Citroën Jumpy 2009 Owner's Manual

READY TO SET OFF

electivity of opening between the cab and

REMOTE CONTROL

the load space, contact a CITROËN dealer.

Accesses

This is confirmed by fixed lighting of
the direction indicators for approximately
two seconds.

ACCESSES

Unlocking the cab

Press this button once to unlock
your vehicle’s cab.

The direction indicators flash
twice.

Press this button a second time to unlock
the side door(s) and the rear doors.

This selective function of the accesses is
active when the vehicle is delivered. At your
request, the network can deactivate this

Unlocking the load space

Press this button to unlock all of
the rear doors.

This separation of the locking

of the cab and load space is an
operating security feature. It enables you
to prevent access to the part of the vehicle
from which you are absent.

Central locking

Press this button to lock your

vehicle, cab and rear doors.

The direction indicators flash

once.
If one of the front doors is open or is not

closed correctly, the central locking will not
work.

Deadlocking

If your vehicle is fitted with deadlocking,
a second press on the closed padlock on
the remote control within five seconds after
locking changes the locking to deadlocking.

Deadlocking renders the exterior and interior
door opening handles inoperative: do not
leave anyone inside the vehicle when it is
deadlocked.

If deadlocking is activated from inside the
vehicle, it will change to normal locking
when the vehicle is started.

Folding/unfolding the key

Press this button to release the
key from its housing.

To fold the key, press the

chromed button then fold the key
into the housing. If you do not press the
button, the mechanism may be damaged.

Good practice

Take care not to allow the remote control to
come into contact with grease, dust, rain or
a damp environment.

A heavy object attached to the key (keyring, ...)
weighing on the shaft of the key in the switch,
may cause a malfunction.

Accesses

KEY

REMOTE CONTROL

ELECTRONIC IMMOBILISER

This locks and unlocks the locks on the
vehicle and starts the engine.

Changing the battery

Battery ref.: CR1620/3 volts.
The information "battery flat" is given by an

audible signal, accompanied by a message
on the display.

To replace the battery, unclip the casing
using a coin at the ring.

If the remote control does not work after the
battery has been changed, re-programme
the remote control.

There is a risk of damage if the replacement
battery does not conform.

Use only identical batteries or batteries of an
equivalent type to those recommended by
CITROËN dealers.

Do not discard the remote control batteries,
they contain metals which are harmful to
the environment.

Deposit them at a CITROËN dealership,
or at any other approved collection point.

Programming the remote control

Following changing of the remote control battery
or disconnection of the vehicle battery, the
remote control may have to be reprogrammed.

Wait at least one minute before using the
remote control.

Insert the key in the ignition switch with the buttons
(padlocks) of the remote control facing you.

Switch on the ignition.
Press the locking padlock for at least five

seconds within the next ten seconds.
Switch off the ignition.
Wait at least one minute before using

the remote control.
The remote control is now working again.

All of the keys contain an electronic
immobiliser device.

This device locks the engine supply system.
It is activated automatically when the key is
removed from the ignition.

After the ignition is switched on, a dialogue
is established between the key and the
electronic immobiliser system.

The metal part of the key must be unfolded
correctly for correct dialogue to take place.

If you lose your keys

Visit a CITROËN dealer with the
vehicle’s V5 registration document and your
identification document.

A CITROËN dealer will be able to retrieve
the key code and the transponder code so
that a replacement key can be ordered.

Accesses

READY TO SET OFF

ALARM

Good practice

Do not make any modifications to the
electronic immobiliser system.

Operating the remote control, even when it
is in your pocket, may result in involuntary
unlocking of the doors.

The simultaneous use of other high
frequency equipment (mobile telephones,
domestic alarms…), may interfere with the
operation of the remote control temporarily.

The remote control does not operate while
the key is in the ignition, even if the ignition
is off.

As a safety precaution (with children on
board), remove the key from the ignition
when leaving the vehicle, even for a short
time.

When purchasing a second-hand vehicle:

- have the keys memorised by a
CITROËN dealer to ensure that the keys
in your possession are the only ones
which can start the vehicle.

If fitted on your vehicle, this provides two
types of protection:

- exterior protection: it sounds if a front/
rear door or the bonnet is opened.

- interior protection: it sounds if
the volume inside the passenger
compartment changes (breaking of
a window or a movement inside the
vehicle).

If your vehicle is fitted with a separation
partition, the interior protection is not active
in the load space.

Locking the vehicle with complete
alarm

Setting the alarm

- Switch off the ignition and get out of the
vehicle.

- Set the alarm within five minutes of
getting out of the vehicle, by locking or
deadlocking using the remote control.
The red diode, located on the centre
console, flashes once per second.

Disarming

- Unlock the vehicle with the remote
control or switch on the ignition, the red
diode goes out.

Locking the vehicle with exterior
protection only

If, while you are away from the vehicle, you
wish to leave a window partially open or a
pet inside the vehicle, you should choose
exterior protection only.

- Switch off the ignition.

- In the next ten seconds, press
this button, located on the
centre console, until the red
diode is on continuously.

- Get out of the vehicle.

- Within the next five minutes, set the
alarm by locking or deadlocking using
the remote control (the red diode flashes
once a second).

Accesses

KEY

REMOTE CONTROL

ELECTRONIC IMMOBILISER

This locks and unlocks the locks on the
vehicle and starts the engine.

Changing the battery

Battery ref.: CR1620/3 volts.
The information "battery flat" is given by an

audible signal, accompanied by a message
on the display.

To replace the battery, unclip the casing
using a coin at the ring.

If the remote control does not work after the
battery has been changed, re-programme
the remote control.

There is a risk of damage if the replacement
battery does not conform.

Use only identical batteries or batteries of an
equivalent type to those recommended by
CITROËN dealers.

Do not discard the remote control batteries,
they contain metals which are harmful to
the environment.

Deposit them at a CITROËN dealership,
or at any other approved collection point.

Programming the remote control

Following changing of the remote control battery
or disconnection of the vehicle battery, the
remote control may have to be reprogrammed.

Wait at least one minute before using the
remote control.

Insert the key in the ignition switch with the buttons
(padlocks) of the remote control facing you.

Switch on the ignition.
Press the locking padlock for at least five

seconds within the next ten seconds.
Switch off the ignition.
Wait at least one minute before using

the remote control.
The remote control is now working again.

All of the keys contain an electronic
immobiliser device.

This device locks the engine supply system.
It is activated automatically when the key is
removed from the ignition.

After the ignition is switched on, a dialogue
is established between the key and the
electronic immobiliser system.

The metal part of the key must be unfolded
correctly for correct dialogue to take place.

If you lose your keys

Visit a CITROËN dealer with the
vehicle’s V5 registration document and your
identification document.

A CITROËN dealer will be able to retrieve
the key code and the transponder code so
that a replacement key can be ordered.

Accesses

READY TO SET OFF

ALARM

Good practice

Do not make any modifications to the
electronic immobiliser system.

Operating the remote control, even when it
is in your pocket, may result in involuntary
unlocking of the doors.

The simultaneous use of other high
frequency equipment (mobile telephones,
domestic alarms…), may interfere with the
operation of the remote control temporarily.

The remote control does not operate while
the key is in the ignition, even if the ignition
is off.

As a safety precaution (with children on
board), remove the key from the ignition
when leaving the vehicle, even for a short
time.

When purchasing a second-hand vehicle:

- have the keys memorised by a
CITROËN dealer to ensure that the keys
in your possession are the only ones
which can start the vehicle.

If fitted on your vehicle, this provides two
types of protection:

- exterior protection: it sounds if a front/
rear door or the bonnet is opened.

- interior protection: it sounds if
the volume inside the passenger
compartment changes (breaking of
a window or a movement inside the
vehicle).

If your vehicle is fitted with a separation
partition, the interior protection is not active
in the load space.

Locking the vehicle with complete
alarm

Setting the alarm

- Switch off the ignition and get out of the
vehicle.

- Set the alarm within five minutes of
getting out of the vehicle, by locking or
deadlocking using the remote control.
The red diode, located on the centre
console, flashes once per second.

Disarming

- Unlock the vehicle with the remote
control or switch on the ignition, the red
diode goes out.

Locking the vehicle with exterior
protection only

If, while you are away from the vehicle, you
wish to leave a window partially open or a
pet inside the vehicle, you should choose
exterior protection only.

- Switch off the ignition.

- In the next ten seconds, press
this button, located on the
centre console, until the red
diode is on continuously.

- Get out of the vehicle.

- Within the next five minutes, set the
alarm by locking or deadlocking using
the remote control (the red diode flashes
once a second).

Accesses

READY TO SET OFF

ALARM

Good practice

Do not make any modifications to the
electronic immobiliser system.

Operating the remote control, even when it
is in your pocket, may result in involuntary
unlocking of the doors.

The simultaneous use of other high
frequency equipment (mobile telephones,
domestic alarms…), may interfere with the
operation of the remote control temporarily.

The remote control does not operate while
the key is in the ignition, even if the ignition
is off.

As a safety precaution (with children on
board), remove the key from the ignition
when leaving the vehicle, even for a short
time.

When purchasing a second-hand vehicle:

- have the keys memorised by a
CITROËN dealer to ensure that the keys
in your possession are the only ones
which can start the vehicle.

If fitted on your vehicle, this provides two
types of protection:

- exterior protection: it sounds if a front/
rear door or the bonnet is opened.

- interior protection: it sounds if
the volume inside the passenger
compartment changes (breaking of
a window or a movement inside the
vehicle).

If your vehicle is fitted with a separation
partition, the interior protection is not active
in the load space.

Locking the vehicle with complete
alarm

Setting the alarm

- Switch off the ignition and get out of the
vehicle.

- Set the alarm within five minutes of
getting out of the vehicle, by locking or
deadlocking using the remote control.
The red diode, located on the centre
console, flashes once per second.

Disarming

- Unlock the vehicle with the remote
control or switch on the ignition, the red
diode goes out.

Locking the vehicle with exterior
protection only

If, while you are away from the vehicle, you
wish to leave a window partially open or a
pet inside the vehicle, you should choose
exterior protection only.

- Switch off the ignition.

- In the next ten seconds, press
this button, located on the
centre console, until the red
diode is on continuously.

- Get out of the vehicle.

- Within the next five minutes, set the
alarm by locking or deadlocking using
the remote control (the red diode flashes
once a second).

Accesses

Triggering

The siren sounds, the direction indicators
flash for approximately 30 seconds and the
red diode flashes rapidly.

- To switch it off, insert the key and switch
on the ignition.

When the alarm has been triggered ten
times in succession (when triggered for the
eleventh time) it is deactivated. Repeat the
rules for setting the alarm.

Incorrect operation

When the ignition is switched on, if the red
diode remains on for ten seconds, there is a
fault in the siren connection.

Contact a CITROËN dealer to have
the system checked.

Locking the vehicle without alarm

- Insert the key in the lock on the driver ’s
door and lock it.

Do not set the alarm when washing your
vehicle.

Failure of the remote control

When the alarm is set but the remote control
does not operate:

- Unlock the doors with the key and open
the door. The alarm is triggered.

- Switch on the ignition in the next ten
seconds. The alarm is disarmed.

Automatic setting of the alarm

Depending on the country in which the
vehicle is sold, the alarm is set automatically
approximately 2 minutes after the last door
is closed.

To prevent triggering of the alarm when a
door is opened, it is imperative to press the
remote control unlocking button again.

Do not make any modifications to
the alarm system as this could cause
faults.

Accesses

READY TO SET OFF

DOORS

From the outside

Use the remote control to lock/unlock the
vehicle.

Insert the metal part of the key in the lock on
the driver’s side if the remote control does
not work.

From the inside

Cab and load space

The first press permits central
locking of the front and rear
doors, if they are closed.

A second press permits central unlocking of
the vehicle.

The control does not work if the vehicle has
been locked using the remote control or the
key from the outside.

Load space - comes on if the accesses are

Pressing permits locking/
unlocking of the rear doors from
the cab.

This selective accesses function
is activated on delivery. At your request,
the network can deactivate this opening
selectivity between the cab and load space,
contact a CITROËN dealer.

The doors can still be opened from the inside.

The indicator light on the controls:

- flashes if the accesses are
locked when stationary with
the engine off,

Protection against attack

When the vehicle is started, the system
automatically locks the front doors. When
you reach approximately 6 mph (10 km/h),
the system locks the rear doors.

Activation/deactivation of the function

Opening warning light

locked and from the time the
ignition is switched on.

With the ignition on, a long
press on this button activates or
deactivates the function.

If this warning light comes on,
check that the cab doors and
the rear or side doors are closed
correctly.

Accesses

SLIDING SIDE DOOR

If fitted on your vehicle, do not open the left­hand side door while filling with fuel as you
risk damaging the fuel filler flap.

From the outside

Pull the handle towards you then towards
the rear.

Good practice

Take care not to block the guide space on
the floor to allow the door to slide correctly.

For safety and operation reasons, do not
drive with the sliding side door open.

From the inside

To unlock and open, push the handle
towards the rear. Ensure that the door opens
fully to lock the device at the base of
the door.

Operation in the event of a battery
failure

Front and side passenger doors

In the event of a malfunction of the battery
or of the central locking, use the lock to lock
the doors mechanically.

- To open the door and get out of
the vehicle, pull the interior control.

- To lock the door, insert the key in the
lock, located on the edge of the door,
then turn it one eighth of a turn .

Driver’s door

- Insert the key in the lock, then turn it to
the right to lock or to the left to unlock.

Accesses

READY TO SET OFF

HINGED REAR DOORS

TAILGATE

From the outside

The two hinged doors open to 90°.
To open, pull the handle towards you then

pull the lever to open the left-hand door.
To close, start with the left-hand door then

close the right-hand door.

Opening to 180°

A retractable check strap system permits
extension of the opening from 90° to 180°.

Disengage the check strap towards you
when the door is partially open.

The check strap will re-attach automatically
on closing.

When parked with the rear
doors open to 90°, the doors
mask the rear lights.

To signal your position to road
users travelling in the same
direction who may not have
noticed that you have stopped,
use a warning triangle or any
other device stipulated by the
legislation and regulations of
your country.

From the outside

If fitted on your vehicle, locking/unlocking is
via the remote control.

To open, press the control then raise the
tailgate.

A strap is provided to secure the tailgate in
the upper position.

From inside

Emergency control

In the event of a central unlocking operating
fault, this permits unlocking of the tailgate
from the inside.

Fold the rear seats to gain access to the lock.
Insert a small screwdriver in this opening to

unlock the tailgate.

