HP Deskjet 3055A User Guide
HP Deskjet 3050A J611 series
Contents
1How Do I?.................................................................................................................................................................................................3
2 Get to know the HP All-in-One
Printer parts...............................................................................................................................................................................................5
Control panel features...............................................................................................................................................................................6
Wireless Settings.......................................................................................................................................................................................6
Status Lights..............................................................................................................................................................................................7
Auto Power-Off ........................................................................................................................................................................................8
3Print
Print photos...............................................................................................................................................................................................9
Print documents.......................................................................................................................................................................................10
Print Quick Forms...................................................................................................................................................................................11
Print envelopes........................................................................................................................................................................................11
Tips for print success...............................................................................................................................................................................11
4 ePrint from anywhere
ePrint from anywhere..............................................................................................................................................................................15
5Paper basics
Recommended papers for printing..........................................................................................................................................................17
Load media..............................................................................................................................................................................................18
6 Copy and scan
Copy........................................................................................................................................................................................................23
Scan to a computer..................................................................................................................................................................................24
Tips for copy success..............................................................................................................................................................................26
Tips for scan success...............................................................................................................................................................................26
7 Work with cartridges
Check the estimated ink levels................................................................................................................................................................27
Order ink supplies...................................................................................................................................................................................27
Replace the cartridges.............................................................................................................................................................................28
Use single-cartridge mode.......................................................................................................................................................................30
Cartridge warranty information...............................................................................................................................................................30
8 Connectivity
Wi-Fi Protected Setup (WPS – requires WPS router).............................................................................................................................31
Traditional wireless connection (requires router)...................................................................................................................................32
USB Connection (non-network connection)...........................................................................................................................................32
Change from a USB connection to a wireless network...........................................................................................................................32
Connect a new printer.............................................................................................................................................................................33
Change wireless network settings...........................................................................................................................................................33
Tips for setting up and using a networked printer...................................................................................................................................33
Advanced printer management tools (for networked printers)...............................................................................................................33
9 Solve a problem
Improve print quality...............................................................................................................................................................................35
Clear a paper jam.....................................................................................................................................................................................36
Unable to print.........................................................................................................................................................................................38
Networking..............................................................................................................................................................................................42
HP support...............................................................................................................................................................................................42
10 Technical information
Notice......................................................................................................................................................................................................45
Specifications..........................................................................................................................................................................................45
Environmental product stewardship program.........................................................................................................................................47
1
Regulatory notices...................................................................................................................................................................................49
Index..............................................................................................................................................................................................................55
2
1 How Do I?
Learn how to use your HP All-in-One
Printer parts
•
Load media
•
Replace the cartridges
•
Clear a paper jam
•
How Do I? 3
Chapter 1
4How Do I?
2 Get to know the HP All-in-One
Printer parts
•
Control panel features
•
Wireless Settings
•
Status Lights
•
Auto Power-Off
•
Printer parts
1 Input tray
2 Paper-width guide for the input tray
3 Control panel
4 Cartridge door
5 Output tray
6 Output tray extender (also referred to as the tray extender)
7 Cartridges
Get to know the HP All-in-One 5
Chapter 2
Control panel features
Control panel features
1
Back: Returns to the previous screen.
2
Cancel: Stops the current operation, restores default settings.
3
Setup: Opens the Setup menu where you can check ink levels, change Auto Power-Off setting, perform maintenance tasks, and set
language and region settings.
4 Selection buttons: Use buttons to select menu items on the printer display.
5
Wireless status light and button: Blue light indicates wireless connection. Pressing button opens wireless menu.
6
ePrint light and button: White light indicates ePrint is connected. Pressing button displays printer's email address and ePrint menu options.
7 On button
Wireless Settings
Press the Wireless button to view wireless status and menu options.
•
If the printer has an active connection to a wireless network, the printer display will show Connected and the printer’s IP
address.
•
If wireless is disabled (wireless radio off) and the wireless network is not available, the display screen shows Wireless
Off.
If wireless is enabled (wireless radio on) and you do not have a wireless connection , the display screen shows that it is
•
either in the process of Connecting or Not Connected.
You can use the printer display to retrieve information about your wireless network, establish a wireless connection, and more.
How do I? Instructions
Print network configuration page.
The network configuration page will display the network status, hostname,
network name, and more.
Print wireless network test report.
The wireless network test report will display the diagnostics results for the status
of the wireless network, wireless signal strength, detected networks, and more.
6 Get to know the HP All-in-One
1. Press the Wireless button to display the Wireless
Menu.
2. From the Wireless Menu, select Print Reports.
3. From the Print Reports menu select
Configuration.
