CB60-BX/ZX

Rev. A+

System Board

User’s Manual

37400849

Copyright

This publication contains information that is protected by copyright. No part of it may be reproduced in any form or by any means or used to make any transformation/adaptation without the prior written permission from the copyright holders.

This publication is provided for informational purposes only. The manufacturer makes no representations or warranties with respect to the contents or use of this manual and specifically disclaims any express or implied warranties of merchantability or fitness for any particular purpose. The user will assume the entire risk of the use or the results of the use of this document. Further,the manufacturer reserves the right to revise this publication and make changes to its contents at any time, without obligation to notify any person or entity of such revisions or changes.

All Rights Reserved. © 1998

Trademarks

Microsoft® MS-DOS®, WindowsTM and Windows® 95 are registered trademarks of Microsoft Corporation. Intel®,Pentium® II and CeleronTM are registered trademarks of Intel Corporation. Award is a registered trademark of Award Software, Inc. Other trademarks and registered trademarks of products appearing in this manual are the properties of their respective holders.

Caution:

Danger of explosion if battery incorrectly replaced.

Replace only with the same or equivalent type recommended by the manufacturer.

Dispose of used batteries according to the battery manufacturer’s instructions.

FCC and DOC Statement on Class B

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and the receiver.

Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

Consult the dealer or an experienced radio TV technician for help.

Notice:

1.The changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

2.Shielded interface cables must be used in order to comply with the emission limits.

Table of Contents

Chapter 1 - Introduction

1.1

Features and Specifications..................................................................................

6

1.2

Package Checklist.........................................................................................................

10

Chapter 2 - Hardware Installation



2.1

System Board Layout .............................................................................................

11

2.2

System Memory.............................................................................................................

13

2.3

DIP Switch Settings for Processors............................................................

13

2.4

Jumper Settings for the CPU’s Front Side Bus................................

14

2.5

Jumper Settings for Clearing CMOS Data..........................................

15

2.6

Jumper Settings for Wake-On-Keyboard/Wake-On-Mouse......

16

2.7

Connecting the Ribbon Cables and Wires of the Ports





and Connectors.............................................................................................................

17

Chapter 3 - Award BIOS Setup Utility



3.1

The Basic Input/Output System.....................................................................

27



3.1.1

Standard CMOS Setup....................................................................

27



3.1.2

BIOS Features Setup..........................................................................

30



3.1.3

Chipset Features Setup....................................................................

33



3.1.4

Power Management Setup............................................................

37



3.1.5

PNP/PCI Configuration....................................................................

42



3.1.6

Load Fail-Safe Settings......................................................................

43



3.1.7

Load Optimal Settings......................................................................

44



3.1.8

Integrated Peripherals.........................................................................

44



3.1.9

Supervisor Password..........................................................................

48



3.1.10

User Password.........................................................................................

49



3.1.11

IDE HDD Auto Detection...........................................................

49



3.1.12

Save & Exit Setup.................................................................................

50



3.1.13

Exit Without Saving..............................................................................

50

Chapter 4 - Supported Softwares

4.1

Desktop Management Interface.....................................................................

51

4.2

Hardware Doctor Utility........................................................................................

54

4.3

Patch Utility for Windows 95...........................................................................

56

Appendix A - System Error Messages

A.1

POST Beep.......................................................................................................................

57

A.2

Error Messages..............................................................................................................

57

Appendix B - Troubleshooting



B.1

Troubleshooting Checklist....................................................................................

59

Chapter 1 - Introduction

1.1 Features and Specifications

1.1.1 Features

Chipset

Intelâ 440BX AGPset (CB60-BX)

Intelâ 440ZX AGPset (CB60-ZX)

Processor

The system board is equipped with Intel® Socket 370 for installing an Intel CeleronTM PPGA processor. The system board is also equipped with a switching voltage regulator that supports 1.30V to 2.05V core voltage for various processors.

300A/333/366/400/433MHz and future 100MHz FSB CeleronTM PPGA processor

System Memory

CB60-BX

-8MB to 384MB memory using unbuffered DIMMs

-32MB to 768MB memory using registered DIMMs

-Three 168-pin DIMM sockets

-Uses x64 or x72 PC SDRAM, 3.3V

:PC-66 SDRAM DIMM for 66MHz FSB processors

:PC-100 SDRAM DIMM for 100MHz FSB processors

-ECC supported (uses x72 PC SDRAM DIMM)

CB60-ZX

-8MB to 256MB memory using unbuffered DIMMs

-Two 168-pin DIMM sockets

-Uses x64 PC SDRAM, 3.3V

:PC-66 SDRAM DIMM for 66MHz FSB processors

:PC-100 SDRAM DIMM for 100MHz FSB processors

6



































































































































































Introduction



1



















































































































































































































































































































































DIMMs

Memory Size

1MBx64/x72

8MB

2MBx64/x72

16MB

4MBx64/x72

32MB

8MBx64/x72

64MB

16MBx64/x72

128MB

32MBx64/x72

256MB*

DIMMs

Memory Size

1MBx64

8MB

2MBx64

16MB

4MBx64

32MB

8MBx64

64MB

16MBx64

128MB

CB60-BX

CB60-ZX

*Supported only when CB60-BX uses registered DIMMs.

Expansion Slots

The system board is equipped with 1 dedicated AGP slot, 3 dedicated PCI slots, 2 dedicated 16-bit ISA slot and 1 shared PCI/ ISA slot. All PCI and ISA slots are bus masters.

Desktop Management Interface (DMI)

The system board comes with a DMI 2.0 built into the BIOS. The DMI utility in the BIOS automatically records various information about your system configuration and stores these information in the DMI pool, which is a part of the system board's Plug and Play BIOS. DMI, along with the appropriately networked software, is designed to make inventory, maintenance and troubleshooting of computer systems easier. Refer to Chapter 4 for instructions on using the DMI utility.

ATX double deck ports

2 USB ports

2 DB-9 serial ports

1 DB-25 parallel port

1 mini-DIN-6 PS/2 keyboard port

1 mini-DIN-6 PS/2 mouse port

Connectors

1 connector for IrDA interface

2 IDE connectors

1 floppy connector

1 20-pin ATX power supply connector

1 1 3-pin WOL (Wake-On-LAN) connector

1 SB-LINK connector

3 fan connectors for CPU, chassis and AGP fans

7

1Introduction

PCI Bus Master IDE Controller

Two PCI IDE interfaces support up to four IDE devices

Ultra DMA/33 supported (Synchronous Ultra DMA mode - data transfer rate up to a maximum of 33MB/sec.)

PIO Mode 3 and Mode 4 Enhanced IDE (data transfer rate up to 16.6MB/sec.)

Bus mastering reduces CPU utilization during disk transfer

ATAPI CD-ROM, LS-120 and ZIP supported

IrDA Interface

The system board is equipped with an IrDA connector for wireless connectivity between your computer and peripheral devices. It supports peripheral devices that meet the IrDA or ASK IR standard.

USB Ports

The system board is equipped with two USB ports. USB allows data exchange between your computer and a wide range of simultaneously accessible external Plug and Play peripherals.

BIOS

• Award BIOS, Windowsâ 95 Plug and Play compatible

Flash EPROM for easy BIOS upgrades

1.1.2System Health Monitor Functions

The system board is capable of monitoring the following “system health” conditions.

Monitors processor/system temperature and processor overheat alarm

Monitors 1.5V/3.3V/±5V/±12V/VCORE voltages and failure alarm

Monitors processor/chassis fan speed and failure alarm

Automatic processor/chassis fan control

Read back capability that displays accurate temperature, voltage and fan speed

8



































































































































































Introduction



1



















































































































































































































































































































































1.1.3 Intelligence

Automatic CPU/Chassis Fan Off

The CPU and chassis fans will automatically turn off once the system enters the Suspend mode.

Dual Function Power Button

Depending on the setting in the BIOS setup, this switch will allow the system to enter the Soft-Off or Suspend mode.

External Modem Ring-on

The Modem Ring-on feature allows the system that is in the Suspend mode or Soft Power Off mode to wake-up/power-on to respond to incoming calls.

Note:

This feature supports external modem only.

RTC Timer to Power-on the System

The RTC installed on the system board allows your system to automatically power-on on the set date and time.

Wake-On-LAN Ready

The Wake-On-LAN function allows the network to remotely wake up a Soft Power Down (Soft-Off) PC.Your LAN card must support the remote wakeup function.

Important:

The 5VSB power source of your power supply must support ³720mA (minimum).

Wake-On-Keyboard/Wake-On-Mouse

This function allows you to use the keyboard or mouse to power-on the system. Refer to “Jumper Settings for Wake-On-Keyboard/Wake- On-Mouse” in Chapter 2 and “Keyboard/Mouse Power On” in the Integrated Peripherals setup of the Award BIOS in Chapter 3 for more information.

9

1Introduction

Important:

The power button will not function once a keyboard password has been set in the “KB Power On Password” field of the Integrated Peripherals setup. You must type the correct password to power-on the system.

The 5VSB power source of your power supply must support ³720mA (minimum).

ACPI

The system board is designed to meet the ACPI (Advanced Configuration and Power Interface) specification. ACPI has energy saving features that enables PCs to implement Power Management and Plug-and-Play with operating systems that support OS Direct Power Management.

Virus Protection

Most viruses today destroy data stored in hard drives. The system board is designed to protect the boot sector and partition table of your hard disk drive.

