Hp MFP E57540 User Manual

HP Color LaserJet Managed MFP E57540
User Guide
Copyright and License
Trademark Credits
© Copyright 2018 HP Development Company, L.P.
Reproduction, adaptation, or translation without prior written permission is prohibited, except as allowed under the copyright laws.
The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
Edition 1, 5/2018
Adobe®, Adobe Photoshop®, Acrobat®, and PostScript
®
are trademarks of Adobe Systems
Incorporated.
Apple and the Apple logo are trademarks of Apple Inc., registered in the U.S. and other countries.
macOS is a trademark of Apple Inc., registered in the U.S. and other countries.
AirPrint is a trademark of Apple Inc., registered in the U.S. and other countries.
Google™ is a trademark of Google Inc.
Microsoft®, Windows®, Windows® XP, and Windows Vista® are U.S. registered trademarks of Microsoft Corporation.
UNIX® is a registered trademark of The Open Group.
Table of contents
1 Printer overview ........................................................................................................................................................................................ 1
For more information: .............................................................................................................................................................. 1
Warning icons ............................................................................................................................................................................ 2
Printer views .............................................................................................................................................................................. 3
Printer front view ................................................................................................................................................. 3
Printer back view .................................................................................................................................................. 4
Interface ports ...................................................................................................................................................... 5
Control-panel view ............................................................................................................................................... 6
How to use the touchscreen control panel ................................................................................. 8
Printer specications ................................................................................................................................................................ 9
Technical specications ....................................................................................................................................... 9
Supported operating systems ......................................................................................................................... 11
Printer dimensions ............................................................................................................................................ 12
Power consumption, electrical specications, and acoustic emissions .................................................... 14
Operating-environment range ........................................................................................................................ 15
Printer hardware setup and software installation ............................................................................................................ 16
2 Paper trays .............................................................................................................................................................................................. 17
For more information: ........................................................................................................................................................... 17
Load paper to Tray 1 (multipurpose tray) .......................................................................................................................... 18
Introduction ........................................................................................................................................................ 18
Tray 1 paper orientation ................................................................................................................................... 20
Use alternative letterhead mode .................................................................................................................... 21
Enable Alternative Letterhead Mode by using the printer control-panel menus ............... 21
Load paper to Trays 2, 3, 4, and 5 ....................................................................................................................................... 22
Introduction ........................................................................................................................................................ 22
Tray 2 and the 550-sheet trays paper orientation ...................................................................................... 24
Use alternative letterhead mode .................................................................................................................... 25
Enable Alternative Letterhead Mode by using the printer control-panel menus ............... 25
Load and print envelopes ..................................................................................................................................................... 26
Introduction ........................................................................................................................................................ 26
Print envelopes .................................................................................................................................................. 26
ENWW iii
Envelope orientation ......................................................................................................................................... 26
Load and print labels ............................................................................................................................................................. 27
Introduction ........................................................................................................................................................ 27
Manually feed labels ......................................................................................................................................... 27
Use the convenience stapler (c model) ............................................................................................................................... 29
3 Supplies, accessories, and parts .......................................................................................................................................................... 31
For more information: ........................................................................................................................................................... 31
Order supplies, accessories, and parts ............................................................................................................................... 32
Ordering .............................................................................................................................................................. 32
Supplies and accessories ................................................................................................................................. 32
Customer self-repair parts ............................................................................................................................... 33
Replace the toner cartridges ................................................................................................................................................ 35
Introduction ........................................................................................................................................................ 35
Toner-cartridge information ............................................................................................................................ 35
Remove and replace the cartridges ................................................................................................................ 36
Replace the toner-collection unit ........................................................................................................................................ 39
Introduction ........................................................................................................................................................ 39
Remove and replace the toner-collection unit .............................................................................................. 39
Replace the staple cartridge (c models) ............................................................................................................................. 42
Introduction ........................................................................................................................................................ 42
Remove and replace the staple cartridge ...................................................................................................... 42
4 Print .......................................................................................................................................................................................................... 45
For more information: ........................................................................................................................................................... 45
Print tasks (Windows) ............................................................................................................................................................ 46
How to print (Windows) .................................................................................................................................... 46
Automatically print on both sides (Windows) ............................................................................................... 46
Manually print on both sides (Windows) ........................................................................................................ 47
Print multiple pages per sheet (Windows) .................................................................................................... 47
Select the paper type (Windows) .................................................................................................................... 48
Additional print tasks ........................................................................................................................................ 49
Print tasks (macOS) ............................................................................................................................................................... 50
How to print (macOS) ........................................................................................................................................ 50
Automatically print on both sides (macOS) ................................................................................................... 50
Manually print on both sides (macOS) ........................................................................................................... 50
Print multiple pages per sheet (macOS) ........................................................................................................ 51
Select the paper type (macOS) ........................................................................................................................ 51
Additional print tasks ........................................................................................................................................ 51
Store print jobs on the printer to print later or print privately ........................................................................................ 52
Introduction ........................................................................................................................................................ 52
iv ENWW
Create a stored job (Windows) ......................................................................................................................... 52
Create a stored job (macOS) ............................................................................................................................ 53
Print a stored job ............................................................................................................................................... 54
Delete a stored job ............................................................................................................................................ 54
Delete a job that is stored on the printer .................................................................................. 54
Change the job storage limit ....................................................................................................... 54
Information sent to printer for Job Accounting purposes ........................................................................... 55
Print from the USB port ........................................................................................................................................................ 56
Introduction ........................................................................................................................................................ 56
Enable the USB port for printing ..................................................................................................................... 56
Print from a USB ash drive ............................................................................................................................. 57
5 Copy .......................................................................................................................................................................................................... 59
For more information: ........................................................................................................................................................... 59
Make a copy ............................................................................................................................................................................. 60
Copy on both sides (duplex) ................................................................................................................................................. 62
Additional options when copying ........................................................................................................................................ 64
Additional copy tasks ............................................................................................................................................................. 66
6 Scan .......................................................................................................................................................................................................... 67
For more information: ........................................................................................................................................................... 67
Set up Scan to Email .............................................................................................................................................................. 68
Introduction ........................................................................................................................................................ 68
Before you begin ................................................................................................................................................ 68
Step one: Access the HP Embedded Web Server (EWS) .............................................................................. 68
Step two: Congure the Network Identication settings ............................................................................ 69
Step three: Congure the Send to Email feature .......................................................................................... 70
Method one: Basic conguration using the Email Setup Wizard ........................................... 70
Method two: Advanced conguration using the Email Setup ................................................ 74
Step four: Congure the Quick Sets (optional) .............................................................................................. 78
Step ve: Set up Send to Email to use Oice 365 Outlook (optional) ....................................................... 79
Introduction ................................................................................................................................... 79
Congure the outgoing email server (SMTP) to send an email from an Oice 365
Outlook account ............................................................................................................................ 79
Set up Scan to Network Folder ............................................................................................................................................ 81
Introduction ........................................................................................................................................................ 81
Before you begin ................................................................................................................................................ 81
Step one: Access the HP Embedded Web Server ......................................................................................... 81
Step two: Set up Scan to Network Folder ...................................................................................................... 82
Method one: Use the Scan to Network Folder Wizard ............................................................ 82
Method two: Use Scan to Network Folder Setup ..................................................................... 83
ENWW v
Step one: Begin the conguration ......................................................................... 83
Step two: Congure the Scan to Network Folder settings ................................. 84
Step three: Complete the conguration ............................................................... 91
Set up Scan to USB Drive ...................................................................................................................................................... 92
Introduction ........................................................................................................................................................ 92
Step one: Access the HP Embedded Web Server ......................................................................................... 92
Step two: Enable Scan to USB Drive ............................................................................................................... 93
Step three: Congure the Quick Sets (optional) ............................................................................................ 93
Default scan settings for Scan to USB Drive setup ...................................................................................... 94
Default le settings for Save to USB Setup ................................................................................................... 94
Set up Save to SharePoint® (Flow models only) ............................................................................................................... 96
Introduction ........................................................................................................................................................ 96
Before you begin ................................................................................................................................................ 96
Step one: Access the HP Embedded Web Server (EWS) .............................................................................. 96
Step two: Enable Save to SharePoint® and create a Save to SharePoint Quick Set ................................ 97
Scan and save a le directly to a Microsoft® SharePoint site ..................................................................... 99
Quick set scan settings and options for Save to SharePoint® ................................................................. 100
Create a Quick Set ................................................................................................................................................................ 102
Introduction ...................................................................................................................................................... 102
Step one: Access the HP Embedded Web Server (EWS) ........................................................................... 102
Step two: Add and manage Quick Sets ........................................................................................................ 103
Add a Quick Set ........................................................................................................................... 103
Edit a Quick Set ........................................................................................................................... 104
Copy a Quick Set ......................................................................................................................... 104
Remove a Quick Set ................................................................................................................... 105
Quick Set settings and options ................................................................................................. 105
Send a scanned document to one or more email addresses ....................................................................................... 111
Introduction ...................................................................................................................................................... 111
Scan and send a document to email ............................................................................................................ 111
Scan and send to network folder ...................................................................................................................................... 113
Introduction ...................................................................................................................................................... 113
Scan and save the document to a folder ..................................................................................................... 113
Scan and save to a USB ash drive ................................................................................................................................... 115
Introduction ...................................................................................................................................................... 115
Scan and save the document to a USB ash drive .................................................................................... 115
Additional options when scanning .................................................................................................................................... 117
HP JetAdvantage business solutions ................................................................................................................................ 119
Additional scan tasks .......................................................................................................................................................... 120
7 Fax .......................................................................................................................................................................................................... 121
For more information: ......................................................................................................................................................... 121
vi ENWW
Set up fax .............................................................................................................................................................................. 122
Introduction ...................................................................................................................................................... 122
Set up fax by using the printer control panel ............................................................................................. 122
Change fax congurations ................................................................................................................................................. 123
Fax dialing settings ......................................................................................................................................... 123
General fax send settings .............................................................................................................................. 124
Fax receive settings ........................................................................................................................................ 124
Send a fax ............................................................................................................................................................................. 126
Additional fax tasks ............................................................................................................................................................. 128
8 Manage the printer .............................................................................................................................................................................. 129
For more information: ......................................................................................................................................................... 129
Advanced conguration with the HP Embedded Web Server (EWS) ........................................................................... 130
Introduction ...................................................................................................................................................... 130
How to access the HP Embedded Web Server (EWS) ................................................................................ 130
HP Embedded Web Server features ............................................................................................................. 131
Information tab ........................................................................................................................... 131
General tab .................................................................................................................................. 132
Copy/Print tab ............................................................................................................................. 133
Scan/Digital Send tab ................................................................................................................ 134
Fax tab .......................................................................................................................................... 135
Troubleshooting tab ................................................................................................................... 135
Security tab ................................................................................................................................. 136
HP Web Services tab .................................................................................................................. 136
Networking tab ........................................................................................................................... 136
Other Links list ............................................................................................................................ 138
Congure IP network settings ........................................................................................................................................... 139
Printer sharing disclaimer .............................................................................................................................. 139
View or change network settings ................................................................................................................. 139
Rename the printer on a network ................................................................................................................ 139
Manually congure IPv4 TCP/IP parameters from the control panel ..................................................... 140
Manually congure IPv6 TCP/IP parameters from the control panel ..................................................... 140
Link speed and duplex settings .................................................................................................................... 141
Printer security features ..................................................................................................................................................... 142
Introduction ...................................................................................................................................................... 142
Security statements ....................................................................................................................................... 142
IP Security ......................................................................................................................................................... 142
Assign or change the system password using the HP Embedded Web Server .................................... 142
Encryption support: HP High Performance Secure Hard Disks ................................................................ 143
Lock the formatter .......................................................................................................................................... 143
Energy-conservation settings ........................................................................................................................................... 144
ENWW vii
Introduction ...................................................................................................................................................... 144
Set the Sleep/Auto O After Inactivity setting ............................................................................................ 144
Set the sleep timer and congure the printer to use 1 watt or less of power ...................................... 144
Set the sleep schedule ................................................................................................................................... 145
Set the Delay Shut Down setting .................................................................................................................. 145
HP Web Jetadmin ................................................................................................................................................................. 146
Software and rmware updates ........................................................................................................................................ 147
9 Solve problems ..................................................................................................................................................................................... 149
For more information: ......................................................................................................................................................... 149
Customer support ................................................................................................................................................................ 150
Control panel help system ................................................................................................................................................. 151
Restore factory settings ..................................................................................................................................................... 152
Introduction ...................................................................................................................................................... 152
Method one: Restore factory settings from the printer control panel ................................................... 152
Method two: Restore factory settings from the HP Embedded Web Server (network-connected
printers only) .................................................................................................................................................... 152
A “Cartridge is low” or “Cartridge is very low” message displays on the printer control panel ............................... 153
Printer does not pick up paper or misfeeds .................................................................................................................... 154
Introduction ...................................................................................................................................................... 154
The printer does not pick up paper .............................................................................................................. 154
The printer picks up multiple sheets of paper ............................................................................................ 156
The document feeder jams, skews, or picks up multiple sheets of paper ............................................ 160
Clear paper jams .................................................................................................................................................................. 161
Introduction ...................................................................................................................................................... 161
Jam locations ................................................................................................................................................... 161
Auto-navigation for clearing paper jams ..................................................................................................... 163
Experiencing frequent or recurring paper jams? ....................................................................................... 163
Clear paper jams in the document feeder ................................................................................................... 164
13.A1 tray 1 paper jam .................................................................................................................................. 167
13.A2 tray 2 paper jam .................................................................................................................................. 169
13.A3, 13.A4, 13.A5 tray 3, tray 4, tray 5 paper jam ................................................................................. 173
13.B right door and fuser area paper jam ................................................................................................... 178
13.E1 output bin paper jam ........................................................................................................................... 183
13.8 staple jams .............................................................................................................................................. 183
Improve print quality ........................................................................................................................................................... 186
Introduction ...................................................................................................................................................... 186
Print from a dierent software program .................................................................................................... 186
Check the paper-type setting for the print job ........................................................................................... 186
Check the paper type setting on the printer .......................................................................... 186
Check the paper type setting (Windows) ................................................................................ 186
viii ENWW
Check the paper type setting (macOS) ................................................................................... 187
Check toner-cartridge status ........................................................................................................................ 187
Print a cleaning page ...................................................................................................................................... 187
Visually inspect the toner cartridge or cartridges ...................................................................................... 188
Check paper and the printing environment ................................................................................................ 188
Step one: Use paper that meets HP specications ............................................................... 188
Step two: Check the environment ............................................................................................ 188
Step three: Set the individual tray alignment ........................................................................ 189
Try a dierent print driver .............................................................................................................................. 189
Improve copy image quality ............................................................................................................................................... 191
Check the scanner glass for dirt and smudges .......................................................................................... 191
Calibrate the scanner ...................................................................................................................................... 192
Check the paper settings ............................................................................................................................... 193
Check the paper selection options ........................................................................................... 193
Check the image-adjustment settings ........................................................................................................ 193
Optimize copy quality for text or pictures ................................................................................................... 194
Edge-to-edge copying .................................................................................................................................... 194
Improve scan image quality ............................................................................................................................................... 195
Check the scanner glass for dirt and smudges .......................................................................................... 195
Check the resolution settings ....................................................................................................................... 196
Check the color settings ................................................................................................................................. 197
Check the image-adjustment settings ........................................................................................................ 197
Optimize scan quality for text or pictures ................................................................................................... 198
Check the output-quality settings ................................................................................................................ 198
Improve fax image quality .................................................................................................................................................. 200
Check the scanner glass for dirt and smudges .......................................................................................... 200
Check the send-fax resolution settings ....................................................................................................... 201
Check the image-adjustment settings ........................................................................................................ 202
Optimize fax quality for text or pictures ...................................................................................................... 202
Check the error-correction settings ............................................................................................................. 202
Check the t-to-page setting ........................................................................................................................ 203
Send to a dierent fax machine .................................................................................................................... 203
Check the sender's fax machine ................................................................................................................... 203
Solve fax problems .............................................................................................................................................................. 204
Checklist for solving fax problems ............................................................................................................... 204
What type of phone line are you using? ................................................................................. 204
Are you using a surge-protection device? .............................................................................. 204
Are you using a phone company voice-messaging service or an answering machine? . 204
Does your phone line have a call-waiting feature? ............................................................... 205
Check fax accessory status ....................................................................................................... 205
General fax problems ..................................................................................................................................... 206
ENWW ix
The fax failed to send ................................................................................................................ 206
An Out of Memory status message displays on the printer control panel ........................ 206
Print quality of a photo is poor or prints as a gray box ........................................................ 206
You touched the Stop button to cancel a fax, but the fax was still sent ............................ 206
No fax address book button displays ...................................................................................... 206
Not able to locate the Fax settings in HP Web Jetadmin ...................................................... 206
The header is appended to the top of the page when the overlay option is enabled ..... 206
A mix of names and numbers is in the recipients box .......................................................... 206
A one-page fax prints as two pages ........................................................................................ 206
A document stops in the document feeder in the middle of faxing ................................... 207
The volume for sounds coming from the fax accessory is too high or too low ............... 207
Index ........................................................................................................................................................................................................... 209
x ENWW

