PB50 Mobile Label and Receipt Printer

User’s

Guide

Intermec Technologies Corporation

Worldwide Headquarters

6001 36th Ave.W.

Everett, WA 98203

U.S.A.

www.intermec.com

The information contained herein is provided solely for the purpose of allowing customers to operate and service Intermec-manufactured equipment and is not to be released, reproduced, or used for any other purpose without written permission of Intermec Technologies Corporation.

Information and specifications contained in this document are subject to change without prior notice and do not represent a commitment on the part of Intermec Technologies Corporation.

© 2007-2008 by Intermec Technologies Corporation. All rights reserved.

The word Intermec, the Intermec logo, Norand, ArciTech, Beverage Routebook, CrossBar, dcBrowser, Duratherm, EasyADC, EasyCoder, EasySet, Fingerprint, i-gistics, INCA (under license), Intellitag, Intellitag Gen2, JANUS, LabelShop, MobileLAN, Picolink, Ready-to-Work, RoutePower, Sabre, ScanPlus, ShopScan, Smart Mobile Computing, SmartSystems, TE 2000, Trakker Antares, and Vista Powered are either trademarks or registered trademarks of Intermec Technologies Corporation.

There are U.S. and foreign patents as well as U.S. and foreign patents pending.

Wi-Fi is a registered certification mark of the Wi-Fi Alliance.

Bluetooth is a trademark of Bluetooth SIG, Inc., U.S.A.

ii

PB50 Mobile Label and Receipt Printer User’s Guide

Document Change Record

This page records changes to this document. The document was originally released as Revision 001.

Version



Number Date

Description of Change

00211/2008 These changes were made for the current release:

Support for the ESC/P programming language.

Addition of a radioless PB50 printer.

Change to the Ready-to-Work indicator behavior.

Addition of linerless media support.

New icons for Bluetooth radio and addition of printhead lifted error message.

Addition of power management options Sleep Timer and Standby Timer.

iii

PB50 Mobile Label and Receipt Printer User’s Guide

PB50 Mobile Label and Receipt Printer User’s Guide

iv

Contents

Contents

Before You Begin. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii Global Services and Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii Warranty Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii Web Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . viii Telephone Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . viii Service Location Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . viii

Who Should Read This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix Related Documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix

1 Using the PB50 Mobile Label and Receipt Printer . . . . . . . . . . . . . . . . . . .

1

Learning About the PB50 Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 What’s New?. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Identifying the Parts of the Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Understanding the Printer Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Understanding the Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Understanding the Printer Sounds . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Managing Power on the PB50 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Using the Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Installing the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Charging the Batteries. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Understanding the Battery Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Extending Battery Life. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Loading Media. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Printing a Testprint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

2 Configuring the PB50. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Configuring the PB50 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Understanding the Display Modes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Understanding Ready Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Understanding Information Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Understanding Pause Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Understanding Setup Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Understanding Error Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Understanding Test Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

Changing Configuration Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Changing Configuration Settings From the Display . . . . . . . . . . . . . . . . 23

PB50 Mobile Label and Receipt Printer User’s Guide

v

Contents

Changing Configuration Settings From PrintSet . . . . . . . . . . . . . . . . . . . 25

Changing Configuration Settings Using the Command Line . . . . . . . . 25

Changing Configuration Settings From the Printer Home Page . . . . . . 26

Changing Configuration Settings From SmartSystems Console. . . . . . 26

Establishing Communications With a Host . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Setting Up Bluetooth Communications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Setting Up 802.11 Radio Communications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Configuring Wireless Printing Using IPL. . . . . . . . . . . . . . . . . . . . . . . . . . .31

Configuring Wireless Printing Using Fingerprint . . . . . . . . . . . . . . . . . . . 33

Setting Up USB Communications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Setting Up Serial Communications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

Upgrading the Firmware. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Downloading Fonts and Graphics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

3 Troubleshooting and Maintaining the PB50 . . . . . . . . . . . . . . . . . . . . . . . .

41

Troubleshooting the PB50 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Contacting Product Support. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Understanding Error Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Troubleshooting Printer Problems and Finding Solutions . . . . . . . . . . . . . . . . . . . 44

Troubleshooting Communication Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Using the Line Analyzer in Fingerprint. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Using Dump Mode in IPL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Cold Booting the PB50 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Cleaning the Printer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

A Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

51

Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Accessories for the PB50 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

B IPL and Fingerprint Setup Menus. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

IPL Setup Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Fingerprint Setup Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

vi

PB50 Mobile Label and Receipt Printer User’s Guide

Before You Begin

Before You Begin

This section provides you with safety information, technical support information, and sources for additional product information.

Safety Information

Your safety is extremely important. Read and follow all warnings and cautions in this document before handling and operating Intermec equipment. You can be seriously injured, and equipment and data can be damaged if you do not follow the safety warnings and cautions.

This section explains how to identify and understand warnings, cautions, and notes that are used in this document.

A warning alerts you of an operating procedure, practice, condition, or statement that must be strictly observed to avoid death or serious injury to the persons working on the equipment.

A caution alerts you to an operating procedure, practice, condition, or statement that must be strictly observed to prevent equipment damage or destruction, or corruption or loss of data.

Note: Notes either provide extra information about a topic or contain special instructions for handling a particular condition or set of circumstances.

Global Services and Support

Warranty Information

To understand the warranty for your Intermec product, visit the

Intermec web site at www.intermec.com and click Support >

Returns and Repairs > Warranty.

PB50 Mobile Label and Receipt Printer User’s Guide

vii

Before You Begin

Web Support

Visit the Intermec web site at www.intermec.com to download our current manuals (in PDF). To order printed versions of the Intermec manuals, contact your local Intermec representative or distributor.

Visit the Intermec technical knowledge base (Knowledge Central) at intermec.custhelp.com to review technical information or to request technical support for your Intermec product.

Telephone Support

In the U.S.A. and Canada, call 1-800-755-5505.

Outside the U.S.A. and Canada, contact your local Intermec representative. To search for your local representative, from the Intermec web site, click About Us > Contact Us.

Service Location Support

For the most current listing of service locations, go to

www.intermec.com and click Support >Returns and Repairs >

Repair Locations.

For technical support in South Korea, use the after service locations listed below:

AWOO Systems

102-1304 SK Ventium

522 Dangjung-dong

Gunpo-si, Gyeonggi-do Korea, South 435-776 Contact: Mr. Sinbum Kang

Telephone: +82-31-436-1191 E-mail: mjyun@awoo.co.kr

IN Information System PTD LTD

6th Floor

Daegu Venture Center Bldg 95 Shinchun 3 Dong

Donggu, Daegu City, Korea

E-mail: jmyou@idif.co.kr or korlim@gw.idif.co.kr

viii

PB50 Mobile Label and Receipt Printer User’s Guide

Before You Begin

Who Should Read This Manual

This user’s guide is for the person who is responsible for installing, configuring, and maintaining the PB50 printer.

This guide provides you with information about the features of the PB50, and how to install, configure, operate, maintain, and troubleshoot it.

Before you work with the PB50, you should be familiar with your network and general networking terms, such as IP address.

Related Documents

This table contains a list of related Intermec documents and their part numbers.

Document Title

Part Number





Intermec Fingerprint Command Reference Manual

937-005-xxx





Intermec Fingerprint Developer’s Guide

934-019-xxx





Intermec Printer Language (IPL) Developer’s Guide

934-013-xxx





Intermec Printer Language (IPL) Command Reference Manual

937-007-xxx





ESC/P Programmer’s Reference Manual

937-010-xxx





The Intermec web site at www.intermec.com contains our documents (as PDF files) that you can download for free.

To download documents

1 Visit the Intermec web site at www.intermec.com.

2 Click Support > Manuals.

3In the Select a Product field, choose the product whose documentation you want to download.

To order printed versions of the Intermec manuals, contact your local Intermec representative or distributor.

PB50 Mobile Label and Receipt Printer User’s Guide

ix

Before You Begin

x

PB50 Mobile Label and Receipt Printer User’s Guide

1Using the PB50 Mobile Label and Receipt Printer

Use this chapter to familiarize yourself with the PB50 and PB50C Mobile Label and Receipt Printers. In this chapter you will find these sections:

Learning About the PB50 Printer

Using the Batteries

Loading Media

Printing a Testprint

1

Chapter 1 — Using the PB50 Mobile Label and Receipt Printer

Learning About the PB50 Printer

The PB50 and PB50C are rugged direct thermal label and receipt printers designed for use with the CK31, 700 series, CK61, CN2B, CN3, and CN3e mobile computers as well as the SF51 and SR61 scanners.

Throughout this manual, both models of the printer are referred to as PB50 unless the information is specific to one model.

The PB50 provides:

print resolution of 203 dpi.

print speeds of up to 100 mm per second (4 ips).

802.11 radio, Bluetooth radio, or no radio options.

What’s New?

This version of the PB50 printer manual contains these changes:

Support for the ESC/P programming language.