1.2 Package Checklist

The system board package contains the following items:

þThe system board

þA user’s manual

þOne 40-pin IDE hard disk cable

þOne 34-pin floppy disk drive cable

þOne CD

If any of these items are missing or damaged, please contact your dealer or sales representative for assistance.

10

Chapter 2 - Hardware Installation

2.1 System Board Layout

CB60-BX

11

2Hardware Installation

CB60-ZX

Note:

The illustrations on the following pages are based on the CB60-BX system board, which is the board equipped with three DIMM sockets.

12



































































































































Hardware Installation



2



















































































































































































































































































2.2 System Memory

CB60-BX is equipped with three DIMM sockets and CB60-ZX is equipped with two DIMM sockets.

2.3 DIP Switch Settings for Processors (For Factory Use Only)

The table on the next page shows the supported processors and their corresponding DIP switch settings (SW1).There are 4 switches on SW1.The black rectangle in the diagram denotes the part that is protruding, the “adjustable” switch. Make sure SW1 is set correctly before applying power, otherwise you will not be able to power-on the system.

In the example above:

Switch 1: Off

Switch 2: On

Switch 3: Off

Switch 4: On

13

2Hardware Installation

Processor

Frequency

SW1

Processor

Frequency

SW1

66MHz

100MHz

Ratio



66MHz

100MHz

Ratio



300MHz

Future

4.5x

433MHz

Future

6.5x



processor





processor

333MHz

Future

5x

Future

Future

7x

processor

processor

processor







366MHz

Future

5.5x

Future

Future

7.5x

processor

processor

processor



400MHz

Future

6x

Future

Future

8x

processor

processor

processor







Note:

1. Intel CeleronTM processors support VID (Voltage Identification). The switching voltage regulator on the system board will automatically set the voltage regulator according to the voltage of the processor.

2. You cannot overclock an Intel CeleronTM processor because its frequency ratio is fixed by the manufacturer. The table above is for factory use only.

2.4 Jumper Settings for the CPU’s Front Side Bus

Jumper JP2

CPU’s Front Side Bus Select

The default setting of jumper JP2 is Auto - the system will automatically run according to the FSB of the processor. The “100MHz” setting (1-2-3 Off) is reserved for future 100MHz FSB processors. Refer to the figure on the next page.

Warning:

If your system is installed with a 66MHz FSB processor, do not move the jumper cap from its default setting which is pins 1 and 2 On; otherwise your system will not boot.

14



































































































































Hardware Installation



2



















































































































































































































































































Jumper JP2’s settings are shown below.

1

1

1

2

2

2

3

3

3

1-2 On: Auto

2-3 On: 66MHz

1-2-3 Off: 100MHz

(default)





2.5 Jumper Settings for Clearing CMOS Data

Jumper JP3

Clear CMOS Data

If, for some reason, the CMOS data becomes corrupted or you forgot the super visor/user/keyboard password, the system can be reconfigured with the default values stored in the ROM BIOS. To load the default values, power off your system and unplug the power cord. Set JP3 pins 2 and 3 to On. Wait for a few seconds and set JP3 back to its default setting, pins 1 and 2 On. You may now plug the power cord and power-on your system.

1

2

3

1

2

3

1-2 On: Normal

2-3 On:

(default)

Clear CMOS Data

15

2Hardware Installation

2.6Jumper Settings for Wake-On-Keyboard/ Wake-On-Mouse

Jumper JP1

Wake-On-Keyboard/Wake-On-Mouse

The system board supports the Wake- On-Keyboard/Wake-On-Mouse function. This function allows you to use the keyboard or mouse to power-on the system. By default, JP1 is disabled. To use this function, set JP1 to 2-3 On. “Keyboard/Mouse Power On” in the Integrated Peripherals setup of the Award BIOS must be set accordingly. Refer to chapter 3 for details.

Warning:

1. If JP1 was previously enabled with a password set in the

“KB Power On Password” field, and now you wish to disable the Wake-On-Keyboard (password) function, make sure to set the “Keyboard/Mouse Power On” field to Disabled prior to setting JP1 to disabled. You will not be able to boot up the system if you fail to do so.

2.The power button will not function once a keyboard password has been set in the “KB Power On Password” field of the Integrated Peripherals setup. You must type the correct password to power-on the system.

3.The 5VSB power source of your power supply must support ³720mA (minimum).

1 2 3 1 2 3





































1-2 On: Disable

2-3 On: Enable



(default)











16



































































































































Hardware Installation



2



















































































































































































































































































2.7Connecting the Ribbon Cables and Wires of the Ports and Connectors

2.7.1 Serial Ports

The built-in serial ports are RS-232C asynchronous communication ports with 16C550A-compatible UARTs that can be used with modems, serial printers, remote display terminals, and other serial devices. You can set the serial ports’ I/O address in the Integrated Peripherals setup of the Award BIOS.

2.7.2 PS/2 Mouse and Keyboard Ports

The PS/2 mouse port uses IRQ12. If a mouse is not connected to this port, the system will reserve IRQ12 for other expansion cards.

Warning:

Make sure to turn off your computer prior to connecting or disconnecting a mouse or keyboard. Failure to do so may damage the system board.

17

2Hardware Installation

2.7.3 Parallel Ports

The system board has a standard printer port for interfacing your PC to a parallel printer. It supports SPP, ECP and EPP modes. You can set the port’s mode in the Integrated Peripherals setup of the Award BIOS.

2.7.4Floppy Disk Controller

1.Install the 34-pin header connector into the shrouded floppy disk header (J4) on the system board. The colored edge of the ribbon should be aligned with pin 1 of J4.

2.Install the other 34-pin header connector(s) into the disk drive(s). Align the colored edge of the daisy chained ribbon cable with pin

1 of the drive edge connector(s). The end-most connector should be attached to the drive you want to designate as Drive A.

18





Hardware Installation

2

2.7.5

IDE Hard Disk Interface



1.

If you are connecting two hard





drives, install the 40-pin connector





of the IDE cable into the primary





shrouded IDE header (connector





J10). If you are adding a third or





fourth IDE device, install the 40-





pin connector of the other IDE





cable into

the secondar y





shrouded IDE

header (connector





J9).





2.

Install the other 40-pin header





connector(s) into the device with





the colored edge of the ribbon





cable aligned with pin 1 of the drive edge connector(s).



Note:

Refer to your disk drive user’s manual for information about selecting proper drive switch settings.

Adding a Second IDE Hard Drive

When using two IDE drives, one must be set as the master and the other as the slave. Follow the instructions provided by the drive manufacturer for setting the jumpers and/or switches on the drives.

We recommend that you use Enhanced IDE or ATA-2, ATA-3 and Ultra DMA hard drives be from the same manufacturer. In a few cases, drives from two different manufacturers will not function properly when used together. The problem lies in the hard drives, not the system board.

Important:

If you encountered problems while using an ATAPI CD-ROM drive that is set in Master mode, please set the CD-ROM drive to Slave mode. Some ATAPI CD-ROMs may not be recognized and cannot be used if incorrectly set in Master mode.

19

2Hardware Installation

2.7.6 USB Ports

You must have the proper drivers installed in your operating system to use these ports. Refer to your operating system’s manual or documentation.

2.7.7 IrDA Connector

The system board is equipped with an IrDA connector for wireless connectivity between your computer and peripheral devices. The IRDA (Infrared Data Association) specification supports data transfers of 115K baud at a distance of 1 meter.

Connect your IrDA cable to connector J12 on the system board. Set “UART2 Mode Select” in the Integrated Peripherals setup of the Award BIOS to the type of IrDA standard supported by your device. You must have the proper drivers installed in your operating system to use this connector. Refer to your operating system’s manual or documentation.







































Pin

Function





































































1

IRTX











































































































































































2

Ground









































































































































3

IRRX



































4

N. C.







































































































5

VCC





































































































































































































































































































































































































































































































































20



Hardware Installation

2

2.7.8 CPU Fan Connector



The processor must be kept cool by using a fan with heatsink.



Connect the CPU fan to the 3-pin fan connector at location J5 on



the system board.



Pin

Function



1

On/Off



2

+12V



3

Sense



2.7.9 Chassis Fan Connector

The system board is equipped with a chassis fan connector. If you are installing a fan in the system unit, connect the fan’s connector to location J2 on the system board. The fan will provide adequate airflow throughout the chassis to prevent overheating the processor.









































































































































































































































































































































































Pin

Function













































































































1

On/Off





















































2

+12V



















































































3

Sense































































































































































































































































21

2Hardware Installation

2.7.10 AGP Fan Connector

The system board is equipped with an AGP fan connector. If the system board is installed with an AGP add-in card and you wish to install a fan on the add-in card, connect the fan’s connector to location J11 on the system board. Refer to the add-in card’s manual for instructions on installing the fan.







































Pin

Function



































1

Ground

















































































































































2

+12V













































































































































3

N. C.

























































































































































































































































































































































































































































































































































































































2.7.11 SB-LINK™ Connector

If the system board is installed with a Creative sound card that requires connecting the card to the SB-LINK™ connector, connect the cable that came with the sound card to connector J13. Refer to the sound card’s manual for more information.

