOR- 3

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5085E Utility Tractor (70 PTO hp)

Continued

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

SUGGESTED

LIST PRICE

USD ($)

ATTACHMENTS FOR FIELD CONVERSION ...Continued...

L154684 Rear Axle 4.4 In. Extension (111 mm)

Two required. Requires (16) 19M9365 Cap Screws (8 per Extension), ordered separately.

Engine:

RE227949 Engine Block Heater (110V) See Parts

LVB25787 Radiator Clean Out Screen

Compatible with cab model only (Code 2050).

SJ13485 Radiator Clean Out Screen

Open Operator Stations Only (Code 2000).

BLV10165 Side Exhaust Kit 734.80

Fenders:

AL180330 MFWD Front Fenders 14.6 In. (370 mm) Wide

Recommended for use with 12.5/80-18, 11.2-24 and 12.4-24 In. Tires. Requires Mounting Bracket and Hardware Kit (LVB25776) ordered separately. Not Compatible with Loaders.

AL180327 MFWD Front Fenders 16.5 In. (420 mm) Wide

Recommended for use with 13.6-24 In. Tires. Requires Mounting Brackets and Hardware Kit (LVB25776) ordered separately. Not Compatible with Loaders.

See Parts

62.70

See Parts

LVB25703 Mounting Brackets and Hardware Kit - MFWD Fenders WITH LOADER

Compatible with 553 loader only. Kit contains parts for both left and right sides. Requires Front Fenders (2 pieces each of AL180328 (320 mm), AL180330 (370 mm) OR L64560 (400 mm) ordered separately.) Requires Loader installation.

LVB25776 Mounting Brackets and Hardware Kit - MFWD Fenders WITHOUT LOADER

Requires Fenders (AL180330, AL180327) ordered separately through parts.

LVB25714 Rear Fender Extension Kit

Cab Only.

BW15741 Stationary Fenders (Quik-Tach) 563.20

Guards:

BW16009 Hood Guard 407.00

Hitch and Drawbar:

T12553 Center Link Conversion Bushing, Cat. II to Cat. I

One required.

R66432 Draft Link Conversion Bushing, Cat. II to Cat. I

Two required.

R133359 Drawbar - Offset See Parts

R196191 Drawbar - Straight Heavy-Duty See Parts

RE39830 Drawbar Clevis Kit (Hammer Strap) - Offset Drawbar See Parts

442.20

831.60

209.00

See Parts

03 December 2014 US & Canada

2-TRACTOR- 4

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5085E Utility Tractor (70 PTO hp)

Continued

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

SUGGESTED

LIST PRICE

USD ($)

ATTACHMENTS FOR FIELD CONVERSION ...Continued...

RE39829 Drawbar Clevis Kit (Hammer Strap) - Straight Drawbar See Parts

TY16042 Quik-Coupler, Economy, Category 2 See Parts

BLV10121 Sway Bar Conversion Kit for Cab Tractors

Converts factory supplied sway chains to sway bars.

BLV10078 Sway Bar Conversion Kit for Open Station Tractors

Converts factory supplied sway chains to sway bars.

Hitch:

LVB25255 iMatch Quick Hitch Category 1 315.70

Hydraulics:

BLV10072 Dual Mid Hydraulic Control Valve Kit with Joystick Control

Recommended for applications WITH Front Loaders. Cab Tractors Only.

BLV10324 Dual Mid Hydraulic Control Valve Kit with Joystick Control

Recommended for applications WITH Front Loaders. Open station tractors Only.

BLV10070 Dual Rear SCV Kit with Lever Controls

Includes second rear SCV lever, valve, hoses, and mounting bracket to add a second rear SCV with Extend/Retract/Re-Gen functionality. Cab Tractors Only.

668.80

1,411.30

1,610.40

BLV10322 Dual Rear SCV Kit with Lever Controls

Includes second rear SCV lever, hoses, and mounting bracket to add a second rear SCV with Extend/Retract/Re-Gen functionality. Open Station Tractors Only.

BLV10074 Mid Couplers Kit 180.40

LVB25697 Power Beyond Coupler Kit 467.50

LVB25771 Second Rear SCV with Detented Float and Lever Control 805.20

BLV10431 Second Rear SCV with Detented Float and Lever Control 805.20

BLV10325 Triple Mid Hydraulic Control Valve Kit (Converting Dual Mid to Triple Mid)

Only for tractors already equipped with Dual Mid Hydraulics. Fits all 5E 4 Cyl. tractors that already have dual mid SCVs installed. For 5E 4-cyl already equipped with triple rear SCVs, also order SJ12253 and SJ12285. Tractors not equipped with Rear SCVs also require RE226516.

BLV10071 Triple Rear Deluxe Hydraulic Control Valve Kit with Lever Controls

For use with Tractors already equipped with Dual Rear Valves. Features: Three selectable detent positions on each valve (auto kickout, continuous flow, or no detent) Float position on each valve Flow priority to #1 valve Pressure compensated flow control for running hydraulics motos on #1 valve

For cab tractors only.

BLV10323 Triple Rear Deluxe Hydraulic Control Valve Kit with Lever Controls (Converting Dual Rear to

Triple Rear)

Open Station Tractors Only.

1,610.40

1,806.20

2,324.30

03 December 2014 US & Canada

2-TRACTOR- 5

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5085E Utility Tractor (70 PTO hp)

Continued

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

SUGGESTED

LIST PRICE

USD ($)

ATTACHMENTS FOR FIELD CONVERSION ...Continued...

LVB24997 Auxiliary Loader Light Kit

LVB25547 Auxiliary Rear Work Light Kit (1 Light)

LVB25720 Auxiliary Work Light Kit (2 Lights)

BLV10120 Beacon Light Kit

LVB25729 Brake Light Kit

LVB25978 Brake Light Kit

RE554568 120 Amp Alternator See Parts

LVB25728 Backup Alarm Kit 161.70

Lighting:

757.90

For Open Station and Cab Tractors.

63.80

Open Station Only.

150.70

Cab Tractors Only. Compatible at Front or Rear of Cab.

236.50

Cab Tractors Only.

110.00

Cab Tractors Only.

240.90

Open Operator Station Only.

Miscellaneous:

BLV10368 Operator's Manual and Decal Kit - French 0.00

BLV10369 Operator's Manual and Decal Kit - Spanish 0.00

LVB25727 PowrReverser Modulation Control Kit 147.40

RE19428 Safety Chain Support Kit See Parts

LVB26096 Single Horn Kit 51.70

LVB24951 Tool Box Kit - Rear Mounted

For Open Station tractors.

Operator Environment:

LVB24983 Air Seat Suspension Kit (Cab Only)

Kit contains seat suspension to change mechanical to air suspension. Kit does NOT include a seat.

SJ10170 Antenna

Compatible with MY2012 and MY2013 Cab Tractors.

AH104259 Ash Tray See Parts

BLV10419 Cab Instructional Seat

For Cab Tractors only.

