FUNAI MWC13D5df User Manual

OWNER’S
MANUAL

COLOR TV/DVD

MWC13D5

(13 inch)

INSTRUCCIONES EN ESPAÑOL INCLUIDAS.

If you need additional operating assistance after reading this owner’s
manual or to order replacement accessories, please call

TOLL FREE : 1-800-605-8610.
Or visit our WEB SITE at http://www.funai-corp.com

Please read before using this equipment

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE

TO RAIN OR MOISTURE.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC

SHOCK, DO NOT REMOVE COVER (OR BACK). NO
USER SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.

The caution marking is located on the rear of the cabinet.

IMPORTANT SAFEGUARDS

1.Read instructions-All the safety and operating instructions

should be read before the appliance is operated.

2.Retain Instructions-The safety and operating instructions

should be retained for future reference.

3.Heed Warnings-All warnings on the appliance and in the

operating instructions should be adhered to.

4.Follow Instructions-All operating and use instructions

should be followed.

5.Cleaning-Unplug the unit from the wall outlet before clean-

ing. Do not use liquid cleaners or aerosol cleaners. Use a
damp cloth for cleaning.
EXCEPTION: A product that is meant for uninterrupted
service and, that for some specific reason, such as the possi­bility of the loss of an authorization code for a CATV con­verter, is not intended to be unplugged by the user for clean­ing or any other purpose, may exclude the reference to
unplugging the appliance in the cleaning description other­wise required in item 5.

6.Attachments-Do not use attachments not recommended by

the unit manufacturer as they may cause hazards.

7.Water and Moisture-Do not use this unit near water-for

example, near a bath tub, wash bowl, kitchen sink, or laun­dry tub, in a wet basement, or near a swimming pool, and
the like.

8.Accessories-Do not place this unit on an unstable cart,

stand, tripod, bracket, or table. The unit may fall, causing
serious injury to someone, and serious damage to the appli­ance. Use only with a cart, stand, tripod, bracket, or table
recommended by the manufacturer, or sold with the unit.
Any mounting of the appliance
should follow the manufacturer’s
instructions and should use a mount­ing accessory recommended by the
manufacturer. An appliance and cart
combination should be moved with
care. Quick stops, excessive force,
and uneven surfaces may cause the
appliance and cart combination to
overturn.

PORTABLE CART WARNING

S3126A

THIS SYMBOL INDICATES THAT
DANGEROUS VOLTAGE
CONSTITUTING A RISK OF ELECTRIC
SHOCK IS PRESENT WITHIN THIS UNIT.

THIS SYMBOL INDICATES THAT THERE
ARE IMPORTANT OPERATING AND
MAINTENANCE INSTRUCTIONS IN THE
LITERATURE ACCOMPANYING THE
APPLIANCE.

AMEUBLES- Cet appareil ne doit
être placé que sur un meuble (avec
ou sans roulettes) recommandé par
le fabricant. Si vous l’installez sur
un meuble à roulettes, déplacez les
deux ensembles avec précaution.
Un arrêt brusque, l’utilisation
d’une force excessive et des sur­faces irrégulières risquent de désta­biliser l’ensemble et de le renverser.

9. Ventilation-Slots and openings in the cabinet and the back

or bottom are provided for ventilation and to ensure reliable
operation of the unit and to protect it from overheating, and
these openings must not be blocked or covered. The open­ings should never be blocked by placing the unit on a bed,
sofa, rug, or other similar surface. This unit should never be
placed near or over a radiator or heat register. This unit
should not be placed in a built-in installation such as a
bookcase or rack unless proper ventilation is provided or
the manufacturer’s instructions have been adhered to.

10.Power Sources-This unit should be operated only from the

type of power source indicated on the marking label. If you
are not sure of the type of power supply to your home, con­sult your appliance dealer or local power company. For the
units intended to operate from battery power, or other
sources, refer to the operating instructions.

11.Grounding or Polarization-This unit is equipped with a

polarized alternating-current line plug(a plug having one
blade wider than the other). This plug will fit into the
power outlet only one way. This is a safety feature. If you
are unable to insert the plug fully into the outlet, try revers­ing the plug. If the plug should still fail to fit, contact your
electrician to replace your obsolete outlet. Do not defeat the
safety purpose of the polarized plug.

12.Power-Cord Protection-Power-supply cords should be

routed so that they are not likely to be walked on or
pinched by items placed upon or against them, paying par­ticular attention to cords at plugs, convenience receptacles,
and the point where they exit from the appliance.

SYMBOLE D'AVERTISSEMENT POUR

LES COMPOSANTES

APPAREIL ET MEUBLE A ROULETTES

S3126A

- 2 - EN

EXAMPLE OF ANTENNA GROUNDING AS PER

NATIONAL ELECTRICAL CODE

S2898A

FIGURE A

ELECTRIC
SERVICE
EQUIPMENT

NEC - NATIONAL ELE CTRIC AL CODE

GROUND

CLAMP

ANTENNA

L EAD IN
WIRE

ANTENNA

DISCHARGE UNI T
(NEC SECTION 810-20)

GROUNDING CONDUCTORS
(NEC SECTION 810-21)

GROUND CLAMPS

POWER SERVICE GROUNDI NG
ELECTRODE SYSTEM
(NEC ART 250, PART H)

13.Outdoor Antenna grounding-If an outside antenna or

cable system is connected to the unit, be sure the antenna
or cable system is grounded so as to provide some protec­tion against voltage surges and built-up static charges.
Article 810 of the National Electrical Code, ANSI/NFPA
No. 70, provides information with respect to proper
grounding of the mast and supporting structure, grounding
of the lead-in wire to an antenna discharge unit, size of
grounding conductors, location of antenna-discharge unit,
connection to grounding electrodes, and requirements for
the grounding electrode. (Fig. A)

14.Lightning-For added protection for this unit receiver dur-

ing a lightning storm, or when it is left unattended and
unused for long periods of time, unplug it from the wall
outlet and disconnect the antenna or cable system. This will
prevent damage to the unit due to lightning and power-line
surges.

15.Power Lines-An outside antenna system should not be

located in the vicinity of overhead power lines or other
electric light or power circuits, or where it can fall into
such power lines or circuits. When installing an outside
antenna system, extreme care should be taken to keep from
touching such power lines or circuits as contact with them
might be fatal.

16.Overloading-Do not overload wall outlets and extension

cords as this can result in a risk of fire or electric shock.

17.Object and Liquid Entry-Never push objects of any kind

into this unit through openings as they may touch danger­ous voltage points or short out parts that could result in a
fire or electric shock. Never spill liquid of any kind on the
unit.

18.Servicing-Do not attempt to service this unit yourself as

opening or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to qualified
service personnel.

19.Damage Requiring Service-Unplug this unit from the wall

outlet and refer servicing to qualified service personnel

under the following conditions:
a. When the power-supply cord or plug is damaged or frayed.
b. If liquid has been spilled, or objects have fallen into the

unit.
c. If the unit has been exposed to rain or water.
d. If the unit does not operate normally by following the oper-

ating instructions. Adjust only those controls that are cov-

ered by the operating instructions, as improper adjustment

of other controls may result in damage and will often

require extensive work by a qualified technician to restore

the unit to its normal operation.
e. If the unit has been dropped or damaged in any way.
f. When the unit exhibits a distinct change in performance,

this indicates a need for service.

20.Replacement Parts-When replacement parts are required,

be sure the service technician has used replacement parts

specified by the manufacturer that have the same character-

istics as the original part. Unauthorized substitutions may

result in fire, electric shock, injury to persons or other haz-

ards.

21.Safety Check-Upon completion of any service or repairs to

this unit, ask the service technician to perform routine safe-

ty checks to determine that the unit is in proper operating

condition.

22.Heat-This unit product should be situated away from heat

sources such as radiators, heat registers, stoves, or other

products (including amplifiers) that produce heat.

- 3 - EN

PRECAUTIONS

IMPORTANT COPYRIGHT INFORMATION

Unauthorized copying, broadcasting, public perfor­mance and lending of discs are prohibited.

This product incorporates copyright protection tech­nology that is protected by U.S. patents and other
intellectual property rights. Use of this copyright
protection technology must be authorized by
Macrovision, and is intended for home and other
limited viewing uses only unless otherwise autho­rized by Macrovision. Reverse engineering or dis­assembly is prohibited.

FCC WARNING- This equipment may gener­ate or use radio frequency energy. Changes or
modifications to this equipment may cause
harmful interference unless the modifications
are expressly approved in the instruction man­ual. The user could lose the authority to oper­ate this equipment if an unauthorized change
or modification is made.

RADIO-TV INTERFERENCE

This equipment has been tested and found to com­ply with the limits for a Class B digital device, pur­suant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and
used in accordance with the instructions, may cause
harmful interference to radio communications.

However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause harmful interference to
radio or television reception, which can be deter­mined by turning the equipment off and on, the
user is encouraged to try to correct the interfer­ence by one or more of the following measures:

1) Reorient or relocate the receiving antenna.

2) Increase the separation between the equipment
and receiver.

3) Connect the equipment into an outlet on a cir­cuit different from that to which the receiver is
connected.

4) Consult the dealer or an experienced radio/TV
technician for help.

LASER SAFETY

This unit employs a laser. Only a qualified service
person should remove the cover or attempt to ser­vice this device, due to possible eye injury.

CAUTION: USE OF CONTROLS OR ADJUST­MENTS OR PERFORMANCE OF PROCE­DURES OTHER THAN THOSE SPECIFIED
HEREIN MAY RESULT IN HAZARDOUS
RADIATION EXPOSURE.

CAUTION: VISIBLE AND INVISIBLE LASER
RADIATION WHEN OPEN AND INTERLOCK
DEFEATED. DO NOT STARE INTO BEAM.

LOCATION: INSIDE, NEAR THE DECK
MECHANISM.

This Class B digital apparatus complies with
Canadian ICES-003.

Cet appareil numérique de la classe B est con­forme à la norme NMB-003 du Canada.

CAUTION: TO PREVENT ELECTRIC SHOCK,

MATCH WIDE BLADE OF PLUG TO WIDE
SLOT, FULLY INSERT.

ATTENTION: POUR ÉVITER LES CHOCS
ÉLECTRIQUES, INTRODUIRE LA LAME LA
PLUS LARGE DE LA FICHE DANS LA
BORNE CORRESPONDANTE DE LA PRISE
ET POUSSER JUSQU’AU FOND.

A NOTE ABOUT RECYCLING

Batteries should never be thrown away or inciner­ated but disposed of in accordance with your local
regulations concerning chemical wastes.

The serial number of this product may be found on the back of the unit. No other unit has the same serial
number as yours. You should record the number and other vital information here and retain this book as a per­manent record of your purchase to aid identification in case of theft. Serial numbers are not kept on file.

Date of Purchase
Dealer Purchase from
Dealer Address
Dealer Phone No.
Model No.
Serial No.

- 4 - EN

LOCATION

Owner's Manual

For safe operation and satisfactory performance of
your unit, keep the following in mind when selecting
a place for its installation:

Shield it from direct sunlight and keep it away from

•

sources of intense heat.
Avoid dusty or humid places.

•

Avoid places with insufficient ventilation for proper

•

heat dissipation. Do not block the ventilation holes at
the top or bottom of the unit. Do not place the unit
on a carpet because this will block the ventilation
holes.

Install unit in a horizontal position.

•

Avoid locations subject to strong vibration.

•

Do not place the unit near strong magnetic fields.

•

Avoid moving the unit to locations where tempera-

•

ture differences are extreme.
Be sure to remove disc and unplug the AC power

•

cord from the outlet before carrying the unit.

AV OID THE HAZARDS OF

ELECTRICAL SHOCK AND FIRE

Do not handle the power cord with wet hands.

•

Do not pull on the power cord when disconnecting

•

it from an AC wall outlet. Grasp it by the plug.
If by accident, water is spilled on your unit, unplug

•

the power cord immediately and take the unit to our
Authorized Service Center for servicing.

Do not put your fingers or objects into the unit disc

•

loading tray.
Do not place anything directly on top of the unit.

•

WARNING

Moisture condensation may occur inside the unit
when it is moved from a cold place to a warm place
or after heating a cold room or under conditions of
high humidity. If a DVD is played in a unit which has
moisture, it may damage the DVD and the unit.
Therefore when the condensation occurs inside the
unit, turn the unit on and allow at least 2 hours for the
unit to dry out.

SYMBOLS USED IN THIS MANUAL

The following symbols below appear in some head­ings and notes in this manual, with the following
meanings.

TV

: Description refers to TV operation (in the TV mode).

DVD-V

: Description refers to playback of DVD video discs

(in the DVD mode).

CD

: Description refers to playback of Audio CDs

(in the DVD mode).

QUICK

: Description refers to the items to be set by the

QUICK mode (in the DVD mode).

SUPPLIED ACCESSORIES

BatteriesRemote Control Unit

2 AA Batteries(NE219UD)

If you need to replace these accessories, please refer to the PART NO. under the illustrations and call our

•

help line mentioned on the front page.
Depending on your antenna system, you may need different types of Combiners (Mixer) or Separators

•

(Splitter). Contact your local electronics store for these items.

