Quick-Start Guide
Important!Important!
!
WARNING: Operation of any feature of this device while driving could be dangerous. Always be careful and attentive to your vehicle and the
tra c around you. Obey all tra c laws and obser ve safe driving practices.
Do not connect or disconnect your portable music player or program the Drive + Play™ 2 system while driving. Always pull o the road and
park in a safe position before browsing your portable music player or adjusting the settings on the Drive + Play 2 system.
Do not use headphones while operating any vehicle. The Drive + Play 2 system audio output is not suitable for driving headphones and is
intended to output a signal appropriate for an audio system’s line-level input jack or FM antenna input.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment
has been tested and found to comply with the limits for a Class B Digital Device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation. This equipment generates and can radiate radio-frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit di erent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Any changes or modi cations not expressly approved by the party responsible for compliance could void the user’s authority to operate the
equipment.
Important!Important!
Connecting the iPod Player
Always hold the Drive + Play™ 2 system’s dock connector for the iPod player by its sides and gently insert (or remove) the dock connector. Never use
excessive force to insert or remove the connector, or damage to your iPod player may occur.
Lost Data
Harman Kardon is not responsible for any lost data when using the Drive + Play 2 system. Be sure to back up the audio data les on your computer.
About Installation
IMPORTANT: The Drive + Play 2 system should be installed according to these instructions and relevant federal, state or local laws and regulations,
which the purchaser should determine prior to installation or use. For safety reasons, do not attempt to disable any safety function incorporated in
this device. Any alteration of this device may cause serious injury and shall void the warranty.
Although we recommend professional installation for your Harman Kardon® Drive + Play 2 system, this product is also designed for do-it-yourself
installation, especially when using the wireless FM transmission method. The enclosed instructions explain how to install the Drive + Play 2 system in
a general sense, but they do not show the exact methods for your particular vehicle. After reading this guide, if you feel uncomfortable in performing
the necessary steps to install the product, consider asking your car-audio dealer about professional installation options.
Warranty Information
The Drive + Play 2 system is warranted against defects. The duration of the warranty depends on the laws in the country in which it was purchased.
Your local Harman Kardon retailer can help determine the length of your warranty. To register your product, please visit www.harmankardon.com.
Your Package Should Include:
Cigarette Lighter Hub
Lighter Extension Cable
Hard-Wire Power Cable
Audio Cable
USB Adapter
iPod Cable
Display Screen
Display Cable
Display Mounting Base
Wired FM Transmitter Adapter
Wireless Control Knob
CR2032 Battery
Adhesive Mounting Pads (2)
Alcohol Cleaning Pads (2)
Mounting Screws (10)
Hex Keys (1.5mm and 3mm)
Quick-Start Guide
Warranty Card
ENGLISH
Quick-Start GuideQuick-Start Guide
3
Quick-Start Guide
Choose the Display Location
!
Select Display Mounting Location
Change Display Base Mount
only if needed for your chosen
mounting location.
Loosen 3mm screw in
center of the base.
Move base to the top
mounting hole.
Tighten screw again to
secure base.
The installation of this device between the driver and the windshield or otherwise in any manner that obstructs the driver’s clear view of the
road or tra c conditions is dangerous and may be prohibited by law. Do not install this device in any manner that impairs the safe operation
!
of the vehicle.
The display should be positioned to eliminate glare and re ections, and should be as close as possible to the driver’s normal line of sight, as long as such
positioning does not otherwise obstruct the driver’s view or impair the safe operation of the vehicle. Do not place device on the vehicle’s dashboard
unsecured. Do not install this device on any air bag panels or in the deployment eld of any air bags. For safety reasons, do not attempt to disable any safety
function incorporated in this device. Any alteration of this device may cause serious injury and shall void the warranty.
4
Quick-Start Guide
See below
Installing the Display Installing the Display
l
lo
th
Ti
th
m
n
in
tig
ba
u
loc
.
Mounting With Screws Mounting With Adhesive Pad
Align mounting plate to
A
1
location and attach with
three screws. Make sure the
arrow points toward the
front of the car.
Place display base onto
Base
Hex Screw
Mounting
Plate
2
mounting plate and rotate
into desired position.
Tighten the hex screw to lock
3
the display base onto the
mounting plate.
After
Mounting
Plug cable
into display. y
Hex Screw
4
1 2
Base
Mounting
Plate
Adhesive
Pad
3 4
Insert mounting plate
I
1
into display base and
tighten hex set screw.
Stick adhesive pad to
base rst, then clean
2
surface of mounting
s
location with supplied
alcohol pad.
Peel adhesive pad and
3
press display rmly
into desired location.
