I - Chapter.
Introduction
I - 1. IPDACT Introduction
The IP module (IPDACT) is a device which, when connected to a security
control panel, carries out three basic tasks:
• To send over an IP network the alarm information sent by the panel
to which this is connected.
• To check the connectivity between the control panel and the alarms
reception center.
• In cases where it is not possible to transmit over the IP network, the
IPDACT will stop intercepting the alarms from the panel. At this
point the alarms will be sent over the telephone line.
The IPDACT operates together with the Teldat VisorALARM device, located
in the alarm receiver center. This behaves as an alarm receiver which
receives the alarms through an IP network (instead of the traditional public
switch telephone network) and sends them through a serial port to automation
software in order to be processed. Additionally, this receives monitoring
messages from multiple IPDACT and generates the corresponding alarm in
cases where communication fails with one or more of these. For further
information on how the IP VisorALARM receiver operates, please see
manual Dm 357-I.
I - 1.1. User Scenario
A traditional security scenario consists of a control panel (CP), located in the
client environment and an alarm receiver center (ARC) located in the security
company’s control center. The CP contains a group of sensors which trigger
a series of alarms or events which, when produced, are sent to the ARC to be
processed.
Communication between the above is traditionally carried out over the
telephone line so that both ends can initiate a call to the remote end: the CP in
order to notify events and the ARC for bi-directional tasks (activation,
teleloading and general control).
IPDACT - Introduction
I-1
Doc.Dm373-I
Rev. 2.0
The communication protocol varies depending on the manufacturers who
usually tend to use their own solutions. The IPDACT supports Contact-ID
protocol.
The CP is placed as the first connection element to the PSTN so that it can
prioritize the customer’s telephone line.
Alarm
Control Panel
Public Telephony
Switched Network
Client
Fax
Alarm Receiver
Sur-Gard/Radionics
Automation SW
IBS/ MAS/ MicroKey
Alarm Receiver Center
Figure 1. Traditional security scenario
Within the general user scenario, the IPDACT device is located in the client
area, next to the control panel, intercepting the telephone line. This is
displayed in Figure 2. The arrow in the figure demonstrates the preferred
path to send alarms from the CP; here the telephone line is used as a backup
in case there is a communication malfunction in the IP network.
Client
Alarm
Control Panel
Teldat
C
M I P
router
hecho por M.A. Berrojo
Eth 10 Mbps
Fax
Intenet
Public Telephony
Switched
Network
Teldat
hecho por M.A. Berrojo
C
router
hecho por M.A. Berrojo hecho por M.A. Berrojo
@Teldat
Visor Alarm
Alarm Receiver
Sur-Gard/Radionics
VisorAlarm
Automation SW
IBS/ MAS/ MicroKey
Alarm Receiver Center
Eth 10 Mbps
Figure 2. Teldat VisorALARM and IPDACT operating scenario
From firmware release 2.2 onwards, the IPDACT has a new functionality
incorporated giving rise to a third possible scenario: network backup. In the
previous scenario, where communication fails between the device and the
ARC, the IPDACT hands over the communications to the control panel. With
the new functionality, the IPDACT tries to open communications with a second
device, the backup VisorALARM. Only in cases where there are problems
with this second device does the control panel take over. Meanwhile, even in
this state, the IPDACT continues to try and communicate with the ARC until
one of the VisorALARMs responds.
IPDACT Module - Introduction
I-2
Doc.Dm373-I
Rev.2.0
In UL compliance installations, the IPDACT must have firmware
version 4.0.
Figure 3. Network backup function scenario.
I - 1.2. Operation Mode
The IP Module (IPDACT) connected to the client control panel carries out two
tasks: sending alarms from the panel and monitoring the connection with the
IP receiver. The network backup option has implications in connection
monitoring. The alarms reception center is composed of two VisorALARM
devices, one main and the other backup. The IPDACTs release 2.2 onwards
has had their monitoring procedures modified in order to contemplate the
presence of two devices in the central.
I - 1.2.1. Monitoring
The IPDACT is a device that intercepts the control panel telephone
connection with two aims: firstly to detect when the panel sends an alarm in
order to capture it and retransmit over the connected IP network and secondly
to allow the telephone line to be used at the same time as sending alarms.
The interception of the telephone line takes place ONLY in cases where
connectivity with either of the Teldat VisorALARM devices has been verified.
The IPDACT-VisorALARM connectivity is checked through a traffic monitor
which the IPDACT periodically sends and to which the main Teldat
VisorALARM responds. (Through configuration, the main VisorALARM IP
IPDACT Module - Introduction
I-3
Doc.Dm373-I
Rev.2.0
address is given to the IPDACT and is the primary communication option.
=
The backup VisorALARM IP address is also configured and is used in cases
where the main device fails). If the exchange of messages does not occur
during the configured time, the IPDACT tries to resend. If, after a configurable
number of attempts, a satisfactory response is not received, the connectivity
with the main VisorALARM is presumed lost. At this point the IPDACT tries
to communicate with the backup VisorALARM, to which it will now try and
send the alarms, polls, etc. In cases where communication with this second
device also fails, the telephone line access is returned to the control panel as
if the IPDACT was not present. From this point on, the IPDACT will try to reestablish communications both with the main Teldat VisorALARM and the
backup, communication with the main device taking priority. The moment
communications are reestablished with either of the two ARC devices, the
IPDACT intercepts the telephone line once more.
The supervision traffic is encrypted UDP. The Ethernet frame size does not
exceed 70 bytes. The monitoring interval, the number of retries and time
between retries are all configurable, and are values that must be carefully
considered. Normally the monitoring interval in the control panel is high as
this implies a telephone call. However, in the case of IPDACT, this cost is
irrelevant as it is dealing with traffic which in all likeliness is running over a flat
rate connection. In addition, a high value here is not advisable in cases where
the IPDACT connects to Internet through a router executing NAT, a very
probable situation. This is because traffic coming from the ARC towards the
IPDACT reaches this thanks to the router maintaining the entry in the NAT
table active during a period of time, the entry being refreshed with supervision
traffic. If the supervision interval is greater than the residence time for the
entry in the NAT table, communications from the ARC will not be possible.
There is no rule to say how long an entry in the NAT table must last for. In
cases of the TELDAT devices, this is around 5 minutes. A low value has the
problem that the traffic the VisorALARM must process is high, the same as
the bandwidth requirements. If ARC Internet access is ADSL, you need to
consider that the upstream channel is smaller than the downstream one and
that supervision traffic returned to the IPDACTs is slighter larger than the
incoming.
The incoming traffic to the ARC is:
NTC **528
−
mipsALIVEKEEP
The minimum supervision time can be 1 second and a VisorALARM can have
3000 IPDACTs registered that give an input traffic of 1,58 Mbps. The return
traffic is approximately 6% larger.
The Teldat VisorALARM received monitoring messages from the IPDACTs.
If these are registered, they are assumed alive and an acknowledgement
response is sent to them; if the IPDACTs are not registered, they are ignored.
Periodically the status of all the registered IPDACTs is checked and all those
which have not notified their availability (i.e. those which have not responded
IPDACT Module - Introduction
I-4
Doc.Dm373-I
Rev.2.0
since the last check) an alarm is generated. This is a 350 code alarm from
the Contact-ID protocol (Communication trouble) which is received in SwAut.
In order to prevent the Teldat VisorALARM from sending hundreds or
thousands of communication failure alarms when faced with a situation of
general failure of IP traffic reception, the device itself monitors the network
access through echo ICMP packets (ping) to a known address: if the echo
ICMP packets (ping) towards this address fail then a code 356 alarm is
generated from the Contact-ID protocol (Loss of central polling).