LVB25785 Canopy - Deluxe

Requires LVB25332 Canopy Mounting Bracket and Hardware Kit ordered separately.

123.20

723.80

See Parts

611.60

961.40

03 December 2014 US & Canada

2-TRACTOR- 6

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5085E Utility Tractor (70 PTO hp)

Continued

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

ATTACHMENTS FOR FIELD CONVERSION ...Continued...

LVB25334 Canopy - Standard

Requires LVB25332 Canopy Mounting Bracket and Hardware Kit ordered separately.

LVB25332 Canopy Mounting Bracket and Hardware Kit

Open Operator Station Only. Requires LVB25785 or LVB25334 Canopy Kit Ordered Separately.

AR60937 Cigarette Lighter

Cab only.

RE334177 John Deere/Delco AM/FM Weatherband Radio

RE244177 Kit, Rear View Mirror Mounting Kit

Requires AL80127 and/or AL80126. Kit contains support plates and hardware for one rear view mirror.

AL80126 Mirror, Telescopic, LH, Manually Adjustable

Cab Compatible Only.

AL80127 Mirror, Telescopic, RH, Manually Adjustable

Cab Compatible Only.

SUGGESTED

LIST PRICE

USD ($)

583.00

105.60

See Parts

171.60

RE68495 Power Strip with Six Outlets See Parts

LVB26040 Right Hand Door Kit 291.50

BLV10173 Wiper/Washer, Rear 343.20

BLV10370 540/1000 RPM Power Take Off Kit

AL71345 Vandal Protection, Door Locks - Custom Key 185.90

AL113087 Vandal Protection, Lockable Fuel Tank Cap See Parts

R262449 Front Weight Support, 187 Lbs

R127764 Weight, Front Suitcase 95 Lb. (43 kg) Quantity of One 134.20

R213907 Weight, Rear Wheel - 95 Lb.

PTO:

1,560.90

Converting from 540/540E to 540/1000. Also backwards compatible with 5E 4 cylinder and 5EN tractors starting MY2012 with green chassis.

Vandal Protection:

Weights:

See Parts

Requires (4) 19M8100 Cap Screws and (4) 24M7242 Washers, ordered separately.

222.20

Not compatible on wheels sized 24" or smaller. Maximum of 2 per wheel.

03 December 2014 US & Canada

2-TRACTOR- 7

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5085E Utility Tractor (70 PTO hp)

Continued

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

ATTACHMENTS FOR FIELD CONVERSION ...Continued...

Wheel Equipment:

AL156778 Wheel Spacers, MFWD, 2.36 In. (60 mm) with Hardware (Qty 2)

Fits MFWD and Rear Axles. Only for axles with 10.82 diameter bolt holes. Tread Setting Should Not exceed 80 In. for Maximum Load Applications.

SUGGESTED

LIST PRICE

USD ($)

657.80

03 December 2014 US & Canada

2-TRACTOR- 8

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5100E Utility Tractor (85 PTO hp)

Equipment for Base Machine

5100E Equipment for Base Machine

ENGINE: 100 (74.6 kW) 97/68/EC Engine Horsepower @ 2400 RPM* 85 (62.5 kW) PTO Horsepower @ 2400 RPM* 4 Cylinder Turbocharged

John Deere PowerTech PWX Diesel Engine

EPA Interim Tier 4 Compliant 276 C.I.D. (4.5 L) High Pressuer Common Rail Oil Cooler Dry Type Air Cleaner with

Safety Element

Underhood Muffler with

Vertical Exhaust Stack Anti-Freeze Water Separator Hand and Foot Throttle Key Engine Shut Off Fan Finger Guard Fuel Cooler

TRANSMISSION: 12F/12R PowrReverser Transmission LH Electrohydraulic (EH)

Directional Reverser Integrated Park Position Differential Lock Neutral Start Safety Switch Wet Traction Clutch

FRONT AXLE AND TIRES: Mechanical Front Wheel Drive

(4 Wheel Drive) Front Axle Mechanical MFWD Engagement Planetary Final Drives 8-Position Steel Front Wheels

with Two 12.4-24 8PR (R1) REAR AXLE AND TIRES:

Flanged Rear Axle Planetary Final Drives 8-Position Steel Rear Wheels

with Two 18.4-30 8PR (R1) STEERING AND BRAKES:

Hydrostatic Power Steering Hydraulic Wet Disk Brakes

Self-Equalizing and

Self-Adjusting HYDRAULICS:

Open Center Hydraulic System Tandem Gear Pump 22.5 GPM

(85.1 LPM) Maximum Total Flow

Steering Pump 6.6 GPM (24.9 LPM)

Implement Pump 15.9 GPM (60.1 LPM) Hydraulic Oil Cooler Dual Rear SCV Control Valve

POWER TAKE-OFF SHAFT: Independent "Live" 540 RPM /540E

Rear PTO Shaft

Electro-hydraulic PTO engagement

@ 2400 Rated Engine RPM

Economy PTO setting for 540 PTO RPM

@ 1716 Engine RPM Wet PTO Clutch Operator Presence Safety

Warning - PTO

Safety Start Switch Flip Up PTO Shield

ROCKSHAFT, HITCH AND DRAWBAR: Telescopic Draft Links with Category II Balls Adjustable Sway Chains Adjustable Straight Drawbar Top Link Draft Sensing

INSTRUMENTATION: Electric Fuel Gauge Tachometer/Hour Meter Oil Pressure Indicator Light Coolant Temperature Gauge Alternator Indicator Light Air Restriction Indicator Light Turn Signal Indicator Light High Beam Indicator Light PTO Engagement Indicator Light MFWD Engagement Indicator Light

ELECTRICAL: 12-Volt Electrical System One Battery - 950 CCA** with

180 Minute Reserve Capacity 7-Pin ASAE Outlet Socket 90 Amp Alternator

LIGHTS: Open Operator Station -

Two Front Halogen Headlights

Two Turn/Warning Lights

Single Rear Work Light Cab -

Two Front Halogen Headlights

Six Turn/Warning Lights

Two Rear Work Lights

Two Front Work Lights MISCELLANEOUS:

SMV Emblem Tilt-Up Hood Side-Mounted Toolbox

OPEN OPERATOR STATION: 25 U.S. Gallon (95 L)

Fuel Tank Capacity Open Station Cup Holder Deluxe Floor Mat

CAB 30 U.S. Gallon (115 L)

Fuel Tank Capacity Left Hand Door Only Air Conditioning Cup Holders Radio/CD Ready (Antenna Cable,

Two Speakers, and Wiring Harness) Front Windshield Wiper 90 Amp Alternator * Manufacturer's Rating ** Cold Cranking Amps

03 December 2014 US & Canada

2-TRACTOR- 1

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5100E Utility Tractor (85 PTO hp)

Continued

SUGGESTED

LIST PRICE

USD ($)

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

Select One Code From Each Required Category

BASE MACHINE

EX-WORKS Augusta, Georgia; Baltimore, Maryland; Benicia, California; Galveston, Texas; Brunswick, Georgia; Port Hueneme, California; Tacoma, Washington

6970LV 5100E Utility Tractor (85 PTO hp) 46,802.00

OPERATORS MANUAL

0409 English Operators Manual and Decal Kit In Base Price

0413 French Operators Manual and Decal Kit Same Price

0437 Spanish Operators Manual and Decal Kit Same Price

OPERATOR STATION

2000 Open Operator Station

Fixed Open Operator Station Tilt/ Telescopic Steering Column 2 post Foldable Roll- Over Protection Structure (ROPS) Adjustable seat with Armrests and seatbelt Speedometer.

