QuickSpecs

Overview

HP Z600 Workstation

1.

Power Button

2.

2 External 5.25" Bays

3.

Front I/O: 3 USB 2.0, 1 IEEE 1394a (optional card required),
Headphone, Microphone

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 1

QuickSpecs

Overview

HP Z600 Workstation

4.

6 DIMM Slots for DDR3 ECC Memory

5.

2 Internal 3.5” Bays

6.

2 External 5.25” Bays

7.

650W, 85% efficient Power Supply

8.

2 Quad Core Intel 5500 Series Processors

Form Factor
Compatible Operating

Systems

Available Processors

Minitower
Genuine Windows 7® Ultimate 64-bit

Genuine Windows 7® Professional 64-bit
Genuine Windows 7® Professional 32-bit
Genuine Windows 7® Professional 64-bit with downgrade to Windows® XP Professional x64
custom installed
Genuine Windows 7® Professional 32-bit with downgrade to Windows® XP Professional 32-bit
custom installed
HP Linux Installer Kit for Linux (includes drivers for both 32-bit & 64-bit OS versions of Red Hat
Enterprise Linux WS4 and WS5 - see:
Red Hat Enterprise Linux® WS5 (as Drop-in-the-box only)
For detailed OS/hardware support information for Linux, see:

http://www.hp.com/support/linux_hardware_matrix

*Systems may require upgraded and/or separately purchased hardware and/or a DVD drive to
install the Windows 7 software and take full advantage of Windows 7 functionality. See

http://www.microsoft.com/windows/windows-7/

Intel® Xeon® Processor X5670 6C 2.93 GHz, 95W, 12M cache, 6.40GT/s QPI, DDR3 1333MHz,
HT, Turbo
Intel® Xeon® Processor X5667 4C 3.06 GHz, 95W, 12M cache, 6.40GT/s QPI, DDR3 1333MHz,
HT, Turbo
Intel® Xeon® Processor X5660 6C 2.80 GHz, 95W, 12M cache, 6.40GT/s QPI, DDR3 1333MHz,

9.

Rear I/O: 6 USB 2.0, PS/2 keyboard/mouse
1 RJ-45 to Integrated Gigabit LAN
1 Audio Line In, 1 Audio Line Out, 1 Microphone In

10.

2 PCIe x16 Gen2 Slots

11.

1 PCIe x4 electrical / x8 mechanical Gen2,
1 PCIe x4 electrical / x8 mechanical Gen1,
2 PCI Slots

12.

3 Internal USB 2.0 ports

*

*
*

http://www.hp.com/workstations/software/linux

for details.

)

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 2

QuickSpecs

Overview

HT, Turbo
Intel® Xeon® Processor X5650 6C 2.66 GHz, 95W, 12M cache, 6.40GT/s QPI, DDR3 1333MHz,
HT, Turbo
Intel® Xeon® Processor E5640 QC 2.66 GHz, 80W, 12M cache, 5.86GT/s QPI, DDR3 1066MHz,
HT, Turbo
Intel® Xeon® Processor E5630 QC 2.53 GHz, 80W, 12M cache, 5.86GT/s QPI, DDR3 1066MHz,
HT, Turbo
Intel® Xeon® Processor E5620 QC 2.40 GHz, 80W, 12M cache, 5.86GT/s QPI, DDR3 1066MHz,
HT, Turbo
Intel Xeon Processor E5507 4C 2.26 GHz, 80W, 4M cache, 4.80GT/s QPI, DDR3 800MHz
Intel Xeon Processor E5506 QC 2.13 GHz, 80W, 4M cache, 4.80GT/s QPI, DDR3 800MHz

Available Processor
Disclaimers

When ordering two processors, the second processor must be the same as the first. Intel
processor numbers are not a measurement of higher performance. Processor numbers
differentiate features within each processor family, not across different processor families. See:

http://www.intel.com/products/processor_number/

Quad-Core technologies are designed to improve performance of multithreaded software products
and hardware-aware multitasking operating systems and may require appropriate operating system
software for full benefits; check with software provider to determine suitability; Not all customers or
software applications will necessarily benefit from use of these technologies.

HP Z600 Workstation

for details.

Additional Details

Form Factor

64-bit computing on Intel® 64 architecture requires a computer system with a processor, chipset,
BIOS, operating system, device drivers, and applications enabled for Intel® 64 architecture.
Processor will not operate (including 32-bit operation) without an Intel® 64 architecture-enabled
BIOS. Performance will vary depending on your hardware and software configurations. See:

http://www.intel.com/info/em64t

Intel® Nehalem Architecture
Up to 6.40GT/s QPI support
3-channel 800/1066/1333 MHz DDR3 memory* subsystem
Up to 48 GB Memory capacity with 6 DIMM slots and 8 GB DIMMs
PCI Express I/O and PCIe x16 Gen2 graphics
Integrated Broadcom 5764 Gigabit LAN on Motherboard (LOM)
6 channels of Serial ATA (SATA) 3.0 Gb/s natively supported internally
SATA RAID** 0, 1, 5, and 10 support standard on motherboard
SAS RAID 0, 1, and 10 supported using the LSI 3041E PCIe controller
SATA optical drives
High Definition integrated audio with internal speaker
650W 85% efficient power supply
ENERGY STAR® qualification and energy-saving features available on selected
configurations (Not supported by Linux)
Protected by HP Services, including a 3 years parts, 3 years labor, and 3 years onsite
service (3/3/3) standard warranty. Terms and conditions vary by country. Certain restrictions
and exclusions apply.

*Each processor supports up to 3 channels of DDR3 memory. To realize full performance at least 1
DIMM must be inserted into each channel. To get full 6 channel support, 2 processors MUST be
installed.
**SATA hardware RAID is not supported on Linux systems. The Linux kernel, with built-in software
RAID, provides excellent functionality and performance. It is a good alternative to hardware-based
RAID. Please visit

http://h20000.www2.hp.com/bc/docs/support/SupportManual/c00060684/c00060684.pdf

capabilities with Linux.

Rackable Minitower

for more information.

for RAID

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 3

QuickSpecs

Overview

HP Z600 Workstation

Color
I/O Slots

board section for more
details)

Bays

section for more details)

Internal Bays
External Bays

Front I/O

Rear I/O

Internal USB

Chassis Dimensions

(H x W x D)

System Weight

Temperature

Humidity

Maximum Altitude

(non-pressurized)

Power Supply

(see system

(see storage

Black/Silver

2 PCI Express Gen2 x16 slots (full-length, full-height)
1 PCI Express Gen2 x4/x8* slot – with x8 open-ended connectors (full-length, full-height)
1 PCI Express Gen1 x4/x8* slot – with x8 open-ended connectors (full-length, full-height)
2 PCI 32bit/33MHz slot, (full-length, full-height)

*These slots have 4 PCI Express lanes routed to them. They are sometimes called "x4 electrial, x8
mechanical" slots.

The PCIe x8 connectors are open ended, allowing a PCIe x16 card to be seated in the slot.
Total Bays = 4

2 internal 3.5" bays (with acoustic dampening rail assemblies)
2 external 5.25" bays

(3rd & 4th HDDs occupy one external bay)
3 USB 2.0, 1 Headphone Out, 1 Microphone In. 1 IEEE 1394a integrated with systems

manufactured beginning 3/22/10.
6 USB 2.0

1 RJ-45 to integrated Gigabit LAN
2 legacy PS/2
1 Audio Line In, 1 Audio Line Out, 1 Microphone In; audio ports can be retasked to function as line
in, line out, microphone, or headphone.
Serial supported with optional rear bulkhead adapter.

3 USB 2.0 headers
[3 USB 2.0 ports available by one 2x5 header and one 1x5 header: supports either up to two HP
Internal USB Port Kits, AMO- EM165AA (one port on each Kit), or one Internal Port kit and one
USB Media Card Reader.]

44.51 x 16.53 x 44 cm (17.5 x 6.5 x 17.3 in)

Exact weights depend upon configuration
Minimum config - 15.0 kg (33.0 lb)
Typical config - 16.9 kg (37.4 lb)
Maximum config - 19.6 kg (43.3 lb)
(Maximum shipping weight - 23.6 kg/52.0 lb)

Operating:
Non-operating
Operating:
Non-operating
Operating:
Non-operating
650W 85% Efficient wide-ranging, active Power Factor Correction, with tool-free & cable-free

connection

5° to 35° C (40° to 95° F)

-40° to 60° C (-40° to 140° F)
8% to 85%
8% to 90%
3,000 m; 10,000 feet
9,100 m; 30,000 feet

Interfaces Supported

The Power Supply Efficiency Report for this product may be found at this link:

http://www.80plus.org/manu/psu/psu_reports/SO-034_DELTA_DPS-25AB%20A_650W_
Report_mod.pdf

6-channel SATA 3.0 Gb/s Interface (6 Serial-ATA connectors on the motherboard, 4 channels are
eSATA configurable for use with eSATA CTO/AMO Kit)
SAS interface supported with optional LSI 3041E 4-port SAS/SATA PCIe card.
1 Floppy interface (1 Floppy connector), USB 2.0. 1 IEEE 1394a interface with systems
manufactured beginning 3/22/10.

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 4

QuickSpecs

Overview

HP Z600 Workstation

Hard Drive Controllers
Supported

Backup Devices

SATA and SAS controllers

For a complete listing of compatible DAT tape drives, LTO tape drives and RDX Removable Disk
Backup System offerings, please visit:

http://www.hp.com/go/connect

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 5

QuickSpecs

Supported Components

HP Z600 Workstation

Processors

Option

Factory

Quad-Core Intel Xeon Processor 5500 Series with Intel® 64 Architecture

Intel Xeon E5506, 2.13GHz, 4MB cache, 800MHz
Memory, 4.80 GT/s QPI, 80W

Intel Xeon E5507, 2.26 GHz, 4MB cache, 800MHz
Memory, 4.80GT/s QPI, 80W

Four-Core and Six-Core Intel Xeon Processor 5600 Series with Intel® 64 Architecture

Intel® Xeon® Processor X5670 6C 2.93 GHz, 95W,
12M cache, 6.40GT/s QPI, DDR3 1333MHz, HT,
Turbo

Intel® Xeon® Processor X5667 6C 3.06 GHz, 95W,
12M cache, 6.40GT/s QPI, DDR3 1333MHz, HT,
Turbo

Intel® Xeon® Processor X5660 6C 2.80 GHz, 95W,
12M cache, 6.40GT/s QPI, DDR3 1333MHz, HT,
Turbo

Intel® Xeon® Processor X5650 6C 2.66 GHz, 95W,
12M cache, 6.40GT/s QPI, DDR3 1333MHz, HT,
Turbo

Intel® Xeon® Processor E5640 4C 2.66 GHz, 80W,
12M cache, 5.86GT/s QPI, DDR3 1066MHz, HT,
Turbo

Intel® Xeon® Processor E5630 4C 2.53 GHz, 80W,
12M cache, 5.86GT/s QPI, DDR3 1066MHz, HT,
Turbo

Intel® Xeon® Processor E5620 4C 2.40 GHz, 80W,
12M cache, 5.86GT/s QPI, DDR3 1066MHz, HT,
Turbo

NOTE 1

processor numbers are not a measurement of higher performance. Processor numbers
differentiate features within each processor family, not across different processor families. See:

http://www.intel.com/products/processor_number/

: When ordering two processors, the second processor must be the same as the first. Intel

Configured

Y Y

Y Y

Y Y

Y Y

Y Y

Y Y

Y Y

Y Y

Y Y

for details.

Option

Kit

Kit Part

Number

NF147AA

WG727AA

WG734AA

WG733AA

WG732AA

WG731AA

WG730AA

WG729AA

WG728AA

Support

Notes

Quad-Core technologies are designed to improve performance of multithreaded software products
and hardware-aware multitasking operating systems and may require appropriate operating system
software for full benefits; check with software provider to determine suitability; Not all customers or
software applications will necessarily benefit from use of these technologies.

64-bit computing on Intel® 64 architecture requires a computer system with a processor, chipset,
BIOS, operating system, device drivers, and applications enabled for Intel® 64 architecture.
Processor will not operate (including 32-bit operation) without an Intel® 64 architecture-enabled
BIOS. Performance will vary depending on your hardware and software configurations. See:

http://www.intel.com/info/em64t

Intel's numbering is not a measurement of higher performance.

Support for Xeon 5600 Series processors requires the C2 revision of the Intel 5520 chipset. Two
methods are available to determine if a specific Z600 system has the C2 revision of the chipset. 1.

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

for more information.

Page 6

QuickSpecs

Supported Components

Use the BIOS setup menu to access the “Boot Block Date” from the “System Information Menu”. All
B3-based systems will have a “1/30/09” date and C2-based systems will have a "01/07/10" date. 2.
HP Performance Advisor SW can be used to determine the PCA ID, which is reported by
Performance Advisor under “System Configuration” and “Baseboard ID”. All B3-based systems will
have the ID "0AE8h" and all C2-based systems will have the ID "0B54h".

HP Z600 Workstation

SAS Hard Drives

SATA Hard Drives

SATA Solid State
Drives

Option

Factory

HP SAS (Serial Attached SCSI) Hard Drives for HP Workstations

146GB SAS 15K rpm 3Gb/s 3.5" HDD

300GB SAS 15K rpm 3Gb/s 3.5" HDD

450GB SAS 15K rpm 3Gb/s 3.5" HDD

600GB SAS 15K rpm 3.5" HDD (6Gb/s enabled)

Sub-Section Description/Notes

(SAS Controller, not integrated, is required)

SATA (Serial ATA) Hard Drives for HP Workstations

160GB SATA 7200 rpm 3Gb/s 3.5" HDD

250GB SATA 7200 rpm 3Gb/s 3.5" HDD

320GB SATA 7200 rpm 3Gb/s 3.5" HDD

500GB SATA 7200 rpm 3Gb/s 3.5" HDD

1000GB (1TB) SATA 7200 rpm 3.0Gb/s 3.5" HDD

1.5TB SATA 7200 rpm 3Gb/s 3.5" HDD

2.0TB SATA 7200 rpm 3Gb/s 3.5" HDD

160GB SATA 10K rpm SFF in 3.5" Frame HDD

300GB SATA 10K rpm SFF in 3.5" Frame HDD

600GB SATA 10K rpm SFF in 3.5" Frame HDD

Sub-Section Description/Notes

(2.5" SFF drives cannot be mixed with 3.5" drives)

HP Solid State Drive for Workstations

HP 64GB SATA SLC Solid State Drive (SFF in 3.5"
Frame)

HP 160GB SATA X25-M SSD

For hard drives, 1 GB = 1 billion bytes; TB = 1 trillion bytes. Actual formatted capacity is less. Up to
12 GB of hard drive (or system disk) is reserved for the system recovery software (XP and XP Pro).
Up to 3 GB of system disk is reserved for system recovery software (Vista).
Up to 3 of the following 3.5" SATA and 3.5" 15K SAS drives, or up to 4 of the 2.5" small form factor
(SFF) 10K SATA drives are allowed.

Configured

Y Y

Y Y

Y Y

Y Y

Y Y

Y Y

Y Y

Y Y

Y Y

Y Y

Y Y

Y Y

Y Y

Y Y

Y Y

Y Y

Option

Kit

Kit Part

Number

EA330AA

EM174AA

FM803AA

VM647AA

PV944A

PY278AA

FH963AA

PV943A

GE262AA

VH997AA

WE464AA

EW222AA

FM802AA

XP309AA

NW778AA

WV915AA

Support

Notes

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 7

QuickSpecs

Supported Components

HP Z600 Workstation

Hard Drive
Controllers

Option Kit

Factory

Integrated SATA 3.0 Gb/s Controller

Integrated SATA 3.0 Gb/s Controller, RAID 0,
1, 10, 5 supported

Factory integrated RAID on motherboard for SATA drives

RAID 0 Configuration – Striped Array

RAID 1 Configuration – Mirrored Array

LSI 3041E 4-Port SAS 3.0 Gb/s RAID Card

LSI 3041E 4-Port SAS 3.0 Gb/s RAID Card

LSI MegaRAID® SAS 8888ELP Host Bus Adapter (HBA)

LSI 8888ELP 8-port SAS HW RAID Card

All RAID arrays must be less than 2 TB in size

NOTE 1

HDD. No Linux support for SATA RAID.

NOTE:

Linux. Please visit:

LSI RAID Definitions

SATA hardware RAID is not supported on Linux systems. The Linux kernel, with built-in software
RAID, provides excellent functionality and performance. It is a good alternative to hardware-based
RAID. Please visit

http://h20000.www2.hp.com/bc/docs/support/SupportManual/c00060684/c00060684.pdf

capabilities with Linux.
IS: Striping of 2 or more HDDs into a single logical volume
IM: Mirroring of 2 HDDs into a single logical volume
IME: Mirroring of 3 or more HDDs into a single logical volume

: Requires 2 identical hard drives (speeds, capacity, interface). RAID 1 does not support a 3rd

Specific user-configured hardware SAS RAID configurations are supported on this system with

http://www.hp.com/support/linux_hardware_matrix

:

Configured

Y

Y

Y

Y Y

N

Option

Kit

N

N

N

Y

for details.

Part

Number

EH417AA

GE258AA

for RAID

Support

Notes

See note 1

See note 1

Graphics

NOTE:

system. Please visit:

Specific user-configured hardware SAS RAID configurations are supported on this Linux

http://www.hp.com/support/linux_hardware_matrix

Professional 2D

NVIDIA Quadro NVS 295 256MB PCIe
Graphics Card

NVIDIA Quadro NVS 450 512 MB
PCIe Graphics Card

NVIDIA NVS300 512MB PCIe
Graphics Card

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

for details

Option

Factory

Configured

Y Y

Y Y

Y Y

Option

Kit

Kit Part

Number

FY943AA

FH519AA

XP612AA

Support

Notes

2nd card must

be NVS 450

or NVS 295

2nd card must

be NVS 450

or NVS 295

2nd card must

be NVS 450

or NVS 300

Supported

Multi

Mixed

2 X

2 X

2 X

Page 8

QuickSpecs

Supported Components

HP Z600 Workstation

NVIDIA Quadro NVS 290 256 MB
PCIe Graphics Card with 'DMS-59 to
Dual DVI cable' included – for
Workstations

Entry 3D

NVIDIA Quadro FX 380 256MB PCIe
Graphics Card

ATI FirePro V3700 256MB PCIe
Graphics Card

NVIDIA Quadro FX 580 512MB PCIe
Graphics Card

NVIDIA Quadro 600 1GB Graphics
Card

ATI FirePro V3800 512MB PCIe
Graphics Card

ATI FirePro V4800 1GB Graphics Card

Mid-range 3D

NVIDIA Quadro FX 1800 768MB PCIe
Graphics Card

NVIDIA Quadro 2000 1GB Graphics
Card

ATI FirePro V5700 512MB PCIe
Graphics Card

ATI FirePro V5800 1GB Graphics Card

High End 3D

NVIDIA Quadro FX 3800 1.0GB PCIe
Graphics Card

ATI FirePro V7750 1.0GB PCIe
Graphics Card

NVIDIA Quadro 4000 2GB Graphics
Card

NVIDIA Quadro FX 4800 1.5GB PCIe
Graphics Card

NVIDIA Quadro 5000 2.5GB Graphics
Card

N

Y Y

Y Y

Y Y

Y Y

Y Y

Y Y

Y Y

Y Y

Y Y

Y Y

Y Y

Y Y

Y Y

Y Y

Y Y

Y

GN502AA

NB769AA

FY944AA

FY945AA

WS093AA

WL048AA

WL049AA

FY946AA

WS094AA

FY947AA

WL050AA

FY949AA

FY948AA

WS095AA

FQ138AA

WS096AA

1 or 2 of

these cards

are supported

– 2nd card

must be NVS

290

2

2

2

2

2

2

2

2

2

2

2

1

1

1

1

1

Memory

CTO

PC3-10600 DDR3-1333 ECC Unbuffered DIMMs CTO

1GB (1x1GB) DDR3-1333 ECC Unbuffered RAM 1-CPU

2GB (2x1GB) DDR3-1333 ECC Unbuffered RAM 1-CPU

3GB (3x1GB) DDR3-1333 ECC Unbuffered RAM 1-CPU

4GB (2x2GB) DDR3-1333 ECC Unbuffered RAM 1-CPU

6GB (3x2GB) DDR3-1333 ECC Unbuffered RAM 1-CPU

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Option Kit Part

Number

Support Notes

Page 9

QuickSpecs

Supported Components

HP Z600 Workstation

8GB (2x4GB) DDR3-1333 ECC Unbuffered RAM 1-CPU

8GB (2x2GB + 1x4GB) DDR3-1333 ECC Unbuffered
RAM 1-CPU

12GB (3x4GB) DDR3-1333 ECC Unbuffered RAM 1­CPU

2GB (2x1GB) DDR3-1333 ECC Unbuffered RAM 2-CPU

4GB (4x1GB) DDR3-1333 ECC Unbuffered RAM 2-CPU

4GB (2x2GB) DDR3-1333 ECC Unbuffered RAM 2-CPU

6GB (6x1GB) DDR3-1333 ECC Unbuffered RAM 2-CPU

8GB (4x2GB) DDR3-1333 ECC Unbuffered RAM 2-CPU

8GB (2x4GB) DDR3-1333 ECC Unbuffered RAM 2-CPU

12GB (6x2GB) DDR3-1333 ECC Unbuffered RAM 2­CPU

16GB (4x4GB) DDR3-1333 ECC Unbuffered RAM 2­CPU

16GB (4x2GB + 2x4GB) DDR3-1333 ECC Unbuffered
RAM 2-CPU

24GB (6x4GB) DDR3-1333 ECC Unbuffered RAM 2­CPU

PC3-10600 DDR3-1333 ECC Registered DIMMs CTO

8GB (2x4GB) DDR3-1333 ECC Registered RAM 1-CPU

Both processor

sockets must be

populated.

