Introduction

Your new Epson® EL 3S/33 computer is a high-performance system offering flexibility and expandability in a compact design. It provides the following features:

386SX, 33 MHz microprocessor 2MB or 4MB of internal memory, expandable to 16MB System and video BIOS shadow RAM 256KB of on-board video memory, expandable to 512KB or

1024KB Built-in VGA port Two built-in serial ports, one built-in parallel port, and one

built-in game port Built-in PS/2 compatible keyboard port Three 16-bit full-length and two 8-bit half-length ISA option

slots Support for up to three mass storage devices.

The shadow RAM feature allows your system to speed up processing by moving the system and video BIOS into the RAM area of memory.

Using the built-in interfaces, you can connect most of your peripheral devices directly to the computer so you do not have to install option cards. You can use the option slots to enhance your system with extra functions such as a modem card, a network controller card, or additional interface ports.

Introduction 1

The VGA controller supports standard resolutions up to 640 x 480 in 16 colors and extended resolutions up to 1024 x 768 in 4 colors (interlaced or non-interlaced). With 512KB video memory, the controller supports resolutions up to 1024 x 768 in

16 colors; with 1024KB, it supports the same resolutions in up

to 256 colors.

VGA Utilities

Your computer comes with special VGA drivers and utilities for use with the integrated VGA interface. With these utilities, you can take advantage of the extended VGA features such as high resolutions and 132-column text mode when you run

popular application programs.

Optional Equipment

You can easily upgrade your computer by installing additional memory and a wide variety of options as described in Chapters 3 and 4.

Memory

By adding 256KB, 1MB, and 4MB SIMMs (single inline memory modules) to the main system board, you can expand the computer’s memory up to 16MB.

Drives

Your system can support up to three internal mass storage devices, including hard disk drives, diskette drives, a tape drive, or a CD-ROM drive. As your storage needs expand, you can install additional drives.

Introduction

Math Coprocessor

You may want to install an 80387SX, 33 MHz coprocessor. This

optional math coprocessor allows your computer to perform mathematical functions faster.

How to Use This Manual

This manual contains the information you need to get the best results from your computer. You do not have to read everything in this book; check the following summary.

Chapter

system and connecting peripheral devices such as the monitor and printer. It also describes running the SETUP program to define your computer’s configuration.

Chapter 2

the computer on and off, resetting the computer, and changing the processor speed.

Chapter 3

cover, change jumper settings, and install optional equipment such as option cards and memory modules.

Chapter 4

Chapter 5 Chapter 6 Appendix A

software that has been tested on your system, and options available for your system.

At the end of this manual you’ll find an

1 provides simple instructions for setting up your

covers general operating procedures, such as turning

describes how to remove and replace the computer’s

explains how to install and remove disk drives. describes how to install VGA drivers and utilities.

contains troubleshooting tips.

lists the specifications of your computer, the

Index.

Introduction 3

Chapter 1

Setting Up Your System

This chapter briefly describes the operations you will use to set up your computer. It includes the following information:

Getting started

Connecting the computer

Running the SETUP program

Post-SETUP procedures.

Getting Started

Follow the instructions below for choosing a location for your new system, unpacking your system, and setting up your computer.

Choosing a Location

When you select a place to set up your system, choose a safe, convenient location that provides the following:

A flat, hard surface. Surfaces like beds and carpets attract static electricity, which can erase data on your disks, damage the computer’s circuitry, and prevent proper ventilation.

Good air circulation. Leave several inches of space around the computer so air can move freely.

Setting Up Your System 1-2

Moderate environmental conditions. Select a cool, dry area and protect your computer from extremes in temperature, humidity, dust, and smoke. Avoid direct sunlight or other sources of heat.

No electromagnetic interference. Do not place your system too close to any electrical device, such as a telephone or television, which generates an electromagnetic field.

Appropriate power source. Connect all your equipment with the appropriate power cords for the power source in your area.

Unpacking Your Computer

When you unpack your system components, make sure you have these items:

computer

po co

diskettes

manual

keyboard

Your system also includes a serial mouse and may come with

the operating system and software already installed on a hard disk drive.

1-2

Setting Up Your System

If you purchased any optional equipment that goes inside the computer-such as option cards, memory modules, a hard

disk, or a diskette drive-you should install these devices

before you connect your computer. See Chapters 3 and 4 for

instructions.

Connecting the Computer

Use the illustration below to locate the ports on the back of your system as you connect the keyboard, monitor, printer, and other devices.

monitor cable

AC outlet

COM1

COM2 PARALLEL

Setting Up Your System

GAME

1-3

Connecting a Keyboard

To connect a keyboard, hold the cable connector so the arrow

on the connector faces up. Insert it into the port marked K/B.

Connecting a Mouse

Your system came with a serial mouse that connects to either of the computer’s built-in serial ports. To connect the mouse, insert the connector into one of the ports marked COM1 and COM2.

When you install the drivers for your mouse, make sure you identify the port to which you connected it. See the README file on the diskette that came with your mouse for more information.

Connecting a Monitor

The way you connect your monitor to the computer depends on the type of monitor you have. If you have a VGA monitor (or a multifrequency monitor with an analog connector), you can connect it to the computer’s built-in VGA port as described below. If you are connecting your monitor to an adapter card, see Chapter 3.

Place your monitor on top of or near the computer. Turn the monitor and computer around so the backs are facing you.

There should be two cables provided with your monitor: the monitor cable (to connect it to the computer) and the power cable (to connect it to the power source). On most monitors, the monitor cable is permanently attached to the monitor. If your monitor does not have an attached cable, connect the cable to it now.

Examine the connector on the monitor cable and line it up

with the VGA port on the computer. Then insert the

connector into the port.

1-4 Setting Up Your System

Caution

To avoid damaging the connector, be careful not to bend the pins when you insert it.

If the connector has retaining screws, tighten them.

Plug the monitor power cord into the monitor’s power inlet.

Plug the other end of the power cord into an appropriate grounded electrical outlet or into the power outlet on the

back of the CPU.

Caution

If you plug the monitor’s power cord into the back of your computer, make sure the monitor’s power requirements do not exceed 1 Amp.

Connecting a Printer of Other Device

Your computer has one parallel and two serial ports. To connect a printer or other peripheral device, follow the appropriate instructions below.

Using the Parallel Port

Follow these steps to connect a parallel printer to your computer:

Place the printer next to the computer so that the backs are facing you.

Align the connector end of the printer cable with the PARALLEL port and plug it in. If the connector has retaining screws, tighten them.

Setting Up Your System

1-5

Connect the other end of the cable to the printer. To secure the cable, squeeze the clips at each side of the printer port and push them into place.

Plug the printer’s power cord into an appropriate grounded electrical outlet.

Using the Serial Ports

If you have a printer, a modem, or a mouse with a serial interface, you can connect it to one of the serial (RS-232C) ports on the back of the computer. Make sure you have a cable compatible with a DB-9P connector.

To connect a serial device, insert the connector into one of the ports marked COM1 and COM2. If you are connecting only one serial device, use the COM1 port.

Connecting the Power Cord

Follow these steps to connect the power cord:

Plug the power cord into the AC power inlet on the back panel.

1-6

Warning

To avoid an electric shock, be sure to plug the cord into

the computer before plugging it into the wall outlet.

Plug the other end of the power cord into an appropriate grounded electrical outlet.

Setting Up Your System

Turning On the Computer

After you set up your system, you are ready to turn on the power. Follow these steps:

Turn your computer around so the front panel faces you. Place your monitor, printer, and other devices in a convenient arrangement.

If there is a protective card in the diskette drive, remove it now.

Turn on the monitor, printer, and any other devices connected to the computer.

Turn on the computer by pressing the power button on the right side of the front panel.

The screen displays a count of the system memory, and then the computer performs its power-on diagnostics, which are a series of checks that make sure everything is working correctly.

If necessary, use the controls on your monitor to adjust the brightness and contrast until you can easily see the characters on the screen.

If your system is configured to automatically load a program (such as Microsoft Windows or a word processing program), you see the first menu or screen display of that program. If not, you may see the operating system prompt, such as C:\> or A:\>.

If there is no operating system installed on your computer, you see an error message. Ignore the message for now; once you install the operating system, you will not see this message.

Now follow the instructions in the next section to configure your system using the SETUP program.

Setting Up Your System 1-7

Running the SETUP Program

You need to run SETUP the first time you use your computer.

