OptiSonde™

General Eastern Chilled Mirror Hygrometer

User’s Manual

Sensing

OptiSonde™

General Eastern Chilled Mirror Hygrometer

User’s Manual

910-282A October 2007

The OptiSonde Chilled Mirror Hygrometer is a General Eastern Instruments product. General Eastern Instruments has joined other GE high-technology sensing businesses under a new name—GE Sensing.

October 2007

Warranty Each instrument manufactured by GE Sensing, Inc. is warranted to be

free from defects in material and workmanship. Liability under this warranty is limited to restoring the instrument to normal operation or replacing the instrument, at the sole discretion of GE Sensing, Inc. Fuses and batteries are specifically excluded from any liability. This warranty is effective from the date of delivery to the original purchaser. If GE Sensing, Inc. determines that the equipment was defective, the warranty period is:

• one year for general electronic failures of the instrument

• one year for mechanical failures of the sensor

If GE Sensing, Inc. determines that the equipment was damaged by misuse, improper installation, the use of unauthorized replacement parts, or operating conditions outside the guidelines specified by GE Sensing, Inc., the repairs are not covered under this warranty.

The warranties set forth herein are exclusive and are in lieu of all other warranties whether statutory, express or implied (including warranties of merchantability and fitness for a particular purpose, and warranties arising from course of dealing or usage or trade).

Return Policy If a GE Sensing, Inc. instrument malfunctions within the warranty

period, the following procedure must be completed:

1. Notify GE Sensing, Inc., giving full details of the problem, and provide the model number and serial number of the instrument. If the nature of the problem indicates the need for factory service, GE Sensing, Inc. will issue a RETURN AUTHORIZATION number (RA), and shipping instructions for the return of the instrument to a service center will be provided.

2. If GE Sensing, Inc. instructs you to send your instrument to a service center, it must be shipped prepaid to the authorized repair station indicated in the shipping instructions.

3. Upon receipt, GE Sensing, Inc. will evaluate the instrument to determine the cause of the malfunction.

Then, one of the following courses of action will then be taken:

• If the damage is covered under the terms of the warranty, the

instrument will be repaired at no cost to the owner and returned.

• If GE Sensing, Inc. determines that the damage is not covered

under the terms of the warranty, or if the warranty has expired, an estimate for the cost of the repairs at standard rates will be provided. Upon receipt of the owner’s approval to proceed, the instrument will be repaired and returned.

iii

October 2007

Table of Contents

Chapter 1: Features and Capabilities

Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

Electronics Enclosure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

Front Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

Input/Output Capability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

The System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

System Components. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

Dew Point Sensors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

Temperature Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

Chapter 2: Installation

Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1

Benchtop Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1

Mounting the Benchtop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1

Wiring the Benchtop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2

Wall-Mount Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3

Mounting the Wall-Mount . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3

Wiring the Wall-Mount. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4

Input Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5

Output Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5

Analog Outputs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6

Alarm Outputs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6

Serial Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8

Sensor Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9

Sampling Lines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10

Ensuring Heat Transfer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-10

Filter Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11

Flow Rate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11

Sensor Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12

Model 1111H Sensor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-12

Model D-2 Sensor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12

Model 1211H Sensor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-13

Connecting the Sensors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-13

October 2007

Table of Contents (cont.)

Chapter 3: Operation

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

Normal Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

Operating the OptiSonde . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2

Status Line Indications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3

Factory Default Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4

Sensor Balancing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5

Helpful Hints For Operating the Unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5

Supercooled Dew Points . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6

Contamination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6

Mirror Flooding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-8

Sample Line Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-8

Pressure Effects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-8

Chapter 4: Programming the OptiSonde

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1

Programming Technique . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2

Programmable Functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3

Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3

Analog Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4

Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5

Logging OptiSonde Data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6

OptiSonde Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8

Automatic Cleaning and Balance Function. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-9

Service Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-11

System Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-11

Locking the System Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-11

Chapter 5: Maintenance

Minor Maintenance of Sensor Optics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1

Cleaning and Balancing the Sensor Mirror . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1

Procedure for Cleaning and Balancing the Sensor Mirror . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2

Field Replacement of Sensor Mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-5

Replacing the Sensor Mirror. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6

Test and Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7

Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7

The Display Doesn’t Light Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7

“Service” Appears on the STATUS Display Line . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7

Incorrect Dew Point Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-8

“Balance” Remains on the Status Line . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-9

No Analog Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-9

No Serial Output. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-9

October 2007

Table of Contents (cont.)

Appendix A: Specifications

Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1

Accuracy. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1

Measurement Ranges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1

Response Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1

Update Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1

Functionality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2

Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2

Operating Ranges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2

Physical (Bench Mount) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2

Physical (Wall Mount) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2

Optional Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-3

Appendix B: Humidity Equations and Conversion Chart

Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-1

Vapor Pressure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-1

Humidity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-2

Appendix C: Configuring the Serial Interface

Wiring to a Personal Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-1

Appendix D: Chilled Mirror Sensors

Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .D-1

Depression. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D-1

Measurement Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .D-2

Comparing OptiSonde Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .D-3

Appendix E: Theory of Operations and Glossary

Theory of Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-1

Hygrometer Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-1

Hygrometer Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-2

Other Hygrometer Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-3

The PACER Cycle. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-3

Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-5

vii

Chapter 1

Features and Capabilities

Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

Electronics Enclosure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

The System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

October 2007

Introduction The GE Sensing OptiSonde™ is a multi-purpose chilled-mirror

hygrometer, suitable for use in a wide variety of applications. The OptiSonde can function with the GE Sensing one and two-stage chilled-mirror sensors to provide the following measurement ranges (depending on the sensor selected):

• one-stage 45° depression @25°C and 1 ATM

two-stage 65° depression @25°C and 1 ATM (depending on sensor, as shown in Figure 1-1 below)

• relative humidity from 0.02% to 100%

• moisture content from 0.9 ppm

to over 5.8 × 105 ppm

• temperature from -100° to +100°C (-212°F to +212°F)

(a)

(b)

(c)

Figure 1-1: Mirror Depressions at Various Temperatures for

1111H (a), D2 (b) and 1211H (c) Sensors

Features and Capabilities 1-1

October 2007

Introduction (cont.) The OptiSonde simultaneously measures and displays any two

parameters with a wide variety of units of measurement. You can use the data logging function to record and upload weeks of data. When the data is uploaded to a PC, PanaView software enables graphing and data reduction. You can also export the data in ASCII text file format for use in spreadsheets such as Excel, or view screen captures in HyperTerminal.

Electronics Enclosure The OptiSonde is available in two configurations:

• a benchtop model, AC powered with DC option

• a wall-mount unit, housed in an IP65 enclosure

See Chapter 2, Installation, for details on how to mount the OptiSonde.

Front Panel The OptiSonde’ s fron t panel is shown in Figure 1 -2 below. The panel

includes: a 128 X 64 graphical display, arrow keys to the right of the display screen.

ENTER and ESC keys, and four

3.30

3.70

Figure 1-2: OptiSonde Benchtop Version

1-2 Features and Capabilities

Input/Output Capability Available inputs and outputs include the following:

• 1111H, 1111H-GE, D2 or 1211H chilled mirror sensor input

• 4-wire Resistance Temperature Detector (RTD) input

• two simultaneous analog outputs, each with a programmable 0-20

mA or 4–20 mA DC signal

• one independent alarm relay (7 A, 30 VDC)

• RS-232 serial communications port

The OptiSonde uses the GE Sensing patented Programmable Automatic Contaminant Error Reduction (PACER) system for automated self-cleaning and optics rebalancing.

Detailed specifications for the OptiSonde are given in Appendix A.

The System

October 2007

System Components A complete OptiSonde system consists of the following items:

• Electronic monitor • Temperature sensor

• Dew point sensor • Maintenance kit

• Interconnecting sensor cable • User’s Manual

• AC line cord (for benchtop)

• Certification that the unit is traceable to the National Institute

of Standards and Technology (Certificate of Conformance)

Sensors The OptiSonde is configured with a chilled-mirror dew point sensor.

The specific sensor is chosen according to the expected dew point range and the environment in which the dew point is to be determined. In addition, the OptiSonde is supplied with a temperature sensor. GE Sensing provides the following sensors for various applications:

Dew Point Sensors • Model 1111H — Dew point single-stage sensor with 1” M-NDT

• Model 11 1 1H-GE — Dew point single-stage sensor with flange for

duct mounting

• Model 1211H — Two-stage sensor; high pressure and temperature

• Model D-2 — Two-stage sensor

Temperature Sensor • Model T-100E

Features and Capabilities 1-3

Chapter 2

Installation

Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1

Benchtop Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1

Wall-Mount Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3

Output Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5

Sensor Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9

Sensor Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12

October 2007

Introduction This chapter explains the installation of the benchtop and wall-mount

versions of the OptiSonde, the various sensors used with the system, and the I/O and power wiring.

Benchtop Installation

Mounting the Benchtop

Note: All dimensions are in inches.

The OptiSonde benchtop dimensions are shown in Figure 2-1 below. A wire bale on the bottom of the case can be unfolded to raise up the front for easier viewing, if desired.

3.30

3.70

8.0

8.84

Figure 2-1: OptiSonde Benchtop Dimensions

Installation 2-1

October 2007

Wiring the Benchtop

Input Power The OptiSonde operates with input power from 100 to 240 VAC

±10%. (See Figure 2-2 below.) The OptiSonde’s voltage and frequency rating are listed on the product label. A DC option offers a minimum of 18 to a maximum of 32 VDC operation (See Figure 2-3 below.)

Sensors Connect the dew point sensor cable to the 25-pin connector on the

OptiSonde’s rear panel (see Figure 2-2 below). Connect the optional temperature sensor cable to the 9-pin temperature connector on the rear panel. Other I/O wiring connects to the appropriate terminal block. Tighten all connector thumbscrews to prevent disconnection s.

LINE

180-240VAC

TEMP

COMM

FUSE: 1A

TYPE T

50-60 Hz

80 VA MAX

Analog

OUTB

DP-SENSOR

OUTA

ANALOG SHIELD

Figure 2-2: OptiSonde Benchtop Rear Panel

TEMP

DP-SENSOR

COMM

Analog

OUTBOUTA

NO NC C

7A, 30V

DC POWER

18-32 VDC/1A

RELAY

NO NC C

7A, 30V

RELAY SHIELD

ANALOG SHIELD RELAY SHIELD

Figure 2-3: OptiSonde DC Option Rear Panel

2-2 Installation

October 2007

Wall-Mount Installation The OptiSonde Wall-Mount unit is designed to mount on a flat,

vertical surface, such as a wall or panel. To mount the wall-mount version, see Figure 2-4 and Figure 2-5 below.

Mounting the Wall-Mount

8.17

4.49

10.479

Note: All dimensions are in inches.

.38

Figure 2-4: OptiSonde Wall-Mount Dimensions

.38

2.86

7.80

Note: All dimensions are in inches.

Figure 2-5: OptiSonde Wall-Mount - Mounting Hole Locations

For mounting, secure the unit to a wall or panel using all four mounting holes. Use stainless hardware, a minimum of 2 inches long, #8 screws with washers. Screws should go directly into wood studs. If no stud is available, use suitable hardware for the application, such as with plasterboard or cement.

Installation 2-3

October 2007

Wiring the Wall-Mount Caution!

The wall-mount unit meets IP65 rating for water ingress

when tested with solid plugs. In order to maintain this

rating, installation personnel must ensure that each of the

two wiring ports use a single cable with a minimum

diameter of 0.24 in (6 mm) and a maximum diameter of

0.47 in (12 mm). Recommended wire nuts torque is 37 in-

lbs (4.2 Nm). Any unused wiring port shall be plugged with

a supplied solid plug.