In Base Price

2050 Standard Cab

Left Side Door Air Conditioning Cup Holders Radio/CD Ready (Antenna Cable,Two Speakers, and Wiring Harness) Front Windshield Wiper Mechanical Suspension Seat.

9,072.00

SEAT SUSPENSION

2115 Vinyl Seat for Open Operator Station In Base Price

2110 Mechanical Suspension Seat for Cab Tractors Same Price

2120 Air Suspension Seat for Cab Tractors 706.00

ENGINE EXHAUST

3020 Vertical Exhaust In Base Price

3025 Deluxe Cornerpost Exhaust

Only compatible with the Cab Operator Station.

500.00

REAR SELECTIVE CONTROL VALVES

3300 Less Rear SCV with Lever Control -1,057.00

3320 Dual Rear SCV's with Lever Control In Base Price

03 December 2014 US & Canada

2-TRACTOR- 2

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5100E Utility Tractor (85 PTO hp)

Continued

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

REAR SELECTIVE CONTROL VALVES ...Continued...

3335 Triple Rear Deluxe SCV's with Lever Control

Features:

- Three selectable detent positions on EACH valve (auto kickout, continuous flow, or no detent)

- Float position on EACH valve

- Flow priority to #1 valve

- Pressure compensated flow control for running hydraulic motors on #1 valve.

MID SELECTIVE CONTROL VALVES

3400 Less Mid Valves

3420 Dual Mid Valves with Joystick Control

Recommended for applications WITHOUT front loaders. Can later be upgraded for front loader and/or other hydraulic applications using field-installed attachments.

Recommended for applications WITH front loaders.

REAR WHEELS WITH TIRES (TWO)

5121 16.9 - 30 In. 6PR R1 Bias

5911 18.4 - 30 In. 8PR R1 Bias

MFWD (4WD) requires Code 6111.

MFWD (4WD) requires Code 6701.

SUGGESTED

LIST PRICE

USD ($)

1,135.00

In Base Price

1,236.00

-395.00

In Base Price

5914 19.5L - 24 In. 10PR R4 Bias

MFWD (4WD) requires Code 6114.

-418.00

FRONT AXLE

6040 MFWD (4 Wheel Drive) In Base Price

FRONT WHEELS WITH TIRES (TWO)

See Loader Section of the Sales Manual for Front Tire/Loader Compatibility Information.

6111 11.2 - 24 In. 6PR R1 Bias -283.00

6114 12.5/80 - 18 In. 6PR I3 (R4 Type) Bias -753.00

6701 12.4 - 24 In. 8PR R1 Bias In Base Price

ATTACHMENTS FOR FIELD CONVERSION

L154683 Rear Axle 1.2 In. Extension (30 mm)

L154682 Rear Axle 1.6 In. Extension (40 mm)

Axle - Rear:

See Parts

Requires (Qty. 2). Order installation hardware separate - See Parts. Requires (16) 19M9364 Cap Screws (8 per Extension), ordered separately.

See Parts

Two required. Requires (16) 19M8979 Cap Screws (8 per Extension), ordered separately.

03 December 2014 US & Canada

2-TRACTOR- 3

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5100E Utility Tractor (85 PTO hp)

Continued

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

SUGGESTED

LIST PRICE

USD ($)

ATTACHMENTS FOR FIELD CONVERSION ...Continued...

L154684 Rear Axle 4.4 In. Extension (111 mm)

Two required. Requires (16) 19M9365 Cap Screws (8 per Extension), ordered separately.

Engine:

RE227949 Engine Block Heater (110V) See Parts

LVB25787 Radiator Clean Out Screen

Compatible with cab model only (Code 2050).

SJ13485 Radiator Clean Out Screen

Open Operator Stations Only (Code 2000).

BLV10165 Side Exhaust Kit 734.80

Fenders:

AL180330 MFWD Front Fenders 14.6 In. (370 mm) Wide

Recommended for use with 12.5/80-18, 11.2-24 and 12.4-24 In. Tires. Requires Mounting Bracket and Hardware Kit (LVB25776) ordered separately. Not Compatible with Loaders.

AL180327 MFWD Front Fenders 16.5 In. (420 mm) Wide

Recommended for use with 13.6-24 In. Tires. Requires Mounting Brackets and Hardware Kit (LVB25776) ordered separately. Not Compatible with Loaders.

See Parts

62.70

See Parts

LVB25703 Mounting Brackets and Hardware Kit - MFWD Fenders WITH LOADER

LVB25776 Mounting Brackets and Hardware Kit - MFWD Fenders WITHOUT LOADER

Requires Fenders (AL180330, AL180327) ordered separately through parts.

LVB25714 Rear Fender Extension Kit

Cab Only.

BW15741 Stationary Fenders (Quik-Tach) 563.20

Guards:

BW16009 Hood Guard 407.00

Hitch and Drawbar:

T12553 Center Link Conversion Bushing, Cat. II to Cat. I

One required.

R66432 Draft Link Conversion Bushing, Cat. II to Cat. I

Two required.

R133359 Drawbar - Offset See Parts

R196191 Drawbar - Straight Heavy-Duty See Parts

RE39830 Drawbar Clevis Kit (Hammer Strap) - Offset Drawbar See Parts

442.20

831.60

209.00

See Parts

03 December 2014 US & Canada

2-TRACTOR- 4

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5100E Utility Tractor (85 PTO hp)

Continued

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

SUGGESTED

LIST PRICE

USD ($)

ATTACHMENTS FOR FIELD CONVERSION ...Continued...

RE39829 Drawbar Clevis Kit (Hammer Strap) - Straight Drawbar See Parts

TY16042 Quik-Coupler, Economy, Category 2 See Parts

BLV10121 Sway Bar Conversion Kit for Cab Tractors

Converts factory supplied sway chains to sway bars.

BLV10078 Sway Bar Conversion Kit for Open Station Tractors

Converts factory supplied sway chains to sway bars.

Hitch:

LVB25255 iMatch Quick Hitch Category 1 315.70

Hydraulics:

BLV10072 Dual Mid Hydraulic Control Valve Kit with Joystick Control

Recommended for applications WITH Front Loaders. Cab Tractors Only.

BLV10324 Dual Mid Hydraulic Control Valve Kit with Joystick Control

Recommended for applications WITH Front Loaders. Open station tractors Only.

