GE Industrial Solutions AKD-5, AKD-6, AKD-8 User Manual

GE Energy
Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
Retrofit doors for the EntelliGuard® Retrofill can be ordered as required, depending on door size and if you want door cutouts for accommodating lamps and ammeters.
Table of Contents
Related Publications ...................................................................................................................................................................................... 3
Doors, Retrofit Ordering and Replacement ............................................................................................................................................... 3
Danger ....................................................................................................................................................................................................................................................3
AKD-5, AK25 Retrofit Door ............................................................................................................................................................................ 4
20-Inch Door (AKD5, AK25) ........................................................................................................................................................................................................... 4
22-Inch Door (AKD5, AK25) ........................................................................................................................................................................................................... 5
27-Inch Door (AKD5, AK25) ........................................................................................................................................................................................................... 6
Assy. DWG—27” RH AK25 Retrofill (Sheet 1) .................................................................................................................................................................. 7
Assy. DWG—27” RH AK25 Retrofill (Sheet 2) .................................................................................................................................................................. 8
AKD-5, AK50 Retrofit Door.............................................................................................................................................................................................................8
27-Inch Door (AKD5, AK50) .................................................................................................................................................................................................... 8
Replace AKD5 Door ......................................................................................................................................................................................10
Modify Existing Door .................................................................................................................................................................................... 10
AKD-6, AKR Retrofit Door ............................................................................................................................................................................10
22-Inch Door (AKD6) ...................................................................................................................................................................................................................... 11
Assy. DWG—22” RH AKD6 Retrofill (Sheet 1) ............................................................................................................................................................... 12
Assy. DWG—22” RH AKD6 Retrofill (Sheet 2) ............................................................................................................................................................... 13
27-inch Door Sizes (AKD6) .......................................................................................................................................................................................................... 13
Replacing AKD6 Door Assembly .............................................................................................................................................................................................. 15
Modifying Existing Door ....................................................................................................................................................................................................... 15
AKD-8, AKR30S, AKR30H, AKR 30/50 Retrofit Door Assemblies ...........................................................................................................15
22-Inch and 30-Inch RH AKD8 ................................................................................................................................................................................................. 16
Assy. DWG—30” RH AKR30S Retrofill (Sheet 1) .......................................................................................................................................................... 17
Assy. DWG—30” RH AKR30S Retrofill (Sheet 2) .......................................................................................................................................................... 18
Assy. DWG—30” RH AKR30/30H/50/50H Retrofill (Sheet 1) ................................................................................................................................ 19
Assy. DWG—30” RH AKR30/30H/50/50H Retrofill (Sheet 2) ................................................................................................................................ 20
Replacing AKD8 Door Assembly .............................................................................................................................................................................................. 21
Modifying Existing Door ....................................................................................................................................................................................................... 21
Retrofill Escutcheon Kit—Spare .................................................................................................................................................................. 23
BOM (Bill of Materials) .................................................................................................................................................................................. 23
BOM 10106255G1 .......................................................................................................................................................................................................................... 23
BOM 10108088G1 .......................................................................................................................................................................................................................... 24
BOM 10108439G1 .......................................................................................................................................................................................................................... 24
BOM 10108090G1 .......................................................................................................................................................................................................................... 25
BOM 10108361G1 .......................................................................................................................................................................................................................... 25
Comprehensive BOM: All Levels ................................................................................................................................................................. 26
AKD-5 AK25 ....................................................................................................................................................................................................................................... 26
AK25 DOOR ASSY, 20” ........................................................................................................................................................................................................... 26
AK25 DOOR ASSY, 20” WITH LIGHT ................................................................................................................................................................................. 27
AK25 DOOR ASSY, 20” RH .................................................................................................................................................................................................... 28
AK25 DOOR ASSY, 22” ........................................................................................................................................................................................................... 29
AK25 DOOR 22” ASSY ............................................................................................................................................................................................................ 30
AK25 DOOR ASSY- 27”, 30”, 38” ........................................................................................................................................................................................ 31
AK25 DOOR ASSY, 27” WITH LIGHT ................................................................................................................................................................................. 32
AK25 DOOR ASSY, 27” WITH LIGHT ................................................................................................................................................................................. 33
Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
1
DEH-41563 02/12
AKD-5 AK50 ....................................................................................................................................................................................................................................... 34
AK50 DOOR ASSY- 27”, 30”,38”.......................................................................................................................................................................................... 34
AK50 DOOR ASSY, 20” WITH LIGHT ................................................................................................................................................................................. 35
AK50 DOOR ASSY-27”, RH ................................................................................................................................................................................................... 36
AK50 DOOR ASSY- 27”, 30”,38”.......................................................................................................................................................................................... 37
AK50 DOOR ASSY, 20” WITH LIGHT ................................................................................................................................................................................. 38
AK50 DOOR ASSY-27”, RH ................................................................................................................................................................................................... 39
AKD-6 ................................................................................................................................................................................................................................................... 40
AKD6 DOOR ASSY, 22” ........................................................................................................................................................................................................... 40
AKD6 DOOR ASSY, 22” WITH LIGHT ................................................................................................................................................................................ 41
Door Assembly of AKD6 ....................................................................................................................................................................................................... 42
AKD6 27”,30” & 38” DOOR ASSY ....................................................................................................................................................................................... 43
AKD6 27” DOOR ASSY WITH LIGHTS............................................................................................................................................................................... 44
AKD6 27 & 30” DOOR ASSY ................................................................................................................................................................................................. 45
AKD-8 ................................................................................................................................................................................................................................................... 46
DOOR ASSY, AKD8 AKR30H ................................................................................................................................................................................................. 46
AKD8 AKR30/50 30” DOOR ASSY ..................................................................................................................................................................................... 47
AKR30S 22” DOOR ASSY ....................................................................................................................................................................................................... 48
AKR30S 30” DOOR ASSY ....................................................................................................................................................................................................... 49
Notes .............................................................................................................................................................................................................50
DEH-41563 02/12
Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
2
Related Publications
Publication Publication Number
Brochure DEA-532 Snapshot DEE-543 Installation Manual AKD8 DEH-41549 Installation Manual AKD6 DEH-41548 Installation Manual AKD5 DEH-41547 Accessory: Door Interlock (Door Interlock Kit) DEH-41529 Accessory Retrofill Doors Assembly DEH-41563 Accessory: Position Switch Plate & Position Switch
Assembly & Wiring (Position Switch Kit) Accessory: Neutral Rogowski CT Disconnect
(Neutral Assemblies) Accessory: Programmer Disconnects DEH-41532 Accessory: Finger Clusters (Cluster Assemblies) DEH-41533 Accessory: Secondary Disconnects DEH-41534 FAQ DEQ-171 Application Guide DET-753 Guideform Spec DET-754 Spare/Renewal Parts Guide DET-755
DEH-41530
DEH-41531
Doors, Retrofit Ordering and Replacement
Danger
• Turn off all power to switchgear. Tagout and lockout main source, up-stream or main breaker.
• Failure to comply with these instructions will result in death or serious injury from
severe burns caused by arc flashing that has exceedingly high temperatures.
• Always wear personal protection equipment according to OSHA standards and appropriate to the severity of potential burns.
• Ensure only qualified personnel install, operate, service, and maintain all electrical equipment.
It takes about 5 to 15 minutes to install the retrofill door(s) in the switchgear, but does not include the 20-minute timing claimed for the roll-in replacement.
Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
3
DEH-41563 02/12
AKD-5, AK25 Retrofit Door
Retrofit doors for the can be ordered as required, depending on door size and if you want door cutouts for accommodating lamps and ammeters (Figure 1 and Figure 2). In this section, the particular wireframe figures feature different door sizes. Table 1 lets you specify a door type. It can be ordered by catalog number by referring to the last column in the table. Some doors allow cutouts for lamps and/or ammeters; some do not. All the doors in Table 1 are right-hand doors.
20-Inch Door (AKD5, AK25)
Figure 1. AK25 (20-inch door assembly) with and without Cutouts for Lights
Figure 2. AK25 (20-inch door assembly) with Cutouts for Lights and Accessories
DEH-41563 02/12
Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
4
22-Inch Door (AKD5, AK25)
Figure 3 displays 22-inch door assemblies, with and without cutouts for lights. The next figure, Figure 4 displays
cutouts for both lights and accessories.
Figure 3. AK25 (22-inch door assembly) with and without Cutouts for Lights
Figure 4. AK25 (22-inch door assembly) with Cutouts for Lights and Accessories
Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
5
DEH-41563 02/12
27-Inch Door (AKD5, AK25)
Figure 5 displays 27-inch door assemblies, with and without cutouts for lights. The next figure, Figure 6, displays
cutouts for both lights and accessories.
Figure 5. AK25 (27-inch door assembly) with and without Cutouts for Lights
Figure 6. AK25 (27-inch door assembly) with Cutouts for
Lights and Accessories
DEH-41563 02/12
Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
6
Table 1. Replacement Door Categories (TOP LEVEL)
Available Stack Width
(in inches)
20 22 27 30 38
Type
Door
Width
(in inches)
Door Bump-out (in inches)
Description
AK25 DOOR
ASSY
AK25 DOOR
ASSY
AK25 DOOR
ASSY
AK25 DOOR
ASSY
AK25 DOOR
ASSY
AK25 DOOR
ASSY
AK25 DOOR
ASSY
AK25 DOOR
ASSY
Cutout Options
Breaker
Type
AK25 AKD5 YES YES YES YES RH 27 YES—3.7
AK25 AKD5 YES YES RH 20 YES—3.7
AK25 AKD5 YES YES RH 22 YES—3.7
AK25 AKD5 YES YES RH 20 YES—3.7
AK25 AKD5 YES YES RH 22 YES—3.7
AK25 AKD5 YES YES RH 22 YES—3.7
AK25 AKD5 YES YES YES YES RH 27 YES—3.7
AK25 AKD5 YES YES YES YES RH 27 YES—3.7
LVS
Fascia
Cutout
Only
Lamps
Only
Lamps +
Amme-
ter
Assy. DWG—27” RH AK25 Retrofill (Sheet 1)
Sheet 1 of Drawing 10106255 is shown below. Sheet 2 of this drawing immediately follows Sheet 1.
Refer to BOM 10106255G1.
GCAT #
10106255G1
10107429G1
10108047G1
10108345G1
10108347G1
10108376G1
10108380G1
10108383G1
DWG 1 (Sheet 1). 10106255 Door Assembly—27” RH AK25 Retrofill
Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
7
DEH-41563 02/12
Assy. DWG—27” RH AK25 Retrofill (Sheet 2)
DWG 1 (Sheet 2). 10106255: Door Assembly—27” RH AK25 Retrofill
AKD-5, AK50 Retrofit Door
27-Inch Door (AKD5, AK50)
Retrofit doors for the can be ordered as required, depending on door size and if you want door cutouts for accommodating lamps and ammeters (Figure 7 and Figure 8). In this section, the particular wireframe figures feature different door sizes. Table 2 lets you select a specific door type. It can be ordered by catalog number by referring to the last column in the table. Two doors allow cutouts for lamps and/or ammeters; one does not allow any cutouts. All the doors in Table 2 are right-hand doors.
DEH-41563 02/12
Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
8
Figure 7. AK50 (27-inch door assembly) with and without Cutouts for Lights
Figure 8. AK50 (27-inch door assembly) with
Cutouts for Lights and Accessories
Table 2. Replacement Door Categories (TOP LEVEL)
Cutout Options
Description
AK50 DOOR
ASSY
AK50 DOOR
ASSY
AK50 DOOR
ASSY
Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
9
Breaker
Type
AK50 AKD5 YES YES YES YES RH 27 No
AK50 AKD5 YES YES YES YES RH 27 No
AK50 AKD5 YES YES YES YES RH 27 No
LVS
Fascia
Cutout
Only
Lamps
Only
Lamps +
Amme-
ter
Available Stack Width
(in inches)
20 22 27 30 38
Type
Door
Width
(in inches)
Door Bump-out (in inches)
GCAT #
10106248G1
10108355G1
10108363G1
DEH-41563 02/12
Replace AKD5 Door
Sequence of replacement of door assemblies will remain the same for all AKD5 type doors.
1. De-energize/switch off the LVS section that is to be retrofitted.
2. Open the compartment door that is to be retrofitted.
3. Rack out the existing legacy AK/AKR breaker from the LVS.
4. Keep the door open for accessing the door mounting hinges. These are placed on the right side wall of the
moving frame in the LVS compartment.
5. The door hinge is mounted via 2/3-mounting pins that hold the door in place.
6. Lift the pin out of the hinge joint. This allows access for removing the old door from the LVS compartment.
7. Unpack the new door assembly and mount it on the door mounting hinges. These are located at the right
side of the moving frame.
8. Replace the hinge pins and secure the joints.
9. Insert the new retrofitted EntelliGuard R Retrofill circuit breaker into the compartment and slide the breaker into
the disconnected condition.
10. Close the new door and secure it to the compartment.
11. Rack-in the new retrofitted EntelliGuard R Retrofill in.
Modify Existing Door
If customer doesn’t want to buy a new door, the customer can modify the existing door:
1. Remove the legacy door assembly from the LVS section.
2. Modify the door cut out as per the new door cutout template.
3. Check the through-door racking with the new door assembly.
AKD-6, AKR Retrofit Door
Retrofit doors for the can be ordered as required, depending on door size and if you want door cutouts for accom­modating lamps and ammeters. Table 3 lets you select a specific door type (Figure 9 and Figure 10). In this section, the particular wireframe figures different door sizes. It can be ordered by catalog number by referring to the last column in the table. Some doors allow cutouts for lamps and/or ammeters; some do not. All the doors in Table 3 are right-hand doors.
