Clarion CZ201 User Manual

Download

CD/USB/MP3/WMA RECEIVER

LECTEUR CD/USB/MP3/WMA

RECEPTOR CD/USB/MP3/WMA

English

Contents

English

Thank you for purchasing this Clarion product.

• Please fully read this owner’s manual before operating this equipment.

• Check the contents of the enclosed warranty card and store it in a safe place with this manual.

1. FEATURES ........................................................................................................................3

Expanding Systems ...........................................................................................................3

2. PRECAUTIONS .................................................................................................................4

Front Panel / Generalities ..................................................................................................5

USB Port ...........................................................................................................................5

Remove the DCP ..............................................................................................................6

Attach the DCP ..................................................................................................................6

3. CONTROLS .......................................................................................................................7

Operational Panel ..............................................................................................................7

Names of Buttons .............................................................................................................. 7

Remote Control (RCX001) ................................................................................................8

Notes of remote control using ...........................................................................................8

4. CAUTIONS ON HANDLING ..............................................................................................9

Handling Discs ..................................................................................................................9

5. OPERATIONS ..................................................................................................................10

Basic Operations .............................................................................................................10

System Setup ..................................................................................................................11

Audio Setup ..................................................................................................................... 12

Radio Operations ............................................................................................................12

CD/MP3/WMA Operations ..............................................................................................13

USB Operations ..............................................................................................................16

iPod & iPhone Operations ...............................................................................................16

AUX Operations ..............................................................................................................17

6. TROUBLE SHOOTING ....................................................................................................18

7. ERROR DISPLAYS..........................................................................................................19

8. SPECIFICATIONS ...........................................................................................................20

9. INSTALLATION / WIRE CONNECTION GUIDE .............................................................21

1. FEATURES

Compatible with iPod ® / iPhone ® via USB 4ch/2V RCA Output with Subwoofer Control and BEAT-EQ with 3 Band Parametric

Equalizer Detachable Front Panel with 3.5mm Auxiliary Input MP3/WMA compatible with ID3-TAG display

Expanding Systems

Expanding audio features

English

4 Channel Amplier

iPod/iPhone

(Connect via CCA-748)

Note:

• The items listed outside of the frames are the

commercial products generally sold.

• CCA-748 and CCA-755: Sold by separately.

USB Memory

(Connect via CCA-755)

Portable Player

(Connect via AUX IN Jack)

English

CHINA

530-1710kHz 87.9-107.9MHz

THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1)THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2)THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.

THIS DEVICE COMPLIES WITH DHHS RULES 21 CFR CHAPTER I SUBCHAPTER J APPLICABLE AT DATE OF MANUFACTURE.

CLARION CO.,LTD. 7-2,SHINTOSHIN,CHUO-KU,SAITAMA-SHI,SAITAMA-KEN,JAPAN

This product includes technology owned by Microsoft Corporation and cannot be used or distributed without a license from MSLGP.

MANUFACTURED:

URF

PN:127070006874TX-1062B-A

65 mm

CHINA

531-1602kHzMW FM LW 153-279kHz

87.5-108MHz

PN:127070006887TX-1072E-A

This product includes technology owned by Microsoft Corporation and cannot be used or distributed without a license from MSLGP.

03 2120

65 mm

531-1602kHzMW FM LW 153-279kHz

87.5-108MHz

PN:127070006832TX-1072E-B

This product includes technology owned by Microsoft Corporation and cannot be used or distributed without a license from MSLGP.

03 2120

65 mm

CHINA

531-1602kHzMW FM LW 153-279kHz

87.5-108MHz

PN:127070006821TX-1073E-A

This product includes technology owned by Microsoft Corporation and cannot be used or distributed without a license from MSLGP.

03 2120

65 mm

531-1602kHzMW FM LW 153-279kHz

87.5-108MHz

PN:127070006835TX-1073E-B

This product includes technology owned by Microsoft Corporation and cannot be used or distributed without a license from MSLGP.

03 2120

2. PRECAUTIONS

WARNING

For your safety, the driver should not operate the controls while driving. Also, while driving, keep the volume to a level at which external sounds can be heard.

1. When the inside of the car is very cold and

the player is used soon after switching

on the heater, moisture may form on the disc or the optical parts of the player and

proper playback may not be possible. If moisture forms on the disc, wipe it off with a soft cloth. If moisture forms on

the optical parts of the player, do not

use the player for about one hour. The condensation will disappear naturally allowing normal operation.

2. Driving on extremely bumpy roads which cause severe vibration may cause the

sound to skip.

3. This unit uses a precision mechanism.

Even in the event that trouble arises, never open the case, disassemble the unit, or lubricate the rotating parts.

4. This equipment ha s been tested a nd found to comply with the limits for a Class

B digital device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide

reasonable protection against harmful

interference in a residential installation.

This equipment generates, users, and can radiate radio frequency energy and,

if not installed and used in accordance

with the instructions, may cause harmful

interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause

harmful interference to radio reception,

wh ic h can be determin ed by turning the equipment off and on, the user is

encouraged to consult the dealer or an experienced radio technician for help.

THIS DEVICE COMPLIES WITH DHHS RULES 21 CFR CHAPTER I SUBCHAPTER J APPLICABLE AT DATE OF MANUFACTURE.

This product includes technology owned by Microsoft Corporation and cannot be used or distributed without a license from MSLGP.

