Please read these instructions before use.

PS-77C

ENGLISH

PS-10C

PS-77C

OPERATION

Shredder head

SafeSense® Technology

Indicator lights (red)

Paper Jam

Door Open

Overheated

Window

Sheet capacity gauge Sheet capacity icon

See safety instructions below

Pull-out bin Paper entry

Breakthrough Safety Technology! SafeSense® stops shredding when hands are too close to the opening.

SET UP

Disconnect Power Switch must be in ON position to operate shredder.

Insert waste bag (Fellowes #36052) for easy disposal.

A B

— To Test SafeSense® Technology

Touch test area

Model PS-10Cs

Disconnect power switch

SafeSense® override switch

Active Not active

SafeSense® (yellow)

Standby (green)

Control switch

Auto-On (I) Off (O) Reverse (R)

Sensor lights upPress Auto-On ( I )

Card entry

PAPER

Continuous operation:

8-10 minutes maximum

Check paper amount

NOTE: Shredder runs briefly after each pass to clear entry. Continuous operation beyond

Set to Off (O) and plug in

CARD

8-10 minutes will trigger 20-minute cool down period.

TROUBLESHOOTING

Paper jam: Set to Off (O) and empty bin. Replace bin, close door and follow any or all of the below procedures.

Press and hold Reverse (R)

ATTENTION: If the SafeSense® light remains on, you must engage the (See SafeSense

instructions below.)

Alternate slowly back and forth

Press Auto-On (I)

Feed into paper entry and release

Press Auto-On (I)

Hold card at edge

Feed into card entry and release

Indicator lights:

Yellow - SafeSense® active

Yellow flashing - SafeSense

Make sure bin is pushed in

Set to Off (O) and unplug

Override Switch in order to perform steps above. Once the jam is cleared, reset the SafeSense

Gently pull uncut paper

from paper entry. Plug in.

Press and hold Reverse (R)

Wait 20 minutes for motor to cool down

Set to Off (O) and unplug

not active

feature.

CAPABILITIES

Will shred: Paper, credit cards, staples and small paper clips Will not shred: Continuous forms, adhesive labels, transparencies, newspaper,

cardboard, large paper clips, laminates or plastic other than noted above Paper shred size:

Cross-Cut .....................................5/32 inches x 1-1/2 inches (3.9mm x 38mm)

IMPORTANT SAFETY INSTRUCTIONS — Read Before Using!

Maximum:

Sheets per pass (Cross-Cut) ............................................................................. 10*

Cards per pass .................................................................................................. 1*

Paper width ................................................................................9 inches/229mm

Continuous operation ........................................................................8-10 minutes

* 20lb., 8.5 inches x11 inches (75g) paper at 120v, 60 Hz, 4.0Amps; heavier paper, humidity or other than rated voltage may reduce capacity. Recommended daily usage rates: 25-50 paper passes; 25 cards.

MAINTENANCE

Run regularly in reverse for one minute

SafeSense® paper jam: If the SafeSense® feature activates (SafeSense® light remains on) to cause the user to think the shredder has jammed when it has not, use the Override Switch to deactivate the SafeSense paper. Warning – when switch is in override position, the SafeSense function. Once the paper is cleared, reset the SafeSense

feature.

light will flash and the SafeSense® feature will NOT

feature and clear the

Follow oiling procedure below and repeat twice.

SafeSense

override switch

Active Not active

Sensor light illuminated–paper

jammed

Oil when bin is full, or immediately, if:

• Capacity decreases

• Motor sounds different, or

Shredder stops running

Set to Off (O) Press Auto-On (I)

*Apply oil across entry

*Only use a non-aerosol vegetable oil in long nozzle container such as Fellowes 35250

WARRANTY

LIMITED WARRANTY Fellowes, Inc. (“Fellowes”) warrants the cutting blades of the machine to be free from defects in material and workmanship for 5 years from the date of purchase by the

original consumer. Fellowes warrants all other parts of the machine to be free of defects in material

and workmanship for 1 year from the date of purchase by the original consumer. If any part is

found to be defective during the warranty period, your sole and exclusive remedy will be repair or replacement, at Fellowes’ option and expense, of the defective part.

This warranty does not apply in cases of abuse, mishandling, or unauthorized repair. ANY IMPLIED WARRANTY, INCLUDING THAT OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, IS

Shred one sheet

Press and hold

Reverse (R) 2-3 seconds

HEREBY LIMITED IN DURATION TO THE APPROPRIATE WARRANTY PERIOD SET FORTH ABOVE. In no event shall Fellowes be liable for any consequential or incidental damages attributable to this

product.

This warranty gives you specific legal rights. The duration, terms, and conditions of this warranty are valid worldwide, except where different limitations, restrictions, or conditions may be required

by local law. For more details or to obtain service under this warranty, please contact us or your dealer.

• Keep away from children and pets. Keep hands away

from paper entry. Always set to off or unplug when not in use.

• Keep foreign objects – gloves, jewelry, clothing, hair, etc. – away from shredder openings. If object enters top opening, switch to Reverse (R) to back out object.

• Avoid touching exposed blades under Cross-Cut shredder head.

• Use only designated entry for cards.

• Never use aerosol, petroleum based or other flammable products on or near shredder. Do not use canned air on shredder.

• Do not use if damaged or defective. Do not open shredder head. Do not place near or over heat or water source.

• 10 sheets per pass to avoid jams.

• The grounded socket-outlet shall be installed near the equipment

and shall be easily accessible.