1. Press the Wireless button to display the Wireless
Menu.
2. From the Wireless Menu, select Print Reports.
3. From the Print Reports menu select Wireless
Test.
(continued)
How do I? Instructions
View signal strength of wireless connection.
Restore network settings to default settings.
The printer will disconnect from the network. To reconfigure the wireless printer
settings, see Connect a new printer.
Turn wireless on or off.
Establish a Wi-Fi Protected Setup (WPS) connection. Wi-Fi Protected Setup (WPS – requires WPS router)
Status Lights
1. Press the Wireless button to display the Wireless
Menu.
2. From the Wireless Menu, select Connected IP
XXX.XXX.XX.XX.
Printer display will show wireless signal strength.
3.
1. Press the Wireless button to display the Wireless
Menu.
2. From the Wireless Menu, select Settings.
3. From the Settings menu, select Restore Defaults.
Confirm selection to restore defaults.
4.
1. Press the Wireless button to display the Wireless
Menu.
2. From the Wireless Menu, select Wireless
Settings.
3. From the Settings menu, select Wireless On/Off.
4. From the Wireless On/Off menu select On or
Off.
Wireless Status Light
•
ePrint Status Light
•
On Button Light
•
Wireless Status Light
Light behavior Solution
Off
Slow blinking Wireless is on but not connected to a network. If
Fast blinking Wireless error has occurred. Refer to messages on
On Wireless connection has been established and you can
ePrint Status Light
Wireless is off. Press Wireless button to access wireless
menu on the printer display. Use wireless menu to
enable wireless printing.
connection cannot be established, make sure printer is
within range of wireless signal.
printer display.
print.
Status Lights 7
Chapter 2
Light behavior Solution
Off
On ePrint is on and connected.
On Button Light
Light behavior Solution
Off The device is powered off.
Pulsing Indicates the device is in sleep mode. The device
Fast blinking Error has occurred. Refer to messages on printer display.
On Printer is on and ready to print.
Auto Power-Off
Auto Power-Off is automatically enabled by default when you turn on the printer. When Auto Power-Off is enabled, the printer
automatically turns off after 2 hours of inactivity to help reduce energy use. Auto Power-Off is automatically disabled when
the printer establishes a wireless or Ethernet (if supported) network connection. You can change the Auto Power-Off setting
from the control panel. Once you change the setting, the printer maintains the setting. Auto Power-Off turns the printer off
completely, so you must use the power button to turn the printer back on.
ePrint is disabled. Press ePrint button to access ePrint
menu on the printer display.
automatically enters sleep mode after 5 minutes of
inactivity.
To change Auto Power-Off setting
1. From the Control Panel home screen, which displays Copy, Scan, and Quick Forms, press the Setup button.
NOTE: If you do not see the home screen, press the Back button until you can see it.
2. From the Setup menu on the printer display, select Auto Power-Off.
3. From the Auto Power-Off menu select Enabled or Disabled, and then confirm the setting.
TIP: If you are printing over a wireless or Ethernet connected network, Auto Power-Off should be disabled to ensure that
print jobs do not get lost. Even when Auto Power-Off is disabled, the printer enters Sleep mode after 5 minutes of inactivity
to help reduce energy use.
8 Get to know the HP All-in-One
3Print
Choose a print job to continue.
See Tips for print success for more information.
Print photos
Print documents
Print envelopes
Print Quick Forms
Print photos
To print a photo on photo paper
Make sure the output tray is open.
1.
Make sure you have paper loaded in the input tray.
2.
See Load media for more information.
3. On the File menu in your software application, click Print.
Make sure the product is the selected printer.
4.
5. Click the button that opens the Properties dialog box.
Depending on your software application, this button might be called Properties, Options, Printer Setup, Printer, or
Preferences.
Select the appropriate options.
6.
•
On Layout tab select Portrait or Landscape orientation.
•
On Paper/Quality tab select the appropriate paper type and print quality from the Media drop-down list and select
the appropriate paper size from the Paper Size drop-down list.
Print 9
Chapter 3
NOTE: For maximum dpi resolution, go to the Paper/Quality tab and select Photo Paper, Best Quality from the
Media drop-down list. Then go to the Advanced tab and select Yes from the Print in Max DPI drop-down list. If you
want to print Max DPI in grayscale, select High Quality Grayscale from Print in Grayscale on the drop-down list,
and then select Max DPI, after selecting Photo Paper, Best Quality.
7. Click OK to return to the Properties dialog box.
8. Click OK, and then click Print or OK in the Print dialog box.
NOTE: Do not leave unused photo paper in the input tray. The paper might start to curl, which could reduce the quality
of your printout. Photo paper should be flat before printing.