Even if your system was configured for you, you may still need

to set the date and time, and if your system came unconfigured, you need to define how it is set up. (You also may need to run SETUP again later if you change your configuration.)

SETUP is stored in the computer’s ROM BIOS, so you can run it

any time. SETUP lets you verify or change the following:

Current date and time Type of diskette drive(s) and hard disk drive(s) System memory Type of video display adapter Keyboard options Processor speed Shadow options Processor chip features.

The configuration information is stored in an area of memory

called CMOS RAM. This memory is backed up by a battery, so

it is not erased when you turn off or reset the computer.

Starting the SETUP Program

You can run SETUP whenever you see the operating system

command prompt, such as:

C:\> or A:\>

To start SETUP, hold down Ctrl and Alt, then press S.

1-8

Setting Up Your System

Also, whenever you start your computer, if the system detects an error in your system configuration, you will see the following message:

Press the F1 key to continue, F2 to run the setup utility

Press

to run the SETUP program to correct your

configuration. The table below lists the keys you can use to perform SETUP

operations. SETUP function keys

Key

PgDn PgUp

Esc

Function

Moves the cursor to the next or previous modifiable

option

Changes the values in the field

Displays the next or the previous menu

Displays a help screen describing the option currently

selected

From the exit menu, saves the changes you have made and restarts your computer

From the exit menu, supplies the factory default values for all SETUP options

From the exit menu, leaves the SETUP program without saving any changes

Displays the exit menu

Whenever you are in the SETUP program, the bottom of the

screen lists the keys you can press to perform specific functions.

Setting Up Your System

1-9

Displaying System Information

The SETUP program provides a system information screen which lists the following:

Processor type

Coprocessor type (if one is installed)

Reserved memory

BIOS version number

Addresses for video mode, serial ports, and printer ports.

To see this information, press F2 from either of the SETUP screens.

Setting the Date and Time

The real-time clock in your computer continuously tracks the date and time-even when the computer is turned off. Once you set the date and time using SETUP, you should not need to change them, unless you adjust the time for daylight savings or other seasonal adjustments. (The computer automatically changes the date for leap years.)

Use ?, J, t or + to move the cursor to the value you want to change. Then press + or - until you see the value you want.

1-10

Setting Up Your System

Setting the Diskette Drive(s)

On your system, diskette drive A is the 3.5-inch high-density drive installed in the lower drive bay on your system. You may also have another drive of a different size or capacity; this is drive B. Check the settings for both drives and correct them if necessary.

Note

If you add a diskette drive and want to reassign the top drive as drive A, you must change jumpers J17 through J20, as described in Chapter 3. Then run SETUP to reassign drive

types.

Setting the Hard Disk Drive(s)

The SETUP program lets you select the type of hard disk drive(s) installed in your computer. If your system was configured for you, the hard disk drive type has been preset. To set the hard disk drive type, follow these guidelines:

If your system does not have a hard disk, select

Not Installed for Hard Disk 1

and

Hard Disk 2.

If your computer came with an Epson-installed hard disk drive, you need to define your own drive type. For more information, see “Defining your own drive type” on page 1-14.

If you have installed another type of hard disk drive, you need to select the drive.

drive

type number that matches your

Setting Up Your System

1-11

Hard disk drive types

The table below lists standard hard disk drives. Check this table and your drive documentation to find the correct type number. If none of the types listed matches your drive, see page 1-14.

Hard disk drive types

Type

2 3 4 5 940 6 512 6 7 8 9

20 21 22

Cyl / Hd 1 Pre / LZ I Sec I Size*(MB)

306 / 4 1 128 / 305 I 17 I 10

615 4 300 615 615 6 300 615 940 8

615 4 462 8 256 733 5

900 10 11 12 13 14 16 17 18 19

820 3

855 5

855 7

306 I 8 I 128 1 319 / 17 / 20

733

612 4

977

1024 1 7

1733

733 733

306 4

5 7

1300

7 5 300 733

20 30 62 46 20 30 30

20 35 49

42 20 40 56

130

42 30

17 17

512

-1

-1 0 300 977

-1

512 I 1023 1 17 / 59

300

940 940 615 511 733 901 820 855 855

733 663

977

1732

732

336

17 17 17 17 17 17 17 17 17

17 17 17 17

117

17 17 17 10

112

1-12

Setting Up Your System

Hard disk drive types (continued)

Actual formatted size may be slightly different than size on drive label.

Setting Up Your System

1-23

Defining your own drive type

If the parameters for your hard disk (listed in its documentation) do not match any of the types listed in the table above, you can define your own type. Follow these steps:

Move your cursor to

Hard Disk

1 or 2

and press + or -

until you see drive type 48 or type 49.

Press + to move the cursor to the

Type the appropriate cylinder value for your hard disk. The

Cyl

field.

documentation that came with your hard disk drive will provide the appropriate information.

Continue pressing + to move the cursor to the next field and type in the appropriate values.

If you are installing Epson-supplied drives, use the information in the following table to define your drive type.

Epson-supplied hard disk drive types

l Actual formatted size may be slightly different than size on drive label.

Note

If you are going to install NetWare 286, version 2.2, you cannot assign a user-defined drive type for your drive without installing two IDE drivers. You can obtain these drivers (IDE.DSK and IDE.OBJ) by downloading IDE286.ZIP from CompuServe®Alternatively, you can select one of the pre-defined hard disk drive types that most closely matches the drive you are installing.

1-14 Setting Up Your System

Checking System Memory

Your computer comes with 2MB or 4MB of random access

memory (RAM) on SIMMs. DOS and application programs that run under DOS use the first 640KB of memory. You can use the memory above 1MB as extended memory.

When you boot your system, the system BIOS detects the type of RAM and updates the base memory size and the extended memory size automatically. You see the memory configuration displayed on this SETUP screen.

Setting the Video Display Type

The Video

Card option lets you define the type of adapter you are using for your primary display. If you connected your monitor to the computer’s built-in VGA port, select

EGA/VGA

If you installed an optional video card, follow the guidelines

below to select the correct adapter type.

Video display type options

Select

EGA/VGA

CGA40*

CGA80*

MONO*

For these options, you must change jumpers J36 and J37 on the system

board to the OFF position.

You connected your monitor to the built-in VGA port or you installed a VGA or enhanced graphics adapter (EGA) card

You installed an optional color graphics adapter set to

40-column color graphics adapter (CGA) mode

You installed a CGA or a multi-mode graphics adapter

(MGA) attached to a color monitor

You installed a monochrome display adapter or an MGA

attached to a monochrome monitor

Setting Up Your System

1-15

Note

If you are installing a monochrome monitor, you also need to set jumper J11 on the main system board to position 2-3. See Chapter 3 for more information on setting jumpers.

Setting Keyboard Options

Two options in the SETUP program allow you to control keyboard settings. The the built-in keyboard connector if you are using an optional connector.

The NumLock on at boot option determines the initial state of the num lock function when you turn on or reset your system. When num lock is off, the keypad controls cursor movement. If num lock is on, the keypad types numbers.

Select

YES

to set the num lock function on when the system

starts.

Keyboard

option allows you to disable

Setting the Processor Speed

The

CPU Speed

slow. At fast speed, your processor operates at its fastest speed, 33 MHz. At the slow speed setting, the processor operates at 8 MHz to provide compatibility with older application programs.

Note

The Cyrix cache option is not available on this system.

1-16

Setting Up Your System

option sets the processor speed to fast or

Setting Chip Set Feature Control Options

The second screen of the SETUP program contains the options related to the features on your system board. Press PgUp or

PgDn to display this screen.

Relocating memory

The Relocate Memory option relocates the memory between A0000h to BFFFFh and D0000h to EFFFFh for use as extended memory. If you enable shadowing, however, relocation is automatically disabled.

Shadow RAM options

Your computer can access RAM (random access memory) faster than ROM (read only memory).

Two shadow features (Shadow

ROM

) allow your system to copy the contents of its system and/or

BIOS ROM

and Shadow Video

video ROM into RAM so it can perform certain operations faster.

You can also shadow 32KB or 64KB of memory that starts at the

indicated addresses to RAM. If you enable these options, you cannot use the Relocate Memory feature.

Additional options

Two additional chipset feature options allow you to slow down your system in case you need compatibility with slower option cards or diskette drives.

If you enable the ISA 1 wait state option, the system inserts one wait state in a 16-bit ISA cycle rather than providing the fastest processing at zero wait states.

