These operating instructions belong with this product. They contain important information
for putting it into service and operating it. This should be noted also when this product is
passed on to a third party.
Therefore look after these operating instructions for future reference!
A list of contents with the corresponding page numbers can be found in the index on page 4.
The product has been EMC-tested and thus meets the requirements of the valid national
guidelines. See also FCC-Information.
In order to maintain this condition and ensure safe operation, you, as the user, have to observe
this operating manual.
Prior to using the product for the first time, please read the entire operating manual and observe
all operating and safety instructions.
We should already like to point out now the correct order for commissioning the
products. Please also observe the installation and calibration instructions in this
F
All company names and product descriptions listed herein are the trademarks of the respective manufacturers. All rights are reserved.
operating manual as well as the information about impairment of radio transmission
between the sensors and base station.
3
Table of Contents
Page
1. Intended use ..........................................................................................................................5
2. Scope of delivery ...................................................................................................................6
Appendix A: Position table (longitude/latitude) ...................................................................33
Appendix B: Table of time zones .........................................................................................51
1. Intended use
The weather station WS 250US Edition is a high-quality universal weather measuring system
which processes a large quantity of weather data and additional information, and displays the
current weather as well as weather forecasts.
All relevant data are displayed simultaneously on the LC display. Additional data can be called
up at the push of a key.
A special feature is „Wiz Kid“. He indicates the current temperature range by means of the
lothes he wears, the current wind speed with his hair and scarf and the forecast and starting or
current precipitation.
The forecasts of the base station serve only the purpose of orientation. They do not represent
an absolutely true forecast. The manufacturer does not assume any responsibility for incorrect
displays, measuring values or weather forecasts or any consequences which may result from
these.
The product is intended for private use. It is not suited for medical purposes or public information.
The components of this product are not toys. Install all components in such a way that children
have no access to them.
The product is battery-operated. All external sensors transmit their data per radio to the base
station (433 MHz, range up to 100 m in open space, see chapter 12 on page 23).
Any other use than that described above may lead to damage to the product or to
other danger.
Read the complete operating manual carefully. It contains much important information
about the installation and operation.
5
2. Scope of delivery
• Weather station WS 250US Edition
• Plastic base for weather station
• Combination sensor
• Metal rods/pegs for the combination sensors
• Operating manual
• 7 x Mignon-batteries (LR6/AA)
3. Terminology
An exclamation mark in a triangle indicates important instructions in the operating
manual which must be observed under all circumstances.
You will see the „hand” symbol for special tips and instructions concerning opera-
F
tion.
4. Features and functions
a) Base station
Display of indoor temperature and air humidity
• Temperature display in °C, °F
• Can be switched to display internal dew point
• Storage of minimum/maximum temperature with time and date of incidence
• Storage of minimum/maximum humidity with time and date of incidence
• Comfort zone indicator
• Graphic display of progress for the past 24 hours
Display of one of a maximum of 9 outdoor sensors (temperature and air humidity)
• Display of the data of the combination sensor or 8 outdoor sensors for temperature/air humidity
(ASH 2200US and S 300 PT US)
• Display of temperature, dew point or wind-chill temperature
• Storage of minimum/maximum temperature with time and date of incidence
• Storage of minimum/maximum humidity with time and date of incidence
• Graphic display of progress for the past 24 hours
Display of wind speed
• Selectable units: km/h, m/s, mph
• Storage of maximum wind speed with time and date of incidence
• Additional graphic display (wind cone) for slight, moderate and strong wind
Display of the amount of rain in mm, l/m2 or inch for:
• total amount since the last clearance, last hour, current hour, last 24 hours, current 24 hours
• storage of the maximum quantity per hour and per day
• additional display for commencing rain (immediate rain display)
6
Display of atmospheric pressure progress / atmospheric pressure tendency:
• graphic display of the progress in the past 24 hours
• display of atmospheric pressure tendency in 5 different stages: increasing strongly, increasing,
steady, falling, falling strongly
Symbolic display of weather forecast
• Symbol for: rainy, cloudy, fair and sunny
Display of time and date
• Integrated quartz clock
Display of sunrise / sunset
• Based on location data to be entered individually; calculation is possible within a range of
–60 to +60 °N
Display of moon phases
• Display of current moon phase: new moon, waxing moon, full moon, waning moon
„Wiz Kid“
Reminiscent of the almost forgotten weather house in which case a person with an umbrella
comes out in case of bad weather and another one with light clothing in case of good weather,
the WS 250US Edition has „Wiz Kid“.
The behaviour of this figure depends on several weather factors so that you can tell at a glance
which clothes you can wear if going outdoors.
This not only evaluates the current measuring values for the outdoor temperature, air humidity,
wind and rain.
The weather forecast also plays an important role here. Depending on the weather situation,
„Wiz Kid“ has a different appearance and wears different clothing.
„Wiz Kid“ shows several weather factors at one glance:
• Wiz Kid’s clothing depends on the outdoor temperature measured by means of the combination
sensor.
• In the case of wind speed in excess of 20 km/h, Wiz Kid’s hair will blow in the wind. If the temperature is below 15 °C at the same time, his scarf will also blow in the wind.