CLARION CO.,LTD. 7-2,SHINTOSHIN,CHUO-KU,SAITAMA-SHI,SAITAMA-KEN,JAPAN

MANUFACTURED:

INFORMATION FOR USERS:

Changes or modifications to this product

unapproved by the manufacturer will void the warranty and will violate FCC approval.

530-1710kHz 87.9-107.9MHz

URF

CHINA

PN:127070006834TX-1061B-A

Front Panel / Generalities

For a longer service life, be sure to read the following cautions.

• Do not allow any liquids on the set from drinks, umbrellas, etc. Doing so may

damage the internal circuitry.

• Do not disassemble or modify the set in any way. Doing so may result in damage.

• Do not let cigarettes burn the display.

Doing so may damage or deform the

body.

• If a problem should occur, have the set

inspected at your store of purchase.

• The remote control unit may not work if

the remote control sensor is exposed to direct sunlight.

Cleaning the body

• Use a soft, dry cloth and gently wipe off

the dirt.

• For tough dirt, apply some neutral detergent diluted in water to a soft cloth, wipe off the dirt gently, then wipe again with a dry cloth.

• Do not use benzene, thinner, car cleaner, etc., as these substances may damage the body or cause the paint to peel. Also, leaving rubber or plastic products in contact with the body for long periods of

time may cause stains.

USB Port

• The USB memory stick may stick out when inserted, so it may cause danger

during driving. When connect USB memory stick to the main unit, please use

a USB extension cable (CCA-755).

• The USB m emor y s tick s m ust be recognized as “USB mass storage class“ to work properly. Some models may not

operate correctly.

When the memorized data is lost or

damaged by any chance, Clarion shall not be liable for any damage.

When using an USB memory stick, we

recommend that you backup your data st ored on it before using a per sonal

computer etc.

• Data les may be broken when using USB memory sticks in the following situation:

When disconnecting the USB memory

st ick or tur ning the powe r off duri ng

reading data.

When a ffected by static electricity or

electric noise.

Connect/disconnect the USB memory stick

when it is not accessed.

• Connecting wi th the computer is no t

covered.

English

About the registered Marks,etc.

“Made for iPod,” and “Made for iPhone” mean that an electronic accessory has

been designed to connect specically to

iPod, or iPhone, respectively, and has

been certied by the developer to meet

Apple performance standards.

Apple is not responsible for the operation of this device or its compliance with safety

and regulatory standards. Please note that

the use of this accessory with iPod or iPhone may affect wireless performance.

iPhone and iPod are trademarks of Apple Inc., registered in the U.S. and other countries.

Remove the DCP

English

The control panel can be detached to prevent

theft. When detaching the control panel, keep it in the safety place and prevent scratches. W e r ec om me nd t a k i n g t h e D CP

(DETACHABLE CONTROL PANEL) with you when leaving the car.

1. Press the [ SRC / ] button (1 sec.) to

turn off the power.

2. Deeply push in [OPEN] button to unlock the DCP.

3. Hold the side popped out, remove the DCP.

Attach the DCP

1. Hold the DCP and ensure that the panel

faces towards you. Set the right side of the DCP into the DCP bracket.

2. Press the left side of the DCP until it locks.

CAUTION

• The DCP can easily be damaged by shocks. After removing it, be carefully not to drop it or

subject it to strong shocks.

• Once the [OPEN] button is pressed and DCP is unlocked, car vibrations can cause the DCP

to fall.

• The connector for the main unit and DCP is extremely important. Be careful not to damage it

by pressing on it with ngernails, screwdrivers, etc.

Note:

If the DCP is dirty, wipe off the dirt with a soft, dry cloth only.

3. CONTROLS

Operational Panel

English

]

[PS/AS]

[VOLUME]

[SOUND]

[ , ]

[MENU] [ ]

[OPEN]

[ SRC /

Names of Buttons

[ SRC / ] Button

• Power / Toggle the audio source

[BAND] Button

• Select tuner band

[MENU] Button

• MP3/WMA mode – Search function.

• CD mode – No function.

• RADIO mode – No function.

• AUX mode – No function.

• USB mode – Search function

• iPod mode – iPod menu

[ ] Button

• Press to eject disc.

[ , ] Buttons

• Previous / next track

• Search (long press)

[Open] Button

• Unlock the front panel.

Disc Slot

[1~6][BAND]

[ISR]

[VOLUME] Knob

• Adjust volume level / Conrm (press)

[ISR] Button

• Recall ISR station stored in memory and

store current station in ISR memory (long press)

[1~6] Buttons

• [1] Button: Scan play / Preset station 1.

• [2] Button: Repeat play / Preset station 2.

• [3] Button: Random play / Preset station 3.

• [4] Button: Play / Pause / Top play (long

press) / Preset station 4.

• [5] Button: Previous folder / Preset station 5. 10 tracks down (long press)

• [6] Button: Next folder / Preset station 6.

10 tracks up (long press)

[ D ] Button

• Display switch

• System setup (long press)

[ D ]

USB Connector

AUX Jack

[PS / AS] Button

• Scan play / Preset scan

• Auto memory store (long press)

[SOUND] Button

• Sound effect setting

Remote Control (RCX001)

English

[ SRC / ] Button

• Toggle the audio source

• Power on / Power off (long press)

[ , ] Buttons

• Preset station up/down

• Previous / next track

• Search (long press)

[DISP] Button

• Display switch

[RDM] Button

• Random play

[RPT] Button

• Repeat play

[SCN/PS/AS] Button

• Scan play / Preset scan

• Auto memory store (long press)

[BAND/TOP] Button

• Select tuner band

• Top play (long press)

[ , ] Buttons

• Volume up / down

[ ] Button

• Play / Pause

[ISR] Button

• Recall ISR station stored in

memory

• Store current station in ISR

memory (long press)

Notes of remote control using

1. Aim the remote control at the remote sensor on the unit.

2. Remove the battery from the remote control or insert a battery insulator if the battery has not been used for a month or longer.