DEH-41563 02/12
Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
10
22-Inch Door (AKD6)
Figure 9. AKD6 (22-inch door assembly) with and without Cutouts for Lights
Figure 10. AKD6 (22-inch door assembly) with
Cutouts for Lights and Accessories
Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
11
DEH-41563 02/12
Assy. DWG—22” RH AKD6 Retrofill (Sheet 1)
Sheet 1 of Drawing 10108439 is shown below. Sheet 2 of this drawing immediately follows Sheet 1. Refer to BOM 10108439G1.
DWG 2 (Sheet 1). 10108439 AKD6 Door Assembly 22” AKD6 Retrofill
DEH-41563 02/12
Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
12
Assy. DWG—22” RH AKD6 Retrofill (Sheet 2)
DWG 3 (Sheet 2). 10108439 AKD6 Door Assembly 22” AKD8 Retrofill
27-inch Door Sizes (AKD6)
For the AKD6, Figure 11 displays the 27-inch door assembly with and without cutouts for lights. Figure 12 shows cutouts or punch-outs for the same door assembly.
Figure 11. AKD6 (27-inch door assembly) with and without Cutouts for Lights
Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
13
DEH-41563 02/12
Figure 12. AKD6 (27-inch door assembly with Cutouts for Lights and Accessories
Table 3. Replacement Door Categories (TOP LEVEL)
Description
AKD6 DOOR
ASSY
AKD6 DOOR
ASSY
AKD6 DOOR
ASSY
AKD6 DOOR
ASSY
AKD6 DOOR
ASSY
AKD6 DOOR
ASSY
Cutout Options
Breaker
Type
AKR AKD6 YES YES RH 22 No
AKR AKD6 YES YES RH 22 No
AKR AKD6 YES YES RH 22 No
AKR AKD6 YES YES YES YES RH 27 No
AKR AKD6 YES YES YES YES RH 27 No
AKR AKD6 YES YES YES YES RH 27 No
LVS
Fascia
Cutout
Only
Lamps
Only
Lamps +
Amme-
ter
Available Stack Width
(in inches)
20 22 27 30 38
Type
Door
Width
(in inches)
Bump-out (in inches)
Door
GCAT #
10107469G1
10108074G1
10108439G1
10108447G1
10108462G1
10108469G1
DEH-41563 02/12
Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
14
Replacing AKD6 Door Assembly
Sequence of replacement of door assemblies will remain the same for all AKD6 type doors.
1. De-energize/switch off the LVS section that is to be retrofitted.
2. Open the compartment door that is to be retrofitted.
3. Rack out the existing legacy AK/AKR breaker from the LVS.
4. Keep the door open for accessing the door mounting hinges. These are placed on the right side wall of the
moving frame in the LVS compartment.
5. The door hinge is mounted via 2/3-mounting pins that hold the door in place. [What does the “2/3” mean: size, inches, type, etc.?] [How many pins are there per door?]
6. Lift the pin out of the hinge joint. This will provide access for removing the old door from the LVS compartment.
7. Unpack the new door assembly and mount it on the door mounting hinges. These are placed [found?] [or are
they already installed there?] at the right side of the moving frame.
8. Replace the hinge pins and secure the joints.
9. Insert the new retrofitted EntelliGuard R Retrofill circuit breaker into the compartment and slide the breaker into
the disconnected condition.
10. Close the new door and secure it to the compartment.
11. Rack-in the new retrofitted EntelliGuard R Retrofill in. [OK, what do I do with the old door? Discard it—salvage it
for something else?]
Modifying Existing Door
If customer doesn’t want to buy a new door, the customer can modify the existing door:
1. Remove the legacy door assembly from the LVS section.
2. Modify the door cut out as per the new door cutout template.
3. Check the through-door racking with the new door assembly.
AKD-8, AKR30S, AKR30H, AKR 30/50 Retrofit Door Assemblies
Retrofit doors for the can be ordered as required, depending on door size and if you want door cutouts for accommodating lamps and ammeters (Figure 13, Figure 14, and Figure 15). Table 4 lets you select a specific door type. It can be ordered by catalog number by referring to the last column in the table. Some doors allow cutouts for lamps and/or ammeters; some do not. All the doors in Table 4 are right-hand doors.
Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
15
DEH-41563 02/12
22-Inch and 30-Inch RH AKD8
Figure 13. AKD8 (22-inch door assembly)
Figure 14. AKD8 (30-inch door assembly)
Figure 15. AKD8 AKR30S (30-inch door assembly)
DEH-41563 02/12
Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
16
Table 4. Replacement Door Categories (TOP LEVEL)
Available Stack Width
(in inches)
20 22 27 30 38
Type
Door
Width
(in inches)
Door Bump-out (in inches)
10108089G1
10108090G1
10106239G1
10108088G1
Description
AKR30S
DOOR ASSY
AKR30S 30" DOOR ASSY
DOOR
ASSY, AKD8
AKR30H
AKD8
AKR30/50 30"
DOOR ASSY
Breaker
Type
AKR
AKR
AKR
AKR
LVS
AKD8—
AKR30S
AKD8—
AKR30S
AKD8—
Regular
AKD8—
Regular
Cutout Options
Fascia
Cutout
Only
YES YES RH 22 YES—2.95
YES YES RH 30 YES—2.95
YES YES RH 22 No
YES YES RH 30 No
Lamps
Only
Lamps +
Amme-
ter
Assy. DWG—30” RH AKR30S Retrofill (Sheet 1)
Sheet 1 of Drawing 10108090 is shown below. Sheet 2 of this drawing immediately follows Sheet 1. Refer to BOM 10108090G1.
DWG 3 (Sheet 1). 10108090 AKR30S 30” Door Assembly AKD8 Retrofill
GCAT #
Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
17
DEH-41563 02/12
Assy. DWG—30” RH AKR30S Retrofill (Sheet 2)
DWG 4 (Sheet 2). 10108090 AKR30S 30” Door Assembly AKD8 Retrofill
DEH-41563 02/12
Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
18
Assy. DWG—30” RH AKR30/30H/50/50H Retrofill (Sheet 1)
Sheet 1 of Drawing 10108088 is shown below. Sheet 2 of this drawing immediately follows Sheet 1. Refer to BOM 10108088G1.
DWG 4 (Sheet 1). 10108088 AKD6 AKR30/50 30” Door Assembly (AKR30/30H/50/50H Retrofill)
Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
19
DEH-41563 02/12
Assy. DWG—30” RH AKR30/30H/50/50H Retrofill (Sheet 2)
DWG 2 (Sheet 2). 10108088 AKD8 AKR30/50 30” Door Assembly (AKR30/30H/50/50H Retrofill)
DEH-41563 02/12
Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
20
Replacing AKD8 Door Assembly
Figure 16 is an example of an AKD-8 installed with a new, retrofill door for the newly installed retrofill breaker. (Note
that the figure shows that a motor can power the racking-in of the retrofill breaker.)
Sequence of replacement of door assemblies will remain the same for all AKD8 type doors.
1. De-energize/switch off the LVS section that is to be retrofitted.
2. Open the compartment door that is to be retrofitted.
3. Rack out the existing legacy AK/AKR breaker from
the LVS
4. Keep the door open for accessing the door mounting pads placed on the right side wall in the LVS compartment.
5. Loosen the screws holding the mounting pads to the compartment frame.
6. Note that this will provide access for removing the old door from the LVS compartment.
7. Unpack the new door assembly and mount it on the compartment and secure via placing the pads and tightening the screws.
8. Insert the new retrofitted EntelliGuard R Retrofill circuit breaker into the compartment and slide the breaker into the disconnected condition.
Figure 16. New Doors Assembled on AKD-8—A 30”-Door
9. Close the new door and secure it to the compartment.
10. Rack-in the new retrofitted EntelliGuard R Retrofill circuit breaker in.
Modifying Existing Door
If customer doesn’t want to buy a new door, the customer can modify the existing door:
1. Remove the legacy door assembly from the LVS section.
2. Modify the door cut out as per the new door cutout template.
3. Check the through-door racking with the new door assembly.
Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
21
DEH-41563 02/12
Figure 17 shows a legacy breaker in the cabinet with the old doors still attached. Figure 18 shows the retrofill breaker,
racked in a compartment, waiting for a retrofill door to be installed. The other three compartment doors have the retrofill doors already, but no retrofill breakers yet.
Figure 18. AKR with New DoorFigure 17. Legacy AK with Old Door
DEH-41563 02/12
Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
22
Retrofill Escutcheon Kit—Spare
Table 5 displays some kit options.
Table 5. Escutcheon Options Kit
Fascia Cutout Only
No
Lamps Only
Description
Retrofill Escutcheon
Kit—Spare
Escutcheon Kit
Drawout
Breaker
Type
AK25 AKD5 YES YES YES YES YES
AKR AKD6 N/A YES YES YES YES
AKR AKD8—AKR30S N/A YES YES YES YES
AKR AKD8 Regular N/A YES YES YES YES
AK50 AKD5 N/A N/A YES YES YES
LVS
Cutouts
BOM (Bill of Materials)
BOM 10106255G1
10106255G1
Seq# Item Number Description Quantity
0 10106255PV1 PCVU 0
0 10106255PV1 PCVU 0
1 10106246G1 AK25 DOOR WELDMENT-27" 1
2 10107389G1 LATCH ASSEMBLY 1
3 10108592G1 HANDLE ASSY 1
4 N22P21008B6 BOLT,STEEL HEX 1/4-20X1/2 1
5 10107388P1 DOOR INTERLOCK CATCH PLATE 1
6 75V100058P104 RIVET POP 2
7 10106236P1 ESCUTCHEON SEAL 1
8 10106237P1 ESCUTCHEON, AK-25 1
9 10100923P2 CERRATED BELLEVILLE WASHER M3 12
10 10102274P1 POZIDRIV CROSS RECESD PAN HEAD 12
11 10108739P1 DOOR LABEL, RETROFILL 0
