QUICK GUIDE
VULCAN
Voyager
Tablet Quick Guide
Thank you for choosing the Tablet TM75A. This portable device is designed to take advantage of micro-mobility and direct interacon through touch/pen input and wireless connecvity (Wi-Fi/Bluetooth) to provide disnct and different use experience for both study and entertainment.
Package Contents
Your package should contain the Tablet you purchased along with the following items. If anything is missing or appears to be damaged, please contact your vendor or agent.
Quick Guide USB cable Power Adapter
NOTE:
The package contents above are for reference only. Please take the actual package items as standard.
Specicaon
Processor
- Intel® Atom™ processor Z2460 1.6GHz
LCD Display
- 7inch (16:9), 1024X600 TN LCD
Touch Panel
- 5-points capacive touch panel
Storage
- 8/16GB eMMC Memory*
Input/ Output (I/O)
- 1 x TF/Micro SD card slot
- 1 x Mini HDMI type C
- 1 x DC-IN Jack
- 1 x MIC/Headphone Jack combo(American type)
- 1 x Micro USB2.0/OTG port without charging status(Type A/B)
System Memory
- 1 x LPDDR2, 1GB
TF/Micro SD Card
- Support 128M~32GB
WiFi/BT
- 802.11 b/g/n, 2.4 GHz antenna
- Bluetooth 2.1+ EDR
Camera
- 2 x cameras (Front: 0.3M, Rear: 2M)
Stereo Speaker
- 2 x internal stereo speakers
Battery
- MBell 3810088
- 1 Cell, lithium polymer, 3.7V, 4100mAh
- Video play: 6 hours
- Music play: 10 hours
- Wi-Fi: 6 hours (with speaker)
Power Adapter
- Shenzhen Frecom F12W-050200SPAU/ F12W-050200SPAI/ F12W-050200SPAV/ F12W-050200SPAC
- Asian Power WA-10P05R/ WA-10P05Fy (y=A,B,C,G,K,N,S,T or U)
- Input: 100-240V ~ 50/60Hz 0.3A
- Output: 5V --- 2A
+-
Tablet Weight
- 384g
Dimension
- 198.8 mm (W) X 130 mm (H) X 12 mm (D)
NOTE:
* The internal storage of the tablet is either 8 or 16GB, please take the actual products
as the standard.
All specificaons are subject to change without noce. All rights reserved legal noces privacy and trademarks.
Interface Introducon
6
NO. Item NO. Item
1 Touch Panel 2 Speakers 7 Power Buon 3 Charging Indicator 8 Volume Up/Down Buon 4 I/O 9 Back Camera 5 Front Microphone -- --
Front Camera
NO. Item NO. Item
A TF/Micro SD Card Slot D Micro USB Port B Mini HDMI Port E DC-IN Jack C Headphone Jack -- --
NOTE:
Due to the system design limitaon, if the tablet is connected to computer by Micro USB, please pull up the USB cable before turnning off the tablet.
Turn On/Off the Tablet
Turn On the Tablet
Press and hold the Power buon on the top le side of the tablet.
Turn Off the Tablet
1. Press and hold the Power buon unl the opons menu appears on the screen.
2. Tap OK on the Power O opon menu to turn off the tablet.
Charging the Baery
Before using your tablet for the rst me, you must fully charge the baery.
Steps:
1. Insert the Power Adapter into a standard AC power outlet.
2. Connect the Power Adapter to your tablet.
Installing the Storage Card
You can choose the TF/micro SD cards in a wide range of capacies, varying from 128M to 32GB.
Install TF/Micro SD Card
1. Turn o the tablet
2. Locate the slot for the TF/micro SD card
3. Insert the TF/micro SD card gently
Remove TF/Micro SD Card
1. Turn off the tablet or Tape (Menu>Sengs>Storage>Unmount SD card)
2. Push the TF/micro SD card to eject from the slot
3. Pull out the TF/micro SD card
FRONT BACK
Note:
Please insert the TF/micro SD card in the correct direcon. Insert in incorrect direcon may result in the damages for both tablet and the TF/micro SD card.
40H053-JT6012
