3DUWLWLRQHG6HFXULW\6\VWHP

,QVWDOODWLRQDQG6HWXS*XLGH



 

2

9,,

677

$

 

N7001V5 5/04 Rev A

Table of Contents

••••••••••••••••••••••••••••••••••••••••••••••••••

List of Figures...................................................................................................................................... v

Conventions Used in This Manual..................................................................................................... vi

SECTION 1: General Description..................................................................................................... 1-1

About the VISTA-40 ...........................................................................................................................................................1-1

Features .............................................................................................................................................................................1-1

SECTION 2: Partitioning................................................................................................................... 2-1

Theory of Partitioning .........................................................................................................................................................2-1

Setting-Up a Partitioned System ........................................................................................................................................2-1

SECTION 3: Installing the Control ................................................................................................... 3-1

Mounting the Control Cabinet ............................................................................................................................................3-1

Installing the Cabinet Lock .................................................................................................................................................3-1

Grade A Mercantile Premises Listing Guidelines...............................................................................................................3-1

Grade A Mercantile Safe and Vault Listing Guidelines ......................................................................................................3-2

Installing the Control’s Circuit Board ..................................................................................................................................3-2

Installing the Keypads ........................................................................................................................................................3-3

Installing External Sounders...............................................................................................................................................3-4

Telephone Line Connections .............................................................................................................................................3-5

Wiring Burglary, Panic and Smoke Detector Devices to Zones 1-9 ...................................................................................3-6

Installing RPM Devices ....................................................................................................................................................3-10

Wireless Zone Expansion.................................................................................................................................................3-13

Installing Relay Devices ...................................................................................................................................................3-16

Installing the Ground Start Module...................................................................................................................................3-17

Installing a Remote Keyswitch .........................................................................................................................................3-18

Remote Keypad Sounder.................................................................................................................................................3-19

Long Range Radio Connected to the J7 Triggers............................................................................................................3-19

Installing a 4100SM..........................................................................................................................................................3-19

Installing the 4285/4286 VIP Module ...............................................................................................................................3-20

Installing the Audio Alarm Verification Module.................................................................................................................3-22

Connecting the Transformer.............................................................................................................................................3-23

Panel Earth Ground Connections.....................................................................................................................................3-25

Determining the Control’s Power Supply Load.................................................................................................................3-25

Determining the Size of the Standby Battery ...................................................................................................................3-26

SECTION 4: Programming................................................................................................................ 4-1

Program Modes..................................................................................................................................................................4-1

Entering and Exiting Programming Mode...........................................................................................................................4-1

Data Field Programming Mode ..........................................................................................................................................4-1

#93 Menu Mode Programming...........................................................................................................................................4-2

Zone Number Designations................................................................................................................................................4-4

Zone Response Type Definitions .......................................................................................................................................4-5

Zone Input Type Definitions ...............................................................................................................................................4-6

Programming for 4100SM ..................................................................................................................................................4-7

Programming for Access Control........................................................................................................................................4-7

SECTION 5: Data Field Descriptions ...............................................................................................5-1

About Data Field Programming..........................................................................................................................................5-1

Programming Data Fields...................................................................................................................................................5-1

SECTION 6: Downloading Primer .................................................................................................... 6-1

General Information ...........................................................................................................................................................6-1

Getting On-Line with a Control Panel.................................................................................................................................6-2

Direct-Wire Downloading....................................................................................................................................................6-3

Telco Handoff.....................................................................................................................................................................6-3

iii

Table of Contents

SECTION 7: Setting the Real-Time Clock........................................................................................ 7-1

General Information ...........................................................................................................................................................7-1

Setting the Time and Date .................................................................................................................................................7-1

SECTION 8: User Access Codes......................................................................................................8-1

General Information ...........................................................................................................................................................8-1

User Codes & Levels of Authority ......................................................................................................................................8-1

Multiple Partition Access ....................................................................................................................................................8-2

Adding a Master, Manager, or Operator Code...................................................................................................................8-3

Changing a Master, Manager, or Operator Code...............................................................................................................8-4

Adding an RF Key to an Existing User...............................................................................................................................8-4

Deleting a Master, Manager, or Operator Code.................................................................................................................8-4

Exiting the User Edit Mode.................................................................................................................................................8-4

SECTION 9: Testing the System ...................................................................................................... 9-1

Battery Test........................................................................................................................................................................9-1

Dialer Test..........................................................................................................................................................................9-1

Burglary Walk-Test (Code + [5] TEST)...............................................................................................................................9-1

Armed Burglary System Test..............................................................................................................................................9-1

Testing Wireless Transmitters............................................................................................................................................9-2

Trouble Conditions .............................................................................................................................................................9-3

To the Installer ...................................................................................................................................................................9-3

APPENDIX A: Regulatory Agency Statements ...............................................................................A-1

UL Installation Requirements ............................................................................................................................................ A-1

UL609 Grade A Local Mercantile Premises/Local Mercantile Safe & Vault ...................................................................... A-1

UL365 Police Station Connected Burglar Alarm ...............................................................................................................A-1

UL611/UL1610 Central Station Burglary Alarm................................................................................................................. A-2

California State Fire Marshal (CSFM) and UL Residential Fire Battery Backup Requirements........................................A-2

APPENDIX B: Summary of System Commands ............................................................................ B-1

APPENDIX C: Specifications........................................................................................................... C-1

APPENDIX D: Contact ID Event Codes........................................................................................... D-1

TABLE OF CONTACT ID EVENT CODES........................................................................................................................D-1

Index ...........................................................................................................................................Index-1

THE LIMITATIONS OF THIS ALARM SYSTEM LIMITED WARRANTY

List of Figures

••••••••••••••••••••••••••••••••••••••••••••••••••

Figure 3-1: Installing the Lock...............................................................................................................................................3-1

Figure 3-2: Cabinet Attack Resistance Considerations.........................................................................................................3-2

Figure 3-3: Mounting the PC Board.......................................................................................................................................3-2

Figure 3-4: Keypad Connections to Control Panel ................................................................................................................3-3

Figure 3-5: Using A Supplementary Power Supply...............................................................................................................3-3

Figure 3-6: Wiring Polarized Fire Devices.............................................................................................................................3-4

Figure 3-7: Wiring Nonpolarized Burglary Devices ..............................................................................................................3-5

Figure 3-8: Telephone Line Connections................................................................................................................................3-6

Figure 3-9: Wiring Connections for Zones 1-9 .......................................................................................................................3-6

Figure 3-10: 2-Wire Smoke Detector on Zone 1.....................................................................................................................3-7

Figure 3-11: 4-Wire Smoke Detectors ....................................................................................................................................3-8

Figure 3-12: Wiring a 333PRM to the Control.......................................................................................................................3-8

Figure 3-13: Wiring a 333PRM using a 4204 ........................................................................................................................3-9

Figure 3-14: Wiring a 333PRM using a 4204 and a Power Supply ......................................................................................3-9

Figure 3-15: Wiring Latching Glassbreaks to Zone 8...........................................................................................................3-10

Figure 3-16: Polling Loop Connections to the VISTA-40 ....................................................................................................3-11

Figure 3-17: Polling Loop Connections Using One 4297 Extender Module .......................................................................3-12

Figure 3-18: Polling Loop Connections Using Multiple Extender Modules .......................................................................3-12

Figure 3-19: Installing the 5881ENHC with Tamper Protection ........................................................................................3-13

Figure 3-20: 5881 RF Receiver (cover removed) ..................................................................................................................3-14

Figure 3-21: 4204 Relay Module...........................................................................................................................................3-17

Figure 3-22: 4204CF Relay Module......................................................................................................................................3-17

Figure 3-23: Ground Start Module Connections..................................................................................................................3-18

Figure 3-24: Remote Keyswitch Wiring ...............................................................................................................................3-19

Figure 3-25: Remote Keypad Sounder Wiring.....................................................................................................................3-19

Figure 3-26: 4100SM Using a Serial Printer........................................................................................................................3-20

Figure 3-27: VIP Module Connections .................................................................................................................................3-21

Figure 3-28: UVS Connections to the Control Panel...........................................................................................................3-23

Figure 3-29: 1361 Transformer and Battery Connections ..................................................................................................3-24

Figure 3-30: 1361X10 Transformer Connections.................................................................................................................3-24

Figure 6-1: Direct-Wire Downloading Connections...............................................................................................................6-3

Conventions Used in This Manual

••••••••••••••••••••••••••••••••••••••••••••••••••

Before you begin using this manual, it is important that you understand the meaning of the following symbols (icons).

ZONE PROG?

1 = YES 0 = NO 0

✴

00 Additional system options are programmed via data fields, which are indicated by a “star” (

These notes include specific information that must be followed if you are installing this system for a UL Listed application.

These notes include information that you should be aware of before continuing with the installation, and that, if not observed, could result in operational difficulties.

This symbol indicates a critical note that could seriously affect the operation of the system, or could cause damage to the system. Please read each warning carefully. This symbol also denotes warnings about physical harm to the user.

Many system options are programmed in an interactive mode by responding to alpha keypad display prompts. These prompts are shown in a single-line box.

followed by the data field number.

✴

)

PRODUCT MODEL NUMBERS:

Unless noted otherwise, references to specific model numbers represent ADEMCO products.

SECTION 1

General Description

••••••••••••••••••••••••••••••••••••••••••••••••••

About the VISTA-40

The VISTA-40 is a 2-partition, UL Listed control panel with the following features:

• Provides 64 zones using hardwired, polling loop and wireless.

• Provides 70 user access codes

Features

Hardwire and Optional Expansion Zones

• Provides 9 hardwire zones.

• Supports up to 16 2-wire smoke detectors on zone 1.

• Supports up to 50 2-wire latching glassbreak detectors on zone 8.

• Supports up to 55 additional expansion zones using a built-in polling (multiplex) loop.

• Supports up to 64 wireless zones (fewer if using hardwire and/or polling loop zones).

• Provides three keypad panic keys: 1 + ✴ (A), ✴ + # (B), and 3 + # (C).

Peripherals Devices

• Supports up to 16 addressable devices, (keypads, RF receivers, relay modules, etc.).

• Provides 8 relays using 4204 and X-10 devices. Can activate relays in response to system events (e.g., alarm, fault,

etc.).

• Supports the 4285/4286 VIP Module, which allows access to the system from either a remote location or on the premises

• Supports the 4146 Keyswitch on any one of the system’s 2 partitions.

Arming/Disarming and Bypassing

• Provides global arming capability (ability to arm both partitions the user code has access to in one command).

Partitioning

• Can control 2 separate areas independently, each functioning as if it had its own separate control.

System Communication

• Supports ADEMCO Contact ID; ADEMCO High Speed; ADEMCO Express; and 3+1, 4+1, and 4+2 ADEMCO and

• Provides an Audio Alarm Verification (AAV) option that permits voice dialog between an operator at the central

The VIP Module is not Listed for use with the VISTA-40 Control Panel in a UL installation.

Sescoa/Radionics Low-Speed formats.

station and a person at the premises. An AAV unit, such as ADEMCO UVS, is required.

Downloading

• Supports upload and download capability.

1-1

VISTA-40 Installation and Setup Guide

Event Log

• Provides an event log (history log) that can store up to 100 events.

• Can print the event log on a serial printer using a 4100SM.

• Can view the event log on an alpha keypad.

Additional Features

• Provides up to 20 installer-defined, custom words that can be used for zone descriptors.

• Contains a built-in User’s Manual, which provides the end user with a brief explanation of the function of a key

when the user presses any of the function keys on the keypad for 5 seconds.

• Provides trigger outputs, which may interface with Long Range Radio equipment or other devices such as keyswitch LEDs or printer.

At least one 2-line alpha keypad (6139/6160) must be connected to the system for programming (if you are using keypad programming), and must remain connected to the system in order to allow the primary user to program additional user codes into the system at a later time.

1-2

SECTION 2

Partitioning

••••••••••••••••••••••••••••••••••••••••••••••••••

Theory of Partitioning

This system provides the ability to arm and disarm up to 2 different areas, as if each had its own control. These areas are called partitions. A Partitioned system allows the user to disarm certain areas while leaving other areas armed, or to limit access to certain areas to specific individuals. Each system user can be assigned to operate any or all partitions, and can be given a different authority level in each.

Before anything can be assigned to those partitions, you must first determine how many partitions (1-2) are required. Following are some facts you need to know about partitioning.

Keypads

Each keypad must be given a unique "address" and be assigned to one partition.

Zones

Each zone must be assigned to one partition. The zones assigned to a partition will be displayed on that partition’s keypad(s).

Users

Each user may be given access to one or more partitions. If a user is to operate more than one partition and would like to arm/disarm all or some of those partitions with a single command, the user must be enabled for Global Arming for those partitions (when entering user codes).

A user with access to more than one partition (multiple access) can "log on" to one partition from another partition’s keypad, provided that program field 2*18: Enable GOTO is enabled for each partition he/she wants to log on to from another.

Setting-Up a Partitioned System

The basic steps to setting up a partitioned system are described below. If you need more information on how to program the options, see SECTION 4: Programming.

1. Determine how many partitions the system will consist of (programmed in field 2*00).

2. Assign keypads to partitions (Device Programming in the #93 Menu Mode).

3. Assign zones to partitions (Zone Programming in the #93 Menu Mode).

4. Confirm zones are displayed at the keypad(s) assigned to those partitions.

5. Assign users to partitions.

6. Enable the GOTO feature (program field 2*18) for each partition a multiple-access user can log on to (alpha keypad only).

7. Program partition-specific fields (see the Data Field Descriptions section).

2-1

VISTA-40 Installation and Setup Guide

2-2

SECTION 3

Installing the Control

•••••••••••••••••••••••••••••••••••••••••••••••••

This section describes the procedures for mounting and wiring the control panel and all the peripheral devices.

Mounting the Control Cabinet

To mount the control cabinet, perform the following steps:

Step Action

1 Before mounting the circuit board, remove the metal knockouts for the wiring entry that you will be using.

DO NOT ATTEMPT TO REMOVE THE KNOCKOUTS AFTER THE CIRCUIT BOARD HAS BEEN INSTALLED.

2 Using fasteners or anchors (not supplied), mount the control cabinet to a sturdy wall in a clean, dry area

that is not readily accessible to the general public. The back of the cabinet has 4 holes for this purpose.

To provide certificated burglary service for UL installations, refer to the special requirements and Figure 3-2

Cabinet Attack Resistance Considerations to follow. For UL Commercial Burglary installations that require

ATTACK RESISTANCE, use the cabinet included in the VISTA-ULKT kit.

Installing the Cabinet Lock

1. Remove cabinet door, then remove the lock

knockout from the door. Insert the key into the lock.

2. Position the lock in the hole, making certain

that the latch will make contact with the latch bracket when the door is closed.

3. When correctly positioned, push the lock until

it is held securely by its snap tabs.

Use Part Number K4445 Lock (supplied).

Grade A Mercantile Premises Listing Guidelines

• The panel door must be supervised. Mount the clip-on tamper switch (supplied) to the cabinet’s right side wall as shown in the diagram below, and wire it to one of the hardwire zones.

• Use a bell with a tamper-protected housing such as the AB12. The bell housing’s tamper switch and inner tamper linings must also be wired to the hardwire zone.

• Assign the tampers’ hardwire zone to a burglary partition. Program the hardwire zone for day trouble/night alarm (zone type 5) when only one burglary partition is used. Program it for 24-hr. audible alarm (zone type 7) when more than one burglary partition is used.

PUSH

ON LOCK

STEP 2STEP 1

ADEMCO

UNTIL IT IS SEATED SECURELY

cab_lock_snap-001-V0

CHECK

POSITION

LOCKED

UNLOCKED

CABINET DOOR

BOTTOM

PUSH

SNAP

TAB

ADEMCO

SNAP

TAB

Figure 3-1: Installing the Lock

• All wiring between the bell and panel must be run in conduit. Remaining wires do not need to be run in conduit.

• All wiring that is not run in conduit must exit from the knockout openings on the bottom or back of the cabinet.

• All unused knockouts must be plugged using the disc plugs and carriage bolts (supplied), as indicated in the diagram below.

• Fasten the cabinet door to the cabinet backbox using the 18 one-inch-long Phillips-head screws (supplied) after all wiring, programming, and checkout procedures have been completed.

3-1

VISTA-40 Installation and Setup Guide

(Shows typical local Grade A listing installation)

RUN BELL WIRES

PLUG THIS

KNOCKOUT

IN CONDUIT

BOARD

PLUG THIS

KNOCKOUT

CLIP-ON DOOR TAMPER SWITCH

CABINET MOUNTING HOLE (4 PLACES)

PLUG THIS KNOCKOUT

TO PLUG AN UNUSED KNOCKOUT OPENING,

REMOVE KNOCKOUT AND INSTALL A PAIR OF

DISC PLUGS AND A CARRIAGE BOLT AS SHOWN.

DISC PLUGS (DIMPLES IN DISC

KNOCKOUT

OPENING

HEX NUT AND

WASHER

PLUG SHOULD REGISTER INSIDE KNOCKOUT OPENING)

CARRIAGE BOLT

CABINET SIDE WALL (OUTSIDE)

PLUG THIS

KNOCKOUT

RUN ALL REMAINING

WIRE THROUGH HERE

Figure 3-2: Cabinet Attack Resistance Considerations

Grade A Mercantile Safe and Vault Listing Guidelines

• Follow the guidelines given above for Grade A Mercantile Premises listing.

• Mount a shock sensor such as Sentrol No. 5402 to the control’s backbox. Follow the manufacturer’s instructions for proper sensor mounting. This sensor also must be wired to a hardwire zone.

• For safe and vault applications, a UL Listed contact must be used inside the cabinet through one of the knockouts for pry-off tamper purposes. This sensor also must be wired to a hardwire zone.

Installing the Control’s Circuit Board

To install the circuit board in the cabinet, perform the following steps:

Step Action

Hang the three mounting clips on the raised cabinet tabs. Refer to Figure 3-3 (Detail B).

Make sure the clip orientation is exactly as shown in the diagram to avoid damage. This will also avoid problems with insertion and removal of the PC board.

Insert the top of the circuit board into the slots at the top of the cabinet. Make certain that the board rests in the slots as indicated (Detail A).

Swing the base of the board into the mounting clips and secure the board to the cabinet with the accompanying screws.

Notes:

• Make certain that the mounting screws are tight. This ensures that there is a good ground connection between the PC board and the cabinet.

• Dress field wiring away from the microprocessor (center) section of the PC board. Use the loops on the left and right sidewalls of the cabinet for anchoring field wiring using tie wraps (Detail C). These steps are important to minimize the risk of panel RF interference with television reception.

DETAIL C

SIDE VIEW OF SLOTS

cabattack-001-V0

DETAIL A

SIDE VIEW OF BOARD INSERTED INTO SLOTS

3-2

DETAIL B

SIDE VIEW OF SHORT MOUNTING CLIPS (TYP.)

Figure 3-3: Mounting the PC Board

hi_end_mnt-PCB

Installing the Keypads

Section 3 - Installing the Control

• Up to 31 addressable keypads (addresses 00-30) may be used (you may need to use an auxiliary power supply if the 750mA aux. output is exceeded). The following keypads may be used:

• 2-line alpha display, 6139/6160

• The length of all wire runs combined,

regardless of the wire gauge, must not exceed 2000 feet when unshielded quad conductor cable is used (1000 feet if unshielded cable is run in conduit, which acts a shield, or if shielded cable is used).

• If more than one keypad is wired to one run, then the above maximum lengths must be divided by the number of keypads on the run (e.g., the maximum length is 225 feet if two keypads are wired on a #22 gauge run).

To wire the keypads, perform the following steps:

Step Action

Determine wire gauge by referring to the Wire Run Length/Gauge table below.

Wire Run Length/Gauge Table

Wire Gauge Length

#22 gauge 450 feet

#20 gauge 700 feet

#18 gauge 1100 feet

#16 gauge 1750 feet

2 Wire keypads to a single wire run or connect

individual keypads to separate wire runs. The maximum wire run length from the control to a keypad, which is homerun back to the control must not exceed the lengths listed in the table.

3 Run field wiring from the control to the

keypads (using standard 4-conductor cable of the wire gauge determined in step 1).

4 Connect the keypad(s) to terminals 6, 7, 8,

and 9 on the control board, as shown in

Figure 3-4.

Addressing the Keypads

The keypads will not operate until they are physically addressed and enabled in the system’s Device Programming in the #93 Menu Mode.

Set each keypad for an individual address (00-15) according to the keypad’s instructions. Set an alpha keypad for address 00 and other keypads for higher addresses. Any keypads set for address 02 and above will appear blank until they are enabled in the system’s program. Each keypad must be set for a different address.

• Do not set any keypads to address 31 (nonaddressable mode). They will interfere with other keypads (as well as other devices) connected to the keypad terminals.

• If an “OC” or “OPEN CIRCUIT” message is present on a keypad, data from the control is not reaching the keypad. Please check your wiring.

Supplementary Power Supply for Additional Keypads

When the control’s auxiliary power load for all devices exceeds 750mA, you can power additional keypads from a regulated 12VDC power supply (e.g., AD12612 (1.2A)). Use a UL Listed, battery-backed supply for UL installations.

Connect the additional keypads as shown in Figure 3-5, using the keypad wire colors shown. Be sure to observe the current ratings for the power supply used.

• Make connections directly to the screw terminals as shown in Figure 3-5. Make no connection to the keypad blue wire (if present).

• Be sure to connect the negative (–) terminal on the power supply unit to terminal 7 (–) on the control.

SUPPLEMENTARY

POWER SUPPLY

–

CONTROL TERMINAL STRIP

DATA

AUX. DATA

AUX.

+ 678 9

OUT

–

RED

BLACK

GREEN

YELLOW

CONTROL TERMINALS

KEYPADS

Figure 3-4: Keypad Connections to Control Panel

IMPORTANT:

MAKE THESE

CONNECTIONS

DIRECTLY TO

SCREW

TERMINALS AS

SHOWN.

RED WIRE

BLACK WIRE

SECONDARY

KEYPAD

YELLOW WIRE

GREEN WIRE

BLACK WIRE

RED WIRE

MAIN

KEYPAD

GREEN WIRE

YELLOW WIRE

pwr_supply-002-V0

Figure 3-5: Using A Supplementary Power Supply

3-3

VISTA-40 Installation and Setup Guide

Installing External Sounders

The VISTA-40 provides a bell circuit output for operating fire and burglary alarm notification appliances. The alarm output is rated as follows: 10VDC – 14VDC, 1.7A max., power-limited.

The output has the following options:

• Selectable for supervision.

• Selectable for confirmation of arming ding.

• Selectable to chime when entry/exit or perimeter

zones are faulted.

• Selectable for no timeout or timeout of 2-30 minutes.

• Burglary bell circuits must be programmed

UL1023 Household Burglary Installations

For Household Burglary installations, the total current drawn from the alarm output must not exceed 1.7A. A battery must be installed, as the battery supplies current from the combined auxiliary power, polling loop, and alarm output in excess of 750mA.

UL985 Household Fire or Combination Household Fire/Burglary Installations

For installations that must provide UL Listed protection, the total combined current drawn from the alarm output, auxiliary power output, and polling loop must not exceed 750mA in order to comply with the battery independence requirements. If, for example, two System Sensor PA400 piezo alarm sounders, wired in parallel, are used (24mA total), then 726mA (750mA – 24mA) is available for auxiliary output and polling loop use.

Non-UL Installations

For non-UL installations, the total current drawn from this output can be up to 1.7 amps. A battery must be installed, as the battery supplies current in excess of 750mA. Up to two 719 sirens can be used wired in parallel.

for a timeout of 16 minutes or longer.

• For Household Fire and combination Household Fire/Burglary installations, the total current drawn from the auxiliary power, polling loop, and alarm output combined must not exceed 750mA.

• For Household Burglary installations, the total current drawn from the alarm output must not exceed 1.7A. A battery must be installed, as it supplies the current for the combined auxiliary power, polling loop, and alarm output in excess of 750mA.

This control complies with National Fire Protection Association (NFPA) requirements for temporal pulse sounding of fire notification appliances.

Alarm Output Supervision

When supervision is enabled, the VISTA-40 monitors the alarm output wiring for open and short circuit faults while the output is inactive. The system provides a trouble indication (Zone 70) when an open occurs; or when a short occurs between the Bell (+) and Bell (-) terminal wiring, or between the Bell (+) terminal wiring and earth ground.

The VISTA-40 indicates the trouble condition regardless of whether the system is armed or disarmed. The zone displays on the keypads, reports to the event log, and transmits to the central station (if programmed) on Partition 1. The Contact ID event code is 321, Bell Trouble. The trouble is cleared from the display by entering the user code + OFF.

Wiring the Alarm Output

The wiring of the alarm output depends upon whether you are going to supervise the output or not. Use the appropriate procedure below for your application.

Use only UL Listed sounding devices for UL

installations.

Compatible Alarm Indicating Devices

Model Number Device Type Polarizing

Diode

719 Compact Outdoor Siren

(not UL Listed)

747 Indoor Siren Yes

AB12 Grade A Bell Yes

System Sensor MA 12/24D

System Sensor P12575

Wheelock

AS-121575W

Fire Piezo Horn No

Fire Horn/Strobe No

Yes

ALARM SOUNDER OUTPUT: 1-VDC - 13.8VDC

1.7A MAXIMUM

BELL

HORN

Figure 3-6: Wiring Polarized Fire Devices

fire_devices-001-V0

3-4

PANEL BELL

POLARIZING DIODES

(MUST MOUNT AT INDICATING DEVICE)

Section 3 - Installing the Control

BELL

PANEL BELL

NONPOLARIZED BURGLARY

INDICATING DEVICES

Figure 3-7: Wiring Nonpolarized Burglary Devices

Supervising the Alarm Output

To wire the alarm output using the supervision feature, perform the following steps:

Step Action

1 Wire polarized fire-indicating devices to the

alarm output as shown in Figure 3-6.

