GE
Sensing & Inspection Technologies
PM880 AC
Panametrics Portable
Hygrometer
Applications
This rugged, line-powered, portable hygrometer
measures moisture in gases and non-aqueous
liquids. It is used in conjunction with Moisture
®
probes for applications including:
Series (MIS), TF and M Series moisture
Features
• Chemical and petrochemical gases
• Non-aqueous liquid applications
• Air separation plants
• Tanker preparation and fi lling
• Industrial gases
• Gas cylinder preparation and fi lling
• Shipboard applications
circuit breakers
• SF
6
• Furnace gases/heat treating
• General plant/facility maintenance
• Hand-held portable design
• 120 or 230 VAC line power for continuous
operation
• Weather-resistant
• Large graphic display
• Internal data logger
®
• IrDA
• Stores up to 60 log/site fi les
• Simple programming via graphic user interface
• Compatible with all GE moisture probes
• Lightweight hand-held sample system
communication with PC
GE imagination at work
• Convenient carrying bag to store hygrometer and
all accessories
The PM880 AC hygrometer is a complete, portable
system with options and accessories to meet all
industrial moisture measurement needs.
PM880 AC Accessories
1 Portable, infrared thermal printer and battery charger
This hygrometer is small, lightweight, and easy to use.
The large LCD displays moisture readings in dew point
(°C or °F), ppmv, ppmw, lb/MMSCF (natural gas), and a
variety of other unit options. Data can be viewed in
alphanumeric or graphic formats. A 120 or 230 VAC
power supply allows for continuous operation of the
analyzer.
The PM880 AC comes in a soft carrying case with
zippered compartments, a handle, and a shoulder strap.
The case accommodates the PM880 AC, a sample
system, fl exible hosing, probes with protective covers,
a Moisture Image Series probe electronics module, an
operating manual, power supply, and probe cables. The
carrying bag is safe for transporting the PM880 AC and
accessories around a site.
2 Zippered soft carrying case
3 Flexible braided–stainless steel hose
4 Moisture Image Series probe electronics module
5 TF moisture probe
6 M Series moisture probe with probe cable
7 Portable sample system
8 PC infrared adapter
9 Optional PM880 AC battery and charger
2
1
The PM880 AC’s large LCD displays moisture readings in dew point (°C or °F), ppmv,
ppm
, lb/MMSCF (natural gas), and a variety of other unit options in graphic or
w
alphanumeric formats.
3
9
8
4
5
67
PM880 AC Specifi cations
Overall
Channels
Single channel
Cables
Cable type dependent on probe type: M Series, TF Series,
or Moisture Image Series. LEMO®-to-bayonet connector
Cable Length
• Standard: 10 ft (3 m)
• Optional: Consult GE for other lengths
Dimensions
• Size: 9.4 x 5.5 x 1.5 in (238 x 138 x 38 mm)
• Weight, electronics: 2.5 lb (1.13 kg)
• Weight, sample system: 4 lb (1.8 kg)
Enclosure
Ruggedized plastic, weather-resistant
Electronics
Power
120 or 230 VAC, 50-60 Hz power supply with appropriate
power cord
Optional Battery Pack
• Requires separate switchable input battery charger:
115 or 230 VAC, 50/60 Hz
• Optional rechargeable battery pack
• Battery life: 15 to 24 hours depending on type of probe;
battery life reduced when operating below 32°F (0°C)
• Requires approximately three hours for full battery
recharge
European Compliance
Complies with EMC Directive 89/336/EEC, EN61326
Annex A
For EN61000-4-3, the PM880 meets performance Criteria
A and in a limited number of frequencies, performance
Criteria B per EN61326.
Operational
Site Parameter Programming
Menu-driven, graphic, operator interface uses keypad
and soft-function keys. Online help functions. Memory
storage for saving site parameters.
Data Logging
Memory capacity to log over 100,000 moisture data
points. Programmable keypad for log units, update times,
and start and stop times.
