Data Sheet

QBVW025A0B Barracuda* Series; DC-DC Converter Power Modules

36-75Vdc Input; 12.0Vdc, 25.0A, 300W Output

RoHS Compliant

Applications

 Distributed power architectures  Intermediate bus voltage applications  Servers and storage applications  Networking equipment including Power over Ethernet

(PoE)

 Fan assemblies and other systems requiring a tightly

regulated output voltage

Options

 Negative Remote On/Off logic (1=option code, factory

preferred)

 Auto-restart after fault shutdown (4=option code,

factory preferred)

 Remote Sense and Output Voltage Trim (9=option

code)

 Base plate option (-H=option code)  Passive Droop Load Sharing (-P=option code)

Features

 Compliant to RoHS II EU “Directive 2011/65/EU (-Z versions)  Compliant to REACH Directive (EC) No 1907/2006  High and flat efficiency profile – >95.5% at 12V

100% output

 Wide Input voltage range: 36-75V  Delivers up to 25A  Fully very tightly regulated output voltage  Low output ripple and noise  Industry standard, DOSA Compliant Quarter brick:

58.4 mm x 36.8 mm x 11.7 mm (2.30 in x 1.45 in x 0.46 in)

 Constant switching frequency  Positive Remote On/Off logic

 Output over current/voltage protection  Over temperature protection  Wide operating temperature range (-40°C to 85°C)

 ANSI/ UL

No.60950-1-07, Second Edition + A1:2011 (MOD) Certified IEC 60950-1:2005 (2nd edition) + A1:2009 and EN 60950-1:2006 + A11:2009 + A1:2010 + A12:2011, and VDE‡ 0805-1 Licensed

 CE mark to 2006/96/EC directive  Meets the voltage and current requirements for ETSI 300-

132-2 and complies with and licensed for Basic insulation rating per EN60950-1

 2250 Vdc Isolation tested in compliance with IEEE 802.3

standards

 ISO** 9001 and ISO14001 certified manufacturing facilities

60950-1-2011 Recognized, CAN/CSA† C22.2

output current

, 40% load to

PoE

Description

The QBVW025A0B Barracuda series of dc-dc converters are a new generation of fully regulated DC/DC power modules designed to support 12Vdc intermediate bus applications where multiple low voltages are subsequently generated using point of load (POL) converters, as well as other application requiring a tightly regulated output voltage. The QBVW025A0B series operate from an input voltage range of 36 to 75Vdc and provide up to 25A output current at output voltages of 12V DOSA compliant quarter brick. The converter incorporates digital control, synchronous rectification technology, a fully regulated control topology, and innovative packaging techniques to achieve efficiency exceeding 96% at 12V output. This leads to lower power dissipations such that for many applications a heat sink is not required. Standard features include on/off control, output overcurrent and over voltage protection, over temperature protection, input under and over voltage lockout.

The output is fully isolated from the input, allowing versatile polarity configurations and grounding connections. Built-in filtering for both input and output minimizes the need for external filtering.

* Trademark of General Electric Company # UL is a registered trademark of Underwriters Laboratories, Inc. † CSA is a registered trademark of Canadian Standards Association. ‡ VDE is a trademark of Verband Deutscher Elektrotechniker e.V.

§ This product is intended for integration into end-user equipment . All of the required procedures of end-use equipment should be followed. ¤ IEEE and 802 are registered trademarks of the Institute of Electrical and Electronics Engineers, Incorporated. ** ISO is a registered trademark of the International Organization of Standards.

in an industry standard,

Data Sheet

QBVW025A0B Barracuda™ Series; DC-DC Converter Power Modules

36-75Vdc Input; 12.0Vdc, 25.0A, 300W Output

Absolute Maximum Ratings

Stresses in excess of the absolute maximum ratings can cause permanent damage to the device. These are absolute stress ratings only, functional operation of the device is not implied at these or any other conditions in excess of those given in the operations sections of the Data Sheet. Exposure to absolute maximum ratings for extended periods can adversely affect device reliability.

Parameter Device Symbol Min Max Unit

Input Voltage*

Continuous V

Operating transient ≤ 100mS 100 Vdc

Non- operating continuous V

Operating Ambient Temperature All T

(See Thermal Considerations section)

Storage Temperature All T

I/O Isolation Voltage (100% factory Hi-Pot tested) All

* Input over voltage protection will shutdown the output voltage when the input voltage exceeds threshold level.

stg

 

Electrical Specifications

Unless otherwise indicated, specifications apply over all operating input voltage, resistive load, and temperature conditions.

