DPR 1005 - 2005 Digital Path Receiver Rev 2
SERVICE MANUAL
harman/kardon
Power for the Digital Revolution®
®
TECHNICAL SPECIFICATIONS
Technical Specifications
Audio Section
Stereo Mode
Continuous Average Power (FTC)
120 Watts per channel, 20Hz–20kHz,
@ < 0.15% THD, both channels driven into 8 ohms
5/7 Channel Surround Modes
Power Per Individual Channel
Front L&R channels:
120 Watts per channel,
@ < 0.15% THD, 20Hz–20kHz into 8 ohms
Center channel:
120 Watts, @ < 0.15% THD, 20Hz–20kHz into 8 ohms
Surround (L & R Side, L & R Back) channels:
120 Watts per channel,
@ < 0.15% THD, 20Hz–20kHz into 8 ohms
Input Sensitivity/Impedance
Linear (High Level) 200mV/47kohms
Signal-to-Noise Ratio (IHF-A) 97dB
Surround System Adjacent Channel Separation
Analog Decoding 40dB
(Pro Logic, etc.)
Dolby Digital (AC-3) 55dB
DTS 55dB
FM Tuner Section
Frequency Range 87.5–108MHz
Usable Sensitivity IHF 1.3 µV/13.2dBf
Signal-to-Noise Ratio Mono/Stereo: 70/68dB (DIN)
Distortion Mono/Stereo: 0.2/0.3%
Stereo Separation 40dB @ 1kHz
Selectivity ±400kHz: 70dB
Image Rejection 80dB
IF Rejection 90dB
AM Tuner Section
Frequency Range 520–1710kHz
Signal-to-Noise Ratio 45dB
Usable Sensitivity Loop: 500µV
Distortion 1kHz, 50% Mod: 0.8%
Selectivity ±10kHz: 30dB
Video Section
Video Format PAL/NTSC
Input Level/Impedance 1Vp-p/75 ohms
Output Level/Impedance 1Vp-p/75 ohms
Video Frequency Response
(Composite and S-Video) 10Hz–8MHz (–3dB)
Video Frequency
Response (Component) 10Hz-50MHz (-3dB)
General
Power Requirement AC 220-240V/50Hz
Power Consumption 59W idle, 1073W maximum
(7 channels driven)
Dimensions (Max)
Width 440mm
Height 114mm
Depth 476mm
Weight 10.5 kg
Depth measurement includes knobs, buttons and terminal connections.
Height measurement includes feet and chassis.
All features and specifications are subject to change without notice.
Harman Kardon and Power for the Digital Revolution are registered trademarks of
Harman International Industries, Incorporated.
is a trademark of Harman International Industries, Inc.
(Patent No.5,386,478).
*Manufactured under license from Dolby Laboratories.
“Dolby,”“Pro Logic,” “Pro Logic II” and the Double-D symbol are
trademarks of Dolby Laboratories.Confidential Unpublished
Works. ©1992–1999 Dolby Laboratories,Inc. All rights reserved.
DTS and DTS Surround, DTS-ES and DTS Neo:6 are trademarks of Digital Theater Systems, Inc.
VMAx is a trademark of Harman International Industries, Inc.,and is an
implementation of Cooper Bauck Transaural Stereo under patent license.
Logic 7 is a registered trademark of Harman International Industries, Incorporated.
HDCD is a registered trademark of Pacific Microsonics,Inc.
A-BUS and A-BUS Ready are registered trademarks of Leisure Tech Electronics Pty Ltd Australia.
**Without input anti slewing and output isolation networks.
TiVo is a registered trademark of TiVo, Inc.
Replay TV is a registered trademark of Digital Networks North America, Inc.
DPR2005/230
TM
TECHNICAL SPECIFICATIONS 57
Technical Specifications
Audio Section
Stereo Mode
Continuous Average Power (FTC)
70 Watts per channel, 20Hz–20kHz,
@ < 0.15% THD, both channels driven into 8 ohms
5/7 Channel Surround Modes
Power Per Individual Channel
Front L&R channels:
70 Watts per channel,
@ < 0.15% THD, 20Hz–20kHz into 8 ohms
Center channel:
70 Watts, @ < 0.15% THD, 20Hz–20kHz into 8 ohms
Surround (L & R Side, L & R Back) channels:
70 Watts per channel,
@ < 0.15% THD, 20Hz–20kHz into 8 ohms
Input Sensitivity/Impedance
Linear (High Level) 200mV/47kohms
Signal-to-Noise Ratio (IHF-A) 97dB
Surround System Adjacent Channel Separation
Analog Decoding 40dB
(Pro Logic, etc.)
Dolby Digital (AC-3) 55dB
DTS 55dB
FM Tuner Section
Frequency Range 87.5–108MHz
Usable Sensitivity IHF 1.3 µV/13.2dBf
Signal-to-Noise Ratio Mono/Stereo: 70/68dB (DIN)
Distortion Mono/Stereo: 0.2/0.3%
Stereo Separation 40dB @ 1kHz
Selectivity ±400kHz: 70dB
Image Rejection 80dB
IF Rejection 90dB
AM Tuner Section
Frequency Range 520–1710kHz
Signal-to-Noise Ratio 45dB
Usable Sensitivity Loop: 500µV
Distortion 1kHz, 50% Mod: 0.8%
Selectivity ±10kHz: 30dB
Video Section
Video Format PAL/NTSC
Input Level/Impedance 1Vp-p/75 ohms
Output Level/Impedance 1Vp-p/75 ohms
Video Frequency Response
(Composite and S-Video) 10Hz–8MHz (–3dB)
Video Frequency
Response (Component) 10Hz-50MHz (-3dB)
General
Power Requirement AC 220-240V/50Hz
Power Consumption 52W idle, 760W maximum
(7 channels driven)
Dimensions (Max)
Width 440mm
Height 114mm
Depth 476mm
Weight 9.1 kg
Depth measurement includes knobs, buttons and terminal connections.
Height measurement includes feet and chassis.
All features and specifications are subject to change without notice.
Harman Kardon and Power for the Digital Revolution are registered trademarks of
Harman International Industries, Incorporated.
is a trademark of Harman International Industries, Inc.
(Patent No.5,386,478).
*Manufactured under license from Dolby Laboratories.
“Dolby,”“Pro Logic,” “Pro Logic II” and the Double-D symbol are
trademarks of Dolby Laboratories.Confidential Unpublished
Works. ©1992–1999 Dolby Laboratories,Inc. All rights reserved.
DTS and DTS Surround, DTS-ES and DTS Neo:6 are trademarks of Digital Theater Systems, Inc.
VMAx is a trademark of Harman International Industries, Inc.,and is an
implementation of Cooper Bauck Transaural Stereo under patent license.
Logic 7 is a registered trademark of Harman International Industries, Incorporated.
HDCD is a registered trademark of Pacific Microsonics,Inc.
A-BUS and A-BUS Ready are registered trademarks of Leisure Tech Electronics Pty Ltd Australia.
**Without input anti slewing and output isolation networks.
TiVo is a registered trademark of TiVo, Inc.
Replay TV is a registered trademark of Digital Networks North America, Inc.
