1. Be sure to ACTIVATE YOUR WARRANTY at www.GOALZERO.com/warranty
2. Open and remove the foam protector on the solar panel.
3. Prop up the legs and angle the panel towards the sun (see below).
4. Plug charging cable into your GOAL ZERO power pack.
Get to know your gear
How to use your gear
Getting Started
BEST
OKAY
BAD
Usage
Output
Input
General
12V charging port (4.7mm)
14-16V, 2.0A max (30W), not regulated
Weight (no pkg) 12.2 lbs (5.5 kgs)
Dimensions 16x22x1.75 in (44.6x55.8x2.5 cm)
Warranty 12 months
Certifications FCC and CE
Optimal Operating Temp. 32-104ºF (0-40ºC)
Optimal Storage Temp. 32-86ºF (0-30ºC)
Solar panel Rated wattage: 30W
Cell type: mono-crystalline
Open-circuit voltage: 18-20V
Converting eff.: 17-18%
Charges the following: Approx. charge time:
ESCAPE 150 6-8 hours
EXTREME 350 12-24 hours
Smart phone, GPS 2-4 hours
SOLAR PANEL
SOLAR PANEL
SOLAR PANEL
Support legs
Metal support legs prop out for ideal positioning.
Power
a. The power plug stores easily around the cable tray. When
using, plug it into the input on you GOAL ZERO power pack.
b. The blue light turns on when power is being received into
the solar panel.
Clean
Wipe it clean with a dry or slightly damp cloth.
Security
Built in locking system secures panel when shut. To open it, push out
on both slide-tabs at the same time.
Technical Specs
BRACE IT
SEE IT
Back legs help with optimum sun
positioning.
The charging light turns on when it is
receiving power.
STORE IT
Panels fold into an easy to carry case with a
comfort grip handle.
POWER IT
Highly efficient monocrystalline solar cells
deliver up to 30 Watts.
SOLAR PANEL
Output Ports
Frequently Asked Questions
Compatible With
Is the ESCAPE 30 waterproof?
Yes, just remember that the devices you are powering might not be.
Does the ESCAPE 30 always deliver 30 Watts?
It can deliver up to 30 watts of power depending on shade, and positioning in the sun.
The ESCAPE 30 will not work indoors.
What kind of solar cells does the ESCAPE 30 use?
Monocrystalline solar cells. It provides more power per square inch than any other available technology.
Can I chain multiple ESCAPE 30 panels together?
Yes. With the use of a GOAL ZERO adapter cord you can charge your power packs faster
with multiple ESCAPE 30 panels.
CONTACT US:
Toll Free: 888.794.6250
14864 Pony Express Road
Bluffdale, UT, 84065
WWW.GOALZERO.COM
We proudly support Tifie Humanitarian
WWW.TIFIE.ORG
USER GUIDE
GOAL ZERO products:
All GOAL ZERO power packs, but recommended
for use with the ESCAPE 150 or EXTREME 350
SOLAR PANEL
