Humanscale Switch Mouse User Manual

USER MANUAL

Mousing Comfort in the Palm of Your Hand

TABLE OF CONTENTS

1

Features

2

Compatibility

3

Switch Mouse Installation

6

Switch Mouse Adjustments

9

Healthy Mousing

13

Cleaning the Switch Mouse

14

Customer Service

14

Warranty

15

Regulatory Information

16

Disposal of the Switch Mouse

FEATURES

The Switch Mouse is a groundbreaking
mousing solution that boosts comfort and
reduces the risk of injury with design and
technology innovations providing the most
ergonomic mouse ever created.

Extender

Patented length­adjustability
feature fits any
hand

Navigation Dish

Replaces the scrolling wheel and
associated repetitive stress with
one-touch four-direction scrolling

Friction Layer

Improves grip and mousing accuracy

Stabilizer

Enables left- or right-handed use

V-Shaped Base

Accommodates a naturally angled forearm
position to minimize injury risks

Palm Rest

Unique design supports
entire hand to keep
wrist straight and
eliminate contact stress

Programmable
Buttons

Three programmable
buttons—one on each
side and the clickable
navigation dish—
enable user-specified
functions

1

COMPATIBILITY

Certified for Windows Vista

Also compatible with:

Windows 8

Windows 7

Windows XP

Windows 2000

Mac OS 9 (plug-and-play only)

Max OS X (plug-and-play only)

Minimum System Requirements

Available USB port
CPU 233MHz or faster processor or equivalent
128MB RAM or higher
Hard disk capacity more than 40MB

Specifications

Resolution: 1200 dpi
Technology: Laser Scanning Technology
Switch: Micro Switch
Current Consumption: Max70mA
Switch Mechanical Life: 1,000,000 cycles
Cable Length: 200 cm (80")
USB Connector

2

SWITCH MOUSE INSTALLATION

Quick-Start Installation

The Switch Mouse is a plug-and-play device. To begin use immediately:

Shut down your computer and unplug your existing mouse.
Plug the Switch Mouse into a USB port.
Restart your computer and begin using the Switch Mouse.

The default settings are as follows:

- Left Top Button: Single Left Click

- Right Top Button: Single Right Click

- Middle Button (Navigation Dish): Not Assigned

- Left Side Button: Not Assigned

- Right Side Button: Not Assigned

- Navigation Dish: Vertical Page Scrolling

3
