GE 45605 User Manual

Wireless Lighting Control

Duplex
Receptacle

Z-Wave®Certified
Wireless Lighting Control

45605

Introduction:
Thank you for your purchase of a GE Z-Wave® control device.

Z-Wave technology is designed to automate lighting/home
control and provide easy remote operation of all your Z-wave
enabled devices. The GE Z-Wave product family includes a
variety of devices to control lighting in your home. It is up
to you whether you want to control one room or your entire
house and whether you want to do it all now or
start with one room and add more over time.

This duplex receptacle is one component
of a Z-Wave® control system and is
designed to work with all other Z-Wave
enabled devices in a home control
network. It will also act as a wireless
repeater to insure that commands
intended for another device in the
network are received, thereby
extending the range of the
wireless controller. Z-Wave
devices of other types and
brands can be added to the
system and will also act as
range extenders if they
support this function of
repeating the signal
received to other nodes
in the system.

The device plugged into the Z-Wave controlled outlet on this

This device is intended for installation in accordance
with the National Electric Code and local regulations
in the United States, or the Canadian Electrical Code
and local regulations in Canada. If you are unsure or
uncomfortable about performing this installation
consult a qualified electrician.

CAUTION

NOT FOR USE WITH MEDICAL OR LIFE SUPPORT EQUIPMENT

Z-Wave enabled devices should never be used to supply power
to, or control the On/Off status of medical and/or life support
equipment.

module must not exceed 600 watts (Incandescent);
15 Amps, 1800W (Resistive); or ½ HP (Motor). The maximum
rating for both outlets combined is 1800W (15A) Resistive.

There are no user serviceable parts in this unit.

Always-on Receptacle

Manual/Program Button

Z-Wave Receptacle

WARNING

RISK OF FIRE
RISK OF ELECTRICAL SHOCK
RISK OF BURNS

Controlling Appliances:

Exercise extreme caution when using Z-Wave devices to control
appliances. Operation of the Z-Wave device may be in a different
room than the controlled appliance, also an unintentional activation
may occur if the wrong button on the remote is pressed. Z-Wave
devices may automatically be powered on due to timed event
programming. Depending upon the appliance, these unattended
or unintentional operations could possibly result in a hazardous
condition. For these reasons, we recommend the following:

Assign Z-Wave controlled appliances to device numbers

1.

10 – 18 on the GE remote. The likelihood of unintentionally
turning on the appliance will be reduced significantly
because the “Shift” button will need to be pressed before
pressing device numbers 10-18.

Z-Wave devices controlling appliances should be removed

2.

from “All” control setting. Instructions on how to do this
are included in the manual for your GE remote.

Do Not include Z-Wave devices in Groups or Scenes if they

3.

control appliances.
Do Not use Z-Wave devices to control electric heaters or

4.

any other appliances which may present a hazardous
condition due to unattended or unintentional or automatic
power on control.

Double check programs for accuracy before using them.

5.