Both processor

sockets must be

populated.

Both processor

sockets must be

populated.

Both processor

sockets must be

populated.

Both processor

sockets must be

populated.

Both processor

sockets must be

populated.

Both processor

sockets must be

populated.

Both processor

sockets must be

populated.

Both processor

sockets must be

populated.

Both processor

sockets must be

populated.

12GB (3x4GB) DDR3-1333 ECC Registered RAM 1­CPU

16GB (2x8GB) DDR3-1333 ECC Registered RAM 1­CPU

24GB (3x8GB) DDR3-1333 ECC Registered RAM 1­CPU

8GB (2x4GB) DDR3-1333 ECC Registered RAM 2-CPU

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Both processor

sockets must be

populated.

Page 10

QuickSpecs

Supported Components

HP Z600 Workstation

16GB (4x4GB) DDR3-1333 ECC Registered RAM 2­CPU

24GB (6x4GB) DDR3-1333 ECC Registered RAM 2­CPU

32GB (4x8GB) DDR3-1333 ECC Registered RAM 2­CPU

48GB (6x8GB) DDR3-1333 ECC Registered RAM 2­CPU

Sub-Section Description/Notes

The Z600 has a three-channel memory architecture. Three channels are associated with each
processor. For optimal performance, populate a DIMM in each channel.

AMO

PC3-10600 DDR3-1333 ECC Unbuffered DIMMs AMO

1GB (1x1GB) DDR3-1333 ECC Unbuffered RAM

2GB (1x2GB) DDR3-1333 ECC Unbuffered RAM

4GB (1x4GB) DDR3-1333 ECC Unbuffered RAM

PC3-10600 DDR3-1333 ECC Registered DIMMs AMO

8GB (1x8GB) DDR3-1333 ECC Registered RAM

4GB (1x4GB) DDR3-1333 ECC Registered RAM

NOTE:

speed at which they operate is dependent upon the processor.
Support for Registered DIMMs on the Z600 requires a systemboard with the C2 revision of the
Intel 5520 chipset. Two methods are available to determine if a specific Z600 system has the C2
revision of the chipset. 1. Use the BIOS setup menu to access the “Boot Block Date” from the
“System Information Menu”. All B3-based systems will have a “1/30/09” date and C2-based
systems will have a "01/07/10" date. 2. HP Performance Advisor SW can be used to determine
the PCA ID, which is reported by Performance Advisor under “System Configuration” and
“Baseboard ID”. All B3-based systems will have the ID "0AE8h" and all C2-based systems will
have the ID "0B54h".

Although all of these memory configurations incorporate 1333MHz memory modules, the

FX698AA

FX699AA

NL797AA

FX622AA

FX621AA

Both processor

sockets must be

populated.

Both processor

sockets must be

populated.

Both processor

sockets must be

populated.

Both processor

sockets must be

populated.

Both processor

sockets must be

populated.

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 11

QuickSpecs

Supported Components

HP Z600 Workstation

Multimedia and Audio
Devices

Optical and
Removable Storage

Factory

Configured

Integrated Intel/Realtek HD ALC262 Audio

HP Thin USB Powered Speakers

Creative X-Fi Titanium PCIe Audio Card

Logitech® QuickCam® Pro 9000 USB Camera Audio
Headset with Boom Microphone

Omni Directional USB Powered Speakers, Desktop
Microphone, SoundBlaster® X-Fi™2 XtremeGamer
Audio Card, PCIe

NOTE 1:

Workstations
with Microsoft Windows XP Pro 32-bit and 64-bit and Microsoft Vista 32-bit and 64-bit versions.
Linux is not supported.

HP 16X DVD-ROM SATA Drive

HP 16X DVD+-RW SuperMulti SATA Drive

HP Slot Load DVD+/-RW Drive

HP Blu-ray Writer

HP 22-in-1 Media Card Reader Kit (Workstations)

HP DX115 Removable Drive Enclosure

HP DX115 Carrier with 160GB SATA HDD

HP DX115 Removable HDD Frame/Carrier

HP DX115 Removable HDD Carrier

Actual speeds may vary. Does not permit copying of commercially available DVD movies or other
copyright protected materials. Intended for creation and storage of your original material and other
lawful uses. Double Layer discs can store more data than single layer discs. However, double-layer
discs burned with this drive may not be compatible with many existing single-layer DVD drives and
players.

The SoundBlaster X-Fi Titanium audio card is supported on the HP Z Series

Factory

Configured

Y

Y Y

Y Y

N

N

Y Y

Y Y

Y

Y Y

Y Y

N

N

N

Option

Kit

N

Y

Y

Option

Kit

N

Y

Y

Y

Option

Kit Part

Number

KK912AA

NH222AA

NG855AA

NG857AA

Option

Kit Part

Number

AR629AA

AR630AA

AR482AA

NK361AA

FZ577AA

FX576AA

NB792AA

Support

Notes

See note

1

Support

Notes

See note 1

As Blu-ray is a new format containing new technologies, certain disc, digital connection,
compatibility and/or performance issues may arise, and do not constitute defects in the product.
Flawless playback on all systems is not guaranteed. In order for some Blu-ray titles to play, they
may require a DVI or HDMI digital connection and your display may require HDCP support. HD­DVD movies cannot be played on this workstation.

NOTE 1

: Not supported as a 2nd Optical Drive.

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 12

QuickSpecs

Supported Components

HP Z600 Workstation

Controller Cards

Monitors

HP FireWire/IEEE 1394a PCI Card

HP IEEE 1394b FireWire PCIe Card

HP LP2065 20-inch LCD Monitor

HP LP2475w 24-inch Widescreen LCD Monitor

HP DreamColor LP2480zx Professional Display

HP LP3065 30-inch Widescreen LCD Monitor

HP ZR22w 21.5-inch S-IPS LCD Monitor

HP ZR24w 24-inch S-IPS LCD Monitor

HP ZR30w 30-inch S-IPS LCD Monitor

Supported by all Operating Systems available from HP

Screen size diagonally measured

Factory

Configured

Y Y

Y Y

Factory

Configured

Y Y

Y Y

Y Y

Y Y

Y Y

Y Y

Y Y

Option

Kit

Option

Kit

Option

Kit Part

Number

PA997A

NK653AA

Option

Kit Part

Number

EF227A4

KD911A4

GV546A4

EZ320A4

VM626A4

VM633A4

VM617A4

Support

Notes

Support

Notes

Networking and
Communications

Racking and Physical
Security

Factory

Configured

Integrated Broadcom 5764 PCIe LOM Controller

Broadcom NetXtreme Gigabit Ethernet Plus NIC
(PCIe)

HP NC360T PCI Express Dual Port Gigabit NIC

Intel Gigabit CT Desktop NIC

The Broadcom NetXtreme Plus card may be used, along with the integrated 5764 LOM, for
teaming, redundancy, or additional network bandwidth.

"Gigabit" Ethernet indicates compliance with IEEE standard 802.3ab for Gigabit Ethernet, and does
not connote actual operating speed of 1 Gb/sec. For high speed transmission, connection to a
Gigabit Ethernet server and network infrastructure is required.

Security Cable with Kensington Lock

HP Solenoid Hood Lock & Hood Sensor

HP (CMT) Solenoid Lock

HP Z6/Z8 Adjustable Sliding Rail Rack Kit

Y

Y Y

N

N

Configured

Option

Kit

N

Y

Y

Factory

N

Y

N

N

Option

Kit Part

Number

FS215AA

KU004AA

FH969AA

Option

Kit

Y

N

Y

Y

Option

Kit Part

Number

PC766A

DE618A

NN124AA

Support

Notes

Support

Notes

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 13

QuickSpecs

Supported Components

HP Z600 Workstation

Input Devices

Other Hardware

HP PS/2 Standard Keyboard

HP USB Standard Keyboard

HP PS/2 Optical Scroll Mouse

HP USB 2-Button Optical Scroll Mouse

HP USB Laser Mouse

HP USB Optical 3-Button Mouse

HP USB Smart Card Keyboard

HP 2.4GHz Wireless Keyboard & Mouse

HP USB Optical 3-Button 2.9M OEM Mouse

HP SpaceExplorer 3D USB Controller

HP SpacePilot 3D USB Intelligent Controller

HP Workstation Mouse Pad

HP Power Cord Kit

HP eSATA PCI Cable Kit

HP Serial Port Adapter

HP Internal USB Port Kit

HP Workstation to LTO SAS Int. Cable

HP Optical Bay HDD Mounting Bracket

HP ENERGY STAR 5.0 Enabled Configuration

Factory

Configured

Y Y

Y Y

Y Y

Y Y

Y Y

Y Y

N

N

N

N

N

Factory

Configured

Y

N

N

N

N

N

Y Y

Y

Option

Option

Kit

N

Y

Y

Y

Y

Y

N

Kit

Y

Y

Y

Y

Y

Option

Kit Part

Number

DM293A

GM110AA

PA716A

EM165AA

EH925A

NQ099AA

Option

Kit Part

Number

DT527A

DT528A

EY703AA

DC172B

GW405AA

DY651A

ED707AA

NB896AA

ET424AA

RY429AA

EF390AA

Japan only.

Provides 1st

Serial Port for

the Z600.

Support

Notes

Support

Notes

For 3.5"

HDDs

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 14

QuickSpecs

Supported Components

HP Z600 Workstation

Software

HP SkyRoom Software

HP Performance Tuning Framework

Roxio Easy Media Creator (CD or DVD burner)

Intervideo WinDVD with DVD player

HP Backup and Recovery

PDF Complete

Microsoft Office 2007 Small Business Edition

Microsoft Office 2007 Trial Edition

HP Client Manager Software v6.2 (optional
download)

HP ProtectTools Security

Elemental Accelerator for NVIDIA Quadro

HP Power Assistant

Parallels Workstation 4.0 Extreme

Factory

Configured

Y

Y

Y

Y

Y

Y

Y

Y

Y

Y

Y

Y

Y

Option

Kit

N

N

N

N

N

N

N

N

N

N

N

N

N

Option

Kit Part

Number

Support

Notes

Supported on

Windows XP

ONLY

Must select as

a Configure to

Order Option.

Delivered as a

"Drop in the

Box" CD

Supported

with dual

NVIDIA

Quadro 2000

graphics
cards and a
minimum of

8GB of

system

memory.

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 15

QuickSpecs

Supported Components

HP Z600 Workstation

Operating Systems

Genuine Windows® 7 Ultimate
64-bit

Genuine Windows® 7
Professional 64-bit

Genuine Windows® 7
Professional 32-bit

HP Linux Installer Kit

Red Hat Linux Workstation 5
Drop In Box OS

Support Notes

Systems may require upgraded and/or separately purchased
hardware and/or a DVD drive to install the Windows 7 software
and take full advantage of Windows 7 functionality. See

http://www.microsoft.com/windows/windows-7/

Systems may require upgraded and/or separately purchased
hardware and/or a DVD drive to install the Windows 7 software
and take full advantage of Windows 7 functionality. See

http://www.microsoft.com/windows/windows-7/

Systems may require upgraded and/or separately purchased
hardware and/or a DVD drive to install the Windows 7 software
and take full advantage of Windows 7 functionality. See

http://www.microsoft.com/windows/windows-7/

see:

http://www.hp.com/workstations/software/linux

This second OS must be ordered with The HPIKL as the first
OS. It is a Drop In the Box (DIB) Red Hat registration card
redeemed directly with Red Hat SW company (using the URL
and Subscription / registration number), NOT through HP.

for details.

for details.

for details.

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 16

QuickSpecs

System Technical Specifications

System Board

System Board Form
Factor

Processor Socket

CPU Bus Speed

Chipset

Super I/O Controller

Memory Expansion
Slots

Memory Type
Supported

Memory Modes

Memory Speed
Supported

Memory

Maximum Memory

36 x 28 cm

14.2 x 11 inches

Dual LGA 1366

QPI: Up to 6.4GT/second, depending on processor

Intel® 5520

SMSC SCH5327, Rev B

6 (3 per processor)

DDR3, UDIMM (Unbuffered), ECC: 1GB, 2GB, and 4GB
DDR3, RDIMM (Registered), ECC: 4GB and 8GB

NUMA (Non-Uniform Memory Architecture), Memory Node Interleave

800, 1066, & 1333MHz

Supports up to 48GB

HP Z600 Workstation

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 17

QuickSpecs

System Technical Specifications

HP Z600 Workstation

Memory Configuration

(Supported)

PCI Express
Connectors

0.7 connectors)

PCI Connectors

Interfaces Supported

Serial Attached SCSI

Integrated RAID

(Gen2 Rev

(5.0V)

Not all memory configurations possible are represented above.
Only ECC DIMMs are supported.
Do not install memory modules into memory slots if corresponding processor is not
installed.
Dual processor configurations with memory modules installed for only one processor is not
supported.
UDIMM (Unbuffered) and RDIMM (Registered) memory cannot be mixed. All memory
installed in the system must be either UDIMM or RDIMM.

2 PCI Express x16 Gen2 graphics
1 PCI Express Gen2 (x8 mechanically, x4 electrically)
1 PCI Express Gen1 (x8 mechanically, x4 electrically)

2 full length 33 MHz 32-Bit

SATA

Requires Optional PCIe card

Integrated SATA RAID

RAID 0, RAID 1*, RAID 5, RAID 10
Supports one RAID array with 2-4 drives
RAID 0 configuration – striped array (supported and configure to order)
RAID 1 configuration – mirrored array (supported and configure to order)
RAID 5 parity striping (supported but not configure to order)
RAID 10 striped and mirrored array (supported but not configure to order)

Integrated 6-channel SATA 3.0Gb/sec controller with
RAID 0, 1, 5, 10 and NCQ. (Factory integrated RAID is
Microsoft Windows only)

Integrated Graphics

NOTES

the Red Hat Operating system instead.

No

: *HW RAID functionality not supported by Linux. Use SW RAID functionality provided in

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 18

QuickSpecs

System Technical Specifications

HP Z600 Workstation

Network Controller

SATA Connectors

IEEE 1394a or 1394b

IEEE 1394 Connector(s)

USB Connector(s)

HD Integrated Audio

Flash ROM

Clear Fan Header

CPU Fan Header

Chassis Fan Header

Front PCI Fan Header

Front Control
Panel/Speaker Header

CMOS Battery Holder –
Lithium

Integrated Trusted
Platform Module

Power Supply Headers

Controller Broadcom 5764 PCI-E LAN Controller
Memory Integrated 48KB receive buffer and 8KB transmit buffer
Data rates supported 10/100/1000 Mb/s
Compliance IEEE 802.3, 802.3AB and 802.3u compliant, 802.3x flow control
Bus architecture PCIe 1.0a
Data path width X1
Data path speed 2.5Gbit per sec per direction transfer rate
Data transfer mode Bus-master DMA
Power requirement 1.0 watts @ +3.3V AUX supply
Boot ROM support Yes
Network transfer rate 10BASE-T (half-duplex) 10 Mb/s
10BASE-T (full-duplex) 20 Mb/s
100BASE-TX (half-duplex) 100 Mb/s
100BASE-TX (full-duplex) 200 Mb/s
1000BASE-T (full-duplex) 2000 Mb/s
Microsoft Windows Vista Business 32 and 64, Microsoft Windows XP Professional 32 and 64
Management capabilities WOL, PXE 2.1 and ASF 2.0

6 ports/connectors (Include 4 are eSATA configurable with optional eSATA After-Market Option
cable kit)

Integrated 1394a (beginning with systems manufactured 3/22/10)
No integrated 1394b – optional PCIe card required.
Cable from Front IO can be plugged into PCI Card.
Not supported in Linux

Front

Rear

Internal

Front

Rear

Internal

High Definition Integrated Realtek ALC262 Audio with Line in, Line Out, Microphone, Headphone
Line-in, Line-out, Mic-in x2, and Headphone jacks

Yes

No

One for each CPU socket

2 Rear System Chassis Fan Header
1 Front Chassis Fan Header

Yes

Yes

Yes

TPM 1.2, Infineon

Yes

1 IEEE 1394a (requires optional PCI card to function with
systems manufactured before 3/22/10 only)

No

No

3 on header for front

6

3 [3 USB 2.0 ports available by one 2x5 header and one
1x5 header: supports either up to two HP Internal USB
Port Kits, AMO- EM165AA (one port on each Kit), or one
Internal Port kit and one USB Media Card Reader.]

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 19

QuickSpecs

System Technical Specifications

HP Z600 Workstation

Power Switch, Power
LED & Hard Drive LED
Header

Clear Password
Jumper

Serial Port

Parallel Port

Keyboard/Mouse

Power Supply

Operating Voltage
Range

Rated Voltage Range

Rated Line Frequency

Operating Line
Frequency Range

Rated Input Current

Heat Dissipation

Power Supply Fan

ENERGY STAR®
qualified (Config
Dependent)

80 PLUS Compliant

FEMP Standby Power
Compliant 115V (Wake­on LAN disabled) (<2W
in S5 - Power Off)

Power consumption in
sleep mode (as defined
by ENERGY STAR) –
Suspend to RAM (S3)

Built-in Self Test (BIST)
LED

Surge Tolerant Full
Ranging Power Supply

(withstands power
surges up to 2000V)

Hood Lock Header

Hood Sensor Header

Multibay Header

Integrated Gigabit
Ethernet

Wake on LAN

Yes

Yes

Optional

No

PS/2

650 watt 85% efficient custom power supply
(Wide Ranging, Active PFC)

90 – 269 VAC

100 - 240 VAC

50/60Hz

47-66Hz

10 A @ 100-240 VAC

Typical = 434 btu/hr (109 kg-cal/hr)
Maximum = 964 btu/hr (243 kg-cal/hr)

92x25 mm variable speed

Yes

Yes. For the ECOs PSU Efficiency Report for the power supply, please go to this link:

http://www.80plus.org/manu/psu/psu_reports/SO-034_DELTA_DPS­725AB%20A_650W_Report_mod.pdf

Yes

<5W

Yes

Withstands power surges up to 2000V

Yes

Yes
Integrated in Front Control Panel Cable

No

Integrated Broadcom 5764 Gigabit Ethernet LOM

Yes

.