2 Wire nonpolarized burglary indicating

devices to the alarm output using a polarizing diode (two 2A diodes supplied), as shown in Figure 3-7.

3 Program Zone 70 with a response type of 05

(trouble by day/alarm by night).

The minimum load on the alarm output must exceed 5mA at 12V for proper supervision operation.

Disabling the Supervision of the Alarm Output

To install the alarm output and disable the supervision feature, perform the following steps:

Step Action

1 Wire the devices to terminals 4 and 5,

observing polarity if necessary.

2 Cut the blue jumper on the upper left-hand

corner of the panel’s PC board.

3 Program Zone 70 with no response type (00).

BELL

HORN

POLARIZED FIRE

INDICATING DEVICE

TO OTHER DEVICES

non_polar_devices

Using a Siren Driver

To install a siren driver, perform the following steps:

Step Action

1 Mount the siren driver in the panel’s cabinet.

2 Wire the siren driver to the control and to the

speaker(s). (See the driver’s instructions.)

3 Cut the blue jumper on the upper left-hand

corner of the panel’s PC board.

4 Program Zone 70 with no response type (00).

If a device such as a siren driver with a high-

resistance trigger input (drawing less than 5mA) is used in a UL Household Fire installation, the siren driver must independently supervise siren speaker wiring.

Telephone Line Connections

Connect the main dialer output to telephone company lines using the RJ31X cables supplied.

The telephone line inputs have overvoltage

protection in accordance with UL1459, as specified in UL985/UL1023.

To prevent the risk of shock, disconnect phone lines at the telco jack before servicing.

If the communicator is connected to a PABX, be sure it has a backup power supply that can support the PABX for 24 hours (central station) or 60 hours (remote station). Many PABXs are not power-backed up, and this can result in a communication failure if power is lost.

Reporting Formats

The system supports the following formats: ADEMCO Low Speed 3+1; 4+1; 4+2; Sescoa/Radionics

3+1; 4+1; 4+2; ADEMCO 4+2 Express; ADEMCO High Speed; ADEMCO Contact ID

3-5

VISTA-40 Installation and Setup Guide

26 27 28 29 30

TERMINALS ON CONTROL

Figure 3-8: Telephone Line Connections

Handset

{

BROWN (TIP)

Telco Line

GREY (RING)

Incoming

{

DIRECT

CONNECT

GREEN (TIP)

RED (RING)

GROUND

CORD

PLUG

EARTH GROUND

INCOMING TELCO LINE

TIP

RING

TIP

RJ31X

RING

JACK

PREMISES PHONES

Wiring Burglary, Panic and Smoke Detector Devices to Zones 1-9

The maximum zone resistance is 100 ohms for zones 1 and 8, and 300 ohms for all other zones (excluding the 2K EOL resistor).

To wire burglary and panic devices to zones 1-9, connect sensors/contacts to the hardwire zone terminals (10 through 23). See Figure 3-9. Connect N.C. and N.O. devices as follows:

Red Jumper

10 11 12 13 14 15 16 17 18 19 20 21 22 23

ZONE 1

2-WIRE SMOKE

SMOKE

N.C.

N.O.

2k EOLR

hw_zones-001-V0

ZONE 2 ZONE 3 ZONE 4 ZONE 5 ZONE 6 ZONE 7 ZONE 8 ZONE 9

N.C.

N.O.

2k EOLR 2k EOLR

DETECTOR LOOP

Fire

Usage

Burg.

Usage

(Also supports NO/NC Burg contacts)

Zone resistance (Excluding EOLR): ZONE 1,8: 100 OHMS MAXIMUM ALL OTHER ZONES: 300 OHMS MAXIMUM

N.C.

N.O. N.O.

N.C.

N.O. N.O.

2k EOLR 2k EOLR

Figure 3-9: Wiring Connections for Zones 1-9

• Connect N.C. devices in series with the high (+)

side of the loop. The 2K EOL resistor must be connected in series with the devices, following the last device.

• Connect N.O. devices in parallel (across) the loop.

The 2K EOL resistor must be connected across the loop wires at the last device.

N.C.

2k EOLR

N.C.

N.O.

BREAK DETECTORS

2k EOLR

LATCHING TYPE GLASS

++-

GLASS BREAK

N.C.

N.O.

2k EOLR

Zone response time: ZONES 1-8: 350mSec-500mSec ZONE 9: Programmable for

Fast: 10mSec-15mSec Normal: 350mSec-500mSec

Programmable Response

(Fast/Normal) Loop

N.C.

(default response)

3-6

2k EOLR

ZONE 1

SMOKE

(+)

(-)

2-WIRE SMOKE

DETECTOR

(+)

(-)

Using 2-Wire Smoke Detectors on Zone 1

Zone 1 can support up to 16 2-wire smoke detectors.

The alarm current on zone 1 supports only one smoke detector in the alarmed state.

Compatible 2-Wire Smoke Detectors

DETECTOR TYPE DEVICE MODEL #

Photoelectric, direct-wire System Sensor 2400

Photoelectric w/heat sensor, direct-wire System Sensor 2400TH

Photoelectric w/B401B base System Sensor 2451

Photoelectric w/heat sensor & B401B System Sensor 2451TH

Ionization, direct-wire System Sensor 1400

Ionization w/B401B base System Sensor 1451

Photoelectric duct detect (DH400 base) System Sensor 2451

Ionization duct detector (DH400 base) System Sensor 1451DH

Ionization, direct-wire System Sensor 1100

Ionization w/B110LP base System Sensor 1151

Photoelectric, direct-wire System Sensor 2100

Photoelectric w/heat sensor, direct-wire System Sensor 2100T

Photoelectric w/B110LP base System Sensor 2151

These smoke detectors are UL Listed for use

Wiring 2-Wire Smoke Detectors to Zone 1

To wire 2-wire smoke detectors to zone 1, perform the following steps:

Step Action

1 Select up to 16 2-wire smoke detectors from

2 Connect 2-wire smoke detectors across zone 1

3 Connect the EOL resistor at the last detector

with the VISTA-40 and are the only 2-wire

smoke detectors that may be used.

2K EOL resistors must be used on fire zones and must be connected across the loop wires of each zone at the last detector.

the list of compatible detectors.

terminals (10 and 11) as shown in Figure 3-

10. Observe proper polarity when connecting the detectors.

in the loop across the zone 1 terminals. The

EOL resistor must be connected across the loop wires at the last detector.

Section 3 - Installing the Control

Figure 3-10: 2-Wire Smoke Detector on Zone 1

Using 4-Wire Smoke Detectors on Zones 1-8

You may use as many 4-wire smoke detectors as can be powered from the panel’s Auxiliary Power output without exceeding the output’s rating (750mA).

Auxiliary power to 4-wire smoke detectors is not automatically reset after an alarm, and therefore must be momentarily interrupted using a 4204 Relay Module.

Compatible 4-Wire Smoke Detectors

Use any UL Listed 4-wire smoke detector that is rated for 10-14VDC operation and that has alarm reset time not exceeding 6 seconds. Some compatible 4-wire smoke detectors are listed below.

Detector Type Detector Model #

Photoelectric, direct wire System Sensor 2412

Photoelectric w/heat sensor, direct wire

Ionization, direct wire System Sensor 1412

Wiring 4-Wire Smoke Detectors

Power to 4-wire smoke detectors must be

supervised with an EOL device (use a System

System Sensor 2412TH

Sensor A77-716B EOL relay module connected as shown in Figure 3-11).

To wire 4-wire smoke detectors to zones 1-8, perform the following steps:

Step Action

1 Select 4-wire smoke detectors (see list of

compatible detectors shown previously in this section).

2 Connect detectors (including heat detectors,

if used) across terminals of the zone selected. All detectors must be wired in parallel. See Figure 3-11.

3 Connect the EOLR at the last detector in the

loop across the zone’s terminals. You must

connect the EOLR across the loop wires at the last detector.

3-7

VISTA-40 Installation and Setup Guide

The 333PRM reverses polarity to smoke detectors

control panel supplies only enough current for one

AUXILIARY

POWER

TERMINALS

NOTES:

· PROGRAM THE RELAY TO TRANSFER ON FIRE ZONE RESET (ACTIVATION CODE 54). SEE 4204 RELAY MODULE SECTION FOR DETAILS.

· SECOND CODE AND OFF ENTERED AT CONSOLE MOMENTARILY INTERRUPTS DETECTOR POWER.

Using Smoke Power Reversal Module

The 333PRM Polarity Reversing Module is used to reverse the polarity of the positive and negative voltages powering smoke detectors. The module is for use with 4-wire smoke detectors that employ a sounder and voltage-reversing feature. The module is triggered by a pulsing bell output.

Smoke Detectors Compatible with the 333PRM

The 333PRM may be used with the System Sensor 2112/24AT and similar models with the required operating features previously stated.

RELAY 1, 2, 3, OR 4

4204 RELAY MODULE

CONTROL PANEL

NO CONNECTION

RESET

Figure 3-11: 4-Wire Smoke Detectors

746

FIRE ZONE

TERMINALS

4-WIRE SMOKE

DETECTORS

DETECTOR

HEAT

EOL POWER SUPERVISION RELAY MODULE A77-716B

SHOWN POWERED. RELAY OPENS WHEN POWER IS LOST.

2k EOLR

with Integral Temp-3 Sounders. Typically, in alarm, each draws 49-60mA of current. The

smoke detector. In order to attach more than one, an external power supply and an external relay may be required.

Installing the 333PRM

Mount the 333PRM inside the control panel’s cabinet or in a separate cabinet using the double-sided tape provided. Wire the 333PRM as shown in Figures 3-12,

3-13 or 3-14. Refer to the 333PRM Installation Instructions for detailed information on the installation

of the module.

V128BP-002-V0

MOMENTARY

RESET SWITCH

333 PRM

-2

JUMPER

JUMPER P1 ON

333 MODULE

MUST BE IN

"B" POSITION

3-8

–

TO FIRE ZONE

TERMINALS

4-WIRE SMOKE

DETECTORS

HEAT DETECTOR

FOUR-WIRE DETECTOR CIRCUIT

Figure 3-12: Wiring a 333PRM to the Control

EOL POWER SUPERVISION RELAY MODULE A77-761B

SHOWN POWERED. RELAY OPENS WHEN POWER IS LOST

2000 OHM EOLR

333PRM-001-V0

333 PRM

-2

JUMPER

JUMPER P1 ON

333 MODULE

MUST BE IN

"B" POSITION

2 3 41 12

NC CNO

CONTROL PANEL

76 4

TO FIRE ZONE

TERMINALS

Section 3 - Installing the Control

4-WIRE SMOKE

DETECTORS

FOUR-WIRE DETECTOR CIRCUIT

HEAT DETECTOR

–

EOL POWER SUPERVISION RELAY MODULE A77-761B

SHOWN POWERED. RELAY OPENS WHEN POWER IS LOST

2000 OHM EOLR

4204

JUMPER P1 ON

333 MODULE

MUST BE IN

"B" POSITION

234 112

4204

Figure 3-13: Wiring a 333PRM using a 4204

CONTROL PANEL

76 4

333 PRM

JUMPER

-2

TO FIRE ZONE

TERMINALS

4-WIRE SMOKE

DETECTORS

HEAT DETECTOR

–

EOL POWER SUPERVISION RELAY MODULE A77-761B

SHOWN POWERED. RELAY OPENS WHEN POWER IS LOST

2000 OHM EOLR

FOUR-WIRE DETECTOR CIRCUIT

333PRM-002-V0

POWER

SUPPLY

USE A 12VDC, BATTERY-BACKED, UL LISTED POWER SUPPLY.

333PRM-003-V0

Figure 3-14: Wiring a 333PRM using a 4204 and a Power Supply

3-9

GLASSBREAK DETECTOR

ZONE 8

(+)

(-)

LATCHING TYPE GLASS BREAK DETECTOR LOOP

2000

OHMS

EOLR

VISTA-40 Installation and Setup Guide

Using 2-Wire Latching Glassbreaks on Zone 8

Zone 8 can support 2-wire glassbreak detectors. The zone provides enough standby current to power up to 50 2-wire glassbreak detectors meeting the requirements listed below.

Compatible Glassbreak Detectors

Use detectors that meet the following ratings:

Standby Voltage:

Standby Resistance:

Alarm Resistance:

Alarm Current:

Reset Time: Less than 6 seconds

NOTES:

• You can use detectors that exceed 1.1k ohms in alarm, provided they maintain a voltage drop of less than 3.8 volts in alarm.

• The ASC-SS1 detector has been tested and found to be compatible with these ratings.

5VDC–13.8VDC

Greater than 20k ohms (equivalent resistance of all detectors in parallel)

Less than 1.1k ohms (see note below)

2mA–10mA

Figure 3-15: Wiring Latching Glassbreaks to Zone 8

• The alarm current provided by zone 8 supports only one glassbreak detector in the alarmed state.

• Do not use other N.O. or N.C. contacts when using glassbreak detectors on zone

8. Other contacts may prevent proper glassbreak detector operation.

To wire 2-wire latching glassbreak detectors to zone 8, perform the following steps:

Step Action

1 Select compatible 2-wire glassbreak

detectors that meet the requirements stated previously.

2 Connect detectors across zone 8 (terminals

21 and 22). See Figure 3-15.

3 Connect the EOL resistor at the last detector

in the loop across the zone’s terminals. You

must connect the EOL resistor across the loop wires at the last detector.

Installing RPM Devices

The polling loop provides both power and data to the RPM devices, and is constantly monitoring the status of all zones enabled on the loop. The maximum current draw of all devices on the polling loop cannot total more than 64mA (unless the system uses a 4297 Polling Loop Extender Module).

Devices that can be programmed via either DIP switches or the built-in unique serial number must be set for the serial number mode operation.

All devices on the polling loop must be wired in parallel to the [+] and [-] polling loop terminals of the control panel (24 and 25). You can wire from device to device, or have multiple branches connected directly to the control panel in a star configuration.

Compatible Polling Loop Devices

Model Number Type

4208 8-Zone Expander

4190WH 2-Zone Expander

4278 Quad PIR

4275 Dual PIR

4194 Surface-Mount Reed Contact (Wide Gap)

4297 Extender Module

4192SD Photoelectric Smoke Detector Devices

4192SDT Photoelectric Smoke Detector w/Heat

Detector

4192CP Ionization Smoke Detector

4101SN Serial Number Single-Output Relay Module

4208U Universal 8-Zone Expander

4939SN-BR

4939SN-GY

4191SN-WH Serial Number Recessed Reed Contact

4959SN Aluminum Overhead Door Contact

Serial Number Surface-Mount Reed Contacts

3-10

Section 3 - Installing the Control

Model Number Type

7500 Single Technology Glassbreak Detector

9500 Dual Technology Glassbreak Detector

4209U Universal Group Zoning Module

4193SN Serialized 2-Zone Expander

4293SN Serialized 1-Zone Expander

4190SN Serialized 2-Zone Expander

998MX Serialized PIR

• The 4208 must be mounted either inside the

control panel’s cabinet or in a separate enclosure that has a tamper-supervised cover.

• The 4190WH right loop must not be used, and the left loop must be EOLR-supervised.

• The 4278 right loop cannot be used.

• The 4194 is not UL Listed.

• The 4297 must be powered from the control

panel’s Auxiliary Power Output or from a UL Listed supplementary power supply.

• The 7500 and 9500 detectors are not UL Listed.

• For new polling loop installations, always use

twisted pair wiring. In many cases, existing non-twisted pair wiring may be used, but it is more susceptible to interference from other sources, and may be problematic in installations with long wire runs or in high noise environments.

• Always locate polling loop wiring at least six inches (15cm) of AC power, telephone, or intercom wiring. The polling loop carries data between the control panel and the devices; interference on this loop can cause an interruption of communication. The polling loop can also cause outgoing interference on the intercom or phone lines. If this spacing cannot be achieved, shielded wire must be used. (Note that the maximum total wire length supported is cut in half when shielded wire is used.)

• No more than 64mA may be drawn on any individual wire run.

• When a star configuration is used, the total length of all wire runs combined cannot exceed 4000 ft (2000 ft. if you are using unshielded wire in conduit or shielded wire).

IMPORTANT NOTE: If the installation exceeds or deviates from these parameters, refer to the application note on the Honeywell website for additional information. To access the application note:

1. Go to the honeywell.com/security website

2. Click the Honeywell Security & Custom Electronics link.

3. Click the Commercial link.

4. Click the Documentation link.

5. Click the V-Plex Application Note.

To install polling loop devices, perform the following steps:

Step Action

1 Select devices from the list of compatible

devices shown previously.

2 Set the DIP switches in the device (if

required). Refer to the device’s instructions for the DIP Switch Tables.

3 Mount each device in the desired location.

Refer to the device’s instructions.

Run wires from the control panel to each device on the polling loop (see Figure 3-16). No individual wire run may exceed the lengths shown in the following table.

Maximum Polling Loop Wire Runs

Wire Gauge Max. Length

#22 gauge 650 feet

#20 gauge 950 feet

#18 gauge 1500 feet

#16 gauge 2400 feet

5 Wire each device to the polling loop, making

sure of the correct polarity (refer to the device’s instructions).

NOTE: If you are using serial number devices, and intend to enroll each device through the keypad automatically, wire no

more than 25 of these devices to the control at a time. Then power up and

program them before connecting the next 25. Leave previously enrolled devices connected.

If you intend to manually enter the serial numbers through the keypad or through Compass downloading software, all the devices may be connected before powering up to program.

POLLING LOOP RATING: 128mA MAXIMUM

POLLING LOOP

4190 RPM

4192SD SMOKE

4278

PIR

TO RIGHT LOOP

poll_loop-001-V0

Figure 3-16: Polling Loop Connections to the

VISTA-40

3-11

VISTA-40 Installation and Setup Guide

Polling Loop Supervision

A short on the polling loop is indicated by a trouble on zone 997 and reports as a trouble condition only. If annunciation is desired, program the zone as type 05.

If a device on the polling loop fails (the panel cannot "see" that device), the system displays a trouble condition for all zones on that device. If the panel is armed when a device fails, and the zone is a burglary zone, the will go into alarm

A trouble on zone 97 prevents a partition from being armed, unless all polling loop zones on that partition are bypassed.

CONTROL PANEL

INPUT LOOP LIMITS:

• 64 mA MAX. LIMIT CURRENT TO 64mA ON ANY INDIVIDUAL WIRE RUN.

• NO MORE THAN 55 DEVICES MAY BE USED.

•

NO INDIVIDUAL WIRE RUN CAN EXCEED:

COMBINED INPUT AND EXTENSION LOOP LIMITS:

• NO MORE THAN 55 DEVICES COMBINED.

• TOTAL LENGTH OF ALL WIRE RUNS ON BOTH LOOPS

COMBINED CANNOT EXCEED 5200 FT. (2600 FT. IF USING UNSHIELDED WIRE IN CONDUIT, OR IF USING SHIELDED WIRE).

INPUT POLLING LOOP

RPM

Figure 3-17: Polling Loop Connections Using One 4297 Extender Module

•

DO NOT CONNECT 4297 MODULES IN SERIES (i.e., DO NOT CONNECT ONE MODULE'S EXTENSION LOOP TO ANOTHER MODULE'S INPUT LOOP.)

Using the 4297 Polling Loop Extender

The 4297 Polling Loop Extender may be used to provide additional polling loop current, to extend the polling loop wire run length, and/or to provide individual electrically isolated polling loops. Refer to Figures 3-17 and 3-18, to follow.

Be sure to include the total current drawn on the polling loop when figuring the total auxiliary load on the panel’s power supply.

EXTENSION POLLING LOOP

4297

EXTENSION POLLING LOOP LIMITS = SAME AS INPUT LOOP

GAUGE LENGTH

#22 650 FT

#20 950 FT

#18 1500 FT

#16 2400 FT

•

TOTAL LENGTH OF ALL WIRE RUNS COMBINED CANNOT EXCEED 5200FT. (2600FT. IF USING UNSHIELDED WIRE).

RPM

EXTENSION POLLING LOOP #1

4297

RPM

TO OTHER RPMS

polling_loop_011-V0

3-12

CONTROL PANEL

INPUT POLLING LOOP

4297

COMBINED INPUT AND EXTENSION LOOP LIMITS:

NO MORE THAN 55 DEVICES COMBINED ON THE INPUT LOOP AND EXTENSION

• LOOP #1. NO MORE THAN 55 DEVICES COMBINED ON THE INPUT LOOP AND EXTENSION LOOP #2.

• TOTAL LENGTH OF ALL WIRE RUNS ON THE INPUT LOOP AND EXTENSION LOOP #1

COMBINED CANNOT EXCEED 5200 FT. (2600 FT. IF USING UNSHIELDED WIRE IN CONDUIT, OR SHIELDED WIRE). TOTAL LENGTH OF ALL WIRE RUNS ON THE INPUT LOOP AND EXTENSION LOOP #2 COMBINED CANNOT EXCEED 5200 FT. (2600 FT. IF USING UNSHIELDED WIRE IN CONDUIT, OR SHIELDED WIRE).

Figure 3-18: Polling Loop Connections Using Multiple Extender Modules

NOTE: The input loop limits stated in Figure 3-17 apply to Figure 3-18 as well.

EXTENSION POLLING LOOP #2

RPM

polling_loop-010-V0

Wireless Zone Expansion

The following table lists the receivers that may be used and the number of zones they support.

RF System Operation and Supervision

The 5800 RF system operation has the following characteristics:

• The receiver responds to a frequency of 345MHz.

• The receiver has a nominal range of 200 feet.

• Supervised transmitters send a supervisory signal

• Zones 88 and 90 are used to supervise the RF

• The 5881ENHC receiver contains front and back

• You may only mount the 5881ENHC its own plastic

• The control checks the receiver connections about

The 5881ENHC RF Receiver and the 5869 Holdup

Switch Transmitter are listed for UL Commercial Burglary applications. All other RF receivers and transmitters are not listed for UL Commercial Burglary applications.

5800 Series Receivers

Receiver Zones

5881L up to 8

5881M up to 16

5881H up to 64

In Canada, 5800 systems must use 5882 Series receivers: 5882L/5882H. Information to the 5881 Receivers applies as well to the 5882 Receivers. Both receivers use the same transmitters.

every 70-90 minutes.

reception of receivers 2 and 1, respectively. The reception is supervised for two conditions:

1. The receiver goes “deaf” (doesn’t hear from any transmitter) within a programmed interval of time (defined by program field 1*30).

2. Proper RF reception is impeded (i.e., jamming or other RF interference). The control checks for this condition every 45 seconds.

A response type (05 Day/Night) must be

programmed for zones 90 (1st receiver) and 88

(2nd receiver) for UL installations.

tampers that permit its use in commercial burglary installations.

housing. Otherwise, the receiver constantly reports a tamper condition.

every 45 seconds. The receiver supervisory zone is 89 and 91 for receivers 2 and 1, respectively.

NOTE: These zones must be programmed with a response type (e.g., type 05 Day/Night Trouble) before they supervise the connection to the receiver.

Section 3 - Installing the Control

• Use two identical receivers to provide either a greater area of coverage or redundant protection. They must be set for different addresses.

• Any zone from 1 to 64 can be used as a 5800 Series wireless zone, with the exception of zone 64 (reserved for a wireless keypad).

RF System Installation Advisories

• Place the receiver in a high, centrally located area. Do not place it on or near metal objects. This will decrease the range and/or block transmissions.

• Install the RF receiver at least 10 feet from the control panel or any keypads, to avoid interference from the microprocessors in these units.

• If dual receivers are used:

a. They must be at least 10 feet from each other,

as well as from the control panel and remote keypads.

b. Each receiver must be set to a different device

address. The receiver set to the lower address is considered the 1 purposes.

c. The House IDs must be the same.

d. Using two receivers does not increase the

number of transmitters the system can support (63 zones using the 5881H, plus a wireless keypad).

Installation and Setup of the 5881 RF Receivers

Take note of the address you select for the RF receiver, as this address must be enabled in the system’s Device Programming in the #93 Menu Mode.

Figure 3-19: Installing the 5881ENHC with Tamper

RF receiver for supervisory

SCREW

5881ENHC-001-V0

Protection

3-13

VISTA-40 Installation and Setup Guide

To install the 5881 RF receiver, perform the following steps:

Step Action

1 Mount the receiver, following the advisories

stated previously.

2 Set the DIP switches in the receiver for the

address (01-07). See Figure 3-20.

Make sure the address setting is not being used by another device (keypad, relay module, etc.).

3 If installing a 5881ENHC, install a flat-head

screw (supplied) in the case tamper tab as shown in Figure 3-19. When the receiver is pried from the wall, the tamper tab will break off and remain on the wall. This will activate a tamper switch in the receiver and cause generation of a tamper signal. Note that this signal will also be generated when the receiver’s front cover is removed.

ANTENNAS

INSERT IN

RIGHT-HAND

TERMINALS

MOUNTING

HOLES

CIRCUIT

BOARD

Step Action

4 Connect the receiver’s wire harness to the

keypad terminals (6, 7, 8, and 9). Plug the connector at the other end of the harness into the receiver.

5 Refer to the Installation Instructions

provided with the receiver for installations regarding antenna mounting, etc.

TO CONTROL'S REMOTE KEYPAD CONNECTION POINTS.

USE MAX. of 220 ft. [67m of #22 (0.64mm) WIRE or 550 ft. (168m) of #18 (1mm) WIRE FOR EACH RUN. OBSERVE 20 ft. MAX. FOR COMMERCIAL FIRE INSTALLATIONS. (SEE RECEIVER'S INSTRUCTIONS.)

YELLOW RED BLACK

GREEN

DIP SWITCH WHITE AREAS = SWITCH HANDLES. POSITION 2-4 DETERMINE RECEIVER'S ADDRESS. CONSULT CONTROL'S INSTRUCTIONS FOR ADDRESS TO USE. DIP SWITCH BELOW SHOWN SET FOR ADDRESS "0."

