Page 1
MTG TUBE DISTORTION
Page 2
15
LEDs
9V DC
INPUT
16
5
4
3
6 87
TREBLE BASS TIGHT
LEVEL LEVEL GAIN
2
MTG TUBE DISTORTION
1
BYPASS BOOST
1. Bypass Footswitch
2. Jewel Indicator
3. Output Jack
4. Level
5. Treble
6. Middle
7. Boost Level
8. Boost LED
9 10
MIDDLE
BOOST
9. Boost
10. Bass
11. Tight
12. Gain
13. Input Jack
14. Boost Footswitch
15. LED Kill Switch
16. DC Power Connector
11
12
13
14
Page 3
MTG TUBE DISTORTION
Thanks for purchasing the MTG Tube Distortion!
Many pedals try to emulate the sound of tube
breakup; we decided instead of emulating tube
distortion, we’d use actual vacuum tubes and
give you the real deal in a compact pedal. The
heart of the MTG’s design is a NOS (New Old
Stock) US-made 6205 preamp tube. 3-Band EQ
with Tight control and switchable boost—with its
own Level and Boost controls—makes it easy to
dial-in just the right sound.
DESIGNED IN CALIFORNIA, U.S.A.
Page 4
Treble
This control affects the amount of high-frequency (treble) content in
the final sound. Counterclockwise settings are darker. Clockwise
settings add brightness.
Middle
This controls the pedal’s midrange response.
Bass
This controls the pedal’s low-frequency response. Use this to bulk up
thinner-sounding guitars, or dial it down for guitars with hotter
humbucking pickups.
Tight
This control helps rein in low end that can make higher gain setting
sound muddy or unclear.
Level
This control adjusts the MTG’s output volume.
Gain
This control adjusts the amount of saturation.
Boost Level
When the Boost is engaged, this control adjusts the MTG’s output
volume.
Boost
When the Boost is engaged, this control adjusts the amount of
saturation added to your instrument’s signal.
Boost LED
This LED indicator shows when the Boost is engaged.
Page 5
Jewel Indicator
The Jewel Indicator shows when the distortion effect is active.
Bypass Footswitch
This footswitch is used to bypass the effect.
Boost Footswitch
This footswitch is used to engage the boost.
Input Jack
This is a high-impedance input suitable for electric guitar, bass,
acoustic guitars with pickup systems, keyboards and other
instruments.
Output Jack
This is a low-impedance output jack that connects to the amp or to
the next effect pedal in a mono signal chain.
DC Power Connector
This is a standard center-negative 9VDC jack for use with
appropriate power supplies.
LED Kill Switch
This switch extinguishes the LEDs that illuminate the knobs.
Page 6
FENDER MUSICAL INSTRUMENTS CORPORATION
A PRODUCT OF:
CORONA, CALIFORNIA, USA
Fender® is a registered trademark of FMIC.
Copyright © 2019 FMIC. All rights reserved.
P/N 7715389000 - REV A
Important Safety Instructions
•WARNING: To prevent damage, fire or shock hazard, do not expose the unit or its AC
power to rain or moisture.
•Do not alter the AC plug of the connected power adapter
•Do not drip or splash liquids on the unit.
•No user serviceable parts inside, refer servicing to qualified personnel only.
• WARNING: The unit must only be connected to a safety agency certified, regulated,
power source (adapter), approved for use and compliant with applicable local and
national regulatory safety requirements.
• Unplug the AC power adapter before cleaning the unit exterior. Use only a damp cloth
for cleaning and then wait until the unit is completely dry before reconnecting it to power.
• Amplifiers and loudspeaker systems, and ear/headphones (if equipped) are capable
of producing very high sound pressure levels which may cause temporary or permanent
hearing damage. Use care when setting and adjusting volume levels during use.
THIS DEVICE COMPLIES WITH PART 15 OF FCC RULES. OPERATION IS SUBJECT TO
THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL
INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED,
INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
Additional Languages
Manual available in additional languages at:
www.fender.com/support
IMPEDANCES:
POWER SUPPLY:
POWER REQUIREMENTS:
DIMENSIONS:
WEIGHT:
Product specifications subject to change without notice
Specifications
INPUT: 500kΩ OUTPUT LOAD: >10kΩ
9VDC regulated adapter,
5.5 x 2.1 mm barrel connector, center negative
290mA @ 9VDC
3.75” x 4.9” x 2.5” (95.25mm x 124.5mm x 63.5mm)
1.2lbs (.54kg)
Page 7
NOTES:
Page 8
