HP SPECTRE PRO X360 G1 User Manual

User Guide

Bluetooth is a trademark owned by its proprietor and used by Hewlett-Packard Company under license. Intel is a trademark of Intel Corporation in the U.S. and other countries. Microsoft and Windows are trademarks of the Microsoft group of companies.

The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

First Edition: July 2015

Document Part Number: 824525-001

Product notice

This guide describes features that are common to most products. Some features may not be available on your computer.

Not all features are available in all editions of Windows. This computer may require upgraded and/or separately purchased hardware, drivers and/or software to take full advantage of Windows functionality. Go to

http://www.microsoft.com for details.

To access the latest user guide, go to

http://www.hp.com/support, and select your

country. Select Drivers & Downloads, and then follow the on-screen instructions.

Software terms

By installing, copying, downloading, or otherwise using any software product preinstalled on this computer, you agree to be bound by the terms of the HP End User License Agreement (EULA). If you do not accept these license terms, your sole remedy is to return the entire unused product (hardware and software) within 14 days for a full refund subject to the refund policy of your seller.

For any further information or to request a full refund of the price of the computer, please contact your seller.

Safety warning notice

WARNING! To reduce the possibility of heat-related injuries or of overheating the computer, do not place

the computer directly on your lap or obstruct the computer air vents. Use the computer only on a hard, flat surface. Do not allow another hard surface, such as an adjoining optional printer, or a soft surface, such as pillows or rugs or clothing, to block airflow. Also, do not allow the AC adapter to come into contact with the skin or a soft surface, such as pillows or rugs or clothing, during operation. The computer and the AC adapter comply with the user-accessible surface temperature limits defined by the International Standard for Safety of Information Technology Equipment (IEC 60950-1).

ENWW iii

iv Safety warning notice ENWW

Processor configuration setting (select products only)

IMPORTANT: Select products are configured with an Intel® Pentium® N35xx/N37xx series or a Celeron®

N28xx/N29xx/N30xx/N31xx series processor and a Windows® operating system. If your computer is configured as described, do not change the processor configuration setting in msconfig.exe from 4 or 2 processors to 1 processor. If you do so, your computer will not restart. You will have to perform a factory

reset to restore the original settings.

ENWW v

vi Processor configuration setting (select products only) ENWW

Table of contents

1 Starting right ................................................................................................................................................ 1

Visit the HP Apps Store .......................................................................................................................................... 1

Best practices ......................................................................................................................................................... 1

More HP resources ................................................................................................................................................. 2

2 Getting to know your computer ...................................................................................................................... 4

Locating hardware ................................................................................................................................................. 4

Locating software .................................................................................................................................................. 4

Right side ............................................................................................................................................................... 5

Left side ................................................................................................................................................................. 6

Display ................................................................................................................................................................... 8

Changing your notebook position ....................................................................................................... 9

Changing your notebook to an entertainment stand ....................................................................... 10

Changing your notebook to an interactive stand ............................................................................. 11

Changing your notebook to a tablet ................................................................................................. 11

Top ....................................................................................................................................................................... 12

TouchPad ........................................................................................................................................... 12

Lights ................................................................................................................................................. 13

Keys ................................................................................................................................................... 14

Using the action keys ........................................................................................................................ 14

Front ..................................................................................................................................................................... 15

Labels ................................................................................................................................................................... 16

3 Connecting to a network .............................................................................................................................. 17

Connecting to a wireless network ....................................................................................................................... 17

Using the wireless controls ............................................................................................................... 17

Airplane mode key .......................................................................................................... 17

Operating system controls ............................................................................................. 17

Connecting to a WLAN ....................................................................................................................... 18

Using HP Mobile Broadband (select products only) ......................................................................... 18

Using HP DataPass (select products only) ........................................................................................ 19

Using GPS (select products only) ...................................................................................................... 19

Using Bluetooth wireless devices (select products only) ................................................................ 19

Connecting to a wired network—LAN (select products only) ............................................................................ 19

