DigiTech HT-2 User Manual
DECLARATION OF CONFORMITY
Manufacturer’s Name: DigiTech
Manufacturer’s Address: 8760 S. Sandy Parkway
Sandy, Utah 84070, USA
declares that the product:
Product name: HardWire HT-2
Product option: All (requires Class II power
conforms to the following Product Specifications:
Safety: IEC 60065 (7th ed. 2001)
EMC: EN 55013 (2001+A1)
EN 55020 (1998)
Supplementary Information:
The product herewith complies with the requirements of the
Low Voltage Directive 2006/95/EC and the EMC Directive
2004/108/EC.
Vice-President of Engineering
8760 S. Sandy Parkway
Sandy, Utah 84070, USA
Date: June 5, 2008
European Contact: Your local DigiTech Sales and
Harman Music Group
8760 South Sandy Parkway
Sandy, Utah
84070 USA
Ph: (801) 566-8800
Fax: (801) 568-7583
adapter that conforms to the
requirements of EN60065,
EN60742, or equivalent.)
Service Office or :
Warning
For your protection, please read the following:
Important Safety Instr uctions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Do not use this apparatus near water.
5. Clean only with dry cloth.
6. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
7. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
8. Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
9. Unplug this apparatus during lightning storms or when unused for long periods of time.
10. No user serviceable par ts inside. Refer all ser vicing to qualified ser vice personnel. Servicing is required
when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged,
liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to
rain or moisture, does not oper ate normally, or has been dropped.
11. WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or
moisture.
12. Refer to labels on the unit, including bottom cover, or other markings and pertinent information.
If you want to dispose of this product, do not mix it with gener al household waste. There
is a separate collection system for used electronic products in accordance with legislation
that requires proper treatment, recovery and recycling.
Private household in the 25 member states of the EU, in Switzerland and Norway may return their used
electronic product free of char ge to designated collection facilities or to a retailer (if you purchase a
similar new one).
For Countries not mentioned above, please contact your local authorities for a correct method of
disposal.
By doing so you will ensure that your disposed product undergoes the necessary treatment, recovery
and recycling and thus prevent potential negative effects on the environment and human health.
WARRANTY:
We at DigiTech are proud of our products and back-up each one with the following warranty:
The warranty registration card must be mailed within ten days after purchase date to validate this warranty.
DigiTech warrants this product, when used solely within the U.S., to be free from defects in materials and workmanship
under normal use and service.
DigiTech liability under this warranty is limited to repairing or replacing defective materials that show evidence of defect,
provided the product is returned to DigiTech WITH RETURN AUTHORIZATION, where all parts and labor will be
covered up to a period of one year (this warranty is extended to a period of six years when the product has been properly
registered by mail or through our website). A Return Authorization number may be obtained from DigiTech by telephone.
The company shall not be liable for any consequential damage as a result of the product's use in any circuit or assembly.
Proof-of-purchase is considered to be the burden of the consumer.
DigiTech reserves the right to make changes in design, or make additions to, or improvements upon this product without
incurring any obligation to install the same on products previously manufactured.
The consumer forfeits the benefits of this warranty if the product's main assembly is opened and tampered with by anyone
other than a certified DigiTech technician or, if the product is used with voltages outside of the range suggested by the
manufacturer.
The foregoing is in lieu of all other warranties, expressed or implied, and DigiTech neither assumes nor authorizes any
person to assume any obligation or liability in connection with the sale of this product. In no event shall DigiTech or its
dealers be liable for special or consequential damages or from any delay in the performance of this warranty due to causes
beyond their control.
NOTE:The information contained in this manual is subject to change at any time without notification. Some information
contained in this manual may also be inaccurate due to undocumented changes in the product or operating system since
this version of the manual was completed. The information contained in this version of the owner's manual supersedes all
previous versions.
Introduction
More than a remarkable achievement, HardWire™ represents a collection of
significant improvements in effects pedals for guitar. HardWire pedals provide a suite of well-known effects, each with superior tone and control. But
these pedals go above and beyond their peers to provide such distinguishing
features as true bypass and high voltage operation, making them essential
additions to the signal chain of players who know about sound quality and
demand the utmost in performance.
Included Items:
HardWire HT-2 Tuner
•
Foot Switch Glow Sticker
•
Hook-and-loop Pedalboard Pad
•
Warranty card
•
1
2
4
5
6
11
1
3
7
3
8 9
10
2
What Does This Do?
Mode Button - Selects the display mode (Normal or Strobe) for
1.
the Tuning LED Array. The modes are labeled below the last two
LEDs of the Tuning LED Array.
Input - Connect your instrument here. This jack enables battery
2.
power to the pedal when connected. To prolong battery life, disconnect the cable from the Input jack when not in use. If the optional
Harman PS200R power supply is used, cables can remain connected.
Foot Switch Release Pins - These two pins are spring loaded
3.
hinges that hold the Foot Switch in place. See page 13 for information on accessing and changing the battery.
Foot Switch - Turns the Tuner on and off.
4.
Thru Output - Connect this output to the input of your amp or
5.
the input of another pedal if you want the output signal from your
instrument to be audible when the tuner is enabled.
3
Mute Output - Connect this output to the input of your amp or
6.
the input of another pedal if you want the output signal from your
instrument to be muted when the tuner is enabled.
Tuning Button - Selects the different tuning references. The tuning
7.
references are labeled below the first 9 LEDs of the Tuning LED Array.
DC Adapter Jack - Connect (an optional) Harman PS200R
8.
power supply to this jack. Use the proper supply for your area’s
mains line voltage.
LED Indicator - Lights when the effect is turned on. When bat-
9.
tery power is low (approximately 15 minutes before it dies), the
Indicator LED begins to dim giving you advanced warning that very
shortly you will need to replace the battery.
Note Display - Displays the note being tuned. The decimal point
10.
in the lower right corner of the display will light to indicate the
sharp of the note is played (i.e. G. = G#).
4
