PORTABLE CART WARNING
S3126A
SYMBOLE D'AVERTISSEMENT POUR
LES COMPOSANTES
APPAREIL ET MEUBLE A ROULETTES
S3126A

Owner’s Manual

MJ420FG

20 INCH COLOR TELEVISION

FEATURES

MTS/SAP Tuner

Flat Screen Picture Tube

181 Channel Selection- All VHF/UHF channels plus up to 125 cable channels.

PLL Frequency Synthesized Tuning- Provides free and easy channel selection and lets you tune directly to any channel using the channel number buttons on the remote control.

Sleep Timer

Closed Caption Decoder

Auto Shut Off Function- If there is no signal input from the antenna terminal and no user operation for 15 minutes, the TV will turn itself off automatically.

Resume Function- If the power fails or is disconnected while the TV is on, the TV will turn on automatically when the power resumes.

V-CHIP- Enables parents to prevent their children from watching inappropriate material on TV.

Full-FunctionRemote Control

On-ScreenFunction Display

S-VIDEO Input- Allows you to get better picture detail and clarity.

Front AV Input

Rear Audio Input

PRECAUTIONS

Place your TV in a room with adequate ventilation.

Keep your TV set away from sources of direct heat, such as heat registers or direct sunlight.

Do not place your TV on soft surfaces, such as rugs or blankets.

Leave enough room for air to circulate around the bottom, top and back of the set.

The serial number of this product may be found on the back of the TV. No others have the same serial number as yours. You should record the number and other vital information here and retain this book as a permanent record of your purchase to aid identification in case of theft.

Date of Purchase



Dealer Phone No.



Dealer Purchase from



Model No.



Dealer Address



Serial No.



LIMITED WARRANTY PERIOD:

This Limited Warranty begins on the date of purchase of the Covered Product and continues for a period of six months.

WHAT IS COVERED:

Meijer will pay the cost of labor and repair or replacement parts in the event Your Covered Product fails to operate as a result of a mechanical or electrical failure caused by defects in workmanship and/or materials. A mechanical or electrical failure caused by a direct result of a power surge is also covered. Parts will be replaced with those of like kind and quality, and may be new or remanufactured. If the Covered Product cannot be repaired, if the cost of the repair exceeds the original purchase price or if parts are not available due to the age of the Covered Product or discontinued by the manufacturer, the Covered Product will be replaced with a product of similar features.

WHERE YOU ARE COVERED:

Coverage under this Limited Warranty is limited to the United States of America, including the District of Columbia. It does not include any Canadian or U.S. Territories including Guam, Puerto Rico, or U.S. Virgin Islands.

WHAT IS NOT COVERED:

PRODUCTS NOT ORIGINALLY COVERED BY A MANUFACTURER’S WARRANTY;

ITEMS THAT ARE STILL COVERED BY THE MANUFACTURER’S WARRANTY, REGARDLESS OF WHETHER THE MANUFACTURER HONORS SUCH WARRANTY;

PERIODIC CHECKUPS AND/OR PREVENTIVE MAINTENANCE AS DIRECTED BY THE MANUFACTURER EXCEPT AS PROVIDED HEREIN;

INHERENT PRODUCT DEFECTS THAT ARE THE RESPONSIBILITY OF THE MANUFACTURER OR PARTS FAILURE DUE TO A MANUFACTURER’S RECALL;

ANY AND ALL PRE-EXISTINGCONDITIONS THAT OCCUR PRIOR TO THE EFFECTIVE DATE OF THIS LIMITED WARRANTY AND/OR ANY COSTS TO REPAIR ANY PRODUCT SOLD“AS-IS”INCLUDING BUT NOT LIMITED TO FLOOR MODELS, DEMONSTRATION MODELS, ETC;

PARTS OR REPAIRS DUE TO NORMAL WEAR AND TEAR AND ITEMS NORMALLY DESIGNED TO BE PERIODICALLY REPLACED BY THE PURCHASER DURING THE COVERED PRODUCT’S LIFE, INCLUDING BUT NOT LIMITED TO BATTERIES, LIGHT BULBS, ETC.;

DAMAGE FROM ACCIDENT, ABUSE, MISUSE, MISHANDLING, INTRODUCTION OF FOREIGN OBJECTS INTO THE COVERED PRODUCT, UNAUTHORIZED MODIFICATIONS OR ALTERATIONS TO A COVERED PRODUCT, FAILURE TO FOLLOW THE MANUFACTURER’S INSTRUCTIONS, AND EXTERNAL CAUSES INCLUDING THIRD PARTY ACTIONS, FIRE, THEFT, INSECTS, ANIMALS, EXPOSURE TO WEATHER CONDITIONS, WINDSTORM, SAND, DIRT, HAIL, EARTHQUAKE, FLOOD, WATER, ACTS OF GOD OR CONSEQUENTIAL LOSS OF ANY NATURE;