Addition of a PB50 printer without a radio.

Change to the Ready-to-Work™ indicator behavior.

Addition of linerless media support.

New icons for Bluetooth radio and addition of printhead lifted error message.

Addition of the power management options Sleep Timer and Standby Timer.

2

PB50 Mobile Label and Receipt Printer User’s Guide

Chapter 1 — Using the PB50 Mobile Label and Receipt Printer

Identifying the Parts of the Printer

Use this illustrations to familiarize yourself with some of the features of the PB50.

Self-strip door

Media cover release button

Control panel

Ready-to-Work

Communications port

indicator



PB50 Printer: This illustration shows the important features of the PB50 printer. A weather-resistant flap protects the communications ports and the external power connector.

Understanding the Printer Firmware

Your PB50 printer comes with Intermec Printer Language (IPL), Fingerprint, or ESC/P firmware. The choice of firmware affects the functionality of the printer and how you interact with it. This manual contains information for using each type of printer firmware.

The current firmware type and version display on the PB50 screen when the printer is in Ready mode.

IPL 11.2.0

SER-COM

The PB50 Display Showing IPL Firmware

PB50 Mobile Label and Receipt Printer User’s Guide

3

Chapter 1 — Using the PB50 Mobile Label and Receipt Printer

Understanding the Control Panel

The PB50 control panel contains four buttons, a liquid crystal display (LCD), and one LED indicator. Use the four buttons to navigate the menu system and perform functions on the PB50 printer. See the following tables to understand the buttons, the menu system, and what the LED means.

Feed button

Setup button

SETUP:

SER-COM

Standby button

Info button

Ready-to-Work indicator

PB50 Control Panel: Use this illustration to familiarize yourself with the buttons and lights on the PB50.

Understanding How to Use the PB50 Buttons

Button



Name

Button Function





Feed

Press to advance label or receipt paper. The amount of



media that feeds is dependent on the type of media you



are using. It will advance by 5 mm (0.2 inch), feed out



an entire label, or feed a configured length of media



based on your media and settings.



If you hold the button down for longer than two



seconds, the printer performs a testfeed and calibrates



the media.



If the printer is printing, pressing this button causes



the printer to pause. Press the button again to resume



printing.





Setup

Press to display the Setup menu.





4

PB50 Mobile Label and Receipt Printer User’s Guide

Chapter 1 — Using the PB50 Mobile Label and Receipt Printer

Understanding How to Use the PB50 Buttons (continued)

Button





Name

Button

Function







Standby



Press to put the printer in Standby mode. In Standby

(Power)



mode, power to the radio, the display, and the





backlight are turned off.





Press to turn the printer back on and put in Ready





mode.







Info



Press to display a summary of error conditions, serial





port settings, USB connection status, and wireless





information (Bluetooth and WiFi). Each setting in the





summary information displays on the screen for five





seconds.







All of the buttons can act as “soft keys,” which means that the function of each button depends on the state of the printer. A small icon appears in the screen next to the button to indicate the function it performs

Understanding the Soft Keys

Button

Soft Keys Description





Moves through the settings at the same level in the menu system.

Exit Setup mode and return to Ready mode.

Moves up one level in the menu system. This soft key appears in Setup mode.

Increases the value of a number when editing settings s uch as an IP address. This soft key appears in Setup mode.

Pauses the printing job. This icon appears only when you are printing.

Moves down one level in the menu system and saves changes to a setting.

Exits a printing job or exits Information mode.

PB50 Mobile Label and Receipt Printer User’s Guide

5

Chapter 1 — Using the PB50 Mobile Label and Receipt Printer

There is only one LED on the PB50 printer: the Ready-to-Work indicator.

Understanding the Ready-to-Work Indicator

Indicator State

Description





Off

When the light is off, it can mean one of several



conditions:



The printer is in Standby mode.



The printer is in Info mode.



The printer is in Setup mode.

On

The PB50 is powered on and operating.





Blinking

A blinking light can mean one of several conditions:



The printer is out of paper.



The media cover is open.



There is a printer error that requires you to perform an



action. For a list of possible problems, see



“Troubleshooting the PB50” on page 42.





Understanding the Printer Sounds

The PB50 plays sounds in response to several actions that you can take with the printer. Use the following table to understand when the sounds occur and what they mean.

Understanding the Printer Sounds

Sound

Occurs When:





Power

You supply power (battery or AC adapter) to the



printer.



The PB50 starts charging the battery.





Hardware

You open the media door, close the media door, or insert a



cable.





Button

You press any of the PB50 buttons.





Error

The printer cannot feed paper or print a job because of



a hardware issue such as the media door open, a paper



jam, or there is no media.



An error occurs such as a paper jam or a print error.





6

PB50 Mobile Label and Receipt Printer User’s Guide

Chapter 1 — Using the PB50 Mobile Label and Receipt Printer

Managing Power on the PB50

Use the power options on the PB50 to manage and conserve battery power. From the Power option in Setup menu, you can set Low Battery, Sleep Timer, and Standby Timer.

Use the Low Battery option to set the battery voltage at which the low battery warning appears. The values for Low Battery range from 12.1 V to 16.8 V in 0.1 V increments. The default setting is 13.5 V.

Use the Sleep Timer option to set the amount of time it takes for the PB50 to go to “sleep” if the printer is not printing and you do not have any interaction with it. When the printer goes to “sleep,” it turns off the backlight and it dims the Ready-to-Work indicator. By default, the printer backlight turns off after 20 seconds of no user interaction. You can set Sleep Timer to always off, always on, 5 seconds, 10 seconds, 20 seconds, 30 seconds, or 60 seconds. The backlight turns on when:

the printer begins printing.

you press a button.

you connect the printer to external power.

you are communicating with or sending data to the printer.

Note: If you have Sleep Timer set to always on, the Standby timer setting will have no effect on the PB50.

Use the Standby Timer option to turn off power to the radio, the display, and the backlight. The Standby Timer option has the same effect on the PB50 as pressing the Standby button. When the printer is in Standby mode, both the LCD and the Ready-to-Work indicator are turned off. You can set Standby Timer to 5 mins, 10 mins, 20 mins, 30 mins, 60 mins, or disabled. Press the Standby button to turn the printer back on.

PB50 Mobile Label and Receipt Printer User’s Guide

7

Chapter 1 — Using the PB50 Mobile Label and Receipt Printer

Using the Batteries

The PB50 uses a rechargeable 2200 mAh lithium-ion battery (Model AB13) for power. You must fully charge the battery before you can use the PB50. A fully charged battery can last up to one week without needing to be recharged when the printer is in Standby mode.

Use Intermec Model AB13 battery only. Use of another battery may present a risk of fire or explosion.

The Model AB13 battery may present a fire or chemical burn hazard if mistreated. Do not disassemble, heat above 100°C (212°F), or incinerate.

Dispose of used batteries promptly. Keep away from children.

Installing the Battery

Make sure you fully charge the battery before you use your PB50. You can charge the battery before or after you install them into the PB50.

To install the battery

1 Lay the PB50 upside down on a flat surface.

2Insert the battery with the tab facing away from the front control panel.

8

PB50 Mobile Label and Receipt Printer User’s Guide

Chapter 1 — Using the PB50 Mobile Label and Receipt Printer

3Insert the edge of the battery under the lip of the PB50 and then push down until you hear the battery latch click.

Charging the Batteries

There are two ways to charge the PB50 battery:

Connect AC power to the printer and charge the battery while it is in the PB50.

Charge the battery in the AC18 4-bay battery charger.

For information on charging your battery in the 4-bay battery charger, see the AC18 4-Bay Battery Charger Instructions

(P/N 943-128-xxx).

It takes approximately 6 hours to charge the battery while it is installed in the PB50 printer. To charge the battery inside the PB50, you need:

an Intermec 12 VDC power supply (Model AE19).

an AC power cord.

To charge the battery inside the PB50

1Install the battery in the PB50. For help, see the previous section,

“Installing the Battery” on page 8.

2Connect the power supply to the DC power connector on the printer.

3Connect one end of the power cord to the power supply and then plug the other end into an AC outlet.

PB50 Mobile Label and Receipt Printer User’s Guide

9

Chapter 1 — Using the PB50 Mobile Label and Receipt Printer

Understanding the Battery Icons

The easiest way to tell the status of your battery is to look at the battery icons on the control panel of the PB50.

Battery Icon Status

Icon Status

Battery is fully charged.

Battery has a medium charge. You should be able to work for several more hours before charging or replacing the battery.

Battery is low. You need to replace the battery soon.

Battery is critically low. You need to replace the battery now.

Battery charging error. You may need to replace the battery.

External power connected and there is no battery in the printer.

Extending Battery Life

Here are some tips for extending the overall life of your battery:

Never expose the battery to direct sunlight or temperatures over 40°C (104°F).

Only charge the battery inside the PB50 using a power supply or in the 4-bay battery charger (Model AC18).

