Humax F1-4000T User Manual 2

Contents

GB1

Safety ................................................................. GB2

Reference ........................................................... GB4

STB Connections ................................................ GB5 ~ GB8

Remote Control Unit ........................................... GB9 ~ GB10

Guide of Functions ............................................. GB11 ~ GB13

Guide of Main Menu ........................................... GB14 ~ GB33

Troubleshooting Guide ....................................... GB34

Menu Map ........................................................... GB35 ~ GB36

Specification ....................................................... GB37 ~ GB38

Safety

This STB has been manufactured to satisfy the international safety standards. Please read the following safety precautions carefully.

MAINS SUPPLY : 90 - 250V AC 50/60Hz OVERLOADING : Do not overload a wall outlet, extension cord or adapter as this may result

in fire electric shock.

LIQUIDS : The STB shall not be exposed to dripping or splashing and that no objects

filled with liquids, such as base, shall be placed on the apparatus.

CLEANING : Disconnect the STB from the wall outlet before cleaning.

Use a light damp cloth(no solvents) to dust the STB.

VENTILATION : The slots on top of the STB must be left uncovered to allow proper airflow

to the unit. Do not stand the STB on soft furnishings or carpets. Do not expose the STB to direct sunlight or do not place it near a heater. Do not stack electronic equipments on top of the STB.

AT TACHMENTS : Do not use any unrecommended attachments as these may cause hazard

or damage the STB.

CONNECTION TO THE ANTENNA :

Disconnect the STB from the mains before connecting or disconnecting

the cable from the antenna. FAILURE TO DO SO CAN DAMAGE THE ANTENNA.

CONNECTION TO THE TV :

Disconnect the STB from the mains before connecting or disconnecting

the cable from the antenna. FAILURE TO DO SO CAN DAMAGE THE TV.

EARTHING :

LOCATION : Place the STB indoor in order not to expose to lightening, rain or sunlight.

The antenna cable MUST BE EARTHED to the system earth for the antenna. The earthing system must comply with SABS 061.

GB2

CAUTION

To watch Pay Per View programmes, be sure to inform your STB dealer of the STB’s and Smart card’s serial numbers. So that they can pair your STB with your Smart card. Otherwise, you cannot watch the programmes because they are scrambled.

NOTE

When the changed Network Information is sent, Nagravision realizes that the appropriate satellite/cable service information has been changed. And it will re-organize the service information based on the sent Network Information. The message “Network Information updated...” appears on the screen. It is automatically done when changing NIT. The manufacturer can’t change it because it is provided by Nagravision. When the user watches it, the message may suddenly appear during AV playback and simultaneously updating will proceed. (This happens about once a year.) Since this is not an error in operating, do not turn off the power.

• Nagravision is a registered trademark of Kudelski S.A.

• VIACCESSTMis a trademark of France Telecom.

• CryptoWorks(TM) is a trademark of Philips Electronics N.V.

• Irdeto is a trademark of Mindport BV.

• Conax is a trademark of Telenor Conax AS.

• “Dolby” and the double-D symbol are trademarks of Dolby Laboratories.

Warning

HUMAX cannot be held responsible for any kind of problems caused by the use of unofficial software. The use of software versions other than HUMAX official software will void the manufacturer’s warranty. It is advised that only the formal software released from HUMAX should be used in all HUMAX product range.

Glossary

• Antenna A device that collects and radiates electromagnetic waves. Includes a satellite dish and abroadband antenna.

• Forward Error Correction(FEC) A system of error control for data transmission.

• Frequency The number of cycles or events per one second, which is expressed in the unit of Hertz(Hz).

• Intermediate Frequency (IF) A frequency to which a carrier frequency is shifted as an intermediate step in transmission or reception.

• Packet Identifier (PID) A set of numbers that idenitifies transport stream packets containing data from a single data stream.

• Service A channel to which a decoder or TV is tuned.

GB3

Reference

1. Loop Through

If you have another analogue or digital STB and you wish to use the same RF Signal then you can connect it via the loop through. Connect one end of a RF cable to the TV/VCR on the STB and connect the other end to the RF(ANT) on your second STB.

2. Software Upgrade

HUMAX digital set-top box is a highly sophisticated product - incorporating one of the best software applications. Whenever a problem is found with this software or, in fact, extra functions or enhanced applications are added, the software in the equipment has to be upgraded. In order to maintain proper performance of the product, it is essential to have the most up to date software. The latest news and release of software versions may be found at HUMAX website - http://www.humaxdigital.com. It is recommended that users register to HCSA (HUMAX Customer Service Area) and periodically check for the availability of software upgrade. There are three methods to upgrade the software : (a) set-top box to set-top box download (copies the software of the main unit into slave unit); (b) pc to set-top box download (downloads the software directly from pc to the model

requiring upgrade);

decide when and where to release over the air). Over The Air (OTA) is simply another alternative for downloading software versions. However, the manufacturer reserves the right to decide when and where this software upgrade can take place by "beaming" latest software versions over the air.