Parameter Device Symbol Min Typ Max Unit

Operating Input Voltage VIN 36 48 75 Vdc

Maximum Input Current (VIN=0V to 75V, IO=I

Input No Load Current

(VIN = V

IN, nom

Input Stand-by Current

(VIN = V

IN, nom

External Input Capacitance All 100 - - μF

Inrush Transient All I2t - - 1 A2s

Input Terminal Ripple Current

(Measured at module input pin with maximum specified input capacitance and ൏ 500uH inductance between voltage source and input capacitance)

5Hz to 20MHz, VIN= 48V, IO= I

Input Reflected Ripple Current, peak-to-peak (5Hz to 20MHz, 12μH source impedance; V Figure 11)

)

O, max

, IO = 0, module enabled)

, module disabled)

Omax

= 48V, IO= I

Omax

; see

All I

All - 350 - mA

All - 40 - mA

IN,max

IN,No load

IN,stand-by

-0.3 75 Vdc

80 100 Vdc

-40 85 °C

-55 125 °C

2250 Vdc

- - 9 Adc

80 mA

22 mA

rms

p-p

Input Ripple Rejection (120Hz) All - 25 - dB

CAUTION: This power module is not internally fused. An input line fuse must always be used.

This power module can be used in a wide variety of applications, ranging from simple standalone operation to an integrated part of sophisticated power architecture. To preserve maximum flexibility, internal fusing is not included, however, to achieve maximum safety and system protection, always use an input line fuse. The safety agencies require a fast-acting fuse with a maximum rating of 30 A in the ungrounded input lead of the power supply (see Safety Considerations section). Based on the information provided in this Data Sheet on inrush energy and maximum dc input current, the same type of fuse with a lower rating can be used. Refer to the fuse manufacturer’s Data Sheet for further information.

Data Sheet

QBVW025A0B Barracuda™ Series; DC-DC Converter Power Modules

36-75Vdc Input; 12.0Vdc, 25.0A, 300W Output

Electrical Specifications (continued)

Unless otherwise indicated, specifications apply over all operating input voltage, resistive load, and temperature conditions.

Parameter Device Symbol Min Typ Max Unit

Output Voltage Set-point (VIN=V

Output Voltage (Over all operating input voltage (40V to 75V), resistive load, and temperature conditions until end of life)

Output Voltage (VIN=36V, TA = 25ºC) All V

Output Regulation[V

Line (VIN= V

Load (IO=I

O, min

IN, min

to I

= 40V]

IN, min

to V

)

IN, max

to V

)

IN, max

)

O, max

)

O, max

), Intentional Droop

O, max

Temperature (TA = -40ºC to +85ºC) All

Output Ripple and Noise on nominal output

(VIN=V

IN, nom

and IO=I

O, min

to I

RMS (5Hz to 20MHz bandwidth) All

Peak-to-Peak (5Hz to 20MHz bandwidth) All

External Output Capacitance

>5000uF, IO must be < 50% I

For C

Output Current All I

Output Current Limit Inception All I

Efficiency (VIN=V

IN, nom

, TA=25°C)

IO=100% I

IO=40% I

O, max , VO

O, max

= V

to 100% I

All η 96.0 %

O,set

O, max , VO

Switching Frequency f

Dynamic Load Response

dIO/dt=1A/10s; Vin=Vin,

nom

(Tested with a 1.0μF ceramic, a 10μF tantalum, and 470μF capacitor and across the load.)

Load Change from IO = 50% to 75% of I Peak Deviation Settling Time (V

<10% peak deviation)

Load Change from IO = 75% to 50% of I Peak Deviation Settling Time (V

<10% peak deviation)

General Specifications

, IO=12.5A, TA =25°C) All V

IN,nom

All w/o -P V

-P Option V

All w/o 9

option

All w/ 9

option

All w/o P or

9 option

All w/ 9

tion

All w/ P

Option

)

O, max

during T

rise

All C

O, set

O, max

O, lim

11.97 12.00 12.03 V

11.76

11.68

11.15



 



 

0.2

0.5

0.2

1.2

0.40

200



12.24 V

12.32 V



% V



2 % V

 

10,000 μF

0 25 Adc



Vdc

O, set

rms

pk-pk

= V

All η 95.5 %

O,set

150 kHz

; TA=25°C;

O,max

All

 __

__ __

300 700

 __

s

Parameter Device Typ Unit

Calculated Reliability Based upon Telcordia SR-332 Issue 2: Method

I, Case 1, (I

=80%I

, TA=40°C, Airflow = 200 lfm), 90%

O, max

confidence

MTBF All 3,598,391 Hours

FIT All 277.9 109/Hours

Weight – Open Frame 47.4 (1.67) g (oz.)

Weight – with Base plate option 66.4 (2.34) g (oz.)

Data Sheet

QBVW025A0B Barracuda™ Series; DC-DC Converter Power Modules

36-75Vdc Input; 12.0Vdc, 25.0A, 300W Output

Isolation Specifications

Parameter Symbol Min Typ Max Unit

Isolation Capacitance C

Isolation Resistance R

iso



1000

 



Feature Specifications

Unless otherwise indicated, specifications apply over all operating input voltage, resistive load, and temperature conditions. See Feature Descriptions for additional information.