Instruments and controls

INSTRUMENT PANEL

INSTRUMENTS AND CONTROLS

1. Distance recorder in kilometres/miles.

2. Display.

3. Fuel level, coolant temperature.

4. Rev counter.

5. Instrument panel lighting rheostat.

6. Trip distance recorder/service indicator

zero reset.

Warning light and controls on
the overhead storage unit

- Passenger air bag disarmed warning
light.

- Driver/passenger heated seat controls
(version with 2 front seats).

Instrument panel display

- Speed limiter/cruise control.

- Kilometres/Miles travelled.

- Service indicator, engine oil level
indicator, total kilometres/miles.

- Presence of water in the diesel filter.

- Diesel pre-heating.

Instruments and controls

READY TO SET OFF

ADJUSTING THE TIME

Instrument panel without display

Centre console without display

To adjust the time of the clock
on the instrument panel, use
the left-hand button on the
instrument panel then carry out

the operations in the following order:

- turn to the left: the minutes flash,

- turn to the right to increase the minutes
(hold the button to the right for rapid
scrolling),

- turn to the left: the hours flash,

- turn to the right to increase the hours
(hold the button to the right for rapid
scrolling),

- turn to the left: 24 H or 12 H is displayed,

- turn to the right to select 24 H or 12 H,

- turn to the left to complete the time
adjustment.

After approximately 30 seconds without any
action, the display returns to the normal
display.

Centre console with display

The display - time sequence
is linked according to model
(version). The access to the Date
is only active when the model
version offers a date in words.

To adjust the time indicated on the
display, refer to the "Adjusting the date
and time" section of chapter 9.

Instruments and controls

READY TO SET OFF

ADJUSTING THE TIME

Instrument panel without display

Centre console without display

To adjust the time of the clock
on the instrument panel, use
the left-hand button on the
instrument panel then carry out

the operations in the following order:

- turn to the left: the minutes flash,

- turn to the right to increase the minutes
(hold the button to the right for rapid
scrolling),

- turn to the left: the hours flash,

- turn to the right to increase the hours
(hold the button to the right for rapid
scrolling),

- turn to the left: 24 H or 12 H is displayed,

- turn to the right to select 24 H or 12 H,

- turn to the left to complete the time
adjustment.

After approximately 30 seconds without any
action, the display returns to the normal
display.

Centre console with display

The display - time sequence
is linked according to model
(version). The access to the Date
is only active when the model
version offers a date in words.

To adjust the time indicated on the
display, refer to the "Adjusting the date
and time" section of chapter 9.

Instruments and controls

WARNING LIGHTS

Each time the engine is started: a series of warning lights comes on applying a check auto-test. They are switched off almost immediately.
When the engine is running: the warning light becomes a warning if it remains on continuously or flashes. This initial warning may be
accompanied by an audible signal and a message on the display.

Do not ignore these warnings

Warning light is indicates Solution - action

STOP

lit, associated
with another
warning
light and
accompanied by
a message on
the display.

major faults linked with the
"Brake fluid level", "Engine oil
pressure and temperature",
"Coolant temperature",
"Electronic brake force
distribution" and "Power
steering" warning lights.

You must stop, park, switch off the ignition and call
a CITROËN dealer.

Handbrake/

Brake fluid
level/EBFD

lit.

handbrake applied or not
released correctly.

Releasing the handbrake switches off the warning light.

lit. low brake fluid level. Top up using a fluid recommended by CITROËN.

remaining on,
even though the
level is correct and
associated with the
ABS warning light.

failure of the electronic brake
force distribution.

You must stop, park, switch off the ignition and call
a CITROËN dealer.

Engine oil

pressure and
temperature

lit while driving.

insufficient pressure or
temperature too high.

Park, switch off the ignition and allow to cool. Visually
check the level. Chapter 6, "Levels" section.

remaining on,
even though the
level is correct.

major fault. Call a CITROËN dealer.

Instruments and controls

READY TO SET OFF

Warning light is indicates Solution-action

Coolant

temperature
and level

lit with needle in
the red zone.

abnormal increase in
temperature.

Park and switch off the ignition then allow to cool.
Visually check the level.

flashing. drop in coolant level. Chapter 6, "Levels" section. Contact a CITROËN dealer.

Service

lit temporarily. minor faults or warnings.

Consult the warnings log on the display or on the screen.
See chapter 9, "Trip computer" section then "Warnings log".
Depending on the seriousness of the fault, contact a

CITROËN dealer.

remaining on. major faults.

Row 1 seat belt
not fastened

lit then flashing.

the driver or a front passenger
has not fastened his seat belt.

Pull the strap then insert the tongue in the buckle.

accompanied
by an audible
signal then
remains on.

the vehicle is moving with the
driver or front passenger seat
belt not fastened.

Check that the seat belt is fastened by pulling the strap.
Chapter 4, "Seat belts" section.

The driver must ensure that all passengers have
fastened their seat belt and use it correctly.

Instruments and controls

Warning light is indicates Solution-action

Front/side/
curtain air bag

flashing or
remaining on.

failure of an air bag.

Have the system checked by a CITROËN dealer without
delay. Chapter 4, "Air bags" section.

Front

passenger air
bag disarmed

lit.

intentional disarming of this air
bag in the presence of a rear
facing child seat.

Chapter 4, "Air bags-children on board" section.

Low fuel level

lit with gauge
needle in the red
zone.

that when it first comes on
approximately 8 litres of fuel
remain.

It is essential to fill the tank to avoid running out of fuel.
Never continue to drive until you run out of fuel, this

could damage the emission control and injection
systems.

Tank capacity: approximately 80 litres

remaining on each
time the ignition is
switched on.

an insufficient top-up of the
fuel.

flashing.

cutting off of the supply
following a serious impact.

Restore the supply. Chapter 6, "Fuel" section.

EOBD emission
control system

flashing or
remaining on.

failure of the system.

Have the system checked by a CITROËN dealer as
soon as possible.

Battery charge

lit. fault in the charging circuit.

Check the battery terminals, … Chapter 7, "Battery"
section.

flashing.

placing of the active functions
on standby (economy mode).

Chapter 7, "Battery" section.

remaining on,
in spite of the
checks.

faulty circuit, injection or
ignition malfunction.

Call a CITROËN dealer.

ABS

ESP

Instruments and controls

READY TO SET OFF

Warning light is indicates Solution-action

Power
steering

lit. system malfunction.

The vehicle retains conventional steering without assistance.
Have the system checked by a CITROËN dealer.

Opening
detection

lit and
accompanied by
a message on
the display.

access not closed correctly.

Check that the cab doors, the rear and side doors and
the bonnet are closed (if your vehicle is fitted with an
alarm).

Rear

suspension
with pneumatic
compensation

flashing.

abnormal difference between
the detected sill height and
the optimum sill height.

In automatic correction mode: drive slowly (approximately
6 mph (10 km/h)) until the warning light is switched off.

In manual correction mode: return the sill which is
still at the upper or lower limit to an optimum height.
Chapter 3, "Rear suspension" section.

lit on starting or
while driving.

failure of the pneumatic
compensation.

You must stop. Call a CITROËN dealer.

ABS remaining on.

failure of the anti-lock braking
system.

The vehicle retains conventional braking without assistance
but you are advised to stop. Call a CITROËN dealer.

ESP

flashing.

triggering of regulation by
the ESP.

The system optimises drive and permits improvement
of the directional stability of the vehicle. Chapter 4,
"Driving safety" section.

remaining on.

system malfunction. E.g.:
under-inflation of the tyres.

E.g. Check the pressure of the tyres. Have them
checked by a CITROËN dealer.

remaining on
with the diode
on the button
(on the fascia)
lit.

deactivation of the system at
the request of the driver.

Operation of the system is deactivated.
Reactivation is automatic above 30 mph (50 km/h) or

after pressing the button (on the fascia).

Instruments and controls

Warning light is indicates Solution-action

Brake
pads

lit. brake pad wear. Have the pads replaced by a CITROËN dealer.

Dipped

headlamps/
Daytime lights

lit.

manual selection or automatic
lighting.

Rotate the ring on the lights stalk to the second position.

lighting of the dipped headlamps
from the time the ignition is
switched on - daytime lights.

Depending on the country in which the vehicle is sold.
Chapter 3, "Steering wheel controls" section.

Main beam
headlamps

pulling of the stalk towards you. Pull the stalk to return to dipped headlamps.

Direction
indicators

flashing with
buzzer.

change of direction via the
lights stalk, to the left of the
steering wheel.

To the Right: control to be pushed upwards.
To the Left: control to be pushed downwards.

Front fog
lamps

lit. manual selection.

The fog lamps only operate if the side lights or dipped
headlamps are on.

Rear fog
lamps

lit. manual selection.

The fog lamps only operate if the side lights or dipped
headlamps are on. In conditions of normal visibility,
take care to switch them off on penalty of being booked.
"This light is a dazzling red."

Particle
emission filter

lit.

a malfunction of the particle
emission filter (diesel additive
level, risk of clogging, ...).

Have the filter checked by a CITROËN dealer.
Chapter 6, "Checks" section.

Instruments and controls

READY TO SET OFF

Display is indicates Solution-action

Cruise
control

Speed
limiter

Diesel pre-
heating

Particle
emission filter

Presence of

water in the
diesel filter

Service
spanner

Time displayed. adjustment of the time.

lit. cruise control selected.

lit. speed limiter selected.

lit.

lit

lit and
accompanied by
a message on
the display.

lit. service due shortly.

climatic conditions requiring
pre-heating.

a malfunction of the particle
emission filter (diesel additive
level, risk of clogging, ...).

water in the diesel filter.

Manual selection. Chapter 3, "Steering wheel controls"
section.

Manual selection. Chapter 3, "Steering wheel controls"
section.

Wait until the warning light is switched off before
operating the starter.

Have the filter checked by a CITROËN dealer.
Chapter 6, "Checks" section.

Have the filter bled by a CITROËN dealer without delay.
Chapter 6, "Checks" section.

Refer to the list of checks in the servicing booklet. Have
the service carried out by a CITROËN dealer.

Use the left-hand button on the instrument panel.
Chapter 2, at the beginning of the "Instruments and
controls" section.

Instruments and controls

FUEL GAUGE

COOLANT TEMPERATURE

The fuel level is tested each time the key is
turned to the "running" position.

The gauge is positioned on:

- 1: the fuel tank is full, approximately

80 litres.

- 0: the reserve is now being used, the

warning light comes on continuously.

The reserve when the warning first comes
on is approximately 8 litres.

Refer to the "Fuel" section of chapter 6.

The needle is positioned before the red
zone: normal operation.

In arduous conditions of use or hot climatic
conditions, the needle may move close to
the red graduations.

What you should do if the needle enters
the red zone:

Reduce your speed or let the engine run at
idle.

What you should do if the warning light
comes on:

- stop immediately, switch off the ignition.
The fan may continue to operate for a
certain time up to approximately
10 minutes.

- wait for the engine to cool down in order
to check the coolant level and top it up if
necessary.

As the cooling system is pressurised, follow
this advice in order to avoid any risk of
scalding:

- wait at least one hour after switching off
the engine before carrying out any work,

- unscrew the cap by 1/4 turn to allow the
pressure to drop,

- when the pressure has dropped, check
the level on the expansion bottle,

- if necessary, remove the cap to top up.

If the needle remains in the red zone, have
the system checked by a CITROËN dealer.

Refer to the "Levels" section of
chapter 6.

Instruments and controls

READY TO SET OFF

SERVICE INDICATOR

EMISSION CONTROL

EOBD (European On Board
Diagnosis) is a diagnostics
system which complies with,
among others, the standards

concerning authorised emissions of:

- CO (carbon monoxide),

- HC (unburnt hydrocarbons),

- NOx (nitrogen oxides) or particles,
detected by oxygen sensors placed
upstream and downstream of the
catalytic converters.

Therefore, the driver is warned of any
malfunction of this emission control system
by the lighting of this specific warning light
on the instrument panel.

There is a risk of damage to the catalytic
converter. Have it checked by a CITROËN
dealer.

This programmes service intervals according
to the use of the vehicle.

Operation

A few moments after the ignition has been
switched on, the spanner indicating a
service operation lights up; the display for
the total distance recorder tells you (in round
figures) the distance remaining before the
next service.

The points at which a service is due are
calculated from the last indicator zero reset.

The point at which a service is due is
determined by two parameters:

- the distance travelled,

- the time which has elapsed since
the last service.

The distance remaining before the next

service may be weighted by the time
factor, depending on the driver’s driving
habits.

More than 1 000 miles/km before
the next service is due

Example: 4 800 miles/km remain before
the next service is due. When the ignition is
switched on and for a few seconds,
the display shows:

A few seconds after the ignition is switched
on, the oil level is displayed, then the total
distance recorder resumes normal operation
showing the total and trip distances.

Less than 1 000 miles/km before the next
service is due

Each time the ignition is switched on and for a few

seconds, the spanner fl ashes and the number of

miles/kilometres remaining is displayed:

A few seconds after the ignition is switched
on, the oil level is displayed, then the total
distance recorder resumes normal operation
and the spanner remains lit. This indicates
that a service should be carried out shortly.

Service overdue

Each time the ignition is switched
on and for a few seconds, the

spanner fl ashes and the excess

distance is displayed.

With the engine running the spanner
remains lit until the service has been
carried out.

First of the two terms reached: the spanner
also lights up if the two-year interval has
elapsed.

Instruments and controls

READY TO SET OFF

SERVICE INDICATOR

EMISSION CONTROL

EOBD (European On Board
Diagnosis) is a diagnostics
system which complies with,
among others, the standards

concerning authorised emissions of:

- CO (carbon monoxide),

- HC (unburnt hydrocarbons),

- NOx (nitrogen oxides) or particles,
detected by oxygen sensors placed
upstream and downstream of the
catalytic converters.

Therefore, the driver is warned of any
malfunction of this emission control system
by the lighting of this specific warning light
on the instrument panel.

There is a risk of damage to the catalytic
converter. Have it checked by a CITROËN
dealer.

This programmes service intervals according
to the use of the vehicle.

Operation

A few moments after the ignition has been
switched on, the spanner indicating a
service operation lights up; the display for
the total distance recorder tells you (in round
figures) the distance remaining before the
next service.

The points at which a service is due are
calculated from the last indicator zero reset.

The point at which a service is due is
determined by two parameters:

- the distance travelled,

- the time which has elapsed since
the last service.

The distance remaining before the next

service may be weighted by the time
factor, depending on the driver’s driving
habits.

