Furuno FAR-2018-MARK-2 Operator's Manual

OPERATOR'S MANUAL

MARINE RADAR

FAR-2218 FAR-2218-BB FAR-2228 FAR-2228-BB FAR-2228-NXT FAR-2228-NXT-BB FAR-2238S

Model

FAR-2238S-BB FAR-2238S-NXT FAR-2238S-NXT-BB FAR-2318 FAR-2328 FAR-2328-NXT FAR-2328W FAR-2338SW FAR-2338S FAR-2338S-NXT FAR-2018-MARK-2 FAR-2028-MARK-2

www.furuno.com

9-52 Ashihara-cho,

A:NOV

2017

N2:APR.15, 2024

Pub. No.

(

)

Nishinomiya, 662-8580, JAPAN

・FURUNO Authorized Distributor/Dealer

REFU

FAR-2xx8 series

Printed in Japan

OME-36520-N2

0 0 0 1 9 9 5 2 7 1 2

IMPORTANT NOTICES

General

• This manual has been authored with simplified grammar, to meet the needs of international users.

• The operator of this equipment must read and follow the instructions in this manual. Wrong operation or maintenance can void the warranty or cause injury.

• Do not copy any part of this manual without written permission from FURUNO.

• If this manual is lost or worn, contact your dealer about replacement.

• The contents of this manual and the equipment specifications can change without notice.

• The example screens (or illustrations) shown in this manual can be different from the screens you see on your display. The screens you see depend on your system configuration and equipment settings.

• Save this manual for future reference.

• Any modification of the equipment (including software) by persons not authorized by FURUNO will void the warranty.

• The following concern acts as our importer in Europe, as defined in DECISION No 768/2008/EC.

- Name: FURUNO EUROPE B.V.

- Address: Siriusstraat 86, 5015 BT, Tilburg, The Netherlands

• The following concern acts as our importer in UK, as defined in SI 2016/1025 as amended SI 2019/

470.

- Name: FURUNO (UK) LTD.

- Address: West Building Penner Road Havant Hampshire PO9 1QY, U.K.

™

• InstantAccess bar

• SDHC is a registered trademark of SD-3C, LLC.

• All brand, product names, trademarks, registered trademarks, and service marks belong to their respective holders.

is a registered trademark of FURUNO Electric co., Ltd.

How to discard this product

Discard this product according to local regulations for the disposal of industrial waste. For disposal in the USA, see the homepage of the Electronics Industries Alliance (http://www.eiae.org/) for the correct method of disposal.

How to discard a used battery

Some FURUNO products have a battery(ies). To see if your product has a battery, see the chapter on Maintenance. If a battery is used, tape the + and - terminals of the battery before disposal to prevent fire, heat generation caused by short circuit.

In the European Union The crossed-out trash can symbol indicates that all types of batteries must not be discarded in standard trash, or at a trash site. Take the used batteries to a battery collection site according to your national legislation and the Batteries Directive 2006/66/EU.

In the USA The Mobius loop symbol (three chasing arrows) indicates that Ni-Cd and lead-acid rechargeable batteries must be recycled. Take the used batteries to a battery collection site according to local laws.

In the other countries There are no international standards for the battery recycle symbol. The number of symbols can increase when the other countries make their own recycle symbols in the future.

Ni-Cd Pb

SAFETY INSTRUCTIONS

WARNINGWARNING

Before servicing the radar, turn off the appropriate external breaker.

ELECTRICAL SHOCK HAZARD. Do not open the equipment.

Turn off the radar power switch before servicing the antenna unit. Post a warning sign near the switch indicating it should not be turned on while the antenna unit is being serviced.

Only qualified personnel should work inside the equipment.

Use the proper fuse.

Use of a wrong fuse can result in damage to the equipment or cause fire.

If the antenna rotates while there is personnel nearby or servicing the antenna, injury or death may result.

Do not place liquid-filled containers near the equipment.

Fire or electrical shock can result if a liquid spills into the equipment.

Do not operate the equipment with wet hands.

Electrical shock can result.

Keep heater away from equipment.

Heat can alter equipment shape and melt the power cord, which can cause fire or electrical shock.

Do not disassemble or modify the equipment.

Fire, electrical shock or serious injury can result.

Immediately turn off the power at the ship’s mains switchboard if water leaks into the equipment or the equipment is emitting smoke or fire.

Continued use can cause fatal damage to the equipment.

This equipment has a valid latitude range of 85°N to 85°S. Operation outside of this range can result in a larger margin of error when calculating position, heading, bearing, etc.

Power is not removed from the radar simply by turning off its power switch.

DANGER

WARNING

CAUTION

The operator must read the applicable safety instructions before attempting to operate the equipment.

Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.

Indicates a potentially hazardous situation which, if not avoided, could result in minor or moderate injury.

Warning, Caution Prohibitive Action Mandatory Action

SAFETY INSTRUCTIONS

WARNING

Keep the area around the antenna free of ropes and other items that may get tangled.

If the antenna becomes tangled,

Make sure no rain or water splash leaks into the equipment.

Fire or electrical shock can result if water leaks into the equipment.

WARNING

damage to the equipment or injury to personnel may occur.

WARNING

Radio Frequency Radiation Hazard

The radar antenna emits electromagnetic radio frequency (RF) energy that can be harmful, particularly to your eyes. Never look directly into the antenna aperture from a close distance while the radar is in operation or expose yourself to the transmitting antenna at a close distance. Distances at which RF radiation level of 100, 50 and 10 W/m

Note: If the antenna unit is installed at a close distance in front of the wheel house, your administration may require halt of transmission within a certain sector of antenna revolution. This is possible. Ask your FURUNO representative or dealer to provide this feature.

Magnetron radar

Solid state radar

*: The following numerical values, shown in the antenna types, indicate antenna length. [12]: 4 ft, [20]: 6.5 ft, [24]: 8 ft, [30]: 10 ft, [36]: 12 ft

**: Unavailable on IMO-type radars ***: 500 W, for Japanese flag vessels.

are given in the table below.

Model Transceiver

FAR-2218(-BB) FAR-2318

FAR-2018-MARK-2

FAR-2228(-BB) FAR-2328

FAR-2328W

FAR-2028-MARK-2

FAR-2238S(-BB) FAR-2338S

FAR-2338SW

FAR-2228-NXT(-BB) FAR-2328-NXT

FAR-2238S-NXT(-BB) FAR-2338S-NXT

RTR-105 (12 kW)

RTR-131 (12 kW)

RTR-106 (25 kW)

RTR-108 (25 kW)

RTR-132 (25 kW)

RTR-107 (30 kW)

RTR-109 (30 kW)

RTR-111 (250 W)

RTR-123

(600 W***)

Magnetron

FNE1201

MG5436

MG5223F

Antenna*

XN12CF XN20CF XN24CF XN12AF XN20AF XN24AF XN12CF XN20CF XN24CF XN20CF XN24CF XN12AF XN20AF XN24AF SN24CF** SN30CF** SN36CF SN36CF XN12CF XN20CF XN24CF SN24CF** SN30CF** SN36CF

100 W/m

0.6 m

0.4 m

0.3 m

0.25 m

0.17 m N/A

1.3 m

1.0 m

0.7 m

0.5 m

0.3 m

0.82 m

0.51 m

0.3 m

1.7 m

1.4 m N/A N/A

0.3 m

0.24 m

0.19 m N/A N/A N/A

50 W/m

1.4 m

0.9 m

0.6 m

0.73 m

0.42 m

0.28 m

2.7 m

1.7 m

1.3 m

1.2 m

0.9 m

1.8 m

0.93 m

0.7 m

2.4 m

2.1 m

0.5 m

0.26 m

0.7 m

0.32 m

0.29 m N/A N/A N/A

10 W/m

4.4 m

3.0 m

2.5 m

4.2 m

2.6 m

1.73 m

9.5 m

6.8 m

5.5 m

4.0 m

8.84 m

5.76 m

4.01 m

3.8 m

3.4 m

4.6 m

2.3 m

3.3 m

1.9 m

1.6 m

N/A N/A N/A

iii

SAFETY INSTRUCTIONS

Name: Warning Label 1 Type: 86-003-1011-3 Code No.: 100-236-233-10

Name: Warning Label Type:

03-160-1042-0

Code No.: 100-302-750-10

WARNING

To avoid electrical shock, do not remove cover. No user-serviceable parts inside.

WARNING LABEL Warning labels are attached to the equipment. Do not remove any label. If a label is missing or damaged, contact a FURUNO agent or dealer about replacement.

WARNINWARNING

CAUTIONCAUTION

No one navigational aid should be relied upon for the safety of vessel and crew. The navigator has the responsibility to check all aids available to confirm position. Electronic aids are not a substitute for basic navigational principles and common sense.

This TT automatically tracks automatically or manually acquired radar targets and calculates their courses and speeds, indicating them by vectors. Since the data generated by the auto plotter are based on what radar targets are selected, the radar must always be optimally tuned for use with the auto plotter, to ensure required targets will not be lost or unwanted targets such as sea returns and noise will not be acquired and tracked.

A target does not always mean a land-mass, reef, ships or other surface vessels but can imply returns from sea surface and clutter. As the level of clutter changes with environment, the operator should properly adjust the A/C SEA, A/C RAIN and GAIN controls to be sure target echoes are not eliminated from the radar screen.

The plotting accuracy and response of this TT meets IMO standards. Tracking accuracy is affected by the following:

The data generated by TT, AIS and video plotter are intended for reference only.

Tracking accuracy is affected by course change. One to two minutes is required to restore vectors to full accuracy after an abrupt course change. (The actual amount depends on gyrocompass specifications.)

The amount of tracking delay is inversely proportional to the relative speed of the target. Delay is on the order of 15 - 30 seconds for high relative speed; 30 - 60 seconds for low relative speed.

The target tracking and pertinent vector calculation accuracy is influenced by the following:

- Echo intensity

- The range measurement accuracy; characterized by both random and biased measurement errors.

- The angular measurement accuracy; characterized by beam shape, target glint and bias errors.

- Radar transmission pulsewidth

- Gyrocompass heading error

- Speed log error

- Curent and wind (set & drift)

- Course change (own ship and target)

Refer to official nautical charts for detailed and up-to-date information.

DANGER

Electrical shock hazard. Turn off power before servicing.

FOREWORD.................................................................................................................. xii

SYSTEM CONFIGURATION ....................................................................................... xvii

1. OPERATIONAL OVERVIEW.................................................................................1-1

1.1 Controls Overview ......................................................................................................1-1

1.1.1 Control Unit RCU-014 ....................................................................................1-1

1.1.2 Control Unit RCU-015/RCU-016 ....................................................................1-3

1.2 How to Turn the Radar On/Off....................................................................................1-4

1.3 How to Adjust the Brilliance........................................................................................1-4

1.4 Display Indications......................................................................................................1-5

1.4.1 InstantAccess bar

1.4.2 Radar display and shortcuts...........................................................................1-7

1.4.3 Information and settings.................................................................................1-9

1.5 Menu Operations......................................................................................................1-10

1.5.1 How to open and close the main menu........................................................1-10

1.5.2 How to operate the menus ...........................................................................1-10

1.6 How to Use the On-screen Box Menus ....................................................................1-12

1.7 How to Use the CURSOR Menu ..............................................................................1-13

1.8 Cursor Data ..............................................................................................................1-14

1.8.1 How to change the cursor data attributes (B/W-type only) ...........................1-15

1.9 How to Set Up Function Keys...................................................................................1-15

1.10 How to Customize Operation....................................................................................1-17

1.11 How to Select the Interface for Heading Input..........................................................1-19

1.12 How to Set Own Ship’s Speed .................................................................................1-19

1.12.1 Automatic speed input (log or EPFS navigator) ...........................................1-19

1.12.2 Manual speed input ......................................................................................1-21

1.13 How to Set the Own Ship Position............................................................................1-21

1.14 How to Adjust the Date and Time.............................................................................1-22

1.15 User Settings............................................................................................................1-23

1.15.1 How to reset the user settings......................................................................1-25

1.15.2 How to save/load user settings ....................................................................1-25

1.16 How to Start/Stop Transmission...............................................................................1-26

1.17 How to Tune the Receiver (Magnetron Radars Only) ..............................................1-27

1.17.1 How to select the tuning method..................................................................1-27

1.17.2 How to initialize tuning..................................................................................1-27

1.17.3 How to tune the receiver manually ...............................................................1-27

1.18 How to Select a Pulselength.....................................................................................1-28

1.18.1 How to select a pulselength .........................................................................1-28

1.18.2 How to change the preset pulselength.........................................................1-28

1.19 How to Adjust Sensitivity ..........................................................................................1-29

1.20 How to Reduce Sea Clutter......................................................................................1-29

1.20.1 How to select the method of clutter adjustment ...........................................1-29

1.20.2 How to fine-tune sea clutter reduction..........................................................1-30

1.20.3 How to manually reduce sea clutter .............................................................1-30

1.20.4 How to use the BERTHING STC function ....................................................1-31

1.21 How to Reduce Rain Clutter.....................................................................................1-31

1.21.1 How to select the method of rain clutter reduction .......................................1-32

1.21.2 How to manually reduce the rain clutter.......................................................1-32

1.22 Interference Rejector................................................................................................1-34

1.23 Echo Stretch.............................................................................................................1-35

1.24 Echo Averaging ........................................................................................................1-36

1.25 Automatic Clutter Elimination (ACE) Function..........................................................1-38

™

buttons ...........................................................................1-6

TABLE OF CONTENTS

1.25.1 How to turn the Automatic Clutter Elimination (ACE) function on/off ........... 1-38

1.25.2 How to adjust the gain in Automatic Clutter Elimination (ACE) mode.......... 1-38

1.25.3 How to get high sensitivity............................................................................ 1-39

1.25.4 How to suppress false echoes .....................................................................1-39

1.26 Noise Rejector..........................................................................................................1-40

1.27 Wiper........................................................................................................................ 1-40

1.28 How to Preset Controls for a Specific Navigation Purpose...................................... 1-41

1.28.1 How to select a customized echo.................................................................1-44

1.28.2 How to edit a customized echo ....................................................................1-44

1.28.3 How to restore a user customized echo to the saved settings..................... 1-45

1.28.4 How to restore a user customized echo to the factory default settings........ 1-46

1.28.5 How to edit the available customized echoes ..............................................1-46

1.29 How to Reject Second-trace Echoes .......................................................................1-47

1.30 Orientation Modes.................................................................................................... 1-48

1.30.1 How to select an presentation mode............................................................ 1-48

1.30.2 Description of presentation modes...............................................................1-48

1.31 How to Select a Range Scale .................................................................................. 1-50

1.32 How to Measure Range ........................................................................................... 1-51

1.32.1 How to show/hide the range rings................................................................ 1-51

1.32.2 How to measure range with the variable range marker (VRM).................... 1-52

1.32.3 How to set the VRM unit of measurement (B-type only).............................. 1-53

1.32.4 How to show TTG to VRM ...........................................................................1-53

1.33 How to Measure Bearing..........................................................................................1-54

1.33.1 Methods to measure bearing ....................................................................... 1-54

1.33.2 True or relative bearing................................................................................1-55

1.34 Collision Assessment by Offset EBL........................................................................1-56

1.34.1 How to assess risk of collision using the offset EBL .................................... 1-56

1.34.2 How to set the origin point reference for EBL OFFSET ............................... 1-57

1.35 How to Measure Range and Bearing Between Two Targets................................... 1-58

1.36 How to Off-Center the Display ................................................................................. 1-60

1.37 Target Trails ............................................................................................................. 1-61

1.37.1 True or relative trails ....................................................................................1-61

1.37.2 Trail time ...................................................................................................... 1-62

1.37.3 Trail gradation ..............................................................................................1-63

1.37.4 Trail level...................................................................................................... 1-63

1.37.5 Narrow trails (B/W-type only) .......................................................................1-64

1.37.6 How to hide the trails temporarily................................................................. 1-64

1.37.7 Trail stabilization in true motion.................................................................... 1-64

1.37.8 How to erase/restart trails ............................................................................1-65

1.37.9 How to prevent sea clutter in true trails........................................................ 1-65

1.37.10How to show/hide OS trails.......................................................................... 1-66

1.37.11How to show/hide land trails (B/W-type only)............................................... 1-66

1.37.12How to set the trail length (B/W-type only)................................................... 1-67

1.37.13How to set the trail color (B/W-type only).....................................................1-67

1.37.14

1.37.15How to offset the colors for multicolored trail (B/W-type only) ..................... 1-69

1.38 Target Analyzer (B/W-type only) .............................................................................. 1-70

1.38.1 How to activate/deactivate the target analyzer ............................................ 1-71

1.39 Target Alarm ............................................................................................................ 1-72

1.39.1 How to set a target alarm............................................................................. 1-72

1.39.2 How to mute the target alarm....................................................................... 1-73

1.39.3 How to deactivate a target alarm ................................................................. 1-73

1.39.4 How to change target alarm attributes ......................................................... 1-73

1.40 PI (Parallel Index) Lines ........................................................................................... 1-74

1.40.1 How to show/hide the PI lines......................................................................1-74

1.40.2 How to set the maximum number of lines to display.................................... 1-74

How to remove the colors from a section of a multicolor trail (B/W-type only)

... 1-68

TABLE OF CONTENTS

1.40.3 How to change PI line bearing and interval..................................................1-75

1.40.4 How to change the PI line bearing reference (B/W-type only) .....................1-75

1.40.5 How to change the PI line orientation...........................................................1-76

1.40.6 How to reset the PI lines to default (ship’s heading) ....................................1-76

1.40.7 How to change PI line length (IMO/A/B/R-types only)..................................1-76

1.41 How to Use the Net (Diamond) Cursor (B/W-type only)...........................................1-77

1.41.1 How to activate the net cursor......................................................................1-77

1.41.2 How to set the net cursor dimensions and orientation .................................1-78

1.42 Zoom ........................................................................................................................1-79

1.43 How to Use Marks ....................................................................................................1-80

1.43.1 Heading line mark ........................................................................................1-80

1.43.2 How to hide/show the stern mark .................................................................1-80

1.43.3 North mark....................................................................................................1-81

1.43.4 How to set up the own ship symbol..............................................................1-81

1.43.5 How to set the barge marker ........................................................................1-81

1.43.6 Antenna mark ...............................................................................................1-82

1.43.7 Latitude/longitude grid ..................................................................................1-82

1.44 Drop Mark.................................................................................................................1-83

1.44.1 How to activate the drop mark......................................................................1-83

1.44.2 How to inscribe a drop mark.........................................................................1-83

1.44.3 How to erase drop marks .............................................................................1-83

1.45 Brilliance and Color Schemes ..................................................................................1-84

1.45.1 How to select a brilliance and color scheme ................................................1-84

1.45.2 How to change the color and brilliance assigned to a palette ......................1-84

1.45.3 How to change the color palette...................................................................1-86

1.46 How to Display and Set Up Navigational Data .........................................................1-87

1.46.1 How to set up the navigational data .............................................................1-87

1.46.2 How to display navigational data..................................................................1-88

1.47 How to Use the Information Box...............................................................................1-89

1.48 Interswitch ................................................................................................................1-91

1.48.1 How to display antenna information .............................................................1-91

1.48.2 How to preset antenna and display combinations........................................1-92

1.48.3 How to clear the interswitch .........................................................................1-94

1.49 Performance Monitor................................................................................................1-94

1.49.1 How to activate/deactivate the performance monitor ...................................1-94

1.49.2 How to check the radar’s performance.........................................................1-96

1.50 How to Change the Reference Position ...................................................................1-97

1.51 Anchor Watch...........................................................................................................1-98

1.52 Alerts ........................................................................................................................1-99

1.52.1 What is an alert? ..........................................................................................1-99

1.52.2 How to interpret the [ALERT] box...............................................................1-100

1.52.3 How to acknowledge an alert .....................................................................1-100

1.52.4 How to silence the alert buzzer ..................................................................1-100

1.52.5 Alert list.......................................................................................................1-101

1.52.6 Alert icons and their meanings ...................................................................1-103

1.52.7 Responsibility transfer alert ........................................................................1-104

1.53 Icing Prevention......................................................................................................1-105

1.54 How to Select a Display Mode (B/W-type Only).....................................................1-106

1.55 How to Manage SD Card Data...............................................................................1-107

1.55.1 Formatting the SD card ..............................................................................1-107

1.55.2 Cautionary notes on handling SD cards.....................................................1-107

1.55.3 Compatible SD cards .................................................................................1-107

1.55.4 How to insert SD cards...............................................................................1-108

1.55.5 How to remove SD cards ...........................................................................1-108

1.55.6 How to save data to an SD card.................................................................1-109

1.55.7 How to read (load) data from an SD card...................................................1-109

vii

TABLE OF CONTENTS

1.55.8 How to delete data from an SD card.......................................................... 1-109

1.56 How to Take a Screenshot..................................................................................... 1-110

1.57 How to Use the Watch Alert (A/B/W-types only) .................................................... 1-110

1.58 Dual Radar (A/B-types only) .................................................................................. 1-111

1.58.1 How to toggle control of each dual radar display .......................................1-112

1.58.2 Operating considerations for the dual radar display...................................1-113

1.59 Wave Mode ............................................................................................................ 1-115

1.60 Doppler Feature (X-band Solid State Radars only)................................................1-116

2. RADAR OBSERVATION .......................................................................................2-1

2.1 General ......................................................................................................................2-1

2.1.1 Minimum range .............................................................................................. 2-1

2.1.2 Maximum range ............................................................................................. 2-1

2.1.3 X-band and S-band........................................................................................2-2

2.1.4 Radar resolution.............................................................................................2-2

2.1.5 Bearing accuracy ........................................................................................... 2-3

2.1.6 Range measurement...................................................................................... 2-3

2.2 False Echoes ............................................................................................................. 2-3

2.3 SART (Search and Rescue Transponder) ................................................................. 2-5

2.3.1 SART description ........................................................................................... 2-5

2.3.2 How to show SART marks on the radar display.............................................2-6

2.3.3 General remarks on receiving SARTs............................................................ 2-6

2.4 RACON ...................................................................................................................... 2-7

2.5 Radar Target Enhancer (RTE)................................................................................... 2-7

2.6 Solid state radar ......................................................................................................... 2-8

3. TARGET TRACKING (TT) .....................................................................................3-1

3.1 Precautions when Using Target Tracking .................................................................. 3-1

3.2 TT Controls ................................................................................................................ 3-2

3.3 TT Box Overview........................................................................................................3-2

3.4 How to Select the TT mode........................................................................................3-3

3.5 How to Acquire and Track Targets.............................................................................3-4

3.5.1 How to manually acquire a target................................................................... 3-4

3.5.2 How to automatically acquire targets............................................................. 3-5

3.6 How to Enter Own Ship Speed .................................................................................. 3-5

3.6.1 Echo-referenced speed input.........................................................................3-5

3.7 How to Cancel Target Tracking..................................................................................3-7

3.7.1 How to cancel tracking for individual TT targets ............................................ 3-7

3.7.2 How to cancel tracking for all TT targets........................................................ 3-7

3.8 TT Lost Alert...............................................................................................................3-8