- 5 - EN

Owner’s Manual

(1EMN20317)

TABLE OF CONTENTS

C IMPORTANT SAFEGUARDS . . . . .2

C PRECAUTIONS . . . . . . . . . . . . . . . .4

LOCATION . . . . . . . . . . . . . . . . . . .5

AVOID THE HAZARDS OF
ELECTRICAL SHOCK AND FIRE .5

WARNING . . . . . . . . . . . . . . . . . . . .5

SYMBOLS USED IN THIS

MANUAL . . . . . . . . . . . . . . . . . . . . .5

C SUPPLIED ACCESSORIES . . . . . . .5

C TABLE OF CONTENTS . . . . . . . . . .6

C FEATURES . . . . . . . . . . . . . . . . . . . .7

C OPERATING CONTROLS AND

FUNCTIONS . . . . . . . . . . . . . . . . . . .8

C PREPARATION FOR USE . . . . . . .10

ANTENNA/CABLE

CONNECTION . . . . . . . . . . . . . . . .10

CONNECTING TO FRONT A/V

INPUT JACKS . . . . . . . . . . . . . . . .11

CONNECTING TO A STEREO
AMPLIFIER EQUIPPED WITH
DIGITALINPUT JACKS (for DVD) .11

CONNECTING TO A DOLBY
DIGITAL DECODER (for DVD) . .12

INSTALLING THE BATTERIES . .12

TV SECTION

C TV OPERATION AND SETTINGS .13

WATCHING A TV PROGRAM . . .13

DEGAUSSING . . . . . . . . . . . . . . . .13

PICTURE CONTROL . . . . . . . . . . .13

SLEEP TIMER . . . . . . . . . . . . . . . .14

CLOSED CAPTION SYSTEM . . . .14

CHANNEL SET UP . . . . . . . . . . . .15

V-CHIP SET UP . . . . . . . . . . . . . . .16

TV RATING SET UP . . . . . . . . .16

MPAA RATING SET UP . . . . . .17

CHANGE ACCESS CODE . . . . .17

MENU LANGUAGE . . . . . . . . . . .17

C CABLE CHANNEL

DESIGNATIONS . . . . . . . . . . . . . .18

DVD SECTION

C ABOUT THE DISCS . . . . . . . . . . . .19

PLAYABLE DISCS . . . . . . . . . . . .19

UNPLAYABLE DISCS . . . . . . . . . .19

C PLAYING A DISC . . . . . . . . . . . . . .20

BASIC PLAYBACK . . . . . . . . . . . .20

GENERAL FEATURES . . . . . . . . .20

DISC MENU . . . . . . . . . . . . . . . . .20

TITLE MENU . . . . . . . . . . . . . . . . .20

RESUME . . . . . . . . . . . . . . . . . . . .21

PAUSE . . . . . . . . . . . . . . . . . . . . . .21

STEP BY STEP PLAYBACK . . . . .21

FAST FORWARD /

FAST REVERSE . . . . . . . . . . . . . .21

SLOW FORWARD /

SLOW REVERSE . . . . . . . . . . . . . .21

ZOOM . . . . . . . . . . . . . . . . . . . . . .21

C SEARCH FUNCTION . . . . . . . . . . .22

TRACK SEARCH . . . . . . . . . . . . .22

TITLE / CHAPTER SEARCH . . . .22

TIME SEARCH . . . . . . . . . . . . . . .22

MARKER SETUP SCREEN . . . . . .22

C

SPECIAL PLAYBACK FUNCTION . . .23

REPEAT . . . . . . . . . . . . . . . . . . . . .23

PROGRAM . . . . . . . . . . . . . . . . . . .23

RANDOM PLAYBACK . . . . . . . . .23

C CHANGING THE SETTINGS . . . .24

SUBTITLE LANGUAGE . . . . . . . .24

AUDIO LANGUAGE . . . . . . . . . . .24

STEREO SOUND MODE . . . . . . . .24

CAMERA ANGLE . . . . . . . . . . . . .24

BLACK LEVEL SETTING . . . . . . .24

VIRTUAL SURROUND . . . . . . . . .25

C

THE ON-SCREEN INFORMATION . . .25

C CHANGING THE DVD SET UP

ITEMS . . . . . . . . . . . . . . . . . . . . . . .26

CUSTOM MENU . . . . . . . . . . . . . .26

LANGUAGE SETTING . . . . . . . .26

DISPLAY SETTING . . . . . . . . . .27

AUDIO SETTINGS . . . . . . . . . . .27

PARENTAL CONTROL . . . . . . . .28

OTHER SETTINGS . . . . . . . . . . .28

INITIALIZE . . . . . . . . . . . . . . . . . .28

C TROUBLESHOOTING GUIDE . . .29

C MAINTENANCE . . . . . . . . . . . . . . .32

DISC HANDLING . . . . . . . . . . . . .32

C SPECIFICATIONS . . . . . . . . . . . . .33

C ESPAÑOL . . . . . . . . . . . . . . . . . . . .34

C WARRANTY . . . . . . . . . . .Back Cover

- 6 - EN

FEATURES

TV Mode

Infrared remote control

•

Trilingual on screen TV setup display selectable

•

in English, Spanish or French
181 channel capability PLL frequency synthesiz-

•

er tuner with direct station call

be necessary to view scrambled cable channels.)

Closed Caption Decoder–You may view specially

•

labeled (cc) TV programs, movies, news, etc. with
either a dialogue caption or text display added to
the program.

DVD Mode

¡Dolby Digital sound

This unit can handle Dolby Digital surround sound
having 5.1 channels when connected to a Dolby
Digital decoder.

¡Still/fast/slow/step playback

Various playback modes are available including still
pictures, fast forward/reverse, slow motion and step
frames.

¡Random playback for Audio CD

This unit can shuffle the order of tracks to play them
in random order.

¡Program playback for Audio CD

You can program the order of tracks to play them in
any desired order.

¡DVD menus in a desired language

You can display DVD menus in a desired language,
if available on a DVD.

¡Screen saver/Auto power-off functions

The screen saver program starts when there is no
input from the unit for 5 minutes in the stop mode.
After the screen saver program is activated for 15
minutes, the power automatically turns off.

¡Subtitles in a desired language

You can select a desired language for the display
subtitles, if that language is available on a disc.

¡Selecting a camera angle

You can select the desired camera angle, if a disc
contains sequences recorded from different angles.

¡Choices for audio language and sound mode

You can select the desired audio language and sound
mode, if different languages and modes are available
on a disc.

(A converter may

Auto power off system–If there is no air signal

•

input from the antenna terminal and no operation
for 15 minutes, the unit will turn itself off automat­ically.

Sleep timer–Allows you to have the unit automati-

•

cally turn off at a desired time.

V-CHIP–Enables parents to prevent their children

•

from watching inappropriate material on TV.

¡Parental lock

You can set the control level to limit playback of
discs which may not be suitable for children.

¡Automatic detection of discs

This unit automatically detects if the loaded disc is
DVD or Audio CD.

¡On-screen display

Information about the current operation can be
displayed on a TV screen, allowing you to confirm
the currently active functions (such as program
playback), on the TV screen using the remote
control.

¡Search

Chapter search / Title search / Track search / Time
search

¡Repeat

Chapter / Title / Track / All / A-B

¡Zoom

Magnified screen can be displayed.

¡Marker

The part designated by user can be called back.

¡Resume Play

User can resume to playback from the part at which
the play was stopped.

¡Virtual Surround
¡Bit rate indication
¡DRC (Dynamic range control)

You can control the range of sound volume.

- 7 - EN

OPERATING CONTROLS AND FUNCTIONS

ySTANDBY-ON

L

VOLUME KL CHANNEL

K

H

PREV NEXT

GB

PLAY

F

PAUSE

C

STOP

A

OPEN/CLOSE

HEADPHONE

VIDEOL –AUDIO–

R

E –

SEARCH

–

D

12 4 56 107 98313141211

- FRONT PANEL - [Fig.1]


0 +10

PLAY

STOP

SLOW

SEARCH MODE

[Fig. 2]

SELECT

OPEN/CLOSE

+100

ZOOM

ENTER

RETURNTITLESETUP

REPEAT

CH.

VOL.

MUTE

DISC

MENU

REPEAT

A-B

ANGLESUBTITLEAUDIO

13
36

6

5

35
34

33

8

32

31
30

29

28

27
26

25

- REMOTE CONTROL -

STANDBY-ON

4

15

16

123

456

789

SLEEP

17

9

PREV NEXT

11
10

PAUSE

12

18

DISPLAY

19
20
21

CLEAR

MODE

22
23

24

1.Disc loading tray

2.VIDEO input Jack

Connect to the video output jack of a video camera or
VCR.

3.AUDIO L/R input Jacks

Connect to the audio output jacks of a video camera or
VCR.

4.STANDBY-ON Button

[P.13]

Hit to turn the power on and off.

5.VOLUME (VOL.) K / L Buttons

[P.13]

Press to control the volume level for the DVD and TV.

6.CHANNEL (CH.) K / L Buttons

[P.13]

Press to select memorized channels.

7.Remote sensor window

8.C STOP Button

[P.20]

Stops operation of the disc.

9.H PREV Button

[P.22]

Hit once to move to the previous chapter or track.

h

SEARCH Button (Front panel) [P.21]

Hit and hold to change reverse playback speed.

10. B PLAY Button

[P.20]

Starts playback of the disc.

11. NEXT G Button

[P.22]

Hit once to move to the next chapter or track.

SEARCH gButton (Front panel) [P.21]

Hit and hold to change forward playback speed.

12. F PAUSE Button

[P.21]

Pauses the current disc operation.

13. A OPEN/CLOSE Button

[P.20]

Hit to insert a disc into or remove it from the
tray.

14. HEADPHONE Jack

To connect headphone (not supplied) for personal
listening.

15. PICTURE Button

[P.13]

Hit to adjust the picture.

16. Number Buttons

TV Mode:

[P.13]

Press two digits to directly access the desired
channel.
Remember to hit [0] before a single digit channel.

+100 Button–

Hit to select cable channels which are higher
than 99.

DVD Mode:

+10 Button–

Hit to enter the desired numbers which are higher
than 9.

Hit to enter the desired number.

17. SLEEP Button

[P.22]

[P.14]

Sets the Sleep Timer.

- 8 - EN- 8 - EN

- REAR PANEL - [Fig.3]

3837

39

COAXIAL

ANT.

18. DISPLAY Button

TV Mode:

Displays the current channel number on the TV
screen.

DVD Mode:

[P.25]

Displays the current status on the TV screen.

19. SETUP Button

[P.26]

Hit to enter or exit the setup menu of TV or DVD.

20. TITLE Button

[P.20]

Displays the title menu.

21. CLEAR Button

[P.22]

Hit to clear or cancel a setting currently entered.

22. MODE Button

[P.23, 24, 25]

Hit to call up the program screen or the random
screen in the stop mode.
Hit to call up the Black Level Setting screen or
the Virtual Surround screen during playback.

23. SEARCH MODE Button

[P.22]

Hit to locate a desired point.

24. AUDIO Button

[P.24]

Hit to select a desired audio language or sound
mode.

25. SUBTITLE Button

[P.24]

Hit to select a desired subtitle language.

26. REPEAT Button

[P.23]

Repeats playback of the current disc, title, chap­ter, or track.

27. ANGLE Button

[P.24]

Hit to change the camera angle to see the
sequence being played back from a different angle
(if available).

28. REPEAT A-B Button

[P.23]

Repeats playback of a selected section.

29. RETURN Button

[P.22]

Returns to the previous screen in the setup menu.

30. ENTER Button

[P.15]

Hit to accept a setting.

31. K / L / { / B Buttons

TV Mode:

[P.13]

Press to select a setting mode from the menu on
the TV screen.
Press to select or adjust from a particular menu.

DVD Mode:

[P.20]

Press to select a menu item.

32. DISC MENU Button

[P.20]

Calls up the DVD menu.

33. h Button [P.21]

Hit to view the DVD picture in fast reverse or
slow reverse motion.

g Button [P.21]

Hit to view in fast or slow forward motion.

34. ZOOM Button

[P.21]

Enlarges part of a DVD-reproduced image.

35. MUTE Button

[P.13]

Mutes the sound. Hit it again to restore sound.

36. SELECT Button

[P.11]

Hit to change to TV mode, external input mode or
DVD mode.

37. COAXIAL Jack

[P.11]

Connect to the digital input of an external
amplifier or decoder (for DVD Audio only).

38. ANT(ENNA). Jack

[P.10]

Connect to an antenna, cable system or satellite
system.

39. Power cord

[P.13]

Connect to a standard AC outlet (120V/60Hz).

NOTE:

Remove the power cord from the hook to avoid

•

breaking a wire before you connect to a stan­dard AC outlet.

NOTE:

We do not recommend the use of universal remote controls. Not all of the functions may be controlled with

•

a universal remote control.
If you decide to use a universal remote control with this unit, please be aware that the code number given

may not operate this unit. In this case, please call the manufacturer of the universal remote control.

- 9 - EN- 9 - EN

PREPARATION FOR USE

ANTENNA/CABLE CONNECTION

Cables used here are commercially available.

[ANTENNA CONNECTION]

75-ohm
Coaxial Cable

VHF/UHF

OR

OR

Adaptor

ANT.

COAXIAL

ANT.

*Some cable TV systems use scrambled signals and

VHF

UHF

VHF

VHF

or

UHF

UHF

VHF/UHF
Combiner

Flat twin­lead cable

or

require a special converter to receive these channels.
Consult your local cable company.

Note to CATV system installer:

This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the NEC that provides
guidelines for proper grounding and in particular, specifies that the cable ground shall be connected to the grounding
system of the building as close to the point of cable entry as practical.

[CATV/SATELLITE CONNECTION]

CATV Box or
Satellite Box *

OUT IN

From Cable System
or Satellite Antenna

75-ohm

OR

Coaxial Cable

From Cable System

[Fig. 4]

NOTE:

Before plugging the antenna into the ANT. jack of the unit, check that the pin is

•

not bent. If it is bent, straighten the pin as illustrated, then plug the pin into the
ANT. jack of the unit.

VHF/UHF COMBINED ANTENNA

A VHF UHF 75 ohm combination antenna can be
connected to ANT. jack of the unit.

VHF/UHF SEPARATE ANTENNAS

In some areas it will be necessary to use an outdoor
antenna.

CABLE WITHOUT CONVERTER/

CABLE WITH CONVERTER/DESCRAM­BLER BOX OR SATELLITE BOX

If your cable service supplies you with a converter
box or if you use a satellite system, you can use the
basic connection shown above.

Channel selection must be made with the converter
box or satellite box. This means that channels cannot
be changed using the remote control of this unit.

Bent pin

Cable

Plug

(Needs to be

straightened)

DESCRAMBLER BOX

Use this connection if your cable system connects
directly to the unit without a converter box.

