Carmelli NG2554W Assembly Guide

HAMPTON CLUB

SPECTATOR BENCH

ASSEMBLY INSTRUCTIONS

Please Do Not Hesitate to

Contact Our Consumer Hotline

800-759-0977

at

with Any Questions That May

Arise During

Use of This Product!

Assembly or

NG2554W

THANK YOU!

Thank you for purchasing this product.

We work around the clock and around the globe to ensure that our products

maintain the highest possible quality. However, in the rare case of issues

during assembly or use of this product, please contact our Consumer Hotline

at 800-759-0977 for immediate assistance before contacting your retailer.

Please read the warranty information at the back of these assembly

instructions for further details.

IMPORTANT! PLEASE READ THESE ASSEMBLY INSTRUCTIONS IN

ENTIRETY BEFORE ASSEMBLING YOUR PRODUCT.

2

PARTS IDENTIFIER (NOT TO SCALE)

NGP6140 (M or W)* NGP6143 (M or W)*

1

NGP6141 (M or W)*

2 3 4

NGP6142 (M or W)*

x1 x1 x1 x1

Back Frame

NGP6144 (M or W)*

5

6

x2 x1 x1

Upper Crosspiece Lower Front Crosspiece

NGP6148 (M or W)*

9

10

x1

Right Cup Holder

13

NGP6150**

14

x2

Seat Cushion Left Side Frame Right Side Frame

NGP6146 (M or W)*NGP6145 (M or W)*

7

NGP6147 (M or W)*

8

x1

Left Cup Holder

x1

x4

11

15

Middle Rail

NGP6150**NGP6149 (M or W)*

x12 x4

Bolt

NGP6150**NGP6150**

x1 x14

Lower Back Crosspiece

NGP6150**

12

Bolt

NGP6150**

16

17

Spring Washer

NGP6150**

Wood Plug

x12

18

NGP6150**

Flat Washer

Rubber Bushing

x2

Allen Wrench

part number to specify your wood color.

**Items included in Hardware Pack, NGP6150

Wood Dowel

5/15 *Use M (mahogany) or W (walnut) after

For replacement parts please call 800-759-0977.
