HP NOTEBOOK 6710B Specification Sheet

HP Compaq 6710b Notebook PC

TAILORED FOR BUSINESS
Extensive connectivity, 15.4” widescreen, Intel processors

HP recommends Windows Vista™ Business

Focused on your business

The HP Compaq 6710b Notebook PC offers cost­effective business computing without compromising
on connectivity or productivity. This thin and light
notebook works just as hard as you do and
includes the latest Intel
range of mobile features, and compatibility with HP
Universal Accessories.

Broaden your perspective

Select the right 15.4-inch diagonal widescreen
display that best suits your needs – either a
WSXGA+ WVA (wide-viewing angle) anti-glare
display or a WXGA with your choice of an anti­glare display or HP BrightView display.

Technology in tune with your needs

Experience new levels of system responsiveness
when running multiple applications and smarter
battery performance designed to help extend
mobility with Intel
Quickly store data and synchronize with different
types of devices with the integrated Media Card
Reader; while the optional DVD+/–RW SuperMulti
DL LightScribe
directly to your disc.

3

Drive lets you burn custom labels

®

Core™2 Duo Processors, a

®

Core™2 Duo Processor.2

Enjoy wireless in more places

Whether you’re across the street or across the
country, HP Broadband Wireless Plus
built-in WWAN + 802.11n (draft) WLAN +
Bluetooth
stay connected in more places.

HP Professional Innovations help you focus on your
business

Built to protect. Multi-layered, customizable security
solutions help defend your network, your
applications, and your data. The new Drive
Encryption for HP ProtectTools encodes all
information on the hard drive volume so it becomes
unreadable to an unauthorized person.

Built to simplify. Boost your productivity while
maximizing simplicity with features such as HP
QuickLook. Now you can quickly browse your
email, calendars, and contact information with a
touch of a button whether your PC is turned on or
not.

Built to last. Reliable features such as HP DuraFinish
and HP 3D DriveGuard so your notebook can go
the distance.

®

technologies) allows you to conveniently

4,5,6

(includes

g

HP Compaq 6710b Notebook PC

HP recommends Windows Vista™ Business

Operating System Preinstalled:

Genuine Windows Vista Business 32/64
Genuine Windows Vista Home Basic

1

1

Genuine Windows XP Professional
FreeDOS

Processor2 Intel® CoreTM2 Duo (up to 2.4-GHz, up to 4-MB L2 cache)

Chipset Mobile Intel® GM965

Memory DDR2 SDRAM, 667-MHz, two SODIMM slots supporting dual channel memory, 512/1024/2048/4096-MB

Hard drive(s)7 SATA 80/120/160-GB 5400 rpm, 80-GB 7200 rpm, HP 3D DriveGuard

Removable media3 12.7-mm optical drives: DVD+/–RW SuperMulti DL LightScribe, DVD+/–RW SuperMulti DL, DVD/CD-RW Combo, DVD-ROM

Display 15.4-inch diagonal WSXGA+ WVA (1680 x 1050 and 16M colors), 15.4-inch diagonal WXGA (1280 x 800 and 16M

colors), 15.4-inch diagonal WXGA BrightView (1280 x 800 and 16M colors)

Graphics8 Intel GMA X3100, up to 384-MB shared system memory

Audio High Definition Audio, stereo speakers, stereo headphone/line out, stereo microphone in, integrated mono microphone

Wireless support

4,5,6

Optional HP ev2200 1xEV-DO Broadband Wireless Module (requires Verizon Wireless Service), optional HP hs2300 HSDPA

Broadband Wireless Module (requires mobile network operator service); Intel PRO/Wireless 802.11a/b/g/draft-n, a/b/g, b/g,
Broadcom 802.11a/b/g/draft-n, a/b/g, b/g, Bluetooth™ 2.0, HP Wireless Assistant

Communications Broadcom NetLink Gigabit Ethernet PCI Controller9 (10/100/1000 NIC), 56K v.92 modem

Expansion slots 1 Type I/II PC Card slot supports 32-bit CardBus and 16-bit cards, Media Card Reader

Ports and connectors 4 USB 2.0 ports, VGA, stereo microphone in, stereo headphone/line out, 1394a, power connector, RJ-11/modem, RJ-

45/ethernet, S-video TV out, docking connector, secondary battery connector

Input device Full-sized keyboard, Touchpad with scroll zone, HP Fingerprint Sensor

Software HP Backup and Recovery Manager, Roxio Creator 9, Microsoft Office 2007 Small Business or Professional (optional)