More than 1 000 miles/km before
the next service is due

Example: 4 800 miles/km remain before
the next service is due. When the ignition is
switched on and for a few seconds,
the display shows:

A few seconds after the ignition is switched
on, the oil level is displayed, then the total
distance recorder resumes normal operation
showing the total and trip distances.

Less than 1 000 miles/km before the next
service is due

Each time the ignition is switched on and for a few

seconds, the spanner fl ashes and the number of

miles/kilometres remaining is displayed:

A few seconds after the ignition is switched
on, the oil level is displayed, then the total
distance recorder resumes normal operation
and the spanner remains lit. This indicates
that a service should be carried out shortly.

Service overdue

Each time the ignition is switched
on and for a few seconds, the

spanner fl ashes and the excess

distance is displayed.

With the engine running the spanner
remains lit until the service has been
carried out.

First of the two terms reached: the spanner
also lights up if the two-year interval has
elapsed.

Instruments and controls

Zero re-set

Your CITROËN dealer carries out this
operation after each service.

However, if you carry out the service
yourself, the re-set procedure is as follows:

- switch off the ignition,

- press and hold the trip recorder reset
button,

- switch on the ignition.

The display begins a countdown.
When the display shows "=0" , release the

button; the spanner disappears.

After this operation, if you wish to

disconnect the battery, lock the vehicle
and wait for at least five minutes, otherwise
the zero re-set will not be registered.

Engine oil level indicator

When the ignition is switched on, the engine
oil level is indicated for a few seconds, after
the service information.

Oil level correct

Lack of oil

Flashing of "OIL" , linked
with the service warning
light, accompanied by

an audible signal and a
message on the display, indicates a lack of
oil which could damage the engine.

If the lack of oil is confirmed by a check
using the dipstick, it is essential that the
level is topped up.

Oil level gauge fault

Flashing of "OIL --"

indicates a malfunction

of the engine oil level

gauge. Consult a

CITROËN dealer.

The level read will only be correct if the

vehicle is on level ground and
the engine has been off for more than
15 minutes.

Dipstick

A = maximum, never exceed
this level as a surplus of oil may
damage the engine.

Contact a CITROËN dealer
without delay.

B = minimum, top up the level via
the oil filler cap, using the type of
oil suited to your engine.

Trip recorder zero reset
button

With the ignition on, press
the button until the zeros
appear.

Lighting rheostat

With the lights on, press the
button to vary the intensity of
the lighting of the instruments

and controls. When the
lighting reaches the minimum (or maximum)
setting, release the button then press it
again to increase (or reduce) the brightness.

As soon as the lighting is of the required
brightness, release the button.

Instruments and controls

Zero re-set

Your CITROËN dealer carries out this
operation after each service.

However, if you carry out the service
yourself, the re-set procedure is as follows:

- switch off the ignition,

- press and hold the trip recorder reset
button,

- switch on the ignition.

The display begins a countdown.
When the display shows "=0" , release the

button; the spanner disappears.

After this operation, if you wish to

disconnect the battery, lock the vehicle
and wait for at least five minutes, otherwise
the zero re-set will not be registered.

Engine oil level indicator

When the ignition is switched on, the engine
oil level is indicated for a few seconds, after
the service information.

Oil level correct

Lack of oil

Flashing of "OIL" , linked
with the service warning
light, accompanied by

an audible signal and a
message on the display, indicates a lack of
oil which could damage the engine.

If the lack of oil is confirmed by a check
using the dipstick, it is essential that the
level is topped up.

Oil level gauge fault

Flashing of "OIL --"

indicates a malfunction

of the engine oil level

gauge. Consult a

CITROËN dealer.

The level read will only be correct if the

vehicle is on level ground and
the engine has been off for more than
15 minutes.

Dipstick

A = maximum, never exceed
this level as a surplus of oil may
damage the engine.

Contact a CITROËN dealer
without delay.

B = minimum, top up the level via
the oil filler cap, using the type of
oil suited to your engine.

Trip recorder zero reset
button

With the ignition on, press
the button until the zeros
appear.

Lighting rheostat

With the lights on, press the
button to vary the intensity of
the lighting of the instruments

and controls. When the
lighting reaches the minimum (or maximum)
setting, release the button then press it
again to increase (or reduce) the brightness.

As soon as the lighting is of the required
brightness, release the button.

READY TO SET OFF

GEARBOXES AND STEERING WHEEL

5-speed gearbox 6-speed gearbox

Gearboxes and steering wheel

To change gear easily, always press
the clutch pedal fully.

To prevent the mat from becoming caught
under the pedal:

- ensure that the mat is positioned
correctly,

- never fit one mat on top of another.

When driving, avoid leaving your hand on
the gear knob as the force exerted, even if
slight, may wear the internal components of
the gearbox over time.

Reverse gear

In the 6-speed configuration, raise the collar
under the gear knob to engage reverse gear.

Never engage reverse gear before
the vehicle is completely stationary.

The lever should be moved slowly to reduce
the noise on engaging reverse gear.

When the vehicle is stationary, unlock
the steering wheel by lowering the lever.

Adjust the height and depth of the steering
wheel, then lock by pushing the lever fully
upwards.

Starting and stopping

STARTING AND STOPPING

Running and accessories position.
To unlock the steering, turn the steering

wheel gently while turning the key, without
forcing. In this position, certain accessories
can be used.

Good practice when starting

Door or bonnet open warning light

If this comes on, a door or the
bonnet is not closed correctly,
check!

Key

Take care to prevent the key from coming
into contact with grease, dust, rain or a
damp environment.

A heavy object attached to the key (key
ring, ...) weighing the key down in the ignition
switch may cause a malfunction.

Good practice when stopping

Minimise engine and gearbox wear

When switching off the ignition, let the
engine run for a few seconds to allow the
turbocharger (Diesel engine) to return to
idle.

Do not press the accelerator when switching
off the ignition.

There is no need to engage a gear after
parking the vehicle.

Starting position.
The starter is operated, the engine turns

over, release the key.

STOP position: steering lock.
The ignition is off. Turn the steering wheel

until the steering locks. Remove the key.

Diesel pre-heating warning light

If the temperature is high
enough, the warning light comes
on for less than one second, you
can start without waiting.

In cold weather, wait for this warning light to
switch off then operate the starter (Starting
position) until the engine starts.

DIRECTION INDICATORS

STEERING WHEEL CONTROLS

LIGHTING CONTROL

(flashing)

Left : downwards passing
the point of resistance.

Right : upwards passing
the point of resistance.

Front and rear lights

Selection is by turning ring A .

Checking by means of the indicator
lights on the instrument panel is
described in the "Instruments and
controls" section of chapter 2.

Steering wheel controls

Lights off

Automatic lights
if your vehicle is fitted with a

brightness sensor.

Side lights

Dipped beam (green)
Main beam (blue)

Dipped beam/main beam change

Pull the stalk fully towards you.

Lights-on buzzer

When the ignition is switched off, when the
driver’s door is opened, a buzzer sounds if
you have left your lights on.

DIRECTION INDICATORS

STEERING WHEEL CONTROLS

LIGHTING CONTROL

(flashing)

Left : downwards passing
the point of resistance.

Right : upwards passing
the point of resistance.

Front and rear lights

Selection is by turning ring A .

Checking by means of the indicator
lights on the instrument panel is
described in the "Instruments and
controls" section of chapter 2.

Steering wheel controls

Lights off

Automatic lights
if your vehicle is fitted with a

brightness sensor.

Side lights

Dipped beam (green)
Main beam (blue)

Dipped beam/main beam change

Pull the stalk fully towards you.

Lights-on buzzer

When the ignition is switched off, when the
driver’s door is opened, a buzzer sounds if
you have left your lights on.

Steering wheel controls

Front and rear fog lights

Rotate ring B forwards to switch on and
rearwards to switch off. The status is
confirmed by the light on the instrument
panel.

These operate with the side lights and the
dipped beam headlamps.

Front fog lights (green,
1st rotation of the ring forwards).

Front fog lights (green)
and rear fog lights (amber,
2nd rotation of the ring
forwards).

To switch off the front and rear fog
lights, turn the ring rearwards twice in
succession.

In clear weather or in rain, both day
and night, rear fog lights dazzle and
are prohibited.

Do not forget to switch them off when they
are no longer needed.

Automatic switching on of the lights switches
off the rear fog lamps, but the front fog
lamps remain on.

Daytime lights

Depending on the country in which the
vehicle is sold, the vehicle may be equipped
with daytime lights. The dipped headlamps
come on when the vehicle is started.

This warning light comes on on
the instrument panel.

The instruments and controls

(instrument panel, display, air
conditioning control panel, ...) are only lit
on switching to the automatic switching on
of the lights mode or when the lights are
switched on manually.

Steering wheel controls

Automatic switching on of the lights

The side lights and dipped
beam headlamps switch
on automatically if the light

is poor, or during operation
of the windscreen wipers. They switch off as
soon as the light becomes bright enough or
the windscreen wipers stop.

This function is not compatible with the
daytime lights.

Activation

Turn the ring to the AUTO position. The
activation of this function is accompanied by
a message on the display.

Deactivation

Turn the ring forwards or rearwards. The
deactivation of this function is accompanied
by a message on the display.

The function is deactivated temporarily when
you use the manual lights stalk.

In foggy weather or in snow, the

brightness sensor can detect sufficient
light. As a consequence, the lights will
not come on automatically. If necessary,
you must switch on the dipped headlamps
manually.

Do not cover the brightness sensor

located on the windscreen, behind the
mirror. It is used for the automatic switching
on of the lights and for the automatic wipers.

If the brightness sensor does not
function correctly , the lights come on
accompanied by the service warning light,
an audible signal and a message on the
display.

Consult a CITROËN dealer.

Depending on the load in your vehicle, the
beam setting must be adjusted.

0 - No load.
1 - Partial load.
2 - Average load.
3 - Maximum authorised load.

Initial setting is position 0.

Steering wheel controls

WINDSCREEN WIPER STALK

Wash-wipe and headlamp wash
Pull the stalk towards you, the wash-wipe

is accompanied by a timed sweep of the
wipers.

The headlamp wash is linked with the wash­wipe, it is triggered if the dipped headlamps
are on.

To top up the levels, refer to the
"Levels" section of chapter 6.

Automatic windscreen wipers

Do not cover the rain sensor,
located in the centre of the
windscreen, behind the mirror.

Manual windscreen wipers

2 Fast wipe (heavy rain).
1 Normal wipe (moderate rain).
l Intermittent wipe.
0 Off.
 Single wipe
(press downwards).

In the I ntermittent position, the wiping speed
is in proportion to the vehicle speed.

Whenever the ignition has been switched
off for more than one minute, with the
windscreen wiper stalk in position 2, 1 or I,
the stalk must be reactivated:

- move the stalk to any position,

- then move it back to the required
position.

In the AUTO position, the windscreen wipers
operate automatically and adapt their speed
to the intensity of the rainfall.

When not in AUTO mode, for the other
positions, refer to the manual windscreen
wipers section.

Steering wheel controls

Activation

Press the control downwards. Activation of
the function is accompanied by a message
on the display.

The automatic windscreen wipers function
must be reactivated if the ignition has been
switched off for more than one minute, by
pressing the stalk downwards.

Deactivation/Switching off

Place the windscreen wipers stalk in
position I , 1 or 2 . Deactivation of the function
is accompanied by a message on the
display.

In the event of malfunction of the automatic
windscreen wipers, the windscreen wipers
will operate in intermittent mode.

Contact a CITROËN dealer to have the
system checked.

When using an automatic car wash,
switch off the ignition to avoid
triggering of the automatic wiping.

In winter, it is advisable to wait for the
windscreen to completely clear of ice before
operating the automatic wipe.

Special position of the windscreen
wipers

In the minute following switching off of the
ignition, any action on the stalk positions the
wipers against the windscreen uprights.

This action enables you to position the
wiper blades for winter parking, cleaning or
replacement.

Refer to the "Changing a windscreen
wiper blade" section of chapter 7.

To park the wipers in their normal position
after this has been done, switch on the
ignition and move the stalk.

Rear windscreen wiper

Turn the ring to the first notch.

Rear windscreen wash

Turn the ring past the first notch:
the windscreen wash then the
windscreen wiper operate for a
fixed time.

In winter, in the event of a considerable

amount of snow or ice, switch on the
rear screen demister. Once de-icing is
complete, remove the snow or ice which has
accumulated on the rear wiper blade. You
can then operate the rear windscreen wiper.

Steering wheel controls

CRUISE CONTROL "CRUISE"

In order for it to be programmed or
activated, the vehicle speed must be greater
than 25 mph (40 km/h) with at least 4th gear
engaged.

Function selected,
displaying of the

"Cruise Control" symbol.

Function deactivated,
OFF (example at

107 km/h).

Function activated
(example at 107 km/h).

Vehicle speed above
(e.g. 118 km/h),

the programmed speed
is displayed flashing.

Operating fault detected,
OFF - the dashes flash.

This cruise control shows the function
selection status on the instrument panel and
displays the programmed speed:

"This is the speed at which the driver wishes
to drive".

This aid to driving in free-flowing traffic
enables the vehicle to maintain the speed
programmed by the driver, unless a steep
gradient makes this impossible.

Steering wheel controls

Selecting the function

- Place the switch in the CRUISE position.

The cruise control is selected but is
not yet active and no speed has been
programmed.

First activation/
programming a speed

- Reach the chosen
speed by pressing the
accelerator.

- Press the SET - or SET +
button.

This programmes/activates the reference
speed and the vehicle will maintain this
speed.

Temporary exceeding of the speed

It is possible to accelerate and drive
momentarily at a speed greater than the
programmed speed. The value programmed
flashes.

When the accelerator pedal is released, the
vehicle will return to the programmed speed.

Reactivation

- Following deactivation of the cruise
control, press this button.

Your vehicle will return to the last
programmed speed.

Alternatively, you can repeat the "first
activation" procedure.

Deactivation (off)

- Press this button or the
brake or clutch pedal.

Steering wheel controls

Switching the function off

- Place the dial in position 0 or switch off

the ignition to switch everything off.

Good practice

When changing the programmed reference
speed by means of a maintained press,
pay attention as the speed can increase or
decrease rapidly.

Do not use the cruise control on slippery
roads or in heavy traffic.

In the event of a steep slope, the cruise
control cannot prevent the vehicle from
exceeding the programmed speed.

In any event, the cruise control cannot
replace the need to observe the speed
limits, nor can it replace the need for
vigilance and responsibility on the part of the
driver.