Parameter Device Symbol Min Typ Max Unit

Remote On/Off Signal Interface

(VIN=V Negative Logic: device code suffix “1”

Logic Low = module On, Logic High = module Off

Positive Logic: No device code suffix required Logic Low = module Off, Logic High = module On

Logic Low Specification

On/Off Thresholds:

Remote On/Off Current – Logic Low (Vin =100V) All I

Turn-On Delay and Rise Times (IO=I

T of Vin with Remote On/Off set to On (Enable with Vin); or operation of Remote On/Off from Off to On with Vin already applied for at least 150 milli-seconds (Enable with on/off). * Increased T

Load Sharing Current Balance (difference in output current across all modules with outputs in parallel, no load to full load)

Remote Sense Range

Output Voltage Adjustment range

Output Overvoltage Protection

Overtemperature Protection (See Feature Descriptions) Input Undervoltage Lockout

Input Overvoltage Lockout

to V

IN, min

, Signal referenced to V

IN, max

terminal)

IN-

Logic Low Voltage All V

Logic High Voltage – (Typ = Open Collector) All V

Logic High maximum allowable leakage current

= 2.0V)

on/off

All I

Maximum voltage allowed on On/Off pin All V

)

O, max

All w/o P

=Time until VO = 10% of V

delay

from either application

O,set

option

All w/o P

option

All w/ P

option

due to startup for parallel modules.

delay

All w/ P

option

=Time for VO to rise from 10% to 90% of V

rise

>5000uF, IO must be < 50% I * Increased T

when pre-bias Vo exists at startup for

rise

O, max

during T

parallel modules.

, For C

O,set

rise

All w/o P

option

All w/ P

option

P Option

All w/ 9

option

All w/ 9

option

All w/o 9

option

All w/ 9

option

All T

Turn-on Threshold (Default)

Turn-off Threshold (Default)

Turn-on Threshold (Default)

on/off

Enable

delay,

with Vin

delay, Enable

with on/off

Enable

delay,

with Vin

delay, Enable

with on/off

rise

diff

Sense

8.1

O, set

14.5

O,limit

ref

280

-0.3

2.0

  

 

O,set

+2.5V



140

310 μA

0.8 Vdc

14.5 Vdc

10 μA

14.5 Vdc

150 ms

10 ms

180* ms

40* ms

15 ms

300* ms

3 A

0.5 Vdc

13.2 Vdc

17.0 Vdc

+5.0V Vdc

O,set



33 35 36 Vdc

31 33 34 Vdc



76 79

 

MΩ

°C

Vdc

Data Sheet

QBVW025A0B Barracuda™ Series; DC-DC Converter Power Modules

36-75Vdc Input; 12.0Vdc, 25.0A, 300W Output

Characteristic Curves, 12Vdc Output

The following figures provide typical characteristics for the QBVW025A0B (12V, 25A) at 25ºC. The figures are identical for either positive or negative Remote On/Off logic.

(A)

INPUT CURRENT, I

EFFCIENCY, η (%)

INPUT VOLTAGE, VO (V)

OUTPUT CURRENT, I

(A)

Figure 1. Typical Input Characteristic. Figure 2. Typical Converter Efficiency Vs. Output Current.

(V) (200mV/div)

(V) (50mV/div)

OUTPUT VOLTAGE,

(A) (5A/div) V

TIME, t (2s/div)

Figure 3. Typical Output Ripple and Noise, Io = I

o,max

OUTPUT CURRENT OUTPUT VOLTAGE

Figure 4. Typical Transient Response to 0.1A/µs Step Change

TIME, t (500 μs/div)

in Load from 50% to 75% to 50% of Full Load, Co=470µF and 48 Vdc Input.

(V) (20V/div)

(V) (5V/div) V

OUTPUT VOLTAGE INPUT VOLTAGE

TIME, t (20 ms/div) TIME, t (5 ms/div)

Figure 5. Typical Start-Up Using Vin with Remote On/Off enabled, negative logic version shown.

(V)(2V/div)

ON/OFF

(V) (5V/div) V

OUTPUT VOLTAGE On/Off VOLTAGE

Figure 6. Typical Start-Up Using Remote On/Off with Vin applied, negative logic version shown.

Data Sheet

QBVW025A0B Barracuda™ Series; DC-DC Converter Power Modules

36-75Vdc Input; 12.0Vdc, 25.0A, 300W Output

Characteristic Curves, 12Vdc Output (continued)

(V)

OUTPUT VOLTAGE, V

INPUT VOLTAGE, Vin (V) OUTPUT CURRENT, IO (A)

Figure 7. Typical Output Voltage Regulation vs. Input Voltage.

(V)

OUTPUT VOLTAGE, V

OUTPUT CURRENT, IO (A)

Figure 9. Typical Output Voltage regulation vs. Input Voltage for the –P Option.

OUTPUT VOLTAGE, V

Figure 8. Typical Output Voltage Regulation vs. Output Current .

Figure 10. Typical Output Voltage Regulation vs. Output Current for the –P Option.

Data Sheet

QBVW025A0B Barracuda™ Series; DC-DC Converter Power Modules

36-75Vdc Input; 12.0Vdc, 25.0A, 300W Output

Test Configurations

Note: Measure input reflected-ripple current with a simulated source inductance (LTEST) of 12 µH. Capacitor CS offsets possible battery impedance. Measure current as shown above.

Figure 11. Input Reflected Ripple Current Test Setup.