3. DO NOT store the remote control under direct sunlight or in high temperature environment, or it may not function properly.

4. Use “button shaped” lithium battery “CR2025”

(3V) only.

5. DO NOT su bject battery to rech arge, disassemble, heat or dispose in re or water.

6. In sert the batte ry in prope r di recti on according to the (+) and (-) polarities.

7. Store the battery in a place where children

cannot reach to avoid the risk of accident.

[MUTE] Button

• Mute the volume

[BAND/TOP]

[ , ]

[ ]

[MUTE]

[SCN/

PS/AS]

[ISR] [DISP]

[RDM]

[RPT]

Inserting the Battery

1. Slide remote control unit’s rear cover in the direction shown.

2. Insert battery (CR2025) into insertion guides with printed side (+) up.

3. Press battery into compartment as shown.

4. Replace and slide cover until it clicks into place.

Insertion guide

4. CAUTIONS ON HANDLING

Handling Discs

English

Handling

• New discs may have some roughness

around the edges. If such discs are used,

the player may not work or the sound may skip. Use a ball-point pen or the like

to remove any roughness from the edge of the disc.

Ball-point pen

Roughness

• Never stick labels on the surface of the disc or mark the surface with a pencil or

pen.

• Never play a disc with any cellophane tape or other glue on it or with peeling off

marks. If you try to play such a disc, you

may not be able to get it back out of the

player or it may damage the player.

• Do not use discs that have large

scratches, are misshapen, cracked, etc.

Use of such discs may cause

misoperation or damage.

• To remove a disc from its storage case, press down on the center of the case and lift the disc out, holding it carefully by the

edges.

• Do not use commercially available disc

protection sheets or discs equipped with stabilizers, etc. These may damage the

disc or cause breakdown of the internal

mechanism.

Storage

• Do not expose discs to direct sunlight or

any heat source.

• Do not expose discs to excess humidity

or dust.

• Do not expose discs to direct heat from

heaters.

Cleaning

• To remove ngermarks and dust, use a soft cloth and wipe in a straight line from

the center of the disc to the

circumference.

• Do not use any solvents, such as

commercially available cleaners, anti-static spray, or thinner to clean discs.

• After using special disc cleaner, let the disc dry off well before playing it.

On Discs

• Never turn off the power and remove the unit from the car with a disc loaded.

CAUTION

For your safety, the driver should not insert or eject a disc while driving.

English

5. OPERATIONS

Basic Operations

Note:

• Refer to the diagrams in “3. CONTROLS” when reading this chapter.

CAUTION

When the unit is turned on, starting and stopping the engine with its volume raised to the maximum level may harm your hearings. Be careful about adjusting the volume.

Power on / off Notes:

• Start the engine before using this unit.

• Be careful about using this unit for a long

time without running the engine. If you drain the car’s battery too far, you may not be able to start the engine and this can reduce the service life of the battery.

1. Start the engine. The power button / knob

illumination on the unit will light up.

Engine ON

2. Press the [ SRC /

panel or the remote control to turn on the

power under standby mode. The unit goes back to the last status after power on.

3. Press and hold the [ SRC / ] button on

the front panel or the remote control to

turn off the power.

position

] button on the front

Mute

Press the [MUTE] button on the remote control to mute the volume from the unit.

Volume adjustment

Turn the [VOLUME] knob on the front panel or press the [ ] or [ ] button on the remote control.

The adjustable range of volume is 0 to 40.

CAUTION

While driving, keep the volume level at which external sounds can be heard.

Playing source selection

Press [ SRC / ] button on the front panel and remote control repeatedly to choose desired playing source.

Notes:

• Playing source selection means selecting

work mode, such as DISC mode, RADIO

mode, AUX mode, etc.

Display system time

Press the [ D ] button on the front panel or [DISP] button on the remote control to switch

the display information, system time and playing source.

RESET Note:

* When the [RESET] button is pressed, frequencies of radio stations, titles, etc.

stored in memory are cleared.

Note:

Doing the operation above again or adjusting volume will release muting.

RESET

System Setup

English

At all mode, press and hold [ D ] button to enter system setup. Press [ ] or [ ]

button to select options, rotate the [VOLUME] knob to adjust.

CLOCK

Press the [VOLUME] knob to enter clock setting mode, Rotate the [VOLUME] knob to set clock, press [ select hour or minute, press and hold the

[VOLUME] knob to conrm.

DX/LO (RADIO mode)

Rotate the [VOLUME] knob to choose radio local or distant at RADIO mode.

• LO: Only stations with strong signal can

be received.

• DX: Stations with strong and weak signals

can be received.

AUX SENS (AUX mode)

Rotate the [VOLUME] knob to choose AUX Input sensitivity LOW, MID or HIGH at AUX mode.

SCRN SVR: ON/OFF

Rotate the [VOLUME] knob to choose SCRN SVR (screen saver) ON or OFF.