Pin

Function

















































































































1

PC-PCI-GNTx









































































2

DGND





















































































































































































3

Key

















































































































4

PC-PCI-REQx





































5

DGND





















































































































































6

SERIRQ





















































































































































































































































































































































































































































































22



































































































































Hardware Installation



2



















































































































































































































































































2.7.12 Wake-On-LAN Connector

The system board supports the Wake-On-LAN function.This function will allow the network to remotely power-on a Soft Power Down (Soft-Off) PC. However, if your system is in the Suspend mode, you can power-on the system only through an IRQ or DMA interrupt.

To use the Wake-On-LAN function, you must enable the “Resume on LAN” field in the Power Management Setup of the Award BIOS. Your LAN card package should include a cable. Connect one end of the cable to the wakeup header on the card and the other end to location J15 on the system board. The network will detect Magic Packet and assert a wakeup signal to power-up the system. Refer to the add-in card’s manual for details. Note: Your LAN card must support the remote wake up function.



























































































Pin

Function













































































































1

+5VSB (720mA)









































































































2

Ground



















































































3

WOL





























































































































































































































































































































































































































Important:

The 5VSB power source of your power supply must support ³720mA (minimum).

23

2Hardware Installation 2.7.13 Power Connector

PS1

The pin assignment of the ATX power connector is shown below.

Pin

Function

Pin

Function











1

3.3V/14A

11

3.3V/14A

2

3.3V/14A

12

-12V

3

COM

13

COM











4

+5V

14

PS-ON

5

COM

15

COM

6

+5V

16

COM

7

COM

17

COM











8

PW-OK

18

-5V

9

5VSB

19

+5V

10

+12V

20

+5V











Important:

Your power supply must meet the ATX specification - supporting 3.3V/14A (minimum), otherwise your system will not boot properly.

24



































































































































Hardware Installation



2



















































































































































































































































































2.7.14 J14 (LEDs and Switches)

HD-LED: Primary/Secondary IDE LED

This LED will light when the hard drive is being accessed.

G-LED: Green LED

This LED will light when the system is in the Suspend mode.

ATX-SW: ATX Power Switch

Depending on the setting in the BIOS setup, this switch is a “dual function power button” that will allow your system to enter the SoftOff or Suspend mode. Refer to “Soft-Off By PWR-BTTN” in the Power Management Setup (Chapter 3).

G-SW: Green Switch

This switch will allow your system to enter the Suspend mode.

RESET: Reset Switch

This switch allows you to reboot without having to power off the system thus prolonging the life of the power supply or system.

SPEAKER: Speaker Connector

This connects to the speaker installed in the system chassis.

25

2Hardware Installation

KEYLOCK: Power/Standby LED and Keylock Connector

Use pins 21-23 to connect to the Power/Standby LED. This LED will light when the system’s power is on and blinks when the system enters the Suspend mode.

Use pins 24 to 25 to connect to the keyboard lock (located on the front panel of the system chassis) for locking the keyboard.



Pin

Pin Assignment

HD-LED

1

HDD LED Power

(Primary/Secondary IDE LED)

2

HDD









3

N. C.

G-LED

4

Green LED Power

(Green LED)

5

Green









6

N. C.

ATX-SW

7

PWRBT

(ATX power switch)

8

Ground



9

N. C.

G-SW

10

SMI

(Green switch)

11

Ground









12

N. C.

RESET

13

H/W Reset

(Reset switch)

14

Ground









15

N. C.

SPEAKER

16

Speaker Data

(Speaker connector)

17

N. C.



18

Ground



19

Speaker Power



20

N. C.

KEYLOCK

21

LED Power

(Keylock and Power LED

22

N.C.

connector)

23

Standby Signal



24

Keylock



25

Ground





Use pins 21 to 23





for the Power/





Standby LED.







26

Chapter 3 - Award BIOS Setup Utility

3.1 The Basic Input/Output System

The Basic Input/Output System (BIOS) is a program that takes care of the basic level of communication between the processor and peripherals. In addition, the BIOS also contain codes for various advanced features found in this system board.This chapter explains the Setup Utility for the Award BIOS.

After you power up your system, the BIOS message appears on your screen and the memory count begins. After the memory test, the following message will appear on the screen:

Press DEL to enter setup

If the message disappears before you respond, restart your system or press the “Reset” button.You may also restart the system by pressing the <Ctrl> <Alt> and <Del> keys simultaneously.

When you press <Del>, the main program screen will appear.

ROM PCI/ISA BIOS

CMOS SETUP UTILITY

AWARD SOFTWARE, INC.



















STANDARD CMOS SETUP

INTEGRATED PERIPHERALS





BIOS FEATURES SETUP

SUPERVISOR PASSWORD





CHIPSET FEATURES SETUP

USER PASSWORD





POWER MANAGEMENT SETUP

IDE HDD AUTO DETECTION





PNP/PCI CONFIGURATION

SAVE & EXIT SETUP





LOAD FAIL-SAFE SETTINGS

EXIT WITHOUT SAVING





LOAD OPTIMAL SETTINGS



























Esc

:

Quit

−↓→←

:

Select Item





F10

:

Save & Exit Setup

(Shift) F2

:

Change Color



















































3.1.1 Standard CMOS Setup

Use the arrow keys to highlight “Standard CMOS Setup” and press <Enter>. A screen similar to the one on the next page will appear.

27

3Award BIOS Setup Utility

ROM PCI/ISA BIOS

STANDARD CMOS SETUP

AWARD SOFTWARE, INC.

Date (mm:dd:yy) : Mon, Oct 12 1998

Time (hh:mm:ss) : 13: 27: 50

HARD DISKS



TYPE SIZE

CYLS

HEAD

PRECOMP LANDZ

SECTOR

MODE

Primary Master

:

Auto

0

0

0

0

0

0

Auto



Primary Slave

:

Auto

0

0

0

0

0

0

Auto

Secondary Master :

Auto

0

0

0

0

0

0

Auto

Secondary Slave

:

Auto

0

0

0

0

0

0

Auto

Drive A : 1.44M, 3.5 in.















Drive B : None









Base Memory :

640K













Extended Memory : 64512K

Video



: EGA/VGA









Other Memory :

384K

Halt on



: All Errors









Total Memory : 65536K





















Esc

:

Quit

−↓→←

:

Select Item

PU/PD/+/- : Modify





F10

:

Save & Exit Setup

(Shift)F2

:

Change









The settings on the screen are for reference only. Your version may not be identical to this one.

Date

The date format is <day>, <month>, <date>, <year>. Day displays a day, from Sunday to Saturday. Month displays the month, from January to December. Date displays the date, from 1 to 31. Year displays the year, from 1994 to 2079.

Time

The time format is <hour>, <minute>, <second>.The time is based on the 24-hour military-time clock. For example, 1 p.m. is 13:00:00. Hour displays hours from 00 to 23. Minute displays minutes from 00 to 59. Second displays seconds from 00 to 59.

Primary Master, Primary Slave, Secondary Master and Secondary Slave

These categories allow you to enter the appropriate specifications for the type of hard disk drive(s) installed in your system. Press <PgUp> or <PgDn> to select a numbered hard disk type or type the number and press <Enter>. The hard disk will not work properly if you enter improper information for this category. You can use Type “User” to define your own drive type manually.This information should be included in the documentation from your hard disk vendor. If you select Type ”Auto”, the BIOS will auto-detect the HDD & CD-ROM drive at the POST stage and show the IDE for the HDD & CD-ROM drive. If a hard disk has not been installed, select “None” and press <Enter>.

28

Award BIOS Setup Utility 3

Drive A and Drive B

These categories identify the types of floppy disk drives installed.

None



No floppy drive is installed

360K, 5.25 in.

5-1/4 in. standard drive; 360KB capacity

1.2M, 5.25

in.

5-1/4 in. AT-type high-density drive; 1.2MB capacity

720K, 3.5 in.

3-1/2 in. double-sided drive; 720KB capacity

1.44M, 3.5

in.

3-1/2 in. double-sided drive; 1.44MB capacity

2.88M, 3.5

in.

3-1/2 in. double-sided drive; 2.88MB capacity

Video

This category selects the type of video adapter used for the primary system monitor. Although secondary monitors are supported, you do not have to select the type in Setup.The default setting is EGA/VGA (BIOS default, Setup default).

EGA/VGA Enhanced Graphics Adapter/Video Graphics Array. For EGA,VGA, SVGA and PGA monitor adapters.

CGA 40 Color Graphics Adapter. Power up in 40-column mode. CGA 80 Color Graphics Adapter. Power up in 80-column mode. Mono Monochrome adapter. Includes high resolution

monochrome adapters.

Halt On

This category determines whether the system will stop if an error is detected during power up. The default setting is All Errors (BIOS default, Setup default).

No Errors The system boot will not stop for any errors detected. All Errors The system boot will stop whenever the BIOS detects

a non-fatal error.

All, But Keyboard The system boot will not stop for a keyboard error; it will stop for all other errors.

All, But Diskette The system boot will not stop for a disk error; it will stop for all other errors.

All, But Disk/Key The system boot will not stop for a disk or keyboard error; it will stop for all other errors.

29

3Award BIOS Setup Utility

3.1.2 BIOS Features Setup

The BIOS Features Setup allows you to configure your system for basic operation. Some entries are defaults required by the system board, while others, if enabled, will improve the performance of your system or let you set some features according to your preference.





ROM PCI/ISA BIOS











BIOS FEATURES SETUP











AWARD SOFTWARE, INC.

