Do not set the backlight to always on. The always on setting disabled automatic power saving modes.

Here are some tips for extending the life of your battery between charges:

Press the Standby button to put the printer in Standby mode.

Remove the battery from the printer if you will not be using it for three days or more.

10

PB50 Mobile Label and Receipt Printer User’s Guide

Chapter 1 — Using the PB50 Mobile Label and Receipt Printer

Do not operate the PB50 in extremely cold temperatures. Using the PB50 in temperatures below freezing reduces the overall battery life.

Remember that any rechargeable battery loses its ability to maintain a charge over time. You can only recharge it a finite number of times before you must replace it.

Loading Media

You can use roll or fanfold receipt media with the PB50 printer. The PB50 ships with a small amount of media loaded and a test page printed to verify that the printer works. The PB50 supports self-strip printing applications. For information on how to correctly load media for self-strip printing, see “To load media for self-strip printing” on page 14. For information on media specifications, see

“Specifications” on page 52.

To load media

1Press down on the blue media cover release button until the cover releases.

PB50 Mobile Label and Receipt Printer User’s Guide

11

Chapter 1 — Using the PB50 Mobile Label and Receipt Printer

2Press down on the media adjust guide and slide the two media supports apart.

3Insert a roll of media and press the media adjust guide until the roll is held firmly in place. Make sure you load the media clockwise so that it pulls off the core from the bottom of the printer.

4 Pull out approximately 8 cm (3 inches) of the media.

12

PB50 Mobile Label and Receipt Printer User’s Guide

Chapter 1 — Using the PB50 Mobile Label and Receipt Printer

5Close the media cover until it latches. The printer emits the hardware sound to tell you that the media door closed correctly.

6Press down on the self-strip door to make sure the media cover is completely latched.

Note: The linerless printer does not have a self-strip door. Instead, the self-strip door is molded plastic and part of the media cover.

7Press and hold the Feed button for more than two seconds to calibrate the media.

PB50 Mobile Label and Receipt Printer User’s Guide

13

Chapter 1 — Using the PB50 Mobile Label and Receipt Printer

To load media for self-strip printing

1 Complete Steps 1 through 4 in the previous procedure.

2 Open the self-strip door in the media cover.

Self-strip door

Self-strip bar

3Remove a label from the roll of media so that you are left with several inches of label liner.

4Feed the label liner over the self-strip bar and out the back of the self-strip door.

5Close the media cover until it latches and press down on the selfstrip door to make sure it locks.

6 Pull on the liner to tighten it and ensure a good self strip.

14

PB50 Mobile Label and Receipt Printer User’s Guide

Chapter 1 — Using the PB50 Mobile Label and Receipt Printer

7Press and hold the Feed button for more than two seconds to calibrate the media.

Printing a Testprint

After you have loaded media in the printer, you are ready to print a testprint. You can choose from several testprint options for each type of firmware. If you cannot get the testprint information to print, see

“Troubleshooting the PB50” on page 42.

To print a testprint with a PB50 loaded with IPL firmware

1

Press the Setup button.

2

Press

until you reach Test/Service.

3

Press

to enter the Test/Service menu system.

4

Press

to enter the Testprint Config menu.

5

Press

to enter the Config menu.

6

Press

to choose a testprint.

7

Press

to print the Config testprint of your choice.

To print a testprint with a PB50 loaded with Fingerprint firmware

1

Press the Setup button.

2

Press

until you reach Print Defs.

3

Press

to enter the Print Defs menu system.

4

Press

until you reach Testprint.

5

Press

to enter the Testprint menu.

6

Press

to choose a testprint.

7

Press

to print the testprint of your choice.

Before you can print a self test with ESC/P firmware, you need to establish communications between the PB50 and your network. For help, see “Establishing Communications With a Host” on page 27.

To print a self test with a PB50 loaded with ESC/P firmware

Send the ESC EZ{TP} command to the printer.

PB50 Mobile Label and Receipt Printer User’s Guide

15

Chapter 1 — Using the PB50 Mobile Label and Receipt Printer

16

PB50 Mobile Label and Receipt Printer User’s Guide

2 Configuring the PB50

In this chapter you will find these sections:

Configuring the PB50

Establishing Communications With a Host

Upgrading the Firmware

Downloading Fonts and Graphics

17

Chapter 2 — Configuring the PB50

Configuring the PB50

You can change the configuration settings of the PB50 printer directly from the display, by sending commands from your PC, by using the web pages, or remotely from the SmartSystems console.

For more information on the IPL and Fingerprint menu systems, see“IPL and Fingerprint Setup Menus” on page 57.

Understanding the Display Modes

The PB50 has six display modes to help you effectively interact with the printer: Ready, Information, Paused, Setup, Error, and Test. Use the following sections to understand the different printer modes.

Understanding Ready Mode

The printer is in Ready mode when the printer is on and ready to print. The main screen displays the power status, the radio status, and the printer language and version.

IPL 11.2.0

SER-COM

The PB50 in Ready Mode

Understanding Information Mode

When the printer is in Information mode, it displays a subset of network information about the printer. If the printer experienced an error, the error message displays first followed by the printer information. Each message displays on the screen for five seconds. After five seconds on the last information screen, the printer exits Information mode.



I/O serial

5

X





SER-COM





8N1 9600













The PB50 in Information Mode

18

PB50 Mobile Label and Receipt Printer User’s Guide

Chapter 2 — Configuring the PB50

To enter Information mode

Press the Information button on the control panel.

Understanding Pause Mode

Use Pause mode to momentarily stop printing or to cancel a current print job. Once you pause the printer, the Pause mode screen appears. Use the Feed button to both pause and resume printing.

PAUSE

X

The PB50 in Pause Mode

To enter Pause mode

Press the Feed button while the printer is printing.

To resume printing

Press the Feed button (or soft key).

To cancel a print job

1 Press the Feed button to pause printing.

2Press the Information button (or soft key) to cancel the print job.

Understanding Setup Mode

Use Setup mode to change the settings on the printer.

Sample Setup Mode Screen

To enter or exit Setup mode

Press the Setup button.

PB50 Mobile Label and Receipt Printer User’s Guide

19

Chapter 2 — Configuring the PB50

Once you enter Setup mode, there are two editing modes: normal and enhanced.

Editing Settings in Setup Mode

Editing Mode

To Navigate

To Accept Value











Normal

Press

to move among

Press .



choices.







Press

to go up a level



in menu system.

Enhanced

Press to move within Press

.



the editable fields. When





the field blinks, you can





edit it.



Press to increase the value of the field.

BAUDRATE:

9600

Normal Editing Mode: In normal editing mode, you see an up arrow and a right arrow for making selections.

+IP ADDRESS: 130.42.240.102

Enhanced Editing Mode: In enhanced editing mode you have a plus sign and a right arrow to change the value of numeric fields.

Understanding Error Mode

The printer enters Error mode when it detects an error condition such as a low battery or a paper fault. Some error messages appear on the screen immediately when they occur, such as DOOR OPEN. Other error messages do not appear until you press the Info button. If there is more than one error at a given time, the errors display in the order that they occurred.

20

PB50 Mobile Label and Receipt Printer User’s Guide

Chapter 2 — Configuring the PB50

PAPER FAULT

Sample Error Mode Screen

If you encounter an error message, see “Understanding Error Messages” on page 42 for information on how to fix the problem.

Understanding Test Mode

Use Test mode to verify printer settings, print test labels, restore factory default settings, or enter Dump mode for troubleshooting purposes. Two test modes are available: Test mode and Extended Test mode.

Using Test Mode

Test mode is a simple sequence of events which requires little user interaction. Extended Test mode requires more user interaction and lets you choose which actions you want the printer to perform.

To enter Test mode

1 Make sure the printer is in Ready mode and is loaded with media.

2Press the Feed and Standby buttons at the same time and hold until Select Media appears on the screen and it displays the type of media you are using.

3Release both buttons. The printer performs a test feed (sensor calibration), prints a series of test labels, and then enters Dump mode.

The printer is now in Dump mode and it scans the communication ports. Any characters received on the communication ports are printed.

4 Press Feed to exit Dump mode.

After you exit Dump mode, the printer returns to Ready mode. For more information on Dump mode, see “Troubleshooting Communication Problems” on page 46.

PB50 Mobile Label and Receipt Printer User’s Guide

21

Chapter 2 — Configuring the PB50

Using Extended Test Mode

Use Extended Test mode to run additional diagnostic tests, including printing specific test labels, entering Dump mode, and resetting to factory defaults.

TEST LABELS

CHESS

Sample Extended Test Mode Screen

To enter Extended Test mode

1 Make sure that the printer is loaded with media.

2 Press the media cover release button to open the media cover.

3 Press the Standby button to turn the printer off.

4Press Feed and Standby buttons at the same time until CLOSE PRINTER DOOR appears on the screen.

5Close the media cover. You are now in Extended Test mode.

Press to cycle through the options.

Press to select a test option.