Display Functions
Displays measurements and logged data in alphanumeric
or graphic format.
Memory
FLASH memory
Operating Temperature
14° to 122°F (–10° to 50°C)
To ensure maximum battery life, GE does not recommend
storing at temperatures exceeding 95°F (35°C) for longer
than one month.
Keypad
25-key, rubberized, tactile membrane
Display
240 x 200 pixel, graphic backlit LCD display
Printer/Terminal Output
Infrared communication port
Display Units
• Moisture: DP temperature, ppmv, ppmw, % RH,
lb/MMSCF, and others
• Temperature: °F, °C, and °K
• Pressure: psig, bar, kPa (gauge), kg/cm
others
2
(gauge), and
Moisture Measurement
Compatibility
Compatible with all GE aluminum oxide moisture probes:
M Series, TF Series, and Moisture Image Series. Each
probe type requires a diff erent type of I/O cable.
Calibration
GE moisture sensors are computer-calibrated to National
Institute of Standards and Technology (NIST) traceable
moisture concentrations.
Dew/Frost Point Temperature
Accuracy
±1% at full scale
Overall Calibration Range Capability
-166°F to 140°F (–110°C to 60°C)
Calibration Range Options
• Standard: 68°F to -112°F (20° to –80°C) with data to
-166°F (–110°C)
• Ultralow: -58°F to -166°F (–50°C to –110°C)
• Extended high: 140°F to -112°F (60°C to –80°C) with
data to -166°F (–110°C)
Accuracy
• ±1°F (±2°C) from 140°F to -85°F (60° to –65°C)
• ±2°F (±3°C) from -85°F to -166°F (–65°C to –110°C)
Repeatability
• ±0.3°F (±0.5°C) from 140°F to -85°F (60°C to –65°C)
• ±0.5°F (±1°C) from -85°F to -166°F (–65°C to –110°C)
Operating Pressure
5 μ of Hg to 5000 psig (345 bar) limited by pressure
sensor―see pressure measurement specifi cations
Temperature Measurement
Proof Pressure
Three times span of available range up to maximum
7500 psig (518 bar)
Sample System
The SS880A standard sample system comprises an inlet
needle valve, a built-in coalescing fi lter and sample cell
with a bypass needle valve and venting tube, a pressure
gauge (various ranges), and an outlet needle valve with
venting tube.
Wetted Parts
316 SS
Operating Pressure
Confi gurations available for 300; 500; 1000; 2000; or
3000 psig (21, 35, 69, 207, or 345 bar), dependent on
pressure gauge)
Maximum Pressure Rating
• Standard: 3000 psig (207 bar)
• Optional: 5000 psig (345 bar)
Optional thermistor available for all GE moisture probes
Range
–22° to 158°F (–30° to 70°C)
Accuracy
±0.3°F (±0.5°C) at -22°F (–30°C)
Pressure Measurement
Optional pressure sensor available for TF Series and
Moisture Image Series moisture probes
Ranges
• 30 to 300 psig (3 to 21 bar)
• 50 to 500 psig (4 to 35 bar)
• 100 to 1000 psig (7 to 69 bar)
• 300 to 3000 psig (21 to 207 bar)
• 500 to 5000 psig (35 to 345 bar)
Other Options
• Inlet pressure regulator, 0 to 500 psig (1 to 345 bar)
outlet
• Armored fl owmeter, 1.3 to 13 SCFH
• 10-ft (3-m), fl exible, polytetrafl uoroethylene-lined,
braided–stainless steel hose with 1/4-inch tube
connections. Not recommended for dew point
temperatures below –103°F (–75°C).
www.gesensinginspection.com
920-132D
© 2009 General Electric Company. All Rights Reserved. Specifi cations are subject to change without notice. GE is a registered trademark of General Electric Company. Other company or product
names mentioned in this document may be trademarks or registered trademarks of their respective companies, which are not affi liated with GE.
