Denon AVR-2113CI Owners Manual

Basic version

Advanced version

Information

DVD

AVR-2113CI

INTEGRATED NETWORK AV RECEIVER

Owner’s Manual

SAFETY PRECAUTIONS

Basic version

Advanced version

Information

DVD

IMPORTANT SAFETY

FCC INFORMATION (For US customers)

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION:

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning ﬂash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufﬁcient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

WARNING:

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

CAUTION:

HOT SURFACE. DO NOT TOUCH.

The top surface over the internal heat sink may become hot

Hot

surface

mark

when operating this product continuously. Do not touch hot areas, especially around the “Hot surface mark” and the top panel.

INSTRUCTIONS

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including ampliﬁers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not ﬁt into your outlet, consult an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11. Only use attachments/accessories speciﬁed by the manufacturer.

12. Use only with the cart, stand, tripod, bracket, or table speciﬁed by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/ apparatus combination to avoid injury from tip-over.

13. Unplug this apparatus during lightning storms or when unused for long periods of time.

14. Refer all servicing to qualiﬁed service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

15. Batteries shall not be exposed to excessive heat such as sunshine, ﬁre or the like.

CAUTION:

To completely disconnect this product from the mains, disconnect the plug from the wall socket outlet. The mains plug is used to completely interrupt the power supply to the unit and must be within easy access by the user.

1. COMPLIANCE INFORMATION

Product Name: Integrated Network AV Receiver Model Number: AVR-2113CI This product complies with Part 15 of the FCC Rules. Operation is subject

to the following two conditions: (1) this product may not cause harmful interference, and (2) this product must accept any interference received,

including interference that may cause undesired operation. Denon Electronics (USA), LLC (a D&M Holdings Company) 100 Corporate Drive Mahwah, NJ 07430-2041 Tel. (201) 762 -6665

2. IMPORTANT NOTICE: DO NOT MODIFY THIS PRODUCT

This product, when installed as indicated in the instructions contained

in this manual, meets FCC requirements. Modiﬁcation not expressly

approved by DENON may void your authority, granted by the FCC, to use

the product.

3. IMPORTANT

When connecting this product to network hub or router, use only a

shielded STP or ScTP LAN cable which is available at retailer. Follow all installation instructions. Failure to follow instructions could void

your authority, granted by the FCC, to use the product.

4. NOTE

This product has been tested and found to comply with the limits for

a Class B digital device, pursuant to Part 15 of the FCC Rules. These

limits are designed to provide reasonable protection against harmful

interference in a residential installation. This product generates, uses and can radiate radio frequency energy and,

if not installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this

product does cause harmful interference to radio or television reception,

which can be determined by turning the product OFF and ON, the user

is encouraged to try to correct the interference by one or more of the

following measures:

•Reorientorrelocatethereceivingantenna.

•Increasetheseparationbetweentheequipmentandreceiver.

•Connect the productintoan outlet on acircuitdifferent from that to

which the receiver is connected.

•Consultthelocalretailerauthorizedtodistributethistypeofproductor

an experienced radio/TV technician for help.

For Canadian customers:

This Class B digital apparatus complies with Canadian ICES-003.

NOTES ON USE

Basic version

Advanced version

Information

DVD

n CAUTIONS ON INSTALLATION

WARNINGS

•Avoid high temperatures. Allow for sufﬁcient heat dispersion when installed in a rack.

•Handle the power cord carefully. Hold the plug when unplugging the cord.

•Keep the unit free from moisture, water, and dust.

•Unplug the power cord when not using the unit for long periods of time.

•Do not obstruct the ventilation holes.

•Do not let foreign objects into the unit.

•Do not let insecticides, benzene, and thinner come in contact with the unit.

•Never disassemble or modify the unit in any way.

•Ventilation should not be impeded by covering the ventilation openings

with items, such as newspapers, tablecloths or curtains.

•Naked ﬂame sources such as lighted candles should not be placed on the unit.

•Observe and follow local regulations regarding battery disposal.

•Do not expose the unit to dripping or splashing ﬂuids.

•Do not place objects ﬁlled with liquids, such as vases, on the unit.

•Do not handle the mains cord with wet hands.

•When the switch is in the OFF (STANDBY) position, the equipment is not

completely switched off from MAINS.

•The equipment shall be installed near the power supply so that the power supply is easily accessible.

z z

Wall

z For proper heat dispersal, do not install this unit in a conﬁned

space, such as a bookcase or similar enclosure.

•More than 12 in. (0.3 m) is recommended.

•Do not place any other equipment on this unit.

Getting started

Basic version

Advanced version

Information

DVD

Thank you for purchasing this DENON product. To ensure proper operation, please read this owner’s manual carefully before using the product. After reading them, be sure to keep them for future reference.

Contents

Getting started ·············································································· 1

Accessories ··················································································2 Features ························································································ 2 Cautions on handling ····································································3

Basic version ············································································4

Connections ··················································································· 5

Important information ··································································· 5 Connecting an HDMI-compatible device ······································ 7 Connecting an HDMI-incompatible device ·································12 Connecting an external control device ········································21 Connecting to a home network (LAN) ········································ 22 Connecting the power cord ························································ 23

Setup ···························································································· 24

Set up speakers (Audyssey® Setup) ·········································· 24 Making the network settings (Network) ····································· 30

Playback (Basic operation) ························································· 31

Important information ································································· 31 Playing a Blu-ray Disc player/DVD player ···································· 32 Playing a CD player ····································································· 32 Playing an iPod············································································33 Playing a USB memory device ····················································36 Listening to FM broadcasts ························································ 39

Network contents ·······································································47

Listening to internet radio ··························································· 47 Playing back ﬁles stored on a PC and NAS ································· 50 Using online services ·································································· 54 Convenient functions ·································································· 62 AirPlay function ··········································································· 66

Selecting a listening mode (Sound Mode) ·······························68

Selecting a listening mode··························································68

Advanced version ································································74

Installation/connection/setup of speakers (Advanced) ··········75

Speaker installation ····································································· 75 Speaker connection ···································································· 77 Set up speakers ·········································································· 85

Playback (Advanced operation) ················································· 87

HDMI control function ································································ 87 Sleep timer function ···································································88 Quick select function ·································································· 89 Web control function ·································································· 90 Various memory functions ·························································· 91