1 Printer overview

For more information:

Warning icons
Printer views
Printer specications
Printer hardware setup and software installation
The following information is correct at the time of publication.
For video assistance, see www.hp.com/videos/LaserJet.
For current information, see www.hp.com/support/colorljE57540mfp.
HP's all-inclusive help for the printer includes the following information:
Install and congure
Learn and use
Solve problems
Download software and rmware updates
Join support forums
Find warranty and regulatory information
ENWW For more information: 1

Warning icons

Warning icon denitions: The following warning icons may appear on HP products. Apply appropriate caution where applicable.
Caution: Electric shock
Caution: Hot surface
Caution: Keep body parts away from moving parts
Caution: Sharp edge in close proximity
2 Chapter 1 Printer overview ENWW

Printer views

1 2
3
4
5
6
7
10
11
12
13
14
15
89

Printer front view

Printer back view
Interface ports
Control-panel view
Printer front view
1 Document-feeder cover (access for clearing jams)
2 Document-feeder input tray
3 Document-feeder output bin
NOTE: When feeding long paper through the document feeder, extend the paper stop at the right side of the output bin.
4 Control panel with color touchscreen display (tilts up for easier viewing)
5 Convenience stapler (c model only)
6 Right door (access to the fuser and for clearing jams)
7 Tray 1
8 On/o button
9 Model name
10 Tray 2
11 Front door (access to the toner cartridges)
12 Standard output bin
13 Physical keyboard (c model only). Pull the keyboard straight out to use it.
ENWW Printer views 3
14 Easy-access USB port (on the side of the control panel)
1
2
3
6
4
5
15 Hardware integration pocket (for connecting accessory and third-party devices)

Printer back view

Insert a USB ash drive for printing or scanning without a computer or to update the printer rmware.
NOTE: An administrator must enable this port before use.
1 Toner-collection-unit door
2 Formatter (contains the interface ports)
3 Power connection
4 Serial number and product number label
5 Slot for a cable-type security lock (on the rear cover of the printer)
6 Formatter cover
4 Chapter 1 Printer overview ENWW

Interface ports

1
2
3
4
1 Fax port (c models only. The port is covered for the dn model.)
2 Local area network (LAN) Ethernet (RJ-45) network port
3 USB port for connecting external USB devices (this port might be covered)
NOTE: For easy-access USB printing, use the USB port near the control panel.
4 Hi-Speed USB 2.0 printing port
ENWW Printer views 5

Control-panel view

3 421
5 6 7
8
9
10
13
12
14
11
The Home screen provides access to the printer features and indicates the current status of the printer.
Return to the Home screen at any time by selecting the Home button.
NOTE: The features that appear on the Home screen can vary, depending on the printer conguration.
1
Home button
2 Applications area Touch any of the icons to open the application. Swipe the screen sideways to access more applications.
3 Reset button Touch the Reset button to clear changes, release the printer from a paused state, display hidden errors,
4 Sign In or Sign Out button Touch the Sign In button to access secured features.
Touch the Home button to return to the printer Home screen at any time.
NOTE: The available applications vary by printer. The administrator can congure which applications
appear and the order in which they appear.
and restore the default settings (including the language and keyboard layout).
Touch the Sign Out button to sign out of the printer. The printer restores all options to the default settings.
NOTE: This button displays only if the administrator has congured the printer to require permission
for access to features.
6 Chapter 1 Printer overview ENWW
5
Information button
Touch the information button to access a screen that provides access to several types of printer information. Touch the buttons at the bottom of the screen for the following information:
Display Language: Change the language setting from this screen.
Sleep Mode: Place the printer into sleep mode from this screen.
Wi-Fi Direct: View information for how to connect directly to the printer using a phone, tablet, or
other device with Wi-Fi.
Wireless: Use this screen to view and change wireless connection settings (for the z model and for
the dn and f models only when an optional wireless accessory is installed).
Ethernet: Use this screen to view and change Ethernet connection settings.
HP Web Services: Find information to connect and print to the printer using HP Web Services
(ePrint).
Fax Number: View the printer fax number (for f and z models and for the dn model only when the
optional fax accessory is installed).
6
Help button
7 Current time Displays the current time.
8 Start Copy button Touch the Start Copy button to start a copy job.
9 Copies eld The copies eld indicates the number of copies that the printer is set to make.
10 Home-screen page
indicator
11 Keyboard
(c model only)
12 Near-eld
communication icon
(c model only)
13 Easy-access USB port Insert a USB ash drive for printing or scanning without a computer or to update the printer rmware.
14 Hardware integration
pocket
Touch the Help button to open the embedded help system.
The Home screen has multiple pages. This icon indicates the number of pages and which page is currently active. Swipe the screen sideways to scroll between pages.
This printer includes a physical keyboard. The keys are mapped to a language in the same way the virtual keyboard on the printer touchscreen is mapped. Whenever the keyboard layout for the virtual keyboard changes, the keys on the physical keyboard are remapped to match the new settings.
NOTE: In some locations, the printer comes with adhesive keyboard overlays to customize the keys
for dierent languages.
This icon indicates the printer includes integrated HP near-eld communication (NFC) and Wi-Fi Direct
NOTE: An administrator must enable this port before use.
For connecting accessory and third-party devices.
ENWW Printer views 7
How to use the touchscreen control panel
Use the following actions to use the printer touchscreen control panel.
Action Description Example
Touch Touch an item on the screen to select that item
or open that menu. Also, when scrolling through menus, briey touch the screen to stop the scrolling.
Swipe Touch the screen and then move your nger
horizontally to scroll the screen sideways.
Scroll Touch the screen and then move your nger
vertically to scroll the screen up and down. When scrolling through menus, briey touch the screen to stop the scrolling.
Touch the Settings icon to open the Settings app.
Swipe until the Settings app displays.
Scroll through the Settings app.
8 Chapter 1 Printer overview ENWW
Printer specications
IMPORTANT: The following specications are correct at the time of publication, but they are subject to change.
For current information, see www.hp.com/support/colorljE57540mfp.
Technical specications
Supported operating systems
Printer dimensions
Power consumption, electrical specications, and acoustic emissions
Operating-environment range
Technical specications
Model name E57540dn E57540c
Product number 3GY25A 3GY26A
Paper handling Tray 1 (100-sheet capacity)
Tray 2 (550-sheet capacity)
1 x 550-sheet paper feeder
NOTE: The printer accepts up to three 1 x
550-sheet paper feeders.
Printer cabinet Optional Optional
Automatic duplex printing
Connectivity 10/100/1000 Ethernet LAN connection with
IPv4 and IPv6
Hi-Speed USB 2.0
Easy-access USB port for printing without a
computer and upgrading the rmware
Hardware Integration Pocket for connecting
accessory and third-party devices
HP Internal USB Ports Optional Optional
Integrated HP near-eld communication
(NFC) and Wi-Fi Direct functionality for printing from mobile devices
HP Jetdirect 3000w NFC/Wireless Accessory
for printing from mobile devices
HP Jetdirect 2900nw Print Server accessory
for wireless connectivity
Optional Optional
Not supported Not supported
Optional Optional
Optional Optional
Memory 1.75 GB base memory
NOTE: The base memory is expandable to
2.5 GB by adding a DIMM memory module.
Mass storage 320 GB Hard Disk Drive
ENWW Printer specications 9
Model name E57540dn E57540c
Product number 3GY25A 3GY26A
Security HP Trusted Platform Module for encrypting
all data that passes through the printer
Control-panel display and keyboard Color touchscreen control panel
Physical keyboard Not supported
Print Prints 38 pages per minute (ppm) on A4
and 40 ppm on letter-size paper
Easy-access USB printing (no computer
required)
Store jobs in the printer memory to print
later or print privately
Fax Optional
Copy and Scan
NOTE: Copy and scan speeds are subject
to change. For the most current information, go to support.hp.com.
100-page document feeder with dual-head
HP EveryPage Technologies including
Copies 38 pages per minute (ppm) on A4 and 40 ppm on letter-size paper
scanning for single-pass duplex copying and scanning
ultrasonic multi-feed detection
Optional Optional
Not supported
Embedded optical character recognition
(OCR) provides the ability to convert printed pages into text that can be edited or searched using a computer
SMART Label feature provides paper-edge
detection for automatic page cropping
Automatic page orientation for pages that
have at least 100 characters of text
Automatic tone adjustment sets contrast,
brightness, and background removal for each page
Digital Send Send documents to E-mail, USB, and shared
folders on a network
Send documents to SharePoint® Not supported
Not supported
Not supported
Not supported
Not supported
10 Chapter 1 Printer overview ENWW

Supported operating systems

Linux: For information and print drivers for Linux, go to www.hp.com/go/linuxprinting.
UNIX: For information and print drivers for UNIX®, go to www.hp.com/go/unixmodelscripts.
The following information applies to the printer-specic HP PCL 6 print drivers, and HP print drivers for macOS.
Windows: Go to the printer-support website for this printer: www.hp.com/support/colorljE57540mfp to download and install the HP print driver.
macOS: Mac computers are supported with this printer. Download HP Easy Start from 123.hp.com/LaserJet to install the HP print driver.
1. Go to 123.hp.com/LaserJet.
2. Follow the steps provided to download the printer software.
Table 1-1 Supported operating systems and print drivers
Operating system Print driver installed (from the software on
the web)
Windows 7, 32-bit and 64-bit The PCL 6 printer-specic print driver is
available for download from the printer­support website. Download the driver, and then use the Microsoft Add Printer tool to install it.
Windows 8, 32-bit and 64-bit The PCL 6 printer-specic print driver is
available for download from the printer­support website. Download the driver, and then use the Microsoft Add Printer tool to install it.
Windows 8.1, 32-bit and 64-bit The PCL 6 printer-specic print driver is
available for download from the printer­support website. Download the driver, and then use the Microsoft Add Printer tool to install it.
Windows 10, 32-bit and 64-bit The PCL 6 printer-specic print driver is
available for download from the printer­support website. Download the driver, and then use the Microsoft Add Printer tool to install it.
Windows Server 2008 R2, SP 1, 64-bit The PCL 6 printer-specic print driver is
available for download from the printer­support website. Download the driver, and then use the Microsoft Add Printer tool to install it.
Notes
Windows Server 2012, 64-bit The PCL 6 printer-specic print driver is
available for download from the printer­support website. Download the driver, and then use the Microsoft Add Printer tool to install it.
Windows Server 2012 R2, 64-bit The PCL 6 printer-specic print driver is
available for download from the printer­support website. Download the driver, and then use the Microsoft Add Printer tool to install it.
ENWW Printer specications 11
Table 1-1 Supported operating systems and print drivers (continued)
K
C
M
Y
1
1
2
2
3
3
Operating system Print driver installed (from the software on
the web)
Windows Server 2016, 64-bit The PCL 6 printer-specic print driver is
available for download from the printer­support website. Download the driver, and then use the Microsoft Add Printer tool to install it.
macOS 10.11 El Capitan, macOS 10.12 Sierra, macOS 10.13 High Sierra
Download HP Easy Start from 123.hp.com/
LaserJet, and then use it to install the print
driver.
Notes
NOTE: Supported operating systems can change. For a current list of supported operating systems, go to www.hp.com/support/colorljE57540mfp for HP's all-inclusive help for the printer.
NOTE: For details on client and server operating systems and for HP UPD driver support for this printer, go to www.hp.com/go/upd. Under Additional information, click the links.
Table 1-2 Minimum system requirements
Windows macOS
Internet connection
Dedicated USB 1.1 or 2.0 connection or a network connection
Internet connection
Dedicated USB 1.1 or 2.0 connection or a network connection
2 GB of available hard-disk space
1 GB RAM (32-bit) or 2 GB RAM (64-bit)