DPR1005/230
TM
NO PART NO. DESCRIPTION Q'TY
H01-ZMC12S20A00 AL BADGE HARMAN/KARDON SILVER 1
1
H01-ZMD03S00300-8 AL PANEL DOOR 1
2
H01-ZVD03DWT434-7 TAPE AL PANEL DOOR 1
3
H01-ZMD03S00200-6 AL DOOR 1
4
H01-ZMD03S05A00-8 BKT MAGNET LEFT 1
5
H01-ZPD0320GABK-8 DOOR HINGE-LEFT 1
6
H01-ZPD0619GABT-A WINDOW DISPLAY DPR1005EU 1
7
H01-ZPD0719GABT-8 WINDOW DISPLAY DPR2005EU 1
ZKC1270HA00 LABEL "PLEASE" 1
8
H01-ZPC1018GART-7 FILTER VFD 1
9
H01-ZPD0301GASG BTN DUMMY -1 1
10
ZFNR10803GY DOOR RUBBER 3
11
H01-ZPD0302GASG BTN DUMMY -2 1
12
H01-ZPD0312GAGY-A PANEL FRONT DPR1005 1
13
H01-ZPD0412GAGY-8 PANEL FRONT DPR2005 1
H01-ZVD03GEAR01-5 DAMPER GEAR DP102 2
14
H01-ZMD03S04A00-7 BKT HINGE 2
15
H01-ZPD0314GAMW-5 INDICATOR STANBY 1
16
ZPD0303GAGY-8 BTN POWER 1
17
H01-ZMD03S09A00-1 BKT SHIELD POWER 1
18
H01-SWE4A21PDA%-5 SW POWER SDKVB10100 5A 250V 4P 1
19
H01-ZPD0306GAGY-3 BTN 1 KEY 1
20
H01-ZPD0307GAGY-1 BTN 4KEY 1
21
H01-ZPD0310GAGY-3 BTN 3 KEY-A 1
22
H01-ZPD0308GAGY-A BTN 3KEY-B 1
23
H01-VDHCA18LL03-7 FL HCA-18LL03 Display 1
24
ZPC1017GABK HOLDER VFD AVR430/630 1
25
H01-SWP1280APS1-8 SW TACH JTP1280AP 20
26
H01-ICRPM6938NN IC-REMOTE RPM6938-RSIP-A3 RECEIVER 38KHZ 1
27
H01-ZMB01S02200 SPRING PLATE GND C5212 0.2T 14
28
ZUD040916BK-A SPONGE VOLUMN 1
29
H01-SWE3A0505S1 VR ROT EC16B24204 5V 500U0A 10T 3P 0 0 1
30
H01-ZMD03S19A00 SPRING-A PLATE 1
31
H01-SORA3W019NN-9 JACK RCA 3P JC03W0191N 1
32
H01-ZMD03S03A00 BKT JACK 1
33
H01-SORAC5016NN-5 JACK S-VIDEO C50160272N 1
34
H01-SORA1JE01NN-0 JACK RCA 1P JE010003MN GND OR 1
35
H01-ZPD0318GAMW-8 INDICATOR VIDEO 2
36
H01-SOTOR179LBA-0 JACK D-LEM TORX-179L 3
37
H01-ZMD03S18A00 BKTSHIELD DIGITAL 1
38
H01-ZMB01S00100 BKT HEADPHONE JACK 1
39
H01-SOSS9CKX3NN-9 JACK PHONE 6.35 H70980110S 9P BK 1
40
H01-ZPD0309GAGY-8 BTN 5KEY 1
41
H01-ZPD0305GASG-2 BTN DUMMY-5 1
42
H01-ZPD0304GASG-4 BTN DUMMY-4 1
43
H01-ZPD0303GASG-6 BTN DUMMY -3 1
44
H01-ZPD0321GABK-6 DOOR HINGE-RIGHT 1
45
H01-ZMD03S05B00-A BKT MAGNET RIGHT 1
47
H01-ZPD0317GACR-4 KNOB VOLUMN CAP 1
47
H01-ZPD0316GASG-A KNOB COVER 1
48
H01-ZPD0315GAMW-3 KNOB VOLUMN 1
49
50
H01-ZMGEN00GAGY-0 AL LOGO BADGE TOP 1
51
H01-ZMD03S08A00-0 COVER TOP 1
52
H01-ZMD06S11A00-7 PANEL REAR DPR1005 EU 1
53
H01-ZMD07S11A00-5 PANEL REAR DPR2005 EU 1
H01-ZMD03S10A00 SHIELD AMP DPR2005 1
54
H01-ZMD04HS0400 HEATSINK AMP 1
55
H01-ZVD03007000-A ASS'Y AMP MODULE GR0070-7 1
56
H01-ZVD04012000-1 ASS'Y AMP MODULE GR0120-7 1
H01-ZMD03S21A00 BKT SHIELD AMP DPR2005 1
57
H01-ZMC12S19A00 BKT AC INLET 2
58
BLANK
NO PART NO. DESCRIPTION Q'TY
H01-SOXA27014NN-9 JACK A/C INLET 7014-NGP AC05-4S020A 1
59
H01-SOPA20019BK-A JACK AC OUTLET 2P 220V FE 19MM2 BK 0 0 1
60
ZFNRB228700 POWER RUBBER 1
61
H01-ZMD03S02A00 BKT MIDDLE 1
62
H01-ZVD06701301-1 SMPS ASS'Y SMPS KJP-7013 70W-EU 1
63
H01-ZVD07013E00-5 SMPS ASS'Y SMPS KJP-10013 120W-EU 1
H01-ZMD03S07A00-A CH FRONT 1
64
ZFNR19720SB-5 FOOT RUBBER 19.7X19.7X2T BK 4
65
ZPC1103GAGY-A FOOT 50MM 15.8MM 4
66
H01-ZMD03MAGN00-2 MAGNET 2
67
H01-ZPD0313GAGY-8 MAGNET CASE 2
68
H01-ZMD03S13A00 CH MAIN 1
69
H01-ZMD03S04AYE-5 STUD-3 H 11MM 2
70
H01-ZMC12S16A00 BKT GROUND 2
71
H01-SOJW2350SNN-A JACK PHONE 3.6 EP-1401A 1P BK 3
72
SO0A18P8CNN-7 JACK-TELE SNAP-IN GOLDEN TELECOM GDL1-8P8C 8T BK 0 0 1
73
H01-ZMD03S20A00 SHIELD VIDEO TERMINAL 1
74
H01-SOPA81900NN-8 JACK TERMINAL SPKR 8P SH081136JP FE 19MM 8 -- 0 0 1
75
H01-SOPA619BKNN-7 JACK TERMINAL SPKR 6P SH0611708P FE 19MM 6 BK 0 0 1
76
ZUC1203AABK SPONGE 15X30X8T BK 2
77
H01-SORA90173NN-6 JACK RCA 9P JB090173FN 1
78
H01-SORA11Y00NN-5 JACK RCA+S VIDEO C5016031DN 8
79
H01-ZMD03S05AYE STUD STANDOFF HEX M4X0.7 6X27.5H 2
80
SOPA96063NN-0 JACK D-SUB 9P 87204-6063 W/DUST COVER BK 1
81
H01-SORA1J440CE-0 JACK RCA 1P PPJ-440CE 1
82
H01-SOTOT179LBA-7 JACK D-LEM TOTX-179L 1
83
H01-SORA20130JN-9 JACK RCA 2P JB020130JN 1
84
H01-SORA40RSANN-6 JACK RCA 4P JB040131ZN GN BN PP TA 2
85
H01-SORA40RSCNN-A JACK RCA 4P JB040131QN WH BU RD GY 2
86
H01-SORA40GNDNN-7 JACK RCA 4P JB040131PN WWRR 1
87
H01-SOPA81900NN-8 JACK RCA 6P JB060132PN 3
88
H01-ZVD06TUNE00-3 TUNER MODULE KST-MV114MA1-83 1
89
H01-ZMD03S03AYE STUD-1 H34MM 2
90
H01-ZMD04S12A00 SHIELD TUNER DPR2005 1
91
H01-ZUD0301AABK-A SPONGE UL 7
92
ZUC1201AABK-7 SPONGE 30X30X10T BK 4
93
ZQB0101AA00 SHIELD FOAM GASKET (WOORI) 1
94
H01-RLHMCRE2500 HMC REACTOR 1
95
H01-ZPC1219ZABK-2 SPEAKER TER'BOARD SH08M790B0 14
96
NO PART NO. DESCRIPTION Q'TY
ZSTBM3010BB SCREW ST BH 3X10 22
S1
ZSTWM3008BY SCREW ST WPH 3X8 32
S2
ZSTPM2006BZ SCREW S-TPG,WASHER 4.8MM,2.0X6,ZI-PLATED 2
S3
ZSTFM0308BN SCREW S.T 3X8 F/H NI PLATED 4
S4
ZSTWM3006BY SCREW S.T 3X6 W/H YELLOW ZINC PLATED 7
S5
ZSTWM4008BC SCREW ST WPH 4X8 SILVER CHROM 8
S6
ZSMWM4008BZ SCREW M.S M4X8 W/H ZN PLATED 8
S7
ZSMWM3008BZ SCREW M.S M3X8 W/H ZN PLATED 10
S8
ZSTGM3010BB SCREW ST BH 3X10 GROUND 49
SG
ZNSSM4045HZ NUT M4 HEXAGON CIRCULAR EXTERNAL 2
N1
AMP section
DPR1005-2005/230
1/2
Location Description Part number
C37 CE 470U0F M 63.0V 12.5X20 SHL H01-CEHJA0477MN-5
C16 18 19 21 CAP ELEC 2200UF 63V M SHL SAMYOUNG H01-CEMJA0228AH-3
D2 DIODE SCHOTTKY SB360 60V 3A DO-201AD H01-DRSB36060NA-1
IC1 IC VOLTAGE REGULATOR KIA7808AP TO-220AB H03-ICKIA7808I2-8
IC2 IC POWER CONVERTER LM2593HVT-ADJ TA07B H01-ICLMO259307-1