All connections to the wall-mount unit are made through the panel at the bottom of the case as shown in Figure 2-6 below. Any I/O cabling is brought into the unit through glands at the lower right of the case and connects to the terminal blocks inside the case. Wiring for these connections is shown below and in Figure 2-8 on page 2-5. The dew point sensor and temperature sensor cable connectors are located on the black mounting block.

IMPORTANT: AC and signal wiring must be done in accordance

with local codes. Wire size cannot exceed 14 AWG

(2.08 mm to being inserted into the connection block.

). Insulation shall be stripped 6 mm prior

ANALOG OUTPUTS PIN

OUTA +1.

OUTA -

OUTB + OUTB -4.

TEMP. SENSOR

PIN WIRE COLORS

RED

1. WHITE2. GREEN

BLACK SHIELD

5. NOTE: CUSTOMER MUST INSTALL SUPPLIED FERRITE (P/N 222-028) OVER THE END OF TEMPERATURE SENSOR ON LOCAL AND REMOTE.

DESCRIPTION SUPPLY VOLTAGE

EARTH GROUND CONNECTION

(TIE TO A COMMON PROTECTIVE EARTH

RELAY

USING THE SAME SIZE , OR GREATER,

WIRE AS AC POWER.) NO1. NC

COMM

SHIELD

A/C POWER

FERRITE

LOCAL SHOWN

COVER ASSEMBLY NOT SHOWN

5 1

1 4 1 3

J11

2 1

J13

1 2 3

A/C POWER TERMINAL BLOCK PIN 1 L1 LINE POWER CONNECTION 100-240VAC

2 L2/ N LINE/NEUTRAL CONNECTION

RS232 PIN

TX1.

RX RTN3.

I/O

Figure 2-6: Wall-Mount Wiring Entrance Locations

CHASSIS GROUND

2-4 Installation

October 2007

Input Power Power wiring enters the case through a gland fitting at the lower right

of the unit and connects to a screw terminal block mounted on the right side of the case. The voltage, frequency and power ratings are listed on the bottom of the unit. shown in Figure 2-7 below. The external ground screw must connect the unit to protective earth using a wire that is sized equal to or great then the wire used for input power connectio ns. Groun ding should b e done in accordance with local codes.

Wiring of this terminal block is

2 1

J13

1 2 3

A/C POWER TERMINAL BLOCK PIN DESCRIPTION 1 L1 LINE POWER CONNECTION

2 L2/ N LINE/NEUTRAL CONNECTION

Figure 2-7: Wall-Mount AC Power Wiring

Output Wiring The benchtop outputs are connected to removable terminal blocks o n

the rear panel. Figure 2-2 on page 2-2 shows the location of the benchtop terminal blocks and Figure 2-8 below shows the wall-mount connections.

The Wall-Mount OptiSonde input/output terminal blocks are located inside the front door as shown in Figure 2-6 on page 2-4. Cabling is brought in through the glands on the bottom of the unit and wired to the terminal blocks shown in Figure 2-8 below. Terminal block screws must be torqued between 0.4 - 0.5 Nm.

Output programming is described in Chapter 4.

TEMP. SENSOR

PIN WIRE COLORS

RED

1. WHITE2. GREEN

BLACK SHIELD

5. NOTE: CUSTOMER MUST INSTALL SUPPLIED FERRITE (P/N 222-028) OVER THE END OF TEMPERATURE

RELAY PIN

NO1. NC

COMM

SHIELD

A/C POWER

SENSOR ON LOCAL AND REMOTE.

EARTH GROUND CONNECTION

5 1

1 4 1 2 3

J11

2 1

J13

1 2 3

RS232 PIN

I/O

TX1. RX RTN3.

ANALOG OUTPUTS PIN

OUTA +1.

OUTA -

OUTB + OUTB -4.

Note:

FERRITE

Figure 2-8: Wall-Mount Input/Output Terminal Blocks

Installation 2-5

October 2007

Analog Outputs Note: When the OptiSonde is being programmed, the analog outputs

provide 4–20 mA signals representing the designated parameters.

• For 4–20mA output, connect to terminals labelled 4–20 (+) and

RTN (–).

Note: The maximum load allowed for current output is 500 Ohms.

Example: Assume a temperature output, scaled to range from 0°C (Tlower) to 100°C (Tupper), with a measured actual temperature of 23°C (Tactual): The current output is calculated by:

Tactual Tlower–()

Iout

yielding an output current of 7.68 mA.

------------------------------------------------- Tupper Tlower–()

23 0–()

---------------------100 0–()

16()4+× 7.68mA=

20 4–()4+×=

(2-1)

(2-2)

Alarm Outputs The alarm output connects to the contacts of a 7-Amp, Form C

(SPDT) relay.

Make connections as follows:

• For normally open contacts, connect to NO and COMM.

• For normally closed contacts, connect to NC and COMM.

Any available parameter can be used to control an alarm relay by programming the parameter name and its threshold values. An alarm can also be programmed to monitor the state of the Control, PACER Balance, or Service indicators. (See Chapter 4 for programming instructions.)

Two threshold values are programmed for each parameter—an upper and a lower value. These values designate an alarm band. How they are used depends on the alarm type programmed. Details of the alarm bands are shown on the following pages.

2-6 Installation

October 2007

Set Point Alarm For the Set Point alarm type, the alarm band provides hysteresis to

prevent frequent operation of the alarm relay when the parameter is near the specified value. The relay is activated when the parameter

exceeds the upper limit, and deactivated when the parameter goes below the lower limit.

Figure 2-9: Set Point Alarm

Inner Band Alarm For the Inner Band alarm type, the alarm relay activates whenever

the parameter value is between the lower and upper limits.

Figure 2-10: Inner Band Alarm

Outer Band Alarm For the Outer Band alarm, the alarm relay activates whenever the

parameter value is greater than the upper limit or less than the lower limit.

Figure 2-11: Outer Band Alarm

Installation 2-7

October 2007

Serial Output The Serial Output connector is located on the rear panel of the

benchtop unit (see Figure 2-2 on page 2-2), and inside the wall-mount unit (Figure 2-6 on page 2-4). The output provides RS-232C serial communications between the unit and a terminal or a PC running in terminal emulation mode.

The benchtop connector is a standard 9-pin D connector. For connection to a serial device, the wallmount cable is wired as shown in Figure 2-8 on page 2-5. The baud rate can be programmed using the Comms menu (see page 4-10). The data format is 8 bits, 1 stop bit, no parity.

2-8 Installation

October 2007

Sensor Information GE Sensing produces a variety of sensors compatible with the

OptiSonde, ranging from one to two stages of thermoelectric cooling. A comparison chart listing specifications of each sensor appears in Appendix D. The following sections provide information on installing the following GE Sensing dew point sensors:

• Model 1111H — Single-stage sensor with 1” M-NDT

• Model 1111H-GE — Dew point single-stage sensor with flange

• Model 1211H — Two-stage sensor; for high pressure and temp.

• Model D-2 — Two-stage sensor

When selecting a location for installing a sensor, consider the following criteria:

• Locate the sensor as close as is practical to the source of the gas to

be measured, to keep the sampling lines as short as possible. This minimizes the system response time and reduces the error rate at low frost points due to sample line outgassing.

Caution!

The OptiSonde electronics and sensors are for General

Purpose Locations only. They are not for use in hazardous

(classified) locations. Sample air/gas shall be non-

combustible only.

• Choose a sensor location that provides access to the dewpoint

sample cavity cover, to facilitate periodic mirror cleaning.

Caution!

Never place the sensor in a location where temperatures

rise above the maximum rated temperature for the device.

See Appendix D for complete sensor specifications.

Installation 2-9

October 2007

Sampling Lines Keep the length of sample tubing between the source and the sensor

short, for quick response and highest accuracy. All sampling line compression fittings provided with the sensor are for ¼-inch diameter tubing, unless otherwise specified at the time of order.The material used for the inlet lines can have an important effect on the validity of the readings. Do not use rubber hose or plastic tubing such as PVC or Tygon, because of their hygroscopic nature.

When measuring frost points below –30°C, sample gas leaving the sensor outlet should be vented through a coil approximately two feet long, since backflow of ambient moisture into the sensor can take place even under positive pressure. Use stainless steel tubing and fittings, and ensure that all plumbing is completely free from leaks.

Stainless steel is the material of choice.The sampling system should allow for periodic cleaning. It may be helpful to install a tee and closing valve on the inlet side, to permit the sensor to be shut off while the sampling lines are flushed. At very low humidities, even a trace amount of contamination can alter measured frost point, so cleanliness is particularly important.

Ensuring Heat Transfer Be sure the sensor has an adequate heat sink when operating in hot

environments. The sensor must never be allowed to reach a temperature above its rated limit. It is not sufficient merely to ensure that the sensor is in an environment whose temperature is below the rated limit; a means must be supplied to remove heat from the sensor.

When the Model 1111H, 1211H or D-2 sensors are used at ambient temperatures of 20° to 24°C, full rated depression can be achieved by mounting the sensor on a smooth, thermally conductive surface (such as metal), which tends to remain at the ambient temperature.

If possible, do not operate the sensor continuously at or near full depression. Doing so may decrease the anticipated life of the thermoelectric heat pump.

When measuring dew points at or above the ambient temperature, the sensor must be heated to a temperature of at least 5 to 10°C above the highest anticipated dew point (but not higher than the sensor temperature rating). Some sensors can be mounted on a liquid heat exchanger, or a temperature-controlled electric hot plate, or installed in a heated enclosure. GE Sensing recommends closed-loop active control of the elevated sensor body temperature.

The sensor base should be coated with zinc-oxide-filled silicone thermal grease and securely anchored to the heat sink with suitable fasteners. Allow ½ hour for the sensor to reach thermal equilibrium after adjusting the temperature of the heat sink.

2-10 Installation

October 2007

Sample Lines for High Dew Point Measurements

Sampling lines carrying gas to the sensor must be heated and insulated when the dew point of the gas is above the sample line’s ambient temperature. The simplest way to achieve this is to use heater tape (either thermostatically controlled, or continuously operating, and sized to provide the required temperature rise). At high temperatures, use stainless steel tubing with adequate insulation to avoid hot and cold sections in the line and to avoid water absorption/ desorption cycling as the heater is thermostatically controlled. GE Sensing can provide custom heated systems. Please contact our application engineers.

Filter Requirements If the gas to be monitored is free from particulates and hydrocarbon

liquids or vapor, filtering is not necessary . However, most sample gas streams contain some particulates, and using a filter reduces the need for frequent mirror cleaning. On the other hand, filtering tends to slow the system’s response, particularly at low frost points.

The model BF12-SS filter may be used inline; GE Sensing’s application engineers would be pleased to review your application and recommend an appropriate sampling system.

A void using glass wool, cellulose, and othe r hygroscopic materials as a filter medium.

Flow Rate It is important to have adequate flow through the sensor. Too little

flow can slow the response (particularly at very low frost points). Too much flow can cause instability of the control system at high dew points and can reduce the depression capability of the thermoelectric cooler at very low dew points. Too much flow also accelerates the

rate of system contamination. A flow rate of 2 to 2.5 ft min) is ideal for most applicatio ns.

/h (∼ 1 liter/

Installation 2-11

October 2007

Sensor Installation This section provides installation details for the GE Sensing line of

chilled-mirror humidity sensors.

Model 1111H Sensor The Model 1111H is an open-type sensor (see Figure 2-12 below )

with 45°C depression capability at 25°C @ 1 A TM. It can be threaded into standard pipe fittings or mounted in a type 0111D pressure boss, which encloses it and adapts it for ¼-inch compression fittings. When installing the sensor in the pressure boss, remove the black aluminum sensor cover. A second version, the 1111H-G E, extends 9 in. and includes a duct-mounted flange and a removable PTFE filter.