Note: Use a 1.0 µF ceramic capacitor and a 10 µF aluminum or tantalum capacitor. Scope measurement should be made using a BNC socket. Position the load between 51 mm and 76 mm (2 in. and 3 in.) from the module.

Figure 12. Output Ripple and Noise Test Setup.

CONTACT AND

DISTRIBUTION LOSSES

SUPPL Y

CONTA CT

RESISTANCE

Note: All measurements are taken at the module terminals. When socketing, place Kelvin connections at module terminals to avoid measurement errors due to socket contact resistance.

(+)

(–)

LOAD

Design Considerations

Input Source Impedance

The power module should be connected to a low ac-impedance source. Highly inductive source impedance can affect the stability of the power module. For the test configuration in Figure 11, a 100μF electrolytic capacitor, C (ESR<0.7 at 100kHz), mounted close to the power module helps ensure the stability of the unit.

Safety Considerations

For safety-agency approval of the system in which the power module is used, the power module must be installed in compliance with the spacing and separation requirements of the end-use safety agency standard, i.e., UL60950-1 2 CSA C22.2 No. 60950-1 2 Ed.

If the input source is non-SELV (ELV or a hazardous voltage greater than 60 Vdc and less than or equal to 75Vdc), for the module’s output to be considered as meeting the requirements for safety extra-low voltage (SELV), all of the following must be true:

 The input source is to be provided with reinforced

insulation from any other hazardous voltages, including the ac mains.

 One V

pin and one V

the input and output pins are to be kept floating.

 The input pins of the module are not operator accessible.  Another SELV reliability test is conducted on the whole

system (combination of supply source and subject module), as required by the safety agencies, to verify that under a single fault, hazardous voltages do not appear at the module’s output.

Note: Do not ground either of the input pins of the module

without grounding one of the output pins. This may allow a non-SELV voltage to appear between the output pins and ground.

The power module has safety extra-low voltage (SELV) outputs when all inputs are SELV.

The input to these units is to be provided with a maximum 30 A fast-acting (or time-delay) fuse in the ungrounded input lead.

Ed., and VDE0805-1 EN60950-1 2nd

pin are to be grounded, or both

OUT

Ed.,

Figure 13. Output Voltage and Efficiency Test Setup.

Data Sheet

QBVW025A0B Barracuda™ Series; DC-DC Converter Power Modules

36-75Vdc Input; 12.0Vdc, 25.0A, 300W Output

Feature Descriptions

Overcurrent Protection

To provide protection in a fault output overload condition, the module is equipped with internal current-limiting circuitry and can endure current limiting continuously. If the overcurrent condition causes the output voltage to fall greater than 4.0V from V The overcurrent latch is reset by either cycling the input power or by toggling the on/off pin for one second. If the output overload condition still exists when the module restarts, it will shut down again. This operation will continue indefinitely until the overcurrent condition is corrected.

A factory configured auto-restart option (with overcurrent and overvoltage auto-restart managed as a group) is also available. An auto-restart feature continually attempts to restore the operation until fault condition is cleared.

Remote On/Off

The module contains a standard on/off control circuit reference to the V logic options are available. Positive logic remote on/off turns the module on during a logic-high voltage on the ON/OFF pin, and off during a logic low. Negative logic remote on/off turns the module off during a logic high, and on during a logic low. Negative logic, device code suffix "1," is the factory-preferred configuration. The On/Off circuit is powered from an internal bias supply, derived from the input voltage terminals. To turn the power module on and off, the user must supply a switch to control the voltage between the On/Off terminal and the V terminal (V equivalent (see Figure 14). A logic low is V The typical I Terminal=0.3V) is 147µA. The switch should maintain a logiclow voltage while sinking 310µA. During a logic high, the maximum V maximum allowable leakage current of the switch at V

2.0V is TBDµA. If using an external voltage source, the maximum voltage V V

If not using the remote on/off feature, perform one of the following to turn the unit on:

For negative logic, short ON/OFF pin to V For positive logic: leave ON/OFF pin open.

Figure 14. Remote On/Off Implementation.

Output Overvoltage Protection

The module contains circuitry to detect and respond to output overvoltage conditions. If the overvoltage condition causes the

, the module will shut down and remain latched off.

o,set

(-) terminal. Two factory configured remote on/off

). The switch can be an open collector or

(-) terminal.

on/off

during a logic low (Vin=48V, On/Off

on/off

generated by the power module is 8.2V. The

on/off

on the pin is 14.5V with respect to the

on/off

= -0.3V to 0.8V.

on/off

(-).

output voltage to rise above the limit in the Specifications Table, the module will shut down and remain latched off. The overvoltage latch is reset by either cycling the input power, or by toggling the on/off pin for one second. If the output overvoltage condition still exists when the module restarts, it will shut down again. This operation will continue indefinitely until the overvoltage condition is corrected.

Overtemperature Protection

These modules feature an overtemperature protection circuit to safeguard against thermal damage. The circuit shuts down the module when the maximum device reference temperature is exceeded. The module will automatically restart once the reference temperature cools by ~25°C.