DIP SWITCH

DIP SWITCH #5 (PRESET ONLY ON 5881EH)

ON: SETS 5881EH FOR USE IN COMMERCIAL FIRE APPLICATIONS (SEE THE RECEIVER'S INSTRUCTIONS)*.

OFF: USE IN NON-COMMERCIAL FIRE INSTALLATIONS. * FOR COMMERCIAL FIRE APPLICATIONS THE 5881EH PC BOARD MUST BE MOUNTED IN A SEPARATE CABINET (SEE RECEIVER'S INSTRUCTIONS FOR DETAILS).

INTERFERENCE INDICATOR LED

PLUG & SOCKET

WIRING OPENING

RECEIVER ADDRESS SETTINGS

SWITCH

POSITION

(" - " MEANS OFF)

0 1 2 3 4 5 6 7

PRESENT ONLY ON 5881EH (SEE TEXT AT LEFT)

FOR FUTURE USE

ON ON ON

ONON

ONON ONON

ONON

5881-001-V1

Figure 3-20: 5881 RF Receiver (cover removed)

3-14

Section 3 - Installing the Control

programmed for Fire, it reports in Contact ID as

Installing the 5800TM Module

Installation of this module is necessary only if you are using a 5827BD or 5804BD Bi-directional device.

The address for the 5800TM must be enabled in the control’s Device Programming in the #93 Menu Mode as a keypad and then assigned to a partition.

To install the 5800TM, perform the following steps:

Step Action

1 Mount the unit using its accompanying

mounting bracket near the RF receiver.

The 5800TM must not be installed within the control cabinet. It must be between one and two feet from the receiver’s antennas.

2 Set the module for the appropriate address.

For Address Setting 28 cut the red jumper; for Address 29 cut the white jumper; for Address 30 cut both jumpers.

3 Connect the module’s wire harness to the

keypad terminals (6, 7, 8, and 9). Plug the connector at the other end of the harness into the module.

House ID Sniffer Mode

This mode applies only if you are using a wireless keypad (e.g., 5827) or bi-directional devices (e.g., 5804BD). Use the House ID Sniffer mode to make sure you do not choose a House ID that is in use in a nearby system. The House ID must be programmed for the receiver in Device Programming in the #93 Menu Mode.

To enter House ID Sniffer mode, enter your Installer

Code + [#] + [2].

The receiver now “sniffs” out any House IDs in the area and displays them. Keep the receiver in this mode for about 2 hours. Use a House ID that is not displayed. Exit the Sniffer mode by entering your Installer Code + OFF.

As Sniffer mode effectively disables RF point reception, Sniffer mode cannot be entered while any partition is armed.

5800 Series Transmitter Setup

5800 Series transmitters have the following characteristics:

• Transmitters have built-in serial numbers that must be enrolled in the system using the #93 Menu Mode Programming, or input to the control via the downloader.

• Transmitters do not have DIP switches (except 5827, described separately).

• Some transmitters, such as the 5816 and 5817, can support more than one “zone” (referred to as loops or inputs). Each loop must be assigned a different zone number.

• For button-type transmitters (wireless keys), such as the 5804 and 5804BD, you must assign a unique zone number to each individual button used on the transmitter.

Transmitter Input Types

All transmitters have one or more unique factoryassigned input (loop) codes. Transmitters can be programmed as one of the following types:

Type Description

RF (Supervised RF)

UR (Unsupervised RF)

BR (Unsupervised Button RF)

Sends periodic check-in signals, as well as fault, restore, and low-battery signals. The transmitter must remain within the receiver’s range.

Sends all the signals that the RF type does, but the control does not supervise the check-in signals. The transmitter may therefore be carried off-premises.

These send only fault signals. They do not send low-battery signals until they are activated. The transmitter may be carried offpremises.

Transmitter Supervision

Supervised RF transmitters send a check-in signal to the receiver at 70–90 minute intervals. If at least one check-in is not received from each supervised transmitter within a programmed period (field 1∗31), the “missing” transmitter number(s) and “CHECK” or “TRBL” are displayed. Unsupervised RF transmitters (5802MN, 5804) may be carried off the premises.

Some transmitters have built-in tamper protection, and annunciate a “CHECK” condition if covers are removed.

If a loss of supervision occurs on a transmitter

a Fire Trouble (373), not Loss of Supervision (381), to the central station.

3-15

VISTA-40 Installation and Setup Guide

Transmitter Battery Life

Batteries in the wireless transmitters may last from 4 to 7 years, depending on the environment, usage, and the specific wireless device being used. Factors such as humidity, high or low temperatures, as well as large swings in temperature may all reduce the actual battery life in a given installation.

The wireless system can identify a true low battery situation, thus allowing the dealer or user of the system time to arrange a change of battery and maintain protection for that point within the system.

Compatible 5800 Series Transmitters

Model Product Input Type

5801 Panic Transmitter UR or RF

5802

5802CP

5802MN Miniature (Personal Emergency

5802MN2 Miniature (Personal Emergency

5804 Wireless Key Transmitter BR Only

5804BD Wireless Key Bi-directional

5804BDV Wireless Key Bi-directional

Pendant (Personal Emergency Transmitter)

Belt Clip (Personal Emergency Transmitter)

Transmitter)

Transmitter

Transmitter with Voice

BR Only

UR or RF

BR Only

Some transmitters (e.g., 5802, 5802CP, and 5803) contain long-life but nonreplaceable batteries. At the end of their life, the complete unit must be replaced (and a new serial number enrolled at the control).

Button-type transmitters (e.g., 5801, 5802, 5802CP and

5803) should be periodically tested, as these

transmitters do not send supervisory check-in signals.

To test the transmitters using the Transmitter ID Sniffer mode and the Go/NoGo Test Mode, see SECTION 10: Testing the System for the procedures.

Model Product Input Type

5806/5807/ 5808

5816 Door/Window Transmitter RF

5816MN Miniature Door/Window Transmitter

5816TEMP Temperature Sensor Transmitter

5817 Multi-Point Universal Transmitter RF

5818 Recessed Transmitter RF

5827 Wireless Keypad House ID

5827BD Wireless Bi-directional Keypad House ID

5849 Glassbreak Detector RF

5850 Glassbreak Detector RF

5890 PIR Detector RF

5890PI PIR Detector with Pet Immunity RF

Wireless Photoelectric Smoke Detectors

Installing Relay Devices

The VISTA-40 support up to 8 relays. Each device must be programmed as to how to act (ACTION), when to activate (START), and when to deactivate (STOP). The 4204 and/or X-10 devices may be used as relay devices.

Installing the 4204 Relay Modules

Each 4204 module provides 4 relays with Form C (normally open and normally closed) contacts.

The relay module will not operate until the device address you have set the DIP switches for is enabled in the control’s Device Programming in the #93 Menu Mode.

To install the relay modules, see Figures 3-21 and 3-22 and perform the following steps:

Step Action

1 Set the 4204 or 4204CF’s DIP switches for a

device address 01-15. Do not use an address being used by another device (keypads, RF receivers, etc.).

2 Mount the 4204 and 4204CF Modules per the

instructions provided with them.

Connect the module’s wire harness to the control (6, 7, 8, and 9). Plug the connector (other end of harness) to the module.

If you are mounting remotely, homerun each module to the control. The table below shows the maximum wire run lengths. Refer to the instructions provided with the 4204CF for its maximum permissible wire lengths.

Wire Gauge Maximum Length

#22 125 feet

#20 200 feet

#18 300 feet

#16 500 feet

3-16

➞

SWITCH 4204CF ADDRESS SETTINGS

POSITION ("—" means "OFF")

0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

ON — ON — ON — ON — ON — ON — ON — ON —

ON ON ——ON ON ——ON ON ——ON ON ——

ON ON ON ON ————ON ON ON ON ————

ON ON ON ON ON ON ON ON —————— ——

12345

➞ ➞

➞

OFF➞ON

➞

13 14 15 16

DIP SWITCH

FOR SETTING DEVICE ADDRESS AND ENABLING/DISABLING TAMPER

➞➞

COVER TAMPER (REED) SWITCH

➞➞

TB1

TB2

4-PIN CONSOLE PLUG

➞➞

121110987654321

▲

EITHER OR BOTH CAN BE USED

➞➞

DATA IN FROM CONTROL

(–) GROUND

DATA OUT TO CONTROL

YEL

BLK

GRN

RED

(+) 12V; SUPPLIES POWER TO MODULE CIRCUITRY (INCLUDING NOTIFICATION APPLIANCE RELAY COILS). CURRENT DRAIN AT 12V IS: 25 mA + (80 mA PER ACTIVE OUTPUT)

NOTIFICATION APPLIANCE AND CONSOLE DATA OUTPUTS ARE POWER LIMITED

–

NOTIFICATION APPLIANCE B 2K EOLR #610-7

POLARIZED

NOTIFICATION

APPLIANCE

–

NOTIFICATION APPLIANCE A 2K EOLR #610-7

}

–

POWER FOR NOTIFICATION APPLIANCE A, NOTIFICATION APPLIANCE B 8-28VDC OR VFW. UP TO 2.4A DEPENDING ON BELL CURRENT

- ALARM POLARITY SHOWN

- EACH OUTPUT PROVIDES STYLE Y SUPERVISION

- EACH OUTPUT RATED 1.2A MAX

- USE NOTIFICATION APPLIANCES COMPATIBLE WITH NOTIFICATION APPLIANCE POWER SUPPLY VOLTAGE RATING

You cannot use Output 1 for the Ground Start if

OFF

➞

12345

SWITCH 4204 ADDRESS SETTINGS

POSITION ("—" means "OFF")

➞

0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

➞

ON — ON — ON — ON — ON — ON — ON — ON —

➞

ON ON ——ON ON ——ON ON ——ON ON ——

➞

ON ON ON ON ————ON ON ON ON ————

➞

ON ON ON ON ON ON ON ON —————— ——

Section 3 - Installing the Control

4204

➞➞

DIP SWITCH

FOR SETTING DEVICE ADDRESS AND ENABLING/DISABLING TAMPER

COVER TAMPER (REED) SWITCH

➞➞

4-PIN CONSOLE PLUG

EITHER OR BOTH CAN BE USED

➞➞

TB1

13 14 15 16

YEL

BLK

GRN

RED

(SHOWN "OFF")

➞➞

DATA IN FROM CONTROL

(–) GROUND

DATA OUT TO CONTROL

(+) 12V

RELAY

TYPICAL

RELAY

121110987654321

▲

TB2

Figure 3-21: 4204 Relay Module

Installing X10 Devices

X-10 devices are either plugged into standard AC outlets or wired into the AC electrical system by a licensed electrician, depending on the type of device used.

Note each device’s House and Unit Code setup, as these codes will be used to program the devices in Output Programming in #93

Menu Mode described in the Programming Guide.

Figure 3-22: 4204CF Relay Module

X-10 devices require the use of a 1361X10 transformer in place of the regular 1361 transformer.

X-10 devices respond to “on” and “off” commands sent from the panel through the 1361X10 transformer.

To connect the 1361X10 transformer, see Connecting the Transformer, later in this section.

Installing the Ground Start Module

Output 1 may be used to trigger an optional 675 Ground Start Module for installations having telephone lines that require ground start instead of loop start operation to obtain a dial tone from the telco central office.

When the panel has a message to transmit to the central station, it seizes the line, goes off hook, and then triggers the 675 Module to connect the RING side of the telephone line to earth ground. The panel causes the module to break the connection between RING and earth ground when it obtains a dial tone.

The Ground Start Module is not intended for

use in UL Listed applications.

To install the 675 Ground Start Module, perform the following steps:

Step Action

1 Determine which side of the telephone line

is the RING side by connecting the (+) lead of a DC voltmeter to earth ground, and the (-) lead to one side of the telephone line.

The wire that reads + 50VDC is the RING side.

2 Connect the 675 Ground Start Module to

the panel’s J7 connector trigger output 1, to auxiliary power, and to the RING side of the telephone line as shown in Figure 3-23.

Program field 1✳46 Auxiliary Output Enable with a [0].

you are using it for Open/Close or an AAV module.

3-17

VISTA-40 Installation and Setup Guide

675

GROUND

START

MODULE

(CUT ORANGE

JUMPER)

BROWN

TELCO

RING

GROUND START TRIGGER

BLUE

TO AUX. POWER TERM. 7

TO AUX. POWER TERM. 6 (50mA CURRENT DRAW)

IF USED:

1. OUT 1 IS NO LONGER USABLE FOR SMOKE DETECTOR RESET (SEE FIELD 1*46).

2. OUT 2, 3, 4 CAN STILL BE USED TO PROVIDE ALARM STATUS INDICATIONS OR TO OPERATE A KEYSWITCH (SEE FIELD *15).

3. THE 675 IS NOT UL LISTED.

GREEN

EARTH

GROUND

BLACK

VIOLET

Figure 3-23: Ground Start Module Connect ions

Installing a Remote Keyswitch

A UL-Listed remote keyswitch, such as the 4146, can be used for remote arming/disarming of the burglary portion of the system and for silencing alarms. The keyswitch can operate in only one particular partition.

The keyswitch is wired across zone 7. This zone is no longer available as a protection zone. Be sure to program Zone 7 with a response type (e.g., type 10).

Operation

• A momentary short across zone 7 arms the partition in the AWAY mode, and a short held for more than 3 seconds arms the partition in STAY mode. A subsequent short disarms the partition.

• The keyswitch LEDs indicate the partition’s status (see table below).

• A momentary short across Zone 7 silences alarm bell and keypad sounds, and disarms the system if it was armed. A subsequent short across Zone 7 clears the alarm memory indication and resets 2wire smoke and glassbreak detectors (if used).

LED Indications

Green Red Indication

On Off Disarmed & Ready

Off Off Disarmed & Not Ready

Off On Steady Armed Away

Off Slow Flash Armed Stay

Off Rapid Flash Alarm Memory

J7 CONNECTOR

4142TR

CABLE

GRAY (GROUND)

YELLOW (OUT 1)

WHITE (GROUND)

RED (OUT 2)

GREEN (GROUND)

BROWN (OUT 3)

BLUE (GROUND)

BLACK (OUT 4)

N/U

123456789

Keyswitch Tamper Operation

The tamper switch need not be used for fire or UL Household Burglary installations. For UL Commercial Burglary installations, the tamper switch must be wired to a zone (zone 6 in Figure 3-24).

Program that zone for Day Trouble/Night Alarm (response type 5). When the keyswitch is removed from the wall, the tamper switch opens, causing an alarm or trouble on the zone. This also causes the control to disable keyswitch operation until the tamper is restored and the associated partition is disarmed.

Wiring for the Remote Keyswitch

To install the 4146 keyswitch, perform the following steps:

Step Action

1 Connect the 4146 to the panel as shown in

Figure 3-24.

2 If you are using the tamper, make sure it is

connected to a zone.

3-18

The keyswitch reports as user 0, if Open/Close reporting is enabled in field ✳40.

TO AUX POWER

(TERMINAL 6)

Section 3 - Installing the Control

TO J7 / OUT 2

TO J7 / OUT 4

ZONE

TO ZONE 7 (+)

(TERMINAL 20)

Figure 3-24: Remote Keyswitch Wiring

2K ELOR

Remote Keypad Sounder

An optional Amseco PAL 328N Piezo Sounder can be used to duplicate the sounds produced by the keypad’s built-in sounder. The panel will remote all sounds (e.g., alarm, trouble, chime, entry/exit, etc.) produced by the keypad’s built-in sounder except for the short beeps associated with keypad key depression. One application of this feature might be to produce chime sounds at a distant location from the panel’s keypads.

Remote Keypad Sounder Setup

To setup for a remote keypad sounder, connect the piezo sounder to the panel’s positive auxiliary power output and to Output 1 on the J7 connector as shown in Figure 3-25.

YELLOW WHITE

RED

(ARMED)

820

ohms

RED BLACK

(CONTACTS CLOSE WHEN

SWITCH DEPRESSED).

GREEN

(READY)

820

ohms

TAMPER SWITCH

LOCK SWITCH

(NORMALLY OPEN)

2K ELOR

J7_keyswitch

To duplicate the keypad sounds for a particular partition, program that partition number in field ✳15.

Program field 1✳46 Auxiliary Output Enable with a [2].

IF USED.

1. OUT 1 IS NO LONGER USABLE FOR SMOKE DETECTOR RESET OR GROUND START (SEE FIELD 1*46).

2. OUT 2 & 4 CAN NO LONGER BE USED TO PROVIDE ALARM TRIGGERS.

TO AUX POWER +

TERMINAL 6

10mA CURRENT DRAIN)

RED

BLACK

–

AMSECO PAL-328N PIEZO SOUNDER

4142TR CABLE

GRAY (GROUND)

YELLOW (OUT 1)

WHITE (GROUND)

RED (OUT 2)

GREEN (GROUND)

BROWN (OUT 3)

BLUE (GROUND)

BLACK (OUT 4)

J7 CONNECTOR

N/U

1 2 3 4 5 6 7 8 9

J7_trigcon-001-V1

Figure 3-25: Remote Keypad Sounder Wiring

Long Range Radio Connected to the J7 Triggers

These triggers may be used to trip auxiliary alarm signaling equipment such as the 7720, 7720ULF, and 7920SE Long Range Radios.

The triggers are common to all partitions and must be enabled for each partition (field 2✳20).

The fire and burglary/audible panic alarm triggers are normally LOW and go HIGH until a User Code + OFF is entered in all enabled partition(s) that display these conditions.

The silent panic/duress trigger latches HIGH, except for duress, which is momentary.

Refer to the installation instructions that accompany your radio for the connections to the control panel.

Installing a 4100SM

The 4100SM is used to print event log reports to a serial printer. NOTE: See SECTION 4: Programming for the programming details when using the 4100SM.

Printer Configurations

Configure the serial printer as follows:

• 8 data bits, no parity, 1 stop bit

• 1200 baud

• Hardware handshaking using DTR.

3-19

VISTA-40 Installation and Setup Guide

Connecting the 4100SM to a Serial Printer

To connect a serial printer using the 4100SM, refer to Figure 3-26 and perform the following steps:

Step

Action

Connect terminal 1 on the 4100SM to the Violet wire on the 4142TR cable.

Connect terminal 6 on the 4100SM to the Brown wire on the 4142TR cable.

Connect the 4142TR cable to J8 on the control.

Connect terminals 8 and 7 of the 4100SM to terminals 6 and 7 (aux. power (+) and (-)), respectively of the control.

Connect the UL EDP Listed serial printer to the 4100SM Interface Module.

The 4100SM Module is supplied with a 10foot RS232 cable. A longer cable can be used if the VISTA-40 is separated from the serial printer by more than 10 feet, but the total cable length should be less than 50 feet.

123456789

VIOLET

GREY

IN 2

PRINTER DTR

4100SM JUMPERS (CUT TO SET RESPECTIVE SIGNAL FLOATING)

COLOR FUNCTION PIN #

RED BLUE

WHITE

RED

GREEN

OUT 5

OUT 6

BROWN

GROUND

YELLOW

IN 3

GROUND

CTS

DSR

J8 CONNECTOR

BLUE

BLACK

GROUND

4142TR CABLE (SUPPLIED WITH 4100SM)

To TB6 Aux. Power (+)

(25mA current draw)

To TB7 Aux. Power (-)

USE GENDER CHANGER SUPPLIED WITH 4100SM

IF PRINTER HAS DB25

MALE CONNECTOR

8 5 6

4100SM SERIAL MODULE

+ PWR

- (GND)

RXD

not used

TXD

not used

DTR

RED

BLUE WHITE

Cable

Supplied with

4100SM

SERIAL PRINTER SET FOR: 8 DATA BITS

EVEN PARITY STOP BIT 300/1200 BAUD

Figure 3-26: 4100SM Using a Serial Printer

NOTE: See the 4100SM Installation Instructions for details concerning the serial printer operation.

4100SM-011-V0

Installing the 4285/4286 VIP Module

The 4285/4286 VIP Module is an add-on accessory that permits the user to access the security system (and relays) via a TouchTone telephone. This may be done either from the premises or by calling the premises from a remote location. Only one VIP Module can be used in a security system. This module must be enabled as Device Address 4 in the Device Programming in #93 Menu Mode, and must be assigned to a partition.

The 4285/4286 is wired between the control panel and the premises’ handset(s) (see Figure 3-27). It listens for TouchTones on the phone line and reports them to the control panel. During on-premises phone access, it powers the premises phones. During off-premises phone access, it seizes the line from the premises phones and any answering machines.

The 4285/4286 VIP Module is not permitted in

UL installations.

Detailed operating instructions for phone access to the security system are provided with the VIP Module.

The 4285/4286 VIP Module features:

• Allows the user to receive synthesized voice messages over the phone regarding the status of the security system.

• Allows the user to arm and disarm the security system and perform most other commands using the telephone keypad.

• Allows the user to control relays using the telephone keypad.

• Provides voice annunciation over the phone to confirm any command that is entered.

• Announces many of the same words that would normally be displayed on an alpha keypad under the same system conditions. Refer to the words in bold on the Alpha Vocabulary list found in the #93 Menu Mode in the Programming Guide.

• Can be supervised for connection to control panel (annunciated and reported as Zone 804).

• The VIP module will not operate until the device address (04) is enabled in the control’s Device Programming in #93 Menu Mode.

• Do not mount the VIP Module on the cabinet door or attempt to attach it to the PC board.

3-20

Section 3 - Installing the Control

To install the VIP module, perform the following steps:

Step Action

1 Mount the module in the control cabinet if

space is available or, if this is not possible, on the side of the cabinet or adjacent to it.

If you mount the VIP Module inside the control cabinet, attach it to the cabinet’s

interior surface with 2-faced adhesive tape. You may leave the module’s cover off if it is mounted within the cabinet.

If you mount the module outside the cabinet, use the screw holes at the rear to

mount horizontally or vertically (2-faced adhesive tape may be used, if preferred).

2 Affix the 4285/4286 connections label

(supplied separately) to the inside of the VIP Module’s cover, if the cover is used. Otherwise, affix the label to the inside of the control cabinet’s door.

3 Make 12V (+) and (–) and data-in and data-

out connections from the VIP Module to the control, using the connector cable supplied with the VIP Module. These are the same connections as for remote keypads.

SPEAKER NOTE: IF CONNECTING SINGLE SPEAKER, USE 8-ohm SPEAKER ONLY.

4286 VIP MODULE

NOTE:

4286 DEVICE ADDRESS IS FACTORY SET TO “4”

YELLOW

GREEN

4500

THERMOSTAT

IF CONNECTING 2 SPEAKERS, USE 4-ohm or 8-ohm SPEAKERS AND CONNECT IN SERIES.

SPEAKER

VOLUME

CONTROL

NO CONNECTION

123456 7

KEYED HEADER

KEYPAD CONNECTIONS

YELLOW NO CONNECTION RED BLACK GREEN

TO CONTROL PANEL

Step Action

SEE SPEAKER NOTE

GREY BROWN

RED

GREEN

TIP RING TIP RING HANDSET INCOMING

TELCO LINE

Connect the module to the phone line as shown below. See Figure 3-27.

4285/4286 Terminal Connects to direct

1. Phone In (Tip) green wire

2. Phone In (Ring) red wire

3. Phone Out (Tip) brown wire

4. Phone Out (Ring) gray wire

5. No Connection

6. Audio Out 1∗ Speaker

7. Audio Out 1∗ Speaker



Supported by the 4286 only

connect cord:

Use an RJ31X Jack with the phone cable supplied with the control to make connections to the VIP module. Make connections exactly as shown in Figure 3-27. This is essential,

even if the system is not connected to a central station. The 4285/4286 will not function if this is not done.

• If touch-tones are not present following phone access to the security system via an on- premises phone, try reversing the pair of wires connected to terminals 3 and 4 on the 4285/4286.

• If the phone plug is disconnected from the control, the premise’s phones will not operate.

INCOMING TELCO LINE

TIP

RING

TIP

RJ31X

RING

PREMISES ANSWERING MACHINE AND PHONES

ANSWERING

MACHINE

EARTH GROUND

JACK

CALLER ID

UNIT

IMPORTANT NOTE FOR EXISTING INSTALLATIONS:

EXISTING WIRES CONNECTED TO THE “HANDSET” TERMINALS ON CONTROL MUST BE MOVED FROM THERE TO TERMINALS 3 AND 4 ON THE 4286.

U.S. PATENT No. 4791658

THIS DEVICE COMPLIES WITH FCC RULES, PART 68 FCC REGISTRATION No. AC3USA-74659-KX-N RINGER EQUIVALENCE: 1.0B

FOR COMPLETE INFORMATION, SEE INSTALLATION INSTRUCTIONS N6431-3 ACCOMPANYING 4286 VIP MODULE

4286_wiring-002-V1

Figure 3-27: VIP Module Connections

3-21

VISTA-40 Installation and Setup Guide

Installing the Audio Alarm Verification Module

Audio Alarm Verification (AAV) is not permitted

in UL installations.

• 685 Receiver software must be rev. 4.6 or higher. Earlier versions will not hold the phone line connection.

• Contact ID code for “Listen-in to Follow” is

606. Contact ID is the only reporting format that will send a “Listen-in to Follow.”

• If you are also using a 4285/4286 VIP Module, be sure to follow Figure 3-30 when making connections.

The UVS consists of a UVCM and at least one UVST. The UVCM board has a DC power jack and a 34position terminal block for making connections to a DC power source, UVSTs, telephone lines, music source, or to the 4286 VIP Module; and to a control panel’s voice trigger and bell outputs (if required). Refer Figure 3-28 for wiring connections. For a detailed explanation of the wiring connections and the functions of the DC power jack and terminal block positions, refer to the installation instructions that accompany the UVS.

If the phone plug is disconnected from the control, the premise’s phones will not operate.

NOTES:

• When the AAV indicates that the audio alarm verification session is completed, all keypad sounds are restored. Sirens are restored if the alarm timeout period has not expired.

• As part of its fail-safe software, the control limits all audio alarm verification sessions to 15 minutes. This is because once the session begins, the AAV Module controls the duration.