The Slow Refresh option, when enabled, improves system performance because it shortens the time needed for each refresh cycle.

Setting Up Your System

1-17

Exiting the SETUP Program

When you leave the SETUP program, you can save your settings and reboot your system, or exit SETUP without saving

your settings. You can also return all values to the factory defaults.

To leave the SETUP program, press Esc from any SETUP screen. From the SETUP exit menu, press these keys to perform the following functions:

Esc

F5 F6

Returns to the SETUP utility Saves the changes you have made to your configuration

and restarts your computer Supplies the factory default values for all SETUP options Exits the SETUP utility and returns to the system prompt

without saving any changes.

Post-SETUP Procedures

After you run SETUP for the first time, you may need to install

the operating system on your computer. See your operating system manual for instructions.

Also, install any software you plan to use. See your application program manuals for instructions.

You may also want to install the optional extended video drivers for some of your application programs. See Chapter 5 for more information.

1-18

Setting Up Your System

Chapter 2

Using Your Computer

This chapter briefly describes the following operations:

Turning the computer on and off

Inserting and removing diskettes

Stopping a command or program

Resetting the computer

Changing the processor speed.

Turning On the Computer

Before you turn on your computer, check the following safety rules to avoid accidentally damaging your computer or injuring yourself:

Do not connect or disconnect any peripheral device cables

(including the keyboard or a mouse) or power cables when

the computer’s power is on.

Never turn off or reset your computer while a disk drive

light is on. This can destroy data stored on the disk.

Always wait at least 20 seconds after you turn off the power before you turn it on again. This prevents possible

damage to the computer’s electrical circuitry.

Do not leave a beverage near your system. Spilled liquid can damage the circuitry of your equipment.

Using Your Computer 2-1

Follow these steps to turn on your system:

Turn on the monitor, printer, and any other peripheral devices connected to the computer.

If you do not have a hard disk with an operating system loaded on it, insert your main operating system diskette in drive A.

To turn on the computer, press the power button located on the right side of the front panel, as shown below.

hard disk or

diskette drive bay

power

button

reset button

hard disk access light

power light

speed (TURBO) light

diskette drive

The power indicator lights up. After a few seconds, the computer displays a count of its system memory, and then performs its power-on diagnostics. This is a series of checks the computer runs each time you turn it on to make sure everything is working correctly.

2-2 Using Your Computer

When the system has successfully completed its diagnostics, DOS prompts you to verify the correct date and time. If they are correct, press Enter. Otherwise, enter the current date and time. If your system is configured to automatically start Microsoft Windows or has a different operating system, you may not see this prompt.

What happens next depends on how your computer is set up.

If your system is configured to automatically load a program (such as Microsoft Windows or a word processing program),

you see the first menu or screen display of that program. If not,

you may see the operating system prompt, such as c : \ > or

A: \>.

Turning Off the Computer

Whenever you turn off your system, follow these steps:

Save your data and exit any application program you are using.

Check the hard disk drive light and the diskette drive light(s) to make sure they are not on. Do not turn off the computer if a drive light is on, because you can damage the drive or lose data.

Remove any diskette(s) from the diskette drive(s).

Press the power button to turn off the computer and then

turn off the monitor, printer, and any other peripheral devices.

Using Your Computer

2-3

Inserting and Removing Disks

To insert a diskette into a 3.5-inch drive, hold the diskette with the label facing up and the metal shutter leading into the drive, as shown in the following illustration. Slide the diskette into the drive until it clicks into place.

release button

metal shutter

To insert a diskette into a 5.25-inch drive, hold the diskette with the label facing up and the read/write slot leading into the drive.

When you want to remove the diskette, make sure the drive light is off; then press the release button or turn the latch. Remove the diskette and store it properly.

Caution

Never remove a diskette or reset or turn off the computer while a diskette drive light is on. You could lose data. Also, remove all diskettes before you turn off the computer.

2-4 Using Your Computer

Stopping a Command or Program

You may sometimes need to stop a command or program while it is running. If you have entered a DOS or application program command that you want to stop, try one of the following:

Press Pause

Hold down Ctrl and press C

Hold down Ctrl and press Break.

If these methods do not work, you may need to reset the computer as described below. Do not turn off the computer to exit a program or stop a command unless you have to, because the computer erases any data you did not save.

Resetting the Computer

Occasionally, you may want to clear the computer’s current settings or its memory without turning it off. You can do this by resetting the computer.

For example, if an error occurs and the computer does not respond to your keyboard entries, you can reset it to reload your operating system and try again. However, resetting erases any data in memory that you have not saved; so reset only if necessary.

Caution

Do not reset the computer to exit a program. Some programs classify and store new data when you exit them in the normal manner. If you reset the computer without properly exiting a program, you may lose data.

Using Your Computer 2-5

To reset the computer, the operating system must be either on the hard disk or on a diskette in drive A; so if you do not have a hard disk, insert the system diskette in drive A. Press the RESET button located on the front left side of your computer. If you are using DOS, you can also hold down Ctrl and Alt and press Del. The screen displays nothing for a moment and then the computer should reload your operating system.

If resetting the computer does not correct the problem, you probably need to turn it off and on again. Remove any diskette(s) from the diskette drive(s). Turn off the computer and wait 20 seconds. If you do not have a hard disk, insert the system diskette in drive A. Then turn on the computer.

Changing the Processor Speed

Your computer’s processor can operate at two speeds: high speed (33 MHz) or low speed (8 MHz). The low speed is available to provide compatibility with older application programs.

When your computer is operating at high speed, the TURBO light on the front panel is on. When the computer is operating at low speed, the light is off.

You should use high speed for almost everything you do because your programs will work faster. However, certain application programs have specific timing requirements and can run only at the slower speed. See your software manual to determine if this is the case.

2-6 Using Your Computer

Some copy-protected programs require the computer to run at low speed while accessing the program on a diskette. These programs also usually require you to leave a

key

disk-the diskette that contains the copy protection-in the diskette drive. If you use a copy-protected program, you can change the speed to low to access the diskette and return it to high speed when you are finished.

You can change the processor speed temporarily by entering one of the following commands from the numeric keypad on your keyboard:

To select low speed, press Ctrl Alt -. (Hold down the Ctrl key and the Alt key simultaneously and then press the - key on the numeric keypad.) The speed light turns off.

To select high speed, hold down the Ctrl and Alt keys and press + on the numeric keypad. The speed light comes on.

Note

You can use the commands listed above while you are running a program. However, if the program uses one of these commands for another function, you cannot use it to change the processor speed. You can, however, change the processor speed through the SETUP program.

The speed setting remains in effect until you do the following:

Reset your computer

Turn off your computer

Change the speed with another keyboard command

Change the speed setting in the SETUP program.

Using Your Computer 2-7

Chapter 3

Installing and Removing Options

You can enhance the performance of your computer by adding

optional equipment such as memory modules, option cards, or a math coprocessor.

Memory modules-also called SIMMs (single inline memory modules)-allow you to increase the amount of memory in

your computer. An option card is a circuit board you install in your computer

to add a particular function, such as a modem or an additional interface port.

The math coprocessor can be installed on the system board to

enhance numeric-intensive operations for software that supports the coprocessor.

This chapter first describes how to remove your computer’s cover to install options and how to replace the cover when you are finished. It then describes the following:

Locating the internal components

Changing the jumper settings

Installing and removing memory modules (SIMMs)

Installing and removing option cards

tl Adding video memory CI

Installing the math coprocessor.

Installing and Removing Options

3-1

Caution

Never install options or change jumper settings with the computer turned on or the power cord connected to the computer.

Once you have installed your option, see “Post-installation Procedures” on page 3-20.

Removing and Replacing the Cover

You need to remove the computer’s cover to install any of the options described in this chapter or to install or remove a disk drive (as described in Chapter 4).

Follow these steps to remove the cover:

Turn off the computer and then any peripheral devices (including the monitor and printer).

Disconnect the computer’s power cable from the electrical outlet and from the back panel. Also disconnect any cables that are connected to the computer, including the keyboard cable.

3-2

If the monitor is on top of the computer, lift it off and set it to one side.

Turn the computer around so the back panel is facing you.

Installing and Removing Options

Remove the three screws securing the back panel, as shown

5. below.

Grasp the sides of the cover and lift it straight up, as shown below:

Installing and Removing Options

3-3

Set the cover aside.

Ground yourself to the computer by touching the metal surface of the back panel.