Printer dimensions

Figure 1-1 Dimensions for the printer
Printer fully closed Printer fully opened
1. Height 583 mm (23 in) 837 mm (33 in)
2. Depth 504 mm (19.8 in) 853 mm (33.6 in)
1.5 GB of available hard-disk space
12 Chapter 1 Printer overview ENWW
Printer fully closed Printer fully opened
3
2
2
1
3
1
1
2
2
3
3
3. Width 482 mm (19 in) 803 mm (31.6 in)
Weight dn model: 38.1 kg (84 lb)
c model: 38.6 kg (85 lb)
Figure 1-2 Dimensions for the 1 x 550-sheet paper feeder
1. Height 130 mm (5.1 in)
2. Depth Tray closed: 465 mm (18.3 in)
Tray opened: 768 mm (30.2 in)
3. Width Lower-right door closed: 458 mm (18.0 in)
Lower-right door opened: 853 mm (33.6 in)
Weight 5.8 kg (12.8 lb)
Figure 1-3 Dimensions for the cabinet/stand
1. Height 295 mm (11.6 in)
2. Depth Door closed: 869 mm (34.2 in)
Door opened: 1113 mm (43.8 in)
ENWW Printer specications 13
3. Width 884 mm (34.8 in)
K
C
M
Y
1
1
2
2
3
3
This value is subject to change. For current information, go to www.hp.com/support/colorljE57540mfp.
Weight 17.7 kg (39 lb)
This value is subject to change. For current information, go to www.hp.com/support/colorljE57540mfp.
Figure 1-4 Dimensions for the printer with three 1 x 550-sheet paper feeders and the cabinet/stand
Printer and accessories fully closed Printer and accessories fully opened
1. Height 1268 mm (49.9 in) 1522 mm (59.9 in)
2. Depth 869 mm (34.2 in) 1113 mm (43.8 in)
3. Width 884 mm (34.8 in) 853 mm (33.6 in)
Weight dn model: 73.2 kg (161.4 lb)
c model: 73.7 kg (162.5 lb)
1
These values are subject to change. For current information, go to www.hp.com/support/colorljE57540mfp.
2
Do not extend more than one paper tray at a time.
Power consumption, electrical specications, and acoustic emissions
See www.hp.com/support/colorljE57540mfp for current information.
CAUTION: Power requirements are based on the country/region where the printer is sold. Do not convert
operating voltages. This will damage the printer and void the printer warranty.
14 Chapter 1 Printer overview ENWW

Operating-environment range

Table 1-3 Operating-environment specications
Environment Recommended Allowed
Temperature 17° to 25°C (62.6° to 77°F) 15° to 30°C (59° to 86°F)
Relative humidity 30% to 70% relative humidity (RH) 10% to 80% RH
Altitude Not applicable 0 to 3000 m (0 to 9,842 ft)
ENWW Printer specications 15

Printer hardware setup and software installation

For basic setup instructions, see the Hardware Installation Guide that came with the printer. For additional instructions, go to HP support on the Web.
Go to www.hp.com/support/colorljE57540mfp for HP's all-inclusive help for the printer. Find the following support:
Install and congure
Learn and use
Solve problems
Download software and rmware updates
Join support forums
Find warranty and regulatory information
16 Chapter 1 Printer overview ENWW

2 Paper trays

For more information:

Load paper to Tray 1 (multipurpose tray)
Load paper to Trays 2, 3, 4, and 5
Load and print envelopes
Load and print labels
Use the convenience stapler (c model)
The following information is correct at the time of publication.
For video assistance, see www.hp.com/videos/LaserJet.
For current information, see www.hp.com/support/colorljE57540mfp.
HP's all-inclusive help for the printer includes the following information:
Install and congure
Learn and use
Solve problems
Download software and rmware updates
Join support forums
Find warranty and regulatory information
ENWW For more information: 17

Load paper to Tray 1 (multipurpose tray)

Introduction

The following information describes how to load paper into Tray 1. This tray holds up to 100 sheets of 75 g/m (20 lb) paper or 10 envelopes.
NOTE: Select the correct paper type in the print driver before printing..
NOTE: Tray 1 does not support labels. To print on sheets of labels, use Tray 2, or one of the optional 550-sheet
paper feeders.
CAUTION: To avoid jams, never add or remove paper from Tray 1 during printing.
1. Open Tray 1.
2
2. Pull out the tray extension to support the paper.
18 Chapter 2 Paper trays ENWW
3. Spread the paper guides to the correct size, and
then load paper in the tray. For information about how to orient the paper, see Tray 1 paper
orientation on page 20.
4. Make sure that the paper ts under the ll line on
the paper guides.
NOTE: The maximum stack height is 10 mm (0.4
in), or approximately 100 sheets of 75g paper.
5. Adjust the side guides so that they lightly touch the
paper stack, but do not bend it.
ENWW Load paper to Tray 1 (multipurpose tray) 19

Tray 1 paper orientation

123
123
123
123
When using paper that requires a specic orientation, load it according to the information in the following table.
NOTE: The Alternative Letterhead Mode settings aects the way to load letterhead or preprinted paper. This
setting is disabled by default. When using this mode, load paper as for automatic duplex printing. For more information, see Use alternative letterhead mode on page 21.
Paper type Image Orientation Single-sided printing Duplex printing or with Alternative
Letterhead Mode enabled
Letterhead or preprinted Portrait Face-down
Top edge leading into the printer
Landscape Face-down
Top edge toward the back of the printer
Face-up
Bottom edge leading into the printer
Face-up
Top edge toward the back of the printer
Prepunched Portrait and landscape Holes toward the back of the printer Holes toward the back of the printer
20 Chapter 2 Paper trays ENWW

Use alternative letterhead mode

Use the Alternative Letterhead Mode feature to load letterhead or preprinted paper into the tray the same way for all jobs, whether printing to one side of the sheet of paper or to both sides. When using this mode, load paper as for automatic duplex printing.
To use the feature, enable it by using the printer control-panel menus.
Enable Alternative Letterhead Mode by using the printer control-panel menus
1. From the Home screen on the printer control panel, swipe from right to left until the Settings menu
displays. Touch the
2. Open the following menus:
Manage Trays
Alternative Letterhead Mode
3. Select Enabled, and then touch the Save button or press the OK button.
Settings icon to open the menu.
ENWW Load paper to Tray 1 (multipurpose tray) 21

Load paper to Trays 2, 3, 4, and 5

Introduction

The following information describes how to load paper in Tray 2 and the optional 550-sheet trays (Trays 3, 4, and 5; part number B5L34A). These trays hold up to 550 sheets of 75 g/m2 (20 lb) paper.
NOTE: The procedure to load paper for the optional 550-sheet trays is the same as for Tray 2. Only Tray 2 is
shown here.
NOTE: The paper guides may be locked before use and may not be adjustable.
CAUTION: Do not extend more than one paper tray at a time.
1. Open the tray.
NOTE: Do not open this tray while it is in use.
2. Before loading paper, adjust the paper-width
guides by squeezing the adjustment latches and sliding the guides to the size of the paper being used. The arrow on the tray guide should line up exactly with the marking on the tray.
22 Chapter 2 Paper trays ENWW
3. Adjust the paper-length guide by squeezing the
adjustment latch and sliding the guide to the size of the paper being used.
4. Load paper into the tray. For information about
how to orient the paper, see Tray 2 and the 550-
sheet trays paper orientation on page 24.
NOTE: Do not adjust the paper guides tightly
against the paper stack. Adjust them to the indentations or markings in the tray.
NOTE: To prevent jams, adjust the paper guides
to the correct size and do not overll the tray. Be sure that the top of the stack is below the tray full indicator, as shown in the enlargement in the illustration.
5. Close the tray.
ENWW Load paper to Trays 2, 3, 4, and 5 23
6. The tray conguration message displays on the
Y
X
printer control panel.
7. If the paper size and type shown is not correct,
select Modify to choose a dierent paper size or type.
For custom-size paper, specify the X and Y dimensions for the paper when the prompt displays on the printer control panel.

Tray 2 and the 550-sheet trays paper orientation

When using paper that requires a specic orientation, load it according to the information in the following table.
NOTE: The Alternative Letterhead Mode settings aects the way to load letterhead or preprinted paper. This
setting is disabled by default. When using this mode, load paper as for automatic duplex printing. For more information, see Use alternative letterhead mode on page 25.
Paper type Image Orientation Single-sided printing Duplex printing or with Alternative
Letterhead Mode enabled
Letterhead or preprinted Portrait Face-up
Top edge toward the right
Face-down
Top edge toward the left
24 Chapter 2 Paper trays ENWW
Paper type Image Orientation Single-sided printing Duplex printing or with Alternative
123
123
Letterhead Mode enabled
Landscape Face-up
Top edge toward the back of the printer
Prepunched Portrait and landscape Holes toward the back of the printer Holes toward the back of the printer
Face-down
Top edge toward the back of the printer

Use alternative letterhead mode

Use the Alternative Letterhead Mode feature to load letterhead or preprinted paper into the tray the same way for all jobs, whether printing to one side of the sheet of paper or to both sides. When using this mode, load paper as for automatic duplex printing.
To use the feature, enable it by using the printer control-panel menus.
Enable Alternative Letterhead Mode by using the printer control-panel menus
1. From the Home screen on the printer control panel, swipe from right to left until the Settings menu
displays. Touch the Settings icon to open the menu.
2. Open the following menus:
Manage Trays
Alternative Letterhead Mode
3. Select Enabled, and then touch the Save button or press the OK button.
ENWW Load paper to Trays 2, 3, 4, and 5 25

Load and print envelopes

Introduction

The following information describes how to print and load envelopes. Use only Tray 1 to print on envelopes. Tray 1 holds up to 10 envelopes.
To print envelopes using the manual feed option, follow these steps to select the correct settings in the print driver, and then load the envelopes into the tray after sending the print job to the printer.

Print envelopes

1. From the software program, select the Print option.
2. Select the printer from the list of printers, and then click or tap the Properties or Preferences button to
open the print driver.
NOTE: The name of the button varies for dierent software programs.
NOTE: To access these features from a Windows 8 or 8.1 Start screen, select Devices, select Print, and
then select the printer.
3. Click or tap the Paper/Quality tab.
4. In the Paper size drop-down list, select the correct size for the envelopes.
5. In the Paper type drop-down list, select Envelope.
6. In the Paper source drop-down list, select Manual feed.
7. Click the OK button to close the Document Properties dialog box.
8. In the Print dialog box, click the OK button to print the job.

Envelope orientation

Load envelopes in either of these orientations:
Face-down
Top edge toward the back of the printer
Face-down
Top edge leading into the printer
26 Chapter 2 Paper trays ENWW

Load and print labels

Introduction

To print on sheets of labels, use Tray 2 or one of the optional 550-sheet trays. Tray 1 does not support labels.
To print labels using the manual feed option, follow these steps to select the correct settings in the print driver, and then load the labels into the tray after sending the print job to the printer. When using manual feed, the printer waits to print the job until it detects the tray has been opened and closed.

Manually feed labels

1. From the software program, select the Print option.
2. Select the printer from the list of printers, and then click or tap the Properties or Preferences button to
open the print driver.
NOTE: The name of the button varies for dierent software programs.
NOTE: To access these features from a Windows 8 or 8.1 Start screen, select Devices, select Print, and
then select the printer.
3. Click or tap the Paper/Quality tab.
4. In the Paper size drop-down list, select the correct size for the sheets of labels.
5. In the Paper type drop-down list, select Labels.
6. In the Paper source drop-down list, select Manual feed.
NOTE: When using manual feed, the printer prints from the lowest-numbered tray that is congured for
the correct size of paper, so it is not necessary to specify a particular tray. For example, if Tray 2 is congured for labels, the printer will print from Tray 2. If Tray 3 is installed and congured for labels, but Tray 2 is not congured for labels, the printer will print from Tray 3.
7. Click the OK button to close the Document Properties dialog box.
8. In the Print dialog box, click the OK button to print the job.
ENWW Load and print labels 27
9. Load sheets of labels face-up with the top of the sheet toward the right side of the printer.
28 Chapter 2 Paper trays ENWW

Use the convenience stapler (c model)

The convenience stapler can staple up to 20 sheets of 75 g/m2 (20 lb) paper.
CAUTION: To avoid damage to the printer, do not attempt to staple materials other than paper.
1. Insert the stack of paper into the slot on the front of the stapler.
2. Wait for the stapler to staple the sheets. The stapler activates when it senses paper, and it makes a stapling
sound.
NOTE: If the printer is in Sleep mode, there might be a short delay.
3. Remove the stapled paper from the slot.
If the stapler does not release the paper, follow these steps to resolve the problem.
WARNING! To avoid injury, do not put your nger inside the stapler area to attempt to release the paper.
1. Open and close the stapler door, and then try removing the paper.
2. If the paper is still stuck, make sure the stapler door is closed, and then turn o the printer and turn it on
again.
ENWW Use the convenience stapler (c model) 29
30 Chapter 2 Paper trays ENWW

3 Supplies, accessories, and parts

For more information:

Order supplies, accessories, and parts
Replace the toner cartridges
Replace the toner-collection unit
Replace the staple cartridge (c models)
The following information is correct at the time of publication.
For video assistance, see www.hp.com/videos/LaserJet.
For current information, see www.hp.com/support/colorljE57540mfp.
HP's all-inclusive help for the printer includes the following information:
Install and congure
Learn and use
Solve problems
Download software and rmware updates
Join support forums
Find warranty and regulatory information
ENWW For more information: 31

Order supplies, accessories, and parts

Ordering

Order supplies and paper www.hp.com/go/suresupply
Order genuine HP parts or accessories www.hp.com/buy/parts
Order through service or support providers Contact an HP-authorized service or support provider.
Order using the HP Embedded Web Server (EWS) To access, in a supported web browser on your computer, enter the
printer IP address or host name in the address/URL eld. The EWS contains a link to the HP SureSupply website, which provides options for purchasing Original HP supplies.