For maximum thermal conductivity, the base of the Model 0111D pressure boss should be coated with heat-conducting grease. When so installed on a surface suitable for dissipating heat, the sensor will achieve its maximum rated depression. See the Chilled Mirror Sensor Comparison Chart in Appendix D.

Figure 2-12: Model 1111H Sensor for Duct Mounting

Model D-2 Sensor The Model D-2 is a general purpose, two-stage sensor with 65°C

(117°F) of depression capability at 25°C @ 1 ATM. It features wetted parts of stainless steel and glass, for durability in demanding industrial applications. The Model D-2 can be used as a benchtop sensor, mounted to a heat sink, or mounted to a cooling fan for maximum operating range. Advanced features include fieldreplaceable optics and cooler assemblies, and auxiliary visible light optics with a viewing window for inspecting the mirror during operation (see Figure 2-13 below).

For maximum thermal conductivity , the base of the Model D-2 sensor should be coated with heat-conducting grease. When so installed on a surface suitable for dissipating heat, the sensor will achieve its maximum rated depression. See the Chilled Mirror Sensor Comparison Chart in Appendix D.

Figure 2-13: Model D-2 Sensor

2-12 Installation

October 2007

Model 1211H Sensor The Model 1211H is a two-stage sensor with 65°C (117°F) of

depression capability at 25°C @ 1 ATM. It features wetted parts of stainless steel and may be used at higher temperature and pressure than the D2 sensor. The Model 1211H can be used as a benchtop sensor, mounted to a heat sink. Features include a field-replaceable mirror, optics and cooler assembly. See the Chilled Mirror Sensor Comparison Chart in Appendix D.

Connecting the Sensors Dew point and temperature sensors provided by GE Sensing for the

OptiSonde monitor are pre-wired with connectors installed. Plug these connectors into their corresponding sockets as shown in Figure 2-2 on page 2-2 for the benchtop unit, or Figure 2-6 on page 24 for the wall-mount unit. The 1111H sensor can be mo un ted d irectly to the wall-mount enclosure to facilitate room monitoring. Ensure that the sensor or cable is fully inserted, and the ring coupler fully handtightened for reliable operation. Tighten dome nut to 22 in-lb (2.5 Nm) to assure a proper seal for IP65 rating.

Installation 2-13

Chapter 3

Operation

Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

Normal Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

Operating the OptiSonde . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2

Status Line Indications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3

Sensor Balancing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5

Helpful Hints For Operating the Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5

October 2007

Introduction Operating instructions fall into three categories:

• Normal Operation - Using the unit’s controls.

• Setup and Programming - Customizing the unit for specialized

applications (not required for many conventional applications).

Note: The unit is shipped pre-programmed to meet typical

requirements. The factory default settings are listed in Table 3-2 on page 3-4. Complete programming instructions are given in Chapter 4.

• Maintenance - Manually testing the unit’s cooling capacity,

cleaning the mirror, and other operations that might be required on a regular basis, or when a problem is suspected, depending on the application. Details are given in Chapter 5, Maintenance.

Normal Operation Normal operation of the OptiSonde is very simple. First, apply power

to the wall-mount unit. For the benchtop unit, switch the main power switch on the rear to ON (—).

The OptiSonde begins its power-up sequence, which lasts about a minute. The unit’s software version is displayed on the initial screen, “Initializing”. Next, the OptiSonde performs an balance. The PACER balance typically requires five to fifteen minutes, depending on the sensor chosen and the humidity of the sample gas during the balance cycle. “AUTO CYCLE” or “PACER” appears on the status line.

Once the balance cycle is completed, the unit displays “Acquiring” until it reaches steady state. The word Control appears on the status bar at the top of the screen.

The sensor can be controlled using the keys to the right of the display, shown on the screen below. The operator can manually heat or cool the sensor, or initiate a PACER balance cycle. To control the sensor, press the key, followed by the

ENT key. (If the OptiSonde keys are locked, press the ESC

ENT key, and then press the ESC key again.)

AUTO or a PACER

Operation 3-1

October 2007

Operating the OptiSonde The parameters chosen during programming are displayed

numerically in the middle of the screen. For programming, see Chapter 4. A typical OptiSonde display screen is shown in Figure 3-1 below. The system status and heating/cooling indicator (small arrow) are shown in the upper right, and the balance indicator is shown in the lower left.

Menu: x Auto Cycle 

mbar

Ta°C

Figure 3-1: Typical OptiSonde Display Screen

To control the sensor, press the locked, press the

ESC key again.) The Function Control screen appears, as shown in

Figure 3-2 below. Use the four arrow keys to select the desired function

ESC key , followed by the ENT key, and then press the

6.0179

+25.09

14:33

ENT key. (If the OptiSonde keys are

Select Function:

HEAT

PACER AUTO`

COOL



Figure 3-2: Function Control Screen

3-2 Operation

October 2007

Status Line Indications The status line at the top of the display shows whether the unit is

ready for normal operation, or is still in its start-up phase, or needs service. The following is a complete list of status indications:

Table 3-1: Status Indications

Indication Meaning

Initializing The unit is initializing.

Acquiring The unit is acquiring stable mirror temperature.

Service Req.

The sensor optics require service, cleaning or adjustment.

Tracking The unit is responding to a changing dew point.

Control

The unit is actively controlling the mirror temperature at a stable dew point.

Alarm* The alarm has been activated.

Auto Cycle The Auto Cycle cleaning and balancing cycle is

active.

PACER The PACER cleaning and balancing cycle is

active.

Heating Sensor Heating is active.

Cooling Sensor Cooling is active.

Flooded The sensor detected a major upset, and

attempts to remove excess water.

*located at bottom center of display.

Operation 3-3

October 2007

Factory Default Settings As shipped from the factory, the OptiSonde is normally programmed

with the configuration shown in Table 3-2 below.

Table 3-2: Factory Default Values

Function Setting

Analog Output A Analog Output B

Humidity, Units: Tdew °C, Range: –40°C to +60°C Temperature, Units: Tmp °C, Range: 0 to 100°C

Alarm Disabled, Humidity, Units: Tdew °C, Set Point: Upper: 0.000, Lower:0.000

Auto Balance Interval: Daily at 12:00 noon, Auto Cycle, Enabled.

Data Field 1 Data Field 2

Humidity, Units: Tdew °C Temperature, Units: Tmp °C (Dry bulb)

Sound On

Gas Molecular Weight of Gas: 28.9645 (typical for air)

Communication

Baud rate: 38,400

Parameters

Serial Outputs

Humidity, Units: Tdew °C Humidity, Units: % RH Temperature, Units: Tmp °C

Data Log

[COMM]

Data Log [FILE]

Status: Stopped, Interval: 60 second, Separator: tab, Parameters: Td °C,

%RH; Flags: enabled*

Status: None/Stopped, Interval: 60 second, Separator: tab, Parameters: Td °C,

Ta°C, %RH; Flags: enabled*

Ta°C,

Pressure 101.325 kPa (typical atmospheric pressure @ sea level).

*A status flag gives an indication, via the RS-232 interface, of the OptiSonde status, such as “Control” and “PACER,” as well as the state of the alarm (“ALARM” or “_______”).

3-4 Operation

October 2007

Sensor Balancing During normal operation, the sensor mirror surface may become

partially obscured with salts or other contaminants from the sample gas. The balance indicator displayed on the screen shows whether the system is operating near the center of its normal range, or has been forced away from the center by mirror contamination. In general, it is recommended to start with an clean gases are being used. If the Service status indicator is displayed after an of a applications, it is desirable to perform a balance operation periodically to maintain optimum performance. The interval and type of balance are configurable as described in the OptiSonde programming chapters.

If the Service indicator is displayed after a balance operation, the sensor may need to be adjusted (see Minor Maintenance of Sensor Optics on page 5-1).

AUTO cycle, the mirror is likely still dirty and may require use

PACER cycle (described in detail on page E-3). In most

AUTO balance cycle provided relatively

Helpful Hints For Operating the Unit

Time response: At dew points above 0°C, the system stabilizes within a few minutes at a consistent dew layer. The status Control is displayed when the system is stable and readings are valid.

When the system is operating at low frost points (below 0°C), extra care may be required when interpreting readings because of the longer response times of the system. Time response depends on a number of factors including dew/frost point, slew rate, upstream filtering, and flow rate.

• As the dew/frost point becomes lower, water molecules in the air

sample become scarcer, and it takes longer to condense a frost layer on the mirror thick enough to establish an equilibrium condition.

• Mirror temperature slew rate depends on dew point and depression

(the temperature difference between the mirror and the sensor body); at higher dew points and moderate depressions, it is typically 1.5°C/second. At lower dew points and/or larger depressions, the slew rate is slower.

• Flow rate affects response by determining the rate at which water

vapor is supplied or carried off.

There is, of course, a trade-off between response time, control system stability, and sensitivity to contamination.

Operation 3-5

October 2007

Supercooled Dew Points Slightly below the freezing point, water can exist in a supercooled

liquid state for extended periods of time. Extra care may be needed when making measurements in the frost point region of 0 to –20°C, because the mirror temperature may temporarily stabilize at the supercooled dew point, 0.5 to 1°C below the actual frost point.

To assure that the unit is operating in the ice phase within this temperature range, allow the instrument to operate continuously. Before manually clearing a frost layer, take a reading, and afterwards allow sufficient time to reform a stable frost layer before taking further readings. The D2 has a viewport to enable viewing the mirror surface.

Contamination

Mirror Cleanliness Proper operation of a condensation hygrometer depends on the

condition of the mirror surface. In general, accuracy is reduced when contaminants accumulate on the mirror.

However, the mirror does not have to be microscopically clean. In fact, the mirror performs best a few hours after cleaning, when nucleation sites have formed. On an unscratched, freshly cleaned mirror, there are relatively few nucleation sites on which dew or frost deposits can form, and more time is required to collect a condensation layer at low frost points. Also, overshoot may occur, which can cause oscillations as the temperature stabilizes.

Particulate Contaminants Particulate matter that is insoluble in water may accumulate on the

mirror surface, but does not affect the instrument accuracy until the mirror reflectance is reduced substantially. In many cases, particulates improve instrument response by providing condensation sites.

3-6 Operation

October 2007

Water-Soluble Contaminants

Contaminants which readily dissolve in water, such as naturally occurring salts, are detrimental to accurate vapor concentration measurement by any condensation method. These materials readily go into solution with the water condensate on the mirror surface, and then reduce the vapor pressure in accordance with Raoult’s Law. As the concentration increases with time, the saturation vapor pressure of the liquid solution decreases.

The unit responds to this lower vapor pressure by elevating the mirror temperature in order to maintain a vapor pressure that is in equilibrium with the partial pressure of atmospheric water vapor. The displayed dew point, therefore, drifts upward above the true dew point. Because the measurement error increases gradually, it often goes undetected.

T o determine whether dissolved contaminants are af fecting dew point measurement, perform the following steps:

1. Note the indicated dew point.

2. Clean the mirror.

3. Balance the detector by initiating a

PACER cycle.

4. Measure the dew point again.

If the new reading is lower than the first reading, it is likely that soluble material was present in sufficient quantity to cause a measurement error.

Gaseous Contaminants When a gaseous material that has a higher condensa tion temperature

than that of water is present (even in very low concentrations), the unit will eventually control on that material, rather than on water . The system then displays the condensation temperature of the contaminant, not of water. Such material accumulates on the mirror only when chilled. In the normal atmosphere, gaseous contaminants do not have a detectable effect.

Operation 3-7

October 2007

Minimizing the Effects of Contaminants

The following steps are suggested for maintaining optimum performance:

• Use the PACER feature to reduce the effect of contaminants on the

unit’s performance (see The PACER Cycle on page E-3).