LOSS OR DAMAGE CAUSED BY WAR, INVASION OR ACT OF FOREIGN ENEMY, HOSTILITIES, CIVIL WAR, REBELLION, RIOT, STRIKE, LABOR DISTURBANCE, LOCKOUT, OR CIVIL COMMOTION;

INCIDENTAL, CONSEQUENTIAL OR SECONDARY DAMAGES OR DELAY IN RENDERING SERVICE UNDER THIS LIMITED WARRANTY, OR LOSS OF USE DURING THE PERIOD THAT THE COVERED PRODUCT IS AT AN AUTHORIZED SERVICE CENTER OR OTHERWISE AWAITING PARTS;

ANY PRODUCT USED IN A COMMERCIAL SETTING OR RENTAL BASIS;

FAILURES THAT OCCUR OUTSIDE OF THE 50 STATES OF THE UNITED STATES OF AMERICA, INCLUDING THE DISTRICT OF COLUMBIA;

NONFUNCTIONAL OR AESTHETIC PARTS INCLUDING BUT NOT LIMITED TO PLASTIC PARTS, KNOBS, ROLLERS, BASKETS, SCRATCHES, PEELING AND DENTS;

UNAUTHORIZED REPAIRS AND/OR PARTS;

COST OF INSTALLATION, SET-UP,DIAGNOSTIC CHARGES, REMOVAL OR REINSTALLATION OF THE COVERED PRODUCT, EXCEPT AS PROVIDED HEREIN;

ACCESSORIES USED IN CONJUNCTION WITH A COVERED PRODUCT;

ANY LOSS OTHER THAN A COVERED BREAKDOWN OF THE COVERED PRODUCT;

SERVICE WHERE NO PROBLEM CAN BE FOUND;

BREAKDOWNS WHICH ARE NOT REPORTED WITHIN THE TERM OF THIS LIMITED WARRANTY;

IMPROPER INSTALLATION OF COMPONENTS OR PERIPHERALS;

CORRUPTION OF ANY RECORDING MEDIA, INCLUDING ANY PROGRAM, DATA OR SETUP INFORMATION RESIDENT ON ANY HARD DRIVES AND INTERNAL OR EXTERNAL REMOVABLE STORAGE DEVICES, AS A RESULT OF THE MALFUNCTIONING OR DAMAGE OF AN OPERATING PART, OR AS A RESULT OF ANY REPAIRS OR REPLACEMENT UNDER THIS LIMITED WARRANTY;

DAMAGE TO CLOTHING;

COLOR RADING OF PICTURE FOR ANY TELEVISION;

BURNED-INPHOSPHOR (INCLUDING IMAGE GHOSTING), PIXEL BURNOUT NOT IN ACCORDANCE WITH THE MANUFACTURER’S SPECIFICATIONS.

WHAT TO DO WHEN YOUR PRODUCT FAILS TO OPERATE:

Call the 24-hourcustomer servicetoll-freenumber at (866)845-9436.

Many oversights, which are not covered under this Limited Warranty, can be due to simple circumstances such as the Covered Product not being switched on, being unplugged, or a fuse blown at the junction box. For a Covered Product that uses batteries as the primary power supply, or a remote control unit, please check that the batteries do not need replacing or recharging.

SERVICE DELIVERABLES:

There is no deductible required to obtain service for Your Covered Product.

OTHER PROVISIONS:

Limit of Liability:

The limit of liability under this Limited Warranty is the least of the cost of (1) the purchase price of the Covered Product excluding tax and delivery costs or (2) authorized repairs not to exceed the purchase price of the Covered Product or (3) replacement of the Covered Product with similar features or (4) reimbursement for authorized repairs or replacement. Upon replacement, there is no longer any obligation for the replaced product under this Limited Warranty.

Limitations of Implied Warranty:

All Implied Warranties which may arise under state law, including all Implied Warranties of Merchantability or Fitness for a particular purpose, are limited to the duration of this Warranty and do not cover incidental or consequential damages. Some states do not allow limitations on how long an Implied Warranty lasts or the exclusion of incidental or consequential damages, so the above limitations or exclusions may not apply to You. This Warranty gives You specific legal rights, and You may also have other rights which vary from state to state.

Transferability and Renewals:

This Limited Warranty is not transferable or renewable.