It is advisable to leave your feet near the
pedals.

To avoid any jamming under the pedals:

- ensure that the mat and its fixings on the
floor are positioned correctly,

- never place one mat on top of another.

Changing the
programmed speed

There are two methods of
memorising a speed higher
than the previous one:

Without using the accelerator:

- press the Set + button.
A brief press increases the speed by 1 mph (km/h).
A maintained press increases the speed in

steps of 5 mph (km/h).

Cancelling the programmed
reference speed

When the vehicle becomes stationary, after
switching off the ignition, the system no
longer memorises a speed.

Using the accelerator:

- exceed the memorised speed until the
speed required is reached,

- press the Set + or Set - button.

To memorise a speed lower than the
previous one:

- press the Set - button.

A brief press decreases the speed by 1 mph
(km/h).

A maintained press decreases the speed in
steps of 5 mph (km/h).

Operating fault

The programmed speed is cleared then
replaced by three dashes. Contact a
CITROËN dealer to have the system
checked.

Steering wheel controls

SPEED LIMITER "LIMIT"

However, pressing the pedal beyond this
point of resistance to the floor permits
exceeding of the programmed speed. To
resume use of the limiter, simply reduce
the pressure on the accelerator pedal
gradually and return to a speed below that
programmed.

Function selected,
displaying of the

"Speed Limiter" symbol.

Function deactivated,
last programmed speed - OFF
(example at 65 mph

(107 km/h)).

Function activated
(example at 65 mph

(107 km/h)).

Vehicle speed above
(example 70 mph

(118 km/h)),
the programmed speed

is displayed flashing.

Operating fault detected,
OFF - the dashes flash.

This speed limiter shows the function
selection status on the instrument panel and
displays the programmed speed:

The operating actions may be carried out

when stationary, with the engine running,
or with the vehicle moving.

"This is the selected speed which the driver
does not wish to exceed".

This selection is made with the engine
running while stationary or with the vehicle
moving. The minimum speed which can be
programmed is 20 mph (30 km/h).

The speed of the vehicle responds to the
pressure of the driver’s foot as far as the
accelerator pedal point of resistance which
indicates that the programmed speed has
been reached.

Steering wheel controls

Selecting the function

- Place the dial in the LIMIT position.
The limiter is selected but is not yet
active. The display indicates the last
programmed speed.

Programming a speed

A speed can be programmed without
activating the limiter but with the engine
running.

To memorise a speed higher than the
previous one:

- press the Set + button.
A brief press increases the speed by 1 mph

(km/h).
A maintained press increases the speed in

steps of 5 mph (km/h).
To memorise a speed lower than the

previous one:

- press the Set - button.
A brief press decreases the speed by 1 mph

(km/h).
A maintained press decreases the speed in

steps of 5 mph (km/h).

Activation/Deactivation (off)

Pressing this button once activates the
limiter, pressing the button again deactivates
it (OFF).

Steering wheel controls

Flashing of the speed

The speed flashes:

- following forcing of the accelerator point
of resistance,

- when the limiter cannot prevent an
increase in the vehicle speed due to the
profile of the road or on a steep descent,

- in the event of sharp acceleration.

Exceeding the programmed speed

Pressing the accelerator pedal in order to
exceed the programmed speed will have
no effect unless you press the pedal firmly
beyond the point of resistance .

Good practice

Operating fault

The programmed speed is cleared then
replaced by three dashes.

Contact a CITROËN dealer to have the
system checked.

The limiter is deactivated temporarily and
the programmed speed flashes.

To return to the limiter function, reduce your
speed to below the programmed speed.

Switching the function off

- Place the dial in position 0 or switch off

the ignition to switch the system off.

The last programmed speed remains in the
memory.

In any event, the speed limiter cannot
replace the need to observe speed limits,
nor can it replace the need for vigilance and
responsibility on the part of the driver.

Always pay attention to the profile of the
road and sharp acceleration and stay in
complete control of your vehicle.

To avoid any jamming under the pedals:

- ensure that the mat and its fixings on the
floor are positioned correctly,

- never place one mat on top of another.

Ventilation

WITH MANUAL ADJUSTMENT

If your vehicle is fitted with these controls,
they are located on the control panel of the
fascia centre console.

Air distribution

The air supply distribution is directed by the
control turned towards:

the side vents and the central
vents,

the side vents, the central vents
and the footwells,

the footwells,

the windscreen and the footwells,

Air flow

The air conditioning does not operate if the
air flow is set to 0.

the windscreen.

Air conditioning A/C

If fitted on your vehicle, the air conditioning
can only operate with the engine running.

Pressing the button triggers the
operation of the air conditioning,
the diode is lit. Pressing the
button again switches the function
off and the diode is switched off.

Temperature adjustment

Control positioned:

- in the red zone, triggers
heating of the interior ambient
air.

- in the blue zone, triggers cool
air,

The air distribution can be
modulated by placing the control
in the intermediate positions,

marked "".

The force of the blown air, from
the vents, varies from 1 to the
strongest 4. Position 0 switches it off.

Remember to adjust this control
in order to reach the ambient air
comfort level.

VENTILATION

Ventilation

Intake of exterior air

Recommended settings

For optimum operation of the manual system, the settings below are recommended:

The diode on the button is off.
This is the preferred operating
position.

Recirculation of interior air

The diode on the button is lit.
Recirculation temporarily prevents
exterior odours and smoke
from entering the passenger
compartment.

Used with the air conditioning switched on
and setting of the force of blown air (from
1 to 4), recirculation enables you to obtain
the required ambient air comfort level more
quickly with both hot or cold settings.

This position should only be temporary.
When your ambient air comfort level has
been reached, return to the intake of exterior
air position to permit renewal of the air in the
passenger compartment and avoid misting.
This operating mode is preferable.

If I require...

Air

distribution

Temperature Air flow

Air

recirculation

Air

conditioning

A/C

Heating

Cooling

Deicing

Demisting

Ventilation

AUTOMATIC AIR CONDITIONING WITH SEPARATE ADJUSTMENTS

Good practice

For maximum cooling or heating of the
passenger compartment, it is possible to
exceed the value 15 by turning until LO is
displayed or the value 27 by turning until HI
is displayed.

For optimum comfort, the difference between
the value displayed for the driver and for the
passenger should not be greater than 3.

If your vehicle is fitted with this control
panel, it is located on the centre console.

On entering the vehicle, the inside
temperature may be much colder (or
warmer) than is comfortable. There is no
advantage in changing the value displayed
in order to quickly reach the level of comfort
required. The system will use its maximum
performance to reach the comfort value set.

Ventilation

Driver or passenger side comfort value

The value indicated on the display
corresponds to a level of comfort and
not a temperature in degrees Celsius or
Fahrenheit.

Automatic operation

Do not cover the sunshine sensor,

located on the windscreen behind the
mirror, it is used for regulation of the air
conditioning.

AUTO comfort programme

This is the normal air conditioning system
operating mode.

Press this button, the AUTO
symbol is displayed.

In accordance with the comfort

value selected, the system
controls the distribution, the flow and the
intake of air to guarantee comfort and a
sufficient circulation of air in the passenger
compartment. No further action on your part
is required. No further action on your part is
required.

When the engine is cold, to prevent an
excessive diffusion of cold air, the ventilation
will reach its optimum level gradually.

For your comfort, the settings are stored
when the ignition is switched off and are
reinstated the next time the vehicle is
started, if the temperature in the passenger
compartment has not changed significantly;
otherwise, operation resumes in automatic
mode.

Turn this control to the left or to
the right to decrease or increase
the value. A setting around the

value 21 provides optimum
comfort.However, depending on your
requirements, a setting between 18 and 24
is usual.

Ventilation

Air flow

Press the small fan button to

reduce the flow or the large fan

button to increase the flow.
On the display, the blades of the fan darken

when the flow is increased.

Manual operation

You can, according to your requirements,
make a different selection from that offered
by the system by changing a setting.
The other functions will still be controlled
automatically. Pressing the AUTO button
restores fully automatic operation.

Intake of exterior air/
Recirculation of interior air

Press this button to recirculate
the interior air. The recirculation

symbol is displayed.
Recirculation prevents exterior odours

and smoke from entering the passenger
compartment. Avoid prolonged operation
in interior air recirculation mode (risk of
condensation, odour and humidity).

Pressing this button again activates the
intake of exterior air.

Air distribution

Pressing this button several times
in succession directs the air flow
towards:

- the windscreen,

- the windscreen and footwells,

- the footwells,

- the side vents, central vents and
footwells,

- the side vents and central vents.

Deactivating the system

Press the air flow small fan
button until the fan symbol
disappears.

This action deactivates all of the
system’s functions, with the exception of the
air recirculation and rear screen demisting (if
fitted on your vehicle). Your comfort setting
is no longer maintained and is switched off.

For your comfort, do not

deactivate the system for long

periods. Pressing the large

fan button or the AUTO button

reactivates the system with

the values set before it was

deactivated.

Switching the air conditioning
On/Off

Press this button, the A/C
symbol is displayed and the air
conditioning is activated.

Pressing this button again switches off the
air cooling.

Ventilation

Press the air conditioning. Direct the control to this air

distribution setting.

Direct the control to this
temperature setting.

Increase the air flow setting.

DE-ICING AND DEMISTING

Manual mode

Returning to exterior air intake
open permits renewal of the air
in the passenger compartment
(diode off).

Ventilation

De-icing the rear screen and/or
mirrors

Pressing this button, with the engine
running, activates the rapid demisting ­de-icing of the rear screen and/or electric
mirrors.

This function switches off:

- when the button is pressed,

- when the engine is switched off,

- automatically to prevent excessive
energy consumption.

Automatic air conditioning: visibility
programme

The comfort programme (AUTO) may not
be sufficient to quickly demist or de-ice the
windows (humidity, several passengers, ice).

In this case, select the visibility programme.
The visibility programme indicator light
comes on.

It activates the air conditioning, the air flow,
the de-icing of the rear screen and provides
optimum distribution of the ventilation to the
windscreen and side windows.

It deactivates the air recirculation.

Ventilation

CORRECT USE OF THE

VENTILATION AND AIR

Vents

"Leave them open"
For optimum distribution and diffusion of hot

or cool air in the passenger compartment,
there are adjustable central and side vents
which can be directed sideways (right or
left) towards the top of the body. For your
comfort while driving, do not close them,
direct the flow of air towards the windows
instead.

The air vents directed towards the floor of
the vehicle complete the equipment.

Passenger compartment filter,
carbon filter

Ensure that this fi lter is in good condition and
have all of the fi lter elements replaced regularly.

Refer to the "Checks" section of
chapter 6.

Air conditioning

In all seasons, if fitted on your vehicle, the
air conditioning should only be used with
the windows closed. However, if the interior
temperature remains high after a prolonged
period parked in the sun, do not hesitate to
ventilate the passenger compartment for a
few minutes.

If your vehicle is fitted with automatic

air conditioning, use the AUTO
mode as much as possible as it permits
optimised control of all of the functions:
air flow, passenger compartment comfort
temperature, air distribution, air intake
mode or air recirculation in the passenger
compartment.

Operate the air conditioning system for 5 to
10 minutes, once or twice a month, to keep
it in perfect working order.

It is normal that the condensation created by
the air conditioning system results in a flow
of water which may form a puddle under the
vehicle when parked.

If the system does not produce cold air, do
not use it and consult a CITROËN dealer.

Ventilation

Good practice

To avoid any risk of poisoning or
asphyxiation, the heater must not be used,
even for short periods, in an enclosed space
such as a garage or workshop which is not
fitted with an exhaust gas extraction system.

Do not park the vehicle on an inflammable
surface (dry grass, dead leaves, paper…),
there is a risk of fire.

The temperature near the heater must not
exceed 120 °C. A temperature higher than
this (for example in the case of painting in
an oven) could damage the components of
the electronic circuits.

The heater is supplied by the vehicle’s fuel
tank. Ensure that the fuel gauge indicator
light is not at reserve.

Coolant circuit heater

This is an additional and autonomous
system which heats the diesel engine hot
coolant loop to make starting easier.

It improves the de-icing and demisting
performance.

Vehicles fitted with an HDi engine may be
fitted with a heater. When the engine is at
idle or the vehicle is stationary, it is normal
to notice a high-pitched whistling noise and
a slight emission of smoke and odour.

Ventilation

Have the heater checked at least

once a year at the beginning of winter.
Maintenance and repairs should only be
carried out by a CITROËN dealer. Use
recommended replacement parts only.

Seats

FRONT SEATS

2 - Seat back angle adjustment

Pull the lever upwards and set the required
angle.

Depending on the version and configuration
of your vehicle, different front seats are
fitted, either:

- a driver ’s seat and a passenger seat,

- an individual driver ’s seat and a two-

seat passenger bench.

Depending on the models, the following
adjustments are available:

1 - Forwards/backwards adjustment

Lift the bar and slide the seat forwards or
backwards.

3 - Driver’s seat height adjustment

Depending on the version and configuration
of your vehicle, you have either:

- a passive adjustment: pull the handle
upwards then take your weight off the
seat to raise, or push on the seat to
lower,

Seats

- an active adjustment: manoeuvre the
handle upwards or downwards until the
desired position is reached.

4 - Driver’s seat lumbar adjustment

Move the lever up or down to obtain the
required position.

Head restraint height adjustment

To raise or lower the restraint, pull it
forwards, then slide it.

The adjustment is correct when the upper
edge of the head restraint is level with the
top of the head.

To remove it, set it in the high position, press
the tabs and pull upwards and forwards at
the same time.

To re-install, engage the head restraint rods
in the holes, making sure they are aligned
with the seat back.

Never drive with the head restraints
removed; they must be in place and
correctly adjusted.

Adjustable armrest

To place the armrest in its rest position:

- raise it until it is in the centreline of the
seat back.

To place the armrest in a position for use:

- fold it down fully,

- raise it slowly to the required position,

- if you pass the required position, raise it
fully then repeat the operations above.

Front heated seat controls

Press the corresponding control,
located on the overhead storage
unit.

The temperature is controlled
automatically.

Pressing a second time stops operation.

Seats

2-SEAT FRONT BENCH

If your vehicle is fitted with this bench seat,
it is fixed and has a 3rd seat belt.

Head restraint

Press the tab to adjust the height of the
head restraint.

To remove the head restraint, press the tabs
and raise the head restraint.

The adjustment is correct when the upper
edge of the head restraint is level with the
top of the head.