Virus Warning

: Disabled













CPU L1 Cache

: Enabled













CPU L2 Cache

: Enabled













CPU L2 Cache ECC Checking

: Enabled













Quick Power On Self Test

: Enabled













Boot Sequence

: A, C, SCSI













Swap Floppy Drive

: Disabled













Boot Up Floppy Seek

: Disabled













Boot Up NumLock Status

: On













Typematic Rate Setting

: Disabled













Typematic Rate (Chars/Sec)

: 6













Typematic Delay (Msec)

: 250













Security Option

: Setup

ESC

: Quit

−↓→←

: Select Item





PCI/VGA Palette Snoop

: Disabled





F1

: Help

PU/PD/+/-

: Modify





OS Select For DRAM > 64MB

: Non-OS2





HDD S.M.A.R.T. Capability

: Disabled

F5

: Old Values (Shift) F2

: Color









F6 : Load Fail-Safe Settings











F7 : Load Optimal Settings





































The settings on the screen are for reference only. Your version may not be identical to this one.

Virus Warning

This category protects the boot sector and partition table of your hard disk drive. When this item is enabled, the Award BIOS will monitor the boot sector and partition table of the hard disk drive. If an attempt is made to write to the boot sector or partition table of the hard disk drive, the BIOS will halt the system and an error message will appear.

After seeing the error message, if necessary, you will be able to run an anti-virus program to locate and remove the problem before any damage is done.

Many disk diagnostic programs which attempt to access the boot sector table will cause the warning message to appear. If you are running such a program, we recommend that you first disable this category. Also, disable this category if you are installing or running certain operating systems like Windows® 95 or the operating system may not install nor work.

30

Award BIOS Setup Utility 3

CPU L1 Cache and CPU L2 Cache

These categories speed up the memory access. The default value is enabled. Enable the External Cache for better performance.

CPU L2 Cache ECC Checking

Intel CeleronTM processor comes with built-in Level 2 cache. By default, ECC is enabled to check the Level 2 cache. If you are not using this function, set this field to Disabled.

Quick Power On Self Test

This category speeds up Power On Self Test (POST) after you power on your system. When Enabled, the BIOS will shorten or skip some check items during POST.

Boot Sequence

This category determines which drive to search first for the disk operating system.The default is A, C, SCSI.The options are:

A, C, SCSI;

C, A, SCSI;

C, CDROM, A;

CDROM, C, A;

D, A, SCSI;

E, A, SCSI;

F, A, SCSI;

SCSI, A, C;

SCSI, C, A;

C only;

LS/ZIP, C.



Swap Floppy Drive

When this option is enabled and the system is booting from the floppy drive, the system will boot from drive B instead of drive A. When this option is disabled and the system is booting from the floppy drive, the system will boot from drive A. You must have two floppy drives to use this function.

Boot Up Floppy Seek

When enabled, the BIOS will check whether the floppy disk drive installed is 40 or 80 tracks. Note that the BIOS cannot distinguish between 720K, 1.2M, 1.44M and 2.88M drive types as they are all 80 tracks. When disabled, the BIOS will not search for the type of floppy disk drive by track number. Note that there will not be any warning message if the drive installed is 360KB.

31

3Award BIOS Setup Utility

Boot Up NumLock Status

This allows you to determine the default state of the numeric keypad. By default, the system boots up with NumLock on wherein the function of the numeric keypad is the number keys. When set to Off, the function of the numeric keypad is the arrow keys.

Typematic Rate Setting

When disabled, continually holding down a key on your keyboard will cause the BIOS to report that the key is down. When the typematic rate is enabled, the BIOS will not only report that the key is down, but will first wait for a moment, and, if the key is still down, it will begin to report that the key has been depressed repeatedly. For example, you would use such a feature to accelerate cursor movements with the arrow keys.

Typematic Rate (Chars/Sec)

This selection allows you to select the rate at which the keys are accelerated.

Typematic Delay (Msec)

This selection allows you to select the delay between when the key was first depressed and when the acceleration begins.

Security Option

System The system will not boot and access to Setup will be denied unless the correct password is entered at the prompt.

Setup The system will boot, but access to Setup will be denied unless the correct password is entered at the prompt.

PCI/VGA Palette Snoop

It determines whether the MPEG ISA/VESA VGA Cards can work with PCI/VGA or not.The default value is Disabled.

Enabled PCI/VGA working with MPEG ISA/VESA VGA cards. Disabled PCI/VGA not working with MPEG ISA/VESA VGA cards.

32

Award BIOS Setup Utility 3

OS Select for DRAM > 64MB

This item allows you to access the memory that is over 64MB in OS/2.The options are: Non-OS/2 and OS/2.

HDD S.M.A.R.T. Capability

The system board supports SMART (Self-Monitoring, Analysis and Reporting Technology) hard drives. SMART is a reliability prediction technology for ATA/IDE and SCSI drives.The drive will provide sufficient notice to the system or user to backup data prior to the drive’s failure. The default is Disabled. If you are using hard drives that support S.M.A.R.T., set this field to Enabled. SMART is supported in ATA-3 or later hard drives.

3.1.3 Chipset Features Setup

ROM PCI/ISA BIOS

CHIPSET FEATURES SETUP

AWARD SOFTWARE, INC.



























SDRAM RAS-to-CAS Delay

:

3



**** System Health Monitor ****





SDRAM RAS Precharge Time

:

3

Current System Temp.

:

28oC/82oF





SDRAM CAS Latency Time

:

3

Current CPU Temperature

:

42oC/107oF





SDRAM Precharge Control

:

Disabled

Current Chassis FAN Speed

:

0 RPM





DRAM Data Integrity Mode

:

Non-ECC

Current CPU FAN Speed

:

4326 RPM





System BIOS Cacheable

:

Disabled

CPU(V)

:

2.00

V









Video BIOS Cacheable

:

Disabled

+1.5 V

:

1.51

V









Video RAM Cacheable

:

Disabled

+3.3 V

:

3.40

V









8 Bit I/O Recovery Time

:

1

+ 5

V

:

5.08

V









16 Bit I/O Recovery Time

:

1

+12 V

:

12.34

V









Memory Hole At 15M-16M

:

Disabled

-12

V

: -11.76 V









PCI 2.1 Compliance

:

Disabled

-5

V

: -5.09

V









AGP Aperture Size (MB)

:

64



















CPU Clock Frequency

:

Default



















Spread Spectrum

:

Disabled













































ESC

: Quit



− ↓ → ←

: Select Item











F1

:

Help



PU/PD/+/-

: Modify











F5

:

Old Values (Shift) F2

: Color











F6

:

Load Fail-Safe Settings











F7

:

Load Optimal Settings





























The settings on the screen are for reference only. Your version may not be identical to this one.

This section gives you functions to configure the system based on the specific features of the chipset. The chipset manages bus speeds and access to system memory resources. It also coordinates communications between the conventional ISA bus and the PCI bus.

These items should not be altered unless necessary. The default settings have been chosen because they provide the best operating conditions for your system. The only time you might consider making any changes would be if you discovered some incompatibility or that data was being lost while using your system.

33

3Award BIOS Setup Utility

SDRAM RAS-to-CAS Delay

This field allows you to insert a timing delay between the CAS and RAS strobe signals, used when DRAM is written to, read from, or refreshed. This field applies only when synchronous DRAM is installed in the system.

SDRAM RAS Precharge Time

If there is insufficient number of cycles for the RAS to accumulate its charge before DRAM refresh, the refresh may be incomplete and the DRAM may fail to retain data.

SDRAM CAS Latency Time

The default setting is 3 which is 3 clock cycles for the CAS latency.

DRAM Data Integrity Mode (CB60-BX only)

This field will appear only when you are using the CB60-BX system board which supports ECC. The ECC (Error Checking and Correction) function is supported only in x72 (72-bit) PC SDRAM DIMMs. If you are using x64 (64-bit) PC SDRAM DIMMs, set this field to Non-ECC.

Non-ECC Uses x64 PC SDRAM DIMM.

ECC This option allows the system to recover from memory failure. It detects single-bit and multiple-bit errors, then automatically corrects single-bit error.

System BIOS Cacheable

When this option is enabled, accesses to the system BIOS ROM addressed at F0000H-FFFFFH are cached, provided that the cache controller is enabled.The larger the range of the Cache RAM, the higher the efficiency of the system.

Video BIOS Cacheable

As with caching the system BIOS, enabling the Video BIOS cache will allow access to video BIOS addresssed at C0000H to C7FFFH to be cached, if the cache controller is also enabled.The larger the range of the Cache RAM, the faster the video performance.

34

Award BIOS Setup Utility 3

Video RAM Cacheable

When enabled, it allows the video RAM to be cacheable thus providing better video performance. If your graphics card does not support this function, leave this field in its default setting - Disabled.

8 Bit I/O Recovery Time and 16 Bit I/O Recovery Time

The recovery time is the length of time, measured in SYSCLK, which the system will delay after the completion of an input/output request. This delay takes place because the CPU is operating so much faster than the input/output bus that the CPU must be delayed to allow for the completion of the I/O. This item allows you to determine the recovery time allowed for 8-bit I/O or 16-bit I/O.

Memory Hole At 15M-16M

In order to improve system performance, certain space in memory can be reserved for ISA cards. This memory must be mapped into the memory space below 16MB. When enabled, the CPU assumes the 1516MB memory range is allocated to the hidden ISA address range instead of the actual system DRAM.When disabled, the CPU assumes the 15-16MB address range actually contains DRAM memory. If more than 16MB of system memory is installed, this option must be disabled to provide contiguous system memory.