• If the weather forecast forecasts rain, Wiz Kid will carry a (closed) umbrella.
• If it starts raining, Wiz Kid will carry an open umbrella.
b) Combination sensor
• Radio transmission of:
- rain quantity
- immediate rain detection
- wind velocity
- temperature
- humidity
7
5. Safety instructions
Damage caused by non-observance of this operating manual can lead to forfeiture of the warranty! We shall not assume any liability for subsequent damage!
We shall not assume any liability for damage to items or persons caused by
improper handling or non-observance of the safety instructions! In such cases,
any guarantee claims shall become null and void .
Dear Customer, the following safety and hazard notices not only serve the protection
of your health but also the protection of the appliance. Please read the following points
carefully!
Do not use this product in hospitals or medical institutions. Although the outdoor sensor only
emits relatively weak radio signals, these may cause interference to life-support systems. The
same can also apply in other areas.
The weather station is only suited for dry, indoor premises. Do not expose it to direct sunlight,
extreme heat, cold, dampness or humidity.
If used correctly, the rain/wind detector is suited on the other hand to unprotected outdoor
locations.
For safety and licensing reasons (CE), it is not permitted to convert or modify the product.
Do not leave the packaging material lying around. Plastic foil and bags, polystyrene parts etc.
are dangerous toys in the hands of children.
Handle the product with care! Blows or impact, or dropping it even from a small height will
damage it.
6. Battery and environment instructions
• Batteries do not belong in the hands of children.
• Observe the right polarity when inserting the batteries/accumulators.
• Do not leave batteries lying around. Pets or small children may swallow them. If they are
swallowed, contact a doctor immediately.
• Leaking or damaged batteries/accumulators may lead to injury to the skin. For this reason,
use suitable protective gloves when changing them.
• Make sure that batteries or accumulators are not thrown into the fire or short-circuited. There
is a likelihood of explosion!
• Never dismantle batteries/accumulators!
• Do not recharge normal batteries. There is a risk of explosion!
• If the product is not used for longer periods of time (e.g. in case of storage), please remove
the inserted batteries/accumulators in order to prevent damage caused by leaking batteries/
accumulators.
8
7. Preparation for operation, commissioning
Please observe:
First of all, put all available outdoor sensors into operation (insert batteries)
and then the base station itself.
If you proceed in the opposite order, it could occur that the base station does
not detect all the existing outdoor sensors.
We always recommend you to first of all try out the base station with all outdoor sensors (in as
much as you have purchased additional outdoor sensors besides the supplied combination sensor)
in a room before installing the outdoor sensors in the open air. However, the distance between
the base station and the outdoor sensors should be at least 2 m in order to avoid interference.
If you notice that one outdoor sensor is out of range after installation, you can assume that radio
reception is not sufficient (and that there is no defect in the outdoor sensor).
This initial function test will save extensive and time-consuming error searches afterwards.
a) Commissioning the combination sensor
• Open the casing of the sensor. First of all, turn the lower casing cover slightly in the direction
of the arrow (1) as shown below and then carefully lower the casing cover.
• Now insert three batteries (LR6/mignon/AA) with the correct polarity
into the battery compartment (see illustration below on the right).
Use preferably alkaline batteries.
Accumulators can also be used but these will reduce
F
For the first 5 minutes the combination sensor is in a test mode and
sends its data-telegrams in an intervall of approx. 3 seconds. After
completion of the test mode the normal transmission interval of
approx. 155 seconds is activated.
It must be guaranteed that the combination sensor has already
left its test mode when the synchronisation mode of the base station is terminated, otherwise a normal reception isn’t possible.
• Close the sensor casing, slide the cover to the top and lock it
again.
• Assemble the installation base.
the range due to the lower voltage / capacity as well as
their operating life!
1
2
As already explained above, you should first of all install the sensors
in the garden etc. after a successful initial function test.
It may be difficult to find a favourable place for the combination sensor as this should stand preferably in the shade in order to measure
the correct temperature. On the other hand, it is also necessary to
consider the functions of the wind and rain sensor.
Closeness to buildings, trees, etc. may impair the measuring values
of the wind and rain sensor.
–
+
+
–
below
–
+
9
Once you have found a favourable location, insert the earth peg deep into the ground in order to
ensure the stability of the combination sensor.
When selecting the installation site, take the safety of children, pets, vehicles,
etc into consideration.
Any risk of the combination sensor’s falling poses the risk of injury or danger
of damaging vehicles or other objects.
You can also use a hammer to insert the earth peg into the ground. However,
use a suitable piece of wood or similar in order not to damage the top end of
the pipe as this makes it impossible to connect the other pieces of pipe (loss
of warranty)!
Make sure that there are no pipes or similar installed in the area where you wish
to insert the peg into the ground (e.g. hoses for irrigation systems or similar).
b) Commissioning additional sensors
If you wish to use one or several additional temperature / humidity sensors, for example of
the type „ASH 2200US“, insert the batteries now into the sensor(s) with the right polarity.
You can operate up to 8 sensors.
