Intel® Server Control Installation Guide For the
HP cc2300 & cc3300 Carrier Grade Servers
Document Release Date: March 2003
Legal Information
Intel® Server Control
System Requirements Overview
Service Partition
Enabling LAN Events
Installing Intel® Server Control (ISC)
Launching Intel Server Control (ISC)
HP Carrier Grade Server Functionality Matrix
Intel Server Control Installation Guide
Legal Information
Hewlett-Packard Corporation (HP) makes no warranty of any kind with regard to this material, including, but not limited to,
the implied warranties of merchantability and fitness for a particular purpose.
HP assumes no responsibility for any errors that may appear in this document.
HP makes no commitment to update nor to keep current the information contained in this document.
No part of this document may be copied or reproduced in any form or by any means without prior written consent of HP.
®
An HP
product, when used in accordance with its associated documentation, is "Year 2000 Capable" when, upon
installation, it accurately stores, displays, processes, provides, and/or receives date data from, into, and between the
twentieth and twenty-first centuries, including leap year calculations, provided that all other technology used in combination
with said product properly exchanges date data with it.
Nothing in this document constitutes a guarantee, warranty, or license, express or implied.
HP disclaims all liability for all such guaranties, warranties, and licenses, including but not limited to: fitness for particular
purpose; merchantability; not infringement of intellectual property or other rights of any third party or of HP; indemnity; and
all others.
The reader is advised that third parties may have intellectual property rights that may be relevant to this document and the
technologies discussed herein, and is advised to seek the advice of competent legal counsel, without obligation to HP.
The Intel
deviate from published specifications. Currently characterized errata are available on request.
Intel, Pentium and LANDesk are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United
States and other countries.
†
®
Server Control product may contain design defects or errors known as errata that may cause the product to
Other names and brands may be claimed as the property of others.
Copyright 2002 Hewlett-Packard Corporation.
2
Intel Server Control Installation Guide
Contents
Intel® Server Control .......................................................................................... 4
System Requirements Overview........................................................................ 4
Windows 2000 Requirements........................................................................................4
Red Hat Linux 7.1 Requirements...................................................................................5
Additional Requirements for DMI-SNMP Translation.....................................................5
Console Requirements Overview............................................................................................5
Windows 2000 Console Requirements..........................................................................5
Service Partition.................................................................................................. 6
Service Partition Installation....................................................................................................6
Requirements.................................................................................................................6
Installation......................................................................................................................6
Boot the Server from the Service Partition..............................................................................7
Locally Booting the Server from the Service Partition....................................................8
Remotely Booting the Server from the Service Partition................................................8
Configuring the Server for EMP Access.........................................................................8
Configuring the Server for LAN Access .........................................................................9
Using the Direct Platform Control (DPC) Console .......................................................11
Using the Client System Setup Utility (CSSU) .............................................................11
Enabling LAN Events........................................................................................ 11
Installing Intel® Server Control (ISC).............................................................. 12
Managed Server Preparation................................................................................................12
Compatibility and Upgrade Issues ........................................................................................12
Linux Red Hat ..............................................................................................................12
LANDesk® Server Manager (LDSM)...........................................................................12
Windows 2000 Advanced Server.................................................................................13
ISC Installation Procedure for Windows 2000 Advanced Server..........................................13
ISC Installation Procedure for Linux Red Hat 7.1 and Red Hat Enterprise Linux AS 2.1 .....14
Installing Linux DMI Service Provider ..........................................................................14
Installing ISC Server Instrumentation...........................................................................15
Configuring the SNMP–DMI Mapper............................................................................16
Launching Intel Server Control (ISC) .............................................................. 16
Intel Server Control H-P Network Node Manager.................................................................17
LANDesk Server Manager....................................................................................................17
CA-Unicenter TNG................................................................................................................17
ISC Console..........................................................................................................................17
HP Carrier Grade Server Functionality Matrix................................................ 18
3
Intel Server Control Installation Guide
Intel® Server Control
This guide explains how to install and launch the Intel® Server Control (ISC) software. ISC is a
server management tool that provides real time monitoring and alerting for server hardware,
emergency remote management and remote server setup.
ISC is implemented using a client-server architecture and has been developed for the HP Carrier
Grade cc2300 and cc3300 servers. Servers can be managed by the client through a LAN, a direct
RS-232 serial connection or a RS-232 connection through a modem.
The Direct Platform Control (DPC) component of ISC accesses system log and sensor information
through the Baseboard Management Controller (BMC) independent of the cc2300 or cc3300
operating system. The server needs to be powered up for DPC access through LAN or RS-232.
The Platform Instrumentation Control (PIC) accesses system log and sensor information online by
utiltizing the cc2300 or cc3300 operating system. The server’s operating system needs to be booted
to run PIC. PIC is accessed through LAN or RS-232.