Playback in ZONE2 (Separate room) ········································· 92

Audio output ··············································································· 92 Playback ······················································································ 92 Sleep timer function ···································································93

How to make detailed settings ·················································· 94

Menu map ··················································································94 Examples of menu screen displays ············································ 96 Examples of menu and front display ··········································97 Inputting characters ···································································· 98 Audio···························································································99 Video ························································································· 105 Inputs ························································································ 110 Speakers ··················································································· 114 Network ···················································································· 118 General ·····················································································122

Information ···········································································128

Part names and functions·························································129

Front panel ················································································ 129 Display ······················································································ 130 Rear panel ················································································· 131 Remote control unit ·································································· 132

Other information ·····································································134

Trademark information ······························································134 Surround ··················································································· 135 Relationship between video signals and monitor output ·········· 139 Explanation of terms ································································· 141

Troubleshooting ········································································ 144

Resetting the microprocessor ··················································148

Speciﬁcations ············································································149

Accessories

Basic version

Advanced version

Information

DVD

Check that the following parts are supplied with the product.

q Getting Started ........................................................................ 1

w CD-ROM (Owner’s manual) .................................................... 1

e Safety Instructions .................................................................. 1

r Warranty (for North America model only) ................................ 1

t Service network list ................................................................. 1

y Remote control unit (RC-1167) ................................................ 1

u R03/AAA batteries ................................................................... 2

i Setup microphone (ACM1HB) ................................................. 1

o FM indoor antenna .................................................................. 1

y oi

Features

With a discrete-circuit conﬁguration, the power ampliﬁer provides identical quality for all 7 channels (125 W x 7ch)

The unit is equipped with a power ampliﬁer that reproduces highﬁdelity sound in sound mode with equal quality and power for all channels, true to the original sound. The power ampliﬁer circuit adopts a discrete-circuit conﬁguration that achieves high-quality surround sound reproduction.

Supports internet radio, music, and photograph streaming Supports AirPlay® (vpage66)

You can enjoy a wide variety of content, including listening to Internet radio, playing the audio ﬁles stored on your PC, and displaying on a TV the photographs stored on your PC. This unit also supports AirPlay that lets you stream your music library from an iPhone, iPad, iPod touch or iTunes.

Compatible with “Denon Remote App” for performing basic operations of the unit with an iPad, iPhone or Android smartphone

“Denon Remote App” is application software that allows you to perform basic operations with an iPad, iPhone, Android smartphone or Android tablet such as turning the unit ON/OFF, controlling the volume, and switching the source.

z1 Download “Denon Remote App” from iTunes® App Store.

The unit needs to be connected to a LAN and the iPhone/iPod touch needs to be connected to the same network by Wi-Fi (wireless LAN).

“Setup Assistant”, providing easy-to-follow setup instructions

First select the language when prompted. Then simply follow the instructions displayed on the TV screen to set up the speakers, network, etc.

Easy to use, Graphical User Interface

This unit is equipped with an easy to see “Graphical User Interface” that uses menu displays and levels. The use of level displays increases operability of the this unit.

HDMI connectors enable connection to various digital AV devices (input: 6, output: 1)

The unit is equipped with 6 HDMI input connectors for connecting devices with HDMI connectors, such as a Blu-ray Disc player, game machine, HD digital camcorder, etc.

Supports HDMI (3D, ARC, Deep Color, “x.v.Color”, Auto Lip Sync, 4K) and HDMI control function (vpage7)

In addition to HDMI 3D and ARC (Auto Return Channel) functions, this unit supports the video pass-through function, which outputs video to TV without changing the video quality when video signals of 4K (3840 × 2160 pixels) are input, and the GUI overlay function, which overlays the menu screen (GUI) on the 4K video screen.

Digital video processor up-scales analog video signals (SD resolution) to 4K

This unit is equipped with the 4K video upscaling function, which allows for outputting analog or SD (standard video quality) video to HDMI at 4K (3840 × 2160 pixels). This enables the unit and a TV connected with a single HDMI cable and any video source to be reproduced precisely with HD level of quality.

Direct play for iPod® and iPhone® via USB (vpage18)

Music data from an iPod can be played back if you connect the USB cable supplied with the iPod via the USB port of this unit, and also an iPod can be controlled with the remote control unit for this unit.

Cautions on handling

Basic version

Advanced version

Information

DVD

•Before turning the power on

Check once again that all connections are correct and that there are no problems with the connection cables.

•Power is supplied to some of the circuitry even when the unit is set to the standby mode. When going on vacation or leaving home for long periods of time, be sure to unplug the power cord from the power outlet.

•About condensation

If there is a major difference in temperature between the inside of the unit and the surroundings, condensation (dew) may form on the operating parts inside the unit, causing the unit not to operate properly. If this happens, let the unit sit for an hour or two with the power turned off and wait until there is little difference in temperature before using the unit.

•Cautions on using mobile phones

Using a mobile phone near this unit may result in noise. If that occurs, move the mobile phone away from this unit when it is in use.

•Moving the unit

Turn off the power and unplug the power cord from the power outlet. Next, disconnect the connection cables to other system units before moving the unit.

•About care

•Wipe the cabinet and control panel clean with a soft cloth.

•Follow the instructions when using a chemical cleaner.

•Benzene, paint thinner or other organic solvents as well as

insecticide may cause material changes and discoloration if brought into contact with the unit, and should therefore not be used.

Basic

Basic version

Advanced version

Information

Basic version

DVD

version

Basic version

Here, we explain the connections and basic operation methods for this unit.

F Connections vpage5 F Settings vpage24 F Playback (Basic operation) vpage31 F Selecting a listening mode (Sound Mode) vpage68

Connections

Basic version

Advanced version

Information

Basic version

DVD

Important information

Make connections before using this unit. To create a home theater that can play back higher quality video and audio by fully utilizing the capabilities of this unit and your video devices, connect this unit to each of your video devices with HDMI cables.

n HDMI-compatible device

vpage8 vpage10 vpage10

n HDMI-compatible device

If your video device does not support HDMI connections, use the following connection.

n HDMI-incompatible device

This unit can change the source that is assigned to the DIGITAL AUDIO IN and COMPONENT VIDEO IN connectors. You can change the source for connectors listed in Input connector setting within pages that describe connections for devices. For details on assigning a source to connectors, see “Changing the source assigned to connectors” (vpage12). For the setting method, see “Input Assign” (vpage111).