11 10108749P1 LABELS, BLANK DOOR 1
12 10108741P1 CAUTION LABEL, RETROFILL 1
Lamps +
Ammeter
Available Stack Width
(in inches)
20 22 27 30 38
GCAT #
10109607G1
10102167G1
Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
23
DEH-41563 02/12
BOM 10108088G1
10108088G1
Seq# Item Number Description Quantity
0 10108088PV1 PCVU 0
1 10106244P1 DOOR, AKD8-30" 1
2 10106237P1 ESCUTCHEON, AK-25 1
3 10106444P1 ESCUTCHEON SEAL 1
4 10106452P1 GASKET SPT, SIDES. AKD8 2
5 10106453P1 GASKET SPT, TOP & BTM 2
6 10100923P2 CERRATED BELLEVILLE WASHER M3 12
7 10102274P1 POZIDRIV CROSS RECESD PAN HEAD 12
8 75C149385P014 BRACKET 1
9 75V100058P104 RIVET POP 2
10 75C149310G002 HINGE PIN 1
11 N84P16006B6 SCREW,STEEL MACH 10-32X3/8 4
12 0317A8780P001 HANDLE-NONLOCKING 1
13 75C149310G001 HINGEPIN 1
14 10108739P1 DOOR LABEL, RETROFILL 0
14 10108749P1 LABELS, BLANK DOOR 1
15 10108741P1 CAUTION LABEL, RETROFILL 1
BOM 10108439G1
10108439G1
Seq# Item Number Description Quantity
0 10108439PV1 PICVU 0
1 10108438G1 AKD6 DOOR WELDMENT, 22 1
2 10108590G1 LATCH ASSY AKD6 RETROFILL 1
3 10108592G1 HANDLE ASSY 1
4 N22P21008B6 BOLT,STEEL HEX 1/4-20X1/2 1
5 10103363P1 ESCUTCHEON SEAL 1
6 10103362P1 ESCUTCHEON 1
7 10100923P2 CERRATED BELLEVILLE WASHER M3 12
8 10102274P1 POZIDRIV CROSS RECESD PAN HEAD 11
9 10108739P1 DOOR LABEL, RETROFILL 0
9 10108749P1 LABELS, BLANK DOOR 1
10 10108741P1 CAUTION LABEL, RETROFILL 1
DEH-41563 02/12
Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
24
BOM 10108090G1
10108090G1
Seq# Item Number Description Quantity
0 10108090PV1 PCVU 0
1 10103266P1 Door, AKR30S- 30" 1
2 10106237P1 ESCUTCHEON, AK-25 1
3 10106444P1 ESCUTCHEON SEAL 1
4 10106452P1 GASKET SPT, SIDES. AKD8 2
5 10106453P1 GASKET SPT, TOP & BTM 2
6 10100923P2 CERRATED BELLEVILLE WASHER M3 12
7 10102274P1 POZIDRIV CROSS RECESD PAN HEAD 12
8 75C149385P014 BRACKET 1
9 75V100058P104 RIVET POP 2
10 75C149310G002 HINGE PIN 1
11 N84P16006B6 SCREW,STEEL MACH 10-32X3/8 4
12 0317A8780P001 HANDLE-NONLOCKING 1
13 75C149310G001 HINGEPIN 1
14 10108739P1 DOOR LABEL, RETROFILL 0
14 10108749P1 LABELS, BLANK DOOR 1
15 10108741P1 CAUTION LABEL, RETROFILL 1
BOM 10108361G1
10108361G1
Seq# Item Number Description Quantity
0 10108361PV1 PICVU 0
1 10108276P1 AK50 DOOR WITH LIGHTS 1
2 10108582P1 HOLDER 3
3 10108597P1 STUD AKD5 & AKD6 RETROFILL 2
4 10108606P1 STUD AK50 -AKD5 & AKD6 1
5 10108401P1 COVER FOR AKD5 AK50 DOOR 1
Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
25
DEH-41563 02/12
Comprehensive BOM: All Levels
AKD-5 AK25
AK25 DOOR ASSY, 20”
Level
GCAT 10108345G1 AK25 DOOR ASSY, 20" 1 EA (each)
__2 0 10108341PV1 1 PICVU 0 EA (each) Phantom
__2 1 10108338P1 1 AK25 DOOR, 20" 1 EA (each) Phantom
___3 CDE22557 0 13GA, CR, B8A3A 33.01 LB (pound) Raw Material
__2 2 10108582P1 1 HOLDER 2 EA (each) Purchased
__2 3 10108597P1 1 STUD AKD5 & AKD6 RETROFILL 2 EA (each) Purchased
__2 4 10108598P1 1 STUD AKD5 & AKD6 RETROFILL 1 EA (each) Purchased
__2 0 10107389PV1 2 PICVU 0 EA (each) Phantom
__2 1 10108586P1 1 LATCH AKD5 AND AKD6 RETROFILL 1 EA (each) Phantom
___3 CDE22608 0 7GA, HR, B8A5B2 0.9 LB (pound) Raw Material
__2 2 10107383P1 2 CLIP 1 EA (each) Phantom
___3 CDE22557 0 13GA, CR, B8A3A 0.223 LB (pound) Raw Material
__2 0 10108592PV1 1 PICVU 0 EA (each) Phantom
__2 1 10108593P1 1 HANDLE AKD5 & AKD6 RETROFILL 1 EA (each) Purchased
__2 2 10108594P1 1 GUIDE AKD5 & AKD6 RETROFILL 1 EA (each) Purchased
__2 1 10109184P1 1 PACKING BOX FOR BUMPEDOUT DOOR 1 EA (each) Purchased
__2 2 10102425P1 1 Small Bag 1 GM (gram) Purchased
__2 3 10102426P1 1 PET band 0 MT (meter) Purchased
__2 4 10102427P1 1 Paper Tape 0 MT (meter) Purchased
Seq#
_1 0 10108345PV1 1 PICVU 0 EA (each) Phantom
_1 1 10108341G1 1 AK25 DOOR WELDMENT, 20" 1 EA (each) Phantom
_1 2 10106236P1 2 ESCUTCHEON SEAL 1 EA (each) Purchased
_1 3 10106237P1 2 ESCUTCHEON, AK-25 1 EA (each) Purchased
_1 4 10107389G1 2 LATCH ASSEMBLY 1 EA (each) Phantom
_1 5 10108592G1 1 HANDLE ASSY 1 EA (each) Phantom
_1 6 N22P21008B6 0 BOLT,STEEL HEX 1/4-20X1/2 1 EA Purchased
_1 7 10100923P2 3 CERRATED BELLEVILLE WASHER M3 12 EA (each) Purchased
_1 8 10102274P1 2 POZIDRIV CROSS RECESD PAN HEAD 12 EA (each) Purchased
_1 9 10108739P1 2 DOOR LABEL, RETROFILL 1 EA (each) Purchased
_1 10 10108741P1 2 CAUTION LABEL, RETROFILL 1 EA (each) Purchased
_1 11 10109181G1 1 PACKAGING FOR BUMPED OUT DOOR 1 EA (each) Phantom
Item Number Rev Description Quantity UM
Item Type
DEH-41563 02/12
Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
26
AK25 DOOR ASSY, 20” WITH LIGHT
Level
GCAT 10108347G1 AK25 DOOR ASSY, 20" WITH LIGHT 1 EA (each)
__2 0 10108346PV1 1 PICVU 0 EA (each) Phantom
__2 1 10108339P1 1 AK25 DOOR 20" WITH LIGHTS 1 EA (each) Phantom
___3 CDE22557 0 13GA, CR, B8A3A 33.01 LB (pound) Raw Material
__2 2 10108582P1 1 HOLDER 2 EA (each) Purchased
__2 3 10108597P1 1 STUD AKD5 & AKD6 RETROFILL 2 EA (each) Purchased
__2 4 10108598P1 1 STUD AKD5 & AKD6 RETROFILL 1 EA (each) Purchased
__2 0 10107389PV1 2 PICVU 0 EA (each) Phantom
__2 1 10108586P1 1 LATCH AKD5 AND AKD6 RETROFILL 1 EA (each) Phantom
___3 CDE22608 0 7GA, HR, B8A5B2 0.9 LB (pound) Raw Material
__2 2 10107383P1 2 CLIP 1 EA (each) Phantom
___3 CDE22557 0 13GA, CR, B8A3A 0.223 LB (pound) Raw Material
__2 0 10108592PV1 1 PICVU 0 EA (each) Phantom
__2 1 10108593P1 1 HANDLE AKD5 & AKD6 RETROFILL 1 EA (each) Purchased
__2 2 10108594P1 1 GUIDE AKD5 & AKD6 RETROFILL 1 EA (each) Purchased
__2 1 10109184P1 1 PACKING BOX FOR BUMPEDOUT DOOR 1 EA (each) Purchased
__2 2 10102425P1 1 Small Bag 1 GM (gram) Purchased
__2 3 10102426P1 1 PET band 0 MT (meter) Purchased
__2 4 10102427P1 1 Paper Tape 0 MT (meter) Purchased
Seq#
_1 0 10108347PV1 1 PICVU 0 EA (each) Phantom
_1 1 10108346G1 1 DOOR WELDMENT, 20" WITH LIGHTS 1 EA (each) Phantom
_1 2 10106236P1 2 ESCUTCHEON SEAL 1 EA (each) Purchased
_1 3 10106237P1 2 ESCUTCHEON, AK-25 1 EA (each) Purchased
_1 4 10107389G1 2 LATCH ASSEMBLY 1 EA (each) Phantom
_1 5 10108592G1 1 HANDLE ASSY 1 EA (each) Phantom
_1 6 N22P21008B6 0 BOLT,STEEL HEX 1/4-20X1/2 1 EA Purchased
_1 7 10100923P2 3 CERRATED BELLEVILLE WASHER M3 12 EA (each) Purchased
_1 8 10102274P1 2 POZIDRIV CROSS RECESD PAN HEAD 12 EA (each) Purchased
_1 9 10108739P1 2 DOOR LABEL, RETROFILL 1 EA (each) Purchased
_1 10 10108741P1 2 CAUTION LABEL, RETROFILL 1 EA (each) Purchased
_1 11 10109181G1 1 PACKAGING FOR BUMPED OUT DOOR 1 EA (each) Phantom
Item Number Rev Description Quantity UM
Item Type
Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
27
DEH-41563 02/12
AK25 DOOR ASSY, 20” RH
Level
GCAT 10107429G1 AK25 DOOR ASSY, 20" RH 1 EA (each)
__2 0 10102789PV1 2 PICVU 0 EA (each) Phantom
__2 1 10102792P1 2 AK25 DOOR, 20", RH 1 EA (each) Phantom
___3 CDE22557 0 13GA, CR, B8A3A 33.01 LB (pound) Raw Material
__2 2 10108582P1 1 HOLDER 2 EA (each) Purchased
__2 3 10108597P1 1 STUD AKD5 & AKD6 RETROFILL 2 EA (each) Purchased
__2 4 10108598P1 1 STUD AKD5 & AKD6 RETROFILL 1 EA (each) Purchased
__2 0 10107389PV1 2 PICVU 0 EA (each) Phantom
__2 1 10108586P1 1 LATCH AKD5 AND AKD6 RETROFILL 1 EA (each) Phantom
___3 CDE22608 0 7GA, HR, B8A5B2 0.9 LB (pound) Raw Material
__2 2 10107383P1 2 CLIP 1 EA (each) Phantom
___3 CDE22557 0 13GA, CR, B8A3A 0.223 LB (pound) Raw Material
__2 0 10108592PV1 1 PICVU 0 EA (each) Phantom
__2 1 10108593P1 1 HANDLE AKD5 & AKD6 RETROFILL 1 EA (each) Purchased
__2 2 10108594P1 1 GUIDE AKD5 & AKD6 RETROFILL 1 EA (each) Purchased
__2 CDE22556 0 11GA, CR, B8A3A 0.213 LB (pound) Raw Material
__2 1 10109184P1 1 PACKING BOX FOR BUMPEDOUT DOOR 1 EA (each) Purchased
__2 2 10102425P1 1 Small Bag 1 GM (gram) Purchased
__2 3 10102426P1 1 PET band 0 MT (meter) Purchased
__2 4 10102427P1 1 Paper Tape 0 MT (meter) Purchased
Seq#
_1 0 10107429PV1 2 PICVU 0 EA (each) Phantom
_1 1 10102789G1 2 AK25 DOOR WELDMENT, 20" RH 1 EA (each) Phantom
_1 2 10107389G1 2 LATCH ASSEMBLY 1 EA (each) Phantom
_1 3 10108592G1 1 HANDLE ASSY 1 EA (each) Phantom
_1 4 N22P21008B6 0 BOLT,STEEL HEX 1/4-20X1/2 1 EA Purchased
_1 5 10107388P1 2 DOOR INTERLOCK CATCH PLATE 1 EA (each) Phantom
_1 6 75V100058P104 7 RIVET POP 2 EA Purchased
_1 7 10106236P1 2 ESCUTCHEON SEAL 1 EA (each) Purchased
_1 8 10106237P1 2 ESCUTCHEON, AK-25 1 EA (each) Purchased
_1 9 10100923P2 3 CERRATED BELLEVILLE WASHER M3 12 EA (each) Purchased
_1 10 10102274P1 2 POZIDRIV CROSS RECESD PAN HEAD 12 EA (each) Purchased
_1 11 10108739P1 2 DOOR LABEL, RETROFILL 1 EA (each) Purchased
_1 12 10108741P1 2 CAUTION LABEL, RETROFILL 1 EA (each) Purchased
_1 13 10109181G1 1 PACKAGING FOR BUMPED OUT DOOR 1 EA (each) Phantom
Item Number Rev Description Quantity UM
Item Type
DEH-41563 02/12
Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
28
AK25 DOOR ASSY, 22”
Level
GCAT 10108376G1 AK25 DOOR ASSY, 22" 1 EA (each)