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 20

QuickSpecs

System Technical Specifications

HP Z600 Workstation

ASF 1.0/2.0

Standard Format)

TPM

Password Clear Header

CD-ROM; analog audio
cable

AUX; analog audio in

Clear CMOS Button

Chassis Speaker
Header

ENERGY STAR®
qualified

Dependent)

Z600 Required Power Supply Info

Power Supply

Operating Voltage Range

Rated Voltage Range

Rated Line Frequency

Operating Line Frequency Range

Rated Input Current

Heat Dissipation (Configuration and software
dependent)

Power Supply Fan

Energy Star Compliant (config dependent)

80 PLUS® Compliant

FEMP Standby Power Compliant@115V (Wake­on LAN disabled)(<2W in S5-Power Off)

EuP Compliant@230V (<1 W in S5-Power Off)

Power Consumption in sleep mode (as defined
by ENERGY STAR) - Suspend to RAM (S3)
(Instantly Available PC) measured at 115V.

Built-in Selft Test LED

Surge Tolerant Full Ranging Power Supply
(withstands power surges up to 2000V

(Alert

(Config

Yes

Integrated TPM 1.2; Infineon

Yes

No

No

Yes

Yes (Integrated in Front Control Panel Cable)

Yes

650 watt custom power supply – (Wide Ranging Active PFC)

90 - 269 VAC

100 – 240 VAC

50-60 Hz

47 – 66 Hz

10 A @ 110-127 VAC

6 A @ 200-240 VAC

Typical 1578 btu/hr (397.7 kg-cal/hr)

Maximum 2705 btu/hr (681.8 kg-cal/hr)

2x60x25 mm variable speed (sleeve-bearing)fans

YES

YES

YES

YES

<9W

YES

YES

118 VAC

400 Hz

393 – 407 Hz

10 A @118 VAC

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 21

QuickSpecs

System Technical Specifications

HP Z600 Workstation

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 22

QuickSpecs

System Technical Specifications

HP Z600 Workstation

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 23

QuickSpecs

System Technical Specifications

HP Z600 Workstation

Declared Noise Emissions

System Configuration
(Entry level)

Processor Info

Memory Info

Graphics Info

Disks/Optical/Floppy

(Entry-level and High-end configurations)

Dual Intel Xeon X5570 2.93Ghz processors

4 x 1GB 1333Mhz

nVidia Quadro NVS 295

250GB 7200 rpm SATA / 1 DVD-ROM/ 1 Floppy

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 24

QuickSpecs

System Technical Specifications

HP Z600 Workstation

Declared Noise
Emissions

accordance with ISO
7779 and ISO 9296)

(in

System Configuration
(High-end)

Declared Noise
Emissions

accordance with ISO
7779 and ISO 9296)

(in

Environmental
Requirements

Idle

SATA Hard drive
Operating

reads)

Floppy Drive Operating

(continuous copy)

DVD-ROM Operating

(sequential reads)

Processor Info

Memory Info

Graphics Info

Disks/Optical/Floppy

Idle

SATA Hard drive
Operating

reads)

Floppy Drive Operating

(continuous copy)

DVD-ROM Operating

(sequential reads)

Temperature

Humidity

Maximum Altitude

Dynamic (new)

(random

(random

Sound Power

Dual Intel Xeon X5570 2.93GHz processors

6 x 2GB 1333 Mhz

nVidia FX4800

2x300GB 15k SAS / 1 DVD-ROM/ 1 Floppy

Sound Power

Operating: 5°C to 35°C (40°F to 95°F)
Non-operating: -40°C to 60°C (-40°F to 140°F)

Operating: 8% to 85% RH, non-condensing
Non-operating: 8% to 90% RH, non-condensing

Operating: 3,048 m (10,000 ft)
Non-operating: 9,100 m (30,000 ft)

Shock
Operating: ½-sine: 40g, 2-3ms
Non-operating:
½-sine: 160 cm/s, 2-3ms (~100g)
square: 422 cm/s, 20g

NOTE:

repetitive shock events.

Values represent individual shock events and do not indicate

( LWAd, bels )

4.1

4.2

5.1

( LWAd, bels )

4.8

4.9

5.3

Deskside Sound Pressure

Deskside Sound Pressure

22

23

37

32

33

38

Vibration
Operating random: 0.5g (rms), 5-300 Hz
Non-operating random: 2.0g (rms), 10-500 Hz

Cooling

NOTE:

Above 1524m (5,000 ft) altitude, maximum operating temperature is de­rated by 1°C (1.8°F) per 305m (1,000 ft) elevation increase

Values do not indicate continuous vibration.

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 25

QuickSpecs

System Technical Specifications

Physical Security and Serviceability

Access Panel

Optical Drive

Floppy Drive

Hard Drives

Expansion Cards

Processor Socket

Green User Touch
Points

Color-coordinated
Cables and Connectors

Memory

System Board

Dual Color Power and
HD LED on Front of
Computer

Configuration RecordSWYes

Tool-less
Includes system board and memory information

Tool-less, no carrier or rails required

Tool-less

Tool-less

Tool-less

Yes

Yes, on tool-free internal chassis components

Yes

Tool-less

Tool-less

Yes

HP Z600 Workstation

Over-Temp Warning on
Screen

Restore CD Set

Dual Function Front
Power Switch

Padlock Support

Cable Lock Support

Universal Chassis
Clamp Lock Support

Solenoid Lock and
Hood Sensor

Rear Port Control
Cover

Serial, Parallel, USB,
Audio, Network,
Enable/Disable Port
Control

Removable Media
Write/Boot Control

Power-On Password

Setup Password

3.3V Aux Power LED on
System PCA

NIC LEDs (integrated)
(Green & Amber)

Yes

Restores the computer to its original factory shipping image - Can be obtained via HP Support

Also acts as a reset switch when held for 4 seconds

No

Yes, Kensington Cable Lock (optional): Prevents entire system theft only. 3mm x 7mm slot at rear
of system

No

Yes (optional)

Yes, locks rear IO cables to prevent cable theft

Enables or disables serial, parallel, USB, 1394, audio, and network ports

User can prevent the workstation from writing to or booting from removable media

Prevents an unauthorized person from booting up the computer

Prevents an unauthorized person from changing the system configuration

No

Yes

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 26

QuickSpecs

System Technical Specifications

HP Z600 Workstation

CPUs and Heatsinks

Power supply
diagnostic LED

Power Button

Power LED

Hard drive activity LED

Internal speaker

System/Emergency
ROM Flash Recovery

OS CD (Restore OS CD)

ASF 2.0 support (Alert
Standard Format)

Cooling Solutions

Power Supply Fans

CPU Heatsink Fan(s)

Chassis Fans

Memory Fans

Insight Diagnostics

A torx driver (T15) is needed to remove the CPU heatsink(s) before the CPU can be removed.
CPU removal is tool-less

Yes

Yes

Yes, blue (normal), red (fault)

Yes, green

Yes

Recovers corrupted system BIOS.

Restores computer to its original factory shipping image; No recovery CDs will ship with Windows
XP, Vista or Linux - an ISO image will be available on an HD partition

Industry-standard specification for network alerting in operating system-absent environments

Air cooled forced convection

2x -- 60mm x 25mm

80mm x 15mm

Rear: 2x -- 92mm x 25mm
Front: 80mm x 25mm

80mm x 25mm

HP Insight Diagnostics Offline Edition

The diagnostics utility enables you to perform testing and to view critical computer hardware and
software configuration information from various sources. This utility enables you to:

Access Panel Key Lock

ACPI-Ready Hardware

Run diagnostics
View the hardware configuration of the system

Key features and benefits

HP Insight Diagnostics simplifies the process of effectively identifying, diagnosing, and isolating
the hardware issues. In addition to robust management tools, service tools can be invaluable in
quickly resolving system problems. To streamline the service process and resolve problems
quickly, it is necessary to have the right information available at the time that a service call is
placed. The primary information requirement, which is also the one that provides the greatest
insight into potential system issues, is the configuration of the system. Insight Diagnostics helps
provide higher system availability. Typical uses of the Insight Diagnostics are:

Testing and diagnosing apparent hardware failures
Documenting system configurations for upgrade planning, standardization, inventory
tracking, disaster recovery, and maintenance
Sending configuration information to another location for more in-depth analysis

Yes, prevents removal of the access panel and all internal components including optical and
floppy drives

Advanced Configuration and Power Management Interface (ACPI).

Allows the system to wake from a low power mode.
Controls system power consumption, making it possible to place individual cards and
peripherals in a low-power or powered-off state without affecting other elements of the
system

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 27

QuickSpecs

System Technical Specifications

HP Z600 Workstation

Trusted Platform
Module Chip with
optional ProtectTools
Software

Integrated Chassis
Handles

Power Supply

PCI Card Retention

Flash ROM

Diagnostic Power
Switch LED on board

Clear Password
Jumper

Clear CMOS Button

CMOS Battery Holder
for easy Replacement

DIMM Connectors for
easy Upgrade

HP ProtectTools
Security Manager

BIOS

BIOS 32-bit Services

PCI 3.0 Support

ATAPI

BBS

WMI Support

BIOS Boot Spec 1.01+

BIOS Power On

ROM Based Computer
Setup Utility (F10)

System/Emergency
ROM Flash Recovery
with Video

Replicated Setup

SMBIOS

Boot Control

Memory Change Alert

Thermal Alert

Yes, Infineon SLB9635TT1.2

Yes

Tool-less, direct-connect (blind-mate)

Yes, rear (all), middle (full-height cards), front (full-length with extender cards)

SPI ROM

Yes

Yes

Yes

Yes

Yes

Yes – Not supported on Microsoft XP x64 or Linux

Standard BIOS 32-Bit Service Directory Proposal v0.4

Full BIOS support for PCI Express through industry standard interfaces

ATAPI Removable Media Device BIOS Specification Version 1.0

BIOS Boot Specification v1.01

WMI is Microsoft's implementation of Web-Based Enterprise Management (WBEM) for Windows.
WMI is fully compliant with the Distributed Management Task Force (DMTF) Common Information
Model (CIM) and WBEM specifications.

Provides more control over how and from what devices the workstation will boot.

Users can define a specific date and time for the system to power on

Review and customize system configuration settings controlled by the BIOS

Recovers system BIOS in corrupted Flash ROM

Saves BIOS settings to diskette or USB flash device in human readable file. Repset.exe utility can
then replicate these settings on machines being deployed without entering Computer
Configuration Utility (F10 Setup).

System Management BIOS 2.5, previously known as DMI BIOS, for system management
information

Disables the ability to boot from removable media on supported devices

Alerts management console if memory is removed or changed

Monitors the temperature state within the chassis. Three modes:

NORMAL – normal temperature ranges

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 28

QuickSpecs

System Technical Specifications

ALERTED – excessive temperatures are detected. Raises a flag so action can be taken to
avoid shutdown or provide for a smoother system shutdown
SHUTDOWN – excessive temperatures are encountered. Automatically shuts down the
computer without warning before hardware component damage occurs

Remote ROM Flash

ACPI

(Advanced
Configuration and Power
Management Interface)

Ownership Tag

Remote
Wakeup/Remote
Shutdown

ASF 2.0 Compliant

Instantly Available PC

(Suspend to RAM –
ACPI sleep state S3)

Remote System
Installation via F12
(PXE 2.1) (Remote Boot
from Server)

ROM revision levels

System board revision
level

Start-up Diagnostics

(Power-on Self-Test)

Auto Setup when new
hardware installed

Keyboard-less
Operation

Localized ROM Setup

Asset Tag

Per-slot Control

Adaptive Cooling

Pre-boot Diagnostics

Industry Standard
Specification Support

Industry Standard

ACPI

ASF

ATA

(IDE)

CD Boot

Provides secure, fail-safe ROM image management from a central network console

Allows the system to enter and resume from low power modes (sleep states).]
Enables an operating system to control system power consumption based on the dynamic
workload.
Makes it possible to place individual cards and peripherals in a low-power or powered-off
state without affecting other elements of the system.
Supports ACPI 2.0 for full compatibility with 64-bit operating systems.

A user-defined string stored in non-volatile memory that is displayed in the BIOS splash screen

System administrators can power on, restart, and power off a client computer from a remote
location

Allows workstation status to be monitored on a remote console

Allows for very low power consumption with quick resume time

Allows a new or existing system to boot over the network and download software, including the
operating system

Reports the system BIOS revision level in Computer Configuration Utility (F10 Setup). Version is
available through an industry standard interface (SMBIOS) so that management SW applications
can use and report this information.

Allows management SW to read the revision level of the system board
Revision level is digitally encoded into the HW and cannot be modified.

Assesses system health at boot time with selectable levels of testing

System automatically detects the addition of new hardware

The system can be booted without a keyboard

Common BIOS image supports System Configuration Utility (F10 Setup) menus in 12 languages
with local keyboard mappings

Allows the user or MIS to set a unique tag string in non-volatile memory

Allows I/O slot parameters (option ROM enable/disable, bus latency) to be configured individually

Fan control parameters are set according to detected hardware configuration for optimal acoustics

Early (pre-video) critical errors are reported via beeps and blinks on the power LED

Revision Supported by the BIOS

Advanced Configuration and Power Management Interface, Version 2.0

Alert Standard Format Specification, Version 2.0

AT Attachment 6 with Packet Interface (ATA/ATAPI-6), Revision 3b

"El Torito" Bootable CD-ROM Format Specification Version 1.0

HP Z600 Workstation

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 29

QuickSpecs

System Technical Specifications

HP Z600 Workstation

EDD

EHCI

PCI

PCI Express

PMM

SATA

SPD

TPM

UHCI

USB 1.1

USB 2.0

SMBIOS

Enhanced Disk Drive Specification Version 1.1
BIOS Enhanced Disk Drive Specification Version 3.0

Enhanced Host Controller Interface for Universal Serial Bus, Revision 1.0

PCI Local Bus Specification, Revision 2.3
PCI Power Management Specification, Revision 1.1
PCI Firmware Specification, Revision 3.0, Draft 0.7

PCI Express Base Specification, Revision 2.0

POST Memory Manager Specification, Version 1.01

Serial ATA Specification, Revision 1.0a
Serial ATA 3.0Gb/s: Extensions to Serial ATA 1.5Gb/s, Revision 1.0

PC SDRAM Serial Presence Detect (SPD) Specification, Revision 1.2B

Trusted Computing Group TPM Specification Version 1.2

Universal Host Controller Interface Design Guide, Revision 1.1

Universal Serial Bus Revision 1.1 Specification

Universal Serial Bus Revision 2.0 Specification

System Management BIOS Reference Specification, Version 2.6

System Software Management and Updating

HP Client Management
Solutions

Product Change

Support Software CD &
WWW

HP Client Manager
System Software

Manager
Social and

Environmental
Responsibility

Eco-Label Certifications
& Declarations

(free)

Visit:

http://www.hp.com/go/easydeploy

Program to proactively communicate Product Change Notifications (PCNs) and Customer
Advisories by email to customers, based on a user-defined profile.
PCNs provide advance notification of hardware and software changes to be implemented in
the factory providing time to plan for transition.
Customer Advisories provide concise, effective problem resolution, greatly reducing the
need to call technical support.

Yes

Visit:

http://www.hp.com/go/easydeploy

Visit:

http://www.hp.com/go/ssm

This product has received or is in the process of being certified to the following approvals and may
be labeled with one or more of these marks:

Batteries

ENERGY STAR (Configuration dependent, Microsoft Windows only)
US Federal Energy Management Program (FEMP)
China Energy Conservation Program
IT ECO declaration
Japan PC Green label*

*This product conforms to the examination standards (2003 version) under JEITA's 'PC Green
Label System.'

This product complies with ISO standards:

EU Directive 91/ 157/ EEC
EU Directive 93/ 86/ EEC

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 30

QuickSpecs

System Technical Specifications

EU Directive 98/ 101/ EEC

Batteries used in the product do not contain:

Mercury greater than 5ppm by weight
Cadmium greater than 10ppm by weight
Lead greater than 4000ppm by weight

Battery size: CR2032 (coin cell)
Battery type: Lithium

Restricted Material
Usage

Packaging

This product does not contain any of the following substances in excess of regulatory limits (refer
to the HP General Specification for the Environment at

http://www.hp.com/hpinfo/globalcitizenship/environment/supplychain/gen_specifications.html

Asbestos
Batteries – Mercury
Batteries – Cadmium
Batteries – Lead (non-rechargeable)
Batteries – Non-rechargeable Alkaline and Carbon-Zinc Batteries
Batteries – Classification as "Not Restricted" for Transport
Brominated Flame Retardants (PBBs, PBDEs, including DecaBDE)
Brominated Flame Retardants (all BFRs in external case plastic parts)
Cadmium and its compounds
Certain Azo Colorants
Chlorinated Hydrocarbons
Chlorinated Paraffins
Formaldehyde
Formaldehyde – emissions
Hexavalent Chromium and its compounds in metallic applications
Hexavalent Chromium and its compounds in non-metallic applications
Lead and its compounds
Lead in paint
Lead in Polyvinyl Chloride (PVC) coating of external cables, wires and cords
Mercury and its compounds
Nickel on external surfaces
Ozone Depleting Substances (ODS)
Polycyclic Aromatic Hydrocarbons (PAH)
Perfluorooctane sulfonates (PFOS) in parts
Perfluorooctane sulfonates (PFOS) in preparations
Polychlorinated Biphenyls (PCBs) and Polychlorinated Terphenyls (PCTs)
Polychlorinated Naphthalenes
Polyvinyl Chloride (PVC) in external case plastic parts
Radioactive Substances
Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)

HP Workstation product packaging meets the following (refer to the HP General Specification for
the Environment at

http://www.hp.com/hpinfo/globalcitizenship/environment/supplychain/gen_specifications.html

HP Z600 Workstation

):

:

Does not contain restricted substances listed in HP Standard 011-1 General Specification
for the Environment (see link above).
Does not contain ozone-depleting substances (ODS).
Design packaging materials for ease of disassembly.
Does not contain heavy metals (lead, mercury, cadmium or hexavalent chromium) in excess
of 100 ppm sum total for all heavy metals listed.

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 31

QuickSpecs

System Technical Specifications

Maximizes the use of post-consumer recycled content materials in packaging materials.
All packaging material is recyclable.
Reduces size and weight of packages to improve transportation fuel efficiency.
Plastic packaging materials are marked according to ISO 11469 and DIN 6120 standards.

Longevity and
Upgrading

Packaging Materials

External
Internal

End-of-Life
Management and
Recycling

Hewlett-Packard
Corporate
Environmental
Information

Service, Support and
Warranty

This product is designed to be upgraded, possibly extending its useful life by several years. Spare
parts are available throughout the warranty period and for up to 5 years after the end of
production. Upgradeability features contained in the product include:

Intel LGA771 processor socket
8 USB ports (5 rear, 2 front, 1 internal)
2 PCI slots and 4 PCI Express slots
5/6 storage bays (2 – 3.5 inch OR 3 – 2.5" internal, 1 – 3.5 inch FDD, 2 – 5.25 inch
removable)
8 memory slots

Cardboard carton and insert: 1.537 kg
LDPE Foam: .740 kg
Hewlett-Packard offers end-of-life HP product return and recycling programs in many geographic

areas. To recycle your product, please go to:
HP sales office. Products returned to HP will be recycled, recovered or disposed of in a
responsible manner.

For more information about HP's commitment to the environment:
[link to new HP white paper now in progress]
Global Citizenship Report:
Eco-label certifications:

http://www.hp.com/hpinfo/globalcitizenship/environment/productdesign/ecolabels.html

ISO 14001 certificates:

http://www.hp.com/hpinfo/globalcitizenship/environment/operations/envmanagement.html

On-site Warranty and Service (
delivers three years of on-site, next business-day (
free telephone support (

2

) ensures that any product purchased in one country and transferred to another, non-restricted

country will remain fully covered under the original warranty and service offering.

