NetworX Series™ NX-4 Control Panel

Installation and Startup

These instructions do not purport to cover all details or variations in equipm ent nor to provide every possible contingency to be met during installation, operation, and maintenance. If further information is desired or if particular problem s arise that are not covered sufficiently for the purchaser’s purpose, the matter should be referred to UTC Fire & Security, Gladewater, Texas, USA.

This document contains proprietary inform ation of UTC Fire & Security, USA and is furnished to its customer solely to assist that customer in the installation, testing, operations, and/or maintenance of the equipment described. This document shall not be reproduced in whole or in part nor shall its contents be disclosed to any third party without the written approval of UTC Fire & Security.

Please refer to the current UTC Fire & Security product catalog for detailed warranty information.

Main

800-727-2339 Technical Support 800-727-2339

Outside the US

903-845-6941 Tech Support Fax 903-845-8409

Main Fax 903-845-6811 Sales & Literature 800-547-2556

www.caddx.com www.interlogix.com

NetworX™ is a trademark of the UTC Fire & Security companies.

NetworX NX-4 Control/Communicator Installation Manual

General Description............................................................................... 2

Ordering Information............................................................................. 2

Board Installation ................................................................................. 2

Feature Definitions ................................................................................ 3

Programming the LED Keypads .............................................................. 8

Programming the NX-4 .........................................................................10

Types of Programming Data ..................................................................10

Enrolling the Modules & Keypads............................................................12

Communicator Formats.........................................................................13

Reporting Events to Phone #1, #2, & #3 ...........................................13-15

Zone Doubling .....................................................................................18

Programming the Outputs ................................................................ 19-20

Standard Zone Types (Configurations) ....................................................25

Programming Worksheets ................................................................ 26-32

SIA and Contact ID Formats ............................................................. 33-34

Expander Trouble Reporting Information .................................................35

Wiring Diagram ...................................................................................36

Terminal Description ............................................................................37

Telephone Interface Information ............................................................39

Underwriters Laboratories Information ....................................................39

SIA / ANSI CP-01 Requirements.............................................................41

Specifications .......................................................................... Back Page

Page

UTC Fire & Security

1-800-727-2339

NX-4 Control

GENERAL DESCRIPTION

The NetworX NX-4 represents a new approach to security systems design. Drawing on our experience in the world market as the largest exporter of USA manufactured controls we have developed the most flexible, durable, and userfriendly control ever seen in our industry. Featuring sophisticated software which allows up to 8 users to interface with 8 zones, and a host of integrated fire, access, verification, and input/output modules, all reported with the most comprehensive and fast SIA and Contact ID formats. The NetworX design allows a fully loaded system to be housed in one single metal enclosure, establishing for the first time, a logical solution and design response to modular systems. A maximum of 8 keypads and 1 other module (excluding hardwire) can be added to expand the capabilities of the NX4 unit. For warranty information, please refer to the current Security Product Catalog.

ORDERING INFORMATION

PART # DESCRIPTION PART # DESCRIPTION

NX-4-KIT NX-4 Control, NX-108E LED Keypad, &

16.5V 40VA Transformer

NX-4 NX-4 Control Only NX-116E 16 Zone LED Keypad

NX-200 ** Zone Doubling Kit (Includes 100 3.74k

and 100 6.98k resistors)

NX-320E Smart Power Supply and Buss Extender NX-148E Alphanumeric LCD Keypad

NX-408E # 8 Zone Wireless Expansion Module

(UL LISTED PART #60-904)

NX-416E # 16 Zone Wireless Expansion Module

(UL LISTED PART #60-904)

NX-448E # 48 Zone Wireless Expansion Module

(UL LISTED PART #60-904)

NX-508E Eight Output Module NX-1308E 8 Zone LED Door Design Keypad

NX-534E ** Two-Way Listen In Module NX-1316E 16 Zone LED Door Design Keypad

NX-540E ** "Operator II" Telephone Interface Module NX-1324E 24 Zone LED Door Design Keypad

NX-591E ** Cellemetry Interface NX-1448E 48 Zone Fixed Language Icon

** These products have not been tested and approved by Underwriters Laboratories, Inc. # These wireless devices are only UL listed for residential applications.

NX-108E 8 Zone LED Keypad

NX-124E 24 Zone LED Keypad

NX-1192E 192 Zone LCD Keypad

NX-1208E 8 Zone LED Keypad

NX-1248E 48 Zone LCD Keypad

Keypad

IMPORTANT NOTES

1. The maximum number of zones available is 8 regardless of devices added. Information regarding Zone Doubling is located on page 7.

2. The NX-4 control panel will send an “Expander Trouble” once each hour if it senses that no devices have been enrolled. This report will show “Expander Trouble” - device zero (0).

BOARD INSTALLATION

The metal enclosure should be installed with the door opening from top to bottom. Refer to the diagram on the right. Inside the can, there are four slots for board insertion, two on the top and two on the bottom of the can. These allow the PC board to be positioned vertically as shown in the diagram. When you slide the board between the grooves of the slots, make sure the terminal strip is toward the front for wire connections.

Page 2

NX-4 Control

FEATURE DEFINITIONS

Abort

If enabled, the NX-4 will wait the programmed number of seconds in location 40 prior to sending an alarm. During this delay time, the "Cancel" LED will flash. To abort the report, type in a code and press the [Cancel] key. The LED will extinguish. If the report is not aborted within the allotted time, the LED will extinguish when the report is sent. (Loc. 40 and 110-149, pages 18 and 24)

AC Fail / Low Battery Report/Warning

The NX-4 can be programmed to report AC failure and/or Low Battery conditions to the central station. It can also be programmed to sound the keypad immediately upon detection of the condition. The AC failure report/warning can be delayed. (Loc. 37 and 39, page 17 - 18)

AC Power / Low Battery Sounder Alert

If enabled, the NX-4 will beep the keypad sounder upon arming or disarming if the AC power is missing or a low battery has been detected. (Loc. 23, page 16)

Arm / Disarm Codes

The NX-4 can have 8 four-digit codes OR same number of digits. The factory default for User #1 is [1]-[2]-[3]-[4] when using a 4-digit code, or [1]-[2][3]-[4]-[5]-[6] for a 6-digit code. This code can then be used to enter the new arm/disarm codes. (Loc. 41,

page 19)

Automatic Arming

If programmed, the NX-4 will Auto Arm at the time specified in location 53. At that time, the keypad will beep for 50 seconds before the panel arms. The arming process will be stopped if a code is entered on the keypad. The NX4 will attempt to arm after every 45 minutes of inactivity until the next Aopening@ time (loc. 52), or until the system is armed. The 45-minute timer will be extended when there is activity in the building causing the "Ready" LED to turn off and on. If closing reports are sent, the user code will be 97. (Loc. 23, and 52-55, pages 16 and 21.

NOTE: For UL installations, this feature shall be disabled.

Automatic Bypass / Instant Arming

When enabled, the control panel can automatically bypass interior follower zones if an exit is not detected during the exit delay time. Entry delay zones can also be made instant. (Loc. 23, segments 1 & 3, page 16)

Auto Cancel / Abort

If enabled, Cancel and/or Abort features will be automatic (means pressing the Cancel button is not required.) The Cancel / Abort features, in Locations 23 and 40 respectively, must be enabled to permit this Auto feature to work. For proper operation of these features, ADialer Delay@ must be enabled in ACharacteristic Select@ of Locations 110- 149 Zone Configuration Groups. (Loc. 41, page 19)

Auto Test

This feature will cause the panel to call the central station to report a communicator test at a specified interval.

(Loc. 37 - Seg. 4, and Loc. 51, pages 17 and 20)

Auxiliary Outputs

The NX-4 has two programmable outputs that can be used to activate relays, LED=s, etc. (See the terminal description on page 37 and locations 45-50, pages 19-20)

Auxiliary Power Over-current

The NX-4 will illuminate the "Service" LED on the keypad whenever too much current is drawn from any device powered by the system. This condition can be reported to the central station. Power down the system to clear.

(Loc. 37, page 17)

Box Tamper

The NX-4 has an input for a normally closed tamper switch (see terminal drawing). The Box Tamper can be programmed to report and/or sound the siren and/or the keypad. These terminals can be enabled or disabled in programming. (Loc. 37 and 39, page 17)

8 six-digit codes to arm/disarm the control. All codes must have the

)

Page 3

NX-4 Control

Built In Siren Driver

The NX-4 has a built-in 112db siren driver. When desired, this built-in driver can be easily converted to a 1 amp voltage output through programming. (Loc. 37, page 17)

Bypass Toggle

This feature will enable the end user to toggle (turn on or off) the bypass of an interior zone with the system armed by pressing the [Bypass] key. (Loc. 23, page 16)

Call Back

When enabled, the control will use the call back phone number to call the download computer before beginning a download. (Loc. 21, page 16)

Cancel

If enabled, the NX-4 will send a "Cancel" report if when the system is disarmed and the [Cancel] button is pressed within 5 minutes of an alarm. Once the [Cancel] key is pressed, the "Cancel" LED will illuminate until the central station acknowledges the "Cancel" report. ADialer Delay@ must be enabled in the ACharacteristic Select@ of Loc. 110-

149. (Loc. 23, page 16)

Code Required Options

The NX-4 can be programmed to require a code for bypassing zones and/or initiating a download using the [r]-[9]- [8] or [r]-[9]-[9] function. (Loc. 23 and 41, pages 16 and 19)

Communication Formats

The NX-4 can report in multiple formats. It is recommended that you use Contact ID or SIA formats if possible. If you wish to report to a pager or in a 4+2 format to a central station, you must program each code to be reported.

(Loc. 56-83 and 111-149, pages 22-25)

Configuration Groups

The NX-4 has 20 programmable configuration groups that determine how each zone will function and report. The default configuration groups (Zone Types) are listed on page 25. (Loc. 111-149, pages 24-25)

Cross Zoning

This feature requires two or more trips on a zone or zones programmed as "cross zones" within a specified time before reporting an alarm. During the time between trips, the NX-4 can be programmed to sound the keypad and/or the siren. The NX-4 can also be programmed to report an alarm after two or more trips on the same zone.

(Loc. 37, 39, 40 and 110-149, pages 17 - 18, 24 - 25)

Dual / Split / Multiple Reports

The NX-4 can send communication reports to three different phone numbers for dual, split or multiple reports selectable by event. (Loc. 4, 10, and 16, pages 13-15)

Duress Code

If a duress code is programmed, the NX-4 will send a duress signal whenever the panel is armed or disarmed with this code. If open/close reports are sent, the user code will be 254. (Loc. 44, page 19)

Dynamic Battery Test

The NX-4 can be programmed to perform a Dynamic Battery Test for a selected duration the first time the panel is armed or disarmed every day, as well as by pressing [t][4] Test Function. The NX-4 can also be programmed to perform a missing battery test every 12 seconds. (Loc. 37 and 40, pages 17 and 18)

Entry-Guard

This unique low level arming mode has been developed to reduce the most common source of false alarms. When armed with the Instant light on, the opening of any zones designated as "Entry Guard zone" will initiate the keypad sounder and start the entry delay before creating an alarm. All other zones will function as normal. This arming mode will encourage system owners to use their system more frequently when the premise is occupied. (Loc. 111- 149, pages 24-25 NOTE: For UL installations, this feature shall be disabled.

Page 4

)

NX-4 Control

Exit Error

If enabled, the NX-4 will send an "Exit Error Report" if an entry/exit zone is faulted at the instant the exit delay expires. This report will be sent along with the user number that armed the system, if the panel is not disarmed before the entry delay expires. The alarm report will also be sent. Even if this feature is not enabled, the siren will sound if any entry/exit zone is faulted at the instant the exit delay expires. (Loc. 23, page 16)

Expander Trouble

The NX-4 will report expander trouble to the central station if enabled. This condition will illuminate the "Service" LED on the keypad even if not reported. NOTE: The keypads are considered expanders. The number of the expansion devices reported can be found on page 35. (Loc. 37, page 17)

Fail to Communicate

The NX-4 will illuminate the "Service" LED if a report fails to reach the central station. If enabled, when the next report is successfully communicated, a Fail to Communicate code will be reported. (Loc. 37, page 17)

Fire Alarm Verification

When enabled, the NX-4 will verify a Fire alarm by requiring more than one trip on a smoke detector within a specified time before creating an alarm. NOTE: For household systems, the Fire Alarm Verification feature is NOT approved for use in California. This feature shall not be programmed into the control unit. (Loc. 40, page 18)

Force Arming

When enabled, the NX-4 can be Force Armed with zones violated. Under this condition, if a force armable zone is not secure, the "Ready" LED will flash. At the end of the exit delay, these zones will become bypassed. If these zones become secured any time during the arming cycle, they will be unbypassed and active in the system. If "Bypass Report" is enabled, the force arming zones can be programmed to report bypass when they are Force Armed (default), or to not report bypass even if "Bypass Report" is enabled. (Loc. 37, and 111-149, pages 17

& 24-25 NOTE: For UL installations, this feature shall be disabled

Group Bypass

A designated group of zones can be programmed to bypass by pressing [Bypass]- [0]-[Bypass]- [Bypass] prior to arming. (Loc. 111-149, pages 24-25 NOTE: For UL installations, this feature shall be disabled

Immediate Restore By Zone

The NX-4 can be programmed to send alarm and restore reports as soon as they occur, or wait until the siren time has expired. (Loc. 37, page 17)

Internal Event Log

Up to 185 events can be stored in memory along with the date and time of the event. These events can later be viewed through downloading or on the LCD keypad. All reportable events report to the log.