SCROLL: ON/OFF

For track information that is longer than the

display panel: When SCROLL is ON, the LCD will display ID3 TAG information cyclely, e.g: FILE>FOLDER -> TITLE-> ARTIST- >A LBUM>TRACK->FILE... When SCROLL is OFF, the LCD will display

one of the ID3 TAG information, the default

is TRACK, but user can adjust it to other ID3 TAG information by press [ D ] button.

] or [ ] button to

S-CTRL (IPOD mode) : ON/OFF

Rotate the [VOLUME] knob to choose S-CTRL (Simple control) ON or OFF. * Refer to P17.

DIMMER: ON/OFF

Rotate the [VOLUME] knob to choose DIMMER ON or OFF.

• ON: LCD dimmer is active when small light

of vehicle is turned ON.

• OFF: LCD always maximum brightness

regardless of the vehicle small light.

REAR/S-W

Rotate the [VOLUME] knob to choose REAR or S-WOOFER (SUB-WOOFER).

TEL-SW

Rotate the [VOLUME] knob to choose OFF, MUTE or ON .

• OFF:

This unit continues normal operation even

when the cellular phone is used.

• MUTE:

The sound from this unit is muted during telephone calls.

• ON:

You can listen to your telephone calls from the speakers connected to this unit. *When listening to your calls on your car

speakers, you can adjust the volume by

turning the [VOLUME] knob.

BEEP: ON/OFF

Rotate the [VOLUME] knob to choose button beep sound ON or OFF.

12/24H

Rotate the [VOLUME] knob to choose time format: 12 or 24 hour.

Audio Setup

English

Press the [SOUND] button to enter sound

effect setting mode. First press shows current EQ. Rotate the [VOLUME] knob to changes BEAT EQ in this order: OFF -> B-BOOST -> IMPACT -> EXCITE ->

CUSTOM Rotate the [VOLUME] knob to changes CUSTOM, and press the [VOLUME] knob, the press [

it including: BAS-G -> BAS-F -> BAS-Q

-> MID-G -> MID-F -> MID-Q -> TRE-G ->

TRE-F, rotate the [VOLUME] knob to select a

value.

BAS-G / MID-G / TRE-G: (-7)- (+7) BAS-F: 60 / 80 / 100 / 200 BAS-Q: 1.0 / 1.25 / 1.5 / 2.0

] or [ ] button to select

Radio Operations

Select tuner as playing source

Press [ SRC / ] button once or more to enter RADIO mode.

Select one radio band

Press the [BAND] button on the panel or [BAND/TOP] button on the remote control to

select one radio band among FM1, FM2, FM3

and AM.

MID-F: 500 / 1K / 1.5K / 2.5K MID-Q: 0.5 / 0.75 / 1.00 / 1.25 TRE-F: 10.0K / 12.5K / 15.0K / 17.5K

Press the [SOUND] button, then press [ ] or [

] button to select USER preset including:

BALANCE -> FADER -> M-B EX -> LPF (low pass lter) -> S-W VOL (Subwoofer Volume), rotate the [VOLUME] knob to select a value. BALANCE: LEFT 1-7->CENTER->RIGHT 1-7 FADER: FRONT 1-7->CENTER->REAR 1-7 M-BEX: ON/OFF LPF: THROUGH / 80 / 120 / 160 SUBW VOL: (-6)- (+6)

Note:

When a station is received, searching stops and the station is played.

Preset scan

Preset scan receives the stations stored in preset memory in order. This function is

useful when searching for a desired station in

memory.

Manual tuning

During manual tuning, the frequency will be

changed in steps. Press the [ ] or [ ] button on the

panel to tune in a higher / lower station.

Press the [ ] or [ ] button on the remote control to tune in preset stations.

Auto tuning

Press and hold the [ ] or [ ] button to seek a higher / lower station. To stop searching, repeat the operation above or press other buttons having radio functions.

1. Press the [PS/AS] button.

2. When a desired station is tuned in, press the [PS/AS] button again to continue receiving that station.

Note:

Be careful not to press and hold the [PS/AS]

button for 1 seconds or longer, otherwise the

auto store function is engaged and the unit starts storing stations.

Auto store

Only stations with sufcient signal strength will be detected and stored in the memory.

Press and hold the [PS/AS] button (1 sec.) to start automatic station .

Radio Operations

To stop auto store, press other buttons

having radio functions.

Notes:

1. After auto store, the previous stored

stations will be overwritten.

2. The unit has 4 bands, such as FM1, FM2,

FM3 and AM. FM3 and AM can store

by AS function. Each bands can store 6

stations, CZ201 can store 24 stations in total.

Manual store

When one expected radio station has been detected, press and hold number button 1-6

to store it in the memory.

CD/MP3/WMA Operations

English

Recall the stored stations

Press one numeric button among 1 to 6 on

the panel to select the corresponding stored station.

Local seeking

When LOCAL seeking is on, only those radio

stations with strong radio signal could be

received. To open or close LOCAL function, press and hold the [ D ] button on the front panel, then press [ ] button repeatedly until LO or

DX displays on the screen, and rotate the [VOLUME] knob to select Local or Distant

mode.

Note:

The number of radio stations that can be received will decrease after the local seeking

mode is on.

This unit can play back MP3/WMA

les

Notes:

• If you play a WMA file wit h active DRM (Digital Rights Management), no audio is output.