__2 0 10107389PV1 2 PICVU 0 EA (each) Phantom
__2 1 10108586P1 1 LATCH AKD5 AND AKD6 RETROFILL 1 EA (each) Phantom
___3 CDE22608 0 7GA, HR, B8A5B2 0.9 LB (pound) Raw Material
__2 2 10107383P1 2 CLIP 1 EA (each) Phantom
___3 CDE22557 0 13GA, CR, B8A3A 0.223 LB (pound) Raw Material
__2 0 10108375PV1 1 PICVU 0 EA (each) Phantom
__2 1 10108374P1 1 AK25 DOOR, 22" 1 EA (each) Phantom
___3 CDE22557 0 13GA, CR, B8A3A 35.455 LB (pound) Raw Material
__2 2 10108582P1 1 HOLDER 2 EA (each) Purchased
__2 3 10108597P1 1 STUD AKD5 & AKD6 RETROFILL 2 EA (each) Purchased
__2 4 10108598P1 1 STUD AKD5 & AKD6 RETROFILL 1 EA (each) Purchased
__2 0 10108592PV1 1 PICVU 0 EA (each) Phantom
__2 1 10108593P1 1 HANDLE AKD5 & AKD6 RETROFILL 1 EA (each) Purchased
__2 2 10108594P1 1 GUIDE AKD5 & AKD6 RETROFILL 1 EA (each) Purchased
__2 1 10109184P1 1 PACKING BOX FOR BUMPEDOUT DOOR 1 EA (each) Purchased
__2 2 10102425P1 1 Small Bag 1 GM (gram) Purchased
__2 3 10102426P1 1 PET band 0 MT (meter) Purchased
__2 4 10102427P1 1 Paper Tape 0 MT (meter) Purchased
Seq#
_1 0 10108376PV1 1 PICVU 0 EA (each) Phantom
_1 1 10100923P2 3 CERRATED BELLEVILLE WASHER M3 12 EA (each) Purchased
_1 2 10102274P1 2 POZIDRIV CROSS RECESD PAN HEAD 12 EA (each) Purchased
_1 3 10106236P1 2 ESCUTCHEON SEAL 1 EA (each) Purchased
_1 4 10106237P1 2 ESCUTCHEON, AK-25 1 EA (each) Purchased
_1 5 10107389G1 2 LATCH ASSEMBLY 1 EA (each) Phantom
_1 6 10108375G1 1 AK25 DOOR WELDMENT, 22" 1 EA (each) Phantom
_1 7 10108592G1 1 HANDLE ASSY 1 EA (each) Phantom
_1 8 N22P21008B6 0 BOLT,STEEL HEX 1/4-20X1/2 1 EA Purchased
_1 9 10108739P1 2 DOOR LABEL, RETROFILL 1 EA (each) Purchased
_1 10 10108741P1 2 CAUTION LABEL, RETROFILL 1 EA (each) Purchased
_1 11 10109181G1 1 PACKAGING FOR BUMPED OUT DOOR 1 EA (each) Phantom
Item Number Rev Description Quantity UM
Item Type
Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
29
DEH-41563 02/12
AK25 DOOR 22” ASSY
Level
GCAT 10108047G1 AK25 DOOR 22" ASSY 1 EA (each)
__2 0 10108046PV1 1 PICVU 0 EA (each) Phantom
__2 1 10108045P1 1 AK25 DOOR 22" 1 EA (each) Phantom
___3 CDE22557 0 13GA, CR, B8A3A 35.455 LB (pound) Raw Material
__2 2 10108582P1 1 HOLDER 2 EA (each) Purchased
__2 3 10108597P1 1 STUD AKD5 & AKD6 RETROFILL 2 EA (each) Purchased
__2 4 10108598P1 1 STUD AKD5 & AKD6 RETROFILL 1 EA (each) Purchased
__2 0 10107389PV1 2 PICVU 0 EA (each) Phantom
__2 1 10108586P1 1 LATCH AKD5 AND AKD6 RETROFILL 1 EA (each) Phantom
___3 CDE22608 0 7GA, HR, B8A5B2 0.9 LB (pound) Raw Material
__2 2 10107383P1 2 CLIP 1 EA (each) Phantom
___3 CDE22557 0 13GA, CR, B8A3A 0.223 LB (pound) Raw Material
__2 0 10108592PV1 1 PICVU 0 EA (each) Phantom
__2 1 10108593P1 1 HANDLE AKD5 & AKD6 RETROFILL 1 EA (each) Purchased
__2 2 10108594P1 1 GUIDE AKD5 & AKD6 RETROFILL 1 EA (each) Purchased
__2 CDE22556 0 11GA, CR, B8A3A 0.213 LB (pound) Raw Material
__2 1 10109184P1 1 PACKING BOX FOR BUMPEDOUT DOOR 1 EA (each) Purchased
__2 2 10102425P1 1 Small Bag 1 GM (gram) Purchased
__2 3 10102426P1 1 PET band 0 MT (meter) Purchased
__2 4 10102427P1 1 Paper Tape 0 MT (meter) Purchased
Seq#
_1 2 10107389G1 2 LATCH ASSEMBLY 1 EA (each) Phantom
_1 3 10108592G1 1 HANDLE ASSY 1 EA (each) Phantom
_1 4 N22P21008B6 0 BOLT,STEEL HEX 1/4-20X1/2 1 EA Purchased
_1 5 10107388P1 2 DOOR INTERLOCK CATCH PLATE 1 EA (each) Phantom
_1 6 75V100058P104 7 RIVET POP 2 EA Purchased
_1 7 10106236P1 2 ESCUTCHEON SEAL 1 EA (each) Purchased
_1 8 10106237P1 2 ESCUTCHEON, AK-25 1 EA (each) Purchased
_1 9 10100923P2 3 CERRATED BELLEVILLE WASHER M3 12 EA (each) Purchased
_1 10 10102274P1 2 POZIDRIV CROSS RECESD PAN HEAD 12 EA (each) Purchased
_1 11 10108739P1 2 DOOR LABEL, RETROFILL 1 EA (each) Purchased
_1 12 10108741P1 2 CAUTION LABEL, RETROFILL 1 EA (each) Purchased
_1 13 10109181G1 1 PACKAGING FOR BUMPED OUT DOOR 1 EA (each) Phantom
Item Number Rev Description Quantity UM
Item Type
DEH-41563 02/12
Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
30
AK25 DOOR ASSY- 27”, 30”, 38”
Level
GCAT 10108383G1 AK25 DOOR ASSY- 27", 30", 38" 1 EA (each)
__2 0 10108382PV1 1 PICVU 0 EA (each) Phantom
__2 1 10108381P1 1 AK25 DOOR, 27", 30",38" 1 EA (each) Phantom
___3 CDE22557 0 13GA, CR, B8A3A 33.01 LB (pound) Raw Material
__2 2 10108582P1 1 HOLDER 2 EA (each) Purchased
__2 3 10108597P1 1 STUD AKD5 & AKD6 RETROFILL 2 EA (each) Purchased
__2 4 10108598P1 1 STUD AKD5 & AKD6 RETROFILL 1 EA (each) Purchased
__2 0 10107389PV1 2 PICVU 0 EA (each) Phantom
__2 1 10108586P1 1 LATCH AKD5 AND AKD6 RETROFILL 1 EA (each) Phantom
___3 CDE22608 0 7GA, HR, B8A5B2 0.9 LB (pound) Raw Material
__2 2 10107383P1 2 CLIP 1 EA (each) Phantom
___3 CDE22557 0 13GA, CR, B8A3A 0.223 LB (pound) Raw Material
__2 0 10108592PV1 1 PICVU 0 EA (each) Phantom
__2 1 10108593P1 1 HANDLE AKD5 & AKD6 RETROFILL 1 EA (each) Purchased
__2 2 10108594P1 1 GUIDE AKD5 & AKD6 RETROFILL 1 EA (each) Purchased
__2 1 10109184P1 1 PACKING BOX FOR BUMPEDOUT DOOR 1 EA (each) Purchased
__2 2 10102425P1 1 Small Bag 1 GM (gram) Purchased
__2 3 10102426P1 1 PET band 0 MT (meter) Purchased
__2 4 10102427P1 1 Paper Tape 0 MT (meter) Purchased
Seq#
_1 0 10108383PV1 1 PICVU 0 EA (each) Phantom
_1 1 10108382G1 1 DOOR WELDMENT- 27", 30",38" 1 EA (each) Phantom
_1 2 10107389G1 2 LATCH ASSEMBLY 1 EA (each) Phantom
_1 3 10108592G1 1 HANDLE ASSY 1 EA (each) Phantom
_1 4 N22P21008B6 0 BOLT,STEEL HEX 1/4-20X1/2 1 EA Purchased
_1 5 10106236P1 2 ESCUTCHEON SEAL 1 EA (each) Purchased
_1 6 10106237P1 2 ESCUTCHEON, AK-25 1 EA (each) Purchased
_1 7 10100923P2 3 CERRATED BELLEVILLE WASHER M3 12 EA (each) Purchased
_1 8 10102274P1 2 POZIDRIV CROSS RECESD PAN HEAD 12 EA (each) Purchased
_1 9 10108739P1 2 DOOR LABEL, RETROFILL 1 EA (each) Purchased
_1 10 10108741P1 2 CAUTION LABEL, RETROFILL 1 EA (each) Purchased
_1 11 10109181G1 1 PACKAGING FOR BUMPED OUT DOOR 1 EA (each) Phantom
Item Number Rev Description Quantity UM
Item Type
Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
31
DEH-41563 02/12
AK25 DOOR ASSY, 27” WITH LIGHT
Level
GCAT 10108380G1 AK25 DOOR ASSY, 27" WITH LIGHT 1 EA (each)
__2 0 10108379PV1 1 PICVU 0 EA (each) Phantom
__2 1 10108378P1 1 AK25 DOOR 27" WITH LIGHTS 1 EA (each) Phantom
___3 CDE22557 0 13GA, CR, B8A3A 33.01 LB (pound) Raw Material
__2 2 10108582P1 1 HOLDER 2 EA (each) Purchased
__2 3 10108597P1 1 STUD AKD5 & AKD6 RETROFILL 2 EA (each) Purchased
__2 4 10108598P1 1 STUD AKD5 & AKD6 RETROFILL 1 EA (each) Purchased
__2 0 10107389PV1 2 PICVU 0 EA (each) Phantom
__2 1 10108586P1 1 LATCH AKD5 AND AKD6 RETROFILL 1 EA (each) Phantom
___3 CDE22608 0 7GA, HR, B8A5B2 0.9 LB (pound) Raw Material
__2 2 10107383P1 2 CLIP 1 EA (each) Phantom
___3 CDE22557 0 13GA, CR, B8A3A 0.223 LB (pound) Raw Material
__2 0 10108592PV1 1 PICVU 0 EA (each) Phantom
__2 1 10108593P1 1 HANDLE AKD5 & AKD6 RETROFILL 1 EA (each) Purchased
__2 2 10108594P1 1 GUIDE AKD5 & AKD6 RETROFILL 1 EA (each) Purchased
__2 1 10109184P1 1 PACKING BOX FOR BUMPEDOUT DOOR 1 EA (each) Purchased
__2 2 10102425P1 1 Small Bag 1 GM (gram) Purchased
__2 3 10102426P1 1 PET band 0 MT (meter) Purchased
__2 4 10102427P1 1 Paper Tape 0 MT (meter) Purchased
Seq#
_1 0 10108380PV1 1 PICVU 0 EA (each) Phantom
_1 1 10108379G1 1 DOOR WELDMENT, 27" WITH LIGHTS 1 EA (each) Phantom
_1 2 10107389G1 2 LATCH ASSEMBLY 1 EA (each) Phantom
_1 3 10108592G1 1 HANDLE ASSY 1 EA (each) Phantom
_1 4 N22P21008B6 0 BOLT,STEEL HEX 1/4-20X1/2 1 EA Purchased
_1 5 10106236P1 2 ESCUTCHEON SEAL 1 EA (each) Purchased
_1 6 10106237P1 2 ESCUTCHEON, AK-25 1 EA (each) Purchased
_1 7 10100923P2 3 CERRATED BELLEVILLE WASHER M3 12 EA (each) Purchased
_1 8 10102274P1 2 POZIDRIV CROSS RECESD PAN HEAD 12 EA (each) Purchased
_1 9 10108739P1 2 DOOR LABEL, RETROFILL 1 EA (each) Purchased
_1 10 10108741P1 2 CAUTION LABEL, RETROFILL 1 EA (each) Purchased
_1 11 10109181G1 1 PACKAGING FOR BUMPED OUT DOOR 1 EA (each) Phantom
Item Number Rev Description Quantity UM
Item Type
DEH-41563 02/12
Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
32
AK25 DOOR ASSY, 27” WITH LIGHT
Level
GCAT 10106255G1 AK25 DOOR ASSY-27" 1 EA (each)
__2 0 10106246PV1 2 PICVU 0 EA (each) Phantom
__2 0 10106246PV1 2 PICVU 0 EA (each) Phantom
__2 1 10103367P1 2 DOOR, 27", RH 1 EA (each) Phantom
___3 CDE22557 0 13GA, CR, B8A3A 33.01 LB (pound) Raw Material
__2 2 10108582P1 1 HOLDER 2 EA (each) Purchased
__2 3 10108597P1 1 STUD AKD5 & AKD6 RETROFILL 2 EA (each) Purchased
__2 4 10108598P1 1 STUD AKD5 & AKD6 RETROFILL 1 EA (each) Purchased
__2 0 10107389PV1 2 PICVU 0 EA (each) Phantom
__2 1 10108586P1 1 LATCH AKD5 AND AKD6 RETROFILL 1 EA (each) Phantom
___3 CDE22608 0 7GA, HR, B8A5B2 0.9 LB (pound) Raw Material
__2 2 10107383P1 2 CLIP 1 EA (each) Phantom
___3 CDE22557 0 13GA, CR, B8A3A 0.223 LB (pound) Raw Material
__2 0 10108592PV1 1 PICVU 0 EA (each) Phantom
__2 1 10108593P1 1 HANDLE AKD5 & AKD6 RETROFILL 1 EA (each) Purchased
__2 2 10108594P1 1 GUIDE AKD5 & AKD6 RETROFILL 1 EA (each) Purchased
__2 CDE22556 0 11GA, CR, B8A3A 0.213 LB (pound) Raw Material
__2 1 10109184P1 1 PACKING BOX FOR BUMPEDOUT DOOR 1 EA (each) Purchased
__2 2 10102425P1 1 Small Bag 1 GM (gram) Purchased
__2 3 10102426P1 1 PET band 0 MT (meter) Purchased
__2 4 10102427P1 1 Paper Tape 0 MT (meter) Purchased
Seq#