Press to exit Extended Test mode.

Options in Extended Test Mode

Function

Description









Select Media

This option is almost the same as the



process in Test mode, except that the



printer performs a slow test feed in



Extended Test mode. The slow test feed



enables the printer to perform a slow



sensor calibration which can help resolve



gap or mark detection problems.









Test Labels

This option allows you to print test labels



one at a time. Press



to print the next







label.









22

PB50 Mobile Label and Receipt Printer User’s Guide







Chapter 2 — Configuring the PB50

Options in Extended Test Mode (continued)









Function

Description













Dump Mode

This options enters Dump mode. For more



information on Dump mode, see



“Troubleshooting Communication



Problems” on page 46.











Factory Default

This option restores the factory default



settings. Press



to select this option and







then follow the instructions on the screen.











Setup and Exit

This option exits Extended Test mode and



puts the printer in Setup mode.











Exit

This option exits Extended Test mode.











Changing Configuration Settings

There are several ways you can change the configuration settings of the printer. You can change the configuration settings:

from the display.

from the host PC using PrintSet.

from the host PC using the command line.

from the printer home page.

from the SmartSystems Console.

Changing Configuration Settings From the Display

You need to enter Setup mode before you can change configuration settings. For more information on entering Setup mode and navigating through the settings, see “Understanding Setup Mode” on page 19.

The top levels of the Setup menu are organized in a one-way loop.

Each level has several sub-levels.

Note: The ESC/P printer does not have a Setup menu.

PB50 Mobile Label and Receipt Printer User’s Guide

23

Chapter 2 — Configuring the PB50

Note: If you have a Bluetooth or radioless printer, you will not see the NETWORK setup menu in Fingerprint or IPL.

















Starting point















































































































SETUP:







SETUP:







SETUP:

















































DISPLAY







SER-COM,UART1







NET-COM, NET1





































SETUP:





















SETUP:

































BATTERY





















NETWORK







































SETUP:







SETUP:







SETUP:































PRINT DEFS







MEDIA







FEEDADJ































The Main Levels of the Setup Menu in Fingerprint



















Starting point













































































































SETUP:







SETUP:







SETUP:













































DISPLAY







SER-COM







NETWORK





































































SETUP:





















SETUP:

































BATTERY





















TEST/SERVICE









































SETUP:







SETUP:











CONFIGURATION







MEDIA





The Main Levels of the Setup Menu in IPL

24

PB50 Mobile Label and Receipt Printer User’s Guide

Chapter 2 — Configuring the PB50

Changing Configuration Settings From PrintSet

PrintSet Version 4.2 (or higher) is a printer configuration tool that you can download from the Intermec web site. PrintSet can communicate with your printer through a serial cable or a network connection. It works on all PCs running Windows 98 (or later). PrintSet allows you to easily change all of the setup parameters. It also includes setup wizards to guide you through some common configuration tasks.

Changing Configuration Settings Using the Command Line

You can change configuration parameters by sending commands directly to the printer using your terminal program (HyperTerminal) and a serial or network connection.

If your printer uses the Fingerprint language, you use the SETUP command, followed by the node, subnode, and parameters setting. Here is a Fingerprint example that sets your media setting to labels with gaps:

SETUP "MEDIA,MEDIA TYPE,LABEL (w GAPS)"

If your printer uses the IPL language, you would send this command:

<STX><SI>T1<ETX>

Fingerprint automatically sends feedback to HyperTerminal as you type. If you want to see what you are typing with IPL, you need to complete the following procedure.

To see IPL commands as you type

1From the HyperTerminal menu, select File > Properties > the

Settings tab.

2 Click the ASCII Setup button.

3 Select Echo typed characters locally.

4 Click OK twice.

For more information on how to change configuration settings, see either the Fingerprint Command Reference Manual (P/N 937-005-xxx) or the IPL Command Reference Manual (P/N 937-007-xxx). You can download both documents from the Intermec web site at www.intermec.com.

PB50 Mobile Label and Receipt Printer User’s Guide

25

Chapter 2 — Configuring the PB50

Changing Configuration Settings From the Printer Home Page

If you have an 802.11 radio in your PB50 printer and it is connected to the network, you can use your web browser to open the printer home page and make configuration changes. To connect to a wireless network, follow the procedure in “Setting Up 802.11 Radio Communications” on page 28.

The PB50 Printer Home Page

To make changes to the configuration

From the home page, click Configuration.

Changing Configuration Settings From SmartSystems Console

You can use the SmartSystems Console to change configuration settings on your printer. The PB50 ships with the SmartSystems client loaded on it. The console is part of SmartSystems Foundation and is available from the Intermec web site. To download SmartSystems Foundation, go to www.intermec.com/products/ smrtsysfoundation/index.aspx.

26

PB50 Mobile Label and Receipt Printer User’s Guide

Chapter 2 — Configuring the PB50

Establishing Communications With a Host

The PB50 must establish communications with a host that will send the data for the printer to print. The PB50 provides four ways to communicate with a host:

Bluetooth radio communications

802.11 b/g radio communications

USB communications

Serial communications

Setting Up Bluetooth Communications

The PB50C can contain a Bluetooth radio that allows wireless communications with a remote device from distances up to 100 meters (approximately 328 feet) depending on the Bluetooth range capabilities of the remote device, environmental conditions, and obstructions. For the Bluetooth-enabled devices to exchange data, both devices must establish a connection. Bluetooth software is always running in the background.

The PB50C cannot initiate a Bluetooth connection. One of the devices, such as a CK31, CK61, 700 series, CN2B, or CN3 mobile computer, must request a connection with the printer. The PB50C then accepts or rejects the connection. Use Intermec Settings on the mobile computer to enable the Bluetooth settings on the PB50C.

The PB50C can also connect to Bluetooth scanners such as the SF51 and the SR61 Cordless scanners. You can create the bar code labels you need to connect the printer to a Bluetooth scanner using EasySet software. If you are going to create the bar code labels using EasySet, you will need to know the Bluetooth Device Address and the PIN of the PB50C. You can download a free version of EasySet from the Intermec web site at www.intermec.com.

Each PB50C equipped with a Bluetooth radio has a unique Bluetooth Device Address (BDA) loaded into its module when manufactured. You can find the BDA on the certification label located on the bottom of the printer.

PB50 Mobile Label and Receipt Printer User’s Guide

27

Chapter 2 — Configuring the PB50

To set up Bluetooth communications with a mobile computer

Follow the procedure to discover and connect to Bluetooth devices in your mobile computer user’s manual.

Note: For maximum security, you need to configure a Bluetooth passcode for the PB50C. The default passcode for the PB50C is “1234.”

To set up Bluetooth communications with a scanner 1 Download and install EasySet.

2Create the following bar code labels using EasySet:

Administrator reset factory defaults

Bluetooth parameters - security - not active

Bluetooth parameters - connect/disconnect - compose BT address

Bluetooth parameters - security - compose PIN:

3 Scan the bar code labels with the Bluetooth scanner.

Understanding Bluetooth Radio Icons

Icon Description

The Bluetooth radio is on and the printer is not connected to a serial cable.

The Bluetooth radio is turned off. The Bluetooth radio turns off when you connect a serial cable.

Setting Up 802.11 Radio Communications

The PB50 can have an internal 802.11 b/g radio to transfer and receive data using wireless communications. This manual assumes that you have already set up your wireless communications network including your access points. The following procedures include information on setting up wireless security for both IPL and Fingerprint versions of the PB50.

28

PB50 Mobile Label and Receipt Printer User’s Guide

Chapter 2 — Configuring the PB50

The PB50 supports these authentication modes: none, WEP, WPA Personal and Enterprise mode (802.1x authentication), WPA2 Personal and Enterprise mode (802.1x authentication).

Note: WPA and WPA2 Enterprise mode currently support PEAP, TTLS, and LEAP. For LEAP authentication, the PB50 supports Open EAP, but does not support Network EAP.

To set up the PB50 to work in your wireless network, you will need:

Serial cable (P/N 075497-001)

Host PC running Windows or Linux

Serial port software such as HyperTerminal

Note: If you are using IPL commands with HyperTerminal, you may want to be able to see the commands as you type them on your screen. For help, see “Changing Configuration Settings Using the Command Line” on page 25.

To set up the PB50 for wireless communications

1Connect the 8-pin circular DIN connector to the serial port on the PB50.

2Connect the other end of the serial cable to a serial port on the back of your PC or to a serial adapter on your mobile computer.

3Open HyperTerminal on your PC and configure the following parameters for the serial port:

Parameter

Default Setting





Baud rate

115200





Data bits

8





Parity

None





Stop bits

1





PB50 Mobile Label and Receipt Printer User’s Guide

29

Chapter 2 — Configuring the PB50

4From the host PC, check the wireless settings.