NOTE

•The menu screen is only displayed on TV connected to this unit via HDMI. If your TV is connected to this unit via other video output connectors, perform menu operations while seeing the display on this unit.

•Do not plug in the power cord until all connections have been completed. However, when the “Setup Assistant” is running, follow the instructions in the “Setup Assistant” (C page 7) screen for making connections. (During “Setup Assistant” operation, the input/output connectors do not conduct current.)

•When running the “Setup Assistant” (C page 7), turn off the power supply of connected devices.

•When making connections, also refer to the operating instructions of the other devices being connected.

•Be sure to connect the left and right channels properly (left with left, right with right).

•Do not bundle power cords together with connection cables. Doing so can result in noise.

vpage10 vpage10 vpage10

n HDMI-incompatible device

vpage13 vpage14 vpage15

vpage16 vpage17 vpage18

vpage19 vpage20 vpage22

vpage77 vpage23

Important information

Basic version

Advanced version

Information

Basic version

DVD

Converting input video signals for output (Video conversion function)

This unit is equipped with three types of video input connectors (HDMI, Component video and video) and two types of video output connectors (HDMI and video). This function automatically converts various formats of video signals input to this unit into the formats used to output the video signals from this unit to a monitor.

GFlow of video signals for MAIN ZONEH

HDMI-compatible TV

Input

HDMI connectorHDMI connector

HDMI-incompatible

Video device

Output

HDMI connector

Component video

connectors

This unit

Input

(IN)

HDMI signal HDMI signal

HDMI connector

Component video

signal

Component video

connectors

Video signal Video signal

Output

(MONITOR OUT)

Make Settings as Necessary

•If you do not want this unit to convert video signals automatically, use the following setting item to disable this function. “Video Conversion” (vpage107)

•If you want to change the resolution of video signals output to the TV, use the following setting item to do so. “Resolution” (vpage108)

•The video conversion function supports the NTSC, PAL, SECAM, NTSC 4.43, PAL-N, PAL-M and PAL-60 formats.

•Resolutions of HDMI-compatible TVs can be checked at “Video” – “Monitor” (vpage124).

NOTE

•HDMI signals are digital. HDMI signals cannot be converted into analog signals.

•When a non-standard video signal from a game machine or some other source is input, the video conversion function might not operate.

Video connector

For example, if you connect this unit to an HDMI-compatible TV with a single HDMI cable, this unit automatically converts input signals other than HDMI video signals to HDMI signals to output from the HDMI connector to the TV. This unit outputs only one type of video signals, so video signals output from this unit to the TV remain unchanged even if you switch to a device that outputs another type of video signals for playback. Therefore, you do not need to switch the video input on the TV. Furthermore, this unit converts the input analog video signals such as video and component video signals to high resolution digital HDMI video signals for output, improving the quality of the video. If your TV does not support HDMI connections, connect this unit to TV with analog video connectors. This unit can not convert HDMI input signals to analog video signals, so when inputting from an HDMI device, use component video or video input connectors.

Video connector Video connector

Video connector

Connecting an HDMI-compatible device

Basic version

Advanced version

Information

Basic version

DVD

You can connect up to seven HDMI-compatible devices (6-inputs/1-output) to the unit. If the device connected to this unit is equipped with an HDMI connector, it is recommended to use HDMI connections. Connections with an HDMI cable offer the following beneﬁts that can not be achieved with other connection methods.

•High quality playback by transmitting audio and video via digital signals

HDMI connections can transmit high deﬁnition video and high quality audio formats adopted by Bluray disc players (Dolby Digital Plus, Dolby TrueHD, dts-HD, dts-HD Master Audio). HDMI connections also convey information required for playback between devices. The information is used for copyright protection and TV resolution recognition, the ARC function, the HDMI control function, etc.

•Transmission of audio and video signals with a single HDMI cable

Previous connections require multiple audio and video cables, but HDMI connections require only a single HDMI cable to transmit audio and video signals. This allows wires in a home theater system, which tend to be complicated, to be more organized.

•Mutual control through the HDMI control function (vpage87)

This unit and the HDMI device connected via HDMI can be linked to perform operations such as power control, volume control, and input source switching.

•Other video and audio functions, such as 3D video playback, Content Type, the ARC function,

are supported (vpage11).

•There is more than one version of HDMI standard. The supported functions and the performance vary according to the version. This unit complies with the HDMI standard, supporting the ARC and 3D playback functions. To enjoy these functions, the HDMI device connected to this unit also needs to use the same version of the standard. For the version of the HDMI standard on the device connected to this unit, see the device’s manual.

•Some TVs do not support audio input via HDMI connections. For details, see your TV’s manual.

n Before connecting this unit to TV via HDMI connections (vpage8) n Connecting this unit to a TV via HDMI connections (vpage9)

n Connecting this unit to video devices via HDMI connections (vpage10)

n HDMI function (vpage11) n Settings related to HDMI connections (vpage11)

Before connecting this unit to TV via HDMI connections

Basic version

Advanced version

Information

Basic version

DVD

There are 2 methods to connect HDMI-compatible TV to this unit. Use the connection method that suits your TV.

Does the TV to be connected to this unit support the ARC function?

Yes No

Connecting an HDMI-compatible device

n About ARC (Audio Return Channel) function

This function plays TV audio on this unit by sending the TV audio signal to this unit via HDMI cable. If a TV without the ARC function is connected via HDMI connections, video signals of the playback device connected to this unit are transmitted to the TV, but this unit can not play back the audio from the TV. If you want to enjoy surround audio for TV program, a separate audio cable connection is required. In contrast, if a TV with the ARC function is connected via HDMI connections, no audio cable connection is required. Audio signals from the TV can be input to this unit through the HDMI cable between this unit and the TV. This function allows you to enjoy surround playback on this unit for the TV.

Connecting this unit to a TV via

HDMI connections (vpage9)

Connecting this unit to a TV via

HDMI connections (vpage9)

Connecting a TV (vpage13)

For audio connections, use a method other than HDMI connections.

When the ARC function is used, connect a device with a “Standard HDMI cable with Ethernet” or “High Speed HDMI cable with Ethernet” for HDMI. Refer to the owner’s manual for your TV for details about TV connection and settings.