_1 0 10106255PV1 2 PCVU 0 EA (each) Phantom
_1 0 10106255PV1 2 PCVU 0 EA (each) Phantom
_1 1 10106246G1 2 AK25 DOOR WELDMENT-27" 1 EA (each) Phantom
_1 2 10107389G1 2 LATCH ASSEMBLY 1 EA (each) Phantom
_1 3 10108592G1 1 HANDLE ASSY 1 EA (each) Phantom
_1 4 N22P21008B6 0 BOLT,STEEL HEX 1/4-20X1/2 1 EA Purchased
_1 5 10107388P1 2 DOOR INTERLOCK CATCH PLATE 1 EA (each) Phantom
_1 6 75V100058P104 7 RIVET POP 2 EA Purchased
_1 7 10106236P1 2 ESCUTCHEON SEAL 1 EA (each) Purchased
_1 8 10106237P1 2 ESCUTCHEON, AK-25 1 EA (each) Purchased
_1 9 10100923P2 3 CERRATED BELLEVILLE WASHER M3 12 EA (each) Purchased
_1 10 10102274P1 2 POZIDRIV CROSS RECESD PAN HEAD 12 EA (each) Purchased
_1 11 10108739P1 2 DOOR LABEL, RETROFILL 1 EA (each) Purchased
_1 12 10108741P1 2 CAUTION LABEL, RETROFILL 1 EA (each) Purchased
_1 13 10109181G1 1 PACKAGING FOR BUMPED OUT DOOR 1 EA (each) Phantom
Item Number Rev Description Quantity UM
Item Type
Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
33
DEH-41563 02/12
AKD-5 AK50
AK50 DOOR ASSY- 27”, 30”, 38”
Level
GCAT 10108355G1 AK50 DOOR ASSY- 27", 30", 38" 1
__2 0 10108354PV1 1 PICVU 0 EA (each) Phantom
__2 1 10108275P1 1 AK50 DOOR, 27", 30",38" 1 EA (each) Phantom
___3 CDE22557 0 13GA, CR, B8A3A 35.455 LB (pound) Raw Material
__2 2 10108582P1 1 HOLDER 3 EA (each) Purchased
__2 3 10108597P1 1 STUD AKD5 & AKD6 RETROFILL 2 EA (each) Purchased
__2 4 10108606P1 1 STUD AK50 -AKD5 & AKD6 1 EA (each) Purchased
__2 5 10108401P1 1 COVER FOR AKD5 AK50 DOOR 1 EA (each) Phantom
___3 CDE3454 0 B8A4C2 .067MIN.X45.000XCL 0.809 LB Raw Material
__2 0 10108585PV1 1 PICVU 0 EA (each) Phantom
__2 1 10108586P1 1 LATCH AKD5 AND AKD6 RETROFILL 1 EA (each) Phantom
___3 CDE22608 0 7GA, HR, B8A5B2 0.9 LB (pound) Raw Material
__2 2 10108589P1 1 CLIP AK50AKD5 & AKD6 RETROFILL 1 EA (each) Phantom
___3 CDE22557 0 13GA, CR, B8A3A 0.445 LB (pound) Raw Material
__2 0 10108592PV1 1 PICVU 0 EA (each) Phantom
__2 1 10108593P1 1 HANDLE AKD5 & AKD6 RETROFILL 1 EA (each) Purchased
__2 2 10108594P1 1 GUIDE AKD5 & AKD6 RETROFILL 1 EA (each) Purchased
__2 1 10109188P1 1 PACKING BOX NON BUMPEDOUT DOOR 1 EA (each) Purchased
__2 2 10102425P1 1 Small Bag 1 GM (gram) Purchased
__2 3 10102426P1 1 PET band 0 MT (meter) Purchased
__2 4 10102427P1 1 Paper Tape 0 MT (meter) Purchased
Seq#
_1 0 10108355PV1 1 PICVU 0 EA (each) Phantom
_1 1 10108354G1 1 DOOR WELDMENT- 27", 30",38" 1 EA (each) Phantom
_1 2 10108585G1 1 LATCH ASSY AK50 AKD5 AND AKD6 1 EA (each) Phantom
_1 3 10108592G1 1 HANDLE ASSY 1 EA (each) Phantom
_1 4 N22P21008B6 0 BOLT,STEEL HEX 1/4-20X1/2 1 EA Purchased
_1 5 10100045P1 2 ESCUTCHEON SEAL - DRAWOUT 1 EA (each) Phantom
_1 6 10100044P1 2 ESCUTCHEON - DRAWOUT 1 EA (each) Phantom
_1 7 10100923P2 3 CERRATED BELLEVILLE WASHER M3 12 EA (each) Purchased
_1 8 10102274P1 2 POZIDRIV CROSS RECESD PAN HEAD 12 EA (each) Purchased
_1 9 10108739P1 2 DOOR LABEL, RETROFILL 1 EA (each) Purchased
_1 10 10108741P1 2 CAUTION LABEL, RETROFILL 1 EA (each) Purchased
_1 11 10109193G1 1 PACKAGING NON BUMPED OUT DOOR 1 EA (each) Phantom
Item Number Rev Description Quantity UM
Item Type
DEH-41563 02/12
Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
34
AK50 DOOR ASSY, 20” WITH LIGHT
Level
GCAT 10108363G1 AK50 DOOR ASSY, 20" WITH LIGHT 1 EA (each)
__2 0 10108361PV1 1 PICVU 0 EA (each) Phantom
__2 1 10108276P1 1 AK50 DOOR WITH LIGHTS 1 EA (each) Phantom
___3 CDE22557 0 13GA, CR, B8A3A 35.455 LB (pound) Raw Material
__2 2 10108582P1 1 HOLDER 3 EA (each) Purchased
__2 3 10108597P1 1 STUD AKD5 & AKD6 RETROFILL 2 EA (each) Purchased
__2 4 10108606P1 1 STUD AK50 -AKD5 & AKD6 1 EA (each) Purchased
__2 5 10108401P1 1 COVER FOR AKD5 AK50 DOOR 1 EA (each) Phantom
___3 CDE3454 0 B8A4C2 .067MIN.X45.000XCL 0.809 LB Raw Material
__2 0 10108585PV1 1 PICVU 0 EA (each) Phantom
__2 1 10108586P1 1 LATCH AKD5 AND AKD6 RETROFILL 1 EA (each) Phantom
___3 CDE22608 0 7GA, HR, B8A5B2 0.9 LB (pound) Raw Material
__2 2 10108589P1 1 CLIP AK50AKD5 & AKD6 RETROFILL 1 EA (each) Phantom
___3 CDE22557 0 13GA, CR, B8A3A 0.445 LB (pound) Raw Material
__2 0 10108592PV1 1 PICVU 0 EA (each) Phantom
__2 1 10108593P1 1 HANDLE AKD5 & AKD6 RETROFILL 1 EA (each) Purchased
__2 2 10108594P1 1 GUIDE AKD5 & AKD6 RETROFILL 1 EA (each) Purchased
__2 1 10109188P1 1 PACKING BOX NON BUMPEDOUT DOOR 1 EA (each) Purchased
__2 2 10102425P1 1 Small Bag 1 GM (gram) Purchased
__2 3 10102426P1 1 PET band 0 MT (meter) Purchased
__2 4 10102427P1 1 Paper Tape 0 MT (meter) Purchased
Seq#
_1 0 10108363PV1 1 PICVU 0 EA (each) Phantom
_1 1 10108361G1 1 DOOR WELDMENT, 27" WITH LIGHTS 1 EA (each) Phantom
_1 2 10108585G1 1 LATCH ASSY AK50 AKD5 AND AKD6 1 EA (each) Phantom
_1 3 10108592G1 1 HANDLE ASSY 1 EA (each) Phantom
_1 4 N22P21008B6 0 BOLT,STEEL HEX 1/4-20X1/2 1 EA Purchased
_1 5 10100045P1 2 ESCUTCHEON SEAL - DRAWOUT 1 EA (each) Phantom
_1 6 10100044P1 2 ESCUTCHEON - DRAWOUT 1 EA (each) Phantom
_1 7 10100923P2 3 CERRATED BELLEVILLE WASHER M3 12 EA (each) Purchased
_1 8 10102274P1 2 POZIDRIV CROSS RECESD PAN HEAD 12 EA (each) Purchased
_1 9 10108739P1 2 DOOR LABEL, RETROFILL 1 EA (each) Purchased
_1 10 10108741P1 2 CAUTION LABEL, RETROFILL 1 EA (each) Purchased
_1 11 10109193G1 1 PACKAGING NON BUMPED OUT DOOR 1 EA (each) Phantom
Item Number Rev Description Quantity UM
Item Type
Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
35
DEH-41563 02/12
AK50 DOOR ASSY-27”, RH
Level
GCAT 10106248G1 AK50 DOOR ASSY-27", RH 1 EA (each)
__2 0 10106247PV1 2 PICVU 0 EA (each) Phantom
__2 0 10106247PV1 2 PICVU 0 EA (each) Phantom
__2 1 10103355P1 2 DOOR-27", AK50, RH 1 EA (each) Phantom
___3 CDE22557 0 13GA, CR, B8A3A 35.455 LB (pound) Raw Material
__2 2 10108582P1 1 HOLDER 3 EA (each) Purchased
__2 3 10108597P1 1 STUD AKD5 & AKD6 RETROFILL 2 EA (each) Purchased
__2 4 10108606P1 1 STUD AK50 -AKD5 & AKD6 1 EA (each) Purchased
__2 5 10108401P1 1 COVER FOR AKD5 AK50 DOOR 1 EA (each) Phantom
___3 CDE3454 0 B8A4C2 .067MIN.X45.000XCL 0.809 LB Raw Material
__2 0 10108585PV1 1 PICVU 0 EA (each) Phantom
__2 1 10108586P1 1 LATCH AKD5 AND AKD6 RETROFILL 1 EA (each) Phantom
___3 CDE22608 0 7GA, HR, B8A5B2 0.9 LB (pound) Raw Material
__2 2 10108589P1 1 CLIP AK50AKD5 & AKD6 RETROFILL 1 EA (each) Phantom
___3 CDE22557 0 13GA, CR, B8A3A 0.445 LB (pound) Raw Material
__2 0 10108592PV1 1 PICVU 0 EA (each) Phantom
__2 1 10108593P1 1 HANDLE AKD5 & AKD6 RETROFILL 1 EA (each) Purchased
__2 2 10108594P1 1 GUIDE AKD5 & AKD6 RETROFILL 1 EA (each) Purchased
__2 1 10109188P1 1 PACKING BOX NON BUMPEDOUT DOOR 1 EA (each) Purchased
__2 2 10102425P1 1 Small Desiccant Bag 1 GM (gram) Purchased
__2 3 10102426P1 1 PET band 0 MT (meter) Purchased
__2 4 10102427P1 1 Paper Tape 0 MT (meter) Purchased
Seq#
_1 0 10106248PV1 2 PICVU 0 EA (each) Phantom
_1 0 10106248PV1 2 PICVU 0 EA (each) Phantom
_1 1 10106247G1 2 AK50 DOOR WELDMENT-27", RH 1 EA (each) Phantom
_1 2 10108585G1 1 LATCH ASSY AK50 AKD5 AND AKD6 1 EA (each) Phantom
_1 3 10108592G1 1 HANDLE ASSY 1 EA (each) Phantom
_1 4 N22P21008B6 0 BOLT,STEEL HEX 1/4-20X1/2 1 EA Purchased
_1 6 75V100058P104 7 RIVET POP 2 EA Purchased
_1 7 10100045P1 2 ESCUTCHEON SEAL - DRAWOUT 1 EA (each) Phantom
_1 8 10100044P1 2 ESCUTCHEON - DRAWOUT 1 EA (each) Phantom
_1 9 10100923P2 3 CERRATED BELLEVILLE WASHER M3 12 EA (each) Purchased
_1 10 10102274P1 2 POZIDRIV CROSS RECESD PAN HEAD 12 EA (each) Purchased
_1 11 10108739P1 2 DOOR LABEL, RETROFILL 1 EA (each) Purchased
_1 12 10108741P1 2 CAUTION LABEL, RETROFILL 1 EA (each) Purchased
_1 13 10109193G1 1 PACKAGING NON BUMPED OUT DOOR 1 EA (each) Phantom
Item Number Rev Description Quantity UM
Item Type
DEH-41563 02/12
Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
36
AK50 DOOR ASSY- 27”, 30”, 38”
Level
GCAT 10108355G1 AK50 DOOR ASSY- 27", 30", 38" 1 EA (each)