Keypad Activated Panics

The NX-4 has three keypad activated panics that will send reports to the central station: Auxiliary 1 (Fire), Auxiliary 2 (Medical), and Keypad Panic. Auxiliary 1 will activate the steady (Fire) siren, Auxiliary 2 will sound the keypad, and the Keypad Panic can be programmed to be silent or audible (sound siren). (Loc. 23, page 16)

Keypad Sounder Control

The NX-4 can be programmed to sound the keypad sounder for certain events. (Loc. 39, page 18)

Keypad Tamper

If enabled, the NX-4 will disable the keypad for 60 seconds and communicate a tamper signal to the central station if 30 keypresses are entered without producing a valid code. (Loc. 23, page 16)

LED Extinguish

This feature will extinguish all LED=s on the keypad, except the "Power" LED, after 60 seconds without a keypress. Pressing any numeric key will illuminate all LED=s. (Loc. 23, page 16)

Page 5

NX-4 Control

Local Programming Lockout

This feature will disable programming of all locations or specified locations from the keypad. (Loc. 21, page 16)

Log Full Report

A report can be sent to the central station when the event log is full. (Loc. 37, page 17)

Lost Clock Service Light

The NX-4 can be programmed to illuminate the "Service" LED when the internal clock has an invalid time due to power loss. (Loc. 37, page 17)

Manual Test

The NX-4 can be programmed to perform a bell and/or communicator test when [r]-[4] is entered while the system is in the disarmed state. (Loc. 37, page 17)

On Board Zone Disable

The four zones on the NX-4 panel can be disabled in order to have a completely wireless alarm system. (Loc. 37, page 17)

Program Code

The factory default for the "Go To Program" code is [9]-[7]-[1]-[3] when using a 4-digit code or, if the 6-digit option is used, the default is [9]-[7]-[1]-[3]-[0]-[0]. The program code can also be used as an Arm/Disarm code. If used as an Arm/Disarm code, and open/close reports are sent, the user code will be 255. (Loc. 43, page 19)

Quick Arm Feature

The NX-4 has a one button "Quick Arm" feature which can be used to arm the system by pressing the [Exit] key or the [Stay] key. If closing reports are sent, the user code will be 98. (Loc. 23, page 16)

Recent Closing

If enabled, the NX-4 will send a "Recent Closing Report" to the central station if an alarm occurs within 2 minutes after the panel is armed. The user number that armed the system will also be sent. (Loc. 23, page 16)

Re-exit

The NX-4 has the ability to restart the exit delay for a quick exit without disarming the system by pressing the [Exit] key while the system is armed. (Loc. 23, page 16)

Shutdown

This mode will cause the keypads to turn off all LED=s, except the "Power" LED, and not accept keypresses. (Loc. 21, page 16)

Siren Blast For Arming

The NX-4 can be programmed to give a one-second siren blast when the panel is armed, at the end of the exit delay, or when the central station receiver acknowledges the closing report. It can also give one blast for wireless arming and two blasts for wireless disarming. (Loc. 37, page 17)

Siren Supervision

The NX-4 has a ASiren Supervision@ circuit that will constantly monitor the siren on the NX-4 and can be programmed to report if the wires are cut. (Loc. 37, page 17)

Silent Exit Option

The exit delay can be silenced by pressing [r]-[Exit] before arming the control panel, or when using the re-exit feature.

Start/End Programming and End Downloading

A report can be sent when local programming is started and ended. A report can also be sent when a download session ends. (Loc. 37, page 17)

Page 6

NX-4 Control

Swinger Shutdown

This feature allows a zone(s) to be automatically bypassed after a specified number of alarms. When a zone is tripped, the alarm ‘counter’ reflects “1” in memory. If a new (first) alarm is detected in a different zone, the counter remains at “1”. If an alarm is detected on a previously tripped zone, the count increments to “2”. The ‘counter’ will increment each time an alarm is detected on a zone with multiple trips. Bypassing will occur on the zone that causes the count to equal the number programmed in location 38; the ‘counter’ will reset to zero (0); and begin a new trip count where the next alarm will set the ‘counter’ to 1. If immediate restore is enabled in location 37, the alarms (and restores, if enabled) will be sent as they occur. If immediate restore is not enabled, a second or subsequent alarm will not be sent until the siren times out. Factory default is 1. (Loc. 37 and 38, page 17)

Temporal Siren Disable

If disabled, the Fire Siren will be steady and Fire Voltage Out will be the same as Burglary (continuous). Otherwise, the Fire Siren will be temporal. (Loc. 37, page 18 NOTE: For UL installations, do NOT disable

Two Call Answering Machine Defeat

If enabled, to defeat an answering machine, two telephone calls must be made to the premises. On the first call, let the phone ring one or two times. The control panel will detect these rings and start a 45-second timer, during which, the control panel will answer the next call on the first ring. This is not recommended for commercial

applications. (Loc. 21, page 16)

Walk-Test Mode [r] [Chime]

If enabled, entering [r] [Chime] followed by a user code will allow a walk-through zone test where all zones become silent and local (non-reporting). Each time a zone is faulted, the zone light on the LED keypad will illuminate and the chime will sound. The number of the faulted zone(s) will be displayed on the LCD keypad. It will also be entered into alarm memory and the internal log. To exit at any time during this mode, enter a user code. Otherwise, the AWalk-Test Mode@ will automatically exit after 15 minutes. (Loc. 41, page 19)

Wireless Sensor Missing/Low Battery

The NX-4 will send a report to the central station when a wireless sensor has detected a low battery or has not reported to the receiver. The "Service" LED will illuminate when either condition exists. (Loc. 37, page 17)

Zone Bypassed Sounder Alert

If this feature is enabled, the NX-4 will beep the keypad sounder upon arming if a zone is bypassed. (Loc. 23, page 16)

Zone Doubling (Requires additional devices)

Zone doubling can only be enabled when at least one other device is added to the basic system (consisting of the main control panel and one keypad). Additional devices can include wireless receivers, extra keypads, etc. If enabled, this feature allows you to use the four zones on the panel as eight normally closed zones. When this feature is used, European double E.O.L. configuration cannot be used. THIS FEATURE DOES NOT INCREASE THE TOTAL NUMBER OF AVAILABLE ZONES BEYOND 8. If one of the eight zones must be a fire zone, it must be one of Zones 1 - 4. The corresponding upper zone will become unavailable. For example, if Zone 4 is a fire zone, then Zone 8 will not be available. (Loc. 37, page 17)

Page 7

NX-4 Control

PROGRAMMING THE LED KEYPADS

This section describes how to program the address of each keypad as well as the options that are available. The address of the keypad is important because this is how the panel supervises the keypads. The factory default for the Master code is [1]-[2]-[3]-[4] when using a 4-digit code or [1]-[2]-[3]-[4]-[5]-[6] for a 6-digit code. The factory default for the "Go To Program" code is [9]-[7]-[1]-[3] for a 4-digit code or [9]-[7]-[1]-[3]-[0]-[0] for a 6-digit code.

[r]-[9]-[3] Set keypad options

1. Enter [r]-[9]-[3] [program code]. The "Service" LED will flash.

2. LEDs 1-8 can now be toggled on/off to enable/disable the following functions:

3. After enabling/disabling the desired functions, press [r]

LED

[r]-[9]-[4] Set keypad number

[r]-[9]-[5] Set elapsed increments since last autotest

[r]-[9]-[6] Set system date

[r]-[9]-[7] Set system clock

KEYPAD FEATURE ENABLED

1 RESERVED. DO NOT PROGRAM THIS AT ALL!

2 Enable Silent Keypad option - silences the entry/exit sounder & chime only.

3 Enable Ding Dong sound for Chime - If off, chime will be a single tone. (See location 40, page 18)

4 Enable Keypress Silence option - silences the pulsing keypad sounder for 5 seconds when a key is

pressed

5 Enable Armed Status Suppression - will not allow the keypad to display faulted or bypassed zones when

the system is armed

6 Enable Panic, Fire, Medical Beeptone - will sound a short beep to verify that the keypress was accepted

7 Suppresses the "Service" LED - will not allow the "Service" LED to illuminate for any reason. If there is a

system trouble, pressing [r]-[2] will still show the service menu. (NOTE: For UL installations, the Service LED shall not be suppressed)

8 RESERVED. This LED should always be “OFF”.

1. Enter [r]-[9]-[4]-[program code]. The "Service" LED and the "Instant" LED will flash.

2. Enter the keypad number (1-8).

3. Press [r]. The "Instant" LED will illuminate steady and the"Service" LED will remain flashing.

4. Enter [1]. The keypad will automatically exit this mode at this time.

1. Enter [r]-[9]-[5]-[program code]. The "Service" LED will flash.

2. Enter [100's digit]

3. Enter [10's digit]

4. Enter [1's digit]

5. Press [#] to save and exit.

1. Enter [r]-[9]-[6]-[master code]. The "Service" LED will flash.

2. Enter [day of week (1=Sun)]

3. Enter [month 10's digit]

4. Enter [month 1's digit]

5. Enter [day 10's digit]

6. Enter [day 1's digit]

7. Enter [year 10's digit]

8. Enter [year 1's digit]

1. Enter [r]-[9]-[7]-[master code]. The "Service" LED will flash.

2. Enter [hour 10's digit]

3. Enter [hour 1's digit]

4. Enter [minutes 10's digit]

5. Enter [minutes 1's digit]

Page 8

NX-4 Control

CHANGING USER CODES:

1. Enter [r]-[5]-[master code]. The "Ready" LED will flash.

2. Enter the 2 digit user number (always 2 digits such as "03" for user 3). The "Ready" LED will illuminate steady.

3. Enter the new user code designated for that individual. The "Ready" LED will flash indicating that the code was accepted. If it rejects the code, the sounder will beep 3 times. Note for NX1300 Series LED Keypad The zone lights will illuminate specifying the first digit of the “user code”. (Lights 1-8 on = code is blank; lights 1-8 off = “0"; lights 1 and 8 = “9".) Use the up and down scroll keys to view the next digit or enter a new 4or 6-digit “user code”. While using the scroll keys you can change any digit by entering a new digit. This will advance you to the next digit.

4. If another user code needs to be programmed, return to step 2.

5. Press [#] while the "Ready" LED is flashing to exit the User Code Programming Mode.

ASSIGNING AUTHORITY LEVEL:

1. Enter [r]-[6]-[master code]. The "Ready" LED will flash.

2. Enter [2 digit user number] (always 2 digit such as 03 for user 3). The "Ready" LED will illuminate steady and the "Instant" LED will flash

3. Refer to this chart for the description of each LED. Turn the LED on for the features that you desire.

LED ATTRIBUTES IF LED 8 IS OFF

1 Reserved

2 Arm Only

3 Arm Only After Close Window

4 Master arm/disarm (can program other codes)

5 Arm/disarm code

6 Allowed to bypass zones (see location 23)

7 Code will send open / close reports

8 If this LED is on, LEDs 1-7 will use the chart to the

right

4. Enter [r] [r]. This step returns you back to step 2 above. At this point you may enter another user number to assign attributes for. You may continue this procedure until you have assigned authority levels to all user numbers - or - you may press [#] key to exit the Assigning Authority Level Program.

[r]-[9]-[8]

Pressing [r]-[9]-[8] while the system is disarmed will cause the control to do a callback for a download.

NOTE: A VALID USER CODE MAY BE REQUIRED AFTER [r]-[9]-[8] IF ENABLED IN LOCATION 41, PAGE 19.

[r]-[9]-[9]

Pressing [r]-[9]-[9] while the system is disarmed will cause the control panel to seize the phone line for a download. NOTE: A VALID USER CODE MAY BE REQUIRED AFTER [r]-[9]-[9] IF ENABLED IN

LOCATION 41, PAGE 19.

LED

1 Activate output #1

2 Activate output # 2

3 Reserved

4 Reserved

5 Arm/disarm

6 Bypass Zones

7 Open / Close Reporting

8 If this LED is off, LEDs 1-7 use the chart to the

left

ATTRIBUTES IF LED 8 IS ON

Page 9

NX-4 Control

PROGRAMMING THE NX-4 CONTROL

ENTERING THE PROGRAM MODE: To enter the Program Mode, press [r]-[8]. At this time, the five function LEDs (Stay, Chime, Exit, Bypass, & Cancel) will begin to flash. Next, enter the "Go To Program Code" (FACTORY DEFAULT IS [9]-[7]-[1]-[3]). If the "Go To Program Code" is valid, the "Service" LED will flash and the five function LEDs will illuminate steady. You are now in the Program Mode and ready to select the module to program.

SELECTING THE MODULE TO PROGRAM: Since all modules connected to the NX-4 are programmed through the keypad, the module you are programming should be the first entry. To program the NX-4 Control Panel, enter [0][#]. The [0] is the module number of the control and the [#] is the entry key. Other module entry numbers can be found in their corresponding manuals.

PROGRAMMING A LOCATION: Once the number of the module to be programmed has been entered, the "Armed" LED will illuminate, indicating it is waiting for a programming location to be entered. Any location can be accessed by directly entering the desired programming location followed by the pound [#] key. If the location entered is a valid location, the "Armed" LED will extinguish, the "Ready" LED will illuminate and the binary data for the first segment of this location will be shown by the zone LED's. While entering new data, the "Ready" LED will begin flashing to indicate a data change in process. The flashing will continue until the new data is stored by pressing the [r] key. Upon pressing the [r] key, the keypad will advance to the next segment and display its data. This procedure is repeated until the last segment is reached. Pressing the [#] key will exit from this location, and the "Armed" LED will illuminate again waiting for a new programming location to be entered. If the desired location is the next sequential location, press the [POLICE] key. If the previous location is desired press the [FIRE] key. If the same location is desired press the [MEDIC] key. To review the data in a location, repeat the above procedure, pressing the [r] key without any numeric data entry. Each time the [r] key is pressed, the programming data of the next segment will be displayed for review.

EXITING A LOCATION: After the last segment of a location is programmed, pressing [r] will save the data, exit that location, turn the "Ready" LED off and the "Armed" LED on. To exit before the last segment, press [#]. As before, you are now ready to enter another programming location. If an attempt is made to program an invalid entry for a particular segment, the keypad sounder will emit a triple error beep (beep, beep, beep), and remain in that segment awaiting a valid entry.

EXITING THE PROGRAM MODE: When all the desired changes in programming have been made, it is time to exit the program mode. Pressing the [Exit] key will exit this programming level, and go to the "Select a Module. To Program" level. If no additional modules are to be programmed, pressing the [Exit] key again will exit the program mode. If there is a module to be programmed, it may be selected by entering its address followed by the [#] key (see "Selecting the Module To Program" above). The procedure for programming these devices is the same as for the control panel, except the locations will be for the module selected.

PROGRAMMING DATA

Programming data is always one of two types. One type of data is numerical and can take on values from 0 -15 or 0 255 depending on the location's segment. The other type of data is a feature selection type. Feature selection data is used to turn features on or off. Use the following procedures when working with these two data types:

NUMERICAL DATA: Numerical data is programmed by entering a number from 0-255 on the numeric keys of the system keypad. To view the data in a location, a binary process is used. With this process, the LED=s for zones 1 through 8 are utilized, and the numeric equivalents of their illuminated LED=s are added together to determine the data in a programming location. The numeric equivalents of these LED=s are as follows:

Zone 1 LED = 1 Zone 2 LED = 2 Zone 3 LED = 4 Zone 4 LED = 8 Zone 5 LED = 16 Zone 6 LED = 32 Zone 7 LED = 64 Zone 8 LED = 128

Example: If the numerical data to be programmed in a location is "66", press [6]-[6] on the keypad. The LED=s for Zone 2 and Zone 7 will become illuminated indicating 66 is in that location (2 + 64 = 66). See this example on page

10. Once the data is programmed, press the [r] key to enter the data and advance to the next segment of that location. After the last segment of a location is programmed, pressing the [r] key will exit that location, turn the "Ready" LED off and the "Armed" LED on. As before, you are now ready to enter another programming location. If an attempt is made to program a number too large for a particular segment, the keypad sounder will emit a triple beep, indicating an error, and remain in that segment awaiting a valid entry.

On the LCD keypad, the number in the location will be displayed. For locations with a maximum of 15, the hexidecimal equivalent will be displayed in parenthesis. Example: 11 (B) or 14 (E).

Page 10

Advances to the next

Returns to the “location” just

FIGURE 2

Audible Keypad Panic and Keypad Auxiliary 2 are enabled.

PROGRAMMING EXAMPLE – FIGURE 1 (Numerical Data)

NX-4 Control

Zone 1 LED = 1 Zone 4 LED = 8

To change data in a segment, enter the data followed by []

Enters the previous programming “location”.

}

Data = 9

programmed.