NOTE:

For your safety and to avoid damages to the unit, unplug the antenna cable from the ANT. jack

•

before moving the unit.

(Straight pin)

- 10 - EN- 10 - EN

- 10 - EN

CONNECTING TO FRONT A/V INPUT JACKS

COAXIAL

ANT.

ex.
MD deck, DAT deck, etc.

To Coaxial digital
Audio input jack

To COAXIAL jack
(Only DVD AUDIO OUT)

When you watch a program recorded on another source (VCR or video camera), use the
AUDIO/VIDEO input jacks on the front of the unit.

Connect the Audio/Video output jacks of another source to the AUDIO L/R and VIDEO
jacks of this unit.

Then press [SELECT] or [CH. KK/ LL] until “AUX” appears on the screen.

ex.
VCR or video camera

(IN)

–

VIDEO

L –AUDIO

R

[Front of the unit]

(IN)

To the Audio output jacks

Audio cable (commercially available)

To the Video output jack

Video cable (commercially available)

(OUT)

(OUT)

[Fig. 5]

NOTE:

When you connect a monaural VCR (another source) to this unit, connect the Audio output jack of the

•

monaural VCR (another source) to the AUDIO L jack of this unit. The audio will output in both L and R
channel equally.

AUX

, etc.

CONNECTING TO A STEREO AMPLIFIER EQUIPPED WITH

DIGITAL INPUT JACKS (for DVD)

Use an audio coaxial digital cable (commercially available) for the audio connections.
Connect to an amplifier equipped with digital input jacks such as MD Deck or DAT Deck.

(OUT)

(IN)

NOTES:

The audio source on a disc in a 5.1 channel Dolby Digital surround format cannot be recorded as digital

•

sound by an MD or DAT deck.
Be sure to turn off the power to all components in the system before connecting another component.

•

Refer to the Owner’s Manuals for the components to be connected to the unit.

•

Set “DOLBY DIGITAL” to “PCM” for audio output in the setup mode. Playing a unit using incorrect set-

•

tings may generate noise distortion and may also damage the speakers. (Refer to page 27.)

Audio coaxial digital cable
(commercially available)

- 11 - EN- 11 - EN

- 11 - EN

[Fig. 6]

CONNECTING TO A DOLBY DIGITAL DECODER (for DVD)

COAXIAL

ANT.

Front speaker

(left)

Center

speaker

Front speaker

(right)

Surround

speaker

(left)

Surround

speaker

(right)

Subwoofer

Dolby Digital

decoder

If using this unit to play a DVD disc in a 5.1 channel Dolby Digital surround format, the unit outputs a
DOLBY DIGITAL Data stream from its COAXIAL jack. By hooking the unit up to a Dolby Digital decoder,
you can enjoy a more convincing, realistic ambience with powerful and high-quality surround sound as
enjoyed in movie theaters.

Use audio coaxial digital cables (commercially available) for the audio connections.

(OUT)

To Coaxial digital
Audio input jack

(IN)

To COAXIAL jack
(Only DVD AUDIO OUT)

Audio coaxial digital cable
(commercially available)

[Fig. 7]

NOTES:

Be sure to turn off the power to all components in the system before connecting another component.

•

Refer to the Owner’s Manuals for the components to be connected to the unit.

•

If connected to a Dolby Digital decoder, set “DOLBY DIGITAL” to “BITSTREAM” for audio output in the

•

setup mode. (Refer to page 27.)
Unless connected to a Dolby Digital decoder, set “DOLBY DIGITAL” to “PCM” for audio output in the

•

setup mode. Playing a unit using incorrect settings may generate noise distortion and may also damage the
speakers. (Refer to page 27.)

Manufactured under license from Dolby Laboratories.“Dolby” and the double-D symbol are
trademarks of Dolby Laboratories.

INSTALLING THE BATTERIES

1)Open the battery compartment cover by pressing
the cover on the remote unit in the direction of the
arrow.

2)Insert 2 “AA” penlight batteries into the battery
compartment in the direction indicated by the
polarity (+/-) markings.

3)Replace the cover.

[BATTERY PRECAUTIONS]

in the battery compartment. Reversed batteries

Be sure to follow the correct polarity as indicated

•

may cause damage to the device.
Do not mix different types of batteries together

•

(e.g. Alkaline and Carbon-Zinc) or old batteries
with fresh ones.

If the device is not to be used for a long period of

•

time, remove the batteries to prevent damage or
injury from possible battery leakage.

Do not try to recharge batteries not intended to be

•

recharged; they can overheat and rupture.

- 12 - EN- 12 - EN- 12 - EN

TV OPERATION AND SETTINGS

TV SECTION

WATCHING A TV PROGRAM

TV

1 Plug in the unit power cord

Plug the unit power cord into a standard
AC outlet.

NOTE:

If any digits appear in the corner of the

•

screen, hit [STANDBY-ON] without
unplugging the power cord.

2 Turn on the unit

Hit [STANDBY-ON] to turn on the unit.

3 Select the channel number

Press [CH. K / L] or the Number buttons to select
your desired channel number.

Note for using the Number buttons:

¡You must precede single-digit channel numbers

with a zero (for example: 02, 03, 04 and so on).

¡When selecting cable channels which are higher

than 99, hit [+100] first, then press the last two
digits. (Example: to select channel 125, first hit

[+100] then hit [2] and [5].)

DEGAUSSING

TV

This television has a degaussing circuit that will clear
up color errors on the TV screen that are caused by
any excess magnetism which happens to get too close
to the TV. This circuit is designed to operate once
when the set is first plugged in. If minor color

errors are seen in some locations on the screen,
please unplug the TV for approximately 30 min­utes. When the TV is plugged back in, the degauss-

ing circuit will operate once to clear them up. Repeat
this procedure any time the TV screen is accidentally
magnetized or when the TV is moved or relocated.

PICTURE CONTROL

TV

The unit’s picture controls – BRIGHT, CON­TRAST, COLOR, TINT and SHARPNESS – are

preset to factory specifications. Although they are
usually the best, you may need to make some further
adjustments for a more natural looking image.

Make sure ...

The unit must be turned on.

•

4 Adjust sound

Press [VOL.KK/ LL] to adjust the
volume.

[MUTE] to instantly mute the

Hit
sound.

Hit it again to restore the previous sound level.

NOTE:

If you press [CH. K / L] in the DVD mode, you

•

can change the TV channels. Even if you turn off
the unit in the DVD mode, when you turn it on
again, it will go into the TV mode.

VOLUME 20

C C C C C C C C C C C C C C C C

TO WATCH CABLE OR SATELLITE
CHANNEL

If the unit is connected to a cable box or satellite

•

box, press [CH. K / L] to select CH3 or CH4
according to the output channel setting of the
device and select desired channel on that device.

TO WATCH EXTERNAL INPUT

When an external equipment is connected to the

•

front AUDIO/VIDEO input jacks, press
[SELECT] or [CH. K / L] repeatedly until
“AUX” appears on the screen.

1 Call up the menu

Hit [PICTURE].

2 Select item you want to adjust

Press [K / L] until desired control is displayed.

BRIGHT
CONTRAST
COLOR
TINT
SHARPNESS

BRIGHT

PP PP PP PP PP PP PP CC PP PP PP PP PP PP PP

–

3 Adjust the setting

Press [s/ B]to adjust to your desired level within 5
seconds.

sB

BRIGHT to decrease to increase

brightness brightness

CONTRAST to decrease to increase

contrast contrast

COLOR to pale to brilliant
TINT to purple to green

SHARPNESS to soft to clear

Even if there is a power failure of any kind, the

•

unit will retain its memory for this feature.

+

- 13 - EN- 13 - EN- 13 - EN

SLEEP TIMER

TV

The Sleep Timer function turns off the unit without
using [STANDBY-ON] after a desired period of
time.

1 Call up the Sleep Timer Setting

Hit [SLEEP] so that “SLEEP 0 MINUTE” appears.

2 Set sleep time

Hit [SLEEP] repeatedly until your
desired sleep time appears.

Each additional press will increase
the time by 30 minutes up to 120
minutes.

SLEEP 120 MINUTE

After 5 seconds, the Sleep Timer setting will disap­pear automatically.

TO CANCEL THE SLEEP TIMER

Hit [SLEEP] to call up the Sleep Timer Setting. Hit
[SLEEP] repeatedly until “SLEEP 0 MINUTE”

appears.

CLOSED CAPTION SYSTEM

TV

You can view specially labeled (cc) TV programs,
movies, news and pre-recorded tapes with either a
dialogue caption or text display.

CAPTION mode: You can watch dramas, movies and

news while captioning the dialogues and the contents
of news.

TEXT mode: You can watch half screen text informa-

tion if you want.

1-2: You may get these captions or text information

by selecting either “1” or “2”. Caption “2” is usually
used for a second language if available.

NOTES:

Not all programs are broadcast with closed cap-

•

tions. Your unit is designed to provide error free
closed captions from high quality antenna, cable
and VCR signals. Conversely, poor quality signals
are likely to result in caption errors or no captions
at all. Common signal conditions which may cause
caption errors are listed below:

Automobile ignition noise

•

Electric motor brush noise

•

Weak snowy reception on TV screen

•

Multiplex signal reception displaying picture

•

ghosts or airplane flutter

If the unit displays a black box

•

on the TV screen, this means that
the unit is set to the TEXT mode.
To clear screen, select [CAP­TION1], [CAPTION2] or [OFF].

Make sure ...

The unit must be turned on.

•

1 Select “CAPTION”

Hit [SETUP].
Press

[K / L] to point to “CAP-

TION”.

- TV SETUP -

CHANNEL SET UP
V-CHIP SET UP
LANGUAGE [ENGLISH]

B CAPTION [OFF]

2 Select your desired caption mode

Hit [ENTER] repeatedly until your
desired caption menu appears.

([CAPTION1], [CAPTION2],
[TEXT1] or [TEXT2])

- TV SETUP -

CHANNEL SET UP
V-CHIP SET UP
LANGUAGE [ENGLISH]

B CAPTION [CAPTION1]

3 Exit the caption setting mode

Hit [SETUP] to exit the menu.
NOTE:

Even if there is a power failure of any kind, the

•

unit will retain its memory for this feature.

TO CANCEL THE CLOSED CAPTION
SYSTEM

Repeat steps 1 to 2 and select [OFF] using
[ENTER]. Then hit [SETUP] to return to TV mode.

- 14 - EN

CHANNEL SET UP

Make sure ...

The unit must be turned on.

•

TV

ADDING/DELETING CHANNELS

The channels you no longer receive or seldom watch
can be deleted from the memory. (Of course, you can
add the deleted channel into the memory again.)

AUTO CHANNEL PROGRAMMING

As the initial setting, this unit has memorized all
channels, including the ones not available in your
area. This feature automatically puts only available
channels into the memory.

1 Select “CHANNEL SET UP”

Hit [SETUP].
Press

[K / L]

to point to

- TV SETUP -

B CHANNEL SET UP

V-CHIP SET UP
LANGUAGE [ENGLISH]
CAPTION [OFF]

“CHANNEL SET UP”, then hit
[ENTER].

2 Begin channel scanning

Press

[K / L]

to point to “AUTO

CH PROGRAMMING”, then hit
[ENTER].

The tuner scans and memorizes all
the active channels in your area.

– CHANNEL SET UP –

ADD / DELETE CH (CATV)

B AUTO CH PROGRAMMING

3 After scanning

The tuner stops on the lowest memorized channel.

NOTES:

When “AUTO CH PROGRAM-

•

MING” is activated where there
is no TV signal input, “NO TV
SIGNALS” will appear on the
display after the completion of
channel scanning.

The unit may recognize CATV channels to be TV

•

channels if reception condition is poor. In this case,
check the antenna connection and try “AUTO CH
PROGRAMMING” again when reception condi­tions are better.

Channel memory programming is NOT neces-

•

sary when connected to a cable box or satellite
box. Just select the channel for cable box or
satellite input (ex. CH3) on the unit, then select
your desired channel on the cable box or satel­lite box.

NO TV SIGNALS

1 Select “CHANNEL SET UP”

Hit [SETUP].
Press

[K / L]

to point to “CHAN-

- TV SETUP -

B CHANNEL SET UP

V-CHIP SET UP
LANGUAGE [ENGLISH]
CAPTION [OFF]

NEL SET UP”, then hit [ENTER].

2 Select “ADD/DELETE CH”

Press

[K / L]

“ADD/DELETE CH”, then hit

to point to

– CHANNEL SET UP –

B ADD / DELETE CH (CATV)

AUTO CH PROGRAMMING

[ENTER].

3 Enter the desired channel number

Press [CH. K / L] or the Number
buttons until your desired channel

number appears. (You can also
press [K / L] to enter it.)

You must precede single-digit

•

channel numbers with a zero

(Example: CH8)

08

ADD / DELETE

(Example: 02 ... 09).
When selecting cable channels which are higher

•

than 99, hit [+100] first, then press the last two
digits. (Example: to select channel 125, first hit
[+100] then hit [2] and [5].)

4 Delete (or add) it from (or into) memory

Hit [ENTER]. The channel number changes to light
red. The channel is deleted from memory.

To delete another channel, repeat steps 3 to 4.

•

If you hit [ENTER] again, the channel is memo-

•

rized again.

Added channel : Light blue
Deleted channel : Light red

5 Exit the channel setup mode

Hit [SETUP] to exit the menu.
NOTE:

To confirm that channel(s) has been deleted or

•

added, press [CH. K / L].

- 15 - EN

V-CHIP SET UP

TV

This feature enables parents to prevent their children
from watching inappropriate material on TV. When
you try to access a program which is blocked,
“PROTECTED PROGRAM by ...” message appears
on the TV screen.

NOTE:

When you select a rating and set

•

it to [BLOCK], the higher ratings
will be blocked automatically.
The lower ratings will be avail-

TV–Y [VIEW]
TV–Y7 ( ) [VIEW]

B TV–G [BLOCK]

TV–PG (DLSV ) [BLOCK]
TV–14 (DLSV ) [BLOCK]
TV–MA ( LSV) [BLOCK]

able for viewing.
When you set the lowest rating to

•

[VIEW], all other ratings will automatically be
available for viewing.