Subrogation:

If We pay for a loss, We may require You to assign Us Your rights of recovery against others. We will not pay for a loss if You impair these rights to recover. Your rights to recover from others may not be waived.

Arbitration:

In the event of a disagreement between You and Us concerning costs, either of us may make a written demand for arbitration. This must be done within sixty (60) days after the day You filed Your claim. Each of us will select an arbitrator. The two arbitrators will select an umpire. Each of us will pay the expenses of the arbitrator We select. The expenses of the umpire will be shared equally. Unless both of us agree otherwise, arbitration will take place in the county and state in which You live. Local rules apply. A majority decision will be binding.

IMPORTANT SAFEGUARDS

WARNING:

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The important note is located on the rear of the cabinet.

1.READ INSTRUCTIONS - All the safety and operating instructions should be read before the appliance is operated.

2.RETAIN INSTRUCTIONS - The safety and operating instructions should be retained for future reference.

3.HEED WARNINGS - All warnings on the appliance and in the operating instructions should be adhered to.

4.FOLLOW INSTRUCTIONS - All operating and use instructions should be followed.

5.CLEANING - Unplug TV from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.

EXCEPTION: A product that is meant for uninterrupted service and, that for some specific reason, such as the possibility of the loss of an authorization code for a CATV converter, is not intended to be unplugged by the user for cleaning or any other purpose, may exclude the reference to unplugging the appliance in the cleaning description otherwise required in item 5.

6.ATTACHMENTS - Do not use attachments not recommended by the TV manufacturer as they may cause hazards.

7.WATER AND MOISTURE - Do not use this TV near water, for example, near a bath tub, wash bowl, kitchen

sink, or laundry tub, in a wet basement, or near a swimming pool, and the like.

8. ACCESSORIES - Do not place this TV on an unstable cart, stand, tripod, bracket, or table. The TV may fall,

causing serious injury to someone, and serious damage to the appliance.

Use only with a cart, stand, tripod, bracket, or table recommended by the

manufacturer, or sold with the TV.

Any mounting of the appliance should follow the manufacturer’s instructions and should use a mounting accessory recommended by the manufacturer. An appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the appliance and cart combination to overturn.

THIS SYMBOL INDICATES THAT DAN-

GEROUS VOLTAGE CONSTITUTING A

RISK OF ELECTRIC SHOCK IS PRE-

SENT WITHIN THIS UNIT.

THIS SYMBOL INDICATES THAT

THERE ARE IMPORTANT OPERATING

AND MAINTENANCE INSTRUCTIONS

IN THE LITERATURE ACCOMPANYING

THE APPLIANCE.

AMEUBLES - Cet appareil ne doit être placé que sur un meuble (avec ou sans roulettes) recommandé par le fabricant. Si vous l’installez sur

un meuble à roulettes, déplacez les deux ensembles avec précaution.

Un arrêt brusque, l’utilisation d’une

force excessive et des surfaces irrégulières risquent de déstabiliser l’ensemble et de le renverser.

9.VENTILATION - Slots and openings in the cabinet and the back or bottom are provided for ventilation and to ensure reliable operation of the TV and to protect it from overheating, these openings must not be blocked or covered. The openings should never be blocked by placing the TV on a bed, sofa, rug, or other similar surface. This TV should never be placed near or over a radiator or heat register. This TV should not be placed in abuilt-ininstallation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions have been adhered to.

10.POWER SOURCES - This TV should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your appliance dealer or local power company. For TVs intended to operate from battery power, or other sources, refer to the operating instructions.

11.GROUNDING OR POLARIZATION - This TV is equipped with a polarized alternating-current line plug(a plug having one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.

12.POWER-CORDPROTECTION- Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, con-

1EMN21784

Printed in Thailand



L3316WS * * * * *

venience receptacles, and the point where they exit from the appliance.

13.OUTDOOR ANTENNA GROUNDING - If an outside antenna or cable system is connected to the TV, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANSI/NFPA No. 70, provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode. (Fig. A)

14.LIGHTNING - For added protection for this TV receiver during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the TV due to lightning andpower-linesurges.

15.POWER LINES - An outside antenna system should not be located in the vicinity of overhead power lines or other electric light of power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

16.OVERLOADING - Do not overload wall outlets and extension cords as this can result in a risk of fire or electric shock.

17.OBJECT AND LIQUID ENTRY - Never push objects of any kind into this TV through openings as they may touch dangerous voltage points or short out parts that could result in a fire or electric shock. Never spill liquid of any kind on the TV.

