Ferguson Ariva T65 User Manual

User manual

Ariva T65

English

WARNING !!!

Ferguson receivers support recording on external hard disk drives (HDDs) and flash memories (pendrives). In all instances, the correct operation of the recording function depends on the type of connected memory! You must read the following limitations.

REMEMBER:

1. In order to use an external USB memory, the memory must support the USB 2.0 standard. To ensure stable recording and playback, you must use a memory with a recording speed of 9.0 MB/s or greater. Slower hard disk drives and flash memories may not function properly, have problems with recording (image jitter), or not function at all!!!

2.Only disks with one basic NTFS or FAT32 partition (we recommend using the NTFS format) will function properly. If you do not have such a format, prepare the disk on your computer before connecting it to the receiver.

3.Highly fragmented or used memories may also not operate smoothly or correctly.

4.External hard disk drives should be autonomously powered, since the built-in USB port is unable to provide sufficient power.

CAUTION

1.Under no circumstances should you disconnect the USB device from the receiver during recording or playback. Disconnecting during operation may cause damage to the receiver and/or flash memory, and to the recorded data.

2.Do not touch the working device (and in particular the USB connector) with wet hands. Risk of electric shock and permanent damage to the receiver!

2

Table of contents
SAFETY MEASURES.......................................................................................................................		5
DOWNLOADABLE SOFTWARE..........................................................................................................		5
ABOUT THE INSTRUCTION MANUAL.................................................................................................		6
MARKINGS AND SIGNS APPLIED TO THE RECEIVER...........................................................................		6
BASIC INFORMATION ABOUT THE RECEIVER....................................................................................		7
1. Main features.......................................................................................................................		7
2. Contents of box....................................................................................................................		7
3. Important instructions concerning handling of the receiver.........................................................		7
4. Remote control.....................................................................................................................		8
4.1 Installation of batteries....................................................................................................		9
5. Front panel..........................................................................................................................		9
6. Rear panel...........................................................................................................................		9
7. Connecting an aerial............................................................................................................		10
8. Connecting the receiver.......................................................................................................		10
8.1 Connection by means of an HDMI cable (recommended).....................................................		10
8.2 Connection by means of SCART cables.............................................................................		11
8.3 Connection of an audio system.......................................................................................		12
8.4 Connection of an external memory..................................................................................		12
8.5 Connection of another receiver.......................................................................................		13
FIRST STEPS..............................................................................................................................		14
INFORMATION ABOUT THE USER MENU..........................................................................................		14
10. Main menu.......................................................................................................................		15
11. Installation.......................................................................................................................		15
11.1	Auto search................................................................................................................	15
11.2	Manual Search ...........................................................................................................	16
11.3	Language...................................................................................................................	16
11.4	Local time settings......................................................................................................	17
MenuInstallation → Time Zone............................................................................................		17
12 TV System........................................................................................................................		18
12.1	Parental lock..............................................................................................................	19
12.2	OSD settings..............................................................................................................	19
13. Tools...............................................................................................................................		20
13.1	Calendar....................................................................................................................	20
13.2	Schedule....................................................................................................................	20
13.3	Games.......................................................................................................................	20
13.4	Information................................................................................................................	20
13.5	Factory settings..........................................................................................................	20
13.6	Upgrade by USB..........................................................................................................	21
13.7	Upgrade by OTA..........................................................................................................	21
15. PVR – recording configuration.............................................................................................		22
15.1	Recordings.................................................................................................................	22
15.2	Storage info...............................................................................................................	22
15.3	TimeShift...................................................................................................................	23
15.4	Timer settings............................................................................................................	23
15.5	Media Player...............................................................................................................	24
16. Edit channels....................................................................................................................		26
16.1	TV channels list...........................................................................................................	26
How do I move a channel?..............................................................................................		26
How do I delete a channel?..............................................................................................		27
How do I add to the group of favourites?...........................................................................		27
How do I change a channel name?....................................................................................		28
16.2	Radio channel list........................................................................................................	28
16.3	Favorite.....................................................................................................................	29
17. Basic functions supported by the remote control....................................................................		30
17.1	EPG...........................................................................................................................	30
17.2	FIND.........................................................................................................................	30
17.3	TXT - teletext.............................................................................................................	30
17.4	AUDIO.......................................................................................................................	31
17.5	SUBTITLE...................................................................................................................	31

3

17.6	REC - recording..........................................................................................................	31
SEMI-TWIN TUNER.........................................................................................................		32
17.7	PAUSE - time shift.......................................................................................................	32
17.8	INFO.........................................................................................................................	33
17.9	FAV – favourites..........................................................................................................	33
ATTACHMENT A - GLOSSARY OF TERMS..........................................................................................		34
SPECIFICATION..........................................................................................................................		35

4

SAFETY MEASURES

We request that you read the instruction manual and recommendations set forward therein. Also remember to correctly position the satellite antenna!