Zone 2 LED = 2 Zone 7 LED = 64

programming “location”.

Data = 66

}

Pressing [#] will exit a location without changing the data in the current segment.

Press the key on the numeric keypad that corresponds to the feature you wish to enable/disable. When an LED is “on, a feature is enabled; when “off” the feature is disabled. For example: With the 1, 5, & 7 LEDs “on”, Quick Arm,

PROGRAMMING EXAMPLE –

(Feature Selection Data)

Location 23  Segment 1

1 = Quick Arm 2 = Re-Exit 3 = Auto Bypass 4 = Silent Keypad Panic 5 = Audible Keypad Panic 6 = Keypad Auxiliary 1 7 = Keypad Auxiliary 2 8 = Multi-Keypad Tamper

Page 11

NX-4 Control

FEATURE SELECTION DATA: Feature selection data will display the current condition (on or off) of eight features

associated with the programming location and segment selected. Pressing a button on the touchpad (1 thru 8) that corresponds to the "feature number" within a segment will toggle (on/off) that feature. Pressing any numeric key between [1] and [8] for selection of a feature, will make the corresponding LED illuminate (feature ON). Press the number again, and the LED will extinguish (feature OFF). You will see that numerous features can be selected from within one segment. For instance, if all eight features of a segment are desired, pressing [1]-[2]-[3]-[4]-[5]-[6]-[7]- [8] will turn on LED's 1 thru 8 as you press the keys, indicating that those features are enabled. LCD Keypad Users

Note: The numbers of the enabled features will be displayed. However, the features not enabled will display a hyphen (-). After the desired setting of features is selected for this segment, press the [r] key. This will

enter the data and automatically advance to the next segment of the location. When you are in the last segment of a location and press the [r] to enter the data, you will exit that location. This will now turn the "Ready" LED off and the "Armed" LED on. As before, you are now ready to enter another programming location.

To load the factory defaults, enter the program mode using the procedure on page 10, then type [9]-[1]-[0]-[#]. The keypad will beep 3 times indicating that the loading is in progress. The loading takes about 6 seconds.

For supervision purposes, the NX-4 has the ability to automatically find and store in its memory, the presence of all keypads, zone expanders, wireless receivers, and any other module connected to the data terminal. This allows these modules to be supervised by the control panel. To enroll the modules, enter the Program Mode of the NX-4 control panel as described on page 10. When the Program Mode is exited, the NX-4 control will automatically enroll the devices. The enrolling process takes about 12 seconds, during which time the "Service" LED will illuminate. User codes will not be accepted during the enrolling process. Once a module is enrolled, if it is not detected by the control, the "Service" LED will illuminate.

CONTROL PANEL PROGRAMMING LOCATIONS

(Note: Various locations have been intentionally omitted. Any attempts to access these locations will

LOCATION 0 - PHONE NUMBER 1 (20 segments, numerical data) The first telephone number is programmed in location 0. A "14" indicates the end of the phone number. Delays of four seconds can be programmed at any point in the phone number by programming a "13" in the appropriate segment. If tone dialing is desired, program a "15" in the segment where tone dialing should begin. If the entire number should be tone dialing, program a "15" in the first segment. Program an A11" for a Ar@, and a A12" for a A#@. Caution: A callwaiting cancel on a non- call waiting line will prevent successful connection to the central station.

LOCATION 1 - ACCOUNT CODE FOR THE PHONE #1 (6 segments, numerical data) The account code sent when Phone #1 is dialed is programmed in location 1. Program a A10" in the segment immediately after the last digit of the account code. If the account code is 6 digits long, program all 6 segments.

LOCATION 2 - COMMUNICATOR FORMAT FOR PHONE #1 (1 segment, numerical data) Location 2 contains the communicator format used to transmit to the receiver connected to Phone #1. Consult the instructions for your central station receiver to determine which format is compatible. Select a format from the list on the following page. If you require a format other than those listed, review the override options described in location 18, to build the appropriate format. A "15" must be programmed in location 2 in addition to the entries in location 18 in order to create a special format. If this location contains a "0", the built-in communicator will be disabled, and the NX-4 will function as a local only control.

LOCATION 3 - DIAL ATTEMPTS/BACKUP CONTROL FOR PHONE # 1 (2 segments, numerical data) Segment 1- Dial attempts: Location 3, Segment 1 is used to enter the number of dial attempts (1 to 15 Attempts)

the communicator will make to Phone #1 before ending the notification process. Factory default is "8" and the communicator will make eight (8) attempts to the first number.

Segment 2- Phone #1 Backup Control: Programming a "0" in Segment 2 of this location will cause the NX-4 to make the designated number of attempts to Phone #2 before setting the "Fail To Communicate" condition and stop reporting. Programming a "1" in this segment will cause the NX-4 to stop trying to communicate after the designated number of attempts have been made to Phone #1. If a "2" is programmed in this segment, it will cause the NX-4 to make the dial attempts in increments of two. The first two attempts will be made to Phone #1, the next two attempts to Phone #2, then repeating until the total number of attempts designated in Segment 1 is completed.

LOADING FACTORY DEFAULTS

ENROLLING MODULES AND KEYPADS

be followed by an error Abeep@.)

Page 12

NX-4 Control

FORMAT SELECTIONS

DATA

10 3/1 or 4/1 fast with

11 4+2 express

12 4+2 fast

13 Ademco Contact ID DTMF (see pages 33-34)

14 SIA

15 Custom format

Location 4 is used to select which events are reported to Phone #1. If dual or split reporting is not should be used to select all only those events that should be reported to Phone #1. If no events should be reported to Phone #1, location 4 should be programmed as "0" (disabled).

LOCATION 4 - EVENTS REPORTED TO PHONE # 1 (2 segments, feature selection data)

Segment 1: 1 = Alarms and Alarm Restores.

Segment 2: 1 = Zone and Box Tamper and Tamper Restore.

FORMAT

Local

Universal 4+2

3+1 fast (or 4+1) One digit event code 1900Hz transmit 1400Hz handshake double round parity

Reserved

Pager

3/1 or 4/1 slow

3/1 or 4/1 fast

3/1 or 4/1 fast with parity

parity

Communicator is disabled

Two digit event code 1800hz transmit 2300hz handshake double round parity 40pps

20pps

Reserved

2 digit event code DTMF transmission

1800hz transmit 2300hz handshake double round parity 20 p.p.s. hex capability

1800hz transmit 1400hz handshake double round parity 20 p.p.s. hex capability

1800hz transmit 2300hz handshake double round parity 40 p.p.s. hex capability

1800hz transmit 1400hz handshake double round parity 40 p.p.s. hex capability

1800hz transmit 2300hz handshake single round w/parity 40 p.p.s. hex capability

1800hz transmit 1400hz handshake single round w/parity 40 p.p.s. hex capability

2 digit event code DTMF transmission

Two-digit event code 1900hz transmit 1400hz handshake double round parity 20 p.p.s.

FSK (see pages 33-34)

(See location 18, page 16)

DESCRIPTION

REPORTING EVENTS TO PHONE NUMBER 1

desired, location 4

events to Phone #1. If dual or split reporting is desired, location 4 should be used to select

2 = Opening and Closings. 3 = Zone Bypass and Bypass Restores. 4 = Zone Trouble and Trouble Restores. 5 = Power Fail, Low Battery, Power Restore, and Low Battery Restore. 6 = Bell Cut, Bell Cut Restore. 7 = Test Reports. 8 = Start and End programming, Download complete.

2 = Auxiliary Power Over-current and Restore. 3 = Wireless Sensor Missing and Restore. 4 = Wireless Sensor Low Battery and Restore. 5 = Expander Trouble and Restore. 6 = Fail To Communicate. 7 = Reserved. 8 = Reserved.

Page 13

NX-4 Control

LOCATION 6 - PROGRAMMING PHONE #2 (20 segments, numerical data)

Phone #2 is programmed in location 6. A "14" indicates the end of the phone number. Delays of four seconds can be programmed at any point in the phone number by programming a "13" in the appropriate segment. If tone dialing is desired, program a "15" in the segment where tone dialing should begin. If the entire number should be tone dialing, program a "15" in the first segment. Program an A11" for a Ar@, and a A12" for a A#@. Caution: A call-waiting cancel on a non- call waiting line will prevent successful connection to the central station.

LOCATION 7 - ACCOUNT CODE FOR THE PHONE #2 (6 segments of numerical data) The account code sent when Phone #2 is dialed is programmed in location 7. Program a A10" in the segment immediately after the last digit of the account code. If the account code is 6 digits long, program all 6 segments. If this location is left unprogrammed, account code 1 will be used when the second phone number is dialed.

LOCATION 8 - COMMUNICATOR FORMAT FOR PHONE # 2 (1 segment, numerical data) Location 8 contains the communicator format used to transmit to the receiver connected to Phone #2. Consult the instruction manual for your central station receiver to determine which format is compatible, and select from the 15 formats listed on page 13. If you require a format other than those listed, review the override options described in Location 18 to build the appropriate format. A "15" must be programmed in location 8 in addition to the entries in location 18 in order to create a special format. If this location contains a "0", format 1 will be used when Phone #2 is dialed.

LOCATION 9 - DIAL ATTEMPTS/BACKUP CONTROL FOR PHONE #2 (2 segments, numerical data)

Segment 1, Dial attempts: Segment 1 of Location 9 is used to enter the number of dial attempts (1 to 15 attempts)

the communicator will make to Phone #2 before ending the notification process. Factory default is "8" and the communicator will make the same number of attempts as those programmed in location 3.

Segment 2, Phone #2 Backup Control: Programming a "0" in Segment 2 of this location will cause the NX-4 to make the designated number of attempts to Phone #1 before setting the "Fail To Communicate" condition and stop reporting. Programming a "1" in this segment will cause the NX-4 to stop trying to communicate after the designated number of attempts have been made to Phone #2. If a "2" is programmed in this segment, it will cause the NX-4 to make the dial attempts in increments of two. The first two attempts will be made to Phone #2, the next two attempts to Phone #1, then repeating until the total number of attempts designated in Segment 1 is completed.

REPORTING EVENTS TO PHONE NUMBER 2

Phone #2 can be used to back up Phone #1 or for a second receiver to multi-report or split report events. Location 10 is used to select which events are reported to Phone #2. If dual or split reporting is not desired, location 10 should be left at the factory default of "0". If multi-reporting or split reporting is desired, location 10 should be used to select only those events that should be reported to Phone #2. If no events should be reported to Phone #2, location 10 should be "0".

LOCATION 10 - EVENTS REPORTED TO PHONE #2 (2 segments of feature selection data)

Segment 1: 1 = Alarms and Alarm Restores.

Segment 2: 1 = Zone and Box Tamper and Tamper Restore.

2 = Auxiliary Power Over-current and Restore. 3 = Sensor Missing and Restore. 4 = Sensor Low Battery and Restore. 5 = Expander Trouble and Restore. 6 = Fail To Communicate. 7 = Reserved. 8 = Reserved.

Page 14

NX-4 Control

LOCATION 12 - PROGRAMMING PHONE #3 (20 segments, numerical data)

Phone #3 is programmed in location 12. A "14" indicates the end of the phone number. Delays of four seconds can be programmed at any point in the phone number by programming a "13" in the appropriate segment. If tone dialing is desired, program a "15" in the segment where tone dialing should begin. If the entire number should be tone dialing, program a "15" in the first segment. Program an A11" for a Ar@, and a A12" for a A#@. Caution: A call-waiting cancel on a non- call waiting line will prevent successful connection to the central station.

LOCATION 13 - ACCOUNT CODE FOR PHONE #3 (6 segments, numerical data) The account code sent when Phone #3 is dialed is programmed in location 13. Program a A10" in the segment immediately after the last digit of the account code. If the account code is 6 digits long, program all 6 segments. If location 6 is left unprogrammed, account code 1 will be used when the Phone #3 is dialed.

LOCATION 14 - COMMUNICATOR FORMAT FOR PHONE #3 (1 segment, numerical data) Location 14 contains the communicator format used to transmit to the receiver connected to phone #3. Consult the instruction manual for your central station receiver to determine which format is compatible, and select from the 15 formats listed on page 13. If you require a format other than those listed, review the override options described in Location 18 to build the appropriate format. A "15" must be programmed in location 14 in addition to the entries in location 18 in order to create a special format. If this location contains a "0", format 1 will be used when Phone #3 is dialed.

LOCATION 15 - DIAL ATTEMPTS/BACKUP CONTROL FOR PHONE #3 (2 segments, numerical data)

Segment 1, Dial Attempts: Segment 1 of Location 15 is used to enter the number of dial attempts (1 to 15

attempts) the communicator will try to Phone #3 before ending the notification process. Factory default is "8" and the communicator will make the same number of attempts as those programmed in location 3.

Segment 2, Phone # 3 Backup Control: Programming a "0" in Segment 2 of this location will cause the NX-4 to make the designated number of attempts to Phone #2 before setting the "Fail To Communicate" condition and stop reporting. Programming a "1" in this segment will cause the NX-4 to stop trying to communicate after the designated number of attempts have been made to Phone #3. If a "2" is programmed in this segment, it will cause the NX-4 to make the dial attempts in increments of two. The first two attempts will be made to Phone #3, the next two attempts to Phone #2, then repeating until the total number of attempts designated in Segment 1 is completed.

REPORTING EVENTS TO PHONE NUMBER 3

Phone #3 can be used for a third receiver to multi-report or split report events. Location 16 is used to select which events are reported to Phone #3. If dual or split reporting is not desired, location 16 should be left at the factory default of "0". If multi-reporting or split reporting is desired, and the split is based on the event type (such as alarm, open/close, etc.), then location 16 should be used to select only those events that should be reported to Phone #3. If no events should be reported to Phone #3, location 16 should be "0".

LOCATION 16 - EVENTS REPORTED TO PHONE #3 (2 segments, feature selection data)

Segment 1: 1 = Alarms and Alarm Restores.

Segment 2: 1 = Zone and Box Tamper and Tamper Restore.

Page 15

NX-4 Control

LOCATION 18 - CUSTOM COMMUNICATOR FORMAT (See locations 2, 8, & 14)

Segment 1: 1 = On for 1800hz transmit; Off for 1900hz.

2= On for 2300hz handshake; Off for 1400hz. 3= On for cksum parity; Off for double round parity. 4= On for 2 digit event code; Off for 1 digit event code. 5 & 6= Reserved. 7= On for 20 p.p.s.; Off for 10 or 40 p.p.s. 8= On for 10 p.p.s.; Off for 20 or 40 p.p.s.

Segment 2 : 1= On for pager format (no handshake required).

2= On for 1400/2300 handshake. 3 & 4 = Reserved 5= On for Contact ID. 6= On for SIA. 7= On for Contact ID or 4+3. 8= On for DTMF.

Segment 3 & 4: Reserved.

LOCATION 19 - DOWNLOAD ACCESS CODE (8 segments, numerical data)

Location 19 contains the eight-digit access code the NX-4 must receive from the downloading software before the panel will permit downloading to occur. The factory default code is 84800000.