PCI 2.1 Compliance

By default, this field is Disabled. However, if you encounter problems with your PCI card, try setting this field to Enabled. It may be that your card is PCI 2.1 compliant.

AGP Aperture Size (MB)

This field is relevant to the memory-mapped graphics data of the AGP card installed in your system. Leave this in its default setting, which is 64MB.

CPU Clock Frequency

If you are using a 66MHz FSB processor, the options are Default, 66MHz, 75MHz and 83MHz. If you are using a 100MHz FSB processor, the options are Default, 83MHz, 100MHz, 103MHz, 105MHz, 110MHz, 112MHz, 115MHz, 120MHz and 124MHz.

35

3Award BIOS Setup Utility

Regardless of the type of processor used, the default setting is

“Default”. Under this setting, the system will run at 66MHz or 100MHz depending on the processor’s clock frequency.

If you selected an option other than “Default” and is unable to boot up the system, there are 2 methods of going back to its default setting.

Method 1: Clear the CMOS data by following the procedure in section 2.5 (chapter 2) of this manual. All fields in the BIOS Setup will automatically be set to its default settings.

Method 2: Press the <Inser t> key and power button simultaneously until the power-on screen appears. This will allow the system to boot according to the FSB of the processor. Now press the <Del> key to enter the Award BIOS setup utility. Select “Chipset Features Setup” and set the “CPU Clock Frequency” field to “Default” or an appropriate clock frequency.

Spread Spectrum

Leave this field in its default setting - Disabled. Do not alter this setting unless advised by an engineer or technician.

System Health Monitor

The BIOS is capable of monitoring the system’s “health” conditions everytime you boot the system. If it detected an abnormal condition during POST (such as when the temperature of the processor is too high or the speed of the fan is too slow), a warning message will appear BUT no alarm will sound.

If you want a warning alarm to sound, you must install the Hardware Doctor utility. This utility, which is included in the provided CD, will allow you to enable the warning alarm and manually set the highest and lowest limit of the “health” conditions monitored by the utility.

Once the utility is installed, the system will ignore the settings in this section (System Health Monitor) of the setup. If you are using Windowsâ 95/98, you may select between using the utility and this setup. For other operating systems, you may only use this setup. Refer to the “Hardware Doctor Utility” section (Chapter 4) for more information.

36

Award BIOS Setup Utility 3

Current System Temperature, Current CPU Temperature,

Current Chassis Fan Speed and Current CPU Fan Speed

These fields show the internal temperature of the system, current temperature of the processor, and the current fan speed of the chassis and CPU fans in RPM (Revolutions Per Minute).

CPU(V)

This field shows the voltage of the processor.

+1.5V, +3.3V, +5V, +12V, -12V and -5V

These fields show the output voltage of the power supply.

3.1.4Power Management Setup

The Power Management Setup allows you to configure your system to most effectively save energy. If you like to use the soft power down feature of Windows 95, you must enable the Power Management below. Select Min. Power, Max. Power or User Defined. Either one can be used as long as it is NOT disabled.





ROM PCI/ISA BIOS













POWER MANAGEMENT SETUP













AWARD SOFTWARE, INC.































ACPI Function

: Disabled

















Power Management

: User Define

















PM Control by APM

: Yes

















Video Off Method

: DPMS

















Video Off After

: Suspend

















MODEM Use IRQ

: 3

















Standby Mode

: Disabled

















Suspend Mode

: Disabled

















HDD Power Down

: Disabled

















VGA Active Monitor

: Disabled

















Soft-Off by PWR-BTTN

: Instant-Off

















PWR Lost Resume State

: Keep Off

















Resume on Ring

: Disabled

















Resume on LAN

: Disabled

















ESC

: Quit

− ↓ → ←

: Select Item





Resume on Alarm

: Disabled









F1

:

Help

PU/PD/+/-

:

Modify









F5

:

Old Values (Shift) F2

:

Color









F6 : Load Fail-Safe Settings













F7

:

Load Optimal Settings















































The settings on the screen are for reference only. Your version may not be identical to this one.

37

3Award BIOS Setup Utility

ACPI Function

By default, the ACPI function is disabled. This function should be enabled only in operating systems that support ACPI.

Power Management

This category allows you to select the type (or degree) of power saving by changing the length of idle time that elapses before the Standby mode and Suspend mode are activated.

Disable No power management. Disables the Standby and Suspend modes.

Min. Power Saving Minimum power management. Standby Mode = 1 hr., and Suspend Mode = 1 hr.

Max. Power Saving Maximum power management. Standby Mode = 1 min., and Suspend Mode = 1 min.

User Defined Allows you to set each mode individually. When enabled, each option ranges from 1 min. to 1 hr.

PM Control by APM

Yes An Advanced Power Management device will be activated to enhance the power saving mode and stop the CPU’s internal clock. Use this option in Windows® 95. (default)

No The system BIOS will ignore APM when initiating the Power Management mode.

Video Off Method

This determines the manner in which the monitor is blanked.

V/H SYNC + Blank This selection will cause the system to turn off the vertical and horizontal synchronization ports and write blanks to the video buffer.

Blank Screen This option only writes blanks to the video buffer.

DPMS Initializes display power management signaling. Use this option if your video board supports it.

38

Award BIOS Setup Utility 3

Video Off After

N/A The system BIOS will never turn off the screen. Suspend The screen is off when the system is in the Suspend

mode.

Standby The screen is off when the system is in the Standby mode.

MODEM Use IRQ

This category is used to set an IRQ channel (IRQ 3, 4, 5, 7, 9, 10 or 11) for the external modem installed in your system. However, if the “Resume on Ring” or “Resume on LAN” field is disabled, the BIOS will mask the IRQ assigned for the modem.This is to prevent the modem or LAN from waking up the system when it is in the Suspend mode.

Standby Mode

This is user configurable only when the Power Management category is set to User Defined. When enabled and after the set time of system inactivity, video will be shut off while all other devices still operate at full speed.

Suspend Mode

This is user configurable only when the Power Management category is set to User Defined. When enabled and after the set time of system inactivity, the CPU and onboard peripherals will be shut off.

HDD Power Down

This is user configurable only when the Power Management category is set to User Defined. When enabled and after the set time of system inactivity, the hard disk drive will be powered down while all other devices remain active.

VGA Active Monitor

Enabled When the system enters the Suspend mode, it will check the status of the VGA. If the VGA is active, it will not turn the screen off. If the VGA is inactive, it will turn the screen off.

Disabled When the system enters the Suspend mode, it will immediately turn the screen off without checking the status of the VGA.

39

3Award BIOS Setup Utility

Soft-Off by PWR-BTTN

This category allows you to select the method of powering off your system.

Hold 4 Sec. Regardless of whether the Power Management field is enabled or disabled, if the power button is pushed and released in less than 4 sec, the system enters the Suspend mode. The purpose of this function is to prevent the system from powering off in case you accidentally “hit” or pushed the power button. Push and release again in less than 4 sec to restore. Pushing the power button for more than 4 seconds will power off the system.

Instant-Off Pressing and then releasing the power button at once will immediately power off your system.

PWR Lost Resume State

Keep Off When power returns after an AC power failure, you must press the Power button to power-on the system.

Turn On When power returns after an AC power failure, the system will automatically power-on.

Last State When power returns after an AC power failure, the operating session where you left off before power failure occurs will resume.

Resume On Ring

With an external modem installed, the Modem Ring-on function will allow your system to power-on to respond to incoming calls. By default, the “Resume on Ring” field is Disabled.To use this function, please follow the steps below.

1.Make sure the computer system is powered off.

2.Connect the external modem to the COM 1 or COM 2 serial port.

3.Switch on the power of the external modem.

4.Power-on the computer system. After the memory test, press <Del> to enter the Award BIOS setup utility.

5.Select Power Management Setup and press <Enter>.

6.Enable the “Resume on Ring” field.

40

Award BIOS Setup Utility 3

7.Press <Esc> to return to the main menu of the Award BIOS setup utility. Select “Save & Exit Setup” and press <Enter>.

8.Type <Y> and press <Enter>.

Resume On LAN

With a LAN card installed, the Wake-On-LAN function allows the network to remotely wake up a Soft Power Down (Soft-Off) PC. However, if your system is in the Suspend mode, you can wakeup the system only through an IRQ or DMA interrupt. Make sure your LAN card supports the remote wakeup function.To use this function, set this field to Enabled. Refer to the “Wake-On-LAN Connector” section in Chapter 2 of this manual for more information.

Resume On Alarm

Enabled When Enabled, you can s et the date and time you would like the Soft Power Down (Soft-Off) PC to power-on. However, if the system is being accessed by incoming calls or the network (Resume On Ring/LAN) prior to the date and time set in this field, the system will give priority to the incoming calls or network. “Date (of Month)” and “Timer (hh:mm:ss)” will appear right below this field.

Disabled Disables the automatic power-on function.(default)

Date (of Month)

0The system will power-on everyday according to the time set in the “Timer (hh:mm:ss)” field.

1-31 Select a date you would like the system to power-on.The system will power-on on the set date, and time set in the “Timer (hh:mm:ss)” field.

Timer (hh:mm:ss)

This is used to set the time you would like the system to poweron. If you want the system to power-on everyday as set in the “Date (of Month)” field, the time set in this field must be later than the time of the RTC in the Standard CMOS Setup.