L1 COIL CHOKE 190UH TOROIDAL H01-LCNN18190NA-4
L11 12 TFPULSE TRANSFORMER 110UH FP-110 FERRIT MAGNET H01-LF11030A2NA-4
SK2 RELAYPWR 5.0V 166.0OHM 1.0A 24.0V H01-RLL0516632B-A
NJ3 CONN-SPE TERMINAL SPKR 6P SH0611708P FE 19MM 6 BK 0 0 H01-SOPA619BKNN-7
NJ2 CONN-SPE TERMINAL SPKR 8P SH081136JP FE 19MM 8 -- 0 0 H01-SOPA81900NN-8
NJ8 JACK RCA 1P PPJ-440CE H01-SORA1J440CE-0
NJ71 JACK RCA 1P JE010003MN GND OR H01-SORA1JE01NN-0
NJ9 JACK RCA 2P JB020130JN H01-SORA20130JN-9
NJ72 JACK S-VIDEO C50160272N H01-SORAC5016NN-5
NJ10 11 70 D-LEM TORX-179L H01-SOTOR179LBA-0
NJ12 D-LEM TOTX-179L H01-SOTOT179LBA-7
N1 WIRE ASS'Y UL1007#24 STR 530mm 2.5mm 2P GRY H01-WG02SD85300-4
N2 WIRE ASS'Y UL1007#16 STR 460mm 3.96mm 8P RED H01-WG08SE84600-1
P3 CONN 2.0MM 2 MA ST NAT GT201-2P-TS H01-WN02SB00000-9
P5 P701 CONN 2.0MM 3 MA ST NAT GT201-3P-TS H01-WN03SB00000-6
N5 CONN 2.0MM 5 MA ST NAT GT201-5P-TS H01-WN05SB00000-0
P4 CNT PLUG BD'BD SOCKET 2.0mm 35237-0610 H01-WN06AB00001-4
P6 7 CONN 2.0MM 11 MA R NAT SOCKET MOLEX 35237-1110 0 0 H01-WN11AB00000-0
N700 WIRE ASS'Y UL1007/1533 #26 980MM 2.0MM 5P RED SHI H01-WS5269805EN-A
N4 WIRE ASS'Y 7P 180MM UL1007/1533#26 BLK H01-WS7261843EN-A
N3 WIRE ASS'Y 13P 170MM UL1533/1007 #26 2.0MM RED SHIELD H01-WSC261705EN-8
FG96 SPRING PLATE GND C5212 0.2T H01-ZMB01S02200-9
BK71 SHIELD DIGITAL H01-ZMD03S18A00-9
SH1 SHIELD VIDEO H01-ZMD03S20A00-A
HS1 HEATSINK AMP H01-ZMD04HS0400-4
AMP1 ASS'Y AMP MODULE GR0120-7 H01-ZVD04012000-1
NJ55 JACK D-SUB 9P 87204-6063 W/DUST COVER BK SOPA96063NN-0
L7 BEAD CORE H610-04 H03-FB0H61004NN-8
L3 4 5 700 LF 47U0H +10% 5.8 OHM 500MI0A H01-LAINB0470CR-2
D1 3 4 5 7 D-SR 1N4004 400.0V 1.0A H01-DR1N04004NA-1
PCB DUAL DPR2005 AMP 233.9MM*219MM *1.6t FR-4 PBD04KAMB20-A
D8 DIODE SCHOTTKY RECTION 1N5819 40V 1A DO-41 H01-DR1N05819NA-6
C408 412 418 CCCFMIC 22P0F +5% -5% 50.0V NP0 0603 CZJII0220BE-5
C407 411 420 CAP CHIP 10N0F +10% -10% 50.0V X7R 0603 CZKII0103BC-5
C38 CAP CHIP 3N3F +10% -10% 50.0V X7R 0603 CZKII0332BC-1
C22 23 24 25 28 29 32 33 34 35 36 396 404 413
416 423 424 437 43 47 48 49 50 700
C15 17 20 31 CAP CHIP 100NF 100V X7R 10% 1206 CZIKI0104DC-3
D9 D-SLP 1SS355 35.0V 225MI0A H01-DS1S50094NB-A
C1 10 11 12 13 14 2 3 4 5 6 7 8 9 CAP CHIP 470PF 100V X7R 10% 1206 CZIKI0471DC-9
B10 11 12 13 17 FBEAD SURFACE MT 2500OHM FCM2012H-252T02 H01-FB2K52012NN-5
L2 6 FBEAD SURFACE MT 300OHM FCM2012V-301T07 H01-FB3002012NN-4
IC3 47 49 IC-LOGIC M74HCU04M1R INVERTER HCT H01-ICM74H04MD4-2
IC43 IC-SPECFUNC UPD4721 DRIVERS/RECEIVERS CMOS RS-232C H01-ICUPD4721D8-3
Q3 4 5 26 TR-SSD DTC114YKA N 10K0 OHM 47K0 OHM H01-TRDTC114YNI-5
R11 12 13 14 RES,CHIP,1K,1/8W,+/-5%,0805 RS3CB0102NN-8
R16 17 420 438 RMGCFMIC 10R0 OHM +5% 62MI5W RS3AD0100NA-7
R422 425 437 RMGCFMIC 100R0 OHM +5% 62MI5W RS3AD0101NA-5
R4 5 8 701 RMGCFMIC 1K0 OHM +5% 62MI5W RS3AD0102NA-3
R484 15 493 RES CHIP,15K 1/16W,+-5%,0603. RS3AD0153NA-8
R445 RMGCFMIC 2R2 OHM +5% 62MI5W RS3AD022ANA-7
R483 487 6 RMGCFMIC 1K2 OHM +5% 62MI5W RS3AD0122NA-8
R1 2 19 RMGCFMIC 4K3 OHM +5% 62MI5W RS3AD0432NA-4
R392 393 7 RMGCFMIC 4K7 OHM +5% 62MI5W RS3AD0472NA-3
R20 RMGCFMIC 10K0 OHM +5% 62MI5W RS3AD0103NA-1
CAP CHIP 100N0F +80% -20% 16.0V Y5V 0603 CZZFI0104BF-8
AMP section
DPR1005-2005/230
2/2
Location Description Part number
R423 426 429 442 435 RMGCFMIC 560R0 OHM +5% 62MI5W RS3AD0561NA-4
R424 436 RMGCFMIC 620R0 OHM +5% 62MI5W RS3AD0621NA-1
R10 RMGCFMIC 510R0 OHM +5% 62MI5W RS3AD0511NA-8
R428 432 439 RMGCFMIC 75R0 OHM +5% 62MI5W RS3AD0750NA-1
D6 DIODE BAT54 SMALL SIGNAL SOT-23 H01-DSBAT0054NB-7
R9 RMGCFMIC 8K2 OHM +5% 62MI5W RS3AD0822NA-2
C702 703 DIODE PG05GBUSC H03-DS05GBUSCNB-5
R21 RMGCFMIC 220R0 OHM +5% 62MI5W RS3AD0221NA-6
C46 CCCFMIC 10P0F +0P5F -0P5F 50.0V NP0 0603 CZEII0100BE-0
C704 CE 100UF +20% 16V D6.3XL7 P2.5MM 2000hours 85C CEHFC01072S-9
C397 403 27 41 42 CE 100UF +20% 16.0V D6.3XL11 P5MM 85C CEHFC01075E-1
C392 393 394 395 401 CE 1UF +20% 50V D5XL11 P5MM 85C CEHIC01055E-6
C40 CE 470UF 25V M 10X16 NXB H01-CEMGC0477AH-7
C30 39 CAP ELEC 220UF 16V M5X11 ELITE CEMFC0227NN-7
FRONT section
DPR1005-2005/230
1/2
Location Description Part number
D902 903 904 905 D-LEM 30B3-20-15 GaN SUPER BLUE WATER CLEAR 15 H01-DL30B2015AA-A
RM90 IC-REMOTE RPM6938-RSIP-A3 RECEIVER 38KHZ H01-ICRPM6938NN-3
NJ80 JACK PHONE 6.35 H70980110S 9P BK H01-SOSS9CKX3NN-9
VR60 SWIROT EC16B24204 5V 500U0A 10T 3P 0 0 H01-SWE3A0505S1-9
W601 WIRE ASS'Y UL1007 #22 TC 40MM 1P BLK H01-WC1220405C1-9
DP90 FL HCA-18LL03 DISPLAY H01-VDHCA18LL03-7
NJ60 JACK RCA 3P JC03W0191N H01-SORA3W019NN-9
P819 CNT PLUG BD'BD SOCKET 2.0mm 35237-0610 H01-WN06AB00001-4
P818 CNT PLUG BD'BD PLUG 2.0mm 35336-0610 6P H01-WN06SB01000-9
P811 CONNECT WAFER 2.0MM 8P 35237-0810 WHT H01-WN08AB100WH-7
P810 CONNECT WFER 2.0MM 8P 35336-0810 WHT H01-WN08SB100WH-4
N900 WIRE ASS'Y 11P 420MM UL1007#20 2.5MM STR H01-WG11SD84220-6
N901 WIRE ASS'Y UL1007#26 STR 90MM 2.0MM 3P RED-UP H01-WG03AB809UP-A
P815 817 CONN 2.0MM 11 MA R NAT SOCKET MOLEX 35237-1110 0 0 H01-WN11AB00000-0
P814 816 CONN 2.0MM 11P MA ST NAT MOLEX 35336-1110 0 0 H01-WN11SB00000-8
P813 CONN WAFER 2.0MM 12P 35237-1210 WHT H01-WN12AB00000-8
P812 CONN WAFER 2.0MM 12P 35336-1210 WHT H01-WN12SB100WH-7
P900 CONNECTOR FFC 17P 1.25MM ANG SCB-1017-00-2 H01-WN17AI00000-8
H901 HOLDER VFD AVR430/630 ZPC1017GABK-6