In order to avoid an electric shock, never open the housing. Damage to the warranty seal shall void the warranty.

Disconnect the device from the mains during thunderstorms or when it is not to be used for an extended period of time. Please remember that the warranty does not cover damage to the equipment caused by a lightning strike.

Do not expose the device to direct sunlight. Place it away from sources of heat and humidity. Do not cover ventilation ducts, in order to ensure the correct circulation of air.

Place the device horizontally on a flat, even and stable surface.

If you move the device from a room that is warm to one that is cold (or vice versa), wait at min. 1 hour before connecting it to the mains. Otherwise, problems may arise.

The device should be placed away from vases, bottles, aquariums and other water containers in order to avoid damage. Do not touch the mains plug with your bare hands.

Do not place any objects on the housing of the device. This may cause overheating and reception problems.

Before commencing maintenance or installation work, disconnect the receiver from the mains. Do not clean the receiver with alcohol or liquids containing ammonia. If necessary, clean it with a soft, lint-free cloth wetted with a gentle solution of water and soap.

•Do not connect any cables when the mains plug is in the socket.

•Check the condition of your cables. Damaged cables may cause a fire.

•Please disconnect the receiver from the mains before connecting any cables.

DOWNLOADABLE SOFTWARE

Ferguson has taken every effort to provide users with software updates in order to ensure that the parameters of the satellite television receiver are up to date. Ferguson reserves itself the right to amend, change or modify the software used in the satellite television receiver as it shall choose and without prior notification. The latest version of the software is available on the website http://www.ferguson-digital.eu

5

ABOUT THE INSTRUCTION MANUAL

Ferguson has made every effort to provide the most current information about its products. Ferguson does not grant any guarantee as to the contents of the present instruction manual and disclaims any implied guarantees concerning market value or suitability for specific purposes. The information contained herein is an instruction intended to enable the correct usage and maintenance of the receiver.

Ferguson reserves itself the right to introduce amendments, changes or translations of the instruction manual without prior notification thereof. For this reason, we recommend you regularly visit our website in order to obtain the latest information.

MARKINGS AND SIGNS APPLIED TO THE RECEIVER

Digital signal transmission logo.

This logo informs that the receiver conforms to the Digital Video Broadcasting standards.

Risk of electric shock - do not open.

This notice warns the user not to open the receiver housing. The housing may be opened solely by authorised service technicians.

CE logo.

This mark tells you that the device is following the provisions of Council Directive 2004/108/EC on the approximation of the laws of the Member States relating to the electromagnetic compatibility and the provisions of Council Directive 2006/95/EC and 93/68/EEC on the approximation of the laws of the Member States relating to low voltage and electrical safety.

Double insulation logo.

This logo informs that the receiver is an electrically safe device, provided that it is used in accordance with the recommendations set forward in the chapter concerning safety.

Take an active part in protecting the natural environment!

•Your device is made from materials that can be processed or recycled.

•To this end, you should deliver it to a designated collection point.

The RoHS mark

This mark tells you that the device is following The Directive on the Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment 2011/65/EU (commonly referred to as the Restriction of Hazardous Substances Directive or RoHS)

6

BASIC INFORMATION ABOUT THE RECEIVER

1.Main features

Reception of high definition channels

Scaling of PAL signals to a resolution of 720p, 1080i or 1080p

Availability of 8 programmable timers

Separate lists of favourite, TV and Radio channels

Quick channel search function (QuickFind)

Teletext and on-screen captions

MPEG-2, MPEG-4, MPEG-4 AVC/H.264 standards

Compatible with DVB-T

2.Contents of box

Unpack the receiver and check whether all of the following elements are present

1 x remote control unit

1 x instruction manual

1 x satellite television receiver

3.Important instructions concerning handling of the receiver

The screen menu (OSD) simplifies operation of the receiver and has made it possible to reduce the number of keys on the remote control. All of the functions are displayed on the screen and may be controlled by means of a small number of keys. Common functions have been connected in one "MENU". The selected function is coloured. Depending on the selected option, various "function keys" are displayed: red, yellow, green, blue and white in the form of graphics and descriptions. The colours represent various functions in individual "Menus". The selected function is activated by pressing a key on the remote control unit. The so-called function keys are active only when in the appropriate field there is information about it. The user interface makes it possible to navigate within a menu and between functions in a number of different ways. Certain buttons on the remote control allow direct access to functions. The buttons are multi-functional, i.e. their functions depend on previously activated elements.