18.SERVICING - Do not attempt to service this TV yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

19.DAMAGE REQUIRING SERVICE - Unplug this TV from the wall outlet and refer servicing to qualified service personnel under the following conditions:

a.When the power supply cord or plug is damaged or frayed.

b.If liquid has been spilled, or objects have fallen into the TV.

c.If the TV has been exposed to rain or water.

d.If the TV does not operate normally by following the operating instructions. Adjust only those controls that are covered by the operating instructions, as improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the TV to its normal operation.

e.If the TV has been dropped or damaged in any way.

f.When the TV exhibits a distinct change in performance, this indicates a need for service.

20.REPLACEMENT PARTS - When replacement parts are required, be sure the service technician uses replacement parts specified by the manufacturer that have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock, injury to persons or other hazards.

21.SAFETY CHECK - Upon completion of any service or repairs to this TV, ask the service technician to perform routine safety checks to determine that the TV is in proper operating condition.

22.HEAT - This TV product should be situated away from heat sources such as radiators, heat registers, stoves, or other products (including amplifiers) that produce heat.

FIGURE A

EXAMPLE OF ANTENNA GROUNDING AS PER

NATIONAL ELECTRICAL CODE



ANTENNA



LEAD IN



WIRE



GROUND



CLAMP



ANTENNA



DISCHARGE UNIT



(NEC SECTION 810-20)

ELECTRIC



SERVICE



EQUIPMENT





GROUNDING CONDUCTORS



(NEC SECTION 810-21)



GROUND CLAMPS

NEC - NATIONAL ELECTRICAL CODE

POWER SERVICE GROUNDING



ELECTRODE SYSTEM

S 2 8 9 8 A

(NEC ART 250, PART H)

FCC WARNING - This equipment may generate or use radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in the instruction manual. The user could lose the authority to operate this equipment if an unauthorized change or modification is made.

Note to CATV system installer:

This reminder is provided to call the CATV system installer's attention to Article 820-40of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building as close to the point of cable entry as practical.

PREPARATION FOR USE

CONNECTIONS

Plug the incoming cable into the ANT. IN jack on the rear of the TV.

Cable

OR

Antenna

TV signal







Incoming cable from home Antenna /

Cable Company (No Cable Box)

Cable Box or

Satellite Box*

OR

OUT

IN

Rear of this TV

ANT. IN

Incoming cable from Cable

Company or Satellite Antenna

*Note (DO NOT DISCONNECT FROM BOX)

Some cable TV systems use scrambled signals and *Cables not included require a special converter to receive these channels.

Consult your local cable company.

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

ATTENTION: POUR ÉVITER LES CHOC ÉLECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU FOND.

Note:

For your safety and to avoid damages to the unit, unplug the antenna cable from the ANT. IN jack before moving the unit.

[EXTERNAL CONNECTION]

VIDEO1 INPUT (Rear)

ex.

S-VideoCable





(IN)











(OUT)





Rear of this TV











(OUT)

(IN)

L

ANT.IN



AUDIO IN











R

S-VIDEO



Video Cassette Recorder















Audio Cable







Note:

The AUDIO L jack is for mono input. The sound is heard from both speakers. Use this jack for connecting monaural audio equipment.

VIDEO2 INPUT (Front)





ex.

Audio Cable





(IN)







(OUT)





Video Cable

VIDEO L - AUDIO - R



(IN)

(OUT)

Video Camera

Video Game

Front of this TV

Note:

The AUDIO L jack is for mono input. The sound is heard from both speakers. Use this jack for connecting monaural audio equipment.

SELECTING AUDIO/VIDEO INPUT

When you use the AUDIO/VIDEO input jacks, select “VIDEO1” or “VIDEO2” mode by pressing [INPUT SELECT] on the remote control. The input mode changes by pressing the button as following:

INPUT

TV channel

VIDEO1 (Rear)

VIDEO2 (Front)

SELECT















To use the jacks on the rear of the TV, select “VIDEO1”.

To use the jacks on the front of the TV, select “VIDEO2”.

INSTALLING THE BATTERIES



1

2

3

Install two AA batteries (supplied)

matching the polarity indicated inside













battery compartment of the remote con-







trol.

[BATTERY PRECAUTIONS]

Be sure to follow the correct polarity as indicated in the battery compartment. Reversed batteries may cause damage to the device.

Do not mix different types of batteries together (e.g. Alkaline and Carbon-Zinc)or old batteries with fresh ones.

If the device is not to be used for a long period of time, remove the batteries to prevent damage or injury from possible battery leakage.

Do not try to recharge batteries not intended to be recharged; they can overheat and rupture.