N902 WIRE ASS'Y 2.0MM 3P 50MM UL1007#26 RED H01-WG03SB80500-2
N602 WIRE ASS'Y 2.0MM 3P 70MM UL1007#26 RED H01-WG03SB80700-6
N601 WIRE ASS'Y UL1007/1533 #26 480MM 2.0MM 13P RED SHIELD H01-WSC264805EN-3
FG93 SPRING-A PLATE H01-ZMD03S19A00-A
N800 WIRE ASS'Y UL1007/2547 #26 580MM 2.0MM 4P RED H01-WS4265805FN-A
D830 D-LEM BLUE/AMBER 3PIE RD RND CL L-3VYMBC H01-DL3BA05V0BA-2
D600 605 D-LEM RED/GREEN 3F RD RND CL H01-DLRED3FRDBA-5
FG81 90 91 94 97 SPRING PLATE GND C5212 0.2T H01-ZMB01S02200-9
R906 907 RCF 470R0 OHM +5% 250MI0W RC3DI0471IN-0
L800 901 LF 47U0H +10% 5.8 OHM 500MI0A H01-LAINB0470CR-2
PCB SINGLE FRONT DPR2005 397MM*163MM*1.6t FR-4 PBD07KFCI20-A
R941 942 RCF 1R0 OHM +5% 250MI0W RC3DI010AIN-1
L900 LF 4U7H +10% 1.7 OHM 190.0A H01-LAINB047ACR-3
C803 907 501 502 503 504 CC 100N0F +80% -20% 50.0V F CCZID0104NA-2
L911 912 BEAD AXIAL/TAP,HC3580 80.5ohm H03-FB05B3580NN-7
C505 506 CC 680P0F +10% -10% 50.0V 2B4 CCKID0681NN-3
C911 CE47UF +20% 16.0V D5XL11 P5MM 85C CEHFC04765E-3
C900 901 CPF 47N0F +10% 100.0V CPIKC0473NN-0
S900 901 902 903 904 905 906 907 908 909 910
911 912 913 914 915 916 917 918 919
Q901 TR-SLPLF MPSA56 Y P -500MI0A -300V H03-TRMPSA56YNA-0
C603 604 609 610 CCCFMIC 100P0F +5% -5% 50.0V NP0 0603 CZJII0101BE-2
C801 802 CAP CHIP 2N2F +10% -10% 50.0V X7R 0603 CZKII0222BC-8
C606 800 902 910 912 913 CAP CHIP 100N0F +80% -20% 16.0V Y5V 0603 CZZFI0104BF-8
C600 601 CAP CHIP 820P0F +10% -10% 50.0V X7R 0603 CZKII0821BC-8
SWITCH TACH JTP1280AP H01-SWP1280APS1-8
FRONT section
DPR1005-2005/230
2/2
Location Description Part number
C908 909 CAP CHIP 22N0F +80% -20% 50.0V Y5V 0603 CZZII0223BF-1
D603 604 800 801 919 D-SLP 1SS355 35.0V 225MI0A H01-DS1S50094NB-A
D918 D-ZENER UDZS 9.1B 9.1V 200MI0W H01-DSUDZ09V1NB-7
B501 502 FBEAD SURFACE MT 300OHM FCM2012V-301T07 H01-FB3002012NN-4
Q600 601 602 603 900 902 905 TR-SSD DTC114YKA N 10K0 OHM 47K0 OHM H01-TRDTC114YNI-5
R929 501 RMGCFMIC 10R0 OHM +5% 62MI5W RS3AD0100NA-7
R939 940 RMGCFMIC 100R0 OHM +5% 62MI5W RS3AD0101NA-5
R912 921 937 RMGCFMIC 1K0 OHM +5% 62MI5W RS3AD0102NA-3
R913 922 610 RMGCFMIC 1K2 OHM +5% 62MI5W RS3AD0122NA-8
R914 930 RMGCFMIC 1K5 OHM +5% 62MI5W RS3AD0152NA-A
R943 RMGCFMIC 10K0 OHM +5% 62MI5W RS3AD0103NA-1
R920 936 RMGCFMIC 18K0 OHM +5% 62MI5W RS3AD0183NA-A
R901 923 924 RMGCFMIC 220R0 OHM +5% 62MI5W RS3AD0221NA-6
R915 931 RMGCFMIC 2K2 OHM +5% 62MI5W RS3AD0222NA-4
R800 801 RMGCFMIC 2R2 OHM +5% 62MI5W RS3AD022ANA-7
R916 932 RMGCFMIC 2K7 OHM +5% 62MI5W RS3AD0272NA-0
R917 933 RMGCFMIC 3K3 OHM +5% 62MI5W RS3AD0332NA-8
R602 603 606 607 RMGCFMIC 390R0 OHM +5% 62MI5W RS3AD0391NA-3
R600 601 604 605 608 609 925 926 RMGCFMIC 470R0 OHM +5% 62MI5W RS3AD0471NA-5
R918 934 RMGCFMIC 5K6 OHM +5% 62MI5W RS3AD0562NA-2
Q904 TR-SLPSWA KTD1304 N 20V 300MI0A SOT-23 H03-TRKTD1304ND-0
R910 911 RMGCFMIC 68K0 OHM +5% 62MI5W RS3AD0683NA-1
R919 935 RMGCFMIC 8K2 OHM +5% 62MI5W RS3AD0822NA-2
C605 CCCFMIC 33P0F +5% -5% 50.0V NP0 0603 CZJII0330BE-9
C510 CAP CHIP FORM,4P +-0.25P,50V,0603,C0G. CSDIE040ABG-1
C602 R902 903 904 905 D601 602 RMGCFMIC 0 OHM +0% 62MI5W RS3AD0000NA-0
PROCESSOR section
DPR1005-2005/230
1/5
Location Description Part number
AC EMBD IMA PROCESSOR BD DPR2005EU 3SA-3154EU-POMI-1-2
C601 CC 100N0F +80% -20% 50.0V F CCZID0104NA-2
C602 CE 10UF +20% 16V D4XL7 P2.5MM 2000hours 85C CEHFC01062S-0
C437 CM 47MI0F +80% -20% 5.5V 70C CEZXA0479MN-5
IC54 IC-KA78R08API TO-220IS-4PIN H03-ICKA78R08I2-A
IC21 IC OP AMP NJM4556AD DIP8 H01-ICNJM4556B2-7
Y2 OSCILLATOR 12.288MHz 3.3V H01-OSCEM12M2RU-9
Y1 CSTLS20MOX51-B0 H01-OSCNI20MOCU-6
NJ1 JACK RCA 4P JB040131PN WWRR H01-SORA40GNDNN-7
NJ16 6 JACK RCA 4P JB040131ZN GN BN PP TA H01-SORA40RSANN-6
NJ15 5 JACK RCA 4P JB040131QN WH BU RD GY H01-SORA40RSCNN-A
NJ2 3 4 JACK RCA 6P JB060132PN H01-SORA64105NN-5
SW80 SWITCH POWER SDKVB10100 5A 250V 4P H01-SWE4A21PDA%-5
W100 WIRE ASS'Y UL1007 #22 TC30MM 1P BLK H01-WC1220305C1-0
P820 CONN 2.0MM 2 MA ST NAT GT201-2P-TS H01-WN02SB00000-9
P821 CON 3.96MM PITCH HEADER 2 POS MOLEX 35328-0210 H01-WN02SE00000-6
P7 CONN 2.0MM 4 MA ST NAT GT201-4P-TS H01-WN04SB00000-3
P13 CNT PLUG BD'BD PLUG 2.0mm 35336-0610 6P H01-WN06SB01000-9
P10 CONN 2.0MM 7P GIL-S-7P-S2T2-EF H01-WN07SB00001-9
P6 CONNECT WFER 2.0MM 8P 35336-0810 WHT H01-WN08SB100WH-4
P4 CONNECT WAFER 2.5MM 10 5267-10A 10P WHT H01-WN10SD100WH-0
P11 12 CONN 2.0MM 11P MA ST NAT MOLEX 35336-1110 0 0 H01-WN11SB00000-8
P5 CONN WAFER 2.0MM 12P 35336-1210 WHT H01-WN12SB100WH-7
P9 CONN 2.0MM 13P GIL-S-13P-S2T2 H01-WN13SB00000-2
P14 CONN FFC 1.25MM SCB-1113-00-2 13P VER H01-WN13SI00000-6
P3 CONN FFC 1.25MM 17P SCB-1117-00-2 VER H01-WN17SI00000-5
N1 WIRE ASS'Y UL2547/1007#26 380MM 2.0MM 10P RED H01-WS0263805FN-6
N2 WIRE ASS'Y 2.0MM 3P 210MM UL2547#26 RED STR H01-WS3262105FN-9
FG1 2 3 4 6 7 8 SPRING PLATE GND C5212 0.2T H01-ZMB01S02200-9
BK72 BRACKET SHIELD POWER H01-ZMD03S09A00-1
L3 5 6 LF 4U7H +10% 1.7 OHM 190.0A H01-LAINB047ACR-3
R20 RCF 2K2 OHM +5% 250MI0W RC3DI0222IN-A
PROCESSOR section
8
2
DPR1005-2005/230
2/5
Location Description Part number
R431 440 500 509 RCF 180 OHM +5% 250MI0W RC3DI0181IN-9
D15 16 D-SR 1N4004 400.0V 1.0A H01-DR1N04004NA-1
L1 13 INDUCTOR COIL AL04TB470K 47UH 1.34OHM H01-LA1340470NN-4
L7 D-SLP 1N4148 100.0V 150E-3A H01-DG1N04148NB-4
