NX1700EIG05
(
Supercedes NX1700EIF04)
NX-1700E Proximity Card Reader
Installation and Startup
© 2012 UTC Fire & Security
All rights reserved. Printed in the United States of America.
NetworX
These instructions do not purport to cover all details or variations in equipment nor to provide every possible contingency to be met during installation,
operation, and maintenance. If further information is desired or if particular problems arise that are not covered sufficiently for the purchaser’s
purpose, the matter should be referred to UTC Fire & Security, Gladewater, Texas, USA.
This document contains proprietary information of UTC Fire & Security, USA and is furnished to its customer solely to assist that customer in the
installation, testing, operations, and/or maintenance of the equipment described. This document shall not be reproduced in whole or in part nor shall
its contents be disclosed to any third party without the written approval of UTC Fire & Security.
Please refer to the current UTC Fire & Security product catalog for detailed warranty information.
is a trademark of the UTC Fire & Security.
Main 800-727-2339 Technical Support 888-437-3287
Outside the US 903-845-6941 Sales & Literature 800-547-2556
Main Fax 903-845-6811 Web: www.utcfireandsecurity
Indicates a procedure, practice, condition, or statement that, if not strictly observed, could result in personal
injury.
Warning
Caution
* This symbol indicates electrical warnings and cautions.
Indicates a procedure, practice, condition, or statement that, if not strictly observed, could result in damage to or
destruction of equipment or property.
** This symbol indicates general warnings and cautions.
.com
Symbol Legend
Note
Tip
Indicates an essential or important procedure, instruction, condition, or statement.
Indicates a user tip. Provides helpful information that is not normally defined in regular use, but from an
experienced user.
Indicates a key or button should be pressed to enter data.
Enter
ORDERING INFORMATION
PART # DESCRIPTION PART # DESCRIPTION
NX-1700E
NX-8E
NX-848E-KIT
NX-8
NX-848-KIT
NX-6
NX-648-KIT
NX-148E
NX-1192E
Card Reader Module
8 – 192 Z
NX-8E Control, NX-148E LCD Key
Transformer
8 – 48 Zone Control Only
NX-8 Control, NX-148E LCD Keypad, 40VA
Transformer
6 – 12 Zone Control Only
NX-6 Control, NX-148E LCD Keypad, 40VA
Transformer
Alphanumeric 48 Zone LCD Keypad
192 Zone LCD Keypad
one Control Only
pad, 40VA
NX-216E
NX-320E
NX-408E
NX-416E
NX-448E
NX-507E
NX-508E
NX-534E
These units are UL listed for residential use only.
one Expander Module
16 Z
Smart Power Supply and Buss Extender
8 Zone Wireless Expansion Module
16 Zone Wireless Expansion Module
48 Zone Wireless Expansion Module
Seven Relay Module
Eight Output Module
Two-Way Listen In Module
TABLE OF CONTENTS
I. GENERAL DESCRIPTION.................................................................................................................................................... 3
II. INSTALLATION AND WIRING ............................................................................................................................................. 3
III. ENROLLING ......................................................................................................................................................................... 3
IV. ADDRESSING....................................................................................................................................................................... 3
V. PROGRAMMING................................................................................................................................................................... 4
A. USING THE LED KEYPAD............................................................................................................................................ 4
Entering the Program Mode........................................................................................................................................... 4
Entering the Module Address ........................................................................................................................................ 4
Programming a Location................................................................................................................................................ 4
Exiting the Program Mode:............................................................................................................................................ 5
B. USING THE LCD KEYPAD............................................................................................................................................ 5
C. PROGRAMMING DATA TYPES.................................................................................................................................... 5
VI. USER CARDS....................................................................................................................................................................... 5
Adding One User................................................................................................................................................................... 6
Adding Multiple Users with Auto-Increment........................................................................................................................... 6
Activate One User (Single User)............................................................................................................................................ 6
De-Activate One User............................................................................................................................................................ 7
Delete / Reset One User........................................................................................................................................................ 7
VII. PROGRAMMING LOCATIONS............................................................................................................................................. 7
Location 0 Programming the Scan Functions.......................................................................................................... 7
Location 241 Programming the X-10 Address for the Scan Functions......................................................................... 8
Location 242 Programming the Options and Reader Partition..................................................................................... 8
Location 243 Programming the Zones......................................................................................................................... 9
Location 244 Programming the Various Reader Timers.............................................................................................. 9
Location 245 Resetting the Reader Address ............................................................................................................... 9
Location 246 Programming the Access Options.......................................................................................................... 9
Location 247 Programming the Opening Time for Schedule 1 ...................................................................................10
Location 248 Programming the Closing Time for Schedule 1.....................................................................................10
Location 249 Programming the Days for Schedule 1..................................................................................................10
Locations 250 - 270 Programming the Schedules 2 - 8.........................................................................................................10
Location 271 Programming the Date of Holidays in January......................................................................................11
Locations 272 - 282 Programming the Date of Holidays from February to December...........................................................11
Location 283 Programming Activation Data for User Cards 1 through 120.................................................................11
Location 284 Programming Activation Data for User Cards 121 through 240.............................................................11
Location 285 Code Entry Logging Partition.................................................................................................................11
VIII. PROGRAMMING WORKSHEETS.......................................................................................................................................12
IX. GLOSSARY .........................................................................................................................................................................17
X. FCC INFORMATION............................................................................................................................................................17
XI. UNDERWRITERS LABORATORIES INFORMATION.........................................................................................................17
XII. SPECIFICATIONS................................................................................................................................................................17
2
NX-1700E Card Reader
I. GENERAL DESCRIPTION
The NetworX NX-1700E is a proximity card reader / door control module used to expand the capabilities of the NetworX control
panels.
$ Microprocessor-controlled
$ Includes one (1) low current trigger output, which can be used to control a door strike relay
$ Up to 15 card readers can be connected to the NetworX control panel
$ Can be programmed to control access in any or all partitions
$ LEDs can be programmed to follow the output and/or the armed or ready status of the system
$ Has an optional optical tamper switch
II. INSTALLATION AND WIRING
To install the card reader, simply wire it into the system. Refer to the following wiring table for details.
DESCRIPTION
GREEN
(DATA)
BLACK
(COM)
RED
(POS)
WHITE
(EGRESS)
BLUE
(OUTPUT)
Connect to the NetworX control panel DATA terminal. This wire is the data-signaling terminal to all
the devices on the buss.