__2 0 10108354PV1 1 PICVU 0 EA (each) Phantom
__2 1 10108275P1 1 AK50 DOOR, 27", 30",38" 1 EA (each) Phantom
___3 CDE22557 0 13GA, CR, B8A3A 35.455 LB (pound) Raw Material
__2 2 10108582P1 1 HOLDER 3 EA (each) Purchased
__2 3 10108597P1 1 STUD AKD5 & AKD6 RETROFILL 2 EA (each) Purchased
__2 4 10108606P1 1 STUD AK50 -AKD5 & AKD6 1 EA (each) Purchased
__2 5 10108401P1 1 COVER FOR AKD5 AK50 DOOR 1 EA (each) Phantom
___3 CDE3454 0 B8A4C2 .067MIN.X45.000XCL 0.809 LB Raw Material
__2 0 10108585PV1 1 PICVU 0 EA (each) Phantom
__2 1 10108586P1 1 LATCH AKD5 AND AKD6 RETROFILL 1 EA (each) Phantom
___3 CDE22608 0 7GA, HR, B8A5B2 0.9 LB (pound) Raw Material
__2 2 10108589P1 1 CLIP AK50AKD5 & AKD6 RETROFILL 1 EA (each) Phantom
___3 CDE22557 0 13GA, CR, B8A3A 0.445 LB (pound) Raw Material
__2 0 10108592PV1 1 PICVU 0 EA (each) Phantom
__2 1 10108593P1 1 HANDLE AKD5 & AKD6 RETROFILL 1 EA (each) Purchased
__2 2 10108594P1 1 GUIDE AKD5 & AKD6 RETROFILL 1 EA (each) Purchased
__2 1 10109188P1 1 PACKING BOX NON BUMPEDOUT DOOR 1 EA (each) Purchased
__2 2 10102425P1 1 Small Desiccant Bag 1 GM (gram) Purchased
__2 3 10102426P1 1 PET band 0 MT (meter) Purchased
__2 4 10102427P1 1 Paper Tape 0 MT (meter) Purchased
Seq#
_1 0 10108355PV1 1 PICVU 0 EA (each) Phantom
_1 1 10108354G1 1 DOOR WELDMENT- 27", 30",38" 1 EA (each) Phantom
_1 2 10108585G1 1 LATCH ASSY AK50 AKD5 AND AKD6 1 EA (each) Phantom
_1 3 10108592G1 1 HANDLE ASSY 1 EA (each) Phantom
_1 4 N22P21008B6 0 BOLT,STEEL HEX 1/4-20X1/2 1 EA Purchased
_1 5 10100045P1 2 ESCUTCHEON SEAL - DRAWOUT 1 EA (each) Phantom
_1 6 10100044P1 2 ESCUTCHEON - DRAWOUT 1 EA (each) Phantom
_1 7 10100923P2 3 CERRATED BELLEVILLE WASHER M3 12 EA (each) Purchased
_1 8 10102274P1 2 POZIDRIV CROSS RECESD PAN HEAD 12 EA (each) Purchased
_1 9 10108739P1 2 DOOR LABEL, RETROFILL 1 EA (each) Purchased
_1 10 10108741P1 2 CAUTION LABEL, RETROFILL 1 EA (each) Purchased
_1 11 10109193G1 1 PACKAGING NON BUMPED OUT DOOR 1 EA (each) Phantom
Item Number Rev Description Quantity UM
Item Type
Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
37
DEH-41563 02/12
AK50 DOOR ASSY, 20” WITH LIGHT
Level
GCAT 10108363G1 AK50 DOOR ASSY, 20" WITH LIGHT 1 EA (each)
__2 0 10108361PV1 1 PICVU 0 EA (each) Phantom
__2 1 10108276P1 1 AK50 DOOR WITH LIGHTS 1 EA (each) Phantom
___3 CDE22557 0 13GA, CR, B8A3A 35.455 LB (pound) Raw Material
__2 2 10108582P1 1 HOLDER 3 EA (each) Purchased
__2 3 10108597P1 1 STUD AKD5 & AKD6 RETROFILL 2 EA (each) Purchased
__2 4 10108606P1 1 STUD AK50 -AKD5 & AKD6 1 EA (each) Purchased
__2 5 10108401P1 1 COVER FOR AKD5 AK50 DOOR 1 EA (each) Phantom
___3 CDE3454 0 B8A4C2 .067MIN.X45.000XCL 0.809 LB Raw Material
__2 0 10108585PV1 1 PICVU 0 EA (each) Phantom
__2 1 10108586P1 1 LATCH AKD5 AND AKD6 RETROFILL 1 EA (each) Phantom
___3 CDE22608 0 7GA, HR, B8A5B2 0.9 LB (pound) Raw Material
__2 2 10108589P1 1 CLIP AK50AKD5 & AKD6 RETROFILL 1 EA (each) Phantom
___3 CDE22557 0 13GA, CR, B8A3A 0.445 LB (pound) Raw Material
__2 0 10108592PV1 1 PICVU 0 EA (each) Phantom
__2 1 10108593P1 1 HANDLE AKD5 & AKD6 RETROFILL 1 EA (each) Purchased
__2 2 10108594P1 1 GUIDE AKD5 & AKD6 RETROFILL 1 EA (each) Purchased
__2 1 10109188P1 1 PACKING BOX NON BUMPEDOUT DOOR 1 EA (each) Purchased
__2 2 10102425P1 1 Small Desiccant Bag 1 GM (gram) Purchased
__2 3 10102426P1 1 PET band 0 MT (meter) Purchased
__2 4 10102427P1 1 Paper Tape 0 MT (meter) Purchased
Seq#
_1 0 10108363PV1 1 PICVU 0 EA (each) Phantom
_1 1 10108361G1 1 DOOR WELDMENT, 27" WITH LIGHTS 1 EA (each) Phantom
_1 2 10108585G1 1 LATCH ASSY AK50 AKD5 AND AKD6 1 EA (each) Phantom
_1 3 10108592G1 1 HANDLE ASSY 1 EA (each) Phantom
_1 4 N22P21008B6 0 BOLT,STEEL HEX 1/4-20X1/2 1 EA Purchased
_1 5 10100045P1 2 ESCUTCHEON SEAL - DRAWOUT 1 EA (each) Phantom
_1 6 10100044P1 2 ESCUTCHEON - DRAWOUT 1 EA (each) Phantom
_1 7 10100923P2 3 CERRATED BELLEVILLE WASHER M3 12 EA (each) Purchased
_1 8 10102274P1 2 POZIDRIV CROSS RECESD PAN HEAD 12 EA (each) Purchased
_1 9 10108739P1 2 DOOR LABEL, RETROFILL 1 EA (each) Purchased
_1 10 10108741P1 2 CAUTION LABEL, RETROFILL 1 EA (each) Purchased
_1 11 10109193G1 1 PACKAGING NON BUMPED OUT DOOR 1 EA (each) Phantom
Item Number Rev Description Quantity UM
Item Type
DEH-41563 02/12
Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
38
AK50 DOOR ASSY-27”, RH
Level
GCAT 10106248G1 AK50 DOOR ASSY-27", RH 1 EA (each)
__2 0 10106247PV1 2 PICVU 0 EA (each) Phantom
__2 0 10106247PV1 2 PICVU 0 EA (each) Phantom
__2 1 10103355P1 2 DOOR-27", AK50, RH 1 EA (each) Phantom
___3 CDE22557 0 13GA, CR, B8A3A 35.455 LB (pound) Raw Material
__2 2 10108582P1 1 HOLDER 3 EA (each) Purchased
__2 3 10108597P1 1 STUD AKD5 & AKD6 RETROFILL 2 EA (each) Purchased
__2 4 10108606P1 1 STUD AK50 -AKD5 & AKD6 1 EA (each) Purchased
__2 5 10108401P1 1 COVER FOR AKD5 AK50 DOOR 1 EA (each) Phantom
___3 CDE3454 0 B8A4C2 .067MIN.X45.000XCL 0.809 LB Raw Material
__2 0 10108585PV1 1 PICVU 0 EA (each) Phantom
__2 1 10108586P1 1 LATCH AKD5 AND AKD6 RETROFILL 1 EA (each) Phantom
___3 CDE22608 0 7GA, HR, B8A5B2 0.9 LB (pound) Raw Material
__2 2 10108589P1 1 CLIP AK50AKD5 & AKD6 RETROFILL 1 EA (each) Phantom
___3 CDE22557 0 13GA, CR, B8A3A 0.445 LB (pound) Raw Material
__2 0 10108592PV1 1 PICVU 0 EA (each) Phantom
__2 1 10108593P1 1 HANDLE AKD5 & AKD6 RETROFILL 1 EA (each) Purchased
__2 2 10108594P1 1 GUIDE AKD5 & AKD6 RETROFILL 1 EA (each) Purchased
__2 1 10109188P1 1 PACKING BOX NON BUMPEDOUT DOOR 1 EA (each) Purchased
__2 2 10102425P1 1 Small Bag 1 GM (gram) Purchased
__2 3 10102426P1 1 PET band 0 MT (meter) Purchased
__2 4 10102427P1 1 Paper Tape 0 MT (meter) Purchased
Seq#
_1 0 10106248PV1 2 PICVU 0 EA (each) Phantom
_1 0 10106248PV1 2 PICVU 0 EA (each) Phantom
_1 1 10106247G1 2 AK50 DOOR WELDMENT-27", RH 1 EA (each) Phantom
_1 2 10108585G1 1 LATCH ASSY AK50 AKD5 AND AKD6 1 EA (each) Phantom
_1 3 10108592G1 1 HANDLE ASSY 1 EA (each) Phantom
_1 4 N22P21008B6 0 BOLT,STEEL HEX 1/4-20X1/2 1 EA Purchased
_1 6 75V100058P104 7 RIVET POP 2 EA Purchased
_1 7 10100045P1 2 ESCUTCHEON SEAL - DRAWOUT 1 EA (each) Phantom
_1 8 10100044P1 2 ESCUTCHEON - DRAWOUT 1 EA (each) Phantom
_1 9 10100923P2 3 CERRATED BELLEVILLE WASHER M3 12 EA (each) Purchased
_1 10 10102274P1 2 POZIDRIV CROSS RECESD PAN HEAD 12 EA (each) Purchased
_1 11 10108739P1 2 DOOR LABEL, RETROFILL 1 EA (each) Purchased
_1 12 10108741P1 2 CAUTION LABEL, RETROFILL 1 EA (each) Purchased
_1 13 10109193G1 1 PACKAGING NON BUMPED OUT DOOR 1 EA (each) Phantom
Item Number Rev Description Quantity UM
Item Type
Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
39
DEH-41563 02/12
AKD-6
AKD6 DOOR ASSY, 22”
Level
GCAT 10108439G1 AKD6 DOOR ASSY, 22" 1 EA (each)
__2 0 10108438PV1 1 PICVU 0 EA (each) Phantom
__2 1 10108437P1 1 AKD6 Door 22" 1 EA (each) Phantom
___3 CDE22557 0 13GA, CR, B8A3A 20.423 LB (pound) Raw Material
__2 2 10108582P1 1 HOLDER 2 EA (each) Purchased
__2 3 10108597P1 1 STUD AKD5 & AKD6 RETROFILL 3 EA (each) Purchased
__2 0 10108590PV1 1 PICVU 0 EA (each) Phantom
__2 1 10108591P1 1 LATCH AKD6 RETROFILL 1 EA (each) Phantom
___3 CDE22608 0 7GA, HR, B8A5B2 0.9 LB (pound) Raw Material
__2 2 10108589P1 1 CLIP AK50AKD5 & AKD6 RETROFILL 1 EA (each) Phantom
___3 CDE22557 0 13GA, CR, B8A3A 0.445 LB (pound) Raw Material
__2 0 10108592PV1 1 PICVU 0 EA (each) Phantom
__2 1 10108593P1 1 HANDLE AKD5 & AKD6 RETROFILL 1 EA (each) Purchased
__2 2 10108594P1 1 GUIDE AKD5 & AKD6 RETROFILL 1 EA (each) Purchased
__2 1 10109186P1 1 PACKING BOX NON BUMPEDOUT DOOR 1 EA (each) Purchased
__2 2 10102425P1 1 Small Desiccant Bag 1 GM (gram) Purchased
__2 3 10102426P1 1 PET band 0 MT (meter) Purchased
__2 4 10102427P1 1 Paper Tape 0 MT (meter) Purchased
Seq#
_1 0 10108439PV1 1 PICVU 0 EA (each) Phantom
_1 1 10108438G1 1 AKD6 DOOR WELDMENT, 22 1 EA (each) Phantom
_1 2 10108590G1 1 LATCH ASSY AKD6 RETROFILL 1 EA (each) Phantom
_1 3 10108592G1 1 HANDLE ASSY 1 EA (each) Phantom
_1 4 N22P21008B6 0 BOLT,STEEL HEX 1/4-20X1/2 1 EA Purchased
_1 5 10103363P1 2 ESCUTCHEON SEAL 1 EA (each) Purchased
_1 6 10103362P1 2 ESCUTCHEON 1 EA (each) Purchased
_1 7 10100923P2 3 CERRATED BELLEVILLE WASHER M3 12 EA (each) Purchased
_1 8 10102274P1 2 POZIDRIV CROSS RECESD PAN HEAD 11 EA (each) Purchased
_1 9 10108739P1 2 DOOR LABEL, RETROFILL 1 EA (each) Purchased
_1 10 10108741P1 2 CAUTION LABEL, RETROFILL 1 EA (each) Purchased
_1 11 10109189G1 1 PACKAGING NON BUMPED OUT DOOR 1 EA (each) Phantom
Item Number Rev Description Quantity UM
Item Type
DEH-41563 02/12
Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
40
AKD6 DOOR ASSY, 22” WITH LIGHT
Level
GCAT 10108447G1 AKD6 DOOR ASSY, 22" WITH LIGHT 1 EA (each)
__2 0 10108446PV1 1 PICVU 0 EA (each) Phantom
__2 1 10108440P1 1 AKD6 Door 22" WITH LIGHT 1 EA (each) Phantom
___3 CDE22557 0 13GA, CR, B8A3A 20.423 LB (pound) Raw Material
__2 2 10108582P1 1 HOLDER 2 EA (each) Purchased
__2 3 10108597P1 1 STUD AKD5 & AKD6 RETROFILL 3 EA (each) Purchased
__2 0 10108590PV1 1 PICVU 0 EA (each) Phantom
__2 1 10108591P1 1 LATCH AKD6 RETROFILL 1 EA (each) Phantom
___3 CDE22608 0 7GA, HR, B8A5B2 0.9 LB (pound) Raw Material
__2 2 10108589P1 1 CLIP AK50AKD5 & AKD6 RETROFILL 1 EA (each) Phantom
___3 CDE22557 0 13GA, CR, B8A3A 0.445 LB (pound) Raw Material
__2 0 10108592PV1 1 PICVU 0 EA (each) Phantom
__2 1 10108593P1 1 HANDLE AKD5 & AKD6 RETROFILL 1 EA (each) Purchased
__2 2 10108594P1 1 GUIDE AKD5 & AKD6 RETROFILL 1 EA (each) Purchased
__2 1 10109186P1 1 PACKING BOX NON BUMPEDOUT DOOR 1 EA (each) Purchased
__2 2 10102425P1 1 Small Desiccant Bag 1 GM (gram) Purchased
__2 3 10102426P1 1 PET band 0 MT (meter) Purchased
__2 4 10102427P1 1 Paper Tape 0 MT (meter) Purchased
Seq#