3.8.1 How to set the TT lost filter ............................................................................ 3-8

3.8.2 How to enable/disable the lost alert............................................................... 3-8

3.9 TT Symbols and Attributes.........................................................................................3-9

3.9.1 How to adjust symbol brilliance...................................................................... 3-9

3.9.2 How to set the symbol color...........................................................................3-9

3.9.3 How to select a TT symbol (B/W-types only) ...............................................3-10

3.10 How to Display/Remove Target Data.......................................................................3-10

3.10.1 TT pop up information..................................................................................3-10

3.10.2 How to show/remove target data in the data display area ........................... 3-11

3.10.3 How to display, hide and sort the target list ................................................. 3-12

3.11 How to Assign a Preset Name to TT Targets (B/W-type only)................................. 3-14

3.11.1 How to activate the preset name function.................................................... 3-14

3.11.2 How to setup preset names .........................................................................3-14

3.11.3 How to assign a name to a TT .....................................................................3-15

3.12 Vector Modes ........................................................................................................... 3-16

3.12.1 Description of vectors...................................................................................3-16

viii

TABLE OF CONTENTS

3.12.2 Vector mode and length ...............................................................................3-18

3.13 Past Position Display................................................................................................3-19

3.13.1 How to display past position points and select the plotting interval..............3-19

3.13.2 How to select the number of past position points to be displayed................3-19

3.14 Set and Drift..............................................................................................................3-20

3.15 Collision Alarm (CPA, TCPA) ...................................................................................3-21

3.15.1 How to set the CPA and TCPA ranges ........................................................3-21

3.15.2 How to acknowledge the TT collision alarm .................................................3-22

3.16 Acquisition Zone.......................................................................................................3-22

3.16.1 How to enable the acquisition zones............................................................3-22

3.16.2 How to activate the first acquisition zone (AZ1) ...........................................3-23

3.16.3 How to set a polygon acquisition zone (AZ2) ...............................................3-23

3.16.4 How to sleep/deactivate an acquisition zone ...............................................3-24

3.16.5 How to acknowledge the acquisition zone alert ...........................................3-24

3.16.6 How to select the target type to acquire (B/W-types only) ...........................3-24

3.16.7 How to change the acquisition zone reference ............................................3-25

3.16.8 How to set acquisition zone shape and stabilization (B/W-types only) ........3-25

3.17 Trial Maneuvers........................................................................................................3-27

3.17.1 Types of trial maneuvers ..............................................................................3-27

3.17.2 How to perform a trial maneuver..................................................................3-28

3.17.3 How to stop the trial maneuver.....................................................................3-30

3.18 TT System Messages...............................................................................................3-31

3.19 TT Simulation Mode .................................................................................................3-32

3.20 Criteria for Tracking Target Selection.......................................................................3-33

3.21 Factors Affecting Target Tracking ............................................................................3-34

4. AIS OPERATION ...................................................................................................4-1

4.1 Controls for AIS ..........................................................................................................4-3

4.2 AIS Box Overview.......................................................................................................4-4

4.3 How to Select the AIS Display Mode..........................................................................4-4

4.4 AIS Symbols and Their Meanings ..............................................................................4-5

4.5 How to Use the AIS Display Filter ..............................................................................4-5

4.6 How to Activate AIS Targets.......................................................................................4-7

4.6.1 How to activate specific targets manually ......................................................4-7

4.6.2 How to set the AIS auto activate function.......................................................4-8

4.7 How to Sleep AIS Targets ..........................................................................................4-9

4.7.1 How to sleep individual AIS targets................................................................4-9

4.7.2 How to sleep all AIS targets ...........................................................................4-9

4.8 How to Set Up For a Voyage....................................................................................4-10

4.8.1 How to access the [VOYAGE DATA] menu .................................................4-10

4.9 How to Display AIS Data ..........................................................................................4-11

4.9.1 AIS pop-up information.................................................................................4-11

4.9.2 How to display basic AIS data......................................................................4-12

4.9.3 How to display expanded AIS data ..............................................................4-13

4.9.4 How to remove AIS data from the display area ............................................4-13

4.9.5 AIS object type and available AIS data ........................................................4-14

4.10 How to Change AIS Symbol Attributes.....................................................................4-15

4.10.1 How to adjust the AIS symbol brilliance .......................................................4-15

4.10.2 How to change the color of the AIS symbol .................................................4-15

4.10.3 How to change the color of the ATON symbol .............................................4-15

4.10.4 How to change the size of the AIS symbol...................................................4-16

4.11 Past Position Display................................................................................................4-16

4.11.1 How to display past position points and select the plotting interval..............4-16

4.11.2 How to select the number of past position points to be displayed................4-17

4.11.3 Past position display orientation...................................................................4-17

4.11.4 Stabilization in true motion ...........................................................................4-17

TABLE OF CONTENTS

4.12 AIS Lost Alert ........................................................................................................... 4-18

4.12.1 How to set the AIS lost filter.........................................................................4-18

4.12.2 How to enable/disable the AIS lost alert ...................................................... 4-19

4.13 ROT Setting ............................................................................................................. 4-19

4.14 AIS Collision Alarm (CPA, TCPA) ............................................................................4-20

4.14.1 How to set the CPA and TCPA ranges ........................................................ 4-20

4.15 How to Associate TT and AIS Targets ..................................................................... 4-21

4.16 How to View Own Ship Data ....................................................................................4-23

4.17 How to Use AIS Messages ...................................................................................... 4-24

4.17.1 How to create and save messages.............................................................. 4-24

4.17.2 How to transmit messages........................................................................... 4-25

4.17.3 How to view messages ................................................................................4-26

4.17.4 How to set up the AIS message notification.................................................4-28

4.17.5 How to show the unread message symbols.................................................4-28

4.17.6 How to mark the AIS messages as read...................................................... 4-28

4.17.7 How to delete the AIS messages that meet the criteria ............................... 4-29

4.18 AIS System Messages ............................................................................................. 4-30

5. VIDEO PLOTTER OPERATION ............................................................................5-1

5.1 Orientation Modes...................................................................................................... 5-1

5.2 How to select a mark type..........................................................................................5-1

5.3 How to select the mark inscription position................................................................ 5-2

5.4 Radar Map ................................................................................................................. 5-3

5.4.1 How to show/hide radar map marks............................................................... 5-3

5.4.2 How to select the mark color (B/W-type only)................................................ 5-4

5.4.3 How to inscribe marks.................................................................................... 5-4

5.4.4 How to delete marks ...................................................................................... 5-6

5.4.5 How to align the radar map............................................................................5-7

5.5 Origin Mark.................................................................................................................5-8

5.5.1 How to inscribe origin marks..........................................................................5-8

5.5.2 How to set origin mark stabilization................................................................5-9

5.5.3 How to delete origin marks............................................................................. 5-9

5.6 How to Change the Shape of the Own Ship Mark ...................................................5-10

5.7 How to Use ECDIS Chart Marks .............................................................................. 5-11

5.8 Own Ship and Other Ship’s Track............................................................................ 5-12

5.8.1 How to show/hide tracks ..............................................................................5-12

5.8.2 How to set the plotting interval.....................................................................5-13

5.8.3 How to set the track color (A/B/W-types only)..............................................5-14

5.8.4 How to automatically plot target tracks (A/B/W-types only) ......................... 5-14

5.8.5 How to delete tracks..................................................................................... 5-15

5.9 How to Use Waypoints.............................................................................................5-16

5.9.1 How to set the data source for waypoints ....................................................5-16

5.9.2 How to enter waypoints................................................................................5-17

5.9.3 How to erase waypoints...............................................................................5-18

5.9.4 How to display the waypoint list ................................................................... 5-19

5.9.5 How to show/hide the waypoint name/number ............................................ 5-19

5.10 Routes......................................................................................................................5-20

5.10.1 How to set/edit an internal route ..................................................................5-20

5.10.2 How to display routes................................................................................... 5-21

5.10.3 How to delete internal routes ....................................................................... 5-23

5.10.4 How to view the routes list ...........................................................................5-23

5.10.5 How to use the waypoint arrival distance function ....................................... 5-24

5.11 Chart Functions........................................................................................................ 5-25

5.11.1 How to show/hide the chart.......................................................................... 5-25

5.11.2 How to align the chart position..................................................................... 5-26

5.11.3 How to select the chart type......................................................................... 5-27

TABLE OF CONTENTS

5.11.4 Chart settings menu .....................................................................................5-27

5.11.5 How to show/hide land mass emphasis .......................................................5-29

5.11.6 How to check your charts/symbol versions ..................................................5-30

6. MAINTENANCE, TROUBLESHOOTING .............................................................. 6-1

6.1 Periodic Maintenance Schedule.................................................................................6-2

6.2 How to Replace the Fuse ...........................................................................................6-3

6.3 Life Expectancy of Major Parts...................................................................................6-4

6.4 Trackball Maintenance ...............................................................................................6-5

6.5 Easy Troubleshooting.................................................................................................6-5

6.6 Advanced-level Troubleshooting ................................................................................6-6

6.7 Diagnostics.................................................................................................................6-8

6.8 Sentence Monitor .....................................................................................................6-13

6.9 Fallback Arrangements.............................................................................................6-14

APPX. 1 MENU TREE..............................................................................................AP-1

APPX. 2 LONGITUDE ERROR TABLE (96 NM SCALE)........................................AP-9

APPX. 3 ALERT LIST ............................................................................................AP-11

APPX. 4 DATA COLOR AND MEANING .............................................................. AP-34

APPX. 5 ABBREVIATIONS ................................................................................... AP-35

APPX. 6 SYMBOLS ...............................................................................................AP-40

APPX. 7 PARTS LOCATION .................................................................................AP-47

APPX. 8 RADIO REGULATORY INFORMATION .................................................AP-57

SPECIFICATIONS ..................................................................................................... SP-1

INDEX ......................................................................................................................... IN-1

FOREWORD

A Word to the Owner of FAR-22x8/23x8 Series Marine Radar

Congratulations on your choice of the FURUNO FAR-22x8/FAR-23x8 series of radars. We are confident you will see why FURUNO has become synonymous with quality and reliability.

Since 1948, FURUNO Electric Company has enjoyed an enviable reputation for innovative and dependable marine electronics equipment. This dedication to excellence is furthered by our extensive global network of agents and dealers.

Your radar is designed and constructed to meet the rigorous demands of the marine environment. However, no machine can perform its intended function unless installed, operated and maintained properly. Please carefully read and follow the recommended procedures for operation and maintenance.We would appreciate hearing from you, the end-user, about whether we are achieving our goal.

Thank you for considering and purchasing FURUNO equipment.

Features

• The FAR-2xx8 series consists of the following models and configurations:

Model

Magnetron radar FAR-2218 FAR-2218-BB Local supply 12 kW Antenna unit FAR-2318 23.1”/27” 12 kW Antenna unit FAR-2018-MARK-2 19.0”/27” 12 kW Antenna unit FAR-2228 19.0” 25 kW Antenna unit FAR-2228-BB Local supply 25 kW Antenna unit FAR-2328 23.1”/27” 25 kW Antenna unit FAR-2028-MARK-2 19.0”/27” 25 kW Antenna unit FAR-2328W 23.1”/27” 25 kW Transceiver unit FAR-2238S FAR-2238S-BB Local supply 30 kW Antenna unit FAR-2338S 23.1”/27” 30 kW Antenna unit FAR-2338SW 23.1”/27” 30 kW Transceiver unit Solid state radar FAR-2228-NXT

FAR-2328-NXT 23.1”/27”

FAR-2228-NXT-BB Local supply

FAR-2238S-NXT FAR-2338S-NXT 23.1”/27” 250 W Antenna unit FAR-2238S-NXT-BB Local supply 250 W Antenna unit

Frequency

band

X-band

S-band

X-band

S-band

Size of

monitor unit

19.0” 12 kW Antenna unit

19.0” 30 kW Antenna unit

19.0”

19.0” 250 W Antenna unit

Output

power

600 W

Transceiver

location

Antenna unit

: Viewing distances are as follows:

• MU-190/MU-190HD/MU-270W: 1020 mm • MU-231: 1200 mm

: 500 W, for Japanese flag vessels.

xii

FOREWORD

• Two methods of operation are available: the standard supply control unit (RCU-014) and the optional trackball unit (RCU-015/RCU-016). The ergonomically designed palm rest on the trackball unit makes it easy to use.

• Simple operation with “point-and-click” menu functionality.

• All functions can be accessed using only the trackball unit, however, RCU-016 trackball units do not have a power button.

• TT, AIS, Radar Map, Interswitch and FURUNO’s unique Target Analyzer are supplied as standard.

• CPA/TCPA alarms.

• Targets activate the user-set alarm zone when entering or exiting the zone.

• The Target Analyzer function helps to find targets in high noise areas (rain/snow), or where there is interference from surface reflections. (Available for B/W-types only.)

• The FAR-2xx8 series complies with MED 2014/90/EU and also the following directives: IEC62388, IEC 62288, IMO MSC. 192(79).

Terminology standards used in this manual

This manual uses the following terminology standards:

Terminology Meaning or usage example

Select • Use the trackball or scrollwheel on the control unit to move the cursor over

the item to be “selected”, then left-click.

• With a menu open: Press the appropriate menu number. Left-click Press the left mouse button. Right-click Press the right mouse button. Control Unit Refers to the RCU-014 Control Unit, unless otherwise specified. Open the menu. Press the MENU key to show the [MENU]. Close the menu. Press the MENU key to close the [MENU].

For the sake of brevity, all procedures in this manual use the terms “Open the menu.” and “Close the menu”.

xiii

FOREWORD

Program numbers

Please access the following URL if you need software information: http://www.furuno.com/en/merchant/radar/FAR-22x8_23x8/#SoftwareVersion

System Program no. Version no. Remarks

Antenna unit (common to all antennas)

SPU 0359281 01.×× For magnetron radar SPU 0359286 01.×× For S-band solid state radar SPU 0359477 01.×× For X-band solid state radar IF-SPU 0359560 01.×× For MARK-2 magnetron radar MTR-DRV 0359293 01.×× MTR-PWR 0359556 01.×× For MARK-2 magnetron radar PM 0359296 01.×× RF-Converter 0359302 01.×× For S-band solid state radar RF-Converter 0359414 01.×× For X-band solid state radar

Processor Unit: RPU-025

MAIN 0359377 03.×× SUB 0359380 03.××

Control Unit: RCU-014/015/016

KEY 0359385 01.××

××: Denotes minor changes to the software.

About the programs used in A/B/W-types with Radar Plotter functionality

• Portions of this software are copyright

2016. The FreeType Project (www.freetype.org). All

right reserved.

• This equipment includes GPL2.0, LGPL2.0, Apache, BSD, MIT or other licensed softwares. For further software information, please access the following URL: https://www.furuno.co.jp/en/contact/cnt_oss_e01.html

Radar Type and Function Availability

This radar is available in several specification types to meet the requirements of Authorities, and function availability depends on specification type. The table below shows the function that have limited availability. This manual provides descriptions for all functions of this radar series, and we have endeavored to denote in the text those functions that have limited availability. For detailed information on the function availability, see the menu tree at the back of this manual.

Type abbreviations and their meanings

• IMO: Meets the IMO requirements and is compliant with IMO regulations

• A: Near-IMO specifications

• B: Standard fishing specifications

• R: Russian River

• W: Washington Ferry

xiv

Function availability and specification type

FOREWORD

Function

TT symbol selection No No Yes No Yes Acquisition zone

range limitation Auto Track Target No Yes Yes No Yes Chart Display No Yes Yes No Yes Color Echo No No Yes No Yes Cursor range unit

selection Cursor Size No No Yes No Yes Echo area

configuration Mark color No No Yes No Yes Mark w/line No No Yes No Yes Range [0.125],

Range unit [NM] only Same as

VRM unit - selectable unit

Track - Other ship No Yes Yes No Yes Trail Eraser No No Yes No Yes Trails - Color No No Yes No Yes Trails - Hide No No Yes No Yes Trails - Long No No Yes No Yes Trails - Narrow No No Yes No Yes WPT marker No Yes Yes No Yes Target Analyzer No No Yes No Yes Net Cursor No No Yes No Yes Target Type to

Acquire Check Area Setting No No Yes No Yes Display Scroll** No No Yes No Yes Dual Radar display No Yes Yes No No

IMO A B R W

Yes No No Yes No

No No Yes No No

No No Yes No Yes

Same as [0.25], [0.5], [0.75], [1.5], [3], [6], [12],

[24], [48],

[96]

No No Yes No No

No No Yes No Yes

IMO

Type

[0.125]***,

[0.25], [0.5],

[0.75], [1],

[1.5], [2], [3],

[4], [6], [8],

[12], [16], [24], [32], [48], [96],

[120]*

[NM], [SM],

[km], [kyd]

Same as

IMO

Same as

IMO

Same as B

*: The range setting [120] is only available when the range unit is set to km,kyd. **: Available only for B/W-types. ***: The range setting [0.125] is only available when the range unit is set to [NM] or [SM].

FOREWORD

Advanced fishing specifications

The following radar plotter features will be available by updating to the software for advanced fishing specifications and installing the RP board to the processor unit. Consult your local dealer regarding the software update and RP board installation.

• A variety of plotter-related functions. (Memory capacity increase for own and other ship’s track, ship’s track color customize function, mark/line function, memory capacity increase for origin mark, origin mark list, etc.)

• TT/AIS symbol customize function.

• Enhanced dynamic range for a more complete EAV (Echo Average) function.

• Compatible with the RCU-031 control unit that is specially designed for fisheries.

For details about advanced fishing specifications, see the operator’s manual (OME-36521).

Signal processing functions

This radar has the signal processing functions listed in the table below.

Function Description Reference

Interference rejector Suppresses interference by other radars.

Interference received simultaneously from multiple radars may be difficult to reduce.

Echo stretch Enlarges target echoes, especially small echoes.

Suppress interference, sea clutter and rain clutter before using echo stretch, to prevent enlargement of unwanted echoes.

Echo averaging The radar samples echoes with each scan.

Targets that show a large change with each scan are judged as clutter and are reduced to display only echoes from legitimate targets.

Automatic clutter elimination Discriminates clutter from the radar echo, then reduc-

es the clutter automatically.

Noise rejector Reduces white noise then improves the on-screen

S/N ratio by processing the weighted moving average filter for the received echoes in the range direction. Use this function with caution. Weak target echoes may disappear from the screen or the range resolution may worsen.

See section 1.22

See section 1.23

See section 1.24

See section 1.25

See section 1.26

CE/UKCA Declaration

With regards to CE/UKCA declarations, please refer to our website (www.furuno.com) for further information about RoHS conformity declarations.

Disclosure of Information about China RoHS

With regards to China RoHS information for our products, please refer to our website (www.furuno.com).

xvi

SYSTEM CONFIGURATION

NOTICE

IMO-type radar(s) must be interconnected to the following type approved sensors. For other radar types, it is recommended to connect the following type approved sensors:

•



EPFS meeting the requirements of the IMO resolution MSC.112(73).

•



Gyrocompass (or equivalent devices) meeting the requirements of the IMO resolution A.424(XI).

•



SDME meeting the requirements of IMO resolution MSC.96(72).

The radar may be interconnected via HUB-3000 to other FURUNO processing units having approved LAN ports.

Control Unit

RCU-014 or RCU-015

Standard supply

Optional or local supply

Control Unit

RCU-016

Sub monitor

Antenna Cable*

100-115/220-230 VAC

1ø, 50-60 Hz (for de-icer)

for FAR-2218(-BB)/2318, 12 kW

(

w/ Performance Monitor PM-32A

) XN12CF-RSB128-105 XN20CF-RSB128-105 XN24CF-RSB128-105

for FAR-2228(-BB)/2328, 25 kW

(

w/ Performance Monitor PM-32A

) XN12CF-RSB128-106 XN20CF-RSB128-106 XN24CF-RSB128-106

Antenna Unit

for FAR-2228-NXT(-BB)/2328-NXT,

600 W (500 W, for Japanese flag vessels)

(w/ Performance Monitor PM-32B*

) XN12CF-RSB128-123 XN20CF-RSB128-123 XN24CF-RSB128-123

100-230 VAC 1ø, 50-60 Hz

Transformer

USB Device*

440 VAC 1ø, 50-60 Hz

24 VDC

AC-DC Power

Supply Unit

Rectifier

100/110/120/200/220/240 VAC

1ø, 50-60 Hz

100/115/ 220/230 VAC 1ø, 50-60 Hz

USB Mouse

Switching Hub

HUB-100

Intelligent Hub

HUB-3000*

Gyrocompass*1 (AD-10 format)

Gyrocompass*1 (IEC61162 format)

AIS Transponder

EPFS*2 (GPS)

SDME (Speed log)

AMS (IEC61162 format)

Sub monitor 1 of ECDIS*

Sub monitor 2 of ECDIS*

AMS (Contact)*

Processor

Unit

RPU-025

100-230 VAC

Intelligent Hub

HUB-3000*

100-230 VAC

Sensors

(IEC61162-450 Ed.2 format)

VDR

(IEC61162-450 format)

Sensors

(IEC61162-450 Ed.1 format)

VDR (Analog RGB)

ECDIS

For AC power

For DC power

Monitor Unit*3

MU-190/MU-231/MU-270W

Monitor Unit*3

MU-190HD

*11

12-24 VDC

Monitor Unit*3

㻴㻰㻝㻥㼀㻞㻞㻙㻲㼁㻰㻙㻹㻭㻝㻛㻹㻭㻠㻙㻲㻭㻳㻭

115/230 VAC

24 VDC

Note: Basic configuration is shown with a solid line. For footnotes, see "Notes" on page xxii.