GConnection to a TV with the ARC functionH

Audio signals from the TV

IN OUT

GConnection to a TV without the ARC functionH

Audio signals from the TV

IN OUT

Audio signals from the TV

Optical cable

This unit SpeakersTV

INOUT

Audio from the TV

Connecting this unit to a TV via HDMI connections

Basic version

Advanced version

Information

Basic version

DVD

Cables used for connections

Audio and video cable (sold separately)

HDMI cable

HDMI

(ARC)

Connecting an HDMI-compatible device

•Video signals are not output if the input video signals do not match the monitor’s resolution. In this case, switch the Blu-ray Disc/DVD player’s resolution to a resolution with which the monitor is compatible.

•When this unit and monitor are connected with an HDMI cable, if the monitor is not compatible with HDMI audio signal playback, only the video signals are output to the monitor. Make audio connections (vpage13 “Connecting a TV”).

NOTE

•The audio signal from the HDMI output connector (sampling frequency, number of channels, etc.) may be limited by the HDMI audio speciﬁcations of the connected device regarding permissible inputs.

•When connecting a TV that does not support the ARC function, an audio cable connection is required in addition to the HDMI cable. In this case, refer to “Connecting a TV” (vpage13) for the connection method. For the ARC function, see “About ARC (Audio Return Channel) function” (vpage8).

Connecting to a device equipped with a DVI-D connector

The DVI-D (Digital Visual Interface) method is also used for video transmission via digital signals. This is developed mainly for computers, and some AV devices such as projectors are equipped with this interface. To output HDMI video signals to a DVI-D video input compatible device, use an HDMI/DVI conversion cable, which converts HDMI video signals to DVI signals. The DVI-D connector can transmit high quality digital signals, but the copy guard and other issues may hinder normal operations for some device combinations.

NOTE

•No sound is output when connected to a device equipped with a DVI-D connector. Make audio connections as described in “Connecting a TV” (vpage13).

•Signals cannot be output to DVI-D devices that do not support HDCP.

•Depending on the combination of devices, the video signals may not be output.

Connecting this unit to video devices via HDMI connections

Basic version

Advanced version

Information

Basic version

DVD

Cables used for connections

Audio and video cable (sold separately)

HDMI cable

•This interface allows transfer of digital video signals and digital audio signals over a single HDMI cable.

Blu-ray

Set-top

box

DVD

player

Disc

player

Game

console

Media player

Digital

camcorder

HDMI

OUT

Connecting an HDMI-compatible device

HDMI

OUT

HDMI

OUT

HDMI

OUT

HDMI

OUT

HDMI

OUT

GRear panelH

GFront panelH

•When this unit is connected to other devices with HDMI cables, connect this unit and TV also with an HDMI cable.

•When connecting a device that supports Deep Color, please use a “High Speed HDMI cable” or “High Speed HDMI cable with Ethernet”.

Connecting an HDMI-compatible device

Basic version

Advanced version

Information

Basic version

DVD

HDMI function

This unit supports the following HDMI functions:

n About 3D function

This unit supports input and output of 3D (3 dimensional) video signals of HDMI. To play back 3D video, you need a TV and player that provide support for the HDMI 3D function and a pair of 3D glasses.

NOTE

•When playing back 3D video, refer to the instructions provided in the manual of your playback device together with this manual.

•When playing back 3D video content, the menu screen or status display screen can be superimposed over the image. However, the menu screen or status display screen cannot be superimposed over certain 3D video content.

•If 3D video with no 3D information is input, the menu screen and status display on this unit are displayed over the playback video.

•If 2D video is converted to 3D video on the television, the menu screen and status display on this unit are not displayed correctly. To view the menu screen and status display on this unit correctly, turn the television setting that converts 2D video to 3D video off.

n About 4K function

This unit supports input and output of 4K (3840 × 2160 pixels) video signals of HDMI.

n HDMI control function (vpage87)

This function allows you to operate external devices from the unit and operate the unit from external devices.

NOTE

•The HDMI control function may not work depending on the device it is connected to and its settings.

•You cannot operate a TV or Blu-ray Disc player/DVD player that is not compatible with the HDMI control

function.

n About Content Type

This function was added with the HDMI standard. It automatically makes settings suitable for the videooutput type (content information).

NOTE

To enable the Content Type, set “Video Mode” to “Auto” (vpage107).

n Deep Color (vpage141)

When a device supporting Deep Color is connected, use a cable compatible with “High Speed HDMI cable” or “High Speed HDMI cable with Ethernet”.

n Auto Lip Sync (vpage106, 141) n “x.v.Color”, sYCC601 color, Adobe RGB color, Adobe YCC601 color

(vpage141, 142) n High deﬁnition digital audio format n ARC (Audio Return Channel) (vpage8)

In order to play back digital video and audio such as BD-Video or DVD-Video via HDMI connection, both this unit and TV or the player need to support the copyright protection system known as HDCP (Highbandwidth Digital Content Protection System). HDCP is copyright protection technology comprised of data encryption and authentication of the connected AV devices. This unit supports HDCP.

•If a device that does not support HDCP is connected, video and audio are not output correctly. Read the owner’s manual of your television or player for more information.

Settings related to HDMI connections

Set as necessary. For details, see the respective reference pages.

n HDMI Setup (vpage106)

Make settings for HDMI video/audio output.

•Auto Lip Sync •HDMI Control •Power Off Control

•HDMI Audio Out •Standby Source

NOTE

The audio signal input from the HDMI input connector can be output as an output signal from the HDMI output connector by setting the HDMI audio output destination to TV. Audio signals input via the Analog/Coaxial/Optical input connectors cannot be output from the HDMI MONITOR output connector.

Connecting an HDMI-incompatible device

Basic version

Advanced version

Information

Basic version

DVD

For high quality video and surround playback, it is recommended to use an HDMI cable to connect this unit to TV and other video devices (vpage7 “Connecting an HDMI-compatible device”). This section describes connections when your device does not support HDMI connections.

