Page 1
MTG: LA
Page 2
15
LEDs
9V DC
INPUT
16
5
4
3
6 87
TONE BASS TIGHT
LEVEL LEVEL GAIN
2
1
BYPASS BOOST
1. Bypass Footswitch
2. Jewel Indicator
3. Output Jack
4. Level
5. Tone
6. Treble
7. Boost Level
8. Boost LED
9 10
TREBLE
BOOST
MTG: LA
9. Boost
10. Bass
11. Tight
12. Gain
13. Input Jack
14. Boost Footswitch
15. LED Kill Switch
16. DC Power Connector
11
12
13
14
Page 3
MTG: LA
Thanks for purchasing MTG: LA – a high-gain
tube distortion pedal inspired by the late ’80s
sounds of the Sunset Strip. MTG: LA uses a real
NOS 6205 preamp tube running at 150 plate
volts for authentic tube tone. You’ll find familiar
Level, Gain, Tone and EQ controls, and a
footswitchable boost that can be configured to
add volume or even more gain.
DESIGNED IN CALIFORNIA, U.S.A.
Page 4
Bypass footswitch
Bypasses effect.
Jewel indicator
Illuminates when effect is active.
Level
Controls overall distortion output level.
Boost Level
Controls output volume.
Boost LED
Illuminates when boost is engaged.
Boost
Controls amount of saturation added to signal.
Gain
Controls amount of distortion added to signal.
Tone
Similar to tone control on a guitar — turn counterclockwise to decrease
treble frequencies; turn clockwise for full-range tone.
Treble
Controls high-frequency boost/cut.
Bass
Controls low-frequency boost/cut.
Tight
Helps control low-end tonal characteristics that can make higher-gain
settings sound muddy or unclear.
Page 5
Input Jack
High-impedance input suitable for electric guitar, bass, acoustic guitars
with pickup systems, keyboards and other instruments.
Output Jack
Low-impedance output jack connects to amp or to next effect pedal in
signal chain.
DC Power Connector
Standard center-negative 9VDC jack for use with appropriate power
supplies.
LED Kill Switch
Deactivates control-knob illumination.
Page 6
FENDER MUSICAL INSTRUMENTS CORPORATION
A PRODUCT OF:
CORONA, CALIFORNIA, USA
Fender® is a registered trademark of FMIC.
Copyright © 2019 FMIC. All rights reserved.
P/N 7717098000 - REV 2
Important Safety Instructions
•WARNING: To prevent damage, fire or shock hazard, do not expose the unit or its AC
power to rain or moisture.
•Do not alter the AC plug of the connected power adapter
•Do not drip or splash liquids on the unit.
•No user serviceable parts inside, refer servicing to qualified personnel only.
• WARNING: The unit must only be connected to a safety agency certified, regulated,
power source (adapter), approved for use and compliant with applicable local and
national regulatory safety requirements.
• Unplug the AC power adapter before cleaning the unit exterior. Use only a damp cloth
for cleaning and then wait until the unit is completely dry before reconnecting it to power.
• Amplifiers and loudspeaker systems, and ear/headphones (if equipped) are capable
of producing very high sound pressure levels which may cause temporary or permanent
hearing damage. Use care when setting and adjusting volume levels during use.
THIS DEVICE COMPLIES WITH PART 15 OF FCC RULES. OPERATION IS SUBJECT TO
THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL
INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED,
INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
Additional Languages
Manual available in additional languages at:
www.fender.com/support
IMPEDANCES:
POWER SUPPLY:
POWER REQUIREMENTS:
DIMENSIONS:
WEIGHT:
Product specifications subject to change without notice
Specifications
INPUT: 500kΩ OUTPUT: 100Ω
9VDC regulated adapter,
5.5 x 2.1 mm barrel connector, center negative
260mA @ 9VDC
3.75” x 4.9” x 2.5” (95.25mm x 124.5mm x 63.5mm)
1.2lbs (.54kg)
Page 7
NOTES:
Page 8
© FENDER MUSICAL INSTRUMENTS 2019