Connect to the NetworX control panel COMMON terminal. Supplies the common side of the power
to the card reader module.
Connect to NetworX control panel AUX POWER + terminal. Supplies power to the card reader
module.
This is an optional EGRESS (exit) input. To use this feature, connect the normally open egress
switch between this terminal and COM. If this feature is not used, there is no need to connect this
wire.
This is an optional open-collector (negative trigger) OUTPUT. It can be used to drive a relay. To
use this feature, connect the coil contacts of a relay between this terminal and AUX POWER +.
Absolute maximum 14 volts @ 25mA.
This is a low current output and must not be used to directly energize high c urrent door
openers.
III. ENROLLING
The NetworX control panels have the ability to automatically find and store in memory the presence of all keypads, zone expanders,
wireless receivers, output modules, and any other device on the keypad buss. This allows these devices to be supervised by the
control panel. To enroll the devices, enter the Program Mode using the procedure outlined in the control panel Installation Manual.
When the Program Mode is exited, the NX control panel will automatically enroll the devices. The enrolling process takes about 12
seconds, during which time the Service LED will illuminate. User codes w ill not be accepted during the enrolling process. Once a
module is enrolled, if it is not detected by the control, the Service LED will illuminate.
IV. ADDRESSING
Once the reader is wired into the system, the module needs to be addressed. Unlike most NetworX expanders,
the address of any particular reader is determined by itself after installation is complete. Follow the procedures
outlined under the section “PROGRAMMING”. When prompted to enter the module device number, a card
must
be scanned at the reader to initiate addressing (one short beep). When completed (1-2 seconds), the
reader will beep back its address (long beeps). Refer to Table IV-1 that follows for possible addresses.
ble IV-1
Ta
Beeps Address Beeps Address
1 113 9 121
2 114 10 122
3 115 11 123
4 116 12 124
5 117 13 125
6 118 14 126
7 119 15 127
8 120
Scan: To
“present” or pass
a card or FOB
within sensing
range of the card
reader module.
NX-1700E Card Reader
3
V. PROGRAMMING
A. USING THE LED KEYPAD
NOTE: The NX-108E / NX-116E / NX-124E series keypads should not be used to program user cards.
ACTION
ENTERING THE PROGRAM MODE
RESULT
[Go To Program Code]
Factory Default is
Enters the Program Mode.
Stay, Chime, Exit, Bypass & Cancel LEDS will flash.
If the "Go To Program Code" is valid, the "Service" LED will flash and
the 5 function LEDs will illuminate steady. You are now in the
Program Mode and ready to select the module address.
ENTERING THE MODULE ADDRESS
Scan a card. The card reader will address itself.
#
(example only)
Enters the module address. Refer to Table IV-1 on page 3 for the
address assigned by
The Armed LED will illuminate while it is waiting for a programming
location to be entered.
the card reader module itself.
PROGRAMMING A LOCATION
To Enter a Location:
[location] #
To Change Location Data:
[changed data]
NOTE: Repeat these steps until the last segment is
reached.
To Exit a Location:
#
To Review The Data:
[location] #
If an attempt is made to program an invalid entry for a particular segment, the keypad sounder will emit
a triple error beep (beep, beep, beep), and remain in that segment awaiting a valid entry.
The Armed LED will flash. If the location is valid, the "Armed" LED
will extinguish, the "Ready" LED will illuminate, and the zone LED’s
will show the data for the first segment of this location.
The "Ready" LED will flash to indicate a data change in process and
will continue until the data is saved.
The new data is saved.
The keypad will increment and display the next segment’s data.
Exits from this location. The “Ready” LED will extinguish. The
"Armed" LED will illuminate waiting for a new p rogramming loca tion to
be entered.
The Armed LED will flash. If the location is valid, the "Armed" LED
will extinguish, the "Ready" LED will illuminate, and the zone LED’s
will show the data for the first segment of this location.
(Do not enter data.)
The next segment is displayed. Each time is pressed, the data of
the next segment will be displayed for review.
Shortcuts:
4
Previous location.
Same location.
Next sequential location.
NX-1700E Card Reader
EXITING THE PROGRAM MODE:
EXIT EXIT
Exits this programming level.
B. USING THE LCD KEYPAD
All steps required for programming are the same as the aforementioned LED keypad. The LCD keypad display will prompt you for
the data required. While in the programming mode, and not in a location, the number in parenthesis is the location you were
previously changing. For example, if the display reads "Enter location, then # (5)", it is reminding you that location 5 was the last
location you programmed. In feature selection data, the numbers of the enabled features will be displayed. The features not enabled
will display a hyphen (-).
C. PROGRAMMING DATA TYPES
a) Numerical Data
Numerical data can take on values from 0-255 or 0-15 depending on the segment size.
b) Feature Selection
Feature selection data is used to turn features on or off.
VI. USER CARDS
Adding and de-activating users is done through a combination of entering information at the keypad and scanning cards. Before a
card can be entered, one reader on the system must be programmed with User Card Programming enabled (Location 242, Segment
1, Option 1, page 8).
It is recommended that only one reader on the system be enabled to modify user cards and that this reader
be located near a keypad. This reader will transfer information to all other readers in the system once
programming is finished.
Once a reader is enabled to modify users, it must be placed into one of the following five modes:
1) Add One User
2) Add Multiple Users w/ Auto-Increment
3) Activate One User
4) De-Activate One User
5) Delete/Reset One User.
Modifying users on a card reader is similar to modifying user codes at a keypad.
MUST BE A MASTER USER IN ORDER TO MODIFY USER CARD INFORMATION.
ACTION
[master code]
Factory Default is
if the control is an NX-6, or NX-8
Unit is now ready for you to choose one of the User Card
if the control is an NX-8E
IMPORTANT NOTE
Adding or de-activating user cards from a reader will cause the code for User Number 2 to become invalid. Therefore, it will need to be
re-entered after all user cards are programmed into the readers.
Accesses Code Programming
If the code is valid, the Ready LED will flash.