Sharing data and drives and accessing software ............................................................................................... 20

ENWW vii

4 Enjoying entertainment features .................................................................................................................. 21

Using a webcam or 3D camera (select products only) ........................................................................................ 21

Using audio .......................................................................................................................................................... 21

Connecting speakers ......................................................................................................................... 21

Connecting headphones .................................................................................................................... 21

Connecting a microphone ................................................................................................................. 22

Connecting headsets ......................................................................................................................... 22

Using sound settings ......................................................................................................................... 22

Using video .......................................................................................................................................................... 22

Connecting video devices using an HDMI cable (select products only) ........................................... 23

Setting up HDMI audio .................................................................................................... 24

Connecting digital display devices using a Mini DisplayPort cable (select products only) ............. 24

Discovering and connecting to Miracast-compatible wireless displays (select products only) ..... 25

Discovering and connecting to Intel WiDi certified displays (select Intel products only) ............... 25

5 Navigating the screen .................................................................................................................................. 26

Using the TouchPad and touch screen gestures ................................................................................................. 26

Tap ..................................................................................................................................................... 26

Two-finger pinch zoom ..................................................................................................................... 27

Two-finger scroll (TouchPad only) ................................................................................................... 27

Two-finger tap (TouchPad only) ....................................................................................................... 27

One-finger slide (touch screen only) ................................................................................................ 28

Using the keyboard and optional mouse ............................................................................................................ 28

Using the integrated numeric keypad .............................................................................................. 28

6 Managing power .......................................................................................................................................... 29

Initiating and exiting Sleep and Hibernation ...................................................................................................... 29

Manually initiating and exiting Sleep ................................................................................................ 30

Manually initiating and exiting Hibernation (select products only) ................................................. 30

Setting password protection on wakeup (exiting Sleep or Hibernation) ......................................... 30

Using the power meter and power settings ........................................................................................................ 31

Running on battery power ................................................................................................................................... 31

Factory-sealed battery ..................................................................................................................... 31

Finding battery information .............................................................................................................. 32

Conserving battery power ................................................................................................................. 32

Identifying low battery levels ........................................................................................................... 32

Resolving a low battery level ............................................................................................................ 33

Resolving a low battery level when external power is available .................................. 33

Resolving a low battery level when no power source is available ................................ 33

Resolving a low battery level when the computer cannot exit Hibernation ................. 33

viii ENWW

Running on AC power ........................................................................................................................................... 33

Troubleshooting power problems .................................................................................................... 34

Shutting down (turning off) the computer ......................................................................................................... 34

7 Maintaining your computer .......................................................................................................................... 36

Improving performance ....................................................................................................................................... 36

Using Disk Defragmenter .................................................................................................................. 36

Using Disk Cleanup ............................................................................................................................ 36

Using HP 3D DriveGuard (select products only) ............................................................................... 36

Identifying HP 3D DriveGuard status .............................................................................. 37

Updating programs and drivers .......................................................................................................................... 37

Cleaning your computer ...................................................................................................................................... 37

Cleaning procedures ......................................................................................................................... 37

Cleaning the display ........................................................................................................ 38

Cleaning the sides or cover ............................................................................................. 38

Cleaning the TouchPad, keyboard, or mouse (select products only) ............................ 38

Traveling with or shipping your computer .......................................................................................................... 38

8 Securing your computer and information ...................................................................................................... 40

Using passwords .................................................................................................................................................. 40

Setting Windows passwords ............................................................................................................. 40

Setting Setup Utility (BIOS) passwords ............................................................................................ 41

Using the fingerprint reader (select products only) ........................................................................................... 41

Using Internet security software ......................................................................................................................... 42

Using antivirus software ................................................................................................................... 42

Using firewall software ..................................................................................................................... 42

Installing software updates ................................................................................................................................ 42

Using HP Touchpoint Manager (select products only) ........................................................................................ 43

Securing your wireless network .......................................................................................................................... 43

Backing up your software applications and information ................................................................................... 43

Using an optional security cable ......................................................................................................................... 43