X-band (TR-UP, CF Antenna)

xvii

SYSTEM CONFIGURATION

100-230 VAC 1ø, 50-60 Hz

Transformer

USB Device*

440 VAC 1ø, 50-60 Hz

USB Mouse

Switching Hub

HUB-100

Control Unit

RCU-014 or RCU-015

Intelligent Hub

HUB-3000*

Gyrocompass*1 (AD-10 format)

Gyrocompass*1 (IEC61162 format)

AIS Transponder

EPFS*2 (GPS)

SDME (Speed log)

AMS (IEC61162 format)

Sub monitor 1 of ECDIS*

Sub monitor 2 of ECDIS*

AMS (Contact)*

Sub monitor

Antenna Cable*

100-115/220-230 VAC

1ø, 50-60 Hz (for de-icer)

Processor

Unit

RPU-025

100-230 VAC

Intelligent Hub

HUB-3000*

100-230 VAC

Sensors

(IEC61162-450 Ed.2 format)

VDR

(IEC61162-450 format)

Sensors

(IEC61162-450 Ed.1 format)

VDR (Analog RGB)

: Standard supply : Optional or local supply

ECDIS

Control Unit RCU-016

For AC power

For DC power

for FAR-2018-MARK-2, 12 kW

(

w/ Performance Monitor PM-32A

) XN12AF-RSB146-131 XN20AF-RSB146-131 XN24AF-RSB146-131

for FAR-2028-MARK-2, 25 kW

(

w/ Performance Monitor PM-32A

) XN12AF-RSB146-132 XN20AF-RSB146-132 XN24AF-RSB146-132

Monitor Unit*3

MU-190/MU-270W

Antenna Unit

Rectifier

100/115/

220/230 VAC

1ø, 50-60 Hz

Monitor Unit*3

MU-190HD

*11

12-24 VDC

24 VDC

AC-DC Power

Supply Unit

100/110/120/200/220/240 VAC

1ø, 50-60 Hz

X-band (TR-UP, AF Antenna)

xviii

S-band (TR-UP)

Sub monitor

Antenna Cable

100-115/220-230 VAC

1ø, 50-60 Hz

(for de-icer)

Antenna Unit

for FAR-2238S(-BB)/2338S, 30 kW

(

w/ Performance Monitor PM-52A

SN24CF-RSB129-107*

SN30CF-RSB129-107*

SN36CF-RSB129-107

Antenna Unit for FAR-2238S-NXT(-BB)/2338S-NXT, 250 W

(

w/ Performance Monitor PM-52B

)

SN24CF-RSB133-111*

SN30CF-RSB133-111*

SN36CF-RSB133-111

Control Unit

RCU-014 or RCU-015

Control Unit RCU-016

Standard supply

Optional or local supply

USB Device*

USB Mouse

100-230 VAC 1ø, 50-60 Hz

100-230 VAC

1ø, 50-60 Hz

Transformer

440 VAC

1ø, 50-60 Hz

VDR

(Analog RGB)

Monitor Unit*3

MU-190 or MU-231 or

MU-270W

Intelligent Hub

HUB-3000*

Switching Hub

HUB-100

Intelligent Hub

HUB-3000*

100-230 VAC

Sensors

(IEC61162-450 Ed.2 format)

VDR

(IEC61162-450 format)

Sensors

(IEC61162-450 Ed.1 format)

Processor Unit

RPU-025

Gyrocompass*1 (AD-10 format)

Gyrocompass*1

(IEC61162 format)

AIS Transponder

EPFS*2 (GPS)

AMS (IEC61162 format)

AMS (Contact)*

Sub Monitor 1 of ECDIS*

Sub Monitor 2 of ECDIS*

ECDIS

SDME (Speed log)

Monitor Unit*3

㻴㻰㻝㻥㼀㻞㻞㻙㻲㼁㻰㻙㻹㻭㻝㻛㻹㻭㻠㻙㻲㻭㻳㻭

115/230 VAC

24 VDC

SYSTEM CONFIGURATION

xix

SYSTEM CONFIGURATION

Sub monitor

Antenna Cable

100-115/220-230 VAC

1ø, 50-60 Hz

(for de-icer)

Transceiver Unit

RTR-108

Antenna Unit for FAR-2328W, 25 kW

(

w/ Performance Monitor PM-32A)

XN20CF-RSB130 XN24CF-RSB130

Wave guideSignal cable

Standard supply

Optional or local supply

Control Unit

RCU-014 or RCU-015

Control Unit RCU-016

USB Device*

USB Mouse

100-230 VAC 1ø, 50-60 Hz

100-230 VAC

1ø, 50-60 Hz

Transformer

440 VAC

1ø, 50-60 Hz

VDR

(Analog RGB)

Intelligent Hub

HUB-3000*

Switching Hub

HUB-100

Intelligent Hub

HUB-3000*

100-230 VAC

Sensors

(IEC61162-450 Ed.2 format)

VDR

(IEC61162-450 format)

Sensors

(IEC61162-450 Ed.1 format)

Processor Unit

RPU-025

100-230 VAC

1ø, 50-60 Hz

Monitor Unit*3

MU-231 or

MU-270W

Gyrocompass*1 (AD-10 format)

Gyrocompass*1

(IEC61162 format)

AIS Transponder

EPFS*2 (GPS)

AMS (IEC61162 format)

AMS (Contact)*

Sub Monitor 1 of ECDIS*

Sub Monitor 2 of ECDIS*

ECDIS

SDME (Speed log)

Monitor Unit*3

㻴㻰㻝㻥㼀㻞㻞㻙㻲㼁㻰㻙㻹㻭㻝㻛㻹㻭㻠㻙㻲㻭㻳㻭

115/230 VAC

24 VDC

X-band (TR-DOWN)

S-band (TR-DOWN)

Sub monitor

Antenna Cable

100-115/220-230 VAC

1ø, 50-60 Hz

(for de-icer)

Transceiver Unit

RTR-109

Antenna Unit

for FAR-2338SW, 30 kW

(

w/ Performance Monitor PM-52A)

SN36CF-RSB131

Coaxial cable

Signal cable

Standard supply

Optional or local supply

Control Unit

RCU-014 or RCU-015

Control Unit RCU-016

USB Device*

USB Mouse

100-230 VAC

1ø, 50-60 Hz

100-230 VAC

1ø, 50-60 Hz

Transformer

440 VAC

1ø, 50-60 Hz

VDR

(Analog RGB)

Intelligent Hub

HUB-3000*

Switching Hub

HUB-100

Intelligent Hub

HUB-3000*

100-230 VAC

Sensors

(IEC61162-450 Ed.2 format)

VDR

(IEC61162-450 format)

Sensors

(IEC61162-450 Ed.1 format)

Processor Unit

RPU-025

100-230 VAC

1ø, 50-60 Hz

Monitor Unit*3

MU-231 or MU-270W

Gyrocompass*1 (AD-10 format)

Gyrocompass*1

(IEC61162 format)

AIS Transponder

EPFS*2 (GPS)

AMS (IEC61162 format)

AMS (Contact)*

Sub Monitor 1 of ECDIS*

Sub Monitor 2 of ECDIS*

ECDIS

SDME (Speed log)

SYSTEM CONFIGURATION

xxi

SYSTEM CONFIGURATION

Category of units

• Antenna units: Exposed to the weather. • Other units: Protected from the weather.

Notes

1) The gyrocompass must be type approved for compliance with IMO resolution A.424(XI) (and/ or resolution A.821(19) for installation on HSC). The gyrocompass must also have an update rate that is adequate for the ship’s rate of turn. The update rate must be better than 40 Hz (HSC) or 20 Hz (conventional vessel).

2) The EPFS must be type approved for compliance with IMO resolution MSC.112(73).

3) The monitors listed in the following table have been approved by the IMO. If a different monitor is to be used on IMO vessels, its effective diameter must meet the applicable Category requirements.

• CAT 1 and CAT 1H: effective diameter of 320 mm or higher

• CAT 2 and CAT 2H: effective diameter of 250 mm or higher

• CAT 3: effective diameter of 180 mm or higher

Category Manufacturer Model Viewing distance

CAT 1 and CAT 1H

CAT 2 and CAT 2H

CAT 3 FURUNO MU-152 1.02 m

FURUNO MU-231 1.20 m

MU-270W 1.02 m

Hatteland Display JH 23T14 FUD 1.20 m

HD 26T21 MMD 0.99 m HD 26T22 FUD 0.99 m HD 27T22 FUD 1.07 m HD 32T22 FUD 0.64 m HD 55T22 FUD 1.09 m

North Invent WA270-01-MON-01 1.07 m

WE270FU* 1.07 m

WA460-01-MON-01 0.60 m FURUNO MU-190/MU-190HD 1.02 m Hatteland Display JH 19T14 FUD 1.02 m

JH 20T17 FUD 0.88 m

HD 19T22 FUD 1.02 m

HD 24T21 FUD 1.12 m

HD 24T22 FUD 1.12 m

Hatteland Display JH 15T17 FUD 1.02 m

HD 15T22 FUD 1.02 m

*: CCS approved only (not approved by MED). When WE270FU is used with FAR-20x8-

MARK-2, the equipment is non-compliant with both CCS and MED.

For installation and operation of other monitors, see the respective manuals. For BB type, a monitor unit is prepared by user.

4) Characteristics of contact output for Alarm:

• (Load current) 250 mA;

• (Polarity) Normally Open: 2 ports, Normally Close: 2 ports;

• Serial I/O for alarm is also possible, which complies with IEC 61162-1.

xxii

SYSTEM CONFIGURATION

5) For configurations including three or more radars, or including a single ECDIS or chart radar, connect via a HUB-3000. For two radars, HUB-100 can be used.

6) For connection to a VDR or IEC61162-450 Ed.2 sensor, connection should be made via the HUB-3000.

7) Some antenna configurations do not have an in-built Performance Monitor. This type of antenna is not usable for IMO-type radars.

8) For connecting non-FURUNO ECDIS only. For connection of radars or plotters, the connection must be done at the radar antenna (or the transceiver unit) via the sub monitor connector.

9) Available only for A/B/W-types with Radar Plotter functionality.

10)Junction boxes are required for antenna cable length greater than 100 m (only for TX-band RUP radar). Max. cable length is 400 m.

11)Unavailable on IMO-type radars.

xxiii

SYSTEM CONFIGURATION

This page is intentionally left blank.

xxiv

1. OPERATIONAL OVERVIEW

1.1 Controls Overview

Two types of control units are available for your FAR-2xx8: a full keyboard (RCU-014) or palm control (RCU-015/RCU-016).

Most operations can be done with either type of Control Unit. Throughout the manual, procedures are outlined using the RCU-014, unless otherwise specified.

1.1.1 Control Unit RCU-014

You can control almost all aspects of your radar from the RCU-014. The figure and table below show an overview of the control unit with a brief description of the controls.

EBL

OFFSET

CU/TM RESET

VECTOR

MODE

BRILL

A/C SEAA/C RAIN

MODE

INDEX

LINE

TARGET

LIST

ENTER

MARK

GAIN

OFF

RANGE

VRM

ACQ

TARGET

DATA

TARGET CANCEL

OFF

EBL

F3 F4

ALARM

ACK

STBY

BRILL

OFF

CENTER

VECTOR

TIME

CANCEL TRAILS

No. Control Name Description

1 Power button Turn the power on or off. See section 1.2. 2 EBL controls • EBL keys: Turn the EBLs on or off.

• EBL knob: Move the selected EBL. See section 1.33.

3 BRILL knob Adjust echo brilliance and screen brilliance. See section 1.3.

A/C RAIN knob Adjust auto/manual clutter reduction for rain. See section 1.21. A/C SEA knob Adjust auto/manual clutter reduction for rough seas. See

section 1.20.

GAIN knob Adjust the gain (sensitivity). See section 1.19.

4 VRM controls • VRM keys: Turn the VRMs on or off.

• VRM knob: Move the selected VRM. See section 1.32.

5 Functions keys (F1 to

Perform a pre-registered function. See section 1.9.

F4) ALARM ACK key Acknowledge active alerts. See section 1.52. STBY TX key Toggle the radar operation between transmit (TX) and standby

(STBY). See section 1.16.

1-1

1. OPERATIONAL OVERVIEW

No. Control Name Description

6 1, HL OFF key • With the menu open: Select menu item "1".

• Press and hold to hide the heading line, range rings and OS symbol. Release to re-show the hidden items. See section 1.43.1.

2, EBL OFFSET key • With the menu open: Select menu item "2".

• Sets the positive/negative value to “+”. See section 1.14 and section 1.10.

• Offset or reset the EBL. See section 1.34.

3, MODE key • With the menu open: Select menu item "3".

• Change the orientation mode. See section 1.30.

4, OFF CENTER key • With the menu open: Select menu item "4".

• Enable or disable off-center. See section 1.36.

5, CU/TM RESET key • With the menu open: Select menu item "5".

• Course Up mode: Reset the heading line to 000°. See section 1.30.

• True Motion mode: Move Own Ship position 75% of the radius in opposite direction of the current heading. See section 1.30.

6, INDEX LINE key • With the menu open: Select menu item "6".

• Short press: Select a PI line. See section 1.40.

• Long press: Show or hide the selected PI line. See section 1.40.

7, VECTOR TIME key • With the menu open: Select menu item "7".

• Change the vector time. See section 3.12.2.

8, VECTOR MODE key • With the menu open: Select menu item "8".

• Sets the positive/negative value to “-”. See section 1.14 and section 1.10.

• Toggle between true and relative vectors. See section 3.12.

9, TARGET LIST key • With the menu open: Select menu item "9".

• Show or hide the TT/AIS object list. See section 3.10.3.

CANCEL TRAILS key

0, BRILL key • With the menu open: Select menu item "0".

ENTER MARK key Inside the Operational Display Area (ODA):

7 MENU key Open or close the menu the menu. See section 1.5.

RANGE controls Increase or decrease the range. See section 1.31. ACQ key • Manually acquire the cursor-highlighted target for Target Track-

TARGET DATA key • Show the information for the cursor-highlighted TT/AIS object.

Without the menu open (see section 1.37.2

• Short press: Change the trail display time.

• Long press: Erase displayed trails.

With the menu open (see section 1.5

• Go back one level in the menu. Closes the menu if the top level is displayed.

• Cancel changes made to a menu setting.

• Change the color scheme. See section 1.45.

Inscribe a mark. See section 1.43. With the menu open: Confirm changes, open the selected menu. See section 1.5

Note: The MENU key will not open/close the menu in the following situations:

• VRM or EBL is being set.

• DROP MARK or MARK is being inscribed.

• Alarm Zone (AZ) or TARGET ALARM is being set.

ing (TT).

• Change the selected TT target’s symbol (B/W-types only).

• Activate a sleeping AIS target. See section 3.2.

1-2

No. Control Name Description

7 TARGET CANCEL key • Cancel tracking for the selected target.

• Sleep the selected AIS target.

• Long press: Cancel tracking for all TT targets. See section 3.2.

8 Trackball controls See section 1.1.2.

1.1.2 Control Unit RCU-015/RCU-016

The RCU-015 and RCU-016 offer an easy to use mouse-like control interface, without the bulkiness of the RCU-014. You can access all your radar functions from the RCU015/RCU-016, however, only the function keys are available as short-cut keys.

1. OPERATIONAL OVERVIEW

No. Control Name Description

1 Power button* Turn the power on or off.

See section 1.2.

2 Functions keys (F1 to F4) Perform a pre-registered function.

See section 1.9.

3 Right mouse button Short press:

• Show the pop up menu for the highlighted item.

• Cancel changes to the currently selected setting.

• With pop up menus shown: Hide pop up menus. Long press:

• Change the screen brilliance to [50].

4 Scrollwheel • Change settings.

• Highlight a menu item. 5 Left mouse button Select a highlighted object or menu item. 6 Trackball • Moves the cursor.

• Highlight an object or menu item.

*: The RCU-016 Control Unit has no power button. To turn the power on or off when using a RCU-016 Control Unit, use the power button on the RCU-014/RCU-015.

1-3

1. OPERATIONAL OVERVIEW

1.2 How to Turn the Radar On/Off

The power button ( ) is located at the top-left corner of the RCU-014 and RCU-015 Control Units.

Note: The RCU-016 Control Unit has no power button. To turn the power on or off when using a RCU-016 Control Unit, use the power button on the RCU-014/RCU-015.

To turn the power on

The LED to the left of the power button lights up (green color) and the system begins

the startup process. The indication "Initializing......" appears at the center of the screen.

When the startup process is complete, the system begins warm-up procedures to prepare the magnetron for transmission. The warm-up can take up to three minutes. During the warm-up, indications for total on-time (magnetron on-time since installation) and total transmission time (since installation) appear below the warm-up countdown timer. These indications are also displayed when the radar is in standby mode. When the warm-up process is complete, the radar goes into standby (STBY) mode and the indication "RADAR STBY" (IMO-types) or "STBY" (A/B/R/W-types) appears. This indication also appears whenever the equipment is in STBY mode.

Note 1: For B/W-types with Radar Plotter functionality, the “STBY” indication appears only once, when the equipment is turned on. Note 2: For B/W-types with Radar Plotter functionality, the numerals on the heading dial (outer-most range ring) are not shown and the TT function is inactive while in standby (STBY) mode. Note 3: Do not turn on the power directly after it has been turned off. Wait several seconds before you reapply the power, to be sure the radar starts up properly.

To turn the power off

Note: Solid state radars do not have a magnetron, therefore they have no warming period.

, open the power switch cover, then press the power button.

1.3 How to Adjust the Brilliance

The screen brilliance (brightness) for monitors can be adjusted as shown below.

Note: The following procedure applies only to monitors supplied by FURUNO for this system. For other monitors, see the monitor operator’s manual to adjust the brilliance.

Brilliance adjustment from the Control Unit (RCU-014)

Rotate the BRILL knob clockwise to increase the brilliance (brighter), or rotate the BRILL knob counter-clockwise to reduce the brilliance (darker).

Brilliance adjustment from the on-screen box

Select the [BRILL] box, the spin the scrollwheel on the Control Unit upwards to reduce the brilliance (darker) or downwards to increase the brilliance (brighter).

Note: The above scrollwheel operation is based on default settings for [2 MOUSE WHEEL DIR]. See section 1.10.

[

BRILL] box

1-4

1.4 Display Indications

SCREEN

SHOT

Note: The example screen below may differ slightly from your display, depending on the monitor purchased in your configuration. The overall information, however, is the same.

The on-screen display for your radar system is divided into three main areas, as shown in the figure below.

1. OPERATIONAL OVERVIEW

• 1: InstantAccess bar

™

. See section 1.4.1.

• 2: Radar display and function boxes. See section 1.4.2.

• 3: Information and settings. See section 1.4.3.

Display specifications

MU-190/190HD MU-231 MU-270W

Nominal viewing distance 1.02 m 1.20 m 1.02 m Text height (min. font) 3.53 mm 4.23 mm 3.64 mm Text width (min. font) 2.36 mm 2.97 mm 2.43 mm

1-5

1. OPERATIONAL OVERVIEW

TUNE

MAN

OFF

EAV OFF

ACE OFF

CHART

MAP

OFF

CU/TM

RESET

OWN

AIS

PLT1

100

1.4.1 InstantAccess bar

Button Description

Upper Half

Standby/Transmit button. Toggle between standby (STBY) and transmit (TX).

PULSE

Pulselength button. Selects the pulselength.

Tune button. Toggles between automatic and manual tuning. (See section 1.17.1.) Note: For SSD antennas, this button appears as "TX CH x" (“x” denotes the channel used for transmission). If your radar is receiving interference from another radar operating at the same frequency, use the [TX CH] button to change the TX frequency.

Interference Rejector button. Activates/deactivates the interference rejector feature.

Echo Stretch button. Activates/deactivates the echo stretch function.

Echo Average button. Activates/deactivates the echo average function. Note: This item is grayed out under the following conditions:

• ACE function is active.

• No position data is input (excludes Dead Reckoning).

™

buttons

Lower Half

ACE button. Activates/deactivates the ACE (Auto Clutter Elimination) function.

Chart button.

• Shows/hides the chart.

• Opens the [CHART] menu. Note: Appears on A/B/W-types with Radar Plotter functionality only.

Radar Map button. Shows/hides the radar map marks.

HEADING LINE button. Left-click and hold to hide the heading line, range rings and OS symbol.

CU/TM RESET button

• Puts the ship’s heading at the top of the screen in course-up mode the moment this button is pressed.

• Resets the ship's position to a point of 75% radius opposite to the extension of the heading line passing through the display center in true motion modes.

Own Ship AIS button. Shows the AIS VOYAGE DATA for AIS data setup.

AIS Message button. Opens the AIS Message menu, allowing you to view received AIS messages.

Brilliance button.

• Adjusts the screen brilliance

• Opens the [BRILLIANCE] menu.

• Selects the color palette. See section 1.45.1.

1-6

1.4.2 Radar display and shortcuts

Operational Display Area

CTRLMWT

1. OPERATIONAL OVERVIEW

No. Name Description

- Operational Display Area Radar echoes are displayed here. 1 [RANGE] box Shows/changes the current range in use. 2 [REF POINT] box Shows/changes the point of reference. 3 Indications Shows indications for SART, shuttle ferry mode, etc. 4 [WATCH] box • Shows the watch alert countdown timer.

• Resets the watch alert countdown. Note: The watch alert is available only for A/B/W-types.

5 [ECHO ADJUST] box Place the cursor on a box to adjust the setting.

• [GAIN] bar: Shows the level of gain in use.

• [SEA] bar: Shows the level and mode of sea clutter reduction.

• [RAIN] bar: Shows the level and mode of rain clutter reduction.

6 Cursor position details • Shows the location (coordinates) of the cursor posi-

7 [MAP ALIGN] indication Shows/hides the map alignment status. 8 [MENU] box Opens/closes the menu. 9 User settings box • Loads pilot settings.

10 [TGT LIST] box Shows the details list for TT/AIS objects.

tion.

• Shows the TTG to the cursor position.

• Shows the bearing and range to the cursor position.

• Opens the [USER SET] menu.

1-7

1. OPERATIONAL OVERVIEW

No. Name Description

11 [TRIAL MANEUVERS] box • Activates/deactivates trial maneuvers.

• Sets up trial maneuver parameters.

12 [ACQUISITION ZONE] box • Adjust acquisition zone settings for target alarms.

• Toggle between sentry zone and acquisition zone alert modes.

13 [VRM] box • Activate/deactivate the VRM (Variable Range Marker).

• Adjust the active (selected) VRM.

• Shows VRM range and TTG.

14 [EBL] box • Activate/deactivate the EBL (Electronic Bearing Line).

• Adjust the active (selected) EBL.

• Shows EBL bearing.

15 [MAP MARK] box • Selects a map mark to use.

• Inscribes the selected map mark.

16 [PI Lines] box • Selects PI line set to use.

• Shows/hides the selected PI lines.

• Shows the angle, reference and range interval for the PI lines.

17 [TARGET ANALYZER] indica-

tion

Shows the target analyzer function’s ON/OFF status. Note: Appears only for B/W-types.

18 [NOISE REJECTOR] indication Shows the noise rejector function’s ON/OFF status. 19 [TUNING LEVEL] bar • Shows the level of tuning in use. See section 1.17.

• Adjusts the tuning (manual only). See section 1.17.3.

Note: The [TUNING LEVEL] bar is not shown for solid state radars.

20 [PICTURE] box • Selects a preset custom display.

• Right-click to open the [CUSTOMIZED ECHO] menu.

21 [ANTENNA SELECTION] box • Selects the antenna to use for radar images.

• Right-click to open the [SELECT ANTENNA] menu.

22 [CONTROL] box Indicates which Dual Radar image is currently selected.

• "M": Master. Operations and settings are applied to the Main (Master) radar image.

• "S": Slave. Operations and settings are applied to the Sub (Slave) radar image.

Note: Appears only for A/B-types when the dual radar function is enabled at installation and the connected radar is turned on.

23 [PRESENTATION MODE] box Change the presentation (orientation) mode for the radar

images. 24 [DROP MARK] box Shows the bearing and range to the drop mark(s). 25 Screenshot button Saves a screenshot of the entire displayed area.

Note: Requires SD card to be inserted in the Processor

Unit. Shown in gray and not selectable if no SD card is in-

serted.