–
+
–
+
c) Commissioning the base station
• Open the battery compartment on the back of the base
station (remove the installation base, if applicable).
• Insert four batteries (LR6/mignon/AA) with the correct
polarity into the battery compartment.
Use preferably alkaline batteries.
It is possible to use accumulators but these
F
• Close battery compartment.
• After you have inserted the batteries, all segments of the LCD are displayed briefly.
• After that, the base station activates the synchronisation mode for 15 minutes. During this
period, the device displays all received radio weather sensors in succession.
If all sensors used have already been received, you can terminate synchronisation mode
prematurely by pressing any key. It must be guaranteed that the combination sensor has
already left its test mode, otherwise a normal reception isn’t possible. In case of doubt
the synchonisation mode of the base station should not be terminated manually.
• Normal display of all weather data takes place after synchronisation. Only the sunset and
sunrise together with the moon phase are not yet displayed because the time and the calendar
have to be set for this purpose.
• You can either hang the base station on a wall (there is a corresponding opening on the back)
or place it on a level surface with the installation base.
• If you want to use the foot, first put the front central spike of the foot into the supports on the
back side of the base station. Then, swing the foot a little bit back till the two rear spikes lock
into the catch supports at the buttom of the base station.
reduce the operational life due to their lower
voltage / capacity.
–
+
+ –
below
10
8. Indications of the LC Display
1
2
3
4
5
6
7
17
16
15
14
13
12
11
8
9
10
11
1 Current indoor temperature
2 Current indoor humidity
3 Comfort zone indicator (for the display of a comfortable/uncomfortable climate)
4 Rain display
5 Amount of rain (in the above illustration, the rain amount in the current 24 hours)
6 Atmospheric tendency display
7 Graphic progress display (history) depending on the unit selected (illustration above: at-
mospheric pressure)
8 Sunrise time and sunset time
9 Time and date display
10 Animated icon „Wiz Kid“
11 Current wind speed
12 Symbol for wind strength
13 Sensor number (no display when the combination sensor is selected)
14 Current air humidity value of the outdoor sensor selected
15 Current temperature value of the outdoor sensor selected
16 Symbol for the moon phase
17 Symbol for the weather forecast (sunny, fair, cloudy, rainy)
12
9. Configuration and Operation
After installation of the radio sensors and the subsequent commissioning of the base station
(this order must be observed!), the data transmitted by the radio sensors should appear on the
LC display of the base station.
a) Basic Settings, configuration
The following settings are still required for operation:
• Year, month, day, hour, minute
• Latitude/longitude of your position
• Time zone
You will then see the display of the moon phase and the sunset/sunrise as well as
F
Additional settings:
• Rain sensor alignment is possible on request (however, this was already carried out by the
manufacturer so that it normally does not have to be repeated!)
• Unit of rain quantity
• Assignment of progress display (air pressure, interior or exterior temperature)
• Wind strength unit
the date and the time.
The keys have the following functions in configuration mode:
Imprint Function Description
IN (unused)
SENSOR - leaving configuration mode
MIN/MAX EXIT increase value
RAIN + decrease value
OUT NEXT to next setting
You will also find the key allocation on the back of the weather station.
Please observe:
F
Configuration takes place in the sequence:
Country ‡ Year ‡ Month ‡ Day ‡ Minute ‡ Hours ‡ Daylight Saving time ‡ Latitude ‡
Longitude ‡ Time zone (ti) ‡ Temperature unit ‡ Rain sensor alignment ‡
Rain unit quantity ‡ Assignment of progress display ‡ Wind unit
The values are adjusted more quickly if you press the keys „+“ or „-“ longer when
making individual settings.
After each setting, you can leave the configuration mode by pressing „EXIT“ or move
on to the next setting using the key „NEXT“.
After that, the setting order commences from the beginning again.
F
13
IN
>2 seconds
Calling up configuration mode
Press key „IN“ for approx. 2 seconds.
You can leave the configuration mode at any time by pressing
„EXIT“ (= „SENSOR“), see „Termi nating configur ation
mode“.
+
NEXT
-
coun
Set country using the keys „+“ and „-“.
• „US“ = USA
• „STD“ = Europe
Press „NEXT“ key.
Setting time and date
Country selection
+
NEXT
+
NEXT
+
NEXT
+
NEXT
+
NEXT
+
NEXT
-
-
year
month
-
minutes
-
-
hours
-
Set current year using the keys „+“ and „-“.
Press „NEXT“ key.
Set current month using the keys „+“ and „-“.
Press „NEXT“ key.
Set current day using the keys „+“ and „-“.
day
Press „NEXT“ key.
Set minutes using the keys „+“ and „-“.
Press „NEXT“ key.
Set hours using the keys „+“ and „-“.
Press „NEXT“ key.
Set daylight saving time:
dst
• „On“ = active
• „Off“ = inactive
Press key „NEXT“; then you can set the latitude („LA“ appears
on the display).
Entering latitude/longitude
It is necessary to state the location of the weather station in order to calculate the sunset/sunrise
times. You can enter the latitude at a range of between -60.0° to +60.0°.