9 Using Setup Utility (BIOS) ............................................................................................................................. 45

Starting Setup Utility (BIOS) ................................................................................................................................ 45

Updating Setup Utility (BIOS) .............................................................................................................................. 45

Determining the BIOS version ........................................................................................................... 45

Downloading a BIOS update .............................................................................................................. 46

Synchronizing a tablet and keyboard (select products only) ............................................................................. 47

ENWW ix

10 Using HP PC Hardware Diagnostics (UEFI) ..................................................................................................... 48

Downloading HP PC Hardware Diagnostics (UEFI) to a USB device .................................................................... 48

11 Backing up, restoring, and recovering ......................................................................................................... 50

Creating recovery media and backups ................................................................................................................ 50

Creating HP Recovery media (select products only) ........................................................................ 50

Using Windows tools ........................................................................................................................................... 51

Restore and recovery .......................................................................................................................................... 52

Recovering using HP Recovery Manager .......................................................................................... 52

What you need to know before you get started ............................................................ 52

Using the HP Recovery partition (select products only) ................................................ 53

Using HP Recovery media to recover ............................................................................. 53

Changing the computer boot order ................................................................................ 54

Removing the HP Recovery partition (select products only) ......................................... 54

12 Specifications ........................................................................................................................................... 55

Input power .......................................................................................................................................................... 55

Operating environment ....................................................................................................................................... 56

13 Electrostatic Discharge .............................................................................................................................. 57

14 Accessibility .............................................................................................................................................. 58

Supported assistive technologies ....................................................................................................................... 58

Contacting support .............................................................................................................................................. 58

Index ............................................................................................................................................................. 59

x ENWW

1 Starting right

This computer is a powerful tool designed to enhance your work and entertainment. Read this chapter to learn about best practices after you set up your computer, fun things to do with your computer, and where to find additional HP resources.

Visit the HP Apps Store

The HP Apps Store offers a wide choice of popular games, entertainment and music apps, productivity apps, and apps exclusive to HP that you can download to the desktop. The selection is updated regularly and includes regional content and country-specific offers. Be sure to check the HP Apps Store frequently for new and updated features.

IMPORTANT: You must be connected to the Internet to access the HP Apps Store.

To view and download an app:

1. Select the Start button, and then select the Store app.

‒ or –

Select the Store icon next to the taskbar search box.

2. Select HP picks to view all the available apps.

NOTE: HP picks is available in select countries only.

3. Select the app you want to download, and then follow the on-screen instructions. When the download is

complete, the app appears on the All apps screen.

Best practices

After you set up and register the computer, we recommend the following steps to get the most out of your smart investment:

●

Back up your hard drive by creating recovery media. See

on page 50.

●

If you haven’t already done so, connect to a wired or wireless network. See details in

network on page 17.

●

Become familiar with the computer hardware and software. For more information, see

your computer on page 4 and Enjoying entertainment features on page 21.

●

Update or purchase antivirus software. See

Backing up, restoring, and recovering

Connecting to a

Getting to know

Using antivirus software on page 42.

ENWW Visit the HP Apps Store 1

More HP resources

To locate resources that provide product details, how-to information, and more, use this table.

Resource Contents

Setup Instructions

Get started app

To access the Get started app:

▲

Select the Start button, and then select the Get started app.

HP support

For U.S. support, go to For worldwide support, go to

country/us/en/wwcontact_us.html.

Safety & Comfort Guide

To access this guide:

1. Type support in the taskbar search box, and then

select the HP Support Assistant app.

‒ or –

Click the question mark icon in the taskbar.

2. Select My PC, select the Specifications tab, and then

select User Guides.

‒ or –

Go to

http://www.hp.com/ergo.

http://www.hp.com/go/contactHP.

http://welcome.hp.com/

●

Overview of computer setup and features

●

A broad range of how-to information and troubleshooting tips

●

Online chat with an HP technician

●

Support telephone numbers

●

HP service center locations

●

Proper workstation setup

●

Guidelines for posture and work habits that increase your comfort and decrease your risk of injury

●

Electrical and mechanical safety information

Regulatory, Safety and Environmental Notices

To access this document:

1. Type support in the taskbar search box, and then

select the HP Support Assistant app.