LOCATION 20 - NUMBER OF RINGS TO ANSWER (1 segment, numerical data) Location 20 contains the number of rings to answer for a download. Enter a number from A0" (disabled) to "15". Factory default is "8" and the NX-4 will answer on 8 rings.

LOCATION 21 - DOWNLOAD CONTROL (1 segment, feature selection data) Location 21 contains the feature selections for the controlling of download sessions. The following features can be enabled or disabled using this location. (See Feature Definitions starting on page 3)

Segment 1:

1 - On enables two call answering machine defeat. 2 - Reserved. 3 - On requires call back before download session. 4 - Shutdown. 5 - % On locks all local programming. 6 - % On locks programming of all locations associated with the communicator 7 - % On locks out download section. (If "On", locations 19 - 22 cannot be viewed from the

keypad; can only be viewed from the keypad when "Off".)

8 - On enables call back at auto test interval.

% These selections can only be viewed from the keypad and must be changed through downloading.

LOCATION 22 - DOWNLOAD CALL BACK NUMBER (20 segments, numerical data) If a telephone number is programmed into this location, and "Require Callback" is enabled in location 21, the control panel will hang up for approximately 36 seconds (ensuring that the calling party has disconnected), and then call back. If tone dialing is desired, program an "15" in the segment where tone dialing should begin. If the entire number should be tone dialing, program an A15" in the first segment. Four-second delays can be obtained anywhere in the sequence by programming a "13" in the appropriate delay location. WARNING: THE CALLBACK PHONE NUMBER

SHOULD ALWAYS BE REVIEWED FOR ACCURACY BEFORE DISCONNECTING.

LOCATION 23 - FEATURE AND REPORT SELECTIONS (3 segments, feature selection data)

Location 23 is used to enable certain features that can be accessed or are visible to the user from the keypad of the system. In addition, certain communicator reports are enabled in location 23. This location contains 3 segments of 8 features each. (See Feature Definitions starting on page 3.)

Segment 1: 1 - On enables the Quick Arm feature.

2 - On enables the Re-exit feature. 3 - On enables the Automatic Bypass feature. (Default is “on”.) 4 - On enables the Silent Keypad Panic feature (overrides the Audible Panic). 5 - On enables the Audible Keypad Panic feature. (Default is “on”.) 6 - On enables the Keypad Aux 1 feature (FIRE). 7 - On enables the Keypad Aux 2 feature (MEDICAL). 8 - On enables the Keypad Multiple Code Attempt Tamper feature.

Page 16

NX-4 Control

Segment 2: 1 - On enables the LED Extinguish feature.

2 - On enables the Require Code for Bypassing feature. 3 - On enables the Zone Bypassed Sounder Alert feature. 4 - On enables the AC Power/Low Battery Sounder Alert feature. (Default is “on”.) 5 - On enables Bypass toggle. 6 - On enables Silent Auto Arm. 7 - On enables the Automatic Instant feature. 8 - Reserved.

Segment 3: 1 - On enables Opening and Closing reports.

2 - On enables Zone Bypass reporting. 3 - On enables Zone Restore reporting. 4 - On enables Zone Trouble reporting. 5 - On enables Zone Tamper reporting. 6 - On enables the Cancel reporting. (Default is “on”.) 7 - On enables the Recent Closing report. (Default is “on”.) 8 - On enables the Exit Error report. (Default is “on”.)

LOCATION 24 - ENTRY / EXIT TIMERS (4 segments, numerical data) Location 24 is used to program the Entry/Exit times. There are 2 separate Entry/Exit times.

Segment 1, Entry time 1: This is the entry time that will be used when a delay 1 zone type initiates an entry

delay. Valid entries are 30-255 seconds.

Segment 2, Exit time 1: This is the exit time that will be used for all zones designated as delay 1. Valid entries

are 45-255 seconds.

Segment 3, Entry time 2: This is the entry time that will be used when a delay 2 zone type initiates an entry

delay. Valid entries are 30-255 seconds.

Segment 4, Exit time 2: This is the exit time that will be used for all zones designated as delay 2. Valid entries

are 45-255 seconds.

LOCATION 25 - ZONES 1-8 ZONE TYPES (8 segments, numerical data) Location 25 contains the Zone Type (Configuration Group) for zones 1-8. Segment 1 is for zone 1, and Segment 8 is for zone 8. Default zone types are found in Table 2.1 on page 25. Refer also to the programming worksheets. To customize a Zone Configuration Group, refer to Locations 110 - 149 starting on page 24.

LOCATION 37 - SIREN AND SYSTEM SUPERVISION (5 segments, feature selection data) Location 37 is used to enable various system feature and reporting options. (Refer to the feature definitions.)

Segment 1: 1 & 2 - Reserved.

3 - On if siren blast at arming. 4 - On if siren blast at exit expiration. 5 - On if siren blast at closing kissoff. 6 - On if siren sounds during a "Cross Zone" verification time. 7 - On if siren sounds for a Zone or Box Tamper. 8 - On if siren blasts 1 time for wireless arming; 2 times for wireless disarming.

for SIA CP-01 installations.)

Segment 2: 1 - On if siren driver should be a voltage output. Off if on board siren driver enabled.

2 - On if siren sounds for expander trouble (required for UL installations). 3 - On for zones to immediately restore. Off for zones to restore only when siren is off. 4 - On if Dynamic Battery Test performed at arming. Off if performed at disarming. (See loc. 40) 5 - On if Battery Missing Test is performed every 12 seconds. 6 - On if Manual Bell Test performed during [r]-[4] test function. 7 - On if Manual Communicator Test performed during [r]- [4] test function. 8 - On if Box Tamper terminals on the control panel are enabled.

Segment 3: 1 - On if Box Tamper report enabled.

2 - On if AC Fail reporting enabled. 3 - On if Low Battery reporting enabled. 4 - On if Aux. Power Over-current report enabled. 5 - On if Siren Supervision report enabled. 6 & 7 - Reserved. 8 - On if Expander Trouble reporting enabled.

(Note: Must be disabled

Page 17

NX-4 Control

Segment 4: 1 - On if Fail To Communicate report enabled.

2 - On if Log Full report enabled. 3 - On if Autotest report enabled. 4 - On if Start/End programming report enabled. 5 - On if End Download report enabled. 6 - On if Sensor Low Battery report enabled. 7 - On if Sensor Missing report enabled. 8 - Reserved.

Segment 5: 1 = On enable Lost Clock service light.

2 = On enables Zone Doubling (Must have extra devices added to basic system to enable, refer to

page 7) (NX-200 Zone Doubling Kit required) 3 = On disables On-Board 4 zones. 4 = On will allow two trips on same cross-zone to activate an alarm. 5 = On will not allow zones that are force armed to report bypass. 6 = Reserved. 7 = Use internal crystal for clock. 8 = Disable Temporal Siren on Fire (NOTE: For UL installations, do NOT disable feature definitions beginning on page 3.

LOCATION 38 - SWINGER SHUTDOWN COUNT

Location 38 contains the number of trips on a zone before that zone is bypassed automatically. Refer to the feature definitions beginning on page 3. Factory default is 1.

LOCATION 39 - KEYPAD SOUNDER CONTROL (1 segment, feature selection data)

Segment 1: 1 & 2 - Reserved.

3 - On if keypad sounds upon AC Power Failure. 4 - On if keypad sounds when a Low Battery is detected. 5 - On if keypad sounds during Cross Zone trip time. 6 - On if keypad sounds for zone and box tampers. 7 - Reserved. 8 - On if keypad sounds for expander trouble (required for UL installations).

LOCATION 40 - SYSTEM TIMERS (10 segments, numerical data) Location 40 contains the duration of various system timing functions. Example: If you desire the duration of the Dynamic Battery Test to be 30 minutes, you should program [3]-[0]-[r] in segment 1 of this location. The [3]-[0] is the number of minutes, and the [r] stores the data and moves to the next segment of this location.

Segment 1 Dynamic Battery Test duration in minutes 0-255 minutes. (Default is 0 = no test) Segment 2 AC Fail report delay in minutes 0-255 minutes. (Default is 5 minutes) Segment 3 Power Up Delay in seconds 0-60 seconds (0 = no power up delay). (Default is 60 seconds) Segment 4 Siren Time in minutes 1-255 minutes. (Default is 8 minutes) Segment 5 Reserved. Segment 6 Cross Zone time in minutes 0-255. (0 = no cross zoning) (Default is 5 minutes) Segment 7 Chime time in 50mS (1/20th second) increments from 0-12 seconds. (0 = follows zone 255 latched). Segment 8 Dial delay in seconds 15-255 seconds. (Default is 30 seconds) Segment 9 Fire Alarm Verification time in seconds 120-255 seconds. (Default is 0 = no verification) Segment 10 Listen-In time in seconds 0-255. (Default is 0 = no Listen-In time)

IMPORTANT NOTES

1. The "Listen-In" feature cannot be enabled for UL Listed systems. The "Dynamic Battery Test" feature cannot exceed four (4) hours. The dial delay shall be set to “0".

2. For household systems, the Fire Alarm Verification feature is NOT approved for use in California. This feature shall not be programmed into the control unit.

.) Refer to the

Page 18

NX-4 Control

LOCATION 41 - CODE REQUIREMENTS (1 segment, feature data)

Segment 1:

1 = On enables the 6-digit code option. If 6-digit option is enabled, all arm/disarm codes and the "Go To

Program Code" must be 6 digits. If this option is enabled, the default user 1 code is [1]-[2]-[3]-[4]-[5]-

[6]. NOTE: IF YOU ENABLE THIS OPTION, VERIFY THAT THE "GO TO PROGRAM CODE" IS A SIXDIGIT CODE BEFORE EXITING PROGRAMMING.

2 = On requires code entry for [r]-[9]-[8] (perform call back download) and [r]-[9]-[9] (answer incoming call

for download) functions. 3 = Enable Auto Cancel/Abort. (Refer to definitions beginning on page 3.) 4 = Enable Walk-Test Mode. (Refer to definitions beginning on page 3.) 5-8 = Reserved.

LOCATION 42 - GO TO PROGRAM CODE (6 segments, numerical data) Location 42 contains the "Go To Program Code". This location contains either a 4 or 6-digit code. If the 6-digit code option is enabled in Location 41, this code must contain six (6) digits. If this option is not enabled in location 41, the last 2 segments (digits) will be ignored. With the NX-4 disarmed, the "Go To Program Code" can be used to enter the Program Mode.

LOCATION 43 - GO TO PROGRAM CODE AND AUTHORIZATION (1 segment, feature selection data) The "Go To Program Code" can be used as a standard arm/disarm code. When using the code to arm or disarm, the user ID is 255. (This code may not be changed in the Run Mode.)

Segment 1: 1 - Reserved.

2 - On enables "Go To Program Code" as an arm only code. 3 - On enables "Go To Program Code" as an arm only after closing. 4 - On enables "Go To Program Code" as a master arm/disarm code (can change user codes). 5 - On enables "Go To Program Code" as an arm/disarm code. 6 - On enables "Go To Program Code" to bypass zones. 7 - On enables "Go To Program Code" opening and closing reports. 8 - Reserved.

LOCATION 44 - DURESS CODE (6 segments, numerical data) Location 44 contains the "Duress" code. This location contains either 4 or 6 digits. If the 6-digit code option is enabled in Location 41, this code must contain six (6) digits. If the 6-digit option is not enabled in location 41, the last 2 digits will be ignored.

LOCATION 46 - AUXILIARY OUTPUT SPECIAL TIMING (2 segments, feature selection data) Location 46 contains special timing feature activation for the two auxiliary outputs. Segment 1 corresponds to output 1, Segment 2 corresponds to output 2.

Segments 1-2: 1 = On if output should be timed in minutes; Off if timed in seconds.

2 = On if output should latch; Off if output should be timed. 3 = On if output should stop timing upon code entry; Off if the output should continue to time upon

code entry. 4 = On if output should only activate between the closing and opening time in loc. 52 and 53. 5 = On if output should only activate between the opening and closing time in loc. 52 and 53. 6 = On if output should be inverted (0 volts going to 12 volts when activated). 7 = Reserved. 8 = Reserved.

LOCATION 47 - AUXILIARY OUTPUT #1, EVENT AND TIME (2 segments, numerical data)

Segment 1: Use the chart on page 20 to select the event that will activate Auxiliary Output 1. Segment 2: Program the timing from 0-255 (minutes or seconds, depending on data programmed in Segment 1,

Location 46). Programming a "0" makes the output follow the event.

LOCATION 48 - AUXILIARY OUTPUT #2, EVENT AND TIME (2 segments, numerical data)

Segment 1: Use the chart on page 20 to select the event that will activate Auxiliary Output 2. Segment 2: Program the timing from 0-255 (minutes or seconds, depending on data programmed in Segment 2,

Location 46). Programming a "0" makes the output follow the event.

Page 19

NX-4 Control

AUXILIARY OUTPUT EVENT SELECTION

DATA EVENT

0 / Burglary Alarm 1 / Fire Alarm 2 / 24 Hour Alarm 3 / Trouble Alarm 4 / Tamper Alarm

10 Low Battery 11 / Duress 12 / Aux 1 Keypad Zone 13 / Aux 2 Keypad Zone 14 / Panic Keypad Zone

15 Keypad Tamper 16 / Autotest

17 Alarm Memory

18 Entry

19 Exit

20 Entry or Exit

21 Armed State

22 Disarmed State

23 Ready

24 Not Ready

25 Fire

Notes: When Event 48 is programmed, it is possible to program a user code's authorization to select which output(s)

a particular code will activate. When LED 8 is on for an authorization, then LEDs 1- 2 correspond to that code activating outputs 1 & 2 respectively. (See programming the LED keypads on page 8.)

LOCATION 51 - AUTOTEST CONTROL (4 segments, numerical data)

Segment 1: Program a "1" if the interval is to be in hours; Program a "0" if in days. Add a A2" to suppress the

Segment 2: Program the Autotest interval from 1-255 hours/days.

Segment 3: Program the Autotest report hour in 24-hour format (if the interval is in hours, this segment is

Segment 4: Program the Autotest report time, number of minutes after the hour.

Yelping Siren (Burglary)

Temporal Siren (Fire)

Any Siren

Any Bypass

AC Fail

˜ Events 49 & 50 require NX-408E, NX-416E or NX-448E wireless receivers to operate.

/ If set to follow condition, these events will be 1 second.

daily test or a A3" to suppress the hourly test if any report has been sent.

ignored).

DATA EVENT

27 28 / Expander Trouble

45 46 / Any Alarm

48 / Code Entry (See note below) 49 ˜ / Key FOB Function 1 50 ˜ / Key FOB Function 2

Fire Trouble

Chime

Dynamic Battery Test Time

Open Period

Closed Period

Listen-In

Line Seizure

Ground Start

Fail To Communicate

Reserved

Program Mode

Download In Process

Reserved

Short Circuit (Over-current)

Box Tamper

Siren Tamper

Any Open

Any Short

Any Fault (Open/ Short on Non-Fire Zone)

Beeping Keypad

Page 20

NX-4 Control

LOCATION 52 - OPENING TIME (2 segments, numerical data)

Location 52 contains the time in 24 hour format the NX-4 enables codes designated as arm only after closing. This time is only valid on those days programmed in location 54. NOTE: Opening time must be earlier than closing time for Auto Arm, Aux. Outputs, or Code Authorization to function properly.