The manufacturer’s setting is Washington D. C.. You can determine your position in different ways:
• in the appendix A on page 33, you will find a table with the coordinates of all US counties
cities. Select a nearby location near and enter its coordinates.
• if you have a GPS navigation device, e.g. in your car or a mobile device, you can adopt its
position details and thus the exact position.
• you can also obtain the exact coordinates in the Internet. There are numerous sites that deal
with navigation.
Please observe the fact that the information concerning the sunrise / sunset would only be correct
to be exact at the sea or for completely level landscape. Mountains, high forests etc. will alter
these values for your location.
Even for the ideal situation, the information can deviate by some minutes as an approximation
formula is used for the calculation.
14
+
-
latitude
Set the latitude using the keys „+“ and „-“.
Example: 52.5°, input: 525
NEXT
+
NEXT
+
EXIT
or
NEXT
longitude
-
-
terminating
configuration
extended
settings
time
zone
Press the „NEXT“ key. After that, you can enter the longitude.
The display shows this as „LO“ („Longitude“).
Set the longitude using the keys „+“ and „-“.
Example: 13.4°, input: 0134
Press the key „NEXT“ and now set the time zone. The display
shows „ti”.
Setting the time zone
The time zone is required for the calculation of the sunrise
and sunset times.
Enter the difference to GMT (Greenwich Mean Time)
= UTC (Universal time).
In the appendix B is a table showing the time zone difference
from UTC for North America time zones.
Enter the current value for your time zone using the keys „+“
and „-“.
All settings have been made at this time for correct operation
of the weather station. The extended settings are not required
for normal operation.
Now press „EXIT“ to leave the configuration mode and return to
normal mode. Now the base station is back in normal mode.
Press the key „NEXT“ to make extended settings.
+
NEXT
tempe-
-
rature
measurement
Set temperature unit for outdoor and indoor temperature.
unit
You can chose between °C or °F.
Press the key „NEXT“ to make rain sensor settings.
15
Selecting the unit for temperature
Entering the alignment value
The rain gauge has been set to a high degree of accuracy ex
works so that you normally do not need to align it.
Simply press „NEXT“ to take over the factory settings.
Otherwise the alignment value will have to be determined
first of all in normal mode (see chapter 13 d) on page 27).
+
NEXT
+
NEXT
+
NEXT
-
-
-
alignment
value
rain
quantity
unit
assigning
progress
display
Enter the previously determined alignment value using the
keys „+“ and „-“.
Press „NEXT“ to set the unit for measuring rain.
Selecting the unit for rainfall
measurement
The unit for the rainfall quantity is displayed in the field „RAIN“
where you can chose between l/m2 or mm.
Select the desired unit using the keys „+“ and „-“.
Press the „NEXT“ key. After that, you can allocate the progression display.
Allocating the progress display
You can allocate the following display types to the graphic
progression display:
• atmospheric pressure
• interior temperature
• exterior temperature
If the progress display is allocated to one of the two temperature displays, the symbol „ “ appears in the display field
concerned in addition.
Overlay/identification in the display field:
P = atmospheric pressure
O = outdoor temperature
I = indoor temperature
Select the desired allocation using the keys „+” and „-”.
Press the key „NEXT“, after that, the unit for the wind velocity
measurement can be entered.
16
Selecting the unit for wind velocity
The following units can be set:
km/h = kilometre per hour
m/s = metre per second
mph = miles per hour
The display will take place in the field „WIND”.
Select the unit with which you wish to display the wind velocity
wind
+
-
velocity
using the keys „+” and „-”.
unit
F
If the „NEXT“ key is pressed, the country collection
will appear again; the input order can commence
from the beginning again. You could now, for example, monitor or alter the entries.
Terminating configuration mode
EXIT
Press „EXIT” to complete input. This can take place at any
desired position, e.g. after setting the time etc.
b) Operation
Selecting indoor temperature display
In normal operation, the indoor temperature and internal humidity are displayed in the display
field „INDOOR”.
By repeatedly pressing the „IN” key, you can switch between:
• indoor temperature
• respective dew point
Selecting outdoor temperature display
In normal operation, the indoor temperature and internal humidity of the selected outdoor sensor
are displayed in the display field „OUTDOOR”.
By repeatedly pressing the „OUT” key, you can switch between:
• outdoor temperature
• respective dew point
• temperature measured (wind chill)
Selecting outdoor sensor
In the display field „Sensor”, the outdoor sensor selected at the moment concerned is displayed
together with its sensor number. Only active (in the synchronisation phase) sensors are displayed.
To select the outdoor sensors or combination sensors, press the „SENSOR“ key so long until
the desired sensor number appears:
• for outdoor sensors 1-8, the sensor number concerned (1-8) is displayed
• no sensor number is displayed for the combination sensor, the overlay „SENSOR“ (alongside
the outside humidity) disappears.
Selecting rain quantity display period
By repeatedly pressing the „RAIN“ key, you can switch between:
• display for the last hour
• display for the current hour
17
• display for the last 24 hours
• display for the current 24 hours
• display of the total quantity since the last clearance of the rain quantity after inserting the
batteries.