• Reduce the gas flow rate to reduce the rate of accumulation of

contaminants on the mirror.

• Clean the mirror according to the recommended optics cleaning

procedure (see Minor Maintenance of Sensor Optics on page 5-1). To determine the proper cleaning interval for a given set of conditions, take a dew point reading before and after the cleaning. Any appreciable shift indicates that under these conditions, the mirror should be cleaned more often.

Mirror Flooding If there is an abrupt transition from dry to moist conditions

(particularly when accompanied by a transition from cold to warm temperatures), the mirror may accumulate an overload of moisture. It then may take several minutes before the sensor dries out and valid readings can be obtained. The drying process can be accelerated by heating the sensor.

Sample Line Maintenance Contaminated sample lines slow the unit’s response time and can

cause erroneous readings, usually on the high side. Clean the sample lines as often as necessary. To determine the required cleaning frequency , take dew point readings before and after cleaning the lines, sensor cavity, and mirror. If the two readings differ appreciably, the sampling lines should be cleaned more often. To reduce the rate of contamination, reduce flow and/or install a filter upstream.

Pressure Effects If the pressure of the gas is increased or reduced from atmospheric

pressure, but the mixing ratio (moisture content) stays constant, the dew point is correspondingly increased or decreased. The OptiSonde displays the dew/frost point at the pressure to which it has been programmed. The sensor location and hookup arrangement can influence the pressure.

The dew point change due to pressure change can be calculated by using psychrometric equations. Appendix C contains basic data for these calculations.

3-8 Operation

Chapter 4

Programming the OptiSonde

Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1

Programming Technique . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2

Programmable Functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3

October 2007

Introduction The OptiSonde can be easily programmed to choose the data to be

displayed, the data to be output on the analog or serial outputs, and the alarm settings. A typical data display appears in Figure 4-1 below:

Menu: ESC Control 

mbar

Ta°C

Figure 4-1: OptiSonde Typical Data Display

Table 4-1 below lists the OptiSonde’s programmable functions. Each function has a number of settings (listed on the following pages). Values for some settings are selected from a list of choices; others are entered as numeric or alphanumeric data using the keypad.

Table 4-1: Programming Functions

Function Settings

Display Select units for parameter display

Outputs Select units and scaling, test and trim values

Alarms Alarm type and alarm limits

Logs Selection of logging card or PC logs, parameter choice,

units/data format

6.0179

+25.09

14:33

Settings Automatic balance, sound, communications, offset val-

ues, gas molecular weight, clock, line pressure, recalibration reminder

Service (Service personnel only.)

About Displays ID number, system status and software version

LOCK Locks keys.

Programming the OptiSonde 4-1

October 2007

Programming Technique The functions of the six keys to the right of the display change

according to the current state of the unit.

Below is the general method for programming the unit:

1. To access the programming menus, press the OptiSonde keys are locked, press the key, and then press the

ESC key again. Then press ESC again to

ESC key , followed by the ENT

ESC key. If the

enter the Main Menu.

2. Press the [S] and [T] keys to step through the functions that can be programmed (shown in Table 4-1 on page 4-1). You can also use the [

W] and [X] keys for adjacent choices.

3. For a particular function, press the ENT key to display the first setting for the function. Press the [T] key to step through its available settings.

4. For a particular setting, press the ENT key to open the setting for editing.

If the setting uses a list of specific choices, the [T] key and/or [S] key are shown. Press them to step through the choices.

Note: To enter numeric data, use the arrow keys to scroll to the

appropriate column; then use the [S] and [T] keys to scroll to the desired numeric value. Note that certain settings have numeric values that are restricted to certain ranges.

5. After choosing a value for a setting, press ENT to lock it in.

Or, you can press the ESC key to cancel the entry (restoring the original value) and return to choose another setting.

To return to the function choice, press the ESC key.

A typical programming screen (for setting the Analog Outputs) is shown in Figure 4-2 below.

Output Menu [Out A]

Select Tracking

Units Test Upper Trim Lower

Figure 4-2: Typical Analog Outputs Programming Screen

4-2 Programming the OptiSonde

October 2007

Programmable Functions

Display For display, the menu first requires that you select Line 1 or Line 2.

You can then select from the display parameter units listed in Table 42 below.

Table 4-2: Display Unit Options

Units Description

Td °C Dew/frost point temperature in degrees Celsius

Td °F Dew/frost point temperature in degrees Fahrenheit

% RH Percentage of relative humidity

Ta °C Temperature in degrees Celsius (dry bulb)

Ta °F Temperature in degrees Fahrenheit (dry bulb)

e mbar Water vapor pressure in millibars

Tw °C Wet bulb temperature in degrees Celsius

Tw °F Wet bulb temperature in degrees Fahrenheit

PPMv Parts per million by volume

ΔT °C

ΔT °F

PPMw Parts per million by weight

AH g/m

AH gr/f

Delta temperature (Ta-Td, or the difference between temperature and dewpoint) in degrees Celsius

Delta temperature (Ta-Td, or the difference between temperature and dewpoint) in degrees Fahrenheit

Absolute humidity in grams per cubic meter

Absolute humidity in grains per cubic foot

Under

Decimal, you can select the number of decimal places (up to

three) for the parameter shown in each line. You can also select

Reverse to change the screen display from the default of blue letters

on a white background to white letters on a blue background.

Programming the OptiSonde 4-3

October 2007

Analog Outputs

Table 4-3: Analog Output Options

Setting Description Available Options

Select

Units

Type Choose the type of output. 4-20 mA, 0-20 mA

Upper

Lower

Tracking Determine how to handle analog output Track (transmits actual temperature of

Test Set the parameter value to test the output

Trim Set values (in zero and span) to compensate

Choose which output channel you will program.

Choose the units for scaling the parameter on the selected channel

Set the parameter value that will produce fullscale output (span) for the selected channel.

Set the parameter value that will produce zero output for the selected channel.

channel for proper operation.

for variation in outputs.

A or B

See Table 4-2 on the previous page for the available units.

Enter a number.

the mirror), Hold (transmits the last prevailing dew point before balance cycle)

Enter a number as a percent of scale.

Enter a number.

Trimming the Output: 1. Attach a precision DVM (digital voltmeter) or mA calibrator to

the 4-20 mA output.

2. Select

3. Select

RESET TRIM. The options available are TRIM ZERO and TRIM

SPAN

TRIM ZERO. The output changes to 4.00 mA.

4. Enter the actual value as read from the DVM/calibrator.

5. Select

TRIM SPAN. The output changes to 20.00 mA.

6. Enter the actual value as read from the DVM/calibrator.

7. Exit the

TRIM setting. You have completed output calibration.

4-4 Programming the OptiSonde

October 2007

Alarms For more information on using the alarms, see Alarm Outputs on

page 2-6.

Table 4-4: Alarm Options

Setting Description Available Options

Status Enable or disable the alarm. Off/On

Units Set the units for the parameter. See Table 4-2 on page 4-3.

Type

Upper The maximum alarm value. Enter a number.

Lower The minimum alarm value. Enter a number.

Tracking Determine how to handle alarm Track (responds to actual temperature

Set the type of condition that will activate the alarm.

The Upper and Lower limits set the alarm thresholds. Alarm types are listed below (see details on page 2-6):

Set Point, Inner Band, Outer Band, Control, Service, PACER

of the mirror), Hold (responds to the last prevailing dew point before balance cycle)

• SetPoint: Alarm activates when parameter exceeds upper limit;

deactivates when parameter is less than lower limit.

• Inner Band: Alarm activates when parameter is between upper and

lower limits.

• Outer band: Alarm activates when parameter is outside upper and

lower limits.

• Control: Alarm activates when the OptiSonde is actively

controlling mirror temperature.

• Service: Alarm activates when the Service indicator is activated.

• PACER: Alarm activates when the PACER or AUTO balance is

active.

Programming the OptiSonde 4-5

October 2007

Logging OptiSonde Data Logging OptiSonde data requires use of either the supplied secure

digital (SD) card (installed internally), or GE Sensing’s PanaView program.

• To use PanaView to log data, refer to the PanaView User’s Guide.

• To create OptiSonde logs, complete the steps below:

1. From the Main Menu, enter

2. Enter

Select and enter either File (for a log stored on the internal

SD card) or

Comm (for a log stored on the PC). Press ENT. The

Logs.

current selection is part of the Logging menu header.

OptiSonde can run two logs at any one time, one for the SD card and one for the PC. (The two logs can measure different parameters.) T o switch between the logs, return to

File or Comm. If you start another log on either File or

either

Comm, OptiSonde automatically closes the previous log.

3. To enter logging parameters, enter

Units. You can select any

Select and enter

combination of the units available in Table 4-2 on page 4-3 for up to eight units. Press

4. To select the logging interval, enter the output interval in seconds (up to 86400). Press

5. To select the output format, enter

ENT to confirm your selections.

Interval. You can then enter

ENT.

Format. You can then choose

from three output formats. x = #.# will display as “TdewC = -12.345” #.# () will display as “-12.345 (TdewC)” #.# will display as “-12.345”

6. To select the field separator, enter

CR-LF, Comma, and Tab.

from

FieldSep. You can then choose

7. You can now start the log:

• To start a new internal (File) log with these parameters, enter

Manage>New Log>Start. OptiSonde begins to log data. (The

log name is always the current date and time when logging begins.)

Note: The

Manage option is only available for internal (File) logs.

• To start a PC (Comm) log, enter Status>Start.

4-6 Programming the OptiSonde

October 2007

Managing Current or Completed Logs

Once the log is running, you can either stop or close it. If you are running both File and Comm logs, enter chosen the log you want to stop. Then enter the

Select and be sure you have

Status option.

• Enter Stop to stop the log from recording further data. Once you

have stopped it, you can restart it by selecting

Start.

• Enter Close to permanently stop and complete the log. Only closed

logs can be erased.

You can retain an internal (File) log in the SD, transfer it to the PC, or erase it.

• T o transfer a log to the PC, enter Manage>Transfer. Then select the

log from the list of logs, and press

ENT.

• To erase a log from the SD, enter Manage>Erase. Then select the

log from the list of logs, and press

ENT.

• The OptiSonde will display up to 8 log files for management.

However, up to 512 log files can be stored on the SD card. You should erase logs from the SD card when they have been safely transferred to a PC for storage.

Logging Parameters

Table 4-5: Logging Parameter Options

Setting Description Available Options

Status Select whether to start or stop transmitting

data.

Select Select logging on PC or SD (secure data) card File (log on internal SD card), Comm

Manage (Internal or File logs only)

Units Set up to eight units to log. See Table 4-2 on page 4-3.

Interval

Format Choose the output format. X=#.#, #.#(), #.#

Field Separator

Handle individual logs. Details (displays file name, interval and

Enter the output interval in seconds (for Serial Mode: All).

Choose the separator to be used between parameters.

Start (start new or currently running log), Stop (stop currently running log), Close (stop and complete log; once closed, the log cannot be reopened).

(log on PC)

size), Transfer (transfer closed log to PC), New Log (set up new log), Erase (delete log from OptiSonde)

Enter a number (up to 86400).

CR-LF, Comma, Tab

Flags Enable logging of status (Control, PACER,

Flooded, etc.) and alarm state (Alarm/-------)

Programming the OptiSonde 4-7

On, Off

October 2007

OptiSonde Settings

Table 4-6: Settings Options

Setting Description Available Options

Balance Set up type and interval of mirror

cleaning and balancing

Comms Set up baud rate and node ID for RS232

communications.

Sound Select whether the OptiSonde produces

a sound when users press the keypad.

Adjust Enter the offset values for the Dew Point,

Temperature and Filter parameters.