Print documents
To print a document
Make sure the paper output tray is open.
1.
Make sure you have paper loaded in the input tray.
2.
See Load media for more information.
3. From your software application, click the Print button.
Make sure the product is the selected printer.
4.
5. Click the button that opens the Properties dialog box.
Depending on your software application, this button might be called Properties, Options, Printer Setup, Printer, or
Preferences.
Select the appropriate options.
6.
•
On Layout tab select Portrait or Landscape orientation.
•
On Paper/Quality tab select the appropriate paper type and print quality from the Media drop-down list and select
the appropriate paper size from the Paper Size drop-down list.
7. Click OK to close the Properties dialog box.
8. Click Print or OK to begin printing.
NOTE: 1 You can print your document on both sides of the paper, instead of just one side. Click on the Advanced button
on the Paper/Quality or Layout tab. From the Pages to Print drop-down menu select Print Odd Pages Only. Click OK
to print. After the odd numbered pages of the document have been printed, remove the document from the output tray.
Reload the paper in the input tray with the blank side facing up. Return to the Pages to Print drop-down menu and then
select Print Even Pages Only. Click OK to print.
NOTE: 2 If your printed documents are not aligned within the margins of the paper, make sure that you have selected the
correct language and region. On the printer display, select Setup, then select Language/Region. Select your language, and
then region from the options provided. The correct Language/Region settings ensure that the printer will have the
appropriate default paper size settings.
10 Print
Print Quick Forms
Use Quick Forms to print Office Forms, Paper Types, and Games.
Print Quick Forms
1. Select Quick Forms from the printer display menu.
TIP: If the Quick Forms option does not appear on the printer display menu, press the Back button until the Quick
Forms option appears.
2. Press the selection buttons to select Office Forms, Paper Type, or Games. Then select OK.
3. After you have selected the type of form that you want to print, select the number of copies, then press OK.
Print envelopes
You can load one or more envelopes into the input tray of the HP All-in-One. Do not use shiny or embossed envelopes or
envelopes that have clasps or windows.
NOTE: For specific details on how to format text for printing on envelopes, consult the help files in your word processing
software. For best results, consider using a label for the return address on envelopes.
To print envelopes
Make sure the output tray is open.
1.
Slide the paper guide all the way to the left.
2.
Place the envelopes in the right side of the tray. The side to be printed on should face up. The flap should be on the left
3.
side.
See
Load media for more information.
Push the envelopes into the printer until they stop.
4.
Slide the paper guide firmly against the edge of the envelopes.
5.
6. Click the button that opens the Properties dialog box.
Depending on your software application, this button might be called Properties, Options, Printer Setup, Printer, or
Preferences.
Select the appropriate options.
7.
•
On Paper/Quality tab select the appropriate paper type and print quality from the Media drop-down list and select
the appropriate paper size from the Paper Size drop-down list.
8. Click OK, and then click Print or OK in the Print dialog box.
Tips for print success
To successfully print, the HP cartridges should be functioning properly with sufficient ink, the paper should be loaded correctly,
and the product should have the appropriate settings.
Tips for print success 11
Chapter 3
Ink tips
Use genuine HP ink cartridges.
•
Install both the black and tri-color cartridges correctly.
•
For more information, see
Check the estimated ink levels in the cartridges to make sure there is sufficient ink.
•
For more information, see
For more information, see
•
If you are seeing ink smears on the back of the pages that you printed, use the Tools menu on the printer display to clean.
•
◦
From the home screen, which displays Copy, Scan, and Quick Forms, press the Setup button.
Replace the cartridges.
Check the estimated ink levels.
Improve print quality.
NOTE: If you do not see the home screen, press the Back button until you can see it.
◦
Scroll through the Tools menu until you see Clean Ink Smear, then select OK.
Follow the onscreen instructions.
◦
Paper loading tips
Load a stack of paper (not just one page). All of the paper in the stack should be the same size and type to avoid a paper
•
jam.
Load paper with side to be printed on facing up.
•
Ensure that paper loaded in the paper tray lays flat and the edges are not bent or torn.
•
Adjust the paper-width guides in the paper tray to fit snugly against all paper. Make sure the paper-width guide does not
•
bend the paper in the paper tray.
For more information, see
•
Load media.
Printer settings tips
•
On the Paper/Quality tab of the print driver, select the appropriate paper type and print quality from the Media drop-down
list.
•
Select the appropriate size from the Paper Size drop-down list on the Paper/Quality tab.