NOTE 1:
NOTE 2:

authorized HP third-party provider, and is not available in certain countries. Global service
response times are based on commercially reasonable best effort and may vary by country.

NOTE 3:

party hardware and software. Toll-free calling and 24 x 7 support may not be available in some
countries.

Terms and conditions may vary by country. Certain restrictions and exclusions apply.
On-site service may be provided pursuant to a service contract between HP and an

Technical telephone support applies only to HP-configured, HP and HP-qualified, third-

HP Z600 Workstation

http://www.hp.com/recycle

http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html

Note 1

): This three-year, limited warranty and service offering

Note 3

) service for parts and labor and includes free telephone support (

Note 2

) service for parts and labor and includes

or contact your nearest

Note

Additional Information

HP Care Pack Services extend service contracts beyond the standard warranties. Service starts
from date of hardware purchase. To choose the right level of service for your HP product, use the
HP Care Pack Services Lookup Tool at
Services information by product is available at
and response times for HP Care Packs may vary depending on your geographic location

This product is in compliance with the Restrictions of Hazardous Substances (RoHS)
directive – 2002/95/EC.
This HP product is designed to comply with the Waste Electrical and Electronic Equipment
(WEEE) Directive – 2002/96/EC.
Plastic parts weighing over 25 grams used in the product are marked per ISO 11469 and
ISO1043.
This product contains 0% recycled materials (by weight)

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

http://www.hp.com/go/lookuptool

http://www.hp.com/hps/carepack

. Additional HP Care Pack

. Service levels

Page 32

QuickSpecs

System Technical Specifications

This product is >90% recycle-able when properly disposed of at end of life.

Global Series SKUs

Title
OS
Base Unit
Localization Unit
Processor 1

Processor 2

Memory
Hard Drive
Optical Drive
Keyboard
Mouse

Title
OS
Base Unit
Localization Unit
Processor 1

Processor 2

Memory
Hard Drive
Graphics
Keyboard
Mouse

Copyright/Disclaimers

Z600A/ZI2.40+/K160 /W6.0/Xa /p (WZ971AW)
Genuine Windows® 7 Professional 64-bit
WD059AV - HP Z600 RDIMM Workstation w/ 650W 85% PSU
FY914AV (with all WS supported localizations)
Intel® Xeon® Processor E5620 4C 2.40 GHz, 80W, 12M cache, 5.86GT/s QPI, DDR3 1066MHz,

HT, Turbo
Intel® Xeon® Processor E5620 4C 2.40 GHz, 80W, 12M cache, 5.86GT/s QPI, DDR3 1066MHz,

HT, Turbo
6GB (6x1GB) DDR3-1333 ECC Unbuffered RAM 2-CPU
160GB SATA 7200 rpm 3Gb/s 3.5" HDD
HP 16X DVD-ROM SATA Drive
HP USB Standard Keyboard
HP USB 2-Button Optical Scroll Mouse

Z600e/ZL2.66+/300L /6.0W /295+A/kp (XN057AW)
Genuine Windows® 7 Professional 64-bit
WD059AV - HP Z600 RDIMM Workstation w/ 650W 85% PSU
FY914AV (with all WS supported localizations)
Intel® Xeon® Processor X5650 6C 2.66 GHz, 95W, 12M cache, 6.40GT/s QPI, DDR3 1333MHz,

HT, Turbo
Intel® Xeon® Processor X5650 6C 2.66 GHz, 95W, 12M cache, 6.40GT/s QPI, DDR3 1333MHz,

HT, Turbo
6GB (6x1GB) DDR3-1333 ECC Unbuffered RAM 2-CPU
300GB SATA 10K rpm SFF HDD
NVIDIA Quadro NVS 295 256MB PCIe Graphics Card
HP USB Standard Keyboard
HP USB 2-Button Optical Scroll Mouse

The above SKU, XN057AW, also includes a 2nd NVS 295 Graphics Card and is Energy
Star 5.0 qualified.

HP Z600 Workstation

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 33

QuickSpecs

Stable & Consistent Offerings

HP Z600 Workstation

Processors

Hard Drives

As part of its commitment to hardware, software, and solution innovation, HP is proud to introduce
this breakthrough platform configuration stability to HP Workstation customers. HP Stable &
Consistent Offerings are built on the foundation of a carefully chosen set of hardware and
software designed and tested to work with all HP Z Workstation platforms through their end of life.
These components and their corresponding HP Workstation platform compatibility are outlined in
this section.
HP Stable & Consistent Offerings are available worldwide to all HP Workstation customers-no
special programs, no additional cost-no kidding. Simply select your hardware and software
components when you customize your HP Workstation and be assured that you'll be able to buy
that same configuration throughout the lifecycle of the product.

Product #

WG712AV

WG720AV

WG715AV

WG723AV

Product #

FX560AV

FX570AV

FX562AV

FX572AV

Offering

Intel Xeon E5620 2.40 12MB/1066 4C CPU-1

Intel Xeon E5620 2.40 12MB/1066 4C CPU-2

Intel Xeon X5650 2.66 12MB/1333 6C CPU-1

Intel Xeon X5650 2.66 12MB/1333 6C CPU-2

Offering

HP 250GB SATA 7200 1st HDD

HP 250GB SATA 7200 2nd HDD

HP 500GB SATA 7200 1st HDD

HP 500GB SATA 7200 2nd HDD

Graphics

Memory

Optical and Removable
Storage

Product #

FY915AV

FY924AV

WS077AV

WS078AV

Product #

NL785AV

NL786AV

NL787AV

NL790AV

NL791AV

NL794AV

NL796AV

Product #

FX600AV

FX602AV

Offering

NVIDIA Quadro NVS 295 256MB Graphics Card

NVIDIA Quadro NVS 295 256MB Graphics (2nd)

NVIDIA Quadro 2000 1GB Graphics Card

NVIDIA Quadro 2000 1GB Graphics Card (2nd)

Offering

3GB (3x1GB) DDR3-1333 ECC Unbuffered RAM 1-CPU

6GB (3x2GB) DDR3-1333 ECC Unbuffered RAM 1-CPU

12GB (3x4GB) DDR3-1333 ECC Unbuffered RAM 1-CPU

4GB (4x1GB) DDR3-1333 ECC Unbuffered RAM 2-CPU

6GB (6x1GB) DDR3-1333 ECC Unbuffered RAM 2-CPU

12GB (6x2GB) DDR3-1333 ECC Unbuffered RAM 2-CPU

24GB (6x4GB) DDR3-1333 ECC Unbuffered RAM 2-CPU

Offering

HP 16X DVD+-RW SuperMulti SATA 1st Drive

HP 16X DVD+-RW SuperMulti SATA 2nd Drive

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 34

QuickSpecs

Stable & Consistent Offerings

HP Z600 Workstation

Input Devices

Operating Systems

Product #

FX596AV

FY931AV

Product #

VM436AV

Offering

HP USB Optical Scroll Mouse

HP USB Standard Keyboard

Offering

Genuine Windows® 7 Professional 64-bit

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 35

QuickSpecs

Technical Specifications - Processors

HP Z600 Workstation

Processors

Intel Xeon E5507, 2.26 GHz, 4MB cache, 800MHz Memory, 4.80GT/s QPI, 80W

Intel Xeon E5506, 2.13GHz, 4MB cache, 800MHz Memory, 4.80 GT/s QPI, 80W

NF147AA

Introduction

Intel's latest-generation microarchitecture represents the next step in unprecedented processor performance and dynamic
scalability. Designed from the ground up to take advantage of hafnium-based Intel® 45nm hi-k metal gate silicon
technology, Intel® Microarchitecture (Nehalem) unleashes parallel processing performance enabled by Intel® QuickPath
technology providing an integrated memory controller and high-speed interconnect per independent processing core.

Performance and Features

Maximum multitasking performance Intel® Microarchitecture (Nehalem) offers the latest in processor innovation, including:

Dynamic scalability, managed cores, threads, cache, interfaces, and power for energy-efficient performance on
demand.
Design and performance scalability for servers, workstations, notebooks and desktops with support for 2-8+ cores and
up to 16+ threads with Intel® Hyper-Threading Technology (Intel® HT Technology), and scalable cache sizes, system
interconnects, and integrated memory controllers.
Intel® Turbo Boost Technology delivers additional performance automatically when needed by taking advantage of
the processor's power and thermal headroom. This enables increased performance of both multi-threaded and single­threaded workloads.
Intel Hyper-Threading Technology brings high-performance applications into mainstream computing with 1-16+
threads optimized for a new generation multi-core processor architecture.
Scalable shared memory of Intel® QuickPath technology features memory distributed to each processor with
integrated memory controllers and high-speed point-to-point interconnects to unleash the performance of future
versions of next-generation Intel® multi-core processors.
Multi-level shared cache improves performance and efficiency by reducing latency to frequently used data.

Turbo Boost Technology

This technology now built into Xeon 5500 processors will increase the speed of your processor on demand (from OS) if the
CPU is operating below power / thermal specifications:

Benefit of Turbo Boost (how much CPU speed up) depends on number of active cores
Likelihood of Turbo Boost operation increases when less cores are active
Likelihood of Turbo Boost operation increases when dynamic power mgt is enabled

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 36

QuickSpecs

Technical Specifications - Processors

HP Z600 Workstation

Processors

Intel® Xeon® Processor X5670 6C 2.93 GHz, 95W, 12M cache, 6.40GT/s QPI,
DDR3 1333MHz, HT, Turbo

Intel® Xeon® Processor X5667 6C 3.06 GHz, 95W, 12M cache, 6.40GT/s QPI,
DDR3 1333MHz, HT, Turbo

Intel® Xeon® Processor X5660 6C 2.80 GHz, 95W, 12M cache, 6.40GT/s QPI,
DDR3 1333MHz, HT, Turbo

Intel® Xeon® Processor X5650 6C 2.66 GHz, 95W, 12M cache, 6.40GT/s QPI,
DDR3 1333MHz, HT, Turbo

Intel® Xeon® Processor E5640 4C 2.66 GHz, 80W, 12M cache, 5.86GT/s QPI,
DDR3 1066MHz, HT, Turbo

Intel® Xeon® Processor E5630 4C 2.53 GHz, 80W, 12M cache, 5.86GT/s QPI,
DDR3 1066MHz, HT, Turbo

Intel® Xeon® Processor E5620 4C 2.40 GHz, 80W, 12M cache, 5.86GT/s QPI,
DDR3 1066MHz, HT, Turbo

WG734AA

WG733AA

WG732AA

WG731AA

WG730AA

WG729AA

WG728AA

Introduction

Intel's latest-generation microarchitecture represents the next step in unprecedented processor performance and dynamic
scalability. Designed from the ground up to take advantage of hafnium-based Intel® 32nm hi-k metal gate silicon
technology, Intel® Microarchitecture (Westmere) unleashes parallel processing performance enabled by Intel® QuickPath
technology providing an integrated memory controller and high-speed interconnect per independent processing core.

Performance and Features

Maximum multitasking performance Intel® Microarchitecture (Westmere) offers the latest in processor innovation, including:

Dynamic scalability, managed cores, threads, cache, interfaces, and power for energy-efficient performance on
demand.
Design and performance scalability for servers, workstations, notebooks and desktops with support for 4-12 cores and
up to 24+ threads with Intel® Hyper-Threading Technology (Intel® HT Technology), and scalable cache sizes, system
interconnects, and integrated memory controllers.
Intel® Turbo Boost Technology delivers additional performance automatically when needed by taking advantage of
the processor's power and thermal headroom. This enables increased performance of both multi-threaded and single­threaded workloads.
Intel Hyper-Threading Technology brings high-performance applications into mainstream computing with 1-24 threads
optimized for a new generation multi-core processor architecture.
Scalable shared memory of Intel® QuickPath technology features memory distributed to each processor with
integrated memory controllers and high-speed point-to-point interconnects to unleash the performance of future
versions of next-generation Intel® multi-core processors.
Multi-level shared cache improves performance and efficiency by reducing latency to frequently used data.

Turbo Boost Technology

This technology, now built into Xeon 5600 processors, will increase the speed of your processor on demand (from OS) if the
CPU is operating below power / thermal specifications:

Benefit of Turbo Boost (how much CPU speed up) depends on number of active cores.
Likelihood of Turbo Boost operation increases when fewer cores are active.
Likelihood of Turbo Boost operation increases when dynamic power mgt is enabled

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 37

QuickSpecs

Technical Specifications - Hard Drives

HP Z600 Workstation

HP SAS (Serial
Attached SCSI) Hard
Drives for HP
Workstations

600GB SAS
15K rpm

3.5" HDD
(6Gb/s
enabled)

450GB SAS
15K rpm
3Gb/s 3.5"
HDD

300GB SAS
15K rpm
3Gb/s 3.5"
HDD

Capacity

Height

Width

Interface

Synchronous Transfer
Rate

(Maximum)

Buffer

Seek Time

reads, includes controller
overhead, including
settling)

Rotational Speed

Logical Blocks

Operating Temperature

Capacity

Height

Width

Interface

Synchronous Transfer
Rate

Buffer

Seek Time

reads, includes controller
overhead, including
settling)

Rotational Speed

Logical Blocks

Operating Temperature

Capacity

Height

Width

Interface

Synchronous Transfer
Rate

Buffer

Seek Time

reads, includes controller
overhead, including
settling)

(typical

(Maximum)

(typical

(Maximum)

(typical

600GB

1 in; 2.54 cm

Media Diameter

Physical Size

SAS

3.0 Gb/s (6Gb/s capable with 6.0 Gb/s controller)

16 MB

Single Track

Average

Full Stroke

15,000 rpm

1,172,123,568 - 512 byte blocks

50° to 95° F (10° to 35° C)

450 GB

1 in; 2.5 cm

Media Diameter

Physical Size

SAS

3.0 Gb/s

16 MB

Single Track

Average

Full Stroke

15,000 rpm

879, 097, 968 – 512 byte blocks

50° to 95° F (10° to 35° C)

300 GB

1 in; 2.5 cm

Media Diameter

Physical Size

SAS

3.0 Gb/s

16 MB

Single Track

Average

Full Stroke

3.5 in; 8.9 cm

4 in; 10.17 cm

0.2 ms

3.4 ms

6.6 ms

3.5 in; 8.9 cm

4 in; 10.2 cm

0.2 ms

3.6 ms

6.6 ms

3.5 in; 8.9 cm

4 in; 10.2 cm

0.2 ms

3.5 ms

6.7 ms

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 38

QuickSpecs

Technical Specifications - Hard Drives

HP Z600 Workstation

146GB SAS
15K rpm
3Gb/s 3.5"
HDD

Rotational Speed

Logical Blocks

Operating Temperature

Capacity

Height

Width

Interface

Synchronous Transfer
Rate

(Maximum)

Buffer

Seek Time

reads, includes controller
overhead, including
settling)

Rotational Speed

Logical Blocks

Operating Temperature

(typical

15,000 rpm

585,937,500 – 512 byte blocks

50° to 95° F (10° to 35° C)

146 GB

1 in; 2.5 cm

Media Diameter

Physical Size

SAS

3.0 Gb/s

16 MB

Single Track

Average

Full Stroke

15,000 rpm

286,749,488 – 512 byte blocks

50° to 95° F (10° to 3°5 C)

3.5 in; 8.9 cm

4 in; 10.2 cm

0.2 ms

3.5 ms

6.7 ms

SATA (Serial ATA) Hard
Drives for HP
Workstations

600GB
SATA 10K
rpm SFF in

3.5" Frame
HDD

300GB
SATA 10K
rpm SFF in

3.5" Frame
HDD

Capacity

Height

Width

Interface

Synchronous Transfer
Rate

(Maximum)

Buffer

Cache

Seek Time

reads, includes controller
overhead, including
settling)

Rotational Speed

Logical Blocks

Operating Temperature

Capacity

Height

Width

Interface

Synchronous Transfer
Rate

(typical

(Maximum)

600GB

1 in; 2.54 cm

Media Diameter

Physical Size

Serial ATA (3.0Gb/s)

Up to 300MB/s

32MB

Segmentable

Single Track

Average

Full Stroke

10,000 rpm

1,172,123,568

41° to 131° F (5° to 55° C)

300,069,052,416 bytes

1 in; 2.54 cm

Media Diameter

Physical Size

Serial ATA (3.0 Gb/s), Native Command Queuing enabled

Up to 300 MB/s

2.5 in; 6.36 cm

4 in; 10.17 cm

0.4 ms (max)

3.6 ms

9.0 ms

2.5 in; 6.36 cm

4 in; 10.2 cm

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 39

QuickSpecs

Technical Specifications - Hard Drives

HP Z600 Workstation

Buffer

Seek Time

reads, includes controller
overhead, including
settling)

Rotational Speed

Logical Blocks

Operating Temperature

160GB
SATA 10K
rpm SFF in

3.5" Frame
HDD

2.0TB SATA
7200 rpm
3Gb/s 3.5"
HDD

1.5TB SATA
7200 rpm
3Gb/s 3.5"
HDD

Capacity

Height

Width

Interface

Synchronous Transfer
Rate

Buffer

Seek Time

reads, includes controller
overhead, including
settling)

Rotational Speed

Logical Blocks

Operating Temperature

Capacity

Height

Width

Interface

Synchronous Transfer
Rate

Buffer

Seek Time

reads, includes controller
overhead, including
settling)

Rotational Speed

Logical Blocks

Operating Temperature

Capacity

Height

Width

(typical

(Maximum)

(typical

(Maximum)

(typical

16 MB

Single Track

Average

Full Stroke

10,000 rpm

586,072,368

41 to 131 F (5 to 55 C)

160,041,885,696 bytes

1 in; 2.5 cm

Media Diameter

Physical Size

Serial ATA (1.5 Gb/s), Native Command Queuing enabled

Up to 300 MB/s

16 MB

Single Track

Average

Full Stroke

10,000 rpm

312,581,808

41 to 131 F (5 to 55 C)

2.0TB

1 in; 2.54 cm

Media Diameter

Physical Size

Serial ATA (3.0 Gb/s), Native Command Queuing Enabled

Up to 300MB/s

64MB

Single Track

Average

Full Stroke

7,200 rpm

3,907,029,168

41° to 131° F (5° to 55° C)

1.5TB

1 in; 2.54 cm

Media Diameter

Physical Size

0.7 ms (maximum)

4.4 ms

9.5 ms

2.5 in; 6.36 cm

4 in; 10.2 cm

0.7 ms (maximum)

4.4 ms

9.5 ms

3.5 in; 8.9 cm

4.0 in; 10.17 cm

1.0 ms

10 ms

Not Specified

3.5 in; 8.9 cm

4.0 in; 10.17 cm

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 40

QuickSpecs

Technical Specifications - Hard Drives

HP Z600 Workstation

Interface

Synchronous Transfer
Rate

(Maximum)

Buffer

Seek Time

reads, includes controller
overhead, including
settling)

Rotational Speed

Logical Blocks

Operating Temperature

1000GB
(1TB) SATA
7200 rpm

3.0Gb/s 3.5"
HDD

500GB
SATA 7200
rpm 3Gb/s

3.5" HDD

320GB

Capacity

Height

Width

Interface

Synchronous Transfer
Rate

Buffer

Seek Time

reads, includes controller
overhead, including
settling)

Rotational Speed

Logical Blocks

Operating Temperature

Capacity

Height

Width

Interface

Synchronous Transfer
Rate

Buffer

Seek Time

reads, includes controller
overhead, including
settling)

Rotational Speed

Logical Blocks

Operating Temperature

Capacity

(typical

(Maximum)

(typical

(Maximum)

(typical

Serial ATA (3.0 Gb/s), Native Command Queuing enabled

Up to 300MB/s

32MB

Single Track

Average

Full Stroke

7,200 rpm

2,930,277,168

41° to 131° F (5° to 55° C)

1,000,204,886,016 bytes

1 in; 2.5 cm

Media Diameter

Physical Size

Serial ATA (3.0 Gb/s), Native Command Queuing enabled

Up to 300 MB/s

32 MB

Single Track

Average

Full Stroke

7,200 rpm

1,953,525,168

41 to 131 F (5 to 55 C)