Input Under/Over voltage Lockout

At input voltages above or below the input under/over voltage lockout limits, module operation is disabled. The module will begin to operate when the input voltage level changes to within the under and overvoltage lockout limits.

Load Sharing

For higher power requirements, the QBVW025A0 power module offers an optional feature for parallel operation (-P Option code). This feature provides a precise forced output voltage

(-)

load regulation droop characteristic. The output set point and droop slope are factory calibrated to insure optimum matching of multiple modules’ load regulation characteristics. To implement load sharing, the following requirements should be followed:

 The V

(+) and V

OUT

connected together. Balance the trace resistance for each module’s path to the output power planes, to insure best load sharing and operating temperature balance.

must remain between 40Vdc and 75Vdc for droop sharing

 V

to be functional.

 These modules contain means to block reverse current flow

upon start-up, when output voltage is present from other parallel modules, thus eliminating the requirement for external output ORing devices. Modules with the –P option will self determine the presence of voltage on the output from other operating modules, and automatically increase its Turn On delay, T Specifications Table.

 When parallel modules startup into a pre-biased output, e.g.

partially discharged output capacitance, the T automatically increased, as specified in the Feature Specifications Table, to insure graceful startup.

 Insure that the load is <50% I

all parallel modules have started (load full start > module

time max + T

delay

 If fault tolerance is desired in parallel applications, output

ORing devices should be used to prevent a single module failure from collapsing the load bus.

(-) pins of all parallel modules must be

OUT

, as specified in the Feature

delay

(for a single module) until

O,MAX

time).

rise











Data Sheet

QBVW025A0B Barracuda™ Series; DC-DC Converter Power Modules

36-75Vdc Input; 12.0Vdc, 25.0A, 300W Output

Feature Descriptions (continued)

Remote Sense (9 Option Code)

Remote sense minimizes the effects of distribution losses by regulating the voltage at the remote-sense connections (See Figure 15). The SENSE(-) pin should be always connected to V ).The voltage between the remote-sense pins and the output terminals must not exceed the output voltage sense range given in the Feature Specifications table:

(+) – VO(–)] – [SENSE(+) ]  0.5 V

The amount of power delivered by the module is defined as the voltage at the output terminals multiplied by the output current. When using remote sense and trim, the output voltage of the module can be increased, which at the same output current would increase the power output of the module. Care should be taken to ensure that the maximum output power of the module remains at or below the maximum rated power (Maximum rated power = Vo,set x Io,max).

Figure 15. Circuit Configuration for remote sense.

Trim, Output Voltage Adjust (9 Option Code)

Trimming allows the output voltage set point to be increased or decreased; this is accomplished by connecting an external resistor between the TRIM pin and either the V

(-) pin.

VO(+)

QBVW033A0

TRIM

VO(-)

Figure 16. Circuit Configuration to Trim Output Voltage.

Connecting an external resistor (R and the Vo(-) (or Sense(-)) pin decreases the output voltage set point. To maintain set point accuracy, the trim resistor tolerance should be ±1.0%.

(+) pin or the

trim-up

trim-down

) between the TRIM pin

trim-down

LOAD

The following equation determines the required external resistor value to obtain a percentage output voltage change of ∆%

511



(–

Where

 



 





downtrim











desiredseto







seto









22.10

 

100%

For example, to trim-down the output voltage of the 12V nominal module by 20% to 9.6V, Rtrim-down is calculated as follows:

20%

511





downtrim





downtrim

Connecting an external resistor (R and the V

(+) (or Sense (+)) pin increases the output voltage set





3.15

trim-up



22.10

 

kR

) between the TRIM pin

point. The following equations determine the required external resistor value to obtain a percentage output voltage change of ∆%:

Where







uptrim

 

 



 

,seto



seto



%)100(11.5

511





%225.1



setodesired



100%



 



22.10

For example, to trim-up the output voltage of the 12V module by 5% to 12.6V, R





uptrim

is calculated is as follows:

trim-up

 





5225.1



uptrim



511

)5100(0.1211.5



22.10



8.938

The voltage between the Vo(+) and Vo(–) terminals must not exceed the minimum output overvoltage protection value shown in the Feature Specifications table. This limit includes any increase in voltage due to remote-sense compensation and output voltage set-point adjustment trim.

Although the output voltage can be increased by both the remote sense and by the trim, the maximum increase for the output voltage is not the sum of both. The maximum increase is the larger of either the remote sense or the trim. The amount of power delivered by the module is defined as the voltage at the output terminals multiplied by the output current. When using remote sense and trim, the output voltage of the module can be increased, which at the same output current would increase the power output of the module. Care should be taken to ensure that the maximum output power of the module remains at or below the maximum rated power (Maximum rated power = V

O,set

x I

O,max





 





 

Data Sheet

QBVW025A0B Barracuda™ Series; DC-DC Converter Power Modules

36-75Vdc Input; 12.0Vdc, 25.0A, 300W Output

Feature Descriptions (continued)

Thermal Considerations

The thermal data presented here is based on physical measurements taken in a wind tunnel, using automated thermo-couple instrumentation to monitor key component temperatures: FETs, diodes, control ICs, magnetic cores, ceramic capacitors, opto-isolators, and module pwb conductors, while controlling the ambient airflow rate and temperature. For a given airflow and ambient temperature, the module output power is increased, until one (or more) of the components reaches its maximum derated operating temperature, as defined in IPC-9592B. This procedure is then repeated for a different airflow or ambient temperature until a family of module output derating curves is obtained.