User Number 2 is used to program user cards, so…
Programming modes (as if user code 2):
1) Add One User
2) Add Multiple Users (w/ Auto-Increment)
3) Activate Single User
4) De-activate One User
5) Delete / Reset One User
RESULT
NX-1700E Card Reader
5
ADDING ONE USER
ACTION
[STAY]
[3-digit user number]
Example: if 4-digit user code
if 6-digit user codes
or
Scan the card designated for the user entered
in the previous step.
ADDING MULTIPLE USERS WITH AUTO-INCREMENT
ACTION
[CANCEL] Use [NIGHT] on NX-1248E
[3-digit user number]
Example: if 4-digit user code
if 6-digit user codes
or
Scan the card designated for the user entered
in the previous step.
Continue scanning user cards until the desired
number of cards has been added.
RESULT
Accesses Activation mode
If a valid user number is entered, LED1 on any enabled readers
will begin to flash.
1) If the user card is not already in the system, it will be added
and mapped to the entered user number and LED1 will
flash.
2) If the card is already in the system, the reader will triple
beep and LED1 will continue flashing.
After about 30 seconds, all the readers in the system will
be updated with the new user card information.
RESULT
Accesses Activation mode
If a valid user number is entered, LED1 on any enabled readers
will begin to flash.
1) If the user card is not already in the system, it will be added
and mapped to the entered user number and LED1 will
continue flashing indicating that the next user card can be
scanned for the next user number.
2) If the card is already in the system, the reader will triple
beep and LED1 will continue flashing; the user number is
not incremented in this case.
After about 30 seconds without a card being scanned, all the
readers in the system will be updated with the new user card
information.
By default, user cards are added and activated. In order to add a user card and de-activate it at
the same time, scan and hold the card to be added until two beeps are sounded at the reader.
ACTIVATE ONE USER (SINGLE USER)
ACTION
[CHIME] not available on NX-1248E
[3-digit user number]
Example: if 4-digit user code
if 6-digit user codes
or
Scan any card.
6
RESULT
Accesses Activation mode
If a valid user number is entered, LED1 on any enabled readers
will begin to flash.
The card information for the user entered in the previous step
will be activated, and LED1 will stop flashing. After about 30
seconds, all the readers in the system will be updated.
NX-1700E Card Reader
DE-ACTIVATE ONE USER
ACTION
[BYPASS]
[3-digit user number]
Example: if 4-digit user code
if 6-digit user codes
or
Scan any card
DELETE / RESET ONE USER
ACTION
[EXIT]
[3-digit user number]
Example: if 4-digit user code
if 6-digit user codes
or
RESULT
Accesses De-activation mode
If a valid user number is entered, LED1 on any enabled readers
will begin to flash.
The card information for the user entered in the previous step
will be cleared, and LED1 will stop flashing. After about 30
seconds, all the readers in the system will be updated.
If an individual keeps the
card, it can still be deleted.
RESULT
Accesses De-activation mode
If a valid user number is entered, LED1 on any enabled readers
will begin to flash.
Scan any card
ACTIVATING / DE-A CTIVATING / RESETTING USERS
If User Number 0 is entered, the desired function will be performed on the user associated with the card scanned.
The card information for the user entered in the previous step
will be cleared, and LED1 will stop flashing. After about 30
seconds, all the readers in the system will be updated.
VII. PROGRAMMING LOCATIONS
SCAN METHODS: Legacy mode is default. Alternative mode is shown below in brackets { }.
Refer to Location 242 Segment 1 on page 8, and the Glossary on page 17 for explanation.
LOCATION 0 PROGRAMMING THE SCAN FUNCTIONS
(3 segments of binary data) Location 0 is used to select the particular function(s) that are activated when a card is scanned. More
than one function may be selected. If more than one function is selected, they will execute in order from function 1 to function 8.
Functions 1-6 will be performed based on the user’s authority as programmed by the [] [6] function (refer to
keypad user manual).
Segment 1 Single Scan Function {Single Beep}
Program the functions that are performed w
LED1 - "On" to send Code Entry function to the control panel.
LED2 - "On" to activate the Armed Away mode.
LED3 - "On" to activate the Armed Stay mode.
LED4 - "On" to send the Disarm function to the control panel.
LED5 - "On" to send Auxiliary Function #1 to the control panel.
LED6 - "On" to send Auxiliary Function #2 to the control panel.
LED7 - "On" to broadcast an X-10 function (see Location 241 for programming).
LED8 - "On" to send a Request To Exit (RTE); and activate the onboard open collector output. (Default is “On”)
Location 243, Segment 2 must be programmed with a valid zone number for the RTE to be sent.
hen a card is scanned {one beep}.
NX-1700E Card Reader
7
Segment 2 Double Scan Function {Double Beep}
Program the functions that are performed when a card is scanned twice within the 2 Scan Hold Time {two beeps}. Location 244,
Segment 1 programs the length of time between beeps. The descriptions of the options are the same as for Single Beep Scan
Function. Default is 1.
Segment 3 Single Scan Hold Function {Triple Beep}
Program
{three beeps}. Location 244, Segment 1 programs the length of time between beeps. The descriptions of the options are the same
as for Single Beep Scan Function. Default is 1.
the functions that are performed when a card is scanned and held at the reader for the duration of the 2 Scan Hold Time
LOCATIONS 1 - 240 RESERVED
LOCATION 241 PROGRAMMING THE X-10 ADDRESS FOR THE SCAN FUNCTIONS
(5 segments of numerical data)
Segment 1 Program a number from 0 -15 to represent the corresponding X-10 Module Number from the following table.
Default is 0.
Module
Seg 1
Segment 2 Program a number from 0-15 to represent the corresponding X-10 House code from the following table. Default is
0.
Segment 3 Single Scan Function {Single Beep}
Program the X-10 function that is performed when a card is scanned {one beep}. This location only needs to be programmed if
Location 0, Segment 1, Option 7 is set. Use the following table. Default is 2.
Function # Function performed Function # Function performed
0 All units off 4 Dim
1 All lights on 5 Bright
2 On
3 Off All others Reserved
Segment 4 Double Scan Function {Double Beep}
Program the X-10 function that is performed w
Segment 1 programs the length of time between beeps. The descriptions of the function codes are the same as for Single Beep
Scan Function. This location only needs to be programmed if Location 0, Segment 2, Option 7 is set. Use the above table. Defaul t is
3.