V-CHIP SET UP

Make sure ...

The unit must be turned on.

•

1 Select “V-CHIP SET UP”

Hit [SETUP].
Press

[K / L] to select “V-CHIP

- TV SETUP -

CHANNEL SET UP

B V-CHIP SET UP

LANGUAGE [ENGLISH]
CAPTION [OFF]

SET UP”, then hit [ENTER].

2 Enter Access code

Press the Number buttons to
enter the access code.

For the first time set-up or in the

•

ACCESS CODE

_ _ _ _

event the unit has lost power,
enter the default code of 0000.

3 Select the desired item

Press [K / L] to select “TV RATING”, “MPAA
RATING” or “CHANGE CODE”, then hit [ENTER].

Refer to the pages below to set up each item.

– V-CHIP SET UP –

B TV RATING

MPAA RATING
CHANGE CODE

A

TV RATING SET UP

A

P16 Step

B

P17 Step

C

P17 Step

4
4
4

5 Setting “Sub-Ratings”

When you select the ratings of TV­Y7, TV-PG, TV-14 or TV-MA you
will have the option of setting sub
rating categories.

Press

[K / L] to select a rating with

sub-ratings you wish to block, then
hit [ENTER] twice.

Press

[K / L] to select a sub-rating,

then hit [ENTER] to set it to
[BLOCK] or [VIEW].

Selection Rating Category Explanations

TV-Y7

FV Fantasy Violence

TV-PG, TV-14, TV-MA

D Suggestive Dialog
L Coarse Language
S Sexual Situation
VViolence

NOTE:

The blocked sub-ratings will

•

appear next to the rating category
in the “TV RATING” menu.

TV–Y [VIEW]

B TV–Y7 ( ) [VIEW]

TV–G [VIEW]
TV–PG ( ) [VIEW]
TV–14 ( ) [VIEW]
TV–MA( ) [VIEW]

TV–Y7 [BLOCK]

B FV [BLOCK]

TV–PG [BLOCK]

B D[BLOCK]

L[BLOCK]
S[BLOCK]
V[BLOCK]

(TV-PG, TV-14 only)

TV–Y [VIEW]
TV–Y7 ( ) [VIEW]
TV–G [VIEW]

B TV–PG (DLSV ) [BLOCK]

TV–14 (DLSV ) [BLOCK]
TV–MA ( LSV) [BLOCK]

Follow steps 1to 3in the “V-CHIP SET UP” sec­tion above.

4 Blocking TV programs

Press [K / L] to select a rating that
you wish to block.

Hit

[ENTER] repeatedly to set it to

[BLOCK] or [VIEW].

Selection Rating Category Explanations

TV-Y Appropriate for all children
TV-Y7 Appropriate for children seven and older
TV-G General Audience
TV-PG Parental Guidance suggested.
TV-14 Unsuitable for children under 14
TV-MA Mature audience only

B TV–Y [VIEW]

TV–Y7 ( ) [VIEW]
TV–G [VIEW]
TV–PG ( ) [VIEW]
TV–14 ( ) [VIEW]
TV–MA( ) [VIEW]

6 Exit the V-Chip setting mode

Hit [SETUP] to exit the menu.
NOTE:

To change the rating, the TV must

•

be turned to an unprotected pro­gram. If “PROTECTED PRO­GRAM by ...” appears on the
screen, please change the channel
to a station that is not protected.

- 16 - EN- 16 - EN- 16 - EN- 16 - EN- 16 - EN- 16 - EN- 16 - EN- 16 - EN

- 16 - EN

PROTECTED PROGRAM

by TV-Y

B

MPAA RATING SET UP

MENU LANGUAGE

Follow steps 1to 3in the “V-CHIP SET UP” sec­tion on page 16.

4 Select your desired item

Press [K / L] to point to your
desired item, then hit [ENTER] to
select [BLOCK] or [VIEW].

Selection Rating Category Explanations

G General Audience
PG Parental Guidance suggested.
PG-13 Unsuitable for children under 13
R Restricted; under 17 requires accompa-

nying parent or adult guardian
NC-17 No one under 17 admitted
X Mature audience only

When you select a rating and set it to [BLOCK],

•

the higher ratings will be blocked automatically.
The lower ratings will be available for viewing.
When you set the lowest rating to [VIEW], all

•

other ratings will automatically be available for
viewing.

G[VIEW]
PG [VIEW]
PG–13 [VIEW]

B R[BLOCK]

NC–17 [BLOCK]
X[BLOCK]

5 Exit the V-Chip setting mode

Hit [SETUP] to exit the menu.

TV

1 Select “LANGUAGE”

Hit [SETUP].
Press

[K / L] to point to “LAN-

GUAGE”.

- TV SETUP -

CHANNEL SET UP
V-CHIP SET UP

B LANGUAGE [ENGLISH]

CAPTION [OFF]

2 Select “ENGLISH”, “ESPAÑOL” or “FRANÇAIS”

Hit [ENTER] repeatedly to select “ENGLISH”,
“ESPAÑOL”= Spanish or “FRANÇAIS”= French.

3 Exit the Language mode

Hit [SETUP] to exit the menu.
NOTES:

This function effects only the language on the

•

screen menu and not the audio source.
If for some reason the menu is in Spanish or

•

French, hit [SETUP], press [K / L] to point to
“IDIOMA [ESPAÑOL]” or “LANGAGE
[FRANÇAIS]”, then hit [ENTER] repeatedly to
select desired language, then hit [SETUP].

C

CHANGE ACCESS CODE

Follow steps 1to 3in the “V-CHIP SET UP” sec­tion on page 16.

4 Enter New code

Press the Number buttons to enter
your desired access code in the

NEW CODE

CONFIRM CODE

_ _ _ _

X X X X

“NEW CODE” space, then enter
the same code in the “CONFIRM
CODE” space. When completed, the menu will
return to “V-CHIP SET UP”.

Make sure you enter exactly the same new code in

•

the “CONFIRM CODE” space as one in the
“NEW CODE” space. If they are different, the
“NEW CODE” space is cleared for redoing.

5 Exit the V-Chip setting mode

Hit [SETUP] to exit the menu.
NOTE:

Your personal access code will be erased and will

•

return to the default (0000) when a power failure
occurs or when you turn off the power using a
wall switch. If you have forgotten the code, unplug
the power cord for 10 seconds to restore the access
code to 0000.

- 17 - EN- 17 - EN- 17 - EN- 17 - EN- 17 - EN- 17 - EN- 17 - EN- 17 - EN

- 17 - EN

CABLE CHANNEL DESIGNATIONS

TV Display

TV Display

TV Display

TV Display

TV Display

TV Display

TV Display

TV Display

CATV channel

TV Display

W+80 W+81 W+82 W+83 W+84

W+65 W+66 W+67 W+68 W+69 W+70 W+71 W+72 W+73 W+74 W+75 W+76 W+77 W+78 W+79

W+55 W+56 W+57 W+58 A-4 A-3 A-2 A-1 W+59 W+60 W+61 W+62 W+63 W+64

W+40 W+41 W+42 W+43 W+44 W+45 W+46 W+47 W+48 W+49 W+50 W+51 W+52 W+53 W+54

W+25 W+26 W+27 W+28 W+29 W+30 W+31 W+32 W+33 W+34 W+35 W+36 W+37 W+38 W+39

W+10 W+11 W+12 W+13 W+14 W+15 W+16 W+17 W+18 W+19 W+20 W+21 W+22 W+23 W+24

A-5

RSTUVWW+1 W+2 W+3 W+4 W+5 W+6 W+7 W+8 W+9

CDEFGHI JKLMNOPQ

5A 2 3 4 5 6 7 8 9 10 11 12 13 A B

123456789101112131415

16 17 18 19 20 21 22 23 24 25 26 27 28 29 30

31 32 33 34 35 36 37 38 39 40 41 42 43 44 45

46 47 48 49 50 51 52 53 54 55 56 57 58 59 60

61 62 63 64 65 66 67 68 69 70 71 72 73 74 75

76 77 78 79 80 81 82 83 84 85 86 87 88 89 90

91 92 93 94 95 96 97 98 99 100 101 102 103 104 105

106 107 108 109 110 111 112 113 114 115 116 117 118 119 120

121 122 123 124 125

CATV channel

CATV channel

CATV channel

CATV channel

CATV channel

CATV channel

CATV channel

CATV channel

If you subscribe to cable TV, the channels are displayed as 1-125. Cable companies often designate channels
with letters or letter-number combinations. Please check with your local cable company. The following is a
chart of common cable channel designations.

- 18 - EN- 18 - EN- 18 - EN- 18 - EN- 18 - EN- 18 - EN- 18 - EN- 18 - EN- 18 - EN- 18 - EN- 18 - EN- 18 - EN- 18 - EN- 18 - EN- 18 - EN- 18 - EN- 18 - EN- 18 - EN- 18 - EN- 18 - EN- 18 - EN- 18 - EN

ABOUT THE DISCS

DVD-Video

* 1,2,3,10

* 1,3,4,5,7,8,9

* 1,3,4,5,6

8,9

* 3,5

* 3,4,5,8,9

or

DVD-RW

DVD-R

DVD+RW

DVD+R

Audio CD

CD-RW

CD-R

Digital video

(MPEG2)

-

-

-

Digital audio

Region code

Mark (logo)

Playable

discs

Recorded

signals

Disc size

Disc types

12 cm

or

8cm

12 cm

or

8cm

Example

Title 1 Title 2

Chapter 1 Chapter 2 Chapter 1

Chapter 2

Chapter 3 Chapter 4

Example

Tra c k 1

Tra c k 2

Tra c k 5

Tra c k 6

Tra c k 3

Tra c k 4

Audio CD

is a trademark of DVD Format/Logo Licensing Corporation.

PLAYABLE DISCS

DVD SECTION

If you cannot play back a disc which bears one of the marks above, check the following notes.

*1: This unit conforms to the NTSC color system. Discs recorded in other color systems such as PAL cannot

be played back.

*2:

Certain DVD-Video discs do not operate as described in this manual due to the intentions of the disc’s producers.
*3: Scratched or stained discs may not be played back.
*4: Some discs cannot be played back because of incompatible recording conditions, characteristics of the

recorder or special properties of discs.
*5: You can play back discs which bear the marks above. If you use nonstandardized discs, this unit may not

play them back. Even if they are played back, the sound or video quality will be compromised.
*6: You may play back the unfinalized DVD-R/RW disc recorded in the video format on our brand’s DVD

recorder. However, depending on the recording status of a disc, the disc may not be played back at all or

normally (the picture or sound may not be smooth, etc.). In this case, you need to finalize the disc with

the DVD recorder. Refer to the manual accompanying the DVD recorder.
*7: Only the discs recorded in the video format and finalized can be played back.

Unfinalized discs cannot be played back. Depending on the recording status of a disc, the disc may not be

played back at all or normally (the picture or sound may not be smooth, etc.).
*8: If there is too much recording space left on a disc (the used portion is less than 55mm across), it may not

play back properly.
*9:

Do not glue paper or put stickers on to the disc. These may damage the disc and the unit may not read it correctly.

*10: The number inside the symbol refers to a region of the world and a disc encoded in a specific region for-

mat can only be played back on unit with the same region code.

:

This label indicates playback compatibility with DVD-RW discs recorded in VR mode (Video Recording Format).

NOTE:

• This player cannot play the DVD-RW that supports CPRM (Contents Protection for Recordable Media).

• This player cannot play the DVD-R discs recorded in VR mode (Video Recording Format).

¡

NEVER play back the following discs. Otherwise, malfunction may result!

DVD-RAM / CD-I / Photo CD / Video CD / DVD with region codes other than 1 or ALL /
DTS-CD / DVD-ROM for personal computers / CD-ROM for personal computers / MP3

¡

On the following disc, the sound MAY NOT be heard.

Super Audio CD
NOTE: Only the sound recorded on the normal CD layer can be delivered.

The sound recorded on the high density Super Audio CD layer cannot be delivered.

¡

Any other discs without compatibility indications

UNPLAYABLE DISCS

–19–

EN

PLAYING A DISC

BASIC PLAYBACK

DVD-V

Getting started

¡Turn on the power of amplifier and any other

components, if necessary.

1 Hit [STANDBY-ON].

¡The power will turn on.

2 Hit [OPEN/CLOSE A] to open disc loading

tray.

3 Place the chosen disc in the tray, with the

label facing up.

4 Hit [PLAY B].

¡The tray will close automatically and playback will

then start from the first chapter or track of the disc.

¡Closing the disc tray manually or by hitting

[OPEN/CLOSE A] also starts playback.

¡If the playback does not start automatically, hit

[PLAY B].

¡When you playback a DVD which features a title

menu, it may appear on the screen. In this case,
refer to “TITLE MENU” on this page.

CD

GENERAL FEATURES

DVD-V

DVD may contain menus to navigate the disc and
access special features. Press the appropriate
Number buttons or [K / L / s / B] to highlight
your selection in the DVD main menu and hit

[ENTER] to confirm.
NOTES:

¡Select DVD mode by hitting [SELECT], then

operate the DVD functions.

¡Unless stated, all operations described are based on

remote control use. Some operations can be carried
out using the menu bar on the TV screen.

DISC MENU

DVD-V

1 Hit [DISC MENU].

¡The DVD main menu will appear.
¡If the feature is not available, symbol may

appear on the TV screen.

¡If disc menu is available on the disc, audio

language, subtitle options, chapters for the title and
other options will appear for selection.

2 Press [K / L / s / B] to select an item and

hit [ENTER] to confirm selection.

TITLE MENU

5 Hit [STOP C] to stop playback.

NOTES:

¡When the DVD mode has been switched to the TV

mode, the DVD mode shuts down first and then the
TV picture and sound appears in about 4 seconds.
Similarly, when [STANDBY-ON] is hit to turn off
in the DVD mode, this mode shuts down first and
then the unit is turned off.