41

3Award BIOS Setup Utility

3.1.5 PNP/PCI Configuration

This section describes configuring the PCI bus system. It covers some very technical items and it is strongly recommended that only experienced users should make any changes to the default settings.

ROM PCI/ISA BIOS

PNP/PCI CONFIGURATION

AWARD SOFTWARE, INC.























Resources Controlled By

: Auto

Assign IRQ for VGA : Enabled







Reset Configuration Data

: Disabled

Assign IRQ for USB

: Enabled











PCI Slot 1 Use IRQ

: Auto













PCI Slot 2 Use IRQ

: Auto













PCI Slot 3 Use IRQ

: Auto













PCI Slot 4 Use IRQ

: Auto





























ESC

: Quit

− ↓ → ←

: Select Item









F1

:

Help

PU/PD/+/-

:

Modify









F5

:

Old Values (Shift) F2

:

Color









F6

:

Load Fail-Safe Settings













F7

:

Load Optimal Settings















































The settings on the screen are for reference only. Your version may not be identical to this one.

Resources Controlled By

The Award Plug and Play BIOS has the capability to automatically configure all of the boot and Plug and Play compatible devices.

Auto The system will automatically detect the settings for you. The categories that follow will not be shown on the screen.

Manual This will allow you to set the IRQ/DMA (you have assigned your add-in card) to Legacy ISA or PCI/ISA PnP. For non-PnP ISA cards, select Legacy ISA. For PnP ISA or PCI cards, select PCI/ISA PnP.

Reset Configuration Data

Enabled The BIOS will reset the configuration data once automatically. It will then recreate a new set of configuration data.

Disabled The BIOS will not reset the configuration data.

42

Award BIOS Setup Utility 3

Assign IRQ for VGA

When Enabled, the system automatically assigns an IRQ for the VGA card installed.Your VGA card will need an IRQ only when using the video capture function of the card. If you are not using this function and a new device requires an IRQ, you can set this function to Disabled. The IRQ (previously occupied by the VGA card) will be available for your new device.

Note:

When Disabled, a “Yellow” mark will appear in Windowsâ 95’s

Device Manager.

Assign IRQ for USB

When Enabled, the system automatically assigns an IRQ for the USB device connected to your system. However, if you are not using USB devices and an ISA slot requires an IRQ, set this function to Disabled. The IRQ previously occupied by the USB device will be available for the ISA slot.

Note:

When Disabled, a “Yellow” mark will appear in Windowsâ 95’s

Device Manager.

PCI Slot 1 Use IRQ to PCI Slot 4 Use IRQ

By default, an IRQ is automatically assigned to each PCI slot. You may also manually assign an IRQ to these slots. The options are: 3, 4, 5, 7, 9, 10, 11, 12, 14 and 15.

3.1.6 Load Fail-Safe Settings

The “Load Fail-Safe Settings” option loads the troubleshooting default values permanently stored in the ROM chips. These settings are not optimal and turn off all high performance features.You should use these values only if you have hardware problems. Highlight this option on the main menu and press <Enter>.The message below will appear.

Load Fail-Safe Settings (Y/N)? N

If you want to proceed, type <Y> and press <Enter>. The default settings will be loaded.

43

3Award BIOS Setup Utility

3.1.7 Load Optimal Settings

The “Load Optimal Settings” option loads optimized settings from the BIOS ROM. Use the Setup default values as standard values for your system. Highlight this option on the main menu and press <Enter>.The message below will appear.

Load Optimal Settings (Y/N)? N

Type <Y> and press <Enter> to load the Setup default values.

3.1.8 Integrated Peripherals

ROM PCI/ISA BIOS

INTEGRATED PERIPHERALS

AWARD SOFTWARE, INC.























IDE HDD Block Mode

: Enabled

KBC Input Clock



:

8MHz





IDE Primary Master PIO

: Auto

Onboard FDC Controller

:

Enabled





IDE Primary Slave PIO

: Auto

Onboard Serial Port 1

:

3F8/IRQ4





IDE Secondary Master PIO

: Auto

Onboard Serial Port 2

:

2F8/IRQ3





IDE Secondary Slave PIO

: Auto

UART2 Mode Select

: Normal





IDE Primary Master UDMA

: Auto

















IDE Primary Slave UDMA

: Auto

Onboard Parallel Port

:

378/IRQ7





IDE Secondary Master UDMA : Auto

Parallel Port Mode



:

ECP+EPP





IDE Secondary Slave UDMA

: Auto

ECP Mode Use DMA

:

3





On-chip Primary PCI IDE

: Enabled

EPP Mode Select



: EPP1.7





On-chip Secondary PCI IDE

: Enabled

Keyboard/Mouse Power On

: Disabled





USB Keyboard Support

: Disabled

















Init Display First

: AGP





















ESC

: Quit

− ↓ → ←

: Select Item









F1

: Help

PU/PD/+/-

: Modify









F5

: Old Values (Shift) F2



: Color









F6

:

Load Fail-Safe Settings











F7

:

Load Optimal Settings















































The settings on the screen are for reference only. Your version may not be identical to this one.

IDE HDD Block Mode

Enabled The IDE HDD uses the block mode. The system BIOS will check the hard disk drive for the maximum block size the system can transfer.The block size will depend on the type of hard disk drive.

Disabled The IDE HDD uses the standard mode.

IDE Primary Master/Slave PIO and IDE Secondary Master/Slave PIO

PIO means Programmed Input/Output. Rather than have the BIOS issue a series of commands to effect a transfer to or from the disk drive, PIO allows the BIOS to tell the controller what it wants and then let the controller and the CPU perform the complete task by

44

Award BIOS Setup Utility 3

themselves.Your system supports five modes, 0 (default) to 4, which primarily differ in timing. When Auto is selected, the BIOS will select the best available mode after checking your drive.

Auto The BIOS will automatically set the system according to your hard disk drive’s timing.

0-4 You can select a mode that matches your hard disk drive’s timing. Caution: Do not use the wrong setting or you will have drive errors.

IDE Primary Master/Slave UDMA and IDE Secondary Master/Slave

UDMA

These categories allow you to set the Ultra DMA in use. When Auto is selected, the BIOS will select the best available option after checking your hard drive or CD-ROM.

Auto The BIOS will automatically detect the settings for you. Disabled The BIOS will not detect these categories.

On-Chip Primary PCI IDE and On-Chip Secondary PCI IDE

These categories allow you to enable or disable the primary and secondary IDE controller.The default is Enabled. Select Disabled if you want to add a different hard drive controller.

USB Keyboard Support

By default, USB Keyboard Support is Disabled. However, if you are using a USB keyboard under DOS, make sure to enable this function.

Init Display First

This field is used to select whether to initialize AGP or PCI first when the system boots.

AGP When the system boots, it will first initialize AGP.

PCI Slot When the system boots, it will first initialize PCI.

KBC Input Clock

This is used to select the input clock of your keyboard.The options are: 8MHz and 12MHz.The default is 8MHz.

45

3Award BIOS Setup Utility

Onboard FDC Controller

Enabled Enables the onboard floppy disk controller.

Disabled Disables the onboard floppy disk controller.

Onboard Serial Port 1 and Onboard Serial Port 2

Auto The system will automatically select an I/O address for the onboard serial port 1 and serial port 2.

3F8/IRQ4, 2F8/IRQ3, 3E8/IRQ4, 2E8/IRQ3 Allows you to manually select an I/O address for the onboard serial port 1 and serial port 2.

Disabled Disables the onboard serial port 1 and/or serial port 2.

UART2 Mode Select

The system board supports IrDA function for wireless connectivity between your computer and peripheral devices.You may not use IrDA (J12) and the COM 2 serial port (J8) at the same time. If you are using the COM 2 serial port, make sure “UART2 Mode Select” is set to Normal.

To use the IrDA function, follow the steps below.

1.Connect your IrDA cable to connector J12 on the system board.

2.Set “UART2 Mode Select” to the type of IrDA standard supported by your IrDA peripheral/device (IrDA 1.0 or ASKIR). For better transmission of data, your IrDA peripheral device must be within a 30o angle and within a distance of 1 meter.

3.The following will appear right after “UART2 Mode Select”.

IR Transmission Delay

If this option is Enabled, transmission of data will be slower.This is recommended when you encounter transmission problem with your device. The options are: Enabled and Disabled.

Onboard Parallel Port

378H/IRQ7, 3BCH/IRQ7, 278H/IRQ5 Selects the I/O address and IRQ for the onboard parallel port.

Disabled Disables the onboard parallel port.

46

Award BIOS Setup Utility 3

Parallel Port Mode, ECP Mode Use DMA and EPP Mode Select

These fields will appear only if you selected an I/O address and IRQ in the Onboard Parallel Por t field. These apply to a standard specification and will depend on the type and speed of your device. Refer to your peripheral’s manual for the best option.

The parallel modes are SPP, EPP, ECP and ECP+EPP. The default is ECP+EPP. Both “ECP Mode Use DMA” and “EPP Mode Select” will appear on the screen. If you selected EPP, “EPP Mode Select” will appear. This field applies to standard specification. The options are EPP1.9 and EPP1.7. Default setting: EPP1.7. If you selected ECP, “ECP Mode Use DMA” will appear. This is used to select a DMA channel for the parallel port. The options are 1 and 3. Default setting: 3.