Segment 5 Single Scan Hold Function {Triple Beep}
Program the X-10 function that
{three beeps}. Location 244, Segment 1 programs the length of time between beeps. The descriptions of the function codes are the
same as for Single Beep Scan Function. This location only needs to be programmed if Loc 0, Seg 3, Option 7 is set. Use the above
table. Default is 2.
is performed when a card is scanned and held at the reader for the duration of the 2 Scan Hold Time
2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
1
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
0
X-10 ADDRESS CODES
0=A 4=E 8=I 12=M
1=B 5=F 9=J 13=N
2=C 6=G 10=K 14=O
3=D 7=H 11=L 15=P
6 All lights off
hen a card is scanned twice within the 2 Scan Hold Time {two beeps}. Location 244,
LOCATION 242 PROGRAMMING THE OPTIONS AND READER PARTITION
(4 segments of binary data)
Segment 1 System Options:
LED1 - "On" if reader is enabled for User Card Programming.
LED2 - "On" if optical tamper is enabled.
LED3 - "On" if reader buzzer is to fo llow typical keypad buzzing. (Default is “On”)
LED4 - "On" if ding-dong chime enabled (dependent on both Option 3 and chime being enabled).
LED5 - “On” if an RTE from a scanned card is to be logged as Code Entry. (Default is “On”)
LED6 - “On” if reader is in NX-1700E Legacy Mo de (Default is “On”). Refer to note below.
LED7 - “On” if an RTE) from a zone or the Egress input is to be logged as Code Entry.
LED8 - “On” if LEDs to extinguish after 2 minutes without a scan. (Note: This option doesn’t disable the flashing green
LED during card programming.)
The card reader is defaulted to the “Legacy mode”. This mode uses the same scan method as previous NX-1700E card
readers. However, an alternative scan method is available by turning off LED6 in Location 242, Segment 1. Rather than
passing the card (scan) within range of the card reader, the card can be held at the reader for a specified number of beeps.
Example of Double Scan
the card by the reader’s sensor once again. Alternative mode -- Hold the card at the card reader for a total of 2 beeps.
Refer to the Glossary on page 24.
8
IMPORTANT
different methods of scanning at various readers.
: If you have older models installed in the system without this enhanced feature, it could result in two
: Legacy mode -- Pass the card by the reader’s sensor, remove it from the sensor area, then pass
NX-1700E Card Reader
Segment 2 LED1 (Green) Options:
LED1 - "On" to follow Read y statu s of system. (Default is “On”)
LED2 - "On" to toggle with the open collector output activation. (Default is “On”)
LED3 - "On" if inverted.
LED4-8 Reserved.
Segment 3 LED2 (Red) Options:
LED1 - "On" to follow Armed status of system. (Default is “On ”)
LED2 - "On" to toggle with the open collector output activation.
LED3 - "On" if inverted.
LED4-8 Reserved.
Segment 4 Read er Partition:
LED1 - "On" if reader is in Partition 1. (Default is “On”)
LED2 - "On" if reader is in Partition 2. (Default is “On”)
LED3 - "On" if reader is in Partition 3. (Default is “On”)
LED4 - "On" if reader is in Partition 4. (Default is “On”)
LED5 - "On" if reader is in Partition 5. (Default is “On”)
LED6 - "On" if reader is in Partition 6. (Default is “On”)
LED7 - "On" if reader is in Partition 7. (Default is “On”)
LED8 - "On" if reader is in Partition 8. (Default is “On”)
LOCATION 243 PROGRAMMING THE ZONES
(2 segments of numerical data)
Segment 1 Door Shunt Zone
Program the zone that will be monitored as a door for access control. This location must be programmed with a valid zone for
monitored access control functions to work properly. (Default is 0)
Additionally, this zone must be configured in the control panel as a Door Shunt zone by programming an unused Zone
Type Characteristic in locations 111-169 (Seg 4, Opt 4).
Segment 2 Request To Exit (RTE) Zone
Program the zone that will be monitored to signal an RTE. If this segment is programmed with a valid zone and the zone is faulted,
the reader will activate its onboard open collector output and send the RTE. (Default is 0)
Additionally, this zone must be configured in the control panel as an RTE zone by programming an unused Zone Type
Characteristic in locations 111-169 (Seg 4, Opt 3).
LOCATION 244 PROGRAMMING THE VARIOUS READER TIMERS
(4 segment of numerical data)
Segment 1 Scan Time
Enter the amount of time required to hold a card between beeps to activate the functions programmed in Location 0, Segments 2 and
3. This timer is timed in 1/100-second increments from 0 to 2.55 seconds. (Default is 100 = 1 second).
Segment 2 Relay Active Time
Enter the amount of time the onboard open
from 0 to 255 seconds. (Default is 10 = 10 seconds).
Segment 3 Door Fault Warning Time
Enter the amount of time a monitored zone (see Location 243, Segment 1) must be faulted before sounding a w
buzzer). The door fault warning is timed in 1-second increments from 0 to 255 seconds. (Default is 30 = 30 seconds).
Segment 4 Door Fault Alarm Time
Enter the amount of time a monitored zone (see Location 243, Segment 1) must be faulted before sending an alarm condition to the
control panel. The door fault alarm is timed in 1-second increments from 0 to 255 seconds. (Default is 0 = disabled).
collector output is energized once activated. This timer is timed in 1-second increments
arning (local
LOCATION 245 RESETTING THE READER ADDRESS
(1 segment of numerical data) If it is necessary to reset the address of the reader, enter a 0 in this location.
This will cause the reader to cease functioning. If a card is scanned with the system in Program Mode, the reader
will again find an available address and set itself, beeping back to the user the address that w as found as per the table
on page 3. If the system is not in Program Mode and a card is scanned at a reader w
sound an error beep.
ith a reset address, then it will
LOCATION 246 PROGRAMMING THE ACCESS OPTIONS
(2 segments of binary data)
Segment 1 Door Options
LED1 - "On" if locking mechanism is a Maglock or Drop Bolt.
LED2 - "On" if access is allowed regardless of Armed status of the system.
NX-1700E Card Reader
9
LED3 -
"On" if the door is not to be latched unlocked during an open schedule.
LED4 - "On" if onboard open collector output only triggers during an open schedule.
LED5 - “On” if onboard open collector output only triggers during a close schedule.
LED6 - “On” if Forced Entry Alarm is logged.
