HP X22LEDC, X23LED, X22LED, X20LED User Manual

HP x20LED, x22LED, x22LEDc and x23LED Monitors
User Guide

© 2010 Hewlett-Packard Development Company, L.P.
Microsoft, Windows, and Windows Vista are either
trademarks or registered trademarks of Microsoft
Corporation in the United States and/or other countries.

The only warranties for HP products and services are set
forth in the express warranty statements accompanying
such products and services. Nothing herein should be
construed as constituting an additional warranty. HP shall
not be liable for technical or editorial errors or omissions
contained herein.

This document contains proprietary information that is
protected by copyright. No part of this document may be
photocopied, reproduced, or translated to another
language without the prior written consent of Hewlett­Packard Company.

Document Part Number: 603461-002

Second Edition, (June 2010)

About This Guide

This guide provides information on setting up the monitor, installing drivers, using the
on-screen display menu, troubleshooting and technical specifications.

WARNING! Text set off in this manner indicates that failure to follow directions

could result in bodily harm or loss of life.

CAUTION: Text set off in this manner indicates that failure to follow directions

could result in damage to equipment or loss of information.

NOTE: Text set off in this manner provides important supplemental information.

ii

Table of Contents

About This Guide

1. Product Features

HP LCD Monitors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

2. Safety and Maintenance Guidelines

Important Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Maintenance Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Cleaning the Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

3. Setting Up the Monitor

Unpacking the Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Installing the Monitor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Connecting Monitor Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

High-Bandwidth Digital Content Protection (HDCP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Connecting the Power Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

4. Operating the Monitor

CD Software and Utilities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Installing Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Installing the monitor driver software from the CD. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Downloading updated drivers from the Internet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Front-Panel Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Using the On-Screen Display (OSD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Selecting Video Input Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Identifying Monitor Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Adjusting Screen Quality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Power-Saver Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

ENWW iii

A. Troubleshooting

Solving Common Problems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Getting Support from hp.com . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Preparing to Call Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Locating the Rating Label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

B. Technical Specifications

HP LCD Monitors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Preset Video Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

LCD Monitor Quality and Pixel Policy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

C. Agency Regulatory Notices

Federal Communications Commission Notice. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Modifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Declaration of Conformity for Products Marked with the FCC Logo (United States Only). . . . . . . . . . . . . . . . . . . . . . . . . 24

Canadian Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Avis Canadien . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

German Ergonomics Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Japanese Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Korean Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Power Cord Set Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Japanese Power Cord Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Product Environmental Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Materials Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Disposal of Waste Equipment by Users in

Private Household in the European Union . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Chemical Substances. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

HP Recycling Program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Restriction of Hazardous Substances (RoHS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Turkey EEE Regulation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

iv

1. Product Features

HP LCD Monitors

The HP LCD (liquid crystal display) monitors have an active matrix, thin-film transistor
(TFT) screen with the following features:

• Large diagonal display

• Maximum graphics resolution:
x20LED: 1600 x 900 @ 60Hz
x22LED/x22LEDc: 1920 x1080 @ 60Hz
x23LED: 1920 x 1080 @ 60Hz

Plus full-screen support for lower resolutions

• VGA analog signal

• DVI digital signal

• Easy viewing from a sitting or standing position, or while moving from one side of
the monitor to the other

• Tilt adjustment

• Removable base

• Security lock slot for a locking security cable (security cable sold separately)

• Plug and Play capability, if supported by your computer system

• On-screen display (OSD) adjustments for ease of setup and screen optimization
(choose English, Spanish, French, Portuguese, Russian, Simplified Chinese,
Traditional Chinese, Korean)

• Power Saver to reduce energy consumption

• Energy-efficient white LED backlight using less power than standard LCD
monitors

• HDCP (High Bandwidth Digital Content Protection) on DVI input

• Software and utilities CD, containing the following:
Drivers
Documents

ENWW HP LCD Monitors 1

2. Safety and Maintenance Guidelines

Important Safety Information

A power cord is included with the monitor. If another cord is used, use only a power
source and connection appropriate for this monitor. For information on the correct

power cord set to use with the monitor, refer to the "

on Chapter 3 .

WARNING! To reduce the risk of electric shock or damage to the equipment:

• Do not disable the power cord grounding feature. The grounding plug is an
important safety feature.

• Plug the power cord in a grounded (earthed) outlet that is easily accessible at all
times.

• Disconnect power from the product by unplugging the power cord from the
electrical outlet.

For your safety, do not place anything on power cords or cables. Arrange them so that
no one may accidentally step on or trip over them. Do not pull on a cord or cable.
When unplugging from the electrical outlet, grasp the cord by the plug.

To reduce the risk of serious injury, read the Safety and Comfort Guide . It describes
proper workstation, setup, posture, and health and work habits for computer users,
and provides important electrical and mechanical safety information. This guide is
located on the Web at http://www.hp.com/ergo
one is included with the monitor.

Connecting the Power Cable" section

and/or on the documentation CD, if

power cords for the computer and its peripheral devices (such as a monitor, printer,
scanner) to some form of surge protection device such as a power strip or
Uninterruptible Power Supply (UPS). Not all power strips provide surge protection; the
power strips must be specifically labeled as having this ability. Use a power strip
whose manufacturer offers a Damage Replacement Policy so you can replace the
equipment, if surge protection fails.

Use the appropriate and correctly sized furniture designed to properly support your
HP LCD monitor.

cases, shelves, desks, speakers, chests, or carts may fall over and cause personal
injury. Care should be taken to route all cords and cables connected to the LCD
monitor so that they can not be pulled, grabbed, or tripped over.

