Dell PowerEdge SC1430 S, PowerEdge SC1430 Getting Started

Dell™ PowerEdge™

SC1430 Systems

Getting Started With

Your System

www.dell.com | support.dell.com

Notes, Notices, and Cautions

NOTE: A NOTE indicates important information that helps you make better use of your computer.

NOTICE: A NOTICE indicates either potential damage to hardware or loss of data and tells you how to avoid the problem.

CAUTION: A CAUTION indicates a potential for property damage, personal injury, or death.

____________________

Information in this document is subject to change without notice.
© 2006 Dell Inc. All rights reserved.

Reproduction in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden.
Trademarks used in this text: Intel and Xeon are registered trademarks of Intel Corporation; Microsoft and Windows are registered trademarks

and Windows Server is a trademark of Microsoft Corporation; Red Hat is a registered trademark of Red Hat, Inc.; SUSE is a registered trademark
of Novell Inc.

Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products.
Dell Inc. disclaims any proprietary interest in trademarks and trade names other than its own.

Model EMS01

March 2006 P/N TD272 Rev. A00

System Features

The major hardware and software features of your system include:

• One or two Dual-Core Intel® Xeon® Processors 5000 Sequence

• Support for symmetric multiprocessing (SMP), which is available on systems with two Intel Xeon
microprocessors. SMP greatly improves overall system performance by dividing microprocessor
operations between independent microprocessors. To take advantage of this feature, you must use an
operating system that supports multiprocessing.

NOTE: If you decide to upgrade your system by installing a second microprocessor, you must order the

microprocessor upgrade kits from Dell. Not all versions of the Intel Xeon microprocessor will work properly
as additional microprocessors. The upgrade kit from Dell contains the correct version of the microprocessor.
Both microprocessors must have the same internal operating frequency and cache size.

• A minimum of 512 MB of 533 or 667 (when available) MHz Fully Buffered DIMMs (FBD), upgradable
to a maximum of 8 GB by installing combinations of 256-MB, 512-MB, 1-GB, or 2-GB memory
modules in the four memory module sockets on the system board

• Support for up to two 3.5-inch internal Serial-Attached SCSI (SAS) or SATA hard drives using the
internal hard drive bays. A third hard drive may be installed in the flex bay. A fourth hard drive may
be installed using a hard drive carrier. A controller expansion card is required for SAS hard drives or for
more than two SATA hard drives.

• One 3.5-inch flex bay for a diskette drive or a third hard drive and two 5.25-inch bays for the following
supported drives: CD, DVD, combination CD-RW/DVD, tape backup device (second bay only),
or fourth hard drive (second bay only, hard drive carrier required)

NOTE: DVD devices are data only.

NOTE: A tape backup device or a second optical drive may not be installed if a fourth hard drive is installed.

• Support for USB 2.0

• Chassis intrusion alert

The system board includes the following built-in features:

• Dual-channel IDE controller that supports up to two of the following supported IDE devices:
CD, DVD, combination CD-RW/DVD, or tape backup device

• SATA controller that supports up to two cabled SATA hard drives, and up to two of the following
supported SATA devices (when available): CD, DVD, combination CD-RW/DVD, or tape backup
device

• Two 64-bit, 100-MHz PCI-X expansion slots, two x8 lane (electrically wired for x4 lanes) PCI Express
(PCIe) expansion slots, and one 32-bit, 33-MHz legacy PCI expansion slot

• An integrated VGA-compatible video subsystem with an ATI ES1000, 33-MHz PCI video controller.
This video subsystem contains a minimum of 16MB of graphics memory with support for 2D graphics.
Maximum resolution is 1600x1200 with 65,536 colors; true-color graphics are supported in the
following resolutions: 640 x 480, 800 x 600, 1024 x 768, 1280 x 1024

Getting Started With Your System 3

• An integrated Gigabit Ethernet NIC, capable of supporting 1000-Mbps, 100-Mbps, or 10-Mbps data
rates, with support for PXE and Wake-on-LAN

• Seven USB 2.0-compliant connectors (two on the front and five on the back) capable of supporting
a diskette drive, a CD-ROM drive, a keyboard, a mouse, or a USB flash drive

• Back-panel connectors include serial, video, parallel, five USB connectors, and one NIC connector

• Front-panel connectors include two USB connectors

• Four front-panel system diagnostic LEDs for pre-POST and POST failure messaging and notification.

For more information about specific features, see "Technical Specifications" on page 7.

Supported Operating Systems

Your system supports the following operating systems:

• Microsoft® Windows Server™ 2003, Standard Edition

• Microsoft Windows Server 2003, Standard x64 Edition

®

• Microsoft Windows

•Red Hat

•SUSE

®

Enterprise Linux (version 4) for Intel Extended Memory 64 Technology (Intel EM64T)

®

LINUX Enterprise Server 9

Small Business Server 2003 Standard and Premium Editions

Other Information You May Need

CAUTION: The Product Information Guide provides important safety and regulatory information.

Warranty information may be included within this document or as a separate document.

• The

• CDs included with your system provide documentation and tools for configuring and managing

• Updates are sometimes included with the system to describe changes to the system, software,

• Release notes or readme files may be included to provide last-minute updates to the system or

Hardware Owner’s Manual

provides information about system features and describes how

to troubleshoot the system and install or replace system components.

your system.

and/or documentation.

NOTE: Always check for updates on support.dell.com and read the updates first because they often

supersede information in other documents.

documentation or advanced technical reference material intended for experienced users or
technicians.