In the process please consider the following peculiarities: The calculation of the rain quantity „last
hour“ always occurs at the half-hour, for example between 2.30 p.m. and 3.30 p.m. The calculation of the rain quantity „last day“ always occurs at 7.30 a.m. The rain quantity „current hour/day“
results from the quantity, that accumulates till the next half-hour, for example 4.30 p.m.
Deleting total rain quantity
Press „RAIN“ key for approx. 2 seconds. After releasing the key, the total rain quantity is deleted.
Displaying MIN-/MAX figures (extreme values)
For the measurement figure of the indoor/outdoor temperature and indoor/outdoor humidity, the
minimum and maximum figures reached since the last clearance of data are stored.
Only the MAX figures are stored for the wind velocity and rain quantity measurements.
The point of time and date of incidence of the extreme value are also stored for all
F
Pressing the „MIN/MAX“ key switches between the display of the minimum values, the maximum
values and the normal display. Proceed in retrieving the stored date as follows:
• Retrieving minimum values
figures.
Press the „MIN/MAX” key. „MIN“ appears in the centre.
F
The minimum values are now overlayed in the displays concerned. No display takes place for
wind and rain (minimum value would always be „0“).
• Retrieving maximum values
Press the „MIN/MAX” key once again (starting from the normal display press the key twice).
„MAX” appears in the display in the centre.
The maximum values are displayed in the display fields concerned.
F
• Returning to normal display
By pressing the „MIN/MAX” key, return to the normal display takes place, the overlay „MAX“
disappears from the display.
Displaying time/date for individual extreme values
If necessary, you can have the appropriate time or date of incidence displayed for each individual
extreme value.
Proceed as follows:
• First of all, select the display of the minimum values (press „MIN/MAX” key once, overlay
„MIN“ in the LCD) or the maximum values (press „MIN/MAX” key twice , overlay „MAX“ in
the LCD).
18
• The desired value can now be displayed by pressing the „SENSOR” several times.
Order of display:
indoor temperature ‡ indoor humidity ‡ outdoor temperature ‡ outdoor humidity ‡ rain
quantity (only MAX value, not for „TOTAL“) ‡ wind velocity (only MAX value)
Only one display field is displayed with its extreme value at one time; the point of time
F
• Pressing the „SENSOR“ key again leads back again to the complete display of all extreme
values (MIN or MAX according to whether you have selected the minimum or maximum values
at the beginning).
Deleting MIN/MAX values
Press the „MIN/MAX“ key once to display the minimum values or twice to display the maximum
values. Now you can choose the value to be deleted by pressing the „SENSOR“ key.
To delete the values displayed (either minimum values or maximum values), press the „RAIN“
key for more than two seconds.
After that, the figures are deleted.
and date of incidence of the extreme value appears below in the time display.
c) Other functions
Moon phase display
The moon phase display appears with the following symbols:
Full-moon
WaningNew-moon
The moon phase display only appears when the time/date have been entered.
Waxing
F
Wiz Kid
„Wiz Kid“ displays several weather factors at once as an animated figure:
• Outside temperature (only combination sensor)
Wiz Kid’s clothing is altered through the outside temperature on the combination sensor.
• Rain
If the weather forecast function has registered „rain“, a closed umbrella is displayed.
If the combination establishes rain, the umbrella is put up.
• Wind velocity
For wind velocities of over 20km/h, Wiz Kid’s hair blows in the wind. If the temperature is under
15 °C at the same time, the scarf displayed also blows in the wind.
19
Weather forecast
The symbols of the weather forecast from the weather station right at the top of the display give
the following forecasts:
Overcast with rain ‡ rainy
Overcast ‡ cloudy
Overcast with sun ‡ bright
Sun ‡ sunny
Wind symbol display (windsock)
The windsock symbol in the display field „WIND” shows at a glance whether the wind is at
present light, moderate or strong:
The combination sensor determines not only the rain quantity but also transmits the current
status (dry/wet) of a special sensor. Through this, even one drop can be transmitted to the base
station as „beginning rain“.
In the LC display of the base station, a symbolic rain drop appears in the field „RAIN“. Apart from
this, „Wiz Kid“ puts up his umbrella.
Comfort indicator
The comfort indicator reflects the climate in the room (ratio of temperature to humidity). You can
find a table of values for the display areas in section 15 on page 29.
The comfort indicator displays three different smiles: J K L
‡ strong wind (> 20 km/h)
Graphic progression display (history)
The bar chart shows the last 24 hours’ progress of atmospheric pressure, outdoor and indoor
temperature. The individual columns represent no absolute value, but the difference to the current
measurement (0-hour column). This point of reference is always situated in the center (4 bars),
so that the tendendy can be interpreted at first glance.
10. Changing battery
Depending on which batteries or accumulators you use, the replacement interval
F
a) Base station
If the battery flat symbol appears in the display ( ), the batteries have to be replaced by
new ones.
20
can be very different. High-quality alkaline batteries keep the longest, accumulators
or cheap zinc-carbon batteries require more frequent changing.
• Always replace the whole set of batteries.
• Do not mix full with „half-full” batteries“.
• Always use four batteries of the same type and manufacturer.