C10 102 103 111 119 120 128 129 13 133 134 139
14 140 147 148 149 150 151 152 159 160 161 162
173 176 185 186 191 192 193 194 197 198 199
200 212 215 216 219 226 229 244 245 339 342
343 345 346 347 348 349 350 351 352 368 369
371 372 377 378 384 385 386 387 392 393 396
397 400 409 417 445 446 449 452 469 470 483
489 490 491 500 505 520 521 522 525 526 546
547 556 557 560 561 566 567 570 571 73 74 77 7
79 80 83 84 85 86 89 9 90 91 92 95 96 579
C122 131 136 138 177 20 203 21 27 277 280 281
293 294 3 323 324 353 424 456 461 463 464 468
473 475 482 494 495 501 508
C125 126 137 142 145 155 157 163 165 167 170
171 174 175 18 19 195 196 222 225 248 249 276
279 287 288 299 300 305 306 311 312 317 318
329 330 335 336 358 359 364 365 370 383 388
403 404 426 447 459 492 499 545 558 559 562
563 568 569 75 76 81 82 87 88 93 94
CE 10UF +20% 16V D4XL7 P2.5MM 2000hours 85C CEHFC01062S-0
CE 100UF +20% 16V D6.3XL7 P2.5MM 2000hours 85C CEHFC01072S-9
CE 47UF +20% 16V D5XL7 P2.5MM 2000hours 85C CEHFC04762S-0
C523 CE 100NF +20% 50V SSE TYPE D4XL7 P2.5MM 85C CEHIC01042S-5
C123 127 498 CE 1UF +20% 50V D5XL11 P5MM 85C CEHIC01055E-6
C113 114 534 CE 2U2F +20% 50.0V 85C 5X11 SHL H01-CEHIC0225AH-5
C830 CAP ELEC 22UF 16V M ELITE CEMFC0226NN-9
Q38 TR-SLPLF MPSA06 N 500MI0A TO-92 H03-TRMPSA06NNA-A
C549 CE 100UF 16V M 5X11 SHL P2.5MM H01-CEMFC0107MN-3
C573 574 CE 100UF 35V M 6.3X11 CEMHC0107NN-3
C550 551 552 553 575 576 577 CE 470UF 16V M 8X11.5 SHL H01-CEMFC0477AH-A
C253 254 CE 330UF 16V M 8X11.5 SHL H01-CEMFC0337NN-5
C1 100 164 166 168 169 178 2 201 202 206 207
211 213 214 217 218 220 221 223 230 231 232
233 236 237 241 242 250 251 255 259 29 30 31 3
33 34 35 36 37 38 389 39 399 40 405 41 410 419
42 43 438 439 440 44 45 46 47 472 477 48 485 49
50 509 51 512 511 513 514 52 527 53 539 54 55
56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71
72 97 98 99 587
C106 107 108 109 11 110 118 12 15 16 183 184
189 190 22 23 240 243 269 270 420 423 548 564
565 572
C421 CAP CHIP 1N2F +10% -10% 50.0V X7R 0603 CZKII0122BC-1
C143 144 156 158 CAP CHIP 2N7F +10% -10% 50.0V X7R 0603 CZKII0272BC-4
C141 146 153 154 394 395 CAP CHIP 560P0F +10% -10% 50.0V X7R 0603 CZKII0561BC-8
C130 135 204 205 208 209 210 224 24 246 247 25
252 256 257 26 260 261 262 263 264 265 266 271
272 28 425 427 428 429 430 431 433 434 435 436
441 442 443 444 448 450 451 453 454 455 457
471 474 479 480 481 497 5 502 504 510 517 518
519 524 528 530 531 533 537 554 555 818 907
908 915 916
CCCFMIC 100P0F +5% -5% 50.0V NP0 0603 CZJII0101BE-2
CCCFMIC 33P0F +5% -5% 50.0V NP0 0603 CZJII0330BE-9
CAP CHIP 100N0F +80% -20% 16.0V Y5V 0603 CZZFI0104BF-8
C411 414 416 CAP CHIP 10N0F +10% -10% 50.0V X7R 0603 CZKII0103BC-5
L12 17 2 22 28 30 4 FBEAD SURFACE MT 300OHM FCM2012V-301T07 H01-FB3002012NN-4
D1 2 4 5 14 25 D-SLP 1SS355 35.0V 225MI0A H01-DS1S50094NB-A
IC9 IC-SWITCH TC9273F-004 SOP28 ANALOG SWITCH H01-ICTC9273NDA-0
Q16 18 25 42 58 59 TR-SSD DTA114YKA P 10K0 OHM 47K0 OHM H01-TRDTA114YNI-9
Q12 13 26 39 7 8 TR-SLPSWA KTD1304 N 20V 300MI0A SOT-23 H03-TRKTD1304ND-0
PROCESSOR section
DPR1005-2005/230
3/5
Location Description Part number
R632 638 641 642 653 656 659 660 692 693 696
699
C274 275 307 308 309 310 337 338 356 357 366
367
C586 CAP CHIP 1N0F +10% -10% 50.0V X7R 0603 CZKII0102BC-7
R443 513 592 594 595 596 RMGCFMIC 100R0 OHM +5% 62MI5W RS3AD0101NA-5
R100 103 104 105 106 108 118 119 129 130 159
161 162 163 164 166 168 172 174 242 243 248
249 250 251 252 258 259 26 267 268 27 270 280
290 300 376 377 423 424 425 426 484 485 512
633 634 643 644 654 655 664 665 689 691 697
698
R107 111 112 236 276 277 287 288 289 291 301
302 303 304 314 315 316 321 337 341 342 343
354 355 356 357 373 374 375 464 466 473 474
527 528 580 589 8 9 624 651
R32 33 34 35 42 43 46 465 469 47 56 57 58 59 64
65 84 85 90 91
R12 13 136 137 147 148 328 329 339 340 370 378
432 433 451 460
R16 17 320 323 358 359 382 383 RMGCFMIC 150R0 OHM +5% 62MI5W RS3AD0151NA-1
C289 290 297 298 319 320 327 328 375 376 379
382
R603 604 611 613 RES CHIP,1.8K,1/16W,+-5%,0603. RS3AD0182NA-1
R216 RMGCFMIC 910 OHM +5% 62MI5W RS3AD0911NA-3
R124 128 139 140 418 430 588 RMGCFMIC 2K2 OHM +5% 62MI5W RS3AD0222NA-4
R177 178 RMGCFMIC 2K4 OHM +5% 62MI5W RS3AD0242NA-9
R176 179 470 471 RMGCFMIC 3K9 OHM +5% 62MI5W RS3AD0392NA-1
R415 526 534 RMGCFMIC 3K3 OHM +5% 62MI5W RS3AD0332NA-8
R224 246 247 260 261 265 266 274 275 30 31 36
37 38 39 40 41 44 45 48 49 52 53 54 55 60 61 62
63 66 67 86 87
R167 2 229 4 5 529 530 531 549 570 571 673 675 RMGCFMIC 4K7 OHM +5% 62MI5W RS3AD0472NA-3
RES CHIP 30K OHM 1/16W 1% 0603 RS1AD0303NA-9
CAP CHIP, 270PF 50V +/-5% CH J 0603 CZJII0271BE-A
RMGCFMIC 1K0 OHM +5% 62MI5W RS3AD0102NA-3
RMGCFMIC 10K0 OHM +5% 62MI5W RS3AD0103NA-1
RMGCFMIC 100K0 OHM +5% 62MI5W RS3AD0104NA-A
RMGCFMIC 1K2 OHM +5% 62MI5W RS3AD0122NA-8
CCCFMIC 180P0F +5% -5% 50.0V NP0 0603 CZJII0181BE-0
RMGCFMIC 470R0 OHM +5% 62MI5W RS3AD0471NA-5
R14 15 169 173 201 203 207 211 212 324 325 348
350 380 381 402 403 486 487 497 616
R171 175 223 278 279 312 313 322 326 371 372
674 676
R206 RMGCFMIC 6K8 OHM +5% 62MI5W RS3AD0682NA-3
R24 25 RMGCFMIC 9K1 OHM +5% 62MI5W RS3AD0912NA-1
R135 141 144 146 RMGCFMIC 5K6 OHM +5% 62MI5W RS3AD0562NA-2