If you have an IPL version of the printer, send these commands to the PB50:

<STX><SI>wt,SSID<ETX>

<STX><SI>wt,WEP1<ETX>

<STX><SI>wt,WEP2<ETX>

<STX><SI>wt,WEP3<ETX>

<STX><SI>wt,WEP4<ETX>

<STX><SI>wt,AUTH<ETX>

<STX><SI>wt,WPA<ETX>

<STX><SI>wt,WPA2<ETX> <STX><SI>wt,WPA_PSK<ETX> <STX><SI>wt,ROAM<ETX> <STX><SI>wt,PWR_MODE<ETX> <STX><SI>wt,CHANNEL<ETX> <STX><SI>wt,AP_MAC<ETX> <STX><SI>wt,SIGNAL<ETX> <STX><SI>wt,SPEED<ETX> <STX><SI>wt,ACTIVE<ETX>

If you have a Fingerprint version of the printer, send this command to the PB50:

setup write "wlan","uart1:"

5Set up the PB50 to use the correct SSID and authentication modes. See one of the following procedures to configure wireless printing on your IPL or Fingerprint printer.

6If you are going to use certificates for validation, transfer the certificate to the printer. The printer can accept .pfx, .pem, and

.der certificates.

7Verify that the PB50 is connected to the access point and make sure it has an IP address allocated to it.

Understanding the 802.11 Radio Icons

Icon

Description







Excellent signal







Strong signal







Good signal





30

PB50 Mobile Label and Receipt Printer User’s Guide

Chapter 2 — Configuring the PB50

Understanding the 802.11 Radio Icons (continued)

Icon

Description







Weak signal







Poor signal







No signal

Use the following sections to set most of your wireless communication settings. For help with additional commands and information, see either the Fingerprint Command Reference Manual (P/N 937-005-xxx) or the IPL Command Reference Manual (P/N 937-007-xxx). You can download both documents from the Intermec web site at www.intermec.com.

Configuring Wireless Printing Using IPL

Use the following procedures to configure your PB50 with IPL for wireless printing.

To configure the printer to use WEP authentication

1Send the following commands to login as an admin and set the SSID:

<STX><ESC>.x,su -p pass admin<ETX> <STX><SI>ws,SSID,xxxxx<ETX>

where xxxxx can be from 0 to 32 ASCII characters, not including the double quote.

Note: The default password for logging in as an admin is “pass.” If you have changed the password, you will need to use your password instead of “pass.”

2Send the following commands to configure the WEP keys. The following example sets WEP key 1 to 1234 and enables WEP key 1.

<STX><SI>ws,WEP1, 0x0001020304<ETX> <STX><SI>ws,.WEP_KEY,1<ETX>

3Send the following command to activate the settings.

<STX><SI>ws,ACTIVE,1<ETX>

PB50 Mobile Label and Receipt Printer User’s Guide

31

Chapter 2 — Configuring the PB50

To configure the printer to use WPA-PSK or WPA2-PSK mode

1Send the following commands to login as an admin and set the SSID:

<STX><ESC>.x,su -p pass admin<ETX> <STX><SI>ws,SSID,xxxxx<ETX>

where xxxxx can be from 0 to 32 alphanumeric characters.

2Send one of the following commands to turn on WPA or WPA2 authentication. Send the WPA-PSK or WPA2-PSK command to set a pre-shared key:

<STX><SI>ws,WPA,ON<ETX>

<STX><SI>ws,WPA2,ON<ETX> <STX><SI>ws,WPA_PSK, xxxxxxxxxx<ETX>

where xxxxxxxxxx is a value between 8 and 64 characters.

3 Send the following command to activate the settings:

<STX><SI>ws,ACTIVE,1<ETX>

To configure the PB50 to use WPA or WPA2 Enterprise mode

1Send the following commands to login as an admin and set the SSID:

<STX><ESC>.x,su -p pass admin<ETX> <STX><SI>ws,SSID,xxxxx<ETX>

where xxxxx can be from 0 to 32 alphanumeric characters.

Note: The default password for logging in as an admin is “pass.” If you have changed the password, you will need to use your password instead of “pass.”

2Send one of the following commands to enable WPA-802.1x or WPA2-802.1x authentication. You should also send the WPA_PSK command that does not contain a value:

<STX><SI>ws,WPA,ON<ETX>

<STX><SI>ws,WPA2,ON<ETX> <STX><SI>ws,WPA_PSK, <ETX>

3 Send these commands to configure the EAP_TYPE:

<STX><SI>ws,EAP_TYPE,xxxx<ETX>

where xxxx can be OFF, LEAP, PEAP, or TTLS.

<STX><SI>ws,.EAP_USER,xxxx<ETX> <STX><SI>ws,.EAP_PASS,xxxx<ETX>

32

PB50 Mobile Label and Receipt Printer User’s Guide

Chapter 2 — Configuring the PB50

where xxxx is the unique username and the unique password for this protocol.

4If you are using TTLS, you may need to send this command to set the TTLS outer name:

<STX><SI>ws,TTLS_USER, xxxx <ETX> where xxxx is the outer name.

5If you are using certificates for validation, here are some commands you may need to use.

Send the following commands to set a certificate and enable validation:

<STX><SI>ws,CA_CERT,c:/testCA.pfx@export<ETX> <STX><SI>ws,VALIDATE,ON<ETX>

where c:/testCA.pfx is the location and name of the certificate and export is the passphrase.

Send the following commands to set a common name for server 1 and server 2:

<STX><SI>ws, .SERVER_CN1,xxxxxxxxxx <ETX> <STX><SI>ws, .SERVER_CN2,xxxxxxxxxx <ETX>

where xxxxxxxxxx can be a value from 0 to 64 characters.

Send the following command to make sure your values match those used by the access point:

<STX><SI>wt,[variable name]<ETX>

All variables are returned with the exception of EAP_PASS which always returns “****” if configured and CA_CERT which transmits the name of the last certificate authority successfully installed. An additional read-only variable for the supplicant state, called STATE, is also returned.

You may need to send the following command several times for the wireless station to connect:

<STX><SI>ws,ACTIVE,1<ETX>

Configuring Wireless Printing Using Fingerprint

Use the following procedures to configure your PB50 with Fingerprint for wireless printing.

PB50 Mobile Label and Receipt Printer User’s Guide

33

Chapter 2 — Configuring the PB50

To configure the printer to use WEP authentication

1Send the following commands to login as an admin and set the SSID:

run"su -p pass admin"

setup write "wlan","uart1:" setup "wlan","SSID","xxxxx"

where xxxxx can be from 0 to 32 ASCII characters, not including the double quote.

Note: The default password for logging in as an admin is “pass.” If you have changed the password, you will need to use your password instead of “pass.”

2Send the following commands to configure the WEP keys. The following example sets WEP key 1 to 1234 and enables WEP key 1.

setup "wlan","WEP1","0x0001020304" setup "wlan",".WEP_KEY","1"

setup "wlan","ACTIVE","1" setup write "wlan","uart1:"

To configure the printer to use WPA-PSK or WPA2-PSK mode

1Send the following commands to login as an admin and set the SSID:

run"su-p pass admin"

setup write "wlan","uart1:" setup "wlan","SSID","xxxxx"

where xxxxx can be from 0 to 32 alphanumeric characters.

2Send one of the following WPA/WPA2 ON commands to turn on WPA or WPA2 authentication. Send the WPA-PSK or WPA2-PSK command to set a pre-shared key:

setup "wlan","WPA","ON" setup "wlan","WPA2","ON"

setup "wlan","WPA_PSK","xxxxxxxxxx" setup "wlan","ACTIVE","1"

setup write "wlan","uart1:"

where xxxxxxxxxx is a value between 8 and 64 characters.

To configure the PB50 to use WPA or WPA2 Enterprise mode

1Send the following commands to login as an admin and set the SSID:

34

PB50 Mobile Label and Receipt Printer User’s Guide

Chapter 2 — Configuring the PB50

run"su-p pass admin"

setup write "wlan","uart1:" setup "wlan","SSID","xxxxx"

where xxxxx can be from 0 to 32 alphanumeric characters.

2Send one of the following WPA/WPA2 ON commands to set up WPA-802.1x or WPA2-802.1x authentication. You should also send the WPA_PSK command that does not contain a value:

setup "wlan","WPA","ON" setup "wlan","WPA2","ON" setup "wlan","WPA_PSK","" setup write "wlan","uart1:"

To view the 802.1x values, send this command:

setup write "8021x","uart1:"

3 Send these commands to configure the EAP_TYPE:

setup "8021x","EAP_TYPE","xxxx"

where xxxx can be OFF, LEAP, PEAP, or TTLS.

setup "8021x",".EAP_USER","xxxx" setup "8021x","EAP_PASS","xxxx"

where xxxx is the unique username and the unique password for this protocol.

4If you are using TTLS, you may need to send this command to set the TTLS outer name:

setup "8021x","TTLS_USER","xxxx" where xxxx is the outer name.

5If you are using certificates for validation, here are some commands you may need to use.