BLV10070 Dual Rear SCV Kit with Lever Controls

Includes second rear SCV lever, valve, hoses, and mounting bracket to add a second rear SCV with Extend/Retract/Re-Gen functionality. Cab Tractors Only.

668.80

1,411.30

1,610.40

BLV10322 Dual Rear SCV Kit with Lever Controls

Includes second rear SCV lever, hoses, and mounting bracket to add a second rear SCV with Extend/Retract/Re-Gen functionality. Open Station Tractors Only.

BLV10074 Mid Couplers Kit 180.40

LVB25697 Power Beyond Coupler Kit 467.50

LVB25771 Second Rear SCV with Detented Float and Lever Control 805.20

BLV10431 Second Rear SCV with Detented Float and Lever Control 805.20

BLV10325 Triple Mid Hydraulic Control Valve Kit (Converting Dual Mid to Triple Mid)

BLV10071 Triple Rear Deluxe Hydraulic Control Valve Kit with Lever Controls

For cab tractors only.

BLV10323 Triple Rear Deluxe Hydraulic Control Valve Kit with Lever Controls (Converting Dual Rear to

Triple Rear)

Open Station Tractors Only.

1,610.40

1,806.20

2,324.30

03 December 2014 US & Canada

2-TRACTOR- 5

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5100E Utility Tractor (85 PTO hp)

Continued

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

SUGGESTED

LIST PRICE

USD ($)

ATTACHMENTS FOR FIELD CONVERSION ...Continued...

LVB24997 Auxiliary Loader Light Kit

LVB25547 Auxiliary Rear Work Light Kit (1 Light)

LVB25720 Auxiliary Work Light Kit (2 Lights)

BLV10120 Beacon Light Kit

LVB25729 Brake Light Kit

LVB25978 Brake Light Kit

RE554568 120 Amp Alternator See Parts

LVB25728 Backup Alarm Kit 161.70

Lighting:

757.90

For Open Station and Cab Tractors.

63.80

Open Station Only.

150.70

Cab Tractors Only. Compatible at Front or Rear of Cab.

236.50

Cab Tractors Only.

110.00

Cab Tractors Only.

240.90

Open Operator Station Only.

Miscellaneous:

BLV10368 Operator's Manual and Decal Kit - French 0.00

BLV10369 Operator's Manual and Decal Kit - Spanish 0.00

LVB25727 PowrReverser Modulation Control Kit 147.40

RE19428 Safety Chain Support Kit See Parts

LVB26096 Single Horn Kit 51.70

LVB24951 Tool Box Kit - Rear Mounted

For Open Station tractors.

Operator Environment:

LVB24983 Air Seat Suspension Kit (Cab Only)

Kit contains seat suspension to change mechanical to air suspension. Kit does NOT include a seat.

SJ10170 Antenna

Compatible with MY2012 and MY2013 Cab Tractors.

AH104259 Ash Tray See Parts

BLV10419 Cab Instructional Seat

For Cab Tractors only.

LVB25785 Canopy - Deluxe

Requires LVB25332 Canopy Mounting Bracket and Hardware Kit ordered separately.

123.20

723.80

See Parts

611.60

961.40

03 December 2014 US & Canada

2-TRACTOR- 6

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5100E Utility Tractor (85 PTO hp)

Continued

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

ATTACHMENTS FOR FIELD CONVERSION ...Continued...

LVB25334 Canopy - Standard

Requires LVB25332 Canopy Mounting Bracket and Hardware Kit ordered separately.

LVB25332 Canopy Mounting Bracket and Hardware Kit

Open Operator Station Only. Requires LVB25785 or LVB25334 Canopy Kit Ordered Separately.

AR60937 Cigarette Lighter

Cab only.

RE334177 John Deere/Delco AM/FM Weatherband Radio

RE244177 Kit, Rear View Mirror Mounting Kit

Requires AL80127 and/or AL80126. Kit contains support plates and hardware for one rear view mirror.

AL80126 Mirror, Telescopic, LH, Manually Adjustable

Cab Compatible Only.

AL80127 Mirror, Telescopic, RH, Manually Adjustable

Cab Compatible Only.

SUGGESTED

LIST PRICE

USD ($)

583.00

105.60

See Parts

171.60

RE68495 Power Strip with Six Outlets See Parts

LVB26040 Right Hand Door Kit 291.50

BLV10173 Wiper/Washer, Rear 343.20

BLV10370 540/1000 RPM Power Take Off Kit

AL71345 Vandal Protection, Door Locks - Custom Key 185.90

AL113087 Vandal Protection, Lockable Fuel Tank Cap See Parts

R262449 Front Weight Support, 187 Lbs

R127764 Weight, Front Suitcase 95 Lb. (43 kg) Quantity of One 134.20

R213907 Weight, Rear Wheel - 95 Lb.

PTO:

1,560.90

Converting from 540/540E to 540/1000. Also backwards compatible with 5E 4 cylinder and 5EN tractors starting MY2012 with green chassis.

Vandal Protection:

Weights:

See Parts

Requires (4) 19M8100 Cap Screws and (4) 24M7242 Washers, ordered separately.

222.20

Not compatible on wheels sized 24" or smaller. Maximum of 2 per wheel.

03 December 2014 US & Canada

2-TRACTOR- 7

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

5100E Utility Tractor (85 PTO hp)

Continued

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

ATTACHMENTS FOR FIELD CONVERSION ...Continued...

Wheel Equipment:

AL156778 Wheel Spacers, MFWD, 2.36 In. (60 mm) with Hardware (Qty 2)

Fits MFWD and Rear Axles. Only for axles with 10.82 diameter bolt holes. Tread Setting Should Not exceed 80 In. for Maximum Load Applications.

SUGGESTED

LIST PRICE

USD ($)

657.80

03 December 2014 US & Canada

2-TRACTOR- 8

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

(MY2015) 5075M Utility Tractor (60 PTO hp)

Equipment for Base Machine

ENGINE: 75 Engine Horsepower @ 2200RPM* 60 PTO Horsepower @ 2100 RPM* 3 Cylinder Turbocharged John Deere PowerTech Diesel Engine 177 C.I.D. (2.9L) Dry Type Air Cleaner with Safety Element Underhood Muffler with Vertical Exhaust Stack

(Aftertreatment: DOC/DPF) Cold Start Aid - Glow Plugs Water Separator Bowl Anti-Freeze Hand and Foot Throttle Key Engine Shut Off Fan Finger Guard

TRANSMISSION: 16F/16R PowrReverser Transmission Right Hand Speed Controls Left Hand F/R Shuttle Control EH Differential Lock Integrated Park Position Neutral Start Safety Switch Wet Traction Clutch

REAR AXLE: Flanged Rear Axle Planetary Final Drives

FRONT AXLE: Mechanical Front Wheel Drive Front Axle Planetary Final Drives Electro-Hydraulic MFWD Engagement via On/Auto/Brake

STEERING AND BRAKES: Hydrostatic Power Steering Hydraulic Wet Disk Brakes Self-Equalizing

and Self-Adjusting

HYDRAULIC: Open Center Hydraulic System Tandem Gear Pump 24.7 GPM (93.5 LPM)

