Goal Zero Crush Light Chroma User guide [ml]
LED LANTERN
BEFORE FIRST USE:
Take the Crush Light Chroma out of DEMO mode
by pressing the on/off button for 10 seconds.
Table of Contents
Get To Know Your Gear 2
How It Works 3
Recharge Your Crush Light Chroma Lantern 4
Technical Specifications 5
Français 6
Deutsch 10
Español 14
日本語
18
1
GET TO KNOW YOUR GEAR HOW IT WORKS
TIP:
Fully charge the crush light before its first use.
With the lantern turned on, double-click the on/off button to
Rechargeable
by Sun
Rechargeable
USB
Hour Runtime
on Lowest
Setting
Weatherproof
IPX4 Rated
Micro USB Input
Removable Hanger
Solar Panel
On/Off Button
2 3
switch from white light to color mode.
3 WHITE MODES + CANDLE FLICKER.
Press 1X for High
Press 2X for Medium
Press 3X for Low
Press and hold for 2 seconds for candle flicker
Press and hold for 3 seconds to turn it off
COLOR RUNTIME LUMENS CHARGE TIME
White High 3 hours 60 lumens USB source 3.5 hours
White Medium 6 hours 25 lumens Built-in panel 20 hours
White Low 35 hours 6 lumens
White Candle Flicker 3.5 hours
MULTI-COLOR FADE + 6 COLOR MODES
Double-click for Multi-color Fade Mode
Press Again for Individual Color Modes:
Press 1X Green
Press 2X Aqua
Press 3X Blue
Press 4X Magenta
Press 5X Red
Press 6X Orange
Double-click to Switch back to White LED mode
NOTE: Runtimes for color modes vary depending on each color.
RECHARGE YOUR CRUSH LIGHT CHROMA LANTERN
Recharge from USB or solar panel.
Built-in
Solar Panel
20 Hrs
Full Sun
Know it’s charging with the LED indicator light next to the
charging port turns red. The Crush Light is fully charged when
the light turns green.
LED Indicator
Micro USB Input
Helpful Recharging Hint:
Place your Crush Light so the solar panel is directly angled at
the sun. For the best charge, reposition it throughout the day
so it stays at the best angle.
USB Port
2.5 Hrs
Goal Zero Crush
Light Chroma Lantern
TECHNICAL SPECIFICATIONS
Battery
Cell chemistry
Cell capacity
Lifecycles
Shelf-life
Solar
Rated Power
Cell type
Ports
USB port (input)
General
Durability
Weight
Dimensions (Open)
Dimensions (Closed)
Operating usage temp.
Certs
Warranty
Be sure to activate your warranty at goalzero.com/warranty
Li-ion Polymer
1.85Wh (3.7V, 500mAh)
Hundreds of cycles
Charge every 3-6 months
~0.12W
Monocrystalline
5V, up to 0.5A (2.5W max)
IPX4
3.2oz (91g)
4.95 x 4.95 x 3.9in (125 x 125 x 100mm)
4.95 x 4.95 x 0.6in (125 x 125 x 15mm)
32-104 F (0-40 C)
12 months
