Datasheet TL-MR100 Specification

300 Mbps Wi-Fi
4G LTE Router

Wi-Fi Where You Need It

TL-MR100

4G(TDD&FDD)/
3G Compatible

300 Mbps
Wi-Fi Speed

Supports Up to

†

32 Devices

†

Highlights

Superfast 4G LTE Speed for Reliable Wi-Fi

The TL-MR100 uses 4G LTE technology to achieve speeds of up to 150 Mbps

download and 50 Mbps upload. It also shares a Wi-Fi network with maximum speed

of 300 Mbps on 2.4 GHz for gaming, streaming, and more.

†

Supports Up to 32 Devices

Easily share a 3G/4G connection. Connect up to 32 wireless devices with ease

while ensuring dependable network stability.

†

Up to

32

Devices

TP-Link 300 Mbps Wireless N 4G LTE Router

TL-MR100

Highlights

Available WAN Connection Design for Maximum Network Coverage

With a fully functional WAN/LAN port, TL-MR100 can work as a router which is

compatible with cable, ber, and DSL modems.

Modem

Internet

Advanced LTE antennas make ecient and stable connections to every

device. Power Amplier and Low Noise Amplier boost sending and receiving

capabilities, creating a wide-coverage Wi-Fi network for your home.

Ethernet Cable

TP-Link 300 Mbps Wireless N 4G LTE Router

TL-MR100

Highlights

Easy Setup and Use

Installation is simple, thanks to an intuitive web interface and the powerful

TP-Link app, Tether. Tether lets you manage your network settings with

your smartphone.

C80

Scan the QR code to download TP-Link Tether.

TP-Link 300 Mbps Wireless N 4G LTE Router

TL-MR100

Features

4G LTE

· 4G LTE – Ideal for cutting-edge 4G LTE network

· Faster Connection – Download Speed 150 Mbps + Upload

Speed 50 Mbps

· Backward Compatible – Compatible with 3G/4G network

Wi-Fi Speed

· 300 Mbps Wireless Speed – 300 Mbps Wi-Fi allows stable

speed for wireless activities, such as streaming, browsing
and posting social media

Wi-Fi Range

· Great Coverage – Better coverage with advanced LTE

antennas

TP-Link 300 Mbps Wireless N 4G LTE Router

TL-MR100

FeaturesFeatures

· Superior Stability – Powerful processor enables you to connect

up to 32 wireless devices with ease

· WAN Connection Backup – Works as a router to provide backup

internet connection

Ease of Use SecurityReliability

· Intuitive Web UI – Ensures quick and simple installation without

hassle

· Fast Encryption – One-touch WPA wireless security encryption

with the WPS button

· Guest Network – Keeps your main network secure by creating a

separate network for friends and visitors

· Access Control – Establishes a whitelist or blacklist to allow or

restrict certain devices to access the internet

· Encryptions for Secure Network – WPA-PSK and WPA2-PSK

encryptions provide active protection against security threats

TP-Link 300 Mbps Wireless N 4G LTE Router

TL-MR100

Hardware Wireless

· LTE: Download Speed 150 Mbps + Upload Speed 50 Mbps

· Antennas: 2 Detachable External 4G LTE Antennas

· Ports: 1 10/100 Mbps LAN/WAN + 1 10/100 Mbps LAN

· Dimensions: 6.06×4.49×1.42 in ( 154×114×36 mm)

· External Power Supply: 9V/0.85A

· Network Type

4G: FDD-LTE: B1/B3/B5/B7/B8/B20/B28 (2100/1800/850/2600/900/800/700 MHz)

TDD-LTE: B38/B40/B41 (2600/2300/2500 MHz)

3G: HSPA/UMTS: B1/B5/B8 (2100/850/900 MHz)

· Wireless Standards: IEEE 802.11b/g/n

· Frequency: 2.4 GHz

· Signal Rate: 300 Mbps

· EIRP (CE): < 20 dBm (2.4 GHz)

· Reception Sensitivity:

11g 54M：-74dBm

11n HT20：-73dBm

Power LAN

Port

LAN/WAN
Port

WPS/
Reset

11n HT40：-70dBm

· Wireless Function: Enable/Disable Wireless Radio, Wireless Schedule, WMM, Wireless

Statistics

· Wireless Security: 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryptions

Nano SIM
Card Slot

TP-Link 300 Mbps Wireless N 4G LTE Router

TL-MR100

Specications

Software

· Operating Modes: 3G/4G Router, Wireless Router

· WAN Type: Dynamic IP/Static IP/PPPoE/PPTP(Dual Access)/L2TP(Dual Access)

· DHCP: Server, DHCP Client List, Address Reservation

· Port Forwarding: ALG, Virtual Server, Port Triggering, UPnP, DMZ

· Dynamic DNS: DynDns, NO-IP

· Security: IPv4 SPI Firewall, IP and MAC Address Binding

· Protocols: IPv4, IPv6

· Management: Local Management, Remote Management

· Administration: Upgrade Firmware, Factory Default, System Log, Diagnostic Tools

· Guest Network: 2.4 GHz Guest Network

Others

· Certication:

CE, RoHS

· Requirements:

Microsoft Windows 98SE/NT/2000/XP/Vista™/7/8/8.1/10, macOS, NetWare,
UNIX or Linux

Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other

Java-enabled browser

Nano SIM Card

· Environment:

Operating Temperature: 0℃~40℃ (32℉ ~104℉)

Operating Humidity: 10%~90% non-condensing

Storage Humidity: 5%~90% non-condensing

· Package Contents

300 Mbps Wireless N 4G LTE TL-MR100

Power Adapter

RJ45 Ethernet Cable

Quick Installation Guide

For more information, please visit

https://www.tp-link.com/products/details/?model=TL-MR100

or scan the QR code left

©2022 TP-Link

Attention: This device may only be used indoors in all EU member states and EFTA countries.
*Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specications. Actual wireless data throughput and wireless coverage, and quantity of connected devices are not guaranteed and will vary as a result of network conditions, client limitations, and
environmental factors, including building materials, obstacles, volume and density of trac, and client location.