OPERATIONS

REMOTE CONTROL AND FRONT PANEL FUNCTION

IR transmitter

To send infrared ray (IR) signal

POWER button

To turn TV on/off

Channel number buttons

Press two digits to directly access the desired channel. Remember to press a "0" before a single digit channel.

CH(ANNEL) K /L buttons

To select channels and move up/down through menu items

MENU button

To view on-screenmenu

POWER



GAME SLEEP







DISPLAY

1

2

3



4

5

6

CHANNEL













RETURN

7

8

9





0

+100

INPUT













SELECT





CH





VOL



VOL





CH









MUTE

MENU







GAME button

Press to set the Game mode

SLEEP button

To set Sleep Timer

DISPLAY button

To display CH No./Audio Status

CHANNEL RETURN button

To return previous screen

INPUT SELECT button

To select TV or external input

MUTE button

To mute sound

VOL(UME) K /L buttons

To adjust volume

To decide the command of settings

Note:

You can test if the remote control sends out the infrared signal with an AM radio. (Refer to “TROUBLESHOOTING GUIDE”.)

VIDEO

L - AUDIO - R

HEADPHONE

MENU

VOLUME

CHANNEL

POWER

Infrared Sensor Window

POWER button

CHANNEL /buttons

VOLUME X/Y buttons

MENU button

HEADPHONE jack

AUDIO L/R input jacks

VIDEO input jack

Note:

If some digits appear in the corner of the screen when the unit is turned on at the first time, press [POWER] without unplugging the power cord.

SLEEP TIMER SETTING

1

SLEEP

SLEEP 0

2

SLEEP repeatedly

SLEEP 10

The time increases by 10 minutes up to 90.

Notes:

When you disconnect the unit from the AC outlet or when you have a power failure, the sleep time will be lost.

To cancel the sleep timer, press [SLEEP] repeatedly until “SLEEP 0” is displayed.

The Sleep Timer Setting display will disappear automatically after 10 seconds of the operation.

NO TV SIGNALS

OPERATIONS (Continued)

MULTI-CHANNELTELEVISION SOUND (MTS)

1



Select “TV SOUND”









Menu









































Selection

MAIN

MONO



SAP*











MENU



















Type of




























broadcast







































-None-

-None-



-None-





















CHANNEL SET





Regular























[ENG] / ESP / FRA

































Stereo

STEREO

MONO



STEREO





















V-CHIPSET UP































broadcast























CAPTION [OFF]



















































































CH







TV SOUND [MAIN]





SAP

MAIN

MAIN



SAP

















































CH

















*Second Audio Program (SAP) :



































Your program can also be received in a sec-



































2

















Select the desired sound











VOL VOL











ond language or sometimes a radio station.















mode.





























































[MAIN]







[MONO]



[SAP]



Note:























If you select [SAP] when second audio is















































not available, the TV will receive normal

































































audio.



















































3 To exit the menu



































































MENU









































































PICTURE ADJUSTMENT

1

Select “PICTURE”











GAME MODE











































Set to the most suitable position for video







MENU














































games.

























































CHANNEL SET

[-] :OFF

[+] : ON



























[ENG] / ESP / FRA



























BRIGHT





























V-CHIPSET UP





















































CAPTION [OFF]

Adjust until the darkest parts of the picture are



























TV SOUND [MAIN]

as bright as you prefer.









VOL





































































[-] :decrease brightness

2 Select an item to adjust











[+] : increase brightness









































CONTRAST









CH

























Adjust to increase or decrease contrast.







CH

























[-] :decrease contrast



[GAME MODE]









[BRIGHT]







[CONTRAST]

[+] : increase contrast

















COLOR























































Adjust to be brilliant or pale color.









































[-] :be pale color

[+] : be brilliant color









































[SHARPNESS]









[TINT]







[COLOR]

TINT



























































Adjust to obtain natural skin tones.

3

Adjust the setting





















[-] :add red

[+] : add green







... +



















SHARPNESS





VOL







































































































Adjust the detail of the picture.







VOL



...



[-]





BRIGHT [+]

[-] :make soft

[+] : make clear



































































































































































[CAPTION MODE (C1, C2)]

CAPTION1 (C1)

displays standard closed captions (what a character is saying).

CAPTION2 (C2)

displays foreign language closed captions (foreign language words showing what a character is saying).

There are three ways of displaying according to programs:

Paint-on mode: Displays input characters on the screen immediately.

Pop-on mode : Once characters are stored in memory, they are displayed all at once.

Roll-up mode : Displays the characters continuously by scrolling (max. 4 lines).