Keyboard/Mouse Power On

This field allows you to use the keyboard or mouse to power-on the system. To use this function, make sure JP1 is set to 2-3 On - the Wake-On-Keyboard/Mouse function enabled. Refer to “Jumper Settings for Wake-On-Keyboard/Wake-On-Mouse” in Chapter 2 of this manual for more information.

Disabled Default setting.

Warning:

If JP1 was previously enabled with a password set in the “KB Power On Password” field, and now you wish to disable the Wake-On- Keyboard (password) function, make sure to set this field to disabled prior to setting JP1 to disabled (1-2 On).You will not be able to boot up the system if you fail to do so.

Password When this option is selected, the “KB Power On Password” field will appear. Move the cursor to this field and press <Enter>. Enter your password.You can enter up to 5 characters. Type in exactly the same password to confirm, then press <Enter>.

Important:

The power button will not function once a keyboard password has been set in the “KB Power On Password” field. You must type the correct password to power-on the system.

47

3Award BIOS Setup Utility

Hot Key When this option is selected, the “KB Power On Hot

Key” field will appear. Move the cursor to this field to select a function key you would like to use to poweron the system.The options are from Ctrl-F1 to CtrlF12.

Mouse Left When this option is selected, double-click the left button of the mouse to power-on the system.

Mouse Right When this option is selected, double-click the right button of the mouse to power-on the system.

Any Key Press any key to power-on the system.

Keyboard 98 When this option is selected, press the “wake up” key of the Windowsâ 98 compatible keyboard to poweron the system.

3.1.9 Supervisor Password

If you want to protect your system and setup from unauthorized entry, set a supervisor’s password with the “System” option selected in the BIOS Features Setup. If you want to protect access to setup only, but not your system, set a supervisor’s password with the “Setup” option selected in the BIOS Features Setup. You will not be prompted for a password when you cold boot the system.

Use the arrow keys to highlight the “Supervisor Password” option and press <Enter>.The message below will appear.

Enter Password:

Type in the password.You are limited to eight characters. When done, the message below will appear:

Confirm Password:

You are asked to verify the password. Type in exactly the same password. If you type in a wrong password, you will be prompted to enter the correct password again. To delete or disable the password function, highlight “Supervisor Password” and press <Enter>, instead of typing in a new password. Press the <Esc> key to return to the main menu.

48

Award BIOS Setup Utility 3

3.1.10 User Password

If you want another user to have access only to your system but not to setup, set a user’s password with the “System” option selected in the BIOS Features Setup. If you want a user to enter a password when trying to access setup, set a user’s password with the “Setup” option selected in the BIOS Features Setup.

Using user’s password to enter Setup allows a user to access only the “User Password” option that appears on the main screen. Access to all other options is denied. To set, confirm, verify, disable or delete a user’s password, follow the procedures described in the section “Supervisor Password”. If you forget your password, refer to the procedure described in the same section.

3.1.11 IDE HDD Auto Detection

Use this option to detect the parameters for the hard disk drives installed in your system. These parameters will then be automatically entered into the "Standard CMOS Setup". The IDE HDD Auto Detection screen displays the following categories of information: Size, Cylinders, Heads, Precomp, LandZone, Sectors and Mode.

ROM PCI/ISA BIOS

CMOS SETUP UTILITY

AWARD SOFTWARE, INC.

HARD DISKS

TYPE

SIZE

CYLS HEAD RECOMP LANDZ

SECTOR

MODE



Primary Master:













































Select Primary Master Option (N=Skip): N













OPTIONS

SIZE

CYLS

HEAD

RECOMP

LANDZ

SECTOR

MODE































2 (Y)

853

827

32

0

1653

63

LBA





1

853

1654

16

65535

1653

63

Normal





3

853

827

32

65536

1653

63

Large



























Note: Some OS (like SCO-UNIX) must be “NORMAL” for installation

ESC: Skip

The settings on the screen are for reference only. Your version may not be identical to this one.

For hard drives larger than 528MB, you would typically select the LBA type. Certain operating systems require that you select Normal or Large. Please check your operating system’s manual or Help desk on which one to select.

49

3Award BIOS Setup Utility

3.1.12 Save & Exit Setup

When all the changes have been made, highlight “Save & Exit Setup” and press <Enter>.The message below will appear:

Save to CMOS and Exit (Y/N)? N

Type “Y” and press <Enter>.The modifications you have made will be written into the CMOS memory, and the system will reboot.You will once again see the initial diagnostics on the screen. If you wish to make additional changes to the setup, press <Ctrl> <Alt> <Esc> simultaneously or <Del> after memory testing is done.

3.1.13 Exit Without Saving

When you do not want to save the changes you have made, highlight “Exit Without Saving” and press <Enter>. The message below will appear:

Quit Without Saving (Y/N)? N

Type “Y” and press <Enter>.The system will reboot and you will once again see the initial diagnostics on the screen. If you wish to make any changes to the setup, press <Ctrl> <Alt> <Esc> simultaneously or <Del> after memory testing is done.

50

Chapter 4 - Supported Softwares

4.1 Desktop Management Interface (DMI)

The system board comes with a DMI built into the BIOS. DMI, along with the appropriately networked software, is designed to make inventory, maintenance and troubleshooting of computer systems easier. With DMI, a network administrator or MIS engineer can remotely access some information about a particular computer system without physically going to it. Quite often a service call may be unnecessary as the problem can be solved remotely.

The DMI utility in the BIOS automatically records various information about your system configuration. Information about the type and speed of CPU, type and amount of memory for each memory slot, BIOS revision level, types of add-in PCI boards and components, certain revision numbers of hardware installed, etc. are automatically detected and stored in the DMI pool, which is a part of the system board's Plug and Play BIOS. Additional information, such as ISA based peripherals, which may not be automatically detected, can be manually recorded in the DMI pool by using the Add DMI menu.The DMI pool data is then verified or updated whenever the system hardware or setup is altered.

4.1.1 Running the DMI Utility

To run the DMI utility, type: DMICFG.EXE.You can download this utility from ftp.dfiusa.com - /utilities/DMI directory.

The DMI utility must run in real mode with at least 180K of base memory. Memory managers like HIMEM.SYS (required by Windows) must not be installed.You may do this by using one of the 3 methods listed below.

1.Boot up from a system diskette without the AUTOEXEC.BAT and CONFIG.SYS files,

2.“REM” HIMEM.SYS in the CONFIG.SYS, or

3.Press <F5> during bootup to bypass your AUTOEXEC.BAT and CONFIG.SYS files.

51

4Supported Softwares

4.1.2 Using the DMI Utility

Award DMI Configuration Utility Copyright Award Software Inc, 1996

[Edit DMI] [Add DMI] [Load DMI File] [Save DMI File]

BIOS

*** BIOS Auto Detect ***

System

Enclosure/Chassis

Type : BIOS Information

Processor

Handle : 0000

Memory Controller

Vendor Name :

Memory Module

BIOS Version :

Memory Module

BIOS Starting Address Segment : E000

Memory Module

BIOS Build Date :

Memory Module

BIOS Characteristics :

Cache

Size of BIOS ROM : 0256K

Cache



Port Connector



Port Connector



Port Connector



Port Connector



Port Connector



Port Connector



Port Connector



System Slots



− ↓ ←

Move cursor ENTER-Accept DEL-Delete ESC-Abort&Exit



The four menus located on top of the DMI Configuration Utility screen are Edit DMI, Add DMI, Load DMI File and Save DMI File. Use the or (left or right) arrow keys to select a menu from the Menu bar.

On the left side of the screen is a list of the system configuration items. Use the or (up or down) arrow keys to select an item.

The commands at the bottom of the screen will allow you to navigate through the various setup menus.

Edit DMI

1.Use the or arrow keys to select the Edit DMI menu.

2.Highlight the item on the left screen that you would like to edit by using the or arrow keys, then press <Enter>.

3.The cursor will move to the screen you select allowing you to edit information. The screen will also display the auto-detected information.

4.Press <F10> to update the edited information into the flash ROM.

52







































































































































Supported Softwares



4



























































































































































































































































































Add DMI

1.Use the or arrow keys to select the Add DMI menu.

2.Highlight the item on the left screen that you would like to add by using the or arrow keys, then press <Enter>.

3.The cursor will move to the screen you select allowing you to enter information about the added item.

4.Press <F10> to save information into the flash ROM.

To view information about the added items, go to the Edit DMI menu.

Load DMI File

1.Use the or arrow keys to select the Load DMI File menu.

2.The following message will appear.

Press [Enter] to select DMI file for load

Press <Enter>.

3.The DMI files will appear on the screen. Select the file you would like to load and press <Enter>.

4.The following message will appear.

Do you want to execute? (Y/N)

Type <Y>. All previous DMI structures will be destroyed and the new file will be saved into the flash ROM.

Save DMI File

1.Use the or arrow keys to select the Save DMI File menu.

2.The following message will appear.

Press [Enter] to select DMI file for save

Press <Enter>.

3.Enter the directory and filename under which you would like the DMI file saved.

53

4Supported Softwares

4.2 Hardware Doctor Utility

The system board comes with a Hardware Doctor utility contained in the provided CD. This utility is capable of monitoring the system’s “health” conditions and allows you to manually set a range (Highest and Lowest Limit) to the items being monitored. If the settings/ values are over or under the set range, a warning message will popup. The utility can also be configured so that a beeping alarm will sound whenever an error occurs. We recommend that you use the “Default Setting” which is the ideal setting that would keep the system in good working condition.