LED7 - “On” if access allowed without an RTE. (Default is “On”)
LED8 - ”On if relay operates normally during off-schedule (outside of regular operating hours).
Segment 2 Enabling the Schedules for the Onboard Open Collector Output:
LED1 - "On" if driver follows Schedule 1.
LED2 - "On" if driver follows Schedule 2.
LED3 - "On" if driver follows Schedule 3.
LED4 - "On" if driver follows Schedule 4.
LED5 - "On" if driver follows Schedule 5.
LED6 - "On" if driver follows Schedule 6.
LED7 - "On" if driver follows Schedule 7.
LED8 - "On" if driver follows Schedule 8.
Segment 3 More Door Options
LED1 - "On" if egress input is to be disabled.
LED2-8 Reserved
LOCATION 247 PROGRAMMING THE OPENING TIME FOR SCHEDULE 1
(2 segments of numerical data)
Segment 1 Program the hour of the opening time in 24-hour format. (Default is 8 = 8:00 AM)
Segment 2 Program the minutes after the hour of the opening time for Schedule 1. (Default is 0)
LOCATION 248 PROGRAMMING THE CLOSING TIME FOR SCHEDULE 1
(2 segments of numerical data)
Segment 1 Program the hour of the closing time in 24-hour format. (Default is 20 = 8:00 PM)
Segment 2 Program the minutes after the hour of the closing time for Schedule 1. (Default is 0)
LOCATION 249 PROGRAMMING THE DAYS FOR SCHEDULE 1
(1 segment of binary data)
LED1 - “On” if schedule is active on Sunday.
LED2 - "On" if schedul e is active on Monday.
LED3 - "On" if schedule is active on Tuesday.
LED4 - "On" if schedule is active on Wednesday.
LED5 - “On” if schedule is active on Thursday.
LED6 - “On” if schedule is active on Friday.
LED7 - “On” if schedule is active on Saturday.
LED8 - “On” if schedule is disabled on holidays.
LOCATIONS 250 - 270 PROGRAMMING THE SCHEDULES 2 - 8
Locations 250 - 270 are used to program the opening times, closing times, and days for Schedules 2 - 8. Each schedule has three
locations that are programmed with the same steps as Schedule 1 described previously. Refer to Schedule 1 (Locations 247 - 249
above) for specific instructions.
Location 250 – Opening Time for Schedule 2 Location 262 – Opening Time for Schedule 6
Location 251 – Closing Time for Schedule 2 Location 263 – Closing Time for Schedule 6
Location 252 – Days for Schedule 2 Location 264 – Days for Schedule 6
Location 253 – Opening Time for Schedule 3 Location 265 – Opening Time for Schedule 7
Location 254 – Closing Time for Schedule 3 Location 266 – Closing Time for Schedule 7
Location 255 – Days for Schedule 3 Location 267 – Days for Schedule 7
Location 256 – Opening Time for Schedule 4 Location 268 – Opening Time for Schedule 8
Location 257 – Closing Time for Schedule 4 Location 269 – Closing Time for Schedule 8
Location 258 – Days for Schedule 4 Location 270 – Days for Schedule 8
Location 259 – Opening Time for Schedule 5
Location 260 – Closing Time for Schedule 5
Location 261 – Days for Schedule 5
10
NX-1700E Card Reader
LOCATION 271 PROGRAMMING THE DATE OF HOLIDAYS IN JANUARY
(8 segments of numerical data) Program the day of the month in January that the Opening time in a schedule is suppressed. For
example, if the opening should not occur on January 1, program a “1” in Segment 1. This feature can be repeated up to a maximum
of 8 holidays per location (month). (Default is No holidays)
LOCATIONS 272 - 282 PROGRAMMING THE DATE OF HOLIDAYS FROM FEBRUARY TO DECEMBER
(8 segments of numerical data) Locations 272 - 282 are used to program the day of each month, from February to December, in
which the Opening time in a schedule is suppressed. Each location will accommodate up to a maximum of 8 holidays, and
programmed with the same steps as Location 271 described previously.
Location 272 – February holidays
Location 273 – March holidays
Location 274 – April holidays
Location 275 – May holidays
Location 283 Programming Activation Data for User Cards 1 through 120
(15 segments of binary data) This location is used to select which user cards 1 - 120 are activated. If the LED is “on”, the card is
active. Each segment has 8 LEDs corresponding to the 8 possible user cards. Example: Segment 4, LED2 indicates that user card
26 is active.
SEG USER
1
2
3
CARDS
1 - 8
9 - 16
17 - 24
SEG USER
4
5
6
Location 276 – June holidays
Location 277 – July holidays
Location 278 – August holidays
Location 279 – September holidays
SEG USER
CARDS
25 - 32
33 - 40
41 - 48
7
8
9
CARDS
49 - 56
57 - 64
65 - 72
Location 280 – October holidays
Location 281 – November holidays
Location 282 – December holidays
SEG USER
CARDS
10
11
12
73 - 80
81 - 88
89 - 96
SEG USER
CARDS
13
14
15
97 - 104
105 - 112
113 - 120
LOCATION 284 PROGRAMMING ACTIVATION DATA FOR USER CARDS 121 THROUGH 240
(15 segments of binary data) This location is used to select which user cards 121 - 240 are activated. If the LED is “on”,
the card is active. Each segment has 8 LEDs corresponding to the 8 possible user cards. Example: Segment 15, LED8
indicates that user card 240 is active.
SEG USER
1
2
3
CARDS
121 - 128
129 - 136
137 - 144
SEG USER
CARDS
4
5
6
145 - 152
153 - 160
161 - 168
SEG USER
CARDS
7
8
9
169 – 176
177 - 184
185 - 192
SEG USER
CARDS
10
11
12
193 - 200
201 - 208
209 - 216
SEG USER
CARDS
13
14
15
217 - 224
225 - 232
233 - 240
LOCATION 285 CODE ENTRY LOGGING PARTITION
(1 segment of numerical data) This location programs the partition that is logged with the Code Entry message and sent when the
following conditions are met:
An RTE scan function is selected (Location 0, Segment 1/2/3, Option 8); and
“RTE from a scanned card is to be logged as Code Entry” is enabled (Location 242, Segment 1, Option 5).
Entering a 0 (zero) will send the lowest valid partition of the reader. Entering 1-16 will send the entered value as the partition.