¡A “prohibited icon” may appear at

the top-right on the TV screen
during operation, warning that a
prohibited operation has been
encountered by the DVD or the
disc.

¡With DVDs that use titles for playback program

signals, playback may start from the second title or
it may skip these titles.

¡During the playback of a two layered disc, pictures

may stop for a moment. This happens when the 1st
layer switches to the 2nd layer. This is not a
malfunction.

1 Hit [TITLE].

¡The title menu will appear.
¡If the feature is not available, symbol may

appear on the TV screen.

2 Press [K / L / s / B] to select an item, and

hit [ENTER] to confirm selection.

CALLING UP A MENU SCREEN
DURING PLAYBACK

¡Hit [DISC MENU] to call up the DVD menu.
¡Hit [TITLE] to call up the title menu.

NOTE:

¡Contents of menu and corresponding menu

operations may vary between discs. Refer to the
manual accompanying the disc for details.

–20–

DVD-V

EN

RESUME

DVD-V

1 During playback, hit [STOP C].

¡Resume message will appear on the TV screen.

2 Hit [PLAY B], playback will resume from the

point at which playback was stopped.

¡To cancel resume, hit [STOP C] twice.
¡The resume information stays on even when the

power is turned off.

CD

PAUSE

DVD-V

1 During playback, hit [PAUSE F].

¡Playback will pause and sound will be muted.

2 To continue playback, hit [PLAY B].

CD

STEP BY STEP PLAYBACK

DVD-V

1 During playback, hit [PAUSE F].

¡Playback will pause and sound will be muted.

2 The disc goes forward by one frame each

time [PAUSE

3

To exit step by step playback, hit [PLAY B].

F] is hit.

FAST FORWARD /

FAST REVERSE

DVD-V

1 During playback, press [g] or

[

h ].

¡“ g 1” or “h 1” appears on the screen.

2 To select another speed, repeat step 1 until

your required speed number appears on the
screen.

¡For DVDs, fast forward/reverse search speed is dif-

ferent depending on the disc. Approximate speed is
1(×2), 2(×8), 3(×20), 4(×50) and 5(×100).

¡For Audio CDs approximate speed is 1(×2), 2(×8)

and 3(

×30).

¡

When you press buttons on the front panel, press and

[SEARCH h / g] for a few seconds.

hold

CD

SLOW FORWARD /

SLOW REVERSE

DVD-V

1 During playback, hit [PAUSE F].
2 Press [g] or [h ].

¡“ 1” or “ 1” appears on the screen.

3 To select another speed, repeat step 2 until

your required speed number appears on the
screen.

¡Slow forward or reverse speed varies with the disc.

Approximate speed is 1(1/16), 2(1/8) and 3(1/2).

¡

When you press buttons on the front panel, press and
hold [SEARCH h / g] for a few seconds.

4

To return to normal playback, hit [PLAY B].

ZOOM

DVD-V

The Zoom function allows you to enlarge the video
image and to pan through the enlarged image.

1 Hit [ZOOM] during playback.

¡Playback will continue.

2 Hit [ZOOM] repeatedly to select the required

zoom factor: ZOOM1, ZOOM2, ZOOM3 or
OFF.

3 Press [K / L / s / B] to move the zoomed

picture across the screen.

4 To exit zoom mode, hit [ZOOM] to OFF.

NOTES:

¡Zooming function does not work while disc menu is

shown.

¡Zooming function is not available on some discs.
¡It may take several seconds to slide the zoomed pic-

ture.

¡The picture may be distorted if you operate other

functions repeatedly (ex.
in the zoom mode.

[PAUSE FF] or [h], etc.)

3

To return to normal playback, hit [PLAY B]

.

–21–

EN

SEARCH FUNCTION

TRACK SEARCH

CD

There are three ways to begin playback on an Audio
CD at a specific track.

Using the Number buttons

1 Press the Number buttons to enter the

desired track number.

¡Playback will start at the selected track.
¡For single digit tracks (1-9), press a single number

(eg. track 3, hit [3]).

¡To play track 26, hit [+10], [2], [6].

Using [SEARCH MODE]

1 Hit [SEARCH MODE].

¡The track search display appears.

2 Within 30 seconds, select the desired track

number using the Number buttons.

¡For single digits hit [0] first, if the total track of the

disc is 10 tracks or more.

¡Playback will start at the selected track.

Using [PREV

During playback, hit [NEXT G] to move the next
track. Hit it repeatedly to skip subsequent tracks. Hit
[PREV H ] to go back to beginning of the current
track. Hit it repeatedly to go to the previous tracks.

¡If [PREV H] or [NEXT G] is pressed while

the playback is paused, the playback will be paused
again after skipping to the next track.

NOTE:

¡[PREV H] and [NEXT G] are not operative

when playback is stopped.

H

] or [NEXT

G

]

TITLE / CHAPTER SEARCH

DVD-V

1 Hit [SEARCH MODE] once for the Chapter

search, twice for the Title search during
playback.

_/2

2 Enter the desired chapter/title number using

the Number buttons.

¡Playback will start at the selected chapter or title.
¡Hit [CLEAR] to erase the incorrect input.
¡For single digits hit [0] first, if the total number of

chapter or title of the disc is 10 or more.

TIME SEARCH

DVD-V

1 During playback, hit [SEARCH MODE] three

times (CD: twice) to display the Time Search
on the TV screen.

2 Within 30 seconds, enter a desired disc

time using the Number buttons.

¡Playback will start at the specified time.
¡Hit [CLEAR] to erase the incorrect input.
¡When there is no need to enter a number, “0”

appears automatically. For example, “ 0 : 0 - :
appears in the Time Search display if the total time
of the track or title is less than 10 minutes.

CD

- -

”

MARKER SETUP SCREEN

DVD-V

Use markers to memorize your favorite places on a
disc.

1 Hit [SEARCH MODE] four times (CD: three

times) during playback.

¡The display screen and Markers will appear on the

TV screen.

2 Press [s / B] to select 1, 2, 3, 4, 5, 6, 7, 8, 9,

or 10 and ensure that “
appears in the display.

- - - - :- - :- -

3 When you reach the desired point, hit

[ENTER].

¡The Title or Track and elapsed playing time will

appear in the TV screen.

4 To return to the Marker later, hit [SEARCH

MODE] four times (CD: three times) during
playback and press [
desired marker, then hit [ENTER].

NOTES:

¡Operations which erase all Markers:

– Opening the disc tray.
– Turning off the power.
– Hitting [SELECT].
– Selecting “AC” at step

¡To clear a marker:

– Press [s / B] to select a cursor on to the marker

number and hit

¡You can mark up to 10 points.

[CLEAR].

s / B] to choose the

2 and hitting [ENTER].

5 Press [SEARCH MODE] or [RETURN] to

exit.

CD

”

–22–

EN

SPECIAL PLAYBACK FUNCTION

REPEAT

REPEAT is available only during playback.

REPEAT TITLE / CHAPTER

DVD-V

To activate the repeat function, hit [REPEAT]
during playback.

¡The repeat mode changes as described below every

time you hit the button.

CHAPTER TITLE OFF

(current chapter repeat) (current title repeat)

NOTES:

¡Repeat Title/Chapter is not available with some

scenes.

¡The REPEAT setting will be cleared when moving

to other title or chapter.

REPEAT TRACK

To activate the repeat function, hit [REPEAT]
during playback.

¡The repeat mode changes as described below every

time you hit the button.

TRACK ALL OFF

(current track repeat) (entire disc repeat)

NOTES:

¡Repeat setting will be cleared when moving to

other track.

¡Repeat playback does not function during A-B

repeat playback.

REPEAT A-B

DVD-V

(repeat

CD

(repeat

CD

off)

off)

PROGRAM

CD

You may determine the order in which tracks will play.

1 In the stop mode, hit [MODE].

¡The “PROGRAM” screen will appear.

2 Press [▲ / ▼] to select a track, then hit

[ENTER].

¡Hit [CLEAR] to erase the

most recently entered track.

¡If the entire Program cannot be

displayed at once on a screen,
“G” appears to go to the next

TOTAL

1 3:30
5 5:10
10 4:20
11 3:00
12 3:20
17 4:10
22 2:50

1/4 2/3

1:03:30

page and “H” appears to go
back to the previous page.

3 Repeat step 2 until you have selected all the

tracks you want to play in the program.

4

Hit [PLAY B] to play the programmed tracks.

NOTES:

¡While the program is being played back, hitting

[STOP C] works as follows.

¡Hit [STOP C] once and then [PLAY B] again,

playback will restart from the point where
[STOP C] was hit. (Program continued)

¡Hit [STOP C] twice and then [PLAY B] again,

playback will restart from the track in the usual
way. (Program canceled)

¡Up to 99 tracks can be entered.
¡To erase all tracks in the program at once, select

“ALL CLEAR” at the bottom of the list at step 2.

¡If you like to repeat the current track in the pro-

gram, hit [REPEAT] several times until “
TRACK” appears during playback. If you like to
repeat the entire program hit [REPEAT] several
times until “ ALL” appears during playback.

RANDOM PLAYBACK

1 Hit [REPEAT A-B] at your chosen starting

point.

¡“ A-” appears briefly on the TV screen.

2 Hit [REPEAT A-B] again at your chosen end

point.

¡“ A-B” appears briefly on the TV screen, and

the repeat sequence begins.

3 To exit the sequence, hit [REPEAT A-B].

NOTES:

¡The repeat A-B section can only be set within the

current title (for DVDs) or current track (for Audio
CDs).

¡Repeat A-B is not available with some scenes in

DVD.

¡To cancel the A point which was set, hit [CLEAR].
¡Repeat A-B playback does not function during title,

chapter, track or all repeat playback.

This function shuffles the playing order of tracks
instead of playback in the sequence.

1 In the stop mode, hit [MODE] twice.

¡“RANDOM” screen appears.

RANDOM

CD-DA TOTAL 0:45:55

PLAY

2 Hit [PLAY B] to start random playback.

NOTE:

¡If you like to repeat the current track in the random

selection, hit [REPEAT] several times until “
TRACK” appears during playback. If you like to
repeat the entire random selection hit [REPEAT]
several times until “ ALL” appears during
playback.

–23–

RANDOM PROGRAM

- - no indication - -

CD

EN

CHANGING THE SETTINGS

OFF

SUBTITLE LANGUAGE

DVD-V

The unit allows you to select a language for subtitles
during DVD disc (if available) playback.

1 Hit [SUBTITLE] during playback.

¡The subtitle language will

appear on the display bar at
the top of the TV screen.

2 Hit [SUBTITLE] repeatedly to select your

desired subtitle language.

3 To turn off subtitles, hit [SUBTITLE] repeat-

edly until “OFF” appears.

NOTES:

¡Hitting [SUBTITLE] may not work on some DVDs

with multiple subtitle languages. In this case, set it
on the disc menu. (Operation varies between discs.
Refer to the manual of the disc.)

¡If the desired language is not shown after hitting

[SUBTITLE] several times, the disc does not have
subtitles in that language.

¡When “NOT AVAILABLE”

appears on the TV screen, it
means no subtitle is recorded
on the scene.

¡If you choose a language that has a 3 letter language

code, the code will be displayed every time you
change the Subtitle language setting. If you choose
any other languages, “---” will be displayed instead.
(Refer to page 26.)

1.ENG/6

NOT AVAILABLE

STEREO SOUND MODE

CD

1 Hit [AUDIO] repeatedly during playback to

select between “STEREO”, “L-ch” or “R-ch”.

STEREO

¡

STEREO - both right and left channels are active (stereo)
L-ch - only left channel is active
R-ch - only right channel is active

CAMERA ANGLE

DVD-V

Some DVD discs contain scenes which have been
shot simultaneously from various angles. You can
change the camera angle when the “ ” icon
appears on the screen.

1 Hit [ANGLE] during playback.

¡The selected angle will be dis-

played on the display bar at
the top of the screen.

¡If the “ANGLE ICON” setting is “OFF” in the

“OTHERS” menu, the “ ” icon will not appear.
(Refer to page 28.)

2 Hit [ANGLE] repeatedly to select your

desired angle.

1 / 8

AUDIO LANGUAGE

The unit allows you to select a language during DVD
disc (if multi languages are available) playback.

1 Hit [AUDIO] during playback.

1.ENG Dolby D 3/2.1ch 48k/ 3

2 Hit [AUDIO] repeatedly to select your

desired language.

NOTE:

¡Hitting [AUDIO] may not work on some DVDs

with multiple audio languages (e.g. DVDs which
allow audio language setting on the disc menu).

DVD-V

–24–

BLACK LEVEL SETTING

DVD-V

Adjust the Black Level Settings to make the black
parts of the picture brighter.

1 Hit [MODE] during playback.

2 Hit [ENTER] to switch “ON/OFF”.

ON: Makes the dark parts brighter.
OFF: Shows the original picture as recorded.

(Initial setting)

3 Press [MODE] twice or [RETURN] to exit.

NOTE:

¡

The setting will be saved even if the unit is turned off.

EN

VIRTUAL SURROUND

OFF

DVD-V

CD

You can enjoy surround-sound effect over two speak­ers on this unit.

1 Hit [MODE] twice (CD: once) during play-

back.

2 Hit [ENTER] to set it “1” (Natural effect),“2”

(Emphasized effect) or “OFF”.

3 Hit [MODE] to exit.

¡You can also exit the menu by hitting [RETURN].

NOTE: (for CD play only)

¡Virtual Surround will not be effective if the sound

mode is set to something other than STEREO.

THE ON-SCREEN INFORMATION

You can check the information about the current disc by hitting [DISPLAY].

DVD-V

CD

For DVD-Vs

1 Hit [DISPLAY] during playback to show

current Chapter.

¡The elapsed and remaining

playing time of the current
chapter will be displayed.

2 Hit [DISPLAY] again to show current Title.

¡The elapsed and remaining

playing time of the current
title will be displayed.

3 Hit [DISPLAY] again.

¡The bit rate and the current

repeat setting will be
displayed.