Supplies and accessories

In order to purchase toner cartridges, contact your managed service representative. Make sure that you know your product model number, which appears on the product label on the printer rear cover.
Item Description Part number
Supplies
HP toner-collection unit Replacement toner-collection unit with attached door B5L37A
HP Staple Cartridge Pack Replacement staple cartridges for the c model.
Contains two staple cartridges of 1500 staples each.
HP LaserJet 110 V Fuser Kit Replacement fuser for 110 V models
NOTE: A message displays on the control panel if the
fuser needs to be replaced.
HP LaserJet 220 V Fuser Kit Replacement fuser for 220 V models
NOTE: A message displays on the control panel if the
fuser needs to be replaced.
HP 200 ADF Roller Replacement Kit Replacement feed rollers for the document feeder B5L52A
Accessories
HP Color LaserJet 550-sheet Media Tray Optional 550-sheet paper feeder
NOTE: The printer supports up to three 550-sheet
paper feeders.
Printer stand and cabinet Optional stand with storage cabinet to support the
printer
Recommended when using multiple optional paper feeders.
Includes installation instructions
HP LaserJet Keyboard Overlay Kit for Simplied Chinese & Traditional Chinese
Language-specic, adhesive overlay for the physical keyboard
Q7432A
B5L35A
B5L36A
B5L34A
B5L51A
A7W12A
(c model only)
32 Chapter 3 Supplies, accessories, and parts ENWW
Item Description Part number
HP LaserJet Keyboard Overlay Kit for Swedish
(c model only)
HP 1GB DDR3 x32 144-Pin 800MMHz SODIMM Optional DIMM for expanding the memory E5K48A
HP Trusted Platform Module Automatically encrypts all data that passes through the
HP Foreign Interface Harness Optional port for connecting third-party devices B5L31A
HP LaserJet MFP Analog Fax Accessory 600 Optional fax accessory for the dn model B5L53A
HP Jetdirect 2900nw Print Server USB wireless print server accessory J8031A
HP Jetdirect 3000w NFC/Wireless Accessory Wi-Fi direct accessory for “touch” printing from mobile
Language-specic, adhesive overlay for the physical keyboard
printer
Includes installation instructions
devices
A7W14A
F5S62A
J8030A

Customer self-repair parts

Customer Self-Repair (CSR) parts are available for many HP LaserJet printers to reduce repair time. More information about the CSR program and benets can be found at www.hp.com/go/csr-support and
www.hp.com/go/csr-faq.
Genuine HP replacement parts can be ordered at www.hp.com/buy/parts or by contacting an HP-authorized service or support provider. When ordering, one of the following will be needed: part number, serial number (found on back of printer), product number, or printer name.
Parts listed as Mandatory self-replacement are to be installed by customers, unless you are willing to pay
HP service personnel to perform the repair. For these parts, on-site or return-to-depot support is not provided under the HP printer warranty.
Parts listed as Optional self-replacement can be installed by HP service personnel at your request for no
additional charge during the printer warranty period.
Item Description Self-replacement options Part number
1 x 550 Sheet Feeder Kit Replacement 1 x 550-sheet feeder Mandatory B5L34-67901
Printer Cabinet Kit Replacement printer cabinet/stand Mandatory B5L51-67901
HP Fuser kit Replacement fuser Mandatory B5L35-67901 (110-volt)
B5L36-67901 (220-volt)
HP Fuser kit, service Replacement fuser, service kit Mandatory B5L35-67902 (110-volt)
B5L36-67902 (220-volt)
ITB and T2 Roller kit, service Replacement transfer belt and secondary
transfer roller
T2 Roller Service Kit Replacement secondary transfer roller Mandatory B5L24-67902
Tray 2-X Roller kit Replacement rollers for Trays 2, 3, 4, and 5 Optional B5L24-67904
Control-panel kit Replacement touchscreen control panel Mandatory B5L47-67018
Optional B5L24-67901
ENWW Order supplies, accessories, and parts 33
Item Description Self-replacement options Part number
320 GB Hard Disk Drive kit Replacement hard disk drive Mandatory 5851-6712
HP 1GB DDR3 x32 144-Pin 800MHz SODIMM
HP Trusted Platform Module kit Replacement trusted platform module Mandatory F5S62-61001
HP Foreign Interface Harness kit Replacement foreign interface harness Mandatory B5L31-67902
Toner Collection Unit Replacement toner-collection unit Mandatory B5L37-67901
Analog FAX 600 Kit Replacement fax board Mandatory B5L53-67901
ADF Maintenance Kit Maintenance kit for the document feeder Mandatory B5L52-67903
Scanner white backing Replacement white plastic backing for the
Retention Clip Assy Replacement retention clips that are behind
U.S. English Keyboard Kit Replacement keyboard for the c model Mandatory B5L47-67019
U.K. English Keyboard Kit Replacement keyboard for the c model Mandatory B5L47-67020
Keyboard Overlay Kit
French, Italian, Russian, German, Spanish, Ukranian
Keyboard Overlay Kit
Canadian French, Latin American Spanish, U.S. Spanish
Replacement memory DIMM Mandatory E5K48A-67902
Mandatory 5851-6570
scanner
Mandatory 5851-6573
the scanner white backing
Replacement keyboard overlay for the c model
Replacement keyboard overlay for the c model
Mandatory 5851-6019
Mandatory 5851-6020
Keyboard Overlay Kit
Swiss French, Swiss German, Danish
Keyboard Overlay Kit
Simplied Chinese, Traditional Chinese
Keyboard Overlay Kit
Spanish, Portuguese
Keyboard Overlay Kit
Japanese (KG and KT)
Replacement keyboard overlay for the c model
Replacement keyboard overlay for the c model
Replacement keyboard overlay for the c model
Replacement keyboard overlay for the c model
Mandatory 5851-6021
Mandatory 5851-6022
Mandatory 5851-6023
Mandatory 5851-6024
34 Chapter 3 Supplies, accessories, and parts ENWW

Replace the toner cartridges

1
2
3
4

Introduction

The following information provides details about the toner cartridges for the printer, and it includes instructions to replace them.

Toner-cartridge information

Remove and replace the cartridges
Toner-cartridge information
This printer indicates when the toner-cartridge level is low and very low. The actual toner-cartridge life remaining can vary. Consider having a replacement cartridge available to install when print quality is no longer acceptable.
To purchase cartridges or check cartridge compatibility for the printer, go to HP SureSupply at www.hp.com/go/
suresupply. Scroll to the bottom of the page and verify that the country/region is correct.
The printer uses four colors and has a dierent toner cartridge for each color: yellow (Y), magenta (M), cyan (C), and black (K). The toner cartridges are inside the front door.
NOTE: High-yield toner cartridges contain more toner than standard cartridges for increased page yield. For
more information, go to www.hp.com/go/learnaboutsupplies.
Do not remove the toner cartridge from its package until it is time to replace it.
CAUTION: To prevent damage to the toner cartridge, do not expose it to light for more than a few minutes.
Cover the green imaging drum if the toner cartridge must be removed from the printer for an extended period of time.
The following illustration shows the toner-cartridge components.
1 Handle
2 Imaging drum
3 Protective shield
4 Memory chip
ENWW Replace the toner cartridges 35
CAUTION: If toner gets on clothing, wipe it o by using a dry cloth and wash the clothes in cold water. Hot water
K
C
M
Y
K
C
M
Y
sets toner into fabric.
NOTE: Information about recycling used toner cartridges is in the toner-cartridge box.

Remove and replace the cartridges

1. Open the front door.
2. Grasp the handle of the used toner cartridge and
pull out to remove it.
36 Chapter 3 Supplies, accessories, and parts ENWW
3. Remove the new toner cartridge from its protective
1
2
3
K
C
M
Y
shell by tearing o the plastic strip and opening the package. Save all packaging for recycling the used toner cartridge.
4. Remove the protective shield from the toner
cartridge.
5. Support the toner cartridge underneath with one
hand while holding the cartridge handle with the other. Align the toner cartridge with its slot on the shelf, and then insert the toner cartridge into the printer.
NOTE: Avoid touching the green imaging drum.
Fingerprints on the imaging drum can cause print defects.
ENWW Replace the toner cartridges 37
6. Close the front door.
K
C
M
Y
2
1
3
7. Pack the used toner cartridge into the box that the
new cartridge came in, or use a large cardboard box and ll it with several cartridges that you need to recycle. See the enclosed recycling guide for information about recycling.
In the U.S., a pre-paid shipping label is included in the box. In other countries/regions, go to
www.hp.com/recycle to print a pre-paid shipping
label.
Adhere the pre-paid shipping label to the box, and return the used cartridge to HP for recycling.
38 Chapter 3 Supplies, accessories, and parts ENWW

Replace the toner-collection unit

Y
Y
Y
Y
Y
Y
Y
Y

Introduction

The following information provides details about the toner-collection unit for the printer, and it includes instructions to replace it.
The printer indicates when the toner-collection unit is nearly full and when it is completely full. When it is completely full, printing stops until the toner-collection unit is replaced.
To purchase a toner-collection unit (part number B5L37A), go to the HP Parts Store at www.hp.com/buy/parts.
NOTE: The toner-collection unit is designed for a single use. Do not attempt to empty the toner-collection unit
and reuse it. Doing so could lead to toner being spilled inside the printer, which could result in reduced print quality. After use, return the toner-collection unit to HP’s Planet Partners program for recycling.
CAUTION: If toner gets on clothing, wipe it o by using a dry cloth and wash the clothes in cold water. Hot water
sets toner into fabric.

Remove and replace the toner-collection unit

1. Open the front door.
2. Open the toner-collection-unit door on the upper-
left side of the printer.
ENWW Replace the toner-collection unit 39
3. Pull out the toner-collection unit and the attached
Y
Y
Y
Y
Y
Y
Y
Y
door.
4. Remove the new toner-collection unit from its
packaging.
5. Install the new toner-collection unit and the
attached door into the printer. Align the tabs on the door with the slots in the printer.
40 Chapter 3 Supplies, accessories, and parts ENWW
6. Close the toner-collection unit door.
Y
Y
Y
Y
Y
Y
Y
Y
7. Close the front door.
To recycle the used toner-collection unit, follow the instructions included with the new toner-collection unit.
ENWW Replace the toner-collection unit 41

Replace the staple cartridge (c models)

Introduction

The following information provides details about the staple cartridges for the printer, and it includes instructions to replace them.
To purchase a package of two staple cartridges (part number Q7432A), go to the HP Parts Store at
www.hp.com/buy/parts. Each cartridge holds 1,500 staples.

Remove and replace the staple cartridge

1. Open the stapler door.
NOTE: Opening the stapler door disables the
stapler.
2. Remove the staple cartridge from the printer.
42 Chapter 3 Supplies, accessories, and parts ENWW
3. Insert the new staple cartridge into the opening
inside the stapler door.
4. Close the stapler door.
ENWW Replace the staple cartridge (c models) 43
44 Chapter 3 Supplies, accessories, and parts ENWW

4 Print

For more information:

Print tasks (Windows)
Print tasks (macOS)
Store print jobs on the printer to print later or print privately
Print from the USB port
The following information is correct at the time of publication.
For video assistance, see www.hp.com/videos/LaserJet.
For current information, see www.hp.com/support/colorljE57540mfp.
HP's all-inclusive help for the printer includes the following information:
Install and congure
Learn and use
Solve problems
Download software and rmware updates
Join support forums
Find warranty and regulatory information
ENWW For more information: 45

Print tasks (Windows)

How to print (Windows)

The following procedure describes the basic printing process for Windows.
1. From the software program, select the Print option.
2. Select the printer from the list of printers. To change settings, click the Properties or Preferences button to
open the print driver.
NOTE: The name of the button varies for dierent software programs.
NOTE: In Windows 10, 8.1, and 8, these applications will have a dierent layout with dierent features
from what is described below for desktop applications. To access the print feature from a Start screen app, complete the following steps:
Windows 10: Select Print, and then select the printer.
Windows 8.1 or 8: Select Devices, select Print, and then select the printer.
For the HP PCL-6 V4 driver, the HP AiO Printer Remote application downloads additional driver features when More settings is selected.
NOTE: For more information, click the Help (?) button in the print driver.
3. Click the tabs in the print driver to congure the available options. For example, set the paper orientation
on the Finishing tab, and set the paper source, paper type, paper size, and quality settings on the Paper/ Quality tab.
4. Click the OK button to return to the Print dialog box. Select the number of copies to print from this screen.
5. Click the Print button to print the job.

Automatically print on both sides (Windows)

Use this procedure for printers that have an automatic duplexer installed. If the printer does not have an automatic duplexer installed, or to print on paper types that the duplexer does not support, print on both sides manually.
1. From the software program, select the Print option.
2. Select the printer from the list of printers, and then click the Properties or Preferences button to open the
print driver.
NOTE: The name of the button varies for dierent software programs.
NOTE: In Windows 10, 8.1, and 8, these applications will have a dierent layout with dierent features
from what is described below for desktop applications. To access the print feature from a Start screen app, complete the following steps:
Windows 10: Select Print, and then select the printer.
Windows 8.1 or 8: Select Devices, select Print, and then select the printer.
For the HP PCL-6 V4 driver, the HP AiO Printer Remote application downloads additional driver features when More settings is selected.
46 Chapter 4 Print ENWW
3. Click the Finishing tab.
4. Select Print on both sides. Click OK to close the Document Properties dialog.
5. In the Print dialog, click Print to print the job.