Send the following commands to set a certificate and enable validation:

setup "8021x","CA_CERT","c:/test.pfx@export" setup "8021x","VALIDATE","ON"

where c:/test.pfx is the location and name of the certificate and export is the passphrase.

Send the following commands to set a common name for server 1 and server 2:

setup "8021x",".SERVER_CN1","xxxxxxxxxx" setup "8021x",".SERVER_CN2","xxxxxxxxxx"

PB50 Mobile Label and Receipt Printer User’s Guide

35

Chapter 2 — Configuring the PB50

where xxxxxxxxxx can be a value from 0 to 64 characters.

Send the following command to make sure your values match those used by the access point:

setup write "8021x","uart1:"

You may need to send the following command several times for the wireless station to connect:

setup "wlan","ACTIVE","1"<ETX>

Setting Up USB Communications

To set up USB communications with your PC, you will need:

USB cable

Intermec InterDriver® software

You can download the InterDriver software from the Intermec web site at www.intermec.com.

Setting Up Serial Communications

Use a serial cable (P/N 075497-001) to connect the PB50 to a PC or a mobile computer. For the mobile computer, you may need to purchase a serial adapter. For more information, contact your local Intermec sales representative.

Before you can establish a serial connection, you need to make sure that the settings on the PC or mobile computer match those of the PB50.

Serial Port Settings on the PB50

Parameter

Default Setting





Baud rate

115200





Data bits

8





Parity

None





Stop bits

1





Flow control

XON_XOFF (IPL)



RTS/CTS (ESC/P)





36

PB50 Mobile Label and Receipt Printer User’s Guide

Chapter 2 — Configuring the PB50

To connect the PB50 to a PC or mobile computer

1Connect the 8-pin circular DIN connector to the serial port on the PB50.

2Connect the other end of the serial cable to a serial port on the back of your PC or to a serial adapter on your mobile computer.

Serial cable

Serial port

Upgrading the Firmware

The latest firmware and software is always available for download from the Intermec web site at www.intermec.com.

To download firmware updates

1 Go to the Intermec web site at www.intermec.com.

2 Click Support > Downloads.

3In the Select a Product field, choose PB50 mobile printer. The latest available software displays on the page.

4Download the latest firmware version to your computer. Make sure you choose the correct firmware upgrade for your IPL, Fingerprint, or ESC/P printer.

5 Extract the .zip file to a folder on your computer.

PB50 Mobile Label and Receipt Printer User’s Guide

37

Chapter 2 — Configuring the PB50

You have options for upgrading the firmware based on whether your PB50 has a Bluetooth radio, an 802.11 b/g radio, or no radio. Use one of the following procedures to upgrade your printer firmware. Your printer should reboot after you finish upgrading the firmware. If it does not reboot, you will need to cold boot the printer. For help, see

“Cold Booting the PB50” on page 48.

To upgrade your printer using PrintSet

1Download the latest version of PrintSet from the Intermec web site at www.intermec.com.

2Select File > Add Printer to start the Add Printer Wizard which guides you through the process of adding your printer.

3Select your printer under My Printers and then go to Printer >

Firmware Wizard.

The Firmware Wizard guides you through the necessary steps to update your firmware.

To upgrade your printer using an 802.11 network connection

1Browse to the home page of the printer. For help, see “Changing

Configuration Settings From the Printer Home Page” on page 26.

2 From the home page, click Maintenance.

3From the Firmware upgrade page, browse to the upgrade firmware file.

4 Click Upgrade.

To upgrade your printer using a serial connection

1Make sure you have established serial communications between your PC and the PB50. For help, see “Setting Up Serial Communications” on page 36.

2Use Fingerprint, IPL, or ESC/P commands to send the upgrade file to the printer.

For help with Fingerprint, IPL, or ESC/P commands and information, see the Fingerprint Command Reference Manual, the IPL Command Reference Manual, or the ESC/P Programmer’s Reference Manual. You can download all of the documents from the Intermec web site at www.intermec.com.

38

PB50 Mobile Label and Receipt Printer User’s Guide

Chapter 2 — Configuring the PB50

Downloading Fonts and Graphics

The easiest way to download fonts and graphics is to use the free Intermec printer application called PrintSet. You can download PrintSet from the downloads page for the PB50 printer on the Intermec web site at www.intermec.com. Follow the procedures in the PrintSet online help to download fonts and graphics.

You can also use Fingerprint, IPL, or ESC/P commands to send fonts and graphics to the printer. For help with commands and information, see either the Fingerprint Command Reference Manual, the IPL Command Reference Manual, or the ESC/P Programmer’s Reference Manual. You can download both documents from the Intermec web site at www.intermec.com.

PB50 Mobile Label and Receipt Printer User’s Guide

39

Chapter 2 — Configuring the PB50

40

PB50 Mobile Label and Receipt Printer User’s Guide

3Troubleshooting and Maintaining the PB50

Use this chapter to solve problems you may encounter while using the PB50. You will also find information on booting the printer and routine maintenance.

In this chapter, you will find these sections:

Troubleshooting the PB50

Cold Booting the PB50

Cleaning the Printer

41

Chapter 3 — Troubleshooting and Maintaining the PB50

Troubleshooting the PB50

You may have printer operation, print quality, or printer communication problems at some time during the life of the PB50 printer. It is easy to fix most of the problems and you will find solutions in “Troubleshooting Printer Problems and Finding Solutions” on page 44. If you cannot find the answer to your problem, you may need to contact Product Support.

Contacting Product Support

Before you call Intermec Product Support, you may want to visit the Intermec technical knowledge base (Knowledge Central) at intermec.custhelp.com to review technical information or to request technical support. If you still need help after visiting Knowledge Central, you may need to call Product Support.

To talk to an Intermec Product Support representative in the U.S.A. or Canada, call:

1-800-755-5505

Outside the U.S.A. and Canada, go to www.intermec.com and click Contact Us to find your local Intermec representative.

Before you call Intermec Product Support, make sure you have the following information ready:

Printer serial number

Firmware type and version

Bluetooth, wireless, or serial port settings

You can find all of the information listed above in the printer menu system or on a testprint page.

Understanding Error Messages

Use the following tables to troubleshoot some common error message you may see display on PB50 screen. Some of the error messages are specific to the type of firmware you have loaded on your PB50.

42

PB50 Mobile Label and Receipt Printer User’s Guide

Chapter 3 — Troubleshooting and Maintaining the PB50

Possible PB50 Error Icons and Messages

Error Icon Error Message

Description





Pause

The print job is paused.





Paper out (IPL)

The printer is out of paper. Load a new roll of

Out of Paper

media. For help, see “Loading Media” on

page 11.

(Fingerprint)







Testfeed not

The printer did not perform a testfeed before

done

it printed out test labels. It is important to



perform a testfeed because it calibrates the



sensor.



To perform a testfeed:



In Fingerprint and ESC/P, press the Feed



button for more than 2 seconds.



In IPL, open and close the media door and



then press the Feed button.





Printhead hot

The printhead is overheated and needs to

cool down. In IPL, wait for printing to resume



automatically. In Fingerprint and ESC/P,



your print job is lost.





Upgrading

The printer is loading new firmware.





LSS too high,

These errors can occur when you run a test

LSS too low

feed without any media installed, or if you



have incorrect media settings.



Load the printer with media (see “Loading



Media” on page 11), run Test mode (see



“Using Test Mode” on page 21), and select



the appropriate media type.





IP configuration

The printer is trying to acquire an IP address

error

from the network. Wait for the printer to



complete the task before taking any action.





IP link error

No network connection.





PB50 Mobile Label and Receipt Printer User’s Guide

43

Chapter 3 — Troubleshooting and Maintaining the PB50

Possible PB50 Error Icons and Messages (continued)

Error Icon Error Message

Description





Field out of label You are attempting to print in an area that extends beyond the print window. See the command reference manual for your type of firmware (IPL, Fingerprint, or ESC/P) for information on how to set the media parameters.

Printhead lifted The printer is not completely closed. Press down on the media cover to make sure it is latched.

Troubleshooting Printer Problems and Finding Solutions

Use the following tables to troubleshoot some common problems you may encounter with the PB50 printer.

Printer Problems and Solutions

Problem

Possible Solution







The printer does not

Replace the battery with a charged battery.

turn on when you press

Connect external power to make sure the

Standby.



printer works correctly and to charge the

battery.

The blue light (Ready- to-Work indicator) is blinking.

Make sure media is loaded and the media cover is closed. For help, see “Loading Media” on page 11.

There is a printing error. The screen displays an error message containing information on the error.

The printer is paused. The printer is cancelling a print job.

Printer keeps printing

Check media settings.

or feeding when it

Make sure the label gap sensor is clean. For

should stop.

help, see “Cleaning the Printer” on page 48.





The printout is not in

Check for errors in the software application.

the desired position.

Make sure the label gap sensor and platen roller



are clean.





