introducing the hp deskjet printer
what’s in the box
printer cables
english
Thank you for buying an HP Deskjet
printer! Your printer box contains the
following items:
• HP Deskjet printer (948c series,
940c series, or 920c series)
• Power c o rd
• Printer software CD
• quick reference guide
• quick start poster
• Black print cartridge
• Tri-Color print cartridge
If any of these items is missing from your
box, talk to your HP dealer or contact
HP Customer Care. See “contacting hp
customer care” for more information.
print cartridges
The HP Deskjet printer box includes both
a black and a color print cartridge. Each
print cartridge box, and the electronic
quick help manual, contains installation
instructions.
When you replace a print cartridge,
verify that you have the correct part
number:
A printer cable is not included in the
box. Purchase one of the following
cables to connect the printer to your
computer:
• An IEEE 1284-compliant parallel
interface cable which is used with all
Windows systems
• A USB-compliant interface cable
which is used with both Macintosh
systems and Windows 98, Me, NT
and 2000 systems
software updates
Printer software, also called the printer
driver, communicates your print requests
to the printer. Use either of the following
methods to obtain copies and updates of
the printer software:
• Download the printer software from
HP’s Website.
• Phone HP Customer Care to request a
CD containing the software update
files.
See “contacting hp customer care” for
Customer Care telephone numbers and
Website addresses.
• Black—
• Tri-Color—HP
HP 15 (6615A)
78
(C6578)
1
getting help
quick help
english
The electronic manual, quick help, offers
instructions for using the HP Deskjet
printer. Information is also provided to
help you solve printer problems that may
occur.
Windows 95, 98, Me, 2000, and
NT 4.0 users
Open quick help through the hp printer
assistant, a tool that also provides:
• Support through HP’s Customer Care
• Printing ideas
• Shopping links to other HP products
• Links to printer software updates
A printer assistant icon is displayed on
the Windows desktop after you install
the printer software.
accessing
To view quick help:
1.
Double-click the
icon on your computer desktop
The hp printer assistant appears.
2.
Click the
the manual’s topics.
You can also open quick help from the
Start menu by clicking
hp deskjet series
>
quick help
quick help
quick help
.
hp printer assistant
button to display
Start
printer assistant
>
Programs
>
Adobe Acrobat versions of
The quick help manual is also available
in the following languages:
• Arabic
• Bulgarian
• Bahasa Indonesia
• Croatian
• Estonian
• Greek
• Hebrew
• Kazakh
• Lithuanian
• Romanian
• Slovak
• Slovene
• Turkish
If you want to view the manual in one of
these languages:
1.
Double-click the
icon on your computer desktop
.
>
2.
Click the
printer assistant screen.
3.
4.
quick help is available in other
Select
languages
help screen.
Insert the printer software CD into the
computer’s CD-ROM drive.
hp printer assistant
quick help
at the bottom of the quick
quick help
.
button in the hp
2
5.
Select your language from the list that
appears.
–
If Acrobat Reader is installed on
your computer, quick help is
displayed.
–
If Acrobat Reader is not installed on
your computer, it installs
automatically. quick help is then
displayed.
Macintosh users
On Macintosh computers, Adobe
Acrobat Reader is required to view the
quick help manual. If you do not have
Acrobat Reader, install it from the printer
software CD.
To open quick help:
1.
Insert the printer software CD into the
computer’s CD-ROM drive.
The
hp deskjet screen appears.
2.
Select the
language.
3.
Do one of the following:
–
Double-click the
Manual
installed on your computer
–or–
–
Double-click the
Installer
not installed on your computer.
Adobe Acrobat Reader installs
automatically. After it is installed,
double-click the
icon to display quick help.
User Manual
folder for your
Electronic User
icon if Acrobat Reader is
Acrobat Reader
icon if Acrobat Reader is
Electronic User Manual
getting help in DOS
In DOS operating systems, information
about the HP Deskjet printer is found in a
text document called dosread.txt. This
file is located on the printer software CD
in the \<
directory. For <language code>
substitute the relevant code from the list
below. To read the file in English, for
example, open dosread.txt in the