The molecular weight of the gas being

Gas

Clock Enter the current time and date. Enter the time (hours and minutes) and

Pressure Pressure value to be used. Enter line pressure in kPA.

Notify Enter a time at which the OptiSonde

analyzed. (The default value is the molecular weight of air: 28.9645 g/mole)

should be recalibrated.

See Automatic Cleaning and Balancing on page 4-9.

Baud Rate (from 1200 to 115,200), Node ID (from 1 to 239, with default of 16), Test (small check confirms RS232 communications are working)

Off/On

Enter the values by which the parameters will be offset.

Enter a number.

the numeric date (month, date and year).

Off, 6 Months, 12 Months, 18 Months, 24 Months

4-8 Programming the OptiSonde

October 2007

Automatic Cleaning and Balance Function

OptiSonde analyzers can run the Auto or PACER self-cleaning and rebalancing cycles at a preset time after the last cycle was run. The automatic balance cycle will always run upon power up of the analyzers.To program the Automatic Cleaning & Balance Function on the OptiSonde:

1. From the main screen: a. Press the ESC key to enter the Main Menu. b. Scroll to c. Enter the

2. Set the Balance a. Enter b. Enter either

Settings and press ENT.

Balance option.

Type:

Type.

AUTO or PACER. Table 4-7 below explains the

difference between the options.

Table 4-7: Automatic Cleaning and Balance Functions

Item Function

AUTO Heats the mirror and balances the optics.

PACER

First cools the mirror to develop a thick dew/frost layer, then heats and balances the optics.

Note: The PACER function will pr ovide mor e thorough cleaning than

the AUTO function because it first develops a thick dew/frost layer into which soluble contaminants dissolve. When heated, some of the contaminants are flash evaporated and the remaining residue accumulates in clusters, resulting in the cleaning of much of the mirror’s surface. The

PACER cycle

generally takes longer to complete.

3. Select whether or not you will use a. From the b. Enter

Balance menu, enter Status.

Off or On

Auto Balance.

4. Determine the Interval at which the OptiSonde will perform

cleaning and balancing.

a. From the

Balance menu, enter Interval.

b. Use the arrow keys to enter the interval time in days (or

decimal fractions of days), up to 90 days. Press

c. If using an interval of whole days (e.g., 1.000, 3.000), use

ENT.

Time

to specify the time of day to perform the balance. Enter time in 24-hour format (e.g., 8:00 p.m. = 2000, 10:30 a.m. = 1030).

Programming the OptiSonde 4-9

October 2007

Automatic Cleaning and Balance Function (cont.)

5. T o view the most recent and next cleaning and balance times, enter

Schedule.

6. Press ESC to exit the Balance Menu and the Main Menu for the

settings to take effect.

IMPORTANT: For environments or a gas sample where the mirror

accumulates contamination rapidly, the use of an inline filter is recommended. Lower flow rates will also reduce the accumulation of contaminants.

Cleaning and Balancing Options

Table 4-8: Cleaning and Balancing Options

Setting Description Available Options

Type Select type of mirror cleaning and balancing Auto (Automatic), PACER

Status Select whether or not to use Auto Balance Off, On

Interval Enter time to balance mirror (in days or decimal

fractions of days).

Time Enter time of day to balance (whole day intervals

only).

Enter value (up to 90.0 days).

0000 = midnight, 1200 = noon 2359 = 11:59 p.m.

Schedule Lists last day and time of balance and next sched-

uled time and day of balance.

(None)

Communications Parameters

Table 4-9: Communication Parameter Options

Setting Description Available Options

Baud

Node ID Select Node ID number for PanaView

Test Run test of RS-232 communications. (After test, a check in lower right corner of

Set the baud rate to be compatible with the receiving device.

transmission

1200, 2400, 4800, 9600, 19200, 38400, 57600, 115,200 (Note: 38400 is the default value for PC communications.)

1 to 239 (Note: The default PanaView node ID is 16.)

screen indicates correct operation; a short message will be transmitted.)

4-10 Programming the OptiSonde

October 2007

Service Options IMPORTANT: The Service menu is intended for factory-trained

personnel only, and access is limited by requiring a service passcode. This menu allows the factory default data, including calibration data and sensor parameters, to be adjusted. Please contact an applications or service engineer at GE Sensing if access to these menus is required. Normal operation of the OptiSonde does not require access to the information contained in the Service menu.

System Information

Table 4-10: About Options

Setting Description Available Options

ID Lists unit and sensor ID numbers. (None)

System Status Lists current uptime, last calibration

date, last balance date and time.

Software Versions Lists current boot and program versions. (None)

(None)

Locking the System Keys If you press ENT when LOCK is highlighted, the OptiSonde keys will

be locked, preventing access to the Main Menu. To unlock the keys,

ESC, ENT, and ESC. (Press ESC again to reenter the Main Menu.)

press

Programming the OptiSonde 4-11

Chapter 5

Maintenance

Minor Maintenance of Sensor Optics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1

Field Replacement of Sensor Mirrors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-5

Test and Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7

October 2007

Minor Maintenance of Sensor Optics

Cleaning and Balancing the Sensor Mirror

Periodically inspect and maintain the sensor optics as described in the following chapter. These procedures can be performed at any time, but are only necessary when the Service indicator appears on the status display, indicating that service is required.

Under normal conditions, the system is self-checking and selfbalancing. However, there are occasions when particulate matter and water-soluble contaminants reduce sensor mirror reflectance and system accuracy (see Contamination on page 3-6). Three features of the OptiSonde system allow users to monitor and adjust the mirror:

• The balance indicator (shown in Figure 5-1 below) provides a

graphic display of how much light is received by the mirror’s photodetector. It is also an indicator of the dew layer thickness. This indicator increases and decreases in digital steps.

• The bias screw adjusts the light signal received by the reference

photodetector and is used as a “coarse adjustment.”

• The automatic balance, or PACER cycle (discussed on page 1-6),

electronically fine tunes the optical balance between the IR emitters and reference photodetectors.

In operation, the position of the balance indicator will depend on the level of humidity and the sensor used. As the humidity changes, the chilled mirror system will seek to establish control.

As contaminants deposit on the mirror, the balance indicator will increase, as will the dew point readings. The cleaning and balancing (followed by the the contamination.

Note: If the mirror is severely scratched or pitted, you may not be

able to balance it. It may be replaced in the field, as discussed on page 5-5. For industrial applications, GE Sensing recommends the solid platinum mirror.

Menu: x Auto Cycle 

Balance

Indicator

mbar

Ta°C

6.0179

+25.09

PACER cycle or manual

PACER cycle) will mitigate

Status

Indicator

14:33

Figure 5-1: Balance and Status Indicator on OptiSonde Display

Maintenance 5-1

October 2007

Procedure for Cleaning and Balancing the Sensor Mirror

When necessary, use the procedure below to clean and balance the sensor mirror. To clean the mirror, you will require the MSK-2 Maintenance Kit, which includes essential supplies:

• Cotton swabs

• Screwdriver or hex driver for some sensors

• Cleaning solution

1. From the OptiSonde analyzer, press the Function window appears. Press the up arrow key to reach HEAT.

2. Allow the dew point temperature (mirror temperature) to attain the maximum value.

3. To clean the mirror: a. Remove the cap or open the cover of the chilled mirror sensor. b. Put one drop of cleaning solution on a cotton swab. c. Gently rub the cotton swab on the mirror in a circular motion

(spiral outwards) to clean the mirror.

d. Use a dry swab to dry and buff the mirror. The mirror should be

bright and shiny.

ENT key. The Select

e. Discard the used swabs.

IMPORTANT: If the contamination is severe, then solvents such as

alcohol, acetone or hexane may be used, followed by a rinse of the cleaning solution then distilled water. Be sure to dry and buff the mirror with a dry swab.

4. Observe the balance indicator. For a dry, clean, balanced mirror, the bar should be at the midpoint of the scale, as shown in Figure 5-2a below. A wet mirror will have a bar similar to Figure 5-2b, and a mirror requiring bias adjustment will appear similar to Figure 5-2c below. Adjust the bias screw to move the gray block as close as possible to the solid center block.

(b) Wet Mirror

(a) Balanced Mirror

Bias Adjustment

Figure 5-2: Balance Indicator for Various Mirror Conditions

5-2 Maintenance

October 2007

Procedure for Cleaning and Balancing the Sensor Mirror (cont.)

5. If the square is not in the center of the bala nc e ba r, use the screw or hex driver to adjust the optical bias screw (shown in Figure 5-3 below) on the sensor until the marker is in the center of the bar. You are performing a coarse balance adjustment.

Model D2

Sensor Balance adjustment screw

Model 1111H

Figure 5-3: Balance Adjustment Screw Locations

IMPORTANT: This adjustment is made while the cap or cover is on

the 1111H & D2 sensors. For the 1211, the adjustment is made with the cap removed. In these cases the adjustment should not be made in sunlight, bright incandescent or infrared light. It might be useful to shade the sensor cavity with your hand or place a coin over the sensor cavity.

6. Once balanced, replace the sensor cap and make sure the balance indicator does not change.

Maintenance 5-3

Model 1211H

October 2007

Procedure for Cleaning and Balancing the Sensor Mirror (cont.)

7. On the OptiSonde analyzer, enter the Function Control screen to reach AUTO.

If the “Automatic Balance” is set for “Pacer,” the system will first cool, then heat. If the unit is set for “Auto,” it will only heat. The system will then automatically fine tune the optical balance. The word Balance will appear in the lower left of the display, followed by the phrase Acquiring.

The unit will then cool to the dew point and the balance indicator will increase when dew or frost condenses on the mirror. The dew point reading might overshoot, then it will stabilize (assuming the sensor is exposed to constant humidity).

When a stable dew or frost layer is attained, you will see the word Control in the lower left. The OptiSonde is now reading the correct dew/frost point and a stable dew or frost layer has been established. When the OptiSonde is exposed to typical room humidity, this process takes 5-6 minutes. For very dry conditions, the unit may not display Control for several hours; however, the PACER indicator will go out. The sensor must first accumulate a dew or frost layer on the mirror before it can display Control.

During large changes in moisture, the to Tracking. This is normal, and indicates that the OptiSonde is tracking the moisture level. When the moisture level stabilizes, the control indicator will reappear.

8. If you see the word Service Req displayed in the lower left, repeat steps 1-7.

Control indicator may change

5-4 Maintenance

October 2007

Field Replacement of Sensor Mirrors

One advantage of using a GE Sensing chilled mirror dew point sensor is that the mirror is user-replaceable. The sensor does not have to be returned to the factory for replacement of the reflective surface, unless that is desired.

A mirror may require replacement for any of the following reasons:

The mirror is constructed of silver/rhodium plated copper. Copper provides excellent thermal conductivity to the platinum thermometer. However, some gas constituents, such as sulfur dioxide (SO2) may react with the copper and eventually pit the surface or form a copper sulfate coating.

The reflective surface may be gradually abraded by sharp dirt particles in the gas being measured.

The mirror surface may be accidentally scratched or gouged during use or cleaning.

If the sensor mirror has reacted with a corrosive material in the gas sample, such as an acid or sulfur compound, it should be replaced with a solid platinum mirror to remove any possibility of copper corrosion.

In extreme cases, a solid platinum mirror can make possible a successful application of chilled mirror technology. For example, measurements in tobacco factories and malting houses have drastically improved after this change, since both locations have sample gas constituents that attack copper.

Maintenance 5-5

October 2007

Replacing the Sensor Mirror

Required equipment: torque driver, set to 20-30 inch-ounces of torque. GE Sensing type TW-1 is recommended.

The kit supplied by the factory contains the replacement mirror, a container of white thermal compound for proper heat transfer, and (in some models) a mylar washer that is to be placed under the mirror.