[TEXT MODE (T1, T2)]

TEXT1 (T1) and TEXT2 (T2) display half-screentext by scrolling (such as a channel guide, schedule or announcement).

Notes:

If closed captioning is not broadcast, you cannot receive it and nothing is displayed.

When your TV receives a special effects playback signal (i.e., Search, Slow and Still) from a VCR’s video output channel (CH3 or CH4), the TV may not display the correct caption or text.

Captions and texts may not match the TV voice exactly.

Interference may cause the closed caption system not to function properly.

The caption or text characters will not be displayed while the menu display or functions display is shown.

If a black box appears on the screen, this means that the TV is set to TEXT mode. To clear screen, select CAPTION [C1], [C2] or [OFF].

OPTIONAL SETTINGS

LANGUAGE SELECTION

1 Select [ENG]



2 Select the desired language

MENU



VOL VOL
















CHANNEL SET

[ENG(lish)]

[ESP(añol)]



[ENG] / ESP / FRA



V-CHIPSET UP







CAPTION [OFF]

[FRA(nçais)]

CH

TV SOUND [MAIN]



CH



3 To exit the menu













MENU



Notes:

The display will disappear automatically after 10 seconds unless you press any buttons.

Magnetism from nearby appliances and speakers might affect the color of the TV picture. If this happens, press [POWER] to turn off the TV and turn it on again after about 30 minutes.

GAME MODE

This feature is helpful for playing video games. By pressing [GAME], you can set Game mode (suitable picture setting for games) and TV selects automatically front A/V input.

1 To use video

GAME

games



GAME





Picture: GAME



Input: Front (VIDEO2)

2 To cancel Game mode only

MENU



[-]

GAME MODE [+]

VOL

OFF

ON

Select “PICTURE”

After 10 seconds

VIDEO2





Picture: Customized



Input: Front (VIDEO2)

3To watch another input (TV or Rear Input)

VIDEO1

INPUT

SELECT

repeatedly

Notes:

If you press [GAME] when the TV is off, the TV turns on and will be in Game mode and external input mode automatically.

If you adjust another picture control while in Game mode, this mode will automatically be canceled.

CLOSED CAPTION

You may view specially labeled (cc) TV pro-

2

Select the desired caption mode

grams, movies, news and prerecorded tapes,









etc. with either a dialogue caption or text dis-



VOL VOL





play added to the program.





[OFF]

[C1]

[C2]

1 Select “CAPTION”















MENU














[T2]



[T1]



CHANNEL SET







[ENG] / ESP / FRA

3









V-CHIPSET UP

To exit the menu





CAPTION [OFF]













CH

TV SOUND [MAIN]



MENU















CH











CHANNEL SETTING

You can select available TV channels in your area with this feature.

[AUTO PRESET CHANNELS]

1 Select “CHANNEL SET”

MENU


















CHANNEL SET





CH



[ENG] / ESP / FRA







V-CHIPSET UP

CH



CAPTION [OFF]







TV SOUND [MAIN]

















VOL

2 Select “AUTO PRESET CH”

CH

CH

ADD/DELETE

AUTO PRESET CH

VOL

The tuner scans and memorizes all available channels in your area.

3When the scanning is completed, the lowest memorized channel appears on the TV screen.

Notes:

The TV distinguishes between standard TV channels and cable (CATV) channels.

The TV may recognize TV channels as CATV channels if reception condition is poor. If this happens, check the antenna connections and try steps 2 to3 again when reception conditions are better.

If there is no TV signal input, “NO TV

SIGNALS” will appear on the display after the completion of channel scanning.

[ADDING/DELETING CHANNELS]

1 Select “CHANNEL SET”

MENU




















CHANNEL SET

CH



[ENG] / ESP / FRA

CH



V-CHIPSET UP



CAPTION [OFF]







TV SOUND [MAIN]









VOL

2 Select “ADD/DELETE”

VOL

ADD/DELETE AUTO PRESET CH

3Select the channel you wish within 10 seconds

CH

CH

4 Add or delete the channel

VOL VOL

15

ADD/DELETE

Add: light blue

Delete: light red

Note:

The menu will disappear automatically after about 10 seconds.

L :
S :
V :

OPTIONAL SETTINGS (Continued)

V-CHIPSET UP

This enables parents to prevent their children from watching inappropriate material on TV. The limitation is not available for news,

sports programs, unedited movies on premium cable channels and Emergency Broadcast System signals.

When you try to access to a program which is blocked, “PROTECTED PROGRAM by ...” message appears on the TV screen.