Safety Precautions

• Use only a power source and connection compatible with this monitor, as

• Be sure the total ampere rating of the products connected to the outlet does not

CAUTION: For the protection of the monitor, as well as the computer, connect all

WARNING: LCD monitors that are inappropriately situated on dressers, book

indicated on the label/back plate of the monitor.

exceed the current rating of the electrical outlet, and the total ampere rating of the
products connected to the power cord does not exceed the rating of the power
cord. Look on the power label to determine the ampere rating (Amps or A) for
each device.

2 Chapter 2. Safety and Maintenance Guidelines ENWW

• Install your monitor near a power outlet that you can easily reach. Disconnect the
monitor by grasping the plug firmly and pulling it from the outlet. Never disconnect
the monitor by pulling the cord.

• Do not allow anything to rest on the power cord. Do not walk on the cord

Maintenance Guidelines

To enhance the performance and extend the life of the monitor:

• Do not open the monitor cabinet or attempt to service this product yourself. Adjust
only those controls that are covered in the operating instructions. If the monitor is
not operating properly or has been dropped or damaged, contact an authorized
HP dealer, reseller, or service provider.

• Use only a power source and connection appropriate for this monitor, as indicated
on the label/back plate of the monitor.

• Be sure the total ampere rating of the products connected to the outlet does not
exceed the current rating of the electrical outlet, and the total ampere rating of the
products connected to the cord does not exceed the rating of the cord. Look on
the power label to determine the ampere rating (AMPS or A) for each device.

• Install the monitor near an outlet that you can easily reach. Disconnect the
monitor by grasping the plug firmly and pulling it from the outlet. Never disconnect
the monitor by pulling the cord.

• Turn the monitor off when not in use. You can substantially increase the life
expectancy of the monitor by using a screen saver program and turning off the
monitor when not in use

• Slots and openings in the cabinet are provided for ventilation. These openings
must not be blocked or covered. Never push objec ts of any kind into cabinet slots
or other openings.

• Do not drop the monitor or place it on an unstable surface.

• Do not allow anything to rest on the power cord. Do not walk on the cord.

• Keep the monitor in a well-ventilated area, away from excessive light, heat or
moisture.

• When removing the monitor base, you must lay the monitor face down on a soft
area to prevent it from getting scratched, defaced, or broken.

Cleaning the Monitor

1. Turn off the monitor and the computer.

2. Unplug the monitor from the wall outlet or the power brick.

3. Clean the monitor plastics with a clean cloth dampened with water.

4. Clean the monitor screen with an antistatic screen cleaner.

CAUTION: Do not use benzene, thinner, ammonia, or any other volatile

substances to clean the monitor or the screen. These chemicals may damage the
cabinet finish as well as the screen.

ENWW Maintenance Guidelines 3

3. Setting Up the Monitor

Unpacking the Monitor

1. Unpack the monitor. Make sure all contents are included. Store the packing box.

2. Turn off the computer and other attached devices.

3. Prepare a flat area to assemble the monitor. You may need a flat, soft, protected
area for placing the monitor screen-down while preparing it for installation.

Installing the Monitor

1. Set the monitor screen face down on a flat, soft, protected table or desk surface
with the support column overhanging the edge.

2. Push the base to the monitor support column and fasten the screw to lock it.

Figure 3-1 Installing the Base

CAUTION: The screen is fragile. Avoid touching or applying pressure to the LCD

screen; doing so can cause damage.

3. Lift the monitor to an upright position and place on a flat, stable surface.

Figure 3-2 Monitor in Upright Position

4 Chapter 3. Setting Up the Monitor ENWW

Connecting Monitor Cables

Connecting the VGA (Analog) Cable or DVI-D (Digital) Cable

Use a VGA video cable or a DVI-D cable to connect your monitor to your computer. To
use DVI, you must have a DVI-compliant graphic card. Connectors are located on the
back of the monitor. Be sure the computer and monitor are turned off and unplugged.

1. To connect the VGA cable (provided with select models)

Connect one end of the VGA video cable to the back of the monitor and the other end
to the VGA video connector on the computer.

2. To connect the DVI-D cable (provided with select models)

Connect one end of the DVI-D video cable to the back of the monitor and the other
end to the DVI-D video connector on the computer. You can use this cable only if your
computer has a DVI compliant graphics card installed. The monitor DVI-D connector
and cable are included.

Figure 3-3

Connecting the VGA or a DVI-D cable - connector locations may vary

High-Bandwidth Digital Content Protection (HDCP)

Your monitor supports HDCP and can receive high-definition content. High-definition
content is available in many sources, such as Blue-ray Disc devices or HDTV air or
cable broadcasts. If you do not have an HDCP-enabled monitor, you will see a blank
screen or a lower resolution picture when playing high-definition protected content.
Your computer graphics card and monitor must both support HDCP to display
protected content.

Connecting the Power Cable

1. Follow all Electrical and Power Warnings

WARNING! To reduce the risk of electric shock or damage to your equipment: Do
not disable the power cord grounding plug. The grounding plug is an important safety
feature.

Plug the power cord into a grounded (earthed) electrical outlet.

Be sure that the grounded power outlet you plug the power cord into is easily
accessible to the operator and located as close to the equipment as possible. A power
cord should be routed so that it is not likely to be walked on or pinched by items that
are placed upon it or against it.

Do not place anything on power cords or cables. Arrange them so that no one may
accidentally step on or trip over them. Do not pull on a cord or cable.

See"Technical Specification" (Appendix B) for additional information.

ENWW Connecting Monitor Cables 5