R227 C408 RMGCFMIC 220R0 OHM +5% 62MI5W RS3AD0221NA-6
R623 650 RMGCFMIC 3K0 OHM +5% 62MI5W RS3AD0302NA-6
R476 RMGCFMIC 2R2 OHM +5% 62MI5W RS3AD022ANA-7
Q31 32 33 36 53 TR-SSD DTC114YKA N 10K0 OHM 47K0 OHM H01-TRDTC114YNI-5
C373 374 380 381 390 398 422 432 465 466 486
487 506 507 529 532
D12 20 21 22 DIODE ZENER UDZ5.1B 5.1V 200MI0W H01-DSUDZ05V1NB-4
IC45 IC-LOWFREQ KIC9459F SOP24 TONE/VOL/BAL/MUTE H01-ICKIC9459D5-8
IC6 IC-OPERAMP NJM2068M DUAL SOP8 H01-ICLM02068D2-A
R605 606 610 614 RES CHIP 15K OHM 1/16W 1% 0603 RS1AD0153NA-2
C401 RMGCFMIC 10R0 OHM +5% 62MI5W RS3AD0100NA-7
C460 467 CAP CHIP 4N7F 50V X7R K 0603 CZKII0472BC-7
C172 CAP CHIP 22N0F +10% -10% 50.0V X7R 0603 CZKII0223BC-6
C17 238 239 258 462 515 516 541 580 581 582
583
C115 116 234 235 406 407 542 543 544 CCCFMIC 33P0F +5% -5% 50.0V NP0 0603 CZJII0330BE-9
C851 CCCFMIC 470P0F +5% -5% 50.0V NP0 0603 CZJII0471BE-2
C535 CAPACITOR CERAMIC CHIP 68PF 50V CH J NPO 0603 CZJII0680BE-4
C538 CAP CHIP 18NF 25V +/-10% 0603 X7R CZKGI0183BC-6
C291 292 295 296 321 322 325 326 354 355 540 CAP CHIP 1N0F +10% -10% 50.0V X7R 0603 CZKII0102BC-7
C402 412 413 415 476 CAP CHIP 10N0F +10% -10% 50.0V X7R 0603 CZKII0103BC-5
C536 CAP CHIP 1N2F +10% -10% 50.0V X7R 0603 CZKII0122BC-1
RMGCFMIC 47K0 OHM +5% 62MI5W RS3AD0473NA-1
RMGCFMIC 5K1 OHM +5% 62MI5W RS3AD0512NA-6
CAP CHIP 1N8F 50V X7R K 0603 CZKII0182BC-5
CCCFMIC 100P0F +5% -5% 50.0V NP0 0603 CZJII0101BE-2
PROCESSOR section
0
DPR1005-2005/230
4/5
Location Description Part number
C101 104 105 112 117 121 124 132 179 180 181
182 187 188 227 228 267 268 273 278 282 283
284 285 286 301 302 303 304 313 314 315 316
331 332 333 334 340 341 344 360 361 362 363
391 4 418 458 478 484 488 493 496 503 578 588
589 590 591 592 593 594 595 596 597 7 8 901
902 903 904 905 906 909 910 911 912 913 914
918 919
D13 17 3 6 D-SLP 1SS355 35.0V 225MI0A H01-DS1S50094NB-A
D18 19 23 24 DIODE ZENER UDZ5.1B 5.1V 200MI0W H01-DSUDZ05V1NB-4
L10 11 14 15 16 18 19 20 21 23 24 25 26 27 29 31
32 33 34 35 41 42 44 47 48 8 9
IC26 IC-FLASH MEMORY ROM AT49LV8192A 70ns H01-IC49L8192I5-A
IC57 IC OPEN COLLECTOR INVER DM74LS05M SOP24 H01-IC74LS05MD5-1
IC23 59 IC-LOGIC 74VHCT244A INVERTER CMOS H01-IC74V244MG5-3
IC60 IC-LOGIC 74VHC244A INVERTER CMOS H01-IC74VC244G5-6
IC10 22 IC A/D CONVERTOR AK5384 SOP28 H01-ICAK05384DA-6
IC56 IC CMOS BU4094BF SOP16 H01-ICBU4094BD3-2
IC61 IC-CODEC CS42528CQ H01-ICCS42528EC-0
IC24 IC CONV CS4391A-KZ SOP20 H01-ICCS4391AD8-5
IC58 IC-DSP CS494003-CQ LQFP144 H01-ICCS49400ED-3
IC62 IC-MICOM FLASH NEC UPD70F3033BGF 0228KK001 JAPAN QFP1
IC44 IC MICOM DDX8228 TQFP64 H01-ICDDX8228E6-5
IC52 IC-SDRAM K4S161622E-TC70 OR TC80 H01-ICK4S1616M6-9
IC15 IC-SWITCH KIC9162AF SOP28 ANALOG SWITCH H01-ICKIC9162DA-5
IC14 IC-LOWFREQ KIC9459F SOP24 TONE/VOL/BAL/MUTE H01-ICKIC9459D5-8
IC12 13 16 17 18 19 2 20 25 27 28 29 3 30 31 32
33 34 35 36 37 38 39 4 40 41 42 46 47 5 7 8
IC55 IC-EEPROM M24C04WMN6T H01-ICM24C04WD2-1
IC70 IC MM1662H LOW DROP VOLTAGE REGULATOR SOP-8 H01-ICMM1662HI3-2
IC43 48 IC NC7SV17 H01-ICNC7SV17XX-4
IC1 IC-NJM2391DL1-33 LOW VOLTAGE H01-ICNJM239133-A
IC11 IC-SWITCH TC9273F-004 SOP28 ANALOG SWITCH H01-ICTC9273NDA-0
Q11 14 15 17 21 44 47 48 51 TR-SSD DTA114YKA P 10K0 OHM 47K0 OHM H01-TRDTA114YNI-9
Q28 29 30 34 35 37 52 TR-SSD DTC114YKA N 10K0 OHM 47K0 OHM H01-TRDTC114YNI-5
Q1 10 19 2 20 22 23 24 27 3 4 40 41 43 45 46 49 5
50 54 55 56 57 6 9
R545 RES CHIP 3.32K OHM 1/16W 1% 0603 RS1AD3321NA-3
C584 585 RMGCFMIC 0 OHM +0% 62MI5W RS3AD0000NA-0
R446 459 462 463 475 492 577 578 579 612 RMGCFMIC 10R0 OHM +5% 62MI5W RS3AD0100NA-7
CAP CHIP 100N0F +80% -20% 16.0V Y5V 0603 CZZFI0104BF-8
FBEAD SURFACE MT 300OHM FCM2012V-301T07 H01-FB3002012NN-4
H01-ICD703033E1-5
IC-OPERAMP NJM2068M DUAL SOP8 H01-ICLM02068D2-A
TR-SLPSWA KTD1304 N 20V 300MI0A SOT-23 H03-TRKTD1304ND-0
R10 11 115 116 117 121 122 132 152 153 154 156
157 158 184 185 188 189 192 193 200 202 21 210
218 22 225 226 23 230 233 237 238 281 282 285
286 305 306 308 311 327 331 332 333 334 335
336 338 361 362 366 367 368 369 394 395 397
398 404 405 406 407 413 414 428 429 438 453
454 455 456 457 458 461 478 479 482 502 523
550 551 559 560 561 562 563 564 565 566 569
587 590 615 622 627 629 631 647 652 663 666
679 680 7 700 72 73 78 79 88 89 94 95
R1 120 123 145 150 253 254 255 439 442 445 447
448 505 506 507 508 520 521 522 546 547 548
568 575 582 6 617
R412 493 496 501 503 504 514 515 518 532 535
538 540 541 542 543
R125 126 155 160 18 180 181 186 187 19 190 191
196 197 198 199 208 209 213 214 215 222 239
240 318 319 360 363 384 385 392 393 396 401
408 409 410 417 436 437 449 450 519 583 584
585 586 618 619 620 625 626 628 636 637 648
649 661 662 671 672 68 69 713 714 74 75 76 77
82 83 92 93 98 99
RMGCFMIC 100R0 OHM +5% 62MI5W RS3AD0101NA-5
RMGCFMIC 1K0 OHM +5% 62MI5W RS3AD0102NA-3
RMGCFMIC 10K0 OHM +5% 62MI5W RS3AD0103NA-1
RMGCFMIC 100K0 OHM +5% 62MI5W RS3AD0104NA-A
PROCESSOR section
DPR1005-2005/230
5/5
Location Description Part number
R498 RES, CHIP, 1, 1/16W, +/-5%, 0603 RS3AD010ANA-6
R452 494 RMGCFMIC 120R0 OHM +5% 62MI5W RS3AD0121NA-A
R411 420 422 552 RMGCFMIC 150R0 OHM +5% 62MI5W RS3AD0151NA-1
R441 572 RMGCFMIC 2K0 OHM +5% 62MI5W RS3AD0202NA-A
R553 554 593 597 598 567 576 RMGCFMIC 220R0 OHM +5% 62MI5W RS3AD0221NA-6