Apart from the above codes, the VisorALARM also generates others related
to network backup. For further information on this, please see manual Dm
298-I “VisorALARM Installation Manual”.
I - 1.2.2. Alarm sending
When the IPDACT has connectivity with the Teldat VisorALARM, the former
intercepts the telephone line and processes all the incoming and outgoing
calls taking place.
The supported alarm sending protocol is Contact-ID. This format sends
alarms through DTMF digits complying with the following format:
AAAA MM QEEE GG CCC S
where AAA is the client number, MM the type of message, Q an event
qualifier, EEE the type of alarm, GG the group or partition number, CCC the
zone number and lastly S is the frame validation digit.
When the panel opens to send an alarm, the IPDACT provides power and
emits the dialing tone. When the control panel dials the alarm center
telephone number, it issues the Contact-ID handshake and receives the alarm
frame. From this point, the IPDACT sends this alarm to the VisorALARM.
The control panel is not given the frame sent acknowledgement (kissoff) until
the said acknowledgement is received from the Teldat VisorALARM. If the
IPDACT does not receive the acknowledgement within 2 seconds, this carries
on resending a configured number of times after which connection with the
Teldat VisorALARM is assumed lost and the control panel sends the alarm
over the telephone line. From this point, the IPDACT tries to re-establish
communication with the VisorALARM as previously described. In cases
where the network backup functionality is operative, a failure in sending an
alarm to the main VisorALARM changes into an attempt to establish
communications with the backup VisorALARM and to send the alarms to this
second device. If this attempt also fails, then the control panel takes over the
process of sending the alarms.
It’s essential that the total time, in which the IPDACT deactivates in
cases where communications fail with both the IP receivers, is
greater than the control panel’s highest retry time.
The IP VisorALARM receiver on receiving an alarm from an IPDACT stores
this in a non-volatile internal memory. When the operation has successfully
IPDACT Module - Introduction
I-5
Doc.Dm373-I
Rev.2.0
finished, it sends the acknowledgement to the IPDACT originating the alarm
so that in turn this is sent to the associated control panel. If the alarm storage
memory cannot store the alarm, no acknowledgement is given.
As regards the SwAut, the Teldat VisorALARM behaves as an alarm receiver
that sends alarms received through a serial port. The Teldat VisorALARM
can emulate a Sur-Gard, an Ademco 685 or a Radionics 6500 receiver. The
serial line parameters are configurable as well as those relative to the
emulated receiver (link-test, receiver and line identifier, start and end frame
characters, etc.)
I - 1.3. Additional features
In order to simplify installation and updating of the registered IPDACTs, the IP
VisorALARM receiver has additional facilities.
To install new IPDACTs, the Teldat VisorALARM possesses configuration
patterns associated to installer passwords. These permit you to automatically
register new IPDACTs in the supported IPDACT list and at the same time
enable the IPDACT to request the necessary configuration for start up. The
device can simultaneously have multiple patterns; the choice of one or other
depends on the installer password used in the IPDACT to request the service.
In order to maintain and update the registered IPDACTs base, the Teldat
VisorALARM has commands available to remotely update one or multiple
configuration parameters used by the IPDACTs.
Additionally, in order to simplify the IP parameters configuration, something
that is not always easy, the IPDACT has a DHCP client program, release 2
onwards, which attempts to automatically obtain all the IP connectivity
information (address, mask and gateway) on startup. To do this, you need to
have a DHCP server in the local network. If the IPDACT does not
automatically obtain the IP address, use the parameters that have been
statically configured, permitting you to make sure that the device operates
even when the said server is down. From release 2.2 onwards, the DHCP
client can be deactivated.
With the aim of adding to point 38.1.5 on UL864, the IPDACT allows trouble
signaling to be sent to a maintenance VisorALARM receiver, which is a
different device from the main and backup VisorALARMs. The IPDACT
does not discriminate between sending to one receiver or another
depending on the type of signal (alarm or trouble), but sends the same
signal to both the operating receiver and to the maintenance receiver. It
is the receiver’s task to filter the signals to be sent to the automation software.
Receivers that can be configured as maintenance are those containing
firmware version 10.5.16 and superior. These receivers are characterized as
they do not execute IPDACTs supervision functions, nor carry out any remote
operations over the IPDACTs, nor do they admit IPDACT registration. These
are repeat alarms coming from the IPDACTs and simply filter the signals,
sending only the required signals to the automation software.
IPDACT Module - Introduction
I-6
Doc.Dm373-I
Rev.2.0
II - Chapter.
IPDACT Description
II - 1. General Description
The figure displayed below, represents the IPDACT hardware.
Figure 4. IPDACT
The hardware version and release is identified through its board number
which is TS-540/X where X is the release number.
The following figure shows the identifier details and how to locate it.
IPDACT Module - Description
II-7
Doc.Dm373-I
Rev. 2.0
Figure 5. Board identification details
The IPDACT basically consists of two elements: the control module and the
telephonic module.
IPDACT Module - Description
II-8
Doc.Dm373-I
Rev. 2.0
Figure 6. IPDACT circuit details.
The device CPU, memory and the LAN (identifiable through the RJ-45
connector) are found in the control module. This manages all the information
procedure and the sending of the information through an IP network over the
LAN.
The telephonic module physically supports the control and contains all the
connection points with the control panel. This manages the entire telephonic
interface with the control panel and the client telephone network (public
telephone network termination point and client phone wiring).
From a configuration / monitoring point of view, the IPDACT possesses LEDs
that permit you to view the status of the various elements, from the P2 jumper
to control various aspects and a telephonic console. This telephonic console
is accessible from the connection to the control panel (TO-AP) and requires
an analog telephone with tone dialing.
The IPDACT has an asynchronous console which permits you to monitor /
configure the device through an asynchronous terminal.
IPDACT Module - Description
II-9
Doc.Dm373-I
Rev. 2.0
II - 2. LEDs
The IPDACT has three groups of LEDs that provide information on the status
of each type. These are displayed in the following figures:
Figure 7. LEDs and pins for a IPDACT
The LED labeled “ON” (LD1 for all the versions and releases) is green and
indicates that the IPDACT is powered.
Line status LED: Next to the relays there is a LED labeled LD6. In green this
indicates that the telephone relays are active i.e. the IPDACT intercepts the
telephone line. In normal working mode, this only occurs when the IPDACT
has connectivity with the configured VisorALARM. The relays also activate
when the telephone console activates (please see section IV.2 for further
information). When the control panel is executing maintenance tasks due to a
bi-directional call, the relays are inactive.
LEDs LD2, LD3, LD4 and LD 5 each have an independent connotation:
• LED A LD2: Supervision information.
ON: a management frame is sent to the VisorALARM (contact or keep-alive).
OFF: a response is received to the sent management frame. If there is no response,
this remains active, indicating the lack of connectivity with the VisorALARM.
• LED B LD3: TO-AP terminal status
ON: the alarms panel telephone line is off hook.
OFF: the alarms panel telephone line is on hook.
IPDACT Module - Description
II-10
Doc.Dm373-I
Rev. 2.0
• LED C LD4: alarm sending to the VisorALARM.
ON: an alarm has been sent to the VisorALARM.
OFF: a response has been received to the sent alarm.
• LED D LD5: a bi-directional call to the alarm panel is in progress.
ON: there is a bi-directional call to the alarm panel. The LED located next to the
relays is off as the alarm panel has directly accessed the telephone line.