500,107,862,016 bytes

1 in; 2.5 cm

Media Diameter

Physical Size

Serial ATA (3.0 Gb/s), Native Command Queuing enabled

300 MB/s

16 MB

Single Track

Average

Full Stroke

7,200 rpm

976,773,168

41 to 131 F (5 to 55 C)

320,072,933,376 bytes

2 ms

11 ms

21 ms

3.5 in; 8.9 cm

4 in; 10.2 cm

2 ms

11 ms

21 ms

3.5 in; 8.9 cm

4 in; 10.2 cm

2 ms

11 ms

21 ms

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 41

QuickSpecs

Technical Specifications - Hard Drives

HP Z600 Workstation

SATA 7200
rpm 3Gb/s

3.5" HDD

250GB
SATA 7200
rpm 3Gb/s

3.5" HDD

160GB
SATA 7200
rpm 3Gb/s

3.5" HDD

Height

Width

Interface

Synchronous Transfer
Rate

(Maximum)

Buffer

Seek Time

reads, includes controller
overhead, including
settling)

Rotational Speed

Logical Blocks

Operating Temperature

Capacity

Height

Width

Interface

Synchronous Transfer
Rate

Buffer

Seek Time

reads, includes controller
overhead, including
settling)

Rotational Speed

Logical Blocks

Operating Temperature

Capacity

Height

Width

Interface

Synchronous Transfer
Rate

Buffer

Seek Time

reads, includes controller
overhead, including
settling)

Rotational Speed

Logical Blocks

(typical

(Maximum)

(typical

(Maximum)

(typical

0.98 in; 2.5 cm

Media Diameter

Physical Size

Serial ATA (3.0 Gb/s), Native Command Queuing enabled

300 MB/s

8 MB

Single Track

Average

Full Stroke

7,200 rpm

625,142,448

41° to 131° F (5° to 55° C)

250,059,350,016 bytes

1 in; 2.5 cm

Media Diameter

Physical Size

Serial ATA (3.0 Gb/s), Native Command Queuing enabled

300 MB/s

8 MB

Single Track

Average

Full Stroke

7,200 rpm

488,397,168

41 to 131 F (5 to 55 C)

160,041,885,696 bytes

1 in; 2.5 cm

Media Diameter

Physical Size

Serial ATA (3.0 Gb/s), Native Command Queuing enabled

300 MB/s

8 MB

Single Track

Average

Full Stroke

7,200 rpm

312,581,808

3.5 in; 8.9 cm

4.0 in; 10.17 cm

2 ms

12 ms

21 ms

3.5 in; 8.9 cm

4 in; 10.2 cm

2 ms

11 ms

21 ms

3.5 in; 8.9 cm

4 in; 10.2 cm

2 ms

11 ms

21 ms

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 42

QuickSpecs

Technical Specifications - Hard Drives

HP Z600 Workstation

HP Solid State Drive for
Workstations

Operating Temperature

HP 160GB
SATA X25-M
SSD

HP 64GB
SATA SLC
Solid State
Drive

(SFF
in 3.5"
Frame)

Capacity

Height

Width

Interface

Synchronous Transfer
Rate

(Maximum)

Seek Time

reads, includes controller
overhead, including
settling)

Logical Blocks

Operating Temperature

Capacity

Height

Width

Interface

Synchronous Transfer
Rate

Seek Time

reads, includes controller
overhead, including
settling)

Logical Blocks

Operating Temperature

(typical

(Maximum)

(typical

41 to 131 F (5 to 55 C)

160,041,885,696 bytes

0.28 in; 0.7 cm

Media Diameter

Physical Size

SATA

3Gb/s

Average

312,581,808

32° to 158° F (0° to 70° C)

64,023,257,088 bytes

0.28 in; 0.7 cm

Physical Size

SATA

3Gb/s

Average

125,045,424

32° to 158° F (0° to 70° C)

NaN in; NaN cm

2.75 in; 6.985 cm

Read: 75 microseconds; Write:
85 microseconds

2.75 in; 6.985 cm

Average Latency (Access):
Read: 75 microseconds typical;
Write: 85 microseconds typical

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 43

QuickSpecs

Technical Specifications - Hard Drive Controllers

HP Z600 Workstation

LSI 3041E 4-Port SAS

3.0 Gb/s RAID Card

PCI Bus

PCI Modes

RAID Levels

PCI Data Burst
Transfer Rate

SAS Bandwidth

PCI Card Type

PCI Voltage

PCI Power

Bracket

Certification Level

IO Bus

SAS Processor

Internal Connectors

External Connectors

Maximum Number of
SCSI Devices

LED Indicators

Integrated Mirroring

PCI-Express x4 lanes

Bus Master DMA

RAID 0, 1, 1E and 10E

250 MB/s per lane half duplex
500 MB/s per lane full duplex
1,000 MB/s 4-lane half duplex

Half Duplex

Full Duplex

3.3 volt add-in c

12 V ± 10%

7.5 Watts

Full height and Low-profile

PCI-Express 1.0a

Four 3 Gb/s SAS/SATA ports

LSISAS1064E

Four- SATA x1 connectors

None

122

On-board activity and fault LEDs

Integrated Mirroring option available

Single lane – 300 MB/s
Wide Port (2 lanes) – 600 MB/s
Wide Port (4 lanes) – 1200 MB/s

Single SAS Lane – 600 MB/s
Wide Port (2 lanes) –1200 MB/s
Wide Port (4 lanes) – 2400 MB/s

LSI MegaRAID® SAS
8888ELP Host Bus
Adapter (HBA)

PCI Bus

PCI Modes

RAID Levels

PCI Data Burst
Transfer Rate

Full Duplex

PCI Voltage

PCI Power

Certification Level

IO Bus

Internal Connectors

External Connectors

Maximum Number of
SCSI Devices

LED Indicators

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

PCI-Express x8 lanes

Bus Master DMA

RAID 0, 1, and 5
RAID spans 10 and 50

Up to 3Gb/s per port

Up to 1.5 GB/s

+3.3V Add-in Card

19.2 Watts Maximum

PCI-Express 1.0a

Eight 3Gb/s SAS/SATA ports

Two SAS SFF8087 x4

Two SAS SFF8088 x4

32

Connector LEDs indicate whether the internal or external connector is
active for ports 0-3 and 4-7

Page 44

QuickSpecs

Technical Specifications - Graphics

HP Z600 Workstation

NVIDIA Quadro NVS
295 256MB Graphics
Card

Form Factor

Graphics Controller

Bus Type

Memory

Connectors

Maximum Resolution

Display Output

Supported Graphics
APIs

Available Graphics
Drivers

2.731 inches (H) × 6.600 inches (L), Half-Height

NVIDIA Quadro NVS 295 Graphics Board

PCI Express x16, Generation 2.0

256 MB GDDR3 SDRAM unified graphics memory

2 DisplayPort
Comes with 2 DisplayPort to DVI-D Adapters
('DisplayPort to VGA' and 'DisplayPort to DL DVI' adapters available as
an accessory)

Two DisplayPort outputs drive two digital displays up to 2560 x 1600

NOTE:

OpenGL 3.0
DirectX 10.0

Genuine Windows 7 Professional (64-bit and 32-bit)
Genuine Windows Vista Business (64-bit and 32-bit)
Microsoft Windows XP Professional (64-bit and 32-bit)
Red Hat Enterprise Linux(RHEL) WS4 (64-bit and 32-bit)

* WS4 not supported on Z200 & Z200 SFF

Red Hat Enterprise Linux(RHEL) 5 Desktop/Workstation (64-bit and 32­bit)
SUSE Linux Enterprise Desktop 11 (64-bit and 32-bit)

This card supports up to two displays

Drives DisplayPort enabled digital displays at resolutions up to
2560 × 1600 at 60 Hz with reduced blanking
Drives DVI enabled digital displays at resolutions up to 1920 ×
1200 at 60 Hz with reduced blanking (through DisplayPort to DVI­D (single link) cable)

Power consumption

HP qualified drivers may be preloaded or available from the HP support
Web site:

http://welcome.hp.com/country/us/en/support.html

Novell SUSE Linux Enterprise drivers may also be obtained from:

ftp://download.nvidia.com/novell

22.69 Watts

or

http://www.nvidia.com

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 45

QuickSpecs

Technical Specifications - Graphics

HP Z600 Workstation

NVIDIA Quadro NVS
450 512 MB PCIe
Graphics Card

Form Factor

Bus Type

Memory

Connectors

Maximum Resolution

Supported Graphics
APIs

Available Graphics
Drivers

ATX Full Height, 1/2 length
Passive cooling

PCI Express x16, Generation 2.0

512 MB GDDR3 (256MB per GPU)

Four DisplayPort;
Four DisplayPort to DVI-D adapters included.
('DisplayPort to VGA' and 'DisplayPort to Dual Link DVI' adapters
available as an accessory)

DisplayPort connectors support ultra-high-resolution panels (up to 2560
x 1600)

NOTE:

OpenGL 3.0
Direct X 10.0

Genuine Windows 7 Professional (64-bit and 32-bit)
Genuine Microsoft Windows Vista (64-bit and 32-bit)
Microsoft Windows XP Professional (64-bit and 32-bit)
Red Hat Enterprise Linux(RHEL) 5 Desktop/Workstation
SUSE Linux Enterprise Desktop 11 (64-bit and 32-bit)

HP qualified drivers may be preloaded or available from the HP support
Web site:

http://welcome.hp.com/country/us/en/support.html

This card supports up to four displays

NVIDIA NVS 300 512MB
Graphics Card

Power consumption

Form Factor

Graphics Controller

Bus Type

Memory

Connectors

Maximum Resolution

Image Quality Features

Display Output

Novell SUSE Linux Enterprise drivers may also be obtained from:

ftp://download.nvidia.com/novell

35 Watts

2.7 inches (H) x 5.7 inches (L), Half-Height

NVIDIA NVS 300 Graphics Board

PCI Express x16, Generation 2.0

512 MB GDDR3 SDRAM unified graphics memory

DMS-59
Includes DMS-59 to Dual DVI-I adapter
DMS-59 to Dual DisplayPort adapter and DMS-59 to Dual VGA adapter
available as an option

DVI: two digital displays up to 1920 x 1200
DisplayPort: two digital displays up to 2560 x 1600
VGA: two analog displays up to 1920 x 1080

This card support up to two displays:
Drives DVI enabled digital displays at resolutions up to 1920 × 1200 at
60 Hz with reduced blanking
Drives DisplayPort enabled digital displays at resolutions up to 2560 ×
1600 at 60 Hz with reduced blanking (through optional DMS-59 to
DisplayPort adapter)
Drives VGA enabled analog displays at resolutions up to 1920 x 1080
(through optional DMS-59 to VGA adapter)

or

http://www.nvidia.com

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 46

QuickSpecs

Technical Specifications - Graphics

HP Z600 Workstation

NVIDIA Quadro NVS
290 256 MB PCIe
Graphics Card

Supported Graphics
APIs

Available Graphics
Drivers

Power Consumption

Form Factor

Bus Type

Memory

Connectors

Maximum Resolution

RAMDAC

Image Quality Features

Programmable Video
Processor

Display Output

Supported Graphics
APIs

Available Graphics

OGL 3.3
DirectX 10.1

Genuine Windows 7 Professional (64-bit and 32-bit)
Genuine Windows Vista Business (64-bit and 32-bit)
Microsoft Windows XP Professional (64-bit and 32-bit)
Red Hat Enterprise Linux(RHEL) 5 Desktop/Workstation
SUSE Linux Enterprise Desktop 11 (64-bit and 32-bit)

HP qualified drivers may be preloaded or available from the HP support
Web site:

Novell SUSE Linux Enterprise drivers may also be obtained from:

ftp://download.nvidia.com/novell

17.5 Watts maximum

Low Profile

PCIe x16

256 MB 400MHz DDR2 SDRAM unified frame buffer, Z-buffer and
Texture storage

DMS-59, includes DMS-59 to Dual DVI-I cable. DMS-59 to Dual VGA
cable available as an option.

Dual integrated analog display controllers supporting up to two analog
displays at 2048x1536 @ 85Hz on both displays or dual digital displays
at 1920x1200 (single-link).
NVIEW advanced multi-display desktop and application management
seamlessly integrated into Microsoft® Windows®

Integrated dual 400MHz

Full-screen, full-frame video playback of HDTV and DVD content
DVD-ready motion compensation for MPEG-2
Independent hardware color controls for video overlay
Hardware color-space conversion (YUV 4:2:2 and 4:2:0)
IDCT motion compensation
5-tap horizontal by 3-tap vertical filtering
8:1 up/down scaling

Full-screen, full-frame video playback of HDTV and DVD content
DVD-ready motion compensation for MPEG-2
Independent hardware color controls for video overlay
Hardware color-space conversion (YUV 4:2:2 and 4:2:0)
IDCT motion compensation
5-tap horizontal by 3-tap vertical filtering
8:1 up/down scaling

Dual integrated analog display controllers supporting up to two analog
displays at 2048x1536 @ 85Hz on both displays or dual digital displays
at 1920x1200 (single-link).
NVIEW advanced multi-display desktop and application management
seamlessly integrated into Microsoft® Windows®

OGL 2.1 & DX10 Support; Shader Model 4.0

Genuine Windows 7 Professional (64-bit and 32-bit)

http://welcome.hp.com/country/us/en/support.html

or

http://www.nvidia.com

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 47

QuickSpecs

Technical Specifications - Graphics

HP Z600 Workstation

NVIDIA Quadro FX 380
256MB Graphics Card

Drivers

High-Resolution
AntiAliasing

CUDA™ Parallel
Processor Cores

Form Factor

Graphics Controller

Bus Type

Memory

Connectors

Maximum Resolution

RAMDAC

Shading architecture

Genuine Windows Vista Business (64-bit and 32-bit)
Microsoft Windows XP Professional (64-bit and 32-bit)
Red Hat Enterprise Linux(RHEL) 5 Desktop/Workstation
SUSE Linux Enterprise Desktop 11 (64-bit and 32-bit)

HP qualified drivers may be preloaded or available from the HP support
Web site:

http://welcome.hp.com/country/us/en/support.html

Novell SUSE Linux Enterprise drivers may also be obtained from:

ftp://download.nvidia.com/novell

Color planes: 32-bit color buffer
Overlay planes: Hardware supported

NVIDIA Quadro NVS 290 (256 MB DH) PCIe Graphics Card with full
height bracket attached, DMS-59 to Dual DVI cable, Workstation
Software Driver CD, documentation.

4.376 inches (H) × 6.60 inches (L)

NVIDIA Quadro FX 380 Graphics Board

PCI Express x16, Generation 2.0

256 MB GDDR3 SDRAM unified graphics memory

2 Dual Link DVI-I
Two DVI-I to VGA adapters included

Two dual-link DVI-I outputs drive two digital displays at resolutions up to
2560 x 1600 @ 60Hz or two analog displays at resolutions up to 2048 x
1536 @ 85Hz

NOTE:

Dual Internal 400 MHz DAC

Full Shader Model 4.0 (OpenGL 2.1/DirectX 10 class)

This card supports up to two displays

or

http://www.nvidia.com

Long fragment programs (unlimited instructions)
Long vertex programs (unlimited instructions)
Looping and subroutines (up to 256 loops per vertex program)
Dynamic flow control
Conditional execution

Supported graphics
APIs

Available graphics
drivers

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

OpenGL 3.0
Direct X 10.0

Genuine Windows 7 Professional (64-bit and 32-bit)
Genuine Windows Vista Business (64-bit and 32-bit)
Microsoft Windows XP Professional (64-bit and 32-bit)
Red Hat Enterprise Linux(RHEL) WS4 (64-bit and 32-bit)

* WS4 not supported on Z200 & Z200 SFF

Red Hat Enterprise Linux(RHEL) 5 Desktop/Workstation
SUSE Linux Enterprise Desktop 11 (64-bit and 32-bit)

HP qualified drivers may be preloaded or available from the HP support
Web site:

http://welcome.hp.com/country/us/en/support.html

Novell SUSE Linux Enterprise drivers may also be obtained from:

Page 48

QuickSpecs

Technical Specifications - Graphics

HP Z600 Workstation

ATI FirePro V3700
256MB Graphics Card

High-level Shader
Languages

CUDA™ Parallel
Processor Cores

Power consumption

Form Factor

Graphics Controller

Bus Type

Memory

Connectors

Maximum Resolution

Shading architecture

Supported graphics
APIs

Available graphics
drivers

ftp://download.nvidia.com/novell

Optimized compiler for Cg and Microsoft HLSL
OpenGL 2.1 and DirectX 10 support
Open source compiler

16

33.91 Watts

4.40 inches (H) × 6.70 inches (L) (11.18 cm (H) × 17.02 cm (L))

ATI FirePro V3700 Graphics Board

PCI Express x16, Generation 2.0

256 MB GDDR3 SDRAM unified graphics memory

2 Dual Link DVI-I
Two DVI-I to VGA adapters included

Two dual-link DVI-I outputs drive two digital displays at resolutions up to
2560 x 1600 @ 60Hz or two analog displays at resolutions up to 2048 x
1536 @ 85Hz

NOTE:

Full Shader Model 4.0

OpenGL 2.1
DirectX 10.1

Genuine Windows 7 Professional (64-bit and 32-bit)
Genuine Windows Vista Business (64-bit and 32-bit)
Microsoft Windows XP Professional (64-bit and 32-bit)
Red Hat Enterprise Linux WS4 (64-bit and 32-bit)

* WS4 not supported on Z200 & Z200 SFF

Red Hat Enterprise Linux 5 Desktop (64-bit and 32-bit)
SUSE Linux Enterprise Desktop 11 (64-bit and 32-bit)

This card supports up to two displays

40 Stream Processing Units
Dynamic load balancing and resource allocation for vertex,
geometry, and pixel shaders
Common instruction set and texture unit access supported for all
types of shaders
Dedicated branch execution units and texture address processors

or

http://www.nvidia.com

HP qualified drivers may be preloaded or available from the HP support
Web site:

http://welcome.hp.com/country/us/en/support.html

Power consumption

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

32 Watts

Page 49

QuickSpecs

Technical Specifications - Graphics

HP Z600 Workstation

NVIDIA Quadro FX 580
512MB Graphics Card

Form Factor

Graphics Controller

Bus Type

Memory

Connectors

Maximum Resolution

RAMDAC

Shading architecture

Supported graphics
APIs

Available graphics
drivers

4.376 inches (H) × 6.60 inches (L)

NVIDIA Quadro FX 580 Graphics Board

PCI Express x16, Generation 2.0

512MB GDDR3 SDRAM unified graphics memory

2 DisplayPort, 1 Dual-Link DVI-I.
One DisplayPort to DVI adapter included
('DVI to VGA', 'DisplayPort to VGA' and 'DisplayPort to Dual Link DVI'
adapters available as an accessory)

Two DisplayPort outputs drive two digital displays up to 2560 x
1600
One dual-link DVI-I output drives one digital display at resolutions
up to 2560 x 1600 @ 60Hz or one analog display at resolutions up
to 2048 x 1536 @ 85Hz

NOTE:

Single Internal 400 MHz DAC

Full Shader Model 4.0 (OpenGL 2.1/DirectX 10 class)

OpenGL 3.0
Direct X 10.0

Genuine Windows 7 Professional (64-bit and 32-bit)
Genuine Windows Vista Business (64-bit and 32-bit)
Microsoft Windows XP Professional (64-bit and 32-bit)
Red Hat Enterprise Linux(RHEL) WS4 (64-bit and 32-bit)

* WS4 not supported on Z200 & Z200 SFF

Red Hat Enterprise Linux(RHEL) 5 Desktop/Workstation
SUSE Linux Enterprise Desktop 11 (64-bit and 32-bit)