• If a new Fire alarm should occur during a session, the control breaks the phone connection and sends the new Fire Alarm report, then re-triggers the AAV Mode. All other dialer messages triggered during ongoing conversation are held until either the AAV Module signals that it is inactive, or the 15-minute timeout occurs.

3-22

UVCM AND UVST SUMMARY OF CONNECTIONS

Refer to UVS Installation and Setup Guide K4214 for complete information

SW SWITCH BANK 1

1 UVST 1 AUX AUDIO, ON = ENABLED 2 UVST 2 AUX AUDIO, ON = ENABLED 3 UVST 3 AUX AUDIO, ON = ENABLED 4 UVST 4 AUX AUDIO, ON = ENABLED 5 UVST 5 AUX AUDIO, ON = ENABLED 6 UVST 6, ON = OUTSIDE, OFF = INSIDE 7 UVST 7, ON = OUTSIDE, OFF = INSIDE 8 VOICE TRIGGER, ON = IMMED, OFF = CALLBACK

SHIPPED WITH ALL SWITCHES IN "ON" POSITION.

ON ON

12345678 12 345678

SWITCH BANK 1 SWITCH BANK 2

ALTERNATE +12 VDC IN FOR PLUG-IN WALL PACK (SEE NOTE 2)

GND

+12VDC IN

RISING VOICE TRIG

NOT USED

1 2 3 4 5 6 7 8 9 10111213

SW SWITCH BANK 2

1 FUTURE USE, SET TO ON 2 FUTURE USE, SET TO ON 3 TELEPHONE RING, ON = ENABLED 4 END USER VOICE, ON = DISABLED 5 FUTURE USE, SET TO ON 6 CS CODE LEARN, ON = DISABLED 7 USER CODE LEARN, ON = DISABLED 8 FUTURE USE, SET TO ON

VOICE RELAY NC

FALLING VOICE TRIG

VOICE RELAY POLE

GND

INSIDE UVST PWR

OUTSIDE UVST PWR

ALARM TRIG IN

MUSIC SOURCE

OPTIONAL (NOTE 4)

MIC 1

MIC 2

Section 3 - Installing the Control

NOTE 1: CONNECT TO PROPER EARTH GROUND.

POWER MAY ALSO BE SUPPLIED BY A LISTED CLASS 2

NOTE 2: POWER SUPPLY RATED 12VDC, MIN 600mA CONNECTED TO THE UVCM +12VDC IN AND GND TERMINALS.

NOTE 3:

SOME CONTROL PANELS USE BUILT-IN TRIGGER AND SOME USE 4204 RELAY MODULE. REFER TO AAV SECTION OF CONTROL PANEL INSTALLATION AND SETUP GUIDE FOR CONNECTION.

NOTE 4: EITHER MUSIC SOURCE OR 4286 VIP MODULE CAN BE USED BUT NOT AT THE SAME TIME.

NOTE 5: DO NOT CONNECT IF 4286 VIP MODULE IS USED.

TIP

NOT USED

EARTH GND

GND

AUXILIARY AUD ENABLE

AUXILIARY AUD IN

SPKR 7

SPKR 6

SPKR 5

SPKR 4

SPKR 3

SPKR 2

SPKR 1

GND

INSIDE UVST PWR

MIC 7

MIC 6

MIC 5

MIC 4

MIC 3

14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34

NOTE 1

AUDIO OUT

GND

RING

AUXILIARY AUDIO LEVEL ADJUSTMENT TRIM POT

(OPTIONAL; NOTE 5)

APPROPRIATE

INPUT

CONTROL PANEL

GREEN

INCOMING RING

BELL OUTPUT

COMPLIES WITH FCC RULES, PART 68 FCC REGISTRATION NO. AC3 USA-40133-SP-T RINGER EQUIVALENCE: 1.0B

THIS DEVICE COMPLIES WITH PART 15 OF FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.

INCOMING TIP

HANDSET RING

HANDSET TIP

SPEAKER VOLUME TRIM POT

RED

SPEAKER

VOLUME

CONTROL

4286 VIP MODULE

OPTIONAL (NOTE 4)

1234

FOR COMPLETE INFORMATION, SEE

4286 VIP MODULE INSTRUCTIONS.

PLUG

DIRECT

CONNECT

CORD

1234 567

KEYED HEADER

WARNING: TO PREVENT RISK

OF ELECTRICAL SHOCK,

DISCONNECT TELCO JACK

BEFORE SERVICING THIS PANEL.

TIP

RJ31X

JACK

RING

GRAY

BROWN

ANSWERING

MACHINE

RING

TIP

PREMISES ANSWERING MACHINE AND PHONE (S)

INCOMING TELCO LINES

UVCM_UVST-SOC-V1

SPKR

GND

MIC

(NOTE 2)

GND

AUX PWR (12VDC)

UVST PWR

VOLUME CONTROL DIAL

UVST

1 2

3 4

SELECT

(SEE NOTE 3)

2-WAY VOICE TRIGGER

TYPICAL 1 OF 7

Figure 3-28: UVS Connections to the Control Panel

Connecting the Transformer

This product uses the 1361 transformer (1361CN in Canada). If you are using X-10 devices, the 1361X10 transformer interface must be used instead of the regular 1361 transformer. The 1361X10 supplies the control panel with AC, and also sends control pulses through the premises electrical system to control the X10 devices.

Use 1361CN Transformer in Canadian

installations.

3-23

VISTA-40 Installation and Setup Guide

Power Limiting Outputs

All outputs are power-limited as per UL985/UL1023. The following table shows the maximum current that may be drawn from each output.

Output Maximum Current Draw

Auxiliary Power 750mA

Polling Loop 64mA

Alarm Output 1.7A

For Household Fire or Combination Household Fire/Burglary Installation: The total current drawn

from the auxiliary power, the polling loop, and the alarm output combined must not exceed 750mA to comply with the battery independence requirements in UL985.

For Household Burglary-Only Installations: The total current drawn from the alarm output may be up to

1.7A. A battery must be installed to supply the current of the combined auxiliary power, polling loop, and alarm output in excess of 750mA.

PRIMARY POWER

Supplied by a transformer which is rated at

16.5VAC, 40VA. Caution must be taken when wiring this transformer to the panel to guard against blowing the fuse inside the transformer (non-replaceable).

Connect to

12VDC, 4AH

or 12VDC, 7AH

GEL CELL

BATTERY

CHARGING

VOLTAGE

13.7VDC

BATTERY

TABS

RED (+)BLK (-)

Connect to 24hr. source of AC mains

Failure to observe the polling loop current rating will cause polling loop malfunction. Failure to observe the auxiliary power current rating will result in a battery that does not charge properly or possibly a tripped circuit breaker.

To connect the transformer to the control, perform the following steps:

Step Action

1 Connect all installed devices to the control.

2 Wire the 1361 Transformer (1361CN in

Canada) to the panel (before connecting the battery) as shown in Figure 3-29, or wire the 1361X10 Transformer as shown in Figure 3- 30 (if using X-10 devices).

3 Plug the transformer into a 24-hour,

uninterrupted, 120VAC, 60Hz outlet. After a few seconds, the keypad display appears.

123

NOTE:

WHEN POWERING UP THE PANEL, PLUG THE TRANSFORMER IN BEFORE CONNECTING THE BATTERY.

TRANSFORMER

16.5VAC, 40VA

ADEMCO No.1361

or 1361X10, if X-10

DEVICES WILL BE USED.

NO CONNECTION

pwr_bat_conn-001-V1

Figure 3-29: 1361 Transformer and Battery Connections

X10 TRANSFORMER/INTERFACE

TERMINALS

ON CONTROL

BOARD

Sync

Output

Signal

Common

Data

123456789

GRAY

WHITE

YELLOW

VIOLET

X10

RED

BROWN

GREEN

J8 CONNECTOR

BLACK

BLUE

4142TR CABLE

1361X10-001-V0

Figure 3-30: 1361X10 Transformer Connections

3-24

Panel Earth Ground Connections

Section 3 - Installing the Control

In order for the lightning transient protective devices in

• AC Power Outlet Ground: Available from 3-

this product to be effective, the designated earth ground terminal (terminal 30) must be terminated in a good earth ground. Recommended wire gauge for the ground connection is #16 AWG, run no farther than 30 feet. The following are examples of good earth grounds available at most installations:

• Metal Cold Water Pipe: Use a noncorrosive metal

strap (copper is recommended) firmly secured to the pipe to which the ground lead is electrically connected and secured.

Determining the Control’s Power Supply Load

Use the tables that follow to calculate the total current for the Auxiliary Power, the Alarm Output, and the Polling Loop. In each table, multiply each device’s standby and/or alarm current by the number of units used.

1. In Table 1, enter devices used on the polling loop. Calculate total current draw on the polling loop.

Table 1: Total Polling Loop Current Draw

Polling Loop Device Current # of Units Total

2. In Table 2, enter devices used on Auxiliary Power.

Table 2: Auxiliary Power Current Load

Model #

prong, 120VAC, power outlets only. To test the integrity of the ground terminal, use a three-wire circuit tester with neon lamp indicators, such as the UL-Listed Ideal Model 61-035, or equivalent, available at most electrical supply stores.

The panel requires the earth ground connection for its lightning transient protection devices.

Calculate standby and alarm currents, then add to get Auxiliary Power current subtotal.

Total Current

Device

Device Current X

Standby Alarm

# of Units

(terminals 6 & 7 – 750mA max.)

Polling Loop Subtotal

(terminals 24 & 25 – 64mA) ✳

✳ The total current cannot exceed 64mA. If total load exceeds

64mA, then a 4297 Loop Extender Module can be used. Note that the total number of points connected to the panel cannot exceed 55.

Auxiliary Power Subtotal

3-25

VISTA-40 Installation and Setup Guide

3. In Table 3, enter devices connected to the Alarm Output. Calculate alarm currents, then add to get the Alarm Output current subtotal.

Table 3: Alarm Output Current Load

Device

Model #

XXXXXX

(terminals 4 & 5 – 1.7A max.)

Device Current X

# of Units

Alarm Output Subtotal

Total Current

Standby Alarm

4. In Table 4, enter the total calculated subtotals of all listed outputs from Tables 1 through 3, then add to get the combined current.

Table 4: Total VISTA-40 Current Load

Polling Loop Subtotal (see Table 1)

Aux. Power Subtotal (see Table 2)

Alarm Output Subtotal (see Table 3)

VISTA-40 PCB Current (Includes 2-

wire smoke detector loading on

zone 1)

Total Current Load

Total Current

Standby Alarm

250mA 330mA

Determining the Size of the Standby Battery

The cabinet supplied with the control panel can house batteries of up to 12V, 14AH (two 12V, 7AH batteries wired in parallel). The VISTA-ULKT kit provides a cabinet that can house batteries of up to 12V, 17.2AH and that may be used with this panel. The total standby current drawn from the auxiliary power and polling loop outputs combined must be limited to 270mA when 14AH batteries are used; and to 390mA when 17.2AH batteries are used.

DO NOT use Gates batteries (sealed lead-acid type). These batteries require a different charging voltage than is supplied by the panel.

Household Fire or Combination

Household/Fire/Burglary installations require the use of a backup battery that is capable of providing 24 hours of standby time followed by 4 minutes of alarm time. UL1023 Household Burglary-only installations require the use of a backup battery that is capable of providing 4 hours of standby time followed by 4 minutes of alarm time.

Use Table 5 to determine the required backup battery capacity and use Table 6 to determine the battery model number. A dual battery harness is supplied that allows two batteries to be wired in parallel for increased capacity.

5. Using the total calculated from Table 4, calculate the battery capacity required for the installation.

Table 5: Battery Capacity Calculation Table

Capacity

Standby Capacity

Alarm Capacity

Total Capacity

Formula

For 4-hour standby time: Total standby current X 4 hours

X 1.4 contingency factor.

For 24-hour standby time: Total standby current X 24 hours X 1.1 contingency factor.

For 4-, 5-, or 15-minute alarm time:

Total alarm curr.

X 0.067 (4 min) X 0.250 (15 min)

Add standby and alarm capacities

Calculated

Value

3-26

Section 3 - Installing the Control

entry into the Test mode initiates a battery test.

6. Use the Battery Selection Table to select the appropriate battery for the installation.

Table 6: Battery Selection Table

Capacity Recommended Battery Comment

4AH Yuasa NP4-12

7AH Yuasa NP7-12

12AH Yuasa NP12-12 Fits in large

mercantile cabinet only.

14AH Yuasa NP7-12 Connect two

in parallel.

17.2AH Yuasa NPG18-12 Fits in large mercantile cabinet only.

7. Connect the battery, referring to Figure 3-29.

The standby battery is automatically tested for 10 minutes every 4 hours, beginning 4 hours after exiting Programming mode. In addition,

3-27

VISTA-40 Installation and Setup Guide

3-28

SECTION 4

Programming

•••••••••••••••••••••••••••••••••••••••••••••••••

Program Modes

There are two programming modes for the VISTA-40. These are the Data Field Program Mode and the #93 Menu Mode. The Data Field Program Mode is where many system options are programmed. The #93 Menu Mode is an interactive mode that requires a 2-line alpha keypad (6139/6160).

Entering and Exiting Programming Mode

Enter Programming mode using either method a or b:

a. Press both the [✳] and [#] keys at the same time

within 30 seconds after power is applied to the control.

b. Enter the Installer Code + [8] + [0] + [0] keys.

The factory installer code can be changed once in the Program mode (field ✳00).

NOTE: The default for the Installer Code is 4140.

Data Field Programming Mode

In the Data Field Program Mode you may access any field simply by entering either [✳] or [#] + the field number:

• To write or change information in a field press [✳] + the field number (✳03).

• To read the information in a field press [#] + the field number (#03).

When the entries for a field are completed, the keypad beeps three times and advances to the next field.

Summary of Data Field Programming Commands

✳91

✳92

✳93

✳94

✳99

✳98

Select partition for programming partition-specific fields

Display the software revision level of the control panel

Enter Menu mode programming

Go to next page of fields

Go back to previous page of fields or exit Programming Mode with no installer code lockout

Exit Programming Mode with Installer Code lockout

The factory-loaded defaults (✳97) enable keypad addresses 00-03 only. A keypad set to one of these addresses must be used to program the system initially.

Local keypad programming can be disabled through Compass downloading software. If this is done, Program mode can only be accessed via the downloading software.

Exit the Programming mode by either method a or b:

a. Press [✳] + [9] + [8]. Exiting by this method

prevents the installer code from being used to reenter Programming mode. Only method “a” can be used to re-enter Programming mode.

b. Press [✳] + [9] + [9]. Exiting by this method

permits the installer code to be being used to reenter Programming mode.

Moving Between Programming Levels

The data fields are grouped into three levels (referred to as “pages”). The first page is accessed as soon as Programming Mode is entered.

The second and third pages of data fields are indicated at the keypad by a 1 and 2, respectively, in front of the 2-digit field address. “ALT PROGRAM MODE” is displayed along with a “100” or “200,” indicating which page of program fields is accessed.

To access the next level of programming fields, perform the following steps:

Step Action

2 Press [7] + [XX], where XX = the last two

NOTES:

Press ✳94 to move to 2 press ✳99 to move back to 1

Press ✳94 to move to 3rd page (fields 2✳00 - 2✳21); press ✳99 to move back to 2

Press ✳94.

digits of the program field, and make the desired entry.

page, (fields 1✳01 - 1✳76);

page.

page

4-1

VISTA-40 Installation and Setup Guide

Entry Errors

• If an address is improperly entered, the keypad displays “FC.”

• If a program entry is improperly entered (for example, a larger number than is permitted), the keypad display will go blank.

In either of the above cases, simply re-enter [✳] + the correct field number and then enter the correct data.

Programming System-Wide Data Fields

Values for some programming fields are system-wide (global), and some can be different for each partition (partition-specific).

To program system-wide data fields, perform the following steps:

Step Action

1 Enter Program Mode: Installer Code + 8 0 0.

The following display appears:

2 If the control has not been programmed before,

enter ✳97 to load factory defaults.

Press [✳] and enter the first field number to be programmed (for example, ✳00, Installers Code). Make the desired entry. When the field is complete, the keypad beeps three times and advances to the next field. If you do not want to change the next field, press [✳] and enter the next field number to be programmed.

To change to the next page of fields, press ✳94. To return to the previous page of fields, press ✳99.

Press ✳99 or ✳98 to exit Program Mode.

The partition-specific programming fields are automatically skipped when programming the global fields. If the system has only 1 partition, the partition-specific fields are not automatically skipped.

Program Mode

✳Fill # View – 00

First Page of fields

(✳00 - ✳90)

NOTE: If the number of digits that you enter in a data field is fewer than the maximum permitted (for example, a phone number), the keypad displays the last entry and waits. To proceed, enter [✳] + the next data field you wish to program.

Programming Partition-Specific Data Fields

To program partition-specific data fields once in Program Mode, do the following:

Step Action

1 Enter Program Mode: Installer Code + 8 0

3 Enter a partition-specific field number (e.g.,

4 Repeat this procedure for the other partition.

NOTE: To return to the global program fields before finishing all fields, enter any global field number.

Enter any global field number to return to the global

Press ✳91, which will prompt you for the partition number desired.

✳09) to begin programming.

When the first field’s entry is completed, the next partition-specific field is automatically displayed. When all partition-specific fields are programmed, the system returns to the global programming fields (page 1 fields).

Programming Partition-Specific Fields

Press ✳91 to select a partition.

Enter the partition to be programmed.

Enter a partition-specific field number and make

entry.

fields at any time.

#93 Menu Mode Programming

The #93 Menu Mode is an interactive mode through which much of the system’s programming is done. In this mode, there are “question and answer” prompts that can be accessed once Data Field Program Mode has been entered. These prompts require a 2-line alpha keypad (6139/6160).

4-2

After programming all system-related programming fields in the usual way, press #93 while still in programming mode to display the first choice of the menu-driven programming functions. Press 0 (NO) or 1 (YES) in response to the displayed menu selection. Pressing 0 will display the next choice in sequence.

VISTA-40 Installation and Setup Guide

Below is a list of the main menus. For details refer to the VISTA-40 Programming Guide.

MAIN MENU

ZONE PROG?

1 = YES 0 = NO 0

OPTIONS

For programming the following:

• Zone Number

• Zone Response Type

• Partition Number for Zone

• Dialer report code for zone

• Input Device Type for zone (whether RF, polling loop, etc.)

• Enrolling serial numbers of 5800 Series transmitters & serial polling loop devices into the system.

EXPERT MODE?

1 = YES 0 = NO 0

ALPHA PROG?

1 = YES 0 = NO 0

Same as Zone Programming except:

• Done with a minimum number of keystrokes.

• Can program wireless keys using pre-defined templates.

For entering alpha descriptors for the following:

• Zone Descriptors

• Installer’s Message

• Custom Words

• Partition Descriptors

• Relay Descriptors

DEVICE PROG?

1 = YES 0 = NO 0

For defining the following device characteristics for addressable devices, including keypads, RF receivers (5881), relay modules (4204), and 4285/4286 VIP Module:

• Device Address

• Device Type

• Keypad Options (including Partition assignment)

• RF House ID

RELAY PGM?

For defining relay device functions.

1 = YES 0 = NO 0

RLY VOICE DESCR?

For entering voice descriptors for relays to be used with the 4285/4286 VIP Module.

1 = YES 0 = NO 0

CUSTOM INDEX ?

For creating custom word substitutes for VIP Module annunciation.

1 = YES 0 = NO 0

Following is a list of commands used while in the Menu Mode:

#93 Menu Mode Programming Commands

#93 Enters Menu Mode.

[✳]

[#] Backs up to previous screen.

0 Press to answer NO.

1 Press to answer YES.

00, or 000+[✳]

Serves as [ENTER] key. Press to have keypad accept entry.

Quits Menu Mode and goes back to Data Field Programming Mode, if entered at first prompt of each main menu option.

4-4

VISTA-40 Installation and Setup Guide

Zone Number Designations

The VISTA-40 supports up to 64 zones of hardwire, polling loop and/or wireless protection, distributed among up to 2 partitions. The following table lists the zone numbers and the types of sensors that can be used with each, and some alternate functions of the zones.

Zone Function

1 2-wire Smoke Detectors (if used)

5 Audio Alarm Verification (if used)

7 Keyswitch (if used)

8 Latching-Type Glassbreak Detectors (if used)

1-9 Traditional Hardwired Zones

1-64 5800 Series Wireless Devices

10-64 Polling Loop Devices

96 # + 3 Panic

✳ + 1 Panic

✳ + # Panic

Zone Defaults

Zone # Zone Type Zone # Zone Type

01 09 70 00

02 03 87 00

03 03 88 00

04 03 90 00

05 03 91 00

06 03 92* N/A

07 03 95 00

08 03 96 00

09 03 97 05

10–64 00 99 06

NOTES: * Zone 92 is the Duress zone. Programming of the zone response type is not applicable. This zone requires only the report code programming.

Zone Index

The zones are designated as follows:

ZONE # RANGE

01 – 64 Protection

70, 88, 89, 90, 91, & 97

92, 95, 96, & 99

Supervisory zones should be given a response type of 05 (Trouble by Day, Alarm by Night).

ZONE

FUNCTION

zones

System Supervisory Zones

Duress and Keypad Panics

ACTUAL ZONE

As indicated

70: Bell Supervision

88: 2

89: 2

90: 1

91: 1

97: Polling Loop (short

92: Duress

95: 1 + ✳ panic (A key)

96: 3 + # panic (C key)

99: ✳ + # panic (B key)

Wireless Receiver –

not receiving signals

Wireless Receiver –

not talking to control

Wireless Receiver –

not receiving signals

Wireless Receiver –

not talking to control

circuit)

Communication Defaults

*45 PRIMARY FORMAT [1] ADEMCO Contact ID

*46 LOW SPEED FORMAT (Prim) [0] ADEMCO Low Speed

*47 SECONDARY FORMAT [1] ADEMCO Contact ID

*48 LOW SPEED FORMAT (Sec.) [0] ADEMCO Low Speed

*49 CHECKSUM VERIFICATION [0] [0]

No checksum Primary Secondary

*50 SESCOA/RADIONICS SEL. [0] Radionics

4-4

*51 DUAL REPORTING [0]

*52 STANDARD/EXPANDED REPORT FOR PRIMARY

[0] [0] [0] [0] [0] [0] standard

Alarm Rstr Bypass Trbl Opn/Cls Low Bat

*53 STANDARD/EXPANDED REPORT FOR SECONDARY

[0] [0] [0] [0] [0] [0] standard

Alarm Rstr Bypass Trbl Opn/Cls Low Bat

Section 4 – Programming

Communication Defaults for Zones

ZONE # 1st 2nd ZONE # 1st 2nd ZONE # 1st 2nd ZONE # 1st 2nd

1 01 00 21 06 00 41 11 00 61 01 00 2 02 00 22 07 00 42 12 00 62 02 00 3 03 00 23 08 00 43 13 00 63 02 00 4 04 00 24 09 00 44 14 00 64 04 5 05 00 25 10 00 45 15 00 70 00 00 6 06 00 26 11 00 46 01 00 88 00 00 7 07 00 27 12 00 47 02 00 89 00 00 8 08 00 28 13 00 48 03 00 90 00 00

9 09 00 29 14 00 49 04 00 91 00 00 10 10 00 30 15 00 50 05 00 92 (DURESS) 11 00 11 11 00 31 01 00 51 06 00 95 00 00 12 12 00 32 02 00 52 07 00 96 00 00 13 13 00 33 03 00 53 08 00 97 06 00 14 14 00 34 04 00 54 09 00 99 06 00 15 15 00 35 05 00 55 10 00 ALARM RST. 00 00 16 01 00 36 16 00 56 11 00 TROUBLE 00 00 17 02 00 37 17 00 57 12 00 TRBLE. RST 00 00 18 03 00 38 18 00 58 13 00 BYPASS 00 00 19 04 00 39 19 00 59 14 00 BYP. RST. 00 00 20 05 00 40 10 00 60 15 00

Zone Response Type Definitions

Each zone must be assigned a zone type, which defines the way in which the system responds to faults in that zone. There are three keypad-activated zones (panic keys; see note) for each partition, a polling loop supervision zone, and four RF supervisory zones, two for each RF receiver installed. Zone types are defined below.

Type 00: Zone Not Used

Program with this zone type if the zone is not used.

Type 01: Entry/Exit #1 Burglary

Provides entry delay whenever the zone is faulted and the system is armed in the AWAY or STAY mode. When the panel is armed in the INSTANT or MAXIMUM mode, no entry delay is provided. Exit delay begins whenever the control is armed, regardless of the arming mode selected. These delays are programmable.

Assign this zone type to zones that are used for primary entry to and exit from the facility.

Type 02: Entry/Exit #2 Burglary

Provides a secondary entry delay, if the system is armed in the AWAY or STAY modes and the zone is faulted. When the panel is armed in the INSTANT or MAXIMUM mode, no entry delay is provided. Secondary exit delay begins whenever the control is armed, regardless of the arming mode selected. These delays are programmable.

Assign this zone type to zones that are used for entry and exit of the facility and require more time than the primary entry and exit point. Delay times for this zone type must be greater than those for zone type 01 (e.g., a garage, loading dock, or basement door).

Type 03: Perimeter Burglary

Provides an instant alarm if the zone is faulted and the system is armed in the AWAY, STAY, INSTANT, or MAXIMUM mode.

Assign this zone type to all exterior door and window zones.

Type 04: Interior, Follower

Provides a delayed alarm (using the programmed entry delay time) if an entry/exit zone is faulted first. Otherwise it produces an instant alarm. It is active when the system is armed in the AWAY or MAXIMUM mode, but the MAXIMUM mode eliminates the entry delay.

Zones programmed for Interior Follower zone are automatically bypassed when the panel is armed in the STAY or INSTANT mode.

Assign this zone type to a zone covering an area such as a foyer, lobby, or hallway through which one must pass upon entry or exit (to and from the keypad).