R109 110 113 114 133 134 165 170 217 219 244
245 257 262 263 264 272 273 419 421 427 480
488 489 495 50 51 517 574 581 678
R231 444 490 491 621 682 RMGCFMIC 2R2 OHM +5% 62MI5W RS3AD022ANA-7
R539 RMGCFMIC 3K0 OHM +5% 62MI5W RS3AD0302NA-6
R292 293 294 295 296 297 298 299 344 345 346
347 349 351 352 353 555 556 557 558
R472 481 525 533 536 537 544 RMGCFMIC 3K3 OHM +5% 62MI5W RS3AD0332NA-8
R102 499 591 600 607 608 639 640 645 646 657
658 669 670 685 687 694 695
R477 RMGCFMIC 47R0 OHM +5% 62MI5W RS3AD0470NA-7
R182 183 194 195 204 205 28 29 390 391 399 400
434 435 599 601 630 635 667 668 70 71 80 81 96
97
R138 220 228 232 234 241 256 269 271 283 284
330 379 416 468 524 573 677
R221 3 307 309 310 317 364 365 388 389 516 RMGCFMIC 47K0 OHM +5% 62MI5W RS3AD0473NA-1
R602 609 RES CHIP,4R7 1/16W +/-5%,0603. RS3AD047ANA-6
R101 142 143 149 151 RMGCFMIC 5K1 OHM +5% 62MI5W RS3AD0512NA-6
R127 131 RMGCFMIC 560R0 OHM +5% 62MI5W RS3AD0561NA-4
R235 RMGCFMIC 5K6 OHM +5% 62MI5W RS3AD0562NA-2
R483 RMGCFMIC 75R0 OHM +5% 62MI5W RS3AD0750NA-1
R386 387 510 511 RES CHIP 91OHM 1/16W 5% 0603 RS3AD0910NA-5
RS1 3 4 5 RCA 10K0 OHM +5% 62M15W 4 RS3AY0103NA-7
RS2 RCA 3K3 OHM +5% 62M15W 4 RS3AY0332NA-3
RS10 11 12 13 14 6 7 8 9 RCA 47R0 OHM +5% 62M15W 4 RS3AY0470NA-2
C603 CAP CHIP FORM,4P +-0.25P,50V,0603,C0G. CSDIE040ABG-1
RMGCFMIC 2K2 OHM +5% 62MI5W RS3AD0222NA-4
RMGCFMIC 330R0 OHM +5% 62MI5W RS3AD0331NA-A
RMGCFMIC 4K3 OHM +5% 62MI5W RS3AD0432NA-4
RMGCFMIC 470R0 OHM +5% 62MI5W RS3AD0471NA-5
RMGCFMIC 4K7 OHM +5% 62MI5W RS3AD0472NA-3
AC EMBD IMA VIDEO BD DPR2005 3SA-3151US-VDMI-1-9
IC32 IC KIA7806AP VOLTQAGE REGULATOR TO-220AB H03-ICKIA7806I2-4
Y100 CRYSTAL 14.31818MHz WOOIN H01-OSXBE14M3AU-7
Y101 CRYSTAL 17.734475MHz WOOIN H01-OSXBE17M7AU-9
SK10 11 RELAY D3009(1-1462033-4) H01-RLL0517811A-A
NJ10 11 12 13 14 15 16 17 JACK RCA+S VIDEO C5016031DN H01-SORA11Y00NN-5
NJ19 JACK RCA 9P JB090173FN H01-SORA90173NN-6
P100 CONNECT WAFER 2.0MM 8P 35237-0810 WHT H01-WN08AB100WH-7
P101 CONN WAFER 2.0MM 12P 35237-1210 WHT H01-WN12AB00000-8
P102 CONN 2.0MM 13P GIL-S-13P-S2T2 H01-WN13SB00000-2
C230 CE 100UF +20% 16.0V D6.3XL11 P5MM 85C CEHFC01075E-1
D102 104 D-SLP 1N4148 100.0V 150E-3A H01-DG1N04148NB-4
L100 101 102 BEAD AXIAL/TAP,HC3580 80.5ohm H03-FB05B3580NN-7
L107 INDUCTOR COIL AL02TB5R6J 5.6UH 1.9OHM +5% H01-LALNB056ACR-A
L104 105 106 108 110 LF 47U0H +10% 5.8 OHM 500MI0A H01-LAINB0470CR-2
VIDEO section
DPR1005-2005/230
1/3
Location Description Part number
C104 106 107 109 115 117 122 124 125 127 155
156 163 165 220 244 248 252 263
C269 CE 10U0F +20% 50.0V 85C P5MM 5X11 CEHIC01065E-4
C149 150 151 152 157 158 159 160 161 162 166
167
C105 108 112 116 123 126 164 183 186 191 238
247 251 264
C188 193 198 229 231 233 236 239 242 245 249
266 267 268
C154 172 174 179 222 235 241 CE47UF +20% 16.0V D5XL11 P5MM 85C CEHFC04765E-3
C102 215 CAP ELEC 22UF 16V M ELITE CEMFC0226NN-9
CE 220UF +20% 10.0V D6.3XL11 P5MM 85C CEHEC02275E-9
CE 470U0F +20% 10.0V 6.3X11 85C ELITE CEHEC0477MN-A
CE 10U0F +20% 16.0V 85C AH SAMYOUNG H01-CEHFC0106AH-5
CE 100UF +20% 16.0V D6.3XL11 P5MM 85C CEHFC01075E-1
VIDEO section
DPR1005-2005/230
2/3
Location Description Part number
C195 204 208 213 CE 1UF +20% 50V D5XL11 P5MM 85C CEHIC01055E-6
C185 189 CE 2U2F +20% 50.0V 85C 5X11 SHL H01-CEHIC0225AH-5
C205 CE 470N0F +20% 50.0V 85C 5X11 ELITE CEHIC0474NN-9
C194 CPF 22N0F +10% 50.0V CPIIC0223NN-4
C196 CPF 6N8F +10% 50.0V CPIIC0682NN-5
Q101 104 114 116 TR-SLPLF 2SA933ASR P -3.0A -20V H01-TR2SA933ANW-2
Q100 117 TR-SLPLF 2SC1740S R N 150MI0A 50V H01-TR2SC1740NW-9
Q115 TR-SLPLF MPSA56 Y P -500MI0A -300V H03-TRMPSA56YNA-0
C200 CCCFMIC 10P0F +0P5F -0P5F 50.0V NP0 0603 CZEII0100BE-0
C100 101 103 110 111 114 118 119 121 153 168
169 170 175 176 177 180 181 182 209 210 211
C202 CCCFMIC 27P0F +5% -5% 50.0V NP0 0603 CZJII0270BE-1
C201 CAP,CHIP FORM 30P +/-5% 50V C0G 0603 CSJIE0300BG-2
C203 206 207 214 CAP CHIP 39PF 50V CH J NPO 0603 CZJII0390BE-2
C228 CCCFMIC 180P0F +5% -5% 50.0V NP0 0603 CZJII0181BE-0
C184 187 192 197 199 CAP CHIP 10N0F +10% -10% 50.0V X7R 0603 CZKII0103BC-5
C227 CAP CHIP 560P0F +10% -10% 50.0V X7R 0603 CZKII0561BC-8
C171 173 178 221 225 226 232 234 237 240 243
246 250
C190 CAP CHIP 22N0F +10% -10% 50.0V X7R 0603 CZKII0223BC-6
D100 101 103 106 107 D-SLP 1SS355 35.0V 225MI0A H01-DS1S50094NB-A
IC19 28 IC BU4053BCF SOP16 ANALOG MPX/DEMPX H01-ICBU4053BB4-7
IC29 30 31 IC CMOS BU4094BF SOP16 H01-ICBU4094BD3-2
IC33 IC OSD LC74763M SOP30 H01-ICLC74763I4-1
IC13 14 26 IC-VIDEO SW MM1501XNRE SOT-26B H01-ICMM1501XDL-A
IC16 17 18 IC-LINEAR NJM2296 H01-ICNJM2296D3-7
IC27 IC-VIDEOPROC TSH95ID VIDEO AMPLIFIER H01-ICTSH95IDB4-6
Q102 103 TR-SSD DTA114YKA P 10K0 OHM 47K0 OHM H01-TRDTA114YNI-9
Q105 106 107 110 111 113 TR-SSD DTC114YKA N 10K0 OHM 47K0 OHM H01-TRDTC114YNI-5
R136 137 138 140 141 142 144 145 146 160 180
190 191 192 195 200 239
R147 RMGCFMIC 100K0 OHM +5% 62MI5W RS3AD0104NA-A
IC15 IC-VIDEO SW MM1511XNRE SOT-26B H01-ICMM1511XDL-8
R182 RMGCFMIC 100R0 OHM +5% 62MI5W RS3AD0101NA-5
R100 104 105 112 117 118 122 126 127 158 159
163 165 179 199 201 210 211 212 213 214 215
238
R185 188 RES CHIP 1M 1/16W +5% 0603 RS3AD0105NA-8
R186 187 197 RMGCFMIC 120R0 OHM +5% 62MI5W RS3AD0121NA-A
R162 166 167 RMGCFMIC 1K2 OHM +5% 62MI5W RS3AD0122NA-8