26 Stabilization mode button Change the stabilization mode (WT (sea stabilization) or

BT (ground stabilization)).

1-8

1.4.3 Information and settings

No. Description

1 Date/Time

Shows date and time (with offset indication). Working indicator

Stops rotating if the system is not functioning normally (screen freeze, etc.).

2 Own Ship information

Shows heading, speed, water tracking speed*1, COG,

SOG*

3 Information box

• Shows information for selected TT or AIS objects.

• Shows the currently selected menu.

• Shows navigational data.

• Shows the performance monitor graph.

• Shows the zoomed area. Note: TT/AIS data are hidden when the menu is open.

4 TT/AIS settings

Contains settings for vectors, CPA, TCPA, lost objects, trails, etc.

5 Alert box

Shows active alerts and contains a shortcut to the alert list.

6 Guidance box

Shows operational guidance for the Control Unit’s left button and right button.

: Direction is indicated with an arrow facing PORT or STBD.

52601 AIS COM ERROR

: Where the data source for COG/SOG is a satellite log, the indica-

tion shows "SLOG".

1. OPERATIONAL OVERVIEW

, coordinates and sensor used for data input.

1-9

1. OPERATIONAL OVERVIEW

Echo processing functions

Manages marks and tracks*

Navigation tools (PI lines/EBL/VRM)

Sets target alarm functions**

Sets TT and AIS functions

Manages stored data

Sets data display box items

Processes nav lines and waypoints

Sets up the radar; changes function key settings

*: Own ship and other ships tracks. **: Alert contact output is set at installation.

Select menu items with arrows ( ) to access the next menu layer. In this example, the [ECHO] menu is accessed, then the [CUSTOMIZED ECHO] menu is accessed.

Menu selection is highlighted and in reverse video.

1.5 Menu Operations

1.5.1 How to open and close the main menu

The main menu can be accessed from the control unit or from the on-screen box. The [MAIN MENU] appears in the information box at the right side of the screen.

From the control unit (RCU-014)

Press the MENU key on the control panel.

From the on-screen box

Place the cursor the [MENU] box, then press the left button.

Note: For the sake of abbreviation in procedures, the above methods are written col-

lectively as “Open the menu.” and “Close the menu.”

1.5.2 How to operate the menus

1. Open the menu.

2. Roll the scrollwheel to select a menu item, then left-click. The menu item currently selected is highlighted and shown in reverse video. You can also select a menu item by pressing the corresponding numeric key on the control unit.

1-10

1. OPERATIONAL OVERVIEW

The next menu layer appears. Menu items with arrows, as shown in the above example figure, have their own menu layer. You can select these items to show the respective menu.

3. Roll the scrollwheel to select a menu item, then left-click. You can also select a menu item by pressing the corresponding numeric key. When required, repeat this step to access the next menu. In the example, [1 ECHO] is selected, which opens the [ECHO (1/2)] menu. Next, [2 CUSTOMIZED ECHO] is selected, which opens the [CUSTOMIZED ECHO (1/

2)] menu. Finally, [3 ECHO STRETCH] is selected, in order to change settings. Menus such as the [ECHO] menu and [CUSTOMIZED ECHO] menu have more than one page. In this case, the currently displayed page is indicated in brackets to the right of the menu title.

To view the next page of a menu, select [0 NEXT]. To go back one layer (or page) in the menu, left-click [1 BACK], or right-click.

4. Roll the scrollwheel to select the desired setting, then left-click. The selected settings is highlighted and displayed in reverse video. In the above example, the selected setting at [3 ECHO STRETCH] is [1].

Note 1: For some menu items, the software keyboard, shown in the figure below, is displayed at the bottom of the menu. Select the number/character desired with the cursor, then left-click. When you finish entering the desired numbers/characters, left-click the [END] button on the software keyboard.

Note 2: Unless otherwise stated, operations in this manual use the scrollwheel for procedures which require menu selection, or settings changed.

5. Close the menu.

1-11

1. OPERATIONAL OVERVIEW

Select the palette indication, then right-click.

1.6 How to Use the On-screen Box Menus

Some radar functions can be accessed using the on-screen box as a shortcut to the respective menus. A “” at the right side of an on-screen box indicates that there is a menu shortcut available.

Note: The cursor changes shape according to its location. When placed outside the

operational display area the cursor is an arrow ( ) shape. When placed inside the

operational display area, it is a cross ( ).

For the purpose of this example, place the cursor on the palette indication (displayed as "PLTx", where x is the currently selected palette number), inside the brilliance settings box at the bottom-left of the screen.

The selected item appears highlighted with a light-blue colored box.

Right-click to show the [BRILL1] box menu.

Similar shortcuts are available from the following on-screen boxes/indications:

• [PICTURE] box.

• [AIS] box.

• [TT] box.

• [HDG] indication.

• [SPD] indication.

• [POSN] indication.

• [PLT] indication.

• [ANTENNA SELECTION] box.

• User settings box.

• [MARK] box.

• Time indication ("UTC" or "Local").

• [TRAIL] indication.

• [CHART ON/OFF] button (A/B/W-types with Radar Plotter functionality only).

1-12

1.7 How to Use the CURSOR Menu

Functions that require the use of the cursor, such as EBL offset and zoom, can be activated directly from the guidance box or from the [CURSOR] menu, either method with the cursor inside the operational display area. Below is the procedure for choosing cursor-related functions from the [CURSOR] menu.

1. Select the operational display area, then press the right button. The [CURSOR] menu appears.

2. Select the desired function, then left-click. Note: Cursor function are also selectable from the

operational display area. With the menu closed, place the cursor inside the operational display area, spin the scrollwheel to show the desired function, then press the left button to activate the function.

1. OPERATIONAL OVERVIEW

3. The guidance box shows "XX / EXIT" (XX = function selected). Use the trackball to place the cursor where desired.

4. Left-click to execute the function selected at step 3.

5. To quit the selected function, right-click when the guidance box shows "XX / EXIT" (XX = function selected). The table below lists the contents of the cursor context menu with a brief description for each menu item.

Menu Item Description

Page 1 TARGET DATA / ACQ TT: Acquires target; displays data for selected

tracked target. AIS: Activates sleeping AIS target; displays data for selected AIS object.

TARGET CANCEL TT: Cancels tracking on selected tracked target.

AIS: Sleeps selected AIS target. TT TGT DATA / ACQ Acquires selected echo as tracked target. REF MARK Inscribes reference mark, for target-based speed

input. EBL OFFSET Offsets EBL to measure range and bearing be-

tween two targets. OFFCENTER Shifts screen center to selected location. ZOOM Zooms selected location.

TARGET TRACK ON*

TARGET TRACK OFF* MARK DELETE Deletes selected mark (plotter mark, origin mark

OWN TRACK DELETE Deletes own ship's tracks.

TGT TRACK DELETE* MAP ALIGN Aligns charts (maps) with the radar picture.

TRAIL ERASER*

1*3

Shows the target tracks.

Hides the target tracks.

or waypoint mark).

Deletes the selected target’s tracks.

Erases trails.

1-13

1. OPERATIONAL OVERVIEW

Press the left button

to switch between

display formats

Menu Item Description

Page 2 TARGET DATA / ACQ SETTING Change target tracking settings. TARGET CANCEL SETTING Change target cancel settings. RANGE RINGS Show/hide the range rings. SLEEP ALL TARGETS Sleep all AIS targets.

*1: Shown on A/B/W-types only

: Shown on B/W-types only

: Shown on A/B/W-types only when [5 AUTO TARGET TRACK], located in [2

* MARKS] ([2 MARKS•CHARTS] for systems with Radar Plotter functionality) → [7 TRACKS] → [3 TARGET TRACK] menu, is set to [OFF].

1.8 Cursor Data

The cursor data display shows the cursor’s latitude and longitude position or the cursor’s X-Y co-ordinates.

Place the cursor on the [CURSOR DATA] box at the top-right side of the display then press the left button to switch between display formats.

The data box shows the cursor location, bearing/range to the cursor location and the time to go (TTG) to the cursor location.

Cursor’s X-Y

co-ordinates

displayed

33°59.156’N

135°06.328’E

X: +1.667NM Y: +3.694NM

TTG 00:05

X/Y axis coordinates to cursor position.

Bearing/range

displayed

33°59.156’N

135°06.328’E

0.24.4ºR

4.028NM

TTG 00:05

Press the left button

to switch between

display formats

Cursor positon’s

latitude/longitude

Bearing/range to cursor position.

TTG to cursor position

Note 1: For the X-Y co-ordinates display, the Y-axis is the upper/lower half of the screen, the upper half of the screen is “plus” and the lower part of the screen is “minus”. The X-axis is the left/right-side of the screen, right is “plus”, left is “minus”.

Note 2: Cursor data reads "- - -.-" when the cursor is placed outside the operational display area.

1-14

1. OPERATIONAL OVERVIEW

1.8.1 How to change the cursor data attributes (B/W-type only)

You can change the cursor bearing reference, cursor range unit, cursor size and also align the cursor by latitude/longitude. Changing some of these settings affects the indications in the cursor data display.

1. Open the menu.

2. Select [3 NAV TOOLS].

3. Select [3 EBL•VRM•CURSOR SET].

4. Select [9 CURSOR]. The [CURSOR] menu appears.

5. Select the item you want to change, referring to the list below.

• [2 CURSOR BEARING]: Sets the bearing reference.

• [3 CURSOR RANGE]: Sets the unit for cursor range.*

• [4 CURSOR SIZE]: Sets the cursor size.

• [5 CURSOR L/L ALIGN]: Set whether to align the cursor with latitude/longitude.

*: Appears for B-types only.

6. Close the menu.

1.9 How to Set Up Function Keys

Some menu functions and menus can be assigned to a function key. This allows onetouch access to the assigned function or menu.

To activate an assigned function, press the corresponding function key (F1, F2, F3 or F4).

The current presets are listed at the bottom of the menu page and the function keys are preset with the following functions:

F1: Interference Rejector, F2: Echo Stretch, F3: AUTO-SEA, F4: AUTO-RAIN.

You can change the function assigned to each key using the following procedure.

1. Open the [MAIN MENU].

2. Select [9 INITIAL SETTINGS].

3. Select [6 FUNCTION KEY SETUP]. The function key setup menu appears.

4. Select the function key to set up.

5. Referring to the following table of available functions, select a function category, then left-click.

1-15

1. OPERATIONAL OVERVIEW

Function category

Available functions

ECHO CUSTOM SELECT, IR, ES, EAV, NOISE REJ, ANT SELECT,

PULSE LENGTH, AUTO-SEA, AUTO-RAIN, TUNE SELECT, 2ND ECHO REJ, STC CURVE, STC RANGE, PM, SART, ECHO TRAIL,

TRAIL T/R, WIPER*

, ACE, ACE HIGH SENSITIVITY

STD KEY ALERT ACK, STBY TX, HL OFF, EBL OFFSET, ORIENTATION-

MODE, OFF CENTER, CU-TM RESET, PI LINE, VECTOR TIME, VECTOR MODE, TARGET LIST, BRILL, MARK, MENU, RANGE UP, RANGE DOWN, ACQ, TARGET DATA, TARGET CANCEL

TT•AIS TT-DISP, AIS-DISP, TARGET DATA & ACQ, PAST POSN INTER-

VAL, REF MARK, CPA LIMIT, CPA, TCPA, AZ1, AZ2, TARGET LIST SORT, TRIAL MANEUVER, TRIAL MODE CHANGE, AIS MESSAGE, AIS SCALED SYMBOL

DELETE DATA MARK DELETE, MARK ALL DELETE, OWN TRK DELETE, OWN

, TGT TRK ALL DELETE*

OPERATION

TRK ALL DELETE, TGT TRK DELETE*

BUZZER STOP, ECHO AREA*

, ECHO COLOR, PALETTE,

RING(ON/OFF), ZOOM, MOB, ALARM1, ALARM2, WATCH ALERT

RESET*

SCREEN SHOT, CHART DISPLAY*

, TLL*1, MAP ALIGN, ANCHOR WATCH, DROP MARK,

, NAV AIDS*

*1: Appears for B/W-types only.

: Appears for A/B/W-types with radar plotter functionality only.

: Appears for A/B/W-types only.

6. Select the appropriate function to assign, then left-click. You can check the currently assigned functions in the bottom half of the menu.

7. Repeat the procedure as necessary to set up other function keys.

8. Close the menu.

1-16

1.10 How to Customize Operation

These menu items appear for all radar types, however B/W-types may have additional menu items. See the following table for details.

Several operation items can be customized to suit your needs.

1. Open the menu.

2. Select [9 INITIAL SETTING].

3. Select [5 OPERATION]. The [OPERATION] menu appears.

1. OPERATIONAL OVERVIEW

4. Referring to the table below, press the menu item number to select the appropriate menu item to customize.

Menu items Description

Page 1 [2 MOUSE WHEEL DIR] Sets the direction of the wheel drive (scrollwheel).

• [NORMAL]: Scroll downwards to increase, or upwards to decrease the value.

• [REVERSE]: Scroll directions are reverse of [NORMAL].

[3 KEY BEEP] Changes the key beep volume.

Select [OFF] to silence the key beeps. Select [LOW], [MID], [HIGH] to adjust the volume for key beeps.

[4 OWN SHIP VECTOR] Select how the own ship vector is displayed.

• [OFF]; Own ship vector is not displayed.

• [HDG]: Vector is displayed in heading direction.

• [COURSE]: Vector is displayed in course direction.

[5 STERN UP RM] Select [ON] to show [STERN UP RM] orientation in

the selection cycle. (See section 1.30.) Note: This item is shown for A/B/W-types only.

[6 SHUTTLE FERRY] Sets the shuttle ferry mode to use.

• [OFF]: Shuttle ferry mode is deactivated.

• [MODE1]: Shuttle ferry mode is activated. See "Shuttle ferry mode" on next page.

• [MODE2]: Shuttle ferry mode is activated. See "Shuttle ferry mode" on next page.

Note: Shuttle ferry mode requires an external switch.

[7 ICING PREVENTION] Select [ON] to rotate the antenna without transmis-

[8 BRG FINE ADJUST] Adjusts the heading line location. 0.0°, the default set-

sion, to prevent ice buildup. See section 1.53.

ting, shows the heading line pointing towards the top of the screen.

1-17

1. OPERATIONAL OVERVIEW

Standard display: Gyro input is displayed normally.

Reversed display: Gyro input is displayed in reverse.

Menu items Description

[9 USB MOUSE SPEED] Adjust the USB mouse sensitivity. A higher value in-

Page 2 [2 AUTO COURSE UP RESET] Select [ON] to enable, or [OFF] to disable the auto-

[3 DISPLAY SCROLL] Select [ON] to enable, [OFF] to disable display scroll-

5. Select the required setting by pressing the menu item number. For this example, set [3 KEY BEEP] to [HIGH]. Press the 3 MODE key to highlight [HIGH]. For [8 BRG FINE ADJUST] and other menu items with a setting range, spin the scrollwheel, or use the number keys to adjust the required setting.

Note: Regarding input for [8 BRG FINE ADJUST], when using the number keys, the indication is first selected as a whole. At this time, you can toggle between plus “+” or minus “-”. Press the 8 key for “-”, press the 2 key for “+”. If single digits are highlighted, toggle is not possible. In this case, press the CANCEL TRAILS key to re-highlight the whole indication.

crease the mouse cursor’s movement speed.

matic reset of the screen when using COURSE UP orientation and your course is more than 22.5° to either side the center of the screen.

ing. When set to [ON], move the cursor to the edge of the screen in the direction you want to scroll. Note: This item is shown for B/W-types only.

6. Close the menu.

Shuttle ferry mode

The shuttle ferry mode changes the orientation of the display when the external switch is turned on. (The external switch should be connected to the RS-232C port on the processor unit at installation.)

There are two variations: Standard display ([SHUTTLE FERRY] is set to [OFF]) and reversed display ([SHUTTLE FERRY] is set to [MODE1] or [MODE2]).

When the display is reversed for shuttle ferry mode, the following changes also occur:

• Echoes are displayed 180° opposite to normal display.

• Bearing for speed data is re-calibrated to 180° opposite to normal.

• Wind direction based on speed input is re-calibrated to 180° opposite to normal.

• Where [Mode2] is selected, data input from the gyrocompass is re-calibrated to 180° opposite to normal.

Note: Gyrocompass data input is not re-calibrated for [Mode1].

1-18

1. OPERATIONAL OVERVIEW

1.11 How to Select the Interface for Heading Input

When a gyrocompass is connected, the ship’s heading appears on the right side of the screen, in the data display area.

Heading input format can be selected as follows:

1. Open the menu.

2. Select [7 INFORMATION BOX].

3. Select [2 OWN SHIP INFO].

4. Select [2 HDG]. The [HDG] menu appears. Note: You can also access the [HDG] menu from the on-screen box. Place the cursor on the [HDG

] indication in the heading box at the top-right of the screen, then right-click.

5. Select [2 HDG SOURCE].

6. Select [GYRO1] or [GYRO2] as appropriate.

7. Close the menu.

Note 1: The heading sensor must be able to follow a minimum ROT of 20° per second. Heading sensors with a lesser capability may degrade the performance of echo averaging, trails and TT. The data refresh rate should also be as short as possible. If the refresh rate is too long, the ability to follow courses lessens, thereby affecting the performance of echo averaging, trails and TT.

Note 2: For IMO-types, Where the heading source is other than the heading sensor (for example, and EPFS device), the sensor indication is displayed in yellow color.

1.12 How to Set Own Ship’s Speed

The TT and azimuth stabilized presentation modes require own ship speed input and compass signal. The speed can be entered from a log (STW, SOG) or EPFS (SOG) or manually on the menu.

1.12.1 Automatic speed input (log or EPFS navigator)

1. Open the menu.

2. Select [7 INFORMATION BOX].

3. Select [2 OWN SHIP INFO].

4. Select [3 SPEED].

5. Select [2 SHIP SPEED]. Note: You can also access the [SPEED] menu from the on-screen box. Place the cursor on the

[SPD ] indication in the speed box at the topright of the screen, then right-click.

6. Select the appropriate source for automatic speed input, referring to following table. Note: Changes to the settings here are also applied to the speed calculations for TT targets, true trails, SOG and STW.

1-19

1. OPERATIONAL OVERVIEW

Selection Explanation Stabilization Mode

[LOG (BT)]* [LOG (WT)] Log, Speed Thru Water (STW) Sea stabilization [EPFS] Speed input by GPS navigator Ground stabilization [MANUAL] Manually input speed Sea stabilization [REF] Echo-referenced speed input Ground stabilization

[ECDIS]*

*1: Set and drift may be required to display [LOG (BT)] correctly in deep waters. To change set and drift, see section 3.14.

: Where [ECDIS] is selected as the speed source, [4 OWN SHIP POSN] in the

[OWN SHIP INFO] menu is automatically set to [ECDIS] also. See section 1.13.

7. If you selected [MANUAL] as the speed data source, see section 1.12.2 to set the speed.

8. Close the menu.

Log, speed over ground (SOG) Ground stabilization

Speed input by ECDIS Ground stabilization or Sea

Stabilization (Dependent on ECDIS settings).

Notes on speed input

It should be noted that in determining a target's aspect by radar, the calculation of its true track is dependent on the choice and accuracy of the own ship's course and speed input. A ground-stabilized target plot may accurately calculate the ground track of the target, but the target's heading may be significantly different from its track when experiencing set, drift or leeway. Similarly, a sea stabilized target plot may be inaccurate when own ship and the target, are experiencing different rates of set, drift or leeway.

• IMO Resolution A.823(19) for TT recommends that a speed log to be interfaced with

a TT should be capable of providing through-the-water speed (forward speed).

• Be sure not to select a [LOG] option when a speed log is not connected. If the log

signal is not provided, the ship speed readout at the top of the screen will be blank. In the event of a log error, enter speed manually.

• If a speed log is selected as the data source and there is no signal present for 30

seconds, the [SPD] is shown as "*.* kn" and the label "LOST LOG(BT) SIG" or "LOST LOG(WT) SIG" in yellow-orange appears and the alert buzzer sounds.

• When the speed input in use is interrupted or lost, the system automatically chang-

es to another speed input (stabilization reference) and shows the "SPD SOURCE CHG" indication.

1-20

• On IMO-type radars with AIS in use, [MANUAL] and [REF] are shown in gray to in-

dicate they are not available for selection.

• A single-axis water log cannot measure speed when the wind is coming from the

leeway direction.

• When [ECDIS] is selected as the speed data source and communication with the

ECDIS is interrupted or lost for 30 seconds, the Alert "LOST ECDIS COM" is released.

• When speed stabilization is changed at the ECDIS and [ECDIS] is selected as the

speed data source, the "SPD SOURCE CHG" indication appears.

1.12.2 Manual speed input

If the speed log is not working, enter speed manually as below. In this case the speed data type is shown as "MANUAL" and is speed thru water (STW). Manual speed input is not available on IMO-type radars when the AIS feature is active.

1. Open the menu.

2. Select [7 INFORMATION BOX].

3. Select [2 OWN SHIP INFO].

4. Select [3 SPEED].

5. Select [2 SHIP SPEED]. Note: You can also access the [SPEED] menu from the on-screen box. Place the

cursor on the [SPD ] indication in the speed box at the top-right of the screen, then right-click.

6. Select [MANUAL].

7. Select [3 MANUAL SPEED INPUT].

8. Spin the scrollwheel to set the speed.

9. Press the ENTER MARK key to confirm the new setting.

1. OPERATIONAL OVERVIEW

10. Close the menu.

1.13 How to Set the Own Ship Position

You can select the data source for own ship’s position as follows:

1. Open the menu.

2. Select [7 INFORMATION BOX].

3. Select [2 OWN SHIP INFO].

4. Select [4 OWN SHIP POSN]. Note: You can also access the [OWN SHIP

POSN] menu from the on-screen box. Place the cursor on the [POSN ] indication in the position box at the top-right of the screen, then rightclick.

5. Select [2 POSITION SOURCE] or [3 MANUAL L/L INPUT] as appropriate.

6. If [2 POSITION SOURCE] is selected at step 2, select the appropriate position source, referring to the list below. [2 POSITION SOURCE] uses navigational aids. Select the navigational aid to use. Available options are listed with a brief description in the table below:

Available options Description

[EPFS1] Use the device assigned as EPFS1 for position data. [EPFS2] Use the device assigned as EPFS2 for position data. [LAN] Use the device connected to the LAN1 port for position data. [ECDIS] Use the connected ECDIS for position data. [DEAD RECKONING] Position data is derived from dead reckoning (manual input)

1-21

1. OPERATIONAL OVERVIEW

19 / SEP / 2016

15 15

Date

Date/time format indication Left-click: Toggle UTC and LOCAL time. Right-click: Open the [DATE] menu.

Time

Note 1: Where [2 POSITION SOURCE] is set to [DEAD RECKONING], the indication "DR" appears at the bottom of the [OS POSN] box.

Note 2: Where [2 POSITION SOURCE] is set to [DEAD RECKONING] or [MANUAL L/L INPUT], the AIS function cannot be used.