SUSS (TM) is an official trademark and logo for HUMAX loader software to perform OTA. The software upgrade will only occur under the following circumstances:

1) the equipment should have appropriate loader software;

2) the manufacturer decides to release software downloading;

3) the equipment must be "tuned" properly to the OTAchannel that the manufacturer uses.

GB4

STB Connections

F1-4000T Free-To-Air

NA-4710T 1 Smart card

Front Panel

STANDBY

Press to switch between Operation and Standby modes.

TV/RADIO

Press to switch between TV and Radio modes.

- p +

Use to change services down/up.

- v +

Use to change volume down/up.

STANDBY LED(RED)

Indicates that the STB is under standby.

TV LED(AMBER)

The LED lights on in TV mode.

RADIO LED(GREEN)

The LED lights on in RADIO mode.

DISPLAY

Shows service number, error messages, RCU commands and time in Standby mode.

GB5

Rear Panel

TV SCART

For the audio/video input of the TV.

VCR SCART

For the VCR.

AUDIO/VIDEO OUTPUT

Audio/video signal from your STB to VCR or TV.

ANTENNA

Use to connect a general Aerial Antenna and CABLE jacks to a ANTENNAinput jack on the STB.

TV/VCR

Use to connect a RF signal from your STB to RF(ANT) input jack on your TV or VCR .

RS-232C

Use it when connecting to your PC.

GB6

STB Connections

Example 1

In this example a TV set is connected to the digital receiver. If possible the TV should be connected with the digital receiver through a Scart cable. If the TV doesn’t have a Scart connection or if you want to connect a second TV to the digital receiver, the UHF output of the modulator may be used.

Example 2

In example 2 a VCR and a hifi stereo components system are connected to the digital receiver in addition to the TV. The VCR should be connected through a Scart cable. In this example the hifi stereo components system is connected with the digital receiver through the analogue Cinch connections.

GB7

Remote Control Unit

GB9

NUMERIC BUTTONS

Press to select a service, enter your PIN Code or numeric on the menu.

INFORMATION (RED)

Press to display the programme information box on the screen. And this button functions same as the RED button on the menus.

SOUNDTRACK (GREEN)

Press to display the soundtrack list for the current service. And this button functions same as the GREEN button on the menus.

SUBTITLE (YELLOW)

Press to display the subtitle language list for the current service. And this button functions same as the YELLOW button on the menus.

UHF (BLUE)

Press to set the UHF menu. This button functions same as the BLUE button on the menus.

TIME (WHITE)

Press to display the current time on the screen. Press to reserve services on the Informaion box or EPG. And this button functions same as the WHITE button on the menus.

EXIT

Press to return to the previous menu and screen.

V+/V-

Volume up/down buttons. Press to increase or decrease the volume.

STANDBY

Press to switch between Operation and Standby modes.

TV/DTV

Press to select the TV/DTV mode.

TV/RADIO

Press to select the TV/RADIO mode.

MUTE

Press to temporarily cut off the sound.

Press to display the Main Menu on the screen or return to the screen from a sub menu screen.

CURSOR

Press to move the highlight bar for selecting options on the menus. And this button is used to change services (up/down) and increase or decrease the audio volume.

Press to display the service list. This button is used to select the item on the menus.

P+/P-

Programme up/down buttons. Press to tune to the next or previous service. Press to move up or down pages on the menus.

HELP

Press to display the help box on the screen.

EPG

Electronic Programme Guide button displays the TV/Radio programme guide.

RCL (Recall)

Press to select the service that was previously viewed.

•

Please note

: The design of Remote Control Unit may be changed without notice in advance.

GB10

Guide of Functions

Information Box (I-Plate)

The details of service part and event part are automatically displayed on the I-Plate when pressing the i button( ) or changing services. I-Plate is divided into service part and event part.

SERVICE-PART (Left side of the box)

SERVICE PART consists of the following items:

• I-Plate icon, Current time and Dolby Digital symbol

• Service name, Service number, icons

• Subtitle, Teletext, Scrambling service symbol (These are automatically displayed when the broadcasting station provides appropriate information.)

• Signal quality bar

EVENT-PART (Right side of the box)

EVENT PART consists of the following items:

• Event name, Event duration time

• Description text of event, State of reserved event

Event Part shows the current and next event information.

button : Use to move from the current event information to

the next event information.

button : Use to move from the next event information to

the current event information.

When the HELP( )button is pressed under I-Plate display and there are no detailed event informations in the I-Plate, the Help window will appear on the screen. The Help window shows the current Network information, including: Satellite Name, Frequency, Polarisation, Symbol Rate, FEC... The detailed information for the event can be displayed by pressing the HELP( )button in the I-Plate with event data displaying mode. You can reserve the programme in the event data display mode by using the WHITE( )button. You can reset timer programme Once, Daily or Weekly mode. When you release the timer programme mode, then you will be asked to confirm the action.

GB11