Warning

Be sure to ground yourself by touching the back panel of the computer every time you remove the cover. If you are not properly grounded, you could generate an electric shock that could damage a component when you touch it.

When you are ready to replace the computer’s cover, follow these steps:

Make sure all the internal components are installed properly.

Check all cable connections, especially those that might have

been loosened during your work.

Make sure all cables are out of the way so they do not catch

on the cover.

Insert the front of the cover between the front bezel and the chassis of the computer and guide it straight down.

Replace the three cover retaining screws.

Reconnect the computer to the monitor, printer, keyboard, and any other peripheral devices you have. Then reconnect the power cable to the back of the computer and to an electrical outlet.

3-4 Installing and Removing Options

Locating the Internal Components

As you follow the instructions in this chapter, refer to the following illustration to locate the different components inside your computer.

option card

J1-J10

J15

video memory

J36,

connector

coprocessor

power

system

board

SlMMs

J17-J20

J25, J27

’

‘c

mounting bracket

drive bays

Installing and Removing Options 3-5

Changing the Jumper Settings

The main system board in your computer has a number of

jumpers which control certain functions. These jumpers are

preset at the factory to default positions; however, you can use the information in the following tables to change their function, if necessary:

Port jumper settings

Jumper number

J10

* Factory setting

DOS automatically reassigns parallel and serial ports. Check your DOS manual for more information.

Jumper setting

1-2*

2-3

1-2*

2-3

1-2*

2-3

1-2*

2-3

1-2*

2-3

1-2*

2-3

1-2*

2-3

Function

Enables COM1 serial port Disables COM1 serial port

Assigns COM1 serial port as COM1 Assigns COM1 serial port as COM3**

Enables COM2 serial port Disables COM2 serial port

Assigns COM2 serial port as COM2 Assigns COM2 serial port as COM4**

Enables parallel port Disables parallel port

Assigns parallel port as LPT1 Assigns parallel port as LPT2**

Enables game port Disables game port

Drive assignment jumper settings

Drive assignment J17

J18 J19

J20

Upper drive is A Lower drive is A

* Factory setting

2-3

1-2* 1-2* 1-2*

3-6 Installing and Removing Options

2-3

2-3 2-3

1-2*

Diskette drive con troller jumper settings

Jumper Jumper number setting Function

J27

* Factory setting

1-2*

2-3

Enables diskette drive controller Disables diskette drive controller

Hard disk drive con troller jumper settings

Hard disk controller

Enable Disable

* Factory setting ** Two-pin jumper

J25

1-2*

2-3

Display adapter jumper settings

Jumper

number

J11 1-2‘

J15**

* Factory setting ** Two-pin jumper

Jumper setting Function

2-3 On

Off Non-interlaced mode

Color VGA display adapter Monochrome display adapter

Interlaced mode

Built-in VGA jumper settings

J22**

On* Off

Built-in VGA

Enable Disable

* Factory setting ** Two-pin jumper

~~ r

J36**

dn*

Off

J37**

On* Off

Note

To use an external display adapter in an expansion slot, you must disable the built-in VGA adapter.

Installing and Removing Options 3-7

I I

Setting the Jumpers

If you need to change any jumper settings, follow these steps:

Refer to the illustration on page 3-5 to locate the jumpers.

If there are any option cards installed in your computer, you need to remove them to access the jumpers. See page 3-16.

A jumper’s setting is determined by where the jumper is placed on the pins. A two-pin jumper either connects both pins (on) or sits on just one of the pins (off). For three-pin jumpers, the jumper connects pin 1 and the middle pin (position 1-2) or pin 3 and the middle pin (position 2-3), as shown below.

3-8

1-2

2-3

To move a jumper from one position to the other, use needle-nose pliers or tweezers to pull it off its pins and gently move it to the desired position.

Caution

Be careful not to bend the jumper pins or damage any surrounding components on the main system board.

Replace any option cards you removed. See page 3-13 for instructions.

Installing and Removing Options

Installing Memory Modules (SlMMs)

Your computer comes with 2MB or 4MB on SIMMs. By installing additional memory modules, you amount of memory in your computer up to 16MB.

There are eight SIMM sockets on the main system board, and each can contain one memory module. You can install 256KB,

1MB, and 4MB SIMMs.

The following table shows the possible SIMM configurations; do not install memory in any other configuration. The label on the system board for each SIMM socket (RAM1 through RAM8) identifies the bank of sockets where you should install SIMMs.

SlMM configurations

can

increase the

Installing and Removing Options 3-9

Before you install SIMMs, check the following guidelines to ensure that they will work properly:

Use only 30-pin, fast-page mode SIMMs that operate at an access speed of 70ns (nanoseconds) or faster. Be sure all the SIMMs operate at the same speed.

Use the correct SIMM configuration to add the amount of memory you want. See the table above.

Inserting SIMMs

Follow these steps to install SIMMs:

Refer to the illustration on page 3-5 to locate the SIMM sockets near the front of the computer.

Remove any option cards that may be blocking your access to the SIMM sockets. (See page 3-16 for instructions.)

3-10

Installing and Removing Options

Position the first SIMM at an angle over the first empty socket in the bank you are filling, as shown below. The components on the SIMM should face the inside of the computer.

Push the SIMM into the socket until it is seated firmly in the slot. Then tilt it upright, as shown above, guiding the hole at each end of the SIMM over the retaining post at each end of the SIMM socket. If it does not go in smoothly, do not force it; pull it all the way out and try again.

Repeat steps 3 and 4 for each additional SIMM.

Replace any option cards you removed. (See page 3-13 for instructions.)

Installing and

Removing

Options

3-11

Removing SlMMs

If you need to remove SIMMs from your computer (to install different ones, for example), follow the steps below:

Remove any option cards that may be blocking your access

to the SIMM sockets. (See page 3-16 for instructions.)

Use your fingers or a small screwdriver to carefully pull

away the metal tabs that secure the SIMM at each end, as shown below. As you pull away the tabs, the SIMM falls to the side. Remove it from the socket.

If necessary, follow the same procedure to remove the other SIMMs.

Replace any option cards you removed, as described below.

3-12 Installing and Removing Options

Installing an Option Card

This section explains how to install option cards in your computer. Your computer has three 16-bit full-length slots and two B-bit half-length slots to accommodate a total of five option cards.

Usually it does not matter which slot an option card occupies as long as the card fits in the slot. For example, you can place some B-bit cards in a 16-bit slot. However, you cannot install a

16-bit card in an B-bit slot.

Caution

Make sure the power requirements for the option cards you install do not exceed the power supply limitations. See your option card manual(s) for the power requirements. Then check Appendix A for the option slot power limits. Note that older option cards that require -5 volts are not supported.

Before you install an option card, see if you need to change any

jumper settings on the system board. For example, if you install

a video card, you may need to change jumpers J11, J15, or J36 and J37. See page 3-6 for more information on jumpers.

Refer to the illustration below and follow these steps to install an option card:

If you are using a 16-bit option slot, go on to step 2. If you are using an B-bit slot near the power supply, you need

to remove the power supply before you can remove the metal slot cover.

Installing and Removing Options

3-13

Remove the two retaining screws securing the power supply to the back of the computer and the third retaining screw holding the power supply to the base of the computer. Be careful not to disconnect any of the cables. Slide the power supply out of the way.

Remove the retaining screws securing the option slot cover to the computer. (Keep the screw to secure the option card to the computer.)

Slide out the slot cover and set it aside. (Store it in a safe place in case you remove the option card later.)

Unpack the option card and adjust any switches or jumpers on it, if necessary. (Check the option card instructions.) When you handle the card, be careful not to touch any of the components on the circuit board or the gold-edged connectors. If you need to set it down before you install it, place it gently on top of its original packing material with the component side facing up. Keep the packing materials in case you remove the card later.

3-14

Installing and

Removing

Options

Hold the card along the top corners and guide it into the

connector, as shown below. (If you are installing a full-length card, insert the front edge of the card into the

corresponding guide inside the computer’s front panel.)

Once the connectors reach the slot, push the card in firmly

(but carefully) to insert it fully. You should feel the card fit into place. If it does not go in smoothly, do not force it; pull the card all the way out and try again.

Secure the end of the card to the computer with the retaining screw.

Installing and Removing Options

3-15

Removing an Option Card

You may need to remove an option card installed in your computer to access components on the main system board-to change a jumper setting, for example. You may also want to remove a card if you no longer need it. Follow these steps:

Remove the retaining screw securing the option card to the computer. Then pull the card straight out of the slot.