Segment 1: Program the hour of the opening time.

Segment 2: Program the minutes after the hour of the opening time.

LOCATION 53 - CLOSING TIME/AUTOMATIC ARMING TIME (2 segments, numerical data)

Location 53 contains the time in 24 hour format the NX-4 disables the disarm capability for codes designated as arm only after closing. This is also the time the Automatic Arming sequence will begin (if enabled in location 55). NOTE: Opening time must be earlier than closing time for Auto Arm, Auxiliary Outputs, or Code Authorization to function properly.

Segment 1: Program the hour of the closing / auto arm time.

Segment 2: Program the minutes after the hour of the closing / auto arm time.

LOCATION 54 - DAYS OF THE WEEK SYSTEM IS OPEN (1 segment, feature selection data)

Location 54 selects which days of the week system is open. On these days, Aarm only after close window@ codes will be able to arm and disarm during open window. NOTE: If system is not programmed to be opened and is

programmed to Auto-Arm (Location 55), the NX-4 will try to arm every 45 minutes for the duration of the closed period. On days not selected here, Aarm only after close window@ codes will not disarm. (See locations 52 and 53 for the opening and closing times for the open days.)

Segment 1: 1 - Open on Sunday.

2 - Open on Monday. 3 - Open on Tuesday. 4 - Open on Wednesday. 5 - Open on Thursday. 6 - Open on Friday. 7 - Open on Saturday. 8 - Reserved.

LOCATION 55 - DAYS OF THE WEEK FOR AUTO ARMING (1 segment, feature selection data) Location 55 selects which days the system will auto arm. If a zone is faulted when the panel tries to auto arm, the zone will be bypassed.

Segment 1: 1 - Auto Arming on Sunday.

2 - Auto Arming on Monday. 3 - Auto Arming on Tuesday. 4 - Auto Arming on Wednesday. 5 - Auto Arming on Thursday. 6 - Auto Arming on Friday. 7 - Auto Arming on Saturday. 8 - Reserved.

Page 21

NX-4 Control

COMMUNICATOR CODES FOR SLOW FORMATS ONLY

LOCATIONS 56- 83 ARE ONLY USED WHEN REPORTING EVENTS TO A PAGER OR USING A SLOW FORMAT SUCH AS 4+2. WHEN USING CONTACT ID OR SIA, THERE IS NO NEED TO PROGRAM THESE LOCATIONS.

LOCATION 56 - ARESTORE@ CODE (1 segment, numerical data) Location 56 contains the event code for any zone "Restore" for a 4+2 format. The digit programmed in this location will be sent as the tens digit in place of the alarm event code. The zone ID will always be reported as the ones

digit of the zone number (i.e. 3 for zone 3).

LOCATION 57 - ABYPASS@ CODE (1 segment, numerical data)

Location 57 contains the event code for a zone "Bypass" for a 4+2 format. The digit programmed in this location will be sent as the tens digit. The zone ID will always be reported as the ones digit of the zone number (i.e. 3 for

zone 3).

LOCATION 58 - ATAMPER@ CODE (1 segment, numerical data)

Location 58 contains the event code for a zone "Tamper" for a 4+2 format. The digit programmed in this location will be sent as the tens digit. The zone ID will always be reported as the zone number (i.e. 3 for zone 3).

LOCATION 59 - ATROUBLE@ CODE (1 segment, numerical data) Location 59 contains the event code for a zone "Trouble" for a 4+2 format. The digit programmed in this location will be sent as the tens digit. The zone ID will always be reported as the zone number (i.e. 3 for zone 3).

LOCATION 60 - ASENSOR LOW BATTERY@ CODE (1 segment, numerical data) Location 60 contains the event code for a zone "Sensor Low Battery" for a 4+2 format. The digit programmed in this location will be sent as the tens digit. The zone ID will always be reported as the zone number (i.e. 3 for zone

3).

LOCATION 61 - ASENSOR MISSING@ CODE (1 segment, numerical data)

Location 61 contains the event code for a zone "Sensor Missing" for a 4+2 format. The digit programmed in this location will be sent as the tens digit. The zone ID will always be reported as the zone number (i.e. 3 for zone

3).

LOCATION 62 - ADURESS@ CODE (2 segments, numerical data)

Location 62 contains the tens and ones digits that will be sent for a 4+2 format if the Duress code is enabled in location 44. Segment 1 contains the tens digit, segment 2 contains the ones digit.

LOCATION 63 - AKEYPAD AUXILIARY 1" CODE (2 segments, numerical data) Location 63 contains the tens and ones digits that will be sent for a 4+2 format if the keypad "Auxiliary 1" (FIRE) is enabled in location 23. Segment 1 contains the tens digit, segment 2 contains the ones digit.

LOCATION 64 - AKEYPAD AUXILIARY 2" CODE (2 segments, numerical data) Location 64 contains the tens and ones digits that will be sent for a 4+2 format if the keypad "Auxiliary 2" (MEDICAL) is enabled in location 23. Segment 1 contains the tens digit, segment 2 contains the ones digit.

LOCATION 65 - AKEYPAD PANIC@ CODE (2 segments, numerical data) Location 65 contains the tens and ones digits that will be sent for a location 23. Segment 1 contains the tens digit segment 2 contains the ones digit.

LOCATION 66 - AKEYPAD MULTIPLE CODE ENTRY TAMPER@ CODE (2 segments, numerical data) Location 66 contains the tens and ones digits that will be sent for a 4+2 format if the keypad "Multiple Code Entry" (Tamper) is enabled in location 23. Segment 1 contains the tens digit, segment 2 contains the ones digit.

LOCATION 67 - ABOX TAMPER / BOX TAMPER RESTORE@ CODES (4 segments, numerical data) Location 67 contains the tens and ones digits that will be sent for a 4+2 format if the "Box Tamper" feature is enabled in location 37. Segment 1 contains the tens digit of the "Box Tamper". Segment 2 contains the ones digit of the "Box Tamper". Segment 3 contains the tens digit of the "Box Tamper Restore". Segment 4 contains the ones digit of the "Box Tamper Restore".

4+2 format if the keypad "Panic" is enabled in

Page 22

NX-4 Control

LOCATION 68 - AAC FAIL / AC FAIL RESTORE@ CODES (4 segments, numerical data)

Location 68 contains the tens and ones digits for a 4+2 format that will be sent if "AC Fail Reporting" is enabled. Segment 1 contains the tens digit of the "AC Fail Reporting". Segment 2 contains the ones digit of the "AC Fail Reporting". Segment 3 contains the tens digit of the "AC Fail Restore". Segment 4 contains the ones digit of the "AC Fail Restore".

LOCATION 69 - ALOW BATTERY / LOW BATTERY RESTORE@ CODES (4 segments, numerical data) Location 69 contains the tens and ones digits for a 4+2 format that will be sent if "Low Battery Reporting" is enabled. Segment 1 contains the tens digit of the "Low Battery Reporting". Segment 2 contains the ones digit of the "Low Battery Reporting". Segment 3 contains the tens digit of the "Low Battery Restore". Segment 4 contains the ones digit of the "Low Battery Restore".

LOCATION 70 - AAUX POWER OVER-CURRENT / AUX POWER OVER-CURRENT RESTORE@ CODES (4 segments, numerical data)

Location 70 contains the tens and ones digits for a 4+2 format that will be sent if "Aux Power Over-current Reporting" is enabled. Segment 1 contains the tens digit of the "Aux Power Over-current Reporting". Segment 2 contains the ones digit of the "Aux Power Over-current Reporting". Segment 3 contains the tens digit of the "Aux Power Overcurrent Restore". Segment 4 contains the ones digit of the "Aux Power Over-current Restore".

LOCATION 71 - ABELL TAMPER / BELL TAMPER RESTORE@ CODE (4 segments, numerical data) Location 71 contains the tens and ones digits for a 4+2 format that will be sent if siren supervision reporting is enabled. Segment 1 contains the tens digit of the "Bell Tamper Reporting". Segment 2 contains the ones digit of the "Bell Tamper Reporting". Segment 3 contains the tens digit of the "Bell Tamper Restore". Segment 4 contains the ones digit of the "Bell Tamper Restore".

LOCATION 74 - AEXPANDER TROUBLE / EXPANDER TROUBLE RESTORE@ CODE (4 segments, numerical data)

Location 74 contains the tens and ones digits for a 4+2 format that will be sent if "Expander Trouble Reporting" is enabled. Segment 1 contains the tens digit of the "Expander Trouble Reporting". Segment 2 contains the ones digit of the "Expander Trouble Reporting". Segment 3 contains the tens digit of the "Expander Trouble Restore". Segment 4 contains the ones digit of the "Expander Trouble Restore".

LOCATION 75 - AFAIL TO COMMUNICATE@ CODE (2 segments, numerical data) Location 75 contains the tens and ones digits for a 4+2 format that will be sent if the "Fail To Communicate Reporting" is enabled. Segment 1 contains the tens digit, segment 2 contains the ones digit.

LOCATION 76 - ALOG FULL@ CODE (2 segments, numerical data) Location 76 contains the tens and ones digits for a 4+2 format if the "Log Full Reporting" is enabled. Segment 1 contains the tens digit, segment 2 contains the ones digit.

LOCATION 77 - AOPENING@ CODE (1 segment, numerical data) Location 77 contains the tens digit of a 4+2 format if the "Opening Reporting" is enabled. The ones digit is the ones

digit of the user number that did the opening. If the user is greater than 9, the numbers will begin repeating.

LOCATION 78 - ACLOSING@ CODE (1 segment, numerical data) Location 78 contains the tens digit of a 4+2 format if the "Closing Reporting" is enabled. The ones digit is the ones digit of the user number that did the closing. If the user is greater than 9, the numbers will begin repeating.

LOCATION 79 - AAUTOTEST@ CODE (2 segments, numerical data)

Location 79 contains the tens and ones digits for a 4+2 format that will be sent if the "Autotest" or "Manual Test" is enabled. Segment 1 contains the tens digit segment 2 contains the ones digit.

LOCATION 80 - ARECENT CLOSING AND EXIT ERROR@ CODE (2 segments, numerical data) Location 80 contains the tens digit for a 4+2 format that will be sent if "Recent Closing" and/or "Exit Error Reporting" is enabled. Segment 1 contains the tens digit for the "Recent Closing Reporting". Segment 2 contains the digit for the "Exit Error Reporting". Closings and Exit Errors for more than 9 users, Contact ID or SIA format must be used.

The ones digit is the ones digit of the user who closed. If it is required to report Recent

Page 23

NX-4 Control

LOCATION 81 - ASTART PROGRAM AND END PROGRAM@ CODES (4 segments, numerical data)

Location 81 contains the tens and ones digits for a 4+2 format that will be sent if "Start / End Programming Reporting" is enabled. Segment 1 contains the tens digit of the "Start Program Reporting". Segment 2 contains the ones digit of the "Start Program Reporting". Segment 3 contains the tens digit of the "End Program Reporting". Segment 4 contains the ones digit of the "End Program Reporting".

LOCATION 82 - AEND DOWNLOAD@ CODE (4 segments, numerical data) Location 82 contains the tens and ones digits for a 4+2 format that will be sent if "End Downloading Reporting" is enabled. Segment 1 and 2 are reserved. Segment 3 contains the tens digit of the "End Download Reporting". Segment 4 contains the ones digit of the "End Download Reporting". Note: A start download report will be sent to the internal event log.

LOCATION 83 - ACANCEL@ CODE (1 segment, numerical data) Location 83 contains the tens digit for a 4+2 format that will be sent if "Cancel Reporting" is enabled. Segment 1 contains the tens digit for the "Cancel Communicator Reporting". The ones digit is the ones digit of the user who canceled. If it is required to report Cancels for more than 9 users, Contact ID or SIA format must be used.

CUSTOMIZING ZONE TYPES (Configuration Groups)

NOTE: Locations 110-149 are used to change the zone types (configurations) as listed in the table on page 25. These locations are considered advanced programming and should only be changed with a thorough understanding of the operation of each bit.

Table 1.1

Segment 1

Segment 2

Segment 3

LOCATION 110 - GROUP 1 ALARM EVENT CODE (1 segment, numerical data)

Location 110 contains the event code sent for a Contact ID or SIA report. The desired event code should be chosen from the list on page 34. The zone ID will be that zone that is in alarm. If 4+2 format is being used, the number programmed in this location will be sent as the tens digit. When using 4+2 the digit in location 110 should be from 1-

15. The zone ID for 4+2 formats will be the ones digit of the zone that is in alarm.

LOCATION 111 - GROUP 1 CHARACTERISTIC SELECT (3 segments, feature selection data) Use Table 1.1 AGroup Characteristic Selection@ above to program this location.

1 = Fire (turn on if this is a fire zone). 2 = 24 hour (turn on for non-fire 24 hour zones). 3 = Reserved 4 = Follower (turn on for burglary zones that are Instant during non-entry times). 5 = Delay 1 zone (follows timer 1 entry and exit times). 6 = Delay 2 zone (follows timer 2 entry and exit times). 7 = Interior (turn on if zone should Automatically Bypass or Bypass for Stay Arming). 8 = Local only (turn on if this zone should not be reported).

1 = On will beep the keypad for alarm. 2 = On will sound the yelping siren for alarm. 3 = On will sound the temporal siren for alarm. 4 = On will chime. 5 = On will bypass. 6 = On will include in the group shunt. 7 = On is force armable. 8 = On is entry guard.

1 = RESERVED 2 = On enables Double End Of Line Tamper zone. (Mainly used for tamper on wireless zones) 3 = On enables Trouble Reporting zone. (Day zone and Fire zones) 4 = On enables Cross Zoning. 5 = On enables Dialer Delay zone. (See location 40, page 18) 6 = On enables swinger shutdown. (See location 38, page 18) 7 = On enables Restore reporting. 8 = On enables Listen-In. (See location 40, page 18)

GROUP CHARACTERISTIC SELECTIONS

Page 24

NX-4 Control

will not automatically bypass even if

This zone will be instant when the system is armed and no

s of the armed state of the control panel. It will not display

of the armed state of the control panel. It

This zone will be instant when the system is armed and no

will start a "Cross Zone" timer. If a "Cross Zone" is being timed it will create an instant alarm. This zone will automatically

A trip will start entry delay 1. This zone will bypass when

the "Group Bypass" command is entered at the keypad. The lack of a trip during exit delay will enable the Automatic

This zone will be instant when the system is armed and no

entry or exit delays are being timed. It is delayed during entry/exit delay times. This zone will bypass when the "Group

This zone will be instant when the system is

armed and no entry or exit delay is being timed. It is delayed during entry and exit delay times. This zone will

This configuration group can be used to enable tamper

This configuration group can be used to enable

LOCATIONS 112 THRU 149 contain the remaining 19 Customized Zone Group information. The even numbered locations reflect the AGroup Alarm Event Code@ and the odd numbered locations designate the Group Characteristics. Locations 112 and 113 correspond to Group 2; Locations 148 and 149 correspond to Group 20. Use the description found in Location 110 for programming the Alarm Event Codes, and use Table 1.1 shown on page 24 to select the Group Characteristics. Refer also to the Programming Worksheets.