44

PB50 Mobile Label and Receipt Printer User’s Guide

Chapter 3 — Troubleshooting and Maintaining the PB50

Printer Problems and Solutions (continued)

Problem

The printer is not printing with an 802.11 wireless connection.

Possible Solution

Verify that the wireless settings are correct. For help, see “Setting Up 802.11 Radio Communications” on page 28.

Make sure the printer has an IP address.

Make sure the printer is connected to the network.

Make sure the printer is in Ready mode.

The printer is not printing with a Bluetooth connection.

Re-establish a Bluetooth connection with the mobile computer or scanner. For help, see your mobile computer user’s manual or “Setting Up Bluetooth Communications” on page 27.

Make sure the mobile computer can print to a known good printer.

Print a Bluetooth testprint page to make sure that the mobile printer discovered your printer. For help, see “Printing a Testprint” on

page 15.

Make sure the printer is in Ready mode.

When printing, the

Perform a testfeed:

printer is skipping

In Fingerprint or ESC/P, press the Feed button

labels.

for more than 2 seconds.





In IPL, open and close the media door and then



press the Feed button.



Make sure the label gap sensor is clean. For



help, see “Cleaning the Printer” on page 48.





Printout is faded or

Fingerprint users: adjust the media constant/

weak.

factor and contrast (-10% to +10%).



IPL users: adjust the media sensitivity setting (-



10 to +10).



ESC/P users: Adjust the darkness.



Check to see if the printhead needs cleaning.



For help, see “Cleaning the Printer” on



page 48.

The battery charge is not lasting as long as it should.

Check the battery date. If the battery is a few years old, the shortened life may be due to normal aging.

Replace the battery.

PB50 Mobile Label and Receipt Printer User’s Guide

45

Chapter 3 — Troubleshooting and Maintaining the PB50

Printer Problems and Solutions (continued)

Problem

Possible Solution





The test pages do not

Make sure that the blue light is not blinking. If

print.

it is, make sure your printer has media and that



the media cover is closed.



Make sure that you can advance media by



pressing the Feed button.





Print quality is poor.

Clean the printhead. For help, see “Cleaning



the Printer” on page 48.



Check the battery and recharge or replace as



necessary. For help, see “Charging the



Batteries” on page 9.



Check the quality of the media. Use only



Intermec media to ensure superior print quality



and product performance.



Check that the printer is set to the appropritae



Constant/Factory or sensitivity number for the



media you are using.





Troubleshooting Communication Problems

Use Dump mode to verify that the printer is receiving data from the host correctly.

Using the Line Analyzer in Fingerprint

In Dump mode, the printer runs a Fingerprint program called Line Analyzer. The Line Analyzer captures incoming characters on the communication ports and prints them on one or more labels.

The easiest way to enter Dump mode is through Test mode or Extended Test mode. For help, see “Understanding Test Mode” on page 21.

After the printer enters Dump mode, it tells you it has entered Dump mode by printing it on a label. The display shows the Dump mode icon and printer is ready to receive data.

While the printer is receiving data, the Ready-to-Work indicator blinks. After a half of a second, if no more characters have been received, the printer times out. The program considers the transmission terminated and prints out a label.

46

PB50 Mobile Label and Receipt Printer User’s Guide

Chapter 3 — Troubleshooting and Maintaining the PB50

Printable characters are printed in black-on-white. Control characters and space characters (ASCII 000 to 032 dec) are printed in white-on- black.

As long as a continuous string of characters is being received, the program wraps the lines until the label is full and then starts to print another label. After each character transmission, the following information prints:

Page number

Number of characters printed on the label

Total number of characters received so far

When you exit Dump mode, a final label prints to inform you that it is exiting from Dump mode.

Using Dump Mode in IPL

When you enter Dump mode, the printer captures incoming characters on the communication ports and prints them on one or more labels.

If you have IPL firmware on your printer, you can access Dump mode in two different ways with slightly different results:

You can access Dump mode through Test mode or Extended Test mode and you will receive printouts that look exactly like those produced with the Line Analyzer program in Fingerprint. For more information, see the previous procedure, “Using the Line Analyzer in Fingerprint” on page 46.

You can access Dump mode using the control panel buttons. If you access Dump mode this way, characters are printed on a continuous line along with corresponding hexadecimal numbers.

To enter Dump mode using the control panel buttons

Press and hold the Feed and Standby buttons until the printer starts feeding out media.

The printer feeds out several labels (or inches of media), prints the test labels, and then enters Dump mode.

To exit Dump mode using the control panel buttons

Press the Feed button.

PB50 Mobile Label and Receipt Printer User’s Guide

47

Chapter 3 — Troubleshooting and Maintaining the PB50

Cold Booting the PB50

You rarely need to cold boot the PB50 printer, unless you are upgrading the firmware. If your printer occasionally locks up, you will want to cold boot it. A cold boot reinitializes the 802.11 radio and clears the working memory.

Note: The Setup menu is not affected by a cold boot. Your printer retains all of your configuration settings after the printer powers back up.

To reset the PB50

1 Disconnect the PB50 from power if externally powered.

2 Remove the battery from the PB50 for at least one second.

3 Insert the battery back into the PB50.

4 Reconnect external power if your PB50 is externally powered.

Cleaning the Printer

To properly maintain your PB50, you should clean it at the recommended intervals. If you have a linerless printer, you may want to clean your printer more often than recommended. Printing may get noisy due to residue from the linerless medai building up on the roller bar.

To avoid possible personal injury or damage to the printer, never insert any pointed or sharp objects into the printer.

Use only the cleaning agents specified in this section. Intermec is not responsible for damage caused by any other cleaning materials used on this printer. Clean most of the printer with a cotton swab saturated with alcohol.

Do not clean the linerless platen roller with isopropyl alcohol. It could damage the surface of the platen roller.

48

PB50 Mobile Label and Receipt Printer User’s Guide

Chapter 3 — Troubleshooting and Maintaining the PB50

Tear bar



Paper sensor

Label taken

sensor



Printhead

Platen roller Label gap

sensor

Parts of the PB50 to Clean Regularly

Cleaning the PB50 Printer

Printer Part

Cleaning Method

Printhead

Use 70% isopropyl alcohol on a



cotton swab to clean the print



elements from end to end.

Cleaning Interval

After every five rolls of media or more often if necessary.

Platen roller

Rotate the platen roller and clean

After every five rolls of



it thoroughly with 70% isopropyl

media or more often if



alcohol on a cotton swab.

necessary.



Do not clean the linerless platen





roller with isopropyl alcohol.









Paper sensors

Clean thoroughly with 70%

After every five rolls of



isopropyl alcohol and a cotton

media or more often if



swab.

necessary.







Tear bar

Clean thoroughly with 70%

As needed.



isopropyl alcohol and a cotton





swab.









Exterior

Clean with a water-dampened

As needed.



cloth.



Interior

Brush or air blow. Make sure the



paper sensor is free of dust.

After every five rolls of media or more often if necessary.

PB50 Mobile Label and Receipt Printer User’s Guide

49

Chapter 3 — Troubleshooting and Maintaining the PB50

50

PB50 Mobile Label and Receipt Printer User’s Guide

A Specifications

51

Chapter A — Specifications

Specifications

Physical Dimensions

Depth:

78.7 mm (3.1 in)

Height:

174.5 mm (6.9 in)





Width:

159.5 mm (6.3 in)





Weight:

1190 g (2 lb) with battery





Power Specifications

AC power adapter

100 to 240V

voltage:







Printer voltage:

100V to 240V and 50 Hz to 60 Hz





Operating power:

Rechargeable 16.8 V 2200 mAh



lithium-ion battery





Temperature and Humidity Specifications

Operating temperature:

-15°C to 50°C (5°F to 122°F)





Storage temperature:

-22°C to 70°C (-30°F to 158°F)





Charging temperature:

0°C to 45°C (32°F to 113°F)





Relative humidity:

0 to 95% non-condensing





Sealing:

IP54





Memory

RAM:

16 MB

Flash:

64 MB





Print Speed and Resolution

Print speed:

4 ips (100 mm/s)

Resolution:

203 dpi (8 dots/mm)





Print Technology

Printhead:

Direct thermal

Maximum print width:

108 mm (4.25 in)





52

PB50 Mobile Label and Recept Printer User’s Guide



Chapter A — Specifications

Media Specifications



Core inside diameter, standard:

19 mm (0.75in)





Core inside diameter, with adapter:

10.2 mm (0.4 in)





Maximum roll outside diameter:

67.3 mm (2.65 in)





Media width, label with liner/receipt:

49mm (1.9 in) to 111.5 mm (4.4 in)





Media length, label:

25.4 mm (1.0 in) to 609.6 mm (24 in)





Media length, receipt:

Continuous





Media caliper, label with liner/receipt:

0.05 mm (0.002 in) to 0.165 mm (0.0065 in)





Media caliper, tag (maximum):

0.15 mm (0.006 in)





Gap length (centered on perforation):

3.17 mm (0.125 in) to 12.7 mm (0.50 in)





Notch length (centered on perforation):

6.35 mm (0.25 in)





Notch width (centered on perforation):

12.7 mm (0.50 in)





Black mark length (centered on perforation):

3.17 mm (0.125 in) to 12.7 mm (0.50 in)





Black mark width (centered on media width):

Full width of media





Receipt roll stock media is supplied as a continuous roll. Label, tag, and fanfold media use repeat indicators for non-continuous media. Gap, notch, and black marks are used as repeat indicators:

Gap: Label and fanfold media

Notch: Tag media

Black mark: Label, tag, and fanfold media

Here are a few things to keep in mind when ordering media for the

PB50 printer:

Black marks can only be sensed on the back side of the media.

