Intel 330T User Manual
English
Français
Italiano
Deutsch
Español
Intel® Express 330T
Stackable Hub
Fiber and Ethernet
Modules
Quick Start
Year 2000 Capable
An Intel product, when used in accordance with its associated documentation, is "Year 2000 Capable" when, upon
installation, it accurately stores, displays, processes, provides, and/or receives date data from, into, and between
the twentieth and twenty-first centuries, including leap year calculations, provided that all other technology used
in combination with said product properly exchanges date data with it.
Copyright © 1999, Intel Corporation. All rights reserved.
Intel Corporation, 5200 NE Elam Young Parkway, Hillsboro OR 97124-6497
Intel Corporation assumes no responsibility for errors or omissions in this manual. Nor does Intel make any commitment to update the
information contained herein.
* Other product and corporate names may be trademarks of other companies and are used only for explanation and
to the owners’ benefit, without intent to infringe.
First Edition April 1999 732045-001
Quick Start
6
1
2
3
Install the Module
• Unplug the power cord from the hub. Remove
the panel from the small expansion slot
(Module A).
• Align the module with the card guides
inside the hub and slide the module into
the slot. Press firmly to connect the module.
• Use the retaining screws to secure the module,
then plug in the power cord.
Connect to a Device
• Plug a device into the module’s port.
• Check the Module A LEDs on the front of the
hub to confirm the link status. A solid green
LED indicates a valid link.
Use the Module
Controls (optional)
Module A Slot
Link\Activity:
Green:Solid = Link
Blink = Activity
Orange: Solid = Disabled
Module A
8
Status:
Off: No module present
On: Module present and
9 1011121314151
functioning
English
The hub’s Module A
expansion slot can
accept either the
Ethernet Module or the
Fiber Module.
Speed
Off: 100Mbps
Orange Solid: 10Mbps
Link\Activity DuplexStatus Speed
Duplex:
Off: Half Duplex
On: Full Duplex
• The Ethernet module will auto-negotiate speed
and duplex.
• The Fiber module can connect to devices at
100Mbps at either half or full duplex.
Intel® Express 300 Series Fiber Module
TX RX
Fiber Ports:
Use 62.5/125-micron fiber
optic cable with an
SC-type connector.
Duplex
Half
Full
Duplex Button: Use
this button to set half or
full duplex.
Crossover
MDI
MDI-X
Crossover Button: Use
this button to connect to
devices using a straightthrough instead of a
crossover cable.
Intel® Express 300 Series
Ethernet Module
Ethernet Port:
Use only CAT 5 UTP to
connect to 100Mbps
devices. To connect to
10Mbps devices use CAT
3, 4, or 5 UTP.
1
1
6
Module A
•
(Module A)
•
Module A
•
2
3
•
• Module A LED
LED
•
• 100Mbps
Intel® Express 300 Series Fiber Module
TX RX
Duplex
100Mbps
10Mbps
Module A
8
Half
Full
9 1011121314151
Crossover
MDI
MDI-X
Link\Activity DuplexStatus Speed
Intel® Express 300 Series
Ethernet Module
CAT 5 UTP
100Mbps
10Mbps
CAT 3 4
5 UTP
62.5/125
SC
2
1
6
2
•
•
•
•
3
8
Module A
9 10 11 12 13 14 15 1
Crossover
MDI
MDI-X
Link\Activity DuplexStatus Speed
Intel® Express 300 Series
Ethernet Module
•
•
•
Intel® Express 300 Series Fiber Module
TX RX
Duplex
Half
Full
3