OFF: no bi-directional call in progress. The panel is operating normally.
II - 3. Jumper
The bridge labeled P2 operates by short-circuiting both pins through a metallic
element such as a screwdriver or a clip. This permits two tasks:
a) On device startup this permits you to configure the IPDACT with the
default configuration. For further information on how to activate the
default configuration, please see section IV.2.1.1.
b) Access the telephonic console. This permits you to configure / monitor
the IPDACT through a telephone connected to the said IPDACT. For
further information, please see section IV.2.
II - 4. Connection points to the Control Panel and
external
In order to connect the IPDACT to the control panel and to power this, there is
a row of choc blocks. All the connections are limited in power. As can be
seen in the following figure, the connections are grouped in the following
manner:
Figure 8. Connection choc block
Choc block connection to the control panel
IPDACT Module - Description
II-11
Doc.Dm373-I
Rev. 2.0
• TO-AP: terminals proving telephonic connection to the control panel.
This must be connected to the control panel connection which this is
using to access the PSTN.
• FROM-AP: terminals receiving telephonic connection from the control
panel. This must be connected to the control panel connection which this
uses to provide a line to the subscriber numbers.
Choc block connection to the Public Switched Telephone Network
• PSTN: access terminals to the public switched telephone network. This
connection is supervised. In cases where there is a failure, the analog
output activates.
Choc block connection to the client telephone numbers
• PHONE: terminals providing telephonic connection to the telephone
numbers possessed by the client at home or at installations.
Choc block associated to the analog output control
• OUT NC: terminals whose state is normally short-circuited. On activating
the output, these terminals stop being short-circuited. Short circuit is
carried out through an electric-mechanical relay. The technical data for
this can be found in appendix V.3.
• OUT NO: terminals whose state is normal open. On activating the output
these terminals pass to a short circuit state. Short circuit is carried out
through an electric-mechanical relay. The technical data for this can be
found in appendix V. 3.
This output is also related to the input status of the PSTN and LAN and with
the IP connectivity status with the alarms reception center. When there is IP
connectivity, the OUT NO terminals will be in their normal state i.e. open. If
there is a failure in IP connectivity, then these terminals pass to a closed
state.
Choc block associated to an analog input
• INPUT: terminals associated to the input. This input is supervised and
considered inactive when a 1K ohms resistance is detected between its
ends. When an open circuit is detected, the device, which should be
connected to this input, is regarded as having been disconnected i.e. it
has been sabotaged.
In UL compliance installations, this input should not be used and
must be bridged with a 1K resistance.
IPDACT Module - Description
II-12
Doc.Dm373-I
Rev. 2.0
Tamper Chock Blocks
• TAMPER: An additional input connecting to a box tamper which indicates
if the box is open. The input is normally closed.
Choc block power connections
+12/24V: It is possible to power the unit at either 12 or 24 volts. For UL
Listed Installations, the power source is regulated, limited in power and
UL compliant.
• GND: power ground terminal.
II - 5. LAN
The device connects to the LAN through an RJ45 (CN1) connector.
Figure 9. LAN Connector and cable.
Failure detection in the Ethernet interface is indicated by the analog output
activating.
II - 6. Console
An asynchronous console is available for configuration / monitoring tasks.
The IPDACT has a black RJ45 connected labeled CNI for console connection.
Consequently you will need a DB9 to RJ45 converter for the said connection
which is provided by Fire-Lite. The following figures show both the converter
and the connector respectively.
IPDACT Module - Description
II-13
Doc.Dm373-I
Rev. 2.0
Figure 10. DB9-RJ45 converter for the console connection
Figure 11. Console connector details
The access configuration is 9600 8N1 (8 bits, without parity, 1 stop bit).
IPDACT Module - Description
II-14
Doc.Dm373-I
Rev. 2.0
The environment is a simple one orientated to menus. The main menu is
displayed in the following figure.
- Main Menu -
Configuration
a) Generic MIP config
b) Remote Alarm report
c) Quick Install
Monitoring
d) General Info
e) Remote Monitor
f) Events
g) IP Connectivity
z) Exit
option:
IPDACT Module - Description
II-15
Doc.Dm373-I
Rev. 2.0
III - Chapter.
Installation and cabling
III - 1. Installation
The IPDACT device is designed to connect a conventional control panel,
which uses the telephone network to transmit alarms, to an IP network. The
module can be connected to a wide variety of panels although only the panels
given in the list in the appendix V.2 should be used for UL compliant
installations.
The IPDACT is installed in a separate box from the panel.
The box is shown in the following figure:
Figure 12. IPDACT Box.
The placement of the IPDACT within the box is as follows:
IPDACT Module – Installationg and cabling
III-17
Doc.Dm373-I
Rev. 2.0
Figure 13. Box with IPDACT.
The following diagram shows the IPDACT installation within the box:
IPDACT Module – Installationg and cabling
III-18
Doc.Dm373-I
Rev. 2.0
Figure 14. IPDACT installation in the box.
III - 1.1. Assembly Instructions for the IPDACT box
The instructions in order to assemble the IPDACT in its box are as follows:
1. Attach the box to the wall; the maximum distance this can be from
the control panel is 6.1 meters (twenty feet).
2. Remove screws 1, 2, 3 and 4.
3. Place the IPDACT board so orifices A, B, C and D coincide with the
bolts.
4. Insert the four bolts into the orifices and slowly tighten them until the
board is firmly attached to the box.
5. The box has two ground connections (T1 and T2).
6. Connect the T1 earthed ground to the panel earth using an AWG 14
cable.
7. The stamped openings available in the box permit wiring to both
enter and exit the box through conduits. Please remember that in
IPDACT Module – Installationg and cabling
III-19
Doc.Dm373-I
Rev. 2.0
cases of UL listed fire installations (UL864) the conduits must be able
to bear any attempts of mechanical injury.
8. The power cables +12V/+24V and GND, from the TO-AP and
FROM-AP telephone, the OUT-NO and the cable connected to the
box earthed ground (T1) leave through an opening and are fed
through a conduit in order to reach the panel.
9. The PSTN and PHONE telephone wires can also enter through the
opening indicated in point 9, if the said cables come from the panel.
10. The Ethernet cable can also enter through the opening indicated in
point 9 if it comes from the panel. The Ethernet cable must be a
CAT 5.
III - 2. Wiring
III - 2.1. Wiring for UL Listed Fire Installations
III - 2.1.1. Installation scheme
The IP module can be used in UL Listed fire installations provided that any of
the fire panels, listed in the appendix, section V.2, are used and the following
mandatory assembly is carried out:
IPDACT Module – Installationg and cabling
III-20
Doc.Dm373-I
Rev. 2.0
Figure 18. Installing an IP Modem with the fire alarm panels.
The IPDACT box must be placed to one side of the control panel. The conduit
carrying the wires between the IPDACT and the panel must be horizontally
placed.
So that it is unnecessary to supervise the wiring between the IPDACT box and
the Control Panel, the following must be fulfilled:
The circuit connections extended to additional fire alarm control unit
equipment when these wiring connections are intended to be made
within 20 feet (6.1 m) of each other and are enclosed within conduit or
equivalently protected against mechanical injury.
Wiring not connected to the panel, and therefore does not have to be where
the IPDACT and the panel are installed, is supervised. This refers to PSTN
lines and Ethernet.
The electrical installation must comply with the NFPA-72 norm, appropriately
adjusted for each installation.
IPDACT Module – Installationg and cabling
III-21
Doc.Dm373-I
Rev. 2.0
The IPDACT wiring is limited in power. Therefore all the wiring
between the IPDACT box and the panel can be enclosed in the
same metal conduit.