Figure 17. Location of the thermal reference temperature TH.

The power modules operate in a variety of thermal environments and sufficient cooling should be provided to help ensure reliable operation.

Thermal considerations include ambient temperature, airflow, module power dissipation, and the need for increased reliability. A reduction in the operating temperature of the module will result in an increase in reliability.

Heat-dissipating components are mounted on the top side of the module. Heat is removed by conduction, convection and radiation to the surrounding environment. Proper cooling can be verified by measuring the thermal reference (TH

or TH2). Peak temperature occurs at the position indicated

in Figure 17 and 18. For reliable operation this temperature should not exceed TH reliability you can limit this temperature to a lower value.

=125°C or TH2=105°C. For extremely high

temperature

Figure 18. Location of the thermal reference temperature TH

for Base plate module.

The output power of the module should not exceed the rated power for the module as listed in the Ordering Information table.

Please refer to the Application Note “Thermal Characterization Process For Open-Frame Board-Mounted Power Modules” for a detailed discussion of thermal aspects including maximum device temperatures.

Heat Transfer via Convection

Increased airflow over the module enhances the heat transfer via convection. The thermal derating of figure 19- 23 shows the maximum output current that can be delivered by each module in the indicated orientation without exceeding the maximum TH (T

) for air flows of, Natural Convection, 1 m/s (200 ft./min), 2

m/s (400 ft./min).

The use of Figure 19 is shown in the following example:

Example

What is the minimum airflow necessary for a QBVW025A0B operating at V maximum ambient temperature of 70 °C in transverse orientation.

Solution: Given: V Determine required airflow (V) (Use Figure 19: V = 0.5m/s (100 LFM) or gre

temperature versus local ambient temperature

= 48 V, an output current of 20A, and a

= 48V, IO = 20A, TA = 60 °C

Data Sheet

QBVW025A0B Barracuda™ Series; DC-DC Converter Power Modules

36-75Vdc Input; 12.0Vdc, 25.0A, 300W Output

Thermal Considerations (continued)

(A)

OUTPUT CURRENT, I

Figure 19. Output Current Derating for the Open Frame QBVW025A0B in the Transverse Orientation; Airflow Direction from Vin(-) to Vin(+); Vin = 48V.

(A)

OUTPUT CURRENT, I

Figure 20. Output Current Derating for the Base plate QBVW025A0B-H in the Transverse Orientation; Airflow Direction from Vin(-) to Vin(+); Vin = 48V.

LOCAL AMBIENT TEMPERATURE, TA (C)

OUTPUT CURRENT, I

Figure 22. Output Current Derating for the Base plate QBVW025A0B-H with 0.5” heatsink in the Transverse Orientation; Airflow Direction from Vin(-) to Vin(+); Vin = 48V

(A)

OUTPUT CURRENT, I

Figure 23. Output Current Derating for the Base plate QBVW025A0B-H with 1.0” heatsink in the Transverse Orientation; Airflow Direction from Vin(-) to Vin(+); Vin = 48V.

LOCAL AMBIENT TEMPERATURE, TA (C)

(A)

OUTPUT CURRENT, I

Figure 21. Output Current Derating for the Base plate QBVW025A0B-H with 0.25” heatsink in the Transverse Orientation; Airflow Direction from Vin(-) to Vin(+); Vin = 48V

LOCAL AMBIENT TEMPERATURE, T

(C)

(A)

OUTPUT CURRENT, I

COLD WALL TEMPERATURE, TC (C)

Figure 24. Output Current Derating for the Base Plate QBVW025A0B-H in a Cold wall application; Local Internal Air Temperature near module=80 anywhere from 6.0V to 12.0V.

C, V

= 48V, V

setting

OUT

Data Sheet

QBVW025A0B Barracuda™ Series; DC-DC Converter Power Modules

36-75Vdc Input; 12.0Vdc, 25.0A, 300W Output

Layout Considerations

The QBVW025 power module series are low profile in order to be used in fine pitch system card architectures. As such, component clearance between the bottom of the power module and the mounting board is limited. Avoid placing copper areas on the outer layer directly underneath the power module. Also avoid placing via interconnects underneath the power module.

For additional layout guide-lines, refer to FLTR100V10 Data Sheet.

Through-Hole Lead-Free Soldering Information

The RoHS-compliant, Z version, through-hole products use the SAC (Sn/Ag/Cu) Pb-free solder and RoHS-compliant components. The module is designed to be processed through single or dual wave soldering machines. The pins have a RoHS-compliant, pure tin finish that is compatible with both Pb and Pb-free wave soldering processes. A maximum preheat rate of 3 preheat process should be such that the temperature of the power module board is kept below 210 recommended pot temperature is 260 solder pot is 270

C max.