1. Deactivate the sensor cooler, using one of the following actions:

• Turn the sensor power off, or

• Place the sensor switch to heat, or

• Disconnect the sensor cable

2. Turn off the sample gas. Make sure the sensor cavity is depressurized before continuing with the next step.

3. Open the sensor by removing the sensor cover.

4. Unscrew and discard the old mirror, using a 3/16-inch (0.187) hex

socket.

5. Use a toothpick or similar tool to place a small amount of thermal compound in the hole supporting the mirror.

Caution!

Do not apply thermal compound to the mirror stem.

Do not use an amount large enough to leak out when the

mirror is tightened.

Do not allow any compound to get on the mirror surface,

as it is very difficult to remove completely.

6. Carefully screw in the new mirror and tighten to the proper torque as specified for the particular sensor.

7. Carefully clean the mirror surface, using a cotton swab and the GE Sensing cleaning solution supplied with the maintenance kit. Distilled alcohol or diluted alcohol is also acceptable.

8. Replace the cover and return the sensor to normal operation. Under some circumstances, a new mirror may operate in a somewhat unstable manner for the first hour or two.

5-6 Maintenance

October 2007

Test and Calibration The procedures in this section effectively test and/or calibrate the

following aspects of the OptiSonde:

• Startup and power supply voltage

• Normal sensor operation

• Front panel display

• Digital and analog outputs.

The unit has been completely tested and calibrated at the factory, and is ready to plug in and operate. As shipped, it meets all of our published specifications.

When ordered as a complete hygrometer system with a chilled mirror sensor and cable, it is verified at a number of points against a dew point system that has been certified by the U.S. National Institute of Standards and Technology (NIST). A Certificate of Compliance is supplied with the unit to indicate traceability.

Troubleshooting

The Display Doesn’t Light Up

“Service” Appears on the STATUS Display Line

1. On the benchtop model, check the POWER switch on the rear panel. Make sure it’s ON.

2. Check the line cord. Make sure both ends are plugged in and that it is plugged into a proper source of AC voltage.

3. Check the power supply. Make sure it is connected and has the proper output voltage.

4. Check the fuse. Make sure the proper fuse size is installed. Make sure the fuse is not open.

The text “Service Req” displayed on the STATUS line means service is required. The most frequent problem requiring service is that the mirror surface is contaminated and should be cleaned.

Clean and balance the sensor mirror (refer to Minor Maintenance of Sensor Optics on page 5-1). Next, run the instrument through a PACER cycle. If, at the end of the cycle, the Service Req status appears again, repeat the cleaning and balancing procedure, or contact the factory .

Maintenance 5-7

October 2007

Incorrect Dew Point Display

If the dew/frost point reads incorrectly, first check the standard preventive maintenance items:

Clean and balance the sensor mirror (refer to page 5-1).

An alternative method for checking the accuracy of the unit’s electronics is to use a precision resistance decade box in place of the platinum thermometer. Wire the decade box to the unit’s sensor connector as shown in Figure 5-4 below, and verify that the resistance settings shown in the table produce the temperatures shown.

OptiSonde

1123HK

Sensor

Cable

Connector

OptiSonde

Sensor

Cable

Connector

LOWHIGH

Resistance

Decade Box

RX100

RX10

RX1

RX0.1

RX0.01

Din Type 100 Ohms at 0°C 0.385 Ohms/°C

Resistance

Ohms

76.33

96.09

100.00

103.90

123.24

Resistance Table

Display Reading

°C (±0.1)

–60.0

–10.0

0.0

10.0

60.0

°F (±0.2)

–76.0

Figure 5-4: Using a Resistance Decade Box

14.0

32.0

50.0

140.0

5-8 Maintenance

October 2007

“Balance” Remains on the Status Line

Check that the sensor and sensor cable are connected. If necessary, connect them, and the unit will complete the PACER cycle after a short time (5 to 15 minutes).

The sensor bridge may be out of balance (refer to page 5-1).

No Analog Output If there is no analog output, but the digital display indicates correctly ,

check the analog output scaling.

No Serial Output Check the serial port programming for proper settings.

Maintenance 5-9

Appendix A

Specifications

Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1

Functionality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2

Physical (Bench Mount) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2

Physical (Wall Mount) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2

Optional Accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-3

October 2007

Performance

Accuracy [complete system at 25°C (77°F)]

Dew/Frost Point: ±0.2°C (±0.36°F)

Temperature: ±0.15°C (±0.27°F)

Relative Humidity: Governed by accuracy of dew point and temperature sensors

Other Humidity Parameters: Governed by accuracy of dew point, temperature and pressure sensors

Sensitivity 0.05°C (0.09°F)

Repeatability ±0.1°C (±0.18°F)

Measurement Ranges

Chilled Mirror Sensors:

(available)

Range: one-stage 45° depression @25°C and 1 ATM

Temperature Sensor: T-100E: –100°C to +100°C (–148°F to +212°F)

Recommended

1111H, 1111H-GE, 1211H, D-2

two-stage 65° depression @25°C and 1 ATM dew/frost point, depending on sensor used

0.5 to 2.5 scfh (0.25 to 1.25 L/min)

Sample Flow

Response Time

Dew/Frost Point Cooling

Rate:

Temperature Response: < 7 sec for step change within +25°C to +70°C (+77°F to +158°F)

1.5°C (2.7° F)/sec [typical, above 0°C (32°F)]

Update Time 1 sec

Specifications A-1

October 2007

Functionality

Digital Interface RS-232

Alarms

Relay (optional): Form C (SPDT) 7 A, 30 VDC (resistive load)

Operating Ranges

Dew Point Sensors

Temperature: • 1111H: -15 to + 80°C

Outputs Two linear simultaneous parameters, 0/4-20 mA (isolated) wi th 250Ω

or 500Ω maximum load resistance

Display 128 X 64 pixel monochrome LCD

Power 100-240 VAC (+/-10%), 50-60 Hz

18 (minimum) -32 (maximum) VDC (benchtop only on special order)

Pressure:

Electronics

Temperature: -10°C to +60°C (+14°F to +140°F)

Relative Humidity: 85% maximum

Physical (Bench Mount)

Dimensions

Weight 3 lbs (1.4 kg)

Environmental IP-20

Physical (Wall Mount)

• D2: -25 to +85°C

• 1211H: -15 to +100°C

• 1111H: 200 psig max

• D2: 150 psig max

• 1211H: 300 psig max

3.7” H × 8.0” W × 8.8” D (9.4 cm × 20.3 cm × 22.4 cm)

Dimensions

10.48" H × 8.2” W × 4.5" D (26.6 cm × 20.8 cm × 11.4 cm)

Weight 5.3 lbs (2.4 kg)

Environmental IP-65

A-2 Specifications

Optional Accessories

PTFE-GE Filter for 1111H-GE PTFE

BF12SS Inline filter

October 2007

FM-1 Rotameter

Specifications subject to change without notice.

Specifications A-3

Appendix B

Humidity Equations and Conversion Chart

Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-1

Vapor Pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-1

Humidity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-2

Introduction The following symbols appear in the equations below:

e = Vapor Pressure, millibars

= Vapor Pressure with respect to ice, millibars

= Vapor Pressure with respect to water, millibars

= Saturation vapor pressure, ice, millibars

= Saturation vapor pressure, water, millibars

P = Total Pressure, millibars

T = Temperature, °C

October 2007

= Ambient temperature, °C

= Dew point temperature, °C

= Frost point temperature, °C

Vapor Pressure Saturation vapor pressure with respect to water is a function of

temperature only and is given by the following:

6.1121E XP

Saturation vapor pressure with respect to ice requires a minor adjustment of the constants as given by the following:

6.1115EXP

In addition to yielding saturation vapor pressure as a function of ambient temperature, the above equations also yield ambient vapor pressure as a function of dew/frost point.

17.502T

------------------------

240.97 T+

22.452T

------------------------

272.55 T+

(B-1)

(B-2)

The total pressure of a gas mixture is equal to the sum of the partial pressure each gas would exert, were it to occupy the same total volume, according to Dalton’s law.

Humidity Equations and Conversion Chart B-1

October 2007

Humidity Relative Humidity is defined as the ratio of the water vapor pressure

(e) to the saturation vapor pressure (e dry bulb temperature (Ta):

⎛⎞

%R H 100

-----

⎝⎠

Absolute humidity is expressed as water vapor density: water vapor mass per unit volume of dry air, according to the following:

216.7E T

-------

--------------------------=

T 273.16+

W ater vapor content expressed as parts per million by volume is given by the following:

PPM

) at the prevailing ambient or

()

WTD

100

--------------------

()

WSTA

()

ETD()

-------------= P

(B-3)

(B-4)

(B-5)

Expressing water vapor content as parts per million by weight (or mixing ratio) requires multiplication of the above by the ratio of the molecular weight of water to that of air as given by the following:

PPM

----------PE–

--------------------------------------------------------------------------------------- -

mw of carrier gas for air (24 g/mole)

(B-6)

See Figure B-1 on page B-3 for a graphical humidity conversion chart.

B-2 Humidity Equations and Conversion Chart

October 2007

Figure B-1: Graphical Humidity Conversion Chart

Humidity Equations and Conversion Chart B-3

Appendix C

Configuring the Serial Interface

Wiring to a Personal Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-1

October 2007

OptiSonde

9-Pin Female

9-Pin

3255

(TX)

(RX)

(GND)

Wiring to a Personal Computer

The OptiSonde is configured as Data Terminal Equipment (DTE). The following pins are used on the serial interface:

• 2 - Transmitted data (TXD)

• 3 - Received data (RXD)

• 5 - Signal ground (GND)

To send the output of a benchtop OptiSonde to a personal computer, use the cable arrangement shown in Figure C-1 below. For a wallmount OptiSonde, use the wiring shown in Figure C-2 below.

Figure C-1: Wiring Diagram - Benchtop OptiSonde to PC

1 2 3

RS232 PIN

1 2 3

TX1.

RX RTN3.

Figure C-2: Wiring Diagram - Wall-Mount OptiSonde to PC

Configuring the Serial Interface C-1

Appendix D

Chilled Mirror Sensors

Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D-1

Depression. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .D-1

Measurement Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .D-2

Comparing OptiSonde Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .D-3

October 2007

Introduction For use with the OptiSonde hygrometer, GE Sensing offers a choice

of three chilled mirror sensors which differ primarily in their depression (cooling) capability. Depression capacity determines the minimum dew point that can be measured. All of the sensors feature low-noise, infrared optics, a field-replaceable mirror, and can be located up to 300 ft (91 m) from the electronics.

Many of these features were pioneered by GE Sensing, and are available only on GE Sensing products.

A chilled mirror sensor is generally selected so that its depression capability will allow it to measure the lowest dew/frost point anticipated for the application.

Depression A Peltier device is a solid-state heat pump. It has one surface

thermally bonded to the body (base) of a dew point sensor and the other surface bonded to the mirror block. When current is supplied to the Peltier device, heat is “pumped” from the mirror block to the sensor body where it is dissipated. With full cooling current, the mirror block will eventually cool to its minimum temperature. The difference between the temperatures of the mirror block and the sensor body when the mirror block is at this minimum temperature is defined as the depression capability of the sensor.

Depression capability is a function of how many “stages” the Peltier device has stacked in series. Thus, a two-stage sensor typically has 60°C to 65°C (108°F to 117°F) of depression capability, and can measure lower dew/frost points than a one-stage sensor which has 45°C (81°F) of depression capability. Depression is normally specified at 25°C (77°F) ambient temperature. As ambient temperature (and, therefore, sensor body temperature) is decreased, depression capability also decreases, due to the drop-off in efficiency of the thermoelectric cooler.