III - 2.1.2. Installation instructions
The following instructions are specific to wiring between the IPDACT and the
Firelite MS-9200UD panel. For any other panel, please consult the
manufacturers’ documentation and instructions.
• Before carrying out any type of operation on the wiring, make sure you
have disconnected all power sources.
• In these installations the IPDACT must be integrated in its box. Connect
the IPDACT box ground to the same ground point where you have
connected the panel ground. This is to prevent current traveling through
grounded circuits. Grounding is essential to avoid unwanted electrostatics
discharges.
Figure 19. Earth ground for the IPDACT and panel boxes.
• Connect the IPDACT power inputs to the panel TB1 connector,
terminals 1 and 2. These terminals can be configured as resettable
or non-resettable power. The latter implies an uninterrupted power
source from the panel and is the one we recommend.
The IPDACT GND terminal is not connected to the box earth ground.
IPDACT Module – Installationg and cabling
III-22
Doc.Dm373-I
Rev. 2.0
Figure 20. Power connection.
Due to FCC requirements, ferrites must be used for power lines.
This is to avoid electromagnetic interferences being conducted to
inside the devices.
Figure 21. Ferrites for power cables.
• The fire panel has two telephone lines in order to send alarm. One is
the main line and the other the backup. The main line, PRI. PHONE
LINE, is connected to the IPDACT TO-AP output. The secondary
line is connected to the client telephone connection.
IPDACT Module – Installationg and cabling
III-23
Doc.Dm373-I
Rev. 2.0
Figure 22. IPDACT-panel MS-9200UD telephone connection.
The following figure shows the connection between the IPDACT and the main
telephone line in greater detail.
Figure 23. IPDACT Connection. Main telephone line.
• Do not connect any telephone connection to the PSTN input. To
prevent the IPDACT from executing any of the anticipated actions
IPDACT Module – Installationg and cabling
III-24
Doc.Dm373-I
Rev. 2.0
when this detects a line supervision failure, configure the IPDACT to
take no actions whatsoever.
The panel’s PRI. PHONE LINE has converted into an IP line. All
alarms sent over the PRI. PHONE LINE are captured and
transmitted over the IP network.
• If the IP line supervision detects connectivity failure, the IPDACT
switches its relays so the PSTN input connects to the TO-AP output
i.e. connects the telephone network to the panel’s PRI. PHONE LINE
input. However given that the PSTN input is not operative, there isn’t
a line. Nor is there a telephone line to the panel’s PRI. PHONE LINE
input. This situation provokes an alarm in the panel, which is then
sent to the central. This is how the panel detects IP connectivity
failure.
• Apart from the IPDACT supervising the IP line, the control panel
must, in order to comply with the UL, have receiver supervision
functionality configured. The IPDACT treats the supervision as an
attempt to send a signal.
• The user installations will have telecommunication devices which
allow the IP module to reach Internet.
For UL Listed Fire Installations, shared on-premises
communications equipment is required to be UL Listed for
Information Technology Equipment.
IPDACT Module – Installationg and cabling
III-25
Doc.Dm373-I
Rev. 2.0
IV - Chapter.
Configuration
IV - 1. Configuration modes
The IPDACT can be configured both locally and remotely.
1. Locally:
a. Telephone console: through a normal analog telephone
connected to the TO-AP labeled choc blocks.
b. Asynchronous console: from a PC with terminal emulated and a
cable for this.
2. Remotely:
a. From the VisorALARM IP receiver: through a register operation
carried out by the IPDACT installer or through ‘update’
commands from the VisorALARM console.
b. From a telnet session: from the IPDACT software release 2, the
remote configuration can also be carried out through a telnet
session to the IPDACT IP address, provided that the said IP
address is available (if this is in the same LAN for example). In
cases of a telnet session, the given interface is identical to the
asynchronous console interface.
c. Through DHCP: this is also from release 2, the parameters for
the IP address, IP mask and gateway can by dynamically
obtained from a DHCP server that is located in the same local
network as the IPDACT. From release 2.2 onwards, the DHCP
client can be disabled.
The following sections will show each of the above methods in more detail.
Accessing the device configuration, both for telephone and serial
port, always requires an access password.
IV - 2. DHCP
DHCP stands for “Dynamic Host Configuration Protocol”. DHCP is an Internet
protocol used to automate the configuration of devices using the TCP/IP
IPDACT Module - Configuration
IV-27
Doc.Dm373-I
Rev. 2.0
protocol stack. DHCP can be used to automatically assign IP addresses and
other TCP/IP configuration parameters such as the network mask and the
default router (or gateway) among others.
In the IPDACT environment, this is used to automatically obtain the IP
communication parameters (IPDACT IP address, network mask and
gateway), simplifying the device installation process.
So this runs correctly, you need to have a DHCP server correctly configured in
the local network where the IPDACT is connected. Normally the access
routers (in ADSL for example) have the possibility to act as a DHCP server,
therefore in these environments, start up is immediate.
The IPDACT functioning mode is as follows: when the device boots up, it tries
to dynamically obtain the IP configuration from any DHCP server which is in
the network. If this is achieved, it activates the said configuration and displays
a message on the console.
Teldat (c)2003
Config file... read
Trying to get DHCP lease...Lease obtained
Address assignment in the DHCP protocol is defined so that this can be
permanent or expire after a certain period of time (configurable in the DHCP
server). If the assignment is permanent, the IPDACT will not renew the
address until the next time it is rebooted. Contrariwise, before the validity of
the address times out, the IPDACT will automatically request the server to
renew the assignment.
If during the first attempt (or during the renewal attempt) the IPDACT cannot
get the IP address from a DHCP server, and with the aim of not leaving the
device without IP connectivity, the device will use the IP parameters which
have been statically configured in the device console and will operate with
these parameters until the next time the IPDACT is restarted. Therefore, if
you need to force to IPDACT to renegotiate an address, you will need to
reboot.
The following message is displayed by the IPDACT on console if it cannot
obtain an assignment through DHCP.
Teldat (c)2003
Config file... read
Trying to get DHCP lease...Lease not obtained.
DHCP server may be down.
Using static IP configuration.
From release 2.2 onwards, the DHCP client can be enabled/disabled. In the
previous releases this was always operating. In the default configuration it is
IPDACT Module - Configuration
IV-28
Doc.Dm373-I
Rev. 2.0
enabled. To enable/disable the client, enter the IPDACT generic
configuration:
-- Generic MIP config --
IP Connectivity
a) DHCP client: OFF
b) IP addr: 192.168.0.202 msk: 255.255.255.0
c) Gateway IP: 192.168.0.250
User Access Control
d) Password: 1234
Miscellaneous
e) Date & time: 01/16/1980 17:37:28
f) Events: PHON RMON CID RALA RCFG
g) PC verifying digit: OFF
z) Exit
option:
In the DHCP client section, you can configure the client as enabled/disabled.
option: a
DHCP client: (0:OFF - 1:ON)
IV - 3. Telephonic Console
In order to use the telephonic console, a normal analog telephone connected
to the choc blocks labeled TO-AP is required. This telephone must be
configured to dial through tones. These choc blocks are used to connect the
IPDACT to the control panel consequently the telephonic console is not
always available and it’s necessary to activate it.
To activate the telephonic console, short circuit the P1 jumper in board
versions up to 4 and P2 in board version 5, for a little more than a second with
some metallic element. You can use a small screwdriver or a simple clip.