• Do not mix batteries with accumulators.
• As already mentioned, accumulator operation is possible, the durability is, however, appreciably
lower than with batteries.
• For changing the batteries, proceed as described in section 7. c).
Please observe the following:
F
After replacing the batteries, all data, values stored in the base station (e.g. time,
date etc.) are deleted and have to be entered again.
b) Combination sensor, outdoor sensor
When the display of the sensor concerned fails for more than 24 hours, the batteries are to be
replaced with new ones as described in section 7. a) and b).
Check as whether there is possibly some disturbance in the radio transmission which
F
is the cause for the failure of the data transmission. In this case also, there will be no
indication in the display of the base station.
The cause could be, for example, a metal object in the radio path (e.g., a parked
vehicle).
21
11. Troubleshooting
Observe the safety instructions contained in these operating instructions
Problem Remedy
No reception • The distance between the base station and outdoor sensors is
too great.
Alter the position of the outdoor sensors.
• Objects or shielding materials are obstructing the radio reception.
Alter the position of the outdoor sensors and the base station.
• The batteries of the outdoor sensors are too weak or flat.
Insert new batteries into the sensors as an attempt.
• Another transmitter on the same or neighbouring frequencies is
disturbing the radio signal of the outdoor sensors. This can be, for
example, radio headphones, radio loudspeakers or similar devices.
Such products are not usually operated constantly; the radio
reception can, for example, be perfect the next day; this makes
the search for the cause more difficult.
If possible, set another frequency on the instruments which can
eliminate the reception problems of the weather station.
Disturbance of • The outdoor sensors transmit their data to the base station approx.
other instruments every 3 minutes for a period of 0.1 (100ms) seconds. In this short
through the outdoor period, disturbances in other devices are also possible.
sensors For example, a very short disturbance signal can be audible from
a radio head phone every 3 minutes.
Problems with the • When inserting the batteries into the outdoor sensors and the base
synchronisation station (observe this order exactly!), these devices are in synchronisation mode. A data telegram is transmitted here every
4 seconds which accelerates the recognition and registration of
the outdoor sensors at the base station.
To enforce new synchronisation, remove the batteries from the
base station and outdoor sensors. After that, wait at least 60
seconds before you insert the batteries into the outdoor sensors
again and, lastly, into the base station (observe this order without
fail – first of all insert the batteries into all existing outdoor sensors,
only then into the base station.
In doing so, however, all values/data which the base station has
stored (e.g. minimum values, maximum values and date/time etc.),
are lost.
• Before you position the outdoor sensors, for example in your
garden, carry out a function test as described at the beginning of
section 7.
22
12. Range
The transmission range of the radio signals to the base station is 100 m under optimum conditions. This is often described as the „free field range”.
This ideal arrangement (e.g. base station and outdoor sensor on a smooth, level field
F
Normally, the base station is set up in the house, the combination in the garden and further
outdoor sensors, for example in ancillary buildings or garage.
The range can be reduced considerably partly through:
• walls, reinforced steel ceilings
• coated/vapoured insulation glass panes
• vehicles
• trees, bushes, earth, rocks
• closeness to metal & conductive objects (e.g. radiators)
• closeness to the human body
• broadband disturbances, e.g. in residential area (DECT telephones, mobile telephones, radio
head-phones, radio loudspeakers, other radio weather stations, baby phones etc.)
• closeness to electric motors. Transformers, network parts pr computers
• closeness to poorly shielded or openly operated computers or other electrical devices
F
Observe section 7 and 11 of these operating instructions.
without trees, houses etc.) is, however, never found in practice.
As the local circumstances are different at every place of set-up, a certain range
cannot be guaranteed.
If the base station is receiving no data from the combination sensor or any additionally
existing outdoor sensors (in spite of new batteries), reduce the distance between the
outdoor sensors and the base station, change the place of set-up .
23
13. Maintenance and cleaning
a) General
Check the technical safety of the product regularly, e.g. damage to the housing.
It can be assumed that operation is no longer ensured without risk if
• the device shows visible damage
• the device is no longer functional
• after longer periods of storage under unfavourable conditions or
• after heavy transport stress
Before cleaning or servicing the device, observe the following safety instructions without
fail:
Remove the batteries before cleaning, servicing or carrying out repair work.
There are no parts in the interior requiring servicing; the device may not be opened.
Repairs may only be carried out by a specialist who is familiar with the associated
hazards and relevant regulations for the device.
b) Cleaning base station
Dust can be removed very easily with a vacuum cleaner and a clean, soft brush. Keep the opening
of the vacuum cleaner close to the base station (do not come into contact, scratching possible!)
and remove the dust with the brush. The dispersed dust will be sucked in by the vacuum cleaner.
Use a soft, dry, lint-free cloth for cleaning the exterior of the product.
For greater contamination, you can use a cloth slightly moistened with warm water.
Never use aggressive cleaners or chemical solutions as the surface of the device or its functionality
could be damaged as a result.
c) Cleaning outdoor sensors or combination sensor
After a longer period of operation in the open air, dirt can gather on the plastic surface of the
outdoor sensors.