Set the card aside with the component side facing up.

Adding Video Memory

Your computer comes with 256KB of video memory. You can increase your video memory to either 512KB or 1024KB by installing four or six video DRAM, 20-pin, 70ns or 80ns, 44256 DIP (Dual Inline Package) chips. This is useful for running graphics-intensive applications or for supporting resolutions up to 1024 x 768 on your monitor. See Appendix A for a table identifying supported colors and resolutions for each amount of video memory.

For the memory to work properly, you must install chips in the following configuration (each bank contains two video memory chips).

Video memory chip configuration

Total

memory

256KB* 512KB

1024KB

Bank 0

Soldered Soldered Soldered

l Standard video memory

3-16

Installing and Removing

Bank 1

Filled Filled

Bank 2

Filled

Options

Bank 3

Filled

Locate the memory chip sockets on the main system board, shown on page 3-5.

Bank 0 (labeled U24 and U40) contains two chips soldered to the system board, so you cannot add video memory in this bank. Bank 1 (U25 and U41) contains the two sockets closest to the soldered chips. Bank 2 (U32 and U46) is the two middle sockets in each set of three and Bank 3 (U33 and U47)

contains the remaining two sockets.

If there is an option card in your way, remove it. See page 3-16 for instructions.

Caution

To avoid generating static electricity and damaging the memory chips, ground yourself by touching the metal surface on the inside of the computer’s back panel. Then remain as stationary as possible while you install them.

Remove the memory chips from their package and inspect each one. The pins should point inward at slightly less than a 90 angle.

If any of the pins are bent, straighten them gently with your fingers or with small tweezers to align them with the other pins. Be careful when you do this; the pins are fragile and can break off easily.

Installing and Removing Options

3-17

Position one of the memory chips over the first socket as shown below, aligning the pins on the chip with the holes in the socket. Make sure the small notch on the end of the chip is facing the outside of the computer.

Gently press the chip halfway into the socket (to make sure

it is correctly aligned). If the chip goes in at an angle, remove it with a chip puller or a small flat-head screwdriver and try again.

When the chip is properly positioned, push down firmly on

both ends of the chip to make sure it is well-seated.

Repeat steps 4 through 6 for each of the remaining chips. Replace any option cards you removed. See page 3-13 for

instructions.

When you start your computer, it displays the video memory briefly before it begins its memory test.

3-18

Installing and Removing Options

Installing the Math Coprocessor

You can enhance your system’s performance for some applications by installing an Intel 80387SX, 33 MHz, 68-pin PLCC type math coprocessor.

Follow these steps to install the math coprocessor:

Locate the socket for the math coprocessor. See page 3-5.

If there is an option card in your way, remove it. See page 3-16 for instructions.

Caution

Before you remove the math coprocessor from its antistatic packaging, touch an unpainted metal surface on the computer chassis. Do not touch the pins on the coprocessor. Handle the coprocessor only by the edges of its case.

Remove the coprocessor from its package and inspect it. If

the pins appear bent, do not install the coprocessor.

Installing and Removing Options

3-19

Position the coprocessor over the socket as shown below. Align the notched corner of the coprocessor (marked with a dot) over the corresponding comer in the socket.

notched corner

’

Be sure to align the pins in the coprocessor directly over the holes in the socket. If you insert the math coprocessor in the wrong position, you could permanently damage it.

Make sure the pins in the coprocessor are directly over the holes in the socket. Then gently push the coprocessor

straight into the socket, pressing evenly on all sides.

Replace any option cards you removed. See page 3-13.

Post-installation Procedures

After you install or remove options such as memory modules or a math coprocessor, you must run SETUP to update the computer’s configuration. See Chapter 1 for instructions. Additionally, you may need to add some commands to your

configuration files. See your operating system manual and the manual that came with your optional equipment.

3-20 Installing and Removing Options

Chapter 4

Installing and Removing Drives

This chapter describes how to install and remove optional drives in your computer. You can use these instructions to install a variety of devices, including hard disk drives, a diskette drive, a tape drive, or a CD-ROM drive. Although your drive may look different from the ones illustrated here, you should be able to install it the same way.

Your computer can hold up to three mass storage devices. You can install a hard disk drive in the internal hard disk drive bay. In the upper horizontal bay, you can install a second hard disk drive (if you have the right cable), a second diskette drive, a tape drive, or a CD-ROM drive.

To install or remove a drive, first remove the computer’s cover as described in Chapter 3. Then use the instructions below to install a hard disk drive in the internal hard disk drive bay or follow the instructions on page 4-11 to install any type of drive in the upper horizontal bay.

If you are installing or removing a non-Epson drive, some of

the steps in this chapter may not apply; see the documentation that came with your drive for more information.

Installing and Removing Drives

4-1

Installing a Hard Disk Drive in the Internal Drive Bay

Your computer may have a hard disk drive already installed

using the hard disk drive mounting bracket. If not, you can install a l-inch (third-height), 3½-inch wide drive below the mounting bracket or above it.

Here you will find steps for the following procedures:

Removing the mounting frames from the hard disk drive (if necessary)

Connecting the hard disk drive cables

Installing the hard disk drive under the mounting bracket (for third-height drives)

Installing the hard disk drive on the mounting bracket.

Note

Be sure to check the jumper settings on the drive before you install a hard disk drive. Also, you will need to know the number of cylinders, heads, sectors, etc. to select the correct

drive type in the SETUP program. See the documentation that came with your drive for this information.

Before you can install a hard disk drive, you need to remove any option cards that may be blocking your access to the hard disk drive area. Once you have installed the drive, replace any option cards you removed. See Chapter 3 for instructions.

4-2

Installing and Removing Drives

Removing the Mounting Frames

If there are mounting frames attached to your hard disk drive, you need to remove them before you can install the drive. Follow these steps:

On your drive, there may be a plastic guiderail and metal grounding plate attached to one of the mounting frames. If so, remove the screws securing them to the mounting frame and remove the guiderail and grounding plate.

plastic guiderail

metal

mounting frames

Then remove the two screws securing each mounting frame to the drive and remove the frames.

Connecting the Hard Disk Drive Cable

To connect the hard disk drive to the computer, you need to

connect two cables: the hard disk drive ribbon cable and a

power supply cable. You should connect these cables before

you secure the drive with the mounting bracket because you

will not be able to attach them once the bracket is in place.

Installing and Removing Drives

4-3

Connecting the Drive Cable to the System Board

If you need to connect the hard disk drive ribbon cable to the system board, follow the steps below. (If the hard disk drive ribbon cable is already attached to the system board, refer to “Connecting the Drive and Power Cables to the Drive” on

page 4-5.)

Locate the hard disk drive connector on the system board.

4-4

Locate the hard disk drive ribbon cable; it is a flat cable with a connector on each end.

Select one of the connectors. Notice the two grooves in one side of the connector. Align the connector so that these grooves face the hard disk drive bay.

Make sure the holes in the cable connector fit over the pins in the system board connector; then push in the cable connector.

Installing and Removing Drives

If you do not correctly align the holes with the pins, you could severely damage your system board when you push m

Connecting the Drive and Power Cables to the Drive

Follow the steps below to connect the hard disk drive ribbon cable and a power supply cable to the drive:

Locate the free connector on the end of the hard disk drive ribbon cable.

Locate pin 1 on the drive connector. If you do not see it on the connector casing, turn the drive over so you can see the drive’s circuit board. You will see a 1 or 2 printed on the

board to identify the side of the connector containing pin 1.

Align the connector on the cable so that the red wire will be closest to pin 1 on the drive.

Make sure the holes in the cable connector fit over all the pins in the hard disk drive connector; then push in the connector.

Locate one of the power supply cables that lead from the power supply. (They have multi-colored wires and a plastic connector on the end.)

Installing and Removing Drives 4-5

Position

the power supply cable connector so that its notched comers line up with the notched comers of the power supply connector on the hard disk drive.

notched

Make sure the holes fit over all the pins and then push in the connector.

Caution

If you do not align the cable connector correctly, you could severely damage your hard disk drive when you push it in.

4-6

Installing and

Removing Drives

Installing the Hard Disk Below the Mounting Bracket

If you have a third-height hard disk drive, you can install it

below the hard disk drive mounting bracket. Refer to the

illustrations below and follow these steps:

Remove the screw securing the mounting bracket to the base of the computer.