During this process the telephone must be on hook. On activating the
console, if the telephone relays are inactive (line status LED off), they activate
(i.e. the LED lights up); if they are already active, they will briefly deactivate to
indicate that the telephonic console is available.
On picking up the phone, you will hear an intermittent tone which requires you
to introduce an access password. In order to introduce the password, you
need to press “**#” (asterisk, asterisk, pad) and the access password. By
default the access password is 24680. If this is correct, you will hear three
IPDACT Module - Configuration
IV-29
Doc.Dm373-I
Rev. 2.0
beeps (the OK signal) and subsequently the telephonic console dialing tone (a
continuous low frequency tone). You have 4 or 5 seconds for this process
after which you return to the initial situation; if the relays are inactive, you also
return to the start. If the password is incorrect, the telephonic console will
automatically deactivate and return to the initial position; if the relays are
inactive then you return to the initial position.
If at any point you hang up the phone, the telephonic console deactivates.
IV - 3.1. Configuration
Configuring the various parameters is carried out through the access and
register writing. A register is used for each parameter to be configured. Each
register is made up of one or various fields. The number of fields and size of
each depends on the type of register. All the fields pertaining to one register
have the same size. In order to access a register, press * and the two digits
corresponding to the register to be configured. After selecting a register you
will hear a simple beep indicating that this register can be configured. From
this point you can configure the first field in the register. Should you select an
invalid register, an error signal is emitted. This consists of a long tone.
The access process for a register can be terminated at any point using the
escape sequence *# (asterisk, pad). In this case an escape signal is emitted
which consists of three short tones.
The available configuration registers are as follows:
Types of register register fields Field size Default value
IPDACT IP address and mask 01 8 (3+1) 192.168.000.100
IPDACT access gateway 02 4 (3+1) 192.168.000.200
Access password for the console 03 2 Variable, max. 16
Remote configuration request 04 1 Variable None
IPDACT Reset 05 1 Variable N/A
IPDACT account number 11 1 (6+1) 000000
Visor Alarm IP address 12 4 (3+1) None
UDP port 13 1 (5+1) 00080
IPDACT message encryption key 14 2 Variable, max. 16
VisorAlarm message encryption
Interval between keep-alive (sec)
Retries after failed keep-alive
Time between retries for sending
key
keep-alives (sec).
15 2 Variable, max. 16
16 1 (5+1) 00010
17 1 (1+1) 3
18 1 (1+1) 3
IPDACT Module - Configuration
characters, these must be
the same.
characters, these must be
the same.
characters, these must be
the same.
IV-30
255.255.255.000
24680
None
None
Doc.Dm373-I
Rev. 2.0
Number of digits for a telephone
sendings (seconds) with the backup
Backup VisorALARM IP address 21 8 (3+1) None
Retries after failed keep-alives with
Time between retries for keep-alive
Action to take when the telephone
Maintenance VisorALARM address 36 4 (3 +1) None
Key to encrypt packets sent to the
configuration automatic request
number.
Retries for sending an alarm 20 1 (1+1) 5
Interval between keep-alives
(seconds) with the backup
VisorALARM
the backup VisorALARM
VisorALARM
DHCP Client activation /
deactivation
Output relay switch time 28 1 (3+1) 0
line fails
maintenance receiver.
Installation key for remote
Use of the checking digits 49 1 (1+1) 1
19 1 (2+1) 09
22 1 (5+1) 00010
23 1 (1+1) 3
24 1 (1+1) 1
27 1 (1+1) 1
29 1 (1+1) 2 (Alarm sending)
37 2 Variable, max. 16
38 2 Variable, max. 16
characters, these must be
equal
characters, these must be
equal
None
None
Through the syntax (n+1) this indicates that n is the number of significant
digits and with +1 this indicates that the last figure is the checking digit
depending on the data. This is done as such to prevent errors when
configuring the device and to reduce the time required for the process. The
passwords are verified through repetition. The checking digit is obtained
through the MIPDATA.exe program in the PC which supplies the data to be
configured. This characteristic enabled and disabled through register 49.
A register’s fields are configured by entering the number of data required and
finally # (pad). If the number of digits is incorrect or the data invalid, an error
signal composed of a long tone is emitted. At this point you must wait to
repeat the value for the said field. If the data is correct an acknowledgement
signal made up of two short tones is emitted and subsequently you move on
to the next field. If this is the last field, all the fields are stored in the
configuration and an OK signal made up of three short beeps is emitted. At
this point, the dialing tone is emitted in order to dial the telephonic console
(continuous low frequency tone).
In some cases it may be necessary to enter A, B, C, D, E or F. These digits
can be obtained through the key sequence * and a number between 1 and 6.
I.e. digit A is obtained through * 1, B through * 2, and so on.
Configuration changes are dynamic, i.e. you do not need to restart the device
to activate the said changes.
IPDACT Module - Configuration
IV-31
Doc.Dm373-I
Rev. 2.0
IV - 3.1.1. Default Configuration
Through a short circuit in the IPDACT P2 jumper during the start up process,
you can configure the IPDACT with the factory settings. This configuration is
displayed in the previous table.
The process for this is as follows: 1) switch off the IPDACT, 2) short circuit
the P2 jumper, 3) switch on the device, 4) maintain the P2 short circuited
during the first burst from LEDs A, B, C and D (they light up and switch off
consecutively) and open it half way through the second burst. If the process
has executed successfully, the IPDACT will display a third burst indicating the
default configuration has been activated.
IV - 3.1.2. Register description
IPDACT IP address and mask
IP address and mask associated to the IPDACT in order to operate in the client’s
local network. From IPDACT software release 2.0 onwards, this parameter is only
necessary in cases where you do not have a DHCP server or as a backup
configuration in cases where the said DHCP server is down.
The register is made up of 8 fields; both the IP address as well as the mask is
composed of 4 numbers between 0 and 255. Each number has a verification digit.
This contains the following
value by default:
192 168 000 100 255 255 255 000
IPDACT access Gateway
IP address associated to the access gateway in the client local network. This
gateway gathers all the traffic from the IPDACT and ensures that it reaches the
next hop to the Teldat VisorALARM. From IPDACT software release 2.0 onwards,
this parameter is only necessary in cases where you do not have a DHCP server
or as a backup configuration in cases where the said DHCP server is down.
The register is made up of 4 fields corresponding to the 4 numbers in the IP
address; this admits values between 0 and 255. Each number has a verification
digit. This contains the following value by default:
192 168 000 200
Access password for the console
Access password for the telephonic console which prevents unauthorized access.
This is also used to verify some operations. This must be entered twice in order to
validate it.
The register is made up of one field with up to 16 digits. The default value is
24680.
The password field cannot be left empty.
IPDACT Module - Configuration
IV-32
Doc.Dm373-I
Rev. 2.0
Remote configuration request
This permits you to prompt the Teldat VisorALARM for the complete configuration
required by the IPDACT in order to function. This register does not require you to
configure any parameters and is limited to simply execute a request. In order to
do this, you require the installer password.
The configuration the IPDACT receives has been configured in the VisorALARM
through a profile. The parameters common to a set of IPDACTs are in the said
profile.
The register mechanism permits you to quickly configure a set of IPDACTs with
common parameters. Only those parameters which uniquely identify an IPDACT
must be configured by the installer: account number, local IP parameters, output
switch and actions to take should the PSTN fail.
The register is composed of one field with up to 16 digits. By default this register
is not configured with a value. Should you enter a value, it is not maintained
between requests. For further information, please see section IV-2.1.3.
IPDACT Reset
Permits you to reset the IPDACT so that some parameters have validity. So that
the operation is effective you need to provide the access password for the
console.