Connection methods for various devices

Cables used for connections

Component video cable

Video cable (sold separately)

Changing the source assigned to connectors

This unit can change the source that is assigned to the DIGITAL AUDIO IN and COMPONENT VIDEO IN connectors.

vpage13 vpage14

vpage15 vpage16

vpage17 vpage18

vpage19 vpage20

vpage22

vpage77

vpage23

Video cable

Coaxial digital cable

Optical cable

Audio cable

Ethernet cable

Audio cable (sold separately)

Cable (sold separately)

Here, a connection to the Blu-ray disc player is taken as an example

for explanation. The rear panel video input and digital audio input connectors do not have the input connector indication for Blu-ray disc players (Blu-ray). However, DIGITAL AUDIO IN and COMPONENT VIDEO IN connectors have the “ASSIGNABLE” indication, which means that you can change the source assigned to these connectors. You can assign Blu-ray disc players to these connectors to use them for Blu-ray disc players. Select “Blu-ray” when switching functions on this unit to play back the source connected to these connectors.

n How to change the source assigned to

connectors (vpage111)

Connecting an HDMI-incompatible device

Basic version

Advanced version

Information

Basic version

DVD

Connecting a TV

•This section describes how to connect when your TV does not support HDMI connections.

For instructions on HDMI connections, see “Connecting an HDMI-compatible device” (vpage7).

•If the TV connected to this unit is equipped with an HDMI connector that supports ARC, digital audio

signals from TV can be transmitted to this unit (vpage 8 “About ARC (Audio Return Channel) function”). The ARC function allows you to enjoy on this unit the audio from TV programs and HDMI devices directly connected to TV, without having to make a separate audio connection. For the ARC function, also see your TV’s manual.

•To listen to TV audio through this device, use the optical digital connection.

For video connections, see “Converting input video signals for output (Video conversion function)” (vpage6).

n Audio connection

The following methods are available for connecting to this unit. Use either of the methods to make a connection.

a DIGITAL AUDIO OPTICAL connector DIGITAL AUDIO COAXIAL connector

When a multichannel audio (digital bit stream audio) is input, this unit decodes the audio to play back surround sound.

z When making this type of connection, you must change the settings on this unit.

(v Input connector setting )

n Video connection

The following methods are available for connecting to the unit.

a VIDEO OUT (MONITOR) connector

This makes an analog video connection.

Input connector setting

When making the following connection, you must change the input connector settings.

a DIGITAL AUDIO COAXIAL connector

Change the default “CBL/SAT” to “TV AUDIO”.

For how to change, see “Input Assign” (vpage111).

COAXIAL

OUT

OPTICAL

OUT

VIDEOAUDIO

VIDEO

a a a

NOTE

•If you do not connect this unit to your TV via HDMI, do not make HDMI connections for video inputs from other video devices, either. For details see “Converting input video signals for output (Video conversion function)” (vpage6).

Connecting an HDMI-incompatible device

Basic version

Advanced version

Information

Basic version

DVD

Connecting a set-top box (Satellite tuner/cable TV)

This section describes how to connect when your satellite tuner or cable TV does not support HDMI connections. For instructions on HDMI connections, see “Connecting an HDMI-compatible device” (vpage7).

n Audio connection

The following methods are available for connecting to this unit. Use either of the methods to make a connection.

The numbers preﬁxed with connectors indicate the recommendation order. The smaller the number is, the higher playback quality is achieved.

a DIGITAL AUDIO COAXIAL connector DIGITAL AUDIO OPTICAL connector

When a multichannel audio (digital bit stream audio) is input, this unit decodes the audio to play back surround sound.

z When making this type of connection, you must change the settings on this unit.

(v Input connector setting )

s AUDIO IN (CBL/SAT) connector

This makes an analog audio connection. This type of connection converts digital audio to analog audio, so the output audio may be degraded compared to connections a.

n Video connection

The following methods are available for connecting to this unit. Use either of the methods to make a connection.

The numbers preﬁxed with connectors indicate the recommendation order. The smaller the number is, the higher playback quality is achieved.

a COMPONENT VIDEO IN connector

s VIDEO IN (CBL/SAT) connector

This makes an analog video connection.

Satellite tuner/Cable TV

AUDIO

OUT

COAXIAL

OUT

a a a ss

OPTICAL

OUT

or or or

Y P

OUT

VIDEOAUDIO

B PR

COMPONENT VIDEO

VIDEO

OUT

Input connector setting

When making the following connection, you must change the input connector settings.

a DIGITAL AUDIO OPTICAL connector

Change the default “TV AUDIO” to “CBL/SAT”.

For how to change, see “Input Assign” (vpage111).

Connecting an HDMI-incompatible device

Basic version

Advanced version

Information

Basic version

DVD

Connecting a DVD player

This section describes how to connect when your DVD player does not support HDMI connections. For instructions on HDMI connections, see “Connecting an HDMI-compatible device” (vpage7).

n Audio connection

The following methods are available for connecting to this unit. Use either of the methods to make a connection.

The numbers preﬁxed with connectors indicate the recommendation order. The smaller the number is, the higher playback quality is achieved.

a DIGITAL AUDIO COAXIAL connector DIGITAL AUDIO OPTICAL connector

When a multichannel audio (digital bit stream audio) is input, this unit decodes the audio to play back surround sound. When making this type of connection, you must change the settings on this unit. (v Input connector setting )

s AUDIO IN (DVD) connector

This makes an analog audio connection. This type of connection converts digital audio to analog audio, so the output audio may be degraded compared to connections a.

n Video connection

The following methods are available for connecting to this unit. Use either of the methods to make a connection.

The numbers preﬁxed with connectors indicate the recommendation order. The smaller the number is, the higher playback quality is achieved.

a COMPONENT VIDEO IN connector

This makes an analog video connection. This connection method separates video signals into 3 signals for transmission based on color components, achieving the best quality video playback among analog video connections, with less signal degradation. When making this type of connection, you must change the settings on this unit. (v Input connector setting )

s VIDEO IN (DVD) connector

This makes an analog video connection.

Input connector setting

When making the following connection, you must change the input connector settings.

a DIGITAL AUDIO COAXIAL connector

Change the default “CBL/SAT” to “DVD”.

DIGITAL AUDIO OPTICAL connector

Change the default “TV AUDIO” to “DVD”.

a COMPONENT VIDEO IN connector

Change the default “CBL/SAT” to “DVD”.

For how to change, see “Input Assign” (vpage111).

DVD player

Y P

OUT

VIDEOAUDIO

B PR

VIDEO

OUT

AUDIO

OUT

COAXIAL

OUT

a a a ss

OPTICAL

OUT

or or or

COMPONENT VIDEO

Connecting a Blu-ray Disc player

Basic version

Advanced version

Information

Basic version

DVD

This section describes how to connect when your Blu-ray disc player does not support HDMI connections. For instructions on HDMI connections, see “Connecting an HDMI-compatible device” (vpage7).

n Audio connection

The following methods are available for connecting to this unit. Use either of the methods to make a connection.