_1 0 10108447PV1 1 PICVU 0 EA (each) Phantom
_1 1 10108446G1 1 DOOR WELDMENT, 22" WITH LIGHT 1 EA (each) Phantom
_1 2 10108590G1 1 LATCH ASSY AKD6 RETROFILL 1 EA (each) Phantom
_1 3 10108592G1 1 HANDLE ASSY 1 EA (each) Phantom
_1 4 N22P21008B6 0 BOLT,STEEL HEX 1/4-20X1/2 1 EA Purchased
_1 5 10103363P1 2 ESCUTCHEON SEAL 1 EA (each) Purchased
_1 6 10103362P1 2 ESCUTCHEON 1 EA (each) Purchased
_1 7 10100923P2 3 CERRATED BELLEVILLE WASHER M3 12 EA (each) Purchased
_1 8 10102274P1 2 POZIDRIV CROSS RECESD PAN HEAD 12 EA (each) Purchased
_1 9 10108739P1 2 DOOR LABEL, RETROFILL 1 EA (each) Purchased
_1 10 10108741P1 2 CAUTION LABEL, RETROFILL 1 EA (each) Purchased
_1 11 10109189G1 1 PACKAGING NON BUMPED OUT DOOR 1 EA (each) Phantom
Item Number Rev Description Quantity UM
Item Type
Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
41
DEH-41563 02/12
Door Assembly of AKD6
Level
GCAT 10107469G1 Door Assembly of AKD6 1 EA (each)
__2 0 10106182PV1 2 PICVU 0 EA (each) Phantom
__2 1 10103370P1 2 DOOR-22", RH, AKD-6 1 EA (each) Phantom
___3 CDE22557 0 13GA, CR, B8A3A 20.423 LB (pound) Raw Material
__2 2 10108582P1 1 HOLDER 2 EA (each) Purchased
__2 3 10108597P1 1 STUD AKD5 & AKD6 RETROFILL 3 EA (each) Purchased
__2 0 10108590PV1 1 PICVU 0 EA (each) Phantom
__2 1 10108591P1 1 LATCH AKD6 RETROFILL 1 EA (each) Phantom
___3 CDE22608 0 7GA, HR, B8A5B2 0.9 LB (pound) Raw Material
__2 2 10108589P1 1 CLIP AK50AKD5 & AKD6 RETROFILL 1 EA (each) Phantom
___3 CDE22557 0 13GA, CR, B8A3A 0.445 LB (pound) Raw Material
__2 0 10108592PV1 1 PICVU 0 EA (each) Phantom
__2 1 10108593P1 1 HANDLE AKD5 & AKD6 RETROFILL 1 EA (each) Purchased
__2 2 10108594P1 1 GUIDE AKD5 & AKD6 RETROFILL 1 EA (each) Purchased
__2 1 10109186P1 1 PACKING BOX NON BUMPEDOUT DOOR 1 EA (each) Purchased
__2 2 10102425P1 1 Small Desiccant Bag 1 GM (gram) Purchased
__2 3 10102426P1 1 PET band 0 MT (meter) Purchased
__2 4 10102427P1 1 Paper Tape 0 MT (meter) Purchased
Seq#
_1 0 10107469PV1 2 PICVU 0 EA (each) Phantom
_1 1 10106182G1 2 DOOR ASSY, RH 1 EA (each) Phantom
_1 2 10108590G1 1 LATCH ASSY AKD6 RETROFILL 1 EA (each) Phantom
_1 3 10108592G1 1 HANDLE ASSY 1 EA (each) Phantom
_1 4 N22P21008B6 0 BOLT,STEEL HEX 1/4-20X1/2 1 EA Purchased
_1 5 10103363P1 2 ESCUTCHEON SEAL 1 EA (each) Purchased
_1 6 10103362P1 2 ESCUTCHEON 1 EA (each) Purchased
_1 7 10100923P2 3 CERRATED BELLEVILLE WASHER M3 12 EA (each) Purchased
_1 8 10102274P1 2 POZIDRIV CROSS RECESD PAN HEAD 12 EA (each) Purchased
_1 9 10108404P1 1 DOOR INTRLOCK CATCH PLATE AKD6 1 EA (each) Purchased
_1 10 75V100058P104 7 RIVET POP 2 EA Purchased
_1 11 10108739P1 2 DOOR LABEL, RETROFILL 1 EA (each) Purchased
_1 12 10108741P1 2 CAUTION LABEL, RETROFILL 1 EA (each) Purchased
_1 13 10109189G1 1 PACKAGING NON BUMPED OUT DOOR 1 EA (each) Phantom
Item Number Rev Description Quantity UM
Item Type
DEH-41563 02/12
Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
42
AKD6 27”,30” & 38” DOOR ASSY
Level
GCAT 10108462G1 AKD6 27",30" & 38" DOOR ASSY 1 EA (each)
__2 0 10108459PV1 1 PICVU 0 EA (each) Phantom
__2 1 10108457P1 1 AKD6 27",30"& 38" DOOR 1 EA (each) Phantom
___3 CDE22557 0 13GA, CR, B8A3A 20.213 LB (pound) Raw Material
__2 2 10108582P1 1 HOLDER 3 EA (each) Purchased
__2 3 10108597P1 1 STUD AKD5 & AKD6 RETROFILL 3 EA (each) Purchased
__2 0 10108590PV1 1 PICVU 0 EA (each) Phantom
__2 1 10108591P1 1 LATCH AKD6 RETROFILL 1 EA (each) Phantom
___3 CDE22608 0 7GA, HR, B8A5B2 0.9 LB (pound) Raw Material
__2 2 10108589P1 1 CLIP AK50AKD5 & AKD6 RETROFILL 1 EA (each) Phantom
___3 CDE22557 0 13GA, CR, B8A3A 0.445 LB (pound) Raw Material
__2 0 10108592PV1 1 PICVU 0 EA (each) Phantom
__2 1 10108593P1 1 HANDLE AKD5 & AKD6 RETROFILL 1 EA (each) Purchased
__2 2 10108594P1 1 GUIDE AKD5 & AKD6 RETROFILL 1 EA (each) Purchased
__2 1 10109186P1 1 PACKING BOX NON BUMPEDOUT DOOR 1 EA (each) Purchased
__2 2 10102425P1 1 Small Desiccant Bag 1 GM (gram) Purchased
__2 3 10102426P1 1 PET band 0 MT (meter) Purchased
__2 4 10102427P1 1 Paper Tape 0 MT (meter) Purchased
Seq#
_1 0 10108462PV1 1 PICVU 0 EA (each) Phantom
_1 1 10108459G1 1 AKD6 27",30" & 38" DOOR WELDME 1 EA (each) Phantom
_1 2 10108590G1 1 LATCH ASSY AKD6 RETROFILL 1 EA (each) Phantom
_1 3 10108592G1 1 HANDLE ASSY 1 EA (each) Phantom
_1 4 N22P21008B6 0 BOLT,STEEL HEX 1/4-20X1/2 1 EA Purchased
_1 5 10103363P1 2 ESCUTCHEON SEAL 1 EA (each) Purchased
_1 6 10103362P1 2 ESCUTCHEON 1 EA (each) Purchased
_1 7 10100923P2 3 CERRATED BELLEVILLE WASHER M3 12 EA (each) Purchased
_1 8 10102274P1 2 POZIDRIV CROSS RECESD PAN HEAD 12 EA (each) Purchased
_1 9 10108739P1 2 DOOR LABEL, RETROFILL 1 EA (each) Purchased
_1 10 10108741P1 2 CAUTION LABEL, RETROFILL 1 EA (each) Purchased
_1 11 10109189G1 1 PACKAGING NON BUMPED OUT DOOR 1 EA (each) Phantom
Item Number Rev Description Quantity UM
Item Type
Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
43
DEH-41563 02/12
AKD6 27” DOOR ASSY WITH LIGHTS
Level
GCAT 10108469G1 AKD6 27" DOOR ASSY WITH LIGHTS 1 EA (each)
__2 0 10108467PV1 1 PICVU 0 EA (each) Phantom
__2 1 10108464P1 1 AKD6 27" DOOR WITH LIGHTS 1 EA (each) Phantom
___3 CDE22557 0 13GA, CR, B8A3A 20.213 LB (pound) Raw Material
__2 2 10108582P1 1 HOLDER 3 EA (each) Purchased
__2 3 10108597P1 1 STUD AKD5 & AKD6 RETROFILL 3 EA (each) Purchased
__2 0 10108590PV1 1 PICVU 0 EA (each) Phantom
__2 1 10108591P1 1 LATCH AKD6 RETROFILL 1 EA (each) Phantom
___3 CDE22608 0 7GA, HR, B8A5B2 0.9 LB (pound) Raw Material
__2 2 10108589P1 1 CLIP AK50AKD5 & AKD6 RETROFILL 1 EA (each) Phantom
___3 CDE22557 0 13GA, CR, B8A3A 0.445 LB (pound) Raw Material
__2 0 10108592PV1 1 PICVU 0 EA (each) Phantom
__2 1 10108593P1 1 HANDLE AKD5 & AKD6 RETROFILL 1 EA (each) Purchased
__2 2 10108594P1 1 GUIDE AKD5 & AKD6 RETROFILL 1 EA (each) Purchased
__2 1 10109186P1 1 PACKING BOX NON BUMPEDOUT DOOR 1 EA (each) Purchased
__2 2 10102425P1 1 Small Desiccant Bag 1 GM (gram) Purchased
__2 3 10102426P1 1 PET band 0 MT (meter) Purchased
__2 4 10102427P1 1 Paper Tape 0 MT (meter) Purchased
Seq#
_1 0 10108469PV1 1 PICVU 0 EA (each) Phantom
_1 1 10108467G1 1 DOOR 27" WELDMENT WITH LIGHTS 1 EA (each) Phantom
_1 2 10108590G1 1 LATCH ASSY AKD6 RETROFILL 1 EA (each) Phantom
_1 3 10108592G1 1 HANDLE ASSY 1 EA (each) Phantom
_1 4 N22P21008B6 0 BOLT,STEEL HEX 1/4-20X1/2 1 EA Purchased
_1 5 10103363P1 2 ESCUTCHEON SEAL 1 EA (each) Purchased
_1 6 10103362P1 2 ESCUTCHEON 1 EA (each) Purchased
_1 7 10100923P2 3 CERRATED BELLEVILLE WASHER M3 12 EA (each) Purchased
_1 8 10102274P1 2 POZIDRIV CROSS RECESD PAN HEAD 12 EA (each) Purchased
_1 9 10108739P1 2 DOOR LABEL, RETROFILL 1 EA (each) Purchased
_1 10 10108741P1 2 CAUTION LABEL, RETROFILL 1 EA (each) Purchased
_1 11 10109189G1 1 PACKAGING NON BUMPED OUT DOOR 1 EA (each) Phantom
Item Number Rev Description Quantity UM
Item Type
DEH-41563 02/12
Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
44
AKD6 27 & 30” DOOR ASSY
Level
GCAT 10108074G1 AKD6 27 & 30" DOOR ASSY 1 EA (each)
__2 0 10108073PV1 1 PCVU 0 EA (each) Phantom
__2 1 10108072P1 1 DOOR AKD6 27&30" 1 EA (each) Phantom
___3 CDE22557 0 13GA, CR, B8A3A 20.213 LB (pound) Raw Material
__2 2 10108582P1 1 HOLDER 3 EA (each) Purchased
__2 3 10108597P1 1 STUD AKD5 & AKD6 RETROFILL 3 EA (each) Purchased
__2 0 10108590PV1 1 PICVU 0 EA (each) Phantom
__2 1 10108591P1 1 LATCH AKD6 RETROFILL 1 EA (each) Phantom
___3 CDE22608 0 7GA, HR, B8A5B2 0.9 LB (pound) Raw Material
__2 2 10108589P1 1 CLIP AK50AKD5 & AKD6 RETROFILL 1 EA (each) Phantom
___3 CDE22557 0 13GA, CR, B8A3A 0.445 LB (pound) Raw Material
__2 0 10108592PV1 1 PICVU 0 EA (each) Phantom
__2 1 10108593P1 1 HANDLE AKD5 & AKD6 RETROFILL 1 EA (each) Purchased
__2 2 10108594P1 1 GUIDE AKD5 & AKD6 RETROFILL 1 EA (each) Purchased
__2 1 10109186P1 1 PACKING BOX NON BUMPEDOUT DOOR 1 EA (each) Purchased
__2 2 10102425P1 1 Small Desiccant Bag 1 GM (gram) Purchased
__2 3 10102426P1 1 PET band 0 MT (meter) Purchased
__2 4 10102427P1 1 Paper Tape 0 MT (meter) Purchased
Seq#
_1 0 10108074PV1 1 PCVU 0 EA (each) Phantom
_1 1 10108073G1 1 AKD6 27 & 30" DOORWELDMENT 1 EA (each) Phantom
_1 2 10108590G1 1 LATCH ASSY AKD6 RETROFILL 1 EA (each) Phantom
_1 3 10108592G1 1 HANDLE ASSY 1 EA (each) Phantom
_1 4 N22P21008B6 0 BOLT,STEEL HEX 1/4-20X1/2 1 EA Purchased
_1 5 10103363P1 2 ESCUTCHEON SEAL 1 EA (each) Purchased
_1 6 10103362P1 2 ESCUTCHEON 1 EA (each) Purchased
_1 7 10100923P2 3 CERRATED BELLEVILLE WASHER M3 12 EA (each) Purchased
_1 8 10102274P1 2 POZIDRIV CROSS RECESD PAN HEAD 12 EA (each) Purchased