The register is made up of a single field, corresponding to the access password. If
the password is valid, the device will reset; should this be incorrect an error tone
will be emitted followed by the console dialing tone. This register does not store
any data in the IPDACT configuration.
IPDACT account number
Account number identifying the IPDACT to the IP Visor Alarm receiver and the
security company’s automation software. In order to simplify the identification
process, we recommend that the last four figures in this parameter coincide with
the account number assigned to the control panel to which this is designated.
The register is made up of one 6-digit field. The default value is 000000.
Teldat VisorALARM IP address
IP address for the IP VisorALARM receiver which receives both the monitoring
traffic as well as the traffic corresponding to the alarms generated by the control
panel.
The register is made up of 4 fields corresponding to the 4 numbers in the IP
address; this admits values between 0 and 255. Each number has a verification
digit. This contains the following value by default:
000 000 000 000
IPDACT Module - Configuration
IV-33
Doc.Dm373-I
Rev. 2.0
UDP Port
UDP port used to send and receive monitoring, alarms and remote configuration
information. This port must coincide with that programmed in the IP VisorALARM
receiver.
The register is composed of one 5-digit field which admits values within the range
of 00000 to 65535. The field contains a verification digit of the configured number.
Default value is 00080.
A 0 value is not permitted.
IPDACT message encryption key
This key is used to encrypt the messages sent to the Teldat VisorALARM. This
must be entered twice in order to validate it.
The register is composed of one field containing up to 16 DTMF digits. By default
there is no configured value.
VisorALARM message encryption key
The Teldat VisorALARM uses this key to encrypt the messages sent to the
IPDACT. This must be entered twice in order to validate it.
The register is composed of one field containing up to 16 DTMF digits. By default
there is no configured value.
Keep-Alive Interval (sec.) (KEEP_ALIVE_INTERVAL)
Time interval when the IPDACT executes a connectivity test with the Teldat
VisorALARM. For this, a keep-alive frame is sent and a response is expected
from the IP receiver.
The register is made up of one 5-digit field. The interval is expressed in seconds
and admits values between 00000 and 90 seconds. The range of values this
register can take comply with the UL1610 section 62.10. The field contains a
verification digit for the number. Default value is 00010.
Retries after failed keep-alive (KEEP ALIVE RETRIES)
If the IPDACT, on executing the connectivity test with the Teldat VisorALARM,
does not receive a response within the “time-between-send-keep-alive-retries”
seconds, the IPDACT repeats the process of sending the keep-alive frame.
Should there be no response within same time interval, the IPDACT repeats the
process until the number of retries configured in the register has been completed.
The connection with the Teldat VisorALARM is considered down once the
number of configured retries in this register has been executed and subsequently
the control panel can access the telephone network.
The register is made up of one single digit field. This admits values between 1
and 9. Default value is 3.
IPDACT Module - Configuration
IV-34
Doc.Dm373-I
Rev. 2.0
Time between send keep-alive retries (secs) (KEEP_ALIVE_RETRIES_TIME)
Time measured between sending of keep-alive frames when a possible
connectivity problem has been detected with the IP VisorALARM receiver.
The register is made up of one single digit field. This is expressed in seconds and
admits values between 3 and 9.
The field contains a verification digit for the number. Default value is 3.
UL listed installations comply with the following:
KEEP_ALIVE_INTERVAL + KEEP_ALIVE_RETRIES x KEEP_ALIVE_RETRIES_TIME
< 25
Backup Teldat VisorALARM IP address
This is the IP address that the backup VisorALARM IP receiver has, which
receives both monitoring traffic as well as traffic corresponding to the alarms
generated by the control panel in cases where the main VisorALARM fails.
The register is made up of 4 fields, corresponding to the 4 numbers in the IP
address; this admits values between 0 and 255. Each number has a verification
digit for this. Default is:
000 000 000 000
Interval between backup keep-alives (seconds)
Time period where the IPDACT executes a check on connectivity with the backup
Teldat VisorALARM. To do this, the IPDACT sends a keep-alive frame and waits
for a response from the IP receiver.
The register is made up of a 5-digit field. The interval is expressed in seconds and
admits values between 00000 and 90 seconds. The field contains one verification
digit for the number. Default value is 00010.
Retries after failed keep-alives to backup
If the IPDACT, on checking connectivity with the backup Teldat VisorALARM,
does not receive a response to this within “interval-between-retries-to-send-keep-
alives” seconds, the IPDACT repeats the keep-alive sending process. If there is
no response within the same time interval, the sending process is repeated and so
on until the configured number of sending times in this register has been
completed. After this number of configured retries, the connection with the Teldat
VisorALARM is considered down and the control panel subsequently accesses
the telephone network.
The register is made up of one 1-digit field. This admits values between 1 and 9.
Default value is 3.
IPDACT Module - Configuration
IV-35
Doc.Dm373-I
Rev. 2.0
Interval between retries to send keep-alives (seconds) for the backup
Time interval between sending keep-alive frames when a possible connectivity
problem with the backup VisorALARM IP receiver has been detected.
The register consists of one 1-digit field. This is expressed in seconds and admits
values between 3 and 9.
This field contains one verification digit for the number. Default value is 3.
Number of digits for a telephone number
This is the number of digits containing the telephone number which the control
panel must dial to carry out a call. Depending on the country, if there is a
switchboard, etc.
This register is composed of one 2-digit field. Admits values between 1 and 15.
The field contains a verification digit for the number. Default value is 9.
Alarm sending retries (ALARM_RETRIES)
Number of times that the IPDACT sends an alarm to the Teldat VisorALARM to
ensure that this receives the alarm and sends an acknowledgement to the
IPDACT. Connection with the main IP receiver is considered lost once this
number of retries has been completed, in which case the IPDACT is forced into
backup and once again tries to send to the backup receiver. If the IPDACT
doesn’t succeed in communicating with the backup after all the retries have been
executed, the telephone relays switch to allow the control panel to send the alarm
over the telephone line.
The register is made up of one single digit field. This admits values between 5 y
10. The field contains a verification digit for the number. Default value is 5.
It is essential to consider what effect the number of alarm send retries parameter
configured in the panel has. The first attempt from the panel activates alarm send
through the IPDACT. If this fails, the panel does not need to try again in order to
force the IPDACT to send the previous alarm to the backup VisorALARM as the
IPDACT does this automatically. However, the panel is responsible for backup
over the telephone line should there be IP connectivity failure, i.e. the number of
retries must be high enough so once these have been completed with both the
main and backup VisorALARMs, the panel takes over the process of sending the
alarm over the telephone line.
This means that the time between the first and the last attempt by the panel to
send an alarm must be greater than the number of alarm sending retries
programmed in the IPDACT by 2 seconds (time between retries) and moreover
twice, given that the same number of retries are executed with the backup
VisorALARM. The time used in the rest of the operations carried out by the
IPDACT is negligible as this can be counted in milliseconds.
IPDACT Module - Configuration
IV-36
Doc.Dm373-I
Rev. 2.0
DHCP Client activation/deactivation
The DHCP client is a device functionality permitting a DHCP server to assign an IP
address and mask to the Ethernet interface plus an output gateway. The majority
of the ADSL routers have a DHCP server so the IPDACT automatically configures
and can connect to Internet through the router.
The registrar consists of a one-digit field which admits a value of 1 to activate the
client and a value of 0 to deactivate it. The field contains a number verification
digit. By default this is configured to 1 i.e. the client is activated.