Manually print on both sides (Windows)

Use this procedure for printers that do not have an automatic duplexer installed or to print on paper that the duplexer does not support.
1. From the software program, select the Print option.
2. Select the printer from the list of printers, and then click the Properties or Preferences button to open the
print driver.
NOTE: The name of the button varies for dierent software programs.
NOTE: In Windows 10, 8.1, and 8, these applications will have a dierent layout with dierent features
from what is described below for desktop applications. To access the print feature from a Start screen app, complete the following steps:
Windows 10: Select Print, and then select the printer.
Windows 8.1 or 8: Select Devices, select Print, and then select the printer.
For the HP PCL-6 V4 driver, the HP AiO Printer Remote application downloads additional driver features when More settings is selected.
3. Click the Finishing tab.
4. Select Print on both sides (manually), and then click OK to close the Document Properties dialog.
5. In the Print dialog, click Print to print the rst side of the job.
6. Retrieve the printed stack from the output bin, and place it in Tray 1.
7. If prompted, select the appropriate control panel button to continue.

Print multiple pages per sheet (Windows)

1. From the software program, select the Print option.
2. Select the printer from the list of printers, and then click the Properties or Preferences button to open the
print driver.
NOTE: The name of the button varies for dierent software programs.
NOTE: In Windows 10, 8.1, and 8, these applications will have a dierent layout with dierent features
from what is described below for desktop applications. To access the print feature from a Start screen app, complete the following steps:
Windows 10: Select Print, and then select the printer.
Windows 8.1 or 8: Select Devices, select Print, and then select the printer.
For the HP PCL-6 V4 driver, the HP AiO Printer Remote application downloads additional driver features when More settings is selected.
ENWW Print tasks (Windows) 47
3. Click the Finishing tab.
4. Select the number of pages per sheet from the Pages per sheet drop-down.
5. Select the correct Print page borders, Page order, and Orientation options. Click OK to close the Document
Properties dialog.
6. In the Print dialog, click Print to print the job.

Select the paper type (Windows)

1. From the software program, select the Print option.
2. Select the printer from the list of printers, and then click the Properties or Preferences button to open the
print driver.
NOTE: The name of the button varies for dierent software programs.
NOTE: In Windows 10, 8.1, and 8, these applications will have a dierent layout with dierent features
from what is described below for desktop applications. To access the print feature from a Start screen app, complete the following steps:
Windows 10: Select Print, and then select the printer.
Windows 8.1 or 8: Select Devices, select Print, and then select the printer.
For the HP PCL-6 V4 driver, the HP AiO Printer Remote application downloads additional driver features when More settings is selected.
3. Click the Paper/Quality tab.
4. Select the paper type from the Paper type drop-down list.
5. Click OK to close the Document Properties dialog. In the Print dialog, click Print to print the job.
If the tray needs to be congured, a tray conguration message displays on the printer control panel.
6. Load the tray with the specied type and size of paper, and then close the tray.
7. Touch the OK button to accept the detected type and size, or touch the Modify button to choose a dierent
paper size or type.
8. Select the correct type and size, and then touch the OK button.
48 Chapter 4 Print ENWW

Additional print tasks

Go to www.hp.com/support/colorljE57540mfp.
Instructions are available for performing specic print tasks, such as the following:
Create and use printing shortcuts or presets
Select the paper size, or use a custom paper size
Select the page orientation
Create a booklet
Scale a document to t a specic paper size
Print the rst or last pages of the document on dierent paper
Print watermarks on a document
ENWW Print tasks (Windows) 49

Print tasks (macOS)

How to print (macOS)

The following procedure describes the basic printing process for macOS.
1. Click the File menu, and then click the Print option.
2. Select the printer.
3. Click Show Details or Copies & Pages, and then select other menus to adjust the print settings.
NOTE: The name of the item varies for dierent software programs.
4. Click the Print button.

Automatically print on both sides (macOS)

NOTE: This information applies to printers that include an automatic duplexer.
NOTE: This feature is available if you install the HP print driver. It might not be available if you are using AirPrint.
1. Click the File menu, and then click the Print option.
2. Select the printer.
3. Click Show Details or Copies & Pages, and then click the Layout menu.
NOTE: The name of the item varies for dierent software programs.
4. Select a binding option from the Two-Sided drop-down list.
5. Click the Print button.

Manually print on both sides (macOS)

NOTE: This feature is available if you install the HP print driver. It might not be available if you are using AirPrint.
1. Click the File menu, and then click the Print option.
2. Select the printer.
3. Click Show Details or Copies & Pages, and then click the Manual Duplex menu.
NOTE: The name of the item varies for dierent software programs.
4. Click the Manual Duplex box, and select a binding option.
5. Click the Print button.
6. Go to the printer, and remove any blank paper that is in Tray 1.
7. Retrieve the printed stack from the output bin and place it with the printed-side facing down in the input
tray.
8. If prompted, touch the appropriate control panel button to continue.
50 Chapter 4 Print ENWW

Print multiple pages per sheet (macOS)

1. Click the File menu, and then click the Print option.
2. Select the printer.
3. Click Show Details or Copies & Pages, and then click the Layout menu.
NOTE: The name of the item varies for dierent software programs.
4. From the Pages per Sheet drop-down list, select the number of pages that you want to print on each sheet.
5. In the Layout Direction area, select the order and placement of the pages on the sheet.
6. From the Borders menu, select the type of border to print around each page on the sheet.
7. Click the Print button.

Select the paper type (macOS)

1. Click the File menu, and then click the Print option.
2. Select the printer.
3. Click Show Details or Copies & Pages, and then click the Media & Quality menu or the Paper/Quality menu.
NOTE: The name of the item varies for dierent software programs.
4. Select from the Media & Quality or Paper/Quality options.
NOTE: This list contains the master set of options available. Some options are not available on all printers.
Media Type: Select the option for the type of paper for the print job.
Print Quality: Select the resolution level for the print job.
Edge-To-Edge Printing: Select this option to print close to the paper edges.
5. Click the Print button.

Additional print tasks

Go to www.hp.com/support/colorljE57540mfp.
Instructions are available for performing specic print tasks, such as the following:
Create and use printing shortcuts or presets
Select the paper size, or use a custom paper size
Select the page orientation
Create a booklet
Scale a document to t a specic paper size
Print the rst or last pages of the document on dierent paper
Print watermarks on a document
ENWW Print tasks (macOS) 51

Store print jobs on the printer to print later or print privately

Introduction

The following information provides procedures for creating and printing documents that are stored on the printer. These jobs can be printed at a later time or printed privately.

Create a stored job (Windows)

Create a stored job (macOS)
Print a stored job
Delete a stored job
Information sent to printer for Job Accounting purposes
Create a stored job (Windows)
Store jobs on the printer for private or delayed printing.
1. From the software program, select the Print option.
2. Select the printer from the list of printers, and then select Properties or Preferences (the name varies for
dierent software programs).
NOTE: The name of the button varies for dierent software programs.
NOTE: In Windows 10, 8.1, and 8, these applications will have a dierent layout with dierent features
from what is described below for desktop applications. To access the print feature from a Start screen app, complete the following steps:
Windows 10: Select Print, and then select the printer.
Windows 8.1 or 8: Select Devices, select Print, and then select the printer.
For the HP PCL-6 V4 driver, the HP AiO Printer Remote application downloads additional driver features when More settings is selected.
3. Click the Job Storage tab.
4. Select a Job Storage Mode option.
Proof and Hold: Print and proof one copy of a job, and then print more copies.
Personal Job: The job does not print until you request it at the printer control panel. For this job-
storage mode, you can select one of the Make Job Private/Secure options. If you assign a personal identication number (PIN) to the job, you must provide the required PIN at the control panel. If you encrypt the job, you must provide the required password at the control panel. The print job is deleted from memory after it prints and is lost if the printer loses power.
Quick Copy: Print the requested number of copies of a job and store a copy of the job in the printer
memory so you can print it again later.
Stored Job: Store a job on the printer and allow other users to print the job at any time. For this job-
storage mode, you can select one of the Make Job Private/Secure options. If you assign a personal identication number (PIN) to the job, the person who prints the job must provide the required PIN at
52 Chapter 4 Print ENWW
the control panel. If you encrypt the job, the person who prints the job must provide the required password at the control panel.
5. To use a custom user name or job name, click the Custom button, and then enter the user name or the job
name.
Select which option to use if another stored job already has that name:
Use Job Name + (1-99): Append a unique number to the end of the job name.
Replace Existing File: Overwrite the existing stored job with the new one.
6. Click the OK button to close the Document Properties dialog box. In the Print dialog box, click the Print
button to print the job.

Create a stored job (macOS)

Store jobs on the printer for private or delayed printing.
1. Click the File menu, and then click the Print option.
2. In the Printer menu, select the printer.
3. By default, the print driver displays the Copies & Pages menu. Open the menus drop-down list, and then
click the Job Storage menu.
4. In the Mode drop-down list, select the type of stored job.
Proof and Hold: Print and proof one copy of a job, and then print more copies.
Personal Job: The job does not print until someone requests it at the printer control panel. If the job
has a personal identication number (PIN), provide the required PIN at the control panel. The print job is deleted from memory after it prints and is lost if the printer loses power.
Quick Copy: Print the requested number of copies of a job and store a copy of the job in the printer
memory to print it again later.
Stored Job: Store a job on the printer and allow other users to print the job at any time. If the job has a
personal identication number (PIN), the person who prints the job must provide the required PIN at the control panel.
5. To use a custom user name or job name, click the Custom button, and then enter the user name or the job
name.
Select which option to use if another stored job already has that name.
Use Job Name + (1-99): Append a unique number to the end of the job name.
Replace Existing File: Overwrite the existing stored job with the new one.
6. If you selected the Stored Job or Personal Job option in step 4, you can protect the job with a PIN. Type a 4-
digit number in the Use PIN to Print eld. When other people attempt to print this job, the printer prompts them to enter this PIN number.
7. Click the Print button to process the job.
ENWW Store print jobs on the printer to print later or print privately 53

Print a stored job

Use this procedure to print a document that is in a job storage folder on the printer.
1. From the Home screen on the printer control panel, select Print, and then select Print from Job Storage.
2. Under Stored Jobs to Print, select Choose, and then select the folder where the document is saved.
3. Select the document, and then touch Select.
If the document is private, enter the four-digit PIN in the Password eld, and then select OK.
4. To adjust the number of copies, select the box to the left of the Print button, and then select the number of
copies from the keypad that opens. Select the Close button to close the keypad.
5. Select Print to print the document.

Delete a stored job

You can delete documents that have been saved to when printer when they are no longer needed. You can also adjust the maximum number of jobs for the printer to store.
Delete a job that is stored on the printer
Change the job storage limit
Delete a job that is stored on the printer
Follow these steps to delete a job that is stored in the printer memory.
1. From the Home screen on the printer control panel, select Print.
2. Select Print from Job Storage.
3. Select Choose, and then select the name of the folder where the job is stored.
4. Select the name of the job.
5. Select the Trash button to delete the job.
If the job is private or encrypted, enter the PIN or password, and then select OK.
6. Select Delete Jobs on the conrmation prompt.
Change the job storage limit
When a new job is stored in the printer memory, the printer overwrites any previous jobs with the same user and job name. If a job is not already stored under the same user and job name, and the printer needs additional space, the printer might delete other stored jobs starting with the oldest. Follow these steps to change the number of jobs that the printer can store:
1. From the Home screen on the printer control panel, select Settings.
2. Open the following menus:
Copy/Print or Print
Manage Stored Jobs
Temporary Job Storage Limit
54 Chapter 4 Print ENWW
3. Use the keypad to enter the number of jobs that the printer stores.
4. Select Done to save the setting.

Information sent to printer for Job Accounting purposes

Printing jobs sent from drivers on the client (e.g., PC) may send personally identiable information to HP’s Printing and Imaging devices. This information may include, but is not limited to, user name and client name from which the job originated that may be used for job accounting purposes, as determined by the Administrator of the printing device. This same information may also be stored with the job on the mass storage device (e.g., disk drive) of the printing device when using the job storage feature.
ENWW Store print jobs on the printer to print later or print privately 55

Print from the USB port

Introduction

This printer features easy-access USB printing, for quickly printing les without sending them from a computer. The printer accepts standard USB ash drives in the USB port near the control panel. It supports the following types of les:
.pdf
.prn
.pcl
.ps
.cht

Enable the USB port for printing

The USB port is disabled by default. Before using this feature, enable the USB port. Use one of the following methods to enable the port:
Method one: Enable the USB port from the printer control-panel menus
1. From the Home screen on the printer control panel, swipe until the Settings menu displays. Touch the Settings icon to open the menu.
2. Open the following menus:
USB Settings
Print From USB Drive Settings
Enable Print From USB Drive
3. Select the Enabled option.
Method two: Enable the USB port from the HP Embedded Web server (network-connected printers only)
1. Open the HP Embedded Web Server (EWS):
a. From the Home screen on the printer control panel, touch the Information icon, and then touch the
Network icon to display the IP address or host name.
b. Open a web browser, and in the address line, type the IP address or host name exactly as it displays
on the printer control panel. Press the Enter key on the computer keyboard. The EWS opens.
NOTE: If the web browser displays a message indicating that accessing the website might not be
safe, select the option to continue to the website. Accessing this website will not harm the computer.
2. Open the Copy/Print tab.
3. On the left side of the screen, click Retrieve from USB Setup.
56 Chapter 4 Print ENWW
4. Select the Enable Retrieve from USB check box.
5. Click Apply.
Print from a USB ash drive
1. Insert the USB ash drive into the easy-access USB port.
NOTE: The port might be covered. For some printers, the cover ips open. For other printers, pull the
cover straight out to remove it.
2. From the Home screen on the printer control panel, select Print.
3. Select Print from USB Drive.
4. Touch Choose, and then select the name of the document to print. Touch Select.
NOTE: The document might be in a folder. Open folders as necessary.
5. To adjust the number of copies, touch the number of copies eld in the bottom-left corner of the screen.
Use the keypad to enter the number of copies to print.
6. Select Print to print the document.
ENWW Print from the USB port 57
58 Chapter 4 Print ENWW

5 Copy

For more information:

Make a copy
Copy on both sides (duplex)
Additional options when copying
Additional copy tasks
The following information is correct at the time of publication.
For video assistance, see www.hp.com/videos/LaserJet.
For current information, see www.hp.com/support/colorljE57540mfp.
HP's all-inclusive help for the printer includes the following information:
Install and congure
Learn and use
Solve problems
Download software and rmware updates
Join support forums
Find warranty and regulatory information
ENWW For more information: 59

Make a copy

1. Place the document face-down on the scanner glass, or place it face-up in the document feeder and adjust
the paper guides to t the size of the document.
2. From the Home screen on the printer control panel, select Copy.
3. In the Options pane, select the number of copies.
4. Select Optimize Text/Picture to optimize for the type of image being copied: text, graphics, or photos.
Select one of the predened options.
5. Set options marked with a yellow triangle before using the preview feature.
NOTE: After the preview scan, these options are removed from the main Options list and are summarized
in the Pre-scan Options list. To change any of these options, discard the preview and start over.
Using the preview feature is optional.
6. Touch the right pane of the screen to preview the document. In the preview screen, use the buttons on the
right of the screen to adjust the preview options and to rearrange, rotate, insert, or remove pages.
Use these buttons to toggle between two-page view and thumbnail view. More options are available in thumbnail view than in two-page view.
Use these buttons to zoom in or out on the selected page.
NOTE: Select only one page at a time to use these buttons.
Use this button to rotate the page 180 degrees.
NOTE: This button is available only in the thumbnail view.
Use this button to delete the selected pages.
NOTE: This button is available only in the thumbnail view.
Use these buttons to rearrange the pages within the document. Select one or more pages and move them to the left or right.
NOTE: These buttons are available only in the thumbnail view.
60 Chapter 5 Copy ENWW
Use this button to add a page to the document. The printer prompts to scan additional pages.
Use this button to clear the changes made in the preview and start over.
7. When the document is ready, touch Start to begin copying.
ENWW Make a copy 61

Copy on both sides (duplex)

1. Place the document face-down on the scanner glass, or place it face-up in the document feeder and adjust
the paper guides to t the size of the document.
2. From the Home screen on the printer control panel, select Copy.
3. In the Options pane, select Original Sides, and then select the option that describes the original document:
Use Automatically detect to detect whether the original is printed on one or both sides of the page.
Use 1-sided for originals that are printed on one side of the page.
Use 2-sided (book-style) for originals that ip on the right/left edge of the page, like books. If the
image is portrait, the output ips on the long edge of the page. If the image is landscape, the output ips on the short edge of the page.
Use 2-sided (ip-style) for originals that ip on the top/bottom edge of the page, like calendars. If the
image is portrait, the output ips on the short edge of the page. If the image is landscape, the output ips on the long edge of the page.
4. Select Output Sides, and then select one of these options:
Match original: The output will match the format of the original. For example, if the original is 1-sided,
the output will be 1-sided. However, if the administrator has restricted 1-sided printing and the original is 1-sided, the output will be 2-sided book-style.
1-sided: The output will be 1-sided. However, if the administrator has restricted 1-sided printing, the
output will be 2-sided book-style.
2-sided (book-style): The output will ip on the right/left edge of the page, like a book. If the image is
portrait, the output ips on the long edge of the page. If the image is landscape, the output ips on the short edge of the page.
2-sided (ip-style): The output will ip on the top/bottom edge of the page, like a calendar. If the
image is portrait, the output ips on the short edge of the page. If the image is landscape, the output ips on the long edge of the page.
5. Set options marked with a yellow triangle before using the preview feature.
NOTE: After the preview scan, these options are removed from the main Options list and are summarized
in the Pre-scan Options list. To change any of these options, discard the preview and start over.
Using the preview feature is optional.
6. Touch the right pane of the screen to preview the document. In the preview screen, use the buttons on the
right of the screen to adjust the preview options and to rearrange, rotate, insert, or remove pages.
Use these buttons to toggle between two-page view and thumbnail view. More options are available in thumbnail view than in two-page view.
62 Chapter 5 Copy ENWW
Use these buttons to zoom in or out on the selected page.
NOTE: Select only one page at a time to use these buttons.
Use this button to rotate the page 180 degrees.
NOTE: This button is available only in the thumbnail view.
Use this button to delete the selected pages.
NOTE: This button is available only in the thumbnail view.
Use these buttons to rearrange the pages within the document. Select one or more pages and move them to the left or right.
NOTE: These buttons are available only in the thumbnail view.
Use this button to add a page to the document. The printer prompts to scan additional pages.
Use this button to clear the changes made in the preview and start over.
7. When the document is ready, touch Start to begin copying.
ENWW Copy on both sides (duplex) 63

Additional options when copying

The following settings are available in the Options list when copying.
NOTE: The following list contains the master set of options available for HP Enterprise MFP printers. Some
options are not available on all printers.
Number of Copies Specify the number of copies to make.
Load and Save Settings Load Quick Set: Load copy settings from a saved Quick Set.
NOTE: Use the HP Embedded Web Server to create and save Quick Sets.
Save Defaults: Save the current settings in the Options list as default settings for future copy jobs.
Sides Specify whether the original document is printed on one side or both sides, and whether the copies are
to be printed on one side or both sides.
Color/Black
For color printers only.
Staple
For printers with automatic nishing accessories only. This feature does not apply to printers with convenience staplers.)
Staple/Hole Punch
For printers with hole-punch accessories only.
Scan Mode Standard Document: Scan a page or stack of pages through the document feeder, or individually on the
Reduce/Enlarge Scale the size of the scanned document up or down.
Original Size Specify the paper size for the original document.
Paper Selection Specify the paper size and type for the copies.
Specify whether copies are to be printed in color, black and gray, or black only.
Specify the placement of staples.
Specify the number and placement of punched holes.
atbed glass.
Book Mode: Scan an open book and output each page of the book onto dierent pages.
2-sided ID Copy: Scan each side of an identication card on the atbed glass and output them onto one page. After scanning the rst side, the printer prompts to place the second side in the correct position on the glass.
Booklet Format and rearrange original scanned images into pages that print as a booklet.
Content Orientation Specify whether the original document is printed in Portrait or Landscape orientation.
Pages per Sheet Copy multiple sheets of paper onto a single sheet. Select one, two, or four pages per sheet.
Output Bin
For printers with multiple output bins only.
Specify which output bin to use for the job when the printer output bins are congured for mailbox mode.
NOTE: This option does not appear when the output bins are congured for stacker mode or
function-separator mode.
64 Chapter 5 Copy ENWW
Paper Path
Select a specic paper path:
For printers that have an option to ip pages inside the paper path.
Image Adjustment Sharpness: Clarify or soften the image. For example, increasing the sharpness could make text appear
Optimize Text/Picture Optimize the job for the type of image being scanned: text, graphics, or photos.
Edge-to-Edge Scan and print a copy closer to the edge of the page than is normally allowed. Printing close to the
Erase Edges Remove blemishes, such as dark borders or staple marks, by cleaning the edges of the scanned image.
Collate Assemble each set of pages in the same order as the original document when making multiple copies
Automatically Straighten
Face-up (straightest path): Pages output to the bin in the opposite order that they were placed in the
document feeder.
Face-down (correct order): Pages are stacked in the same order as they were placed in the document
feeder.
crisper, but decreasing it could make photos appear smoother.
Darkness: Increase or decrease the amount of white and black used in colors in scanned images.
Contrast: Increase or decrease the dierence between the lightest and the darkest color on the page.
Background Cleanup: Remove faint colors from the background of scanned images. For example, if the
original document is printed on colored paper, use this feature to lighten the background without aecting the darkness of the image.
Automatic Tone: Available for Flow printers only. The printer automatically adjusts the Darkness, Contrast, and Background Cleanup settings to the most appropriate for the scanned document.
edge can result in some print-quality issues.
of a document.
Automatically straighten a scanned image.
NOTE: Available on Flow
models only.
This feature is not available for all rmware versions. You might need to update the printer rmware to use this feature.
Blank Page Suppression
NOTE: This feature is not
available for all rmware versions. You might need to update the printer rmware to use this feature.
Multi-feed Detection Enable or disable multi-feed detection. When enabled, scanning stops when the printer detects more
Exclude blank pages in the original document from scanned images. This feature is useful for scanning pages printed on both sides to eliminate blank pages in the resulting scanned document.
than one page at a time being fed in the document feeder. When disabled, scanning continues when a multi-feed is detected, to allow scanning pages that are stuck together, originals with self-adhesive notes on them, or thick paper.
ENWW Additional options when copying 65

Additional copy tasks

Go to www.hp.com/support/colorljE57540mfp.
Instructions are available for performing specic copy tasks, such as the following:
Copy or scan pages from books or other bound documents
Copy mixed-size documents
Copy or scan both sides of an identication card
Copy or scan a document into a booklet format
66 Chapter 5 Copy ENWW

6 Scan

For more information:

Set up Scan to Email
Set up Scan to Network Folder
Set up Scan to USB Drive
Set up Save to SharePoint® (Flow models only)
Create a Quick Set
Send a scanned document to one or more email addresses
Scan and send to network folder
Scan and save to a USB ash drive
Additional options when scanning
HP JetAdvantage business solutions
Additional scan tasks
The following information is correct at the time of publication.
For video assistance, see www.hp.com/videos/LaserJet.
For current information, see www.hp.com/support/colorljE57540mfp.
HP's all-inclusive help for the printer includes the following information:
Install and congure
Learn and use
Solve problems
Download software and rmware updates
Join support forums
Find warranty and regulatory information
ENWW For more information: 67

Set up Scan to Email

Introduction

Before you begin

Step one: Access the HP Embedded Web Server (EWS)