Type 05: Trouble by Day/Alarm by Night

Provides an instant alarm if the zone is faulted and the system is armed in the AWAY, STAY, INSTANT, or MAXIMUM mode. During the disarmed state (day), the system annunciates a latched trouble sounding from the keypad (and a central station report, if desired).

Assign this zone type to a zone that contains a foilprotected door or window (such as in a store), or to a zone covering a sensitive area such as a stock room or drug supply room. It can also be used on a zone in an area where immediate notification of an entry is desired.

4-5

VISTA-40 Installation and Setup Guide

Type 06: 24-Hour Silent Alarm

Sends a report to the central station but provides no keypad display or sounding. Assign this zone type to a zone containing an Emergency button.

Type 07: 24-Hour Audible Alarm

Sends a report to the central station and provides an alarm sound at the keypad and an audible external alarm. Assign this zone type to a zone containing an Emergency button.

Type 08: 24-Hour Auxiliary Alarm

Sends a report to central station and provides an alarm sound at the keypad only. (No bell output is provided.) Assign this zone type to a zone an Emergency button or one containing monitoring devices such as water sensors or temperature sensors.

Type 09: Supervised Fire (Without Verification)

Provides a fire alarm on a short circuit and a trouble condition on open circuit. A fire alarm produces a pulsing of the bell output. A zone of this type is always active and cannot be bypassed.

Type 10: Interior with Delay

Provides entry and exit delays (using the programmed entry and exit delay times) when armed in the AWAY mode. Provides only exit delay when armed in the MAXIMUM mode (no entry delay). Delay begins whenever sensors in this zone are violated, regardless of whether or not an entry/exit delay zone was tripped first.

Zones programmed for Interior with Delay are automatically bypassed when the panel is armed in the STAY or INSTANT mode.

Assign this zone type to a zone covering an area such as a foyer, lobby, or hallway through which one must pass upon entry or exit (to and from the keypad).

Type 20: Arm-STAY (5800 Series devices only)

Causes the system to arm in the STAY mode when the zone is activated.

Type 21: Arm-AWAY (5800 Series devices only)

Causes the system to arm in the AWAY mode when the zone is activated.

Type 22: Disarm (5800 Series devices only)

Causes the system to disarm when the zone is activated.

Type 23: No Alarm Response

Used on a zone when an output relay action is desired, but with no accompanying alarm (e.g., for access door).

NOTE FOR PANIC KEYS: Keypad panic zones share the same zone response type for both partitions, but panics may be individually enabled for each partition.

IMPORTANT! FAULT ANNUNCIATION

Polling loop and RF troubles (zones 88, 89, 90, 91, and 97) report as trouble conditions only, and as such, should be assigned zone type 05 if annunciation is desired. See Polling Loop Supervision and RF System Operation and Supervision in SECTION 3 Installing the Control for more information.

Zone Input Type Definitions

Each zone must be assigned an input type, which defines the where the system will “look” for status of the zone (RF receiver, polling loop, etc.). Zone input types are defined below.

Type 01 Hardwired (HW)

Reserved for the built-in hardwired zones 1-9.

Type 03 Supervised RF (RF)

Select for 5800 Series RF transmitters that will be supervised for check-in signals. The transmitter must remain within the receiver’s range.

Type 04 Unsupervised RF (UR)

Select for 5800 Series RF transmitters that will not be supervised for check-in signals. The transmitter may therefore be carried off-premises.

4-6

Type 05 Unsupervised Button RF (BR)

Select for 5800 Series RF transmitters specifically designed for this input type. Check the transmitter’s instructions for proper programming of the input type. These transmitters send only fault signals. They do not send low-battery signals until they are activated. The transmitter may be carried off-premises.

Type 06 Serial Number Polling Loop (SL)

Select for polling loop devices with a built-in serial number.

Type 07 DIP Switch Loop (DP)

Select for polling loop devices that use DIP switches for programming the zone number of the device.

Type 08 Dip Switch Polling Loop Right Loop (PS)

Select for the second loop of two-zone polling loop devices (e.g., 4190WH; 4278).

Programming for 4100SM

• 1✳40 & 1✳41 Date and Time Set Report Codes

• 1✳70 Event Log Types (1=enable; 0=disable

• 1✳71 12/24-Hour Time Stamp (0=12 hr; 1=24 hr)

Programming for Access Control

A user can trigger an access point (i.e., door strike) for 2 seconds by entering User Code + [0].

To program the VISTA-40 for access control, perform the following steps:

Step Action

1 Enter Relay Programming in the #93 Menu

Mode.

2 Program the relay type as 1, or 2.

3 For type 1, program the ECP address and

relay number.

4 For type 2, program the house and unit codes.

5 Program the relay number in field 1∗76

(partition-specific).

See Relay Programming in the Programming Guide for a detailed explanation.

Section 4 – Programming

4-7

VISTA-40 Installation and Setup Guide

4-8

SECTION 5

Data Field Descriptions

•••••••••••••••••••••••••••••••••••••••••••••••••

About Data Field Programming

The following pages list this control’s data fields in numerical order. Field numbers are listed in the left column, followed by a “Title and Data Entries column, which lists the valid entries for each field. Experienced installers can simply follow this column when programming the data fields. The “Explanation” column provides explanatory information and special notes where applicable.

NOTE: Refer to the Programming Guide for the default values. They are not listed in this section.

Programming Data Fields

Data field programming involves making the appropriate entries for each of the data fields. Start Data Field programming by entering the installer code + 8 + 0 + 0.

FIELD TITLE and DATA ENTRIES EXPLANATION

*00

*02

*03

*04

*05

*09

*10

*11

Use the Programming Guide to record the data for this installation.

Installer Code

Enter 4 digits, 0-9

Response Types for Zones 01–08

Response Types for Zones 09–16

Response Types for Zones 17–24

Response Types for Zones 25– 27, 97, 95, 96, and 99

Entry Delay #1 (partition-specific)

Enter 02-15 multiplied by 15 seconds. 00 = no delay.

Exit Delay #1 (partition-specific)

Enter 03-15 multiplied by 15 seconds. 00 = no delay.

Entry Delay #2 (partition-specific)

Enter 02-15 multiplied by 15 seconds. 00 = no delay.

The Installer Code is a 4-digit code reserved for installation company use.

This is the only code that can be used to enter the Program Mode from the keypad. This code cannot be used to disarm the system if it isn’t used to arm the system. This code cannot be used to re-enter Program Mode if Program Mode is exited by the *98 command.

Skip this field. Use #93 Menu Mode, Zone Programming to program the response types. Refer to the Programming Guide for details.

Entry delay defines the delay time that allows users to re-enter the premises through a door that has been programmed as an entry delay door and disarm the system without sounding an alarm. The system must be disarmed within this period or an alarm will occur.

NOTE: The delay may not exceed 45 seconds for UL installations.

Exit delay defines the delay period that allows users to leave the premises through a door that has been programmed as an entry/exit delay door after arming the system without setting off the alarm.

Entry Delay #2 is used for a secondary door requiring a longer delay than those assigned to Entry Delay #1.

NOTE: The delay may not exceed 45 seconds for UL installations.

5-1

VISTA-40 Installation and Setup Guide

FIELD TITLE and DATA ENTRIES EXPLANATION

*12

*13

*14

*15

*16

*17

*19

*20

*21

*22

*23

Exit Delay #2 (partition-specific)

Enter 03-15 multiplied by 15 seconds. 00 = no delay.

Alarm Sounder Duration (partition-specific)

Enter 01-15 multiplied by 2 minutes. 00 = no timeout.

Zone 9 Fast/Slow Response

0 = slow 350ms 1 = fast 10ms

Keyswitch Assignment

Enter 1-2 partition keyswitch is being used. Enter 0 if the keyswitch is not used.

Confirmation of Arming Ding (partition-specific)

0 = disable 1 = enable

AC Loss Keypad Sounding

0 = disable 1 = enable

Randomize AC Loss Report

0 = disable 1 = enable

VIP Module Phone Code

1-9 = first digit of access code



or # = second digit of access code (enter # +11 for “∗”, or # +12 for “#”) To disable enter 00 for the 1

digit

Prevent Fire Timeout

0 = disable (timeout) 1 = enable (no timeout)

Keypad Panic Enables (partitionspecific)

0 = disable 1 = enable

Multiple Alarms (partitionspecific)

0 = disable 1 = enable

Exit Delay #2 is used for a secondary door requiring a longer delay than those assigned to Exit Delay #1.

NOTE: The delay may not exceed 60 seconds for UL installations.

Defines the length of time the Bell Output and the keypad’s sounder will sound for all audible alarms.

Must be minimum 16 minutes for UL Commercial Burglary installations.

Select the response time for devices connected to zone 9.

The keyswitch requires the use of zone 7 wired loop (zone 7 is no longer available as protection zone). The fire and panic alarm voltage triggers (J7) automatically become ARMING and READY status outputs for the Keyswitch LEDs.

Openings/closing report as user “0” if enabled in field *40.

If enabled, produces ½-second external alarm sounding (“ding”) at the end of exit delay (or after kissoff from the central station, if sending closing reports).

Must be 1 for UL installations.

If enabled, sounding at the keypad (rapid beeping) occurs when AC power is lost (sounding occurs about 2 minutes after actual AC loss).

If enabled, randomizes AC loss reporting between 10 and 40 min. after an actual AC loss.

If disabled, AC loss reporting about 2 minutes after actual AC loss.

Selecting this option helps prevent an overload of AC loss messages at the central station during a community blackout.

If a 4285/4286 Voice Module is being used, enter the 2-digit phone code used to access the system.

Must be disabled for UL installations.

If enabled, there is no timeout of the alarm sounder duration for all fire zones, regardless of partition, so that fire sounding continues until the system is reset.

If disabled, (timeout) the normal burglary sounder duration (field ✳13) applies to fire alarms.

If enabled, the keypad panics (zones 995, 996, and 999) may be used in this partition. There are 3 entries in this field, one for each panic.

If enabled, allows more than one alarm sounding for a given zone during an armed period.

NOTE: that multiple alarm soundings will not occur more frequently than allowed by the programmed alarm sounder duration. This has no impact on the number of communication messages transmitted.

Must be 1 for UL installations.

5-2

FIELD TITLE and DATA ENTRIES EXPLANATION

*24

*25

*26

*27

*28

*29

*30

*31

*32

Ignore Expansion Zone Tamper

0 = disable (tamper detection) 1 = enable (no tamper detection)

Burglary Trigger for Response Type 8

0 = disable 1 = enable

Intelligent Test Report

0 = disable 1 = enable

Test Report Interval

Enter 001-199 for the test report interval in hours. Enter 000 for test reporting.

Power-Up in Previous State

0 = disable 1 = enable

Quick Arm (partition-specific)

0 = disable 1 = enable

TouchTone or Rotary Dial

0 = disable 1 = enable

If you select TouchTone, make sure the subscriber has requested and is paying for TouchTone service. Note that whether or not TouchTone dialing for call placement is permitted, communication by the use of DTMF signaling (ADEMCO High Speed) will still take place. See field 1*33 for TouchTone w/Rotary backup

PABX Access Code

Enter 00-09; B-F (11-15)

Primary Subscriber’s Account Number (partition-specific)

Enter 00-09; B-F (11-15)

If disabled, the system monitors the tampers on expansion zones.

NOTE: Only applicable to certain polling loop sensors with tamper switches or 5800 Series transmitters.

Must be 0 for UL installations.

If enabled, allows triggering of Output 3 (pin 7) of the J7 header to include zone response type 8 (24-hr. auxiliary).

If enabled, no test report is sent if any other type of report was sent since the last test report.

If disabled, test reports are sent at the set intervals, regardless of whether or not any other report has been sent.

Must be 0 for UL applications.

If a test report is desired, enter a test code in field *81 and *82. Set first test report time in field *83.

Maximum Test report interval is 024 for UL installations.

If enabled, the system, upon power-up, reverts to its status prior to a complete power loss.

If disabled, the system always powers up in a disarmed state.

NOTE: Neither authority level 0 nor 5 can be used to disarm the system if the control powers up armed.

Must be 1 for UL applications.

If enabled, allows arming of the burglary system in AWAY, STAY, INSTANT, or MAXIMUM mode by using the [#] key instead of the user code.

NOTES:

When armed, the system reports closing as User 0 if Open/Close reporting for User #2 (typically a Master level user) was enabled for a given partition.

If Quick Arm is used, the Installer Code and Authority Level 5 codes cannot disarm the system.

Select the dialing method for the system

This field is used to enter up to four 2-digit numbers representing the prefix needed to obtain an outside telco line. If not required, enter nothing and proceed to next field.

Enter a 3- or 4-digit (depending on report format) primary subscriber account number. Each number requires a 2-digit entry so as to allow entry of hexadecimal digits (B-F). If a 3-digit account number is to be used, enter data only in the first 3 locations, and enter * in the fourth location.

Section 5 – Data Field Descriptions

5-3

VISTA-40 Installation and Setup Guide

FIELD TITLE and DATA ENTRIES EXPLANATION

*33

*34

*35

*36

*37

*38

*39

*40

*41

*42

Primary Phone Number

Enter 0-9; #11 for *, #12 for #, #13 for a 2second pause.

Secondary Phone Number

Enter 0-9; #11 for *, #12 for #, #13 for a 2second pause.

Download Phone Number

Enter 0-9; #11 for *, #12 for #, #13 for a 2second pause.

Download ID Number

Make entries as 2-digit numbers as follows: 00=0 01=1 02=2 03=3 04=4 05=5 06=6 07=7 08=8 09=9 10=A 11=B 12=C 13=D 14=E 15=F

Download Command Enables

0 = disable 1 = enable

Prevent Zone XX Bypass (partition-specific)

Enter a zone number (01-64). Enter 00 if all zones can be bypassed.

Enable Open/Close Report for Installer Code (partition-specific)

0 = disable 1 = enable

Enable Open/Close report for Keyswitch

0 = disable 1 = enable

Normally Closed or EOLR (Zones 2-8)

0 = disable 1 = enable

Dial Tone Pause

Enter the wait time for dial tone detection: 0 = 5 seconds; 1 = 11 seconds; 2 = 30 seconds.

Enter the primary central station phone number, up to 17 digits. This is the phone number the control will use to transmit Alarm and status messages to the central station. Do not fill unused spaces.

NOTE: Backup reporting is automatic only if a secondary phone number is entered.

Enter the secondary phone number, up to 17 digits. The secondary phone number is used if communication on the primary number is unsuccessful, or if split/dual reporting is desired. Do not fill unused spaces.

NOTE: If this field is programmed, a secondary subscriber account number (field *90) must also be programmed.

Enter the downloading phone number, up to 17 digits. Do not fill unused spaces.

NOTE: This field is applicable only if downloading is utilized.

Enter eight digits.

NOTE: This field is applicable only if downloading is utilized.

Enabling a function means that you are able to perform that function via the Compass Downloading software.

Functions are as follows: Dialer Shutdown; System Shutdown; Not Used; Remote Bypass; Remote Disarm; Remote Arm; Upload Program; Download Program.

For UL installations, all entries must be 0.

Enter two digits for zone that cannot be bypassed by the user.

NOTES:

The actions manual bypass, and STAY/INSTANT arming modes cannot bypass any zone programmed in this field.

If enabled, whenever the Installer Code is used to arm or disarm the partition, an open/close report is sent to the central station.

If enabled, whenever the keyswitch is used to arm or disarm the partition, an open/close report is sent to the central station.

If disabled, end-of-line resistors must be used on zones 2-8.

If enabled end-of-line resistors cannot be used and only normally closed devices must be used.

Must be 0 for UL installations.

Enter the time the system waits for dial tone before dialing. Applies if true dial tone is not selected in field *43.

Must be 0 for UL installations.

5-4

FIELD TITLE and DATA ENTRIES EXPLANATION

*43

*44

*45

*46

*47

*48

*49

*50

*51

Dial Tone Detection

0 = disable 1 = enable

Ring Detection Count

Enter 00 to disable ring detection. Enter 01-14 for ring counts of 1-14. Enter 15 to select Answering Machine Defeat Mode

Primary Format

0=Low Speed; 1=Contact ID; 2=ADEMCO High Speed; 3=ADEMCO Express

Low Speed Format (Primary)

0 = ADEMCO Low Speed 1 = Sescoa/Radionics

Secondary Format

0=Low Speed; 1=Contact ID; 2=ADEMCO High Speed; 3=ADEMCO Express

Low Speed Format (Secondary)

0 = ADEMCO Low Speed 1 = Sescoa/Radionics

Checksum Verification

Enter 2 digits, one for the primary and one for the secondary.

0 = disable 1 = enable

Sescoa/Radionics Select

0 = disable 1 = enable

Dual Reporting

0 = disable 1 = enable

If enabled, the system waits for true dial tone. If no dial tone is detected, control dials at end of pause programmed in field *42.

If disabled, the system pauses for seconds entered in field *42, then dials.

NOTE: Disabling may be necessary in high-noise environment telco networks where noise can be confused with dial tone, resulting in premature dialing.

Only applicable if using a 4285/4286 VIP Module and/or if stationinitiated downloading will be used.

NOTES:

Do not enter 00 if a 4285/4286 is installed.

In the Answering Machine Mode, the caller should let the phone ring once, then hang up, and call again within 30 seconds. The system, upon hearing one ring followed by nothing, does not answer the first call, but readies itself to pick up on the first ring of the next incoming call that is received within 30 seconds (i.e., the downloader calling again).

Must be 00 for UL installations.

Enter the reporting format for the primary telephone number.

Enter the low speed format for the primary telephone number.

Enter the reporting format for the secondary telephone number.

Enter the low speed format for the secondary telephone number.

If enabled, the system for either or both primary/secondary formats sends a verification digit to validate the message at the receiver without having to send two message rounds. Selection is valid for 3+1, 4+1, and 4+2 reports.

If disabled, selects Radionics, which uses hexadecimal 0-9, B-F reporting.

If enabled, selects Sescoa, which uses only numeric reporting (0-9).

NOTE: The selection applies to both primary and secondary phone numbers.

If enabled, all reports are to be sent to both primary and secondary phone numbers.

NOTE: If used with Split Reporting option 1 (1*34), alarms go to both primary and secondary numbers, while all other reports go to secondary only. If used with Split Reporting option 2, alarms go to both lines, open/close and test messages go to secondary only, while all other reports go to primary.

Section 5 – Data Field Descriptions

5-5

VISTA-40 Installation and Setup Guide

FIELD TITLE and DATA ENTRIES EXPLANATION

*52

*53

*54

*55

*56

*57

*58

*59

*60

*61

*62

*63

*64

*65

*66

*67

Standard/Expanded Reporting Primary

0 = disable 1 = enable

Standard/Expanded Reporting Secondary

0 = disable 1 = enable

Alarm Code for Zones 01–08

ID Digit for Zones 01–08

Alarm Code for Zones 09–16

ID Digit for Zones 09–16

Supervisory and Restore Codes for Zones 01–16

Enter 00-15.

Alarm Code for Zones 17–24

ID Digit for Zones 17–24

Alarm Code for Zones 25–32

ID Digit for Zones 25–32

Supervisory and Restore Codes for Zones 17–32

Enter 00-15.

Alarm Code for Zones 33–40

ID Digit for Zones 33–40

Alarm Code for Zones 41–48

ID Digit for Zones 41–48

This field has six entries as follows: Alarm, Restore, Bypass, Trouble, Open/Close, Low Battery. If enabled, expanded reports are sent to the primary phone number if low speed format is selected in field *45.

NOTE: Expanded overrides 4+2 format.

This field has six entries as follows: Alarm, Restore, Bypass, Trouble, Open/Close, Low Battery. If enabled, expanded reports are sent to the secondary phone number if low speed format is selected in field *47.

NOTE: Expanded overrides 4+2 format.

Skip this field. Use #93 Menu Mode, Zone Programming to program the report codes. Refer to the Programming Guide for details.

This field has five two-digit entries as follows: Alarm Restore, Trouble, Trouble Restore, Bypass, and Bypass Restore. Enter the report code 01-15 for each type of report. Enter 00 for no report.

NOTE: Each report code is the same for zones 01-16. When using 4+2 format, the system uses the ID digit of the zone (fields *55 and *57).

Skip this field. Use #93 Menu Mode, Zone Programming to program the report codes. Refer to the Programming Guide for details.

This field has five two-digit entries as follows: Alarm Restore, Trouble, Trouble Restore, Bypass, and Bypass Restore. Enter the report code 01-15 for each type of report. Enter 00 for no report.

NOTE: Each report code is the same for zones 17-32. When using 4+2 format, the system uses the ID digit of the zone (fields *60 and *62).

Skip this field. Use #93 Menu Mode, Zone Programming to program the report codes. Refer to the Programming Guide for details.

5-6

FIELD TITLE and DATA ENTRIES EXPLANATION

*68

*69

*70

*71

*72

*73

*74

*75

*76

*77

*78

*79

*80

*81

Supervisory and Restore Codes for Zones 33–48

Enter 00-15.

Alarm Code for Zones 49–56

ID Digit for Zones 49–56

Alarm Code for Zones 57–64

ID Digit for Zones 57–64

Supervisory and Restore Codes for Zones 49–64

Enter 00-15.

Alarm Code for Zones 87–88

ID Digit for Zones 87–88

Alarm Code for Zones 89–99

ID Digit for Zones 89–99

Supervisory and Restore Codes for Zones 87–99

Enter 00-15.

Zone Type Restores for Zone Types 1-8

0 = disable 1 = enable

Zone Type Restores for Zone Types 9 and 10

0 = disable 1 = enable

Non-Alarm Report Codes (First Digit

Enter 00-15.

This field has five two-digit entries as follows: Alarm Restore, Trouble, Trouble Restore, Bypass, and Bypass Restore. Enter the report code 01-15 for each type of report. Enter 00 for no report.

NOTE: Each report code is the same for zones 33-48. When using 4+2 format, the system uses the ID digit of the zone (fields *65 and *67).

Skip this field. Use #93 Menu Mode, Zone Programming to program the report codes. Refer to the Programming Guide for details.

This field has five two-digit entries as follows: Alarm Restore, Trouble, Trouble Restore, Bypass, and Bypass Restore. Enter the report code 01-15 for each type of report. Enter 00 for no report.

NOTE: Each report code is the same for zones 49-64. When using 4+2 format, the system uses the ID digit of the zone (fields *70 and *72).

Skip this field. Use #93 Menu Mode, Zone Programming to program the report codes. Refer to the Programming Guide for details.

This field has five two-digit entries as follows: Alarm Restore, Trouble, Trouble Restore, Bypass, and Bypass Restore. Enter the report code 01-15 for each type of report. Enter 00 for no report.

NOTE: Each report code is the same for zones 17-32. When using 4+2 format, the system uses the ID digit of the zone (fields *75 and *77).

This field has eight entries, one for each zone type. Select the zone types that will send Restore reports.

This field has two entries, one for each zone type. Select the zone types that will send Restore reports.

This field has ten two-digit entries as follows: Close, Open Low Battery, Low Battery Restore, AC Loss, AC Restore, Test, Power-up, Cancel, and Program Tamper. Enter the report code 01-15 for each type of report. Enter 00 for no report.

Section 5 – Data Field Descriptions

5-7

VISTA-40 Installation and Setup Guide

FIELD TITLE and DATA ENTRIES EXPLANATION

*82

*83

*84

*85

*86

*87

*88

*89

*90

Non-Alarm Report Codes (Second Digit

Enter 00-15.

First Test Report Time

Enter 00-07 the for day (01 = Monday) Enter 00-23 for the hour Enter 00-59 for the minutes

Swinger Suppression (partitionspecific)

Enter 01-15. Enter 00 for unlimited reports

Enable Dialer Reports for Panics & Duress (partition-specific)

0 = disable 1 = enable

4208 Module Zone Assignment

0 = other configurations 1 = 10-17 only

Entry Warning (partition-specific)

0 = 3 short beeps 1 = slow continuous beeps

Burglary Alarm Communicator Delay (partition-specific)

0 = no delay 1 = 16-second delay

Restore Report Timing

0 = instant 1 = after bell timeout 2 = when system is disarmed

Secondary Subscriber Account Number (partition-specific)

Enter 00-09; B-F (11-15)

This field has ten two-digit entries as follows: Close, Open, Low Battery, Low Battery Restore, AC Loss, AC Restore, Test, Power-up, Cancel, and Program Tamper. Enter the report code 01-15 for each type of report. Enter 00 for no report.

Enter the day and time that the first Test report shall be transmitted. Enter 00 in all locations if the Test report is to be sent immediately upon exiting. Enter 00 in the day location if the report is to be sent at the next occurrence of the time that is set.

This option limits the number of messages (alarms or troubles) sent for a specific zone in an armed period.

Must be 00 for UL installations.

This field has four entries as follows: Zone 95, 96, 99, and Duress. Enable for each partition that the panics and duress reporting is desired.

NOTE: Non-zero report code must be assigned to zone 92 to enable Duress reporting.

Entering 1 allows a single 4208 to be set to zone numbers 10-17, but precludes the use of any other polling loop devices.

Entering 0 allows all other configurations, such as no 4208, more than one 4208, or other polling loop expansion present.

4208 Zone #s available when: When *86 = 1 4208 DIP switches must be set to:

*86 = 1 *86 = 0

10-17 10-16 sw 2 = ON sw 2 = OFF

Precludes use of any other polling loop expansion

Select the type of warning for the entry delay period.

Select the delay, if any, for burglary alarm communications.

Must be 0 for UL installations.

Select the time when restore reports are sent after an alarm.

Must be 2 for UL installations.

Enter a 3- or 4-digit (depending on report format) secondary subscriber account number. Each number requires a 2-digit entry so as to allow entry of hexadecimal digits (B-F). If a 3-digit account number is to be used, enter data only in the first 3 locations, and enter * in the fourth location.

NOTE: This field must be programmed if a secondary phone number is used (field *34). This account number can be the same as the primary account number.