Never drive with the head restraints
removed; they must be in place and
adjusted correctly.

Storage basket

This is located under the seat.

Seats

Practical information

CAB LAYOUT

PRACTICAL INFORMATION

Depending on the vehicle’s equipment, the
various fittings below enhance your cab.

Sun visor

To prevent dazzle from ahead, fold the sun
visor down.

A pocket is provided in the driver ’s sun visor
for storing toll cards, tickets, ...

Glove box

This is fitted with a lock, you can lock it
using the key.

It contains three sockets for the connection
of portable electronic equipment (video
equipment, ...) if the vehicle is fitted with a
colour screen.

It also contains can holders and
compartments for storing maps, a packet of
cigarettes, an A4 format document, a pen,
etc.

Storage compartment

Practical information

Ashtray Storage tray and bottle holder (1.5 L) Cup holder

Any liquid transported in the vehicle in
a cup (mug or similar) , which may spill,
presents a risk of damage on contact with
the instrument panel and centre console
controls. "Take care".

12 volt socket

The maximum power of the socket, which is
of the lighter type, is 120 W.

Practical information

Ticket storage

According to the configuration of the vehicle.

Overhead storage unit

This is located above the sun visors and has
two compartments for storing a jumper, a
file, ...

Be aware that storing a hard object in direct
contact with the compartment may result in
noise.

Tip: the central cavity of the overhead
storage unit, located in the extension of the
vehicle’s roof between the rear space and
the cab, permits the transportation of long
objects. Take care to support and wedge
them securely.

The tunnel may be added to by an internal
rack, offered as an accessory.

For raised vehicles, a shelf located above
the overhead storage unit permits the
storing of small objects and materials
(straps, cloths, gloves, helmets, etc...).

Practical information

COURTESY LIGHTS

Front courtesy light

Automatic switching on/off

The front courtesy light comes on when
the key is removed from the ignition, when
the vehicle is unlocked, when one of the
front doors is opened and for location of the
vehicle using the remote control.

It switches off gradually after the ignition is
switched on and when the vehicle is locked.

Permanently on, ignition on.

Cab: comes on when one of the
front doors is opened.

Load space: comes on when one
of the rear doors is opened.

If the doors remain open for a few
minutes, the courtesy lights are
switched off.

Permanently off.

Front individual reading lights Rear courtesy light

These are switched on and off by
means of a manual switch, with the
ignition on.

Areas for toll cards/car park
tickets

The athermic windscreen has two non­reflective zones located either side of the
base of the interior mirror.

They are intended for affixing toll cards
and/or car park tickets.

Practical information

COURTESY LIGHTS

Front courtesy light

Automatic switching on/off

The front courtesy light comes on when
the key is removed from the ignition, when
the vehicle is unlocked, when one of the
front doors is opened and for location of the
vehicle using the remote control.

It switches off gradually after the ignition is
switched on and when the vehicle is locked.

Permanently on, ignition on.

Cab: comes on when one of the
front doors is opened.

Load space: comes on when one
of the rear doors is opened.

If the doors remain open for a few
minutes, the courtesy lights are
switched off.

Permanently off.

Front individual reading lights Rear courtesy light

These are switched on and off by
means of a manual switch, with the
ignition on.

Areas for toll cards/car park
tickets

The athermic windscreen has two non­reflective zones located either side of the
base of the interior mirror.

They are intended for affixing toll cards
and/or car park tickets.

Practical information

LOAD SPACE LAYOUT

Depending on the vehicle’s equipment, the
various fittings below enhance your load
space.

Locations for stowing rail

Locations for securing a stowing rail are
available on each side of the vehicle.

Stowing rings

Use the stowing rings on the rear floor to
secure your loads.

As a safety precaution in case of sharp
braking, you are advised to place heavy
objects as far forwards towards the cab as
possible.

You are advised to immobilise the load by
securing it firmly using the stowing rings on
the floor.

Trims

The lower parts of the sides are fitted with
load protection trims.

Roof box on raised version

This is a storage compartment located in the
load space, above the cab roof.

Practical information

12 volt socket

This operates with the ignition off, therefore
limit its use to avoid discharging the battery.
Maximum power: 120 W.

Ladder type vertical separation or
partition

Behind the driver’s seat, a ladder type
vertical separation or partition protects the
driver against the risk of load movement.

Load retainer

On the floor, behind the front seats, a
horizontal partition protects the driver and
front passengers against the risk of load
movement.

Panel or glazed separation partitions permit
separation of the load space from the cab.

Practical information

Tunnel and internal rack

Located above the cab, access to the tunnel
is via the load space.

The tunnel can be added to by an internal rack which will enable you to transport long, light
items (electrical rods, pipes, etc...).

Rear suspension

REAR SUSPENSION

Two types of suspension are offered.

Metal suspension

This equipment adopts long movement
limiters which make it possible to guarantee
stable behaviour both when loaded and
when empty. No action on your part is
required except to ensure that maintenance
is carried out and that the authorised loads
are complied with.

Rear suspension with pneumatic
compensation

If fitted on your vehicle, this type of
suspension regulates the variations in the
height of the rear platform of your vehicle

irrespective of the weight of the load, within
the limit of the authorised values. On board,
the increasing or lightening of the load on
the vehicle’s platform is detected by two
height sensors. When all of the doors are
closed, the sensors trigger the automatic
compensation and determine the optimum
height of the sill for the vehicle’s driving
conditions.

Two functions

1. Automatic correction

2. Manual correction

1 - Automatic correction of the

height of the rear sill

The pneumatic suspension automatically
regulates the variations in the height of the
rear platform of your vehicle.

A red warning light on your

instrument panel fl ashes if the

height is not at its optimum level and
requires correction, drive slowly until
this warning light is switched off.

The automatic compensation is temporarily
inactive:

- if a door/the tailgate is open,

- when braking or when stopped at a red
light (brake pedal pressed).

Deactivation of the automatic correction

The control which permits deactivation of the
automatic control is located on the right­hand side, at the rear of the vehicle.

With the vehicle stationary:

- press and hold,

- release the control.

Deactivation is confirmed by
the diode which is lit. It remains lit for
approximately 30 seconds.

You must deactivate the automatic
correction manually in the following
situations:

- when working underneath the vehicle,

- when changing a wheel,

- when the vehicle is being transported by

lorry, train, ferry, boat, ...

Return to automatic correction

With the vehicle stationary:

- press and hold,

- release the control.

Return to automatic correction is confirmed
by the diode which is switched off.

According to the configurations, a bleep may
be heard during these operations.

Rear suspension

2 - Manual correction of the height

of the rear sill

If your vehicle is fitted with this adjustment,
the control is located on the right-hand side
at the rear of the vehicle.

This manual adjustment permits "lowering"
or "raising" of the height of the sill of the rear
platform to facilitate operations in a parking
area.

This adjustment of the height of the sill is
restricted by a lower limit and an upper limit.

Carry out these operations with the vehicle
still stationary and:

- with the front and side doors closed,

- with the handbrake applied,

- do not leave your foot on the brake
pedal.

First use

To initialise the function, press the control
for approximately 2 seconds.

Lower: downwards adjustment
of the platform sill

Press the control downwards
continuously.

Release the button to stop the movement,
"3 bleeps" indicate that you have reached
the maximum limit, the movement stops
automatically.

Raise: upwards adjustment of
the platform sill

Press the control upwards
continuously.

Release the button to stop the movement,
"3 bleeps" indicate that you have reached
the maximum limit, the movement stops
automatically.

Return to the optimum sill height

Press the control up or down twice in
succession, the opposite of the position of
the load sill.

Operating faults

If the load sill is not adjusted when the
control is pressed, "3 bleeps" indicate a
malfunction for the following reasons:

- foot on the brake pedal with the key in
the ignition,

- excessive use of the manual correction,

- low battery charge,

- failure of the system.

If the audible signal persists, contact a
CITROËN dealer.

Rear suspension

Deactivation of the manual correction

With the vehicle stationary:

- press and hold,

- release the control.

Deactivation is confirmed by
the diode which is lit. It remains lit for
approximately 30 seconds.

Return to manual correction

With the vehicle stationary:

- press and hold,

- release the control.

Return to manual correction is
confirmed by the diode which is switched off.

According to the configurations, a bleep may
be heard during these operations.

You must deactivate the manual
correction in the following situations:

- when working underneath the vehicle,

- when changing a wheel,

- when the vehicle is being transported by

lorry, train, ferry, boat, ...

Good practice

When stationary and with the ignition key
removed, excessive use of the system
consumes battery charge.

Driving with the height of the rear platform:

- too low, risks damaging the technical
components underneath the vehicle,

- too high, risks unstable driving.

If you start and the warning light flashes,
to switch it off:

- correct the position of the manual

control which is still at the lower or
upper limit,

- or drive slowly at above 6 mph (10 km/h),

until the compensation returns to
automatic mode.

Parking for a long duration

Avoid parking for a long duration on ground
which could present a potential obstacle as
your vehicle could lower.

Following a long period out of use, the
height of the platform may change due to the
automatic compensation on unlocking or on
opening one of your vehicle’s doors.

Warning light

Refer to the "Instruments and controls"
section of chapter 2.

Mirrors and windows

MIRRORS

MIRRORS AND WINDOWS

The mirror is spherical to broaden the field
of side vision. Objects observed are, in
reality, closer than they appear. Therefore,
take this into account in order to judge the
distance correctly.

Electric exterior mirrors

- Move switch A to the right or to the left

to select the corresponding mirror.

- Move knob B in all four directions to

adjust.

- Return switch A to the centre position.

Electric folding/unfolding

If your vehicle is fitted with this function, the
mirrors can be folded or unfolded electrically
from the inside, with the vehicle parked and
the ignition on:

- Place switch A in the centre position.

- Pull switch A rearwards.

Heated mirrors

If your vehicle is fitted with this function,
press the rear screen demisting button.

Manual exterior mirrors

Move the lever in all four directions to
adjust.

When the vehicle is parked, the exterior
mirrors can be folded back manually.

If the mirror casing has come out of its
initial location, with the vehicle stationary,
reposition the mirror casing manually or use
the electric folding switch.

There is no risk of breakage even in the
presence of ice.

Mirrors and windows

Manual interior mirror

The interior mirror has two positions:

- day (normal),

- night (anti-dazzle).
To change from one to the other, push or

pull the lever on the lower edge of the mirror.

Mirrors and windows

ELECTRIC WINDOWS

1. Driver ’s electric window control

2. Passenger electric window control

The electrical functions of the electric
windows are deactivated:

- approximately 45 seconds after the

ignition is switched off,

- after one of the front doors is opened,

if the ignition is off.

Reinitialisation

Following reconnection of the battery,
the safety auto-reverse function must be
reinitialised.

Lower the window fully, then raise it, it will
rise in steps of a few centimetres each time
the control is pressed. Repeat the operation
until the window is fully closed.

Continue to press the control for at least one
second after the window closed position has
been reached.

The safety auto-reverse does not operate
during these operations.

Manual mode

Press or pull the control, without passing the
point of resistance. The window stops when
you release the control.

Automatic mode

Press or pull the control, beyond the point
of resistance. The window opens or closes
fully when the control is released. Pressing
the control again stops the movement of the
window.

Safety auto-reverse

If your vehicle is fitted with the safety auto­reverse function, when the window rises
and meets an obstacle, it stops and partially
lowers.

In the event of unwanted opening of the
window on closing, press the control until
the window is fully open.

Within the next 4 seconds, pull the control
until the window is fully closed.

The safety auto-reverse does not operate
during these operations.

Good practice

If the electric windows meet an obstacle
during operation, you must reverse the
movement of the window. To do this, press
the control concerned.

When the driver operates the passenger
electric window controls, he must ensure
that no one is preventing correct closing of
the windows.

The driver must ensure that the passengers
use the electric windows correctly.

Be aware of children when operating the
windows.

There are two operating modes:

Driving safet

HAZARD WARNING LIGHTS

DRIVING SAFETY

Applying

Pull the handbrake to immobilise your
vehicle.

Check that the handbrake is applied firmly
before leaving the vehicle.

If the handbrake is still on or has
not been released properly, this
is indicated by this warning light
which comes on on the instrument
panel.

When parking on a slope, direct your wheels
towards the pavement and pull the handbrake.

There is no advantage in engaging a gear after
parking the vehicle, particularly if the vehicle is
loaded.

Releasing

Pull the handle and press the button to lower
the handbrake.

Press this button, the direction indicators fl ash.

They can operate with the ignition off.
The hazard warning lights should only be

used in dangerous situations, when stopping
in an emergency or when driving in unusual
conditions.

The audible and/or visual rear parking

REAR PARKING ASSISTANCE

assistance consists of four proximity
sensors, installed in the rear bumper. The
sensors detect any obstacle which enters
the field: person, vehicle, tree, fence, behind
the vehicle during the manoeuvre.

Certain objects detected at the beginning of
the manoeuvre will no longer be detected
at the end of the manoeuvre due to the
blind spots between and below the sensors.
Examples: stake, roadworks cone or
pavement post.

Engage reverse gear

An audible signal confirms the activation of
the system by engaging reverse gear.

The proximity information is indicated by an
audible signal which becomes more rapid as
the vehicle approaches the obstacle. When
the distance between the rear of the vehicle
and the obstacle is less than approximately
thirty centimetres, the audible signal
becomes continuous.

Display on the screen

Parking assistance

Activation/Deactivation

You can activate or deactivate the
system by pressing this button.

The activation or deactivation of
the system is stored when the
vehicle stops.

Operating fault

In the event of an operating fault, when
reverse gear is engaged the diode on
the button comes on, accompanied by
an audible signal and a message on the
display. Consult a CITROËN dealer.

Good practice

In bad weather or in winter, ensure that the
sensors are not covered with mud, ice or
snow.

The system will be deactivated automatically
if a trailer is being towed or if a bicycle
carrier is fitted (vehicle fitted with a
towbar or bicycle carrier recommended by
CITROËN).

The parking assistance cannot, in any
circumstances, take the place of the
vigilance and responsibility of the driver.

Stop the assistance

Change to neutral.

You are advised to deactivate the system if
your vehicle is fitted with a rear ladder or if
you are transporting a load which exceeds
the length of the vehicle.

ABS

ABS

Driving safet

HORN

ANTI-LOCK BRAKING SYSTEM

EMERGENCY BRAKING

ASSISTANCE SYSTEM (EBA)

Press the centre of the steering wheel.

The ABS and EBFD (electronic brake force
distribution) systems improve the stability
and manoeuvrability of your vehicle on
braking, in particular on poor or slippery
surfaces.