Step two: Congure the Network Identication settings
Step three: Congure the Send to Email feature
Step four: Congure the Quick Sets (optional)
Step ve: Set up Send to Email to use Oice 365 Outlook (optional)
Introduction
The printer has a feature that enables it to scan a document and send it to one or more email addresses. To use this scan feature, the printer must be connected to a network; however, the feature is not available until it has been congured. There are two methods for conguring Scan to Email, the Scan to Email Setup Wizard for basic and Email Setup for advanced. Use the following information to set up the Scan to Email feature.
Before you begin
To set up the Scan to Email feature, the printer must have an active network connection.
Administrators need the following information before beginning the conguration process.
Administrative access to the printer
DNS suix (e.g., companyname.com)
SMTP server (e.g., smtp.mycompany.com)
NOTE: If you do not know the SMTP server name, SMTP port number, or authentication information,
contact the email/Internet service provider or system administrator for the information. SMTP server names and port names are typically found by doing an Internet search. For example, use terms like "Gmail smtp server name" or "Yahoo smtp server name" to search.
SMTP server authentication requirements for outgoing email messages, including the user name and
password used for authentication, if applicable.
NOTE: Consult your email service provider's documentation for information on digital sending limits for your
email account. Some providers may temporarily lock your account if you exceed your sending limit.
Step one: Access the HP Embedded Web Server (EWS)
1. From the Home screen on the printer control panel, touch the Information icon, and then touch the
Network
icon to display the IP address or host name.
68 Chapter 6 Scan ENWW
2. Open a web browser, and in the address line, type the IP address or host name exactly as it displays on the
printer control panel. Press the Enter key on the computer keyboard. The EWS opens.
NOTE: If the web browser displays a message indicating that accessing the website might not be safe,
select the option to continue to the website. Accessing this website will not harm the computer.
Step two: Congure the Network Identication settings
NOTE: Conguring email setup on the Networking tab is an advanced process and might require the assistance
of a system administrator.
1. Using the EWS top navigation tabs, click Networking.
NOTE: For conguring the network settings for use with Oice 365, Step ve: Set up Send to Email to use Oice 365 Outlook (optional) on page 79
2. In the left navigation pane, click TCP/IP Settings. A username/password might be required to access the
Network Identication tab of the EWS.
3. On the TCP/IP Settings dialog, click the Network Identication tab.
ENWW Set up Scan to Email 69
4. If DNS is required on the network, in the TCP/IP Domain Suix area, verify that the DNS suix for the email
client being used is listed. DNS suixes have this format: companyname.com, gmail.com, etc.
NOTE: If the Domain Name suix is not set up, use the IP address.
5. Click Apply.
6. Click OK.
Step three: Congure the Send to Email feature
The two options for conguring Send to Email are the Email Setup Wizard for basic conguration and Email Setup for advanced conguration. Use the following options to congure the Send to Email feature:
Method one: Basic conguration using the Email Setup Wizard
Method two: Advanced conguration using the Email Setup
Method one: Basic conguration using the Email Setup Wizard
This option opens the Email Setup Wizard in the HP Embedded Web Server (EWS) for basic conguration.
1. Using the EWS top navigation tabs, click Scan/Digital Send.
2. In the left-navigation pane, click Email and Scan to Network Folder Quick Setup Wizards.
70 Chapter 6 Scan ENWW
3. In the Email and Scan to Network Folder Quick Setup Wizards dialog, click the Email Setup link.
NOTE: If a message displays indicating that the Scan to Email feature is disabled, click Continue to
proceed with the conguration and enable the Scan to Email feature upon completion.
4. On the Congure Email Servers (SMTP) dialog, select one of the following options and complete the steps:
Option one: Use a server already in use by Email
Select Use a server already in use by Email, and then click Next.
Option two: Search network for outgoing email server
NOTE: This option nds outgoing SMTP servers inside your rewall only.
a. Select Search network for outgoing email server, and then click Next.
b. Select the appropriate server from the Congure Email Server (SMTP) list, and then click Next.
c. Select the option that describes the server’s authentication requirements:
Server does not require authentication: Select Server does not require authentication, and then
click Next.
-OR-
Server requires authentication: From the drop-down list, select an authentication option:
Use credentials of user to connect after Sign In at the control panel: Select Use credentials
of user to connect after Sign In at the control panel, and then click Next.
-OR-
Always use these credentials: Select Always use these credentials, enter the User name
and Password, and then click Next.
ENWW Set up Scan to Email 71
Option three: Add SMTP server
a. Select Add SMTP server
b. Enter the Server Name and Port Number, and then click Next.
NOTE: In most cases, the default port number does not need to be changed.
NOTE: If you are using a hosted SMTP service such as Gmail, verify the SMTP address, port number,
and SSL settings from the service provider’s website or other sources. Typically, for Gmail, the SMTP address is smtp.gmail.com, port number 465, and the SSL should be enabled.
Please refer to online sources to conrm these server settings are current and valid at the time of
conguration.
c. Select the appropriate server authentication option:
Server does not require authentication: Select Server does not require authentication, and then
click Next.
-OR-
Server requires authentication: Select an option from the Server requires authentication drop-
down list:
Use credentials of user to connect after Sign In at the control panel: Select Use credentials
of user to connect after Sign In at the control panel, and then click Next.
-OR-
Always use these credentials: Select Always use these credentials, enter the User name
and Password, and then click Next.
5. On the Congure Email Settings dialog, enter the following information about for the sender’s email
address, and then click Next.
NOTE: When setting up the From, Subject, and Message elds, if the User editable check box is
unchecked, users will not be able to edit those elds at the printer control panel when sending an email.
Option Description
From
(Required)
Select one of the following options from the From drop-down list:
User’s address (sign-in required)
Default From: Enter a default email address and display name in the Default From Email
Address and Default Display Name elds
NOTE: Create an email account for the printer, and use this address for the default
email address.
NOTE: Congure the email feature so that users must sign in before using it. This
prevents users from sending an email from an address that is not their own.
72 Chapter 6 Scan ENWW
Option Description
Subject
(Optional)
Message
(Optional)
Provide a default subject line for the email messages.
Create a custom message.
To use this message for all emails sent from the printer, clear the User editable check box for Message.
6. In the Congure File Scan Settings area, set the default scanning preferences, and then click Next.
Option Description
File Type Select the default le type that the for the scanned document:
PDF
JPEG
TIFF
MTIFF
XPS
PDF/A
Color/Black Select the default color setting for the scanned document:
Color
Black
Black/Gray
Automatically detect
Quality and File Size Select the default output quality for the scanned document:
Low (small le)
Medium
High (large le)
Resolution Select the default scan resolution for the scanned document:
75 dpi
150 dpi
200 dpi
300 dpi
400 dpi
600 dpi
7. Review the Summary area, and then click Finish to complete the setup.
ENWW Set up Scan to Email 73
Method two: Advanced conguration using the Email Setup
1. Using the EWS top navigation tabs, click Scan/Digital Send, and then click Email Setup in the left navigation
pane.
NOTE: By default, the Email Setup page displays the basic settings for Scan to Email setup. To access
additional settings, click the Advanced Settings button at the bottom of the page.
2. On the Email Setup dialog, select the Enable Send to Email check box. If this check box is not selected, the
feature is unavailable at the printer control panel.
3. In the Outgoing Email Servers (SMTP) area, complete the steps for one of the following options:
Select one of the displayed servers
Click Add to start the SMTP wizard.
1. In the SMTP wizard, select one of the following options:
Option one: I know my SMTP server address or host name: Enter the address of an SMTP
server, and then click Next
Option two: If you do not know the address of the SMTP server, select Search network for
outgoing email server, and then click Next. Select the server, and then click Next.
74 Chapter 6 Scan ENWW
NOTE: If an SMTP server was already created for another printer function, the Use a server
already in use by another function option displays. Select this option, and then congure it to be used for the email function.
2. On the Set the basic information necessary to connect to the server dialog, set the options to use, and then click Next.
NOTE: Some servers have problems sending or receiving emails that are larger than 5
megabytes (MB). These problems can be prevented by entering a number in Split emails if larger than (MB).
NOTE: In most cases, the default port number does not need to be changed. However, when
using the Enable SMTP SSL Protocol option, port 587 must be used.
NOTE: If you are using Google™ Gmail for email service, select the Enable SMTP SSL Protocol
check box. Typically, for gmail, the SMTP address is smtp.gmail.com, port number 465, and the SSL should be enabled.
Please refer to online sources to conrm these server settings are current and valid at the time of conguration.
3. On the Server Authentication Requirements dialog, select the option that describes the server’s authentication requirements:
Server does not require authentication, and then click Next.
Server requires authentication
From the drop-down box, select Use credentials of user to connect after Sign In at
the control panel, and then click Next.
From the drop-down box, select Always use these credentials, enter the Username
and Password, and then click Next.
NOTE: If using a signed-in user's credentials, set email to require sign in by the user on the
printer control panel. Deny device guest access to email by clearing the check box for email in the Device Guest column in the Sign in and Permission Policies area on the Access Control dialog of the Security tab. The icon in the check box changes from a check mark to a lock.
4. On the Server Usage dialog, choose the printer functions that will send email through this SMTP server, and then click the Next button.
NOTE: If the server requires authentication, a user name and password for sending automatic
alerts and reports from the printer will be required.
5. On the Summary and Test dialog, enter a valid email address in the Send a test email to: eld, and then click Test.
6. Verify that all of the settings are correct, and then click Finish to complete the outgoing email server set up.
4. In the Address and Message Field Control area, enter a From: setting and any of the other optional settings.
Address and Message Field Control settings:
ENWW Set up Scan to Email 75
Feature Description
1
Address Field Restrictions
Specify whether users must select an email address from an address book or whether users are allowed to enter in an email address manually.
CAUTION: If Users must select from address book is selected, and any of the address elds are
also set as User editable, changes to those editable elds also change the corresponding values in the address book.
To prevent users from changing contacts in the Address Book at the printer control panel, go to the Access Control page on the Security tab, and deny Device Guest access to address book
modications.
Allow invalid email address
1
formats
Select to allow an invalid email address format.
User editable To use the Default From address and Default Display Name for all emails sent from this printer
(unless a user is signed in), do not select the User editable check box.
When setting up the address elds, if the User editable check box is unchecked, users will not be able to edit those elds at the printer control panel when sending an email. For send-to-me functionality, clear the User editable check boxes for all of the address elds, including the From: To: CC:, and BCC: elds, and then set that user's send email From: their own email address and To: their own email address.
Default From: and Default
Provide an email address and name to use for the From: address for the email message.
Display Name:
NOTE: Create an email account for the printer, and use this address for the default email
address.
NOTE: Congure the email feature so that users must sign in before using it. This prevents users
from sending an email from an address that is not their own.
To:
CC:
BCC:
1
1
1
Provide a To (recipient) email address for emails.
Provide a CC email address for emails.
Provide a BCC email address for emails.
Subject: Provide a default subject line for the email messages.
Message: Create a custom message. To use this message for all emails sent from the printer, clear or do not
select the User editable check box for Message:.
1
This setting is available only on the Advanced Settings page.
5. In the Signing and Encryption area, set the signing and encryption preferences.
NOTE: These settings are available only on the Advanced Settings page.
Signing and Encryption settings:
Feature Description
Signing Select whether to sign the security certicate.
Select the User editable check box to make this setting editable at the printer control panel.
Hashing Algorithm Select the algorithm to use for signing the certicate.
Encryption Select whether to encrypt the email.
Select the User editable check box to make this setting editable at the printer control panel.
Encryption Algorithm Select the algorithm to use for encrypting the email.
76 Chapter 6 Scan ENWW
Feature Description
Attribute for Recipient Public Key
Use the recipient public key certicate to verify the recipient
Enter which attribute to use to retrieve the recipient’s public key certicate from LDAP.
Select this setting to use the recipient’s public key certicate to verify the recipient.
6. In the Notication Settings area, select when users will receive notications about sent emails. The default
setting is using the signed in user's email address. If the recipient email address is blank, no notication is sent.
7. In the Scan Settings area, set the default scanning preferences.
NOTE: These settings are available only on the Advanced Settings page.
Scan settings:
Feature Description
Original Size Select the page size of the original document.
Original Sides Select whether the original document is single-sided or double-sided.
Optimize Text/Picture Select to optimize for the output of a particular type of content.
Content Orientation Select the way the content of the original document is placed on the page: Portrait or Landscape.
Background Cleanup Select a value to remove faint images from the background or to remove a light background color.
Darkness Select a value to adjust the darkness of the le.
Contrast Select a value to adjust the contrast of the le.
Sharpness Select a value to adjust the sharpness of the le.
Image Preview Select whether to require or make optional a displayed preview of the job or to disable a preview.
Cropping Options Select whether or not to allow a job to be cropped and the type of cropping option.
Erase Edges Select this setting to specify the width of edge margins to be erased, in either inches or
millimeters, for the front side and back side of a job.
8. In the File Settings area, set the default le settings preferences.
File settings:
Feature Description
File Name Prex
File Name Default le name for the le to be saved.
File Name Suix
File Name Preview
File Numbering Format
1
1
1
1
Set the default le name prex used for les saved to a network folder.
Select the User editable check box to make this setting editable at the printer control panel.
Set the default le name suix used for les saved to a network folder.
Duplicate lename suix default [lename]_YYYYMMDDT
Enter a le name, and then click the Update Preview button.
Select a le name format for when the job is divided into multiple les.
ENWW Set up Scan to Email 77
Feature Description
Add numbering when job has just one le (ex. _1–1)
File Type Select the le format for the saved le.
High Compression (smaller
1
le)
PDF encryption
Resolution Set the resolution for the le. Higher resolution images have more dots per inch (dpi), so they
Quality and File Size Select the quality for the le. Higher-quality images require a larger le size than lower-quality
Color/Black Specify whether copies are to be printed in color, black and gray, or black only.
Suppress blank pages
Create Multiple Files
1
This setting is available only on the Advanced Settings page.
1
1
1
1
Select this setting to add numbering to a le name when the job is only one le instead of multiple
les.
Select the User editable check box to make this setting editable at the printer control panel.
Select this setting to compress the scanned le, which reduces the le size. However, the scanning process for a High compression le might take longer than for a Normal compression le.
If the le type is PDF, then this option encrypts the output PDF le. A password must be specied as part of the encryption. The same password must be used to open the le. The user will be prompted to enter a password prior to scanning their job if one has not been set prior to pressing start.
show more detail. Lower resolution images have fewer dots per inch and show less detail, but the le size is smaller.
images, and they take more time to send.
If the Suppress blank pages option is enabled, blank pages will be ignored.
Select this setting to scan pages into separate les based on a predetermined maximum number of pages per le.
9. Review the selected options to verify that they are accurate, and then click Apply to complete the setup.
Step four: Congure the Quick Sets (optional)
Quick Sets are optional short-cut jobs that can be accessed on the main Home screen or within the Quick Sets application at the printer.
1. In the Email Setup area of the left navigation pane, click Quick Sets.
2. Select one of the following options:
Select an existing Quick Set under Quick Sets Application in the table.
-OR-
Click Add to start the Quick Set Wizard.
3. If you selected Add, the Quick Sets Setup page opens. Complete the following information:
Quick Set Name: Enter a title for the new Quick Set.
Quick Set Description: Enter a description of the Quick Set.
Quick Set Start Option: To set how the Quick Set starts, click either Enter application, then user
presses Start or Start instantly when selected from the Home Screen.
4. Dene the following settings for the Quick Set: Address and Message Field Control, Signing and Encryption,
Notication Settings, Scan Settings, File Settings.
5. Click Finish to save the Quick Set.
78 Chapter 6 Scan ENWW
Step ve: Set up Send to Email to use Oice 365 Outlook (optional)
Introduction
Microsoft Oice 365 Outlook is a cloud-based email system provided by Microsoft which uses Microsoft's Simple Mail Transfer Protocol (SMTP) server to send or receive emails. Complete the following to enable the printer to send an email with an Oice 365 Outlook account from the control panel.
NOTE: You must have an email address account with Oice 365 Outlook to congure the settings in the EWS.
Congure the outgoing email server (SMTP) to send an email from an Oice 365 Outlook account
1. Using the EWS top navigation tabs, click Networking.
2. In the left navigation pane, click TCP/IP Settings.
3. In the TCP/IP Settings area, click the Network Identication tab.
4. If DNS is required on the network, in the TCP/IP Domain Suix area, verify that the DNS suix for the email
client being used is listed. DNS suixes have this format: companyname.com, Gmail.com, etc.
NOTE: If the Domain Name suix is not set up, use the IP address.
5. Click Apply.
6. Click the Scan/Digital Send tab.
7. On the left navigation pane, click Email Setup.
ENWW Set up Scan to Email 79
8. On the Email Setup page, select the Enable Send to Email check box. If this check box is not available, the
feature is unavailable at the printer control panel.
9. In the Outgoing Email Servers (SMTP) area, click Add to start the SMTP wizard.
10. In the I know my SMTP server address or host name eld, type smtp.onoice.com, and then click Next.
11. On the Set the basic information necessary to connect to the server dialog, in the Port Number eld, type
587.
NOTE: Some servers have problems sending or receiving emails that are larger than 5 megabytes (MB).
These problems can be prevented by entering a number in Split emails if larger than (MB).
12. Select the Enable SMTP SSL Protocol check box, and then click Next.
13. On the Server Authentication Requirements dialog, complete the following information:
a. Select Server requires authentication.
b. From the drop-down list, select Always use these credentials
c. In the Username eld, type the Oice 365 Outlook email address.
d. In the Password eld, type the Oice 365 Outlook account password, and then click Next.
14. On the Server Usage dialog, choose the printer functions that will send email through this SMTP server, and
then click the Next button.
15. On the Summary and Test dialog, enter a valid email address in the Send a test email to: eld, and then click
Test.
16. Verify that all of the settings are correct, and then click Finish to complete the outgoing email server set up.
80 Chapter 6 Scan ENWW