Note 3: Where [2 POSITION SOURCE] is set to [ECDIS], the source for own ship speed data is automatically set to [ECDIS] also.

Note 4: On IMO-type radars with AIS in use, [DEAD RECKONING] is shown in gray to indicate it is not available for selection.

Note 5: Speed and heading data is required in order to correctly display [DEAD

RECKONING] position data.

7. To set [3 MANUAL L/L INPUT], do the following:

1) Select [3 MANUAL L/L INPUT]. The first digit of the latitude is highlighted.

2) Spin the scrollwheel to set the value, then left-click. The cursor moves to the next digit. Use the same method to select [N]/[S]/[E]/[W]. You can also use the number keys on the Control Unit to input the value.

3) Repeat step 2 to set the latitude and longitude.

8. To share [OS POSN] data across the same network, do the following:

1) Select [4 SIO DATA LAN OUTPUT].

2) Select [ON] to share data. To disable [OS POSN] data sharing, select [OFF].

Note: A navigational aid must be selected at [2 POSITION SOURCE] to share [OS POSN] across the same network.

9. Close the menu.

1.14 How to Adjust the Date and Time

Date and time are displayed at the top-right of the screen in the [DATE/TIME box]. You can left-click the date/time format indication to toggle between [UTC] format and [LOCAL] format.

You can also adjust the local time and switch between time formats from the menu.

To adjust the local time, follow the procedure below.

1. Open the menu.

2. Select [7 INFORMATION BOX].

3. Select [2 OWN SHIP INFO].

4. Select [5 DATE]. Note: You can also access the [DATE] menu from

the on-screen box. Place the cursor on the [UTC ] or [LOCAL ] indication in the date box at the topright of the screen, then right-click.

1-22

1. OPERATIONAL OVERVIEW

5. Select [2 DATE-TIME], then select [UTC] or [LOCAL] as appropriate.

• [UTC]: Date and time are displayed in UTC format.

• [LOCAL]: Date and time are shown with the local time offset applied.

If you selected [UTC], close the menu. If you selected [LOCAL], go to step 6.

6. Select [3 ADJUST LOCAL TIME].

Time indication highlighted as a whole. Toggle between “+” and “-” is possible.

7. Spin the scrollwheel, or use the number keys to input the desired offset. The offset must be in 30 minute increments.

Note: Regarding input for [3 ADJUST LOCAL TIME], when using the number keys, the indication is first selected as a whole. At this time, you can toggle between plus “+” or minus “-”. Press the 8 key for “-”, press the 2 key for “+”. If single digits are highlighted, toggle is not possible. In this case, press the CANCEL TRAILS key to re-highlight the whole indication.

8. Close the menu.

1.15 User Settings

The user functions shown in the table below can be reset to their default settings by enabling the [PILOT SETTING] option in the [USER SET] menu. Functions not shown in the table below maintain their previous setting.

The unit can store two separate user settings, for the functions listed below, in the internal memory. These settings can also be recalled. Functions not shown in the table below cannot be stored or recalled.

Single digit is highlighted. Toggle between “+” and “-” is not possible.

Function Setting(s) Menu/On-screen box

GAIN Maintained as per

previous setting. SEA [MAN], the setting RAIN [RAIN] box

TUNE [AUTO] [TUNE] box (Magnetron radars only) TX CH Maintained as per previous setting. (Solid State radars on-

Range [6 NM] [RANGE] box Range rings [OFF]

VRM1 Display [ON] [VRM1] box

Distance [0.250 NM]

value is maintained

as per previous set-

ting.

ly)

[GAIN] box

[SEA] box

[MAIN MENU] [4 RANGE RINGS]

→ [3 NAV TOOLS] →

1-23

1. OPERATIONAL OVERVIEW

Function Setting(s) Menu/On-screen box

VRM2 Display [ON] [VRM2] box

Distance Maintained as per

EBL1 Display [ON] [EBL1] box

Bearing Maintained as per Reference

EBL2 Display [ON] [EBL2] box

Bearing Maintained as per Reference

PI Lines Display Maintained as per

Interval Orientation Bearing (True

or Relative)

Number of PI lines

Mode (Parallel or

Perpendicular) Presentation Mode [NORTH UP TM] [PRESENTATION MODE] box Stabilization mode (Sea/

Ground) Off-centering TM reset position

Target trails

Past position [OFF] [PAST POSN] box Vector mod [REL] [VECTOR] box Vector time [6 MIN] AZ1 [OFF] [AZ1] box AZ2 [OFF] [AZ2] box TT acquisition mode [MAN100] AIS display [DISP ALL] [AIS] box Association [ON] (TT < AIS)

Lost Alert [OFF] (Disabled) LOST TARGET ALERT box CPA/

TCPA alarm

Display, time [ON], [6 MIN] [TRAIL MODE] box

Mode [TRUE] [PAST POSN] box

ON/OFF [ON] [CPA LIMIT] box

CPA [2 NM]

TCPA [12 MIN]

previous setting.

[LOG(WT)] (Sea)

[MAIN MENU] [3 EBL•VRM•CURSOR SET] → [5 EBL•CURSOR BEARING]

[MAIN MENU] [3 EBL•VRM•CURSOR SET] EBL•CURSOR BEARING]

[PI Line] box

[MAIN MENU] [2 PI LINES]

ING] * [MAIN MENU]

[2 PI LINES] → [3 SET MAXIMUM PI LINE]

[MAIN MENU] [2 PI LINES] → [4 PI LINE MODE]

[SPEED] box

OFF CENTER key.*

[TT TARGET]

[MAIN MENU] TARGET ASSOCIATION] → [2 ASSOCIATION TGT TYPE]

→ [3 NAV TOOLS] →

→ [5

→ [3 NAV TOOLS] →

→ [2 PI LINE BEAR-

→ [3 NAV TOOLS] →

→ [2 SHIP SPEED]

→ [TT SELECT]

→ [5 TT•AIS] → [7

1-24

*1: This menu is not available for IMO/A/R/W-types and the setting is fixed to [TRUE].

: Has the same effect as selecting the True Motion presentation mode.

1.15.1 How to reset the user settings

1. OPERATIONAL OVERVIEW

Menu operation

1. Open the menu.

2. Select [9 INITIAL SETTINGS].

3. Select [4 USER SETTINGS]. You can also access this menu from the [USER SET] box, as shown to the right.

4. Select [2 PILOT SETTING].

5. Select [YES].

6. Close the menu.

Select the [USER SET box

, then right-click.

]

From the on-screen box

Place the cursor on the [USER SET] box, then long-press the left button.

Note 1: Items not shown in the table on the previous page keep their previous settings when [PILOT SETTING] is activated.

Note 2: TT tracking is continued after [PILOT SETTING] is activated.

Note 3: The radar map displays the same map as before [PILOT SETTING] is activat-

ed.

1.15.2 How to save/load user settings

1. Open the menu.

2. Select [9 INITIAL SETTINGS].

3. Select [4 USER SETTINGS].

4. Select [USER1(2) LOAD] or [USER1(2) SAVE] to recall or save user settings, respectively.

5. Select [YES].

6. Close the menu.

When loading settings, the following points apply:

• If the newly loaded settings cannot be applied to items not listed in the table above,

then these items keep their previous settings.

• TT tracking is continued after the settings are loaded.

• The radar map displays the same map as before the settings were loaded.

1-25

1. OPERATIONAL OVERVIEW

1.16 How to Start/Stop Transmission

The radar is ready to transmit when the message "STBY" appears in the operational display area. Transmission can be started using one of the following procedures:

• Using the control unit: Press the STBY TX key.

• Using the on-screen box: Left-click the button on the InstantAccess bar

When the radar is switched to TX (transmit) status, most settings (such as brilliance, range, pulse width, etc) are restored with the same settings as before standby.

For magnetron radars, it is recommended to place the radar in standby when transmission is not required, to reduce wear on the magnetron. You can also set a “blank sector” where transmission is stopped (see the Installation Manual for details).

How to stop antenna rotation

Antenna rotation can be stopped using one of the following procedures:

• Turn the antenna switch off.

™

• Turn antenna rotation off from the menu (See installation manual).

Screen freeze

The screen is not refreshed if the screen has frozen. An audio alarm is released 30 seconds after a screen freeze. The ALARM ACK key flashes and a contact alert sig- nal is also released. To return the radar to normal operation, turn the radar off, then on again.

Quick start

Provided that the radar was in use and the magnetron (transmitter tube) is still warm, you can switch to transmit mode without the three minute warm-up time. If the radar was turned off by mistake or you wish to restart the radar promptly, wait several seconds before you press the POWER switch.

1-26

1. OPERATIONAL OVERVIEW

1.17 How to Tune the Receiver (Magnetron Radars Only)

Your magnetron radar has a tuning function (automatic or manual). For solid-state radars, tuning is not available.

1.17.1 How to select the tuning method

Tuning of the magnetron is typically done at installation and is not normally required unless you have replaced the magnetron.

1. Select the [TUNE] button, at the top of the InstantAccess bar

ing method. The tuning box is displayed as "TUNE AUTO" or "TUNE MAN", depending on the currently selected tuning method.

2. Left-click to toggle between automatic and manual tuning.

Tuning method Shown as “TUNE MAN” or “TUNE AUTO”.

1.17.2 How to initialize tuning

Automatic tuning is initialized at installation. However, if you feel that the automatic tuning is not functioning properly, re-initialize it by following the procedure below.

1. Open the menu.

2. Select [2 ECHO].

3. Select [4 TUNING INITIALIZE].

The indication "TUNE INIT" appears in yellow characters at the top of the display during the initialization.

Tuning level indication

™

, to change the tun-

4. Close the menu.

1.17.3 How to tune the receiver manually

1. Select the 48-mile range from the [RANGE] box. Left-click to lower the range;

right-click to raise the range.

2. Select manual tuning following the procedure in section 1.17.1.

3. Place the arrow on the tuning level indication.

4. Spin the scrollwheel to adjust tuning. The best tuning point is where the bar graph

swings maximum. The tuning control position is indicated with a triangle, displayed inside the tuning bar.

1-27

1. OPERATIONAL OVERVIEW

PULSE

Current pulse length appears here. (S1, S2, M1, M2, M3, L)

[

PULSE] button

1.18 How to Select a Pulselength

The pulselength in use is indicated on the PULSE button of the InstantAccess bar™, at the top-left of the screen.The table below shows the indications and their meaning.

Appropriate pulselengths are preset to individual range scales and function keys. If you are not satisfied with the current pulselength settings, you can change them as shown in the procedure below.

1.18.1 How to select a pulselength

The pulselength can be changed using the procedure below.

1. Place the cursor in the [PULSE] box at the top left corner of the screen.

2. Left-click to decrease, right-click to increase the pulselength; or spin the scrollwheel to cycle through pulselengths. The order in which the pulselengths are cycled is shown in the table below. "*" indicates the default preset for each range setting.

Range (PULSE) indication Range (PULSE) indication

0.5 NM S1*, S2 6 NM M1, M2*, M3, L

0.75 NM S1*, S2, M1 12 NM M1, M2, M3*, L

1.5 NM S1*, S2, M1, M2 24 NM M2, M3, L* 3 NM S2*, M1, M2, M3

Note: Available pulselengths are restricted depending on the range.

1.18.2 How to change the preset pulselength

To change the preset pulselength for a range setting, follow the procedure below.

1. Open the menu.

2. Select [1 ECHO].

3. Select [2 CUSTOMIZED ECHO]. Note: You can also access the [CUSTOMIZED

ECHO] menu from the on-screen box. Place the cursor on the [PICTURE] indication in the date box at the top-left of the screen, then right-click.

4. Select [9 PULSE LENGTH].

5. Select the desired range, then select the required pulselength.

6. Close the menu.

1-28

1.19 How to Adjust Sensitivity

The gain control adjusts the sensitivity of the receiver.

The proper setting is such that the background noise is just visible on the screen. If you set up for too little sensitivity, weak echoes may be missed. On the other hand excessive sensitivity yields too much background noise; strong targets may be missed because of the poor contrast between desired echoes and the background noise on the display.

To adjust receiver sensitivity, adjust the gain control so background noise is just visible on the screen.

How to adjust the GAIN from the control unit (RCU-014)

Rotate the GAIN knob. Rotate anticlockwise to decrease the gain, or clockwise to increase the gain.

How to adjust the GAIN from the on-screen box

1. Place the cursor in the [GAIN] box at the top of the screen.

1. OPERATIONAL OVERVIEW

40GAIN

2. Spin the scrollwheel to adjust the gain. The setting range is [0] to [100].

Place the cursor inside the gain level indication, then spin the scrollwheel.

1.20 How to Reduce Sea Clutter

Echoes from waves cover the central part of the display with random signals known as sea clutter. The higher the waves, and the higher the antenna above the water, the further the clutter extends. When sea clutter masks the picture, reduce it with the A/C SEA control, either manually or automatically.

Note 1: When both sea clutter and rain clutter are reduced, the sensitivity is decreased more than when only one is changed. For that reason adjust them carefully.

Note 2: The echo average function (see section 1.24) is useful for reducing reflections from the sea surface. However, high-speed targets are harder to detect than stationary ones when echo average is active.

1.20.1 How to select the method of clutter adjustment

1. Place the cursor in the [SEA AUTO] or [SEA MAN] (whichever is shown) level indication at the top of the display.

Place the cursor on the [AUTO] or [

MAN] indication, then left-click.

40SEA MAN

2. Left-click to display [SEA AUTO] or [SEA MAN] as appropriate.

1-29

1. OPERATIONAL OVERVIEW

SEA AUTO

Place the cursor inside the level indication, then spin the scrollwheel.

1.20.2 How to fine-tune sea clutter reduction

Auto A/C SEA allows for fine tuning of the A/C SEA circuit, within ±20 dB. Accordingly, with the bar reading set to 50, gain is not lowered to minimum as with manual A/C SEA on close-in ranges. Further, the auto A/C SEA level is low because the average value of the original input echo is low in areas where there are no sea surface reflections. For example, when the ship is alongside a quay and the radar picture shows echoes from both land and sea, you can observe the size of the echoes because the STC curve changes with the size of the echoes.

Note: The auto A/C function can erase weak target echoes. Adjust the control carefully, watching the display.

How to fine-tune sea clutter reduction from the control unit (RCU-014)

Rotate the AC/SEA knob. Rotate anticlockwise to decrease the AC/SEA, or clockwise to increase the A/C SEA.

How to fine-tune sea clutter reduction from the on-screen box

1. Select [SEA AUTO], following the procedure in section 1.20.1.

2. Place the arrow on level indicator inside the A/C SEA box at the top of the display.

3. While observing the A/C SEA level indicator, spin the scrollwheel to adjust the clutter reduction. The setting range is [-50] to [50].

1.20.3 How to manually reduce sea clutter

Sea clutter at screen center

Note: The proper setting of the A/C SEA should be such that the clutter is broken up into small dots, and small targets become distinguishable. If the setting is set too low, targets will be hidden in the clutter, while if the setting is too high, both sea clutter and targets will disappear from the display. In most cases adjust the control until clutter has disappeared to leeward, but a little is still visible windward. Be careful not to remove all sea clutter, because you may erase weak echoes. Further, the possibility of losing weak echoes is greater when you use both A/C SEA and A/C RAIN to reduce clutter.

A/C SEA control adjusted;

sea clutter reduced

1-30

How to reduce sea clutter manually from the control unit (RCU-014)

Rotate the AC/SEA knob. Rotate anticlockwise to decrease the AC/SEA, or clockwise to increase the A/C SEA.

How to reduce sea clutter manually from the on-screen box

40SEA MAN

Place the cursor inside the level indication, then spin the scrollwheel.

Shown only for FAR-2228-NXT, FAR-2228-NXT-BB and FAR-2328-NXT.

1. Select [SEA MAN], following the procedure in section 1.20.1.

2. Place the cursor on the level indicator inside the A/C SEA box at the top of the display.

3. While observing the A/C SEA level indicator, spin the scrollwheel to adjust the clutter reduction. The setting range is [0] to [100].

1.20.4 How to use the BERTHING STC function

The [BERTHING STC] function allows you to show the main bang echo, even with the range set at 0.5 NM or less with AUTO SEA at maximum setting. This is particularly useful when attempting to berth, as it gives a clearer view of the berthing area and your ship’s location.

To use the [BERTHING STC] function, follow the procedure below.

1. OPERATIONAL OVERVIEW

1. Open the menu.

2. Select [1 ECHO].

3. Select [0 NEXT]. The second page of the [ECHO] menu appears.

4. Select [5 BERTHING STC].

5. Select [ON] to activate, or [OFF] to deactivate, this function.

6. Close the menu.

1.21 How to Reduce Rain Clutter

Use the AUTO RAIN and A/C RAIN to reduced rain clutter. AUTO RAIN reduces rain clutter in the picture and A/C RAIN reduces clutter picked up by the antenna.

Note 1: When both sea clutter and rain clutter are reduced, the sensitivity is decreased more than when only one is changed. For that reason adjust them carefully.

1-31

1. OPERATIONAL OVERVIEW

Rain clutter at screen center

A/C RAIN control adjusted;

rain clutter reduced

1.21.1 How to select the method of rain clutter reduction

1. Place the cursor in the [RAIN AUTO] or [RAIN MAN] (whichever is shown) level indication at the top of the display.

Place the cursor inside the level indication, then left-click.

40RAIN MAN

2. Left-click to display [RAIN AUTO] or [RAIN MAN] as appropriate. Note: Unlike sea clutter reduction, rain clutter cannot be finely adjusted when set to [AUTO].

1.21.2 How to manually reduce the rain clutter

The vertical beam width of the antenna is designed to see surface targets even when the ship is rolling. However, by this design the unit will also detect rain clutter (rain, snow, or hail) in the same manner as normal targets.

Note: The A/C RAIN control adjusts the receiver sensitivity as the A/C SEA control does but rather in a longer time period (longer range). The higher the setting the greater the anti-clutter effect. When echoes from precipitation mask solid targets, adjust the A/C RAIN control to split up these unwanted echoes into a speckled pattern, making recognition of solid targets easier. Be careful remove all rain clutter, because you can erase weak echoes. Further, the possibility of losing weak echoes is greater when you use both A/C RAIN and A/C SEA to reduce clutter.

How to fine-tune rain clutter reduction from the control unit (RCU-014)

Rotate the A/C RAIN knob. Rotate anticlockwise to decrease the A/C RAIN, or clockwise to increase the A/C RAIN.

How to fine-tune rain clutter reduction from the on-screen box

1. Select [RAIN MAN], following the procedure in section 1.21.1.

2. Place the cursor on the level indicator inside the A/C SEA box at the top of the display.

40RAIN MAN

3. While observing the A/C RAIN level indicator, spin the scrollwheel to increase or decrease the level. 100 levels (0-100) are available.

Place the cursor inside the level indication, then spin the scrollwheel.

1-32

Note: The detection range is reduced when the RAIN is used to show targets in rain.

Generally, the amount of rain, TX pulse length and TX frequency are factors in determining how the detection range is affected. The figure below illustrates this.

1. OPERATIONAL OVERVIEW

Reduction of range of first detection (NM)

16 mm/h rain - short pulse 4 mm/h rain - short pulse 16 mm/h rain - long pulse 4 mm/h rain - long pulse

0 2 4 6 8 10 12 14 16

4 mm/h rain (short pulse)

16 mm/h rain (short pulse)

4 mm/h rain (long pulse)

16 mm/h rain (long pulse)

4 mm/h rain (short pulse)

16 mm/h rain (short pulse)

4 mm/h rain (long pulse)

16 mm/h rain (long pulse)

Original range of first detection (NM)

16 mm/h rain - short pulse 4 mm/h rain - short pulse 16 mm/h rain - long pulse 4 mm/h rain - long pulse

Reduction of rain to first detection due to rain at S-band

Reduction of rain to first detection due to rain at X-band

The author thanks the International Electrotechnical Commission (IEC) for permission to reproduce Information from its Interantional Standard IEC 62388 ed.1.0 (2007). All such extracts are copyright of IEC, Geneva, Switzerland. All rights reserved. Further information on the IEC is available from www.iec.ch. IEC has no responsibility for the placement and context in which the extracts and contents are reproduced by the author, or is IC in any way responsible for the other content or accuracy therein.

Reduction of Range of First Detection (NM)Reduction of Range of First Detection (NM)

How to interpret the graph

Using the graph below as an example, a radar target originally detected on the 8 NM range can only be detected in rain at the ranges shown below:

Accordingly, the short pulse may be preferable in rain on ranges less than 10 NM.

1-33

1. OPERATIONAL OVERVIEW

Interference from radars using the same frequency.

1.22 Interference Rejector

Mutual radar interference can occur in the vicinity of another shipborne radar operating in the same frequency band. It is seen on the screen as a number of bright spikes either in irregular patterns or in the form of usually curved spoke-like dotted lines extending from the center to the edge of the picture. Activating the interference rejector circuit can reduce this type of interference. The interference rejector is a kind of signal correlation circuit. It compares the received signals over successive transmissions and reduces randomly occurring signals. There are three levels of interference rejection depending on the number of transmissions that are correlated.

You can access this feature from the InstantAccess bar

™

, or from the menu. The avail-

able settings are: [OFF], [1], [2] or [3].

Note: When multiple radars using the same frequency are nearby, interference may appear in a similar manner to that shown in the figure to the right. If this kind of interference appears, do one of the following:

• Press the HL OFF key, or click the [HL OFF] button on

the InstantAccess bar™.

• Change the range.

How to reject interference from the InstantAccess bar

To adjust the interference rejector, select the [IR] button ( ) on the InstantAc-

OFF

™

cess bar

The available settings, in cyclic order, are: [OFF] → [1] → [2] → [3] → [OFF]...

Level [3] provides the highest level of rejection.

, then left-click to cycle through the rejection levels.

How to reject interference from the menu

1. Open the menu.

2. Select [1 ECHO].

3. Select [2 CUSTOMIZED ECHO].

4. Select [2 INT REJECTOR].

5. Select the required setting.

6. Close the menu.

1-34

Note: You can also right-click the [PICTURE]

box to access this menu.

1.23 Echo Stretch

The echo stretch feature enlarges targets in the range and bearing directions to make them easier to see, and it is available on any range. There are three types of echo stretch, 1, 2 and 3, and the higher the number the greater the amount of stretch.

Note: The echo stretch magnifies not only small target pips but also returns (clutter) from sea surface, rain and radar interference. For this reason, make sure these types of interference have been sufficiently reduced before activating the echo stretch.

1. OPERATIONAL OVERVIEW

You can access this feature from the InstantAccess bar able options are: [OFF], [1], [2] or [3].

How to use echo stretch from the InstantAccess bar

To set echo stretch, select the [ES] button ( ) on the InstantAccess bar™, then

™

, or from the menu. The avail-

OFF

left-click to cycle through the settings.

The available settings, in cyclic order, are: [OFF] → [1] → [2] → [3] → [OFF]...