C/s is suggested. The wave

C. For Pb solder, the

C, while the Pb-free

Reflow Lead-Free Soldering Information

The RoHS-compliant through-hole products can be processed with following paste-through-hole Pb or Pb-free reflow process.

Max. sustain temperature : 245

C (J-STD-020C Table 4-2: Packaging Thickness>=2.5mm

/ Volume > 2000 Peak temperature over 245 potential reliability risk of components under continuous high-temperature. Min. sustain duration above 217

C is not suggested due to the

C : 90 seconds

Reflow Lead-Free Soldering Information (continued)

Min. sustain duration above 180C : 150 seconds Max. heat up rate: 3 Max. cool down rate: 4 In compliance with JEDEC J-STD-020C spec for 2 times reflow requirement.

C/sec

Pb-free Reflow Profile

BMP module will comply with J-STD-020 Rev. C (Moisture/Reflow Sensitivity Classification for Nonhermetic Solid State Surface Mount Devices) for both Pb-free solder profiles and MSL classification procedures. BMP will comply with JEDEC J-STD-020C specification for 3 times reflow requirement. The suggested Pb-free solder paste is Sn/Ag/Cu (SAC). The recommended

linear reflow profile using Sn/Ag/Cu solder is shown in Figure

25.

Peak Temp. 240-245°C

Ramp down

max. 4°C/Sec

217°C 200°C

150°C

25°C

Figure 25. Recommended linear reflow profile using Sn/Ag/Cu solder.

Ramp up

max. 3°C/Sec

Preheat time

100-150 Sec.

Time

Time Limited 90 Sec.

above 217°C

MSL Rating

The QBVW025A0B modules have a MSL rating of 2a.

Storage and Handling

The recommended storage environment and handling procedures for moisture-sensitive surface mount packages is detailed in J-STD-033 Rev. A (Handling, Packing, Shipping and Use of Moisture/Reflow Sensitive Surface Devices). Moisture barrier bags (MBB) with desiccant are required for MSL ratings of 2 or greater. These sealed packages should not be broken until time of use. Once the original package is broken, the floor life of the product at conditions of according to the MSL rating (see J-STD-033A). The shelf life for dry packed SMT packages will be a minimum of 12 months from the bag seal date, when stored at the following conditions: < 40° C, < 90% relative humidity.

30°C and 60% relative humidity varies

Mount

Post Solder Cleaning and Drying Considerations

Post solder cleaning is usually the final circuit-board assembly process prior to electrical board testing. The result of inadequate cleaning and drying can affect both the reliability of a power module and the testability of the finished circuit-board assembly. For guidance on appropriate soldering, cleaning and drying procedures, refer to GE Board Mounted Power Modules: Soldering and Cleaning Application Note (AN04-001).

If additional information is needed, please consult with your GE representative for more details.

Data Sheet

QBVW025A0B Barracuda™ Series; DC-DC Converter Power Modules

36-75Vdc Input; 12.0Vdc, 25.0A, 300W Output

EMC Considerations

The circuit and plots in Figure 26 shows a suggested configuration to meet the conducted emission limits of EN55022 Class A. For further information on designing for EMC compliance, please refer to the FLT012A0Z data sheet.

Figure 26. EMC Considerations

Data Sheet

QBVW025A0B Barracuda™ Series; DC-DC Converter Power Modules

36-75Vdc Input; 12.0Vdc, 25.0A, 300W Output

Mechanical Outline for QBVW025A0B Through-hole Module

Dimensions are in millimeters and [inches]. Tolerances: x.x mm x.xx mm

TOP VIEW*

SIDE VIEW

BOTTOM VIEW

Number

1* VIN(+) 2* ON/OFF 3* VIN(-) 4* VOUT(-) 5† SENSE(-) 6† TRIM 7† SENSE(+) 8* VOUT(+)

† - Optional Pins See Table 2

 0.5 mm [x.xx in.  0.02 in.] (Unless otherwise indicated)  0.25 mm [x.xxx in  0.010 in.]

*Top side label includes GE name, product designation, and data code. ** Standard pin tail length. Optional pin tail lengths shown in Table 2, Device Options.

Name

Data Sheet

QBVW025A0B Barracuda™ Series; DC-DC Converter Power Modules

36-75Vdc Input; 12.0Vdc, 25.0A, 300W Output

Mechanical Outline for QBVW025A0B–H (Base plate) Through-hole Module

Dimensions are in millimeters and [inches]. Tolerances: x.x mm x.xx mm

TOP VIEW

SIDE VIEW*

BOTTOM VIEW***

Number

1* VIN(+) 2* ON/OFF 3* VIN(-) 4* VOUT(-) 5† SENSE(-) 6† TRIM 7† SENSE(+) 8* VOUT(+)

† - Optional Pins See Table 2

Name

 0.5 mm [x.xx in.  0.02 in.] (Unless otherwise indicated)  0.25 mm [x.xxx in  0.010 in.]