The numbers preﬁxed with connectors indicate the recommendation order. The smaller the number is, the higher playback quality is achieved.

a DIGITAL AUDIO COAXIAL connector DIGITAL AUDIO OPTICAL connector

When a multichannel audio (digital bit stream audio) is input, this unit decodes the audio to play back surround sound. However, digital bit stream audio signals for HD audios from Blu-ray disc players (such as Dolby Digital Plus and dts-HD) can not be transmitted. When making this type of connection, you must change the settings on this unit. (v Input connector setting )

s AUDIO IN (Blu-ray) connector

This makes an analog audio connection. This type of connection converts digital audio to analog audio, so the output audio may be degraded compared to connections a.

n Video connection

The following methods are available for connecting to this unit.

a COMPONENT VIDEO IN connector

Blu-ray Disc player

AUDIO

OUT

COAXIAL

OUT

a a as

or or

OPTICAL

OUT

VIDEOAUDIO

COMPONENT VIDEO

OUT

B PR

Y P

Connecting an HDMI-incompatible device

Input connector setting

When making the following connection, you must change the input connector settings.

a DIGITAL AUDIO COAXIAL connector

Change the default “CBL/SAT” to “Blu-ray”.

DIGITAL AUDIO OPTICAL connector

Change the default “TV AUDIO” to “Blu-ray”.

a COMPONENT VIDEO IN connector

Change the default “CBL/SAT” to “Blu-ray”.

For how to change, see “Input Assign” (vpage111).

When you want to play back HD Audio (Dolby TrueHD, DTS-HD, Dolby Digital Plus, DTS Express) and Multichannel PCM with this unit, use an HDMI connection (vpage 7 “Connecting an HDMI-compatible device”).

Basic version

Advanced version

Information

Basic version

DVD

Connecting a digital camcorder

This section describes how to connect when your digital camcorder does not support HDMI connections. For instructions on HDMI connections, see “Connecting an HDMI-compatible device” (vpage7).

n Audio connection

The following methods are available for connecting to this unit. Use either of the methods to make a connection.

The numbers preﬁxed with connectors indicate the recommendation order. The smaller the number is, the higher playback quality is achieved.

a DIGITAL AUDIO COAXIAL connector DIGITAL AUDIO OPTICAL connector

s AUDIO IN (AUX) connector

This makes an analog audio connection. This type of connection converts digital audio to analog audio, so the output audio may be degraded compared to connections a.

n Video connection

The following methods are available for connecting to this unit. Use either of the methods to make a connection.

The numbers preﬁxed with connectors indicate the recommendation order. The smaller the number is, the higher playback quality is achieved.

a COMPONENT VIDEO IN connector

s VIDEO IN (AUX) connector

This makes an analog video connection.

Input connector setting

When making the following connection, you must change the input connector settings.

a DIGITAL AUDIO COAXIAL connector

Change the default “CBL/SAT” to “AUX”.

DIGITAL AUDIO OPTICAL connector

Change the default “TV AUDIO” to “AUX”.

a COMPONENT VIDEO IN connector

Change the default “CBL/SAT” to “AUX”.

For how to change, see “Input Assign” (vpage111).

Connecting an HDMI-incompatible device

Digital camcorder

VIDEO

OUT

Digital camcorder

VIDEO AUDIO

COMPONENT VIDEO

OUT

B PR

Y P

AUDIOVIDEO

AUDIO

OUT

OPTICAL

OUT

COAXIAL

OUT

GFront panelH

GRear panelH

aaa

You can enjoy games by connecting a game machine via the AUX input connector. In this case, select the input source to “AUX”.

NOTE

When a non-standard video signal from a game machine or some other source is input, the video conversion function (vpage 6) might not operate. In this case, use the monitor output of the same connector as the input.

Connecting an iPod or USB memory device to the iPod/USB port

Basic version

Advanced version

Information

Basic version

DVD

Connecting an HDMI-incompatible device

Supported iPod models

•You can enjoy music stored on an iPod or USB memory device.

•For operating instructions see “Playing an iPod” (vpage 33) or “Playing a USB memory device”

(vpage36).

Cables used for connections

To connect an iPod to this unit, use the USB cable supplied with the iPod.

iPod

USB memory

device

DENON does not guarantee that all USB memory devices will operate or receive power. When using a portable USB connection type HDD of the kind to which an AC adapter can be connected to supply power, use the AC adapter.

NOTE

•USB memory devices will not work via a USB hub.

•It is not possible to use this unit by connecting the unit’s iPod/USB port to a PC via a USB cable.

•Do not use an extension cable when connecting a USB memory device. This may cause radio interference

with other devices.

•When connecting an iPhone to this unit, keep the iPhone at least 20 cm away from this unit. If the iPhone is kept closer to this unit and a telephone call is received by the iPhone, noise may be output from this device.

•If the iPod is connected using an iPod cable (commercially available) that is longer than 2 m (6.6 ft), sound may not be played correctly. In this case, use a genuine iPod cable, or a cable that is shorter than 1 m (3.3 ft).

•iPod classic

•iPod nano

•iPod touch

•iPhone

(as of March 2012)

Connecting an HDMI-incompatible device

Basic version

Advanced version

Information

Basic version

DVD

Connecting a CD player

You can enjoy CD sound.

n Audio connection

The following methods are available for connecting to this unit. Use either of the methods to make a connection.

The numbers preﬁxed with connectors indicate the recommendation order. The smaller the number is, the higher playback quality is achieved.

a DIGITAL AUDIO COAXIAL connector DIGITAL AUDIO OPTICAL connector

s AUDIO IN (CD) connector

This makes an analog audio connection. This type of connection converts digital audio to analog audio, so the output audio may be degraded compared to connections a.

Input connector setting

When making the following connection, you must change the input connector settings.

a DIGITAL AUDIO COAXIAL connector

Change the default “CBL/SAT” to “CD”.

DIGITAL AUDIO OPTICAL connector

Change the default “TV AUDIO” to “CD”.

For how to change, see “Input Assign” (vpage111).

