Clarion M301RC-RET User Manual
M301RC-RET
VOLUME
VOLUME
SELECT
SELECT
BAND
DISC
SOURCE
POWER
MUTE
MARINE REMOTE-MOUNTED CONTROL PANEL
Owner's Manual / Installation Guide
Precautions
Table of Contents Page
Make certain that the remote is installed in a location which
does not interfere with the safe and proper operation of the
boat.
The M301RC-RET is only comp atible with the XMD3-RET AM/
FM/CD Player.
About Installation
Installation of Clarion marine audio components requires
experience with a variety of mechanical and electrical
procedures. Even though this manual provides general
installation and operation instructions for your new Clarion
marine audio remote control panel, it does not show the exact
methods which may be required for your particular installation.
If you do not have the required knowledge and experience to
successfully complete the installation, we strongly recommend
consulting an authorized Clarion marine audio dealer about
professional installation options.
1. Introduction.....................................................................4
2. Care and Maintenance ...................................................4
3. Using the Remote Control Panel ...................................5
4. Installation and Wiring ...................................................7
Limited Warranty Information ......................................... 11
1. INTRODUCTION
2. CARE AND MAINTENANCE
The M301RC-RET is a waterproof remote control panel which
allows operation of the Clarion XMD3-RET head unit from a
remote location. The XMD3-RET unit is an AM/FM CD player
with controls for an optional CD changer and an optional
Sirius Satellite Radio receiver.
A maximum of two M301RC-RET units may be used with a
single XMD3-RET (using an optional M101RYC-RET
adapter). The M301RC-RET can be connected to your boat’s
illumination circuit, backlighting the panel in low-light condi
tions.
What is included
• Remote control panel (1)
• One mounting bracket and four 7mm hex nuts (1 set)
• Owner’s Manual / Installation Guide (1)
Note: An 24’ extension DIN cable is available separately
(P/N M101RXC-RET).
Clean the remote control panel with a slightly damp, soft cloth
using household glass cleaner. Do not use solvents such as
benzene, thinner, or commercially available cleaners.
From time to time, inspect the connections on the rear of the
unit for corrosion and correct as needed.