This card supports up to two displays

Long fragment programs (unlimited instructions)
Long vertex programs (unlimited instructions)
Looping and subroutines (up to 256 loops per vertex program)
Dynamic flow control
Conditional execution

HP qualified drivers may be preloaded or available from the HP support
Web site:

http://welcome.hp.com/country/us/en/support.html

Novell SUSE Linux Enterprise drivers may also be obtained from:

ftp://download.nvidia.com/novell

High-level Shader
Languages

CUDA™ Parallel
Processor Cores

Power consumption

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Optimized compiler for Cg and Microsoft HLSL
OpenGL 2.1 and DirectX 10 support
Open source compiler

32

40 Watts

or

http://www.nvidia.com

Page 50

QuickSpecs

Technical Specifications - Graphics

HP Z600 Workstation

NVIDIA Quadro 600
1GB Graphics Card

Form Factor

Graphics Controller

Bus Type

Memory

Connectors

Maximum Resolution

Shading Architecture

Supported Graphics
APIs

Available Graphics
Drivers

2.731" H x 6.6" L
Single Slot
Small Form Factor

NVIDIA Quadro 600 Graphics Card

PCI Express 2.0 x16

1 GB GDDR3
128-bit

1 DVI-I output, 1DisplayPort output
One DP to DVI adapter included with card

DVI to VGA, DisplayPort to VGA and DisplayPort to DVI adapters
available as accessories

DisplayPort (up to 2560 x 1600 @ 60Hz and 1920x1200 @ 120Hz)
Dual-link DVI-I output (up to 2560 x 1600 @ 60Hz and 1920x1200 @
120Hz)

Shader Model 5.0

OpenGL 4.0
DirectX 11
CUDA API support includes:
CUDA C, CUDA C++, DirectCompute 5.0, OpenCL, Java, Python, and
Fortran

Genuine Windows 7 Professional (64-bit and 32-bit)
Genuine Windows Vista Business (64-bit and 32-bit)
Microsoft Windows XP Professional (64-bit and 32-bit)
Red Hat Enterprise Linux (RHEL) WS4 (64-bit and 32-bit)

* WS4 not supported on Z200 and Z200 SFF

Red Hat Enterprise Linux (RHEL) 5 Desktop/Workstation (64-bit and 32­bit)
SUSE Linux Enterprise Desktop 11 (64-bit and 32-bit)

HP qualified drivers may be preloaded or available from the HP support
Web site:

Novell SUSE Linux Enterprise drivers may also be obtained from:

ftp://download.nvidia.com/novell

Parallel Processor
Cores

Power consumption

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

96 CUDA parallel processing cores

40 Watts

http://welcome.hp.com/country/us/en/support.html

or

http://www.nvidia.com

Page 51

QuickSpecs

Technical Specifications - Graphics

HP Z600 Workstation

ATI FirePro V3800
512MB Graphics Card

Form Factor

Graphics Controller

Bus Type

Memory

Connectors

Maximum Resolution

RAMDAC

Image Quality Features

Shading architecture

Supported graphics
APIs

2.71 in (H) x 6.61 in (L) "Single-Wide"

ATI FirePro V3800 Graphics Board

PCI Express x16, Generation 2.0

512 MB DDR3 SDRAM

1 DL DVI, 1 DP output
One DP to DVI adapter included

Up to two digital displays at resolutions up to 2560 x 1600 @ 60Hz or
two analog displays, one at resolutions up to 2048 x 1536 @ 85Hz, the
other at up to 1920 x 1200 @ 60Hz (165 MHz dot clock)

NOTE:

This card supports up to two displays

400 MHz DAC, 10-bits per channel

Full 30-bit display pipeline for more accurate color reproduction
superior image quality (30-bit monitor required for full 30-bit
display)
Advanced video capabilities, including high fidelity gamma, color
correction and scaling
Dedicated hardware (UVD2) for H.264, VC-1, and MPEG2 decode

Support for Full Shader Model 5.0
400 Stream Processing Units
Dynamic load balancing and resource allocation for vertex,
geometry, and pixel shaders
Common instruction set and texture unit access supported for all
types of shaders
Dedicated branch execution units and texture address processors
Anti-aliases Shaders and Textures as well as Polygon Edges

DirectX 11, OpenGL 3.2, OpenCL 1.0 and full implementation of
DirectCompute 11

ATI FirePro V4800 1GB
Graphics Card

Available graphics
drivers

Parallel Processor
Cores

Power consumption

Form Factor

Graphics Controller

Bus Type

Memory

(OpenCL™ compliant driver and SDK release scheduled in 2010)

Genuine Windows 7 Professional (64-bit and 32-bit)
Genuine Windows Vista Business (64-bit and 32-bit)
Microsoft Windows XP Professional (64-bit and 32-bit)
Red Hat Enterprise Linux (RHEL) WS4

* WS4 not supported on Z200 & Z200 SFF

Red Hat Enterprise Linux(RHEL) 5 Desktop/Workstation
SUSE Linux Enterprise Desktop 11 (64-bit and 32-bit)
HP qualified drivers may be preloaded or available from the HP support
Web site:

http://welcome.hp.com/country/us/en/support.html

400 Stream processors (675 single-precision GFLOPS performance)

43 Watts

4.37 in (H) x 6.61 in (L)

ATI FirePro V4800 Graphics Card

PCI Express x 16, Generation 2.0

1GB GDDR5 SDRAM

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 52

QuickSpecs

Technical Specifications - Graphics

HP Z600 Workstation

Connectors

Maximum Resolution

RAMDAC

Image Quality Features

Shading architecture

Supported graphics
APIs

2 DisplayPort, 1 dual link DVI Output
One DP to DVI adapter included

Up to three digital displays at resolutions up to 2560 x 1600 @ 60Hz or
up to three analog displays, one at resolutions up to 2048 x 1536 @
85Hz, plus two resolutions up to 1920 x 1200 @ 60Hz (165 MHz dot
clock)

NOTE:

This card supports up to three displays with Windows 7, Vista or

Linux, and up to two displays on XP

400 MHz DAC, 10-bit per channel

Up to 3 independent outputs with ATI Eyefinity technology support
(More information at:

www.amd.com/us/products/technologies/eyefinity/

Full 30-bit display pipeline for more accurate color reproduction
superior image quality2
Advanced video capabilities, including high fidelity gamma, color
correction and scaling
Dedicated hardware (UVD2) for H.264, VC-1, and MPEG2 decode

NOTE:

xrandr 1.2 or greater in the X server

DirectX 11, OpenGL 3.2, OpenCL 1.03 and full implementation of
DirectCompute 11

The use of more than two displays on Linux requires support for

Support for Full Shader Model 5.0
Dynamic load balancing and resource allocation for vertex,
geometry, and pixel shaders
Common instruction set and texture unit access supported for all
types of shaders
Dedicated branch execution units and texture address processors
Anti-aliases Shaders and Textures as well as Polygon Edges

)

(OpenCL™ compliant driver and SDK release scheduled in 2010)

Available graphics
drivers

Parallel Processor
Cores

Power consumption

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Genuine Windows 7 Professional (64-bit and 32-bit)
Genuine Windows Vista Business (64-bit and 32-bit)
Microsoft Windows XP Professional (64-bit and 32-bit)
Red Hat Enterprise Linux(RHEL) WS4 (64-bit and 32-bit)

* WS4 not supported on Z200 & Z200 SFF

Red Hat Enterprise Linux (RHEL) 5 Desktop/Workstation (64-bit and 32­bit)
SUSE Linux Enterprise Desktop 11 (64-bit and 32-bit)
HP qualified drivers may be preloaded or available from the HP support
Web site:

http://welcome.hp.com/country/us/en/support.html

800 stream processors (675 MFLOPS single-precision performance)

69 Watts

Page 53

QuickSpecs

Technical Specifications - Graphics

HP Z600 Workstation

NVIDIA Quadro FX
1800 768MB Graphics
Card

Form Factor

Graphics Controller

Bus Type

Memory

Connectors

Maximum Resolution

RAMDAC

Shading Architecture

Supported Graphics
APIs

Available Graphics
Drivers

4.376 inches (H) x 7.8 inches (L)

NVIDIA Quadro FX 1800 Graphics Board

PCI Express x16, Generation 2.0

768MB GDDR3 SDRAM unified graphics memory

2 DisplayPort, 1 Dual-Link DVI-I.
One DisplayPort to DVI-D adapter included
('DVI to VGA', 'DisplayPort to VGA' and 'DisplayPort to Dual Link DVI'
adapters available as an accessory)

Two DisplayPort outputs drive two digital displays up to 2560 x
1600
One dual-link DVI-I output drives one digital display at resolutions
up to 2560 x 1600 @ 60Hz or one analog display at resolutions up
to 2048 x 1536 @ 85Hz

NOTE:

Single Internal 400 MHz DAC

Full Shader Model 4.0 (OpenGL 2.1/DirectX 10 class)

OpenGL 3.0
Direct X 10.0

Genuine Windows 7 Professional (64-bit and 32-bit)
Genuine Windows Vista Business (64-bit and 32-bit)
Microsoft Windows XP Professional (64-bit and 32-bit)
Red Hat Enterprise Linux(RHEL) WS4 (64-bit and 32-bit)

* WS4 not supported on Z200 & Z200 SFF

Red Hat Enterprise Linux(RHEL) 5 Desktop/Workstation
SUSE Linux Enterprise Desktop 11 (64-bit and 32-bit)

This card supports up to two displays

Long fragment programs (unlimited instructions)
Long vertex programs (unlimited instructions)
Looping and subroutines (up to 256 loops per vertex program)
Dynamic flow control
Conditional execution

HP qualified drivers may be preloaded or available from the HP support
Web site:

http://welcome.hp.com/country/us/en/support.html

Novell SUSE Linux Enterprise drivers may also be obtained from:

ftp://download.nvidia.com/novell

High-level Shader
Languages

CUDA™ Parallel
Processor Cores

Power consumption

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Optimized compiler for Cg and Microsoft HLSL
OpenGL 2.1 and DirectX 10 support
Open source compiler

64.

59 Watts

or

http://www.nvidia.com

Page 54

QuickSpecs

Technical Specifications - Graphics

HP Z600 Workstation

NVIDIA Quadro 2000
1GB Graphics Card

Form Factor

Graphics Controller

Bus Type

Memory

Connectors

Maximum Resolution

Image Quality Features

Shading Architecture

Supported Graphics
APIs

Available Graphics
Drivers

4.376" H x 7" L
Single Slot

NVIDIA Quadro 2000 Graphics Card

PCI Express 2.0 x16

1 GB GDDR5
128-bit

1 DVI-I output, 2 DisplayPort outputs
One DP to DVI adapter included with card

DVI to VGA, DisplayPort to VGA and DisplayPort to DVI adapters
available as accessories

Dual DisplayPort (up to 2560 x 1600 @ 60Hz and 1920x1200 @ 120Hz)
Dual-link DVI-I output (up to 2560 x 1600 @ 60Hz and 1920x1200 @
120Hz)

Up to 16K x16K texture and render processing
Transparent multisampling and super sampling
16x angle independent anisotropic filtering
128-bit floating point performance
32-bit per-component floating point texture filtering and blending
Support for any combination of two connected displays
DisplayPort 1.1a, HDMI 1.3a, and HDCP support
NVIDIA® 3D Vision™ technology, 3D DLP, Interleaved, and other
3D stereo format support
Full OpenGL quad buffered stereo support
Underscan/overscan compensation and hardware scaling
NVIDIA® nView® multi-display technology

Shader Model 5.0

OpenGL 4.0
DirectX 11
CUDA API support includes:
CUDA C, CUDA C++, DirectCompute 5.0, OpenCL, Java, Python, and
Fortran

Genuine Windows 7 Professional (64-bit and 32-bit)
Genuine Windows Vista Business (64-bit and 32-bit)
Microsoft Windows XP Professional (64-bit and 32-bit)
Red Hat Enterprise Linux (RHEL) WS4 (64-bit and 32-bit)

* WS4 not supported on Z200 and Z200 SFF

Red Hat Enterprise Linux (RHEL) 5 Desktop/Workstation (64-bit and 32­bit)
SUSE Linux Enterprise Desktop 11 (64-bit and 32-bit)

HP qualified drivers may be preloaded or available from the HP support
Web site:

Novell SUSE Linux Enterprise drivers may also be obtained from:

ftp://download.nvidia.com/novell

Parallel Processor
Cores

Power consumption

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

192 CUDA parallel processing cores

62 Watts

http://welcome.hp.com/country/us/en/support.html

or

http://www.nvidia.com

Page 55

QuickSpecs

Technical Specifications - Graphics

HP Z600 Workstation

ATI FirePro V5700
512MB Graphics Card

Form Factor

Graphics Controller

Bus Type

Memory

Connectors

Maximum Resolution

Shading architecture

Supported graphics
APIs

Available graphics
drivers

4.40 inches (H) × 6.70 inches (L) (11.18 cm (H) × 17.02 cm (L))

ATI FirePro V5700 Graphics Board

PCI Express x16, Generation 2.0

512 MB GDDR3 SDRAM unified graphics memory

2 DisplayPort, 1 Dual-Link DVI-I.
One DisplayPort to DVI adapter included
('DVI to VGA', 'DisplayPort to VGA' and 'DisplayPort to Dual Link DVI'
adapters available as an accessory)

Two DisplayPort outputs drive two digital displays up to 2560 x
1600
One dual-link DVI-I output drives one digital display at resolutions
up to 2560 x 1600 @ 60Hz or one analog display at resolutions up
to 2048 x 1536 @ 85Hz

NOTE:

Full Shader Model 4.0

OpenGL 3.0
DirectX 10.1

Genuine Windows 7 Professional (64-bit and 32-bit)
Genuine Windows Vista Business (64-bit and 32-bit)
Microsoft Windows XP Professional (64-bit and 32-bit)
Red Hat Enterprise Linux WS4 (64-bit and 32-bit)

* WS4 not supported on Z200 & Z200 SFF

Red Hat Enterprise Linux 5 Desktop/Workstation (64-bit and 32-bit)
SUSE Linux Enterprise Desktop 11 (64-bit and 32-bit)

This card supports up to two displays

320 Stream Processing Units
Dynamic load balancing and resource allocation for vertex,
geometry, and pixel shaders
Common instruction set and texture unit access supported for all
types of shaders
Dedicated branch execution units and texture address processors

HP qualified drivers may be preloaded or available from the HP support
Web site:

http://welcome.hp.com/country/us/en/support.html

Power consumption

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

56 Watts

Page 56

QuickSpecs

Technical Specifications - Graphics

HP Z600 Workstation

ATI FirePro V5800 1GB
Graphics Card

Form Factor

Graphics Controller

Bus Type

Memory

Connectors

Maximum Resolution

RAMDAC

Image Quality Features

Shading architecture

Supported graphics
APIs

4.38 in (H) x 9.0 in (L)

ATI FirePro V5800 Graphics Card

PCI Express x 16, Generation 2.0

1GB GDDR5 SDRAM

2 DP, 1 DL DVI

One DP to DVI adapter included

Up to three digital displays at resolutions up to 2560 x 1600 @ 60Hz or
up to three analog displays, one resolution up to 2048 x 1536 @ 85Hz,
plus two display resolutions up to 1920 x 1200 @ 60 Hz (165 MHz dot
clock)

NOTE:

This card supports up to three displays with Vista, Win7, or

Linux, up to two displays with XP

400 MHz DAC, 10-bits per channel

3 independent outputs with ATI Eyefinity1 technology support
(More information at:

www.amd.com/us/products/technologies/eyefinity/

Full 30-bit display pipeline for more accurate color reproduction
superior image quality2
Advanced video capabilities, including high fidelity gamma, color
correction and scaling
Dedicated hardware (UVD2) for H.264, VC-1, and MPEG2 decode

Support for Full Shader Model 5.0
Dynamic load balancing and resource allocation for vertex,
geometry, and pixel shaders
Common instruction set and texture unit access supported for all
types of shaders
Dedicated branch execution units and texture address processors
Anti-aliases Shaders and Textures as well as Polygon Edges

DirectX 11, OpenGL 3.2, OpenCL 1.0 and full implementation of
DirectCompute 11

)

(OpenCL™ compliant driver and SDK release scheduled in 2010)

Available graphics
drivers

Parallel Processor
Cores

Power consumption

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Genuine Windows 7 Professional (64-bit and 32-bit)
Genuine Windows Vista Business (64-bit and 32-bit)
Microsoft Windows XP Professional (64-bit and 32-bit)
Red Hat Enterprise Linux(RHEL) WS4 (64-bit and 32-bit)

* WS4 not supported on Z200 & Z200 SFF

Red Hat Enterprise Linux (RHEL) 5 Desktop/Workstation (64-bit and 32­bit)
SUSE Linux Enterprise Desktop 11 (64-bit and 32-bit)
HP qualified drivers may be preloaded or available from the HP support
Web site:

800 stream processors (1.35 TFLOPS single-precision performance)

75 Watts

http://welcome.hp.com/country/us/en/support.html

Page 57

QuickSpecs

Technical Specifications - Graphics

HP Z600 Workstation

NVIDIA Quadro FX
3800 1.0GB Graphics
Card

Form Factor

Graphics Controller

Bus Type

Memory

Connectors

Maximum Resolution

RAMDAC

Shading architecture

Supported graphics
APIs

Available graphics
drivers

4.376 inches (H) x 9.0 inches (L)
Single slot card

NVIDIA Quadro FX 3800 Graphics Board

PCI Express x16, Generation 2.0

1GB GDDR3 SDRAM unified graphics memory

2 DisplayPort, 1 Dual-Link DVI-I.
One DisplayPort to DVI-D adapter included
('DVI to VGA', 'DisplayPort to VGA' and 'DisplayPort to Dual Link DVI'
adapters available as an accessory)

Two DisplayPort outputs drive two digital displays up to 2560 x
1600
One dual-link DVI-I output drives one digital display at resolutions
up to 2560 x 1600 @ 60Hz or one analog display at resolutions up
to 2048 x 1536 @ 85Hz

NOTE:

Single Internal 400 MHz DAC

Full Shader Model 4.0 (OpenGL 2.1/DirectX 10 class)

OpenGL 3.0
Direct X 10.0

Genuine Windows 7 Professional (64-bit and 32-bit)
Genuine Windows Vista Business (64-bit and 32-bit)
Microsoft Windows XP Professional (64-bit and 32-bit)
Red Hat Enterprise Linux(RHEL) 5 Desktop/Workstation
SUSE Linux Enterprise Desktop 11 (64-bit and 32-bit)

This card supports up to two displays

Long fragment programs (unlimited instructions)
Long vertex programs (unlimited instructions)
Looping and subroutines (up to 256 loops per vertex program)
Dynamic flow control
Conditional execution

HP qualified drivers may be preloaded or available from the HP support
Web site:

http://welcome.hp.com/country/us/en/support.html

Novell SUSE Linux Enterprise drivers may be obtained from:

ftp://download.nvidia.com/novell

High-level Shader
Languages

CUDA™ Parallel
Processor Cores

Power consumption

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Optimized compiler for Cg and Microsoft HLSL
OpenGL 2.1 and DirectX 10 support
Open source compiler

192

107.9 Watts

or

http://www.nvidia.com

Page 58

QuickSpecs

Technical Specifications - Graphics

HP Z600 Workstation

ATI FirePro V7750

1.0GB Graphics Card

Form Factor

Graphics Controller

Bus Type

Memory

Connectors

Maximum Resolution

Shading architecture

Supported graphics
APIs

Available graphics
drivers

4.40 inches (H) × 13.0 inches (L) (11.18 cm (H) × 33.02 cm (L))

ATI FirePro V7750 Graphics Board

PCI Express x16, Generation 2.0

1024 MB GDDR3 SDRAM unified graphics memory

2 DisplayPort, 1 Dual-Link DVI-I.
One DisplayPort to DVI adapter included
('DVI to VGA', 'DisplayPort to VGA' and 'DisplayPort to Dual Link DVI'
adapters available as an accessory)