You can use higher caliper media in the printer, but print quality will be reduced.

Receipt roll stock media has an end of roll indicator. The end of roll indicator is a red marking (on last 3 feet of roll) on the thermally sensitive side of the paper.

PB50 Mobile Label and Recept Printer User’s Guide

53

Chapter A — Specifications

External Fanfold Media Specifications

Stack height:

70 mm (2.75 in)

Page length:

152 mm (6 in) to 305 mm (12 in)





Note: A 6-inch page length is supplied in 12-inch long stacks (two 6- inch stacks of equal height with the bottom page linked).

Specialty media is required for unique customer environments, including printer operating temperature extremes. Media performance is format and environment dependent. Not all media will work in all customer applications. Intermec recommends that you test the media in your application.

Supported Media

The PB50 printer supports direct thermal label, tag, and receipt media. Both North American and European label media are supported in multiple label lengths. Receipt media is supported in both a top coated and an uncoated paper in continuous roll stock only.

The default media sensitivity number is 180.

The default media sensitivity number for linerless media is 103

Use the following table as a guide when setting sensitivity numbers.

Recommended Media Sensitivity, Constant, Factor, and Print Speed

Sensitivity

Constant

Factor

Description

Max Print Speed







North American Label Media















720

60

40

Duratherm Lightning Plus

4 ips











470

52

40

Duratherm Lightning

4 ips











450

48

40

Duratherm Lightning

2 ips











430

100

40

Duratherm Synthetic

4 ips











180

80

40

Duratherm II Label

4 ips











180

80

40

Duratherm III Label

4 ips











180

80

40

Duratherm Near IR

4 ips











150

50

40

Duratherm 5 mil Tag

2 ips











54

PB50 Mobile Label and Recept Printer User’s Guide

Chapter A — Specifications

Recommended Media Sensitivity, Constant, Factor, and Print Speed (continued)

Sensitivity

Constant

Factor

Description

Max Print Speed





North American Label Media (continued)













103

110

45

Direct Thermal Linerless

Dependent on format









and environment







North America Receipt Media















401

45

40

Duratherm TC

2 ips











102

32

40

Duratherm NTC - 2

2 ips











101

30

40

Duratherm NTC

2 ips









European Label Media

















440

47

30

Thermal Eco

2 ips











140

70

40

Thermal Top

4 ips











Accessories for the PB50

You can use these accessories (sold and ordered separately) with the PB50 printer. To order accessories, contact your local Intermec sales representative.

AB13 Battery

Use the lithium-ion 2200 mAh battery to provide power to the printer.

AC18 4-Bay Battery Charger

Use the AC18 to charge up to four batteries at a time. The battery charger is designed to sense when a battery is fully charged and not overcharge it, ensuring long and consistent battery life.

AV8 Vehicle Cradle

Use the vehicle cradle to attach the PB50 to a truck or forklift. You will need the forklift power supply kit to connect your vehicle power to the PB50.

Belt Clip

Use the PB50 belt clip to attach the printer to your belt.

PB50 Mobile Label and Recept Printer User’s Guide

55

Chapter A — Specifications

Cart Dock

Use the cart dock to easily attach the PB50 to a movable cart or a flat surface.

Forklift Power Supply Kit

Use the forklift power supply kit to connect the PB50 and vehicle cradle to a truck or forklift.

Handstrap

Use the PB42 and PB50 handstrap to conveniently carry your PB50 printer. With the handstrap attached, you can also attach the shoulder strap.

Power Supply (Model AE19)

Provides power to the PB50 and the 4-bay battery charger (Model

AC18).

Protective Case

Use the protective case to transport and store your PB50. The protective case keeps the printer free of dust, dirt, and moisture and still provides easy access to the printer for printing.

Serial Cable

The serial adapter is an 8-pin DIN to DB9 connector that connects from the PB50 printer to your desktop PC.

Shoulder Strap

Use the shoulder strap in combination with the handstrap to easily carry the PB50 printer. The wide padded strap makes it comfortable to wear the printer for long periods of time.

56

PB50 Mobile Label and Recept Printer User’s Guide

B IPL and Fingerprint Setup Menus

57

Chapter B — IPL and Fingerprint Setup Menus

IPL Setup Menu

SETUP

























































































SER-COM

































































































































































































































































































































BAUDRATE





DATA BITS



PARITY





STOPBITS



PROTOCOL





































































































































































































NETWORK





























































































































































































































































































































IP SELECTION



IP ADDRESS



NETMASK





DEFAULT



NAMESERVER





MAC ADDRESS

































ROUTER

























































































































































































TEST/SERVICE

























































































































































































































































































































TESTPRINT



DATA DUMP



MEMORY RESET





LSS TEST























































































































































































































CONFIG























































































































































































































































































































TEST LABELS





















































































































































































































































































































FORMAT





















































































































































































































































































































PAGE























































































































































































































































































































UDC





















































































































































































































































































































FONT













































































































































































































































MEDIA













































































































































































































































MEDIA TYPE





TESTFEED



LBL LENGTH





LBL WIDTH



SENSITIVITY





DARKNESS



LBL REST POINT



FORM ADJ DOTS



FORM ADJ DOTS









MODE



DOTS





DOTS















X





Y













































































































































CONFIGURATION































































































































































































































































































































PWRUP





PRINT SPEED





LTS





















































EMULATION







CALIBRATION











































































































































































































POWER





























































































































































































































































































































LOW BATTERY





SLEEP TIMER



STANDBY TIMER



























































































































































































































DISPLAY





















































































































































































































































ORIENTATION





CONTRAST







































































































































58

PB50 Mobile Label and Receipt Printer User’s Guide

Chapter B — IPL and Fingerprint Setup Menus

Fingerprint Setup Menu

SETUP

SER-COM,UART1















































































































































































































BAUDRATE





CHAR LENGTH





PARITY





STOPBITS





FLOWCONTROL







NEW LINE







REC BUF





TRANS BUF



































































































































































RTS/CTS





































NET-COM NET 1





















































































































































































































































































































































































































































ENQ/ACK







































NEW LINE































































































































































































































































XON/XOFF





































































































































































































































































































































































































DATA TO HOST





























































































































































































































































































NETWORK























































DATA FROM

















































































HOST



















































































































































































































































































































































IP SELECTION





IP ADDRESS





NETMASK







DEFAULT





NAMESERVER







MAC ADDRESS







































ROUTER



































































































































































































































FEEDADJ



















































































































































































































































































































































































































STARTADJ







STOPADJ























































































































































































MEDIA













































































































































































































































































































MEDIA SIZE







MEDIA TYPE





PAPER TYPE



CONTRAST







TESTFEED





TESTFEED





LEN (SLOW































MODE





MODE)







































































































































































































XSTART









LABELS







DIRECT













































































(w GAPS)







THERMAL

























































































































































































































































WIDTH









TICKET









LABEL











































































(w MARK)









































































































CONTRAST













































































TICKET



















































































LENGTH









(w GAPS)









LABEL

































































































FACTOR













































































FIX LENGTH



























































































STRIP

































































































































































































VAR LENGTH



























































































STRIP





















































































































































































PRINT DEFS



















































































































































































































































































































































































































HEAD RESIST







TESTPRINT





PRINT SPEED





LSS TEST





CLIP DEFAULT







LTS





































































































































































































































































LESS AUTO















LTS VALUE























POWER





















































































































































































































































































































































LTS ADJUST

































































LSS MANUAL



































LOW BATTERY







SLEEP TIMER





STANDBY TIMER

















































































































































































































































































































LTS TEST

























































































































































































































DISPLAY



















































































































































































































































































































ORIENTATION











CONTRAST





























































































































































































































































PB50 Mobile Label and Receipt Printer User’s Guide

59

Chapter B — IPL and Fingerprint Setup Menus

60

PB50 Mobile Label and Receipt Printer User’s Guide

Worldwide Headquarters

6001 36th Avenue West

Everett, Washington 98203

U.S.A.

tel 425.348.2600

fax 425.355.9551

www.intermec.com

© 2008 Intermec Technologies Corporation. All rights reserved.

PB50 Mobile Label and Receipt Printer User’s Guide

*934-012-002*

P/N 934-012-002
