5 km / 20 km
Long Range Wireless
AC Bridges
Resilient solutions that overcome the challenges of rural
areas and tricky terrain to supply stable, high-speed
connectivity over vast distances
DAP-3711 / DAP-3712
• The DAP-3711 & DAP-3712 feature high-gain 15 and
23 dBi directional antennas, respectively, supplying
high-speed, stable coverage to up to 20 km away
• Integrated TDMA Technology cuts through
interference to ensure high-speed, consistent
coverage
• Superior throughput with single-band transfer speeds
of up to 867 Mbps
• Stay secure with 128-bit personal and enterprise
wireless encryption
• Support for Power over Ethernet means fewer wires,
for cleaner and easier deployment, and comes with
PoE injector
• IP66-rated water-resistant and dust-tight housing
means the DAP-3711 & DAP-3712 are suitable for
harsh outdoor environments
• 8 kV surge protection protects your network against
unexpected surges, such as lightning strikes
High-Gain Directional Antenna TDMA Technology IP66 Rated PoE Ready
Fast, stable, and long-range wireless
coverage
8 kV Surge Protection High-Speed Wi-Fi Wi-Fi Security Durable, Industrial Design
Your device and network are
protected against unexpected
surges, such as lightning strikes
High speeds and consistent coverage
that filters out interference
Blazing speeds of up to 867 Mbps 128-bit personal and enterprise
Water-resistant and dust-tight
housing boasts a longer product life
128-bit
wireless encryption
Power over Ethernet makes for a
cleaner installation
Modest yet resilient design endures
external conditions while easily
blending into surroundings
2
DAP-3711 & DAP-3712 | 5 km / 20 km Long Range Wireless AC Bridges
Technical Specications
/ DAP-3711 , DAP-3712
Model
DAP-3711 DAP-3712
Product Image
General
Device Interfaces 2 x 100/1000 Mbps Ethernet port, reset button
LEDs Power, LAN, WLAN, signal strength
Antenna Type
Antenna Gain
Internal
15 dBi
1 x 100/1000 Mbps Ethernet port, reset button
Signal strength
Dish
23 dBi
Beamwidth H: 40°, V: 15° H: 10°, V: 10°
Standards 802.11a/n/ac 802.11a/n/ac
Protection 8 kV ESD Protection 8 kV ESD Protection
Enclosure ABS, IP66 compliant ABS, IP66 compliant
Functionality
Operation Modes AP, Station, WDS AP, WDS Station AP, Station, WDS AP, WDS Station
Operating Frequency 5180~5320 MHz, 5745~5825 MHz 5180~5320 MHz, 5745~5825 MHz
Max. Transmit Power¹ 27 dBm 27 dBm
Wireless Speed Up to 867 Mbps Up to 867 Mbps
Bandwidth Support
20/40/80 MHz 20/40/80 MHz
Maximum Bridging Distance Up to 5 km (between 2 x DAP-3711) Up to 20 km (between 2 x DAP-3712)
Software
Wireless Configuration
Auto channel support, transmit power selection,
SSID broadcast enabling/disabling
Auto channel support, transmit power selection,
SSID broadcast enabling/disabling
Security 802.11i 128-bit AES Personal / Enterprise 802.11i 128-bit AES Personal / Enterprise
System Tools
Smart Wireless Technology
Advanced Features
LAN Type
VLAN Support
Firewall
Monitors
Firmware Upgrade
Ping, traceroute, NTP, ping watchdog, syslog,
spectrum analyzer, throughput testing (lperf)
TDMA, Auto ACK, intelligent rate control,
co-channel interference avoidance
Ping, traceroute, NTP, ping watchdog, syslog,
spectrum analyzer, throughput testing (lperf)
TDMA, Auto ACK, intelligent rate control,
co-channel interference avoidance
Max. station limit Max. station limit
Static, DHCP Static, DHCP
Yes Yes
IP / MAC filter IP / MAC filter
Throughput, interfaces, routes table, bridge
table, ARP table, AP information, syslog
Throughput, interfaces, routes table, bridge
table, ARP table, AP information, syslog
Web-based upgrade Web-based upgrade
3
DAP-3711 & DAP-3712 | 5 km / 20 km Long Range Wireless AC Bridges
Technical Specications
/ DAP-3711 , DAP-3712
Model
DAP-3711 DAP-3712
Product Image
Physical
Power Input
PoE 24 V
PoE+ 48 V
(PoE Injector included)
Power Consumption ≤ 15 W ≤ 15 W
Operating Temperature -40ºC to 65ºC -40ºC to 65ºC
Storage Temperature
-40ºC to 85ºC -40ºC to 85ºC
Operating Humidity 0% to 90% 0% to 90%
Storage Humidity 0% to 90% 0% to 90%
Weight 600 g
Dimensions 288 x 88 x 45 mm
Certifications CE, FCC
900 g
372 x 372 x 241 mm
CE, FCC
Antenna Patterns
Horizontal
Vertical
¹ Note that the maximum transmit power varies depending on the regulations of individual countries and jurisdictions.