The ABS prevents locking of the wheels,
the EBFD provides control of the braking
pressure wheel by wheel.

Good practice

The anti-lock braking system comes into
operation automatically when there is a risk
of wheel lock. It does not reduce the braking
distance.

On very slippery surfaces (ice, oil, etc...)
the ABS may increase the braking distance.
When braking in an emergency, do not
hesitate to press the brake pedal firmly,
without releasing the pressure, even on a
slippery surface, you will then be able to
continue to manoeuvre the vehicle to avoid
an obstacle.

Normal operation of the ABS may be felt by
slight vibration of the brake pedal.

When changing wheels (tyres and rims),
ensure that these are recommended by
CITROËN.

If this warning light comes on,
accompanied by an audible signal
and a message on the display,

it indicates a malfunction of the
ABS which could result in a loss of control of
the vehicle on braking.

If this warning light comes on,
together with the brake and STOP
warning lights, accompanied by

an audible signal and a message
on the display, it indicates a malfunction of
the electronic brake force distribution which
could result in a loss of control of the vehicle
on braking.

Stop immediately.

In both cases, contact a CITROËN dealer.

In an emergency, this system enables the
optimum braking pressure to be reached
more quickly, press the pedal firmly without
releasing it.

It is triggered by the speed at which the brake
pedal is activated. This alters the resistance
of the brake pedal under your foot.

To prolong the operation of the emergency
braking assistance system: keep your foot
on the brake pedal.

ESP

Driving safety

TRACTION CONTROL (ASR) AND

These systems are linked and complement
the ABS.

The ASR system is very useful for
maintaining optimum drive and avoiding
losses of control of the vehicle on
acceleration.

The system optimises drive to prevent the
wheels skidding, by acting on the brakes of
the drive wheels and on the engine. It also
allows the directional stability of the vehicle
to be improved on acceleration.

Use the ESP to hold your course without
attempting to countersteer.

If there is a variation between the trajectory
followed by the vehicle and that required
by the driver, the ESP system automatically

acts on the engine and the brake of one
or more wheels, in order to put the vehicle
back on course.

Operation of the ASR and ESP
systems

The luminous diode flashes when
the ASR or ESP is triggered.

Disarming the ASR/ESP systems

In certain exceptional conditions (starting
the vehicle when stuck in mud or snow, or
on loose ground...), it could prove useful to
disarm the ASR and ESP systems to make
the wheels spin and regain grip.

- Press the button, located on the centre
console.

- The indicator light comes on: the ASR
and ESP systems no longer act.

They engage again:

- automatically above 30 mph (50 km/h),

- manually by pressing the button again.

Operating check

When a malfunction of the
systems occurs, the indicator light
comes on, accompanied by an
audible signal and a message on
the display.

Contact a CITROËN dealer to have the
system checked.

The warning light may also come on if the
tyres are under-inflated. Check the pressure
of each tyre.

Good practice

The ASR/ESP systems offer increased
safety during normal driving, but should not
incite the driver to take risks or to drive at
high speed.

The operation of these systems is ensured
if the recommendations of the manufacturer
regarding the wheels (tyres and rims),
the braking components, the electronic
components and the fitting and repair
procedures within the CITROËN network are
observed.

After an impact, have these systems
checked by a CITROËN dealer.

Seat belts

SEAT BELTS

Height adjustment

Squeeze the control with the return and slide
the assembly on the driver’s seat side and
on the individual passenger seat side.

If your vehicle is fitted with a front bench,
the height of the seat belt associated with
the centre seat cannot be adjusted.

Fastening

Pull the strap, then insert the tongue into the
buckle.

Check that the seat belt is fastened correctly
by pulling the strap.

Unfastening

Press the red button.

Driver’s seat belt not fastened warning
light

When the vehicle is started, this
warning light comes on if the
driver has not fastened his seat
belt.

Passenger seat belt not fastened warning
light

If your vehicle is fitted with a front
passenger seat, when the vehicle
is started, this warning light
comes on if the passenger has not
fastened his seat belt.

Good practice

The driver must ensure that passengers use
the seat belts correctly and that they are all
strapped in securely before moving off.

Wherever you are seated in the vehicle,
always fasten your seat belt, even for short
journeys.

The seat belts are fitted with an inertia reel
which automatically adjusts the length of the
strap to your size.

Do not use accessories (clothes pegs, clips,
safety pins, etc.) which permit a clearance
with the seat belt straps.

Ensure that the seat belt is rolled up
correctly after use.

After folding or moving a seat or a rear
bench seat, ensure that the seat belt is
rolled up correctly and that the buckle is
ready to accommodate the tongue.

Depending on the nature and seriousness
of any impact, the pretensioning device may
be triggered before and independently of
inflation of the air bags. It instantly tightens
the seat belts against the body of the
occupants.

Triggering of the pretensioners is
accompanied by a slight discharge of
harmless smoke and a noise, due to the
activation of the pyrotechnic cartridge
incorporated in the system.

Seat belts

The force limiter reduces the pressure of the

FRONT SEAT BELTS

seat belt against the body of the occupants.
The pretensioning seat belts are active when

the ignition is switched on.
The inertia reels are fitted with a device

which automatically locks the strap in the
event of a collision or emergency braking or
if the vehicle rolls over.

You can unfasten the seat belt by pressing
the red button on the buckle. Guide the seat
belt after unfastening.

The air bag warning light comes on if the
pretensioners are triggered. Consult a
CITROËN dealer.

In order to be effective, a seat belt must:

- restrain one person only,

- must not be twisted, check by pulling in
front of you with an even movement,

- be tightened as close to the body as
possible.

The upper part of the seat belt should be
positioned in the hollow of the shoulder.

The lap part should be placed as low as
possible on the pelvis.

Do not invert the seat belt buckles as they
will not fulfil their role completely. If the
seats are fitted with armrests, the lap part of
the seat belt should always pass under the
armrest.

Check that the seat belt is fastened correctly
by pulling the strap firmly.

Recommendations for children:

- use a suitable child seat if the
passenger is less than 12 years old or
shorter than one metre fifty,

- never allow a child to travel on your lap,
even with the seat belt fastened.

For further information regarding child
seats, refer to the "Children on board"
section of chapter 4.

In accordance with current safety
regulations, your CITROËN dealer
guarantees all work or any checks, from
testing to maintenance, on your seat belt
equipment.

Have the seat belts checked regularly
(even after a minor impact) by a CITROËN
dealer: they must not show any signs of
wear, cutting or fraying and they must not be
transformed or modified.

Clean the seat belt straps with soapy
water or a textile cleaning product,
sold by CITROËN dealers.

With front air bags

The front seats are fitted with pretensioners
and force limiters.

Without front air bag

If your vehicle is fitted with a front bench
without front air bag, the centre passenger’s
seat belt does not have a pretensioner.

With bench seat

If your vehicle is fitted with a front bench
seat, take care to fasten the correct seat belt
using the correct buckle. Do not invert the
driver’s seat belt or buckle with the buckle or
seat belt of the centre seat.

Air bags

AIR BAGS

Air bags only operate when the
ignition is switched on.

This equipment only operates once. If a
second impact occurs (during the same or
a subsequent accident), the air bag will not
operate.

The triggering of an air bag or air bags
is accompanied by a slight discharge of
harmless smoke and a noise, due to the
activation of the pyrotechnic cartridge
incorporated in the system.

This smoke is not harmful, but sensitive
individuals may experience some irritation.

The noise of the detonation may result in a
slight loss of hearing for a short time.

The air bags have been designed to
maximise the safety of the occupants in the
event of a serious collision; they work in
conjunction with the force limiting seat belts.

In the event of a serious collision, the
electronic detectors record and analyse the
front and side impacts suffered in the impact
detection zones:

- in the event of a serious impact, the air
bags inflate instantly and protect the
occupants of the vehicle. Immediately
after the impact, the air bags deflate
rapidly, so that they do not hinder the
visibility of the occupants nor their
possible exit from the vehicle.

- in the event of a minor or rear impact
and in certain roll-over conditions,
the air bags will not be deployed; the
seat belt alone is sufficient to provide
maximum protection in these situations.

The seriousness of the collision depends on
the nature of the obstacle and the speed of
the vehicle at the moment of impact.

It is imperative that the passenger

air bag is disarmed if a child seat is
installed facing rearwards. Refer to the
"Children on board" section of chapter 4.

Air bags

Good practice

Sit in a normal upright position.
Wear a correctly adjusted seat belt.
Do not leave anything between the

occupants and the air bags (a child, pet,
object...). This could hamper the operation
of the air bags or injure the occupants.

After an accident or if the vehicle has been
stolen or broken into, have the air bag
systems checked.

All work on the air bag system is strictly
forbidden unless it is carried out by qualified
personnel of the CITROËN network.

Even if all of the precautions mentioned are
observed, a risk of injury or of minor burns
to the head, chest or arms when an air bag
is triggered cannot be ruled out. In fact, the
bag inflates almost instantly (within a few
milliseconds) then deflates within the same
time discharging the hot gas via openings
provided for this purpose.

Side air bags

Only put recommended covers on the seats.
These will not hinder inflation of the side air
bags. Consult a CITROËN dealer.

Do not fix or glue anything to the seat backs.
This could cause injury to the chest or arms
when the side air bag inflates.

Do not sit with the upper part of the body
any nearer to the door than necessary.

Front air bags

Do not drive holding the steering wheel
by its spokes or resting your hands on the
centre part of the wheel.

Do not allow passengers to place their feet
on the fascia, they risk serious injury if the
air bag is triggered.

Smoke as little as possible as deployment of
the air bags can cause burns or the risk of
injury from a cigarette or pipe.

Never remove or pierce the steering wheel
or hit it violently.

Air bags

Front air bags

The front air bags are incorporated in the
centre of the steering wheel for the driver
and in the fascia for the front passenger.

Activation

They are deployed simultaneously, unless
the passenger’s front air bag has been
disarmed, in the event of a serious front
impact applied to all or part of the front
impact zone A in the longitudinal centreline
of the vehicle on a horizontal plane directed
from the front towards the rear of the
vehicle.

The front air bag inflates between the front
occupant of the vehicle and the fascia to
cushion his forward movement.

Disarming

The passenger’s front air bag alone can be
disarmed:

- With the ignition switched off , insert

the key into the passenger air bag
disarming switch,

- turn it to the "OFF" position,

- then remove the key keeping the slot in
this position.

The air bag warning light on the
instrument panel is lit throughout
the period of disarming.

To ensure the safety of your child, it

is essential to disarm the passenger
air bag when you install a rear-facing child
seat on the front passenger seat. Otherwise,
the child would risk being killed or seriously
injured if the air bag were to inflate.

Reactivation

In the "OFF" position, the passenger air
bag will not be triggered in the event of an
impact.

As soon as the child seat is removed, turn
the air bag slot to the "ON" position to
re-activate the air bag and thus ensure the
safety of your passenger in the event of an
impact.

Front air bag fault

If this warning light comes on,
accompanied by an audible signal
and a message on the display,
contact a CITROËN dealer to
have the system checked.

If the two air bag warning lights are lit

continuously, do not install a rear­facing child seat. Consult a CITROËN
dealer.

Air bags

AIR BAGS

Air bags only operate when the

ignition is switched on.

This equipment only operates once. If a
second impact occurs (during the same or
a subsequent accident), the air bag will not
operate.

The triggering of an air bag or air bags
is accompanied by a slight discharge of
harmless smoke and a noise, due to the
activation of the pyrotechnic cartridge
incorporated in the system.

This smoke is not harmful, but sensitive
individuals may experience some irritation.

The noise of the detonation may result in a
slight loss of hearing for a short time.

The air bags have been designed to
maximise the safety of the occupants in the
event of a serious collision; they work in
conjunction with the force limiting seat belts.

In the event of a serious collision, the
electronic detectors record and analyse the
front and side impacts suffered in the impact
detection zones:

- in the event of a serious impact, the air
bags inflate instantly and protect the
occupants of the vehicle. Immediately
after the impact, the air bags deflate
rapidly, so that they do not hinder the
visibility of the occupants nor their
possible exit from the vehicle.

- in the event of a minor or rear impact
and in certain roll-over conditions,
the air bags will not be deployed; the
seat belt alone is sufficient to provide
maximum protection in these situations.

The seriousness of the collision depends on
the nature of the obstacle and the speed of
the vehicle at the moment of impact.

It is imperative that the passenger

air bag is disarmed if a child seat is
installed facing rearwards. Refer to the
"Children on board" section of chapter 4.

Air bags

Good practice

Sit in a normal upright position.
Wear a correctly adjusted seat belt.
Do not leave anything between the

occupants and the air bags (a child, pet,
object...). This could hamper the operation
of the air bags or injure the occupants.

After an accident or if the vehicle has been
stolen or broken into, have the air bag
systems checked.

All work on the air bag system is strictly
forbidden unless it is carried out by qualified
personnel of the CITROËN network.

Even if all of the precautions mentioned are
observed, a risk of injury or of minor burns
to the head, chest or arms when an air bag
is triggered cannot be ruled out. In fact, the
bag inflates almost instantly (within a few
milliseconds) then deflates within the same
time discharging the hot gas via openings
provided for this purpose.

Side air bags

Only put recommended covers on the seats.
These will not hinder inflation of the side air
bags. Consult a CITROËN dealer.

Do not fix or glue anything to the seat backs.
This could cause injury to the chest or arms
when the side air bag inflates.

Do not sit with the upper part of the body
any nearer to the door than necessary.

Front air bags

Do not drive holding the steering wheel
by its spokes or resting your hands on the
centre part of the wheel.

Do not allow passengers to place their feet
on the fascia, they risk serious injury if the
air bag is triggered.

Smoke as little as possible as deployment of
the air bags can cause burns or the risk of
injury from a cigarette or pipe.

Never remove or pierce the steering wheel
or hit it violently.

Air bags

Operating fault

If this warning light comes
on on the instrument panel,
accompanied by an audible signal
and a message on the display,

contact a CITROËN dealer to
have the system checked. The air bags
may no longer be triggered in the event of a
serious impact.

Side air bags

If fitted on your vehicle, this is a system
which protects the driver and front
passenger in the event of a serious side
impact in order to limit the risk of injury to
the chest.

Each side air bag is incorporated in the front
seat back frame, on the door side.

Activation

It is triggered unilaterally in the event of a
serious side impact applied to all or part
of the side impact zone B , perpendicular
to the longitudinal centreline of the vehicle
on a horizontal plane and directed from the
outside towards the inside of the vehicle.