ENGLISH
Quick-Start GuideQuick-Start Guide
5
Quick-Start Guide
Installing the Wireless Control Knob
t
2
Install Control
Cont
Knob Battery
Use a coin to remove
the bottom cover.
Toward front of car
UP
6
Quick-Start Guide
3
Orient the base so that the arrow is
facing the front of the car.
You can either screw the base to
the mounting location or use the
supplied adhesive pad.
If you use the adhesive pad, you
must FIRST CLEAN the surface with
the supplied alcohol cleaning pad.
CR2032/DL2032
Mount Control Knob Base
1
Select Control Knob Mounting Location
1 2
4
Attach Control
h Con
Knob to Base
3
Push the knob down
onto the base, and
turn clockwise to lock
UP
it into place. The knob
can be removed by
turning the bottom
counterclockwise.
4
Connections to the Cigarette Lighter HubConnections to the Cigarette Lighter Hub
dio
Indica
1
Direct Cigarette
Lighter Plug-In
Options
Detach lighter stalk.
Stalk ts tightly. Some force is
required to separate.
Plug into vehicle.
Cigarette Lighter Extension Cable
2
YELLOW = Constant
source of +12V
RED = Switched source
3
of +12V (ACC)
BLACK = Ground
Hard-Wired
Installation
1 2 3
Power Indicator
harman
net
Expansion Port
Display
Audio
iPod Player
Output
Audio Output Options
1. If using the built-in wireless FM transmitter, leave the audio
output jack empty.
2. To wire directly to your vehicle’s antenna, plug the supplied
FM transmitter adapter into the audio output jack. See
diagram on next page.
3. To wire into an AUX input, connect the included audio cable’s
3.5mm plug to the audio output jack and then into your
vehicle’s AUX input.
Quick-Start Guide
ENGLISH
7
Quick-Start Guide
Wired FM Transmitter Adapter ConnectionsWired FM Transmitter Adapter Connections
Connect in the line between
vehicle antenna and radio.
Plug the adapter into
the back of radio or
1
FM tuner location.
Connect FM
transmitter adapter to
2
Drive + Play 2 system.
Plug the vehicle’s
antenna into FM
3
transmitter adapter.
1 2 3
If your car’s audio system does not provide an auxiliary input and there is no third-party adapter available, use the Drive + Play 2 system’s wired FM antenna
8
Quick-Start Guide
adapter for the best audio performance. See page 12.
Using the Control KnobUsing the Control Knob
Rotate ring to move
the highlight bar on
the screen
ENGLISH
Show previous menu
(press and hold to show
special features)
Previous
Press and hold to
REWIND
Press once to toggle
PLAY/PAUSE
Press and hold for 2
seconds to turn ON/OFF
Note: If the Drive + Play 2 system is turned o using the bottom button, it must be turned back on that way!
If the control knob is unresponsive, try pressing the top, center and right buttons simultaneously for 2 seconds, then turn the outer ring
until the highlight bar moves. If the control knob is still unresponsive, try a fresh CR2032-type battery.
Next
Press and hold
to FFWD
Press to select the
highlighted menu item
Quick-Start GuideQuick-Start Guide
9
Quick-Start Guide
iPodiPod PlayerPlayer Functions Functions
d
Y
e
g
.
1
iPod Connection Con rmation
When your iPod player is successfully connected, the iPod icon appears
in the top-right corner of the display. “iPod” will also appear as the rst
menu item.
iPod
Playing Music
The Drive + Play 2 system is designed to make navigating the menus on your iPod player simple and intuitive.
Select menu items using the scroll wheel and press the center button to select.
1
Select “iPod” from source menu.
iPod
Po
Your iPod Name
our iPod Nam
2
Browse list and select song.
3
View current selection on the screen.
10
Quick-Start Guide
Playlists
Name of Song
Name of Son
2 3
Connecting USB DevicesConnecting USB Devices
selection on
USB Drive Connection Con rmation
The Drive + Play 2 system is compatible with USB ash memory devices and other USB
devices. For a complete list of compatible devices, please visit www.driveandplay2.com.
USB
Storage
Device
When your USB drive is successfuly connected, the USB icon appears in the topright corner of the display. “USB Drive” will also appear as the rst menu item.
Playing Music
If your music les contain ID3 tags, you can browse just as you browse the iPod player
(see previous page). If no ID3 tags are contained in the les, use the folder structure
described below.
Select “USB Drive” from source menu.
1
1 2 3
USB Drive
ENGLISH
USB
Adapter
iPod Cable
USB Drive
Name of Folder
Name of Song
2
Select song.
View current selection on
3
the screen.