Slide the mounting bracket toward the diskette drive bays until the slots clear the tabs.

Lift the mounting bracket out of the computer and set it aside.

Installing and Removing Drives

4-7

Align the hard disk drive so that the cable connectors are facing the diskette drive bays and the four holes at the base of the drive are above the four pegs, as shown below.

pegs

Gently lower the drive over the pegs. When the hard disk

drive is resting on the pegs, it will not move from side to side.

Lower the mounting bracket over the hard disk drive, making sure that the tabs on the computer align with the slots in the mounting bracket.

4-8 Installing and Removing Drives

Slide the bracket toward the side of the computer until the tabs hold the bracket secure.

Secure the mounting bracket with the screw, as shown above.

Installing the Hard Disk On the Mounting Bracket

You can also install a hard disk drive on top of the mounting bracket rather than under it. Refer to the illustration on page 4-7 and the one below while following these steps:

Remove the screw securing the mounting bracket to the base of the computer.

Slide the mounting bracket toward the diskette drive bays until the slots clear the tabs.

Installing and Removing Drives

4-9

Lift the mounting bracket out of the computer.

Turn the hard disk drive over and locate the four mounting holes on the drive.

Position the bracket on the hard disk drive, aligning the holes in the bracket with the holes on the drive.

Secure the bracket to the drive with four screws.

4-10

Lower the slots on the mounting bracket onto the tabs on the computer.

Slide the bracket toward the side of the computer until the

tabs hold the bracket secure.

Secure the mounting bracket with the screw.

Installing and Removing Drives

Removing a Hard Disk Drive From the Internal Drive Bay

To remove a hard disk drive, reverse the installation steps outlined above. Then disconnect the hard disk drive ribbon cable and the power supply cable from the back of the drive. When you disconnect the cables, grasp the connectors and pull them straight out so you do not bend the pins; do not pull on the cables. Use the screw to again secure the hard disk drive mounting bracket to the base of the computer.

Installing a Drive in the Upper Horizontal Drive Bay

Your system comes with a 3.25-inch diskette drive installed in

the lower horizontal drive bay. You can also install a diskette drive, a CD-ROM, a tape drive, or a second hard disk drive in the upper horizontal drive bay. If you install a second hard disk

drive in this bay, make sure you purchase the appropriate cable

to connect both drives to the hard disk drive connector.

Before you install a drive in the upper drive bay, remove the

cover. Once you have the drive installed, replace the cover,

following the instructions in Chapter 3.

Installing and Removing Drives 4-11

Follow these steps to install a drive in the upper horizontal drive bay:

Remove the faceplate from the bay. Place your hand behind

1. the plate through the hole in the drive bay, and push the faceplate forward, as shown below.

4-12

Keep the faceplate in a safe place in case you remove a drive later.

Remove any brackets or mounting frames from the drive.

Installing and Removing Drives

Slide the drive into the bay as far as it will go.

The side of the drive bay contains slots

that

correspond to the mounting holes in the drive. Secure the drive using retaining screws in both sides of the drive.

Installing and Removing Drives

4-13

Connecting the Drive and Power Cables

To connect the drive to the computer, you need to connect both the drive ribbon cable and a power supply cable. Follow the steps below.

If you are installing a diskette drive, locate the diskette drive ribbon cable. The middle of the cable system board.

connected to the

4-14

If you are installing a second diskette drive, one end of the cable is connected to the bottom diskette drive. The cable contains both a card-edge connector and a header connector.

Installing and

Removing Drives

If you are installing a hard disk drive in the upper horizontal bay, make sure you use the proper hard disk drive ribbon cable and connect the drive to the hard disk drive connector. Also, if this is the second hard disk drive in your system, make sure you set the jumpers on both hard disk drives to indicate which is the master and which is the slave drive.

If the drive connector extending from the back of the drive has gold contacts on both sides, use the card-edge connector on the ribbon cable. Make sure you align the key-way (the plastic divider) with the gap in the drive connector.

If the drive connector contains a series of pins, use the header connector. Identify pin 1 on the drive and align the connector so that the red wire is at pin 1.

Locate one of the power supply cables that lead from the power supply. (They have multi-colored wires and a plastic connector on the end.)

Installing and Removing Drives 4-15

Position the power supply cable connector so that its notched comers line up with the notched corners of the drive’s power supply connector. Make sure the holes fit over all the pins and then push in the connector.

notched

corners

Caution

If you do not align the cable connectors correctly, you could severely damage your drive when you push them in.

If you installed a diskette drive in the upper bay, it is drive B; the lower drive is A. However, if you want to reassign the upper diskette drive as drive A, you can change jumpers J17 through J20. See Chapter 3 for instructions.

4-16 Installing and Removing Drives

Removing a Drive from the Upper Drive Bay

To remove a drive from the upper drive bay, follow these steps:

Remove both the ribbon cable connector and the power cable connector from the drive.

Remove the screws securing the drive.

Reach behind the drive and gently push it to the front of the

bay; then pull it out of the slot.

Once you have removed the drive, replace the faceplate by inserting one side of the plate, then gently guiding the other side into place. You will hear it snap into place.

Post-installation Procedures

After you install or remove your drive(s) and replace the cover

on your computer, you need to run the SETUP program to define the correct configuration for your newly-installed drive.

See Chapter 1 for instructions.

Installing and Removing Drives

4-17

Chapter 5

Installing Video Drivers

The Utility diskettes included with your system contain enhanced VGA (video graphics array) drivers and utilities for your computer’s built-in VGA adapter. This chapter describes how to install and use these drivers and utilities.

Your computer’s built-in VGA adapter is compatible with IBM VGA. The drivers and utilities described in this chapter work with any VGA and compatible, multifrequency monitors that use analog input.

Standard VGA monitors display resolutions up to 640 x 480, and you do not need to install the drivers or utilities for your system to operate properly with your application programs at this resolution.

However, if you want to use resolutions over 640 x 480 or take

advantage of the following special features when using certain application programs, you need to install the appropriate drivers:

Enhanced graphic and text modes in 4, 16, and 256 colors

Resolutions up to 1024 x 768

Extended text mode for 132-column text with 25, 30, 43, and

rows.

Your computer comes with 256KB of video memory installed on the system board. You can upgrade the video memory to either 512KB or 1MB by installing additional video memory chips, allowing you to use higher resolutions and more colors. See Chapter 3 for installation instructions.

Installing Video Drivers

5-1

This chapter describes installation procedures for the following

common applications:

Lotus 1-2-3 and Symphony, version 2.x (see page 5-3)

Microsoft Windows, version 3.1 (see page 5-4)

Microsoft Word, version 5.0 (see page 5-5)

Quattro Pro, version 2.x (see page 5-6)

WordPerfect, version 5.1 (see page 5-7)

Your Utility diskettes contain VGA utilities and drivers for additional applications. If you want to install these utilities or an extended video driver for an application not listed above, read the README files on your Utility diskettes. These files will tell you what additional applications are supported and will describe the VGA utilities.

Installing the Drivers

The information in this guide is organized alphabetically by application program or operating environment. To install a particular driver, turn to the page listed above for your application or environment.

Note

Each of the VGA drivers is designed to work with a specific

version of software. Make sure the driver you select is

compatible with the version of software you are using, or you may get unpredictable results.

5-2 Installing Video Drivers

Lotus 1-2-3 or Symphony

If you have not yet installed Lotus 1-2-3 or Symphony, follow the instructions in your Lotus documentation to install it. Then follow these steps to install the drivers:

Insert Utility Diskette 1 in drive A.

Type A : and press Enter to log onto drive A.

Copy the drivers from the Utility Diskette 1 to the Lotus or Symphony program directory on your hard disk.

If you are installing drivers for 1-2-3 to the C:\LOTUS directory, type the following and press Enter:

SET123 C:\LOTUS

If you are installing drivers for Symphony to the C:\SYMPHONY directory, type the following and press

Enter:

SETSYMPH C:\SYMPHONY

Log onto your Lotus program directory.

Type

INSTALL

and press Enter to run the installation

program.

From the main menu,

select Advanced

options

Enter.

Then

select Add new drivers to library

and press

Enter.

When the program finishes adding drivers to the library, select

Modify current driver

set and press Enter.

Installing Video Drivers 5-3

and press

Select Text display to modify the text mode or Graphics Then press

10. Select the TVGA driver you want to install from the displayed list and press Enter.

display to modify the graphics resolution.