How to use echo stretch from the menu

1. Open the menu.

2. Select [1 ECHO].

3. Select [2 CUSTOMIZED ECHO]. Note: You can also right-click the [PICTURE]

box to access this menu.

4. Select [3 ECHO STRETCH].

5. Select the required setting.

6. Close the menu.

1-35

1. OPERATIONAL OVERVIEW

1.24 Echo Averaging

The echo averaging feature effectively reduces sea clutter. Echoes received from stable targets such as ships appear on the screen at almost the same position every rotation of the antenna. On the other hand, unstable echoes such as sea clutter appear at random positions.

To distinguish real target echoes from sea clutter, echoes are averaged over successive picture frames. If an echo is solid and stable over successive frames, it is presented in its normal intensity. Sea clutter is averaged over successive scans and its brilliance reduced, making it easier to discriminate real targets from sea clutter.

Echo averaging uses a scan-to-scan signal correlation technique based on the true motion over the ground of each target. Thus, small stationary targets such as buoys will be shown while reducing random echoes such as sea clutter. However, true echo averaging is not effective for picking up small targets running at high speeds over the ground.

Note 1: With echo average active it is harder to detect high-speed targets than stationary ones.

Note 2: Do not use the echo averaging function under heavy pitching and rolling; loss of targets can result.

Note 3: Echo averaging requires heading, position and speed data.

Before using the echo averaging function, reduce sea clutter with the A/C SEA control. Leave a little sea clutter on the screen so as not to erase weak targets. The available settings options are shown in the table below.

Setting

(level)

[OFF] Echo averaging is not enabled [1], [2] Detects targets hidden in sea clutter. [2] is more effective than [1] in detecting

targets hidden in strong sea clutter. However, [1] is more effective than [2] in displaying high-speed targets. Select the setting best suited to current conditions. For effective monitoring of high-speed craft, you should use [2] together with the Wiper function.

[3] Stably displays unstable targets; distinguishes high-speed craft.

You can access this feature from the InstantAccess bar

How to adjust the echo average function from the InstantAccess bar

Select the [EAV] button ( ) on the InstantAccess bar™, then left-click to select

EAV

Description

™

, or from the menu.

OFF

the desired level of echo averaging.

1-36

1. OPERATIONAL OVERVIEW

How to use the echo average function from the menu

1. Open the menu.

2. Select [1 ECHO].

3. Select [2 CUSTOMIZED ECHO]. Note: You can also right-click the [PICTURE] box to access this menu.

4. Select [4 ECHO AVERAGE].

5. Select the required setting.

6. Close the menu.

How to highlight fast-moving targets

Normally, when echo averaging is in use, fast-moving targets may be displayed weakly, or not at all. The fast target emphasis function highlights fast-moving targets, but can also highlight sea-surface reflections and other noise.

To use the fast target emphasis function, follow the procedure below.

1. Open the menu.

2. Select [1 ECHO].

3. Select [0 NEXT].

4. Select [6 EAV EMPH-FAST TGT].

5. Select [ON] or [OFF] as appropriate.

6. Close the menu.

1-37

1. OPERATIONAL OVERVIEW

1.25 Automatic Clutter Elimination (ACE) Function

This radar has the Automatic Clutter Elimination (ACE) function. This function detects sea and rain clutter from received echoes’ and automatically reduces sea and rain clutter according to the Automatic Clutter Elimination (ACE) threshold setting.

Note: Use this function with caution. Weak target echoes may disappear from the screen.

1.25.1 How to turn the Automatic Clutter Elimination (ACE) function on/off

You can activate/deactivate the ACE function with one of the two methods outlined below.

From the InstantAccess bar

Place the cursor on the [ACE] button, then left-click to toggle between [ON] and [OFF].

From the menu

1. Open the menu.

2. Select [1 ECHO].

3. Select [2 CUSTOMIZED ECHO].

Note: You can also right-click the [PICTURE]

box to access this menu.

4. Select [0 NEXT].

5. Select [4 ACE].

6. Select [ON] or [OFF] as appropriate.

7. Close the menu.

When [ACE] is activated, the [SEA] box and [RAIN] box are gray colored and cannot be adjusted, and the echo averaging function is disabled. The [GAIN] box changes to [GAIN ACE], as shown in the figure below.

ACE turned off. ACE turned on.

30GAIN

MAN MAN

Note: When [PERFORMANCE MON] (see section 1.49) or [SART] (see section 2.3) is [ON], [ACE] is disabled and cannot be activated.

30SEA

30RAIN

ACE

MAN MAN

30GAIN 30SEA 30RAIN

1.25.2 How to adjust the gain in Automatic Clutter Elimination (ACE) mode

Rotate the GAIN knob to adjust the sensitivity.

ACE can also be adjusted by placing the cursor inside the [GAIN ACE] level indication, then spinning the scrollwheel.

1-38

1.25.3 How to get high sensitivity

When the ACE function is [ON], the high sensitivity mode is also available. This requires a function key to be assigned with the [ACE HIGH SENSITIVITY] function (see section 1.9).

To use high sensitivity mode, activate the ACE feature, then press the assigned function key.

You can select the level for the high sensitivity mode as follows:

1. Open the menu.

2. Select [1 ECHO].

3. Select [0 NEXT].

4. Select [2 ACE]. The [ACE] menu appears.

5. Select [2 SIGNAL ENHANCEMENT].

6. Select the level from [1], [2] or [3].

7. Close the menu.

1. OPERATIONAL OVERVIEW

1.25.4 How to suppress false echoes

When the ACE function is [ON], the echo signals can appear on the screen at positions where there is no target or disappear when there are targets (see section 2.2). You can suppress these false echoes.

Note: This procedure is only available when the Automatic Clutter Elimination (ACE) function is [ON].

1. Open the menu.

2. Select [1 ECHO].

3. Select [0 NEXT].

4. Select [2 ACE].

5. Select [3 SUPPRESS SECTOR].

6. Spin the scrollwheel, or use the number keys, to set the start angle for sector suppression. If you use the number keys, the cursor moves from left to right. When all three digits are input, the cursor moves to the [ANGLE] item. If you use the scrollwheel, left-click when the start angle is set. To cancel any changes, press the CANCEL TRAILS key.

7. Left-click, or press the ENTER MARK key to confirm the start angle. The cursor moves to the [ANGLE] item.

8. Spin the scrollwheel, or use the number keys, set the angle range of the sector to be suppressed. If you use the number keys, the cursor moves from left to right. When all three digits are input, the setting process is complete. If you use the scrollwheel, left-click when the angle range is set. To cancel any changes, press the CANCEL TRAILS key.

9. Close the menu.

1-39

1. OPERATIONAL OVERVIEW

Noise Rejector indication

1.26 Noise Rejector

White noise can show itself on the screen as random “speckles” spread over the entire radar image. This equipment reduces the white noise, then improves the on-screen S/ N ratio by processing the weighted moving average filter for the received echoes in the range direction.

Note: Use this function with caution. Weak target echoes may disappear from the screen or the range resolution may worsen.

To remove this noise do the following:

1. Open the menu.

2. Select [1 ECHO].

3. Select [2 CUSTOMIZED ECHO]. Note: You can also right-click the [PICTURE] box to access this menu.

4. Select [7 NOISE REJECTOR].

5. Select [OFF] or [ON] as appropriate. The indication for noise rejection is located at the top-left of the screen. The indication changes according to the selected setting.

1.27 Wiper

The wiper feature automatically reduces the brilliance of weak signals (noise, sea clutter, rain clutter, etc.) and unwanted signals such as radar interference to clear the picture of unwanted echoes. Its effect depends on the wiper setting used and whether each averaging is turned on or off, as described below.

Echo averaging [OFF] Condition A Condition A Echo averaging on ([1], [2] or [3]) Condition A Condition B

Condition A: The brilliance of unwanted weak echoes, such as noise, sea clutter and rain clutter, is reduced to clear up the picture. Condition B: Echo averaging is automatically activated when the wiper feature is turned on, allowing you to instantly see how the picture is affected with echo averaging turned off and turned on.

Note 1: The [WIPER] function requires valid data input for position, speed and heading. Note 2: The [WIPER] function is unavailable when the high speed rotation mode is ac-

tivated (at installation). For details of the high speed rotation mode, contact your dealer.

To activate the wiper feature, do the following:

1. Open the menu.

Wiper setting 1 Wiper setting 2

1-40

2. Select [1 ECHO].

3. Select [9 WIPER].

4. Select the desired setting. The options are: [OFF], [1] or [2].

5. Close the menu.

1. OPERATIONAL OVERVIEW

1.28 How to Preset Controls for a Specific Navigation Purpose

Every time your navigating environment or task changes, you must adjust the radar, which can be a nuisance in a busy situation. Instead of changing radar settings case by case, it is possible to assign the function keys to provide optimum settings for oftenencountered situations.

The radar's internal computer offers several picture preset options to be assigned to each function key for your specific navigating requirements. For instance, one of the presets is [ROUGH SEA], and is designed to be used in heavy rain.

Three user-programmable presets are also provided (labeled as [CUSTOM1], [CUSTOM2] and [CUSTOM3]), so that you can have the radar automatically set to those conditions which are not covered by the provided setup options.

Below are the preset options provided with this radar.

Preset Description

[CUSTOM1], [CUSTOM2] and [CUSTOM3]

[NEAR] Optimum setting for short range detection using a range

[FAR] Optimum setting for long range detection, on a range

[NEAR BUOY]* Optimum setting for detecting buoys within 3 NM range. [FAR BUOY] Optimum setting for detecting buoys on a range scale of

[ROUGH SEA] Optimum setting for rough weather or heavy rain. [SHIP] Optimum setting for detecting other vessels. [HARBOR] Optimum setting for harbor berthing. [BIRD] Optimum setting for detecting birds. [ICE]* Optimum setting for navigating though sea ice. [COAST] Optimum setting for coastal travel.

User-defined custom settings.

scale of 3 NM or less on calm seas.

scale of 6 NM or larger.

6 NM or larger.

*: [SMALL TARGET] replaces [NEAR BUOY] and [ICE] replaces [BIRD] when Ice Mode is enabled at installation.

Each picture option defines a combination of several radar settings for achieving optimum setup for a particular navigating situation. These include gain, target analyzer, hatching, ACE, ACE gain, interference rejector, echo stretch, echo average, noise rejector, automatic anti-sea and anti-rain clutter, video contrast, pulse length and sea and radar conditions.

Changing these features from the [CUSTOMIZED ECHO] menu changes the original function key settings. To restore the original settings for a particular customize option, it is necessary to select the default setting. For this reason, we recommended that you use the user-programmable presets ([CUSTOM1], [CUSTOM2] or [CUSTOM3]) when frequent adjustment of the radar image is necessary.

The default settings for the custom presets are listed on the following pages.

1-41

1. OPERATIONAL OVERVIEW

Default settings

IR ES EA NR

CUSTOM1 1 1 1 OFF MAN-30 MAN-0 OFF OFF CUSTOM2 1 1 1 OFF AUTO-30 MAN-0 OFF OFF CUSTOM3 1 1 1 OFF MAN-30 MAN-0 OFF OFF NEAR 1 1 1 OFF MAN-30 MAN-0 OFF OFF FAR 1 2 1 OFF AUTO-40 MAN-0 OFF OFF NEAR BOUY 1 1 2 OFF MAN-30 MAN-0 OFF OFF FAR BUOY 1 2 2 OFF AUTO-30 MAN-0 OFF OFF ROUGH SEA 1 OFF 2 OFF MAN-50 MAN-40 OFF OFF SHIP 1 2 1 OFF MAN-30 MAN-0 OFF OFF HARBOR 1 OFF 1 OFF MAN-30 MAN-0 OFF OFF BIRD 1 OFF 1 OFF MAN-30 MAN-0 OFF OFF ICE 2 OFF OFF OFF MAN-30 MAN-0 OFF OFF COAST OFF OFF OFF OFF MAN-30 MAN-0 OFF OFF

STC

CURVE

CUSTOM1 3 8 0 85 OFF 50 2-B CUSTOM2 3 8 0 85 OFF 50 2-C CUSTOM3 3 8 0 85 ON 50 2-B NEAR 3 8 0 85 OFF 50 1-B FAR 3 8 0 85 ON 60 4-B NEAR BOUY 3 8 0 85 OFF 50 1-C FAR BUOY 3 8 0 85 OFF 50 4-C ROUGH SEA 3 9 0 85 OFF 35 2-C SHIP 3 8 0 85 ON 50 2-B HARBOR 3 8 0 75 ON 50 1-C BIRD 3 8 0 85 OFF 50 3-C ICE 3 7 0 80 OFF 50 1-B COAST 3 8 0 85 OFF 50 2-C

STC

RANGE

AUTO

SEA

LOW

LEVEL

ECHOES

AUTO

RAIN

GAIN ACE

TARGET

ANALYZER*

ACE

GAIN

HATCHING*

VIDEO

CONTRAST

1-42

*: Available for B/W-type radars only.

Default settings for [PULSELENGTH]

1. OPERATIONAL OVERVIEW

0.125 NM to 0.5 NM

CUSTOM1 S1 S1 S1 S2 S2 M1 CUSTOM2 S1 S1 S1 S2 S2 M1 CUSTOM3 S1 S1 S1 S2 S2 M1 NEAR S1 S1 S1 S2 S2 M1 FAR S1 S1 S1 S2 S2 M1 NEAR BOUY S1 S1 S1 S2 S2 M1 FAR BUOY S1 S1 S1 S2 S2 M1 ROUGH SEA S1 S1 S1 S2 S2 M1 SHIP S1 S1 S1 S2 S2 M1 HARBOR S1 S1 S1 S2 S2 M1 BIRD S1 S1 S1 S2 S2 M1 ICE S1 S1 S1 S1 S1 S2 COAST S1 S1 S1 S2 S2 M1

4 NM* 6 NM 8 NM* 12 NM 16 NM* 24 NM

CUSTOM1 M1 M2 M2 L L L CUSTOM2 M1 M2 M2 L L L CUSTOM3 M1 M2 M2 L L L NEAR M1 M3 M3 M3 M3 L FAR M1 M3 M3 L L L NEAR BOUY M1 M2 M2 M3 M3 L FAR BUOY M1 M3 M3 L L L ROUGH SEA M1 M2 M2 M3 M3 L SHIP M1 M2 M2 L M3 L HARBOR M1 M2 M2 M3 M3 L BIRD M1 M2 M2 M3 M3 L ICE S2 M1 M1 M1 M1 M2 COAST M1 M2 M2 M3 M3 L

0.75 NM 1 NM* 1.5 NM 2 NM* 3 NM

*: These ranges are available for B/W-type radars only.

About the ICE custom setting (optional specification)

The ICE custom setting sets up the radar to detect areas of ice on the sea surface. With ICE active, the following restrictions or requirements apply:

• For interswitch configurations with a FAR-2xx8 series as the main radar and a FAR2xx7 series as the sub radar, ice echoes may not appear correctly on the FAR-2xx7 series screen. Avoid using a FAR-2xx7 series radar as the interswitch sub-radar with Ice Mode enabled.

• Ice Mode must be enabled from the [RADAR INSTALLATION] menu. See the Installation Manual for details.

• Dual radar mode must be disabled from the [RADAR INSTALLATION] menu. See the Installation Manual for details.

• Ice Mode replaces Bird Mode. While Ice Mode is in use, Bird Mode-related settings and operations are not available.

• Video Contrast settings are fixed to ICE settings when the performance monitor is activated while Ice Mode is enabled.

• While Ice Mode is enabled, the following functions are not available:

• Target Analyzer • Rain Echo Hatching • Video Contrast

• Automatic Clutter Elimination (ACE) • Fast Target Emphasis • Trail Hide

1-43

1. OPERATIONAL OVERVIEW

CONTRAST

LEVEL

CONTRAST

LEVEL

CONTRAST

LEVEL

CONTRAST

LEVEL

B C

[

VIDEO CONTRAST] set to [ADVANCE] at installation:

[

VIDEO CONTRAST] set to [LEGACY] at installation:

CONTRAST

1.28.1 How to select a customized echo

Left-click the [CUSTOMIZE ECHO] box at the top left of the screen to cycle through the options and select a customized echo option.

The available options depend on the settings selected for [3 SELECT CUSTOM] in the [ECHO] menu. See section 1.28.5.

1.28.2 How to edit a customized echo

1. Select a customize echo option to edit (see section 1.28.1).

2. Open the menu.

3. Select [1 ECHO].

4. Select [2 CUSTOMIZED ECHO]. Note: You can also right-click the [PICTURE] box to access this menu.

5. Set the items below referring to the sections shown.

• [2 INT REJECTOR] : section 1.22

• [3 ECHO STRETCH] : section 1.23

• [4 ECHO AVERAGE] : section 1.24

• [5 TARGET ANALYZER]* : section 1.38

• [6 HATCHING]* : section 1.38

• [7 NOISE REJECTOR] : section 1.26

• [8 VIDEO CONTRAST TYPE] : described in this section.

• [9 PULSE] : section 1.18

• [2 CONDITION] : described in this section.

• [4 ACE] : section 1.25

*: Available for B/W-type radars only. Note: To set [2 CONDITION] and [4 ACE], select [0 NEXT] to show the second page of the [CUSTOMIZED ECHO] menu.

6. Select [8 VIDEO CONTRAST TYPE].

7. Select [1], [2], [3] or [4] (Dynamic Range) or [A], [B], [C] (Curve) as appropriate. Video contrast and curve change depending on setting for [VIDEO CONTRAST] (set at installation), as shown in the figure below.

1-44

1. OPERATIONAL OVERVIEW

1 to 4: Control dynamic range. 1 provides the widest dynamic range; 4 is the narrowest dynamic range.

A: Low level echo brilliance is reduced and noise and clutter are also reduced. B: Low and high level echoes are displayed evenly. C: High level echoes' outer edge has gradation to indicate the echo level, with the

higher level echo at the core.

8. Select [0 NEXT] to show the next menu page.

9. Select [2 CONDITION].

10. Select [2 STC CURVE].

11. Select the appropriate setting for the current sea conditions. The available settings are: [2], [2.5], [3], [3.5], [4.2]. A higher setting is recommended for rough weather.

12. Select [3 STC RANGE].

13. Set the distance for STC effectiveness. A higher setting eliminates farther surface reflections.

14. If necessary, select [4 LOW LEVEL ECHO] to reject low level echoes. The setting range is [0] to [8]. The higher the figure, the stronger the low level echo that is erased.

15. Select [1 BACK] to show the second page of the [CUSTOMIZED ECHO] menu.

16. To save custom settings, select [SAVE] from [3 DEFAULT].

17. Close the menu.

1.28.3 How to restore a user customized echo to the saved settings

If you get lost in operation while changing the settings for a user customized echo, you can easily restore the settings for that user customized echo saved at section 1.28.2.

1. Open the menu.

2. Select [1 ECHO].

3. Select [2 CUSTOMIZED ECHO]. Note: You can also right-click the [PICTURE] box to access this menu.

4. Select [0 NEXT] to show the next menu page.

5. Select [3 DEFAULT].

6. Select [USER].

7. Close the menu.

1-45

1. OPERATIONAL OVERVIEW

Page 1

Page 2

1.28.4 How to restore a user customized echo to the factory default settings

You can restore customized echo options to their factory default settings (see the tables on page 1-42 for a list of the default settings).

1. Open the menu.

2. Select [1 ECHO].

3. Select [2 CUSTOMIZED ECHO].

Note: You can also right-click the [PICTURE] box to access this menu.

4. Select [0 NEXT] to show the next menu page.

5. Select [3 DEFAULT].

6. Select [FACTORY].

1.28.5 How to edit the available customized echoes

To edit which customizations are available from the [CUSTOMIZE ECHO] box, follow the procedure below.

1. Open the menu.

2. Select [1 ECHO].

3. Select [0 NEXT].

4. Select [3 SELECT CUSTOM]. The [SELECT CUS-

TOM] menu appears.

5. Select the customization you want to edit.

The customizations are listed over two menu pages. Select [0 NEXT] to see the next page, or select [1 BACK] to return to the previous menu page.

6. Select [ON] to make the customization available from

the [CUSTOMIZE ECHO] box, or select [OFF] to hide the customization from the [CUSTOMIZE ECHO] box.

7. Close the menu.

1-46

1. OPERATIONAL OVERVIEW

1.29 How to Reject Second-trace Echoes

In certain situations, echoes from very distance targets can appear as false echoes (second-trace echoes) on the screen. This occurs when the return echo is received one transmission cycle later, or after a next radar pulse has been transmitted.

Pulse interval

Actual ranges

Second-trace echo

Measured ranges

This equipment lengthens the pulse repetition period to reject false echoes.

Note: his function decreases the number of echo hits. Use this function carefully so that the possibility of detecting small targets and high-speed craft does not lessen.

To enable or disable second-trace echo rejection, do the following:

1. Open the menu.

2. Select [1 ECHO].

3. Select [3 2ND ECHO REJ].

4. Select [ON] to enable second-trace echo rejection. Select [OFF] to disable rejection.

5. Close the menu.

1-47

1. OPERATIONAL OVERVIEW

Heading line

North marker

1.30 Orientation Modes

This radar has the following orientation modes available:

Mode Description

Relative Motion (RM) modes

[HEAD UP RM] Not stabilized [STERN UP RM]* The radar image is rotated 180°. Graphics and relative and

true bearings are also rotated 180°.

[STAB HEAD UP RM] Head-up with compass bearing scale (True Bearing) where

the bearing scale rotates with the compass reading.

[COURSE UP RM] Compass-stabilized relative to ship’s orientation at the time of

selecting COURSE UP.

[NORTH UP RM] Compass-stabilized with reference to North.

True Motion (TM ) modes

[NORTH UP TM] Land objects and sea are stationary. Requires compass and

speed data.

*: [STERN UP RM] is only available for A/B/W-types.

1.30.1 How to select an presentation mode

Select the [ORIENTATION MODE] box at the top left corner of the screen, then left-click to cycle through the available orientation modes.

Loss of gyrocompass signal

When the compass signal is lost, "LOST GYRO SIGNAL" appears in yellow-orange in the [ALERT] box, the orientation mode automatically becomes HEAD UP, and TT and AIS objects, map and chart are erased. Stop the alert with the ALARM ACK key or left-click the [ALERT] box. Check the GYRO data.

1.30.2 Description of presentation modes

HEAD UP mode

A display without azimuth stabilization in which the line that connects the center with the top of the display indicates your heading. Targets are shown at their measured distances and their directions relative to your heading. The short dotted line on the bearing scale is the north marker.

1-48

COURSE UP mode

Heading line

North marker

Heading line

North

1. OPERATIONAL OVERVIEW

The radar picture is stabilized and displayed with the currently selected course at the top of the screen. When you change the heading, the heading line moves with the course selected. If you select a new course, select the course up mode again to display the new course at the top of the display. Targets are shown at their measured distances and their directions relative to the set course, which is at the 0-degree position. The heading line moves according to the yawing and any course change.