NOTE:

Please keep in mind that new software may change the functionality of the receiver. Photographs and descriptions included in the instruction manual are for informational purposes only. If you should notice an error, please report it - we shall make every

effort to have it rectified.

7

4. Remote control

Due to the standardization of Ferguson equipment, the majority of these devices use the same remote control unit, i.e. RCU-200. This means that not all keys are used by this equipment model!!

POWER	Turns the receiver on and sets it in standby mode.
MUTE	Switches the sound on and off.
BACK	Returns to the previously displayed channel.
EPG	Displays the electronic programme guide.
MENU	Displays the main menu on-screen.
OPT	Changes the image resolution. The following resolutions are available: 576i, 576p,
	720p, 1080i, 1080p.
USB/PVR	Displays the USB menu, if a USB memory device has been connected.
FAV	Displays a selection of favorite channel lists.
VOL+ VOL–	Used to change the volume level (lower, higher).
CH+ CH–	Switches to the next or previous channel.
INFO	Displays information about the current programme.
EXIT	Returns to the previous submenu, or exits the menu.
TEXT	Switches on the teletext on-screen, if this is available.
AUDIO	Switching between soundtrack versions, if these are available.
SUBTITLE	Switches the on-screen captions on and off, if these are available.
FIND	A quick search for channels according to successive name letters.
EDIT	Add an event to the schedule recording.
	Move to the specified time of the movie (when watching recordings and videos from
	USB).
FORMAT	Change the aspect ratio of 16:9, 4:3, etc..
REV, PLAY,	Buttons used to operate the recording, playback and time shift mode functions.
PAUSE, FF,
STOP, REC
TV/RADIO	Switching between the list of television and radio programmes.

8

4.1 Installation of batteries

Remove the cover of the battery compartment on the rear panel of the remote control unit; slide it downwards and put it aside. Insert two AAA (R03) batteries into the compartment, observing the indicated polarity. Do not mix old and new batteries, or batteries of different types. Replace the battery compartment cover. Slide it upwards until it locks in place.

5. Front panel

POWER: Turns the receiver on and sets it in standby mode.

CH+/CH-: Switches to the next/previous channel, moves the cursor up/down in the Menu.

6. Rear panel

ANT IN:	Input of the concentric cable from the antenna.
LOOP OUT:	Output signal to another receiver. It is not RF-out.
HDMI:	Digital image and sound output to HD TV.
SPDIF (COAXIAL):	Digital coaxial audio output.
USB:	Port for connecting an external USB memory device.
TV:	SCART output, for connection to SD TV.

9

7. Connecting an aerial

In order to check the correctness of connection of external equipment, for example a terrestrial antenna, read the installation manual or hire a professional technician!

Good reception is conditional on the precise placement of the antenna. Even the best antenna will cause reception problems if it is incorrectly adjusted. Even slight placement errors may render reception impossible or considerably impair image/sound quality. Before installation make sure that the location is suitable. The proper direction may be initially determined by making a comparison with other antennas. There should be no objects directly in front of the antenna, for these may block the signal from reaching the bowl! Once you select an optimal location for the antenna, fix and adjust it initially, and then proceed to a precise adjustment. Each antenna is fitted with regulating screws that make it possible to correct its vertical and horizontal placement.

Adjusting is somewhat more difficult in the case of digital tuners. You cannot perform adjustments on the basis of the image, because this appears with a certain delay. What is more, the indicators available in the settings menu also act with a delay, and therefore adjustment may take considerable time and be very imprecise. An antenna signal meter will be indispensable for setting up the antenna. The meter must be connected to the antenna cable between the antenna and the receiver. We strongly recommend hiring a professional technician!

8. Connecting the receiver

The following illustrations show cable connections for a television and other devices connected with the receiver. If you require any assistance in connecting individual devices, contact your local technician. Before connecting or altering cabling, disconnect the receiver from the mains !!!

8.1Connection by means of an HDMI cable (recommended)

1.Connect the antenna to the ANT IN socket of the receiver.

2.Connect the HDMI to the receiver out and the television in.

Connection by means of an HDMI cable allows you to obtain the highest image quality.

10

If you have an amplifier with an HDMI out and in, which supports sound sent over HDMI, connect the devices by two HDMI cables. As in the following figure: one cable to the amplifier, and the other from the amplifier to the television set.

8.2 Connection by means of SCART cables

1. Connect the antenna to the ANT IN socket of the receiver.

2.Connect the television to the port in accordance with the description. We recommend using shielded SCART cables.

11