This can be removed very readily with a soft cloth which has been moistened with water.
Never spray the outdoor sensors with, for example, a garden hose as the outdoor
sensors are only protected against rain from above and not against water jets from
the side or from below.
The rain gauge should be monitored from time to time.
24
Depending on the location, leaves, particles of dirt carried by the wind, small twigs and similar
can enter the cone collector of the rain gauge. Large parts can clog the flow-through!
Sand can also collect in the count rocker which will affect the measuring result negatively as it
increases.
For this reason, the rain gauge should be cleaned at least once a year.
F
Proceed as follows:
• open the lower part of the rain gauge. To do this, turn the lower part approx. 1 cm to the left
until you can let the metal nips slide downwards.
• remove the upper cone collector by turning it first of all a small distance to the right; then lift
it off to the top.
• the rainfall sensor (the plastic part with the two brass pins and cable) can now be removed.
Make a note of the orientation; the connection cable of the rainfall sensor can be
F
• Remove the count rocker.
F
• Now clean the components of the rain gauge. Think also of the drain hole in the plastic lower
part of the rain gauge which you have pushed downwards at the metal pipe.
• To reassemble, place the count rocker first of all in the holder.
F
found at one side.
Make a note of the orientation; there is a small magnet at one side of the count
rocker.
For this, the magnet of the count rocker has to
relocated on the side which points to the cable.
The two lower trapezoid pins have to be inserted
into the lower part of the holder correctly.
Only in this manner is it guaranteed that the count
rocker can be moved easily.
25
• Insert the rainfall sensor into its holder. It will hold
the count rocker firmly automatically.
Only one orientation is correct; the cable
F
• Place the cone collector from the top onto the sensor carrier and snap it in by turning it to the
left.
• Push the lower part of the rain gauge housing upwards and lock it by turning it to the right
until it snaps in.
F
of the rainfall sensor and the magnet of the
count rocker have to be on the same side;
the plastic nib on the other side has to be
inserted precisely into the holder, look at
the circle in the picture on the right.
The drain holes in the lower part of the housing have to point to the outside so that
the water does not run on to the metal stands.
26
d) Aligning rain sensor
The measuring system of the rain gauge has already been set ex works to a high
F
The alignment process takes fairly long (at least 10 minutes) and has to be carried out very
exactly and conscientiously as, otherwise, the exactitude is much lower than that which already
exists.
Proceed as follows for alignment:
• First of all, set any rain quantity value which may have accumulated back to zero.
For this, press the „RAIN“ key in normal display mode for about two seconds. After releasing
the key, the display of the total rain quantity must indicate „0“.
• Make sure that the rain gauge is clean and the count rocker dry.
• Pour 100 ml of clear water very slowly (distributed over 10 minutes) into the cone collector of
the rain sensor.
• The total quantity displayed should be 6.5 l/m2.
• If any other value is displayed, the so-called rocker value is to be recalculated as follows:
6.5 x current rocker value
New rocker value =
Actual value (display after filling with water)
level of exactitude.
Any alignment is therefore normally not necessary.
CAUTION!
If the water is poured too quickly, it results in an inaccurate measuring result.
Pour the water into the cone so slowly that at no point of time water stands
in the cone.
• This new value has to be entered in the configuration menu (see section 9. a), „enter alignment
value of rain sensor“) .
It is always entered in ml/rocker beat, the unit on the right is the subsequent
F
The setting ex works is 295 ml/rocker beat (the ”current rocker value“ for the formula above).
display unit of rain quantity!
27
14. Handling
Observe all the safety precautions in these operating instructions!
a) General
The product may not be opened or taken apart (except for the work described in these operating
instructions, e.g. change of battery or cleaning the rain gauge).
There are no parts to be maintained by the user in the inside of the product.
The product will be damaged even if dropped from a low height.
b) Base station
Avoid the following adverse ambient conditions during operation or transport:
- moisture or excessive humidity
- extreme cold or heat direct sunlight
- dust or flammable gases, vapours or
- heavy vibration
- strong magnetic fields, such as, for example, in the vicinity of machines or speakers
Never use the product immediately if it has been taken from a cold area to a warm area. The
condensation developing could in certain cases destroy the device.
Wait until the base station has reached room temperature. This can take some hours!
A place for set-up has to be selected so that the base station stands securely and cannot fall
down. There is danger of injury due to its extreme heaviness.
Valuable or easily scratched furniture surfaces should be protected from damage by suitable
mats before setting up the base station.
c) Combination sensor
Although the combination sensor is protected against rain from above, this is not the case,
however, from the side or from below. Therefore, avoid any direct spraying, for example, through
a garden hose or another watering system.
Select the place of set-up so that children cannot tip the combination sensor over; do not place
the combination sensor in the proximity of vehicles, glass doors, windows or similar!
28
15. Terminology
Sensed temperature
See „windchill“.
Comfort indicator
The symbol of the comfort indicator (the three different „smiles“ J K L) reflect the room
climate whereby the weather station works according to the following table:
Independent of the ratio temperature to humidity, there are clearly delimited areas which are
defined as comfortable or uncomfortable climate.