NORTH UP mode

Targets are shown at their measured distances and their true (compass) directions from your ship. North is at the top of the screen. The heading line changes its direction according to your heading.

STAB HEAD UP mode

North marker

Heading line

Radar echoes are shown in the same way as in the HEAD UP mode. The difference from normal HEAD UP presentation lies in the orientation of the bearing scale. The bearing scale is heading sensor stabilized. That is, it rotates in accordance with the heading sensor signal, enabling you to know own ship's heading at a glance.

This mode is available when the radar is interfaced with a gyrocompass. If the gyrocompass fails, the bearing scale returns to the state of HEAD UP mode.

True motion mode

Your ship and other objects in motion move with their true courses and speed. All fixed targets, like landmasses, appear as fixed echoes in ground stabilized TM. When your ship reaches a point that is 50% of the radius of the display, the position is reset. The ship appears at 75% radius opposite to the extension of the current course. You can manually reset your ship symbol if you highlight the [CU/TM RESET] indication at the top of the screen, then left-click.

Heading line

North marker

(a) True motion is selected

(b) Your ship has reached a point 50% of display radius

1-49

1. OPERATIONAL OVERVIEW

Heading line

North marker

RANGE box

Note: The position of the own ship marker and bearing scale change according to reference position and off-centering.

• [ANT]: When OFF CENTER is active, the bearing scale intervals change accordingly.

• [CCRP]: When the CCRP moves outside the operational display area, the bearing scale intervals may not be displayed correctly.

STERN UP mode

The STERN UP mode rotates the HEAD UP mode picture, relative and true bearings and display graphics 180°. This mode is useful on dual-radar tugboats when backing up; one radar shows HEAD UP and another shows STERN UP. To enable the STERN UP mode, turn on [STERN UP] on the [OPERATION] menu.

Note: STERN UP mode is only available for A/B/W-types.

1.31 How to Select a Range Scale

The selected range scale and range ring interval are shown at the upper left corner on the screen. When a target of interest comes closer, reduce the range scale so that it appears in 50-90% of the display radius.

1. Place the cursor in the [RANGE] box at the top left corner of the screen.

In the above example, the range scale is set to 0.125 NM and the interval between range rings is set to 0.025 NM.

2. Left-click to lower the range; right-click to raise the range.

You can also select the range with the RANGE key on the control unit. Press "+" to increase the range, or press "-" to reduce the range. Press and hold a key to successively change the range upwards or downwards.

Changing the plotter range (A/B/W-types with Radar Plotter functionality only)

With the radar in standby (STBY) mode, you can change the plotter range by pressing the RANGE key. In this case, “range” means the on-screen displayed distance from the left-hand edge of the screen to the right-hand edge of the screen.

[+]: expands the range scale with the cursor location as the center.

[-]: reduces the range scale with the cursor location as the center.

Press and hold the [+] or [-] key to change the range scale continuously.

1-50

1.32 How to Measure Range

The range to a target can be measured three ways: with the fixed range rings, with the cursor, or with the VRM.

Use the fixed range rings to get an estimate of the range to a target. The rings are the concentric solid circles on the display. The number of rings is automatically set by the current range scale. The distance between the rings is the range ring interval, and the current interval appears at the upper-left position on the screen. To measure the range to a target with the range rings, count the number of rings between the center of the display and the target. Check the range ring interval and estimate the distance of the echo from the inner edge of the nearest ring.

1.32.1 How to show/hide the range rings

Main menu operation

1. Open the menu.

2. Select [3 NAV TOOLS] to show the [NAV TOOLS] menu.

1. OPERATIONAL OVERVIEW

3. Select [4 RANGE RINGS].

4. Select [ON] or [OFF] as appropriate.

5. Close the menu.

Using the [CURSOR] menu (on-screen box)

1. Select the operational display area, then right-click. The [CURSOR] context menu appears.

2. Select [RANGE RINGS].

3. Select [ON] or [OFF] as appropriate.

4. Close the menu.

Scrollwheel operation

With the menu closed, place the cursor inside the operational display area, spin the scrollwheel to show “RANGE RINGS/EXIT” on the guidance box, then press the left

button to show/hide the range rings.

1-51

1. OPERATIONAL OVERVIEW

1.32.2 How to measure range with the variable range marker (VRM)

There are two VRMs, No. 1 and No. 2, which appear as dashed rings so that you can distinguish them from the fixed range rings. The two VRMs can be distinguished from each other by the different lengths of their dashes; the dashes on the No. 2 VRM are longer.

000

010

020

030

Target echo

040

050

VRM1

060

300

310

320

330

340

350

130

120

070

110

080

090

100

VRM2

280

270

260

290

250

240

230

220

210

200

190

180

170

140

150

160

There are two methods for measuring range with the VRMs, using the VRM key and on-screen menu box operation.

Range to VRM

VRM1 VRM2

28.11 36.44

TTG

50:00 60:00

TTG

TTG to VRM

Currently active VRM is highlighted.

Note: The maximum VRM distance is set by the current display range and can be set as high as twice the distance of the display range.

Using the VRM keys

1. Press the VRM ON key to activate the VRM1 box. Press the VRM ON key again to activate the VRM2 box. Press the VRM ON key again to switch between active VRMs. The currently active VRM marker is displayed as shown in the above figure.

2. Rotate the VRM knob to align the active VRM with the inner edge of the target, then read the distance at the lower right of the screen. In the previous figure, the active VRM reads "36.44 NM". Each VRM remains at the same geographical distance when you operate the RANGE key or the [RANGE] box. This means that the apparent radius of the VRM ring changes in proportion to the selected range scale.

3. Press the VRM OFF key to hide the VRMs.

1-52

1. OPERATIONAL OVERVIEW

On-screen menu box operation

1. Select the appropriate [VRM] box.

2. The guidance box reads "VRM ON/". Left-click to turn on the VRM. The guidance box now reads "VRM SET L = DELETE /". Further, the box is highlighted and the corresponding VRM appears.

3. Left-click again and the cursor jumps to inside the operational display area. The guidance box now reads "VRM FIX L = DELETE / EXIT".

4. Move the trackball to adjust the VRM.

5. Left-click to anchor the VRM and fix its readout, or right-click to cancel and return the VRM to its previous location (range).

6. To hide the VRM, left-click the [VRM] box to show "VRM SET L = DELETE /" in the guidance box, then press and hold the left button on the trackball.

1.32.3 How to set the VRM unit of measurement (B-type only)

VRMs can be displayed in the following units of measurement:

• NM (Nautical Miles)

• SM (Statute Miles)

To change the unit of measurement, do the following:

1. Open the menu.

2. Select [3 NAV TOOLS].

3. Select [3 EBL•VRM•CURSOR SET].

4. Select [VRM1] or [VRM2] as appropriate.

5. Select the unit of measurement.

6. Close the menu.

Note: Changes made to the measurement units also affect active VRMs.

• km (Kilometers)

• kyd (Kiloyards)

1.32.4 How to show TTG to VRM

TTG (Time To Go) to a selected VRM can be displayed as follows:

1. Open the menu.

2. Select [3 NAV TOOLS].

3. Select [3 EBL•VRM•CURSOR SET].

4. Select [3 VRM TTG].

5. Select [OFF], [1], [2] or [1&2] as appropriate.

• [OFF]

• [1]

• [2]

• [1and2]

6. Close the menu.

: No TTG to VRM displayed. : TTG from OS to VRM1 displayed. : TTG from OS to VRM2 displayed. : TTG from OS to VRM1 and VRM2 displayed.

1-53

1. OPERATIONAL OVERVIEW

EBRLs

1.33 How to Measure Bearing

The Electronic Bearing Lines (EBLs) are used to take bearings of targets.There are two EBLs, EBL1 and EBL2. Each EBL is a straight dashed line extending out from the own ship position up to the circumference of the radar picture. The two EBLs can be distinguished from each other by the different lengths of their dashes; the dashes on EBL2 are longer.

Each EBL has an EBRL (Electronic Bearing Range Line, indicated as a short line, crossing the EBL at right angles). When VRM is not displayed and only EBL is displayed, the EBRL shows the range from the EBL origin.

When VRMs are displayed with EBLs the VRM overlaps the EBRL. The value for EBRL and VRM is the same and is displayed in the VRM box at the bottom-right of the screen.

000

010

020

290

300

310

320

330

340

350

EBRLs

030

040

050

060

070

Target echo

EBL2

280

270

260

250

240

230

220

EBL1 EBL2

045.3 287.1

°R

210

200

190

°R

170

180

Currently active EBL is highlighted.

1.33.1 Methods to measure bearing

There are two methods for measuring bearing, using the EBL key and on-screen menu box operation.

Using the EBL keys

1. Press the EBL ON key to activate the [EBL1] box. Press the EBL ON key again to activate the EBL2 box. Press the EBL ON key again to toggle active EBLs. The active EBL marker is displayed as shown on the previous page.

160

150

140

130

120

110

080

090

100

EBL1

1-54

2. Rotate the EBL knob clockwise or counterclockwise until the active EBL bisects the target of interest, then read its bearing at the lower-left corner of the screen.

3. Press the EBL OFF key to erase the active EBL.

On-screen menu box operation

1. Select the appropriate EBL box.

2. The guidance box reads "EBL ON/". Press the left button to turn on the EBL.The guidance box now reads "EBL SET L=DELETE /".

3. Press the left button again and the cursor jumps to inside the operational display area. The guidance box now reads "EBL FIX L=DELETE/".

4. Spin the scrollwheel, or use the trackball, to move the EBL until the active EBL bisects the target of interest, then press the left button to anchor the EBL. Read the bearing at the lower-left corner of the screen.

5. Press the EBL OFF key to erase EBLs.

1.33.2 True or relative bearing

The EBL readout is affixed by "R" (relative) if it is relative to own ship's heading, "T" (true) if it is referenced to the north. True or relative indication is available regardless of presentation mode.

1. Open the menu.

1. OPERATIONAL OVERVIEW

2. Select [3 NAV TOOLS].

3. Select [3 EBL•VRM•CURSOR SET].

4. For IMO/A/R-type radars, select [5 EBL•CURSOR BEARING]. For B-type radars, select [2 EBL1] or [3 EBL2] as appropriate.

5. Select the [REL] or [TRUE] as required, then press the ENTER MARK key.

6. Close the menu.

Note: The EBL and its indication change with gyrocompass changes as follows:

Gyro heading EBL changes

HEAD UP / relative EBL indication and EBL marker are unchanged. HEAD UP / true EBL indication does not change, however the EBL marker

moves accordingly

COURSE UP / relative EBL indication does not change, however the EBL marker

moves accordingly. COURSE UP / true EBL indication and EBL marker are unchanged. NORTH UP / relative EBL indication does not change, however the EBL marker

moves accordingly NORTH UP / true EBL indication and EBL marker are unchanged.

1-55

1. OPERATIONAL OVERVIEW

000

010

020

030

040

050

060

070

080

090

100

110

120

130

140

150

160

170

180

190

200

210

220

230

240

250

260

270

280

290

300

310

320

330

340

350

000

010

020

030

040

050

060

070

080

090

100

110

120

130

140

150

160

170

180

190

200

210

220

230

240

250

260

270

280

290

300

310

320

330

340

350

No. 1 EBL

(a) (b)

EBL range marker

1.34 Collision Assessment by Offset EBL

The origin of the EBL can be placed anywhere to enable measurement of range and bearing between any two targets. This function is also useful for assessment of the potential risk of collision. It is possible to read CPA (Closest Point of Approach) by using the EBL range marker as shown in (a) in the illustration below. If the EBL passes through the sweep origin (own ship) as shown in (b) in the illustration below, the target ship is on a collision course.

1.34.1 How to assess risk of collision using the offset EBL

There are two methods for assessing risk collision. You can use the control unit or the [CURSOR] menu.

Using the control unit (RCU-014)

1. Press the EBL ON key to display or activate an EBL (EBL1 or EBL2).

2. Place the cursor on a target appearing as threatening (indicated as “A” in the example figure on the previous page).

3. Press the EBL OFFSET key and the origin of the active EBL shifts to the cursor position.

4. Press the EBL OFFSET key again to anchor the EBL origin.

5. After waiting for a few minutes (at least 3 minutes), operate the EBL knob until the

EBL bisects the target at the new position (A ship's course, which can be true or relative depending on the EBL bearing reference setting.

Note: If relative motion is selected, it is also possible to read CPA by using the range marker as shown in left-hand figure at the top of the next page. If the EBL passes through the sweep origin (own ship) as illustrated in the right-hand figure above, the target ship is on a collision course.

). The EBL readout shows the target

1-56

6. To return the EBL origin to the own ship's position, then press the EBL OFFSET key.

1. OPERATIONAL OVERVIEW

Using the [CURSOR] menu (on-screen box)

1. Select the operational display area, then right-click. The [CURSOR] context menu appears.

2. Select [EBL OFFSET].

3. Select the operational display area, then left-click. The EBL line is attached to the cursor.

4. Place the offset EBL on the target appearing as threatening, then left-click.

5. After waiting for a few minutes (at least 3 minutes), operate the EBL used in step

4 until it bisects the target at the new position (A

). The EBL readout shows the target ship's course, which can be true or relative depending on the EBL bearing reference setting.

6. To return the EBL origin to the own ship's position, repeat steps 1 to 3.

7. Close the menu.

1.34.2 How to set the origin point reference for EBL OFFSET

The origin point of the offset EBL can be ground stabilized (geographically fixed), north stabilized (true) or referenced to own ship’s heading (relative).

1. Open the menu.

2. Select [3 NAV TOOLS].

3. Select [3 EBL•VRM•CURSOR SET].

4. Select [2 EBL OFFSET BASE].

5. Select [STAB GND], [STAB HDG] or [STAB NORTH] as appropriate.

• [STAB GND]:

• [STAB HDG]:

• [STAB NORTH]:

Reference to latitude and longitude. Origin position is always fixed regardless of your ship's movement.

Reference to heading. The relationship between origin position and own position is kept always.

Reference to North. The origin position changes with North position.

6. Close the menu.

1-57

1. OPERATIONAL OVERVIEW

Target 1

Target 2

Target 3

Target 4

1.35 How to Measure Range and Bearing Between Two Targets

030

150

040

140

EBL2

050

060

120

130

Range Marker

070

080

090

100

110

EBL1

Range Marker

310

300

290

280

270

260

EBL origin

250

240

230

330

320

Target 1

220

210

350

340

Target 2

200

190

000

010

Target 4

170

180

020

Target 3

160

Range/bearing between targets 1 and 2

EBL1 EBL2

045.3 287.1

°R

VRM1 VRM2

28.11 36.44

TTG

50:00 60:00

TTG

Range/bearing between targets 3 and 4

How to measure range and bearing from the [CURSOR] menu

This procedure uses EBL1 and VRM1 as an example and is written on the premise that neither of the EBLs or VRMs is active.

1. Place the cursor on the EBL1 box, then left-click. EBL1 is now active.

2. Place the cursor inside the operational display area, then right-click to show the

[CURSOR] context menu.

3. Select [EBL OFFSET]. The cursor is displayed with a red surround, indicating that

the [EBL OFFSET] mode is now active.

4. With the cursor in the operational display area, left-click. EBL1 moves to the cur-

sor location.

5. Place the offset EBL on the target of interest (Target 1), then left-click.

6. Right-click to deactivate the [EBL OFFSET] mode. The red surround on the cursor

disappears.

7. Place the cursor on the [EBL1] box, then spin the scrollwheel until EBL1 intersects

the secondary target (Target 2 in the example figure).

8. Place the cursor on the [VRM1] box, then spin the scrollwheel until the range

marker on EBL1 aligns with Target 2. The readouts for EBL1 and VRM1, at the bottom of the screen, indicate the bearing and range between the Target 1 and Target 2.

1-58

9. You can repeat the same procedure on third and fourth targets (shown as “Target

3” and “Target 4” in the above example) by using EBL2 and VRM2.

Bearing is shown relative to own ship with suffix "R" or as a true bearing with suffix "T" depending on EBL relative/true settings in the [EBL•VRM•CURSOR SET] menu.

1. OPERATIONAL OVERVIEW

000

010

020

030

040

050

060

070

080

090

100

110

120

130

140

150

160

170

180

190

200

210

220

230

240

250

260

270

280

290

300

310

320

330

340

350

Target 2Target 2

EBL1EBL1

EBL originEBL origin

Linked VRM1Linked VRM1

Target 1Target 1

How to measure range and bearing from the control unit (RCU-014)

Range and bearing can be measure using the EBL OFFSET key.

1. Press the EBL ON key to activate EBL1.

2. Place the cursor inside the operational display area, then press the EBL OFFSET key. EBL1 moves to the cursor.

3. Place the cursor (EBL1 moves with the cursor) on a target of interest. (Shown as “Target 1” in the above example), then press the EBL OFFSET key.

4. Rotate the EBL knob to move the EBL until it passes through another target of interest. (Shown as “Target 2” in the above example).

5. Place the cursor on the [VRM1] box.

6. Rotate the VRM knob until the range marker on the EBL is on the inside edge of Target 2. The readouts for EBL1 and VRM1, at the bottom of the screen, indicate the bearing and range between the Target 1 and Target 2.

7. You can repeat the same procedure on third and fourth targets (shown as “Target 3” and “Target 4” in the above example) by using the No. 2 EBL and the No. 2 VRM.

Bearing is shown relative to own ship with suffix "R" or as a true bearing with suffix "T" depending on EBL relative/true settings in the [EBL•VRM] menu.

How to reset the EBL origin to the center of the screen

1. Place the cursor on the box for the EBL to reset, then left-click. The selected EBL is now active and highlighted.

2. Place the cursor inside the operational display area, then right-click. The [CURSOR] context menu appears.

3. Select [EBL OFFSET]. The cursor is now displayed with a red surround.

4. Left-click to return the EBL to the center of the display.

5. Right-click to deactivate the [EBL OFFSET] mode. The red surround on the cursor disappears.

How to link EBL and VRM OFFSET

You can link the EBL and VRM offset to show the VRM range ring with one target as the center-point. This may helpful if the range marker on the EBL is difficult to see.

1. Open the menu.

2. Select [3 NAV TOOLS].

3. Select [3 EBL•VRM•CURSOR].

4. Select [8 VRM OFFSET].

5. Select [LINK EBL] to link the offset EBL is now displayed with the VRM range ring, as indicated in the figure below. Select [OFF] to deactivate the link between the offset EBL and the VRM.

6. Close the menu.

1-59

1. OPERATIONAL OVERVIEW

1.36 How to Off-Center the Display

Own ship position, or sweep origin, can be displaced to expand the view field without switching to a larger range scale. The sweep origin can be off-centered to the cursor position, but not more than 75% of the range in use; if the cursor is set beyond 75% of the range scale, the sweep origin will be off-centered to the point of 75% of the limit.

Cursor

and do appropriate off-center procedure.

Cursor

Off-centered displayPut cursor where desired

This feature is not available on the 96 nm range or in the true motion mode.

If the conning position is outside the effective radar display, some parts of the bearing scale are not shown. For details, see section 1.50.

How to off-center the display from the control unit (RCU-014)

1. Place the cursor at the position where you wish to move the sweep origin.

2. Press the OFF CENTER key. The sweep origin is now off-centered at the cursor position.

3. To cancel off-centering, press the OFF CENTER key again.

How to off-center the display from the on-screen menu

1. Place the cursor inside the operational display area, then right-click to show the [CURSOR] menu.

2. Select [OFF CENTER]. The cursor is now displayed with a red surround, indicating that [OFF CENTER] mode is active.

1-60

3. Move the cursor to the position where you wish to move the sweep origin, then left click. The display is now centered at the cursor position.

Note: If you need to move off-center position, you can reset the off-center while the cursor is displayed with the red surround by left-clicking the operational display area.

4. Right-click to cancel [OFF CENTER] mode.

5. To reset the sweep origin to the center of the operational display area, repeat steps 1 to 2, then left-click the operational display area.

Note: When the conditions shown below are met, off-center cannot be canceled. This is because the radar antenna position is located at a position greater than 75% of the effective radar display.

• Own ship marker is large.

• The distance between antenna position and conning position is large.

• Short-distance display range. To cancel the off-center in these cases, select a larger range, then cancel the off-center.

1.37 Target Trails

[

TRAIL] box

Trail time

Trail mode indication

Right-click the

[

TRAIL box] to show

the [TRAILS] menu.

The trails of the radar echoes of targets can be displayed in the form of synthetic afterglow. Target trails are shown either relative or true and can be sea or ground stabilized. True motion trails require a compass signal, and position and speed data. When the range is changed, trails are continued for targets which were already displayed in the previous range. Newly detected targets have no trail when first detected.

1.37.1 True or relative trails

You can display echo trails in true or relative motion. Relative trails show relative movements between targets and own ship. True motion trails present true target movements in accordance with their over-the-ground speeds and courses.

1. OPERATIONAL OVERVIEW

True target trails - Stationary

targets are not smeared.

Relative target trails - Targets move relative

to own ship, stationary targets are smeared.

Note: The indication in the [TRAIL MODE] box changes color based on the trail mode and orientation, as shown in the following table.

Trail mode Orientation Color

True trails (TRUE-G or TRUE-S)

HEAD UP (relative) Yellow STERN UP (relative) CURSOR GYRO (relative) White COURSE UP (relative) NORTH UP (relative)

The reference for the past position displays for AIS and TT is also switched whenever the trail reference is switched.

1. Open the menu.

2. Select [1 ECHO].

3. Select [0 NEXT].

4. Select [4 TRAILS]. The [TRAILS] menu appears.

Note: You can also right-click the [TRAIL] box to access this menu.

1-61

1. OPERATIONAL OVERVIEW

00:00

Trail time

Trail mode and stabilization. Displayed as: “TRUE-S”, “TRUE-G” or “REL”. S: Sea stablized, G: Ground stabilized, REL: Relative

Trail time setting

5. Select [2 TRAIL MODE].

6. Select the appropriate trail mode.

• [REL]: Relative target trails. Targets move relative to own ship and stationary

targets appear smeared.

• [TRUE]: True target trails. Targets true movements are shown, stationary tar-

gets are not smeared.

7. Close the menu.

You can also click the trail mode indication to toggle between relative and true trails.

1.37.2 Trail time

Trail time is the interval at which the trail is plotted on-screen. You can change the trail time as follows:

Using the control unit (RCU-014)

Press the CANCEL TRAILS key to cycle through and select the desired setting.

The options, in cyclic order, are: [OFF] → [15 sec] → [30 sec] → [1 min] → [3 min] → [6min] → [15 min] → [30 min] → [CONT] → [OFF]...

For B/W-types, the available options depend on the setting for [TRAIL LENGTH] in the [TRAILS] section of the [ECHO] menu.

[TRAIL LENGTH]

setting

[NORMAL] [OFF], [15 sec], [30 sec], [1 min], [3 min], [6 min], [15 min], [30

min], [CONT]. [12H] [OFF], [30 min], [1 hr], [3 hr], [6 hr], [12 hr], [CONT]. [24H] [OFF], [1 hr], [2 hr], [3 hr], [6 hr], [12 hr], [18 hr], [24 h], [CONT]. [48H] [OFF], [2 hr], [4 hr], [8 hr], [16 hr], [24 hr], [36 hr], [48 h], [CONT].