Two DisplayPort outputs drive two digital displays up to 2560 x
1600
One dual-link DVI-I output drives one digital display at resolutions
up to 2560 x 1600 @ 60Hz or one analog display at resolutions up
to 2048 x 1536 @ 85Hz

NOTE:

Full Shader Model 4.0

OpenGL 3.0
DirectX 10.1

Genuine Windows Vista Business (64-bit and 32-bit)
Microsoft Windows XP Professional (64-bit and 32-bit)
Red Hat Enterprise Linux 4 (64-bit and 32-bit)
Red Hat Enterprise Linux 5 Desktop (64-bit and 32-bit)
SUSE Linux Enterprise Desktop 11 (64-bit and 32-bit)

This card supports up to two displays

320 Stream Processing Units
Dynamic load balancing and resource allocation for vertex,
geometry, and pixel shaders
Common instruction set and texture unit access supported for all
types of shaders
Dedicated branch execution units and texture address processors

NVIDIA Quadro 4000
2GB Graphics Card

HP qualified drivers may be preloaded or available from the HP support
Web site:

http://welcome.hp.com/country/us/en/support.html

Power consumption

Form Factor

Graphics Controller

Bus Type

Memory

Connectors

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

76 Watts

4.376" H x 9.50" L
Single Slot

NVIDIA Quadro 4000 Graphics Card

PCI Express 2.0 x16

2 GB GDDR5
256-bit

1 DVI-I output, 2 DisplayPort outputs;
One DP to DVI adapter included with card

DVI to VGA, DisplayPort to VGA and DisplayPort to DVI (single- link or
dual-link) adapters available as accessories
(Optional stereo bracket available from 3rd party)

Page 59

QuickSpecs

Technical Specifications - Graphics

HP Z600 Workstation

Maximum Resolution

RAMDAC

Image Quality Features

Shading Architecture

Supported Graphics
APIs

Available Graphics
Drivers

Dual DisplayPort (up to 2560 x 1600 @ 60Hz and 1920x1200 @ 120Hz)
Dual-link DVI-I output (up to 2560 x 1600 @ 60Hz and 1920x1200 @
120Hz)

400 MHz integrated RAMDAC

Up to 16K x16K texture and render processing
Transparent multisampling and super sampling
16x angle independent anisotropic filtering
128-bit floating point performance
32-bit per-component floating point texture filtering and blending
Support for any combination of two connected displays
DisplayPort 1.1a, HDMI 1.3a, and HDCP support
NVIDIA 3D Vision™ technology, 3D DLP, Interleaved, and other
3D stereo format support
Full OpenGL quad buffered stereo support
Underscan/overscan compensation and hardware scaling
NVIDIA nView® multi-display technology

Shader Model 5.0

OpenGL 4.0
DirectX 11
CUDA API support includes:
CUDA C, CUDA C++, DirectCompute 5.0, OpenCL, Java, Python, and
Fortran

Genuine Windows 7 Professional (64-bit and 32-bit)
Genuine Windows Vista Business (64-bit and 32-bit)
Microsoft Windows XP Professional (64-bit and 32-bit)
Red Hat Enterprise Linux (RHEL) WS4 (64-bit and 32-bit)

* WS4 not supported on Z200 and Z200 SFF

Red Hat Enterprise Linux (RHEL) 5 Desktop/Workstation (64-bit and 32­bit)
SUSE Linux Enterprise Desktop 11 (64-bit and 32-bit)

HP qualified drivers may be preloaded or available from the HP support
Web site:

http://welcome.hp.com/country/us/en/support.html

Novell SUSE Linux Enterprise drivers may also be obtained from:

ftp://download.nvidia.com/novell

High-Resolution
Antialiasing

Parallel Processor
Cores

Power consumption

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

64x full scene antialiasing (FSAA)/128x FSAA in SLI Mode

256 CUDA parallel processing cores

142 Watts

or

http://www.nvidia.com

Page 60

QuickSpecs

Technical Specifications - Graphics

HP Z600 Workstation

NVIDIA Quadro FX
4800 1.5GB PCIe
Graphics Card

Form Factor

Graphics Controller

Bus Type

Memory

Connectors

Maximum Resolution

Shading Architecture

Supported Graphics
APIs

Available Graphics
Drivers

4.36" (H) x 10.5" (L)
Dual slot card

NVIDIA Quadro FX 4800 graphics board

PCI Express x16, Generation 2.0

1.5 GB GDDR3 SDRAM unified graphics memory

2 DisplayPort, 1 Dual-Link DVI-I, 1 3-pin Mini DIN stereo output, One
DisplayPort to DVI-D adapter included
('DVI to VGA', 'DisplayPort to VGA' and 'DisplayPort to Dual Link DVI'
adapters available as an accessory)

2 DisplayPort connectors support ultra-high-resolution panels (up
to 2560 x 1600)
Dual-link DVI-I output drives one digital display at resolutions up
to 2560 x 1600 @ 60Hz
Internal 400 MHz DACs-One analog display up to 2048 x 1536 @
85Hz

NOTE:

OpenGL 3.0
Direct X 10.0

Genuine Windows 7 Professional (64-bit and 32-bit)
Genuine Windows Vista Business (64-bit and 32-bit)
Microsoft Windows XP Professional (64-bit and 32-bit)
Red Hat Enterprise Linux(RHEL) 5 Desktop/Workstation
SUSE Linux Enterprise Desktop 11 (64-bit and 32-bit)

This card supports up to two displays

Full Shader Model 4.0 (OpenGL 2.1/DirectX 10 class)
Long fragment programs (unlimited instructions)
Long vertex programs (unlimited instructions)
Looping and subroutines (up to 256 loops per vertex program)
Dynamic flow control
Conditional execution

NVIDIA Quadro 5000

2.5GB Graphics Card

HP qualified drivers may be preloaded or available from the HP support
Web site:

http://welcome.hp.com/country/us/en/support.html

Novell SUSE Linux Enterprise drivers may be obtained from:

ftp://download.nvidia.com/novell

High-Resolution
AntiAliasing

High-level Shader
Languages

CUDA™ Parallel
Processor Cores

Power consumption

Form Factor

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Rotated Grid Full-Scene Antialiasing (RG FSAA)
32xFSAA dramatically reduces visual aliasing artifacts or "jaggies"
at resolution up to 1920 x 1200
64x FSAA SLI Mode

Optimized compiler for Cg and Microsoft HLSL
OpenGL 2.1 and DirectX 10 support
Open source compiler

192

146 Watts

4.376" H x 9.75" L
Dual Slot

or

http://www.nvidia.com

Page 61

QuickSpecs

Technical Specifications - Graphics

HP Z600 Workstation

Graphics Controller

Bus Type

Memory

Connectors

Maximum Resolution

Image Quality Features

Shading Architecture

Supported Graphics
APIs

Available Graphics
Drivers

NVIDIA Quadro 5000 Graphics Card

PCI Express 2.0 x16

2.5 GB GDDR5
320-bit

DVI-I (1), DP (2), Stereo (1)
One DP to DVI adapter included with card

DVI to VGA, DisplayPort to VGA and DisplayPort to DVI adapters
available as accessories

Dual DisplayPort (up to 2560 x 1600 @ 60Hz and 1920x1200 @ 120Hz)
Dual-link DVI-I output (up to 2560 x 1600 @ 60Hz and 1920x1200 @
120Hz)

Up to 16K x16K texture and render processing
Transparent multisampling and super sampling
16x angle independent anisotropic filtering
128-bit floating point performance
32-bit per-component floating point texture filtering and blending
Support for any combination of two connected displays
DisplayPort 1.1a, HDMI 1.3a, and HDCP support
NVIDIA 3D Vision™ technology, 3D DLP, Interleaved, and other
3D stereo format support
Full OpenGL quad buffered stereo support
Underscan/overscan compensation and hardware scaling
NVIDIA nView® multi-display technology

Shader Model 5.0

OpenGL 4.0
DirectX 11
CUDA API support includes:
CUDA C, CUDA C++, DirectCompute 5.0, OpenCL, Java, Python, and
Fortran

Genuine Windows 7 Professional (64-bit and 32-bit)
Genuine Windows Vista Business (64-bit and 32-bit)
Microsoft Windows XP Professional (64-bit and 32-bit)
Red Hat Enterprise Linux (RHEL) WS4 (64-bit and 32-bit)

* WS4 not supported on Z200 and Z200 SFF

Red Hat Enterprise Linux (RHEL) 5 Desktop/Workstation (64-bit and 32­bit)
SUSE Linux Enterprise Desktop 11 (64-bit and 32-bit)

HP qualified drivers may be preloaded or available from the HP support
Web site:

http://welcome.hp.com/country/us/en/support.html

Novell SUSE Linux Enterprise drivers may also be obtained from:

ftp://download.nvidia.com/novell

High-Resolution
Antialiasing

Parallel Processor
Cores

Power consumption

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

64x full scene antialiasing (FSAA)/128x FSAA in SLI Mode

352 CUDA parallel processing cores

152 Watts

or

http://www.nvidia.com

Page 62

QuickSpecs

Technical Specifications - Multimedia and Audio Devices

HP Z600 Workstation

Integrated Intel/Realtek
HD ALC262 Audio

Type

High Definition Codec

FM Synthesis Support

OPL3 FM Synthesis
Support

Sound Blaster
Compatibility

Meets Premium
performance for
Windows Logo
Program 3.0

Audio Jacks

Sampling

Wavetable Syntheses

(software)

3D Positional Sound

Digital Audio

Analog Audio

DVD Audio

Number of Channels
on Line-Out

Internal Audio Speaker
Power Rating

Internal Speaker

Hardware Equalizer for
Internal Speaker

External Speaker Jack

(Line-Out)

Integrated

Yes

Yes

Yes

Yes

Yes

Front panel microphone in and headphone out - fixed usage.
Rear panel line in and line out jacks - jacks are retaskable
One Line-In* (12-K ohm Input Impedance)*

NOTE:

3 stereo ADCs support 16/20-bit PCM format with 44.1K/48K/96kHz
sample rate
2 stereo DAC supports 16/20/24-bit PCM format with

44.1K/48K/96K/192kHz sample rate

Yes – GM and FM Midi Support, Direct Music and Down Loadable
Soundset (4 Meg DLS Level 1 and 2 Support)

No

Yes

Yes

Yes

Stereo (Left & Right channels)

1.5 W

Yes

No

Yes

External Speakers need to be powered externally.

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 63

QuickSpecs

Technical Specifications - Multimedia and Audio Devices

HP Z600 Workstation

SoundBlaster (Creative
Labs) X-Fi Titanium
PCIe Audio Card

24-bit Analog-to-Digital
conversion of analog
inputs

24-bit Digital-to-Analog
conversion of digital
sources

24-bit Digital-to-Analog
conversion of stereo
digital sources

16-bit to 24-bit
recording sampling
rates

Enhanced SoundFont
support

Signal-to-Noise Ratio

(2okHz Low-pass filter,
A-Weighted)

Total Harmonic
Distortion + Noise at
1kHz

(20kHz Low-pass

filter)

Frequency Response

3dB, 24-bit/96kHz input)

Frequency Response

3dB, 24-bit/192kHz
input)

Speaker and
Headphone
connections

Flexijack

Front Panel Header

Operating System

Minimum System
Requirements

(-

(-

96kHz sample rate

96kHz to analog 7:1 speaker output

8, 11.025, 16, 22.05, 24, 32, 44.1, 48 and 96kHz

16-bit/44.1kHz, 16-bit/48kHz, 24-bit/44.1kHz, 24-bit/48kHz and 24­bit/96kHz with direct monitoring

Up to 24-bit resolution

109dB

.004%

10Hz to 46kHz

10Hz to 46kHz

Stereo to 7.1 (Line Out via three 3.5mm mini jacks)

Line In/ Microphone In/Optical Out via shared 3.5mm mini jack

Intel HD Audio Compatible (2x5 pin)

Microsoft Windows Vista Business 64
Microsoft Windows Vista Business 32
Microsoft® Windows® XP Professional SP2
Microsoft Windows XP Professional x64 Edition

System RAM

Operating System

512MB

Windows Vista 32-bit and 64-bit version or
Windows XP 32-bit or 64-bit version

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 64

QuickSpecs

Technical Specifications - Multimedia and Audio Devices

HP Z600 Workstation

HP SkyRoom Standard
Accessory Hardware
Kit

System requirements

Kit Contents

Webcam

Headset

Product Safety

EMC

CE Mark

Telecom

USA

Windows® 7, Windows Vista™, Windows XP
Intel® Core 2 Duo 2.3 GHz or higher
Available analog microphone jacks

Webcam
Audio headset
Software and Documentation CD-ROM
Product and warranty documentation

Video – Up to 30 fps VGA
Lens – Carl Zeiss Lens
Color Depth – 24 bit
USB 2.0 Interface with Cable – 6 feet

Frequency Response:

Microphone – 100 Hz to 16000 Hz
150 Hz to 20000 Hz
Sensitivity – - 44 dB ± 3dB
Cable – 8 ft shielded plug with 3.5 mm analog plugs

UL/cUL; TUV/(Europe only); NOM (Mexico)

FCC; CE; VCCI; RRL; C-Tick; BSMI; GOST

EN 55022:1998; EN 50024

All local telecom requirements and approvals for intended markets

FCC Part 15 Equipment Certificate; CFR 47, Part 15; other local
requirements

HP SkyRoom Desktop
Audio Kit (PCIe)

USB Powered
Speakers

Microphone

Creative X-Fi Titanium
Audio Card, PCIe

Power LED

Frequency response

Dimensions (H x W xD)90.4mm x 90.4mm x 252.2mm (10.94 x 8.11 x

Net weight

USB cable length

Speaker cable length

Frequency Response

Input sensitivity

Cable

Dimensions (H x W xD)17.2 x 68.5 x 88 mm (0.68 x 2.7 x 3.54 in)

24-bit Analog-to-Digital
conversion of analog
inputs

24-bit Digital-to-Analog
conversion of stereo
digital sources

24-bit Digital-to-Analog
conversion of stereo
digital sources

Front of one speaker

80Hz - 20kHz, +/-10dB

5.28 in.)per speaker

648 g (1.43 pounds)

200 cm(6.6 feet )

122 cm (4 feet)

E110 Hz to 15000 Hz

-35 dBV/µbar, -32dBV/Pa +/- 3 dB

294.2 cm (9.6 ft) shielded plug with a 3.5 mm
analog plug

96kHz sample rate

96kHz to analog 7:1 speaker output

192 kHz to stereo output

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 65

QuickSpecs

Technical Specifications - Multimedia and Audio Devices

HP Z600 Workstation

16-bit to 24-bit
recording sampling
rates

Enhanced SoundFont
support

Signal-to-Noise Ratio

Frequency Response (­3dB, 24-bit/96kHz
input)

Frequency Response (­3dB, 24-bit/192kHz
input)

Speaker and
Headphone
connections

Flexijack

Front Panel Header

Kit contents

System requirements

8, 11.025, 16, 22.05, 24, 32, 44.1, 48 and
96kHz

Up to 24-bit resolution

Stereo Output 109dB
Front and Rear Channels 109dB
Center, Subwoofer and Side Channels 109dB

0Hz to 46kHz

10Hz to 46kHz

Stereo to 7.1 (Line Out via three 3.5mm mini
jacks)

Line In/ Microphone In/Optical Out via shared

3.5mm mini jack

HDMI SPDIF (1 x 3 header), HDAudio FP (2 x
5 header)

USB Powered Speakers
Unidirectional Microphone
Creative X-Fi Titanium Audio Card,
PCIe
Product and warranty documentation

Windows® 7, Windows Vista™, Windows XP
Intel® Core 2 Duo 2.3 GHz or higher
Available analog microphone jacks

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 66

QuickSpecs

Technical Specifications - Optical and Removable Storage

HP Z600 Workstation

NOTE 1

protected materials. Intended for creation and storage of your original material and other lawful uses. Double Layer discs
can store more data than single layer discs. However, double-layer discs burned with this drive may not be compatible with
many existing single-layer DVD drives and players.

HP DVD-ROM Drive

: Actual speeds may vary. Does not permit copying of commercially available DVD movies or other copyright

Description

Mounting Orientation

Interface Type

Dimensions

Disc Capacity

Access Times

Power

Operating
Environmental

conditions non­condensing)

(WxHxD)

(all

5.25-inch, half-height, tray-load

Either horizontal or vertical

SATA/ATAPI

15.0 x 4.4 x 20.3 cm (5.9 x 1.7 x 8.0 in)

DVD-ROM

DVD-ROM Single
Layer

CD-ROM Mode 1

Full Stroke DVD

Full Stroke CD

Source

DC Power
Requirements

DC Current

Temperature

Relative Humidity

Maximum Wet Bulb
Temperature

Operating Systems
Supported

Single layer: Up to 4.7 GB Double layer: Up to 8.5
GB

< 140 ms (typical)

< 125 ms (typical)

< 250 ms (seek)

< 210 ms (seek)

SATA DC power receptacle

5 VDC ± 5%-100 mV ripple p-p
12 VDC ± 5%-200 mV ripple p-p

5 VDC - <1000 mA typical, < 1600 mA maximum
12 VDC - < 600 mA typical, < 1400 mA maximum

5° to 50° C (41° to 122° F)

10% to 90%

30° C (86° F)

Windows Vista Business 64*, Windows Vista
Business 32*, Windows Vista Home Basic 32*,
Windows 2000, Windows XP Professional or
Windows XP Home 32*.
Red Hat Enterprise Linux(RHEL) WS4**, 5
Desktop/Workstation
Novell SLED 10 & SLED 11
No driver is required for this device. Native support
is provided by the operating system.

* Certain Windows Vista product features require
advanced or additional hardware. See

http://www.microsoft.com/windowsvista/
getready/hardwarereqs.mspx
http://www.microsoft.com/windowsvista/
getready/capable.mspx

Upgrade Advisor can help you determine which
features of Windows Vista will run on your
computer. To download the tool, visit:

http://www.windowsvista.com/upgradeadvisor

Windows Vista system requirements, visit:

http://www.windowsvista.com/systemrequirements

** RHEL WS4 not supported on Z200/Z200SFF

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

and

for details. Windows Vista

. For

.

Page 67

QuickSpecs

Technical Specifications - Optical and Removable Storage

HP Z600 Workstation

HP DVD+/-RW Drive

Description

Mounting Orientation

Interface Type

Dimensions

Disc Formats

Disc Capacity

Maximum Data
Transfer Rates

Power

Operating
Environmental

conditions non­condensing)

(WxHxD)

(all

5.25-inch, half-height, tray-load

Either horizontal or vertical

SATA/ATAPI

15.0 x 4.4 x 20.3 cm (5.9 x 1.7 x 8.0 in)

DVD-RAM
DVD+R
DVD+RW
DVD+R DL
DVD-R DL
DVD-R
DVD-RW
CD-R
CD-RW

DVD-ROM

Full Stroke DVD

Full Stroke CD

CD ROM Read

DVD ROM Read

Source

DC Power
Requirements

DC Current

Temperature

Relative Humidity

Maximum Wet Bulb
Temperature

Operating Systems
Supported

8.5 GB DL or 4.7 GB standard

< 250 ms (seek)

< 210 ms (seek)

CD-ROM, CD-R Up to 40X
CD-RW Up to 32X

DVD-RAM

DVD+RW

DVD-RW

DVD+R DL

DVD-R DL

DVD-ROM

DVD-ROM DL

DVD+R

DVD-R

SATA DC power receptacle

5 VDC ± 5%-100 mV ripple p-p
12 VDC ± 5%-200 mV ripple p-p

5 VDC -1000 mA typical, 1600 mA maximum
12 VDC -600 mA typical, 1400 mA maximum

5° to 50° C (41° to 122° F)

10% to 90%

30° C (86° F)

Windows Vista Business 64*, Windows Vista
Business 32*, Windows Vista Home Basic 32*,
Windows 2000, Windows XP Professional or
Windows XP Home 32*.
Red Hat Enterprise Linux (RHEL) WS4**, 5
Desktop/Workstation
Novell SLED 10 & SLED 11

Up to 12X

Up to 8X

Up to 8X

Up to 8X

Up to 8X

Up to 16X

Up to 8X

Up to 16X

Up to 16X

No driver is required for this device. Native
support is provided by the operating system.

