MODEL 610 SLICER
MODEL
610 ML-38388
701 S. RIDGE AVENUE
TROY, OHIO 45374-0001
937 332-3000
www.hobartcorp.com
FORM 34569 (Jan. 2001)
Installation, Operation, and Care of
MODEL 610 SLICER
SAVE THESE INSTRUCTIONS

GENERAL

The model 610 slicer is compact, convenient, and easy to use. The finish is polished anodized aluminum and the slicer is designed to be easy to clean. The 1⁄5 HP motor delivers acceptable performance in kitchens or food stores.

INSTALLATION

UNPACKING
Immediately after unpacking the slicer, check it for possible shipping damage. If the slicer is found to be damaged after unpacking, save the packaging material and contact the carrier within 15 days of delivery.
Prior to installation, test the electrical service to make sure that it agrees with the specifications on the machine data plate
(120 Volts / 60 Hertz / 1 Phase).
CARRIAGE HANDLE
To install the carriage handle, the carriage must be removed. Loosen the carriage hand knob (Fig. 1) and lift the carriage from its support. Install the carriage handle (Fig. 1) in the hole in the back of the carriage and secure it with the supplied fasteners.
Replace the carriage and secure it by tightening the carriage hand knob.
This machine must be thoroughly cleaned and sanitized after installation and before being put into service. Refer to C
ELECTRICAL
WARNING: THIS MACHINE IS PROVIDED WITH A THREE-PRONG GROUNDING PLUG. THIS
PLUG MUST BE CONNECTED TO A PROPERLY GROUNDED OUTLET. IF THE RECEPTACLE IS NOT THE PROPER GROUNDING TYPE, CONTACT AN ELECTRICIAN.
LEANING, page 3.
Fig. 1
CARRIAGE HAND KNOB
PL-41517-1

OPERATION

SAFETY
SAFETY DEVICES INCORPORATED IN THIS SLICER MUST BE IN THEIR CORRECT OPERATING POSITIONS ANYTIME THE SLICER IS IN USE.
The
KNIFE GUARD
(Fig. 2).
(Fig. 2) must be in position over the knife and secured by tightening the hand knob
The
MEAT GRIP
When the slicer is not running, the prevent the knife edge from being exposed.
Always UNPLUG the power cord before cleaning or moving the slicer.
(Fig. 2) must be used when slicing to keep your hands away from the knife.
INDEX KNOB
(Fig. 2) must be set on zero (fully clockwise) to