For example, you feel humidity of under 30% to be too dry at a temperature of 25° C (e. g. heating
air) and humidity of over approx. 60% to be humid.
Dewpoint
This concerns a temperature which is dependent on the coincidence of a certain air pressure, a
certain temperature and a certain humidity.
The condensation of the humidity begins at this temperature point, the co-called thaw, the
humidity condenses and comes down as liquid (mist, vapour).
If the melting point for water vapour lies at below 0° C, condensation will take place as snow
or frost.
L L L K K K K K K LL L L K J J J J K LL L K J J J J K L LL K J J J J K L L LL K K K K K K L L L
L L L L L L L L L L
Weather forecast
The weather forecast of the weather station takes place by means of various weather symbols
which are calculated from the rising or falling speed of the air temperature (tendency).
This speed of change in the air temperature is the decisive volume for forecast of the approaching
weather, the absolute value plays a sub-ordinate role here. In general you can say that increasing
air pressure signalises better weather while falling air pressure, on the other hand, means poor
weather.
The human being feels temperatures under certain circumstances quite differently from what a
thermometer can show. In the case of low outdoor temperatures, you sense the temperature on
the naked skin as being much lower the quicker any additional wind blows.
29
The „windchill“ is defined as a cooling down effect on the naked skin with a theoretical surface
temperature of 33°C and a wind velocity of over 2.6 m/s.
The higher the wind velocity is and the lower the actual environment temperature, the more the
windchill effect can be felt.
The „sensed temperature” is approximately comparable to the so-called felt temperature which,
in addition, amongst other things, also takes into consideration the radiation effect of the sun,
the light reflection of the clouds, the light wave length etc.
Wind strength table (Beaufort)
Beaufort Wind velocity Description
0 0 - 0.7km/h calm
1 0.7 - 5.4 km/h light draught
2 5.5 - 11.9 km/h light breeze
3 12.0 - 19.4 km/h weal breeze
4 19.5 - 28.5 km/h moderate breeze
5 28.6 - 38.7 km/h fresh breeze
6 38.8 - 49.8 km/h strong wind
7 49.9 - 61.7 km/h stiff wind
8 61.8 - 74.6 km/h stormy wind
9 74.7 - 88.9 km/h storm
10 89.0 - 102.4 km/h heavy storm
11 102.5 - 117.4 km/h gale-force storm
12 > 117.4 km/h hurricane
16. Disposal
a) General
Dispose of the unusable product according to valid legal regulations
b) Disposing of used batteries and accumulators
You, as ultimate consumer, are required by law (battery regulations) to return all used batteries.
Disposing of used batteries with domestic waste is prohibited!
Batteries / accumulators containing toxins are marked by appropriate symbols which
refer to the prohibition of disposal with domestic waste.
The designations for the decisive heavy metals are: Cd = cadmium, Hg = mercury,
Pb = lead (The designation can be found on the battery under the dustbin symbol
illustrated on the left).
You may return used batteries/accumulators free of charge to collecting stations, our
outlets or anywhere else where batteries/accumulators are sold.
By doing so, you fulfil the legal requirements and contribute to the conservation of our environment.
30
17. Technical data
Measuring interval of the outdoor sensors: ......................................................approx. 3 minutes
Measuring interval of the indoor sensor: ........................................................approx. 10 minutes
Dissolution: .........................................................up to 100km/h: 0.1km/h; over 100km/h: 1km/h
Voltage supply:
Base station: ....................................................................................... 4 x 1.5 V LR6, mignon, AA
Combination sensor: .......................................................................... 3 x 1.5 V LR6, mignon, AA
Dim. (B x H x D) base station: .....................approx. 136 mm x 198 mm x 35 mm (without base)
31
18. FCC Information
FCC ID: RNT-WS250US
Changes or modifications not expressly approved in writing by ELV Electronics Limited may void
the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for help.
The internal antenna used for this mobile transmitter must provide a separation distance of at
least 20 cm from all persons and must not be co-located or operating in conjunction with any
other antenna or transmitter.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
32
Appendix A: Table of latitude/longitude for US counties.
Source: US Census Bureau. Data is provided "as-is". Not responsible for errors.
Source: US Census Bureau. Data is provided "as-is". Not responsible for errors.
50
Appendix B: Table of time zone difference from UTC
Time ZoneMajor CitiesSymbolDifference
from UTC
Atlantic TimeSan JuanAST20
Eastern TimeBoston, New York, Washington DC, EST19
Miami
Central TimeMinneapolis, New Orleans, Houston, CST18
Chicago
Mountain TimeSalt Lake City, Boise, DenverMST17
Pacific TimeSeattle, San Francisco, Los Angeles, PST16
Las Vegas
Alaska TimeFairbanksAKST15
Hawaii-Aleutian HonoluluHAST14
Time
Enter the difference from UTC (Coordinate Universal Time)/GMT (Greenwich Mean
Time) for your time zone when you configure the Weather Station as par chapter 9.
Do not consider daylight saving time when making this entry. Follow instructions
for setting the status of daylight saving time as a separate entry.
51
52
ELV Electronics Ltd. · Hongkong
Loading...
+ hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