17-24

25-32

33-40

41-48

49-56

57-64

With word OFF With word ON

sw 3 = ON sw 3 = OFF

sw 4 = ON sw 4 = OFF

sw 5 = OFF sw 5 = ON

5-8

FIELD TITLE and DATA ENTRIES EXPLANATION

1*01

1*02

1*03

1*04

1*05

1*09

1*28

1*29

1*30

1*31

1*33

1*34

1*35

Response Types for Zones 28–32

Response Types for Zones 33–40

Response Types for Zones 41–48

Response Types for Zones 49–56

Response Types for Zones 57–64

Response Types for Zones 87–91

RF Transmitter Low Battery Sound

0 = disarmed state only 1 = both armed and disarmed states

RF Transmitter Low Battery Reporting

0 = disable 1 = enable

RF Receiver Supervision Checkin Interval

Enter 02-15 times 2 hours (4-30 hours). 00 = disable receiver supervision.

RF Transmitter Check-in Interval

Enter 02-15 times 2 hours (4-30 hours). 00 = disable transmitter supervision.

TouchTone with Rotary Backup

0 = disable 1 = enable

Communicator Split Reporting

0 = Split Reporting disabled 1 = Alarm, Alarm Restore, and Cancel

reports to primary, all others to secondary 2 = Open/Close and Test reports to secondary, all other reports to primary

Alarm Code for Zones 65–72

Skip this field. Use #93 Menu Mode, Zone Programming to program the response types. Refer to the Programming Guide for details.

Select when the RF transmitter low-battery condition should display and audible beep annunciate on the keypad.

Must be 1 for UL installations.

If enabled, the system sends a Trouble message for RF transmitter lowbattery condition to the central station.

NOTE: The Trouble message will be sent for a transmitter supervision failure, independent of this selection.

Must be 1 for UL.

Select the check-in monitoring interval for the RF receiver(s).

Failure of a receiver to receive any RF signal within the time entered results in the activation of the response type programmed for zone 990 for the first receiver and zone 988 for the second receiver and their related communication reports.

Maximum is 2 (4 hr) for UL installations.

Select the check-in monitoring interval for the RF transmitters.

Failure of an individual transmitter to send a supervision signal within the time entered will result in a trouble response and related communication report.

Maximum is 2 (4 hr) for UL.

If enabled, the system reverts to rotary dialing if communicator is not successful in dialing using TouchTone DTMF on first attempt.

Select the type of split reporting for system communication.

NOTE: See *51 for split/dual reporting combinations.

Skip this field. Use #93 Menu Mode, Zone Programming to program the report codes. Refer to the Programming Guide for details.

Section 5 – Data Field Descriptions

5-9

VISTA-40 Installation and Setup Guide

FIELD TITLE and DATA ENTRIES EXPLANATION

1*36

1*37

1*38

1*39

1*40

1*41

1*43

1*44

1*45

1*46

1*47

1*48

ID Digit for Zones 65–72

Alarm Code for Zones 73–80

ID Digit for Zones 73–80

Supervisory and Restore Codes for Zones 65–80

Enter 00-15.

Arm Stay and Time Set Report Codes (First Digit)

Enter 00-15.

Arm Stay and Time Set Report Codes (Second Digit)

Enter 00-15.

Permanent Keypad Display Backlighting (partition-specific)

0 = disable 1 = enable

Wireless Keypad Tamper Detect

0 = disable 1 = enable

Exit Delay Sounding (partitionspecific)

0 = disable 1 = enable

Auxiliary Output Mode

0 = ground start output. 1 = open/close trigger. 2 = keypad sounds at an auxiliary sounder. 3 = AAV module.

Chime on External Siren (partition-specific)

0 = disable 1 = enable

Wireless Keypad Assignment

0 = none 1-8 = partition number

Skip this field. Use #93 Menu Mode, Zone Programming to program the report codes. Refer to the Programming Guide for details.

This field has five two-digit entries as follows: Alarm Restore, Trouble, Trouble Restore, Bypass, and Bypass Restore. Enter the report code 01-15 for each type of report. Enter 00 for no report.

NOTE: Each report code is the same for zones 17-32. When using 4+2 format, the system uses the ID digit of the zone (fields *75 and *77).

This field has two two-digit entries as follows: Arm STAY, and Time/Date set or Event Log Reset. Enter the report code 01-15 for each type of report. Enter 00 for no report.

If enabled, backlighting for the keypad display remains on at all times. Otherwise the backlighting comes on when a key is pressed.

NOTE: When a key is pressed, display backlighting turns on for all keypads in that partition.

If enabled, when more than 40 key depressions are received without a valid sequence (arm, disarm, etc.), the control panel disables the wireless keypad. The inhibit is removed once a valid key sequence is received from a wired keypad.

If enabled, the system produces slow beeping from the keypads during exit delay and reverts to rapid beeping during the last 10 seconds of the exit delay.

NOTE: The duration of the beeping is the programmed value of field *10 regardless of which entry/exit zone is used to exit the premises.

Select the mode for output 1 on the J7 triggers.

NOTES:

Only one of the options may be active within the system.

Open/close trigger is produced only when both partitions are armed.

Keypad sounds apply only to the partition enabled in field *15.

If enabled, the system produces chime annunciation on the external alarm sounder.

Select the partition in which RF keypad is used.

5-10

FIELD TITLE and DATA ENTRIES EXPLANATION

1*49

1*52

1*53

1*57

1*58

1*60

1*70

1*71

1*74

1*75

1*76

2*00

2*01

Suppress Transmitter Supervision Sound

0 = disable 1 = enable

Send Cancel If Alarm + Off (partition-specific)

0 = disable 1 = enable

Disable Download Callback

0 = callback required 1 = no callback required

Enable 5800 RF Button Global Arm

0 = disable 1 = enable

Enable 5800 RF Button Force Arm

0 = disable 1 = enable

Zone 5 Audio Alarm Verification

0 = disable 1 = enable

Event Log Types

0 = disable 1 = enable

12/24 Hour Type Stamp Format

0 = 12-hour 1 = 24-hour

Relay Timeout XXX Minutes

Enter 000-127 times 2 minutes (000-254).

Relay Timeout YYY Seconds

Enter 000-127 seconds.

Access Control Relay (partitionspecific)

01-08 = relay number 00 = relay not used.

Number of Partitions

Enter 1-2.

Daylight Saving Time Start/End Month

0 = disable 1 = enable

If enabled, no trouble soundings occur on the keypad for transmitter check-in failures.

Must be 0 for UL.

If enabled, Cancel reports are sent when the system is disarmed after an alarm, regardless of how much time has gone by.

If disabled, Cancel reports are sent within Bell Timeout period only.

NOTE: This option must be enabled so Cancel reports are always sent.

Select whether a callback from the control panel is required for downloading.

Must be 0 for UL installations.

If enabled, the system arms/disarms in accordance with the button’s user’s global arming settings.

If enabled, allows the RF button user to force a bypass of all faulted zones when arming the system.

NOTE: When attempting to arm the system, the keypad beeps once after the button is pressed if any faulted zones are present. The user should then press the button again within 4 seconds to force-bypass those zones and arm the system.

If enabled, zone 5 is used for 2-way audio (AAV).

Must be 0 for UL installations.

NOTE: Zone 5 cannot be used as protection zone.

This field has five entries as follows: Alarm, Check, Bypass, Open/Close, and System. If enabled, the system logs those events into the event log.

Select the type of time stamping for the event log.

This is used for Relay Programming in the #93 Menu Mode Programming relay command “56.”

This is used for Relay Programming in the #93 Menu Mode Programming command “57.”

If enabled, the assigned relay closes for 2 seconds when the user enters his code and presses 0.

Must be 00 for UL installations.

Enter the number of partitions used in the system.

Enter the months (00-12) in which daylight saving time starts and ends.

Enter 00, 00 if daylight saving time does not apply to the user’s region. Standard setting for U.S. is 04,10.

Section 5 – Data Field Descriptions

5-11

VISTA-40 Installation and Setup Guide

FIELD TITLE and DATA ENTRIES EXPLANATION

2*02

2*17

2*18

2*19

2*20

2*21

Daylight Saving Time Start/End Weekend

0 = disable 1 = enable

Number of Codes per Partition

Enter 01-69

Enable GOTO for this Partition (partition-specific)

0 = disable 1 = enable

Use Partition Descriptor

0 = disable 1 = enable

Enable J7 Triggers for Partition (partition-specific)

0 = disable 1 = enable

Supervision Pulses for LRR

0 = disable 1 = enable

Enter the start and end weekends for daylight saving time as follows: 1=first; 2=second; 3=third; 4=fourth; 5=last; 6=next to last; 7=third from last. Standard setting for U.S. is 1,5.

This field has two 2-digit entries. Enter the number user codes for each partition. The total number of user codes cannot exceed 70 for the system. Enter 01 for an unused partition.

NOTE: The installer code is automatically assigned to each partition regardless of whether that partition has been enabled.

If enabled, this partition can be accessed from another partition’s keypad using the GOTO command.

If enabled, the normal keypad display will include a partition number and four-digit descriptor.

If enabled, the J7 triggers function for this partition.

There are three entries in this field as follows: Fire, Burglary/Audible Panic, Silent Panic/Duress.

If enabled, causes the control to send periodic short pulses on the J7 radio triggers to the LRR. The LRR uses these pulses to determine that its connection to the control is still intact.

Must be 1 for UL installations.

5-12

SECTION 6

Downloading Primer

(Remote Downloading is not a UL Listed feature)

•••••••••••••••••••••••••••••••••••••••••••••••••

General Information

Downloading allows the operator to remotely access, program, and control the security system over normal telephone lines. Anything that can be done directly from the keypad can be done remotely, using the COMPASS downloading software. To communicate with the control panel, the following is required:

1. IBM PC-compatible 486 33MHz PC or better with 30 MB of available hard disk space and at least 8MB of RAM (12MB is preferred). Windows 3.X, Windows 95, 98, or Windows NT.

2. One of the following modems:

• ADEMCO CIA

• Hayes Smartmodem 1200 (external: level 1.2 or

higher; internal: level 1.1 or higher)

• Hayes Optima 24 + Fax 96 external

• Hayes Optima 336

• BizComp Intellimodem 1200 w/volume

• BizComp Intellimodem 2400

Other brands are not compatible, even if claimed to be 100% compatible.

3. COMPASS DOWNLOADING software available on CD ROM with a complete User’s Manual. It may also be downloaded from the Honeywell web page. The web address is www.honeywell.com/security.

Internal modems must have a 4-position DIP switch. Modems with a 6-position DIP switch will not work.

Access Security

The following four levels of protection guard the control against compromise while it is being accessed from a remote location:

1. Security code handshake: The subscriber’s account number as well as an 8-digit ID number (known only to the office) must be matched between the control and computer.

2. Hang-up and callback: The control panel “hangs up” and calls the computer back at the preprogrammed number only if the security codes match.

3. Data encryption: All data that is exchanged between the computer and control is encrypted to reduce the possibility of anyone “tapping” the line and corrupting data.

4. Operator access levels: Operators may be assigned various levels of access to the downloader, each having its own log-on code. The access levels allow the operators read/write capabilities of the customers’ account information. For a detailed explanation of the access levels, see the downloading software User Manual.

NOTES:

• Each time the control panel is accessed successfully, a Callback Requested report is sent to the central station, if Opening reports are programmed.

• When the system is downloading, the keypad displays “MODEM COMM.”

• After each download or save, an automatic time stamp is done, to indicate the last download (or save) and the operator ID number.

• A complete hard copy of each individual account can be obtained by connecting a printer to the computer. Refer to your computer Owner’s Manual or contact your dealer for printer recommendations.

6-1

VISTA-40 Installation and Setup Guide

Getting On-Line with a Control Panel

At the protected premises, the control panel must be connected to the existing telephone line (refer to SECTION 3: Installing the Control). No programming of the panel is required before downloading to an initial installation unless you are performing an unattended download.

When establishing a connection between the computer and the control panel, the following occurs:

Stage What Happens

1 The computer calls up the control panel.

(The phone number for each customer must be entered into the customer’s account file on the computer.)

2 The control panel answers the phone call at

the pre-programmed ring count and executes a handshake with the computer.

3 The computer sends a request for callback to

the control, unless callback is not required.

4 The panel acknowledges the request and

hangs up. During the next few seconds, the control processes the request, making sure certain encrypted information received from the computer matches its own memory.

5 Upon a successful match, the control panel

seizes the phone line and calls the computer back, unless callback is not required. (The phone number to which the computer’s modem is connected must be programmed into the control field ✳35.)

6 The computer answers, usually by the

second ring, and executes a handshake with the panel.

7 The panel then sends other default

information to the computer. If this information matches the computer’s information, a successful link is established. The system is now “on-line” with the computer.

Alarms and Trouble responses and reports are disabled during actual uploading or downloading sessions.

To download a control without programming any information, perform the following steps:

Step Action

1 Enter the Installer Code + [#] + [5]. The

panel temporarily enables a ring count of 5 and sets the Download Callback option to “1” (callback not required).

2 From the computer, call the panel using the

downloader software set to “First Communication” Mode.

The downloader establishes a session with no callback. The panel information can then be downloaded.

On-Line Control Functions

The following functions can be performed while on-line with a control panel (see field *37):

• Arm the system in the AWAY Mode; disarm the system

• Bypass a zone

• Force the system to accept a new program

download

• Shut down communication (dialer) functions (for nonpayment of monitoring fees in an owned system)

• Shut down all security system functions (for nonpayment for a leased system)

• Inhibit local keypad programming (prevents takeover of your accounts)

• Leave a message for customer

NOTE: Messages sent to the control panel from the downloader will be viewable at ALL partitions.

• Command the system to upload a copy of its resident program to the office

• Read: arming status, AC power status, list of faulted zones, list of bypassed zones, 100 event log, list of zones currently in alarm, list of zones currently in trouble, and ECP equipment list

• Set the real-time clock

6-2

Direct-Wire Downloading

Section 24 - Downloading Primer

The VISTA-40 can be downloaded without using a modem or telephone line by using a 4100SM Serial Module and Compass Downloading Software. The direct-wire downloading connection is to be temporary, and is not part of the permanent installation. Directwire downloading is meant as a tool for the installer during the installation process.

The connections between the control and the 4100SM are different than those shown in the 4100SM Installation Instructions. See Figure 6- 1 for the correct connections. In addition, in place of the green wire, referred to in step 2 of the “IN CASE OF DIFFICULTY” section of the 4100SM Instructions, use the violet wire instead.

Connector J8 on the main PC board (see the Summary of Connections diagram on the inside back cover of this

manual) is intended to be interfaced to either a local serial printer (see SECTION 3:Installing the Control) or a computer. Make connections to a computer as shown below. Note that the violet wire connection for a

computer differs from that used when connecting a serial printer.

Figure 6-1: Direct-Wire Downloading Connections

Telco Handoff

Telco handoff is another method of getting on-line with the downloader. The installer or customer enters the User Code + [#] + [1], while on the phone line with the computer’s modem phone line. The customer will get cut-off and the panel

and download computer will establish a connection.

6-3

VISTA-40 Installation and Setup Guide

6-4

SECTION 7

Setting the Real-Time Clock

•••••••••••••••••••••••••••••••••••••••••••••••••

General Information

This system provides a real-time clock, which must be set in order for the system’s event log to keep track of events by time and date.

Setting the Time and Date

To set the real time clock, perform the following steps:

Step Action

1 Enter Installer or Master Code + [#] 63.

Typical display shows:

TIME/DATE –– THU

12:01 AM 01/01/90

The day of the week is automatically calculated based on the date entered. Time and date entries are made by simply entering the appropriate hour, minute, month, day and year.

Press [✳] to move the cursor to the right of the display, to the next position.

Press [#] to move the cursor to the left of the display, to the previous position.

4 Press any key 0-9 to change AM to PM, or PM

5 Enter the correct month using a 2-digit entry.

6 Enter the correct day using a 2-digit entry.

7 Enter the correct year.

Enter the correct hour. Then press [✳] to move to the “minutes” field.

Enter the correct minutes. Press [✳] to move to the AM/PM position.

to AM. Press [✳] to move cursor to the “month” field position.

Press [✳] to move cursor to the “day” field position.

Press [✳] to move cursor to the “year” field position.

Press [✳] to continue.

Use a 6139/6160 alpha keypad to set the realtime clock, or set the clock via the downloader software. Only users with Installer or Master authority level can set the clock.

7-1

VISTA-40 Installation and Setup Guide

7-2

SECTION 8

User Access Codes

•••••••••••••••••••••••••••••••••••••••••••••••••

General Information

The VISTA-40 allows a total of 70 security access codes to be allocated. Each security access code is identified by a user ID number. A maximum of 69 user codes may be assigned to any one of the partitions. The installer code is automatically assigned to both partitions regardless of whether both partitions are used.

The Quick Arm feature can also be programmed (partition-specific program field *29). The Quick Arm feature allows the user to arm the system by pressing the [#] key instead of the security code. The security code must always be entered to disarm the system.

User Codes & Levels of Authority

Each user of the system can be assigned a level of authority, which authorizes the user for certain system functions. A user can have different levels of authority within different partitions

Level 0: Installer (User 1) Code

• Programmed in field *00 (default = 4-1-4-0). Installer Open/Close reporting selected in field *39.

• Can perform all system functions (arm, disarm, bypass, etc.), but cannot disarm if armed by another code (or by Quick Arm).

• Can add, delete, or change all other codes, and can select Open/Close reports for any user.

• Is the only code that can be used to enter program mode. The Installer Code can be prevented from reentering the Program Mode by exiting using ∗98.

• Must program at least one Master Code during initial installation. Master Codes are codes intended for use by the primary user(s) of the system.

Level 1: Master Codes

• Can perform all normal system functions.

• Can be used to assign up to 68 lower-level codes,

which can be used by other users of the system.

• Cannot assign anybody a level of 0 or 1.

• May change his own code.

• Can add, delete, or change Manager or Operator

Codes. Each user’s code can be individually eliminated or changed at any time.

• Open/Close reporting is automatically the same as that of the Master who is adding the new user.

User code number 2 must be programmed in order for the Quick Arm feature to function. Open/Close reporting for Quick Arm is enabled if User 2 is enabled for Open/Close and reports as User 0.

Use the “View Capabilities” keypad function (User Code + [✳] + [✳]) to view the partitions and authority

levels for which a particular user is authorized. These levels are described below.

Level 2: Manager Codes

• Can perform all system functions (arm, disarm, bypass, etc.) programmed by Master.

• May add, delete, or change other users of the system below this level (Manager cannot assign anybody a level of 0, 1, or 2).

• May change his own code.

• Open/Close reporting is automatically the same as

that of the Manager who is adding the new user.

Levels 3-5: Operator Codes

• Can operate a partition, but cannot add or modify any user code (see table below).

Level Title Functions Permitted

3 Operator A Arm, Disarm, Bypass

4 Operator B Arm, Disarm

5 Operator C Arm, Disarm only if armed with

same code

• Operator C (sometimes known as the Babysitter Code) cannot disarm the system unless the system was armed with that code. This code is usually assigned to persons who may need to arm and disarm the system at specific times only (e.g., a babysitter needs to control the system only when babysitting).

8-1

VISTA-40 Installation and Setup Guide

code for zone 92 (duress) must be programmed,

Level 6: Duress Codes

• Sends a silent alarm to a central monitoring station if the user is being forced to disarm (or arm) the system under threat (system must be connected to a central station).

• When the system’s Auxiliary Voltage Triggers are connected to another communication’s media (Derived Channel/Long Range Radio), note that duress is signaled on the same trigger that signals silent panic (whereas duress has its own unique report when digitally communicated).

• Assigned on a partition-by-partition basis, and can be any code or codes desired.

General Rules on Authority Levels and Changes

The following rules apply to users when making modifications within the system based on the user code authority levels:

• Master Codes and all lower-level codes can be used interchangeably when performing system functions within a partition (a system armed with a user’s temporary code can be disarmed with the Master Code or another user’s temporary code), except the Operator Level C Code described above.

• A user may not delete or change the user code of the SAME or HIGHER authority than that which he is assigned.

• A user (levels 0, 1 and 2 only) may only ADD users to a LOWER authority level.

• A user may assign other users access to only those partitions to which he himself has access.

• A user code can be DELETED or CHANGED only from within the partition it was created in.

• User numbers must be entered in 2-digits. Single-digit user numbers must, therefore, always be preceded by a “0” (e.g., 03, 04, 05, etc.). Make sure the end user understands this requirement. Temporary codes are entered as 4-digit numbers.

Duress Reporting Note: A non-zero report

and partition-specific field *85 duress location enabled, to enable Duress reporting.

• The Duress report-triggering logic activates on the 5th key depression (such as OFF), not the 4th key depression (last digit of code). Duress reports are not triggered if the 5th key is a [*], such as when you perform a GOTO or view the capabilities of a user.

Open/Close Reporting Note: When a user is added, the system prompts for Open/Close reporting capability only if the installer is adding the new user. When a Master or Manager adds a new user, the new user’s Open/Close reporting is the same as that of the Master or Manager who is adding the user. If Open/Close reports are required to be selectable by the Master or Manager, the Installer should assign two Master or Manager user codes: one with Open/Close reporting enabled, and one without.

Note that Open/Close reporting of Quick Arm is enabled if User 02 is enabled for Open/Close reporting, and that Quick Arm reports as User 00. In order for Quick Arm reports to be sent for all partitions, User 02 must have authority and Open/Close must be enabled for all partitions. If a code with access to all partitions is not desired, it is suggested that user 02 be assigned authority level 5 in all partitions, and that the code be kept secret. Authority level 5 cannot disarm the system unless armed by that user.

ADEMCO Contact ID format is capable of reporting Users 01-70 uniquely. If any other report format is used, only user numbers 01 – 15 can uniquely report to the central station. Users 16 – 70 will report as User 15.

Multiple Partition Access

Each user is programmed for a primary (home) partition. A user can also be given access to operate one or both partitions. Within each partition, each user may be programmed to have different levels of authority. For example, User 03, the VP of Engineering, could be assigned to work within the Engineering Department (Partition 1) of ABC Manufacturing. Because he needs the full capabilities in his area, he is assigned as a MASTER with Level 1 authority.

He must also be able to gain access to the manufacturing area (Partition 2) on an emergency basis. You can set this up easily by requesting that he also be assigned to Partition 2, with a level of authority set lower, such as Level 4 (OPERATOR Level B).

8-2

The control automatically assigns him the same user number within Partition 2.

EXAMPLE OF MULTIPLE PARTITION ACCESS

Part 1 Part 2

User 3 User 3

Level 1 Level 4

Master Oper B

In the above example, User 3 has MASTER authority in Partition 1 and OPERATOR B authority in Partition 2. His user number is the same for both partitions.

Adding a Master, Manager, or Operator Code

Section 9 – User Access Codes

During user code entry, normal key depressions at other keypads in a partition are ignored. However, panic key depression causes an alarm and terminates user entry.

PROMPT

User Number = 03

Enter Auth. Level

Open/Close Rep.?

0 = NO , 1 = YES

RF Button ?

0=NO , 1=YES

Enter Button ZN #

(01-63)

Multi-Access ?

0 = NO , 1 = YES

Global Arm ?

0 = NO , 1 = YES

Part. 2 – SHOP ?

0 = NO , 1 = YES

Part. 1 A06 WHSE

User 03 Auth=3G.

Enter Installer Code†+ [8] + new user no. (02-69) + new user’s code

†

Or Master or Manager Code, but the code must be a higher level of authority than the code being changed (e.g., a Manager Code can add an Operator-level Code, but cannot add a Master or another Manager Code). Keypad prompts for the authority level for this user.

EXPLANATION

Enter the level number as follows:

1 = Master

2 = Manager

3 = Operator Level A

4 = Operator Level B

5 = Operator Level C

6 = Duress

Keypad then prompts for Open/Close reporting option for this user.

Press 0 (NO) or 1 (YES), depending on whether or not arming/disarming by this user will trigger Opening and Closing reports. This prompt appears only if the Installer Code is used to add a user.

If a 5800 Series button transmitter has been enabled for arming/disarming functions, and is not assigned to a user, this prompt appears. Press 0 (NO) or 1 (YES).

If you answered “yes” to the RF button question, the zone number for the button is requested. Enter any one of the zone numbers assigned to the button transmitter as AWAY, STAY, or DISARM. The system then assigns all buttons of the transmitter to this user number.

Press 0 (NO) if the user is to have access to this partition only. Press 1 (YES) if the user is to have access to more than one partition. If NO, the program exits this mode. If YES, the keypad prompts for the Global Arm option for this user.

Press 0 (NO) or 1 (YES), depending on whether this user will be allowed to arm more than one partition via Global Arm prompts.

The keypad now prompts for the user’s access to the next partition.

Press 0 (NO) or 1 (YES), depending on whether this user will have access to the displayed partition number. If NO, the keypad displays this prompt for the next partition number in sequence.

If YES, the keypad prompts for the following:

• User’s authority level in the displayed partition (see Authority Level prompt above).

• Open/Close option for this user in the displayed partition (see Open/Close prompt above).

• Global Arm option for this user in the displayed partition (see Global Arm prompt above).

When all partitions have been displayed, the keypad will scroll through all partitions to which access has been assigned, and will display the user number, authority level, open/close and global arm options that were programmed for each partition to which the user was granted access. See next prompt.

Note that the “G” following the authority level indicates that the global arm feature is enabled for this user in the displayed partition, and that the period at the end of the second line indicates Open/Close reporting is enabled for this user in the displayed partition. The “ changed or deleted.

” indicates the partition from which the user may be

8-3

VISTA-40 Installation and Setup Guide

Changing a Master, Manager, or Operator Code

Enter Installer Code*+ [8] + new user no. (02-69) + new user’s code *

Or Master or Manager Code, but the code must be a higher level of authority than the code being changed (e.g. a

Manager Code can add an Operator-level Code, but cannot add a Master or another Manager Code).

PROMPT

User Number = 03

NEW USER?

EXPLANATION

The system detects that the user number is already assigned, and prompts if this is a new user.

Press 0 (NO).