Switch time for the output relay
The two output relays in the device (terminals OUT NO) have two complementary
states, i.e. when the first is open the other one is closed. These states show
device connectivity with the IP receiver (VisorALARM) so when the IPDACT loses
connectivity the relay closes (the other stays open) remaining in this state while
connectivity is lost. This behavior can be modified by introducing periodicity in the
status of the relays, i.e. that this remains closed during a programmable period of
time, open for a set time (2 seconds) and returning to the closed state. This
behavior is maintained while there is no connectivity.
Switch time can take values between 0 and 300 seconds. A zero value means
that the relay permanently remains in a closed position provided that the
connectivity state does not change.
Action to execute when a telephone line failure occurs
The IPDACT supervises the telephone line so if a failure is detected, it can carry
out three actions:
• Send an alarm to the VisorALARM (programmed value 2).
• Activate the output relay in the same way as if a communication failure
had been detected (programmed value 1).
• Both of the above actions (programmed value 3).
The possibility of not doing anything at all exists together with the above actions
(programmed value 0).
In UL listed fire installations, this value must be programmed to 0.
Maintenance VisorALARM address
Apart from the main VisorALARMs and the backups, you can send trouble alarms
(300-388 CONTACT-ID group) to a third VisorALARM known as maintenance.
This device does not have IP module registers, nor monitors its status and does
not have backup. The main VisorALARMs and the backups execute those
functions. The maintenance device only receives trouble alarms and resends
them to the automation software.
IPDACT Module - Configuration
IV-37
Doc.Dm373-I
Rev. 2.0
The register is made up of four fields corresponding to the 4 numbers of the IP
address; this admits values between 0 and 255. Each number has a verification
digit. The default value is:
000 000 000 000
Alarm encryption key for the IPDACT to the maintenance receiver
This is the key used by the IPDACT to send alarms to the Teldat maintenance
VisorALARM. So the configuration is valid, this must be repeated twice.
The registrar consists of one field with up to 16 DTMF digits. By default, no value
is configured.
Installation key for remote configuration automatic request
This key is used to encrypt the remote configuration request packet. This manner
of request is automatic, e.g., the IPDACT sends a request packet until a remote
configuration was received from the VisorALARM+.
In the case of the installation key was empty the automatic request process will be
terminated, if existed.
The register is composed of one field containing up to 16 DTMF digits. By default
there is no configured value.
Using the testing digits
In order to increase the reliability of the telephonic console, some registers require
an additional testing digit in each of their fields so that if the control digit does not
adjust to the introduced value, the data is considered invalid and an error tone is
emitted. This facility can be enabled or disabled through this register.
The register is made up of a single digit field which admits a value of 1 to activate
the use of the testing digits and value 0 to deactivate. The fields contain a
verification digit for the number. Default value is 0.
IV - 3.1.3. Minimum configuration for the installer
By using the configuration patterns in the Teldat VisorALARM, you can
simplify the IPDACT installation process. So that the whole of the process is
possible, it is essential that there is a configuration pattern configured in the
VisorALARM. In the pattern, an installer password is associated to a given
IPDACT configuration. This configuration includes the passwords through
which information is exchanged between the IPDACT and the VisorALARM,
monitoring time, etc.
The minimum configuration for an IPDACT which permits an installer to use
this installation mechanism is as follows:
a) If you do not have a DHCP server
Type of register Register
IPDACT Module - Configuration
IV-38
Doc.Dm373-I
Rev. 2.0
IPDACT IP address and mask 01
IPDACT access gateway 02
IPDACT account number 11
Main VisorAlarm IP address 12
Backup VisorAlarm IP Address 21
UDP Port 13
b) If you have a DHCP server
Type of register Register
IPDACT account number 11
Main VisorAlarm IP address 12
Backup VisorAlarm IP Address 21
UDP Port 13
After configuring these parameters and restarting the device, the installer
must re-access the telephonic console as previously described and access
register 04. Here the installer password configured in the VisorALARM must
be configured. If the IPDACT has IP connectivity with the VisorALARM and
the password is correct, the IPDACT will receive the configuration defined in
the profile configured in the VisorALARM.
Through this mechanism, the installed IPDACT is registered in the Teldat
VisorALARM which from this point begins to monitor the former and the
IPDACT receives the necessary configuration in order to exchange
information with the Teldat VisorALARM.
If the whole process has gone smoothly, the IPDACT will begin to exchange
monitoring messages with the VisorALARM and from this point onwards the
IPDACT telephone relays activate (the line status LED lights up).
IV - 3.1.4. Configuration Example
In cases of configuring the IPDACT with the following data:
IP address: 192.168.1.100, mask 255.255.255.0
Access GW: 192.168.1.20
IPDACT account number: 1234
Main VisorAlarm IP: 10.24.6.1
Backup VisorAlarm IP: 80.6.189.123
UDP port: 3000
The registers and the data are, in cases where the testing digit is disabled
(through register 49):
IPDACT Module - Configuration
IV-39
Doc.Dm373-I
Rev. 2.0
IP Address del IPDACT *01 192# 168# 001# 100# 255# 255# 255# 000#
Gateway *02 192# 168# 001# 020#
CID *11 001234#
IP VisorAlarm principal *12 010# 024# 006# 001#
IP VisorAlarm backup *21 080# 036# 189# 123#
UDP Port *13 03000#
And in cases where the testing digit is enabled:
IP Address del IPDACT *01
1928#1684#0018#1008#2550#2550#2550#0005#
Gateway *02 1928#1684#0018#0206#
CID *11 001234#
IP VisorAlarm principal *12 010#024#006#001#
IP VisorAlarm backup *21 0808#0368#1894#1238#
UDP Port *13 03000#
IPDACT Module - Configuration
IV-40
Doc.Dm373-I
Rev. 2.0
IV - 4. Asynchronous Console
You have the same access from the telephonic console as from the
asynchronous console which also provides a better display of the processes
taking place in the IPDACT. The console is orientated to menus whose
options permit the monitoring and configuration of the various IPDACT
parameters. The asynchronous console access parameters are 9600 bps, 8
bits, without parity, 1 stop bit. The console is password protected.
IV - 4.1. Accessing the console
The asynchronous console is protected by a user password. This password is
the same as that configured in the telephonic console register 03. This is
24680 by default. Entering the valid password accesses the main menu.
Password:
IV - 4.2. Main Menu
This provides access to the configuration and monitoring menus. If you select
an invalid option, the main menu is displayed once more. When configuring
an option, if you press the ESC key, the operation is aborted and the
parameter does not change. If you press INTRO in the parameters being
handled as character strings, these are deleted. The z options releases the
asynchronous console and requests the access password as described in the
above section.
- Main Menu -
Configuration
a) Generic MIP config
b) Transmission Parameters
c) Quick Install
Monitoring
d) General Info
e) Remote Monitor
f) Events
g) IP Connectivity
z) Exit
option:
IPDACT Module - Configuration
IV-41
Doc.Dm373-I
Rev. 2.0
IV - 4.3. IPDACT generic configuration
Configures data pertaining to the IPDACT which is not related to the
monitoring function and the sending of alarms. Data included here is the
IPDACT IP address, the access gateway to the Teldat VisorALARM, the
console access password, the events you wish to view, use of the check digit
in the telephone console, etc.
In the following figure, the default values are displayed. Press z to return to
the previous menu.