R139 143 RMGCFMIC 12K0 OHM +5% 62MI5W RS3AD0123NA-6
R202 RMGCFMIC 120K0 OHM +5% 62MI5W RS3AD0124NA-4
D108 109 110 111 112 113 114 115 116 117 DIODE PG05GBUSC H03-DS05GBUSCNB-5
R196 RMGCFMIC 1K5 OHM +5% 62MI5W RS3AD0152NA-A
R168 194 RMGCFMIC 150K0 OHM +5% 62MI5W RS3AD0154NA-6
R181 RMGCFMIC 220R0 OHM +5% 62MI5W RS3AD0221NA-6
R206 207 RMGCFMIC 2K2 OHM +5% 62MI5W RS3AD0222NA-4
R153 161 164 240 RMGCFMIC 22K0 OHM +5% 62MI5W RS3AD0223NA-2
R203 RMGCFMIC 220K0 OHM +5% 62MI5W RS3AD0224NA-0
R150 152 RES CHIP 158OHM 1% 1/16W 0603 RS1AD1580NA-0
IC10 11 12 IC-VIDEO SW MM1510XNRE SOT-26A H01-ICMM1510XDL-7
R154 RES CHIP,430 OHM,1/16W,+/-5%,0603 RS3AD0431NA-6
R241 RES CHIP 18 OHM 1/16W +/-5% 0603. RS3AD0180NA-5
R149 RMGCFMIC 330R0 OHM +5% 62MI5W RS3AD0331NA-A
R205 208 RMGCFMIC 33K0 OHM +5% 62MI5W RS3AD0333NA-6
R217 218 219 220 221 222 223 224 226 227 228
229 230 231 232 233 234 235 236
R155 156 RMGCFMIC 43R0 OHM +5% 62MI5W RS3AD0430NA-8
R176 RESISTOR CHIP 470OHM 1/16W 1% 0603 RS1AD0471NA-A
R177 RES CHIP 510OHM 1% 1/16W 0603 RS1AD0511NA-2
R193 RMGCFMIC 51K0 OHM +5% 62MI5W RS3AD0513NA-4
CCCFMIC 100P0F +5% -5% 50.0V NP0 0603 CZJII0101BE-2
CAP CHIP 100N0F +80% -20% 16.0V Y5V 0603 CZZFI0104BF-8
RMGCFMIC 1K0 OHM +5% 62MI5W RS3AD0102NA-3
RMGCFMIC 10K0 OHM +5% 62MI5W RS3AD0103NA-1
RES, CHIP, 1, 1/16W, +/-5%, 0603 RS3AD010ANA-6
VIDEO section
DPR1005-2005/230
3/3
Location Description Part number
R204 209 RMGCFMIC 68R0 OHM +5% 62MI5W RS3AD0680NA-7
R198 RMGCFMIC 6K8 OHM +5% 62MI5W RS3AD0682NA-3
R101 102 103 106 107 108 109 110 111 119 120
121 128 129 130 131 132 133
R225 RMGCFMIC 82R0 OHM +5% 62MI5W RS3AD0820NA-6
R169 RMGCFMIC 8K2 OHM +5% 62MI5W RS3AD0822NA-2
SK10 11 RELAY D3009(1-1462033-4) H03-RLL0517811A-5
R113 114 115 116 123 124 125 RES CHIP 78.7OHM 1% 1/16W 0603 H01-RS1AD78R7NA-9
DATA IN/OUT section
RES CHIP 75OHM 1% 1/16W 0603 RS1AD0750NA-6
DPR1005-2005/230
1/1
Location Description Part number
C403 CAPACITOR CERAMIC 0.0047UF 400V M CCMPA0472NA-2
F401 FUSVDETIMELG 2.0A 250.0 V 5X20 H01-FUGF202A0XX-4
IC51 52 53 IC PHOTOCOUPLER PC-17T1 DIP4 KODENSHI H01-ICPC17T10B1-2
SK41 42 RELAYPWR 12.0V 270.0OHM 10.0A H01-RLL1227111K-1
NJ51 52 53 JACK PHONE 3.6 EP-1401A 1P BK H01-SOJW2350SNN-A
NJ42 CONN-SPE AC OUTLET 2P 220V FE 19MM2 BK 0 0 H01-SOPA20019BK-A
NJ41 CON MAINS INLET A/C INLET 7014-NGP AC05-4S020A H01-SOXA27014NN-9
N403 WIRE ASS'Y UL1007#26 STR 220MM 2.0MM 2P RED H01-WG02SB82200-1
N404 WIRE ASS'Y UL1007 #26 STR 450MM 2.0MM 2P RED H01-WG02SB84500-9
N401 WIRE ASS'Y UL1617#22 STR 480MM 7.92/3.96MM 2P WHT H01-WG02SG84800-A
P402 CONNECTOR WAFER B02P-VL 12.0MM 2P H01-WN02S12MM00-A
P501 CONNECT 2.0MM 10P GIL-S-10P-S2T2-EF H01-WN10SB00000-0
BK51 52 BKT GROUND H01-ZMC12S16A00-A
NJ54 JACK-TELE SNAP-IN GOLDEN TELECOM GDL1-8P8C 8T BK 0 0 SO0A18P8CNN-7
C514 CC 100N0F +80% -20% 50.0V F CCZID0104NA-2
C502 CE 100UF +20% 16.0V D6.3XL11 P5MM 85C CEHFC01075E-1
C501 CE 100U0F +20% 50.0V 85C SHL H01-CEHIC0107AH-9
Q501 502 503 TR-SLPSWA KRA107M P H03-TRKTA107MNA-2
F501 FUSE T 2A 250V 7.6X8.6 SS-5 SAVE FUSETECH H01-FURN2200006-6
FH41 42 TERMFUSEHLDR FUSE-HOLDER J4210020001X H01-SOPS1FEHDNN-9
C503 504 505 506 CCCFMIC 100P0F +5% -5% 50.0V NP0 0603 CZJII0101BE-2
C512 513 CAP CHIP 100N0F +80% -20% 16.0V Y5V 0603 CZZFI0104BF-8
D503 504 505 506 D-SLP 1SS355 35.0V 225MI0A H01-DS1S50094NB-A
L501 502 FBEAD SURFACE MT 2500OHM FCM2012H-252T02 H01-FB2K52012NN-5
R503 RMGCFMIC 270R0 OHM +5% 62MI5W RS3AD0271NA-2
R507 508 RMGCFMIC 3K9 OHM +5% 62MI5W RS3AD0392NA-1
R510 511 RMGCFMIC 47R0 OHM +5% 62MI5W RS3AD0470NA-7
R501 502 521 522 RMGCFMIC 470R0 OHM +5% 62MI5W RS3AD0471NA-5
R504 505 506 RMGCFMIC 4K7 OHM +5% 62MI5W RS3AD0472NA-3
R509 RMGCFMIC 100K0 OHM +5% 62MI5W RS3AD0104NA-A
C511 D511 512 RMGCFMIC 0 OHM +0% 62MI5W RS3AD0000NA-0
D401 402 D-SLP 1N4148 100.0V 150E-3A H01-DG1N04148NB-4
PCB SINGLE DPR1005EU OUT 174MMX144MM*1.6t FR-1-EU PBD06KOUI00-5
R515 RCF 100R0 OHM +5% 250MI0W RC3DI0101IN-0
R401 402 RESISTOR CARBON FILM 33 OHM 1/4W 5% RC3DI0330IN-7
MODULES AND PCB ASSY'S
AMP MODULE DPR1005
AMP MODULE DPR2005
POWER SUPPLY DPR1005
POWER SUPPLY DPR2005
DPR1005-2005/230
ASS'Y AMP MODULE GR0070-7 H01-ZVD03007000-A
ASS'Y AMP MODULE GR0120-7 H01-ZVD04012000-1
SMPS ASS'Y SMPS KJP-7013 70W-EU H01-ZVD06701301-1
SMPS ASS'Y SMPS KJP-10013 120W-EU H01-ZVD07013E00-5
1/1
FRONT PCB DPR 1005 AC EMBD IMA FRONT BD DPR1005 3SA-3150US-FCMI-15
FRONT PCB DPR 2005 AC EMBD IMA FRONT BD DPR2005 3SA-3151US-FCMI-1-2
IR IN/OUT-RS232 PCB AC ESABD IMA OUT BD DPR1005EU/DPR2005 3SA-3153EU-OUMI-1-5
DSP-INPUT-PROCESSOR PCB AC EMBD IMA PROCESSOR BD DPR1005EU 3SA-3153EU-POMI-15
DSP-INPUT-PROCESSOR PCB AC EMBD IMA PROCESSOR BD DPR2005EU 3SA-3154EU-POMI-1-2
VIDEO PCB DPR1005 AC EMBD IMA VIDEO BD DPR2005 3SA-3151US-VDMI-1-9
VIDEO PCB DPR2005 AC EMBD IMA VIDEO BD DPR2005 3SA-3151US-VDMI-1-9
OUTLET BOARD (TOP VIEW)
OUTLET BOARD (BOTTOM VIEW)
VIDEO BOARD (TOP VIEW)
VIDEO BOARD (BOTTOM VIEW)
PROCESSOR BOARD (TOP VIEW)
PROCESSOR BOARD (BOTTOM VIEW)
FRONT BOARD (TOP VIEW)
FRONT BOARD (BOTTOM VIEW)
AMP BOARD (TOP VIEW)
AMP BOARD (BOTTOM VIEW)
J1, p7-16
J3, p31-33
J1, p20
J1, p26-27
J1, p21-22
No spare parts available for the SMPS from HCGI use complete SMPS part #H01-ZVD06701301-1
Loading...