To install the utility, insert the CD (included in the system board package) into a CD-ROM drive. The autorun screen will appear. Double-click the Hardware Doctor icon to install the utility. After installing the utility, the screen below will appear.

(Click here for a clearer view of the screen)

The rightmost column of the screen shows the current value of each monitored item.To set the highest and lowest limit of each item, click on the arrow buttons in the “Lowest Limit” or “Highest Limit” column. However, we DO NOT recommend that you change the

54







































































































































Supported Softwares



4



























































































































































































































































































settings of the Voltages. Make sure to leave them in their default setting.

To further configure the utility, select “Configuration” in the Tools menu.The Monitoring Config. screen will appear.

(Click here for a clearer view of the screen)

Enable

Click on the items you want to be monitored.

Faults Count (1 or 3)

This allows you to select the number of fault counts detected before a warning message pop-up. "1" = The warning message will pop-up once an error has been detected. "3" = The warning message will pop-up after the error has been detected thrice.

Beep

Besides the pop-up warning message, you can choose to enable the beep alarm so that if an abnormal condition occurs, an alarm will sound. Due to its hardware limitation, the only item that cannot be

55

4Supported Softwares

enabled is “System Temp”. If the internal temperature of the system is too high, only a warning message will pop-up.

Temperature Unit

You can select the temperature unit between Celsius and Fahrenheit. The default unit is Celsius.

Polling Interval

This is used to set the interval for monitoring the system. The range is from 1 sec. to 120 sec.The default interval is 2 sec.

4.3 Patch Utility for Windowsâ 95

The CD included in the system board package contains a patch utility. If you are running Windowsâ 95 (Win95, Win95+, Win95 OSR1: Windows 95 OEM Service Release 1, Win95 OSR2:Windows 95 OEM Service Release 2.0 or Win95 OSR2.1: Windows 95 OEM Service Release 2.0 plus USB Supplement), you need to run the patch utility.

Insert the CD into a CD-ROM drive. The autorun screen (Main Board Utility CD) will appear. Click “Patch Utility for Windows 95”. Please refer to its “readme” file for instructions on installing the utility.

All steps or procedures to install the utility are subject to change without notice as the utility may occassionally be updated. Please refer to the readme file for the latest information.

56

Appendix A - System Error Message

When the BIOS encounters an error that requires the user to correct something, either a beep code will sound or a message will be displayed in a box in the middle of the screen and the message, PRESS F1 TO CONTINUE, CTRL-ALT-ESC or DEL TO ENTER SETUP, will be shown in the information box at the bottom. Enter Setup to correct the error.

A.1 POST Beep

There are two kinds of beep codes in the BIOS. One code indicates that a video error has occured and the BIOS cannot initialize the video screen to display any additional information. This beep code consists of a single long beep followed by three short beeps. The other code indicates that a DRAM error has occured. This beep code consists of a single long beep.

A.2 Error Messages

One or more of the following messages may be displayed if the BIOS detects an error during the POST. This list indicates the error messages for all Awards BIOSes:

CMOS BATTERY HAS FAILED

The CMOS battery is no longer functional. It should be replaced.

Caution:

Danger of explosion if battery incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the battery manufacturer’s instructions.

CMOS CHECKSUM ERROR

Checksum of CMOS is incorrect. This can indicate that CMOS has become corrupt. This error may have been caused by a weak battery. Check the battery and replace if necessary.

DISPLAY SWITCH IS SET INCORRECTLY

The display switch on the motherboard can be set to either monochrome or color. This indicates the switch is set to a different

57

ASystem Error Message

setting than indicated in Setup. Determine which setting is correct, either turn off the system and change the jumper or enter Setup and change the VIDEO selection.

FLOPPY DISK(S) fail (80)

Unable to reset floppy subsystem.

FLOPPY DISK(S) fail (40)

Floppy type mismatch.

Hard Disk(s) fail (80)

HDD reset failed.

Hard Disk(s) fail (40)

HDD controller diagnostics failed.

Hard Disk(s) fail (20)

HDD initialization error.

Hard Disk(s) fail (10)

Unable to recalibrate fixed disk.

Hard Disk(s) fail (08)

Sector Verify failed.

Keyboard is locked out - Unlock the key

The BIOS detects that the keyboard is locked. Keyboard controller is pulled low.

Keyboard error or no keyboard present

Cannot initialize the keyboard. Make sure the keyboard is attached correctly and no keys are being pressed during the boot.

Manufacturing POST loop

System will repeat POST procedure infinitely while the keyboard controller is pull low. This is also used for the M/B burn in test at the factory.

BIOS ROM checksum error - System halted

The checksum of ROM address F0000H-FFFFFH is bad.

Memory test fail

The BIOS reports memory test fail if the memory has error(s).

58

Appendix B -Troubleshooting

B.1 Troubleshooting Checklist

This chapter of the manual is designed to help you with problems that you may encounter with your personal computer. To efficiently troubleshoot your system, treat each problem individually. This is to ensure an accurate diagnosis of the problem in case a problem has multiple causes.

Some of the most common things to check when you encounter problems while using your system are listed below.

1.The power switch of each peripheral device is turned on.

2.All cables and power cords are tightly connected.

3.The electrical outlet to which your peripheral devices are connected is working. Test the outlet by plugging in a lamp or other electrical device.

4.The monitor is turned on.

5.The display’s brightness and contrast controls are adjusted properly.

6.All add-in boards in the expansion slots are seated securely.

7.Any add-in board you have installed is designed for your system and is set up correctly.

Monitor/Display

If the display screen remains dark after the system is turned on:

1.Make sure that the monitor’s power switch is on.

2.Check that one end of the monitor’s power cord is properly attached to the monitor and the other end is plugged into a working AC outlet. If necessary, try another outlet.

3.Check that the video input cable is properly attached to the monitor and the system’s display adapter.

4.Adjust the brightness of the display by turning the monitor’s brightness control knob.

59

BTroubleshooting

The picture seems to be constantly moving.

1.The monitor has lost its vertical sync. Adjust the monitor’s vertical sync.

2.Move away any objects, such as another monitor or fan, that may be creating a magnetic field around the display.

3.Make sure your video card’s output frequencies are supported by this monitor.

The screen seems to be constantly wavering.

1.If the monitor is close to another monitor, the adjacent monitor may need to be turned off. Fluorescent lights adjacent to the monitor may also cause screen wavering.

Power Supply

When the computer is turned on, nothing happens.

1.Check that one end of the AC power cord is plugged into a live outlet and the other end properly plugged into the back of the system.

2.Make sure that the voltage selection switch on the back panel is set for the correct type of voltage you are using.

3.The power cord may have a “short” or “open”. Inspect the cord and install a new one if necessary.

Floppy Drive

The computer cannot access the floppy drive.

1.The floppy diskette may not be formatted. Format the diskette and try again.

2.The diskette may be write-protected. Use a diskette that is not write-protected.

3.You may be writing to the wrong drive. Check the path statement to make sure you are writing to the targeted drive.

4.There is not enough space left on the diskette. Use another diskette with adequate storage space.

60























































































































































Troubleshooting



B



























































































































































































































































































































Hard Drive

Hard disk failure.

1.Make sure the correct drive type for the hard disk drive has been entered in the BIOS.

2.If the system is configured with two hard drives, make sure the bootable (first) hard drive is configured as Master and the second hard drive is configured as Slave. The master hard drive must have an active/bootable partition.

Excessively long formatting period.

1.If your hard drive takes an excessively long period of time to format, it is likely a cable connection problem. However, if your hard drive has a large capacity, it will take a longer time to format.

Parallel Port

The parallel printer doesn’t respond when you try to print.

1.Make sure that your printer is turned on and that the printer is on-line.

2.Make sure your software is configured for the right type of printer attached.

3.Verify that the onboard LPT port’s I/O address and IRQ settings are configured correctly.

4.Verify that the attached device works by attaching it to a parallel port that is working and configured correctly. If it works, the printer can be assumed to be in good condition. If the printer remains inoperative, replace the printer cable and try again.

61

BTroubleshooting

Serial Port

The serial device (modem, printer) doesn’t output anything or is outputting garbled characters.

1.Make sure that the serial device’s power is turned on and that the device is on-line.

2.Verify that the device is plugged into the correct serial port on the rear of the computer.

3.Verify that the attached serial device works by attaching it to a serial port that is working and configured correctly. If the serial device does not work, either the cable or the serial device has a problem. If the serial device works, the problem may be due to the onboard I/O or the address setting.

4.Make sure the COM settings and I/O address are configured correctly.

Keyboard

Nothing happens when a key on the keyboard was pressed.

1.Make sure the keyboard is properly connected.

2.Make sure there are no objects resting on the keyboard and that no keys are pressed during the booting process.

System Board

1.Make sure the add-in card is seated securely in the expansion slot. If the add-in card is loose, power off the system, re-install the card and power up the system.

2.Check the jumper settings to ensure that the jumpers are properly set.

3.Verify that all memory modules are seated securely into the memory sockets.

4.Make sure the memory modules are in the correct locations.

5.If the board fails to function, place the board on a flat surface and seat all socketed components. Gently press each component into the socket.

6.If you made changes to the BIOS settings, re-enter setup and load the BIOS defaults.

62
