Chromebook 3120
Specifications

Technical Specifications

Table 1. System Information

Feature Specification

System Chipset Intel Atom

Smart Cache 1MB L2 Cache

BIOS Chip 8 MB

Table 2. Processor

Feature Specification

Processor type N2840

L1 cache On-die, 32 KB 8-way L1 instruction cache and 24 KB 6-way L1

data cache per core

L2 cache On-die, 1 MB, 16-way L2 cache, shared per two cores

Table 3. Memory

Feature Specification

Type DDR3L

Speed 1333 MT/s

Minimum Memory 2 GB

Maximum memory 4 GB

Table 4. Audio

Feature Specification

Integrated Dual-channel High-Definition audio

Table 5. Communication

Feature Specification

Wireless IEEE802.11AC and BT 4.0

Table 6. Ports and Connectors

Feature Specification

Connector DC-IN One (7.4mm)

Audio Microphone/Headphone Global Headset

USB 2.0 One

USB 3.0 One with BC1.2 charging