System Requirements Overview
ISC contains two parts:
• ISC Console Software
• ISC Server Instrumentation Software
The ISC console software is installed on a client. The ISC server instrumentation software is
installed on the HP Carrier Grade cc2300/cc3300 Servers.
ISC Console Software allows interaction with the managed server. It can be installed on these
system (client) configurations:
• Windows NT 4.0 server, Enterprise Edition, Service Pack 6a
• Windows NT Workstation, Service Pack 6a
• Windows 2000 Advanced Server, Service Pack 2
• Windows 2000 Professional, Service Pack 2
ISC Server Instrumentation Software, when installed on the cc2300 or cc3300 servers, creates a
managed server that can be managed from the system (client) running ISC Console Software. ISC
is supported on:
• Windows 2000 Server (Service Pack 2).
• Linux RedHat 7.1
Windows 2000 Requirements
• Windows 2000 Advanced Server (Service Pack 2)
• 64 MB of RAM
• 60 MB of available disk space
• SNMP service installed (required only for connectivity to an SNMP management console)
4
Intel Server Control Installation Guide
Red Hat Linux 7.1 Requirements
If you intend to manage a Linux file server, it must meet the following minimum requirements:
• Linux Red Hat 7.1 or Red Hat Enterprise Linux AS 2.1 operating system running multipleprocessor kernel
• 32 MB of RAM
• 60 MB of available disk space
Additional Requirements for DMI-SNMP Translation
Simple Network Management Protocol (SNMP) support must be installed if you want to integrate
ISC with an SNMP-based management framework. On the managed server, you should consider
the following issues when configuring SNMP:
• Community string names for SNMP Get and Set operations
• Community string names for sending traps
• The destination address for the management console receiving the traps
On the management console, you should consider the following issues when configuring SNMP:
• Compiling the MIBs into the SNMP management consoles
• Integration of ISC traps into SNMP management consoles
Console Requirements Overview
ISC Console Software can integrate into an Enterprise System Management Console or it can be
installed on a stand-alone console. The supported Enterprise System Management Consoles are:
1. H-P OpenView
2. Intel
®
LANDesk® Server Manager 6.1
1. CA UnicenterTNG
Console System requirements may be different when using one of the supported management
applications. Please refer to their installation requirements for additional information.
You can use the ISC stand-alone console to manage ISC-enabled servers without Enterprise System
Management. The ISC Console is implemented as an ActiveX
container or a third party container application (e.g., Microsoft Management Console, Internet
†
Explorer
v5.6, or Netscape Navigator† v6.0 with ActiveX plug-in).
• Windows 2000 Advanced Server
®
• Intel
Pentium® microprocessor or higher
• At least 64 MB of RAM
• At least 10 MB of available disk space
• Microsoft Windows-compatible modem must be used if you connect to the server by modem
†
Network Node Manager 6.1 for Windows NT
†
2.4 for Windows NT
†
Windows 2000 Console Requirements
control that runs within its own
5
Intel Server Control Installation Guide
Service Partition
The service partition is a special hard disk partition. The service partition has been installed on the
HP Carrier Grade cc2300 and cc3300 Servers. The service partition size is 40Mbytes.
The service partition contains utilities and other software required for remote management. The
service partition is not marked as an active partition and the server will only boot from it by a
special request. It is not normally visible to the server user because it has a special non-standard
partition type that does not appear as an accessible file system to the end user operating system.
However, low-level disk utilities may see the partition entry as an EISA partition, and recognize its
space.
The utilities on the service partition can be run locally or remotely. In order to run the utilities the
server must boot from the service partition. Remote execution is available from the Direct Platform
Control (DPC) Console Manager and the Client System Setup Utility (CSSU).
Service Partition Installation
It is recommended that you install the service partition:
• On a clean hard drive with no partitions defined.
• Before installing any operating system.
The service partition should not be installed if the operating system has already been loaded. The
operating system may not boot if the service partition is installed after operating system installation.
Some hard drives may have free entries in the partition table with 40MB of available space.
Utilizing the freeentry is not recommended. .
Requirements
• The service partition can be on any of the first 4 BIOS-supported physical hard drives.
• Service partition hard drives must support BIOS 22.
• Current BIOS must be installed.
• Remove old service partitions and create the new service partition with a current HP Server
cc3300 & cc2300 User Information, Diagnostics & Utilities Resource CD .
• At least 40 MB of unused (not partitioned) hard drive space is required. On large hard drives
this unused space must be within the first 8 GB.
NOTE
There are commercial utilities that can resize existing partitions to free space
if more is needed. Alternately, you can add a low capacity hard drive for the
service partition.
This procedure is for installing the service partition on unpartitioned hard drive only.
6
Installation