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 68

QuickSpecs

Technical Specifications - Optical and Removable Storage

*Certain Windows Vista product features require
advanced or additional hardware. See

http://microsoft.com/windowsvista/
getready/hardwarereqs.mspx
http://www.microsoft.com/windowsvista/
getready/capable.mspx

Upgrade Advisor can help you determine which
features of Windows Vista will run on your
computer. To download the tool, visit:

http://www.windowsvista.com/upgradeadvisor

Windows Vista system requirements, visit:

http://www.windowsvista.com/systemrequirements

* LightScribe functionality is not natively
supported by Linux distributions. Customers may
download LightScribe Linux drivers from:

http://www.lightscribe.com/
downloadSection/linux/index.aspx

** RHEL WS4 not supported on Z200/Z200SFF

Kit Contents

HP SATA SuperMulti LightScribe DVD Writer
drive, LightScribe software, Roxio Easy Media
Creator software, Intervideo WinDVD Software,
installation guide, and DVD+R media.

HP Z600 Workstation

and

for details. Windows Vista

. For

HP Slot Load DVD+/­RW Drive

Description

Mounting Orientation

Interface Type

Dimensions

Disc Formats

Disc Capacity

(WxHxD)

Slim-Line, Slot-load

Either horizontal or vertical

SATA

12.7 x 1.2 x 12.9 cm (5 x 0.5 x 5 in)

DVD-RAM DVD+R DVD+RW DVD+R DL DVD-R DL DVD-R DVD-RW
CD-R CD-RW

DVD-ROM

CD-ROM

Full Stroke DVD

Full Stroke CD

5/9/10/18 G DVD-Single / Dual (PTP, OTP)
(Read Only)

4.7G DVD±R/RW (Read & Write)
DVD±R Dual (Read & Write)
80mm DVD
DVD-RAM (Read & Write)

650 MB CD-ROM (Read Only)
80mm CD
800/700/650/ CD-Recordable (Read & Write)
700/650MB CD-Rewritable (Read & Write)
700/650MB High Speed CD-Rewritable (Read
& Write)
700/650MB Ultra & Ultra+ Speed CD­Rewritable (Read & Write)

< 270 ms (seek)

< 250 ms (seek)

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 69

QuickSpecs

Technical Specifications - Optical and Removable Storage

HP Z600 Workstation

HP Blu-Ray Writer

Maximum Data
Transfer Rates

Power

Operating
Environmental

conditions non­condensing)

Description

Mounting Orientation

Interface Type

Dimensions

Disc Formats

Disc Capacity

(all

(WxHxD)

CD ROM Read

DVD ROM Read

Source

DC Power
Requirements

DC Current

Temperature

Relative Humidity

Operating Systems
Supported

Kit Contents

5.25-inch, half-height, tray-load

Either horizontal or vertical

SATA

15.0 x 4.4 x 20.3 cm (5.9 x 1.7 x 8.0 in)

BD-ROM
BD-R
BD-RE
DVD-RAM
DVD+R
DVD+RW
DVD+R DL
DVD-R DL
DVD-R
DVD-RW
CD-R
CD-RW

DVD-ROM

Blu-ray

Full Stroke DVD

Full Stroke CD

Blu-ray

Startup Time

drive ready from tray
loading)

(Time to

CD-ROM, CD-R and CD-RW Up to 24X

DVD-RAM Up to 5X DVD Single layer Up to
8X DVD Dual Layer up to 6X

SATA DC power receptacle

5 VDC ± 5%-100 mV ripple p-p

5 VDC 40 mA typical, 800 mA maximum

5° to 50° C (41° to 122° F)

10% to 90%

Windows Vista Business 64*, Windows Vista
Business 32*, Windows Vista Home Basic
32*, Windows XP Professional or Windows
XP Home 32*.
Red Hat Enterprise Linux(RHEL) WS4, 5
Desktop/Workstation
Novell SLED 10 & SLED 11
No driver is required for this device. Native
support is provided by the operating system.

Factory integrated only. Not available as a kit.

8.5 GB DL or 4.7 GB standard

50 GB DL or 25 GB standard

< 250 ms (seek)

< 210 ms (seek)

Blu-ray

BD-ROM (SL/DL)

BD-R (SL/DL)

BD-RE (SL/DL)

DVD-ROM (SL/DL)

DVD-R (SL/DL)

25S / 28S

25S / 28S

25S / 28S

18S / 18S

25S / 25S

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 70

QuickSpecs

Technical Specifications - Optical and Removable Storage

HP Z600 Workstation

Maximum Data
Transfer Rates

Power

Operating
Environmental

conditions non­condensing)

(all

CD ROM Read

DVD ROM Read

Blu-Ray

Source

DC Power
Requirements

DC Current

Temperature

Relative Humidity

Maximum Wet Bulb
Temperature

Operating Systems
Supported

DVD-RW

DVD+R (SL/DL)

DVD+RW

DVD-RAM

CD-ROM

CD-ROM
CD-R
CD-RW

DVD-RAM

DVD+RW

DVD-RW

DVD+R DL

DVD-R DL

DVD-ROM

DVD-ROM DL

DVD+R

DVD-R

BD-ROM

BD-ROM DL

BD-R

BD-R DL

BD-R

BD-RE SL/DL

SATA DC power receptacle

5 VDC ± 5%-100 mV ripple p-p
12 VDC ± 10%-100 mV ripple p-p

5 VDC -900 mA typical, 1200 mA maximum
12 VDC -1000 mA typical, 1600 mA maximum

5° to 50° C (41° to 122° F)

15% to 80%

30° C (86° F)

Windows Vista Business 64*, Windows Vista
Business 32*, Windows Vista Home Basic
32*, Windows 2000, Windows XP
Professional or Windows XP Home 32*.
Red Hat Enterprise Linux (RHEL) WS4**, 5
Desktop/Workstation
Novell SLED 10 & SLED 11

25S

25S / 25S

25S

45S

45S

Up to 40X
Up to 40X
Up to 40X

Up to 5X

Up to 10X

Up to 10X

Up to 8X

Up to 8X

Up to 16X

Up to 8X

Up to 12X

Up to 12X

Up to 6X

Up to 4.8X

Up to 6X

Up to 4.8X

Up to 6X

Up to 4.8X

* No driver is required for this device. Native
support is provided by the operating system.

** RHEL WS4 not supported on
Z200/Z200SFF

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 71

QuickSpecs

Technical Specifications - Optical and Removable Storage

HP Z600 Workstation

HP 22-in-1 Media Card
Reader

Disclaimer

Description

Mounting Orientation

Interface Type

Dimensions

Disc Formats

(WxHxD)

Kit Contents

As Blu-Ray is a new format containing new technologies, certain disc,
digital connection, compatibility and/or performance issues may arise,
and do not constitute defects in the product. Flawless playback on all
systems is not guaranteed. In order for some Blu-Ray titles to play, they
may require a DVI or HDMI digital connection and your display may
require HDCP support. HD-DVD movies cannot be played on this
workstation.

The Media Card Reader device uses the same physical form factor and
mounting as a Floppy Disk Drive. The device connects to a 2x5 two­channel USB header on the motherboard of the system. There is no
USB controller card provided. Please see the Disc Formats section
below for a list of flash memory card formats that are supported.

The Media Card Reader can be mounted in a dedicated Floppy Drive
bay (if the chassis provides one) or in an appropriate Optical Bay
adapter. It will operate in any orientation.

USB 2.0 (one channel dedicated to the separate USB port; one channel
dedicated to the flash memory card slots)

124.5 x 101.6 x 25.4 mm (4.9 x 4.0 x 1.0 in)

xD-Picture
Micro SD
Micro SDHC
SD
SDHC
Mini SD
Mini SDHC
MultiMediaCard (MMC)
Reduced Size MultiMediaCard (RS MMC)
MultiMedia Card 4.2 (MMC Plus, including MMC Plus HC)
Reduced Size MultiMedia Card 4.2 (MMC Mobile, including MMC Mobile
HC)
CompactFlash Card Type I
CompactFlash Card Type II
MicroDrive
Memory Stick (MS)
MagicGate Memory Stick (MG)
MagicGate Memory Stick Duo
Memory Stick Select
Memory Stick Duo (MS Duo)
Memory Stick PRO (MS PRO)
Memory Stick PRO Duo (MS PRO Duo)
Memory Stick PRO-HG Duo

HP Blue Laser RW Drive, LightScribe
software, Roxio Easy Media Creator software,
Intervideo WinDVD Software, installation
guide.

Two additional formats are usable with adapters (not supplied):
MMC Micro
Memory Stick Micro (M2)

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 72

QuickSpecs

Technical Specifications - Optical and Removable Storage

HP Z600 Workstation

HP DX115 Removable
Drive Enclosure

Interface Type

Dimensions

Weight

(WxHxL)

Compatible with SAS or SATA controllers

147.6 x 41.1 x 205 mm (5.81 x 1.62 x 8.08 in)

Frame and Carrier: 1.73 kg (3.8 lbs)
Carrier: 0.45 kg (1 lbs)

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 73

QuickSpecs

Technical Specifications - Controller Cards

HP Z600 Workstation

HP FireWire/IEEE
1394a PCI Card

Data Transfer Rate

Device Interface
Protocol

Devices Supported

Bus Type

Certification Level

Ports

Internal Connectors

System Requirements

Temperature ­Operating

Temperature - Storage

Relative Humidity ­Operating

Operating Systems
Supported

Burst Data Rate up to 400 Mbps

IEEE-1394a

IEEE-1394 compliant devices

PCI card with brackets for low profile and full height PCI slots.

FCC Part 15B, cULus 60950, CE Mark EN55022B(1995)/EN55024­1998 STD, Taiwan BSMI CNS13438, Korea MIC

Two IEEE 1394 6-Pin Connector (Rear)

One 10-Pin (9 Contacts) Custom Connector

Windows Vista Business 64*, Windows Vista Business 32*, Windows
Vista Home Basic 32*, Windows 2000, Windows XP Professional or
Windows XP Home 32*. No driver is required for this device. Native
support is provided by the operating system.

* Certain Windows Vista product features require advanced or additional
hardware. Windows Vista Upgrade Advisor can help you determine
which features of Windows Vista will run on your computer. To
download the tool, visit:
For Windows Vista system requirements, visit:

http://www.windowsvista.com/systemrequirements

Pentium II 266 or above
128-MB RAM
1-GB Hard Drive
CD-ROM drive
Built-in sound system
Available PCI slot

50° to 131° F (10° to 55° C)

-22° to 140° F (-30° to 60° C)

20% to 80%

Windows Vista Business 64*, Windows Vista Business 32*, Windows
Vista Home Basic 32*, Windows 2000, Windows XP Professional or
Windows XP Home 32

http://www.windowsvista.com/upgradeadvisor

.

*

.

* Certain Windows Vista product features require advanced or additional
hardware. Windows Vista Upgrade Advisor can help you determine
which features of Windows Vista will run on your computer. To
download the tool, visit:
For Windows Vista system requirements, visit:

http://www.windowsvista.com/systemrequirements

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

http://www.windowsvista.com/upgradeadvisor

.

.

Page 74

QuickSpecs

Technical Specifications - Controller Cards

HP Z600 Workstation

HP IEEE 1394b
FireWire PCIe Card

Data Transfer Rate

Devices Supported

Bus Type

Ports

Internal Connectors

System Requirements

Temperature –
Operating

Temperature – Storage

Relative Humidity –
Operating

Compliances

Operating Systems
Supported

Supports up to 800 Mbps

IEEE-1394 compliant devices

PCIe card full height PCIe slots

Two IEEE-1394b bilingual 9-Pin Connector (Rear)

One 10-Pin header Custom Connector

Microsoft Windows XP Professional, Windows XP Home, Windows
Vista. Not supported on Linux. Pentium® III or higher processor 128-MB
RAM 1-GB Hard Drive CD-ROM drive Built in sound system Available
PCI slot

50° to 131° F (10° to 55° C)

–22° to 140° F (–30° to 60° C)

20% to 80%

FCC Part 15B, cULus 60950, CE Mark EN55022B(1995)/EN55024­1998 STD, Taiwan BSMI CNS13438, Korea MIC

Microsoft Windows XP and Windows Vista

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 75

QuickSpecs

Technical Specifications - Networking and Communications

HP Z600 Workstation

NOTE 1

actual operating speed of 1 Gb/sec. For high speed transmission, connection to a Gigabit Ethernet server and network
infrastructure is required.

Integrated Broadcom
5764 PCIe LOM
Controller

Broadcom (5761)
NetXtreme Gigabit
Ethernet Plus NIC

: "Gigabit" Ethernet indicates compliance with IEEE standard 802.3ab for Gigabit Ethernet, and does not connote

Connector

Data Rates Supported

Bus Architecture

Alerting

Connector

Controller

Memory

Data Rates Supported

Compliance

Bus Architecture

Data Path Width

Data Transfer Mode

Hardware
Certifications

Power Requirement

Boot ROM Support

Network Transfer Mode

Network Transfer Rate

Operating Temperature

Operating Humidity

Dimensions

Operating System
Driver Support

RJ45

10/100/1000BT

PCIe X1

ASF 2.0

RJ-45

Broadcom 5761 PCI-Express LAN Controller

8 MB NVRAM serial Flash

10/100/1000 Mbps

IEEE 802.1P, 802.1Q, 802.2, 802.3, 802.3AB, 802.3u, and 802.3x

PCI-Express

Single Channel PCI-Express

Bus Master DMA

FCC class B, Canada and US NRTL Mark, C-Tick for Australia, BSMI
for Taiwan, VCCI for Japan, MIC for Korea, GOST for Russia, UL listed
(E212044), European Union Notice (CE 0682)

1.8W @ 3.3V

Yes

Full-duplex
Half-duplex (not available for the 1000BASE-T transceiver)

10BASE-T (half-duplex) 10 Mbps
10BASE-T (full-duplex) 20 Mbps
100BASE-TX (half-duplex) 100 Mbps
100BASE-TX (full-duplex) 200 Mbps
1000BASE-T (full-duplex) 2000 Mbps

32° to 131°F (0° to 55° C)

131° F (55° C) with 5% to 95% non-condensing humidity

7 cm x 10.5 cm (2.75 in x 4.13 in), low profile compatible

Windows Vista 32-bit SP1, Windows Vista x64 SP1, Windows XP 32 bit
professional, Windows XP x64
Red Hat Enterprise Linux (RHEL) WS4*, 5 Desktop/Workstation
Novell SLED 10 & 11

*RHEL WS4 not supported on Z200/Z200SFF

Management
Capabilities

Kit Contents

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

ACPI, WOL and DMI 2.0, PXE 2.0, WfM 2.0, Broadcom mgmt utility,
ASF2.0, DASH 1.0 and DASH 1.1 profiles

Broadcom NetXtreme Gigabit Ethernet Plus NIC, Broadcom NetXtreme
Gigabit Ethernet Plus NIC USB Cable Assembly, CD, drivers, quick
install guide, product warranty statement

Page 76

QuickSpecs

Technical Specifications - Networking and Communications

HP Z600 Workstation

HP NC360T PCI
Express Dual Port
Gigabit NIC

Connector

Controller

Memory

Data Rates Supported

Compliance

Bus Architecture

Data Path Width

Data Transfer Mode

Hardware
Certifications

Power Requirement

Boot ROM Support

Network Transfer Rate

Operating Temperature

Operating Humidity

Dimensions

Operating System
Driver Support

Two RJ-45

Intel 82571EB

Integrated 96KB

10/100/1000 Mbps

802.3, 802.3u, 802.3x, 802.3ab, 802.3ad, 802.1p, 802.1Q

PCI-E 1.0a

Four lane (x4) PCI Express compatible with x4, x8, and x16 PCI
Express slots

Bus-master DMA

FCC Class B, VCCI Class B, BSMI Class A, CISPR 22 Class B, EN
55022 Class B, EN55024-1, ICES-003 Class B, MIC Class B, ACA
Class B, UL, Canada UL, EN60950

1280 mA @ 3.3V typical

Yes

10BASE-T (half-duplex) 10 Mbps
10BASE-T (full-duplex) 20 Mbps
100BASE-TX (half-duplex) 100 Mbps
100BASE-TX (full-duplex) 200 Mbps
1000BASE-T (full-duplex) 2000 Mbps

32° to 131°F (0° to 55° C)

0% to 95% non-condensing

12.95 x 6.8 cm (5.1 x 2.7 in)

Windows Vista Business 64*, Windows Vista Business 32*, Windows
XP Professional, Windows XP Professional x64 Edition.
Red Hat Enterprise Linux(RHEL) WS4, 5 Desktop/Workstation
Novell SLES 9 & SLE 10

Management
Capabilities

Kit Contents

* Certain Windows Vista product features require advanced or additional
hardware. Windows Vista Upgrade Advisor can help you determine
which features of Windows Vista will run on your computer. To
download the tool, visit:
For Windows Vista system requirements, visit:

http://www.windowsvista.com/systemrequirements

WOL , PXE 2.1

HP NC360T PCI Express Dual Port Gigabit NIC, low profile bracket, CD
containing Intel PROset II NIC drivers, quick install guide, product
warranty statement

http://www.windowsvista.com/upgradeadvisor

.

.

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 77

QuickSpecs

Technical Specifications - Networking and Communications

HP Z600 Workstation

Intel Gigabit CT
Desktop NIC

Connector

Controller

Memory

Data Rates Supported

Compliance

Bus Architecture

Data Path Width

Data Transfer Mode

Hardware
Certifications

Power Requirement

Boot ROM Support

Network Transfer Rate

Operating Temperature

Operating Humidity

Dimensions

Operating System
Driver Support

Management
Capabilities

Kit Contents

RJ-45

Intel WG82574L Gigabit Ethernet Controller

Integrated Dual 48K configurable transmit receive FIFO Buffers

10/100/1000 Mbps

IEEE 802.1P, 802,1Q, 802.2, 802.3, 802.3AB and 802.3u compliant,

802.3x flow control

PCI-E 1.0a

X1, 250 MB/s, Bi-directional interface

Bus-master DMA

FCC, B, CE, TUV- cTUVus Mark Canada and United States, TUV- GS
Mark for European Union

Aux 3.3V, 3.0 Watts in 1000base-T and 2.0 Watts in 100Base-T

Yes

10BASE-T (half-duplex) 10 Mbps
10BASE-T (full-duplex) 20 Mbps
100BASE-TX (half-duplex) 100 Mbps
100BASE-TX (full-duplex) 200 Mbps
1000BASE-T (full-duplex) 2000 Mbps

32° to 131°F (0° to 55° C)

85% at 131° F (55° C)

12.1 x 5.7 x 2.0 cm ()4.75 x 2.25 x 0.8 in

Windows Vista Business 64, Windows Vista Business 32, Windows XP
Professional, Windows XP x64.
Red Hat Enterprise Linux 4 (RHEL4.8 or newer)*, Red Hat Enterprise
Linux 5 (RHEL5.3 or newer).

* RHEL WS4 not supported on Z200/Z200SFF

WOL , PXE, DMI, WFM 2.0

Intel Gigabit CT Desktop NIC, low profile bracket, CD containing Intel
PROset II NIC drivers, quick install guide, product warranty statement

© 2010 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice.
The only warranties for HP products and services are set forth in the express warranty statements accompanying such
products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for
technical or editorial errors or omissions contained herein. Intel, Xeon, and QuickPath are trademarks of Intel Corporation in
the U.S. and other countries. Microsoft and Windows are U.S. registered trademarks of Microsoft Corporation. Windows
Vista is either a registered trademark or trademark of Microsoft Corporation in the United States and/or other countries.

DA - 13277 Worldwide QuickSpecs — Version 23 — 12/1/2010

Page 78