Enter.

11. Select Return to menu and press

12. At the Installation menu, select Save changes.

13. At the prompt, type the name you want to use for the driver set and press Enter.

14. Exit the Install program.

15. When you start 1-2-3 or Symphony, type followed by the name of the driver set you want to use, and then press Enter.

Enter.

123

SYMPHONY,

Microsoft Windows

If you have not yet installed Windows 3.1, follow the instructions in your Windows documentation to install it with

the standard VGA driver. Then follow these instructions to

install the new driver:

Log onto your Windows program directory.

Type

SETUP

and press

Enter.

At the System Information

Enter.

From the Display menu, select Other (Requires disk

provided by hardware manufacturer) and press

Enter.

5-4 Installing Video Drivers

screen, select Display and press

Insert the Utility Diskette 1 in drive A.

Type the following path:

A:\WIN

Select the driver you want to install.

Follow the instructions on the screen to finish running SETUP.

Note

All Windows driver files are compressed using Microsoft COMPRESS. If you install the drivers to or from a network server, you must expand all driver files by using Microsoft EXPAND. See your Windows documentation for instructions.

Microsoft Word

If you have not yet installed Word 5.0, follow the instructions in your Word documentation to install it. Then follow these instructions to install the appropriate driver:

Log onto your Word program directory.

Rename the driver file SCREEN.VID to the name SCREEN.OLD.

Insert the Utility Diskette 1 in drive A.

Copy the SCREEN.VID file from the diskette to your Word program directory. Type the following command and press

Enter to copy the file:

COPY A:\WORD\SCREEN.VID

Installing Video Drivers

5-5

Start your Word application.

Press Esc to enter a command.

Press 0 to enter an Option command.

Select Display Mode.

Press F1 to list the display modes available. Choose one of the following display modes to indicate the number of rows for your display:

Text,

*These are 132-column modes and provide no mouse support. Press 1 to see additional drivers.

lines,

30 lines,

43 lines,

lines,

color

color*

16 color*

color*

Your Word application now uses the display mode you

selected.

Quattro Pro

If you have not yet installed your Quattro Pro application, follow the instructions in the Quattro Pro documentation to install it now. Then follow these steps to install the extended

VGA drivers for Quattro Pro:

Log onto your Quattro Pro directory.

Insert the Utility Diskette 1 in drive A.

5-6 Installing Video Drivers

Type the following command and press Enter to copy the new display drivers to your Quattro Pro directory:

COPY A:\QPRO\VIDEO.RSC

Start your Quattro Pro application.

Type /O to select the Options menu.

Type D to display the available display mode drivers.

7. Select Trident VGA.

Select the extended text mode you want to use.

Your Quattro Pro application now uses the display mode you selected.

WordPerfect

If you have not yet installed WordPerfect 5.1, follow the instructions in your WordPerfect documentation to install it. Then follow the instructions below to install the new drivers.

Log onto the WordPerfect directory on your hard disk.

Insert the Utility Diskette 1 in drive A.

Copy the extended text and graphics drivers from the utility disk to your WordPerfect directory by typing:

COPY A:\WP51\*.VRS

Start your WordPerfect application.

Press Shift F1 to display the Setup menu.

Select Display.

Installing Video Drivers 5-7

7. Select Graphics Screen Type.

8. Choose Trident TVGA.

Select one of the extended graphics drivers. Choose from

800 x 600, 16

colors;

1023x768, 16 colors; and 786x1024,

16 colors.

10. Now select

Text Screen Type.

11. Choose Trident VGA.

12. Select the resolution you want for your text driver.

13. Press F7 to exit. Your selection is saved and used for displaying text as well as the print preview and graphics functions of WordPerfect.

5-8 Installing Video Drivers

Chapter 6

Troubleshooting

If you have any problems as you set up and use your computer, refer to this chapter. You can correct most problems by adjusting a cable connection, repeating a software procedure, or resetting the computer.

The troubleshooting suggestions in this chapter are organized in general categories, such as “The computer will not start.” Within each category, a more specific problem is described with possible solutions.

If the suggestions here do not solve the problem, contact your Epson dealer.

Identifying Your System

When you request technical assistance, be ready to provide the serial number of your computer, its system BIOS version

number, its configuration (including the type of disk drives,

monitor, and option cards), and the names and version numbers of any software programs you are using.

Troubleshooting 6-1

Use the following table to locate this information.

Location of system information

System information Location

Serial number On the back panel of the computer Video BIOS version

System BIOS version On SETUP System Information screen

System configuration On SETUP screens

On the screen during power-on diagnostics

DOS version

Software versions

In response to the DOS VER command

In application banner screen; in “About” application window; within application documentation

The Computer Will Not Start

The power light is on, but the computer does not start.

Replace your main operating system diskette and turn on the computer again.

Caution

If you turn off the computer, always wait at least 20 seconds

before turning it back on. This prevents damage to the

computer’s electrical circuitry.

The computer does not start and the power light is not lit.

Make sure the power cord is securely connected to both the AC inlet on the back panel and an electrical outlet.

6-2 Troubleshooting

The power cord is securely connected, but the computer

still does not staff.

Check the electrical outlet for power. Turn off your computer

and unplug the power cord. Plug a lamp into the outlet and turn it on.

You installed of removed system components, and now

your computer does not staff.

Check to make sure you have reconnected all the internal and external cables correctly.

The Computer Does Not Respond

The computer locks up.

Wait a few moments; if your computer does not respond after a reasonable length of time, turn it off, wait 20 seconds, and try again.

You may have installed memory using SIMMs that work at the wrong speed. You can try using the SETUP program to insert a wait state (see Chapter 1) or you can install the correct SIMMs (see Chapter 3).

You turned the computer off and on again, but it still does

not respond.

Try resetting the computer using the Ctrl Alt Del command.

Your computer suddenly stops operating.

You may have overloaded the power supply limitations. See your option card manual(s) for the power requirements for your option card(s). Then check Appendix A to see if you have exceeded the option slot power limits.

Troubleshooting 6-3

Keyboard Problems

The screen displays a keyboard error message when you turn on of reset the computer.

Make sure the keyboard is securely connected to the correct port.

Nothing happens when you type on the keyboard.

See “The Computer Does Not Respond,” above.

The cursor keys on the numeric keypad do not work

properly.

If the Num Lock light in the upper right corner of the keyboard is lit, press NumLock to turn off the function.

If you want to change the initial settings of the num lock function, see “Setting the NumLock On at Boot” in Chapter 1.

Monitor Problems

There is no display on the screen.

Check that the monitor’s power switch is on and that its power light is lit.

The power light is on, but you still do not see anything on the screen.

Check the brightness and contrast controls. If you still do not see anything on the screen, make sure you

connected your monitor to the computer securely.

6-4 Troubleshooting

If you installed a display adapter card, make sure your monitor and display adapter match. Also check to see if the card’s switches or jumpers and the jumpers on the system board are set properly. See Chapter 3 for system board jumper information.

If you are running an application program, see if you need to set up the program for the type of monitor and display adapter you have. Also make sure you are using the appropriate monitor and display adapter for your software.

If your application program requires a monitor that supports graphics but you have a monochrome monitor, the results

%;.,.,.,,.I

The power switch is on but the power light is not on.

Turn off the monitor’s power, wait five seconds, and turn it back on.

If the light still does not come on, check the electrical outlet for power. Turn off your monitor and unplug it from the outlet. Then plug a lamp into the wall outlet and turn it on. If the light turns on, your monitor may be faulty.

Troubleshooting 6-5

Diskette Problems

You see a diskette error message.

Reinsert the diskette, making sure you insert it all the way. If the drive has a latch, turn it down to secure the diskette.

Also, check to see that you have inserted the right type of diskette in the drive. For example, make sure you are not inserting a high-density diskette in a double-density drive.

Reinserting the diskette does not solve the problem.

Insert the diskette in another diskette drive of the same type. If you can read the diskette in a different drive, your drive may be faulty.

The diskette is the right

Check that the diskette is not write-protected, preventing the

drive from writing to the diskette.

Make sure the diskette is formatted. See your operating system

documentation for instructions on formatting diskettes.

You may have a defective diskette. Try copying the files from

the bad diskette to a new diskette.

Something

If you are using DOS, use CHKDSK to repair the files. You may also be able to use special utilities or diagnostics to solve this problem.

is wrong with the data in the files.

type,

but you still see an error.