Precautions when creating MP3/

WMA le

Usable sampling rates and bit rates

1. MP3: Sampling rate 8 kHz-48 kHz, Bit rate

8 kbps-320 kbps / VBR

2. WMA: Bit rate 8 kbps-320 kbps

File extensions

1. Always add a le extension “.MP3”, “.WMA”

to MP3, WMA file by using single byte

letters. If you add a file extension other than specified or forget to add the file

extension, the le cannot be played.

2. Files without MP3/WMA data will not play.

The files will be played soundlessly if you attempt to play les without MP3/WMA data.

* When VBR les are played, the play time

display may differ the play location.

* When MP3/WMA les are played, a little

no sound part is caused between tunes.

Logical format (File system)

1. When writing MP3/WMA file on a CD-R dis c or CD- RW di sc, ple ase sel ect

“ISO9660 level 1, 2 or Joliet or Romeo” or

Apple ISO as the writing software format. Normal play may not be possible if the

disc is recorded on another format.

2. The folder name and file name can be

displayed as the title during MP3/WMA

play but the title must be within 32 single byte alphabetical letters and numerals

(including an extension).

CD/MP3/WMA Operations

TEXT

English

3. Do not afx a name to a le inside a folder

having the same name.

Folder structure

A disc with a folder having more than 8 hierarchical levels will be impossible.

Number of les or folders

1. Up to 999 files can be recognized per

folder.

Up to 3000 les can be played.

2. Tracks are played in the order that they

were recorded onto a disc. (Tracks may not always be played in the order displayed on

the PC.)

3. Some noise may occur depending on

the type of encoder software used while

recording.

Eject function

Just pressing the [ ] button, ejects the disc even if the power to the unit was not turned

on.

Notes:

• I f you fo rce a CD int o bef ore au to

reloading, this can damage the CD.

• If a CD (12 cm) is left ejected for 15

seconds, the CD is automatically reloaded (Auto reload).

Listening to a disc already loaded in the unit

Press the [ SRC / ] button to select the CD/ MP3/WMA mode. When the unit enters the CD/MP3/WMA mode, play starts automatically.

Loading a CD

Insert a CD into the center of the CD

SLOT with label facing up. The CD plays

automatically after loading.

Notes:

• Never insert foreign objects into the CD

SLOT.

• If the CD is not inserted easily, there may be another CD in the mechanism or the unit may require service.

• Discs without the CD-ROMs cannot be played by this unit.

mark and

• Some CD-R/CD-RW discs may not be usable.

Pausing play

1. Press the [ 4 ] button to pause play.

“PAUSE” appears in the display.

2. To resume CD play, press the [ 4 ] button again.

Displaying CD titles

This unit can display title data for MP3/WMA disc. When SCROLL is OFF, each time you press the [ D ] button to change the title display.

MP3/WMA disc

FILE->FOLDER->TITLE->ARTIST->ALBUM>TRACK->FILE ...

Notes:

• If MP3/WMA disc is not input TAG, “NO TITLE” appears in the display.

• Only ASCII characters can be displayed in

Tags.

Selecting a track

Track-up

1. Press the [ ] button to move to the beginning of the next track.

2. Each time you press the [ ] button, the track advances to the beginning of the next

track.

3. For MP3/WMA disc, press and hold the

[ 6 ] button (1 sec.) to move ahead to +10 tracks.

Track-down

1. Press the [ ] button to move back to the beginning of the current track.

2. Press the [ ] button twice to move back to the beginning of the previous track.

CD/MP3/WMA Operations

3. For MP3/WMA disc, press and hold the

[ 5 ] button (1 sec.) to move back to -10

tracks.

Fast-forward/Fast-reverse

Fast-forward Press and hold the [ ] button . Fast-reverse

Press and hold the [ ] button . * For MP3/WMA discs, it takes some time

until the start of searching and between

tracks. In addition, some errors may occur in the play time.

Folder Select

This function allows you to select a folder containing MP3/WMA les and start playing from the rst track in the folder.

1. Press the [ 5 ] or [ 6 ] button. Press the [ 6 ] button to move the next

folder. Press the [ 5 ] button to move the previous folder.

2. To select a track, press the [

button.

Search Function

1. Press the [MENU] button to enter FOLD SCH mode. Press the [VOLUME] button to enter the folder list search mode.

2. Turn the [VOLUME] knob to select a folder.

3. Press the [VOLUME] button to enter the file list search mode. And then the track list appears in the display.

4. Turn the [VOLUME] knob to select a track.

5. Press the [VOLUME] knob to play.

* When play back MP3 / WMA file, this

function is performed in the current folder.

] or [ ]

English

Top function

The top function resets the CD player to the

rst track of the disc. Press and hold the [ 4 ] button (1 sec.) to play the first track (track

No. 1) on the disc.

* In case of MP3/WMA, the rst track of the

current folder will be played.

Other various play functions

Scan play

This function allows you to locate and play the rst 10 seconds of all the tracks recorded

on a disc. Press the [ 1 ] button to perform scan play.

Repeat play

This function allows you to play the current

track repeatedly or play a track currently

bei ng pl ayed in th e MP 3/W MA fo lde r

repeatedly.

CD:

1. Press the [ 2 ] button once or more until “RPT ON” appears on the LCD to perform repeat play.

2. Press [ 2 ] button repeatedly until “RPT OFF” appears on the LCD to cancel repeat

playback.

MP3/WMA:

1. Press the [ 2 ] button once or more until “TRACK RPT” appears on the display to perform repeat play, and “RPT” segment lights on.