_1 9 10108404P1 1 DOOR INTRLOCK CATCH PLATE AKD6 1 EA (each) Purchased
_1 10 75V100058P104 7 RIVET POP 2 EA Purchased
_1 11 10108739P1 2 DOOR LABEL, RETROFILL 1 EA (each) Purchased
_1 12 10108741P1 2 CAUTION LABEL, RETROFILL 1 EA (each) Purchased
_1 13 10109189G1 1 PACKAGING NON BUMPED OUT DOOR 1 EA (each) Phantom
Item Number Rev Description Quantity UM
Item Type
Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
45
DEH-41563 02/12
AKD-8
DOOR ASSY, AKD8 AKR30H
Level
GCAT 10106239G1 DOOR ASSY, AKD8 AKR30H 1 EA (each)
__2 CDE22557 0 13GA, CR, B8A3A 15.16 LB (pound) Raw Material
__2 R/M 45130172 1 B8A3A .112 X 49 X 120 0.0651 LB (pound) KB Purchase Stock
__2 2 75C149310P002 14 2P!BOTTOM HINGE PLT 1 PC (piece) Manufactured
___3 R/M 52140127 1 B4A2C .187 X .75 0.121 LB (pound) KB Purchase Stock
__2 3 75A106200P201 10 WP! HINGE PIN "SIENNA" 1 PC (piece) Purchased
__2 1 75C149310P001 14 WP! TOP HINGE PLATE 1 PC (piece) Manufactured
___3 R/M 52140127 1 B4A2C .187 X .75 0.121 LB (pound) KB Purchase Stock
__2 3 75A106200P201 10 WP! HINGE PIN "SIENNA" 1 PC (piece) Purchased
__2 1 10109186P1 1 PACKING BOX NON BUMPEDOUT DOOR 1 EA (each) Purchased
__2 2 10102425P1 1 Small Desiccant Bag 1 GM (gram) Purchased
__2 3 10102426P1 1 PET band 0 MT (meter) Purchased
__2 4 10102427P1 1 Paper Tape 0 MT (meter) Purchased
Seq#
_1 0 10106239PV1 2 PICVU 0 EA (each) Phantom
_1 1 10102751P1 2 AKD8 DOOR 22" 1 EA (each) Phantom
_1 2 10106237P1 2 ESCUTCHEON, AK-25 1 EA (each) Purchased
_1 3 10106444P1 2 ESCUTCHEON SEAL 1 EA (each) Purchased
_1 4 10106452P1 2 GASKET SPT, SIDES. AKD8 2 EA (each) Purchased
_1 5 10106453P1 2 GASKET SPT, TOP & BTM 2 EA (each) Purchased
_1 6 10100923P2 3 CERRATED BELLEVILLE WASHER M3 12 EA (each) Purchased
_1 7 10102274P1 2 POZIDRIV CROSS RECESD PAN HEAD 12 EA (each) Purchased
_1 8 75C149385P014 12 BRACKET 1 PC (piece) KB Stock Make
_1 9 75V100058P104 7 RIVET POP 2 EA Purchased
_1 10 75C149310G002 14 HINGE PIN 1 PC (piece) RO Make
_1 11 N84P16006B6 0 SCREW,STEEL MACH 10-32X3/8 4 EA Purchased
_1 12 75C149310G001 14 HINGEPIN 1 PC (piece) RO Make
_1 13 0317A8780P001 5 HANDLE-NONLOCKING 1 PC (piece) Purchased
_1 14 10108739P1 2 DOOR LABEL, RETROFILL 1 EA (each) Purchased
_1 15 10108741P1 2 CAUTION LABEL, RETROFILL 1 EA (each) Purchased
_1 16 10109189G1 1 PACKAGING NON BUMPED OUT DOOR 1 EA (each) Phantom
Item Number Rev Description Quantity UM
Item Type
DEH-41563 02/12
Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
46
AKD8 AKR30/50 30” DOOR ASSY
Level
GCAT 10108088G1 AKD8 AKR30/50 30" DOOR ASSY 1 EA (each)
__2 CDE22557 0 13GA, CR, B8A3A 20.213 LB (pound) Raw Material
__2 R/M 45130172 1 B8A3A .112 X 49 X 120 0.0651 LB (pound) KB Purchase Stock
__2 2 75C149310P002 14 2P!BOTTOM HINGE PLT 1 PC (piece) Manufactured
___3 R/M 52140127 1 B4A2C .187 X .75 0.121 LB (pound) KB Purchase Stock
__2 3 75A106200P201 10 WP! HINGE PIN "SIENNA" 1 PC (piece) Purchased
__2 1 75C149310P001 14 WP! TOP HINGE PLATE 1 PC (piece) Manufactured
___3 R/M 52140127 1 B4A2C .187 X .75 0.121 LB (pound) KB Purchase Stock
__2 3 75A106200P201 10 WP! HINGE PIN "SIENNA" 1 PC (piece) Purchased
__2 1 10109188P1 1 PACKING BOX NON BUMPEDOUT DOOR 1 EA (each) Purchased
__2 2 10102425P1 1 Small Desiccant Bag 1 GM (gram) Purchased
__2 3 10102426P1 1 PET band 0 MT (meter) Purchased
__2 4 10102427P1 1 Paper Tape 0 MT (meter) Purchased
Seq#
_1 0 10108088PV1 1 PCVU 0 EA (each) Phantom
_1 1 10106244P1 2 DOOR, AKD8-30" 1 EA (each) Phantom
_1 2 10106237P1 2 ESCUTCHEON, AK-25 1 EA (each) Purchased
_1 3 10106444P1 2 ESCUTCHEON SEAL 1 EA (each) Purchased
_1 4 10106452P1 2 GASKET SPT, SIDES. AKD8 2 EA (each) Purchased
_1 5 10106453P1 2 GASKET SPT, TOP & BTM 2 EA (each) Purchased
_1 6 10100923P2 3 CERRATED BELLEVILLE WASHER M3 12 EA (each) Purchased
_1 7 10102274P1 2 POZIDRIV CROSS RECESD PAN HEAD 12 EA (each) Purchased
_1 8 75C149385P014 12 BRACKET 1 PC (piece) KB Stock Make
_1 9 75V100058P104 7 RIVET POP 2 EA Purchased
_1 10 75C149310G002 14 HINGE PIN 1 PC (piece) RO Make
_1 11 N84P16006B6 0 SCREW,STEEL MACH 10-32X3/8 4 EA Purchased
_1 12 0317A8780P001 5 HANDLE-NONLOCKING 1 PC (piece) Purchased
_1 13 75C149310G001 14 HINGEPIN 1 PC (piece) RO Make
_1 14 10108739P1 2 DOOR LABEL, RETROFILL 1 EA (each) Purchased
_1 15 10108741P1 2 CAUTION LABEL, RETROFILL 1 EA (each) Purchased
_1 16 10109193G1 1 PACKAGING NON BUMPED OUT DOOR 1 EA (each) Phantom
Item Number Rev Description Quantity UM
Item Type
Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
47
DEH-41563 02/12
AKR30S 22” DOOR ASSY
Level
GCAT 10108088G1 AKD8 AKR30/50 30" DOOR ASSY 1 EA (each)
__2 CDE22557 0 13GA, CR, B8A3A 31.787 LB (pound) Raw Material
__2 R/M 45130172 1 B8A3A .112 X 49 X 120 0.0651 LB (pound) KB Purchase Stock
__2 2 75C149310P002 14 2P!BOTTOM HINGE PLT 1 PC (piece) Manufactured
___3 R/M 52140127 1 B4A2C .187 X .75 0.121 LB (pound) KB Purchase Stock
__2 3 75A106200P201 10 WP! HINGE PIN "SIENNA" 1 PC (piece) Purchased
__2 1 75C149310P001 14 WP! TOP HINGE PLATE 1 PC (piece) Manufactured
___3 R/M 52140127 1 B4A2C .187 X .75 0.121 LB (pound) KB Purchase Stock
__2 3 75A106200P201 10 WP! HINGE PIN "SIENNA" 1 PC (piece) Purchased
__2 1 10109184P1 1 PACKING BOX FOR BUMPEDOUT DOOR 1 EA (each) Purchased
__2 2 10102425P1 1 Small Desiccant Bag 1 GM (gram) Purchased
__2 3 10102426P1 1 PET band 0 MT (meter) Purchased
__2 4 10102427P1 1 Paper Tape 0 MT (meter) Purchased
Seq#
_1 0 10108089PV1 1 PCVU 0 EA (each) Phantom
_1 1 10102710P1 2 AKR30S front door 1 EA (each) Phantom
_1 2 10106237P1 2 ESCUTCHEON, AK-25 1 EA (each) Purchased
_1 3 10106444P1 2 ESCUTCHEON SEAL 1 EA (each) Purchased
_1 4 10106452P1 2 GASKET SPT, SIDES. AKD8 2 EA (each) Purchased
_1 5 10106453P1 2 GASKET SPT, TOP & BTM 2 EA (each) Purchased
_1 6 10100923P2 3 CERRATED BELLEVILLE WASHER M3 12 EA (each) Purchased
_1 7 10102274P1 2 POZIDRIV CROSS RECESD PAN HEAD 12 EA (each) Purchased
_1 8 75C149385P014 12 BRACKET 1 PC (piece) KB Stock Make
_1 9 75V100058P104 7 RIVET POP 2 EA Purchased
_1 10 75C149310G002 14 HINGE PIN 1 PC (piece) RO Make
_1 11 N84P16006B6 0 SCREW,STEEL MACH 10-32X3/8 4 EA Purchased
_1 12 0317A8780P001 5 HANDLE-NONLOCKING 1 PC (piece) Purchased
_1 13 75C149310G001 14 HINGEPIN 1 PC (piece) RO Make
_1 14 10108739P1 2 DOOR LABEL, RETROFILL 1 EA (each) Purchased
_1 15 10108741P1 2 CAUTION LABEL, RETROFILL 1 EA (each) Purchased
_1 16 10109181G1 1 PACKAGING FOR BUMPED OUT DOOR 1 EA (each) Phantom
Item Number Rev Description Quantity UM
Item Type
DEH-41563 02/12
Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
48
AKR30S 30” DOOR ASSY
Level
GCAT 10108090G1 1 AKR30S 30" DOOR ASSY 1 EA (each)
__2 CDE22557 0 13GA, CR, B8A3A 30.564 LB (pound) Raw Material
__2 R/M 45130172 1 B8A3A .112 X 49 X 120 0.0651 LB (pound) KB Purchase Stock
__2 2 75C149310P002 14 2P!BOTTOM HINGE PLT 1 PC (piece) Manufactured
___3 R/M 52140127 1 B4A2C .187 X .75 0.121 LB (pound) KB Purchase Stock
__2 3 75A106200P201 10 WP! HINGE PIN "SIENNA" 1 PC (piece) Purchased
__2 1 75C149310P001 14 WP! TOP HINGE PLATE 1 PC (piece) Manufactured
___3 R/M 52140127 1 B4A2C .187 X .75 0.121 LB (pound) KB Purchase Stock
__2 3 75A106200P201 10 WP! HINGE PIN "SIENNA" 1 PC (piece) Purchased
__2 1 10109187P1 1 PACKING BOX FOR BUMPEDOUT DOOR 1 EA (each) Purchased
__2 2 10102425P1 1 Small Bag 1 GM (gram) Purchased
__2 3 10102426P1 1 PET band 0 MT (meter) Purchased
__2 4 10102427P1 1 Paper Tape 0 MT (meter) Purchased
Seq#
_1 0 10108090PV1 1 PCVU 0 EA (each) Phantom
_1 1 10103266P1 2 Door, AKR30S- 30" 1 EA (each) Phantom
_1 2 10106237P1 2 ESCUTCHEON, AK-25 1 EA (each) Purchased
_1 3 10106444P1 2 ESCUTCHEON SEAL 1 EA (each) Purchased
_1 4 10106452P1 2 GASKET SPT, SIDES. AKD8 2 EA (each) Purchased
_1 5 10106453P1 2 GASKET SPT, TOP & BTM 2 EA (each) Purchased
_1 6 10100923P2 3 CERRATED BELLEVILLE WASHER M3 12 EA (each) Purchased
_1 7 10102274P1 2 POZIDRIV CROSS RECESD PAN HEAD 12 EA (each) Purchased
_1 8 75C149385P014 12 BRACKET 1 PC (piece) KB Stock Make
_1 9 75V100058P104 7 RIVET POP 2 EA Purchased
_1 10 75C149310G002 14 HINGE PIN 1 PC (piece) RO Make
_1 11 N84P16006B6 0 SCREW,STEEL MACH 10-32X3/8 4 EA Purchased
_1 12 0317A8780P001 5 HANDLE-NONLOCKING 1 PC (piece) Purchased
_1 13 75C149310G001 14 HINGEPIN 1 PC (piece) RO Make
_1 14 10108739P1 2 DOOR LABEL, RETROFILL 1 EA (each) Purchased
_1 15 10108741P1 2 CAUTION LABEL, RETROFILL 1 EA (each) Purchased
_1 16 10109191G1 1 PACKAGING FOR BUMPED OUT DOOR 1 EA (each) Phantom
Item Number Rev Description Quantity UM
Item Type
Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
49
DEH-41563 02/12
Notes
DEH-41563 02/12
Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
50
GE Energy
41 Woodford Avenue Plainville, CT 06062 www.geindustrial.com
© 2012 GE Company
DEH-41563 02/12
Loading...