Available options

Using the on-screen box

1. Place the cursor on the trail time setting inside the [TRAIL] box, at the bottom-right of the screen.

2. Left-click the [TRAIL] box to change the trail time. The options, in cyclic order, are: [OFF] → [15 sec] → [30 sec] → [1 min] → [3 min] → [6min] → [15 min] → [30 min] → [CONT] → [OFF]...

For B/W-types, the available options depend on the setting for [TRAIL LENGTH] in the [TRAILS] section of the [ECHO] menu.

1-62

Spin the scrollwheel to change the trail time. The options for each [TRAIL LENGTH] setting are listed the following table.

1. OPERATIONAL OVERVIEW

[TRAIL LENGTH]

setting

[NORMAL] [OFF], [15 sec], [30 sec], [1 min] to [30 min] at 30-seconds inter-

[12H] [OFF], [00:30] to [12:00] at 30 minute intervals, [CONT]. [24H] [OFF], [00:30] to [24:00] at one hour intervals, [CONT]. [48H] [OFF], [00:30] to [48:00] at two hour intervals, [CONT].

Note 1: The timer displays the elapsed time of the selected trail. Use caution when using this feature, as the displayed time is not the overall trail time. Also, when the trail timer is displayed, the trail accuracy of other ship’s echoes may be lowered. When the trail time reaches the preset interval, the timer disappears.

Note 2: The [CONT] option sets the trail time plotting as continuous. When the plotting time reaches 29:59, the timer is hidden. The timer reappears when [TRAIL ALL CLEAR] is selected, or when the range is changed.

1.37.3 Trail gradation

The trail afterglow can be displayed in a single tone or with gradual shading.

(Monotone shading)

vals, [CONT].

Single

Available options

Multiple

(Gradual shading)

1. Open the menu.

2. Select [1 ECHO].

3. Select [0 NEXT].

4. Select [4 TRAILS]. The [TRAILS] menu appears. Note: You can also right-click the [TRAIL] box to access this menu.

5. Select [3 TRAIL GRADATION].

6. Select [SINGLE] or [MULTI] (Multiple) as appropriate.

7. Close the menu.

1.37.4 Trail level

The level, or intensity, of the afterglow that extends from radar targets can be selected as below.

1. Open the menu.

2. Select [1 ECHO].

3. Select [0 NEXT].

4. Select [4 TRAILS]. The [TRAILS] menu appears. Note: You can also right-click the [TRAIL] box to access this menu.

5. Select [5 TRAIL LEVEL].

6. Select the appropriate setting. The higher the number, the greater the intensity of the afterglow.

7. Close the menu.

1-63

1. OPERATIONAL OVERVIEW

1.37.5 Narrow trails (B/W-type only)

Target trails can be painted with thinner lines if desired. This csection 1.37.2an be useful when there are a lot of targets on the screen and it is hard to distinguish one from another.

1. Open the menu.

2. Select [1 ECHO].

3. Select [0 NEXT].

4. Select [4 TRAILS]. The [TRAILS] menu appears. Note: You can also right-click the [TRAIL] box to access this menu.

5. Select [8 NARROW TRAIL].

6. Select the appropriate setting from [OFF], [1] or [2], then press the ENTER MARK

key. A trail with a setting of [2] is thinner than a trail with a setting of [1].

7. Close the menu.

1.37.6 How to hide the trails temporarily

Following the procedure outlined in section 1.37.2, set the trail time to [OFF]. The trails are hidden from view, but are continued. To show the trails again, repeat the procedure, setting the trail time to any interval other than [OFF].

1.37.7 Trail stabilization in true motion

True motion trails can be ground stabilized or sea stabilized. The [TRAIL] box shows current stabilization as "TRUE-G" or "TRUE-S". You can change the stabilization mode with the following procedure.

Note: The stabilization mode is applied to own ship speed and TT trails.

Using the on-screen box

Click the stabilization mode button to toggle the mode (BT (ground stabilization) or WT (see stabilization)).

Using the menu

1. Open the menu.

2. Select [7 INFORMATION BOX].

3. Select [2 OWN SHIP INFO].

Stabilization mode button

1-64

4. Select [3 SPEED]. The [SPEED] menu appears. Note: You can also right-click the [SPD ] indication to access this menu.

5. Select [2 SHIP SPEED].

6. Select [LOG(BT)] (ground stabilization) or [LOG(WT)] (sea stabilization) as required.

7. Close the menu.

1.37.8 How to erase/restart trails

All trails can be erased (including those in the memory) and restarted to start fresh trails. There are three methods you can use to erase trails.

To erase all trails displayed in the operational display area:

• Select the [TRAIL] box, then press and hold the left button on the trackball; or

• Press and hold CANCEL TRAILS key.

To erase a section of a trail (B/W-types only):

1. Place the cursor inside the operational display area, then right-click to show the [CURSOR] menu.

2. Select [TRAIL ERASER]. The cursor is now displayed with a red surround and a dashed circle, indicating that [TRAIL ERASER] mode is active.

3. Press the left button to change the diameter of the dashed circle, as shown in the figure below.

1. OPERATIONAL OVERVIEW

4. Place the cursor on the trail whose section you want to erase, then press and hold the left button.

5. With the left button pressed, drag the cursor over the section of the trail you want to erase. The section of trail “covered” by the dashed circle is erased.

6. Release the left button.

7. Right-click to deactivate the [TRAIL ERASER] function. The cursor is no longer highlighted and the dashed circle disappears.

1.37.9 How to prevent sea clutter in true trails

You can prevent the display of sea clutter in true trails about your ship to clear the radar picture. Your ship's trails can also be shown or hidden.

1. Open the menu.

2. Select [1 ECHO].

3. Select [0 NEXT].

4. Select [4 TRAILS]. The [TRAILS] menu appears. Note: You can also right-click the [TRAIL] box to access this menu.

5. Select [7 SUPPRESS AROUND OS].

6. Select [OFF] or [ON] as appropriate. Note: When [6 OS TRAIL] is set to [ON], [7 SUPPRESS TRAILS] is automatically

fixed at [ON]. To disable the sea clutter suppression feature, change [6 OS TRAIL] to [OFF], then change the setting for [7 SUPPRESS TRAILS].

7. Close the menu.

1-65

1. OPERATIONAL OVERVIEW

1.37.10 How to show/hide OS trails

To show or hide the OS trail at any time, follow the procedure below.

1. Open the menu.

2. Select [1 ECHO].

3. Select [0 NEXT].

4. Select [4 TRAILS]. The [TRAILS] menu appears. Note: You can also right-click the [TRAIL] box to access this menu.

5. Select [6 OS TRAIL].S

6. Select [OFF] or [ON] as appropriate.

Note: When [6 OS TRAIL] is set to [ON], [7 SUPPRESS AROUND OS] is automatically fixed at [ON]. To disable the sea clutter suppression feature, change [6 OS TRAIL] to [OFF], then change the setting for [7 SUPPRESS AROUND OS].

7. Close the menu.

1.37.11 How to show/hide land trails (B/W-type only)

You can improve the on-screen display visibility by hiding trails generated by landmasses and non-moving objects. Hiding the trails has the following possible benefits:

• Land-masses have no trail, allowing you to use relative trails near coastlines.

• Only moving echoes create a trail, improving target identification.

1. Open the menu.

2. Select [1 ECHO].

3. Select [0 NEXT].

4. Select [4 TRAILS]. The [TRAILS] menu appears.

Note: You can also right-click the [TRAIL] box to access this menu.

5. Select [0 NEXT].

6. Select [2 HIDE LAND TRAILS(T)] or [3 HIDE LAND TRAILS(R)] as appropriate.

7. Referring to the table below, select the appropriate setting.

Setting

[OFF] Trails are shown Trails are shown Trails are shown [1] Trails are hidden Trails are shown Trails are shown [2] Trails are hidden Trails are hidden Trails are shown

Trails for non-moving objects

Large objects Small objects

Trails for moving objects

1-66

8. Close the menu.

Note: When option [1] or [2] is selected trails for echoes outside the displayed area are not generated. It is important to note that, where the displayed area is moved by functions such as off-centering or true motion, newly displayed echoes do not have trails.

1. OPERATIONAL OVERVIEW

1.37.12 How to set the trail length (B/W-type only)

You can save up to 48 hours of trails. the [TRAIL LENGTH] can be set to one of the following lengths: [NORMAL], [12H], [24H] or [48H]. To set the trail length, follow the procedure below.

1. Open the menu.

2. Select [1 ECHO].

3. Select [0 NEXT].

4. Select [4 TRAILS]. The [TRAILS] menu appears. Note: You can also right-click the [TRAIL] box to access this menu.

5. Select [0 NEXT] to show the second page of the menu.

6. Select [4 TRAIL LENGTH].

7. Select the desired length.

[NORMAL]: Trails are displayed in a single, continuous line with a single color. [12H], [24H] or [48H]: Trails appear in segments. The interval for each segment

change depends on your selection, as shown below.

• 12H: One hour intervals.

• 24H: Two hour intervals.

• 48H: Four hour intervals.

Note: When a length other than [NORMAL] is selected, set [3 TRAIL GRADATION] to [SINGLE]. If you select [MULTI], the interval between each colored segment may be difficult to see clearly.

8. Close the menu.

1.37.13 How to set the trail color (B/W-type only)

The setting for trail coloration depends on the setting for [3 TRAIL GRADATION] and [4 TRAIL LENGTH], as shown in the following table.

Length Gradation Setting location

NORMAL SINGLE [MAIN] → [2 ECHO] → [0 NEXT] → [4 TRAILS] →

MULTI

[12H], [24H], [48H] MULTI

SINGLE [MAIN] → [2 ECHO] → [0 NEXT] → [4 TRAILS] →

When [TRAIL LENGTH] is set to [NORMAL]

You can assign one of six colors when [4 TRAIL LENGTH] is set to [NORMAL].

1. Open the menu.

[4 TRAIL COLOR]

[0 NEXT] → [6 LONG TRAIL COLOR]

2. Select [1 ECHO].

3. Select [0 NEXT].

4. Select [4 TRAILS]. The [TRAILS] menu appears. Note: You can also right-click the [TRAIL] box to access this menu.

5. Select [4 TRAIL COLOR].

6. Select the required color. The available colors are: [GRN] (green), [BLU] (blue), [CYA] (cyan), [MAG] (magenta), [WHT] (white) and [YEL] (yellow).

7. Close the menu.

1-67

1. OPERATIONAL OVERVIEW

When [TRAIL LENGTH] is set to other than [NORMAL]

When [4 TRAIL LENGTH] is set to [12H], [24H] or [48H], you can select the color for each trail segment.

1. Open the menu.

2. Select [1 ECHO].

3. Select [0 NEXT].

4. Select [4 TRAILS]. The [TRAILS] menu appears. Note: You can also right-click the [TRAIL] box to access this menu.

5. Select [0 NEXT] to show the second page of the menu.

6. Select [6 LONG TRAIL COLOR]. The [LONG TRAIL COLOR MENU] appears (see figure to the right).

7. Select [3 LONG TRAIL COLORS].

8. Set the colors as desired. Left-click to move the cursor through the colors, spin the scrollwheel to change the highlighted color. The menu shows 12 colors, numbered accordingly from [1] to [12]. The first segment of the trails is assigned the color for number [1].

9. Close the menu.

1.37.14 How to remove the colors from a section of a multicolor trail (B/W-type only)

You can remove the color(s) from a section of a multicolor trail, leaving the selected section as a gray trail. To remove the color(s), follow the procedure below.

Note: This function is only available when [4 TRAIL LENGTH] is set to other than [NORMAL].

1. Open the menu.

2. Select [1 ECHO].

3. Select [0 NEXT].

4. Select [4 TRAILS]. The [TRAILS] menu appears.

Note: You can also right-click the [TRAIL] box to access this menu.

5. Select [0 NEXT] to show the second page of the menu.

6. Select [5 TRAIL GRAY-OUT TIME].

7. Select the start and end times for the period you want to gray-out.

8. Close the menu.

1-68

To disable the color removal, set the start and end to [00:00] at step 7 of the above procedure.

1. OPERATIONAL OVERVIEW

Target echo

Fuschia coloration starts here

Fuschia Maroon Red Magenta Yellow

Maroon Red Magenta Yellow Lime

Echo trail

Trail coloration before offset is applied

Trail coloration after offset is applied

1.37.15 How to offset the colors for multicolored trail (B/W-type only)

You can “shift” the order of the trail colors. When this function is active, the first color used to paint the trail is changed.

Note: If the trail time set at the [TRAIL] box is longer than the time selected at [4 TRAIL LENGTH] in the [TRAIL] menu, trails are not displayed after the trail time elapses. For example, based on the above figure, if the trail time is set to [05:00] at the [TRAIL] box and [4 TRIAL LENGTH] is set to [12H], the trail coloration will stop after Yellow.

To offset the colors, follow the procedure below.

1. Open the menu.

2. Select [1 ECHO].

3. Select [0 NEXT].

4. Select [4 TRAILS]. The [TRAILS] menu appears. Note: You can also right-click the [TRAIL] box to access this menu.

5. Select [0 NEXT] to show the second page of the menu.

6. Select [6 LONG TRAIL COLOR].

7. Select [2 OFFSET TRAIL COLOR].

8. To offset the color by one, select [ON]. For example, if you selected [FUSCHIA] as the starting color for multicolor trails, the first color after the offset becomes [MAROON]. To leave the colors in their original order, select [OFF].

9. Close the menu.

1-69

1. OPERATIONAL OVERVIEW

No echo adjustment (Target analyzer off, EAV off, hatching off) Rain, moving targets and surface reflections are all displayed with no filtering.

Minimal echo adjustment (Target analyzer on, EAV off, hatching off) Echoes are colored, surface reflections are filtered, rain is displayed.

Maximum echo adjustment (Target analyzer on, EAV on, hatching on) Echoes are colored, surface reflections are filtered, rain is displayed in gray colored hatching.

Moderate echo adjustment (Target analyzer on, EAV on, hatching off) Echoes are colored, surface reflections and rain are filtered.

1.38 Target Analyzer (B/W-type only)

The target analyzer function analyzes echoes and assists the operator to determine dangerous targets. This function is particularly useful under heavy rain/snow or where there is surface reflection, which can cause interference and noise.

The target analyzer function can also place hatching over heavy rain areas, reducing the visible interference and allowing a clearer view of potential targets.

Echoes are displayed in five different colors to assist the operator in identifying targets. The colors and their respective echoes change depending on the echo color selected from the [BRILL] menu (see section 1.45) are shown in the table below.

Echo

YEL GRN WHT AMB M-GRN M-CYA

Selected echo color

Surface reflection Green Green Green Green Green Green Rain Gray Gray Gray Gray Gray Gray Moving target Red Red Red Red Pink Pink Approaching target Pink Pink Pink Pink White White Other echoes Yellow Green White Amber Red to green Red to blue

The following example figures show the manner in which this function affects displayed echoes.

1-70

1. OPERATIONAL OVERVIEW

Target Analyzer indication

Note 1: This function works best when the settings for [GAIN], [STC], [RAIN], [NOISE REJECT] and [VIDEO CONTRAST] are properly adjusted (surface reflections are displayed in green and rain is displayed in gray).

Note 2: This function recognizes moving targets as approaching targets. Buoys and other stationary objects are not recognized as approaching targets by this function.

Note 3: The target analyzer function requires a short period of time to analyze echoes and display them on-screen. If your antenna revolves at more than 40 rpm, moving targets may not be displayed correctly. For this reason, caution is advised when using the target analyzer function.

Note 4: The target analyzer function’s performance may be affected by factors such as target size, weather and sea conditions, physical equipment configuration, offset settings and other factors.

Note 5: When the high speed function mode is activated (at installation), this function is automatically deactivated at a range of 2 NM or less. For details of the high speed rotation mode, contact your dealer.

What is “hatching”?

Where echo averaging may hide light rain on the display, the hatching feature, when activated, places a gray “veil” over the areas where rain is detected. This allows the operator to see where the rain is without affecting the quality of the displayed echoes.

1.38.1 How to activate/deactivate the target analyzer

1. Open the menu.

2. Select [1 ECHO].

3. Select [2 CUSTOMIZED ECHO]. Note: You can also right-click the [PICTURE] box to access this menu.

4. Select [5 TARGET ANALYZER].

5.Select [OFF] to deactivate the function, or [ON] to activate the function.

6.Select [6 RAIN ECHO HATCHING].

7.Select [OFF] to deactivate the function, or

[ON] to activate the function.

8. Close the menu.

1-71

1. OPERATIONAL OVERVIEW

CAUTIONCAUTION

The alarm should not be relied upon as the sole means for detecting possible collision situations.

A/C SEA, A/C RAIN and GAIN controls should be properly adjusted to be sure the alarm system does not overlook target echoes.

Click the Alarm Zone you want to set.

The indication changes to “SET”.

TGT ALR

TT / AIS 1: 2:

TGT ALR

TT / AIS 1:SET 2:

1.39 Target Alarm

The target alarm serves to alert the navigator to targets (ships, landmasses, etc.) entering a specific area, with audiovisual alerts.

The operator can set the alarm zones at any location, with any size, however, the zones must be inside the operational display area.

Note: The target alarm boxes are not displayed when the setting for [AZ/ALR SELECT] in the [TT•AIS] menu is set to the default setting [AQUISITION ZONE]. To enable this function, set [AZ/ ALR SELECT] in the [TT•AIS] menu to [TARGET ALARM ZONE].

1.39.1 How to set a target alarm

The procedure below shows how to set a target alarm using the figure below as an example. The alarm boxes are labeled [1:] and [2:], and are located at the bottom-right of the screen, near the VRM boxes.

1. Select the appropriate alarm box, then left-click. The cursor jumps into the operational display area and the indication "SET" appears inside the target alarm box selected.

2. Using the trackball, move the cursor to Point A, then left-click.

3. Using the trackball, move the cursor to Point B, then left-click. The indication “SET” is replaced with “WORK” in the box. The target alarm zone’s lines are shown as dashed lines.

000

010

350

340

330

320

310

300

290

280

270

260

250

240

230

220

210

200

020

030

040

050

Target

060

alarm

160

190

170

180

070

080

zone

090

100

110

120

130

140

150

Other alarm zone examples

Point B

Point A

Point B

Point A

Note 1: To create a 360° alarm zone, set Point B at the same location as Point A.

Note 2: Two alarm zones can be set simultaneously. The second alarm zone is only

available when the first alarm zone is active, however.

Note 3: When the target alarm zone is not within the range in use the indication "UP RNG" appears to the right of the target alarm box. In this case select a range that will

1-72

display the target alarm zone.

1.39.2 How to mute the target alarm

A target in the target alarm zone produces both visual (flashing) and audible (beep) alarms. To silence the audio alarm select the appropriate target alarm box then leftclick. The target alarm box indication shows "MUTE". This will deactivate the audio alarm but will not stop the flashing of the offending target. You can also stop the alarm by deactivating the target alarm zone (see section 1.39.3).

To reactivate the audio alarm, select the target alarm box then left-click to show "WORK" in the box.

1.39.3 How to deactivate a target alarm

Select the target box to be deactivated, then press and hold the left button on the Control Unit.

Note: When both alarm zones are active, the second ([2:]) alarm zone must be deactivated before the first ([1:]) can be deactivated. If both zones are active when you try to deactivate zone [1:], the system releases two audible beeps and shows the message "DELETE ALR2 FIRST".

1. OPERATIONAL OVERVIEW

1.39.4 How to change target alarm attributes

You can select the echo strength level that triggers the alarm, the condition that generates the alarm and the volume of the audio alarm as follows:

1. Open the menu.

2. Select [4 ALERTS].

3. Select [6 TARGET ALARM].

4. Select [2 ALR1 MODE] or [3 ALR2 MODE] as appropriate.

5. Select [IN] or [OUT] as appropriate. [IN]: Targets entering the alarm zone trigger the alarm. [OUT]: Targets leaving the alarm zone trigger the alarm.

6. Select [4 LEVEL].

7. Select the appropriate level of echo strength to trigger the alarm. [1]: weak echoes can trigger the alarm, [4]: only strong echoes trigger the alarm.

8. Select [1 BACK] to return to the [ALERT] menu.

9. Select [3 ALERT VOLUME].

10. Select [OFF], [LOW], [MID] or [HIGH] as appropriate.

Note 1: This setting is applied to all alarms output from this radar system.

Note 2: The [OFF] options is not shown for IMO/R-type radars.

11. Close the menu.

1-73

1. OPERATIONAL OVERVIEW

PI lines

PI line number

PI line interval

PI line status

PI line bearing and reference

1.40 PI (Parallel Index) Lines

PI lines are useful for keeping a constant distance between own ship and a coastline or a partner ship when navigating.

You can control the presentation and interval of the PI lines from the [PI Line] box, which is at the lower-left corner of the screen.

[PI Line] box

1.40.1 How to show/hide the PI lines

You can show or hide the PI lines as required with the following procedure.

1. Place the cursor on the PI line number or PI line status in the PI line box.

2. Spin the scrollwheel to select the PI line (PI1 to PI6) you want to show or hide. Note 1: For IMO/A/B/R-types, PI5 and PI6 are only available when [SET MAXI-

MUM PI LINES] is set to [1].

Note 2: For W-types, PI5 and PI6 are not available.

3. Left-click to toggle between [ON] (PI line is shown) or [OFF] (PI line is hidden).

1.40.2 How to set the maximum number of lines to display

The maximum number of PI lines available to display depends on your radar type. Further, the actual number of lines visible can be less depending on line interval.

IMO/A/B/R-types

1. Open the menu.

2. Select [3 NAV TOOLS].

3. Select [2 PI LINES]. The [PI LINES] menu appears.

4. Select [3 SET MAXIMUM PI LINES]. Up to six sets of PI lines are available depending on the maximum number of PI lines selected on the menu.

• [1]: Six sets of PI lines (PI1 to PI6) are avail-

able.

• [2], [3] or [6]: Four sets of PI lines (PI1 to PI4).

5. Select the appropriate option.

6. Close the menu.

1-74

Furuno FAR-2018-MARK-2 Operator's Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

IMPORTANT NOTICES

SAFETY INSTRUCTIONS

TABLE OF CONTENTS

FOREWORD

SYSTEM CONFIGURATION

1. OPERATIONAL OVERVIEW

1.1 Controls Overview

1.1.1 Control Unit RCU-014

1.1.2 Control Unit RCU-015/RCU-016

1.2 How to Turn the Radar On/Off

1.3 How to Adjust the Brilliance

1.4 Display Indications

1.4.2 Radar display and shortcuts

1.4.3 Information and settings

1.5 Menu Operations

1.5.1 How to open and close the main menu

1.5.2 How to operate the menus

1.6 How to Use the On-screen Box Menus

1.7 How to Use the CURSOR Menu

1.8 Cursor Data