*Side label includes product designation, and data code. ** Standard pin tail length. Optional pin tail lengths shown in Table 2, Device Options. ***Bottom label includes GE name, product designation, and data code

Data Sheet

QBVW025A0B Barracuda™ Series; DC-DC Converter Power Modules

36-75Vdc Input; 12.0Vdc, 25.0A, 300W Output

Recommended Pad Layouts

Dimensions are in millimeters and (inches). Tolerances: x.x mm x.xx mm

Through-Hole Modules

Number

1* VIN(+) 2* ON/OFF 3* VIN(-) 4* VOUT(-) 5† SENSE(-) 6† TRIM 7† SENSE(+) 8* VOUT(+)

† - Optional Pins See Table 2

 0.5 mm ( x.xx in.  0.02 in.) [unless otherwise indicated]

 0.25 mm ( x.xxx in  0.010 in.)

Name

Hole and Pad diameter recommendations:

Pin Number Hole Dia (mm) Pad Dia (mm) 1, 2, 3, 5, 6, 7 1.6 2.1 4, 8 2.2 3.2

Data Sheet

QBVW025A0B Barracuda™ Series; DC-DC Converter Power Modules

36-75Vdc Input; 12.0Vdc, 25.0A, 300W Output

Packaging Details

All versions of the QBVW025A0B are supplied as standard in the plastic trays shown in Figure 27.

Tray Specification

Material PET (1mm)

Max surface resistivity Color Clear Capacity 12 power modules Min order quantity 24 pcs (1 box of 2 full trays

-10

+ 1 empty top tray)

/PET

Each tray contains a total of 12 power modules. The trays are self-stacking and each shipping box for the QBVW025A0B module contains 2 full trays plus one empty hold-down tray giving a total number of 24 power modules.

Open Frame Module Tray Base Plate Module Tray

Figure 27. QBVW025 Packaging Tray

Data Sheet

QBVW025A0B Barracuda™ Series; DC-DC Converter Power Modules

36-75Vdc Input; 12.0Vdc, 25.0A, 300W Output

Ordering Information

Please contact your GE Sales Representative for pricing, availability and optional features.

Table 1. Device Codes

Product codes Input Voltage

QBVW025A0BZ

QBVW025A0B1Z QBVW025A0B41Z QBVW025A0B61Z QBVW025A0B54Z QBVW025A0B64Z

QBVW025A0B641Z QBVW025A0B841Z QBVW025A0B941Z QBVW025A0B964Z QBVW025A0B981Z

QBVW025A0B1-HZ QBVW025A0B41-HZ QBVW025A0B51-HZ QBVW025A0B61-HZ

QBVW025A0B641-HZ QBVW025A0B941-HZ

QBVW025A0B-PHZ QBVW025A0B1-PHZ

QBVW025A0B41-PHZ

QBVW025A0B641-PHZ

Table 2. Device Options

48V (36 48V (36 48V (36 48V (36 48V (36 48V (36 48V (36 48V (36 48V (36 48V (36 48V (36 48V (36 48V (36 48V (36 48V (36 48V (36 48V (36 48V (36 48V (36 48V (36 48V (36

75Vdc) 75Vdc) 75Vdc) 75Vdc) 75Vdc) 75Vdc) 75Vdc) 75Vdc) 75Vdc) 75Vdc) 75Vdc) 75Vdc) 75Vdc) 75Vdc) 75Vdc) 75Vdc) 75Vdc) 75Vdc) 75Vdc) 75Vdc) 75Vdc)

Output

Voltage

12V 25A 96.0% Through hole CC109167796 12V 25A 96.0% Through hole CC109167383 12V 25A 96.0% Through hole CC109166195 12V 25A 96.0% Through hole CC109167391 12V 25A 96.0% Through hole 150024264 12V 25A 96.0% Through hole CC109169875 12V 25A 96.0% Through hole CC109166204 12V 25A 96.0% Through hole CC109168407 12V 25A 96.0% Through hole 150022025 12V 25A 96.0% Through hole CC109173167 12V 25A 96.0% Through hole 150028904 12V 25A 96.0% Through hole CC109167400 12V 25A 96.0% Through hole CC109166798 12V 25A 96.0% Through hole CC109167417 12V 25A 96.0% Through hole CC109167821 12V 25A 96.0% Through hole CC109166815 12V 25A 96.0% Through hole 150020599 12V 25A 96.0% Through hole CC109170065 12V 25A 96.0% Through hole CC109167425 12V 25A 96.0% Through hole CC109167433 12V 25A 96.0% Through hole CC109173092

Output

Current

Efficiency

Connector

Type

Comcodes

Data Sheet

QBVW025A0B Barracuda™ Series; DC-DC Converter Power Modules

36-75Vdc Input; 12.0Vdc, 25.0A, 300W Output

For more information, call us at

USA/Canada:

+1 888 546 3243, or +1 972 244 9288

Asia-Pacific:

+86.021.54279977*808

Europe, Middle-East and Africa:

+49.89.878067-280

India: +91.80.28411633

www.ge.com/powerelectronics

GE Industrial Solutions QBVW025A0B User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