CD player

AUDIO

OUT

or or

COAXIAL

a as

AUDIO

OUT

OPTICAL

OUT

Connecting an FM antenna

Basic version

Advanced version

Information

Basic version

DVD

Connecting an HDMI-incompatible device

Direction of broadcasting station

•Connect the FM antenna supplied with the unit to enjoy listening to radio broadcasts.

•After connecting the antenna and receiving a broadcast signal (vpage 39 “Listening to FM

broadcasts”), ﬁx the antenna with tape in a position where the noise level becomes minimal.

NOTE

•Do not connect two FM antennas simultaneously.

•If you are unable to receive a good broadcast signal, we recommend installing an outdoor antenna. For

details, inquire at the retail store where you purchased the unit.

FM outdoor

antenna

75 Ω coaxial

cable

FM indoor antenna

(supplied)

Connecting an external control device

Basic version

Advanced version

Information

Basic version

DVD

REMOTE CONTROL jacks

If this unit is installed in a location that is out of range of the signal from the remote control unit, you can still operate the unit and the devices connected to it by using a commercially available IR receiver. You can also use it to remotely control ZONE2 (another room).

retransmitter

AUX OUT

Infrared

Input

Infrared sensor

Device equipped with a

REMOTE CONTROL IN jack

Output

RS-232C connector

When you connect an external control device, you can control this unit with the external control device (such as power supply operation, volume adjustment, and input source switching).

External serial controller

Perform the operation below beforehand.

q Turn on the power of this unit. w Turn off the power of this unit from the external controller. e Check that the unit is in the standby mode.

Connecting to a home network (LAN)

Basic version

Advanced version

Information

Basic version

DVD

You can connect this unit to your home network (LAN) to perform various types of playbacks and operations as follows. Make network connections for this unit by carefully reading information on this page.

•Playback of network audio such as the Internet radio and music servers

•Playback of music from online services

•AirPlay

•Operations on this unit via the network

In addition, when an updated ﬁrmware becomes available for improving this unit, the update information is delivered from us to this unit over the network. You can then download the latest ﬁrmware. For more information, on the menu, select “Update” (vpage125).

Network settings are necessary. See “Network” on the menu (vpage 118) for more information on network setting.

NAS

(Network Attached

Modem

Internet

To WAN side

To LAN port

Router

For connections to the Internet, contact an ISP (Internet Service Provider) or a computer shop.

LAN port/

Ethernet

connector

Storage)

LAN port/

Ethernet

connector

Required system

n Broadband internet connection n Modem

Device that connects to the broadband circuit and conducts communications on the Internet. A type that is integrated with a router is also available.

n Router

When using this unit, we recommend you use a router equipped with the following functions:

•Built-in DHCP server This function automatically assigns IP addresses on the LAN.

•Built-in 100BASE-TX switch When connecting multiple devices, we recommend a switching hub with a speed of 100 Mbps or greater.

n Ethernet cable

(CAT-5 or greater recommended)

•Use only a shielded STP or ScTP LAN cable which is available at retailer.

•The normal shielded-type Ethernet cable is recommended. If a ﬂat-type cable or unshielded-type cable is used, other devices could be affected by noise.

•If you have an Internet provider contract for a line on which network settings are made manually, make the settings at “Network” (vpage118).

•With this unit, it is possible to use the DHCP and Auto IP functions to make the network settings automatically.

•When using this unit with the broadband router’s DHCP function enabled, this unit automatically performs the IP address setting and other settings. When using this unit connected to a network with no DHCP function, make the settings for the IP address, etc., at “Network” (vpage118).

•When setting manually, check the setting contents with the network administrator.

NOTE

•A contract with an ISP is required to connect to the Internet. No additional contract is needed if you already have a broadband connection to the Internet.

•The types of routers that can be used depend on the ISP. Contact an ISP or a computer shop for details.

•DENON assumes no responsibility whatsoever for any communication errors or troubles resulting from customer’s network environment or connected devices.

•This unit is not compatible with PPPoE. A PPPoEcompatible router is required if you have a contract for a type of line set by PPPoE.

•Do not connect an NETWORK connector directly to the LAN port/ Ethernet connector on your computer.

•To listen to audio streaming, use a router that supports audio streaming.

Connecting the power cord

Basic version

Advanced version

Information

Basic version

DVD

After completing all the connections, insert the power plug into the power outlet.

To household power outlet

(AC 120 V, 60 Hz)

NOTE

•Do not plug in the power cord until all connections have been completed.

•Do not bundle power cords together with connection cables. Doing so can result in humming or noise.

Power cord

Setup

Basic version

Advanced version

Information

Basic version

v See overleaf

DVD

Here, we explain “Audyssey® Setup”, which allows you to automatically make the optimal settings for your speakers, and “Network”, which allows you to connect this unit to a home network (LAN). This unit lets you play via your home network (LAN) music ﬁles stored on a computer and music content such as that from Internet radio.

n Speaker connection (vpage77)

n Set up speakers (Audyssey® Setup) (vpage24) n Making the network settings (Network)

(vpage30)

Playback (Basic operation) (vpage31)

Selecting a listening mode (Sound Mode)

(vpage68)

Playback (Advanced operation) (vpage87)

Set up speakers (Audyssey® Setup)

The acoustic characteristics of the connected speakers and listening room are measured and the optimum settings are made automatically. This is called “Audyssey® Setup”. To perform measurement, place the setup microphone in multiple locations all around the listening area. For best results, we recommend you measure in six or more positions, as shown in the illustration (up to eight positions).

•When performing Audyssey® Setup, Audyssey MultEQ® XT/ Audyssey Dynamic EQ®/Audyssey Dynamic Volume® functions become active (vpage103).

•To set up the speakers manually, use “Speakers” (vpage114) on the menu.

NOTE

•Make the room as quiet as possible. Background noise can disrupt the room measurements. Close windows and turn off the power on electronic devices (TVs, radios, air conditioners, ﬂuorescent lights, etc.). The measurements could be affected by the sounds emitted by such devices.

•During the measurement process, place cell phones outside the listening room. Cell phone signals could disrupt the measurements.

•Do not unplug the setup microphone from the main unit until Audyssey® Setup is completed.

•Do not stand between the speakers and setup microphone or allow obstacles in the path while the measurements are being made. This will cause inaccurate readings.

•During the measurement process, loud test sounds may be played, but this is part of normal operation. If there is background noise in room, these test signals will increase in volume.