(Default is 0.)
NX-1700E Card Reader
11
VIII. PROGRAMMING WORKSHEETS
Defaults are shown in bold italics.
IMPORTANT TIP:
LOC PG DESCRIPTION DEFAULT YOUR DATA
0
7 SCAN FUNCTIONS
Seg 1 SINGLE SCAN FUNCTION (1 Beep)
1 = "On" to send Code Entry function to the control panel.
8
2 = "On" to activate the Armed Away mode.
3 = "On" to activate the Armed Stay mode.
4 = "On" to send the Disarm function to the control panel.
5 = "On" to send Auxiliary Function #1 to the control panel.
6 = "On" to send Auxiliary Function #2 to the control panel.
7 = "On" to broadcast an X-10 function (Loc 241 for programming).
8 = "On" to send an RTE; and activate the onboard open collector output.
Seg 2 DOUBLE SCAN FUNCTION (2 Beep)
1 = "On" to send Code Entry function to the control panel.
1
2 = "On" to activate the Armed Away mode.
3 = "On" to activate the Armed Stay mode.
4 = "On" to send the Disarm function to the control panel.
5 = "On" to send Auxiliary Function #1 to the control panel.
6 = "On" to send Auxiliary Function #2 to the control panel.
7 = "On" to broadcast an X-10 function (Loc 241 for programming).
8 = "On" to send an RTE; and activate the onboard open collector output.
Seg 3 SINGLE SCAN HOLD FUNCTION (3 Beep)
1 = "On" to send Code Entry function to the control panel.
1
2 = "On" to activate the Armed Away mode.
3 = "On" to activate the Armed Stay mode.
4 = "On" to send the Disarm function to the control panel.
5 = "On" to send Auxiliary Function #1 to the control panel.
6 = "On" to send Auxiliary Function #2 to the control panel.
7 = "On" to broadcast an X-10 function (Loc 241 for programming).
8 = "On" to send an RTE; and activate the onboard open collector output.
1-240
241
8 RESERVED
8 X-10 ADDRESS
Seg 1 MODULE NUMBER
Seg 2 HOUSE CODE
Seg 3 SINGLE SCAN FUNCTION (1Beep)
0 =
(see chart)
All units off
0=A
1=B 5=F 9=J 13=N
2=C 6=G 10=K 14=O
3=D 7=H 11=L 15=P
1 = All lights on
2 = On
X-10 ADDRESS CODES
4=E 8=I 12=M
4 = Dim
5 = Bright
6 = All lights off
0
0
2
3 = Off
8 Seg 4 DOUBLE SCAN FUNCTION (2 Beep)
0 = All units off
1 = All lights on
2 = On
4 = Dim
5 = Bright
6 = All lights off
3
3 = Off
Seg 5 SINGLE SCAN HOLD FUNCTION (3 Beep)
0 = All units off
1 = All lights on
2 = On
4 = Dim
5 = Bright
6 = All lights off
2
3 = Off
242
8 OPTIONS AND READER PARTITION
Seg 1 SYSTEM OPTIONS
1 = "On" if enabled for User Card Programming
3, 5, 6
2 = "On" if optical tamper enabled
3 = "On" if buzzer follows keypad buzzing
4 = "On" if ding-dong chime enabled (Opt 3 & chime must be enabled)
5 = “On” if an RTE from a scanned card is to be logged as Code Entry
6 = “On” if reader is in NX-1700E Legacy Mode
7 = “On” if an RTE from a zone or the Egress input is to be logged as Code Entry.
8 = “On” if LED extinguish after 2 minutes without a scan.
Seg 2 LED1 (GREEN) OPTIONS
1 = "On" follows system Ready status
1,2
2 = "On" to toggle with the Open Collector output
3 = "On" if inverted
4 = 4-8= Reserved.
12
NX-1700E Card Reader
LOC PG DESCRIPTION DEFAULT YOUR DATA
242
8 Seg 3 LED2 (RED) OPTIONS
1 = "On" follows system Armed status
1
2 = "On" to toggle with the Open Collector output
3 = "On" if inverted
4 = 4-8= Reserved.
Seg 4 READER PARTITION
1 = "On" if reader is in Partition 1
1,2,3,4,5,6,7,8
2 = "On" if reader is in Partition 2
3 = "On" if reader is in Partition 3
4 = "On" if reader is in Partition 4
5 = "On" if reader is in Partition 5
6 = "On" if reader is in Partition 6
7 = "On" if reader is in Partition 7
8 = "On" if reader is in Partition 8
243
244
245
9 PROGRAMMING THE ZONES
Seg 1 Door Shunt Zone
Seg 2 Request To Exit (RTE)
9 READER TIMES
Seg 1 Scan Time (1/100 seconds)
Seg 2 Relay Active Time (seconds)
Seg 3 Door Fault Warning Time (seconds)
Seg 4 Door Fault Alarm Time (seconds)
9 RESET THE READER ADDRESS
0 = Disabled
0 = Disabled
100 = 1 second
10 = 10 seconds
30 = 30 seconds
0 = Disabled
Entering a “0” will reset and cause the reader to cease
functioning.
246
9 PROGRAMMING THE ACCESS OPT IONS
Seg 1 DOOR OPTIONS
1 = "On" if locking mechanism is a Maglock or Drop Bolt.
2 = "On" if access is allowed regardless of Armed status of the system.
3 = "On" if the door is not to be latched unlocked during an open schedule.
4 = "On" if onboard open collector output only triggers during an open schedule.
5 = “On” if onboard open collector output only triggers during a close schedule.
6 = “On” if Forced Entry Alarm is logged.
7 = “On” if access allowed without an RTE.
8 = “On” if relay operates normally during off-schedule (
Seg 2 SCHEDULES FOR ONBOARD OPEN COLLECTOR OUTPUT
1 = "On" if driver follows Schedule 1.
outside of regular operating hours).
2 = "On" if driver follows Schedule 2.
3 = "On" if driver follows Schedule 3.
4 = "On" if driver follows Schedule 4.
5 = "On" if driver follows Schedule 5.
6 = "On" if driver follows Schedule 6.
7 = "On" if driver follows Schedule 7.
8 = "On" if driver follows Schedule 8.
Seg 3 MORE DOOR OPTIONS
1 = “On” if egress input is to be disabled.