Therefore, there are limitations to using liquid-cooled sensors to increase low-end measurement range. At nominal dew/frost points, approximately one third of the additional cooling is lost due to cooler inefficiency, and does not result in additional measurement range. At low dew/frost points, as much as one half may be lost. As ambient temperature is increased, depression capability increases, resulting in a wider measurement range.

Chilled Mirror Sensors D-1

October 2007

Measurement Range The measurement range of a chilled mirror sensor is defined as the

temperature range over which a stable dew or frost layer can be maintained on the mirror. Note that in order to acquire a dew or frost layer on the mirror, the depression capability of a sensor must extend below its measurement range. The minimum required differential between depression range and measurement range is 5°C (9°F) at nominal dew/frost points, and increases to 10°C to 12°C (18°F to 22°F) at very low frost points.

Measurement range is normally specified at 25°C (77°F) ambient temperature in air at atmospheric pressure. For sensor body temperatures other than 25°C (77°F), measurement range can be estimated by first estimating depression capability, and then decreasing this range according to the minimum required differential. For most gases other than air, the effect on measurement range is negligible. However, gases such as hydrogen or helium, which are more thermally conductive than air , will result in a decrease of several degrees in the measurement range. Measurement range will decrease as gas pressure is increased, because the increased density (and, therefore, increased thermal conductivity) of the gas results in an increased heat load. For air or nitrogen, each 50 psi (3 bar) increase above atmospheric pressure will result in a loss of approximately 2°C (4°F) of depression capability. Conversely, operating under vacuum may result in a small increase.

Other factors influencing sensor selection include temperature and pressure ratings, and whether anticipated dew points will be higher than ambient temperature.

D-2 Chilled Mirror Sensors

Comparing OptiSonde Sensors

Table D-1: Chilled Mirror Sensor Comparison Chart

October 2007

Model

1111H/1111H-GE

Model

D-2

Model 1211H

System Performance

Standard Accuracy* 0.2°C 0.2°C 0.2°C

Cooling Stages 1 2 2

Depression (at 25°C (77°F), 1 atm, in air) 45°C 65°C 65°C

Typical Measurement Range (at given

ambient, 1 atm)

Dew/Frost Point –15° to +25°C –35° to +25°C –35° to +25°C

RH (equivalent) 6% to 100% 1.5% to 100% 1.5% to 100%

Power From OptiSonde From OptiSonde From OptiSonde

Ambient Temperature Range

Pressure Range (psig) –3 to +200 –3 to +150 0 to +300

Auxiliary Cooling No No No

at 25°C

ambient

Functional Characteristics:

–15° to +80°C –25° to +85°C –15° to +100°C

at 25°C

ambient

at 25°C

ambient

Sensor Cavity

Material

*Complete system at 25°C (77°F)

Epoxy-coated

Aluminum

Stainless Steel Stainless Steel

Chilled Mirror Sensors D-3

Appendix E

Theory of Operations and Glossary

October 2007

Theory of Operation The OptiSonde utilizes condensation hygrometry, which is a precise

technique for determining the water vapor content in gases by directly measuring dew point or frost temperatures. Using this technique, a metal mirror is cooled until it reaches a temperature at which a thin layer of condensation begins to form on it. The dew layer is detected optically; the temperature of the mirror is regulated such that the condensed mass is constant. The mirror temperature, measured with a platinum resistance thermometer, is an accurate indicator of the dew or frost point. These hygrometers are widely used as reference standards in many of the world’s metrology laboratories, because the measurement is highly accurate and repeatable.

Hygrometer Function Figure E-1 on page E-2 illustrates how GE Sensing hygrometers

detect and measure dew point. The condensate mirror is illuminated with a solid state, infrared emitter (IR). A photodetector monitors the IR light reflected from the mirror. The photodetector is fully illuminated when the mirror is clear of dew, and it receives less light as dew forms. A separate LED and photodetector pair are used as a known reference to compensate for any thermally induced changes in the OptiSonde components. The photodetectors are arranged in an electrical bridge circuit, the output current of which is proportional to the light reflected from the mirror. The bridge output controls the electrical current to the thermoelectric cooler.

A large bridge current develops when the mirror is dry, causing the mirror to cool toward the dew point. As dew begins to form on the mirror, less light is reflected, and the bridge output decreases. This, in turn, causes a decrease in cooling current. A rate feedback loop within the amplifier ensures critical response, causing the mirror to stabilize at constant mass at a temperature that maintains a thin dew or frost layer on the mirror surface. A precision thermometer element embedded within the mirror directly monitors this dew point temperature.

Theory of Operations and Glossary E-1

October 2007

Hygrometer Calibration The OptiSonde unit can be sent to the National Institute of Standards

and T echnology (NIST) in Gaithersbur g, Maryland for certification o r to any National Standards lab for calibration against their primary humidity standards. A calibrated instrument can then be used as a transfer standard in local laboratories to calibrate lower echelon instruments.

Caution!

Field calibration is not recommended.

Hygrometers used as calibration standards must have the following characteristics:

• The mirror thermometer must have suitable long-term accuracy

(such as that obtained with a platinum resistance thermometer).

Figure E-1: Chilled-Mirror Hygrometer Diagram

E-2 Theory of Operations and Glossary

October 2007

Other Hygrometer Applications

Many GE Sensing chilled mirror hygrometers are used in industrial applications in addition to metrology. The OptiSonde condensation hygrometer is not readily damaged or contaminated by industrial process gases that can degrade other secondary measurement schemes such as saturated salt and polymer-based sensors. If the sensor or sampling components should become contaminated with oils, salts, etc., they can be cleaned without harm to the sensor or impairment to the system accuracy. The performance of the hygrometer can be checked at any time by heating the mirror above the dew point, causing the dew deposit to evaporate, then reclosing the servoloop and checking to see that the system cools and returns to the same dew point.

The GE Sensing OptiSonde condensation sensors cover a wide range of applications limited only by the heat pumping capabilities of the thermoelectrically-cooled mirror.

At high dew points (up to 100°C), the sensor is limited by the thermal properties of the solid state OptiSonde components as well as the thermoelectric heat pump capacity.

In a typical application measuring sub-ambient dew points, a twostage thermoelectrically-cooled mirror can reach a temperature approximately 65°C lower than an ambient (heat sink) temperature of +25°C. The thermoelectric cooler pumps heat from the mirror into the heat sink. By reducing the temperature of the heat sink, even lower dew points can be measured. In meteorological applications where the heat sink temperature is considerably lower, frost points down to –40°C can be monitored.

For lower levels, GE Sensing’s Optica series features four and five stage chilled mirror sensors.

The PACER Cycle GE Sensing has developed and patented a compensation technique

called PACER (Programmable Automatic Contaminant Error Reduction) that is very effective in reducing the Raoult Effect error associated with soluble contaminants, particularly for near-ambient dew points. The OptiSonde is equipped with the PACER cycle as well as AUTO balance as found on earlier models. The user can choose which self-cleaning and balancing routine to run depending on the severity of contamination.

The PACER cycle, diagrammed in Figure E-2 on page E-4, begins with a coalescence period, during which the mirror is cooled well below the dew point of the sample gas, condensing out a large amount of water.

Theory of Operations and Glossary E-3

October 2007

The PACER Cycle (cont.)

Figure E-2: A Typical PACER Cycle

This excess water easily dissolves any water-soluble contaminants. The mirror is then heated. During the heating phase, due to surface tension, the remaining contaminants aggregate into dry “islands”. Empirically, this yields about 80 to 85% clean surface. The reflected light signal is then electronically balanced against the reference. Figure E-3 below illustrates the results.

Before

PACER Cycle

After

PACER Cycle

Figure E-3: Results of the PACER Cycle

E-4 Theory of Operations and Glossary

Glossary

Depression Capability The temperature difference by which the chilled mirror can be

lowered from the ambient temperature.

PACER GE Sensing patented Programmable Automatic Contaminant Error

Reduction system, which consolidates soluble contaminants to reduce their effect on system accuracy (see The PACER Cycle on page E-3).

Parameter A measured quantity available for display by the unit, such as Dew

Point in °C, Humidity in Grams/Kilograms, or Pressure in Bar.

Process Pressure The gas pressure of the system under test. In some applications,

humidity of this gas may be measured at a lower pressure.

Scaling The process of selecting the maximum and minimum output values of

a chosen parameter.

October 2007

Theory of Operations and Glossary E-5

Index

October 2007

Accessory Specifications . . . . . . . . . . . . . . . .A-3

Alarm Outputs

Inner Band Alarm. . . . . . . . . . . . . . . . . . . . 2-7

Outer Band Alarm . . . . . . . . . . . . . . . . . . . 2-7

Set Point Alarm . . . . . . . . . . . . . . . . . . . . . 2-7

Wiring. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6

Alarms

OptiSonde. . . . . . . . . . . . . . . . . . . . . . . . . . 4-5

Analog Outputs

OptiSonde. . . . . . . . . . . . . . . . . . . . . . . . . . 4-3

Troubleshooting . . . . . . . . . . . . . . . . . . . . . 5-9

Wiring. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6

Automatic Cleaning and Balancing

OptiSonde. . . . . . . . . . . . . . . . . . . . . . . . . . 4-9

Balancing a Sensor. . . . . . . . . . . . . . . . . . . . . 3-5

Balancing, Automatic

OptiSonde. . . . . . . . . . . . . . . . . . . . . . . . . . 4-9

Benchtop

Specifications. . . . . . . . . . . . . . . . . . . . . . .A-2

Wiring Input Power . . . . . . . . . . . . . . . . . . 2-2

Wiring Outputs. . . . . . . . . . . . . . . . . . . . . . 2-5

Wiring Sensors. . . . . . . . . . . . . . . . . . . . . . 2-2

Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7

Chilled Mirror Sensor

Comparison Chart . . . . . . . . . . . . . . . . . . .D-3

Chilled Mirror Sensors. . . . . . . . . . . . . . . . . .D-1

Cleaning Sensor Mirror . . . . . . . . . . . . . . . . . 5-1

Cleaning, Automatic

OptiSonde. . . . . . . . . . . . . . . . . . . . . . . . . . 4-9

Communication Parameters

OptiSonde. . . . . . . . . . . . . . . . . . . . . . . . . . 4-7

Contamination

Gaseous Contaminants. . . . . . . . . . . . . . . . 3-7

Minimizing the Effects. . . . . . . . . . . . . . . . 3-8

Mirror Cleanliness . . . . . . . . . . . . . . . . . . . 3-6

Particulate Matter. . . . . . . . . . . . . . . . . . . . 3-6

Water-Soluble Contaminants . . . . . . . . . . . 3-7

Default Settings. . . . . . . . . . . . . . . . . . . . . . . .3-4

Definitions. . . . . . . . . . . . . . . . . . . . . . . . . . . E-5

Depression Capability. . . . . . . . . . . . . . D-1, E-5

Dew Point

Sampling Lines . . . . . . . . . . . . . . . . . . . . .2-11

Supercooled. . . . . . . . . . . . . . . . . . . . . . . . .3-6

Display

“Balance” Displayed. . . . . . . . . . . . . . . . . .5-9

Incorrect Dew Point . . . . . . . . . . . . . . . . . .5-8

Troubleshooting . . . . . . . . . . . . . . . . . . . . .5-7

Electronics Enclosure

Benchtop . . . . . . . . . . . . . . . . . . . . . . . . . . .1-2

Wall-Mount. . . . . . . . . . . . . . . . . . . . . . . . .1-2

Enclosure

Benchtop, Installation . . . . . . . . . . . . . . . . .2-1

Benchtop, Wiring . . . . . . . . . . . . . . . . . . . .2-2

Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-11

Flow Rate . . . . . . . . . . . . . . . . . . . . . . . . . . .2-11

Functional Specifications . . . . . . . . . . . . . . . A-2

Gaseous Contaminants . . . . . . . . . . . . . . . . . .3-7

Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-5

Humidity

Conversion Chart . . . . . . . . . . . . . . . . . . . B-3

Equations. . . . . . . . . . . . . . . . . . . . . . . . . . B-2

Symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . B-1

Humidity Equations

Vapor Pressure . . . . . . . . . . . . . . . . . . . . . B-1

Hygrometer

Applications . . . . . . . . . . . . . . . . . . . . . . . E-3

Calibration. . . . . . . . . . . . . . . . . . . . . . . . . E-2

Diagram. . . . . . . . . . . . . . . . . . . . . . . . . . . E-2

Function . . . . . . . . . . . . . . . . . . . . . . . . . . E-1

Index 1

October 2007

Index (cont.)