Programming may be rated by the Motion Picture Association of America (MPAA) or according to the Television Parental Guidelines. In order to block any inappropriate programming, set your limits in both MPAA RATING and TV RATING.

1 Select“V-CHIPSET UP”

MENU














CHANNEL SET







[ENG] / ESP / FRA







V-CHIPSET UP







CAPTION [OFF]



CH



TV SOUND [MAIN]



CH







VOL





2 Enter4-digitcode

ACCESS CODE







1

2

3

_ _ _ _







4

5

6



7

8

9



0

If you have not set up your personal access code, enter 0000 (default access code).

3 Select a feature to set up

CH

TV RATING

A





B

CH

MPAA RATING



CHANGE CODE

C





A [TV RATING SET UP]



4

Select a rating

TV-Y

[VIEW]







CH

TV-Y7(

) [VIEW]



TV-G

[VIEW]



CH

TV-PG(

) [VIEW]



TV-14(

)[VIEW]









TV-MA(

)[VIEW]

<Selection> <Rating Category Explanations>

TV-Y :Appropriate for all children

TV-Y7 :Appropriate for children seven

and older

TV-G :General Audience

TV-PG :Parental Guidance suggested

TV-14 :Unsuitable for children under

14

TV-MA :Mature audience only

5-1 * Rating with no sub categories Set to [BLOCK] or [VIEW]



TV-Y

[VIEW]

VOL

TV-Y7(

) [VIEW]

TV-G

[BLOCK]



TV-PG(DLSV)[BLOCK]

TV-14(DLSV)[BLOCK]

TV-MA(DLSV)[BLOCK]

5-2 * Rating with sub categories

VOL

TV-Y







[VIEW]

2 times

TV-Y7

(

)

[VIEW]

TV-G







[VIEW]





TV-PG

(

)

[VIEW]





TV-14

(

)

[VIEW]





TV-MA

(

)

[VIEW]





Sub

categories

Select a rating

TV-PG





[BLOCK]









CH

D





[BLOCK]

CH

L





[BLOCK]

S





[BLOCK]













V





[BLOCK]























VOL

Set to [BLOCK] or [VIEW]

VOL

TV-PG

[BLOCK]



D

[VIEW]



L

[BLOCK]



S

[BLOCK]



V

[BLOCK]







<Selection> <Rating Category Explanations>

TV-Y7

FV : Fantasy Violence

TV-PG /TV-14 /TV-MA :

D : Suggestive Dialog

(TV-PG,TV-14only)

Coarse Language

Sexual Situation

Violence

6 To exit the menu



MENU





B [MPAA RATING SET UP]



4

Select a rating

G

[VIEW]







CH

PG

[VIEW]



PG-13

[VIEW]



CH

R

[VIEW]



NC-17

[VIEW]









X

[VIEW]

5 Set to [BLOCK] or [VIEW]





G

[VIEW]

VOL

repeatedly

PG

[VIEW]

PG-13

[VIEW]





R

[BLOCK]





NC-17

[BLOCK]





X

[BLOCK]









<Selection> <Rating Category Explanations>

G : General Audience

PG : Parental Guidance suggested

PG-13 :Unsuitable for children under

13

• R : Restricted; under 17 requires accompanying parent or adult guardian

NC-17 :No one under 17 admitted

X : Mature audience only

6 To exit the menu

MENU

Notes (for TV RATING and MPAA RATING):

You cannot access the setup menu when the “PROTECTED PROGRAM by ...” message appears. Move to an unblocked channel before you press [MENU].

When you select a rating and set it to [BLOCK], the higher ratings will be blocked automatically. The lower ratings will be available for viewing.

When you set the lowest rating to [VIEW], all other ratings will automatically be available for viewing.

C [CHANGING THE ACCESS CODE]

4 Enter4-digitcode

NEW CODE

1

2

3

[ [ [ [







4

5

6

COMFIRM CODE







7

8

9

_ _ _ _



0

5 To exit the menu

MENU

Notes:

Make sure you enter exactly the same new code in the “CONFIRM CODE” space as one in the “NEW CODE” space. If they are different, the “NEW CODE” space is cleared for redoing.

Your personal access code will be erased and will return to the default (0000) when a power failure occurs or when you turn off the power using a wall switch. If you have forgotten the code, unplug the power cord for 10 seconds to restore the access code to 0000.

TROUBLESHOOTING GUIDE

Sometimes a performance problem can be easily solved by checking seemingly apparent but often overlooked possibilities. Before arranging for service, check these items. It could save your time and money.