‒ or –

Click the question mark icon in the taskbar.

2. Select My PC, select the Specifications tab, and then

select User Guides.

Limited Warranty*

To access this document:

1. Type support in the taskbar search box, and then

select the HP Support Assistant app.

‒ or –

Click the question mark icon in the taskbar.

2. Select My PC, and then select Warranty and

services.

‒ or –

●

Important regulatory notices, including information about proper battery disposal, if needed.

●

Specific warranty information about this computer

2 Chapter 1 Starting right ENWW

Resource Contents

Go to

http://www.hp.com/go/orderdocuments.

*You can find your HP Limited Warranty located with the user guides on your product and/or on the CD or DVD provided in the box. In some countries or regions, HP may provide a printed warranty in the box. For countries or regions where the warranty is not provided in printed format, you can request a copy from can write to HP at Hewlett Packard, POD, P.O. Box 200, Alexandra Post Office, Singapore 911507. Include your product name, and your name, phone number, and postal address.

http://www.hp.com/go/orderdocuments. For products purchased in Asia Pacific, you

ENWW More HP resources 3

2 Getting to know your computer

Locating hardware

To find out what hardware is installed on your computer:

▲

Type device manager in the taskbar search box, and then select the Device Manager app.

A list displays all the devices installed on your computer.

For information about system hardware components and the system BIOS version number, press fn+esc (select products only).

Locating software

To find out what software is installed on your computer:

▲

Select the Start button, and then select All apps.

‒ or –

Right-click the Start button, and then select Programs and Features.

4 Chapter 2 Getting to know your computer ENWW

Right side

Component Description

(1)

(2) Volume button Decreases or increases speaker volume incrementally while you

(3)

(4)

(5)

(6)

Windows button (select products only) Opens the Start menu.

NOTE: Pressing the Windows button again will close the Start

menu.

hold down the button.

Mini DisplayPort Connects an optional digital display device, such as a high-

HDMI port Connects an optional video or audio device, such as a high-

USB 3.0 charging (powered) ports (2) Connect optional USB devices, such as a keyboard, mouse,

Audio-out (headphone)/Audio-in (microphone) combo jack

performance monitor or projector.

definition television, any compatible digital or audio component, or a high-speed High-Definition Multimedia Interface (HDMI) device.

external drive, printer, scanner or USB hub. Standard USB ports will not charge all USB devices or will charge using a low current. Some USB devices require power and require you to use a powered port.

NOTE: USB charging ports can also charge select models of

cell phones and MP3 players, even when the computer is off.

Connects optional powered stereo speakers, headphones, earbuds, a headset, or a television audio cable. Also connects an optional headset microphone. This jack does not support optional microphone-only devices.

WARNING! To reduce the risk of personal injury, adjust the

volume before putting on headphones, earbuds, or a headset. For additional safety information, refer to the Regulatory, Safety, and Environmental Notices.

To access this document:

1. Type support in the taskbar search box, and then select

the HP Support Assistant app.

‒ or –

Click the question mark icon in the taskbar.

2. Select My PC, select the Specifications tab, and then

select User Guides.

NOTE: When a device is connected to the jack, the computer

speakers are disabled.

ENWW Right side 5

Left side

Component Description

(1)

(2) AC adapter/battery light

(3) Vent Enables airflow to cool internal components.

(4)

(5) Power button

Power connector Connects an AC adapter.

●

White: The AC adapter is connected and the battery is fully charged.

●

Amber: The AC adapter is connected and the battery is charging.

●

Off: The battery is not charging.

NOTE: The computer fan starts up automatically to cool

internal components and prevent overheating. It is normal for the internal fan to cycle on and off during routine operation.

USB 3.0 charging (powered) port Connects an optional USB device, such as a keyboard, mouse,

NOTE: USB charging ports can also charge select models of

cell phones and MP3 players, even when the computer is off.