Table 2.1 STANDARD ZONE TYPES (Default Configurations)

Zones can be programmed to be one of twenty different zone types (configurations). Zone types # 17 - 20 can be used for wireless or hardwired zones using European double EOL configuration. The default zone types are listed below. If none of the following zone types meet your needs, these configurations can be customized by programming locations 110-149.

DATA

"10"

"11"

"12"

"13"

"14"

"15"

"16"

"17"

"18"

"19"

"20"

DAY ZONE - Instant when system is armed trouble zone when system is disarmed.

"1"

24-HOUR AUDIBLE - Creates an instant yelping siren alarm regardless of the armed state of the panel.

"2"

ENTRY/EXIT DELAY 1- A trip will start entry delay 1. The lack of a trip during exit delay will enable the Automatic

"3"

Bypass or Instant mode if so programmed.

FOLLOWER WITH AUTO- BYPASS DISABLED - This zone will be instant when the system is armed and no entry or exit delays are being timed. It is delayed during entry and exit delay times. This zone

"4"

enabled in Segment 1 of Location 23.

INTERIOR FOLLOWER WITH AUTO- BYPASS ENABLED -

entry or exit delay is being timed. It is delayed during entry and exit delay times. This zone will automatically bypass if

"5"

enabled in Segment 1 of Location 23. INSTANT - This zone creates an instant alarm whenever it is tripped and the Armed LED is on.

"6"

24-HOUR SILENT - Creates an instant silent alarm regardles

"7"

on the keypad.

FIRE - This zone will light the Fire LED and sound the temporal siren each time the zone is shorted. It will also rapidly

"8"

flash the Fire LED indicating a trouble if the zone is open.

ENTRY/EXIT DELAY 2- A trip will start entry delay 2. The lack of a trip during exit delay will enable the Automatic

"9"

Bypass or Instant mode if so programmed.

24-HOUR SILENT SUPERVISED- Creates an instant silent alarm regardless will display on the keypad.

RESERVED

INTERIOR FOLLOWER WITH "CROSS ZONE" ENABLED -

entry or exit delay is being timed. It is delayed during entry and exit delay times. If a "Cross Zone" is not being timed it

bypass when enabled in Segment 1 of Location 23.

INSTANT ENTRY GUARD - This zone creates an instant alarm whenever it is tripped and the Stay LED is off. It will start an entry delay time 2 if it is tripped and the system is armed and the Stay LED is on.

ENTRY/EXIT DELAY 1 WITH GROUP BYPASS ENABLED -

Bypass or Instant mode if so programmed.

INTERIOR FOLLOWER WITH GROUP BYPASS ENABLED -

Bypass" command is entered at the keypad. This zone will automatically bypass if enabled in Segment 1 of Location 23.

INSTANT WITH GROUP BYPASS ENABLED - This zone creates an instant alarm whenever it is tripped and the Armed LED is on. This zone will bypass when the "Group Bypass" command is entered at the keypad.

ENTRY/EXIT DELAY 1 WITH TAMPER ENABLED- A trip will start entry delay 1. The lack of a trip during exit delay will enable the Automatic Bypass or Instant mode if so programmed. This configuration group can be used to enable

tamper on a wireless transmitter.

INTERIOR FOLLOWER WITH TAMPER AND AUTO-BYPASS ENABLED -

automatically bypass if enabled in Segment 1 of Location 23.

on a wireless transmitter.

INSTANT WITH TAMPER ENABLED - This zone creates an instant alarm whenever it is tripped and the Armed LED is on. This configuration group can be used to enable tamper on a wireless transmitter.

ENTRY/EXIT DELAY 2 WITH TAMPER ENABLED-A trip will start entry delay 2. The lack of a trip during exit delay will

enable the Automatic Bypass or Instant mode if so programmed.

tamper on a wireless transmitter.

DESCRIPTION OF STANDARD ZONE TYPES

Page 25

NX-4 Control

PROGRAMMING WORKSHEETS

? Factory defaults for segments are in bold italics text. Some locations are reserved and have

LOC PG

0 12 PHONE #1

1 12 PHONE #1, ACCOUNT CODE

2 12 PHONE #1, REPORTING FORMAT

3 12 PHONE #1, DIAL ATTEMPTS

6 14 PHONE #2

7 14 PHONE #2, ACCOUNT CODE

8 14 PHONE #2, REPORTING FORMAT

9 14 PHONE #2, DIAL ATTEMPTS

10 14

12 15 PHONE #3

13 15 PHONE #3, ACCOUNT CODE

14 15 PHONE #3, REPORTING FORMAT

15 15 PHONE #3, DIAL ATTEMPTS

16 15

DESCRIPTION

BACKUP CONTROL

PHONE #1, SELECTING EVENTS TO REPORT TO PHONE #1

Segment #1 (Circle Numbers To Program)

Alarms and Restores

Open/Close

Bypass

Zone Trouble

Power Trouble (AC Failure or Low Battery)

Siren

Test Reports

Program, Download, & Log Full

BACKUP CONTROL

PHONE #2, SELECTING EVENTS TO REPORT TO PHONE #2

Segment #1 (Circle Numbers To Program)

BACKUP CONTROL

PHONE #3, SELECTING EVENTS TO REPORT TO PHONE #3

Segment #1 (Circle Numbers To Program)

Alarms and Restores

Open/Close

Bypass

Zone Trouble

Power Trouble (AC Failure or Low Battery)

Siren

Test Reports

Program, Download, & Log Full

Alarms and Restores

Open/Close

Bypass

Zone Trouble

Power Trouble (AC Failure or Low Battery)

Siren

Test Reports

Program, Download, & Log Full

been intentionally omitted.

DEFAULT

14-14-14-14-14-14-14-14-14-14-

14-14-14-14-14-14-14-14-14-14

10 - 10 - 10 - 10 - 10 - 10

Segment #2 (Circle Numbers To Program)

Tampers

Short Circuit

Sensor Lost

Sensor Low Battery

Expander Trouble

Failure To Communicate

Reserved

14-14-14-14-14-14-14-14-14-14-

14-14-14-14-14-14-14-14-14-14

10 - 10 - 10 - 10 - 10 - 10

Reserved

Segment #2 (Circle Numbers To Program)

1 2 3 4 5 6 7

14-14-14-14-14-14-14-14-14-1414-14-14-14-14-14-14-14-14-14

10 - 10 - 10 - 10 - 10 - 10

8 0

Segment #2 (Circle Numbers To Program)

Tampers

Short Circuit

Sensor Lost

Sensor Low Battery

Expander Trouble

Failure To Communicate

Reserved

PROGRAMMING DATA

__ __ __ __ __ __ __ __ __ __

_ _ _ _ _ _

__ __ __ __ __ __ __ __ __ __

_ _ _ _ _ _

Tampers Short Circuit Sensor Lost Sensor Low Battery Expander Trouble Failure To Communicate Reserved Reserved

__ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __

_ _ _ _ _ _

_ _

Page 26

LOC PG

18 16

DESCRIPTION

FORMAT OVERRIDE

Segment #1 (Circle Numbers To Program)

On = 1800hz transmit; Off = 1900hz

On = 2300hz handshake; Off = 1400hz.

On = cksum parity; Off = double round parity

On = 2 digit event code; Off = 1 digit code

Reserved.

On = 20 p.p.s.; Off = 10 or 40 p.p.s.

19 16 DOWNLOAD ACCESS CODE

20 16 RINGS TO ANSWER DOWNLOAD

Segments #3 & #4 RESERVED

21 16

On = 10 p.p.s.; Off = 20 or 40 p.p.s.

DOWNLOAD CONTROL

Segment #1 (Circle Numbers To Program)

Enables two call answering machine defeat

Reserved

Requires callback before downloading

Shutdown control panel

Lock out local programming

Lock out communicator programming

Lock out download section

Enables callback at autotest interval

22 16 CALLBACK PHONE NUMBER

23 16

FEATURE SELECTION

Segment #1

25 17 ZONES 1-8, ZONE TYPES (

Quick Arm

Re-Exit

Auto Bypass

Silent Panic

Audible Panic

Auxiliary 1

Auxiliary 2

Multi Keypress Tamper

ENTRY/EXIT TIMERS

Segment #1 (Entry Time #1)

Segment #2 (Exit Time #1)

Segment #3 (Entry Time #2)

Segment #4 (Exit Time #2)

DAY ZONE

Standard (Default)

Zone Types Pg 25

24 HOUR AUDIBLE

ENTRY/EXIT DELAY 1

FOLLOWER W/ AUTO- BYPASS DISABLED

INTERIOR FOLLOWER W/ AUTO- BYPASS

INSTANT

24 HOUR SILENT

FIRE

ENTRY/EXIT DELAY 2

24 HOUR SILENT SUPERVISED

Default Configuration)

DEFAULT

Segment #2 (Circle Numbers To Program)

On = pager format (no handshake required)

On = 1400/2300 handshake

Reserved

On = Contact ID

On = SIA

On = Contact ID or 4+3

On = DTMF

8-4-8-0-0-0-0-0

14-14-14-14-14-14-14-14-1414-14-14-14-14-14-14-14-14-

14-14

Segment #2 1

LED extinguish enable

Require user code for bypassing zones

Bypass sounder alert

AC power/low battery sounder alert

Enables bypass toggle

Enables silent auto arm

Enables automatic instant

Reserved

3-5-6-6-6-6-6-6

RESERVED

INTERIOR FOLLOWER W/CROSS ZONE

INSTANT ENTRY GUARD

ENTRY/EXIT DELAY 1 W/GROUP BYPASS

INTERIOR FOLLOWER W/GROUP BYPASS

INSTANT W/GROUP BYPASS

ENTRY/EXIT DELAY 1 W/TAMPER

INTERIOR FOLLOWER W/TAMPER & AUTO-BYPASS

INSTANT W/TAMPER

ENTRY/EXIT DELAY 2 W/TAMPER

NX-4 Control

DATA

_ _ _ _ _ _ _ _

__ __ __ __ __ __ __ __ __

__ __

Segment #3 1

Open/Close

Bypass

Restore

Trouble

Tamper

Cancel

Recent Closing

Exit Error

_ _ _ _ _ _ _ _

Page 27

NX-4 Control

LOC PG

38 18 SWINGER SHUTDOWN COUNT

SIREN AND SYSTEM SUPERVISION

Segment #1 (Circle numbers to program)

1 2 3 4 5 6 7 8

Segment #2 (Circle numbers to program)

1 2 3 4 5 6 7 8

Segment #3 (Circle numbers to program)

1 2 3 4 5 6 7 8

Segment #4 (Circle numbers to program)

1 2 3 4 5 6 7 8

Segment #5 (Circle numbers to program)

1 2 3 4 5 6 7 8

DESCRIPTION

Reserved. Reserved. Siren blast at arming. Siren blast at exit delay expiration. Siren blast at closing kissoff. Siren sounds during a cross zone verification time. Siren sounds for a tamper. Siren blast one time for wireless arming, two times for wireless disarming. (Note: Must be disabled

for SIA CP-01 installations.)

Convert siren driver to voltage out. Siren sounds for expander trouble (required for U.L.). Immediate Restore by Zone. Dynamic battery test performed upon arming. Battery missing test performed every 12 seconds. Manual bell test performed during [r]-[4] test function. Manual communicator test performed during [r]-[4] test function. Box tamper enabled.

Box Tamper report enabled. AC Fail report enabled. Low Battery report enabled. Auxiliary power over current report enabled. Siren supervision report enabled. Reserved. Reserved. Expander trouble report enabled.

Failure To Communicate report enabled. Log Full report enabled. Autotest report enabled. Start and End Programming report enabled. End Download report enabled. Sensor Low Battery report enabled. Sensor Missing report enabled. Reserved.

Lost Clock service LED enable. Zone Doubling enable. (Requires additional devices, see page 7) Disable on-board four zones. Enables two trips on the same cross-zone to activate the alarm. Disables bypass reports for force armed zones Reserved. Clock uses internal crystal. Disable Temporal Siren on Fire. (Do NOT disable for UL installations.)

DEFAULT

DATA

Page 28

NX-4 Control

LOC PG

39 18

42 19 GO TO PROGRAM CODE

43 19

44 19 DURESS CODE 15-15-15-15-15-15 _ _ _ _ _ _

46 19 AUXILIARY OUTPUTS 1 & 2 SPECIAL TIMING

KEYPAD SOUNDER CONTROL Segment #1 (Circle numbers to program)

Reserved.

Keypad sounds upon AC Power Failure.

Keypad sounds upon Low Battery Detection.

Keypad sounds during Cross Zone Trip Time.

Keypad sounds for Tamper Alarm.

Reserved.

Keypad sounds for expander trouble (required for UL).

SYSTEM TIMERS Segment #1 Dynamic Battery Test duration (0-255 min.) 0 _ Segment #2 AC Failure report delay (0-255 minutes) 5 _ Segment #3 Power Up Delay (0-60 seconds) 60 _ Segment #4 Siren Time (1-255 minutes) 8 _ Segment #5 Reserved 0 _ Segment #6 Cross Zone Time (0-255 minutes) 5 _ Segment #7 Chime Time in 50 mS increments (0-255) 3 _ Segment #8 Dialer delay (15-255 seconds) 30 _ Segment #9 Fire Alarm Verification Time (120-255 sec.) 0 _ Segment #10 Listen-In Time (0-255 seconds) 0 _

USER CODE REQUIREMENTS

Segment #1 (Circle numbers to program)

Enables six-digit code option. All arm/disarm/Go To Program codes require six digits

Requires valid user code entry for [r]-[9]-[8] and [r]-[9]-[9] functions to work.

Enables Auto Cancel/Abort.

Enables Walk Test mode.

5-8

Reserved.

GO TO PROGRAM CODE AND AUTHORIZATION

Segment #1 (Circle numbers to program)

Reserved.

Enables "Go To Program Code" as an arm only code.

Enables "Go To Program Code" as an arm only after closing.

Enables "Go To Program Code" as a master arm/disarm code (can change user codes)

Enables "Go To Program Code" as an arm/disarm code.

Enables "Go To Program Code" to bypass zones.

Enables "Go To Program Code" opening and closing reports.

Reserved.

Segments 1 2

Auxiliary output timed in minutes.

Auxiliary output to latch.

Auxiliary output to stop timing upon user code entry.

Auxiliary output to activate only between closing and opening time.

Auxiliary output to activate only between opening and closing time.

Invert auxiliary output (0 volts going to 12 volts when activated).

Reserved

DESCRIPTION

DEFAULT

9-7-1-3-0-0

1 2 3 4 5 6 7 8

_ _ _ _ _ _

DATA

1 2 3 4 5 6 7 8

Page 29

NX-4 Control

LOC PG

47 19

48 19

51 20

52 21

54 21

55 21

AUXILIARY OUTPUT #1, EVENT & TIME

Segment #1: Program the event number for output #1. 0=Burglary alarm

Segment #2: Program the timing for output #1 here . 10 seconds

AUXILIARY OUTPUT #2, EVENT & TIME

Segment #1: Program the event number for output #2. 1=Fire alarm

Segment #2: Program the timing for output #2 here . 10 seconds

AUTOTEST CONTROL Segment #1: Program a "1" if the interval is hours, a "0" if in

days. Add a A2" to suppress the daily test or a A3" to suppress the hourly test.