2. For MP3/WMA file s, press [ 2 ] button repeatedly until “FOLD RPT” appears on the display for folder repeat play.

3. Press [ 2 ] button repeatedly until “RPT OFF” appears o n the d isplay to cancel repeat playback, and “RPT” segment goes

o.

Random play

This function allows you to play all tracks

recorded on a disc in a random order. Press the [ 3 ] button to perform random play.

USB Operations

English

1. Open the cover of the USB connector to the

right. Insert a USB cable (CCA-755) into

the USB connector. Insert a USB device

into the USB cable.

When connecting a USB device, the unit

will read the les automatically.

2. To remove the USB device, you should rst select another source or turn off the power,

in order to avoid damaging the USB device. Then take off the USB device. Close the cover to the left.

3. Operation is same as MP3/WMA operation.

iPod & iPhone Operations

Connect

Connect an iPod or iPhone to the USB

connector via CCA-748 cable. When connecting a device, the unit will read

the files automatically. The track information

display on the screen once playback start.

CCA-755

In the S-CTRL OFF mode, press [MENU] button,rotate the [VOLUME] knob select

“MUSIC” or “VIDEO”. Select “MUSIC”, press the [VOLUME] knob, then rotate the [VOLUME] knob to show PLAY LISTS / ARTISTS / ALBUMS / GENRES / SONGS / COMPOSERS, press and rotate the

[VOLUME] knob to select a desired option,

then press the [VOLUME] knob to conrm. Select “VIDEO”, press the [VOLUME]

knob, then rotate the [VOLUME] knob to show MOVIES MUSIC VIDEO / TV SHOWS

VIDEO PODCASTS / RENTALS, press and rotate the [VOLUME] knob to select a desired option, then press the [VOLUME] knob to

conrm.

NOTE:

VIDEO MENU item is different by the model of

connected iPod and language setting.

to monitor

CCA-748

Repeat play

This function allows you to play the current

track repeatedly or play all tracks in your iPod/iPhone repeatedly.

1. Press the [ 2 ] button once or more until “RPT ON” appears on the LCD to perform repeat play.

2. Press [ 2 ] button repeatedly until “RPT OFF” appears on the LCD to cancel repeat

playback.

Random play

This function allows you to play all tracks

recorded on a disc in a random order.

iPod & iPhone Operations

1. Press [ 3 ] button repeatedly until “ALBUM

RDM” a ppears on the LCD fo r album

random play.

2. Press the [ 3 ] button once or more until “SONG RDM” appears on the LCD to perform random play.

3. Press [ 3 ] button repeatedly until “RDM OFF” appears on the LCD to cancel

random playback.

Setting iPod simple control mode

Use this function if you wish to operate

through your iPod connected to this unit via

the USB cable.

* The factory default setting is “ OFF “.

1. Press and hold [ D ] button to enter system

setup. 2 Press [ ] or [ ] button to select “ S-CTRL“.

3. Rotate the [VOLUME] knob to select “ ON “ or “ OFF “ .

• ON: Operations are made through your

iPod.

• OFF: Op era tions can not be made

through your iPod.

Notes:

• When performing iPod operations using

simple control mode, make the operations

slo wly. If re pet itive op erati ons are performed too quickly, unforeseen errors

may occur.

• When performing iPod operations using

English

simple control mode, please do not operate the iPod and the unit at the same

time, otherwise there may be unexpected

event happened.

• Some iPod models do not support this

function. Consult your nearest Clarion

dealer or website to conrm which models

do not support this function.

iPod menu alphabet search

This function searches the subfolders for desired alphabetical letters.

1. Press the [MENU] button to select the iPod menu mode.

2. Press the [VOLUME] knob to switc h

between categories.

MUSIC: PLAYLIST, ARTISTS, ALBUMS,

GENRES, SONGS, COMPOSERS

VIDEO: MOVIES, MUSIC VIDEOS, TV

SHOWS VIDEO

PODCASTS, RENTALS

3. Press the [VOLUME] knob. (The contents

of the category are displayed.)

4. Press and hold the [ D ] button (1 sec.).

5. Rotate the [VOLUME] knob to select the

desired letter to search.

6. Press the [ D ] button again to next perform

search.

AUX Operations

Press [ SRC / ] button on the panel or remote control to select “AUX”.

AUX is just for audio content with 3.5mm Jack connector plugged into audio-in socket

on the front panel.

AUX Input sensitivity setting

1. Press and hold the [ D ] button (1 sec.).

2. Turn the [VOLUME] knob to select “AUX

SENS”.

3. If the output level of connected external

audio player is “HIGH”, rotate [VOLUME] knob and choose “LOW”. And if the output level is “LOW”, choose “HIGH”.

English

6. TROUBLE SHOOTING

GENERAL

Problem Cause Measure

Unit can not power

on.

Unit can not power

on. Nothing happens

when buttons are

pressed. Display is not

accurate.

Remote control

does not work

No/low audio

output.

Poor sound quality

or distortion

Tel-Mute

malfunction Unit resets itself

when engine is off.

Unit fuse blown.

Car battery fuse blown.

The microprocessor has malfunctioned due to noise, etc.

Battery depleted. Change the battery. Battery installed incorrectly. Install the battery correctly. Improper audio output connection. Check wiring and correct. Volume set too low. Increase volume level. Speakers damaged. Replace speakers.

Heavily biased volume balance. Adjust the channel balance to center position.

Speaker wiring is in contact with

metal part of car.

Non-standard disc used. Use a standard disc.