●

When the computer is off, press the button to turn on the computer.

●

When the computer is on, press the button briefly to initiate Sleep.

●

When the computer is in the Sleep state, press the button briefly to exit Sleep.

●

When the computer is in Hibernation, press the button briefly to exit Hibernation.

CAUTION: Pressing and holding down the power button

results in the loss of unsaved information.

If the computer has stopped responding and shutdown procedures are ineffective, press and hold the power button down for at least 5 seconds to turn off the computer.

To learn more about your power settings, see your power options.

▲

Type power in the taskbar search box, and then select Power and sleep settings.

‒ or –

6 Chapter 2 Getting to know your computer ENWW

Component Description

Right-click the Start button, and then select Power Options.

(6)

(7) Memory card reader Reads optional memory cards that enable you to store, manage,

Power light

●

On: The computer is on.

●

Off: The computer is off or in Hibernation. Hibernation is a power-saving state that uses the least amount of power.

share, or access information.

To insert a card:

1. Hold the card label-side up, with connectors facing the

computer.

2. Insert the card into the memory card reader, and then

press in on the card until it is firmly seated.

To remove a card:

▲

Press in on the card, and then remove it from the memory card reader.

ENWW Left side 7

Display

Component Description

(1) WLAN antennas* Send and receive wireless signals to communicate with wireless local

(2) Internal microphones Record sound.

(3) Webcam light On: The webcam is in use.

(4) Webcam

‒ or –

3D camera (select products only)

(5) Internal display switch Turns off the display and initiates Sleep if the display is closed while

*The antennas are not visible from the outside of the computer. For optimal transmission, keep the areas immediately around the antennas free from obstructions.

For wireless regulatory notices, see the section of the Regulatory, Safety, and Environmental Notices that applies to your country or region.

area networks (WLANs).

Records video and captures photographs. Some products allow you to video conference and chat online using streaming video.

To use the webcam or 3D camera:

▲

Type camera in the taskbar search box, and then select

Camera.

NOTE: A 3D camera captures 3D images and displays them on the

computer screen. It includes additional hardware (a 3D camera sensor and a 3D laser projector) plus special software. To learn more about using a 3D camera, open the Intel RealSense app Welcome to

Intel RealSense. To access the 3D camera apps, go to the Intel RealSense Technology app.

the power is on.

NOTE: The internal display switch is not visible from the outside of

the computer.

To access this document:

1. Type support in the taskbar search box, and then select the HP Support Assistant app.

8 Chapter 2 Getting to know your computer ENWW

Component Description

‒ or –

Click the question mark icon in the taskbar.

2. Select My PC, select the Specifications tab, and then select User Guides.

Changing your notebook position

Your computer can function as a classic notebook, and in addition, the display can be rotated so that the computer transforms into an entertainment stand, an interactive stand, or a tablet.

NOTE: The TouchPad and keyboard functions are locked during the entertainment and tablet modes.

ENWW Display 9

Changing your notebook to an entertainment stand

To change your notebook to an entertainment stand, raise the display, and then rotate the display backward to a stand position (about 315 degrees).

10 Chapter 2 Getting to know your computer ENWW

Changing your notebook to an interactive stand

To change your notebook to an interactive stand, raise the display, and then rotate the display backward to a stand position (about 315 degrees). Position the notebook on its edges.

Changing your notebook to a tablet

To change your notebook to a tablet, raise the display, and then rotate the display backward until it is flush with the computer bottom (360 degrees).

ENWW Display 11

Top

TouchPad

Component Description

(1) TouchPad zone Reads your finger gestures to move the pointer or activate

items on the screen.

NOTE: For more information, see

touch screen gestures on page 26.

Using the TouchPad and

(2) Left TouchPad button Functions like the left button on an external mouse.

(3) Right TouchPad button Functions like the right button on an external mouse.

12 Chapter 2 Getting to know your computer ENWW

+ 49 hidden pages