Segment #2: Program the autotest interval from 1-255 days or hours.

Segment #3: Program the autotest report in 24 hour time format.

Segment #4: Pro after the hour.

OPENING TIME

Segment #1: Program the hour of the opening time.

Segment #2: Program the minutes after the hour of the

opening time.

CLOSING TIME / AUTO ARMING TIME Segment #1: Program the hour of the closing time/auto

arming time. Segment #2: Pro

auto arming time.

DAYS OF THE WEEK SYSTEM IS OPEN

Sunday

Monday

Tuesday

1 2 3 4

Wednesday

Sunday Monday Tuesday Wednesday

DAYS OF THE WEEK "AUTO ARMING" WILL OCCUR

DESCRIPTION

ram the autotest report time, minutes

ram the minutes after hour of closing /

5 6 7 8

Thursday Friday Saturday Reserved

DEFAULT

LOC 56 - 83 COMMUNICATOR CODES FOR SLOW SPEED FORMATS ONLY

DATA

LOC PG DESCRIPTION DEFAULT DATA

56 22 RESTORE COMMUNICATOR CODE 14 _

57 22 BYPASS COMMUNICATOR CODE 0 _

58 22 TAMPER COMMUNICATOR CODE 0 _

59 22 TROUBLE COMMUNICATOR CODE 0 _

60 22 SENSOR LOW BATTERY COMMUNICATOR CODE 0 _

61 22 SENSOR MISSING COMMUNICATOR CODE 0 _

62 22 DURESS 0-0 _ _

63 22 AUXILIARY 1 0-0 _ _

Page 30

NX-4 Control

Delay 1 zone (enable to follow Timer 1 Entry/Exit

Delay 2 zone (enable to follow Timer 1 Entry/Exit

LOC PG DESCRIPTION DEFAULT DATA

64 22 65 22 KEYPAD PANIC 0-2 _ _

66 22 KEYPAD MULTIPLE CODE ENTRY TAMPER 0-0 _ _

67 22 BOX TAMPER / BOX TAMPER RESTORE 0-0-0-0 _ _ _ _

68 23 AC FAIL / AC RESTORE 0-0-0-0 _ _ _ _

69 23 LOW BATTERY / LOW BATTERY RESTORE 0-0-0-0 _ _ _ _

70 23 POWER SHORT / POWER SHORT RESTORE 0-0-0-0 _ _ _ _

71 23 BELL TAMPER / BELL TAMPER RESTORE 0-0-0-0 _ _ _ _

74 23 EXPANDER TROUBLE / EXPANDER TROUBLE RESTORE 0-0-0-0 _ _ _ _

75 23 FAILURE TO COMMUNICATE 0-0 _ _

76 23 LOG FULL COMMUNICATOR CODE 0-0 _ _

77 23 OPENING CODE COMMUNICATOR CODE 11 _

78 23 CLOSING COMMUNICATOR CODE 12 _

79 23 AUTOTEST COMMUNICATOR CODE 0-0 _ _

80 23 RECENT CLOSING AND EXIT ERROR 0-0 _ _

81 24 START PROGRAMMING / END PROGRAMMING 0-0-0-0 _ _ _ _

82 24 END DOWNLOAD 0-0-0-0 _ _ _ _

83 24 CANCEL COMMUNICATOR CODE 0 _

AUXILIARY 2 0-0 _ _

CUSTOMIZING ZONE TYPES (GROUPS)

These locations are considered advanced programming and should only be changed with a thorough operation of each bit. These locations are used to design or customize zones when the Standard Zones Types in Table 2.1 on page 25 do not fit your needs.

110 24 GROUP 1 ALARM EVENT CODE

111 24

GROUP 1 CHARACTERISTIC SELECT

Segment #1 (Circle numbers to program)

Fire (enable for fire zone)

24 Hour (enable for non-fire 24 hour zone)

Reserved

Follower (enable for burg zones that are instant during non-entry times)

Segment #2 (Circle numbers to program)

Keypad audible on alarm.

Yelping siren on alarm.

Temporal siren on alarm.

Chime.

Segment #3 (Circle numbers to program)

RESERVED.

Double End of Line Tamper zone.

Trouble zone (Day zone).

Cross Zone.

times)

Interior (Enable for auto bypass or stay arming)

Local Only (enable if zone is not to be reported)

Bypassable.

Group Shunt.

Force Armable.

Entry Guard.

Dialer Delay zone.

Swinger zone.

Restore reporting.

Listen-In.

understanding of the

Page 31

NX-4 Control

THE DEFAULTS LISTED IN THE ODD NUMBERED LOCATIONS BELOW REPRESENT THE THREE SEGMENTS OF EACH OF THOSE LOCATIONS. USE THE THREE SEGMENT CHARTS FROM LOCATION 111 TO UNDERSTAND THESE DEFAULTS.

112 25 GROUP 2 ALARM EVENT CODE

113 25 GROUP 2 CHARACTERISTIC SELECT

114 25 GROUP 3 ALARM EVENT CODE

115 25 GROUP 3 CHARACTERISTIC SELECT

116 25 GROUP 4 ALARM EVENT CODE

117 25 GROUP 4 CHARACTERISTIC SELECT

118 25 GROUP 5 ALARM EVENT CODE

119 25 GROUP 5 CHARACTERISTIC SELECT

120 25 GROUP 6 ALARM EVENT CODE

121 25 GROUP 6 CHARACTERISTIC SELECT

122 25 GROUP 7 ALARM EVENT CODE

123 25 GROUP 7 CHARACTERISTIC SELECT

124 25 GROUP 8 ALARM EVENT CODE

125 25 GROUP 8 CHARACTERISTIC SELECT

126 25 GROUP 9 ALARM EVENT CODE

127 25 GROUP 9 CHARACTERISTIC SELECT

128 25 GROUP 10 ALARM EVENT CODE

129 25 GROUP 10 CHARACTERISTIC SELECT

130 25 GROUP 11 ALARM EVENT CODE

131 25 GROUP 11 CHARACTERISTIC SELECT

132 25 GROUP 12 ALARM EVENT CODE

133 25 GROUP 12 CHARACTERISTIC SELECT

134 25 GROUP 13 ALARM EVENT CODE

135 25 GROUP 13 CHARACTERISTIC SELECT

136 25 GROUP 14 ALARM EVENT CODE

137 25 GROUP 14 CHARACTERISTIC SELECT

138 25 GROUP 15 ALARM EVENT CODE

139 25 GROUP 15 CHARACTERISTIC SELECT

140 25 GROUP 16 ALARM EVENT CODE

141 25 GROUP 16 CHARACTERISTIC SELECT

142 25 GROUP 17 ALARM EVENT CODE

143 25 GROUP 17 CHARACTERISTIC SELECT

144 25 GROUP 18 ALARM EVENT CODE

145 25 GROUP 18 CHARACTERISTIC SELECT

146 25 GROUP 19 ALARM EVENT CODE

147 25 GROUP 19 CHARACTERISTIC SELECT

148 25 GROUP 20 ALARM EVENT CODE

149 25 GROUP 20 CHARACTERISTIC SELECT

5-1245-5678

45-125-5678

457-125-5678

0-1245-5678

6-1245-5678

457-125-45678

0-12458-5678

5-12456-5678

457-1256-5678

0-12456-5678

5-1245-25678

457-125-25678

0-1245-25678

6-1245-25678

2-125-78

2-0-78

1-13-378

24-5-78

3-0-0

Page 32

NX-4 Control

APPENDIX 1 REPORTING FIXED CODES IN CONTACT ID AND SIA

The table below list the event codes sent for the following reports (if enabled) when using CONTACT ID or SIA formats.

REPORT

MANUAL TEST 601 RX AUTOTEST 602 RP OPEN (user number) 401 OP CLOSE (user number) 401 CL CANCEL (user number) 406 OC DOWNLOAD COMPLETE 412 RS START PROGRAM 627 LB END PROGRAM 628 LX RECENT CLOSE (user number) 401 CR EXIT ERROR (user number) 457 EE EVENT LOG FULL 605 JL FAIL TO COMMUNICATE 354 RT EXPANDER TROUBLE (device number) 333 ET EXPANDER RESTORE (device number) 333 ER SIREN TAMPER (device number) 321 YA SIREN RESTORE (device number) 321 YH AUX POWER OVER CURRENT (device number) 312 YP AUX POWER RESTORE (device number) 312 YQ LOW BATTERY (device number) 309 YT LOW BATTERY RESTORE (device number) 309 YR AC FAIL (device number) 301 AT AC RESTORE (device number) 301 AR BOX TAMPER (device number) 137 TA BOX TAMPER RESTORE (device number) 137 TR KEYPAD TAMPER 137 TA KEYPAD PANIC (audible) 120 PA KEYPAD PANIC (silent) 121 HA DURESS 121 HA KEYPAD AUXILIARY 1 110 FA KEYPAD AUXILIARY 2 100 MA RF SENSOR LOST (zone number) 381 *T RF SENSOR RESTORE (zone number) 381 *R SENSOR LOW BATTERY (zone number) 384 XT SENSOR BATTERY RESTORE (zone number) 384 XR ZONE TROUBLE (zone number) 380 *T ZONE TROUBLE RESTORE (zone number) 380 *R ZONE TAMPER (zone number) 137 TA ZONE TAMPER RESTORE (zone number) 137 TR ZONE BYPASS (zone number) 570 *B BYPASS RESTORE (zone number) 570 *U

CONTACT ID SIA

THE NUMBER IN PARENTHESES FOLLOWING THE EVENT IS THE NUMBER THAT WILL BE REPORTED AS THE ZONE NUMBER. IF THERE ARE NO PARENTHESES, THE ZONE WILL BE A0". SEE PAGE 35 FOR THE DEVICE NUMBERS.

* The character transmitted in this slot will be the first character from the event code of the zone that is bypassed or in trouble. (See locations 110 - 141)

Page 33

NX-4 Control

APPENDIX 2 REPORTING ZONE CODES IN SIA OR CONTACT ID

The NX-4 has the ability to report SIA level 1 transmissions to either or both phone numbers. Each report in SIA consists of an Event Code and a Zone or User ID. The Zone ID will be the zone number that is in alarm. The event code will come from the chart below and be programmed in the configuration group event code.

Programmed Event Code

0 HA Holdup Alarm

1 FA Fire Alarm

2 PA Panic alarm

3 BA Burglary Alarm

4 BA Burglary Alarm

5 BA Burglary Alarm

6 UA Untyped Alarm

7 BA Burglary Alarm

8 BA Burglary Alarm

9 UA Untyped Alarm

10 HA Holdup Alarm

11 MA Medical Alarm

12 PA Panic alarm

13 TA Tamper Alarm

14 RP Periodic Test

15 GA Gas Alarm

16 KA Heat Alarm

17 WA Water Alarm

18 QA Emergency Alarm

19 SA Sprinkler Alarm

20 ZA Freeze Alarm

The NX-4 has the ability to report Ademco Contact ID transmissions. Each report in Contact ID consists of an Event Code and a Zone ID. The zone ID is the zone that created the alarm. The event code will come from the chart below and be programmed in the configuration group event code.

Programmed Event Code

0 122 Silent Panic 1 110 Fire Alarm 2 120 Panic alarm 3 130 Burglary Alarm 4 131 Perimeter Alarm 5 132 Interior Alarm 6 133 24 Hour Burglary 7 134 Entry Alarm 8 135 Day/Night Alarm 9 150 Non Burglary 24 Hour 10 121 Duress Alarm 11 100 Medical Alarm 12 123 Audible Panic Alarm 13 137 Tamper Alarm 14 602 Periodic Test 15 151 Gas Detected 16 158 High Temp 17 154 Water Leakage 18 140 General Alarm 19 140 General Alarm 20 159 Low Temp

SIA Code Description

Contact ID Code Description

Page 34

NX-4 Control

APPENDIX 3 EXPANDER NUMBERS FOR REPORTING EXPANDER TROUBLE

The tables below list the device numbers that will be reported for trouble conditions.

Device Device # reported NX-4 Control Panel 0 See pages 33 - 34 for possible report codes. NX-534E Two Way Listen-In 64 NX-540E AOperator@ 40 NX-582E AES Interface 77 NX-591E Cellemetry Interface 76

KEYPADS

Keypad 1 2 3 4 5 6 7 8

Device # 192 200 208 216 224 232 240 248

REMOTE POWER SUPPLY (NX-320E) OUTPUT MODULE (NX-508E)

Address & Dip Switch Setting

84 (All switches off) 88 (Switch 3 on) 24 (Switch 1 & 2 on) 28 (Switch 1,2,&3 on) 85 (Switch 1 on) 89 (Switch 1 & 3 on) 25 (Switch 3 on) 29 (All switches off) 86 (Switch 2 on) 90 (Switch 2 & 3 on) 26 (Switch 1 & 3 on) 30 (Switch 1 on) 87 (Switch 1 & 2 on) 91 (All switches on) 27 (Switch 2 & 3 on) 31 (Switch 2 on)

WIRELESS RECEIVER (NX-448E)

Switch Setting

All switches off 35 Switch 1 on 32 Switch 2 on 33 Switch 1 & 2 on 34

Expander #

reported

Address & Dip Switch Setting

KEYPAD MAXIMUM WIRE RUN

(Note: These numbers are for one keypad at the end of the wire. When connecting more than one keypad to the end of the wire, a higher gauge wire will be required.)

Length in feet Wire Gauge Wire Gauge

250 24 22

500 20 18 1000 18 16 1500 16 14 2500 14 12

WHEN CONNECTED TO NX-4 WHEN CONNECTED TO NX-320E

Page 35

NX-4 Control

WIRING DIAGRAM

Page 36

TERMINAL

EARTH

AUX 1

SIREN

COM

SMOKE+

AUX 2

KEYPAD

DATA

COM

AUX PWR -

POS

AUX PWR

ZONE 4

COM

ZONE 3

ZONE 2

COM

ZONE 1



NX-4 Control

TERMINAL DESCRIPTIONS

House Telephone Ring (Grey).

Telephone Ring (Red).

Telephone Tip (Green).

House Telephone Tip (Brown).

AC input. Connect to a 16.5V 25, 40 or 50 VA Class ll U.L. approved transformer.

Earth Ground. Connect to a cold water pipe or a 6 to 10 foot driven rod.

Connect negative lead of low current device [relay, LED (install 1K Ω resistor in series with LED), etc.]. Connect positive lead of device to KEYPAD +. Current is limited to 250mA when output is negative, and 250FA when output is positive.

If used as a siren output (default), the speaker rating should be 15 watt at 8 or 16 ohm, or 30/40 watt at 4, 8, or 16 ohms. If voltage output is selected in location 37, this output becomes voltage output, 12VDC, 1 Amp maximum load. NOTE: A 3.3K Ω resistor may be required across the bell terminals

when a 12 VDC siren is used. If no resistor is used, you may experience voltage leakage into the siren, which will cause these devices to output a small signal.