The side air bag inflates between the
front occupant of the vehicle and the
corresponding door trim pad.

Impact detection zones

A. Front impact zone.
B. Side impact zone.

In the event of a minor impact or bump

on the side of the vehicle or if the
vehicle rolls over, the air bag may not be
triggered.

The air bag is not triggered in the event of a
rear or front collision.

GENERAL POINTS RELATING TO

Although one of CITROËN’s main criteria
when designing your vehicle, the safety of
your children also depends on you.

For maximum safety, please follow these
precautions:

- all children under the age of 12 or less
than one metre fifty tall must travel in
approved child seats suited to their
weight, on seats fitted with a seat belt or
ISOFIX mountings.

- statistically, the safest seats in your
vehicle for the transportation of children
are the rear seats,

- a child weighing less than 9 kg must
travel in the "rearwards-facing" position
both in the front and in the rear,

- the passenger must not travel with a
child on his lap.

INSTALLING A CHILD SEAT USING A THREE POINT SEAT BELT

"Rearwards-facing"

Recommended on the rear seats up to the
age of 2.

When a "rearwards-facing" child seat is
installed on the front passenger seat, it
is essential that the passenger air bag is
disarmed. Otherwise, the child would risk
being seriously injured or killed if the air bag
were to inflate.

"Forwards-facing"

Recommended on the rear seats over the
age of 2.

When a "forwards-facing" child seat is
installed on the front passenger seat, leave
the passenger air bag armed.

The rules for transporting children are
specific to each country. Consult the current
legislation in your country.

Please consult the list of seats approved
in your country. The isofix mountings, the
rear seats, the passenger air bag and the
disarming of this air bag depend on the
version sold.

Child safety

Child safety

UNIVERSAL CHILD SEATS RECOMMENDED BY CITROËN

CITROËN offers a complete range of recommended child seats which are secured using a
three point seat belt :

Group 0: from birth to 10 kg

Group 0+: from birth to 13 kg

L1

"ROMER Baby-Safe Plus"

Installed in the rear-facing position

Groups 1, 2 and 3: from 9 to 36 kg

The child seats function and the
passenger air bag disarming function

are common to the entire CITROËN range.
If the passenger air bag is not disarmed, the

installation of a "rearwards-facing" child seat
in the front is strictly prohibited.

Refer to chapter 4, "Air bags" section.

Use of the restraining cushion is

compulsory for the transportation of young

Groups 2 and 3: from 15 to 36 kg

L3

"RECARO Start’’

L2

"KIDDY Life"

children (from 9 to 18 kg).

L4

"KLIPPAN Optima"

From the age of

6 years (approximately

22 kg), the booster is

used on its own.

Child safety

UNIVERSAL CHILD SEATS RECOMMENDED BY CITROËN

CITROËN offers a complete range of recommended child seats which are secured using a
three point seat belt :

Group 0: from birth to 10 kg

Group 0+: from birth to 13 kg

L1

"ROMER Baby-Safe Plus"

Installed in the rear-facing position

Groups 1, 2 and 3: from 9 to 36 kg

The child seats function and the
passenger air bag disarming function

are common to the entire CITROËN range.
If the passenger air bag is not disarmed, the

installation of a "rearwards-facing" child seat
in the front is strictly prohibited.

Refer to chapter 4, "Air bags" section.

Use of the restraining cushion is

compulsory for the transportation of young

Groups 2 and 3: from 15 to 36 kg

L3

"RECARO Start’’

L2

"KIDDY Life"

children (from 9 to 18 kg).

L4

"KLIPPAN Optima"

From the age of

6 years (approximately

22 kg), the booster is

used on its own.

Child safety

a: Group 0: from birth to 10 kg. Infant car seats and "car cots" cannot be installed on the front passenger seat.
b: consult the legislation in force in your country before installing your child on this seat.
U: seat suitable for the installation of a child seat secured using a seat belt and universally approved, "rear facing" and/or "forward facing".

INSTALLING CHILD SEATS ATTACHED USING THE SEAT BELT

This table indicates the options for installing child seats secured using a seat belt and universally approved in accordance with the weight of
the child and the seat in the vehicle.

Weight of the child and indicative age

Seat

Under 13 kg

(groups 0 (a) and 0+)

Up to approx

1 year

Individual seat U U U U

From 9 to 18 kg

(group 1)

1 to 3 years

approx

From 15 to 25 kg

(group 2)

3 to 6 years

approx

From 22 to 36 kg

(group 3)

6 to 10 years

approx

Row 1 (b)

Bench, side seat U U U U

Bench, centre

seat

L1 L2 L2, L3, L4 L2, L3, L4

Child safety

ADVICE ON CHILD SEATS

The incorrect installation of a child seat in a
vehicle compromises the child’s protection in
the event of an accident.

Remember to fasten the seat belts or the
child seat harnesses keeping the slack in
relation to the child’s body to a minimum ,
even for short journeys.

For optimum installation of the "forward
facing" child seat, ensure that the back of
the child seat is in contact with the back of
the vehicle’s seat and that the head restraint
does not cause any discomfort.

If the head restraint has to be removed,
ensure that it is stored or attached securely
to prevent it from being thrown around the
vehicle in the event of sharp braking.

Children under the age of 10 must not travel
in the "forward facing" position on the front
passenger seat, unless the rear seats are
already occupied by other children, cannot
be used or are absent.

Disarm the passenger air bag when a "rear
facing" child seat is installed on the front
seat.

Otherwise, the child would risk being
seriously injured or killed if the air bag were
to inflate.

As a safety precaution, do not leave:

- one or more children alone and
unsupervised in a vehicle,

- a child or an animal in a vehicle which
is exposed to the sun, with the windows
closed,

- the keys within reach of children inside
the vehicle.

To prevent accidental opening of the doors,
use the "Child Lock".

Take care not to open the rear windows by
more than one third.

To protect young children from the rays of
the sun, fit side blinds to the rear windows.

Installing a booster seat

The chest part of the seat belt must be
positioned on the child’s shoulder without
touching the neck.

Ensure that the lap part of the seat belt
passes correctly over the child’s thighs.

CITROËN recommends the use of a booster
seat which has a back, fitted with a seat belt
guide at shoulder level.

Towing a trailer

ACCESSORIES

TOWING A TRAILER, CARAVAN, BOAT, ETC...

For more information about weights,

refer to the administrative documents
(V5 registration document, ...) or to the
"Weights" section of chapter 8.

Driving advice

A towed vehicle must free wheel: gearbox in
neutral.

Distribution of loads
Distribute the load in the trailer so that the

heaviest objects are as close as possible
to the axle and the nose weight is close to
the maximum authorised without, however,
exceeding it.

Cooling
Towing a trailer on a slope increases the

coolant temperature.
As the fan is electrically controlled, its

cooling capacity is not dependent on the
engine speed.

Towing a trailer

On the contrary, use a high gear to lower the
engine speed and reduce your speed.

In all cases, pay attention to the coolant
temperature.

Good Practice

In certain cases of particularly arduous
use (towing the maximum load up a steep
slope in high temperatures), the engine
automatically limits its power. In this
case, the automatic cutting off of the air
conditioning allows the engine power to be
recovered.

If the coolant temperature warning
light comes on, stop the vehicle
and switch off the engine as soon
as possible.

See the "Levels" section of chapter 6.

Tyres: check the tyre pressures of the

towing vehicle (see the "Identification
features" section of chapter 8) and of
the trailer, observing the recommended
pressure.

Brakes
Towing increases the braking distance. Drive

at a moderate speed, change down early
and brake gradually.

Side wind
Sensitivity to side wind is increased. Drive

smoothly and at a moderate speed.

ABS/ESP
The ABS or ESP systems only control the

vehicle, not the trailer or caravan.

Rear parking assistance
The assistance does not function while the

vehicle is towing.

Towbar

We recommend the use of original
CITROËN towbars and their harnesses,
which have been tested and approved from
the design stage of your vehicle, and that
you entrust the fitting of this equipment to a
CITROËN dealer.

If this equipment is not fitted by a CITROËN
dealer, it is imperative that it is fitted using
the electrical pre-equipment installed at the
rear of the vehicle and in accordance with
the manufacturer ’s instructions.

In accordance with the general instructions
a reminder of which has been given above,
we draw your attention to the risk linked with
fitting a towbar or electrical accessory not
recommended by CITROËN. Fitting such
equipment could result in the failure of your
vehicle’s electronic system. Please contact
a CITROËN dealer for information before
fitting this type of equipment.

ACCESSORIES

OTHER ACCESSORIES

These accessories and parts, having been
tested and approved for reliability and
safety, are all adapted to your vehicle. A
wide range of recommended products and
original parts is offered.

Roof bars for the various heights, roof bars,
ladder.

Separation partitions and grilles, smooth,
non-slip wooden protective floor.

Protective grilles, multimedia.

Equipment

Audio equipment, hands-free kit, speakers,
CD changer, navigation, ...

Regardless of the audio and telematic
equipment offered on the market, the
technical constraints linked with the fitting
of equipment of these families of products
mean that the special features of the
equipment and its compatibility with the
capacities of the your vehicle’s standard
equipment must be taken into account.
Please contact a CITROËN dealer for
information before fitting such equipment.

Range of professional equipment

Parts and Service technical information
publishes an accessories catalogue offering
various equipment and fittings, such as:

Roof bars for short, medium and long
wheelbase (load retainers for all models).

Sill plate, loading roller, sill. Sill plate,
loading roller, sill.

Towbar, towbar harness: trailer towbar which
must be fitted by the CITROËN network.

Another range is also available, structured
around comfort, leisure and maintenance:

Anti-theft alarm, window engraving, first aid
kit, high visibility safety jacket, rear parking
assistance, warning triangle,

Front seat covers compatible with air bags,
bench, rubber mats, carpet mats, snow
chains.

To prevent the mat from becoming caught
under the pedals:

- ensure that the mat and its fixings are

positioned correctly,

- never fit one mat on top of another.

Equipment

ROOF BARS

Installation of radiocommunication
transmitters

Before installing accessory
radiocommunication transmitters with an
external aerial on your vehicle, you are
advised to contact a representative of the
CITROËN marque.

The CITROËN Network will inform you of the
specifications (frequency band, maximum
output power, aerial position, specific
installation conditions) of the transmitters
which can be fitted, in accordance with the
Motor Vehicle Electromagnetic Compatibility
Directive (2004/104/CE).

Front mud flaps, rear mud flaps, ....

Screenwash, interior and exterior cleaning
and maintenance products, replacement
bulbs, ...

The fitting of electrical equipment

or accessories which are not
recommended by CITROËN may result
in the failure of your vehicle’s electronic
system. Please note this specific warning.
You are advised to contact a representative
of the Marque to be shown the range of
recommended equipment and accessories.

Depending on the country in which the
vehicle is sold or operated, it is compulsory
to have a high visibility safety jacket,
warning triangle and replacement bulbs
available in the vehicle.

To install the transverse roof bars, use the
fixings provided for this purpose.

Maximum load: 170 kilogrammes.

Equipment

ROOF BARS

Installation of radiocommunication
transmitters

Before installing accessory
radiocommunication transmitters with an
external aerial on your vehicle, you are
advised to contact a representative of the
CITROËN marque.

The CITROËN Network will inform you of the
specifications (frequency band, maximum
output power, aerial position, specific
installation conditions) of the transmitters
which can be fitted, in accordance with the
Motor Vehicle Electromagnetic Compatibility
Directive (2004/104/CE).

Front mud flaps, rear mud flaps, ....

Screenwash, interior and exterior cleaning
and maintenance products, replacement
bulbs, ...

The fitting of electrical equipment

or accessories which are not
recommended by CITROËN may result
in the failure of your vehicle’s electronic
system. Please note this specific warning.
You are advised to contact a representative
of the Marque to be shown the range of
recommended equipment and accessories.

Depending on the country in which the
vehicle is sold or operated, it is compulsory
to have a high visibility safety jacket,
warning triangle and replacement bulbs
available in the vehicle.

To install the transverse roof bars, use the
fixings provided for this purpose.

Maximum load: 170 kilogrammes.

Opening the bonnet

OPENING THE BONNET

From inside:

- lift the cover located at the left foot of
the passenger’s seat.

- pull the control upwards.

From outside: partially open the bonnet, lift
the catch and raise the bonnet.

Bonnet strut

Secure the strut in one of the two notches,
according to the height required, to hold the
bonnet open.

Before closing the bonnet, replace the strut
in its housing.

To close

Lower the bonnet and release it at the end of its
travel. Check that the bonnet is properly locked.

"Bonnet open" warning

This warning is linked to the alarm option
only.

With the engine running or the
vehicle moving, a warning light
and a diagram on the display,
accompanied by an audible
signal, warn you that the bonnet
is not properly closed.

Under the bonnet

UNDER THE BONNET

DIESEL ENGINES

1 - Windscreen/headlamp wash reservoir.
2 - Fuse box.
3 - Coolant reservoir.
4 - Brake and clutch fluid reservoir.
5 - Air filter.
6 - Dipstick.
7 - Engine oil filler cap.

8 - Power steering reservoir.
9 - Removable towing eye.
10 - Repriming pump

( a : 1.6 litre HDi; b : 2 litre HDi).

11 - Engine oil filling funnel (2 litre HDi).

7.1 - Engine oil filler cap.
If your vehicle is fitted with this oil filler tube,

proceed as follows:
A - Remove the oil filler cap.
B - Remove the filler tube from its location.
C - Place the filler tube in the filler opening

as shown on the illustration.

D - Turn it a 1/4 of a turn to the left to lock it

then top up the oil.

To refit, proceed in the reverse order without
forgetting to retighten the cap A correctly.

Under the bonnet

CHECKS

PETROL ENGINE

4. Brake and clutch fluid reservoir.

5. Air filter.

6. Dipstick.

7. Engine oil filler cap.

8. Power steering reservoir.

9. Removable towing eye.

1. Windscreen/headlamp wash reservoir.

2. Fuse box.

3. Coolant reservoir.

Levels

LEVELS

These regular maintenance operations

will keep your vehicle in good running
order. Consult the instructions at CITROËN
dealerships or in the servicing booklet
enclosed in the handbook pack.

If you have to remove/refit the engine

style cover, handle it with care to avoid

damaging the fixing clips.

Oil level

Check the level regularly and top up
between changes.

Check the level with the vehicle level,
engine cold, using the dipstick.