Maximum Total Flow -

Steering Pump 6.3 GPM (23.7 LPM) Implement Pump 18.4 GPM (69.7 LPM)

Dual Mid & Dual Rear SCV Control Valves POWER TAKE-OFF SHAFT:

Independent "Live" 540 RPM Rear PTO Shaft

@ 2100 Engine RPM

Economy PTO Setting for 540 PTO RPM

@ 1645 Engine RPM Electro-Hydraulic PTO Engagement Wet PTO Clutch Operator Presence Safety Warning - PTO Safety Start Switch Flip Up PTO Shield

ROCKSHAFT, HITCH AND DRAWBAR: 56mm Lift Cylinder Standard Adjustable Straight Drawbar Telescoping Draft Links with

Category II Balls

Lower Link Draft Sensing INSTRUMENTATION:

Electric Fuel Gauge Flashing Warning Lamp High Beam Indicator Light Service Transmission Indicator PTO Speed Indicator/Roll Mode Neutral Indicator (PR Only) Tachometer/Hour Meter Engine Oil Pressure Hydraulic Temperature Indicator Coolant Temperature Gauge Alternator Indicator Light Air Restriction Indicator Light Exhaust Filter Cleaning Switch Roll Mode for Instrument Cluster PTO Engagement Indicator Light 4WD Engagement Light (4WD Front Axle Only) Hi/Lo Transmission Indicator

(32/16 Transmission Only)

ELECTRICAL: 12-Volt Electrical System One Battery - 950 CCA** with

180 Minute Reserve Capacity

7-Pin ASAE Outlet Socket LIGHTS:

Two Front Halogen Headlights Two Turn/Warning Lights

MISCELLANEOUS: SMV Emblem Toolbox English Operator's Manual

ISOLATED OPEN OPERATOR STATION (Code 2010): 2-Post Foldable Roll-Over Protective

Structure (ROPS) Less Canopy

Vinyl Seat with Flip Up Feature and

Retractable Seat Belt Tilt and Telescopic Steering Column 21 U.S. Gallon (80L) Fuel Tank Capacity 90 Amp Alternator Flashing Warning Light Dual Tail Lights Single Rear Work Light Beverage Holder Floor Mat Plexi-glass Debris/Air Deflector with Grab Handles 8-Position Standard Steel Rear Wheels with Two 18.4R30 R1 Radial Tires Two 12.4R24 R1 Radial Front Tires

* Manufacturer's Rating

** Cold Cranking Amps

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

Select One Code From Each Required Category

SUGGESTED

LIST PRICE

USD ($)

03 December 2014 US & Canada

2-TRACTOR- 1

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

(MY2015) 5075M Utility Tractor (60 PTO hp)

Continued

SUGGESTED

LIST PRICE

USD ($)

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

BASE MACHINE

EX-WORKS Augusta, Georgia; Baltimore, Maryland; Benicia, California; Galveston, Texas; Brunswick, Georgia; Port Hueneme, California; Tacoma, Washington.

191BLV (MY2015) 5075M Utility Tractor (60 PTO hp) 53,367.00

OPERATORS MANUAL

0409 English Operators Manual and Decal Kit In Base Price

0413 French Operators Manual and Decal Kit Same Price

0437 Spanish Operators Manual and Decal Kit Same Price

TRANSMISSION

1362 12F/4R SyncShuttle Plus Transmission - 540/540E

Not compatible with code 2060 (Premium Cab). Requires Shiftable 540/540E Rear PTO (code 3820).

1380 16F/16R PowrReverser Transmission - 540/540E

Electrohydraulic (EH) Directional Reverser Electrohydraulic Differential Lock Hydraulic Oil Cooler Wet Traction Clutch Wet PTO Clutch Park Lock Neutral Start Safety Switch B-C-D Range Synchronization Requires Shiftable 540/540E Rear PTO (code 3820).

-3,080.00

In Base Price

1382 16F/16R PowrReverser Transmission - 540/540E with Creeper

Electrohydraulic (EH) Directional Reverser Hydraulic Oil Cooler Neutral Indicator Service Hitch Indicator Service Engine Indicator B-C-D Range Synchronization Requires Shiftable 540/540E Rear PTO (code 3820). Requires MFWD (Code 6040).

1384 32F/16R PowrReverser Plus Transmission - 540/540E

Electrohydraulic (EH) Directional Reverser Push Button, Electrohydraulic (EH) Hi/Lo Hydraulic Oil Cooler Hi/Lo Indicator PowrReverser Modulation Control Knob B-C-D Range Synchronization Requires Premium Isolated Open Station (Code 2005) or Cab. Requires Electrohydraulic (EH) Hitch (Code 4030) Requires Shiftable 540/540E Rear PTO (code 3820). Requires MFWD (Code 6040).

2,632.00

1,688.00

OPERATOR STATION

2005 Premium Isolated Open Operator Station

Includes all features of Standard Isolated Open Operator Station plus: Fender Extensions with Front Work Lights Requires ElectroHydraulic (EH) rear hitch (Code 4030).

2010 Standard Isolated Open Operator Station In Base Price

508.00

03 December 2014 US & Canada

2-TRACTOR- 2

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

(MY2015) 5075M Utility Tractor (60 PTO hp)

Continued

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

OPERATOR STATION ...Continued...

Isolated Open Operator Station with Flat Floor Standard Floor mat Tilt and Telescoping Steering Column 2-Post Isolated Foldable Roll-Over Protection Structure (ROPS) Plexiglass Debris/Air Deflector with Grab Handles Speedometer Deluxe Seat with Swivel, Armrests, and Retractable Seat Belt 21 U.S. Gallon Fuel Tank Capacity (5075M Only) 30 U.S. Gallon Fuel Tank Capacity (5085M, 5100M Only) 40 U.S. Gallon Fuel Tank Capacity (5115M) Beverage Holder 90 AMP Alternator Two Rear Work Lights Flashing Warning Lights Dual Taillights Requires Mechanical Hitch (code 4010).

2055 Standard Cab

Deluxe Isolated Cab with Flat Floor Tilt and Telescopic Steering Column Left and Right Side Doors with Steps Air Conditioning and Heater Speedometer Beverage Holder Sunvisor for Front Window 2-Speed Front Windshield Wiper and Washer Two Front/Two Rear Roof-Mounted Work Lights Two Front/Two Rear Roof-Mounted Warning Lights Two Fender-Mounted Taillights 90 Amp Alternator Convenience Power Outlet Monitor Mounting Bosses (2 Sets) 30 U.S. Gallon Fuel Tank Capacity (5075M) 36 U.S. Gallon Fuel Tank Capacity (5085M, 5100M Only) 46 U.S. Gallon Fuel Tank Capacity (5115M Only) Swing-Out Rear Window with Two Removable Rear Plugs for Monitor Right-Hand Console Light Radio Preparation (with speakers, wiring) Rear window grab handle Swivel Seat with Adjustable Seat Pan Bluetooth Ready.