Connect negative wire of siren/speaker or voltage output devices.

Smoke detector power 12VDC, 250 mA maximum (For those jurisdictions which allow the Priority zone to be used with smoke detectors.)

Connect to the data terminal on the keypads and the expanders. MAXIMUM: 8 keypads + 1 other device.

Connect to the Common terminal on the keypads, expanders, and other power devices.

Connect to the Positive terminal on the keypads, expanders, and other power devices. This terminal is limited to 1 amp total current.

Connect to one side of zone 4 loop. Connect the other side to com terminal. Open or short causes alarm.

Common (-) terminal for zones 3 & 4.

Connect to one side of zone 3 loop. Connect the other side to com terminal. Open or short causes alarm.

Connect to one side of zone 2 loop. Connect the other side to com terminal. Open or short causes alarm.

Common (-) terminal for zones 1 & 2.

Connect to one side of zone 1 loop. Connect the other side to com terminal. Open or short causes alarm.

IMPORTANT!

1. If separate power supplies are necessary to accommodate additional devices, safety standards require that each power supply be prominently marked with adequate instructions for removing all power from the unit.

2. Dispose of used batteries according to the manufacturer’s instructions and/or local government authorities.

3. Installation personnel should thoroughly read and understand the installation instructions and the users manuals

for the panel and all the accessories to be included with the system before attempting to install a security system.

WARNING!

Replace only with Panasonic #LC12V4BP or Yuasa #NP4-12 battery. Observe polarity when installing a new battery. Installing the battery backwards may cause damage to the panel. There is a risk of explosion if the battery is replaced with an incorrect type.

NOTE

Electrical codes will vary depending upon the country and city where the system is installed. It is the installer’s responsibility to ensure that the electrical installation is safe and conforms to all applicable codes, laws, or regulations. Only qualified persons should connect this device to the mains supply.

DESCRIPTION

Page 37

NX-4 Control

Notices (Applies to products which

have the CE mark attached)

DECLARATION OF CONFORMITY

Manufacturer’s Name: Caddx Controls Manufacturer’s Address: 1420 N. Main Street

Gladewater, TX 75647

EU Representative: Interlogix Europe

Product Identification Product: NetworX Model: NX-4 Brand: CADDX

R&TTE Directive

See EMC and LVD tests below

EMC Directive

EN50081-1

EN50130-4 EN55022 EN60950 EN61000-3-2 EN61000-3-3

LVD Directive

EN 60950: 1999-4 3rd edition

Means of Conformity

We declare under our sole responsibility that this product is in conformity with Directive 1999/5/EC (R&TTE); Directive 73/23/EEC (LVD); and Directive 89/336/EEC (EMC) and based on test results using (non)-harmonized standards in accordance with the Directives mentioned.

Additional Tests

This equipment has been tested and found to comply with the following standards (which are no longer required for compliance).

Network Compatibility Declaration

We declare under our sole responsibility that this product is designed to work with the networks in the countries marked with a check () and may have interworking problems with the countries that are not checked. Due to the inherent differences in the individual PSTNs, certain software settings may need to be adjusted on a country-to-country basis. If it is desired to use this equipment on a network other than the one on which it was originally installed, you should contact your equipment supplier.

() Austria (_) Liechtenstein () Belgium () Luxembourg () Denmark () Netherlands () Finland () Norway () France () Poland () Germany () Portugal () Greece () Spain () Iceland () Sweden () Ireland () Switzerland () Italy () United Kingdom

Telecom Approval Notice

This equipment has been approved in accordance with the Council Decision 98/482/EC for panEuropean, single terminal connection to the public switched telephone network (PSTN). However, due to the differences between the individual PSTNs provided in different countries, the approval does not, of itself, give an unconditional assurance of successful operation on every PSTN network termination point. In the event of problems, you should contact your equipment supplier in the first instance.

Electrical Requirements

This device automatically adjusts to voltages within the range of 230 V 50/60 Hz. Fuse: Type T 200mA 250 VAC

Page 38

LOCAL TELEPHONE COMPANY INTERFACE INFORMATION

TELEPHONE CONNECTION REQUIREMENTS

Except for telephone company provided ringers, all connections to the telephone network shall be made through standard plugs and standard telephone company provided jacks or equivalent in such a manner as to allow for immediate disconnection of the terminal equipment. Standard jacks shall be so arranged that if the plug connected thereto is withdrawn, no interference to the operation of the equipment at the customers premises which remains connected to the telephone network, shall occur by reason of such withdrawal.

INCIDENCE OF HARM

Should terminal equipment or protective circuitry cause harm to the telephone network, the telephone company shall, where practical, notify the customer that temporary discontinuance of service may be required. However, where prior notice is not practical, the telephone company may temporarily discontinue service if such action is deemed reasonable in the circumstances. In the case of such temporary discontinuance, the telephone company shall promptly notify the customer who will be given the opportunity to correct the situation. The customer also has the right to bring a complaint to the FCC if he feels the disconnection is not warranted.

CHANGES IN TELEPHONE COMPANY EQUIPMENT OR FACILITIES

The telephone company may make changes in its communications facilities, equipment, operations, or procedures where such action is reasonably required and proper in its business. Should any such change render the customers terminal equipment incompatible with the telephone company facilities, the customer shall be given adequate notice to make modifications to maintain uninterrupted service.

GENERAL

The FCC prohibits customer provided terminal equipment be connected to party lines.

IMPORTANCE OF THE RINGER EQUIVALENCE NUMBER

The Ringer Equivalence Number (REN) of this device is 0.1B. This number is a representation of the electrical load that it applies to your telephone line.

MALFUNCTION OF THE EQUIPMENT

In the event that the device should fail to operate properly, the customer shall disconnect the equipment from the telephone line to determine if it is the customer’s equipment that is not functioning properly. If the problem is with the device, the customer shall discontinue use until it is repaired.

EQUIPMENT INFORMATION

MANUFACTURER OF CONNECTING EQUIPMENT: CADDX CONTROLS, INC. FCC REGISTRATION NUMBER: GCQUSA-33408-AL-E, RINGER EQUIVALENCE: 0.1 B

LISTING No: 7167-1249:105 CATEGORY: Control Unit (Household) DESIGN: Model NX-4 combination household fire and burglary alarm control units. RATING: 120 VAC primary, 16.5 VAC secondary; 12 VDC standby INSTALLATION: In accordance with listee’s printed installation instructions, NFPA 72, applicable

APPROVAL: Listed as household fire alarm control unit for use with separately listed compatible

CALIFORNIA STATE FIRE MARSHAL LISTING

codes & ordinances and in a manner acceptable to the authority having jurisdiction. The system must have the secondary power supply capable of operating the system for at least 24 hours (battery standby) in the normal condition and followed by not less than 4 minutes of alarm as required by code.

initiating and indicating devices. The control unit can generate the three pulse temporal code pattern fire alarm signal (for total evacuation) as required per NFPA 72, 1996 Edition.

Page 39

UNDERWRITERS LABORATORIES INFORMATION

The NetworX NX-4 holds the following listings from Underwriters Laboratories (US and Canada):

Household Burglary (UL1023) (ORD-C1023-1974) Household Fire (UL985) (CAN/ULC S545-M89) Local Grade A Mercantile, Police Station Connect with Basic Line Security (UL609) (requires #NX-003-C enclosure) (CAN/ULC S303-M91) Grade B & C Central Station Burglar Alarm Unit (UL1610) (CAN/ULC S304-M88) Home Health Care Signaling (UL1637)

When installing an NX-4 in compliance with Underwriters Laboratories, the following instructions must be observed:

! Initiating and indicating devices must be rated at 11.5 to 12.4 V DC residential, 12.0 V DC commercial. ! Force Arming and Auto Arming shall not be enabled. ! For residential fire applications, the indicating devices shall be a Wheelock 34T-12 or equivalent. ! The "Listen-In" feature shall not be enabled. ! The Siren/Bell Test shall be enabled. The auxiliary outputs controlling the audible device require a minimum

cutoff time of 15 minutes for commercial burglary, 4 minutes for residential applications, or 30 minutes for commercial burglary for Canada.

! For residential fire installations, the Dynamic Battery Test time cannot exceed four (4) hours. ! Ringback shall be enabled on UL commercial burglary installations. ! On commercial burglary installations, the fire initiating circuits shall not be connected. ! The Entry-Guard feature shall be disabled. ! Group Bypassing shall be disabled. ! Delay before dial seizure shall be set to "0". ! Total current draw from aux power connections at terminal positions POS, AUX PWR, and SMOKE PWR must not

exceed 400 mA.

! Remote Downloading shall not be used on UL listed systems. ! For residential burglary applications, the maximum entry and exit delay times shall be 45 and 60 seconds

respectively. The exit delay time shall not exceed 60 seconds for commercial burglar alarm applications.

! The keyswitch option shall not be used. ! The telephone line monitor shall be enabled. ! The Telephone Line Cut delay shall not exceed 90 seconds. ! 24-hour communicator test transmission is required. ! For 24 hours of standby power using a 7.0 AH battery, limit auxiliary power load to 140 mA. ! For 24 hours of standby power using a 17.2 AH battery, limit auxiliary power load to 400 mA. ! The silent keypad option shall not be enabled. ! UL has only verified compatibility with the following listed DACRs and formats: Sure-Gard SG-MLR2-DG:

2,9,10,12,13,14; Silent Knight 9000 - 2,12; FBI - CP220FBI, 13; and Ademco 685: 2,11,12, and 13.

! For burglary installations, cross-zoned detectors shall overlap 100 percent in the area of coverage and similar

coverage areas must be used. For example, interior protection is cross-zoned with interior protection, etc.

! Expander trouble must activate the siren (Loc 37, Segment 2, LED 2) ! For UL 1637, expander trouble must activate keypad sounder (Loc 39, Segment 1, LED 8) ! The keypad used with wireless receivers and hardwire expansion must be able to display all zones in a system. ! For Canadian installations, the Class II transformer secure tab shall not be employed.

MINIMUM SYSTEM CONFIGURATIONS FOR UL INSTALLATIONS

(Residential Fire, Residential Burglary, Commercial Burglary)

! The NetworX NX-4 panel is necessary to initiate Residential and Commercial installations. ! At least one compatible keypad is needed for all applications. ! At least one bell fixture is required for all applications, except Grade C Central Station. For Grade A Local, the

AD10-12 bell and Grade A bell housing shall be used.

! Commercial UL applications require #NX-003-C metal enclosure. Supplied screws to be used. ! A minimum of two (2) keypads are required for Home Health applications and each keypad must be set to a

unique address.

! The wireless devices are only UL listed for residential applications. ! The DACT shall be enabled for all commercial burglary applications.

Page 40

SIA SYSTEM REQUIREMENTS (ANSI-SIA CP-01)

To meet SIA CP-01 requirements –

•

Minimum System Requirements: 1 control panel; 2 keypads

• Remote arming shall NOT be enabled in SIA classified installations.

• Off-premise transmission must be in the SIA format.

• The Abort window and Entry Delay must not exceed 1 minute.

Exit Time Exit 1 Delay 24 2 60 45 – 240 sec. Exit 2 Delay 24 4 60 45 – 240 sec. Progress Annuncation / Disable – for Silent Exit Exit Time Restart This feature is non-programmable in the panel. Enabled Auto Stay Arm on Unvacated

Premises Exit Time and Progress Annunciation / Disable

– for Remote Arm Entry Delay(s) Entry 1 Delay 24 1 30 30 – 240 sec. Entry 2 Delay 24 3 30 30 – 240 sec. Abort Window – for Non-Fire Zones

Abort Window Time – for Non-Fire Zones Abort Annunciation This feature is non-programmable in the panel. -- Flashing Cancel LED goes off when

Cancel Annunciation Cancel 23 3 / 6 Enabled Enabled Duress Feature Duress 44 Disabled Disabled Cross Zoning 2 Trips on Cross Zone 37 5 / 4 Disabled Required Keypad sounds on Cross Zone trip 39 5 Disabled Zone Type Characteristic 111 3 / 4 Disabled Programmable Cross Zoning Time Cross Zone Time 40 6 5 minutes Allowed Swinger Shutdown Swinger Shutdown Count 38 n/a Enabled for 1 trip For all non-fire zones, shut down at 1–2 trips Swinger Shutdown Disable Swinger Shutdown Count 38 n/a Enabled for 1 trip Allowed Fire Alarm Verification Fire Alarm Verification Time 40 9 Disabled Required (depends on panel & sensors) Call Waiting Cancel Must be programmed as part of

Exit Error 23 3 / 8 Enabled Power Up Delay 40 3 60 sec.

• CAUTION – A call waiting cancel on a non-call waiting line will prevent successful connection to the central station.

CP-01 Feature

Description

Default Changes (from prior

versions):

Feature Description as shown in manual

Silent Keypad Option  9 3 2 All annunciators enabled Allowed

Auto Bypass 23 1 / 3 Enabled Enabled

This feature is non-programmable in the panel. -- Exit time and progress are always enabled.

Dialer Delay 40 8 30 Enabled

Dialer Delay 40 8 30 15 – 45 sec.

disarming.

the phone number

Recent Closing 23 3 / 7 Enabled

Program

Loc

0 n/a n/a Required (depends on user phone line)

Seg / Opt

Factory Default

(individual keypads may be disabled)

Enabled (may be disabled for remote arming)

(may be disabled by zone/ zone type)

Enabled

CP-01 Required

Setting

NOTE:

Combined Abort window and Entry Delay must not exceed 1 minute.

I-NX4-IM

Printed in Mexico

SPECIFICATIONS

OPERATING POWER 16.5 VAC 25, 40, or 50 VA Transformer

AUXILIARY POWER

w/25 VA Transformer 12 VDC Regulated 500 mA w/40 or 50 VA Transformer 12 VDC Regulated 1 AMP

LOOP RESISTANCE

Standard Loop 300 Ohms Maximum

BUILT-IN SIREN DRIVER 2-tone (Temporal and Yelp)

LOOP RESPONSE 500mS

OPERATING TEMPERATURE 32 to 120 degrees F

LED KEYPAD

Current Draw 130 mA max. Zones Normal w/o Sounder 55 mA Dimensions 6.4" Wide

4.0" High

1.1" Deep

NX-148E LCD KEYPAD

Current Draw 110 mA max. w/o Sounder 75 mA Dimensions 6.4" Wide

5.3" High

1.0" Deep

METAL ENCLOSURE DIMENSION 9.25" Wide

8.25" High

3.50" Deep

SHIPPING WEIGHT 9 lbs.

Main 800-727-2339 Technical Support 800-727-2339 Outside the US 903-845-6941 Tech Support Fax 903-845-8409 Main Fax 903-845-6811 Sales & Literature 800-547-2556 Web: www.caddx.com

www.interlogix.com

NX-4 INSTALLATION MANUAL NX4IM04 REV. N (DEC 2012)

1420 N. MAIN STREET

GLADEWATER, TEXAS 75647

UL approved for ANSI/SIA

CP-01-2000

Interlogix NX-4 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