QUICK SERVICE CHECK LIST

PROBLEM

Doesn’tControlRemote Work

ScreenOnBars

DistortedPicture

VerticallyRollsPicture

ColorNo

onReceptionPoorSome Channels

PictureWeak

StreaksorLinesin Picture

pictureinGhosts

BlurredPicture

PictureOK,SoundPoor

SoundOK,PicturePoor

SoundorPictureNo

markscolorDifferenton screen































































POSSIBLE REMEDY































Try a new channel, if OK, then possible station trouble.

Is TV plugged in?

Power at outlet?

Is TV’s power on?

Is antenna or cable connected to terminal on the back of the set?

If outside antenna is being used, check for broken wire or loose connection.

Check for local interference.

Turn off the TV and then turn it on after about a minute.

Adjust COLOR control.

Adjust CONTRAST & BRIGHT control.

Check batteries in remote control.

Move the TV away from the nearby appliances which generate a magnetic field.

Turn off using [POWER], then turn it on again 30 minutes later or so.

Check if there is an obstacle between the sensor and the remote control.

Test the signal output.* If OK, then possible remote sensor trouble.

*Additional Remote test

Tune an AM radio to a band with no broadcasting. Press a button on the remote control toward the radio. Sound will be fluttering when you press any key and the radio receives the signal. This means the remote control unit is working.

Closed Caption Problem

Possible Remedy

Misspelled captions are shown.

Spelling errors may pass through uncorrected by the closed caption-



ing production company in a live broadcast.





Text is not shown in its entirety

Captions that are delayed a few seconds behind the actual dialogue

or there is a delay of what is being said.

are common for live broadcasts. Most captioning production compa-



nies can display a dialogue to a maximum of 220 words per minute.



If a dialogue exceeds that rate, selective editing is used to insure that



the captions remain up-to-datewith the current TV screen dialogue.





Captions are scrambled with white boxes

Interference caused by building, power lines, thunderstorms, etc.

on the TV screen.

may cause scrambled or incomplete captions to appear.





No captions are displayed in a program

Broadcasters may a time compression process to the actual pro-

which must contain closed caption.

gram so that additional advertising time can be given. In this case,



captions will be lost since the decoder cannot read the compressed



information.





No captions are displayed when playing a

The videotape may be either an illegal copy or the tape duplicating

prerecorded videotape with closed caption.

company may accidentally have left out the captioning signals dur-



ing the copying process.





The TV screen shows a black box.

You are in TEXT mode. Select CAPTION [C1], [C2] or [OFF].





MAINTENANCE

CABINET CLEANING



PICTURE TUBE CLEANING

Wipe the front panel and other exterior sur-



Wipe the picture tube of the TV with a soft

faces of the TV with a soft cloth immersed



cloth. Before cleaning the picture tube, discon-

in lukewarm water and wrung dry.



nect the power cord.

Never use a solvent or alcohol. Do not spray insecticide liquid near the TV. Such chemicals may cause damage and discoloration to the exposed surfaces.

SUPPLIED ACCESSORIES

Owner’s Manual

Remote control unit

Batteries

(1EMN21784)

(NE122UE)

(“AA” x 2)

SPECIFICATIONS

GENERAL SPECIFICATIONS

Television system:

NTSC-M

Closed Caption

TV Standard



System:

§15.119/FCC

Channel coverage



VHF:

2 ~ 13

UHF:

14 ~ 69

CATV:

2 ~ 13, A ~ W,



W+1 ~ W+84,



A-5~A-1,5A

Tuning System:

181 channel



frequency synthesized



tuning system

Channel access:

Direct access keyboard,



programmable

Terminals

scan and up/down



Antenna input:

VHF/UHF/CATV



75 ohm unbalanced



(F-type)

S-Videoinput:

Mini DIN 4-pinjack

Video input:

RCA connector x 1

Audio input:

RCA connector x 4

(2 (L/R) x Front / 2 (L/R) x Rear)

Headphone:

1/8" stereo (3.5mm)

Stereo Sound System 2 speakers

ELECTRICAL SPECIFICATIONS

Sound output: 1W, 8 ohm x2

OTHER SPECIFICATIONS

Remote control:

Digital encoded

Operating

infrared light system



temperature:

5°C to 40°C



(41°F~104°F)

Power requirements:

AC120V, 60Hz

Power consumption



(Maximum):

74W

Picture tube:

20"

Dimensions:

H : 17-1/8"(435mm)



W: 19-15/16"(506mm)



D : 17-15/16"(455mm)

Weight:

44.1 lbs. (20kg)

•Designs and specifications are subject to change without notice and without our legal obligation.

•If there is a discrepancy between languages, the default language will be English.