Inner Band Alarm. . . . . . . . . . . . . . . . . . . . . .2-7

Inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-3

Installation

Benchtop. . . . . . . . . . . . . . . . . . . . . . . . . . .2-1

Sampling Lines. . . . . . . . . . . . . . . . . . . . .2-10

Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . .2-12

Wall-Mount. . . . . . . . . . . . . . . . . . . . . . . . .2-3

Wall-Mount Wiring. . . . . . . . . . . . . . . . . . .2-4

Logging Data . . . . . . . . . . . . . . . . . . . . . . . . .4-6

Maintenance

Calibration . . . . . . . . . . . . . . . . . . . . . . . . .5-7

Cleaning the Sensor Mirror . . . . . . . . . . . .5-1

Replacing Sensor Mirrors. . . . . . . . . . . . . .5-5

Sample Line . . . . . . . . . . . . . . . . . . . . . . . .3-8

Sensor Optics . . . . . . . . . . . . . . . . . . . . . . .5-1

Testing. . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-7

Troubleshooting . . . . . . . . . . . . . . . . . . . . .5-7

Measurement

Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . D-2

Ranges. . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1

Mirror

Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . .5-1

Flooding . . . . . . . . . . . . . . . . . . . . . . . . . . .3-8

Mirror, Cleaning and Balancing . . . . . . . . . . .5-1

Operation

Helpful Hints . . . . . . . . . . . . . . . . . . . . . . . 3-5

Normal. . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

OptiSonde . . . . . . . . . . . . . . . . . . . . . . . . . 3-2

Theory of . . . . . . . . . . . . . . . . . . . . . . . . . . E-1

OptiSonde

Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5

Analog Outputs . . . . . . . . . . . . . . . . . . . . . 4-3

Communication Parameters. . . . . . . . . . . . 4-7

Display Screen. . . . . . . . . . . . . . . . . . . . . . 3-2

Operation. . . . . . . . . . . . . . . . . . . . . . . . . . 3-2

Programmable Functions. . . . . . . . . . . . . . 4-3

Programming. . . . . . . . . . . . . . . . . . . . . . . 4-1

OptiSonde Sensor Comparison . . . . . . . . . . .D-3

Outer Band Alarm . . . . . . . . . . . . . . . . . . . . . 2-7

Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

PACER

Cycle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-3

Definition. . . . . . . . . . . . . . . . . . . . . . . . . . E-5

Parameter Definition . . . . . . . . . . . . . . . . . . . E-5

Particulate Contaminants. . . . . . . . . . . . . . . . 3-6

Performance. . . . . . . . . . . . . . . . . . . . . . . . . . A-1

Pressure

Effects . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-8

Vapor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-1

Process Pressure

Definition. . . . . . . . . . . . . . . . . . . . . . . . . . E-5

Programming

OptiSonde . . . . . . . . . . . . . . . . . . . . . . . . . 4-1

2 Index

Index (cont.)

October 2007

Sample Line Maintenance . . . . . . . . . . . . . . . 3-8

Sampling Lines. . . . . . . . . . . . . . . . . . 2-10, 2-11

Scaling, Definition . . . . . . . . . . . . . . . . . . . . .E-5

Sensor Mirror, Cleaning and Balancing. . . . . 5-1

Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

Balancing . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5

Chilled Mirror . . . . . . . . . . . . . . . . . . . . . .D-1

Cleaning the Mirror . . . . . . . . . . . . . . . . . . 5-1

Comparison Chart . . . . . . . . . . . . . . . . . . .D-3

Connecting . . . . . . . . . . . . . . . . . . . . . . . . 2-13

Dew Point. . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

Heat Transfer . . . . . . . . . . . . . . . . . . . . . . 2-10

Information. . . . . . . . . . . . . . . . . . . . . . . . . 2-9

Installation . . . . . . . . . . . . . . . . . . . . 2-9, 2-12

Maintenance. . . . . . . . . . . . . . . . . . . . 5-1, 5-5

Model 1111H . . . . . . . . . . . . . . . . . . . . . . 2-12

Model 1211H . . . . . . . . . . . . . . . . . . . . . . 2-13

Model D-2 . . . . . . . . . . . . . . . . . . . . . . . . 2-12

Pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

Replacing Mirrors . . . . . . . . . . . . . . . . . . . 5-5

Temperature . . . . . . . . . . . . . . . . . . . . . . . . 1-3

Serial Outputs

Troubleshooting . . . . . . . . . . . . . . . . . . . . . 5-9

Wiring. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8

Service Required . . . . . . . . . . . . . . . . . . . . . . 5-7

Set Point Alarm . . . . . . . . . . . . . . . . . . . . . . . 2-7

Specifications

Functional. . . . . . . . . . . . . . . . . . . . . . . . . .A-2

Optional Accessories . . . . . . . . . . . . . . . . .A-3

Performance . . . . . . . . . . . . . . . . . . . . . . . .A-1

Physical (Benchtop) . . . . . . . . . . . . . . . . . .A-2

Physical (Wall-Mount). . . . . . . . . . . . . . . .A-2

Status Line Indications . . . . . . . . . . . . . . . . . . 3-3

Supercooled Dew Points . . . . . . . . . . . . . . . . 3-6

System

Components . . . . . . . . . . . . . . . . . . . . . . . . 1-3

Testing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-7

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . .5-7

“Balance” on Display . . . . . . . . . . . . . . . . .5-9

“Service” Required . . . . . . . . . . . . . . . . . . .5-7

Incorrect Dew Point Display. . . . . . . . . . . .5-8

No Analog Output. . . . . . . . . . . . . . . . . . . .5-9

No Display . . . . . . . . . . . . . . . . . . . . . . . . .5-7

No Serial Output . . . . . . . . . . . . . . . . . . . . .5-9

Vapor Pressure . . . . . . . . . . . . . . . . . . . . . . . B-1

Wall-Mount

Installation. . . . . . . . . . . . . . . . . . . . . . . . . .2-3

Specifications . . . . . . . . . . . . . . . . . . . . . . A-2

Wiring Input Power. . . . . . . . . . . . . . . . . . .2-5

Wiring Outputs . . . . . . . . . . . . . . . . . . . . . .2-5

Water-Soluble Contaminants . . . . . . . . . . . . . 3 -7

Wiring

Alarm Outputs. . . . . . . . . . . . . . . . . . . . . . .2-6

Analog Outputs. . . . . . . . . . . . . . . . . . . . . .2-6

Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-5

Serial Output. . . . . . . . . . . . . . . . . . . . . . . .2-8

Wall-Mount. . . . . . . . . . . . . . . . . . . . . . . . .2-4

Index 3

USA

1100 Technology Park Drive Billerica, MA 01821-4111 Web: www.gesensing.com

Ireland

Shannon Industrial Estate Shannon, County Clare Ireland

GE Sensing OptiSonde Operating Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Chapter 1

Features and Capabilities

Introduction The GE Sensing OptiSonde™ is a multi-purpose chilled-mirror

Electronics Enclosure The OptiSonde is available in two configurations:

Front Panel The OptiSonde’ s fron t panel is shown in Figure 1 -2 below. The panel

Figure 1-2: OptiSonde Benchtop Version

Input/Output Capability Available inputs and outputs include the following:

The System

System Components A complete OptiSonde system consists of the following items:

Sensors The OptiSonde is configured with a chilled-mirror dew point sensor.

Dew Point Sensors • Model 1111H — Dew point single-stage sensor with 1” M-NDT

Temperature Sensor • Model T-100E

Chapter 2

Installation

Introduction This chapter explains the installation of the benchtop and wall-mount

Benchtop Installation

Mounting the Benchtop

Figure 2-1: OptiSonde Benchtop Dimensions

Wiring the Benchtop

Figure 2-2: OptiSonde Benchtop Rear Panel

Figure 2-3: OptiSonde DC Option Rear Panel

Wall-Mount Installation The OptiSonde Wall-Mount unit is designed to mount on a flat,

Mounting the Wall-Mount

Figure 2-4: OptiSonde Wall-Mount Dimensions

Figure 2-5: OptiSonde Wall-Mount - Mounting Hole Locations

Wiring the Wall-Mount Caution!

Figure 2-6: Wall-Mount Wiring Entrance Locations

Input Power Power wiring enters the case through a gland fitting at the lower right

Figure 2-7: Wall-Mount AC Power Wiring

Output Wiring The benchtop outputs are connected to removable terminal blocks o n

Figure 2-8: Wall-Mount Input/Output Terminal Blocks

Analog Outputs Note: When the OptiSonde is being programmed, the analog outputs

Alarm Outputs The alarm output connects to the contacts of a 7-Amp, Form C

Figure 2-9: Set Point Alarm

Figure 2-10: Inner Band Alarm

Figure 2-11: Outer Band Alarm

Serial Output The Serial Output connector is located on the rear panel of the

Sensor Information GE Sensing produces a variety of sensors compatible with the

Sampling Lines Keep the length of sample tubing between the source and the sensor

Ensuring Heat Transfer Be sure the sensor has an adequate heat sink when operating in hot

Filter Requirements If the gas to be monitored is free from particulates and hydrocarbon

Flow Rate It is important to have adequate flow through the sensor. Too little

Sensor Installation This section provides installation details for the GE Sensing line of

Model 1111H Sensor The Model 1111H is an open-type sensor (see Figure 2-12 below )

Figure 2-12: Model 1111H Sensor for Duct Mounting

Model D-2 Sensor The Model D-2 is a general purpose, two-stage sensor with 65°C

Figure 2-13: Model D-2 Sensor

Model 1211H Sensor The Model 1211H is a two-stage sensor with 65°C (117°F) of

Connecting the Sensors Dew point and temperature sensors provided by GE Sensing for the

Chapter 3

Operation

Introduction Operating instructions fall into three categories:

Normal Operation Normal operation of the OptiSonde is very simple. First, apply power

Operating the OptiSonde The parameters chosen during programming are displayed

Figure 3-1: Typical OptiSonde Display Screen

Figure 3-2: Function Control Screen

Status Line Indications The status line at the top of the display shows whether the unit is

Table 3-1: Status Indications

Factory Default Settings As shipped from the factory, the OptiSonde is normally programmed

Table 3-2: Factory Default Values

Sensor Balancing During normal operation, the sensor mirror surface may become

Helpful Hints For Operating the Unit

Supercooled Dew Points Slightly below the freezing point, water can exist in a supercooled

Contamination

Mirror Flooding If there is an abrupt transition from dry to moist conditions

Sample Line Maintenance Contaminated sample lines slow the unit’s response time and can

Pressure Effects If the pressure of the gas is increased or reduced from atmospheric

Chapter 4

Programming the OptiSonde

Introduction The OptiSonde can be easily programmed to choose the data to be

Figure 4-1: OptiSonde Typical Data Display

Table 4-1: Programming Functions

Programming Technique The functions of the six keys to the right of the display change

Figure 4-2: Typical Analog Outputs Programming Screen

Programmable Functions

Display For display, the menu first requires that you select Line 1 or Line 2.