6-6 Troubleshooting

Diskette Drive Problems

A newly-installed diskette drive is not working properly.

Make sure you have installed the drive correctly and check all

the cable connections.

You see a diskette drive error when you start your computer.

Run the SETUP program and configure your system for the correct type of diskette drive.

The diskette drive is making loud or unusual noises.

Contact your dealer or service representative.

Hard Disk Drive Problems

A newly-installed hard disk drive is not working properly.

Make sure you have installed the drive correctly and check all cable connections. Also, check the jumper settings on your drive.

You see a hard disk drive error when you start your system.

Run SETUP and update your system configuration for the hard disk drive. Make sure you selected the correct drive type.

Make sure the jumpers on the system board are set correctly. See Chapter 3 for jumper information.

You are unable to store data on the hard disk drive.

Make sure you have partitioned and formatted the drive correctly for your operating system. Use the procedures provided in your operating system manual.

Troubleshooting 6-7

Also, make sure your hard disk drive has been physically formatted by the manufacturer. If it has not been physically formatted, use the format utility that came with the drive to format it.

Note that a physical format is different from software-based formatting commands, such as the DOS FORMAT command.

You have been using your hard disk drive successfully for

some time but notice a reduction in performance.

The data on the disk may have become fragmented. Back up all your data and use a disk compaction utility to reorganize the files on your disk.

If you cannot access data on your hard disk or you are seeing read/write errors, the disk may have a physical problem. Contact your dealer.

Software Problems

The application program does not start.

Check that you are following the correct procedure for starting the program and that it is installed correctly. If you do not have a hard disk, make sure the correct diskette is in the diskette drive.

The application program is having trouble reading a key disk.

You may be running an application that requires a slower processor speed. See Chapter 2 for information on setting the processor speed.

6-8 Troubleshooting

Your application has locked the computer, making if

unresponsive to keyboard commands.

Reset the computer and try again. If resetting the computer does not help, turn it off, wait 20 seconds, then turn it on again.

Some software, like OS/2, Unix, or NetWare 3.11, needs a minimum of 4MB to 8MB of RAM to work correctly. Check your software documentation for the minimum memory requirements. If necessary, add additional memory using the instructions in Chapter 3.

Printer Problems

The printer does not work at all.

Check that the printer has power and is properly connected to

the computer. Also make sure your printer has paper in it.

The printer prints garbled information.

Check the printer manual for the printer’s correct DIP switch or control panel settings.

Also, make sure you have the proper drivers installed for your printer.

Option Card Problems

A new/y installed option card is not working correctly.

Make sure the option card is installed correctly and is well-seated in its slot. Run the SETUP program to update your computer’s configuration after you install the card. Also, perform setup procedures for any software you are using with the option card.

Troubleshooting 6-9

Also, see the documentation that came with the option card to set any necessary DIP switches or jumpers on the card.

The main system board of your computer may also have some

jumpers that must be set for the option card to work properly.

See Chapter 3 for system jumper information. Your system may need to operate at the slower processor speed

to access the device. Try reducing the processor speed (see Chapter 2) or inserting a wait state through the SETUP program (see Chapter 1).

You may have inserted an older option card that works at

-5 volts. Make sure you install option cards that meet the system’s power requirements.

An external device connected to the option card is not

working correctly.

Make sure you are using the proper cable to connect the device

to the card.

Memory Module Problems

The memory count displayed by the power-on diagnostics

program is incorrect.

You may have installed the SIMMs incorrectly. They may be

the wrong type or speed, or they may not be inserted all the

way. See Chapter 3 for information on installing SIMMs.

6-10 Troubleshooting

Controller Problems

You see a controller error for the hard disk drive controller, the video controller, or the I/O port controllers when you start your system.

The indicated controller on your system board may be faulty.

If you have an option card with a controller that will work with

your device, you can install it and change the jumper settings

on the system board to disable the built-in controller. You can then continue to use your system until it is convenient for you to have it serviced.

Mouse Problems

Your mouse isn’t working properly or you see an auxiliary device error message.

Make sure the mouse cable is securely connected to one of the

serial ports. Also make sure you installed the mouse driver correctly and selected the right settings for the serial ports in the SETUP program. See the documentation that came with

your mouse and Chapter 1 for instructions.

Troubleshooting

6-11

Appendix A

Specifications

CPU and Memory

32-bit CPU

System speed

Memory

ROM

Video RAM

Intel or AMD 80386SX, 33 MHz microprocessor with 16-bit data bus

High and low speeds available; high speed is 33 MHz, low speed is 8 MHz; speed selection through SETUP program and keyboard commands; zero wait state memory access at high speed; wait states of zero or one selectable through SETUP

2MB or 4MB RAM standard on SIMMs; expandable to 16MB using 256KB, 1MB,

and 4MB SIMMs; SIMMs must be 30-pin, fast-page mode type with 70ns or faster access speed

64KB system BIOS, video BIOS, and SETUP code located in EPROM on main system board

256KB DRAM on main system board; expandable to 512KB or 1024KB using 70ns or 80ns 44256 DIP chips

Shadow RAM

Math coprocessor

Supports shadowing of system and video BIOS ROM into RAM

Optional 80387SX, 33 MHz coprocessor

available

Specifications A-l

Clock/

calendar

Controllers

Real-time clock, calendar, and CMOS RAM socketed on main system board with built-in battery backup

Video

Diskette

Hard disk

Interfaces

Monitor

Parallel

Serial

Trident VGA controller on main system board; provides resolutions up to

1024 x 768

Controller on main system board supports up to two diskette drives

Interface on main system board supports

up to two IDE hard disk drives with

built-in controllers

VGA interface built into system board; 15-pin, D-shell connector

One standard 8-bit parallel, uni-directional interface built into main system board; 25-pin, D-shell connector

Two RS-232C, programmable, asynchronous interfaces built into main system board; 9-pin, D-shell connectors

in 16 colors

Game Keyboard

A-2 Specifications

One 15-pin, D-shell connector PS/2 compatible keyboard interface built

into main system board; num lock setting

selectable through SETUP; 6-pin, mini DIN

connector

Option slots

Three 16-bit full-length and two B-bit half-length I/O expansion slots, ISA compatible, 8 MHz bus speed

Speaker

Mass storage

Diskette drives

Hard disk drives

Other devices

Internal Two 3 1/2-inch wide drives (one internal

mount) and one 5 1/4-inch wide, half-height drive

3.5-inch diskette drive, 1.44MB (high-density) storage capacity

5.25-inch diskette drive, 1.2MB (high-density) storage capacity

3.5-inch diskette drive, 720KB (double-density) storage capacity

5.25-inch diskette drive, 360KB (double-density) storage capacity

3 1/2-inch form factor hard disk drive(s), up to half-height size; the first mounted internally, and second mounted in the horizontal drive bay

Half-height tape drive, CD-ROM, or other storage device; 5 1/4-inch or 3 1/2-inch with mounting frames

Specifications A-3

Physical Characteristics

Width Depth

Height

Weight

15.6 inches (396 mm)

14.5 inches (368 mm)

4.1 inches (104 mm) 15 lb (6.8 kg), without drives or keyboard

Power Supply

Type

Input ranges Maximum

outputs Frequency

Option Slot Power Limits (Total)

Maximum current* For all slots

65 Watt, fan-cooled

90 to 260 VAC

+5 VDC at 7.5 Amps, +12 VDC at

2.0 Amps, -12

to 63 Hz

Volts

4.6 Amps

VDCat0.3

+ 12 Volts

1.8 Amps

Amps

- 12 Volts

0.3 Amps

This system does not support older option cards that may require -5 volts.

A-4 Specifications

Video Memory and Supported Resolutions

Memory

256KB

512KB

1MB

Resolutions

640x480 800x600

1024x768

640x480 800x600

1024x768

640x480 800x600

1024x768

Environmental Requirements

Condition

Temperature

Humidity (non- 20% to 90% condensing)

Altitude -330 to 9,900 ft

Operating range range

41° to 90°F (5° to 32°C)

(-100 to 3.000 m) (-100 to 12,000 m) (-100 to 12,000m)

Non-operating

-4° to 140°F (-20° to 60°C)

10% to 90%

-330 to 39,600 ft

16 16

256 256

256 256 256

Storage range

-4° to 140°F (-20° to 60°C)

10% to 90%

330 to 39,600 ft

Specifications A-5