-- Generic MIP config --
IP Connectivity
a) DHCP client: OFF
b) IP addr: 192.168.0.100 msk: 255.255.255.0
c) Gateway IP: 192.168.0.200
User Access Control
d) Password: 24680
Miscellaneous
e) Date & time: 06/16/2003 12:41:25
f) Events: PHON
g) PC verifying digit: 0
z) Exit
option:
IV - 4.4. Monitoring configuration and sending of alarms
Configures everything relative to the IPDACT as a security element. Permits
you to configure the account number associated to the IPDACT, the Teldat
VisorALARM IP address and the UDP port used for communication, the
passwords used to encrypt the IPDACT messages (local password) and that
used to decrypt the Teldat VisorALARM messages (remote password), the
interval used to send the monitoring messages (keep-alive) and the number of
retries and the time between these in cases where the Teldat VisorALARM
does not acknowledge them. Lastly this also permits you to configure the
number of digits a telephone number has, the number of times an alarm is
sent to the Teldat VisorALARM until this can be sent over the telephone line.
The following figure displays the default values. Press z to return to the
previous menu.
IPDACT Module - Configuration
IV-42
Doc.Dm373-I
Rev. 2.0
-- Alarm Report --
Supervisory VisorALARM
Main
a) Remote IP addr: 80.26.96.183
Backup
b) Remote IP addr: 80.36.189.123
Maintenance VisorALARM
c) Remote IP addr: 172.24.51.32
Common Params
d) Account Number: 9005
e) Port: 1222
f) Local Password: 1234567890
g) Remote Password: 0987654321
VisorAlarm Main Keep-Alive
h) Timer: 60
i) Retries: 3 Timer 3
VisorAlarm backup Keep-Alive
j) Timer: 3
k) Retries: 3 Timer 3
Remote Alarm
l) Telephone len: 3
m) Tx retries: 5
Output
n)Output Switching Period: 20
PSTN Survaillance
o)Action due to Alarm: BOTH
z) Exit
option:
IV - 4.5. IPDACT Quick Configuration
This allows an installer to completely configure an IPDACT from a single
menu. This includes all the parameters described in section IV.2.1.3.
Additionally, this also permits you to reset the device, execute the device
register in the configured Teldat VisorALARM and trigger the automatic
device register.
The IPDACT registration process (option i) in the Quick Menu) implies
registering the device in the VisorALARM . The result of the register
operation is dumped in the console. If the process has successfully
IPDACT Module - Configuration
IV-43
Doc.Dm373-I
Rev. 2.0
completed, an OK will appear on the console. If however there has been as
error, this could be either:
q “VA unreachable”: It has not been possible to send the register
command over the IP network.
q “No answer”: The register command has been sent but a response
has not been received from the VisorALARM.
q “Error on answer”: The answer from the VisorALARM for the register
command is wrong.
The automatic device register consist on the attempts of the IPDACT to
register in the VisorALARM without the operation from the console. When the
option k) is chosen form the Quick Menu the IPDACT triggers a process in
which the IPDACT attempts to register until a response from the VisorALARM
is received.
During the automatic register none message is dumped in the console. The
way to know the status of the automatic register is by checking the LED_A.
This LED is blinking while the IPDACT does not received the response from
the VisorALARM and will turn off when the register took place.
The following figure displays the default values. Press z to return to the
previous menu.
-- Quick Install - a) DHCP client: ON
b) IP addr: 192.168.0.100 mask: 255.255.255.0
c) Gateway IP: 192.168.0.200
d) Account Number: 0
e) Supervisory Main:
f) Supervisory Backup:
g) Maintenance:
h) Port: 80
i) Register MIP
j) Reset
k) AutoRegister MIP
z) Exit
option:
IV - 4.6. Monitoring
The rest of the options permit you to inspect the distinct IPDACT aspects and
to monitor the state and view the enabled events. In order to exit each option,
press any key which will return you to the main menu.
Option d) displays the IPDACT general parameters, such as the serial
number, firmware release, etc.
IPDACT Module - Configuration
IV-44
Doc.Dm373-I
Rev. 2.0
General Info
Teldat MIP
S/N: 8209/01101 FF190504 0
v4.1 Apr 06 2006
01/02/1980 09:16:20
LAN
MAC: 0-A0-26-30-3-E9 state: up
INPUT, OUTPUT
Input:OFF Output:INACT
Reset/Phone console jumper
state:OPEN
Press any key to continue...
Option e) displays the state of the connection with the VisorALARM IP
receiver.
State: Active (4)
Press any key to continue...
Option f) displays the enabled events. To return to the menu, strike any key.
Option g) displays the IP parameters that are running in the device. If the
device has not obtained an address through DHCP, this displays the IP
address, mask and gateway configured in the “a) Generic MIP config”
menu. If on the other hand, IP configuration has been dynamically obtained
from a DHCP server, these parameters will be displayed together with other
parameters pertaining to the DHCP protocol: remaining time for the obtained
address value, remaining time until the next attempt to renew the said address
and the DHCP server the parameters were taken from.
My IP Address: 61.156.44.3
Netmask: 255.255.252.0
Gateway: 61.156.44.1
DHCP information.
Remaining lease = 107559 (sec)
Renew lease in 53559 (sec)
DHCP server: 61.156.44.1
Press any key to continue...
IPDACT Module - Configuration
IV-45
Doc.Dm373-I
Rev. 2.0
IV - 5. Telnet
As previously mentioned, it is possible to access the IPDACT console through
a telnet client, from a PC or any other workstation. To do this, simply execute
the telnet client, indicating the IPDACT IP address. The interface for this said
console is identical to the one for the asynchronous console, so for further
information on this please see the section on this console.
The following figure shows an example of accessing through telnet from the
default client program in the Windows operating system.
Figure 27. Example of accessing through Telnet
Figure 28. Access Results
IPDACT Module - Configuration
IV-46
Doc.Dm373-I
Rev. 2.0
V - Chapter.
Appendix
V - 1. UL Compliance
• UL 864 (Ninth Edition): The Standard for Control Units and
Accessories for Fire Alarm Systems.
V - 2. Control Panels
The above standards are guaranteed with the following lists of panels:
Fire Panels:
• MS-9200UD
• MS-9600
• MS-9200UDLS
• MS-9600LS
• MS-9050UD
• MS-5UD, MS-10UD
• ADT-UNIMODE 200PLUS
• ADT-UNIMODE 9600
• UNIMODE 9050UD
• UNIMODE 9200UDLS
• UNIMODE 9600LS
• UNIMODE 5
• UNIMODE 10
IPDACT Module - Appendix
V-47
Doc.Dm373-I
Rev. 2.0
V - 3. Technical Specifications
Power Supply
NOMINAL VOLTAGE RANGE 10 VDC – 24 VDC
MAX CURRENT1 12V: Idle: 190 mA Alarm: 240 mA Transient2: 500mA
Dimensions and weight
LENGTH x WIDTH x HEIGHT 140 x 92 x 29 mm
WEIGHT 150 gr
Environmental Specifications
OPERATING TEMPERATURE 0º to 49º C (32º to 120º F).
RELATIVE HUMIDITY Maximum: 93%
LAN Port
CONNECTOR RJ45 female
SPEED 10 Mbps
PROTOCOLS UDP, IP, ARP, DHCP, Telnet, Ethernet Blue Book
Other Characteristics
OUTPUT
INPUT 1A max.
1
The IPDACT power consumption should be subtracted from the maximum power of the output delivered
by the control panel. A 750mA power source is recommended in all cases.
2
Transient lasting 75ms is produced when the control panel takes over the telephone line to call the control
center.
24 V: Idle: 100 mA Alarm: 120 mA Transient2: 300mA
2A max. if V ≤ 30 VDC for resistive loads
IPDACT Module - Appendix
V-48
Doc.Dm373-I
Rev. 2.0
Loading...