Dipstick

There are two marks on the
dipstick:

A = maximum
If you fill past this mark,

contact a CITROËN dealer.
B = minimum
Never allow the level to fall

below this mark.

To maintain the reliability of engines and emission control
systems, the use of additives in engine oil is prohibited.

Oil change

It is imperative that this is carried out at the
intervals specified and the viscosity grade of
the oil selected must fulfil the requirements
in accordance with the manufacturer’s
servicing schedule. Consult the instructions
at CITROËN dealerships.

Remove the dipstick before filling.
For the 2 litre HDi engine, use the funnel

supplied when filling via the sump opening.
Check the level after filling (never exceed

the max mark).
Screw the cap back onto the sump before

closing the bonnet.

Viscosity selection

In all cases, the oil selected must meet the
manufacturer ’s requirements.

Changing the brake fluid

The brake fluid must be changed at
the intervals stated, according to the
manufacturer ’s servicing schedule.

Use fluids recommended by the
manufacturer, which fulfil DOT4 standards.

The level must be between the MIN and
MAX marks on the reservoir.

If fluid has to be added frequently, this
indicates a failure which must be checked by
a CITROËN dealer as soon as possible.

Warning lights

Checking by means of the warning

lights on the instrument panel
is described in chapter 2, refer to the
"Instruments and controls" section.

Levels

CHECKS

Cooling system

Only use the fluid recommended by the
manufacturer.

Otherwise, you risk seriously damaging your
engine.

When the engine is warm, the temperature
of the coolant is controlled by the engine
fan. As this fan can operate with the ignition
key removed and because the cooling
system is pressurised, wait for at least one
hour after the engine has stopped before
carrying out any work.

Slacken the cap by 1/4 of a turn to release
the pressure to prevent any risk of scalding.
When the pressure has dropped, remove the
cap and top up the level with coolant.

If fluid has to be added frequently, this
indicates a failure which must be checked by
a CITROËN dealer as soon as possible.

Power steering fluid level

The vehicle must be parked on level ground
with the engine cold. Unscrew the cap
integrated with the gauge and check the
level which must be between the MIN and
MAX marks.

When this occurs with the engine running it
is due to the start of saturation of the particle
emission filter (exceptionally prolonged
urban type driving conditions: low speed,
long traffic jams, ...).

In order to regenerate the filter, you are
advised to drive at a speed higher than
40 mph (60 km/h) for at least five minutes
as soon as possible, when traffic conditions
permit (until the message disappears and
the service warning light is switched off).

During regeneration of the particle emission
filter, relay noise may be heard under the
fascia.

If the message is still displayed and if the
service warning light remains on, contact a
CITROËN dealer.

Topping up

The level must be between the MIN and
MAX marks on the expansion bottle. If
more than 1 litre of fluid is required to top
up the level, have the system checked by a
CITROËN dealer.

Windscreen wash and headlamp
wash level

For best quality cleaning and for your safety,
we would advise that you use products of
the CITROËN Universal range.

Capacity of the screenwash reservoir:
approximately 4.5 litres.

If your vehicle is fitted with headlamp
washers, the capacity of the reservoir is

7.5 litres.
To guarantee optimum cleaning and prevent

freezing, this fluid must not be topped up or
replaced with water.

Diesel additive level (Diesel
with particle emission filter)

The minimum level of this additive

is indicated by lighting of the
service warning light, accompanied by
an audible signal and a message on the
display.

Topping up

It is imperative that this additive is topped up
by a CITROËN dealer without delay.

Checks

CHECKS

Battery

At the start of winter, have your battery
checked by a CITROËN dealer.

Brake pads

Brake pad wear depends on the style of
driving, in particular for vehicles which are
used in town, over short distances. It may
be necessary to check the thickness of the
pads, even between services.

Unless there is a leak on the circuit, a drop
in the brake fluid level indicates that the
brake pads are worn.

Brake disc/drum wear status

For any information relating to checking
the brake disc/drum wear status, contact a
CITROËN dealer.

Handbrake

Where the handbrake travel is too great
or there is a reduction in the performance
of the system, the handbrake should be
adjusted, even between services.

Have the system checked by a CITROËN
dealer.

Oil filter

Change the filter regularly, in accordance
with the servicing schedule.

Carbon filter and passenger
compartment filter

The carbon fi lter permits continuous and
effective fi ltering of dust.

If the passenger compartment fi lter becomes

clogged, this may reduce the performance
of the air conditioning system and generate
unpleasant odours.

We recommend the use of a combined

passenger compartment fi lter. By means of
its second special active fi lter, it contributes
to the purifi cation of the air breathed by the

occupants and the cleanness of the passenger
compartment (reduction of allergic symptoms,
unpleasant odours and greasy deposits).

Refer to the servicing booklet to fi nd out the

replacement interval for these components.
Depending on the environment (dusty

atmosphere...) and the use of the vehicle
(urban driving...), change them twice as often
if necessary.

Refer to the "Under the bonnet" section
of chapter 6.

Particle emission filter (Diesel)

It is imperative that particle
emission filter maintenance is
carried out by a CITROËN dealer.

On acceleration after the vehicle
has been running for a prolonged period
at very low speed or at idle, you may, in
exceptional circumstances, notice the
emission of water vapour at the exhaust.
This water vapour does not have any
adverse effect on vehicle handling or the
environment.

Checks

CHECKS

1.6 litre HDi 2 litre HDi

Bleeding the water contained in the
diesel filter

If this warning light comes on,
bleed the filter. Otherwise bleed
regularly each time the engine is
drained.

To evacuate the water, unscrew the bleed
screw located on the filter.

Operate until all of the water in the
transparent pipe has been drained out then
tighten the bleed screw.

HDi engines use advanced technology.
All work requires a special qualification

which is guaranteed by a CITROËN dealer.

Manual gearbox

Have the level checked in accordance with
the manufacturer ’s servicing schedule.

To check the main levels and certain

components, in accordance with the
manufacturer ’s servicing schedule, refer to
the pages of the Maintenance and Warranty
Guide which correspond to your vehicle’s
engine.

Only use products recommended by

CITROËN or products of equivalent
quality and specification.

In order to optimise the operation of units as
important as the braking system, CITROËN
selects and offers specific products.

In order to avoid damaging the electrical
units, high pressure washing to clean the
engine compartment is strictly prohibited.

FILLING WITH FUEL

Low fuel level

When this warning light fi rst comes

on and when the needle is at the
start of the red zone, the minimum
fuel tank level has been reached.

At this moment, you have approximately
8 litres of fuel remaining.

Fill up without delay to avoid running out of fuel.

Never continue to drive until you run
out of fuel as this may damage the
emission control and injection systems.

Filling with fuel
The fuel tank must be filled with the engine

off .

When filling with fuel, do not open the

left-hand side door, if fitted on your
vehicle, as there is a risk of damage to the
fuel filler flap.

- Open the fuel filler flap.
Insert the key, then turn it a quarter turn.

- Remove the cap and hook it onto the

clip located on the inside of the flap.

Fuel

It is normal to hear an air intake noise when
the cap is opened as there is a vacuum
linked with the sealing of the fuel circuit.

A label affixed to the inside of the flap
reminds you of the type of fuel to be used.

More than 8 litres of fuel must be added in
order to be registered by the fuel gauge.

When filling the fuel tank, do not continue
after the 3 rd cut-off of the nozzle. This could
cause malfunctions.

The capacity of the fuel tank is
approximately 80 litres.

- After filling the fuel tank, lock the cap
and close the flap.

CHECKS

DIESEL

Fuel

FUEL CIRCUIT DISARMED

DIESEL REPRIMING PUMP

Quality of the fuel used for petrol engines

The petrol engines are perfectly compatible
with E10 type petrol biofuels (containing
10 % ethanol), conforming to European
standards EN 228 and EN 15376.

E85 type fuels (containing up to 85 %
ethanol) are reserved exclusively for
vehicles marketed for the use of this type
of fuel (BioFlex vehicles). The quality of
the ethanol must comply with European
standard EN 15376.

For Brazil only, special vehicles are
marketed to run on fuels containing up to
100 % ethanol (type E100).

Quality of the fuel used for Diesel
engines

The Diesel engines are perfectly compatible
with biofuels which conform to current
and future European standards (diesel
fuel which complies with standard EN 590
mixed with a biofuel which complies with
standard EN 14214) available at the pumps
(containing up to 7 % Fatty Acid Methyl
Ester).

The B30 biofuel can be used in certain
Diesel engines; however, this use is subject
to strict application of the special servicing
conditions. Consult a CITROËN dealer.

The use of any other type of (bio)fuel
(vegetable or animal oils, pure or diluted,
domestic fuel...) is strictly prohibited (risk of
damage to the engine and fuel circuit).

In a serious collision, a mechanism
automatically prevents fuel from reaching
the engine.

The flashing of this warning light
is accompanied by a message on
the display.

Check that there is no odour or leakage of
fuel outside the vehicle and re-establish the
fuel supply:

- switch off the ignition (STOP position).

- remove the key.

- put the key back in the ignition.

- switch on the ignition and start.

If you should run out of fuel, it is necessary
to re-prime the circuit:

- fill the fuel tank with at least five litres of
diesel,

- squeeze and release the manual re­priming pump, under the bonnet under
the protective cover, until fuel appears in
the transparent pipe,

- operate the starter until the engine
starts.

DIESEL

Fuel

FUEL CIRCUIT DISARMED

DIESEL REPRIMING PUMP

Quality of the fuel used for petrol engines

The petrol engines are perfectly compatible
with E10 type petrol biofuels (containing
10 % ethanol), conforming to European
standards EN 228 and EN 15376.

E85 type fuels (containing up to 85 %
ethanol) are reserved exclusively for
vehicles marketed for the use of this type
of fuel (BioFlex vehicles). The quality of
the ethanol must comply with European
standard EN 15376.

For Brazil only, special vehicles are
marketed to run on fuels containing up to
100 % ethanol (type E100).

Quality of the fuel used for Diesel
engines

The Diesel engines are perfectly compatible
with biofuels which conform to current
and future European standards (diesel
fuel which complies with standard EN 590
mixed with a biofuel which complies with
standard EN 14214) available at the pumps
(containing up to 7 % Fatty Acid Methyl
Ester).

The B30 biofuel can be used in certain
Diesel engines; however, this use is subject
to strict application of the special servicing
conditions. Consult a CITROËN dealer.

The use of any other type of (bio)fuel
(vegetable or animal oils, pure or diluted,
domestic fuel...) is strictly prohibited (risk of
damage to the engine and fuel circuit).

In a serious collision, a mechanism
automatically prevents fuel from reaching
the engine.

The flashing of this warning light
is accompanied by a message on
the display.

Check that there is no odour or leakage of
fuel outside the vehicle and re-establish the
fuel supply:

- switch off the ignition (STOP position).

- remove the key.

- put the key back in the ignition.

- switch on the ignition and start.

If you should run out of fuel, it is necessary
to re-prime the circuit:

- fill the fuel tank with at least five litres of
diesel,

- squeeze and release the manual re­priming pump, under the bonnet under
the protective cover, until fuel appears in
the transparent pipe,

- operate the starter until the engine
starts.

Battery

BATTERY

This is housed in a compartment located
underneath the floor, in front of the driver’s
seat.

To charge the battery using a battery
charger

- Disconnect the battery,

- Follow the instructions for use given by
the battery charger manufacturer,

- Reconnect starting with the negative (-)
terminal,

- Check that the terminals and connectors
are clean. If they are covered with
sulphate (white or greenish deposit),
disconnect them and clean them

To start the vehicle from another
battery

- Connect the red cable to the positive (+)
terminals of the two batteries,

- Connect one end of the green or black
cable to the negative (-) terminal of the
slave battery,

- Connect the other end of the green or
black cable to an earth point on the
broken down vehicle as far as possible
from the battery,

- Operate the starter, let the engine run,

- Wait for the engine to return to idle, then
disconnect the cables.

It is advisable to disconnect the battery
if the vehicle is not to be used for a
period of more than one month.

Before disconnecting the battery, you must
wait for 2 minutes after switching off the
ignition.

Never disconnect a terminal when the
engine is running.

Never charge a battery without first
disconnecting the terminals.

After every reconnection of the battery,
switch on the ignition and wait 1 minute
before starting to allow the electronic
systems to be initialised. If slight difficulties
are experienced after this, please contact a
CITROËN dealer.

After the engine has stopped, with the key
in the ignition position, certain functions
(windscreen wiper, electric windows, courtesy
lights, audio equipment, etc.) can only be
used for a cumulative duration of thirty
minutes, to prevent discharging of the battery.

Once the thirty minutes are over, the active
functions are put on standby and the battery
warning light flashes accompanied by a
message on the display.

To resume the use of these functions
immediately, start the engine and let it run
for a few minutes.

The time available will then be double the
time for which the engine was left running.
However, this time will always be between
five and thirty minutes.

A flat battery will prevent the engine from
starting.

Repairing a wheel

PUNCTURE REPAIR KIT

The temporary tyre repair kit consists of
a compressor and a bottle (containing a
sealant).

Vehicles supplied with a temporary puncture
repair kit do not have a spare wheel or
tooling (jack, wheelbrace, ...).

Using the kit

1. Tick the deflated wheel on the speed

limitation sticker then affix the sticker to
the vehicle’s steering wheel to remind
you that a wheel is in temporary use.

2. Clip the bottle 1 on the compressor 2 .

3. Connect the bottle 1 to the valve of the

tyre to be repaired.

4. Take care to unwind the compressor

pipe before connecting it to the bottle.

5. Connect the power lead to one of the

vehicle’s 12 V sockets.

6. Switch on the compressor by pressing
button A until the tyre pressure reaches

2.0 bars. If this pressure cannot be
reached, the tyre cannot be repaired.

7. Remove and store the compressor.

8. Drive immediately, for a few miles
(kilometres), at reduced speed, to fill the
puncture.

9. Adjust the pressure using the
compressor in accordance with the
recommendation for the vehicle and
check that the leak is filled correctly (no
further loss of pressure).

10. Drive at reduced speed (50 mph [80 km/h]).
The tyre must be examined and repaired by
a professional as soon as possible.

After use, the bottle can be stored in a
plastic bag, supplied in the kit, to avoid
staining your vehicle with traces of fluid.

Warning: the bottle of gel contains
ethylene-glycol, a product which is
harmful if swallowed and which causes

irritation to the eyes.
Keep it out of reach of children.
After use, do not discard the bottle into the

environment, take it to a CITROËN dealer or
to an specialised waste disposal site.

Replacement bottles of sealant are available
from CITROËN dealers.