Security HP ProtectTools, TPM Embedded Security Chip 1.2,12 HP Fingerprint Sensor, Symantec Norton Internet Security, optional Smart

Card Reader,10 Kensington lock, HP Privacy Filter (optional)

Dimensions (h × w × d) 1.37 in (at front) x 14.05 in x 10.43 in / 34.8 mm (at front) x 356.9 mm x 264.9 mm

Weight starting at weight: 5.93 lbs / 2.69 kg (weight will vary by configuration)

Power 6-cell (55 WHr) Lithium-Ion battery, 6-cell (47 WHr) Lithium-Ion battery, optional HP (52 WHr) Extended Life Battery,10 optional

HP (95 WHr) Ultra-Capacity Battery,

10

90W HP Smart AC Adapter, HP Fast Charge11

Expansion solutions10 HP 3-in-1 NAS Docking Station, HP Advanced Docking Station, HP Docking Station, HP Monitor Stand, HP Adjustable Notebook

Stand, HP External MultiBay II

Warranty Limited 3-year, 1-year and 90-day warranty options available, depending on country, 1-year limited warranty on primary battery

1. Certain Windows Vista product features require advanced or additional hardware. See http://www.microsoft.com/windowsvista/getready/hardwarereqs.mspx and

http://www.microsoft.com/windowsvista/getready/capable.mspx for details. Windows Vista Upgrade Advisor can help you determine which features of Windows Vista will run on your computer. To download the

tool, visit www.windowsvista.com/upgradeadvisor. 2. Dual Core is a new technolo
from use of this technology. 64-bit computing on Intel architecture requires a computer system with a processor, chipset, BIOS, operating system, device drivers and applications enabled for Intel® 64 architecture.
Processors will not operate (including 32-bit operation) without an Intel 64 architecture-enabled BIOS. Performance will vary depending on your hardware and software configurations. See www.intel.com/info/em64t
for more information. 3. Do not copy copy-right protected materials. Intended for creation and storage of your original material and other lawful uses. Double Layer discs can store more data than single layer discs.
Double-layer discs burned with this drive may not be compatible with many existing single-layer DVD drives and players. LightScribe creates a monochrome image. LightScribe media required and sold separately.
Note that DVD-RAM cannot read or write to 2.6GB Single Sided/5.2 GB Double Sided – Version 1.0 media. 4. Wireless use requires separately purchased service contract. Check with service provider for
availability and coverage in your area. Available in select countries only. 5. The specifications for the 802.11n WLAN are draft specifications and are not final. If the final specifications differ from the draft
specifications, it may affect the ability of the notebook to communicate with other 802.11n WLAN devices. 6. Wireless access point required and is not included. Availability of public wireless access points limited.
Wireless Internet use requires separately purchased Internet service contract. 7. For hard drives, GB = 1 billion bytes. Actual formatted capacity is less. Up to 8GB (for XP) and 10GB (for Vista) of system disk is
reserved for the system recovery software. 8. Shared video memory (UMA) uses part of the total system memory for video performance. System memory dedicated to video performance is not available for other use
by programs. 9. The term "10/100/1000" or "Gigabit" Ethernet indicates compliance with IEEE standard 802.3ab for Gigabit Ethernet, and does not connote actual operating speed of 1 Gb/sec. For high speed
transmission, connection to a Gigabit Ethernet server and network infrastructure is required. 10. Sold separately or purchased as an optional feature. 11. HP Fast Charge recharges your primary battery up to 90%
within 90 minutes when the system is off. HP Fast Charge does not apply to 9 cell primary and 12 cell Ultra Capacity batteries.

© 2007 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without
notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying
such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be
liable for technical or editorial errors or omissions contained herein. Bluetooth is a trademark of its proprietor and used by
Hewlett-Packard Company under license. Microsoft and Windows are U.S. registered trademarks of Microsoft
Corporation. Windows Vista is either a registered trademark or trademark of Microsoft Corporation in the United States
and/or other countries. Intel Core and Intel Celeron are trademarks or registered trademarks of Intel Corporation or its
subsidiaries in the U.S. and other countries.

y designed to improve performance of certain software products. Not all customers or software applications will necessarily benefit

Supported:
Genuine Windows Vista Enterprise

Certified:

SuSe Linux Enterprise Desktop 10

12 TPM module disabled where not permitted by law (for example, Russia).

To learn more, visit www.hp.com

January 2007