SUGGESTED

LIST PRICE

USD ($)

11,481.00

2060 Premium Cab

Includes all features of Standard Cab plus: Load View Window (Sunroof) with Shade Front Sunshade Factory Installed Radio Bluetooth and Satellite Ready Radio Rear Window Wiper Radio Antenna Additional Defrost Louvers Requires PowrReverser Transmission (1380, 1382 or 1384) Requires Deluxe Corner Post Exhaust (3025) Requires EH Hitch Controls (4030) Requires MFWD (6040).

12,975.00

SEATS

2110 Standard Mechanical Suspension Seat In Base Price

03 December 2014 US & Canada

2-TRACTOR- 3

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

(MY2015) 5075M Utility Tractor (60 PTO hp)

Continued

SUGGESTED

LIST PRICE

USD ($)

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

SEATS ...Continued...

2120 Standard Air Suspension Seat

Available on cab tractors only.

845.00

CAB INSTRUCTIONAL SEAT

2400 Less Instructional Seat In Base Price

2410 Instructional Seat with Seatbelt 556.00

ENGINE EXHAUST

3010 Horizontal Side Exhaust

Not compatible with the following tire options: Code 5151 230/95R48.

3020 Vertical Exhaust In Base Price

3025 Deluxe Corner Post Exhaust (Cab Only) 600.00

150.00

REAR SELECTIVE CONTROL VALVES

3320 Dual Rear Valve with Lever Controls In Base Price

3330 Triple Rear Deluxe Valve with Lever Controls

Features:

- Three selectable detent positions on #1 valve (auto kickout, continuous flow, or no detent)

- Float position on EACH valve

- Flow priority to #1 valve

- Pressure compensated flow control for running hydraulic motors on #1 valve.

1,179.00

MID SELECTIVE CONTROL VALVES

3400 Less Mid Valve -962.00

3420 Dual Mid Valve with Joystick Control

Includes side frames.

3430 Triple Mid Valve with Joystick Control

Features:

- Valve #1 Push button, Electrohydraulic (EH) control Priority flow Pressure compensated flow control (0 - 12 GPM) for intermittent hydraulic applications

- Valve #2 - Float position

- Valve #3 - Extend/Retract positions ONLY Includes Side Frames.

In Base Price

770.00

PTO

3820 Shiftable 540 / 540E Rear PTO In Base Price

HITCH CONTROLS

4010 Mechanical

Requires Standard Isolated Open Station (code 2010) or Standard Cab (Code 2055).

In Base Price

03 December 2014 US & Canada

2-TRACTOR- 4

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

(MY2015) 5075M Utility Tractor (60 PTO hp)

Continued

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

HITCH CONTROLS ...Continued...

4030 Electrohydraulic (EH) with remote LH fender control

Electrohydraulic (EH) Hitch Engagement Requires Premium Isolated Open Station (Code 2005), Standard Cab (Code 2055), or Premium Cab (Code 2060).

REAR WHEELS WITH TIRES (TWO)

5103 22.5LL-16.1 In. 6PR R3 (Turf Special) Bias

5121 16.9-30 In. 6PR R1 Bias (Firestone)

5141 15.5R38 In. 125A8 R1 Radial (Firestone)

5151 230/95R48 134A8 R1W Radial (Kleber)

5161 420/85R34 142A8 R1W Radial (Michelin)

2WD compatible Code 6103 or 6113. MFWD (4WD) requires Code 6123.

2WD compatible Code 6112 or 6113. MFWD (4WD) requires Code 6111.

2WD compatible Code 6112. MFWD (4WD) requires Code 6210.

Required MFWD Code 6040 and Code 6131. High Clearance Applications.

Requires MFWD (Code 6040) and Code 6210.

SUGGESTED

LIST PRICE

USD ($)

473.00

-1,277.00

-1,914.00

-1,038.00

393.00

198.00

5180 16.9R30 (42085R30) R1W Radial (Michelin)

MFWD (4WD) requires Code 6200.

5190 18.4R30 (460/85R30) R1 Radial (Goodyear)

MFWD (4WD) requires Code 6200.

5203 480/70R34 R1W Radial (Michelin)

MFWD (4WD) requires Code 6211.

5913 23.1-26 In. 8PR R3 (Turf) Bias (Titan)

2WD compatible Code 6103 or 6113. 4WD compatible Code 6214. Not compatible with Rear Wheel Weights R213907.

5914 19.5L-24 In. 10PR R4 Bias (Goodyear)

2WD compatible Code 6113. MFWD (4WD) requires Code 6133.

5924 19.5L-24 In. 10PR R4 Bias Sod Harvester (Goodyear)

2WD compatible Code 6113. MFWD (4WD) requires Code 6133.

84.00

In Base Price

1,058.00

-691.00

-1,937.00

REAR TIRE PREFERENCE CODE

5999 No Rear Tire Brand Preference In Base Price

FRONT AXLE

6020 2 Wheel Drive -6,845.00

6040 MFWD (4 Wheel Drive)

Limited Slip Differential

In Base Price

03 December 2014 US & Canada

2-TRACTOR- 5

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

(MY2015) 5075M Utility Tractor (60 PTO hp)

Continued

SUGGESTED

LIST PRICE

USD ($)

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

FRONT AXLE ...Continued...

Push Button, On-The-Go Engagement Engagement Indicator Light on PowrReverser Transmission. Auto Engagement Mode on PowrReverser Transmissions (Code 1380, 1382, or 1384).

FRONT WHEELS WITH TIRES (TWO)

See Loader Section of the Sales Manual for Front Tire/Loader compatibility information.

6103 27/12LL-15 In. 6PR R3 (Turf Special) Bias -1,445.00

6112 11L-15 In. 8PR F2 Bias (Firestone) -1,881.00

6113 11LL-15 In. 8PR F3 (Truck Type) Bias (Firestone) -1,856.00

6111 11.2-24 6PR R1 Bias -688.00

6123 12LL-16 In. 6PR R3 (Turf Special) Bias -1,263.00

6131 230/95R32 126A8 R1W Radial (Kleber)

FOR OPTION CODE 6020 (2WD - 2 WHEEL DRIVE):

FOR OPTION CODE 6040 (MFWD - 4 WHEEL DRIVE):

784.00

High Clearance Applications.

6133 12.5/80-18 In. 12PR I3 Bias (Firestone) -1,177.00

6200 12.4R24 (320/85R24) R1W Radial (Michelin) or R1 Radial (Goodyear) In Base Price

6210 13.6R24 (340/85R24) R1W Radial (Michelin or Firestone) 1,060.00

6211 380/70R24 R1W Radial (Michelin) 904.00

6214 44X18-20 In. 4PR R3 Bias (Titan) -253.00

FRONT TIRE PREFERENCE CODE

6799 No Front Tire Brand Preference In Base Price

ATTACHMENTS - ORDER AS DESIRED

Attachments ordered in this section will be factory installed if ordered by code, or may be shipped separately under the bundle number and dealer installed.