Speaker power rating does not

match unit. Wrong connections. Check wiring and correct. Speaker is shorted. Check wiring and correct.

MUTE wire is grounded. Check the MUTE wiring and correct.

Incorrect connection between ACC

and Battery.

Replace with new fuse of correct rating.

Turn o the power and remove the DCP.

Press the [RESET] button with a thin rod.

Note: When the [RESET] button is pressed, turn o

the ACC power.*

* When the [RESET] button is pressed,

frequencies of radio stations, titles, etc. stored in memory are cleared.

Insulate all speaker wiring connections.

Replace speakers.

Check wiring and correct.

DISC Player

Problem Cause Measure

Disc cannot be

loaded.

Sound skips or is noisy.

Sound is bad when power is rst turned

on.

Another disc is already loaded. Eject the disc before loading the new one.

There is an object installed inside the

unit. Compact disc is dirty. Clean the compact disc with a soft cloth. Compact disc is heavily scratched or

warped.

Condensation may form on the internal

lens when the car is parked in a humid

place.

Remove the object inside the unit.

Replace with a compact disc with no

scratches.

Let dry for about 1 hour with power on.

USB Devices

Problem Cause Measure

USB device cannot

be inserted.

The USB device has been inserted with wrong direction.

The USB connector is broken. Replace with a new USB device.

Reversing the connection direction of the USB device, try it again.

English

USB device is not

recognized.

No sound heard with

the display “No File”

shown.

Sound skips or is noisy.

The USB device is damaged. Connectors are loose.

No MP3/WMA le is stored in the

USB device.

MP3/WMA les are not encoded

properly.

Disconnect the USB device and reconnect. If the

device is still not recognized, try replacing with a

different USB device.

Store these les properly in the USB device.

Use MP3/WMA les encoded properly.

7. ERROR DISPLAYS

If an error occurs, one of the following displays is displayed. Take the measures described below to solve the problem.

Display Cause Measure

ERROR 3

ERROR 5 This is a failure of deck’s mechanism. Consult your store of purchase.

If an error display other than the ones described above appears, press the problem persists, turn off the power and consult your store of purchase.

Disc is inserted incorrectly. Eject the disc then reload it properly.

The disc format is not supported. Try another disc.

[RESET]

button. If the

* When the

[RESET]

memory are cleared.

button is pressed, frequencies of radio stations, titles, etc. stored in

English

7-2/5”

2-7/25” 58mm

6-2/5” 163mm

1/2” 14 m

1-4/5” 46mm

2” 50mm

7” 178mm

8. SPECIFICATIONS

FM Tuner

Frequency range: 87.9-107.9MHz Usable sensitivity: 8dBμ Frequency response: 30Hz-15kHz Stereo separation: 30dB (1kHz) Signal/noise ratio: >55dB

AM Tuner

Frequency range: 530-1710kHz Usable sensitivity (S/N=20dB): 30dBμ

CD Player

System: Disc digital audio system Frequency response: 20Hz-20kHz Signal/noise ratio: >80dB Total harmonic distortion: Less than 0.1% (1kHz) Channel separation: >60dB

MP3/WMA mode

MP3 sampling rate: 8 kHz to 48 kHz MP3 bit rate: 8 kbps to 320 kbps / VBR WMA bit rate: 8 kbps to 320 kbps Logical format: ISO9660 level 1,2 Joliet or Romeo le system

USB

Specication: USB 1.0/2.0 Playable audio format: MP3(.mp3): MPEG 1/2/Audio Layer-3 WMA(.wma): Ver 7/8/9.1/9.2

General

Power supply voltage:

14.4VDC (10.8 to 15.6V allowable),

negative ground

Pre-Amp output voltage:

2.0V (CD play mode: 1kHz, 0dB, 10k load)

Fuse: 15A Dimensions of the Main Unit: 7-2/5(width) × 2-7/25(Height) × 7-12/25(Depth) (188mm Width × 58mm Height × 190mm Depth) Weight of the Main Unit: 2.98lb. (1.35kg) Dimensions of the Remote Control unit: 1-2/3(Width) × 2/5(Height) × 4-2/5(Depth) ( 43mm Width × 11mm Height × 113mm Depth) Weight of the Remote Control Unit:

1.16oz. (36g) (including battery)

7-12/25” 190mm

6-2/3” 170mm

188mm

Notes:

Specifica ti ons an d de si gn are subjec t to chan ge wit hout no tice fo r fu rth er

improvement.

Audio Amplier

Maximum power output:

180W (45W x 4) Speaker impedance: 4 (4 to 8 allowable)

Input

Audio input sensitivity: High: 320mV (at 1V output) Mid: 650mV (at 1V output) Low: 1.3V (at 1V output)

(input impedance 10 k or greater)

Aux-in level: ≤2V

Power Output:

18 W x 4 C h a n n e ls RMS

(4Ω@14.4V≤1% THD+N)

Signal to Noise Ratio:

80 dBA (reference: 1 W into 4 Ω)

9. INSTALLATION / WIRE CONNECTION GUIDE

CONTENTS

1) Before Starting ......................................................................21

2) Package Contents ................................................................. 21

3) General Cautions ..................................................................21

4) Cautions on Installation ......................................................... 22

5) Installing the Source Unit ......................................................22

6) Removing the Source Unit ....................................................24

7) Wiring and Connections ........................................................25

8) Connecting the accessories ..................................................26

1) Before Starting

1. This set is exclusively for use in cars with a

negative ground 12 V power supply.