The system then confirms that the change is allowed based on authorization level.

Adding an RF Key to an Existing User

To add an RF key to an existing user, or to change a user’s global arm option, first delete that user’s code, then re-add the user code as described in the “Adding a Master, Manager, or Operator Code” paragraph.

Deleting a Master, Manager, or Operator Code

Enter your code*+ [8] + new user no. (02-69) + your code again *

Or Master or Manager Code, but the code must be a higher level of authority than the code being changed (e.g. a

Manager Code can add an Operator-level Code, but cannot add a Master or another Manager Code).

PROMPT

OK TO DELETE 03?

0=NO 1=YES

EXPLANATION

The system prompts to confirm that you want to delete this user. Press 0 (NO) or 1 (YES).

If you answer “yes,” that user’s code is removed from all partitions to which it was assigned, and all authorization levels and other information about that user are deleted. Note: A user can be deleted only by a user with a higher authority level. A user cannot delete himself.

A user code can be deleted only from the partition through which it was entered. If an attempt is made to delete from another partition, the message “User [XX] Not Deleted” is displayed.

Exiting the User Edit Mode

Press either [7] or [#], or don’t press any key for 10 seconds.

8-4

SECTION 9

Testing the System

•••••••••••••••••••••••••••••••••••••••••••••••••

Battery Test

When AC power is present, the VISTA-40 runs a brief battery test every 4 hours to determine if there is a battery connected.

If the VISTA-40 finds that the battery voltage is low (less than approximately 11.5V), it initiates a keypad “SYSTEM LOBAT” display and a rapid keypad beeping sound.

Dialer Test

The VISTA-40 may be programmed to automatically transmit test reports to a central station at intervals ranging from once per hour to once per 199 hours (field ✳27).

Burglary Walk-Test (Code + [5] TEST)

This test causes the system to sound keypad beeps in response to faults on zones for the purpose of allowing proper zone operation to be checked without triggering alarms. This test can be activated by any-level user by entering the corresponding security code and pressing TEST while the burglary portion of the system is disarmed. UL requires that this test be conducted on a weekly basis.

When this test is first entered, the system activates the alarm output for 3 seconds. The system sends a test message to the central station. The keypad displays “Test in Progress” and sounds a single beep every 15 seconds while the test remains active.

It also sends a Low Battery report to the central station (if programmed). The keypad is cleared by entering any security code + OFF, and a Restore report is sent to the central station if the situation has been corrected.

UL requires the test report to be transmitted at least once every 24 hours. The system can be programmed to send the first report at any time of the day, or on any day of the week (field ✳83).

Open and close each protected door and window in turn. Each action should produce 3 beeps from the keypad. Walk in front of any motion detectors. Listen for three beeps when the detector senses movement.

The keypad displays the zone number and alpha descriptor while a door or window remains open or while a detector remains activated. The system automatically issues a Zone 8 Glassbreak Detector Power Reset about 10 seconds after it finds a fault on this zone, to allow faulted detectors to be reset.

To end this test, enter any security code and press OFF.

Armed Burglary System Test

Alarm messages are sent to the central station during the armed system tests. Notify the central station that a test will be in progress.

A display of “COMM. FAILURE” indicates a failure to communicate (no kissoff by the receiver at the central station after the maximum number of transmission attempts is tried). If this occurs, verify that the phone line is connected, the correct report format is programmed, etc.

To perform an armed burglary test, proceed as follows:

Step Action

1 Notify the central station that a test of the

system is being performed.

2 Arm the system.

3 Fault one or more zones.

4 Silence alarm sounder(s) each time by

entering the code and pressing OFF. NOTE: The system must be rearmed after

each code + off sequence.

5 Check that entry/exit delay zones provide the

assigned delay times.

9-1

VISTA-40 Installation and Setup Guide

Step Action

6 Check the keypad-initiated alarms, if

programmed, by pressing the panic key pairs (✳ and #, 1 and ✳, and/or 3 and #).

The word ALARM and a descriptor “99” are displayed for ✳ and #. If [1] and [✳] are pressed, “95” is displayed; if [3] and [#] are pressed, “96” is displayed.

7 If the system has been programmed for

audible emergency, the keypad emits a loud, steady alarm sound. Silence the alarm by entering the security code and pressing OFF. If the system has been programmed for silent panic, there are no audible alarms or displays. A report is sent to the central station, however.

8 Notify the central station that all tests are

finished, and verify results with them.

Testing Wireless Transmitters

Transmitter ID Sniffer Mode

Use the Transmitter Sniffer Mode to test that transmitters have all been properly programmed.

If a transmitter does not have its serial number “enrolled,” it will not turn off its zone number.

To enter the Transmitter ID Sniffer Mode, proceed as follows:

Step Action

1 Enter Installer Code + [#] + [3]. The

keypad displays all zone numbers of wireless units programmed into the system.

2 Fault each wireless zone, causing each device

to transmit.

As the system receives a signal from each of the transmitters, the zone number of that transmitter disappears from the display.

3 Enter Installer Code + OFF to exit the

Sniffer Mode.

Go/No Go Test Mode

Checking the transmitters in this mode assists in determining good mounting locations, and verifies that the RF transmission has sufficient signal amplitude margin for the installed system.

To enter the Go/No Go Test Mode, proceed as follows:

Step Action

1 Enter Installer Code + [5].

2 Fault each wireless transmitter, causing each

device to transmit.

NOTE: If a single receiver is used, the keypad beeps three times to indicate signal reception. If two receivers are used, the keypad beeps once if the first receiver received the signal, twice if the second receiver received the signal, and three times if both receivers heard the signal.

3 If the keypad does not beep, reorient or move

the transmitter to another location. Usually a few inches in either direction is all that is required.

4 Enter Installer Code + OFF to exit the

Go/No Go Test Mode.

• All partitions containing wireless transmitters must be placed in the test mode for sensitivity reduction of the RF receiver (50% sensitivity). Otherwise, the RF receiver remains at full strength.

• Make sure that all partitions are disarmed when performing this test, as the wireless receiver gain is reduced in half.

9-2

Trouble Conditions

Section 10 – Testing The System

Check or Trouble Messages

Display Description

CHECK

This indicates that a problem exists on the zone number displayed. Zone trouble may be caused by one of the following conditions:

• A hardwired fire zone is open (broken wire).

• A Day/Night zone (zone type 5) is faulted.

• A polling loop zone is not seen by the control panel.

• A polling loop zone has been tampered (cover removed on a

4190).

• A wireless zone has not checked in during the time programmed in field 1✳31.

• A 5800 Series transmitter has been tampered (cover removed).

• A system trouble exists (RF receiver, bell output, etc.).

If the problem has been corrected, enter an OFF sequence (Security Code + OFF) twice to clear the display.

Power Failure

Display Description

AC LOSS POWER

LED is off

This indicates that the system is operating on battery power only. Check to see that the circuit breaker for the branch circuit that your system’s transformer is wired to has not been accidentally turned off. Instruct the

user to call a service representative immediately if AC power cannot be restored.

Other System Messages

Display Description

COMM FAILURE

LO BAT

SYSTEM LO BAT

RCVR SETUP ERROR

MODEM COMM

This indicates that a failure occurred in the telephone communication portion of your system.

This indicates that a low-battery condition exists in the wireless transmitter displayed. Pressing any key silences the audible warning sound.

This indicates that a low-battery condition exists with the system’s backup battery.

This indicates that the system has more wireless zones programmed than the wireless receiver can support. If this is not corrected, none of the zones in the system will be protected. If additional wireless zones are desired, use an appropriate receiver.

This indicates that the control is on-line with a remote computer.

To the Installer

Regular maintenance and inspection (at least annually) by the installer and frequent testing by the user are vital to continuous satisfactory operation of any alarm system.

The installer should assume the responsibility of developing and offering a regular maintenance program to the user as well as acquainting the user with the proper operation and limitations of the alarm system and its component parts. Recommendations must be included for a specific program of frequent testing (at least weekly) to ensure the system’s proper operation at all times.

Turning the System over to the User

Fully explain the operation of the system to the user by going over each of its functions, as well as the User’s Manual supplied.

In particular, explain the operation of each zone (entry/exit, perimeter, interior, fire, etc.). Be sure the user understands how to operate any emergency feature(s) programmed into the system.

9-3

VISTA-40 Installation and Setup Guide

Contacting Technical Support

PLEASE, before you call Technical Support, be sure you:

• READ THE INSTRUCTIONS!

• Check all wiring connections.

• Determine that the power supply and/or backup

battery are supplying proper voltages.

• Verify your programming information where applicable.

• Verify that all keypads and devices are addressed properly.

• Note the proper model number of this product, and the version level (if known) along with any documentation that came with the product.

• Note your customer number and/or company name.

Technical Support:.................................................... 1-800-645-7492 (8 a.m.-8 p.m. EST)

ATLIS-FAX FAXBACK Automated Fax Retrieval System:.................... 1-800-573-0153 or

.................................................................................................1-516-921-6704 / ext. 1667

World Wide Web Address: .......................................... http://www.honeywell.com/security

Having this information handy will make it easier for us to serve you quickly and effectively.

You may contact Technical Support via Toll-Free Fax. Please include your return fax number. You will receive a reply within 24 hours.

9-4

APPENDIX A

Regulatory Agency Statements

•••••••••••••••••••••••••••••••••••••••••••••••••

UL Installation Requirements

The following requirements apply to both UL Residential and UL Commercial Burglary installations:

• All partitions must be owned and managed by the same person(s).

• All partitions must be part of one building at one street address.

• The audible alarm device(s) must be placed where it/they can be heard by all partitions.

• The control cabinet must be protected from unauthorized access. This can be done by installing a tamper switch on

the cabinet door (not supplied with VISTA-40) or by installing a UL Listed passive infrared detector positioned to detect cabinet access. Wire the selected device to any EOLR-supervised zone (Zone 1-8). Program this zone for day trouble/night alarm (type 05) or 24-hour audible alarm (type 07) response. The 24-hour alarm response must be used for multiple-partitioned systems.

• Remote downloading and auto-disarming are not UL Listed features.

NOTE: UL Commercial Burglary installations require the attack resistant cabinet. The cabinet is included in the

VISTA-ULKT kit.

UL609 Grade A Local Mercantile Premises/Local Mercantile Safe & Vault

Use the following guidelines for a Grade A Local Mercantile Premises/Local Mercantile Safe & Vault installation:

• All zones must be configured for EOLR supervision (✳41=0). Wireless sensors may not be used. If 4190WH RPMs are used, set field ✳24 to “0” to enable tamper detection.

• Attach a door tamper switch (supplied) to the VISTA-40 cabinet backbox. For safe and vault installations, a shock sensor (not supplied) must also be attached to the backbox. (Also see SECTION 3: Installing the Control)

• Wire an AB12 Grade A Bell/Box to the bell output. Bell wires must be run in conduit. Program the bell output for a timeout of 16 minutes or longer timeout and for confirmation of arming ding. (Also see SECTION 3: Installing the Control.)

• Wire the VISTA-40 tamper switch and AB12 Bell/Box tamper switches to any EOLR-supervised zone (zones 1-8). Program this zone for day trouble/night alarm (type 05) or 24-hour audible alarm (type 07) response. The 24-hour alarm response must be used for multiple-partitioned systems.

• Entry delays must not exceed 45 seconds, and exit delays must not exceed 60 seconds.

UL365 Police Station Connected Burglar Alarm

Follow the instructions for UL609 local installations given above.

For Grade A Service:

• You may use the VISTA-40 dialer alone, or the 7720 Long Range Radio alone.

• When using the dialer, program it to send Burglary Alarm, Low Battery, and Communicator Test reports. Field ✳27

must be set to “024” (or less).

• If you are using the 7720, connect it to the VISTA-40 burglary/audible panic alarm trigger.

For Grade AA Service:

• You must use a 7920SE Long Range Radio.

• Connect the 7920SE to the VISTA-40 burglary/audible panic alarm trigger.

A-1

VISTA-40 Installation and Setup Guide

UL611/UL1610 Central Station Burglary Alarm

Follow the instructions for UL609 Local installations given above.

For Grade A Service:

• You must use the VISTA-40 dialer with a 7720 Long Range Radio.

• Connect the control’s burglary/audible panic alarm trigger (on J7 header) and the 659EN’s phone line monitor

output to the 7720. The 7720 will send a report to the central station when a telephone line fault condition is detected.

• Also connect the 7720’s radio fault output to one of the VISTA-40 EOLR-supervised zones (i.e., 1-8). Program this zone for a trouble by day/alarm by night (type 05) or a 24-hour alarm (type 07, 08) response to radio faults.

• Program the control’s dialer to send Burglary Alarm, Trouble, Opening/Closing, and Low Battery reports.

For Grade AA Service:

Follow the instructions for Grade A service, except use the 7920SE in place of the 7720.

California State Fire Marshal (CSFM) and UL Residential Fire Battery Backup Requirements

The California State Fire Marshal and UL have regulations that require all residential fire alarm control panels to have backup battery with sufficient capacity to operate the panel and its attached peripheral devices for 24 hours in the intended standby condition, followed by at least 4 minutes in the intended fire alarm signaling condition.

The VISTA-40 can meet this requirement without using a supplemental power supply, provided that the panel’s outputs (including the current drawn from the auxiliary power output terminals) are limited as shown below:

• Output current is limited to 750mA maximum total auxiliary power, polling loop, and bell output current.

• Maximum auxiliary current is 300mA (including polling loop current).

• A 14AH battery is used. (Yuasa model NP7-12 recommended; use two connected in parallel.) A dual-battery harness

is provided with the 4100EOLR Resistor Kit (kit also contains EOL resistors having spade lug/heat shrink tubing construction approved by UL and CSFM for fire zone usage). Both batteries fit inside the panel’s cabinet.

A-2

Appendix A – Regulatory Agency Statements

FEDERAL COMMUNICATIONS COMMISSION (FCC) PART 15 STATEMENT

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

IN THE EVENT OF TELEPHONE OPERATIONAL PROBLEMS

In the event of telephone operational problems, disconnect the control panel by removing the plug from the RJ31X (CA38A in Canada) wall jack. We recommend that you demonstrate disconnecting the phones on installation of the system. Do not disconnect the phone connection inside the control panel. Doing so will result in the loss of your phone lines. If the regular phone works correctly after the control panel has been disconnected from the phone lines, the control panel has a problem and should be returned for repair. If upon disconnection of the control panel, there is still a problem on the line, notify the telephone company that it has a problem and request prompt repair service. The user may not under any circumstances (in or out of warranty) attempt any service or repairs to the system. It must be returned to the factory or an authorized service agency for all repairs.

FCC PART 68 NOTICE

This equipment complies with Part 68 of the FCC rules. On the front cover of this equipment is a label that contains, among other information, the FCC registration number and ringer equivalence number (REN) for this equipment. If requested, this information must be provided to the telephone company.

This equipment uses the following jacks: An RJ31X is used to connect this equipment to the telephone network. The REN is used to determine the quantity of devices that may be connected to the telephone line. Excessive

RENs on the telephone line may result in the devices not ringing in response to an incoming call. In most, but not all areas, the sum of the RENs should not exceed five (5.0). To be certain of the number of devices that may be connected to the line, as determined by the total RENs, contact the telephone company to determine the maximum REN for the calling area.

If this equipment causes harm to the telephone network, the telephone company will notify you in advance that temporary discontinuance of service may be required. If advance notice is not practical, the telephone company will notify the customer as soon as possible. Also, you will be advised of your right to file a complaint with the FCC if you believe necessary.

The telephone company may make changes in its facilities, equipment, operations, or procedures that could affect the operation of the equipment. If this happens, the telephone company will provide advance notice in order for you to make the necessary modifications in order to maintain uninterrupted service.

If trouble is experienced with this equipment, please contact the manufacturer for repair and warranty information. If the trouble is causing harm to the telephone network, the telephone company may request that you remove the equipment from the network until the problem is resolved.

There are no user serviceable components in this product, and all necessary repairs must be made by the manufacturer. Other repair methods may invalidate the FCC registration on this product.

This equipment cannot be used on telephone company-provided coin service. Connection to Party Line Service is subject to state tariffs.

This equipment is hearing-aid compatible. When programming or making test calls to an emergency number, briefly explain to the dispatcher the

reason for the call. Perform such activities in the off-peak hours, such as early morning or late evening.

A-3

VISTA-40 Installation and Setup Guide

CANADIAN EMISSIONS STATEMENTS

This Class B digital apparatus complies with Canadian ICES-003

NOTICE

The Industry Canada Label identifies certified equipment. This certification means that the equipment meets telecommunications network protective, operational and safety requirements as prescribed in the appropriate Terminal Equipment Technical Requirements document(s). The Department does not guarantee the equipment will operate to the user’s satisfaction.

Before installing this equipment, users should ensure that it is permissible to be connected to the facilities of the local telecommunications company. The equipment must also be installed using an acceptable method of connection. The customer should be aware that compliance with the above conditions may not prevent degradation of service in some situations.

Repairs to certified equipment should be coordinated by a representative designated by the supplier. Any repairs or alterations made by the user to this equipment, or equipment malfunctions, may cause the telecommunications company to request the user to disconnect the equipment.

Users should ensure for their own protection that the electrical ground connections of the power utility, telephone lines, and internal metallic water pipe system, if present, are connected together. This precaution may be particularly important in rural areas.

Caution: Users should not attempt to make such connections themselves, but should contact an appropriate electric inspection authority, or electrician, as appropriate.

NOTICE: The Ringer Equivalence Number (REN) assigned to each terminal device provides an indication of the maximum number of terminals allowed to be connected to a telephone interface. The termination on an interface may consist of any combination of devices subject only to the requirement that the sum of the Ringer Equivalence Numbers of all the devices does not exceed 5.

AVIS

L’étiquette d’Industrie Canada identifie le matériel homologué. Cette étiquette certifie que le matériel est conforme aux normes de protection, d’exploitation et de sécurité des réseaux de télécommunications, comme le prescrivent les documents concernant les exigences techniques relatives au matériel terminal. Le Ministère n’assure toutefois pas que le matériel fonctionnera à la satisfaction de l’utilisateur. Avant d’installer ce matériel, l’utilisateur doit s’assurer qu’il est permis de le raccorder aux installations de l’enterprise locale de télécommunication. Le matériel doit également être installé en suivant une méthode acceptée da raccordement. L’abonné ne doit pas oublier qu’il est possible que la conformité aux conditions énoncées ci-dessus n’empêche pas la dégradation du service dans certaines situations.

Les réparations de matériel nomologué doivent être coordonnées par un représentant désigné par le fournisseur. L’entreprise de télécommunications peut demander à l’utilisateur da débrancher un appareil à la suite de réparations ou de modifications effectuées par l’utilisateur ou à cause de mauvais fonctionnement.

Pour sa propre protection, l’utilisateur doit s’assurer que tous les fils de mise à la terre de la source d’energie électrique, de lignes téléphoniques et des canalisations d’eau métalliques, s’il y en a, sont raccordés ensemble. Cette précaution est particulièrement importante dans les régions rurales.

Avertissement : L’utilisateur ne doit pas tenter de faire ces raccordements lui-même; il doit avoir racours à un service d’inspection des installations électriques, ou à un électricien, selon le cas.

AVIS : L’indice d’équivalence de la sonnerie (IES) assigné à chaque dispositif terminal indique le nombre maximal de terminaux qui peuvent être raccordés à une interface. La terminaison d’une interface téléphonique peut consister en une combinaison de quelques dispositifs, à la seule condition que la somme d’indices d’équivalence de la sonnerie de tous les dispositifs n’excède pas 5.

A-4

APPENDIX B

Summary of System Commands

••••••••••••••••••••••••••••••••••••••••••••••••••

User Code Commands

Programming Commands

Event Logging Commands

Wireless System Commands

Additional Commands

Relay Device Control Commands

Access Control Commands

Add A User Code = User Code + 8 + New User Number + New User’s Code

Change a Code = User Code + 8 + User Number + New User’s Code

Delete a User’s Code = Your User Code + 8 + User Number to Be Deleted + Your Code Again

View User Capability = User’s Code + [✳] + [✳]

Set Real-Time Clock (Installer, Master Only) = Code + [#] + 63

Site Initiated Download = User Code + [#] + 1.

Direct-Wire Download Enable = User Code + [#] + 5.

Enter Program Mode = Installer Code + 800.

Enter Interactive Program Mode = Installer Code + 800 + [#] + 93

Exit Program Mode = ✳99 or ✳98.

Event Log Display = Code + [#] + 60 (Installer or Master Only)

Event Log Print = Code + [#] + 61 (Installer or Master Only)

Clear Event Log = Code + [#] + 62 (Installer or Master Only)

House ID Sniffer Mode = Code + [#] + 2 (Installer Only)

Transmitter ID Test = Code + [#] + 3 (Installer Only)

Go/No Go Test = Code + 5 (Test Key)

Partition GOTO

GOTO Home Partition

Panics

View Downloaded Messages Press 0 for 5 Seconds.

Display All Zone Descriptors

Display User Self Help Hold Any Key for 5 Seconds.

Activate Relay Device as Programmed = User Code + [#] + 71.

Activate Relay Device as Programmed = User Code + [#] + 72.

Activate Relay Device Manually = User Code + [#] + 70.

Activate Access Relay for Current Partition = User Code + 0.

User Code + [✳] + Partition Number 0-2.

User Code + [✳] + 0.

[✳] + 1 or A Key (Zone 95).

[✳] + [#] or B Key (Zone 99).

[#] + 3 or C Key (Zone 96).

Press [✳] for 5 Seconds.

B-1

VISTA-40 Installation and Setup Guide

B-2

APPENDIX C

Specifications

••••••••••••••••••••••••••••••••••••••••••••••••••

VISTA-40 CONTROL

Physical:

Standard Cabinet (included) 12 1/2" W x 14 1/2" H x 3" D

UL Cabinet (optional) 14 1/2" W x 18" H x 4.3" D (Included in the VISTA-ULKT kit)

Electrical:

Voltage Input: From the 1361 Plug-In Transformer (use 1361CN in Canada) or 1361X10 transformer

(for X-10 installations) rated 16.5VAC, 40 VA.

Alarm Sounder Output: 10VDC-13.8VDC, 1.7 amps max. (UL1023, UL609 installations); 750mA less aux.

current draw (UL985 installations).

Auxiliary Power Output: 9.6VDC-13.8VDC, 750mA max. For UL installations, the accessories connected to the

output must be UL Listed, and rated to operate in the above voltage range.

Backup Battery: 12VDC, 4AH or 7AH gel cell. YUASA NP4-12 (12V, 4AH) or NP7-12 (12V, 7AH)

recommended.

Standby Time: 4 hours min. with 750mA aux. load using 7 AH battery.

Circuit Protectors: PTC circuit breakers are used on battery input to protect against reverse battery

connections and on alarm sounder output to protect against wiring faults (shorts).

A solid-state circuit breaker is used on auxiliary power output to protect against wiring

faults (shorts).