8010 Front Fenders Rigid

370 mm / 420 mm / 480 mm width depending on front tire selection.

8020 Rear Fender Extensions

Compatible with Cab Tractors only.

8300 Cold Weather Package - Coolant Heater 88.00

832E SCV Oil Spillage Collector 152.00

550.00

240.00

8458 63mm Heavy Duty Hitch Lift Cylinders - (2692 kg/5935 lbs. at 24"/610mm) 340.00

03 December 2014 US & Canada

2-TRACTOR- 6

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

(MY2015) 5075M Utility Tractor (60 PTO hp)

Continued

SUGGESTED

LIST PRICE

USD ($)

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

ATTACHMENTS - ORDER AS DESIRED ...Continued...

8510 Telescopic Rear View Cab Mirrors (2) Manually Adjustable

Cab models only.

8912 Loader Preparation Package

Hydraulic hoses and hydraulic connections still need to be ordered with loader. Loader Preparation Package only compatible with H260 and H310 loaders. Includes loader mounting frames and hood guard.

8955 Front Weight Support - (55 kg/121 lbs.) 235.00

8310 High Capacity Fuel Tank

Inner fuel tank 6 gal/ 22L additional for Open Staion, 7 gal/ 26 L additional for Cab.

303.00

1,644.00

204.00

ATTACHMENTS FOR FIELD CONVERSION

L154683 Rear Axle 1.2 In. Extension (30 mm)

L154682 Rear Axle 1.6 In. Extension (40 mm)

Axle - Rear:

See Parts

Two required. Requires (16) 19M9364 Cap Screws (8 per Extension), ordered separately.

See Parts

Two required. Requires (16) 19M8979 Cap Screws (8 per Extension), ordered separately.

L154684 Rear Axle 4.4 In. Extension (111 mm)

Two required. Requires (16) 19M9365 Cap Screws (8 per Extension), ordered separately.

Engine:

LV150155 Engine Coolant Heater Kit (3 Cyl.) 96.80

LVB25787 Radiator Clean Out Screen

Compatible with cab model only.

RE264139 Radiator Clean Out Screen

Compatible with OOS model only.

BLV10157 Side Exhaust Kit

For 5085M, 5100M and 5115M Only. Not compatible with the following tire options: 230/95R48.

Fenders:

AL180328 MFWD Front Fenders 12.6 In. (320 mm) Wide

Recommended for use with 8.3-24 and 9.5-24 In. Tires. Requires Mounting Bracket and Hardware Kit (LVB25776) ordered separately. Not compatible with Loaders or HI-CROP Tractors.

AL180330 MFWD Front Fenders 14.6 In. (370 mm) Wide

Recommended for use with 12.5/80-18, 11.2-24 and 12.4-24 In. Tires. Requires Mounting Bracket and Hardware Kit (LVB25776) ordered separately. Not compatible with Loaders or HI-CROP Tractors.

See Parts

62.70

See Parts

734.80

See Parts

03 December 2014 US & Canada

2-TRACTOR- 7

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

(MY2015) 5075M Utility Tractor (60 PTO hp)

Continued

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

SUGGESTED

LIST PRICE

USD ($)

ATTACHMENTS FOR FIELD CONVERSION ...Continued...

AL180327 MFWD Front Fenders 16.5 In. (420 mm) Wide

Recommended for use with 13.6-24 In. Tires. Requires Mounting Brackets and Hardware Kit (LVB25776) ordered separately. Not compatible with Loaders or HI-CROP Tractors.

LVB25776 Mounting Brackets and Hardware Kit - MFWD Fenders WITHOUT LOADER

Requires Fenders (AL180328, AL180330, AL180327) ordered separately through parts.

LVB25714 Rear Fender Extension Kit

Cab Tractors only.

LVB25066 Rear Fender Extension Kit

Open Station Tractors only.

Guards:

BW15683 Brush Guard

Requires BW15657 Hood Guard.

BW15657 Hood Guard 407.00

BW16009 Hood Guard 407.00

BLV10076 Skid Plate Kit, Fuel Tank Protection

Kit contains hardware and skid plates for both main and inner fuel tank with additional protective components. Compatible with Open Station and Cab Tractors.

See Parts

831.60

209.00

463.10

133.10

92.40

T12553 Center Link Conversion Bushing, Cat. II to Cat. I

R66432 Draft Link Conversion Bushing, Cat. II to Cat. I

LVB25949 Drawbar - Hammerstrap and Chain Clevis Kit

LVB25716 Electrohydraulic (EH) Hitch Right Fender Switch Kit

LVB25941 Heavy Duty Drawbar Kit

TY16042 Quik-Coupler, Economy, Category 2 See Parts

LVB25255 iMatch Quick Hitch Category 1

LVB25976 iMatch Quick Hitch Category 1 with adjustable top hook

Hitch and Drawbar:

See Parts

One required.

See Parts

Two required.

140.80

Kit contains all necessary parts and hardware (instructions included).

150.70

Cab Tractors (Codes 2055 or 2060) and Electrohydraulic (EH) Hitch (Code 4030) ONLY.

282.70

Kit contains Heavy Duty Drawbar with support assembly. Hardware and instructions included.

Hitch:

315.70

Bushings NOT included. Orderable through parts (LVU15507). Not compatible on a 5115M.

357.50

Includes one set of Bushings(LVU15507). Not compatible on a 5115M.

03 December 2014 US & Canada

2-TRACTOR- 8

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

(MY2015) 5075M Utility Tractor (60 PTO hp)

Continued

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

SUGGESTED

LIST PRICE

USD ($)

ATTACHMENTS FOR FIELD CONVERSION ...Continued...

LVB24995 Dual Mid SCV to Triple Mid SCV Conversion Kit

LVB24993 Dual Mid SCV with Joystick Control Kit

BLV10074 Mid Couplers Kit 180.40

LVB25093 Oil Collection System

RE222718 Plumbing, Hydraulic Case Drain

RE227760 Plumbing, Hydraulic Motor Return

Hydraulics:

1,806.20

Includes components and parts required to install Triple Mid SCV's on Tractors already equipped with Dual Mid and Rear SCV's.

1,411.30

Includes components and parts required to install Dual Mid SCV on Tractors not equipped with Mid SCV. (Must also order and install Engine Side Frame Kit LVB26136)

112.20

Kit contains Dust Caps with Oil Collection Reservoir, Hoses and Brackets (Hardware and instructions included).

See Parts

Supplies non-restricted flow of hydraulic fluid to reservoir. Also order: (1) 61M5035 Fitting, (1) RE268341 Tube, (2) R120797 Snap Ring, (1) R218933 Cover, (1) R252725 Bracket, (2) 19M7866 Screw, (2) 14M7298 Nut, (1) T77613 O-Ring, (1) 51M7042 O-Ring.

See Parts

Also order: (1) A79902 Cover, (1) R269471 Fitting, (2) T77858 O-Ring, (1) 51M7045 O-Ring, (1) 34H5254 Fitting.