Quick-Start Guide
11
Con guring Audio PlaybackCon guring Audio Playback
Wireless FM Transmitter or Wired FM Antenna Adapter
If you use the built-in wireless FM transmitter, no additional wired audio connection is necessary. To use
the wired FM antenna adapter, you will need to wire it into your vehicle’s FM antenna connection rst, then
complete these steps. Either way, you must enable and select the FM transmitter frequency to hear audio
through your vehicle’s FM radio. Remember, you may try several frequencies for the best result.
1
Enable the FM transmitter and select FM frequency preset.
Settings System Settings
Once you have selected an FM preset, tune your FM radio to that same station. You should hear audio playback clearly.
If that frequency is not playing music clearly, select another preset by locating a frequency on your radio that is only
static and save that as a preset. This will o er the clearest path for the Drive + Play 2 system’s audio playback.
FM Transmitter
Line-Output Audio Connections
To use the Line-Out audio connection, the FM transmitter must rst be disabled using the steps shown.
Following that, you will need to connect into your head unit’s AUX input. Many vehicles may require a
third-party adapter (not included) to provide this type of connection.
1
Disable the FM transmitter.
Settings System Settings
12
Quick-Start Guide
FM Transmitter
Enable Yes
Preset 1 : 88.1
Preset 2 : 88.7
Preset 3 : 107.9
Add Preset
Enable No
Letter SeekLetter Seek
a
.
T
Se
t
st
ess
t
i
y
g
and
, in the
This feature allows you to quickly browse alphabetically sorted lists, such as Artist, Playlists and Songs, in the
iPod player.
1
s Art
2
s
, Pl
3
s
4
s, in
ENGLISH
1
2
Press and hold
top menu
button in an
alphabetically
sorted list.
Large letter appears on the screen.
L
3
Turn the ring to advance the letters manually
u
n
or press the “Next” or “Previous” buttons
to begin automatic scrolling.
Press “Select” to
P4“
r
advance to the rst
nce to the r
menu item that
begins with the
displayed letter.
” to
Quick-Start GuideQuick-Start Guide
13
Quick-Start Guide
Automatic MixAutomatic Mix
r
u
o
e
a
ent d
e
g
The Drive + Play 2 system creates channels automatically, and you can re ne the channel content during
playback. Choose “More like this” to place a higher priority on songs similar to the current selection. Choose
“Less like this” to place a lower priority on songs similar to the current selection. Choose “Play something
else” to reprioritize selections to something di erent from the song that’s currently playing.
1
Select “iPod” and then select “Automatic Mix”.
iPod Automatic Mix
3
1
Press and hold top
P
menu button during
A
Automatic Mix playback
to con gure content.
e th
2
c
ch
ont
3
4
rin
2
14
Browse the list and select the channel.
Now your iPod player plays the channel. This lets you customize the content.
Quick-Start Guide
4
C
Con gure the channel.
“Keep playing” / “Jump to” Options“Keep playing” / “Jump to” Options
In shu e mode, this feature will allow you to continue playing songs from the current artist or album without
leaving the “Now Playing” screen.
Press and hold
1
top menu button
during playback.
n
Keep playing artist
This feature will continue playing the current
song, then play the remaining songs by that artist
in order.
Jump to artist
This feature will stop playing the current song and
begin playing all the songs by that artist in order.
Keep playing album
This feature will continue playing the current
song, then begin playing the remaining songs on
that album in order.
Jump to album
This feature will stop playing the current song and
begin playing all the songs on that album in order.
ENGLISH
Quick-Start GuideQuick-Start Guide
15
TroubleshootingTroubleshooting
Troubleshoot problems, download updates and
nd out about more features at:
www.driveandplay2.com
For customer and technical support, call:
516.255.4545 (USA only)
Declaration of Conformity
We, Harman Consumer Group, Inc.
2, route de Tours
72500 Château du Loir
FRANCE
declare in own responsibility that the product described
in this manual is in compliance with technical standards:
EN 301 357-1-2
EN 301 489-1/-9
EN 60950-1:2001+A11:2004
IEC 60950-1:2001
Klaus Lebherz
Harman Consumer Group, Inc.
Chateau du Loir, France. 10/07
250 Crossways Park Drive, Woodbury, New York 11797 USA
www.harmankardon.com
©2007 Harman International Industries, Incorporated. All rights reserved.
950 - 0189 - 001
Part No.
Features, speci cations and appearance are subject to change without
notice. Screen images may di er from actual product.
Harman Kardon is a trademark of Harman International Industries,
Incorporated, registered in the United States and/or other countries.
Drive + Play is a trademark of Harman International Industries,
Incorporated.
iPod is a trademark of Apple Inc., registered in the U.S. and other
countries.
Please Recycle