Digital Communicator

Formats Supported: ADEMCO High Speed, ADEMCO 4 + 2 Express, ADEMCO Low Speed, ADEMCO

Contact ID, Sescoa and Radionics Low Speed

Line Seize: Double Pole

Ringer Equivalence: 0.7B

FCC Registration No.: AC398U-68192-AL-E

Remote Keypads

6139

Physical:

Width: 6.25 inches

Height: 4.75 inches

Depth: 1.25 inches

Electrical:

Voltage Input: 12VDC

Current Drain: 100mA

Interface Wiring:

RED: 12VDC input (+) auxiliary

power

BLUE: Not Used

GREEN: Data to control panel

YELLOW: Data from control panel

BLACK: Ground and (-) connection from

supplemental power supply

6160

Physical:

Width: 7.437 inches

Height: 5.25 inches

Depth: 1.312 inches

Electrical:

Voltage Input: 12VDC

Current Drain: 150mA

Interface Wiring:

RED: 12VDC input (+) auxiliary

power

BLUE: Not Used

GREEN: Data to control panel

YELLOW: Data from control panel

BLACK: Ground and (-) connection from

supplemental power supply

C-1

VISTA-40 Installation and Setup Guide

C-2

APPENDIX D

Contact ID Event Codes

••••••••••••••••••••••••••••••••••••••••••••••••••

TABLE OF CONTACT ID EVENT CODES

Code Definition

110 Fire Alarm

121 Duress

122 Silent Panic

123 Audible Panic

131 Perimeter Burglary

132 Interior Burglary

134 Entry/Exit Burglary

135 Day/Night Burglary

150 24-Hour Auxiliary

301 AC Loss

302 Low System Battery

305 System Reset

306 Program Tamper

309 Battery Test Fail

321 Bell 1 Trouble

332 Poll Loop Short-Trouble

333 Expansion Module Failure

344 RF Jam

373 Fire Loop Trouble

380 Trouble (global)

Code Definition

381 Loss of Supervision (RF)

382 Loss of RPM Supervision

383 RPM Sensor Tamper

384 RF Transmitter Low Battery

401 O/C by User

403 Power-Up Armed/Auto-Arm

406 Cancel by User

407 Remote Arm/Disarm (Download)

408 Quick Arm

409 Keyswitch O/C

411 Callback Requested

441 Armed STAY

570 Bypass

602 Communicator Test

606 Listen-In to Follow

607 Burglary Walk-Test

621 Event Log Reset

625 Time/Date Reset

626 Time/Date Inaccurate

D-1

VISTA-40 Installation and Setup Guide

D-2

Index

••••••••••••••••••••••••••••••••••••••••••••••••••

#93 Menu Mode Programming.................................... 4-2

#93 Menu Mode Programming Commands................. 4-3

12/24 Hour Type Stamp Format................................ 5-11

1361 ...................................................................3-24, C-1

1361X10 Transformer ...................................... 3-17, 3-24

24-hour Audible Alarm Type 07................................... 4-6

24-hour Auxiliary Alarm Type 08 ................................. 4-6

24-hour Silent Alarm Type 06...................................... 4-6

2-Wire Latching Glassbreak Detectors...................... 3-10

2-Wire Smoke Detectors ............................................. 3-7

333 PRM ..................................................................... 3-8

4100SM .............................................................. 3-19, 4-7

4100SM Serial Module ................................................ 6-3

4146 .......................................................................... 3-18

4197 Polling Loop Extender ...................................... 3-12

4204 and 4204CF Relay Modules............................. 3-16

4208 Module Zone Assignment................................... 5-8

4285/4286 VIP Module.............................................. 3-20

4297 Polling Loop Extender ...................................... 3-12

4-Wire Smoke Detectors ............................................. 3-7

5800 Series Transmitters .......................................... 3-15

5800TM Module ........................................................ 3-15

5869 .......................................................................... 3-13

5881 RF Receivers.................................................... 3-13

5881ENHC ................................................................ 3-13

6139 ............................................................................C-1

6160 ............................................................................C-1

675 Ground Start Module .......................................... 3-17

685 Receiver ............................................................. 3-22

719 .............................................................................. 3-4

747 .............................................................................. 3-4

7720 .......................................................................... 3-19

7720ULF.................................................................... 3-19

7920SE...................................................................... 3-19

Alarm Code for Zones 25–32 .......................................5-6

Alarm Code for Zones 33–40 .......................................5-6

Alarm Code for Zones 41–48 .......................................5-6

Alarm Code for Zones 49–56 .......................................5-7

Alarm Code for Zones 57–64 .......................................5-7

Alarm Code for Zones 65–72 .......................................5-9

Alarm Code for Zones 73–80 .....................................5-10

Alarm Code for Zones 87–88 .......................................5-7

Alarm Code for Zones 89–99 .......................................5-7

Alarm Output Current Load ........................................3-26

Alarm Output Supervision ............................................3-4

Alarm Sounder Duration...............................................5-2

ALPHA PROG ..............................................................4-3

Arm Stay and Time Set Report Codes (First Digit).....5-10

Arm Stay and Time Set Report Codes (Second Digit)5-10

Arm-Away Type 21.......................................................4-6

Arm-STAY Type 20 ......................................................4-6

Audio Alarm Verification Module ................................3-22

AUXILIARY OUTPUT ENABLE........................ 3-17, 3-19

Auxiliary Output Mode................................................5-10

Auxiliary Power Current Load.....................................3-26

BACK-UP BATTERY................................................... C-1

Battery Capacity Worksheet.......................................3-27

Battery Selection Table ..............................................3-27

Battery Test..................................................................9-1

Burglary Alarm Communicator Delay ...........................5-8

Burglary Trigger for Response Type 8 .........................5-3

Burglary Walk Test.......................................................9-1

Button RF (BR) Type 05..................................... 3-15, 4-6

AAV ........................................................................... 3-22

AB12............................................................................ 3-1

ABB1031 ..................................................................... 3-4

AC Loss Keypad Sounding.......................................... 5-2

AC Outlet Ground...................................................... 3-25

Access Control ............................................................ 4-7

Access Control Commands......................................... B-1

Access Relay Number............................................... 5-11

Adding a User Code .................................................... 8-3

Adding an RF Key to a User Code .............................. 8-4

Addressing the Keypads.............................................. 3-3

ADEMCO 4+2 EXPRESS.....................................3-5, C-1

ADEMCO CONTACT ID..............................................C-1

ADEMCO HIGH SPEED.............................................. C-1

ADEMCO LOW SPEED .......................................3-5, C-1

Agency Statements ..................................................... A-1

Alarm Code for Zones 01–08 ...................................... 5-6

Alarm Code for Zones 09–16 ...................................... 5-6

Alarm Code for Zones 17–24 ...................................... 5-6

Cabinet Lock ................................................................3-1

California State Fire Marshal (CSFM) ......................... A-2

Callback .......................................................................6-2

Callback Requested .....................................................6-1

CANADIAN EMISSIONS STATEMENTS.................... A-4

Changing a User Code.................................................8-4

Check Messages..........................................................9-3

Checksum Verification..................................................5-5

Chime on External Siren ............................................5-10

CIRCUIT PROTECTORS............................................ C-1

Code + TEST [5] ..........................................................9-1

Cold Water Pipe .........................................................3-25

COMM FAILURE..........................................................9-3

Communication Defaults ..............................................4-4

Communicator Split Reporting Selection......................5-9

Compass Downloading Software ......................... 6-1, 6-3

Compatible 2-Wire Smoke Detectors...........................3-7

Compatible 4-Wire Smoke Detectors...........................3-7

Compatible 5800 Series Transmitters........................3-16

Compatible Alarm Indicating Devices...........................3-4

Compatible Glass Break Detectors ............................3-10

Index-1

VISTA-40 Installation and Setup Guide

Compatible Polling Loop Devices.............................. 3-11

Confirmation of Arming Ding ....................................... 5-2

CONTACT ID EVENT CODES....................................D-1

Contacting Technical Support ..................................... 9-4

Control Unit Power Supply Load ............................... 3-26

Conventions Used in This Manual.................................. vi

CUSTOM INDEX......................................................... 4-3

Data Encryption........................................................... 6-1

Data Field Descriptions ............................................... 5-1

Data Field Programming Mode.................................... 4-1

Daylight Saving Time Start/End Month...................... 5-11

Daylight Saving Time Start/End Weekend ................ 5-12

Deleting a User Code .................................................. 8-4

DEVICE PROG............................................................ 4-3

Dial Tone Detection..................................................... 5-5

Dial Tone Pause.......................................................... 5-4

Dialer Test ................................................................... 9-1

DIGITAL COMMUNICATOR........................................C-1

DIP Switch Loop (DP) Type 07.................................... 4-6

Dip Switch Polling Loop Right Loop (PS) Type 08 ...... 4-6

Direct-Wire Downloading............................................. 6-3

Disable Download Callback....................................... 5-11

Disarm Type 22 ........................................................... 4-6

Download Command Enables..................................... 5-4

Download ID Number .................................................. 5-4

Download Phone Number ........................................... 5-4

Downloading................................................................ 6-1

Downloading Access Security ..................................... 6-1

Downloading Requirements ........................................ 6-1

Dual Reporting ............................................................ 5-5

Duress Codes Level 6 ................................................. 8-2

Duress Reporting ........................................................ 8-2

Earth Ground............................................................. 3-25

Enable 5800 RF Button Force Arm ........................... 5-11

Enable 5800 RF Button Global Arm .......................... 5-11

Enable Dialer Reports for Panics & Duress................. 5-8

Enable GOTO for this Partition.................................. 5-12

Enable J7 Triggers for Partition................................. 5-12

Enable Open/Close Report for Installer Code ............. 5-4

Enable Open/Close report for Keyswitch..................... 5-4

Entering Programming Mode....................................... 4-1

Entry Delay #1............................................................. 5-1

Entry Delay #2............................................................. 5-1

Entry Warning.............................................................. 5-8

Entry/Exit #1 Type 01 .................................................. 4-5

Entry/Exit #2 Type 02 .................................................. 4-5

Event Log .................................................................. 3-19

Event Log .................................................................... 1-2

Event Log Types ....................................................... 5-11

Event Logging Commands .......................................... B-1

Exit Delay #1 ............................................................... 5-1

Exit Delay #2 ............................................................... 5-2

Exit Delay Sounding .................................................. 5-10

Exiting the User Edit Mode.......................................... 8-4

EXPERT MODE ...........................................................4-3

External Sounders........................................................3-4

FCC Part 15 STATEMENT.......................................... A-3

FCC PART 68 NOTICE............................................... A-3

FCC REGISTRATION NO........................................... C-1

First Communication ....................................................6-2

First Test Report Time..................................................5-8

General Description......................................................1-1

Getting On-Line with a Control Panel...........................6-2

Global Arm ? ................................................................8-3

Go/No Go Test Mode ...................................................9-2

Grade A Mercantile Premises Listing...........................3-1

Grade A Mercantile Safe and Vault Listing ..................3-2

Grade A Service...................................................A-1, A-2

Grade AA Service.................................................A-1, A-2

Ground Start Module..................................................3-17

Hardwire and Optional Expansion Zones.....................1-1

Hardwired (HW) Type 01..............................................4-6

House ID Sniffer Mode...............................................3-15

ID Digit for Zones 01–08 ..............................................5-6

ID Digit for Zones 09–16 ..............................................5-6

ID Digit for Zones 17–24 ..............................................5-6

ID Digit for Zones 25–32 ..............................................5-6

ID Digit for Zones 33–40 ..............................................5-6

ID Digit for Zones 41–48 ..............................................5-6

ID Digit for Zones 49–56 ..............................................5-7

ID Digit for Zones 57–64 ..............................................5-7

ID Digit for Zones 65–72 ..............................................5-9

ID Digit for Zones 73–80 ............................................5-10

ID Digit for Zones 87–88 ..............................................5-7

ID Digit for Zones 89–99 ..............................................5-7

Ignore Expansion Zone Tamper...................................5-3

Installer (User 1) Code Level 0.....................................8-1

Installer Code ...............................................................5-1

Installing RPM Devices ..............................................3-10

Installing The Control ...................................................3-1

Installing the Control's Circuit Board ............................3-2

Intelligent Test Report ..................................................5-3

Interior w/Delay Type 10 ..............................................4-6

Interior, Follower Type 04 ............................................4-5

Keypad Panic Enables .................................................5-2

Keypads .......................................................................2-1

Keyswitch ...................................................................3-18

Keyswitch Assignment .................................................5-2

Index-2

Keyswitch Tamper..................................................... 3-18

LINE SEIZE ................................................................. C-1

List of Figures.................................................................. v

LO BAT........................................................................ 9-3

Long Range Radio to J7 Triggers ............................. 3-19

Low Speed Format (Primary) ...................................... 5-5

Low Speed Format (Secondary).................................. 5-5

Index

Prevent Zone XX Bypass .............................................5-4

Primary Format.............................................................5-5

Primary Phone Number................................................5-4

Primary Subscriber’s Account Number.........................5-3

Printer Configurations ................................................3-19

Program Modes............................................................4-1

Programming................................................................4-1

Programming Commands ........................................... B-1

PROGRAMMING COMMANDS ...................................4-1

Programming Entry Errors............................................4-2

Programming Partition-Specific Data Fields.................4-2

Programming System-Wide Data Fields ......................4-2

Manager Codes Level 2 .............................................. 8-1

Master Codes Level 1.................................................. 8-1

MODEM COMM ................................................... 6-1, 9-3

modems....................................................................... 6-1

Mounting The Control Cabinet .................................... 3-1

Multi-Access ? ............................................................. 8-3

Multiple Alarms............................................................ 5-2

Multiple Partition Access ............................................. 8-2

No Alarm Response Type 23 ...................................... 4-6

Non-Alarm Report Codes (First Digit........................... 5-7

Non-Alarm Report Codes (Second Digit...................... 5-8

Non-UL Installations .................................................... 3-4

Normally Closed or EOLR (Zones 2-8)........................ 5-4

Number of Codes per Partition.................................. 5-12

Number of Partitions.................................................. 5-11

OC or OPEN CIRCUIT ................................................ 3-3

On-Line Control Functions .......................................... 6-2

Open/Close Reporting................................................. 8-2

Operator Access Levels .............................................. 6-1

Operator Codes Levels 3-5 ......................................... 8-1

Output Device Control Commands.............................. B-1

Output Devices.......................................................... 3-16

Overvoltage Protection................................................ 3-5

PA400.......................................................................... 3-4

PABX Access Code..................................................... 5-3

Partitioned System ...................................................... 2-1

Partitioning ........................................................... 1-1, 2-1

Perimeter Type 03....................................................... 4-5

Peripherals Devices..................................................... 1-1

Permanent Keypad Display Backlighting................... 5-10

Phone Module Access Code ....................................... 5-2

Polling Loop............................................................... 3-10

Polling Loop Current Draw ........................................ 3-26

Polling Loop Supervision........................................... 3-12

Power Failure .............................................................. 9-3

Power-Up in Previous State ........................................ 5-3

Prevent Fire Timeout................................................... 5-2

Quick Arm............................................................. 5-3, 8-1

RADIONICS LOW SPEED .......................................... C-1

Randomize AC Loss Report.........................................5-2

RCVR SETUP ERROR ................................................9-3

Real-Time Clock...........................................................7-1

Regulatory Agency Statements................................... A-1

RELAY PGM ................................................................4-3

Relay Timeout XXX Minutes ......................................5-11

Relay Timeout YYY Seconds.....................................5-11

Remote Keypad Sounder...........................................3-19

Reporting Formats........................................................3-5

Response Types for Zones 01–08 ...............................5-1

Response Types for Zones 09–16 ...............................5-1

Response Types for Zones 17–24 ...............................5-1

Response Types for Zones 25–27, 97, 95, 96,

and 99 ......................................................................5-1

Response Types for Zones 28–32 ...............................5-9

Response Types for Zones 33–40 ...............................5-9

Response Types for Zones 41–48 ...............................5-9

Response Types for Zones 49–56 ...............................5-9

Response Types for Zones 57–64 ...............................5-9

Response Types for Zones 87–91 ...............................5-9

Restore Report Timing .................................................5-8

RF Receiver Supervision Check-in Interval..................5-9

RF System Installation Advisories..............................3-13

RF System Operation and Supervision......................3-13

RF Transmitter Check-in Interval .................................5-9

RF Transmitter Low Battery Reporting.........................5-9

RF Transmitter Low Battery Sound ..............................5-9

Ring Count ...................................................................6-2

Ring Detection Count ...................................................5-5

RINGER EQUIVALENCE............................................ C-1

RJ31X ..........................................................................3-5

RJ31X jack .................................................................3-21

RLY VOICE DESCR.....................................................4-3

Secondary Format........................................................5-5

Secondary Phone Number...........................................5-4

Secondary Subscriber Account Number ......................5-8

Send Cancel If Alarm + Off ........................................5-11

Index-3

VISTA-40 Installation and Setup Guide

serial number devices................................................ 3-11

Serial Number Polling Loop (SL) Type 06................... 4-6

Serial Printer.............................................................. 3-20

SESCOA .....................................................................C-1

Sescoa/Radionics........................................................ 3-5

Sescoa/Radionics Select............................................. 5-5

Siren Driver ................................................................. 3-5

Smoke Power Reversal Module .................................. 3-8

Specifications .............................................................. C-1

Standard/Expanded Reporting Primary....................... 5-6

Standard/Expanded Reporting Secondary.................. 5-6

Standby Battery Size................................................. 3-27

Supervised Fire (Without Verification) Type 09........... 4-6

Supervised RF........................................................... 3-15

Supervised RF (RF) Type 03....................................... 4-6

Supervision Pulses for LRR....................................... 5-12

Supervisory and Restore Codes for Zones 01–16 ...... 5-6

Supervisory and Restore Codes for Zones 17–32 ...... 5-6

Supervisory and Restore Codes for Zones 33–48 ...... 5-7

Supervisory and Restore Codes for Zones 49–64 ...... 5-7

Supervisory and Restore Codes for Zones 65–80 .... 5-10

Supervisory and Restore Codes for Zones 87–99 ...... 5-7

Supplementary Power Supply ..................................... 3-3

Suppress Transmitter Supervision Sound................. 5-10

Swinger Suppression .................................................. 5-8

System Commands ..................................................... B-1

System Communication............................................... 1-1

SYSTEM LO BAT........................................................ 9-3

System LoBat”............................................................. 9-1

System Messages ....................................................... 9-3

System Sensor A77-716B EOL Relay Module............ 3-7

System Sensor MA 12/24D ......................................... 3-4

System Sensor P12575............................................... 3-4

Telco Handoff .............................................................. 6-3

Telephone Line Connections....................................... 3-5

TELEPHONE OPERATIONAL PROBLEMS................ A-3

Test Report Interval..................................................... 5-3

Testing The System..................................................... 9-1

TouchTone or Rotary Dial ........................................... 5-3

TouchTone with Rotary Backup .................................. 5-9

Transformer Connections.......................................... 3-24

Transmitter Battery Life ............................................. 3-16

Transmitter ID Sniffer Mode ........................................ 9-2

Transmitter Input Types............................................. 3-15

Transmitter Supervision............................................. 3-15

Trouble by Day/Alarm by Night Type 05...................... 4-5

Trouble Conditions ...................................................... 9-3

Trouble Messages....................................................... 9-3

Turning the System Over to the User.......................... 9-3

UL Installation Requirements ......................................A-1

UL1023 Household Burglary Installations ................... 3-4

UL365 Police Station Connected Burglar Alarm.......... A-1

UL609 Grade A Local Mercantile Premises/Local

Mercantile Safe & Vault........................................... A-1

UL611/UL1610 Central Station Burglary Alarm........... A-2

UL985 Household Fire or Household Fire/Burglary

Installations ..............................................................3-4

Unsupervised RF........................................................3-15

Unsupervised RF (UR) Type 04 ...................................4-6

Use Partition Descriptor .............................................5-12

User Access Codes......................................................8-1

User Code Authority Levels..........................................8-1

User Code Commands................................................ B-1

User Code Rules..........................................................8-2

Users............................................................................2-1

View Capabilities..........................................................8-1

VIP Module.................................................................3-20

VIP Module Phone Code..............................................5-2

VISTA-40 Current Load..............................................3-26

Wheelock AS-121575W ..............................................3-4

Wire Run Length/Gauge ..............................................3-3

Wireless Keypad Assignment.....................................5-10

Wireless Keypad Tamper Detect................................5-10

Wireless System Commands ...................................... B-1

Wireless Zone Expansion...........................................3-13

Wiring Devices to Zones 1-9 ........................................3-6

Wiring the Alarm Output...............................................3-4

Wiring the Keypads ......................................................3-3

Worksheets to calculate the total current ...................3-26

World Wide Web Address ............................................9-4

X-10............................................................................3-17

Yuasa .........................................................................3-27

Zone 5 Audio Alarm Verification.................................5-11

Zone 804 ....................................................................3-20

Zone 9 Fast/Slow Response ........................................5-2

Zone Defaults...............................................................4-4

Zone Index ...................................................................4-4

Zone Input Type Definitions .........................................4-6

Zone Number Designations..........................................4-4

ZONE PROG........................................................... vi, 4-3

Zone Response Type Definitions .................................4-5

Zone Type Restores for Zone Types 1-8 .....................5-7

Zone Type Restores for Zone Types 9, and 10............5-7

Zones ...........................................................................2-1

Index-4

WARNING!

THE LIMITATIONS OF THIS ALARM SYSTEM

While this System is an advanced wireless security system, it does not offer guaranteed protection against burglary, fire or other emergency. Any alarm system, whether commercial or residential, is subject to compromise or failure to warn for a variety of reasons. For example:

• Intruders may gain access through unprotected openings or have the technical sophistication to bypass an alarm sensor or disconnect an alarm warning device.

• Intrusion detectors (e.g., passive infrared detectors), smoke detectors, and many other sensing devices will not work without power. Battery-operated devices will not work without batteries, with dead batteries, or if the batteries are not put in properly. Devices powered solely by AC will not work if their AC power supply is cut off for any reason, however briefly.

• Signals sent by wireless transmitters may be blocked or reflected by metal before they reach the alarm receiver. Even if the signal path has been recently checked during a weekly test, blockage can occur if a metal object is moved into the path.

• A user may not be able to reach a panic or emergency button quickly enough.

• While smoke detectors have played a key role in reducing residential fire deaths in the United States, they may not acti-

vate or provide early warning for a variety of reasons in as many as 35% of all fires, according to data published by the Federal Emergency Management Agency. Some of the reasons smoke detectors used in conjunction with this System may not work are as follows. Smoke detectors may have been improperly installed and positioned. Smoke detectors may not sense fires that start where smoke cannot reach the detectors, such as in chimneys, in walls, or roofs, or on the other side of closed doors. Smoke detectors also may not sense a fire on another level of a residence or building. A second floor detector, for example, may not sense a first floor or basement fire. Finally, smoke detectors have sensing limitations. No smoke detector can sense every kind of fire every time. In general, detectors may not always warn about fires caused by carelessness and safety hazards like smoking in bed, violent explosions, escaping gas, improper storage of flammable materials, overloaded electrical circuits, children playing with matches, or arson. Depending on the nature of the fire and/or location of the smoke detectors, the detector, even if it operates as anticipated, may not provide sufficient warning to allow all occupants to escape in time to prevent injury or death.

• Passive Infrared Motion Detectors can only detect intrusion within the designed ranges as diagrammed in their installation manual. Passive Infrared Detectors do not provide volumetric area protection. They do create multiple beams of protection, and intrusion can only be detected in unobstructed areas covered by those beams. They cannot detect motion or intrusion that takes place behind walls, ceilings, floors, closed doors, glass partitions, glass doors, or windows. Mechanical tampering, masking, painting or spraying of any material on the mirrors, windows or any part of the optical system can reduce their detection ability. Passive Infrared Detectors sense changes in temperature; however, as the ambient temperature of the protected area approaches the temperature range of 90° to 105°F (32° to 40°C), the detection performance can decrease.

• Alarm warning devices such as sirens, bells or horns may not alert people or wake up sleepers if they are located on the other side of closed or partly open doors. If warning devices are located on a different level of the residence from the bedrooms, then they are less likely to waken or alert people inside the bedrooms. Even persons who are awake may not hear the warning if the alarm is muffled by noise from a stereo, radio, air conditioner or other appliance, or by passing traffic. Finally, alarm warning devices, however loud, may not warn hearing-impaired people.

• Telephone lines needed to transmit alarm signals from a premises to a central monitoring station may be out of service or temporarily out of service. Telephone lines are also subject to compromise by sophisticated intruders.

• Even if the system responds to the emergency as intended, however, occupants may have insufficient time to protect themselves from the emergency situation. In the case of a monitored alarm system, authorities may not respond appropriately.

• This equipment, like other electrical devices, is subject to component failure. Even though this equipment is designed to last as long as 20 years, the electronic components could fail at any time.

The most common cause of an alarm system not functioning when an intrusion or fire occurs is inadequate maintenance. This alarm system should be tested weekly to make sure all sensors and transmitters are working properly. The security keypad (and remote keypad) should be tested as well.

Wireless transmitters (used in some systems) are designed to provide long battery life under normal operating conditions. Longevity of batteries may be as much as 4 to 7 years, depending on the environment, usage, and the specific wireless device being used. External factors such as humidity, high or low temperatures, as well as large swings in temperature, may all reduce the actual battery life in a given installation. This wireless system, however, can identify a true low battery situation, thus allowing time to arrange a change of battery to maintain protection for that given point within the system.

Installing an alarm system may make the owner eligible for a lower insurance rate, but an alarm system is not a substitute for insurance. Homeowners, property owners and renters should continue to act prudently in protecting themselves and continue to insure their lives and property. We continue to develop new and improved protection devices. Users of alarm systems owe it to themselves and their loved ones to learn about these developments.

LIMITED WARRANTY

Honeywell International Inc., 165 Eileen Way, Syosset, New York 11791, warrants its product(s) to be in conformance with its own plans and specifications and to be free from defects in materials and workmanship under normal use and service for 24 months from the date stamp control on the product(s) or, for product(s) not having a date stamp, for 12 months from date of original purchase unless the installation instructions or catalog sets forth a shorter period, in which case the shorter period shall apply. Seller’s obligation shall be limited to repairing or replacing, at its option, free of charge for materials or labor, any product(s) which is proved not in compliance with Seller’s specifications or proves defective in materials or workmanship under normal use and service. Seller shall have no obligation under this Limited Warranty or otherwise if the product(s) is altered or improperly repaired or serviced by anyone other than Honeywell factory service. For warranty service, return product(s) transportation prepaid, to Honeywell Factory Service, 165 Eileen Way, Syosset, New York 11791.

THERE ARE NO WARRANTIES, EXPRESS OR IMPLIED, OF MERCHANTABILITY, OR FITNESS FOR A PARTICULAR PURPOSE OR OTHERWISE, WHICH EXTEND BEYOND THE DESCRIPTION ON THE FACE HEREOF. IN NO CASE SHALL SELLER BE LIABLE TO ANYONE FOR ANY CONSEQUENTIAL OR INCIDENTAL DAMAGES FOR BREACH OF THIS OR ANY OTHER WARRANTY, EXPRESS OR IMPLIED, OR UPON ANY OTHER BASIS OF LIABILITY WHATSOEVER, EVEN IF THE LOSS OR DAMAGE IS CAUSED BY THE SELLER’S OWN NEGLIGENCE OR FAULT.

Seller does not represent that the product(s) it sells may not be compromised or circumvented; that the product(s) will prevent any personal injury or property loss by burglary, robbery, fire or otherwise; or that the product(s) will in all cases provide adequate warning or protection. Customer understands that a properly installed and maintained alarm system may only reduce the risk of a burglary, robbery, fire, or other events occurring without providing an alarm, but it is not insurance or a guarantee that such will not occur or that there will be no personal injury or property loss as a result. CONSEQUENTLY, SELLER SHALL HAVE NO LIABILITY FOR ANY PERSONAL INJURY, PROPERTY DAMAGE OR OTHER LOSS BASED ON A CLAIM THAT THE PRODUCT(S) FAILED TO GIVE WARNING. HOWEVER, IF SELLER IS HELD LIABLE, WHETHER DIRECTLY OR INDIRECTLY, FOR ANY LOSS OR DAMAGE ARISING UNDER THIS LIMITED WARRANTY OR OTHERWISE, REGARDLESS OF CAUSE OR ORIGIN, SELLER’S MAXIMUM LIABILITY SHALL NOT IN ANY CASE EXCEED THE PURCHASE PRICE OF THE PRODUCT(S), WHICH SHALL BE THE COMPLETE AND EXCLUSIVE REMEDY AGAINST SELLER.

This warranty replaces any previous warranties and is the only warranty made by Seller on this product(s). No increase or alteration, written or verbal, of the obligations of this Limited Warranty is authorized.

NOTES

165 Eileen Way, Syosset, New York 11791

¬19+l

N7001V5 5/04 Rev A

www.honeywell.com/security

Honeywell G-3000 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