LVB25771 Second Rear SCV with Detented Float and Lever Control 805.20

BLV10431 Second Rear SCV with Detented Float and Lever Control 805.20

LVB24992 Triple Rear Deluxe SCV Kit with Lever Controls

For use with Tractors ALREADY equipped with Dual Rear Valves. Features:

- Three selectable detent positions on EACH valve (auto kickout, continuous flow, or no detent)

-Float position one EACH valve

- Flow priority to #1 valve

- Pressure compensated flow control for running hydraulic motors on #1 valve

Lighting:

LVB24997 Auxiliary Loader Light Kit

Requires Loader installation.

LVB25720 Auxiliary Work Light Kit (2 Lights)

Cab Tractors Only.

RE244176 Beacon Light Kit

Open Operator Station only. (Code 2005 and 2010).

BLV10120 Beacon Light Kit

Cab Tractors Only.

LVB25729 Brake Light Kit

Cab Tractors Only.

LVB25978 Brake Light Kit

Open Operator Station Only.

2,324.30

757.90

150.70

See Parts

236.50

110.00

240.90

03 December 2014 US & Canada

2-TRACTOR- 9

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

(MY2015) 5075M Utility Tractor (60 PTO hp)

Continued

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

SUGGESTED

LIST PRICE

USD ($)

ATTACHMENTS FOR FIELD CONVERSION ...Continued...

RE554568 120 Amp Alternator See Parts

LVB25022 Backup Alarm Kit 161.70

BLV10145 Front 3-Point Hitch

BLV10032 Inner Fuel Tank 222.20

LVB25727 PowrReverser Modulation Control Kit 147.40

RE19428 Safety Chain Support Kit

AL203265 Service Horn

L113922 Antenna

Miscellaneous:

4,376.90

Includes all components necessary to install hitch system. Mid SCV required.

See Parts

Kit contains necessary parts and hardware.

See Parts

Requires bolt and nut 19m7865 and 14m7298.

Operator Environment:

See Parts

All 5M Series Cab Tractors are "Radio Ready", including Radio Wiring Harness and Speakers as Standard Equipment. Requires Radio Ordered Separately.

BLV10077 Antenna - Satellite Radio

All 5M Series Cab Tractors are "Radio Ready," including Radio Wiring Harness and Speakers as Standard Equipment. Requires Radio Ordered Separately. Requires Radio Subscription Ordered Separately.

AH104259 Ash Tray

Cab only.

BLV10419 Cab Instructional Seat

For Cab Tractors only.

LVB25785 Canopy - Deluxe

Includes Amber lights front and rear, hard liner and wiring harness. Requires LVB25783 Canopy Mounting Bracket and Hardware Kit ordered separately.

LVB25334 Canopy - Standard

Requires LVB25783 Canopy Mounting Bracket and Hardware Kit ordered separately.

LVB25783 Canopy Mounting Kit

Open Operator Stations Only.

AR60937 Cigarette Lighter

Cab only.

RE52682 Convenience Outlet

Open Station only (Codes 2005 and 2010). Also order: (1) L157467 strap, (4) 37M70995 screws.

RE244177 Kit, Rear View Mirror Mounting Kit

Requires AL80127 and/or AL80126. Kit contains support plates and hardware for one rear view mirror.

85.80

See Parts

611.60

961.40

583.00

74.80

See Parts

03 December 2014 US & Canada

2-TRACTOR- 10

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

(MY2015) 5075M Utility Tractor (60 PTO hp)

Continued

CODE

ATTACHMENT IDENTIFIER DESCRIPTION

ATTACHMENTS FOR FIELD CONVERSION ...Continued...

AL80126 Mirror, Telescopic, LH, Manually Adjustable

Cab only.

AL80127 Mirror, Telescopic, RH, Manually Adjustable

Cab only.

RE68495 Power Strip with Six Outlets

Cab Tractors (Codes 2050, 2055 or 2060) ONLY. Requires (1) RE67013, (1) RE67014, and (1) RE67015 Ordered Separately.

AL77888 Seat Backrest Extension

Premium Open Operator Station (Code 2005) Tractors ONLY.

AT162291 Seat Backrest Extension

Cab Tractors ONLY.

BLV10173 Wiper/Washer, Rear

Cab only.

PTO:

BLV10099 1000/540/540E RPM Power Take Off Kit

Not compatible with any Tractor equipped with a single speed PTO (540 only). New gear box (assembly required) and reversible PTO stub shaft included.

SUGGESTED

LIST PRICE

USD ($)

171.60

See Parts

343.20

1,479.50

BW16094 Stationary Fenders

AL71345 Vandal Protection, Door Locks - Custom Key 185.90

R262449 Front Weight Support, 187 Lbs See Parts

R127764 Weight, Front Suitcase 95 Lb. (43 kg) Quantity of One 134.20

R213907 Weight, Rear Wheel - 95 Lb.

AL156778 Wheel Spacers, MFWD, 2.36 In. (60 mm) with Hardware (Qty 2)

Stationary Fenders:

539.00

Compatible with H260 and H310 Loader only. Loader ordered separately. Fenders bolt directly to Loader mounting frame assembly.

Vandal Protection:

Weights:

222.20

Not compatible on wheels sized 24" or smaller. Maximum of 3 per wheel.

Wheel Equipment:

657.80

Fits MFWD Axles. Tread setting should not exceed 80 In. for maximum load applications. Kit contains (2) L154685 Hubs, (16) 24M7242 Washers, and (16) L152521 Bolts. Only for axles with 10.82 diameter bolt holes. For other hub thickness, see Parts.

03 December 2014 US & Canada

2-TRACTOR- 11

AGRICULTURAL PRODUCTS

JOHN DEERE TRACTORS

(MY2015) 5075M Utility Tractor (60 PTO hp)

Continued

THIS PAGE IS INTENTIONALLY LEFT BLANK

03 December 2014 US & Canada

2-TRACTOR- 12

John Deere 5045E, MY2015 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

(MY2015) 5045E Utility Tractor (37 PTO hp)

(MY2015) 5055E Utility Tractor (41-45 PTO hp)

(MY2015) 5065E Utility Tractor (49-53 PTO hp)

(MY2015) 5075E Utility Tractor (57-61 PTO hp)

5045D Open Operator Station Utility Tractor (37 PTO hp)

5055D Open Operator Station Utility Tractor (45 PTO hp)

5045E Open Operator Station Utility Tractor (37 PTO hp)

5055E Open Operator Station Utility Tractor (45 PTO hp)

5055E Cab Utility Tractor (45 PTO hp)

5065E Open Operator Station Utility Tractor (49-53 PTO hp)

5065E Cab Utility Tractor (49 PTO hp)

5075E Open Operator Station Utility Tractor (57-61 PTO hp)

5075E Cab Utility Tractor (57 PTO hp)

5085E Utility Tractor (70 PTO hp)

5100E Utility Tractor (85 PTO hp)

(MY2015) 5075M Utility Tractor (60 PTO hp)