2. Read these instructions carefully.

3. Be sure to disconnect the battery “terminal”

before starting. This is to prevent short circuits

during installation. (Figure 1)

Figure 1

2) Package Contents

English

Car battery

Source unit ..........................................1

Front panel ..........................................1

Trim ring ..............................................1

Mounting bracket ................................. 1

Screws M5x6 mm ................................ 4

L-key ....................................................2

3) General Cautions

1. Do not open the case. There are no

user serviceable parts inside. If you

drop anything into the unit during installation, consult your dealer or an authorized Clarion service center.

Wire connector ....................................1

Remote control unit (with battery)........1

Owner’s manual...................................1

Warranty card ...................................... 1

Special screw (Front panel lock) ........1

2. Use a soft, dry cloth to clean the case. Never use a rough cloth, thinner,

benzine, or alcohol etc. For tough dirt, apply a little cold or warm water to a soft cloth and wipe off the dirt gently.

4) Cautions on Installation

(182 mm)

7-3/16"

2-1/8"

53 mm

English

1. Prepare all articles necessary for

installing the source unit before

starting.

2. Install the unit within 30° of the horizontal plane. (Figure 2)

3. If you have to do any work on the car

your car dealer beforehand.

4. Use the enclosed screws for

installation.

Using other screws can cause

damage.

(Figure 3)

body, such as drilling holes, consult

Chassis Chassis

Damage

Max 30

Max. 6 mm (M5 screw)

Figure 2 Figure 3

5) Installing the Source Unit

1. Place the mounting bracket into the instrument panel, use a screwdriver to bend each stopper of the mounting bracket inward, then secure the stopper.

2. Wire as shown in Section 7) .

3. Insert the source unit into the mounting bracket until it locks.

4. Take care of the top and bottom of the trim ring and mount it so that all the hooks

are locked.

Notes:

1. Some car models require special mounting kits for proper installation.

Consult your Clarion dealer for details.

2. Fasten the front stopper securely to prevent the source unit from coming loose.

• Console opening dimensions

Hole

Notes of installation

1. Before installation, please make sure proper connections are conducted and the unit operates normally. Improper connection may result in damage to the unit.

2. Use only accessories designed and manufactured for this unit and other

unauthorized accessories may result in

damage to the unit.

3. Before installation, please fasten all power cables.

4. DO NOT install the unit in the place where

close to hot area to prevent damage to electrical components such as the laser head.

5. Install the unit horizontally. Installing the

unit more than 30 degree vertically may

result in worse performance.

6. To prevent electric spark, connect the

positive pole rst and then the negative

pole.

7. DO NOT block the cooling fan exit to ensure sufcient heating dissipation of this

unit, or it may result in damage to this unit.

Unit Installation

Method A

1. Insert mounting bracket into dash board, choose appropriate mounting tab according to the gap width, bending the mounting tab outwards with a screwdriver to x the mounting bracket in place.

2. Slide the unit into the bracket until you hear

a click sound.

English

Dashboard

Mounting Bracket

Screwdriver

Method B

English

6) Removing the Source Unit

Disassemble trim ring

1. Push the trim ring to right and pull out the right part.

M5x6

2. Push the trim ring to left and pull out the left part.

Mounting Frame

Dashboard

1. Insert this unit directly to the opening of

the dashboard.

2. Place M5×6 cylindrical screw through the

holes of the mounting frame located inside the opening to holes of the unit and fasten

the screws to left & right.

Trim Ring installation

Attach the trim ring around the front panel.

Disassemble the unit

1. Switch off the power.

2. Remove the panel.

3. Remove the trim ring.

4. Insert the removal keys straight back until

they lock, then pull the unit out.

5. Disconnect all the wires.

7) Wiring and Connections

SWC

Steering wheel

control terminal

Black

REAR LEFT / SUB OUT 1

Black

REAR RIGHT / SUB OUT 2

Gray

White

Rear audio output (Left)/

Subwoofer output 1

Red

Rear audio output (Right)/

Subwoofer output 2

White

Left Right

Red

4 Channel Amplier

English

Fro nt aud io output terminal

(Black)

Antenna

Refer to next page

English

Front Right

Front Left

Rear Right

Rear Left

Gray

Gray/Black White

White/Black Purple

Purple/Black Green

Green/Black

16-Pin Connector Extension Lead

(attached to the source unit)

Brown wire (Phone mute lead)

Connect to cellular phone mute lead.

Yellow wire (Memory back-up lead)

Red wire (Power lead)

Connect directly to battery

Accessory

12V

4-Speaker system

2-Speaker system

Front Right

Front Left

Not used.

Insulate each wire

Gray

Gray/Black White

White/Black Purple

Purple/Black Green

Green/Black

Blue/White wire (Amplier turn-on lead)

Connect to remote turn-on lead of amplier

Black wire (Ground lead)

Connect to vehicle chassis ground

Orange/White wire (Illumination lead)

Connect it to the car power supply terminal

for illumination

Blue wire (Auto antenna lead)

Connect it to the car power supply terminal

for antenna

8) Connecting the accessories

• Connecting to the external amplier

External ampliers can be connected to the 4 channel RCA output connections.

Ensure that the connectors are not grounded or shorted to prevent damage to the

unit.

Clarion Co., Ltd.

Printed in China / Imprimé en Chine / Impreso en China

PN: 127075012840

Clarion CZ201 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