2-8 = Reserved.
247
248
249
10 OPENING TIME FOR SCHEDULE 1
Seg 1 Hour of Opening Time (24-hr format)
Seg 2 Minutes after Hour of Opening
10 CLOSING TIME FOR SCHEDULE 1
Seg 1 Hour of Closing Time (24-hr format)
Seg 2 Minutes after Hour of Closing
10 DAYS FOR SCHEDULE 1
8 = 8 AM
0
20 = 8 PM
0
1 = "On" if schedule is active on Sunday.
2 = "On" if schedule is active on Monday.
3 = "On" if schedule is active on Tuesday.
4 = "On" if schedule is active on Wednesday.
5 = “On” if schedule is active on Thursday.
6 = “On” if schedule is active on Friday.
7 = “On” if schedule is active on Saturday.
8 = “On” if schedule is disabled on holidays.
250
251
10 OPENING TIME FOR SCHEDULE 2
Seg 1 Hour of Opening Time (24-hr format)
Seg 2 Minutes after Hour of Opening
10 CLOSING TIME FOR SCHEDULE 2
Seg 1 Hour of Closing Time (24-hr format)
Seg 2 Minutes after Hour of Closing
8 = 8 AM
0
20 = 8 PM
0
NX-1700E Card Reader
13
LOC PG DESCRIPTION DEFAULT YOUR DATA
252
10 DAYS FOR SCHEDULE 2
1 = "On" if schedule is active on Sunday.
2 = "On" if schedule is active on Monday.
3 = "On" if schedule is active on Tuesday.
4 = "On" if schedule is active on Wednesday.
5 = “On” if schedule is active on Thursday.
6 = “On” if schedule is active on Friday.
7 = “On” if schedule is active on Saturday.
8 = “On” if schedule is disabled on holidays.
253
254
255
10 OPENING TIME FOR SCHEDULE 3
Seg 1 Hour of Opening Time (24-hr format)
Seg 2 Minutes after Hour of Opening
10 CLOSING TIME FOR SCHEDULE 3
Seg 1 Hour of Closing Time (24-hr format)
Seg 2 Minutes after Hour of Closing
10 DAYS FOR SCHEDULE 3
8 = 8 AM
0
20 = 8 PM
0
1 = "On" if schedule is active on Sunday.
2 = "On" if schedule is active on Monday.
3 = "On" if schedule is active on Tuesday.
4 = "On" if schedule is active on Wednesday.
5 = “On” if schedule is active on Thursday.
6 = “On” if schedule is active on Friday.
7 = “On” if schedule is active on Saturday.
8 = “On” if schedule is disabled on holidays.
256
257
258
10 OPENING TIME FOR SCHEDULE 4
Seg 1 Hour of Opening Time (24-hr format)
Seg 2 Minutes after Hour of Opening
10 CLOSING TIME FOR SCHEDULE 4
Seg 1 Hour of Closing Time (24-hr format)
Seg 2 Minutes after Hour of Closing
10 DAYS FOR SCHEDULE 4
8 = 8 AM
0
20 = 8 PM
0
1 = "On" if schedule is active on Sunday.
2 = "On" if schedule is active on Monday.
3 = "On" if schedule is active on Tuesday.
4 = "On" if schedule is active on Wednesday.
5 = “On” if schedule is active on Thursday.
6 = “On” if schedule is active on Friday.
7 = “On” if schedule is active on Saturday.
8 = “On” if schedule is disabled on holidays.
259
260
261
10 OPENING TIME FOR SCHEDULE 5
Seg 1 Hour of Opening Time (24-hr format)
Seg 2 Minutes after Hour of Opening
10 CLOSING TIME FOR SCHEDULE 5
Seg 1 Hour of Closing Time (24-hr format)
Seg 2 Minutes after Hour of Closing
10 DAYS FOR SCHEDULE 5
8 = 8 AM
0
20 = 8 PM
0
1 = "On" if schedule is active on Sunday.
2 = "On" if schedule is active on Monday.
3 = "On" if schedule is active on Tuesday.
4 = "On" if schedule is active on Wednesday.
5 = “On” if schedule is active on Thursday.
6 = “On” if schedule is active on Friday.
7 = “On” if schedule is active on Saturday.
8 = “On” if schedule is disabled on holidays.
262
263
264
10 OPENING TIME FOR SCHEDULE 6
Seg 1 Hour of Opening Time (24-hr format)
Seg 2 Minutes after Hour of Opening
10 CLOSING TIME FOR SCHEDULE 6
Seg 1 Hour of Closing Time (24-hr format)
Seg 2 Minutes after Hour of Closing
10 D OAYS F R SCHEDULE 6
8 = 8 AM
0
20 = 8 PM
0
14
NX-1700E Card Reader
LOC PG DESCRIPTION DEFAULT YOUR DATA
1 = "On" if schedule is active on Sunday.
2 = "On" if schedule is active on Monday.
3 = "On" if schedule is active on Tuesday.
4 = "On" if schedule is active on Wednesday.
5 = “On” if schedule is active on Thursday.
6 = “On” if schedule is active on Friday.
7 = “On” if schedule is active on Saturday.
8 = “On” if schedule is disabled on holidays.
265
266
267
10 OPENING TIME FOR SCHEDULE 7
Seg 1 Hour of Opening Time (24-hr format)
Seg 2 Minutes after Hour of Opening
10 CLOSING TIME FOR SCHEDULE 7
Seg 1 Hour of Closing Time (24-hr format)
Seg 2 Minutes after Hour of Closing
10 DAYS FOR SCHEDULE 7
8 = 8 AM
0
20 = 8 PM
0
1 = "On" if schedule is active on Sunday.
2 = "On" if schedule is active on Monday.
3 = "On" if schedule is active on Tuesday.
4 = "On" if schedule is active on Wednesday.
5 = “On” if schedule is active on Thursday.
6 = “On” if schedule is active on Friday.
7 = “On” if schedule is active on Saturday.
8 = “On” if schedule is disabled on holidays.
268
269
270
10 OPENING TIME FOR SCHEDULE 8
Seg 1 Hour of Opening Time (24-hr format)
Seg 2 Minutes after Hour of Opening
10 CLOSING TIME FOR SCHEDULE 8
Seg 1 Hour of Closing Time (24-hr format)
Seg 2 Minutes after Hour of Closing
10 DAYS FOR SCHEDULE 8
8 = 8 AM
0
20 = 8 PM
0
1 = "On" if schedule is active on Sunday.