¡If you are playing a dual layered disc, the layer

number will also be displayed (L0: Layer 0 is
playing. L1: Layer 1 is playing).

4 Hit [DISPLAY] again to exit.

9/49 0:00:00 -0:03:30

1/3 0:00:00 - 1:23:45

TL1

For Audio CDs

1 Hit [DISPLAY] during playback to show the

current Track.

¡The elapsed and remaining playing time of the

current track will be
displayed.

2 Hit [DISPLAY] again to show current Total

Track.

¡The elapsed and remaining playing time of the total

track will be displayed.

3 Hit [DISPLAY] again to exit.

NOTE:

¡When you are playing a disc in PROGRAM or

RANDOM mode, “ PROGRAM” (or
RANDOM) will be displayed at step 2.

4/12 0:03:21 - 0:02:15

4/12 0:13:45 - 0:45:40

PROGRAM B

T

T

–25–

EN

CHANGING THE DVD SET UP ITEMS

CUSTOM MENU

DVD-V

You can change the DVD player’s settings.

1 Hit [SETUP] twice in the stop mode so that

the DVD SETUP menu appears.

¡Hit [L] to select “CUSTOM”

then hit [ENTER].

NOTE:

¡If the menu does not appear, hit [PLAY B] first,

then hit

[STOP C]. Make sure the disc is in the stop

mode, then slowly hit [SETUP] twice.

2 Select the desired item.

¡Press [K / L] to select the desired item then hit

[ENTER] to confirm.

Refer to the pages below to set up each item.

SETUP CUSTOM

LANGUAGE
DISPLAY
AUDIO
PARENTAL
OTHERS

A

LANGUAGE SETTING

Follow steps 1to 2in the “CUSTOM MENU” sec­tion above.

3 Press [K / L] to select the desired item then

hit [ENTER].

AUDIO:

Sets the audio language.

SUBTITLE:

Sets the subtitle language.

DISC MENU:

Sets the language for DVD menu.

4 Press [K / L] to select a setting then hit

[ENTER].

¡If “OTHER” is selected on

the “AUDIO”, “SUBTI­TLE” or “DISC MENU”
screen, press four-digit
number to enter the code
for the desired language.
(Refer to the language
code list.)

¡Only the languages sup-

ported by the disc can be
selected.

5 Hit [SETUP] to exit the menu.

NOTES:

¡Language Setting for Audio and Subtitle are not

valid for some discs due to default setting of the
disc. In this case, set them by hitting
[SUBTITLE]. (Refer to page 24.)

¡If you select a language that is not supported by the

disc, subtitle will automatically be set OFF and the
first item of the audio languages will be automati­cally set.

SETUP

QUICK
CUSTOM
INITIALIZE

A

P26 Step

B

P27 Step

C

P27 Step

D

P28 Step

E

P28 Step

SETUP LANGUAGE

AUDIO
SUBTITLE
DISC MENU

SETUP LANGUAGE

AUDIO

ORIGINAL
ENGLISH
FRENCH

SETUP LANGUAGE

SUBTITLE

OFF
ENGLISH
FRENCH

SETUP LANGUAGE

DISC MENU

ENGLISH
FRENCH
SPANISH

ORIGINAL
OFF
ENGLISH

[AUDIO] and

3
3
3
3
3

Language Code

Abkhazian 4748
Afar 4747
Afrikaans 4752
Albanian 6563
Amharic 4759
Arabic 4764
Armenian 5471
Assamese 4765
Aymara 4771
Azerbaijani 4772
Bashkir 4847
Basque 5167
Bengali;Bangla 4860
Bhutani 5072
Bihari 4854
Bislama 4855
Breton 4864
Bulgarian 4853
Burmese 5971
Byelorussian 4851

Cambodian 5759
Catalan 4947
Chinese [CHI] 7254
Corsican 4961
Croatian 5464
Czech 4965
Danish [DAN] 5047
Dutch [DUT] 6058
English [ENG] 5160
Esperanto 5161
Estonian 5166

Faroese 5261
Fiji 5256
Finnish [FIN] 5255
French [FRE] 5264
Frisian 5271
Galician 5358
Georgian 5747
German [GER] 5051
Greek [GRE] 5158
Greenlandic 5758
Guarani 5360
Gujarati 5367
Hausa 5447
Hebrew 5569
Hindi 5455
Hungarian [HUN] 5467

Icelandic [ICE] 5565
Indonesian 5560
Interlingua 5547
Interlingue 5551
Inupiak 5557
Irish [IRI] 5347
Italian [ITA] 5566
Japanese [JPN] 5647
Javanese 5669
Kannada 5760
Kashmiri 5765
Kazakh 5757
Kinyarwanda 6469
Kirghiz 5771
Kirundi 6460
Korean [KOR] 5761
Kurdish 5767

A-B

C-E

F-H

I-K

Language Code

Laothian 5861
Latin 5847
Latvian;Lettish 5868
Lingala 5860
Lithuanian 5866
Macedonian 5957
Malagasy 5953
Malay 5965
Malayalam 5958
Maltese 5966
Maori 5955
Marathi 5964
Moldavian 5961
Mongolian 5960
Nauru 6047
Nepali 6051
Norwegian [NOR] 6061

Occitan 6149
Oriya 6164
Oromo(Afan) 6159
Panjabi 6247
Pashto;Pushto 6265
Persian 5247
Polish 6258
Por tuguese [POR] 6266
Quechua 6367
Rhaeto-Romance 6459
Romanian [RUM] 6461
Russian [RUS] 6467

Samoan 6559
Sangho 6553
Sanskrit 6547
Scots Gaelic 5350
Serbian 6564
Serbo-Croatian 6554
Sesotho 6566
Setswana 6660
Shona 6560
Sindhi 6550
Singhalese 6555
Siswat 6565
Slovak 6557
Slovenian 6558
Somali 6561
Spanish [SPA] 5165
Sundanese 6567
Swahili 6569
Swedish [SWE] 6568

Tagalog 6658
Tajik 6653
Tamil 6647
Tatar 6666
Telugu 6651
Thai 6654
Tibetan 4861
Tigrinya 6655
Tonga 6661
Tsonga 6665
Tu rkish [TUR] 6664
Tu rkmen 6657
Tw i 6669

Ukrainian 6757
Urdu 6764
Uzbek 6772
Vietnamese 6855
Volapuk 6861
Welsh 4971
Wolof 6961
Xhosa 7054
Yiddish 5655
Yo r uba 7161
Zulu 7267

L-N

O-R

S

T

U-Z

If you choose a language that has a 3 letter language
code, the code will be displayed every time you
change the AUDIO or SUBTITLE language setting
above. If you choose any other languages, ‘---’ will
be displayed instead. (3 letter language code is writ­ten in bracket.)

–26–

–26–

EN

EN

B

DISPLAY SETTING

Follow steps 1to 2in the “CUSTOM MENU”
section on page 26.

3 Press [K / L] to select the below items

then hit [ENTER].

TV MODE:

You can change certain aspects of the DVD display
screens and on-screen messages on the TV screen.

¡4:3 LETTER BOX (default):

To show black bars on top
and bottom of the screen.

¡4:3 PAN & SCAN: To show

a full height picture with both sides trimmed.

STILL MODE:

This function allows you to adjust picture resolution
and quality in the still mode.

¡AUTO (default):

Automatically select the best
resolution setting (FRAME
or FIELD) based on the data
characteristics of the pictures.

¡FIELD: Select “FIELD” when the pictures are still

unstable even if “AUTO” is selected.
FIELD stabilizes the pictures, although the picture
quality may become coarse due to the limited
amount of data.

¡FRAME: Select “FRAME” to display relatively

motionless pictures in higher resolution.
FRAME improves the picture quality, although it
may unstabilizethe pictures due to simultaneous
output of two field data.

QUICK

SETUP DISPLAY

TV MODE

AUTO

STILL MODE

SETUP DISPLAY

TV MODE

AUTO

STILL MODE

4:3 LETTER BOX

4:3 LETTER BOX

C

AUDIO SETTINGS

Choose the appropriate Audio settings for your
equipment as it only affects during the playback of
DVD discs.

Follow steps 1to 2in the “CUSTOM MENU”

section on page 26.

3 Press [K / L] to select the below items

then hit [ENTER].

DRC (Dynamic Range
Control):

¡To compress the range of

soft to loud sound.

¡The default setting is “ON”.

DOWN SAMPLING:

¡ON : Output in 48 kHz.

(default)

¡OFF : Output the original

sound.

When playing disc with copyright Protection

¡If you select “OFF”, copyright protection will be

activated and sound will be down sampled at
48kHz.

DOLBY DIGITAL:

QUICK

Set to “BITSTREAM” when
the unit is connected to a
Dolby Digital Decoder.

¡BITSTREAM: Output a Dolby Digital signal

(default)

¡PCM: Convert the Dolby Digital to PCM

(2 channel stereo)

SETUP AUDIO

DRC ON
DOWN SAMPLING
DOLBY DIGITAL BITSTREAM

SETUP AUDIO

DRC ON
DOWN SAMPLING
DOLBY DIGITAL BITSTREAM

SETUP AUDIO

DRC ON
DOWN SAMPLING
DOLBY DIGITAL BITSTREAM

ON

ON

ON

4 Hit [SETUP] to exit the menu.

4 Hit [SETUP] to exit the menu.

QUICK MENU

¡You can select the “TV MODE” or “DOLBY DIGITAL” from the QUICK menu quickly. To access the

QUICK menu, select “QUICK” instead of “CUSTOM” at step 1on page 26.

LANGUAGE SETTING FOR THE ON-SCREEN MENUS

¡You can access the TV SETUP menu by hitting [SETUP] from the DVD mode. Refer to

“MENU LANGUAGE” on page 17 to change the language for the on-screen menus.

–27–

EN

D

PARENTAL CONTROL

Parental Control limits the disc viewing that exceed
your setting (with a password or playback will stop).
This feature allows you to prevent discs with alterna­tive scenes from being played by your children.

PARENTAL LEVEL

Parental Level allows you to set the rating level of
your DVD discs. Playback will stop if the disc’s rat­ings exceed the level you set.

Follow steps 1 to 2 in the “CUSTOM MENU” sec-

tion on page 26.

3 Enter your four-digit password then hit

[ENTER].

SETUP PARENTAL

PASSWORD

Enter current password.

IF YOU FORGET THE PASSWORD

1 Hit the Number buttons [4], [7], [3], [7] at

step 3. Then enter your new password.

¡Password will be cleared and parental level will be

set to “ALL”.

2 Proceed with steps 4 to 6 again.

E

OTHER SETTINGS

Follow steps 1to 2in the “CUSTOM MENU” sec­tion on page 26.

3 Press [K / L] to select the below items,

then hit [ENTER].

SETUP OTHERS

ANGLE ICON
AUTO POWER OFFONON

4 Press [K / L] to select “PARENTAL LEVEL”

then hit [ENTER].

SETUP PARENTAL

PARENTAL LEVEL ALL
PASSWORD CHANGE

5 Press [K / L] to select the desired level

then hit [ENTER].

SETUP PARENTAL

PARENTAL LEVEL
ALL

8
7 [NC-17]
6 [R]

6 Hit [SETUP] to exit the menu.

NOTES:

¡When doing this for the first time, enter any 4 dig-

its. (except for 4737) That number will be used as
the password. (in the event you forget the pass­word, see below)

¡To change the password, press [K / L] to select

“PASSWORD CHANGE” at step 4 then hit

[ENTER]. Enter the four-digit password, then hit
[ENTER].

¡With some DVDs, it may be difficult to find if they

are compatible with parental lock. Be sure to check
if the parental lock function operates in the way
that you have set.

¡Record the password in case you forget it.

CONTROL LEVELS

¡ALL

All parental lock is cancelled.

¡Level 8

DVD software of any grade (adult/general/children)
can be played back.

¡Levels 7 to 2

Only DVD software intended for general use and
children can be played back.

¡Level 1

Only DVD software intended for children can be
played back, with those intended for adult and
general use prohibited.

ANGLE ICON:

¡Hit [ENTER] repeatedly to turn Angle icon “ON”

or “OFF”.

¡The default setting is “ON”.

AUTO POWER OFF:

¡Hit [ENTER] repeatedly to turn Auto Power off

“ON” or “OFF”.

¡The default setting is “ON” and the screen saver

program starts when there is no input from the unit
for 5 minutes in the stop mode. After the screen
saver program is activated for 15 minutes, the
power is automatically turned off.

5 Hit [SETUP] to exit the menu.

INITIALIZE

DVD-V

This allows you to return all selections of SETUP
(except for “PARENTAL” and menu language) to
their default settings.

1 Hit [SETUP] twice in the stop mode so that

the “INITIALIZE” menu appears.

2 Press [K / L] to select “INITIALIZE” then

hit [ENTER].

3 Press [K / L] to select “YES” then hit

[ENTER] twice.

All the settings (except for
“PARENTAL” and menu
language) will be cleared.

¡To cancel the initialization,

select “NO”.

4 Hit [SETUP] to exit the menu.

SETUP

QUICK
CUSTOM
INITIALIZE

SETUP INITIALIZE

Initialize?
NO
YES

–28–

–28–

EN

TROUBLESHOOTING GUIDE

If the unit does not perform properly when operated as instructed in this Owner’s Manual, check the unit, con­sulting the following checklist.

PROBLEM CORRECTIVE ACTION

No power

No operation by infrared remote
control

TV Mode

Sometimes a performance problem can be easily solved by checking seemingly apparent but often overlooked
possibilities. Before arranging for service, check these items. It could save your time and money.

PROBLEM CORRECTIVE ACTION

No picture or sound

No picture or poor picture on the
unit

No sound or poor sound

Bars On Screen

Picture Distorted or Blurred

Picture Rolls Vertically
Lines or Streaks in Picture

No Color

Poor Reception on Some Channels
Ghosts in Picture

Weak Picture

Sound OK, Picture Poor

Make sure the power plug is connected to an AC outlet.

•

Make sure the power is turned on.