•
Click the HP All-in-One desktop icon to open the Printer Software. In the Printer Software, click Printer Actions and then
click Set Preferences to access the print driver.
NOTE: You can also access the Printer Software by clicking Start > Programs > HP > HP Deskjet 3050A J611
series > HP Deskjet 3050A J611 series
Notes
Genuine HP ink cartridges are designed and tested with HP printers and papers to help you easily produce great results,
•
time after time.
NOTE: HP cannot guarantee the quality or reliability of non-HP supplies. Product service or repairs required as a result
of using a non-HP supply will not be covered under warranty.
If you believe you purchased genuine HP ink cartridges, go to:
www.hp.com/go/anticounterfeit
Ink level warnings and indicators provide estimates for planning purposes only.
•
NOTE: When you receive a low-ink warning message, consider having a replacement cartridge available to avoid
possible printing delays. You do not need to replace the cartridges until print quality becomes unacceptable.
Software settings selected in the print driver only apply to printing, they do not apply to copying or scanning.
•
12 Print
You can print your document on both sides of the paper, instead of just one side.
•
NOTE: Click the Advanced button on the Paper/Quality or Layout tab. From the Pages to Print drop-down list
select Print Odd Pages Only. Click OK to print. After the odd numbered pages of the document have been printed,
remove the document from the output tray. Reload the paper in the input tray with the blank side facing up. Return to
the Pages to Print drop-down list and then select Print Even Pages Only. Click OK to print.
Print using black ink only
•
NOTE: If you want to print a black and white document using black ink only, click the Advanced button. From the
Print in Grayscale drop-down menu select Black Ink Only, then click the OK button.
Print using the maximum dpi
Use maximum dots per inch (dpi) mode to print high-quality, sharp images on photo paper.
See technical specifications for the print resolution of the maximum dpi mode.
Printing in maximum dpi takes longer than printing with other settings and requires a large amount of disk space.
To print in Maximum dpi mode
Make sure you have photo paper loaded in the input tray.
1.
2. On the File menu in your software application, click Print.
Make sure the product is the selected printer.
3.
4. Click the button that opens the Properties dialog box.
Depending on your software application, this button might be called Properties, Options, Printer Setup, Printer, or
Preferences.
5. Click the Paper/Quality tab.
6. In the Media drop-down list, click Photo Paper, Best Quality.
NOTE: Photo Paper, Best Quality must be selected from the Media drop-down list on the Paper/Quality tab to
enable printing in maximum DPI.
7. Click the Advanced button.
8. In the Printer Features area, select Yes from the Print in Max DPI drop-down list.
9. Select Paper Size from Paper/Output drop-down list.
10. Click OK to close the advanced options.
11. Confirm Orientation on Layout tab, then click OK to print.
Print using the maximum dpi 13
Chapter 3
14 Print
4 ePrint from anywhere
The ePrint feature on your product provides convenience printing that allows you to print from anywhere. Once enabled,
ePrint assigns an email address to your product. To print, simply send an email containing your document to that address. You
can print images, Word, PowerPoint, and PDF documents. It's easy!
ePrint from anywhere
•
ePrint from anywhere
To ePrint a document from anywhere
1. Find your ePrint email address.
a.Press the ePrint button on the control panel. You will see the web services Settings menu on the printer display.
b. Select Display Email Address from the printer display to view the printer’s email address.
NOTE: To use ePrint, web services must first be enabled. If web services have not been enabled, you will see a message
directing you to the Printer Software. Open the Printer Software, select ePrint, then follow the onscreen instruction to
enable.
TIP: To print the email address or registration url, select Print Info Sheet from the Settings menu on the printer display.
Compose and send email.
2.
a. Create a new email and type the product email address in the To box.
Type text in the body of the email and attach the documents or images that you want to print.
b.
Send the email.
c.
The product prints your email.
NOTE: To receive email, your product must be connected to the Internet. Your email will print as soon as it is
received. As with any email, there is no guarantee when or if it will be received. When you register online with
ePrint, you can check the status of your jobs.
TIP: If you have enabled Auto Power-Off, you should disable it before using ePrint. For more information, see Auto
Power-Off
NOTE: 1 Device must be connected wirelessly and on an active network with internet access.
NOTE: 2 Documents printed with ePrint may appear different from the original. Style, formatting, and text flow may
differ from the original document. For documents that need to be printed with a higher quality (such as legal documents),
we recommend that you print from the software application on your computer, where you will have more control over what
your printout looks like.
Click here to go online for more information.
ePrint from anywhere 15
Chapter 4
16 ePrint from anywhere
Loading...