•Operating control unit or MASTER VOLUME on the main unit during the measurements will cancel the measurements.

•Measurement cannot be performed when headphones are connected. Unplug the headphones before performing Audyssey® Setup.

VOLUME df on the remote

About setup microphone placement

•Measurements are performed by placing the setup microphone successively at multiple positions throughout the entire listening area, as shown in GExample qH. For best results, we recommend you measure in six or more positions, as shown in the illustration (up to eight positions).

•Even if the listening environment is small as shown in GExample wH, measuring at multiple points throughout the listening environment results in more effective correction.

GExample qH GExample wH

FL SW C FR

( : Measuring positions)

FL Front speaker (L) SW Subwoofer FR Front speaker (R) SL Surround speaker (L) C Center speaker SR Surround speaker (R)

SRSL

FL SW C FR

( : Measuring positions)

SRSL

About the main listening position (*M)

The main listening position is the position where listeners would normally sit or where one would normally sit alone within the listening environment. Before starting Audyssey® Setup, place the setup microphone in the main listening position. Audyssey MultEQ® XT uses the measurements from this position to calculate speaker distance, level, polarity, and the optimum crossover value for the subwoofer.

Set up speakers (Audyssey® Setup)

Basic version

Advanced version

Information

Basic version

v See overleaf

DVD

Prepare the included setup microphone

Mount the setup microphone on a tripod or stand and place it in the main listening position.

When placing the setup microphone, adjust the height of the sound receptor to the level of the listener’s ear.

Sound receptor

If you do not have a tripod or stand, set up the microphone on, for example, a seat without a back.

NOTE

•Do not hold the setup microphone in your hand during measurements.

•Avoid placing the setup microphone close to a seat back or wall as sound reﬂections may give inaccurate results.

Setup microphone

Set up the subwoofer

If using a subwoofer capable of the following adjustments, set up the subwoofer as shown below.

For details, see your subwoofer’s manual.

n When using a subwoofer with a direct mode

Set the direct mode to “On” and disable the volume adjustment and crossover frequency setting.

n When using a subwoofer without a direct mode

Make the following settings:

•Volume : “12 o’clock position”

•Crossover frequency : “Maximum/Highest Frequency”

•Low pass ﬁlter : “Off”

•Standby mode : “Off”

Set up the remote control unit

n Set up the zone mode

Press MAIN to switch the zone mode to the MAIN ZONE.

MAIN lights.

Press MAIN

Preparation

Connect the setup microphone to the SETUP MIC

jack of this unit.

When the setup microphone is connected, the following screen is displayed.

Audyssey Setup

Your AV receiver can automatically measure the acoustics of your room then optimize your speakers using the included microphone. Set the following items if necessary.

Amp Assign

Channel Select

Start

•Here, we explain setup using the example of 5.1-channel speaker playback. For settings other than 5.1-channel speaker playback, select “Amp Assign” and perform step 3 to 6 of “Set up “Amp Assign”” (vpage85). If unused channels are set with “Channel Select”, measuring time can be shortened. For setting, perform steps 7 to 12 of “Set up “Channel Select”” (vpage86).

Set up speakers (Audyssey® Setup)

Basic version

Advanced version

Information

Basic version

v See overleaf

DVD

Preparation (Continued)

Select “Start” and then press

ENTER.

The subwoofer volume setting screen is displayed.

Audyssey Setup

Connect the calibration microphone to the SETUP MIC input on the front the AV receiver.

Back Next

Select “Next” and then press ENTER.

Audyssey Setup

If your subwoofer has a volume control on it, please set it at 50%...

VOLUME

MIN

MAX

Back Next

Detection & Measurement (Main)

•This step automatically checks the speaker conﬁguration and speaker size, and calculates the channel level, distance, and crossover frequency. It also corrects distortion in the listening area.

Select “Begin Test” and then press ENTER.

When measuring begins, a test tone is output from each speaker.

•Measurement requires several minutes.

The detected speakers are displayed.

•The illustration below shows an example of when the front speakers, center speaker, subwoofer and surround speakers have been detected.

Audyssey Setup

Speaker Detection

Front Center Subwoofer Surround Surround Back

NOTE

If a connected speaker is not displayed, the speaker may not be connected correctly. Check the speaker connection.

:Yes :Yes :Yes :Yes :None

Repeat Last Test Next

NOTE

If “Caution!” is displayed on TV screen:

Go to “Error messages” (vpage 29). Check any related items, and perform the necessary procedures. If the problem is resolved, return and restart “Audyssey® Setup”.

Going back to the previous screen

Select “Back” and then press ENTER.

When measuring has stopped

q Press BACK to display the popup screen. w Press o to select “Yes”, and then press ENTER.

Setting up the speakers again

Repeat the operation from step 4.

Select “Next” and then press ENTER.

Set up speakers (Audyssey® Setup)

Basic version

Advanced version

Information

Basic version

v See overleaf

DVD

Measurement (2nd – 8th)

•In this step, you will perform measurements at multiple positions (two to eight positions) other than the main listening position.

•Just one position can be measured but measuring multiple positions increases the accuracy of the correction of acoustic distortion within the listening area.

Move the setup microphone to position 2, select

“Continue”, and then press ENTER.

The measurement of the second position starts. Measurements can be made in up to eight positions.

Audyssey Setup

Place the microphone at ear level at the 2nd listening position, then select "Continue"...

Continue

Calculation

Audyssey Setup

Place the microphone at ear level at the 3rd listening position, then select "Continue"...

Repeat step 10, measuring positions 3 to 8.

When measurement of position 8 is completed, a

“Measurements ﬁnished.” message is displayed.

Audyssey Setup

Measurements finished.

Calculation

Repeat Last Test

Calculation

Select “Calculation” and then press ENTER.

Measuring results are analyzed, and the frequency response of each speaker in the listening room is determined.

Audyssey Setup

Calibration completed! Now calculating...Please wait.

50%

•Analysis takes several minutes to complete. The more speakers and measurement positions that there are, the more time it takes to perform the analysis.

•To skip measuring the third and subsequent listening position, use

ui to select “Calculation” and press ENTER to proceed to step

13.

•To measure the second position again, use ui to select “Repeat

Last Test” and press ENTER.

Continue

Calculation

Repeat Last Test

+ 126 hidden pages