•

Check if the power plug is connected to an AC outlet.

•

Check the batteries in the remote control.

•

Aim the remote control directly at the remote sensor. If necessary,

•

remove all the obstacles between the sensor and the remote control.
You have to be within 23 feet of the unit.

•

Check if the correct mode is selected. If not switch the mode by

•

hitting [SELECT], whichever you need.

Make sure the AC cord is connected to an AC outlet.

•

Check antenna connection.

•

Hit [SELECT] to select TV mode.

•

Then try other TV feature.
Let the unit program its tuner memory.

•

Adjust direction or replace antenna.

•

Adjust picture controls.

•

Check for broken pin of the antenna cable.

•

Adjust volume control on remote control or main unit.

•

Hit [MUTE] to restore sound.

•

If outside antenna is being used, check for broken wire.

•

Check for local interference.

•

Try a new channel, if OK, then possible station trouble.

•

If outside antenna is being used, check for broken wire.

•

Try a new channel, if OK, then possible station trouble.

•

If outside antenna is being used, check for broken wire.

•

Check for local interference.

•

Try a new channel, if OK, then possible station trouble.

•

Is antenna connected to jack on the back of the set?

•

If outside antenna is being used, check for broken wire.

•

Adjust “COLOR” control.

•

Try a new channel, if OK, then possible station trouble.

•

Is antenna connected to jack on the back of the set?

•

If outside antenna is being used, check for broken wire.

•

Check for local interference.

•

Try a new channel, if OK, then possible station trouble.

•

Is antenna connected to jack on the back of the set?

•

If outside antenna is being used, check for broken wire.

•

Adjust “CONTRAST” & “BRIGHT” control.

•

Try a new channel, if OK, then possible station trouble.

•

Is antenna connected to jack on the back of the set?

•

If outside antenna is being used, check for broken wire.

•

Check for local interference.

•

Adjust “CONTRAST” & “BRIGHT” control.

•

–29–

EN

PROBLEM CORRECTIVE ACTION

Picture OK, Sound Poor

No operation by infrared Remote
Control

Different color marks on screen

CLOSED CAPTION PROBLEM POSSIBLE REMEDY

Misspelling in captions

Text is not shown in its entirety or

a delay occurs from what is being
said. exceeds that rate, selective editing is used to insure that the captions

Captions scrambled with white
boxes
No captions in a program which

must contain closed caption

Black box in the TV screen

Try a new channel, if OK, then possible station trouble.

•

Check for local interference.

•

Make sure the AC cord is connected to an AC outlet.

•

Check batteries in remote control.

•

Magnetism from nearby appliances and geomagnetism might affect

•

the color of the TV picture. Move the unit away from the appliances,
the unit can repair itself automatically. If you want to repair immedi­ately,

unplug the power cord, then plug it in again 30 minutes later or

so. This automatically resets the unit.

Error committed by the closed captioning production company.

•

Possible in a live broadcast. Not in case of a prerecorded program.

A few seconds of delay is common for live broadcast.

•

Display capacity may not exceed 220 words per minute. If a dialogue-

•

remain up-to-date with the current TV screen dialogue.

Caused by interferences of building, power lines, thunderstorms, etc.

•

The broadcast may use a time compression process to speed up the

•

program. The decoder cannot read the compressed information and
captions will be lost.

You are in TEXT mode. Select a CAPTION mode (“C1”, “C2”) or

•

Caption “OFF”.

–30–

EN

DVD Mode

PROBLEM CORRECTIVE ACTION

No picture

Disc cannot be played

No sound

No DTS audio is output
Distorted picture

Audio or subtitle language
does not match the set up DVD. (This is not a malfunction.)

The camera angle cannot be changed

Audio or subtitle language cannot be
changed language. (This is not a malfunction.)
“Prohibited icon” appears on the
screen, prohibiting an operation (This is not a malfunction.)
CD sound dropout
No CD reproduction
DVD picture dropout
DVD picture freeze
DVD picture in mosaic
No DVD reproduction

Insert a correct video disc that plays on this unit.

•

Hit [SELECT] to select DVD mode, then try other DVD feature.

•

Insert the disc.

•

Clean the disc.

•

Place the disc correctly, with the label side up.

•

Cancel the parental lock or change the control level.

•

Connect the audio cables firmly.

•

Turn the power of the audio component on.

•

Correct the audio output settings.

•

Correct the input settings on the audio component.

•

This unit does not support DTS audio. This is not a malfunction.

•

There are some cases where pictures may be slightly distorted,

•

which are not a sign of a malfunction.

Although pictures may stop for a moment, this is not a malfunction.

•

The selected language is not available for audio or subtitles on the

•

The DVD does not contain sequences recorded from different cam-

•

era angles. (This is not a malfunction.)
The DVD does not contain audio source or subtitles in the selected

•

That operation is prohibited by the unit or the disc.

•

Scratched disc. Replace the disc with an unscratched one.

•

NOTES:

Some functions are not available in specific modes, but this is not a malfunction. Read the description in

•

this Owner’s Manual for details on correct operations.
Playback from a desired track and random playback are not available during program playback.

•

–31–

EN

MAINTENANCE

CABINET CLEANING

Wipe the front panel and other exterior surfaces of

•

the unit with a soft cloth immersed in lukewarm
water and wrung dry.

Never use a solvent or alcohol. Do not spray insec-

•

ticide liquid near the unit. Such chemicals may
cause damage and discoloration to the exposed sur­faces.

SERVICING

Should your unit become inoperative, do not try to

•

correct the problem by yourself. There are no user­serviceable parts inside. Turn off, unplug the power
cord and please call our help line mentioned on
the front page to locate an Authorized Service
Center.

IF THE LASER OPTICAL PICKUP UNIT IS DIRTY

If the unit still does not perform properly when it is operated, while referring to the relevant sections and to

•

“TROUBLESHOOTING GUIDE” in this Owner’s Manual, the laser optical pickup unit may be dirty.
Consult your dealer or an Authorized Service Center for inspection and cleaning of the laser optical pickup
unit.

DISC HANDLING

Handle the discs so that fingerprints and dust do

•

not adhere to the surfaces of the discs.

To clean-off, use a soft cloth.

•

Do not use a hard cloth since this will mar the disc.

•

Wipe the disc in a straight line from center to edge.

•

Never wipe with a circular motion.

•

Do not use detergent or abrasive cleaning agents.

•

Always store the disc in its protective case when it

•

is not used.

–32–

ENEN

SPECIFICATIONS

GENERAL SPECIFICATIONS ELECTRICAL SPECIFICATIONS

TV

Sound output: 2 speakers, 1W, 8 ohm

CRT 13 inch in-line gun,

90˚ deflection tube
Television system : NTSC-M
Closed caption system :§15.119/FCC
Channel coverage:

VHF: 2 ~ 13
UHF: 14 ~ 69
CATV: 2 ~13, A ~ W,

W+1 ~ W+84,

A-5 ~ A-1, 5A
Tuning System: 181 channel

frequency synthesized

tuning system
Channel access: Direct access keyboard,

programmable

scan and up/down

DVD

Product type: DVD Player
Discs: DVD video, Audio CD
Output signal format: NTSC color

OTHER SPECIFICATIONS

Terminals

Antenna input: VHF/UHF/CATV

75 ohm unbalanced (F-type)
Video input: RCA connector [ 1
Audio L/R input: RCA connector [ 2
Headphone: 1/8" stereo (3.5 mm)
Coaxial digital
audio output: One pin jack,

500m Vpp (75 ohm)

Remote control: Digital encoded

infrared light system

Operating
temperature: 5°C to 40°C

(41°F~104°F)

Power requirements: AC 120V, 60Hz
Power consumption
(Maximum): 70W
Picture tube: 13"
Dimensions: H:15-13/16" (402mm)

W:15-3/16" (386mm)

D:14-13/16" (376mm)

Weight: 21.6 lbs. (9.8kg)

Designs and specifications are subject to change without notice.

•

If there is a discrepancy between languages, the default language will be English.

•

–33–

EN

INDICE

■ INDICE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

■ CONTROLES DE OPERACIÓN Y FUNCIONES . . . . . 34

■ PREPARACIÓN PARA LA UTILIZACIÓN . . . . . . . . . . 35

CONEXIONES DE ANTENA/CABLE . . . . . . . . . . . . . . 35

CONEXIÓN A TOMAS DE ENTRADA DELANTERAS 36
CONEXIÓN A UN AMPLIFICADOR ESTÉREO
EQUIPADO CON TOMAS DE ENTRADA DIGITAL

(para DVD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

CONEXIÓN A UN DECODIFICADOR DOLBY DIGITAL

(para DVD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

PARA INSERTAR LAS PILAS . . . . . . . . . . . . . . . . . . . . 36

SECCIÓN DE TV

PARA MIRAR UN PROGRAMA DE TV . . . . . . . . . . . . 37

IDIOMA DEL MENÚ . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

SECCIÓN DE DVD

REPRODUCCIÓN BÁSICA . . . . . . . . . . . . . . . . . . . . . . 38

MENÚ DE DISCO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

REANUDACIÓN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

CONTROLES DE OPERACIÓN Y FUNCIONES

• Consulte la figura 1 de la página 8 para el panel frontal de la unidad

• Consulte la figura 2 de la página 8 para el mando a distancia

• Consulte la figura 3 de la página 9 para la vista posterior

1. Bandeja de carga del disco

2. Toma de entrada VIDEO

Conecte aquí la toma de salida de vídeo de una
videocámara o de una videograbadora.

3. Tomas de entrada AUDIO L/R

Conecte aquí las tomas de salida de audio de una
videocámara o de una videograbadora.

4. Botón STANDBY-ON

Presione para encender y apagar la unidad.

5. Botones VOLUME (VOL.) K / L

Presione para controlar el nivel de volumen del DVD y
el televisor.

6. Botones CHANNEL (CH.) K / L

Utilice para seleccionar canales memorizados.

7. Ventanilla del sensor de mando a distancia

8. Botón C STOP

Detiene la operación del disco.

9. Botón H PREV

Presione una vez para desplazarse a capítulo o pista
anterior.

Botón h SEARCH (Panel frontal)

Mantenga el botón presionado para cambiar la
velocidad de reproducción en retroceso.

10. Botón B PLAY

Inicia la reproducción del contenido del disco.

11. Botón NEXT G

Presione una vez para desplazarse a capítulo o pista
siguiente.

Botón SEARCH h (Panel frontal)

Mantenga el botón presionado para cambiar la
velocidad de reproducción en avance.

12. Botón F PAUSE

Hace una pausa en la reproducción del disco.

13. Botón A OPEN/CLOSE

Presione para insertar un disco en la bandeja o retirarlo
de ella.

14. Toma HEADPHONE

Para conectar auriculares (no suministrados) y escuchar
en privado.

15. Botón PICTURE

Presione para ajustar la imagen.

16. Botones Numéricos
Modo TV:

Presione dos cifras para acceder directamente al canal
deseado.
No olvide presionar
sola cifra.

Botón +100

Presione para seleccionar canales de televisión por
cable cuyo número sea superior a 99.

Modo DVD:

Presione para introducir el número deseado.

Botón +10

Presione para introducir números superiors a 9.

17. Botón SLEEP

Utilise para ajustar el temporizador de dormir.

18. Botón DISPLAY
Modo TV:

Indica el número del canal en la pantalla del televisor.

Modo DVD:

Indica el estado actual en la pantalla del televisor.

19. Botón SETUP

Presione para entrar o salir del menú de configuración
de televisor o DVD.

20. Botón TITLE

Para visualizar el menú de títulos.

21. Botón CLEAR

Para cancelar o borrar un ajuste entrado actualmente.

22. Botón MODE

Presione para llamar la pantalla de la reproducción
programada o la de reproducción aleatoria en el modo
de parada.
Presione para llamar la pantalla de ajuste del nivel del
negro o la pantalla de sonido ambiental durante la
reproducción.

23. Botón SEARCH MODE

Presione para localizar un punto deseado.

24. Botón AUDIO

Presione para seleccionar un modo de sonido o idioma
de audio deseado.

25. Botón SUBTITLE

Presione para seleccionar el idioma de subtítulos
deseado.

[0] antes de elegir un canal de una

–34–

ES

26. Botón REPEAT

Repite la reproducción del disco, título, capítulo o pista
actual.

27. Botón ANGLE

Presione para cambiar el ángulo de la cámara y ver la
secuencia que se está reproduciendo desde un ángulo
diferente (si existe).

28. Botón REPEAT A-B

Repite la reproducción de una sección seleccionada.

29. Botón RETURN

Permite volver a la pantalla anterior en el menú de
configuración.

30. Botón ENTER

Presione para establecer un ajuste.

31. Botones K / L / { / B
Modo TV:

Presione para seleccionar un modo de ajuste en el
menú que aparece en la pantalla del televisor.
Presiónelos también para seleccionar opciones o
establecer ajustes en un menú en particular.

Modo DVD:

Presione para seleccionar un ítem de menú.

32. Botón DISC MENU

Muestra menú del DVD.

33. Botón h

Presione para mover la imagen de DVD en retroceso
rápido en o en cámara lenta en retroceso.

Botón g

Presione para mover en avance rápido o en cámara
lenta.

34. Botón ZOOM

Amplía parte de la imagen reproducida de un DVD.

35. Botón MUTE

Suprime la salida de sonido. Presiónelo de nuevo para
restablecer el sonido.

36. Botón SELECT

Presione para cambiar al modo TV, modo de entrada
externa o modo de DVD.

37. To ma COAXIAL

Conecte solamente a la entrada digital de un
amplificador externo o decodificador (para audio de
DVD solamente).

38. Toma ANT.

Conecte a una antena, sistema de televisión por cable o
sistema de satélite.

39. Cable eléctrico

Conécte a un toma de CA estándar (120 V, /60 Hz).

NOTA:

Antes de conectar el cable eléctrico a una toma de

•

CA, retírelo del gancho para evitar dañarlo.