Set up Scan to Network Folder

Introduction

Before you begin

Step one: Access the HP Embedded Web Server

Step two: Set up Scan to Network Folder
Introduction
This document explains how to enable and congure the Scan to Network Folder function. The printer has a feature that enables it to scan a document and save it to a network folder. To use this scan feature, the printer must be connected to a network; however, the feature is not available until it has been congured. There are two methods for conguring Scan to Network Folder, the Save to Network Folder Setup Wizard for basic setup and Save to Network Folder Setup for advanced setup.
Before you begin
NOTE: To set up the Scan to Network Folder feature, the printer must have an active network connection.
Administrators need the following items before beginning the conguration process.
Administrative access to the printer
The fully-qualied domain name (FQDN) (e.g., \\servername.us.companyname.net\scans) of the
destination folder OR the IP address of the server (e.g., \\16.88.20.20\scans).
NOTE: The use of the term "server" in this context refers to the computer where the shared folder resides.
Step one: Access the HP Embedded Web Server
1. From the Home screen on the printer control panel, touch the Information icon, and then touch the
Network icon to display the IP address or host name.
2. Open a web browser, and in the address line, type the IP address or host name exactly as it displays on the
printer control panel. Press the Enter key on the computer keyboard. The EWS opens.
NOTE: If the web browser displays a message indicating that accessing the website might not be safe,
select the option to continue to the website. Accessing this website will not harm the computer.
ENWW Set up Scan to Network Folder 81

Step two: Set up Scan to Network Folder

Method one: Use the Scan to Network Folder Wizard
This option opens the setup wizard that is in the HP Embedded Web Server (EWS) for the printer. The setup wizard includes the options for basic conguration.
NOTE: Before you begin: To display the printer's IP address or host name, touch the Information icon, and
then touch the Network icon on the printer's control panel.
1. Using the EWS top navigation tabs, click Scan/Digital Send tab. The Email and Scan to Network Folder Quick
Setup Wizards dialog opens.
2. In the left-navigation pane, click Email and Scan to Network Folder Quick Setup Wizards.
3. Click the Save to Network Folder Quick Set Wizard link.
4. On the Add or Remove a Save to Network Folder Quick Set dialog, click Add.
NOTE: Quick Sets are short-cut jobs that can be accessed on the printer Home screen or within the Quick
Sets application.
NOTE: The Save to Network Folder feature can be minimally congured without creating a quick set.
However, without the quick set, users must enter the destination folder information at the control panel for each scan job. A quick set is required to include Save to Network Folder metadata.
5. On the Add Folder Quick Set dialog, complete the following information:
a. In the Quick Set Title eld, type a title.
82 Chapter 6 Scan ENWW
NOTE: Name the Quick Set something that users can understand quickly (e.g., "Scan and save to a
folder").
b. In the Quick Set Description eld, type a description explaining what the Quick Set will save.
c. Click Next.
6. On the Congure Destination Folder dialog, complete the following information:
a. In the UNC Folder Path eld, type a folder path where the scan will go.
The folder path can either be the fully-qualied domain name (FQDN) (e.g., \ \servername.us.companyname.net\scans) or the IP address of the server (e.g., \\16.88.20.20\scans). Be sure that the folder path (e.g., \scans) follows the FQDN or IP address.
NOTE: The FQDN can be more reliable than the IP address. If the server gets its IP address via DHCP,
the IP address can change. However, the connection with an IP address might be faster because the printer does not need to use DNS to nd the destination server.
b. From the Authentication Settings drop-down, select one of the following options:
Use credentials of user to connect after Sign In at the control panel
Always use these credentials
NOTE: If Always use these credentials is selected, a user name and password must be entered
in the corresponding elds, and the printer’s access to the folder must be veried by clicking Verify Access.
c. In the Windows Domain eld, type the Windows domain.
TIP: To nd the Windows domain in Windows 7, click Start, click Control Panel, click System.
To nd the Windows domain in Windows 8, click Search, enter System in the search box, and then click System.
The domain is listed under Computer name, domain, and workgroup settings.
d. Click Next.
7. On the Congure File Scan Settings dialog, set the default scanning preferences for the Quick Set, and then
click Next.
8. Review the Summary dialog, and then click Finish.
Method two: Use Scan to Network Folder Setup
This option enables advanced conguration of the Save to Network Folder feature using the HP Embedded Web Server (EWS) for the printer.
NOTE: Before you begin: To display the printer's IP address or host name, touch the Information icon, and
then touch the Network icon on the printer's control panel.
Step one: Begin the conguration
1. Click the Scan/Digital Send tab.
2. On the left navigation menu, click the Scan to Network Folder Setup link.
ENWW Set up Scan to Network Folder 83
Step two: Congure the Scan to Network Folder settings
1. On the Scan to Network Folder Setup page, select the Enable Scan to Network Folder check box. If this box
is not selected, the feature is unavailable at the printer control panel.
2. In the Scan to Network Folder area of the left navigation pane, click Quick Sets. Click Add to open the Quick
Sets Setup dialog.
NOTE: Quick Sets are short-cut jobs that can be accessed on the printer Home screen or within the Quick
Sets application.
NOTE: The Scan to Network Folder feature can be minimally congured without creating a quick set.
However, without the quick set, users must enter the destination folder information at the control panel for each scan job. A quick set is required to include Scan to Network Folder metadata.
Complete all of the settings in the Quick Set Setup to fully congure the Scan to Network Folder feature.
Dialog one: Set the Quick Set name, description, and options for user interaction at the control panel
Use the Set the button location for the Quick Set and options for user interaction at the control panel dialog to congure where the Quick Set button will display on the printer control panel and to congure the level of user interaction at the printer control panel.
1. In the Quick Set Name eld, type a title.
NOTE: Name the Quick Set something that users can understand quickly (e.g., "Scan and save to a
folder").
2. In the Quick Set Description eld, type a description explaining what the Quick Set will save.
3. From the Quick Set Start Option list, select one of the following options:
Option one: Enter application, then user presses Start
Option two: Start instantly upon selection
Select one of the following prompt options :
Prompt for original sides
Prompt for additional pages
Require Preview
NOTE: If Start instantly upon selection is selected, the destination folder must be entered in the next
step.
4. Click Next.
Dialog two: Folder Settings
Use the Folder Settings dialog to congure the types of folders the printer sends scanned documents to.
There are two types of destination folders to select from:
Shared folders or FTP folders
Personal shared folders
84 Chapter 6 Scan ENWW
There are two types of folder permissions to select from:
Read and write access
Write access only
The following information describes how to congure the folder settings.
Congure the destination folder for scanned documents
Option 1: Shared folders or FTP folders
To save scanned documents to a standard shared folder or an FTP folder, complete the following steps:
1. If it is not already selected, select Save to shared folders or FTP folders.
2. Click Add.... The Add Network Folder Path dialog opens.
3. On the Add Network Folder Path dialog, select one of the following options:
Option one: Save to a standard shared network folder
ENWW Set up Scan to Network Folder 85
NOTE: For more information about creating shared network folders see Set up a shared folder
(c04431534).
1. If it is not already selected, select Save to a standard shared network folder.
2. In the UNC Folder Path eld, type a folder path.
The folder path can either be the fully-qualied domain name (FQDN) (e.g., \ \servername.us.companyname.net\scans) or the IP address of the server (e.g., \ \16.88.20.20\scans). Be sure that the folder path (e.g., \scans) follows the FQDN or IP address.
NOTE: The FQDN can be more reliable than the IP address. If the server gets its IP address via
DHCP, the IP address can change. However, the connection with an IP address might be faster because the printer does not need to use DNS to nd the destination server.
3. To automatically create a subfolder for scanned documents in the destination folder, select a format for the subfolder name from the Custom Subfolder list.
To restrict the subfolder access to the user who creates the scan job, select Restrict subfolder access to user.
4. To view the complete folder path for scanned documents, click Update Preview.
5. From the Authentication Settings list, select one of the following options:
Use credentials of user to connect after Sign In at the control panel
Always use these credentials
NOTE: If Always use these credentials is selected, a user name and password must be entered
in the corresponding elds.
6. In the Windows Domain eld, type the Windows domain.
86 Chapter 6 Scan ENWW
NOTE: To nd the Windows domain in Windows 7, click Start, click Control Panel, click System.
To nd the Windows domain in Windows 8, click Search, enter System in the search box, and then click System.
The domain is listed under Computer name, domain, and workgroup settings.
NOTE: If a shared folder is set to be accessed by everyone, values for a workgroup name
(default is “Workgroup”), a user name and password must be entered in the corresponding elds. However, if the folder is within a particular user’s folders and not Public, the user name and password of that user must be used.
NOTE: An IP address might be necessary instead of a computer name. Many home routers do
not handle computer names well, and there is no Domain Name Server (DNS). In this case, it is best to set up a static IP address on the shared PC to alleviate the problem of DHCP assigning a new IP address. On a typical home router, this is done by setting a static IP address that is on the same subnet, but outside the DHCP address range.
7. Click OK.
Option two: Save to an FTP Server
NOTE: If an FTP site is outside the rewall, a proxy server must be specied under the network
settings These settings are located in the EWS Networking tab, under the Advanced options.
1. Select Save to an FTP Server.
2. In the FTP Server eld, type the FTP server name or IP address.
3. In the Port eld, type the port number.
NOTE: In most cases, the default port number does not need to be changed.
ENWW Set up Scan to Network Folder 87
4. To automatically create a subfolder for scanned documents in the destination folder, select a format for the subfolder name from the Custom Subfolder list.
5. To view the complete folder path for scanned documents, click Update Preview.
6. From the FTP Transfer Mode list, select one of the following options:
Passive
Active
7. In the Username eld, type the user name.
8. In the Password eld, type the password.
9. Click Verify Access to conrm the destination can be accessed.
10. Click OK.
Option 2: Personal shared folders
To save scanned documents to a personal shared folder, complete the following steps:
NOTE: This option is used in domain environments where the administrator congures a shared folder for each
user. If the Save to a personal shared folder feature is congured, users will be required to sign in at the printer control panel using Windows credentials or LDAP authentication.
1. Select Save to a personal shared folder.
2. In the Retrieve the device user’s home folder using this attribute eld, type the user’s home folder in the
Microsoft Active Directory.
NOTE: Verify that the user knows where this home folder is located on the network.
3. To add a user name subfolder at the end of the folder path, select Create subfolder based on user name.
To restrict the subfolder access to the user who creates the scan job, select Restrict subfolder access to user.
Select the destination folder permissions
Option 1: Read and write access
To send scanned documents to a folders congured for read and write access, complete the following steps:
NOTE: Send only to folders with read and write access supports folder verication and job notication
1. If it is not already selected, select Send only to folders with read and write access.
2. To require the printer to verify folder access before starting a scan job, select Verify folder access prior to
job start.
NOTE: Scan jobs can complete more quickly if Verify folder access prior to job start is not selected;
however, if the folder is unavailable, the scan job will fail.
3. Click Next.
Option 2: Write access only
88 Chapter 6 Scan ENWW
To send scanned documents to a folder congured for write access only, complete the following steps:
NOTE: Allow sending to folders with write access only does not support folder verication or job notication
NOTE: If this option is selected, the printer cannot increment the scan lename. It sends the same lename for
all scans.
Select a time-related lename prex or suix for the scan lename, so that each scan is saved as a unique le, and does not overwrite a previous le. This lename is determined by the information in the File Settings dialog in the Quick Set Wizard.
1. Select Allow sending to folders with write access only.
2. Click Next.
Dialog three: Notication settings
On the Notication Settings dialog, complete one of the following tasks:
NOTE: In order to send notication emails, the printer must be set up to use an SMTP server for sending
email jobs. For more information about setting up the SMTP server for sending emails see Set up Scan to
Email (c04017973).
Option one: Do not notify
1. Select Do not notify.
2. To prompt the user to review their notication settings, select Prompt user prior to job start, and then click Next.
Option two: Notify when job completes
1. Select Notify when job completes.
2. Select the method for delivering the notication from the Method Used to Deliver Notication list.
If the method of notication selected is Email, type the email address in the Notication Email Address eld.
3. To include a thumbnail of the rst scanned page in the notication, select Include Thumbnail.
4. To prompt the user to review their notication settings, select Prompt user prior to job start, and then click Next.
Option three: Notify only if job fails
1. Select Notify only if job fails.
2. Select the method for delivering the notication from the Method Used to Deliver Notication list.
If the method of notication selected is Email, type the email address in the Notication Email Address eld.
3. To include a thumbnail of the rst scanned page in the notication, select Include Thumbnail.
4. To prompt the user to review their notication settings, select Prompt user prior to job start, and then click Next.
ENWW Set up Scan to Network Folder 89
Dialog four: Scan Settings
On the Scan Settings dialog, set the default scanning preferences for the Quick Set, and then click Next.
Scan settings:
Feature Description
Original Size Select the page size of the original document.
Original Sides Select whether the original document is single-sided or double-sided.
Optimize Text/Picture Select to optimize for the output of a particular type of content.
Content Orientation Select the way the content of the original document is placed on the page: Portrait or Landscape.
Background Cleanup Select a value to remove faint images from the background or to remove a light background color.
Darkness Select a value to adjust the darkness of the le.
Contrast Select a value to adjust the contrast of the le.
Sharpness Select a value to adjust the sharpness of the le.
Image Preview Select whether to require or make optional a displayed preview of the job or to disable a preview.
Cropping Options Select whether or not to allow a job to be cropped and the type of cropping option.
Erase Edges Select this setting to specify the width of edge margins to be erased, in either inches or millimeters, for
the front side and back side of a job.
Dialog ve: File Settings
On the File Settings dialog, set the default le settings for the Quick Set, and then click Next.
File settings:
Feature Description
File Name Prex Set the default le name prex used for les saved to a network folder.
File Name Default le name for the le to be saved.
File Name Suix Set the default le name suix used for les saved to a network folder.
File Name Preview Enter a le name, and then click the Update Preview button.
File Numbering Format Select a le name format for when the job is divided into multiple les.
Add numbering when job has just one le (ex. _1–1)
File Type Select the le format for the saved le.
High Compression (smaller le) Select this setting to compress the scanned le, which reduces the le size. However, the scanning
Select the User editable check box to make this setting editable at the printer control panel.
Select this setting to add numbering to a le name when the job is only one le instead of multiple les.
Select the User editable check box to make this setting editable at the printer control panel.
process for a High compression le might take longer than for a Normal compression le.
PDF encryption If the le type is PDF, then this option encrypts the output PDF le. A password must be specied as
part of the encryption. The same password must be used to open the le. The user will be prompted to enter a password prior to scanning their job if one has not been set prior to pressing start.
90 Chapter 6 Scan ENWW