2 = "On" if schedule is active on Monday.
3 = "On" if schedule is active on Tuesday.
4 = "On" if schedule is active on Wednesday.
5 = “On” if schedule is active on Thursday.
6 = “On” if schedule is active on Friday.
7 = “On” if schedule is active on Saturday.
8 = “On” if schedule is disabled on holidays.
271
272
273
274
275
276
277
278
279
280
281
282
283
11 HOLIDAYS IN JANUARY (8 max)
11 HOLIDAYS IN FEBRUARY (8 max)
11 HOLIDAYS IN MARCH (8 max)
11 HOLIDAYS IN APRIL (8 max)
11 HOLIDAYS IN MAY (8 max)
11 HOLIDAYS IN JUNE (8 max)
11 HOLIDAYS IN JULY (8 max)
11 HOLIDAYS IN AUGUST (8 max)
11 HOLIDAYS IN SEPTEMBER (8 max)
11 HOLIDAYS IN OCTOBER (8 max)
11 HOLIDAYS IN NOVEMBER (8 max)
11 HOLIDAYS IN DECEMBER (8 max)
11 ACTIVATION DATA FOR USER CARDS 1 - 120
1 = User Cards 1 – 8
2 = User Cards 9 – 16
3 = User Cards 17 – 24
4 = User Cards 25 – 32
5 = User Cards 33 – 40
6 = User Cards 41 – 48
7 = User Cards 49 – 56
9 = User Cards 65 – 72
10 = User Cards 73 – 80
11 = User Cards 81 – 88
12 = User Cards 89 – 96
13 = User Cards 97 – 104
14 = User Cards 105 – 112
15 = User Cards 113 - 120
holidays
No
No holidays
holidays
No
holidays
No
holidays
No
holidays
No
holidays
No
holidays
No
holidays
No
holidays
No
holidays
No
holidays
No
LED1 = Card 1
LED2 = Card 2
LED3 = Card 3
LED4 = Card 4
LED5 = Card 5
LED6 = Card 6
LED7 = Card 7
LED8 = Card 8
_ _ _ _ _ _ _ _
_ _ _ _ _ _ _ _
_ _ _ _ _ _ _ _
_ _ _ _ _ _ _ _
_ _ _ _ _ _ _ _
_ _ _ _ _ _ _ _
_ _ _ _ _ _ _ _
_ _ _ _ _ _ _ _
_ _ _ _ _ _ _ _
_ _ _ _ _ _ _ _
_ _ _ _ _ _ _ _
_ _ _ _ _ _ _ _
8 = User Cards 57 – 64
284
11 ACTIVATION DATA FOR USER CARDS 121 - 240
User Cards 185 – 192 1 = User Cards 121 – 128
9 =
10 = User Cards 193 – 200 2 = User Cards 129 – 136
11 = User Cards 201 – 208 3 = User Cards 137 – 144
4 = User Cards 145 – 152
5 = User Cards 153 – 160
6 = User Cards 161 – 168
7 = User Cards 169 – 176
12 = User Cards 209 – 216
13 = User Cards 217 – 224
14 = User Cards 225 – 232
15 = User Cards 233 – 240
8 = User Cards 177 – 184
NX-1700E Card Reader
15
LOC PG DESCRIPTION DEFAULT YOUR DATA
285
11 CODE ENTRY LOGGING PARTITION
0
16
NX-1700E Card Reader
IX. GLOSSARY
TERM DESCRIPTION
Alternative Mode Alternative mode is an optional scan method, as opposed to the default Legacy mode (see below).
The card is to be continuously held at the reader for a specified number of beeps. Example: Hold
the card at the card reader’s sensor for a total of 2 beeps. This is a “double beep” in the Alternative
mode. This method becomes available when Location 272, Segment 1, Option 6 is disabled.
Double
Beep……………….
Double Beep Scan……….. When a user card is scanned and held at the reader for 2 beeps, the reader will perform the functions
Legacy Mode……………… Legacy mode is used to describe the default operation of the card reader’s scanning method. This
Request To Exit
(RTE)……
Scan………………………. To “present” or pass a card or FOB within sensing range of the card reader module.
Single Beep……………….. An audible indicator (beep).
Single Beep Scan………… When a user card is scanned and held at the reader for 1 beep, the reader will perform the functions
Triple Beep………………... An audible indicator (beep, beep, beep).
Triple Beep Scan…………. When a user card is scanned and held at the reader for 3 beeps, the reader will perform the functions
An audible indicator (beep, beep).
as programmed in Location 241, Segment 4.
mode uses the same scan methods as prior versions of the card reader modules. Example
user card by the reader’s sensor, remove it from the field, then pass the card by the reader’s sensor
once again during the time programmed in Location 244, Segment 1. This is a “double scan” in the
legacy mode.
A zone can be programmed to monitor an open door. The RTE activates the onboard open collector
output and sends a message on the buss.
as programmed in Location 241, Segment 3.
as programmed in Location 241, Segment 5.
: Pass a
X. FCC INFORMATION
This device complies with Part 15 of the FCC rules. Operation is subject to the following three conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause undesired operation.
3. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
FCC ID: CGGNX-1700E
XI. UNDERWRITERS LABORATORIES INFORMATION
The NX-1700E module has received UL listing: UL294 Access Control Systems Units
XII. SPECIFICATIONS
DIMENSIONS Approx. 1.5"W x 4.5"L x 1"D with 6’ cable
OPERATING POWER 12 VDC, Supplied by NX-6, NX-8, NX-8E, or NX-320E
CURRENT DRAW 40mA Standby with Green LED
110mA Maximum
OPERATING TEMPERATURE -31 to +151 degrees F
5 to +66 degrees C
SHIPPING WEIGHT < 1 lb.
1420 N. MAIN STREET; GLADEWATER, TEXAS 75647
Main 800-727-2339 Technical Support 888-437-3287
Outside the US 903-845-6941 Sales & Literature 800-547-2556
NX-1700E Card Reader
17
Revision B (Mar 2012)
Main Fax 903-845-6811 www.utcfireandsecurity.com
Loading...