PREPARACIÓN PARA LA UTILIZACIÓN

CONEXIONES DE ANTENA/CABLE

Consulte la figura 4 de la página 10

ANTENA COMBINADA DE VHF/UHF

La antena combinada de VHF/UHF de 75 ohmios
puede conectarse a la toma ANT.

ANTENAS SEPARADAS DE VHF/UHF

En algunas zonas será necesario utilizar una antena
exterior.

TELEVISIÓN POR CABLE SIN CAJA DE
CONVERTIDOR/DECODIFICADOR

Utilice esta conexión si su sistema de televisión por
cable se conecta directamente a la unidad, sin una
caja de convertidor.

TELEVISIÓN POR CABLE CON CAJA
DE CONVERTIDOR/DECODIFICADOR
O CAJA DE SATÉLITE

Si su compañía de televisión por cable le suministra
una caja de convertidor o si utiliza un sistema de
satélite, podrá utilizar la conexión básica que se
muestra en la ilustración.
La selección de los canales deberá hacerse con la caja
de convertidor o con la caja de satélite. Esto significa
que no es posible cambiar de canal utilizando el
mando a distancia de la unidad.

Nota para el instalador de sistemas CATV

Esta nota tiene la finalidad de llamar la atención
del instalador de sistemas CATV para que tenga
en cuenta el Artículo 820-40 de la NEC, que
proporciona recomendaciones para hacer una
conexión a tierra apropiada y, en particular,
especifica que la tierra del cable debe conectarse
al sistema de puesta a tierra del edificio, tan cerca
del punto de entrada del cable como sea posible.

NOTA:

Antes de enchufar la antena a la toma ANT. de la
unidad, compruebe que la clavija no esté doblada.
Si esta doblada, póngala derecha como se muestra
en la ilustración, y luego conéctela en la toma
ANT. de la unidad.

Clavija doblada

Cable

(Necesita enderezarse)

Clavija

(Clavija derecha)

NOTA:

Para su seguridad y para evitar que se dañe

•

la unidad, desenchufe el cable de antena de la
toma ANT. antes de mover la unidad.

–35–

ES

CONEXIÓN A TOMAS DE

ENTRADA DELANTERAS

Cuando vea un programa grabado en otra fuente
(videograbadora o videocámara), utilice las tomas de
entrada AUDIO/VIDEO de la parte delantera de la
unidad.
Conecte las tomas de salida de audio/vídeo de otra
fuente a las tomas AUDIO L/R y VIDEO de esta
unidad.

Despúes, presione [SELECT] o [CH. K / L] hasta
que aparezca “AUX” en la pantalla.

Consulte la figura 5 de la página 11

NOTA:

Cuando conecte una videograbadora monofónica

•

(otra fuente) a esta unidad, conecte la toma de
salida de audio de la videograbadora monofónica
(otra fuente) a la toma AUDIO L de esta unidad. El
audio saldrá igualmente por los canales izquierdo y
derecho.

CONEXIÓN A UN AMPLIFICADOR

ESTÉREO EQUIPADO CON TOMAS

DE ENTRADA DIGITAL(para DVD)

Utilice un cable digital coaxial de audio (disponible
en el comercio) para hacer las conexiones de audio.
Conexión a un amplificador equipado con tomas de
entrada digital, platina MD o platina DAT.

Consulte la figura 6 de la página 11

NOTAS:

• La fuente de audio de un disco grabado en formato

de sonido envolvente Dolby Digital de 5,1 canales
no se puede grabar como sonido digital mediante
una platina MD o DAT.

• Asegúrese de apagar todos los componentes del

sistema antes de conectar otro componente.

• Consulte los manuales de instrucciones de los

componentes que va a conectar a la unidad.

• Ajuste la función “DOLBY DIGITAL” a “PCM”

para salida de audio en el modo de configuración.
La reproducción en una unidad utilizando ajustes
incorrectos puede generar ruido y distorsión, y
también puede provocar daños a los altavoces.

CONEXIÓN A UN

DECODIFICADOR DOLBY

DIGITAL (para DVD)

Si utiliza esta unidad para reproducir un disco DVD
en un formato de sonido envolvente Dolby Digital de
5,1 canales, la unidad dará salida a un flujo de datos
DOLBY DIGITAL desde su toma COAXIAL. Si
conecta la unidad a un decodificador Dolby Digital,
podrá disfrutar de una tonalidad más convincente y
real, con un sonido envolvente potente y de alta
calidad similar al de los cines.

Utilice cables digitales coaxiales de audio
(disponibles en el comercio) para hacer las
conexiones de audio.

Consulte la figura 7 de la página 12

NOTAS:

Asegúrese de apagar todos los componentes del

•

sistema antes de conectar otro componente.
Consulte los manuales de instrucciones de los

•

componentes que va a conectar a la unidad.
Si conecta un decodificador Dolby Digital, ajuste

•

la función “DOLBY DIGITAL” a “BITSTREAM”
para salida de audio en el modo de configuración.
A menos que se haga la conexión a un

•

decodificador Dolby Digital, ajuste la función
“DOLBY DIGITAL” a “PCM” para salida de
audio en el modo de configuración. La
reproducción en una unidad utilizando ajustes
incorrectos puede generar ruido y distorsión, y
también puede provocar daños a los altavoces.

Fabricado bajo licencia de Dolby
Laboratories. “Dolby” y el símbolo de la
doble D son marcas comerciales de Dolby
Laboratories.

PARA INSERTAR LAS PILAS

1) Abra la cubierta del compartimiento de las pilas
empujando la cubierta del mando a
distancia en el sentido de la flecha.

2) Inserte 2 pilas “AA” en el
compartimiento de las pilas, en el
sentido indicado por las marcas de polaridad (+/-).

3) Vuelva a poner la cubierta.

–36–

ES

SECCIÓN DE TV

PARA MIRAR UN

PROGRAMA DE TV

TV

1 Enchufe el cable eléctrico

Enchufe el cable eléctrico de la unidad en un
tomacorriente de CA del hogar.

NOTA:

Si aparecen números en la esquina de la pantalla,

•

presione [STANDBY-ON] sin desenchufar el cable
eléctrico.

2 Encienda la unidad

Presione [STANDBY-ON] para encender la unidad.

3 Seleccione el número de canal

Presione [CH. K / L] o los botones numéricos para
seleccionar su número de canal deseado.

Nota para el uso de los botones numéricos:

¡Debe colocar un cero antes de los números de

canal de una sola cifra (por ejemplo: 02, 03, 04,
etc.).

¡Cuando seleccione canales de cable de más de 99,

presione primero [+100] y después las dos últimas
cifras. (Ejemplo: para seleccionar el canal 125,
primero presione [+100] y después presione [2] y

[5].)

IDIOMA DEL MENÚ

TV

1 Seleccione “LANGUAGE”

Presione [SETUP].
Presione

2 Seleccione “ENGLISH”, “ESPAÑOL” o

Presione [ENTER] repetidamente para seleccionar
“ENGLISH” = inglés, “ESPAÑOL” o “FRANÇAIS”
= francés.

3 Salga del modo de idioma

Presione [SETUP] para salir del menú.
NOTAS:

•

•

[K / L] para apuntar a “LANGUAGE”.

“FRANÇAIS”

Esta función afecta sólo el idioma en el menú de la
pantalla y no la fuente de audio.

Si por alguna razón, el menú está en francés,
presione [SETUP], presione [K / L] para apuntar
al “LANGAGE [FRANÇAIS]” y presione
[ENTER] repetidamente para seleccionar el
idioma deseado y presione [SETUP].

4 Ajuste el sonido

Presione [VOL. KK/ LL] para ajustar el volumen.
Presione

sonido.
Presione nuevamente para recuperar el nivel de

sonido anterior.

NOTA:

•

[MUTE] para silenciar instantáneamente el

Si presione [CH. K / L] en el modo DVD, puede
cambiar los canales de TV. Incluso si desconecta la
unidad en el modo DVD, cuando vuelva a
conectar, volverá al modo TV.

PARA VER CANALES DE CABLE O
SATELITE

Si la unidad está conectada a una caja de cable o

•

caja de satélite, presione [CH. K / L] para
seleccionar CH3 o CH4 de acuerdo con el ajuste
de canal de salida del dispositivo y seleccione el
canal deseado en el dispositivo.

PARA VER UNA ENTRADA EXTERNA

Cuando se conecta un equipo externo en las tomas

•

de entrada AUDIO/VIDEO frontales, presione
[SELECT] o [CH. K / L] repetidamente hasta que
aparezca “AUX” en la pantalla.

–37–

ES

SECCIÓN DE DVD

REPRODUCCIÓN BÁSICA

DVD-V

Para empezar

¡Conecte la alimentación del amplificador y otros

componentes, si es necesario.

1 Presione [STANDBY-ON].

¡La alimentación se conectará.

2 Presione [OPEN/CLOSE A] para abrir la

bandeja de carga del disco.

3 Ponga el disco deseado en la bandeja, con

la etiqueta hacia arriba.

4 Presione [PLAY B].

¡La bandeja se cerrará automáticamente y la

reproducción comenzará desde el primer capítulo o
pista del disco.

¡La reproducción también empieza cerrando

manualmente la bandeja del disco o presionando
[OPEN/CLOSE AA].

¡Si la reproducción no comienza automáticamente,

presione [PLAY B].

¡Cuando reproduzca un DVD que tenga grabado un

menú de títulos, el menú podrá aparecer en la
pantalla.

CD

MENÚ DE DISCO

DVD-V

1 Presione [DISC MENU].

¡Aparecerá el menú principal de DVD.
¡Si no existe la función, puede aparecer el símbolo

en la pantalla de TV.

¡Si el menú de disco existe en el disco, aparecerán el

idioma de audio, opciones de subtítulo, capítulos para el
título y otras opciones para su selección.

2 Presione [K / L / s / B] para hacer una

selección y presione [ENTER] para
confirmar la selección.

REANUDACIÓN

DVD-V

1 Durante la reproducción, presione

[STOP

C].

¡Aparecerá el mensaje de continuación en la pantalla

de TV.

2 Presione [PLAY B], la reproducción continuará

desde el punto donde se paró la reproducción.

¡Para cancelar la continuación, presione dos veces

[STOP C].

¡La información de continuación permanece activada

incluso cuando apaga el interruptor principal.

CD

5 Presione [STOP C] para detener la

reproducción.

–38–

ES

MEMO

–39–

ES

LIMITED WARRANTY

FUNAI CORP. will repair this MAGNAVOX product, free of charge in the USA in the event of defect in materials
or workmanship as follows:

DURATION:
PARTS:

LABOR: FUNAI CORP. will provide the labor without charge for a period of ninety (90) days from the date

LIMITS AND EXCLUSIONS:

This warranty is extended only to the original retail purchaser. A purchase receipt or other proof of original retail
purchase will be required together with the product to obtain service under this warranty.

This warranty shall not be extended to any other person or transferee.

This warranty is void and of no effect if any serial numbers on the product are altered, replaced, defaced, missing
or if service was attempted by an unauthorized service center. This MAGNAVOX Limited warranty does not apply
to any product not purchased and used in the United States.

This warranty only covers failures due to defects in material or workmanship which occurs during normal use. It
does not cover damage which occurs in shipment, or failures which are caused by repairs, alterations or product not
supplied by FUNAI CORP. or damage which results from accident, misuse, abuse, mishandling, misapplication,
alteration, faulty installation, improper maintenance, commercial use such as hotel, rental or office use of this
product or damage which results from fire, flood, lightning or other acts of God.

THIS WARRANTY DOES NOT COVER PACKING MATERIALS, ANY ACCESSORIES (EXCEPT REMOTE
CONTROL), ANY COSMETIC PARTS, COMPLETE ASSEMBLY PARTS, DEMO OR FLOOR MODELS.

FUNAI CORP. AND ITS REPRESENTATIVES OR AGENTS SHALL IN NO EVENT BE LIABLE FOR ANY
GENERAL, INDIRECT OR CONSEQUENTIAL DAMAGES ARISING OUT OF OR OCCASIONED BY THE
USE OF OR THE INABILITY TO USE THIS PRODUCT. THIS WARRANTY IS MADE IN LIEU OF ALL
OTHER WARRANTIES, EXPRESS OR IMPLIED AND OF ALL OTHER LIABILITIES ON THE PART OF
FUNAI, ALL OTHER WARRANTIES INCLUDING THE WARRANTY OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE, ARE HEREBY DISCLAIMED BY A FUNAI AND ITS
REPRESENTATIVES IN THE UNITED STATES. ALL WARRANTY INSPECTIONS AND REPAIRS MUST BE
PERFORMED BY A FUNAI AUTHORIZED SERVICE CENTER. THIS WARRANTY IS ONLY VALID WHEN
THE UNIT IS CARRIED-IN TO A FUNAI AUTHORIZED SERVICE FACILITY.

FUNAI CORP. will provide parts to replace defective parts without charge for one (1) year from the
date of original retail purchase. Two (2) years for Picture Tube. Certain parts are excluded from this
warranty.

of original retail purchase.

IMPORTANT:

THIS LIMITED WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY HAVE OTHER RIGHTS
THAT VARY FROM STATE TO STATE. IF, AT ANY TIME DURING THE WARRANTY PERIOD, YOU ARE
UNABLE TO OBTAIN SATISFACTION WITH THE REPAIR OF THIS PRODUCT, PLEASE CONTACT FUNAI
CORP.

ATTENTION:

FUNAI CORP. RESERVES THE RIGHT TO MODIFY ANY DESIGN OF THIS PRODUCT
WITHOUT PRIOR NOTICE.

To locate your nearest Funai Authorized Service Center or for general service inquiries, please call
or write to the following:

FUNAI CORPORATION, INC.

SERVICE CENTER

19900 Van Ness Avenue, Torrance, CA 90501

Tel :[phone]

http://www.funai-corp.com

Head Office: 100 North Street, Teterboro, NJ 07608

PLEASE DO NOT SHIP YOUR UNIT TO THE TETERBORO ADDRESS.

Printed in Malaysia 1EMN20317

T8106UG ★★★★★
